1.

METHOD AND DEVICE FOR DETECTING LIQUID POOL AT LOWER END OF NOZZLE


Numéro d'application JP2025005275
Numéro de publication 2025/178006
Statut Délivré - en vigueur
Date de dépôt 2025-02-18
Date de publication 2025-08-28
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a technique with which it is possible to simply and accurately determine a liquid pool generated at the lower end of a nozzle. [Solution] Provided are a method for detecting a liquid pool at the lower end of a nozzle of a liquid material ejection device, and a detection device that executes the method. The method comprises: a first step in which a nozzle 103 is moved to a detection position on a detection surface; a second step in which the nozzle 103 is lowered until the distance between the lower end of the nozzle 103 and the detection surface 107a reaches a predetermined detection distance L and, is raised once the predetermined detection distance L is reached; and a third step in which a liquid pool at the lower end of the nozzle 103 is detected by detecting whether a liquid material is attached to the detection surface 107a by the detection device 104.

Classes IPC  ?

  • B05D 3/00 - Traitement préalable des surfaces sur lesquelles des liquides ou d'autres matériaux fluides doivent être appliquésTraitement ultérieur des revêtements appliqués, p. ex. traitement intermédiaire d'un revêtement déjà appliqué, pour préparer les applications ultérieures de liquides ou d'autres matériaux fluides
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 11/00 - Parties constitutives, détails ou accessoires non prévus dans les groupes
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05C 13/02 - Moyens pour manipuler ou tenir des objets, p. ex. des objets individuels pour des objets particuliers

2.

LIQUID MATERIAL DISCHARGE DEVICE


Numéro d'application JP2025001983
Numéro de publication 2025/159138
Statut Délivré - en vigueur
Date de dépôt 2025-01-23
Date de publication 2025-07-31
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a liquid material discharge device capable of compactly constituting a device size while allowing a liquid contact part to be attached to a body part without positional deviation. [Solution] This liquid material discharge device comprises: a body part 20 having an operation shaft 61 and a drive device 22 for driving the operation shaft 61; a liquid contact part 30 having a liquid chamber 62 and a liquid feed passage 34 for supplying a liquid material to the liquid chamber 62; and a liquid contact part connector 50 for detachably connecting the liquid contact part 30 to the body part 20. The liquid contact part 30 comprises an insertion part 323 in which a first screw groove 324 is formed on at least a part of a side surface. The liquid contact part connector 50 comprises: a rotary member 51 in which a second screw groove 511 to be screwed with the first screw groove 324 is formed; and a rotary member holder 52 for rotatably supporting the rotary member 51. The tip end of the insertion part 323 is inserted into the rotary member 51 to rotate the rotary member 51, whereby the liquid contact part 30 is raised and fixed to the body part 20.

Classes IPC  ?

  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide

3.

Liquid precision discharge control machine


Numéro d'application 29866658
Numéro de brevet D1077877
Statut Délivré - en vigueur
Date de dépôt 2022-09-22
Date de la première publication 2025-06-03
Date d'octroi 2025-06-03
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

4.

Liquid precision discharge control machine


Numéro d'application 29799775
Numéro de brevet D1074771
Statut Délivré - en vigueur
Date de dépôt 2021-07-16
Date de la première publication 2025-05-13
Date d'octroi 2025-05-13
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

5.

Syringe tip cap for liquid dispensing machine


Numéro d'application 29790326
Numéro de brevet D1071207
Statut Délivré - en vigueur
Date de dépôt 2021-11-19
Date de la première publication 2025-04-15
Date d'octroi 2025-04-15
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

6.

Miscellaneous Design


Numéro d'application 019154460
Statut En instance
Date de dépôt 2025-03-11
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Apparatus for dispensing liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for dispensing liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for dispensing liquids, pastes and other fluids for food processing or beverage processing; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Apparatus for dropping liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for dropping liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for dropping liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for dropping liquids, pastes and other fluids for food processing or beverage processing; Apparatus for dropping liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and equipment; Apparatus for dropping liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Apparatus for coating liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for coating liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for coating liquids, pastes and other fluids for precision machinery, for the manufacture of automobile parts, for the manufacture of pharmaceuticals; Apparatus for coating liquids, pastes and other fluids for food processing or beverage processing; Apparatus for coating liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for coating liquids, pastes and other fluids for the manufacture of mobile information terminals, and parts and accessories thereof; Apparatus for injecting liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for injecting liquids, pastes and other fluids for the manufacture of circuit boards on whichelectronic components are mounted; Apparatus for injecting liquids, pastes and other fluids, for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for injecting liquids, pastes and other fluids for food processing or beverage processing; Apparatus for injecting liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for injecting liquids, pastes and other fluids for the manufacture of mobile information terminals, together with parts and accessories thereof; Apparatus for filling liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for filling liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for filling liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for filling liquids, pastes and other fluids for food processing or beverage processing; Apparatus for filling liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for filling liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Semiconductor manufacturing apparatus; Machinery and apparatus for food or beverage processing; Plastics processing machinery and apparatus; Painting machinery and apparatus; Pumps; 3D printers. Apparatus for dispensing liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for dripping liquids, pastes and other fluid for research or laboratory use, as well as parts and accessories thereof; Apparatus for coating liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for injecting liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for filling liquids, pastes and other fluids for research or laboratory use, as well as parts and accessories thereof; Laboratory robots; Measuring machinery and apparatus; Electric telecommunications machinery and apparatus; Electronic calculators.

7.

LIQUID COATING METHOD AND LIQUID COATING DEVICE


Numéro d'application JP2024023446
Numéro de publication 2025/005210
Statut Délivré - en vigueur
Date de dépôt 2024-06-28
Date de publication 2025-01-02
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To solve the problem of degradation of coating quality that occurs when the width of a concave coating region changes between a start point and an end point of a coating path. [Solution] Provided is a liquid coating method for filling a liquid material into a coating region comprising a gap between an inner wall surface of a concave section (201) of a workpiece (111) and outer peripheries of components (202, 203) disposed in the concave section (201). The liquid coating method comprises: a position acquisition step in which positional coordinates of the components (202, 203) are acquired on the basis of a captured image that includes characteristic portions of the components (202, 203); a coating path setting step in which the coating region and a coating path for coating by a discharge device (102) are set on the basis of the positional coordinates; a coating parameter setting step in which the coating path of the discharge device (102) is divided on the basis of the positional coordinates and a coating quantity is set for each section of the divided coating path; and a coating step in which the discharge device (102) is moved along the coating path to coat the coating region with the liquid material. Also provided is a liquid coating method device for executing the liquid coating method.

Classes IPC  ?

  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 11/00 - Parties constitutives, détails ou accessoires non prévus dans les groupes
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05C 13/02 - Moyens pour manipuler ou tenir des objets, p. ex. des objets individuels pour des objets particuliers
  • B05D 7/00 - Procédés, autres que le flocage, spécialement adaptés pour appliquer des liquides ou d'autres matériaux fluides, à des surfaces particulières, ou pour appliquer des liquides ou d'autres matériaux fluides particuliers
  • B05D 7/22 - Procédés, autres que le flocage, spécialement adaptés pour appliquer des liquides ou d'autres matériaux fluides, à des surfaces particulières, ou pour appliquer des liquides ou d'autres matériaux fluides particuliers à des surfaces internes, p. ex. à l'intérieur de tubes

8.

LIQUID MATERIAL COATING METHOD AND COATING DEVICE


Numéro d'application 18715197
Statut En instance
Date de dépôt 2023-01-18
Date de la première publication 2024-12-19
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Problem: To provide a technique by which high-precision application can be performed even under conditions where positional misalignment occurs in regularly arranged workpieces. Problem: To provide a technique by which high-precision application can be performed even under conditions where positional misalignment occurs in regularly arranged workpieces. Solution: Provided is a liquid-material application method of performing application in a predetermined application pattern on a plurality of workpieces 10, 30 arranged with positional misalignment. The liquid-material application method includes: a horizontal-position information measuring step of measuring horizontal-position information of each of the plurality of workpieces 10, 30 by an imaging device 112; a height information measuring step of measuring height information of each of the plurality of workpieces 10, 30 by a ranging device 113; and an application step of performing application in the application pattern on the plurality of workpieces 10, 30 based on the horizontal-position information measured in the horizontal-position information measuring step and the height information measured in the height information measuring step. Also provided is an apparatus for carrying out the method.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

9.

DISCHARGE STATE INSPECTION METHOD, DISCHARGE STATE INSPECTION DEVICE, AND DROPLET INSPECTION SYSTEM


Numéro d'application JP2024019632
Numéro de publication 2024/248016
Statut Délivré - en vigueur
Date de dépôt 2024-05-29
Date de publication 2024-12-05
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Problem: To provide a technology that makes it possible to simultaneously inspect droplet discharge amount and flight state. Solution: A discharge state inspection method, a discharge state inspection device, and a droplet inspection system involve an emission step for emitting droplets from a discharge device (10) toward a weighing scale (30), an event data acquisition step for acquiring event data for the droplets emitted from the discharge device (10) by means of an event sensor (20), a weighing step for acquiring weight value data for the droplets emitted at the emission step from the weighing scale (30), and an inspection step for inspecting the discharge amount of the discharge device (10) on the basis of the event data and the weight value data. At the inspection step, the discharge device (10) is also inspected for flight abnormalities on the basis of the event data.

Classes IPC  ?

  • B05C 11/00 - Parties constitutives, détails ou accessoires non prévus dans les groupes
  • G01G 17/04 - Appareils ou méthodes pour peser un produit ayant une forme ou des propriétés particulières pour peser des fluides, p. ex. des gaz, des produits pâteux

10.

Syringe for liquid dispensing machine


Numéro d'application 29790330
Numéro de brevet D1045499
Statut Délivré - en vigueur
Date de dépôt 2021-11-19
Date de la première publication 2024-10-08
Date d'octroi 2024-10-08
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

11.

LIQUID MATERIAL DISCHARGE DEVICE


Numéro d'application 18735743
Statut En instance
Date de dépôt 2024-06-06
Date de la première publication 2024-10-03
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A discharge device capable of suppressing pressure fluctuation of a compressed gas supplied to a container in which a liquid material is stored. The device includes a storage container in which a liquid material is stored; a discharge port through which the liquid material is discharged; a pressure control valve that adjusts a pressure of a compressed gas supplied from an external compressed gas source to a desired level; a discharge valve that establishes or cuts off communication between the pressure control valve and the storage container; a control device that controls operation of the discharge valve; a first flow line connecting the pressure control valve and the discharge valve; and a second flow line connecting the discharge valve and the storage container. The device further includes a third flow line branched from the first flow line, and a leak mechanism connected to the third flow line.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • A61B 17/00 - Instruments, dispositifs ou procédés chirurgicaux
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 17/005 - Outils à main ou appareils utilisant des outils tenus à la main pour appliquer ou étaler des liquides ou d'autres matériaux fluides sur des surfaces, pour enlever partiellement des liquides ou d'autres matériaux fluides des surfaces pour décharger par pression des matériaux à travers un orifice d'évacuation
  • B05C 17/01 - Outils à main ou appareils utilisant des outils tenus à la main pour appliquer ou étaler des liquides ou d'autres matériaux fluides sur des surfaces, pour enlever partiellement des liquides ou d'autres matériaux fluides des surfaces pour décharger par pression des matériaux à travers un orifice d'évacuation avec un piston actionné mécaniquement, électriquement ou analogue
  • B65D 83/66 - Récipients pour distribuer des contenus liquides ou semi-liquides par pression interne de gaz, c.-à-d. réceptacles aérosols contenant un propulseur avec un contenu et un propulseur séparés d'abord séparés puis mélangés, p. ex. dans une tête de distribution
  • G05D 16/02 - Modifications du système pour réduire les effets d'instabilité, p. ex. dus aux vibrations, au frottement, à la température anormale, à la surcharge ou au balourd

12.

Tube adapter for liquid precision discharge machine


Numéro d'application 29791900
Numéro de brevet D1045074
Statut Délivré - en vigueur
Date de dépôt 2022-02-17
Date de la première publication 2024-10-01
Date d'octroi 2024-10-01
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

13.

Syringe for liquid dispensing machine


Numéro d'application 29790329
Numéro de brevet D1039326
Statut Délivré - en vigueur
Date de dépôt 2021-11-19
Date de la première publication 2024-08-20
Date d'octroi 2024-08-20
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

14.

Atomization nozzle, atomization device, spraying device, and atomization method


Numéro d'application 18683924
Numéro de brevet 12115548
Statut Délivré - en vigueur
Date de dépôt 2023-03-27
Date de la première publication 2024-08-08
Date d'octroi 2024-10-15
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Provided is an atomization nozzle including: a nozzle body member having a gas ejection path and a gas ejection port; a liquid nozzle member having a liquid ejection path and a liquid ejection port, a tip portion of the liquid nozzle member being inserted through the gas ejection path; a pattern adjustment groove that produces a swirling flow in the gas ejection path; and a spraying pattern adjustment member having a communication flow path and a blocking portion, where a spraying pattern can be changed by switching between a first position in which the pattern adjustment groove and a gas supply flow path are in communication via the communication flow path and a second position in which the pattern adjustment groove is covered by the blocking portion. Also provided are an atomization device, a spraying device, and a spraying method.

Classes IPC  ?

  • B05B 7/10 - Pistolets pulvérisateursAppareillages pour l'évacuation produisant une turbulence à la sortie
  • B05B 1/02 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour produire un jet, un pulvérisat ou tout autre écoulement de forme ou de nature particulière, p. ex. sous forme de gouttes individuelles
  • B05B 1/12 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage capables de produire différents types d'écoulements de sortie, p. ex. sous forme d'un jet ou d'un pulvérisat
  • B05B 1/34 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour influencer la forme de l'écoulement du liquide ou d'autre matériau fluide, p. ex. pour produire une turbulence
  • B05B 7/06 - Pistolets pulvérisateursAppareillages pour l'évacuation avec un orifice de sortie en entourant un autre situé approximativement dans le même plan
  • B05B 7/24 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides provenant de plusieurs sources, p. ex. un liquide et de l'air, une poudre et un gaz avec des moyens, p. ex. un récipient, pour alimenter en liquide ou autre matériau fluide un dispositif de décharge

15.

Syringe head cap for liquid dispensing machine


Numéro d'application 29790324
Numéro de brevet D1021081
Statut Délivré - en vigueur
Date de dépôt 2021-11-19
Date de la première publication 2024-04-02
Date d'octroi 2024-04-02
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

16.

Syringe head cap for liquid dispensing machine


Numéro d'application 29790325
Numéro de brevet D1021082
Statut Délivré - en vigueur
Date de dépôt 2021-11-19
Date de la première publication 2024-04-02
Date d'octroi 2024-04-02
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

17.

Syringe tip cap for liquid dispensing machine


Numéro d'application 29790327
Numéro de brevet D1021083
Statut Délivré - en vigueur
Date de dépôt 2021-11-19
Date de la première publication 2024-04-02
Date d'octroi 2024-04-02
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

18.

STORAGE CONTAINER ADAPTER, STORAGE CONTAINER, AND STORAGE DEVICE


Numéro d'application JP2023018859
Numéro de publication 2023/228890
Statut Délivré - en vigueur
Date de dépôt 2023-05-22
Date de publication 2023-11-30
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a storage container adapter, a storage container, and a storage device, with which it is possible to confirm that the storage container and the storage container adapter are in a correct connection position, even when a slight dimensional deviation arises due to non-uniform shrinkage during manufacture. [Solution] A storage container adapter 10 is attached to a storage container 20 equipped with a storage tube 21 and a pair of flanges 23, and is configured by comprising: a base 11; a blocking part 13; a pair of lateral members 12; and a pair of flange-holding claws 14. The pair of flange-holding claws 14 are provided with first engagement elements 15. The pair of flanges are provided with second engagement elements 27 that engages with the first engagement elements 15. The blocking part 13 is inserted in an upper opening of the storage container 20, and when rotated in one direction, the flanges 23 enter a gap between the flange-holding claws 14 and the base 11 and are aligned due to engagement between the first engagement elements 15 and the second engagement elements 27.

Classes IPC  ?

  • B65D 83/00 - Réceptacles ou paquets comportant des moyens particuliers pour distribuer leur contenu

19.

ATOMIZATION NOZZLE, ATOMIZATION DEVICE, SPRAYING DEVICE, AND ATOMIZATION METHOD


Numéro d'application JP2023012096
Numéro de publication 2023/190284
Statut Délivré - en vigueur
Date de dépôt 2023-03-27
Date de publication 2023-10-05
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide an atomization nozzle, an atomization device, a spraying device, and an atomization method which make it possible to change a spraying pattern with a simple configuration. [Solution] Provided is an atomization nozzle comprising: a nozzle body member 122 which has a gas ejection path 142 and a gas ejection port 143; a liquid nozzle member 121 which has a liquid ejection path 123 and a liquid ejection port 124, and a tip end part of which is inserted in the gas ejection path 142; a pattern adjustment groove 152 which produces a rotational flow in the gas ejection path 142; and a spraying pattern adjustment member 150 which has a communication flow path 151 and a blocking part 153. A spraying pattern can be changed by switching between a first position, at which the pattern adjustment groove 152 and a gas supply flow path 130-132 are put in communication via the communication flow path 151, and a second position, at which the pattern adjustment groove 152 is covered with the blocking part 153. Also provided are an atomization device, a spraying device, and an atomization method.

Classes IPC  ?

  • B05B 1/34 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour influencer la forme de l'écoulement du liquide ou d'autre matériau fluide, p. ex. pour produire une turbulence
  • B05B 1/28 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des moyens incorporés pour faire écran au liquide ou autre matériau fluide sortant, p. ex. pour limiter l'aire de pulvérisationBuses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des moyens pour empêcher l'égouttement ou pour recueillir l'excès de liquide ou autre matériau fluide
  • B05B 7/06 - Pistolets pulvérisateursAppareillages pour l'évacuation avec un orifice de sortie en entourant un autre situé approximativement dans le même plan
  • B05B 7/10 - Pistolets pulvérisateursAppareillages pour l'évacuation produisant une turbulence à la sortie
  • B05D 1/02 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces réalisés par pulvérisation

20.

Fluid transfer device, coating device comprising same, and coating method


Numéro d'application 18044983
Numéro de brevet 11815092
Statut Délivré - en vigueur
Date de dépôt 2022-01-19
Date de la première publication 2023-08-24
Date d'octroi 2023-11-14
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Problem: To provide a fluid transfer device that can solve an issue of pulsation that occurs when a liquid material is discharged from a nozzle by eccentrically rotating a male-screw-shaped rotor within a stator having a female-screw-shaped insertion hole, an application device including the fluid transfer device, and an application method. Solution: A fluid transfer device 1 includes: an outer cylinder 10; a stator 11 that has a female-screw-shaped insertion hole 12 as a through-hole and is provided on an inner periphery of the outer cylinder; and a male-screw-shaped rotor 20 that is connected to a rotor driving part and eccentrically rotates in contact with an inner periphery of the stator. In the fluid transfer device 1 capable of transferring a fluid in a transport path formed by the stator 11 and the rotor 20, by rotating the rotor 20 inserted through the insertion hole 12, contact force with the rotor 20 at an inlet portion and an outlet portion of the stator 11 is smaller than contact force with the rotor 20 at a central portion of the stator 11.

Classes IPC  ?

  • F04C 15/00 - Parties constitutives, détails ou accessoires des "machines", des pompes ou installations de pompage non couverts par les groupes
  • F04C 2/107 - Machines ou pompes à piston rotatif du type à engrènement extérieur, c.-à-d. avec un engagement des organes coopérants semblable à celui d'engrenages dentés du type à axe interne, l'organe externe ayant plus de dents ou de parties équivalentes de prise, p. ex. de rouleaux, que l'organe interne avec des dents hélicoïdales
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

21.

LIQUID MATERIAL DISCHARGE DEVICE AND LIQUID MATERIAL APPLICATION DEVICE


Numéro d'application 18012139
Statut En instance
Date de dépôt 2021-06-16
Date de la première publication 2023-08-24
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

To provide a liquid material discharge device capable of adjusting relative alignment of a valve element with respect to a valve seat by mechanical means. A liquid material discharge device includes: a base member; a valve device mounted on the base member and including a valve element and a valve seat; and a valve driving device configured to move the valve element forward to and backward from the valve seat. The liquid material discharge device further includes an adjustment device 140 configured to adjust relative alignment of the valve element with respect to the valve seat, wherein the adjustment device includes a movable member 141 on which the valve driving device is disposed, and an inclination adjuster 146 configured to adjust an inclination of the movable member. A liquid material application device includes the liquid material discharge device.

Classes IPC  ?

  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 13/00 - Moyens pour manipuler ou tenir des objets, p. ex. des objets individuels

22.

LIQUID MATERIAL DISCHARGE DEVICE


Numéro d'application 18011901
Statut En instance
Date de dépôt 2021-06-16
Date de la première publication 2023-08-03
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A liquid material discharge device includes: a valve stem having a valve element provided at a tip portion, and a contact portion; a liquid chamber in which the valve element moves forward and backward; a nozzle communicating with the liquid chamber; a valve seat having a hole via which the liquid chamber and the nozzle communicate with each other; an arm that is in separable contact with the valve stem; and a valve driving device configured to move the valve element forward to and backward from the valve seat by causing the arm to pivot. The liquid material discharge device further includes a coupling device that couples the valve stem with the arm, wherein the coupling device includes a pressing portion that presses the contact portion against the arm.

Classes IPC  ?

  • B05B 1/08 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour produire un jet, un pulvérisat ou tout autre écoulement de forme ou de nature particulière, p. ex. sous forme de gouttes individuelles de nature pulsatoire, p. ex. débitant un liquide en quantités successives séparées

23.

LIQUID MATERIAL COATING METHOD AND COATING DEVICE


Numéro d'application JP2023001245
Numéro de publication 2023/140264
Statut Délivré - en vigueur
Date de dépôt 2023-01-18
Date de publication 2023-07-27
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a technique by which highly precise coating can be performed even under conditions in which a misalignment occurs between workpieces arranged in a regular way. [Solution] Provided is a liquid material coating method in which a plurality of workpieces 10, 30 disposed to include a misalignment are coated in a prescribed coating pattern, the method comprising a horizontal position information measurement step in which horizontal position information on each of the plurality of workpieces 10, 30 is measured by an imaging device 112; a height information measurement step in which height information on each of the plurality of workpieces 10, 30 is measured by a distance measurement device 113; and a coating step in which the plurality of workpieces 10, 30 are coated in the coating pattern on the basis of the horizontal position information measured in the horizontal position information measurement step and the height information measured in the height information measurement step. Also provided is a device for carrying out said method.

Classes IPC  ?

  • B05C 11/00 - Parties constitutives, détails ou accessoires non prévus dans les groupes
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 3/00 - Traitement préalable des surfaces sur lesquelles des liquides ou d'autres matériaux fluides doivent être appliquésTraitement ultérieur des revêtements appliqués, p. ex. traitement intermédiaire d'un revêtement déjà appliqué, pour préparer les applications ultérieures de liquides ou d'autres matériaux fluides
  • B05D 7/00 - Procédés, autres que le flocage, spécialement adaptés pour appliquer des liquides ou d'autres matériaux fluides, à des surfaces particulières, ou pour appliquer des liquides ou d'autres matériaux fluides particuliers
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage

24.

Miscellaneous Design


Numéro d'application 018879442
Statut Enregistrée
Date de dépôt 2023-05-25
Date d'enregistrement 2024-01-26
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Apparatus for dispensing liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for dispensing liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for dispensing liquids, pastes and other fluids for food processing or beverage processing; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Apparatus for coating liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for coating liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for coating liquids, pastes and other fluids for precision machinery, for the manufacture of automobile parts, for the manufacture of pharmaceuticals; Apparatus for coating liquids, pastes and other fluids for food processing or beverage processing; Apparatus for coating liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for coating liquids, pastes and other fluids for the manufacture of mobile information terminals, and parts and accessories thereof; Apparatus for injecting liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for injecting liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for injecting liquids, pastes and other fluids, for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for injecting liquids, pastes and other fluids for food processing or beverage processing; Apparatus for injecting liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for injecting liquids, pastes and other fluids for the manufacture of mobile information terminals, together with parts and accessories thereof; Apparatus for filling liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for filling liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for filling liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for filling liquids, pastes and other fluids for food processing or beverage processing; Apparatus for filling liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for filling liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Pressure regulators (mechanical parts); Electro-pneumatic pressure regulator; Manifold with pressure regulator (mechanical part); Pneumatic circuits with pressure regulators; Mechanical fluid flow control valve; Pressure control valve (mechanical part); Valves (machine elements except those for land vehicles); Pressure reducing valve (machine part); Electric pressure reducing valve; Industrial robots and parts and accessories thereof; Semiconductor manufacturing apparatus; Machinery and apparatus for food or beverage processing; Plastics processing machinery and apparatus; Chemical machinery and apparatus; Painting machinery and apparatus; Pumps; 3D printers; Pressure regulators for vacuums as part of machines. Apparatus for dispensing liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for coating liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for injecting liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for filling liquids, pastes and other fluids for research or laboratory use, as well as parts and accessories thereof; Solenoid valve; Pressure regulator with solenoid valve; Electric direct-acting pressure reducing valve; Manifold with pressure regulator with solenoid valve; Pressure regulator for vacuum with solenoid valve; Pressure regulator with solenoid valve for pressure booster pump; Pressure gauge with pressure switch; Sensor with high-precision digital pressure switch; Flow sensors; Pressure sensors; Pressure sensors for small air pressure; Pressure sensors for general purpose fluids; Laboratory robots; Physical and chemical machinery and apparatus; Measuring machinery and apparatus; Electronic circuits for pressure regulators; Electronic circuits; Electronically applied machinery and apparatus and parts thereof; Electric telecommunications machinery and apparatus; Electronic calculators and peripheral apparatus.

25.

Mu BOOK


Numéro d'application 018879451
Statut Enregistrée
Date de dépôt 2023-05-25
Date d'enregistrement 2023-11-17
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Industrial robots; Robots for the manufacture of semiconductors; Robots for the assembly of electronic components; Robots for the manufacture of pharmaceuticals; Robots for the processing of food or beverages; Robots for the manufacture of cosmetics; Liquid or fluid dispensing devices used in the manufacture of semiconductors, precision machinery, automotive components, pharmaceuticals, food processing, cosmetics, and parts and accessories thereof; Liquid metering and dispensing apparatus for the manufacture of semiconductors, precision machinery, automobile parts, pharmaceuticals, food processing and cosmetics, as well as parts and accessories thereof; Apparatus for pouring, applying, adding and injecting liquid, liquid or fluid foodstuffs used for food production; Other machinery and apparatus for food processing or beverage processing; Plastic processing machinery and apparatus and parts and accessories thereof; Chemical machinery and apparatus; Painting machinery and apparatus; Robots for painting operations; Robots for printing, Metering pumps for resins and other liquids; Other pumps. Laboratory robot; Automated dispensing and aspirating apparatus for laboratory use and research; Non-contact droplet dispensing apparatus for proteins, biological samples, special reagents, aqueous solutions, solvents, alcohol solutions, liquid crystals, inks, oils, magnetic fluids, etc. used as physics and chemistry machinery and apparatus; Software for intercommunication of data between industrial robots and dispensing apparatus controller of liquid, liquid or fluid substances or for programming of drawing patterns on workpieces; Data processing programmes; Data processing software; Electronically applied machinery and apparatus and parts thereof; Measuring machinery and apparatus.

26.

MuBOOK


Numéro d'application 018879469
Statut Enregistrée
Date de dépôt 2023-05-25
Date d'enregistrement 2023-11-17
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Industrial robots; Robots for the manufacture of semiconductors: Robots for the assembly of electronic components; Robots for the manufacture of pharmaceuticals; Robots for the processing of food or beverages: Robots for the manufacture of cosmetics; Liquid or fluid dispensing devices used in the manufacture of semiconductors, precision machinery, automotive components, pharmaceuticals, food processing, cosmetics, and parts and accessories thereof; Liquid metering and dispensing apparatus for the manufacture of semiconductors, precision machinery, automobile parts, pharmaceuticals, food processing and cosmetics, as well as parts and accessories thereof; Apparatus for pouring, applying, adding and injecting liquid, liquid or fluid foodstuffs used for food production; Other machinery and apparatus for food processing or beverage processing; Plastic processing machinery and apparatus and parts and accessories thereof; Chemical machinery and apparatus; Painting machinery and apparatus; Robots for painting operations; Robots for printing; Metering pumps for resins and other liquids; Other pumps. Laboratory robot; Automated dispensing and aspirating apparatus for laboratory use and research; Non-contact droplet dispensing apparatus for proteins, biological samples, special reagents, aqueous solutions, solvents, alcohol solutions, liquid crystals, inks, oils, magnetic fluids, etc. used as physics and chemistry machinery and apparatus; Software for intercommunication of data between industrial robots and dispensing apparatus controller of liquid, liquid or fluid substances or for programming of drawing patterns on workpieces; Data processing programmes; Data processing software; Electronically applied machinery and apparatus and parts thereof; Measuring machinery and apparatus.

27.

LABO DISPENSE MASTER


Numéro d'application 018879489
Statut Enregistrée
Date de dépôt 2023-05-25
Date d'enregistrement 2023-11-16
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Apparatus for dispensing liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for dispensing liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for dispensing liquids, pastes and other fluids for food processing or beverage processing; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Apparatus for dropping liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for dropping liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for dropping liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for dropping liquids, pastes and other fluids for food processing or beverage processing; Apparatus for dropping liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and equipment; Apparatus for dropping liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Apparatus for coating liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for coating liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for coating liquids, pastes and other fluids for precision machinery, for the manufacture of automobile parts, for the manufacture of pharmaceuticals; Apparatus for coating liquids, pastes and other fluids for food processing or beverage processing; Apparatus for coating liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for coating liquids, pastes and other fluids for the manufacture of mobile information terminals, and parts and accessories thereof; Apparatus for injecting liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for injecting liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for injecting liquids, pastes and other fluids, for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for injecting liquids, pastes and other fluids for food processing or beverage processing; Apparatus for injecting liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for injecting liquids, pastes and other fluids for the manufacture of mobile information terminals, together with parts and accessories thereof; Apparatus for filling liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for filling liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for filling liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for filling liquids, pastes and other fluids for food processing or beverage processing; Apparatus for filling liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for filling liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Semiconductor manufacturing apparatus; Machinery and apparatus for food or beverage processing; Plastics processing machinery and apparatus; Chemical machinery and apparatus; Painting machinery and apparatus; Pumps; 3D printers. Apparatus for dispensing liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for dripping liquids, pastes and other fluid for research or laboratory use, as well as parts and accessories thereof; Apparatus for coating liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for injecting liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for filling liquids, pastes and other fluids for research or laboratory use, as well as parts and accessories thereof; Laboratory robots; Physical and chemical machinery and apparatus; Measuring machinery and apparatus; Electronically applied machinery and apparatus and parts thereof; Electric telecommunications machinery and apparatus; Electronic calculators and peripheral apparatus.

28.

Planar liquid film forming method and planar liquid film forming apparatus


Numéro d'application 17910098
Numéro de brevet 12365005
Statut Délivré - en vigueur
Date de dépôt 2021-03-01
Date de la première publication 2023-03-30
Date d'octroi 2025-07-22
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Problem: To provide a technology for forming a planar liquid film having less surface unevenness than ever before using a jet-type discharge device. Solution: Provided is a planar liquid film forming method of forming a planar liquid film on an application target using a jet-type discharge device having a plurality of discharge ports, and an apparatus for implementing the method. In the method, the plurality of discharge ports are arranged on a straight nozzle arrangement line 140, and are arranged with such a distance from one another that globs of a liquid material having landed on the application target can join together to form a linear liquid film. The method includes: a unitary linear liquid film forming step of forming a unitary linear liquid film 404 by discharging the liquid material such that a plurality of liquid globs simultaneously discharged from the plurality of discharge ports have no contact with one another before landing on the application target, and by letting globs of the liquid material having landed join together on the application target; and a specific planar liquid film forming step of forming a specific planar liquid film 405 from a plurality of unitary linear liquid films 404 by successively executing the unitary linear liquid film forming steps while moving the jet-type discharge device and the application target relative to each other in a direction perpendicular to the nozzle arrangement line 140 so that the plurality of unitary linear liquid films 404 join together.

Classes IPC  ?

  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide

29.

Liquid material application apparatus and liquid material application method


Numéro d'application 17840760
Numéro de brevet 12162027
Statut Délivré - en vigueur
Date de dépôt 2022-06-15
Date de la première publication 2022-09-29
Date d'octroi 2024-12-10
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Object: A liquid material application apparatus and a liquid material application method are provided with which a liquid material can be discharged in a predetermined discharge amount per unit time regardless of a relative moving speed in a series of application works. Solution: The liquid material application apparatus includes a discharge head, a robot moving the discharge head relative to a workpiece, a movement control unit controlling relative movement of the discharge head and the workpiece, and a discharge control unit controlling an operation of discharging a liquid material from a discharge head, wherein the discharge control unit executes, in a switchable manner in accordance with an application program, first mode discharge control of changing a discharge amount of the liquid material, which is discharged from the discharge head per unit time, depending on a relative moving speed between the discharge head and the workpiece, and second mode discharge control of operating the discharge head to discharge the liquid material in a predetermined discharge amount per unit time regardless of the relative moving speed. The liquid material application method is implemented using the liquid material application apparatus.

Classes IPC  ?

  • B05B 12/12 - Aménagements de commande de la distributionAménagements de réglage de l’aire de pulvérisation sensibles à l'état du liquide ou d'un autre matériau fluide expulsé, du milieu ambiant ou de la cible sensibles à l'état du milieu ambiant ou de la cible, p. ex. à l'humidité, à la température
  • B05B 13/04 - Moyens pour supporter l'ouvrageDisposition ou assemblage des têtes de pulvérisationAdaptation ou disposition des moyens pour entraîner des pièces les têtes de pulvérisation étant déplacées au cours de l'opération
  • B05D 1/02 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces réalisés par pulvérisation

30.

FLUID TRANSFER DEVICE, COATING DEVICE COMPRISING SAME, AND COATING METHOD


Numéro d'application JP2022001827
Numéro de publication 2022/158492
Statut Délivré - en vigueur
Date de dépôt 2022-01-19
Date de publication 2022-07-28
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a fluid transfer device, a coating device comprising the same, and a coating method which solve the pulsation issues that occur when a male-threaded rotor is eccentrically rotated inside a stator having a female-threaded through-hole, and a fluid material is discharged from a nozzle. [Solution] A fluid transfer device 1 comprising: an outer tube 10; a stator 11 that has a female-threaded through-hole 12 provided in the inner circumferential surface of the outer tube; and a male-threaded rotor 20 connected to a rotor drive unit and eccentrically rotating and abutting the inner circumferential surface of the stator. The fluid transfer device 1 can transfer fluid in a transport path comprising the stator 11 and the rotor 20, by rotating the rotor 20 inserted into the through-hole 12. The fluid transfer device 1 is configured such that the adhesive force between the rotor 20 and inlet and outlet sections of the stator 11 is smaller than the adhesive force between the rotor 20 and a central section of the stator 11.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • F04C 2/107 - Machines ou pompes à piston rotatif du type à engrènement extérieur, c.-à-d. avec un engagement des organes coopérants semblable à celui d'engrenages dentés du type à axe interne, l'organe externe ayant plus de dents ou de parties équivalentes de prise, p. ex. de rouleaux, que l'organe interne avec des dents hélicoïdales
  • F04C 15/00 - Parties constitutives, détails ou accessoires des "machines", des pompes ou installations de pompage non couverts par les groupes

31.

Planar layered material manufacturing method and apparatus


Numéro d'application 17604256
Numéro de brevet 12325045
Statut Délivré - en vigueur
Date de dépôt 2020-04-24
Date de la première publication 2022-06-30
Date d'octroi 2025-06-10
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Continuously manufacturing a planar layered material by repeatedly performing a bank portion forming step of supplying a first liquid material to a first workpiece and forming a bank portion in a frame shape, filled portion forming step of supplying a second liquid material to an inner side of the formed bank portion and forming a filled portion, and a bonding step of bonding the first workpiece with the filled portion formed thereon and a second workpiece to each other, the planar layered material manufacturing method comprises a height measurement step of measuring, by a height measurement device, a height of the filled portion or the bank portion formed on the first workpiece, and a height adjustment step of adjusting a relative height between the filled portion and the bank portion on the basis of the height of the filled portion or the bank portion measured in the height measurement step.

Classes IPC  ?

  • B05D 1/36 - Applications successives de liquides ou d'autres matériaux fluides, p. ex. sans traitement intermédiaire
  • B05D 3/06 - Traitement préalable des surfaces sur lesquelles des liquides ou d'autres matériaux fluides doivent être appliquésTraitement ultérieur des revêtements appliqués, p. ex. traitement intermédiaire d'un revêtement déjà appliqué, pour préparer les applications ultérieures de liquides ou d'autres matériaux fluides par exposition à des rayonnements
  • B29C 65/00 - Assemblage d'éléments préformésAppareils à cet effet
  • G02F 1/13 - Dispositifs ou dispositions pour la commande de l'intensité, de la couleur, de la phase, de la polarisation ou de la direction de la lumière arrivant d'une source lumineuse indépendante, p. ex. commutation, ouverture de porte ou modulationOptique non linéaire pour la commande de l'intensité, de la phase, de la polarisation ou de la couleur basés sur des cristaux liquides, p. ex. cellules d'affichage individuelles à cristaux liquides
  • G02F 1/1341 - Remplissage ou fermeture des cellules

32.

FAD


Numéro d'application 018645909
Statut Enregistrée
Date de dépôt 2022-01-31
Date d'enregistrement 2022-08-09
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Industrial robots; Manufacturing robots; Equipment for manufacturing industrial products for injecting, filling, applying, adding or spraying liquid, fluid or fluid materials; Equipment for manufacturing semiconductors; Equipment for painting operations; Printing equipment; Equipment for processing industrial food and beverages; Equipment for manufacturing electronic components; Equipment for manufacturing LEDs; Equipment for manufacturing automobile parts; Equipment for manufacturing FPD (flat panel display); Medical and pharmaceutical manufacturing equipment; Cosmetics manufacturing equipment; Chemical machinery; Food manufacturing equipment; Mechanical pumps; Plastic processing machinery; Liquid metering dispensing machines for injecting, filling, applying, adding or spraying liquids, fluids or fluid materials used in the manufacture of industrial products. Laboratory robots; Laboratory apparatus for injecting, filling, applying, adding or spraying liquid, liquid or fluid reagents or samples; Automatic liquid dispensing apparatus for experiments and research; Laboratory physical and chemical machines; Dispensing apparatus for proteins, biological samples, special reagents, aqueous solutions, solvents, alcoholic solutions, solvents, liquid crystals, inks, oils, magnetic fluids; Light-emitting diodes.

33.

370PC SKY


Numéro d'application 018646065
Statut Enregistrée
Date de dépôt 2022-01-31
Date d'enregistrement 2022-08-09
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; Robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceuticals; Robots for manufacturing cosmetics; Robots for precision machinery manufacturing; Robots for precision machine parts manufacturing; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; Electromechanical machines for chemical industry; Painting machinery; Liquid metering pumps for resins; Pumps [machines]. Laboratory robots; Laboratory apparatus for injecting, filling, applying, adding or spraying liquid, liquid or fluid reagents or samples; Automatic liquid dispensing apparatus for experiments and research; Laboratory physical and chemical apparatus; Dispensing apparatus for proteins, biological samples, special reagents, aqueous solutions, solvents, alcoholic solutions, solvents, liquid crystals, inks, oils, magnetic fluids.

34.

LIQUID MATERIAL DISCHARGE DEVICE AND LIQUID MATERIAL APPLICATION DEVICE


Numéro d'application JP2021022908
Numéro de publication 2021/261353
Statut Délivré - en vigueur
Date de dépôt 2021-06-16
Date de publication 2021-12-30
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a liquid material discharge device, the relative position of which can be adjusted with respect to a valve seat of a valve by a mechanical means. [Solution] Provided is a liquid material discharge device comprising a base member, a valve device that is provided to the base member and comprises a valve body and a valve seat, and a valve drive device that moves the valve body back and forth with respect to the valve seat. The liquid material discharge device further comprises an adjustment device 140 for adjusting the relative position of the valve body with respect to the valve seat, and the adjustment device comprises a movable member 141 in which the valve drive device is located, and an inclination adjusting part 146 for adjusting the inclination of the movable member. Further provided is a liquid material application device provided with the liquid material discharge device.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage

35.

LIQUID MATERIAL DISCHARGE DEVICE


Numéro d'application JP2021022911
Numéro de publication 2021/261354
Statut Délivré - en vigueur
Date de dépôt 2021-06-16
Date de publication 2021-12-30
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a liquid material discharge device capable of follow the movement of a valve element, without using a strong spring, through the high-speed operation of an actuator. [Solution] A liquid material discharge device comprising: a valve bar 105 having a contact portion and a valve body provided to a tip portion, a liquid chamber in which the valve body moves back and forth, a nozzle that communicates with the liquid chamber, a valve seat 108 having a hole that communicates with the liquid chamber and the nozzle, and arm 121 that separably contacts the valve bar, and a valve drive device that moves the valve body back and forth with respect to the valve seat by rotating the arm 121. The liquid material discharge device is further provided with a coupling device 201 that couples the valve bar 105 to the arm 121, said coupling device 201 being equipped with a pushing portion that pushes the contact portion against the arm 121.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • F16K 31/44 - Moyens mécaniques d'actionnement
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage

36.

Adapter for precision fluid dispenser tube


Numéro d'application 29716996
Numéro de brevet D0936189
Statut Délivré - en vigueur
Date de dépôt 2019-12-13
Date de la première publication 2021-11-16
Date d'octroi 2021-11-16
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

37.

MLC


Numéro d'application 018591281
Statut Enregistrée
Date de dépôt 2021-11-01
Date d'enregistrement 2022-03-12
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ? 07 - Machines et machines-outils

Produits et services

Liquid dispensing, dripping, and coating device used in flat panel display manufacturing and liquid crystal display manufacturing; liquid dispensing device used in semiconductor wafer manufacturing, semiconductor manufacturing, and precision machinery manufacturing; semiconductor manufacturing device and its parts and accessories; precision machinery manufacturing device and its parts and accessories; flat panel display manufacturing device and its parts and accessories; painting machinery.

38.

Miscellaneous Design


Numéro d'application 018565212
Statut Enregistrée
Date de dépôt 2021-09-24
Date d'enregistrement 2022-01-26
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 16 - Papier, carton et produits en ces matières

Produits et services

Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; Robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment. Seals (stationery), Hologram Seals, Stickers.

39.

M WITH MUSASHI


Numéro d'application 018565213
Statut Enregistrée
Date de dépôt 2021-09-24
Date d'enregistrement 2022-01-26
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 16 - Papier, carton et produits en ces matières

Produits et services

Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; Robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment. Seals (stationery), Hologram Seals, Stickers.

40.

M WITH MUSASHI


Numéro d'application 018565214
Statut Enregistrée
Date de dépôt 2021-09-24
Date d'enregistrement 2022-01-26
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 16 - Papier, carton et produits en ces matières

Produits et services

Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; Robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment. Seals (stationery), Hologram Seals, Stickers.

41.

Adapter for precision fluid dispenser tube


Numéro d'application 29716990
Numéro de brevet D0931423
Statut Délivré - en vigueur
Date de dépôt 2019-12-13
Date de la première publication 2021-09-21
Date d'octroi 2021-09-21
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

42.

PLANAR LIQUID FILM FORMING METHOD AND PLANAR LIQUID FILM FORMING APPARATUS


Numéro d'application JP2021007599
Numéro de publication 2021/182146
Statut Délivré - en vigueur
Date de dépôt 2021-03-01
Date de publication 2021-09-16
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a technique to form a planar liquid film with less unevenness on a surface than in the prior art, using a jet-type dispensing device. [Solution] Provided is a planar liquid film forming method for forming a planar liquid film on a coating target using a jet-type dispensing device with a plurality of dispensing outlets, each of which is arranged on a rectilinear, nozzle arrangement line 140 and which are spaced by a distance such that liquid materials can merge to form a linear liquid film when the liquid materials touch the coating target, the method comprising a linear unit liquid film forming step of dispensing the liquid materials such that a plurality of liquid lumps ejected simultaneously from the plurality of dispensing outlets do not contact each other before touching the coating target and the liquid materials merge when the liquid materials touch the coating target, thereby forming a linear unit liquid film 404, and a specific planar liquid film forming step of continuously repeating the linear unit liquid film forming step while moving the jet-type dispensing device and the coating target relative to each other in a direction perpendicular to the nozzle arrangement line 140, so as to let a plurality of linear unit liquid films 404 merge and form a specific planar liquid film 405. Also provided is an apparatus for conducting the method.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage

43.

Liquid material discharge device, and application device and application method therefor


Numéro d'application 16305553
Numéro de brevet 11458501
Statut Délivré - en vigueur
Date de dépôt 2017-05-25
Date de la première publication 2021-07-22
Date d'octroi 2022-10-04
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

u in rising of the valve rod by the actuator to be held within a range of 2 to 300 [ms], thus preventing generation of bubbles caused with the rising of the valve rod.

Classes IPC  ?

  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • F16K 1/42 - Sièges de soupapes
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage

44.

Liquid material discharge device comprising booster circuit


Numéro d'application 16078154
Numéro de brevet 11344903
Statut Délivré - en vigueur
Date de dépôt 2017-02-20
Date de la première publication 2021-06-24
Date d'octroi 2022-05-31
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A liquid material discharge device includes: a plunger including a piston formed at a rear end a piston chamber in which the piston is disposed and to which pressurized gas is supplied; a pressure supply device that supplies, to the piston chamber, air pressurized in excess of the urging force of the elastic body, or that purges pressurized air out of the piston chamber, the liquid material discharge device discharging the liquid material from the discharge port by causing the plunger to move forward and applying an inertial force to the liquid material; a booster circuit that communicates the pressure supply device and an air source with each other, and the booster circuit includes a first and a second booster system including a booster valve and a pressure reducing valve, and a merging section in which the first booster system and the second booster system merge together.

Classes IPC  ?

  • B05B 9/04 - Appareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides, n'impliquant pas de mélange avec des gaz ou des vapeurs caractérisés par les moyens d'alimentation en liquide ou en autre matériau fluide comportant un réservoir sous pression ou compressibleAppareillages de pulvérisation pour débiter des liquides ou d'autres matériaux fluides, n'impliquant pas de mélange avec des gaz ou des vapeurs caractérisés par les moyens d'alimentation en liquide ou en autre matériau fluide comportant une pompe

45.

Character string display device and character string display method


Numéro d'application 17252030
Numéro de brevet 11361733
Statut Délivré - en vigueur
Date de dépôt 2019-07-22
Date de la première publication 2021-06-24
Date d'octroi 2022-06-14
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

There is provided a character string display device including a character string display unit (10) including a plurality of display elements (110) arrayed two-dimensionally, and a display controller (20) configured to cause the character string display unit (10) to display a predetermined character string pattern by controlling display states of the plurality of display elements (110). In the character string display device, the display controller (20) is configured to cause the character string display unit (10) to display the character string pattern such that there is no blank line between consecutive character patterns of the character string pattern and that, when two display elements corresponding to the respective consecutive character patterns are adjacent to each other, a character pattern part corresponding to one of the adjacent display elements (110) is not displayed. The character string display device and a character string display method are simple and low cost, allow effective use of display space, and achieve higher legibility of a character string.

Classes IPC  ?

  • G09G 5/24 - Génération du tracé de caractères individuels
  • G09G 3/00 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques

46.

Cable unit, and liquid material supply device and application device in which said cable unit is used


Numéro d'application 16605852
Numéro de brevet 11456564
Statut Délivré - en vigueur
Date de dépôt 2018-04-24
Date de la première publication 2021-04-29
Date d'octroi 2022-09-27
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Problems: To provide a cable unit that can save space for a work space, and a liquid material supply device and an application device including the cable unit. Solution: A cable unit 30 that detachably and electrically connects a discharge head 10 configured to discharge a liquid material with a relative-moving robot 20 configured to carry out relative movement between the discharge head 10 and a workpiece 25, the cable unit having a dispense controller 33 configured to control a discharge operation of the discharge head 10, and a liquid material supply device and an application device including the cable unit.

Classes IPC  ?

  • H01R 13/66 - Association structurelle avec des composants électriques incorporés
  • B05B 12/16 - Aménagements de commande de la distributionAménagements de réglage de l’aire de pulvérisation pour régler l’aire de pulvérisation
  • B05B 13/04 - Moyens pour supporter l'ouvrageDisposition ou assemblage des têtes de pulvérisationAdaptation ou disposition des moyens pour entraîner des pièces les têtes de pulvérisation étant déplacées au cours de l'opération
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • H01R 13/502 - SoclesBoîtiers composés de différentes pièces
  • H01R 13/621 - Boulon, vis de serrage ou attache à vis

47.

Droplet ejection device and droplet ejection method


Numéro d'application 16954330
Numéro de brevet 11338589
Statut Délivré - en vigueur
Date de dépôt 2018-12-17
Date de la première publication 2021-03-18
Date d'octroi 2022-05-24
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a droplet ejection device and a droplet ejection method with which a liquid material can be continuously delivered to an ejection head when the liquid material is delivered between arbitrary tanks. [Solution] Provided are a droplet ejection device and a droplet ejection method using the droplet ejection device, the droplet ejection device comprising a droplet ejection head; a supply tank that is in communication with a first positive pressure source; a collection tank that is in communication with a first negative pressure source; a replenishment tank that is in communication with the supply tank and the collection tank; an opening/closing valve A that opens and closes a flow passage communicating between the supply tank and the replenishment tank; an opening/closing valve B that opens and closes a flow passage communicating between the collection tank and the replenishment tank; a switching valve that switches communication between the replenishment tank and a second positive pressure source and communication between the replenishment tank and a second negative pressure source; and a control device, wherein the control device has an ejection mode in which a liquid material is ejected from the droplet ejection head, a replenishment mode in which the liquid material is delivered from the replenishment tank to the supply tank while the liquid material is delivered from the supply tank to the collection tank, and a collection mode in which the liquid material is delivered from the collection tank to the replenishment tank while the liquid material is delivered from the supply tank to the collection tank.

Classes IPC  ?

  • B41J 29/38 - Entraînements, moteurs commandes ou dispositifs d'arrêt automatiques pour le mécanisme d'impression tout entier
  • B41J 2/18 - Systèmes de recirculation de l'encre
  • B41J 2/175 - Systèmes d'alimentation en encre

48.

Liquid material ejecting apparatus


Numéro d'application 16979593
Numéro de brevet 11833335
Statut Délivré - en vigueur
Date de dépôt 2019-03-15
Date de la première publication 2021-01-07
Date d'octroi 2023-12-05
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Problem: To provide a liquid-material discharge device that enables easier correction of a changed discharge amount during discharge operation than conventional techniques. Solution: A liquid-material discharge device according to the present invention, which includes a discharging member having a rod-shaped body, a liquid chamber wider than the discharging member, in which a tip portion of the discharging member is disposed, a discharge port communicating with the liquid chamber, a liquid feed path that makes the liquid chamber communicate with a liquid-material reservoir, and a driving device configured to drive the discharging member, includes a discharge amount adjustment member positioned at the liquid feed path, and a member position adjustment mechanism configured to shift a position of the discharge amount adjustment member within the liquid feed path, the discharge amount adjustment member being kept from interrupting communication between the liquid chamber and the liquid-material reservoir.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • A61M 5/315 - PistonsTiges de pistonGuidage, blocage, ou limitation des mouvements de la tigeAccessoires disposés sur la tige pour faciliter le dosage
  • A61M 5/31 - Seringues Parties constitutives

49.

SHOTMASTER


Numéro d'application 018363686
Statut Enregistrée
Date de dépôt 2020-12-24
Date d'enregistrement 2021-07-16
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; Laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment.

50.

MuSkySensing


Numéro d'application 018363689
Statut Enregistrée
Date de dépôt 2020-12-24
Date d'enregistrement 2021-07-16
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; Electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; Laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment.

51.

SHOTmini


Numéro d'application 018363687
Statut Enregistrée
Date de dépôt 2020-12-24
Date d'enregistrement 2021-07-20
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; Laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment.

52.

MuSkyCapture


Numéro d'application 018363688
Statut Enregistrée
Date de dépôt 2020-12-24
Date d'enregistrement 2021-07-16
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; Laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment.

53.

Liquid material application apparatus and liquid material application method


Numéro d'application 16903789
Numéro de brevet 11396028
Statut Délivré - en vigueur
Date de dépôt 2020-06-17
Date de la première publication 2020-11-12
Date d'octroi 2022-07-26
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Object: A liquid material application apparatus and a liquid material application method are provided with which a liquid material can be discharged in a predetermined discharge amount per unit time regardless of a relative moving speed in a series of application works. Solution: The liquid material application apparatus includes a discharge head, a robot moving the discharge head relative to a workpiece, a movement control unit controlling relative movement of the discharge head and the workpiece, and a discharge control unit controlling an operation of discharging a liquid material from a discharge head, wherein the discharge control unit executes, in a switchable manner in accordance with an application program, first mode discharge control of changing a discharge amount of the liquid material, which is discharged from the discharge head per unit time, depending on a relative moving speed between the discharge head and the workpiece, and second mode discharge control of operating the discharge head to discharge the liquid material in a predetermined discharge amount per unit time regardless of the relative moving speed. The liquid material application method is implemented using the liquid material application apparatus.

Classes IPC  ?

  • B05B 12/12 - Aménagements de commande de la distributionAménagements de réglage de l’aire de pulvérisation sensibles à l'état du liquide ou d'un autre matériau fluide expulsé, du milieu ambiant ou de la cible sensibles à l'état du milieu ambiant ou de la cible, p. ex. à l'humidité, à la température
  • B05B 13/04 - Moyens pour supporter l'ouvrageDisposition ou assemblage des têtes de pulvérisationAdaptation ou disposition des moyens pour entraîner des pièces les têtes de pulvérisation étant déplacées au cours de l'opération
  • B05D 1/02 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces réalisés par pulvérisation

54.

LAYERED SURFACE MATERIAL MANUFACTURING METHOD AND DEVICE


Numéro d'application JP2020017748
Numéro de publication 2020/222303
Statut Délivré - en vigueur
Date de dépôt 2020-04-24
Date de publication 2020-11-05
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Problem: To provide a layered surface material manufacturing method and device that can minimize a difference in height between a bank section and a filled section, said difference occurring over time. Solution: A layered surface material manufacturing method and a device therefor, said method being a layered surface material manufacturing method for continuously manufacturing a layered surface material by repeatedly performing a bank section forming step in which a first liquid material is supplied to a first workpiece 71 to form a bank section 72 in a frame shape, a filled section forming step in which a second liquid material is supplied inside the formed bank section to form a filled section 73, and an adhering step in which the first workpiece 71 that has the filled section 73 formed thereon and a second workpiece 72 are adhered to one another, wherein said layered surface material manufacturing method comprises a height measurement step in which a height measurement device is used to measure the height of the filled section 73 or the bank section 72 that is formed on the first workpiece 71, and a height adjustment step in which the relative height of the filled section 73 and the bank section 72 is adjusted on the basis of the height of the filled section 73 or the bank section 72 that was measured in the height measurement step.

Classes IPC  ?

  • B05D 1/36 - Applications successives de liquides ou d'autres matériaux fluides, p. ex. sans traitement intermédiaire
  • B05D 3/00 - Traitement préalable des surfaces sur lesquelles des liquides ou d'autres matériaux fluides doivent être appliquésTraitement ultérieur des revêtements appliqués, p. ex. traitement intermédiaire d'un revêtement déjà appliqué, pour préparer les applications ultérieures de liquides ou d'autres matériaux fluides
  • B05D 7/24 - Procédés, autres que le flocage, spécialement adaptés pour appliquer des liquides ou d'autres matériaux fluides, à des surfaces particulières, ou pour appliquer des liquides ou d'autres matériaux fluides particuliers pour appliquer des liquides ou d'autres matériaux fluides particuliers
  • G02F 1/13 - Dispositifs ou dispositions pour la commande de l'intensité, de la couleur, de la phase, de la polarisation ou de la direction de la lumière arrivant d'une source lumineuse indépendante, p. ex. commutation, ouverture de porte ou modulationOptique non linéaire pour la commande de l'intensité, de la phase, de la polarisation ou de la couleur basés sur des cristaux liquides, p. ex. cellules d'affichage individuelles à cristaux liquides
  • G02F 1/1333 - Dispositions relatives à la structure
  • G02F 1/1335 - Association structurelle de cellules avec des dispositifs optiques, p. ex. des polariseurs ou des réflecteurs

55.

Liquid material discharge device, and application device and application method therefor


Numéro d'application 16304819
Numéro de brevet 11110481
Statut Délivré - en vigueur
Date de dépôt 2017-05-25
Date de la première publication 2020-10-08
Date d'octroi 2021-09-07
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A liquid material discharge device and method capable of remedying the problem of liquid leakage caused by a closing failure that may occur in a negative pressure environment. The liquid material discharge device is used in a negative pressure space, and includes a storage container, a compressed-gas supply source pressurizing the storage container, a nozzle having a discharge flow path, a reciprocating valve rod, an actuator driving the valve rod, a valve seat having a communication hole that is communicated with the discharge flow path, and a discharge control device controlling the actuator to open and close the communication hole by a tip of the valve rod. The device can further include a resin film disposed at a lower end of the valve rod, or a resin film disposed on an upper surface of the valve seat and having a through-hole communicating with the communication hole.

Classes IPC  ?

  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • F16K 1/42 - Sièges de soupapes

56.

Liquid material application device and application method


Numéro d'application 16652824
Numéro de brevet 11001085
Statut Délivré - en vigueur
Date de dépôt 2018-11-01
Date de la première publication 2020-07-23
Date d'octroi 2021-05-11
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

An application device and an application method are disclosed which enable a three-dimensional applying and drawing process to be performed without provision of any rotary mechanism on a discharge head. The application device comprises a discharge head that includes a discharge device having a discharge port opened in a Z direction, a stage that holds a workpiece, a set of XYZ relatively-moving devices that moves the discharge head and the stage relative to each other, an R-axis rotation device that rotates the stage about an R-axis parallel to an XY plane, a P-axis rotation device that rotates the stage about a P-axis parallel to the XY plane, the P-axis extending in a different direction from the R-axis, a control device, and a stand, wherein the P-axis rotation device is disposed under the R-axis rotation device, and the P-axis rotation device rotates the stage and the R-axis rotation device together.

Classes IPC  ?

  • B41J 25/00 - Mécanismes ou mouvements non prévus ailleurs
  • B41J 25/304 - Mécanismes mobiles pour têtes d'impression ou chariots mobiles vers ou à partir de la surface du papier
  • B41J 11/20 - Réglage des appuis pour faire varier la force d'impression, lorsqu'on change le nombre de papiers, pour compenser l'usure ou pour l'alignement
  • B41J 3/407 - Machines à écrire ou mécanismes d'impression ou de marquage sélectif caractérisés par le but dans lequel ils sont construits pour le marquage sur des matériaux particuliers
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 13/02 - Moyens pour manipuler ou tenir des objets, p. ex. des objets individuels pour des objets particuliers

57.

Discharge device for liquid material containing solid particles, discharge method and coating device


Numéro d'application 16729886
Numéro de brevet 11266957
Statut Délivré - en vigueur
Date de dépôt 2019-12-30
Date de la première publication 2020-07-16
Date d'octroi 2022-03-08
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Problem: To supply a device and a method for accurately discharging a fixed amount of a liquid, the liquid containing solid particles, in a state that the solid particles are dispersed in the liquid material. Solution: A discharge device for a liquid material containing solid particles includes a first reservoir, a first air pressure supply pipe, a metering portion having a metering hole, a plunger moving back and forth in the metering hole, a nozzle, a switching valve having a first position and a second position, a plunger driver, and a switching valve driver. The discharge device further includes a second reservoir, a second air pressure supply pipe, a branch portion provided in an upper portion of the metering hole and having a branch flow path, and an opening/closing mechanism that establishes or cuts off communication between the second reservoir and the metering hole. In the discharge device, the liquid material inside the first reservoir can be transferred to the second reservoir, and the liquid material inside the second reservoir can be transferred to the first reservoir. A discharge method is carried out using the discharge device.

Classes IPC  ?

  • B01F 3/08 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de liquides avec des liquides; Emulsion
  • B01J 4/02 - Dispositifs d'alimentationDispositifs de commande d'alimentation ou d'évacuation pour introduire des quantités mesurées de réactifs
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B01F 11/00 - Mélangeurs avec mécanismes à secousses, oscillants ou vibrants
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B01F 15/02 - Mécanismes d'alimentation ou d'évacuation
  • B01F 3/12 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de liquides avec des solides
  • B01F 5/00 - Mélangeurs à écoulement; Mélangeurs pour matériaux tombants, p.ex. particules solides
  • B01F 15/04 - Réalisation de proportions prédéterminées de substances à mélanger

58.

Liquid material application method and device for implementing said method


Numéro d'application 16615658
Numéro de brevet 11958072
Statut Délivré - en vigueur
Date de dépôt 2018-05-28
Date de la première publication 2020-06-11
Date d'octroi 2024-04-16
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A discharge device includes a nozzle (50) having a plurality of discharge ports, a liquid chamber (26) communicating with the plurality of discharge ports via a plurality of discharge flow paths, and a plunger rod (18) that reciprocates in the liquid chamber and is narrower than the liquid chamber. The plurality of discharge ports (62) is arranged un a straight nozzle arrangement line, and arranged with such a distance therebetween that globs of a liquid material having landed on an application target join together to form an application line. A plurality of liquid globs having been discharged from the plurality of discharge ports (62) have no contact with each other before landing on the application target, and letting the globs of the liquid material having landed join together on the application target.

Classes IPC  ?

  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B05D 5/06 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces pour obtenir des effets, finis ou des structures de surface particuliers pour obtenir des effets multicolores ou d'autres effets optiques
  • G02F 1/1335 - Association structurelle de cellules avec des dispositifs optiques, p. ex. des polariseurs ou des réflecteurs

59.

Method and device for filling of liquid material


Numéro d'application 16744219
Numéro de brevet 10913279
Statut Délivré - en vigueur
Date de dépôt 2020-01-16
Date de la première publication 2020-05-14
Date d'octroi 2021-02-09
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A liquid material filling device and method are provided which are intended to prevent air bubbles from remaining along an entire length of a flow passage extending from a liquid material reservoir (51) to a discharge port (53). The liquid material filling device includes a chamber (10) of an airtight structure, a pressure regulator (70) for regulating pressure in the chamber (10), and a control device (100). The liquid material is filled as follows. A negative pressure supply source (71) is communicated with a chamber communication pipe (90) and with a discharge device communication pipe (91) to reduce the pressure in the chamber (10) and pressure in an upper space of the reservoir (51) to a vacuum or a low pressure level close to a vacuum, and a resulted low-pressure state is maintained for a certain time to expel out air bubbles in the liquid material.

Classes IPC  ?

  • B41J 2/175 - Systèmes d'alimentation en encre
  • B41J 2/19 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par la mise en contact sélective d'un liquide ou de particules avec un matériau d'impression à jet d'encre caractérisés par la manipulation de l'encre pour éliminer les bulles d'air

60.

Laser soldering method and device


Numéro d'application 16607922
Numéro de brevet 11453076
Statut Délivré - en vigueur
Date de dépôt 2018-04-24
Date de la première publication 2020-03-26
Date d'octroi 2022-09-27
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A laser soldering technique prevents generation of scorching of a substrate or heat-susceptible components in the surroundings, residues, etc. A method includes adjusting a height of the laser soldering device 1 to a position at which laser light has a preset irradiation diameter D1 larger than a diameter of a solder droplet S, irradiating the solder droplet S with the laser light to heat the solder droplet S to a temperature at which a flux solvent component volatilizes and a solder powder does not melt; adjusting the height of the laser soldering device to a position at which the laser light has a preset irradiation diameter D2 smaller than the diameter of the solder droplet S, and irradiating the solder droplet S with the laser light to heat the solder droplet S to a temperature at which the solder powder melts, and performing soldering.

Classes IPC  ?

  • H05K 3/34 - Connexions soudées
  • B23K 1/005 - Brasage par énergie rayonnante
  • G06F 30/367 - Vérification de la conception, p. ex. par simulation, programme de simulation avec emphase de circuit intégré [SPICE], méthodes directes ou de relaxation

61.

Liquid discharge device, application device with said discharge device, and application method


Numéro d'application 16468947
Numéro de brevet 11400481
Statut Délivré - en vigueur
Date de dépôt 2017-12-19
Date de la première publication 2020-03-12
Date d'octroi 2022-08-02
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A liquid discharge device to discharge a liquid material stirred near a metering chamber, an application device and an application method using the application device. A liquid discharge device includes a storage unit including a storage container storing a liquid material, and a stirrer drive mechanism; a discharge unit including a metering chamber to be filled with the liquid material, a plunger sliding in close contact with an inner peripheral surface of the metering chamber, a nozzle in communication with the metering chamber, and a switching valve between a first position at which the storage container and the metering chamber are communicated with each other, and a second position at which the metering chamber and the nozzle are communicated; and a connection flow path through which the storage container and the metering chamber are communicated, The stirrer drive mechanism is separable from the storage unit.

Classes IPC  ?

  • B05C 9/10 - Appareillages ou installations pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par des moyens non prévus dans l'un des groupes , ou dans lesquels le moyen pour déposer le liquide ou autre matériau fluide n'est pas important pour appliquer un liquide ou autre matériau fluide et exécuter une opération auxiliaire l'opération auxiliaire étant exécutée avant l'application
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

62.

Liquid material discharge device with temperature control device, application device for same, and application method


Numéro d'application 16339556
Numéro de brevet 11426750
Statut Délivré - en vigueur
Date de dépôt 2017-10-05
Date de la première publication 2020-02-06
Date d'octroi 2022-08-30
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Application of liquid material is carried out without causing variations in discharge amount even on a stage under heating while temperature of a liquid material is adjusted by a temperature control device. A liquid material discharge device includes a discharge port, a liquid chamber in communication with the discharge port, and a temperature control device adjusting a temperature of the liquid chamber, the liquid material discharge device discharging the liquid material from the discharge port while a workpiece and the discharge port are moved relative to each other. The liquid material discharge device also includes a coolant flow path through which a coolant for heat exchange with the temperature control device flows, and a discharge control device controlling a discharge operation. An application device including the liquid material discharge device and an application method using the application device are also provided.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05B 12/10 - Aménagements de commande de la distributionAménagements de réglage de l’aire de pulvérisation sensibles à l'état du liquide ou d'un autre matériau fluide expulsé, du milieu ambiant ou de la cible sensibles à la température ou à la viscosité du liquide ou d'un autre matériau fluide expulsé
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05B 1/14 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des orifices de sortie multiplesBuses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des filtres placés dans ou à l'extérieur de l'orifice de sortie
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B05D 3/00 - Traitement préalable des surfaces sur lesquelles des liquides ou d'autres matériaux fluides doivent être appliquésTraitement ultérieur des revêtements appliqués, p. ex. traitement intermédiaire d'un revêtement déjà appliqué, pour préparer les applications ultérieures de liquides ou d'autres matériaux fluides

63.

Lid for liquid material storage container, and liquid material storage container


Numéro d'application 16497992
Numéro de brevet 11117713
Statut Délivré - en vigueur
Date de dépôt 2018-03-23
Date de la première publication 2020-02-06
Date d'octroi 2021-09-14
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A lid for a liquid material storage container solves problems of uplift and breakage of the lid, and ensures high efficiency in attachment and detachment operations. The lid includes an upper plate portion covering a flange and a large-diameter opening of a storage cylinder; a plug portion extending downward from a central region of the upper plate portion and plugging the large-diameter opening of the storage cylinder; a pair of first lateral portions coming into contact with lateral surfaces of a pair of short sides of the flange when the lid is closed; a pair of claw portions extending from the pair of first lateral portions toward the plug portion and coming into contact with lower surfaces of the pair of short sides of the flange when the lid is closed; and a push-up operating portion formed in at least one of the pair of first lateral portions.

Classes IPC  ?

  • A61M 5/315 - PistonsTiges de pistonGuidage, blocage, ou limitation des mouvements de la tigeAccessoires disposés sur la tige pour faciliter le dosage
  • B65D 41/28 - Capuchons combinés avec des bouchons
  • B65D 51/16 - Fermetures non prévues ailleurs avec moyens pour laisser partir l'air ou le gaz

64.

CHARACTER STRING DISPLAY DEVICE AND CHARACTER STRING DISPLAY METHOD


Numéro d'application JP2019028623
Numéro de publication 2020/022253
Statut Délivré - en vigueur
Date de dépôt 2019-07-22
Date de publication 2020-01-30
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

This character string display device is provided with: a character string display unit (10) provided with a plurality of display elements (110) arrayed in a two-dimensional shape; and a display control unit (20) which displays, on the character string display unit (10), a prescribed character string pattern by controlling a display state of the plurality of display elements (110), wherein the display control unit (20) does not provide a blank space column between consecutive character patterns in the character string pattern, and, when two display elements respectively corresponding to the consecutive character patterns are adjacent to each other, displays, on the character string display unit (10), a characters string pattern in which a character pattern part corresponding to one of the adjacent display elements (110) is not caused to be displayed. Accordingly, the present invention easily and inexpensively provides a character string display device and a character string display method in which a display space can be validly utilized and character readability is high.

Classes IPC  ?

  • G09G 5/32 - Dispositions ou circuits de commande de l'affichage communs à l'affichage utilisant des tubes à rayons cathodiques et à l'affichage utilisant d'autres moyens de visualisation caractérisés par l'affichage de caractères ou de signes individuels en utilisant des signaux de commande d'affichage dérivés de signaux codés représentant les caractères ou les signes avec une mémoire de codes de caractères avec des moyens pour commander la position de l'affichage
  • G09G 5/00 - Dispositions ou circuits de commande de l'affichage communs à l'affichage utilisant des tubes à rayons cathodiques et à l'affichage utilisant d'autres moyens de visualisation

65.

Adapter for precision fluid dispenser tube


Numéro d'application 35504684
Numéro de brevet D0873388
Statut Délivré - en vigueur
Date de dépôt 2017-09-27
Date de la première publication 2020-01-21
Date d'octroi 2020-01-21
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

66.

SUPER HI SET


Numéro d'application 018181714
Statut Enregistrée
Date de dépôt 2020-01-17
Date d'enregistrement 2020-05-22
Propriétaire MUSASHI ENGINEERING Inc. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; Chemical machinery and equipment; painting machinery; Liquid metering pumps for resins; pumps [machines]. Dosage dispensers; Non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, solvents, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment.

67.

Seal structure, and device with said seal structure


Numéro d'application 16487296
Numéro de brevet 11384862
Statut Délivré - en vigueur
Date de dépôt 2018-02-22
Date de la première publication 2019-12-12
Date d'octroi 2022-07-12
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

2) of the needle fitting insertion hole.

Classes IPC  ?

  • F16K 41/04 - Joints d'étanchéité pour tiges avec un presse-étoupe avec une bague au moins, en caoutchouc ou d'un matériau analogue, entre la tige et son logement
  • B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide

68.

Liquid material application apparatus and liquid material application method


Numéro d'application 16066834
Numéro de brevet 10786827
Statut Délivré - en vigueur
Date de dépôt 2017-05-25
Date de la première publication 2019-11-28
Date d'octroi 2020-09-29
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A liquid material is discharged in a constant amount per unit time regardless of a relative moving speed. The liquid material application apparatus includes a discharge head, a robot moving the discharge head relative to a workpiece, a movement control unit controlling relative movement of the discharge head and the workpiece, and a discharge control unit controlling an operation of discharging a liquid material from a discharge head, wherein the discharge control unit executes, in a switchable manner in accordance with an application program, first mode discharge control of changing a discharge amount of the liquid material, which is discharged from the discharge head per unit time, depending on a relative moving speed between the discharge head and the workpiece, and second mode discharge control of operating the discharge head to discharge the liquid material in a predetermined discharge amount per unit time regardless of the relative moving speed.

Classes IPC  ?

  • B05B 12/12 - Aménagements de commande de la distributionAménagements de réglage de l’aire de pulvérisation sensibles à l'état du liquide ou d'un autre matériau fluide expulsé, du milieu ambiant ou de la cible sensibles à l'état du milieu ambiant ou de la cible, p. ex. à l'humidité, à la température
  • B05B 13/04 - Moyens pour supporter l'ouvrageDisposition ou assemblage des têtes de pulvérisationAdaptation ou disposition des moyens pour entraîner des pièces les têtes de pulvérisation étant déplacées au cours de l'opération
  • B05D 1/02 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces réalisés par pulvérisation

69.

Liquid material-discharging device


Numéro d'application 16331353
Numéro de brevet 11059069
Statut Délivré - en vigueur
Date de dépôt 2017-09-08
Date de la première publication 2019-11-28
Date d'octroi 2021-07-13
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A liquid material discharge device includes a discharge member made of a rod-shaped body, a liquid chamber which is wider than the discharge member and in which a tip portion of the discharge member is disposed, a discharge port in communication with the liquid chamber, a liquid feed path establishing communication between the liquid chamber and a liquid material storage container, a drive device driving the discharge member, and a main body. The liquid material discharge device further includes an elongate insert member that is removably inserted into the liquid feed path without cutting the communication between the liquid chamber and the liquid material storage container.

Classes IPC  ?

  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B41J 2/045 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par la mise en contact sélective d'un liquide ou de particules avec un matériau d'impression à jet d'encre caractérisés par le procédé de formation du jet en produisant à la demande des gouttelettes ou des particules séparées les unes des autres par pression, p. ex. à l'aide de transducteurs électromécaniques
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface

70.

LIQUID MATERIAL EJECTING APPARATUS


Numéro d'application JP2019010989
Numéro de publication 2019/181812
Statut Délivré - en vigueur
Date de dépôt 2019-03-15
Date de publication 2019-09-26
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Problem: To provide a liquid material ejecting apparatus in which a discharge amount that has changed during a discharge operation can be more easily corrected than in the prior art. Solution: A liquid material ejecting apparatus according to the present invention is provided with: an ejection member formed in a bar shape; a liquid chamber which has a greater width than the ejection member and in which a distal end of the ejection member is disposed; an ejection hole that communicates with the liquid chamber; a liquid feeding path that communicates the liquid chamber and a liquid material storage container; and a driving device that drives the ejection member, and is also provided with: a discharged amount adjustment member that is positioned in the liquid feeding path but does not block the communication between the liquid chamber and the liquid material storage container; and a member position adjustment member that moves the position of the discharged amount adjustment member inside the liquid feeding path.

Classes IPC  ?

  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface

71.

DISCHARGE HEAD WITH PICKUP MEMBER, AND LIQUID-MATERIAL DISCHARGE DEVICE


Numéro d'application JP2019007927
Numéro de publication 2019/172090
Statut Délivré - en vigueur
Date de dépôt 2019-02-28
Date de publication 2019-09-12
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

The purpose of the present invention is to provide a handy-type device capable of performing an application work and a placement work with one device when attaching parts to a workpiece. Provided are a handy-type liquid-material discharge head, comprising: a nozzle; a liquid storing portion; and a pickup member arranged in line with the nozzle, for holding a subject, and a liquid-material discharge device comprising the liquid-material discharge head. Preferably, the pickup member holds the subject by generating a negative pressure on its distal end portion.

Classes IPC  ?

  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B25B 11/00 - Porte-pièces ou dispositifs de mise en position non couverts par l'un des groupes , p. ex. porte-pièces magnétiques, porte-pièces utilisant le vide

72.

Working apparatus and working method


Numéro d'application 16331688
Numéro de brevet 11229923
Statut Délivré - en vigueur
Date de dépôt 2017-09-29
Date de la première publication 2019-06-27
Date d'octroi 2022-01-25
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

An apparatus and a method performing work free from variations among a plurality of work heads having individual differences. A working apparatus includes a number n (a natural number 2 or greater) of work heads, a stage retaining a work object, drive devices moving the stage and the work heads relative to each other in three directions, a work amount measurement device measuring a work amount of each work head, and a control device, wherein the first-direction drive device enables the number n of work heads to be independently moved in a first direction, and the second-direction drive device includes a second-direction main drive device moving the number n of work heads simultaneously in a second direction, and a second-direction auxiliary drive device moving n−1 work heads among the number n of work heads independently in the second direction. A working method is carried out using the working apparatus.

Classes IPC  ?

  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • H01L 21/67 - Appareils spécialement adaptés pour la manipulation des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide pendant leur fabrication ou leur traitementAppareils spécialement adaptés pour la manipulation des plaquettes pendant la fabrication ou le traitement des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide ou de leurs composants
  • B05C 11/00 - Parties constitutives, détails ou accessoires non prévus dans les groupes
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • H01L 21/68 - Appareils spécialement adaptés pour la manipulation des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide pendant leur fabrication ou leur traitementAppareils spécialement adaptés pour la manipulation des plaquettes pendant la fabrication ou le traitement des dispositifs à semi-conducteurs ou des dispositifs électriques à l'état solide ou de leurs composants pour le positionnement, l'orientation ou l'alignement
  • G01C 3/00 - Mesure des distances dans la ligne de viséeTélémètres optiques
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • G01B 11/14 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques pour mesurer la distance ou la marge entre des objets ou des ouvertures espacés

73.

DROPLET EJECTION DEVICE AND DROPLET EJECTION METHOD


Numéro d'application JP2018046286
Numéro de publication 2019/124295
Statut Délivré - en vigueur
Date de dépôt 2018-12-17
Date de publication 2019-06-27
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a droplet ejection device and a droplet ejection method, in which a liquid material can be continuously delivered to an ejection head when delivering the liquid material between arbitrary tanks. [Solution] Provided are a droplet ejection device and a droplet ejection method using said device, the droplet ejection device comprising: a droplet ejecting head; a supply tank communicating with a first pressure source; a recovery tank communicating with a first negative pressure source; a replenishment tank communicating with the supply tank and the recovery tank; an opening/closing valve A for opening and closing a fluid passage communicating the supply tank and the replenishment tank; an opening/closing valve B for opening and closing a fluid passage communicating the recovery tank and the replenishment tank; a switching valve for switching between communication of the replenishment tank and a second pressure source and communication of the replenishment tank and a second negative pressure source; and a control device, wherein the control device has: an ejection mode in which a liquid material is ejected from the droplet ejection head; a replenishment mode in which the liquid material is delivered from the replenishment tank to the supply tank while the liquid material is delivered from the supply tank to the recovery tank; and a recovery mode in which the liquid material is delivered from the recovery tank to the replenishment tank while the liquid material is delivered from the supply tank to the recovery tank.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B05D 3/00 - Traitement préalable des surfaces sur lesquelles des liquides ou d'autres matériaux fluides doivent être appliquésTraitement ultérieur des revêtements appliqués, p. ex. traitement intermédiaire d'un revêtement déjà appliqué, pour préparer les applications ultérieures de liquides ou d'autres matériaux fluides
  • B41J 2/175 - Systèmes d'alimentation en encre
  • B41J 2/18 - Systèmes de recirculation de l'encre

74.

LIQUID MATERIAL APPLICATION DEVICE AND APPLICATION METHOD


Numéro d'application JP2018040765
Numéro de publication 2019/088237
Statut Délivré - en vigueur
Date de dépôt 2018-11-01
Date de publication 2019-05-09
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide an application device and an application method that allow three-dimensional application and drawing without a rotary mechanism being provided on a delivery head. [Solution] An application device comprising a delivery head that comprises a delivery device having a delivery opening opened in the Z direction, a stage that holds a workpiece, an XYZ relative motion device that moves the delivery head and the stage relative to each other, an R-axis rotation device that rotates the stage about an R-axis parallel to the XY plane, a P-axis rotation device that rotates the stage about a P-axis in a different direction than the R-axis and parallel to the XY plane, a control device, and a stand, wherein the P-axis rotation device is disposed under the R-axis rotation device, and the P-axis rotation device rotates the stage and the R-axis rotation device. An application method using same device.

Classes IPC  ?

  • B05C 13/02 - Moyens pour manipuler ou tenir des objets, p. ex. des objets individuels pour des objets particuliers
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage

75.

Discharge device for liquid material containing solid particles, discharge method and coating device


Numéro d'application 16078904
Numéro de brevet 10556207
Statut Délivré - en vigueur
Date de dépôt 2017-02-20
Date de la première publication 2019-02-21
Date d'octroi 2020-02-11
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A device and a method for accurately discharging a fixed amount of a liquid, the liquid containing solid particles, in a state that the solid particles are dispersed in the liquid material. The device includes a first reservoir, a first air pressure supply pipe, a metering portion having a metering hole, a plunger moving back and forth in the metering hole, a nozzle, a switching valve having a first position and a second position, a plunger driver, and a switching valve driver. The discharge device further includes a second reservoir, a second air pressure supply pipe, a branch portion provided in an upper portion of the metering hole and having a branch flow path, and an opening/closing mechanism that establishes or cuts off communication between the second reservoir and the metering hole. A discharge method is carried out using the discharge device.

Classes IPC  ?

  • B01F 3/08 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de liquides avec des liquides; Emulsion
  • B01J 4/02 - Dispositifs d'alimentationDispositifs de commande d'alimentation ou d'évacuation pour introduire des quantités mesurées de réactifs
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B01F 5/00 - Mélangeurs à écoulement; Mélangeurs pour matériaux tombants, p.ex. particules solides
  • B01F 15/02 - Mécanismes d'alimentation ou d'évacuation
  • B01F 15/04 - Réalisation de proportions prédéterminées de substances à mélanger
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide

76.

Liquid material ejection device


Numéro d'application 16070367
Numéro de brevet 11536259
Statut Délivré - en vigueur
Date de dépôt 2017-01-11
Date de la première publication 2019-01-24
Date d'octroi 2022-12-27
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A liquid material ejection device in which a plunger is efficiently accelerated. The device includes a liquid chamber communicating with an ejection port and being supplied with a liquid material, a plunger including a tip portion having a smaller diameter than the liquid chamber and is moved in the liquid chamber, an elastic member urging the plunger upward, an arm disposed in a state extending in a substantially horizontal direction, an arm driver serving as a driving source to operate the arm, and a base member on which the arm driver is disposed. The device further includes a rocking mechanism unit connected to the arm driver and rockingly supporting the arm, the arm driver includes a plurality of actuators, the arm includes a pressing portion pressing the plunger downward, the plunger is pressed by the pressing portion, and the plunger is linearly reciprocated with rocking motion of the arm.

Classes IPC  ?

  • B05B 17/06 - Appareils de pulvérisation ou d'atomisation de liquides ou d'autres matériaux fluides, non couverts par les autres groupes de la présente sous-classe opérant suivant des procédés particuliers utilisant des vibrations ultrasonores
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • F04B 17/00 - Pompes caractérisées par leur combinaison avec des machines motrices ou moteurs particuliers qui les entraînent ou par leur adaptation à ceux-ci
  • F04B 43/04 - Pompes ayant un entraînement électrique
  • F04B 9/00 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • F04B 9/04 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail les moyens étant mécaniques constitués par des cames, des excentriques ou des mécanismes à téton et rainure guide

77.

LIQUID MATERIAL APPLICATION METHOD AND DEVICE FOR IMPLEMENTING SAID METHOD


Numéro d'application JP2018020263
Numéro de publication 2018/221432
Statut Délivré - en vigueur
Date de dépôt 2018-05-28
Date de publication 2018-12-06
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] Provided is a technique by which it is possible to perform cross-sectional line-drawing application having a small height ratio relative to width using a jet-type discharge device. [Solution] A discharge device comprises: a nozzle (50) having a plurality of discharge ports; a liquid chamber (26) that is in communication with the plurality of discharge ports via a plurality of discharge flow paths; and a plunger rod (18) that reciprocates inside the liquid chamber, the plunger rod being narrower in width than the liquid chamber. The plurality of discharge ports (62) are disposed on a nozzle disposition line, which is a straight line, and are disposed at a distance at which a liquid material deposited on an application object joins together to form an application line. While the discharge device and the application object are moved in a relative fashion in a direction orthogonal to the nozzle disposition line, the liquid material is continuously discharged in a manner in which a plurality of liquid masses discharged from the plurality of discharge ports (62) do not come into contact with one another prior to deposition on the application object, and the liquid material that has deposited on the application object is joined, thereby forming an application line that is orthogonal to the nozzle disposition line.

Classes IPC  ?

  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 3/00 - Traitement préalable des surfaces sur lesquelles des liquides ou d'autres matériaux fluides doivent être appliquésTraitement ultérieur des revêtements appliqués, p. ex. traitement intermédiaire d'un revêtement déjà appliqué, pour préparer les applications ultérieures de liquides ou d'autres matériaux fluides
  • B05D 7/00 - Procédés, autres que le flocage, spécialement adaptés pour appliquer des liquides ou d'autres matériaux fluides, à des surfaces particulières, ou pour appliquer des liquides ou d'autres matériaux fluides particuliers
  • G02F 1/13 - Dispositifs ou dispositions pour la commande de l'intensité, de la couleur, de la phase, de la polarisation ou de la direction de la lumière arrivant d'une source lumineuse indépendante, p. ex. commutation, ouverture de porte ou modulationOptique non linéaire pour la commande de l'intensité, de la phase, de la polarisation ou de la couleur basés sur des cristaux liquides, p. ex. cellules d'affichage individuelles à cristaux liquides
  • G02F 1/1333 - Dispositions relatives à la structure

78.

LIQUID MATERIAL COATING DEVICE AND LIQUID MATERIAL COATING METHOD


Numéro d'application JP2017019623
Numéro de publication 2018/216183
Statut Délivré - en vigueur
Date de dépôt 2017-05-25
Date de publication 2018-11-29
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a liquid material coating device and a liquid material coating method which are capable of discharging, during a series of coating operations, a predetermined discharge amount of a liquid material per unit time irrespective of a relative moving speed. [Solution] Provided are a liquid material coating device and an coating method using said device, the liquid material coating device being provided with: a discharging head; a robot which moves the discharging head relative to a workpiece; a movement control unit which controls the relative movement of the discharging head and the workpiece; and a discharge control unit which controls an operation of discharging the liquid material from the discharging head, wherein the discharge control unit is capable of switching, on the basis of a coating program, between a first mode discharge control in which a discharge amount per unit time at which the discharging head discharges the liquid material is changed on the basis of the relative moving speed of the discharging head and the workpiece, and a second mode discharge control in which liquid material is discharged at a discharge amount per unit time, the discharge amount being predetermined for the discharging head, irrespective of the relative moving speed.

Classes IPC  ?

  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface

79.

LASER SOLDERING METHOD AND DEVICE


Numéro d'application JP2018016599
Numéro de publication 2018/199086
Statut Délivré - en vigueur
Date de dépôt 2018-04-24
Date de publication 2018-11-01
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a laser soldering technique with which it is possible to prevent scorching, residue, etc., in a substrate or in surrounding heat-sensitive components. [Solution] Provided is an automatic soldering method in which there is used an automatic soldering device 40 comprising a laser soldering device 1 and a Z-axis drive device 43, wherein the method is characterized by including: a step for causing the height of the laser soldering device 1 to match a position where the irradiation diameter D1 of laser light reaches a pre-set size that is greater than the diameter of a solder drop S; a step for irradiating the solder drop S with the laser light to volatilize a flux solvent component and heating at a temperature at which a solder powder does not melt; a step for causing the height of the laser soldering device to match a position where the irradiation diameter D2 of the laser light reaches a pre-set size that is less than the diameter of the solder drop S; and a step for irradiating the solder drop S with the laser light, heating at a temperature at which the solder powder melts, and performing soldering. Also provided is a device for said automatic soldering method.

Classes IPC  ?

80.

CABLE UNIT, AND LIQUID MATERIAL SUPPLY DEVICE AND APPLICATION DEVICE IN WHICH SAID CABLE UNIT IS USED


Numéro d'application JP2018016641
Numéro de publication 2018/199103
Statut Délivré - en vigueur
Date de dépôt 2018-04-24
Date de publication 2018-11-01
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a cable unit capable of saving space in a workspace, and a liquid material supply device and an application device in which said cable unit is used. [Solution] A cable unit 30 that electrically connects in a detachable manner, a discharge head 10 that discharges a liquid material, and a relative movement robot 20 that moves the discharge head 10 and a workpiece 25 in a relative manner, wherein said cable unit has a dispense controller 33 that controls a discharge operation for the discharge head 10, and a liquid material supply device and application device in which said cable unit is used.

Classes IPC  ?

  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05B 12/00 - Aménagements de commande de la distributionAménagements de réglage de l’aire de pulvérisation
  • B05B 15/00 - Parties constitutives des installations ou des appareillages de pulvérisation non prévus ailleursAccessoires
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide

81.

LID FOR LIQUID MATERIAL STORAGE CONTAINER, AND LIQUID MATERIAL STORAGE CONTAINER


Numéro d'application JP2018011615
Numéro de publication 2018/180956
Statut Délivré - en vigueur
Date de dépôt 2018-03-23
Date de publication 2018-10-04
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a lid for a liquid material storage container having good workability of attachment and detachment thereof, and whereby the problems of failure and uplift of the lid for a liquid material storage container are overcome, and a liquid material storage container. [Solution] A lid for a liquid material storage container, and a liquid material storage container, the lid for a liquid material storage container characterized by being provided with: an upper plate part for covering a flange part and a large-diameter opening; a stopper part for blocking a large-diameter opening of a storage cylinder, the stopper part extending downward from a center part of the upper plate part; a pair of first side parts for coming in contact with side surfaces of a pair of short sides of the flange part when the lid is closed; a pair of hook parts for coming in contact with bottom surfaces of the pair of short sides of the flange part when the lid is closed, the hook parts extending toward the stopper part from the pair of first side parts; and a push-up operation part formed in at least one of the pair of first side parts; the length of the hook parts being less than the distance between the hook parts and the upper plate part.

Classes IPC  ?

  • B65D 41/28 - Capuchons combinés avec des bouchons
  • B65D 51/16 - Fermetures non prévues ailleurs avec moyens pour laisser partir l'air ou le gaz

82.

Nozzle and liquid material discharge device provided with said nozzle


Numéro d'application 15994143
Numéro de brevet 10562045
Statut Délivré - en vigueur
Date de dépôt 2018-05-31
Date de la première publication 2018-09-27
Date d'octroi 2020-02-18
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A nozzle capable of removing a surplus liquid material, which is adhered to outer surfaces of the nozzle and which affects a discharge operation, without undergoing a special process, and a liquid material discharge device provided with the nozzle. The nozzle (1) includes a body (2) having a liquid inflow space, and a discharge tube (4) communicating with the liquid inflow space and extending downwards from the body (2). A liquid removing member (16) is disposed at a lower end of the body (2) in a state laterally surrounding the discharge tube (4), and the liquid removing member (16) includes a groove-like space (15) that is formed between adjacent to of plural surrounding surfaces (10), and that generates capillary force acting in a direction laterally away from the discharge tube (4).

Classes IPC  ?

  • B05B 1/28 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des moyens incorporés pour faire écran au liquide ou autre matériau fluide sortant, p. ex. pour limiter l'aire de pulvérisationBuses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des moyens pour empêcher l'égouttement ou pour recueillir l'excès de liquide ou autre matériau fluide
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05B 15/50 - Aménagements pour le nettoyageAménagements pour empêcher les dépôts, le séchage ou un blocageAménagements pour détecter une évacuation incorrecte en raison de la présence d’un corps étranger
  • B05B 1/08 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour produire un jet, un pulvérisat ou tout autre écoulement de forme ou de nature particulière, p. ex. sous forme de gouttes individuelles de nature pulsatoire, p. ex. débitant un liquide en quantités successives séparées
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage

83.

Liquid material discharge apparatus


Numéro d'application 15537604
Numéro de brevet 10449566
Statut Délivré - en vigueur
Date de dépôt 2016-01-14
Date de la première publication 2018-09-20
Date d'octroi 2019-10-22
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

In a liquid material discharge apparatus, attachment/detachment of a liquid contact unit (2) and a main body unit (15) is more safely and easily performed. The apparatus includes the liquid contact unit (2) provided with a housing (6) including a nozzle (3) and a discharge member (5), and with a storage container (4) fluidly connected to the housing with the aid of a mounting member, and a main body unit provided with a holder (19) to which the housing is detachably attached, and with a drive unit (16) for actuating the discharge member that is detachably coupled to the drive unit, the apparatus further includes a movable member (12) being movable in an up-down direction along the housing while the movable member remains attached to the housing, and the discharge member and the drive unit are attachable with movement of the movable member in the up-down direction.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05C 11/11 - Cuves ou autres récipients à liquides ou autres matériaux fluides
  • B05C 13/00 - Moyens pour manipuler ou tenir des objets, p. ex. des objets individuels
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage

84.

SEAL STRUCTURE, AND DEVICE WITH SAID SEAL STRUCTURE


Numéro d'application JP2018006538
Numéro de publication 2018/155580
Statut Délivré - en vigueur
Date de dépôt 2018-02-22
Date de publication 2018-08-30
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a seal structure in which a needle and a seal do not slide and which is easily mountable and removable, and also to provide a device provided with the seal structure. [Solution] Provided are a seal, a seal structure which is provided with the seal, and a device which is provided with the seal structure. The seal allows the needle of a valve device to be passed therethrough, the valve device comprising a fluid chamber which has an outflow hole and an inflow hole, and also comprising the needle having a front end reciprocating within the fluid chamber. The seal comprises: a body section consisting of an elastic body and having formed therein a needle insertion hole through which the needle is passed; and a flange section consisting of an elastic body and extended annularly and radially outward from the body section. The seal is characterized in that the diameter (D3) of the opening at one end of the needle insertion hole is smaller than the diameter (D2) of the opening at the other end of the needle insertion hole.

Classes IPC  ?

  • F16J 15/18 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par presse-étoupes pour garnitures élastiques ou plastiques
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • F16J 15/24 - Joints d'étanchéité entre deux surfaces mobiles l'une par rapport à l'autre par presse-étoupes pour garnitures élastiques ou plastiques la garniture étant comprimée radialement ou tangentiellement
  • F16J 15/48 - Joints d'étanchéité par bague de garniture dilatée ou comprimée dans son logement par pression d'un fluide, p. ex. garnitures gonflables la pression provenant de celle existant dans l'organe à isoler
  • F16K 1/32 - Soupapes ou clapets, c.-à-d. dispositifs obturateurs dont l'élément de fermeture possède au moins une composante du mouvement d'ouverture ou de fermeture perpendiculaire à la surface d'obturation Détails

85.

Discharge device and discharge method for liquid material containing solid particles, and coating device


Numéro d'application 15746108
Numéro de brevet 10799906
Statut Délivré - en vigueur
Date de dépôt 2016-07-21
Date de la première publication 2018-08-02
Date d'octroi 2020-10-13
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A device and a method of discharging a liquid in a state of solid particles being dispersed in the liquid with a minimum additional structure for dispersing the solid particles. A discharge device and an application device each include a storage container; a measuring unit having a measuring hole; a plunger disposed in the measuring hole; a nozzle; a selector valve having a first position at which the storage container and the measuring unit are communicated, and a second position at which the measuring unit and the nozzle are communicated; a plunger drive device; a selector valve drive device; and a discharge control device, wherein a discharge control program includes a filling stepinto the measuring hole; an ejection step; an inflow step causing the liquid material in the measuring hole to flow into the storage container; a discharge step; and a stirring step.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 7/24 - Procédés, autres que le flocage, spécialement adaptés pour appliquer des liquides ou d'autres matériaux fluides, à des surfaces particulières, ou pour appliquer des liquides ou d'autres matériaux fluides particuliers pour appliquer des liquides ou d'autres matériaux fluides particuliers
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • H01L 33/50 - DISPOSITIFS À SEMI-CONDUCTEURS NON COUVERTS PAR LA CLASSE - Détails caractérisés par les éléments du boîtier des corps semi-conducteurs Éléments de conversion de la longueur d'onde
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B01F 11/00 - Mélangeurs avec mécanismes à secousses, oscillants ou vibrants
  • B05C 17/005 - Outils à main ou appareils utilisant des outils tenus à la main pour appliquer ou étaler des liquides ou d'autres matériaux fluides sur des surfaces, pour enlever partiellement des liquides ou d'autres matériaux fluides des surfaces pour décharger par pression des matériaux à travers un orifice d'évacuation

86.

Liquid material ejector


Numéro d'application 15933481
Numéro de brevet 11111129
Statut Délivré - en vigueur
Date de dépôt 2018-03-23
Date de la première publication 2018-07-26
Date d'octroi 2021-09-07
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

The liquid material ejector has a liquid material supply port through which the liquid material is supplied, a nozzle for ejecting the liquid material, a valve block having a metering bore to be filled with the ejected liquid material and a liquid material supply channel communicating with the liquid material supply port, a selector valve having a first channel for allowing communication between the metering bore and the liquid material supply channel and a second channel for allowing communication between the metering bore and the nozzle, a plunger advancing and retracting in the metering bore, a plunger driving section for driving the plunger, a valve driving section for driving the selector valve, and a transmission section for transmitting driving power from the valve driving section to the selector valve. The plunger driving section, the valve driving section, and the valve block are arranged successively in the longitudinal direction.

Classes IPC  ?

  • B67D 7/16 - Aménagements des compteurs à liquide
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B67D 7/42 - Buses de remplissage
  • B67D 7/64 - Aménagements des pompes à moteur du type à piston

87.

Liquid material discharge device for discharging a fixed amount of liquid material


Numéro d'application 15745779
Numéro de brevet 12036574
Statut Délivré - en vigueur
Date de dépôt 2016-07-21
Date de la première publication 2018-07-26
Date d'octroi 2024-07-16
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A discharge device capable of suppressing pressure fluctuation of a compressed gas supplied to a container in which a liquid material is stored. The device includes a storage container in which a liquid material is stored; a discharge port through which the liquid material is discharged; a pressure control valve that adjusts a pressure of a compressed gas supplied from an external compressed gas source to a desired level; a discharge valve that establishes or cuts off communication between the pressure control valve and the storage container; a control device that controls operation of the discharge valve; a first flow line connecting the pressure control valve and the discharge valve; and a second flow line connecting the discharge valve and the storage container. The device further includes a third flow line branched from the first flow line, and a leak mechanism connected to the third flow line.

Classes IPC  ?

  • B05C 17/01 - Outils à main ou appareils utilisant des outils tenus à la main pour appliquer ou étaler des liquides ou d'autres matériaux fluides sur des surfaces, pour enlever partiellement des liquides ou d'autres matériaux fluides des surfaces pour décharger par pression des matériaux à travers un orifice d'évacuation avec un piston actionné mécaniquement, électriquement ou analogue
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05C 17/005 - Outils à main ou appareils utilisant des outils tenus à la main pour appliquer ou étaler des liquides ou d'autres matériaux fluides sur des surfaces, pour enlever partiellement des liquides ou d'autres matériaux fluides des surfaces pour décharger par pression des matériaux à travers un orifice d'évacuation
  • B65D 83/66 - Récipients pour distribuer des contenus liquides ou semi-liquides par pression interne de gaz, c.-à-d. réceptacles aérosols contenant un propulseur avec un contenu et un propulseur séparés d'abord séparés puis mélangés, p. ex. dans une tête de distribution
  • A61B 17/00 - Instruments, dispositifs ou procédés chirurgicaux
  • G05D 16/02 - Modifications du système pour réduire les effets d'instabilité, p. ex. dus aux vibrations, au frottement, à la température anormale, à la surcharge ou au balourd

88.

LIQUID DISCHARGE DEVICE, APPLICATION DEVICE WITH SAID DISCHARGE DEVICE, AND APPLICATION METHOD


Numéro d'application JP2017045580
Numéro de publication 2018/117113
Statut Délivré - en vigueur
Date de dépôt 2017-12-19
Date de publication 2018-06-28
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide: a liquid discharge device capable of discharging a liquid material stirred near a measurement chamber; an application device provided with the discharge device; and an application method. [Solution] Provided is a liquid discharge device comprising a stirring mechanism, wherein the liquid discharge device is provided with: a storage unit provided with a storage container for storing a liquid material, and with a stirrer drive mechanism for driving a stirrer disposed within the storage container; a discharge unit provided with a measurement chamber filled with a liquid material, a plunger in close contact with and sliding on the inner peripheral surface of the measurement chamber, a nozzle in communication with the measurement chamber, and a switching valve switched between a first position at which the storage container and the measurement container are in communication with each other, and a second position at which the measurement chamber and the nozzle are in communication with each other; and a connection flow passage for providing communication between the storage container and the measurement chamber. The provided liquid discharge device is characterized in that the stirrer drive mechanism is configured to be separable from the storage unit. An application device provided with the liquid discharge device, and an application method are also provided.

Classes IPC  ?

  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B05D 3/00 - Traitement préalable des surfaces sur lesquelles des liquides ou d'autres matériaux fluides doivent être appliquésTraitement ultérieur des revêtements appliqués, p. ex. traitement intermédiaire d'un revêtement déjà appliqué, pour préparer les applications ultérieures de liquides ou d'autres matériaux fluides

89.

LIQUID MATERIAL DISCHARGE DEVICE WITH TEMPERATURE CONTROL DEVICE, APPLICATION DEVICE FOR SAME, AND APPLICATION METHOD


Numéro d'application JP2017036337
Numéro de publication 2018/066660
Statut Délivré - en vigueur
Date de dépôt 2017-10-05
Date de publication 2018-04-12
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a device and method with which application operations can be carried out without variations in amount of discharge while adjusting the temperature of liquid material by a temperature control device even on a stage that is heated. [Solution] Provided is a liquid material discharge device, which is provided with a discharge opening, a liquid chamber linked to the discharge opening, and a temperature control device for adjusting the temperature of the liquid chamber and which discharges a liquid material from the discharge opening while moving a workpiece and the discharge opening relative to each other, wherein the liquid material discharge device is provided with a refrigerant flow path for flow of a refrigerant for heat exchange with the temperature control device, and a discharge control device for controlling discharge operations. Also provided are an application device provided with the liquid material discharge device, and an application method that uses this application device.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface
  • B05D 3/00 - Traitement préalable des surfaces sur lesquelles des liquides ou d'autres matériaux fluides doivent être appliquésTraitement ultérieur des revêtements appliqués, p. ex. traitement intermédiaire d'un revêtement déjà appliqué, pour préparer les applications ultérieures de liquides ou d'autres matériaux fluides

90.

WORKING APPARATUS AND WORKING METHOD


Numéro d'application JP2017035393
Numéro de publication 2018/062463
Statut Délivré - en vigueur
Date de dépôt 2017-09-29
Date de publication 2018-04-05
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a work apparatus and a work method whereby work can be obtained that is free of variations among a plurality of work heads having machine differences. [Solution] A work apparatus and a work method that uses the apparatus, the work apparatus provided with n (where n is a natural number equal to 2 or greater) work heads for performing the same work, a stage for retaining a work object, a first-direction drive device for moving the stage and the work heads relative to each other, a second-direction drive device for moving the stage and the work heads relative to each other, a third-direction drive device for moving the stage and the work heads relative to each other, a work amount measurement device for measuring the work amount of each work head, and a control device, the first-direction drive device being capable of moving each of the n work heads independently in a first direction, and the second-direction drive device being provided with a second-direction main drive device for moving the n work heads in a second direction simultaneously and a second-direction secondary drive device for moving each of n-1 work heads of the n work heads independently in the second direction.

Classes IPC  ?

  • B05C 11/00 - Parties constitutives, détails ou accessoires non prévus dans les groupes
  • B05D 1/00 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces
  • G01B 11/00 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface

91.

LIQUID MATERIAL-DISCHARGING DEVICE


Numéro d'application JP2017032395
Numéro de publication 2018/056072
Statut Délivré - en vigueur
Date de dépôt 2017-09-08
Date de publication 2018-03-29
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A liquid material-discharging device provided with a discharging member made of a rod-shaped body, a liquid chamber that is wider than the discharging member and in which the tip of the discharging member is disposed, a discharge port that is in communication with the liquid chamber, a liquid delivery path that brings the liquid chamber into communication with a liquid material storage container, a drive device for driving the discharging member, and a main body. The liquid material-discharging device is provided with a long thin inserted member that is inserted in the liquid delivery path so as to be freely removable without blocking the communication between the liquid chamber and the liquid material storage container.

Classes IPC  ?

  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface

92.

Droplet discharge device


Numéro d'application 15560044
Numéro de brevet 10016778
Statut Délivré - en vigueur
Date de dépôt 2016-04-01
Date de la première publication 2018-03-15
Date d'octroi 2018-07-10
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

The droplet discharge device includes a liquid chamber which is in communication with a nozzle and to which a liquid material is supplied, a plunger having a tip portion that is thinner than the liquid chamber and that is moved back and forth in the liquid chamber, a piezoelectric actuator serving as a drive source that operates the plunger to be moved back and forth, a lever mechanism that increases a displacement of the piezoelectric actuator, a base having a mounting surface to which the piezoelectric actuator is mounted, and a discharge control device. The lever mechanism includes an arm that is operated to perform a swinging motion by the piezoelectric actuator, and a leaf spring including ends that are linked to a lower portion of the arm and to the base, and a plunger-linked portion in a central region thereof.

Classes IPC  ?

  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
  • H01L 41/09 - Eléments piézo-électriques ou électrostrictifs à entrée électrique et sortie mécanique
  • B05B 17/06 - Appareils de pulvérisation ou d'atomisation de liquides ou d'autres matériaux fluides, non couverts par les autres groupes de la présente sous-classe opérant suivant des procédés particuliers utilisant des vibrations ultrasonores
  • B05B 13/04 - Moyens pour supporter l'ouvrageDisposition ou assemblage des têtes de pulvérisationAdaptation ou disposition des moyens pour entraîner des pièces les têtes de pulvérisation étant déplacées au cours de l'opération
  • H02N 2/04 - Détails de structure

93.

Plunger for dispenser, dispenser, and method for dispensing liquid material


Numéro d'application 15702908
Numéro de brevet 10501256
Statut Délivré - en vigueur
Date de dépôt 2017-09-13
Date de la première publication 2018-01-11
Date d'octroi 2019-12-10
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

The present invention provides a plunger (20) for a dispenser, the plunger including a large diameter body portion (23) provided with ring-shaped contact surfaces (24, 25) that contact an inner wall surface of a syringe, a rear opening (26) formed in a backside of the large diameter body portion (23), and a small diameter body portion (22) provided with a front opening (28), wherein the front opening (28) is formed in a size allowing a liquid material to be directly pressed by pressurized air, and allowing at least the plunger (20) to move following a fall in water head position, which is caused with discharge and consumption of the liquid material. With those features, the liquid material can be prevented from adhering to the inner wall surface of the syringe, and the liquid material in the syringe can be prevented from flowing backwards.

Classes IPC  ?

  • B05C 17/005 - Outils à main ou appareils utilisant des outils tenus à la main pour appliquer ou étaler des liquides ou d'autres matériaux fluides sur des surfaces, pour enlever partiellement des liquides ou d'autres matériaux fluides des surfaces pour décharger par pression des matériaux à travers un orifice d'évacuation
  • B65D 83/00 - Réceptacles ou paquets comportant des moyens particuliers pour distribuer leur contenu
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 17/015 - Outils à main ou appareils utilisant des outils tenus à la main pour appliquer ou étaler des liquides ou d'autres matériaux fluides sur des surfaces, pour enlever partiellement des liquides ou d'autres matériaux fluides des surfaces pour décharger par pression des matériaux à travers un orifice d'évacuation avec un piston actionné pneumatiquement ou analogue

94.

LIQUID MATERIAL DISCHARGE DEVICE, AND APPLICATION DEVICE AND APPLICATION METHOD THEREFOR


Numéro d'application JP2017019506
Numéro de publication 2017/208958
Statut Délivré - en vigueur
Date de dépôt 2017-05-25
Date de publication 2017-12-07
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a liquid material discharge device and method which are capable of ameliorating the problem of liquid leakage caused by closing failure which occurs when the discharge device is provided in a negative pressure environment. [Solution] This liquid material discharge device is used in a negative pressure space, and is provided with: a storage container; a compressed gas supply source for pressurizing the storage container; a nozzle provided with a discharge flow path; a reciprocating valve rod; an actuator for driving the valve rod; a valve seat provided with a communication hole which communicates with the discharge flow path; and a discharge control device which controls the actuator such that the communication hole is opened and closed by the tip of the valve rod. The liquid material discharge device is provided with a resin film which is provided to the lower end of the valve rod, or a resin film which is provided to the upper surface of the valve seat, and which has a through hole which communicates with the communication hole.

Classes IPC  ?

  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface

95.

LIQUID MATERIAL DISCHARGE DEVICE, AND APPLICATION DEVICE AND APPLICATION METHOD THEREFOR


Numéro d'application JP2017019503
Numéro de publication 2017/208956
Statut Délivré - en vigueur
Date de dépôt 2017-05-25
Date de publication 2017-12-07
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a liquid material discharge device and method which are capable of suppressing the formation of bubbles caused by a rod raising operation, in a negative pressure environment. Furthermore, to provide a liquid material discharge device and method which solve the problem of leakage of a liquid material which occurs as a result of insufficient blockage by a valve rod tip due to wear of the valve rod tip or a valve seat. [Solution] This liquid material discharge device is used in a negative pressure space, and is provided with: a storage container; a compressed gas supply source for pressurizing the storage container; a nozzle provided with a discharge flow path; a reciprocating valve rod; an actuator which drives the valve rod; a valve seat provided with a communication hole which communicates with the discharge flow path; and a discharge control device which controls the actuator such that the communication hole is opened and closed by the tip of the valve rod. The discharge control device inhibits the formation of bubbles which accompanies the raising of the valve rod, by controlling the acceleration time Au when the valve rod is raised by the actuator, to within the range of 2-300 [ms].

Classes IPC  ?

  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface

96.

DISCHARGE DEVICE FOR LIQUID MATERIAL CONTAINING SOLID PARTICLES, DISCHARGE METHOD, AND COATING DEVICE


Numéro d'application JP2017006090
Numéro de publication 2017/145978
Statut Délivré - en vigueur
Date de dépôt 2017-02-20
Date de publication 2017-08-31
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To supply a device and method, for discharging a fixed quantity of a liquid containing solid particles, discharging same with good precision and in a state in which the solid particles are dispersed. [Solution] A discharge device for a liquid material containing solid particles and a discharge method using said device. The discharge device comprises: a first storage container; a first air pressure supply pipe; a measuring unit having a measuring hole; a plunger that moves into and retracts from the measuring hole; a nozzle; a switching valve having a first position and a second position; a plunger drive device; and a switching valve drive device. The discharge device further comprises: a second storage container; a second air pressure supply pipe; a branch section provided in an upper section of the measuring hole and having a branch flow path; and an opening/closing mechanism that connects or blocks between the second storage container and the measuring hole. The discharge device is characterized by: being capable of sending the liquid material inside the first storage container to the second storage container; and by being capable of sending the liquid material inside the second storage container to the first storage container.

Classes IPC  ?

  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • B01F 3/08 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de liquides avec des liquides; Emulsion
  • B01F 5/00 - Mélangeurs à écoulement; Mélangeurs pour matériaux tombants, p.ex. particules solides
  • B01F 15/02 - Mécanismes d'alimentation ou d'évacuation
  • B01F 15/04 - Réalisation de proportions prédéterminées de substances à mélanger
  • B01J 4/02 - Dispositifs d'alimentationDispositifs de commande d'alimentation ou d'évacuation pour introduire des quantités mesurées de réactifs
  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05D 1/26 - Procédés pour appliquer des liquides ou d'autres matériaux fluides aux surfaces par application de liquides ou d'autres matériaux fluides, à partir d'un orifice en contact ou presque en contact avec la surface

97.

LIQUID MATERIAL DISCHARGE DEVICE COMPRISING BOOSTER CIRCUIT


Numéro d'application JP2017006062
Numéro de publication 2017/145969
Statut Délivré - en vigueur
Date de dépôt 2017-02-20
Date de publication 2017-08-31
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

[Problem] To provide a liquid material discharge device capable of reducing takt time. [Solution] A liquid material discharge device comprising: a liquid chamber connected to a discharge port and having liquid material supplied thereto; a plunger having a piston formed in a rear end section thereof and having a tip section thereof entering into and retracting from the liquid chamber; an elastic member that applies an impelling force to the plunger; a piston chamber having the piston arranged therein and having a pressurized gas supplied thereto; and a pressure supply device that supplies pressurized air that exceeds the impelling force of an elastic body, to the piston chamber, or discharges pressurized air from inside the piston chamber. The liquid material discharge device discharges liquid material from the discharge port, by causing the plunger to move forward and by applying inertial force to the liquid material, and is characterized by: comprising a booster circuit connecting the pressure supply device and an air source; and the booster circuit comprising a first booster system having a booster valve and a decompression valve, a second booster system having a booster valve and a decompression valve, and a merging section that causes the first booster system and the second booster system to merge.

Classes IPC  ?

  • B05C 11/10 - Stockage, débit ou réglage du liquide ou d'un autre matériau fluideRécupération de l'excès de liquide ou d'un autre matériau fluide
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • F15B 11/028 - Systèmes comportant essentiellement des moyens particuliers pour commander la vitesse ou la puissance d'un organe de sortie pour régler la puissance

98.

Syringe attachment/detachment mechanism and device provided with mechanism


Numéro d'application 15329359
Numéro de brevet 10441967
Statut Délivré - en vigueur
Date de dépôt 2015-07-17
Date de la première publication 2017-08-10
Date d'octroi 2019-10-15
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

A syringe attachment/detachment mechanism enables a syringe to be easily attached to and detached from a discharge device without causing twisting of a tube, and enabling the syringe and an adapter to be fixedly held in a desired orientation. In the syringe attachment/detachment mechanism and the device provided with the mechanism, the mechanism being adapted for a discharge device to which a syringe including an attachment part and an upper connection part is attached through screwing, the attachment part includes an inner cylindrical portion having a small-diameter opening, an outer cylindrical portion surrounding the inner cylindrical portion, and a screw portion. The attachment/detachment mechanism includes a support member including a cylindrical insertion portion into which the inner cylindrical portion is inserted, and having a channel formed therein for communication between the small-diameter opening and a nozzle of the discharge device. A rotation member includes a screw portion.

Classes IPC  ?

  • B05C 11/00 - Parties constitutives, détails ou accessoires non prévus dans les groupes
  • B05C 11/11 - Cuves ou autres récipients à liquides ou autres matériaux fluides
  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • F16L 37/24 - Accouplements du type à action rapide dans lesquels l'assemblage est réalisé par insertion selon l'axe d'un organe dans l'autre organe et en le faisant tourner d'une amplitude limitée, p. ex. comme dans un raccord à baïonnette
  • B05C 5/02 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage à partir d'un dispositif de sortie en contact, ou presque en contact, avec l'ouvrage
  • B05C 13/00 - Moyens pour manipuler ou tenir des objets, p. ex. des objets individuels
  • F16L 19/04 - Raccords dans lesquels les surfaces d'étanchéité sont maintenues en contact par un organe, p. ex. un écrou à oreilles vissé dans, ou vissé sur une des parties du raccord utilisant des segments rigides additionnels, scellés directement à une extrémité du tuyau au moins, cette extrémité étant rabattue soit avant, soit pendant l'opération d'assemblage

99.

LIQUID MATERIAL EJECTION DEVICE


Numéro d'application JP2017000639
Numéro de publication 2017/122683
Statut Délivré - en vigueur
Date de dépôt 2017-01-11
Date de publication 2017-07-20
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Inventeur(s) Ikushima, Kazumasa

Abrégé

Problem: To provide a liquid material ejection device in which a plunger can be efficiently accelerated, the device having a low center of gravity and satisfactory maintainability, and a coating device in which the liquid material ejection device is mounted. Solution: The liquid material ejection device is provided with: a liquid chamber which communicates with an ejection opening and to which liquid material is supplied; a plunger of which a tip-end portion having a diameter smaller than the liquid chamber is moved back and forth in the liquid chamber; an elastic member which urges the plunger upward; an arm disposed so as to extend in a substantially horizontal direction; an arm drive device providing a driving source for operating the arm; and a base member on which the arm drive device is disposed. The liquid material ejection device is further provided with a pivotal mechanism unit which is connected to the arm drive device and which pivotally supports the arm drive device and the arm. The arm drive device is provided with a plurality of actuators disposed in a longitudinal direction of the arm. The arm is provided with a pressing portion which presses the plunger downward. The plunger is provided with an abutment portion pressed by the pressing portion. The plunger executes a linear reciprocating motion as the arm is pivotally moved. The coating device incorporates the liquid material ejection device.

Classes IPC  ?

  • B05C 5/00 - Appareillages dans lesquels un liquide ou autre matériau fluide est projeté, versé ou répandu sur la surface de l'ouvrage
  • F04B 9/00 - "Machines" ou pompes à piston caractérisées par les moyens entraînants ou entraînés liés à leurs organes de travail

100.

HYPER JET


Numéro de série 87465803
Statut Enregistrée
Date de dépôt 2017-05-26
Date d'enregistrement 2021-08-17
Propriétaire MUSASHI ENGINEERING, INC. (Japon)
Classes de Nice  ?
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Liquid precision measuring and discharging modules sold as an integral component of semiconductor manufacturing machines, and parts therefor; Painting machines and parts therefor Physical and chemical machinery and appliances, namely, machines for dripping liquid onto plates, glass slides and chips having multi-arrays that can be used in chemical analysis, biological analysis or patterning for scientific laboratory or medical research use
  1     2     3        Prochaine page
