[Problem] To provide a technique with which it is possible to simply and accurately determine a liquid pool generated at the lower end of a nozzle. [Solution] Provided are a method for detecting a liquid pool at the lower end of a nozzle of a liquid material ejection device, and a detection device that executes the method. The method comprises: a first step in which a nozzle 103 is moved to a detection position on a detection surface; a second step in which the nozzle 103 is lowered until the distance between the lower end of the nozzle 103 and the detection surface 107a reaches a predetermined detection distance L and, is raised once the predetermined detection distance L is reached; and a third step in which a liquid pool at the lower end of the nozzle 103 is detected by detecting whether a liquid material is attached to the detection surface 107a by the detection device 104.
B05D 3/00 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05C 11/00 - Component parts, details or accessories not specifically provided for in groups
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 13/02 - Means for manipulating or holding work, e.g. for separate articles for particular articles
[Problem] To provide a liquid material discharge device capable of compactly constituting a device size while allowing a liquid contact part to be attached to a body part without positional deviation. [Solution] This liquid material discharge device comprises: a body part 20 having an operation shaft 61 and a drive device 22 for driving the operation shaft 61; a liquid contact part 30 having a liquid chamber 62 and a liquid feed passage 34 for supplying a liquid material to the liquid chamber 62; and a liquid contact part connector 50 for detachably connecting the liquid contact part 30 to the body part 20. The liquid contact part 30 comprises an insertion part 323 in which a first screw groove 324 is formed on at least a part of a side surface. The liquid contact part connector 50 comprises: a rotary member 51 in which a second screw groove 511 to be screwed with the first screw groove 324 is formed; and a rotary member holder 52 for rotatably supporting the rotary member 51. The tip end of the insertion part 323 is inserted into the rotary member 51 to rotate the rotary member 51, whereby the liquid contact part 30 is raised and fixed to the body part 20.
09 - Scientific and electric apparatus and instruments
Goods & Services
Apparatus for dispensing liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for dispensing liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for dispensing liquids, pastes and other fluids for food processing or beverage processing; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Apparatus for dropping liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for dropping liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for dropping liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for dropping liquids, pastes and other fluids for food processing or beverage processing; Apparatus for dropping liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and equipment; Apparatus for dropping liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Apparatus for coating liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for coating liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for coating liquids, pastes and other fluids for precision machinery, for the manufacture of automobile parts, for the manufacture of pharmaceuticals; Apparatus for coating liquids, pastes and other fluids for food processing or beverage processing; Apparatus for coating liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for coating liquids, pastes and other fluids for the manufacture of mobile information terminals, and parts and accessories thereof; Apparatus for injecting liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for injecting liquids, pastes and other fluids for the manufacture of circuit boards on whichelectronic components are mounted; Apparatus for injecting liquids, pastes and other fluids, for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for injecting liquids, pastes and other fluids for food processing or beverage processing; Apparatus for injecting liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for injecting liquids, pastes and other fluids for the manufacture of mobile information terminals, together with parts and accessories thereof; Apparatus for filling liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for filling liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for filling liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for filling liquids, pastes and other fluids for food processing or beverage processing; Apparatus for filling liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for filling liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Semiconductor manufacturing apparatus; Machinery and apparatus for food or beverage processing; Plastics processing machinery and apparatus; Painting machinery and apparatus; Pumps; 3D printers. Apparatus for dispensing liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for dripping liquids, pastes and other fluid for research or laboratory use, as well as parts and accessories thereof; Apparatus for coating liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for injecting liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for filling liquids, pastes and other fluids for research or laboratory use, as well as parts and accessories thereof; Laboratory robots; Measuring machinery and apparatus; Electric telecommunications machinery and apparatus; Electronic calculators.
[Problem] To solve the problem of degradation of coating quality that occurs when the width of a concave coating region changes between a start point and an end point of a coating path. [Solution] Provided is a liquid coating method for filling a liquid material into a coating region comprising a gap between an inner wall surface of a concave section (201) of a workpiece (111) and outer peripheries of components (202, 203) disposed in the concave section (201). The liquid coating method comprises: a position acquisition step in which positional coordinates of the components (202, 203) are acquired on the basis of a captured image that includes characteristic portions of the components (202, 203); a coating path setting step in which the coating region and a coating path for coating by a discharge device (102) are set on the basis of the positional coordinates; a coating parameter setting step in which the coating path of the discharge device (102) is divided on the basis of the positional coordinates and a coating quantity is set for each section of the divided coating path; and a coating step in which the discharge device (102) is moved along the coating path to coat the coating region with the liquid material. Also provided is a liquid coating method device for executing the liquid coating method.
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05C 11/00 - Component parts, details or accessories not specifically provided for in groups
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 13/02 - Means for manipulating or holding work, e.g. for separate articles for particular articles
B05D 7/00 - Processes, other than flocking, specially adapted for applying liquids or other fluent materials to particular surfaces or for applying particular liquids or other fluent materials
B05D 7/22 - Processes, other than flocking, specially adapted for applying liquids or other fluent materials to particular surfaces or for applying particular liquids or other fluent materials to internal surfaces, e.g. of tubes
Problem: To provide a technique by which high-precision application can be performed even under conditions where positional misalignment occurs in regularly arranged workpieces.
Problem: To provide a technique by which high-precision application can be performed even under conditions where positional misalignment occurs in regularly arranged workpieces.
Solution: Provided is a liquid-material application method of performing application in a predetermined application pattern on a plurality of workpieces 10, 30 arranged with positional misalignment. The liquid-material application method includes: a horizontal-position information measuring step of measuring horizontal-position information of each of the plurality of workpieces 10, 30 by an imaging device 112; a height information measuring step of measuring height information of each of the plurality of workpieces 10, 30 by a ranging device 113; and an application step of performing application in the application pattern on the plurality of workpieces 10, 30 based on the horizontal-position information measured in the horizontal-position information measuring step and the height information measured in the height information measuring step. Also provided is an apparatus for carrying out the method.
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
9.
DISCHARGE STATE INSPECTION METHOD, DISCHARGE STATE INSPECTION DEVICE, AND DROPLET INSPECTION SYSTEM
Problem: To provide a technology that makes it possible to simultaneously inspect droplet discharge amount and flight state. Solution: A discharge state inspection method, a discharge state inspection device, and a droplet inspection system involve an emission step for emitting droplets from a discharge device (10) toward a weighing scale (30), an event data acquisition step for acquiring event data for the droplets emitted from the discharge device (10) by means of an event sensor (20), a weighing step for acquiring weight value data for the droplets emitted at the emission step from the weighing scale (30), and an inspection step for inspecting the discharge amount of the discharge device (10) on the basis of the event data and the weight value data. At the inspection step, the discharge device (10) is also inspected for flight abnormalities on the basis of the event data.
A discharge device capable of suppressing pressure fluctuation of a compressed gas supplied to a container in which a liquid material is stored. The device includes a storage container in which a liquid material is stored; a discharge port through which the liquid material is discharged; a pressure control valve that adjusts a pressure of a compressed gas supplied from an external compressed gas source to a desired level; a discharge valve that establishes or cuts off communication between the pressure control valve and the storage container; a control device that controls operation of the discharge valve; a first flow line connecting the pressure control valve and the discharge valve; and a second flow line connecting the discharge valve and the storage container. The device further includes a third flow line branched from the first flow line, and a leak mechanism connected to the third flow line.
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
A61B 17/00 - Surgical instruments, devices or methods
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 17/005 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure
B05C 17/01 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure with mechanically or electrically actuated piston or the like
B65D 83/66 - Containers for dispensing liquid or semi-liquid contents by internal gaseous pressure, i.e. aerosol containers comprising propellant with contents and propellant separated initially separated and subsequently mixed, e.g. in a dispensing head
G05D 16/02 - Modifications to reduce the effects of instability, e.g. due to vibrations, friction, abnormal temperature, overloading or imbalance
12.
Tube adapter for liquid precision discharge machine
Provided is an atomization nozzle including: a nozzle body member having a gas ejection path and a gas ejection port; a liquid nozzle member having a liquid ejection path and a liquid ejection port, a tip portion of the liquid nozzle member being inserted through the gas ejection path; a pattern adjustment groove that produces a swirling flow in the gas ejection path; and a spraying pattern adjustment member having a communication flow path and a blocking portion, where a spraying pattern can be changed by switching between a first position in which the pattern adjustment groove and a gas supply flow path are in communication via the communication flow path and a second position in which the pattern adjustment groove is covered by the blocking portion. Also provided are an atomization device, a spraying device, and a spraying method.
B05B 7/10 - Spray pistolsApparatus for discharge producing a swirling discharge
B05B 1/02 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to produce a jet, spray, or other discharge of particular shape or nature, e.g. in single drops
B05B 1/12 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means capable of producing different kinds of discharge, e.g. either jet or spray
B05B 1/34 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to influence the nature of flow of the liquid or other fluent material, e.g. to produce swirl
B05B 7/06 - Spray pistolsApparatus for discharge with one outlet orifice surrounding another approximately in the same plane
B05B 7/24 - Spraying apparatus for discharge of liquids or other fluent materials from two or more sources, e.g. of liquid and air, of powder and gas with means, e.g. a container, for supplying liquid or other fluent material to a discharge device
[Problem] To provide a storage container adapter, a storage container, and a storage device, with which it is possible to confirm that the storage container and the storage container adapter are in a correct connection position, even when a slight dimensional deviation arises due to non-uniform shrinkage during manufacture. [Solution] A storage container adapter 10 is attached to a storage container 20 equipped with a storage tube 21 and a pair of flanges 23, and is configured by comprising: a base 11; a blocking part 13; a pair of lateral members 12; and a pair of flange-holding claws 14. The pair of flange-holding claws 14 are provided with first engagement elements 15. The pair of flanges are provided with second engagement elements 27 that engages with the first engagement elements 15. The blocking part 13 is inserted in an upper opening of the storage container 20, and when rotated in one direction, the flanges 23 enter a gap between the flange-holding claws 14 and the base 11 and are aligned due to engagement between the first engagement elements 15 and the second engagement elements 27.
[Problem] To provide an atomization nozzle, an atomization device, a spraying device, and an atomization method which make it possible to change a spraying pattern with a simple configuration. [Solution] Provided is an atomization nozzle comprising: a nozzle body member 122 which has a gas ejection path 142 and a gas ejection port 143; a liquid nozzle member 121 which has a liquid ejection path 123 and a liquid ejection port 124, and a tip end part of which is inserted in the gas ejection path 142; a pattern adjustment groove 152 which produces a rotational flow in the gas ejection path 142; and a spraying pattern adjustment member 150 which has a communication flow path 151 and a blocking part 153. A spraying pattern can be changed by switching between a first position, at which the pattern adjustment groove 152 and a gas supply flow path 130-132 are put in communication via the communication flow path 151, and a second position, at which the pattern adjustment groove 152 is covered with the blocking part 153. Also provided are an atomization device, a spraying device, and an atomization method.
B05B 1/34 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to influence the nature of flow of the liquid or other fluent material, e.g. to produce swirl
B05B 1/28 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with integral means for shielding the discharged liquid or other fluent material, e.g. to limit area of sprayNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with integral means for catching drips or collecting surplus liquid or other fluent material
B05B 7/06 - Spray pistolsApparatus for discharge with one outlet orifice surrounding another approximately in the same plane
B05B 7/10 - Spray pistolsApparatus for discharge producing a swirling discharge
B05D 1/02 - Processes for applying liquids or other fluent materials performed by spraying
20.
Fluid transfer device, coating device comprising same, and coating method
Problem: To provide a fluid transfer device that can solve an issue of pulsation that occurs when a liquid material is discharged from a nozzle by eccentrically rotating a male-screw-shaped rotor within a stator having a female-screw-shaped insertion hole, an application device including the fluid transfer device, and an application method. Solution: A fluid transfer device 1 includes: an outer cylinder 10; a stator 11 that has a female-screw-shaped insertion hole 12 as a through-hole and is provided on an inner periphery of the outer cylinder; and a male-screw-shaped rotor 20 that is connected to a rotor driving part and eccentrically rotates in contact with an inner periphery of the stator. In the fluid transfer device 1 capable of transferring a fluid in a transport path formed by the stator 11 and the rotor 20, by rotating the rotor 20 inserted through the insertion hole 12, contact force with the rotor 20 at an inlet portion and an outlet portion of the stator 11 is smaller than contact force with the rotor 20 at a central portion of the stator 11.
F04C 15/00 - Component parts, details or accessories of machines, pumps or pumping installations, not provided for in groups
F04C 2/107 - Rotary-piston machines or pumps of intermeshing-engagement type, i.e. with engagement of co-operating members similar to that of toothed gearing of internal-axis type with the outer member having more teeth or tooth-equivalents, e.g. rollers, than the inner member with helical teeth
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
21.
LIQUID MATERIAL DISCHARGE DEVICE AND LIQUID MATERIAL APPLICATION DEVICE
To provide a liquid material discharge device capable of adjusting relative alignment of a valve element with respect to a valve seat by mechanical means. A liquid material discharge device includes: a base member; a valve device mounted on the base member and including a valve element and a valve seat; and a valve driving device configured to move the valve element forward to and backward from the valve seat. The liquid material discharge device further includes an adjustment device 140 configured to adjust relative alignment of the valve element with respect to the valve seat, wherein the adjustment device includes a movable member 141 on which the valve driving device is disposed, and an inclination adjuster 146 configured to adjust an inclination of the movable member. A liquid material application device includes the liquid material discharge device.
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 13/00 - Means for manipulating or holding work, e.g. for separate articles
A liquid material discharge device includes: a valve stem having a valve element provided at a tip portion, and a contact portion; a liquid chamber in which the valve element moves forward and backward; a nozzle communicating with the liquid chamber; a valve seat having a hole via which the liquid chamber and the nozzle communicate with each other; an arm that is in separable contact with the valve stem; and a valve driving device configured to move the valve element forward to and backward from the valve seat by causing the arm to pivot. The liquid material discharge device further includes a coupling device that couples the valve stem with the arm, wherein the coupling device includes a pressing portion that presses the contact portion against the arm.
B05B 1/08 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to produce a jet, spray, or other discharge of particular shape or nature, e.g. in single drops of pulsating nature, e.g. delivering liquid in successive separate quantities
[Problem] To provide a technique by which highly precise coating can be performed even under conditions in which a misalignment occurs between workpieces arranged in a regular way. [Solution] Provided is a liquid material coating method in which a plurality of workpieces 10, 30 disposed to include a misalignment are coated in a prescribed coating pattern, the method comprising a horizontal position information measurement step in which horizontal position information on each of the plurality of workpieces 10, 30 is measured by an imaging device 112; a height information measurement step in which height information on each of the plurality of workpieces 10, 30 is measured by a distance measurement device 113; and a coating step in which the plurality of workpieces 10, 30 are coated in the coating pattern on the basis of the horizontal position information measured in the horizontal position information measurement step and the height information measured in the height information measurement step. Also provided is a device for carrying out said method.
B05C 11/00 - Component parts, details or accessories not specifically provided for in groups
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 3/00 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials
B05D 7/00 - Processes, other than flocking, specially adapted for applying liquids or other fluent materials to particular surfaces or for applying particular liquids or other fluent materials
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
09 - Scientific and electric apparatus and instruments
Goods & Services
Apparatus for dispensing liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for dispensing liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for dispensing liquids, pastes and other fluids for food processing or beverage processing; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Apparatus for coating liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for coating liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for coating liquids, pastes and other fluids for precision machinery, for the manufacture of automobile parts, for the manufacture of pharmaceuticals; Apparatus for coating liquids, pastes and other fluids for food processing or beverage processing; Apparatus for coating liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for coating liquids, pastes and other fluids for the manufacture of mobile information terminals, and parts and accessories thereof; Apparatus for injecting liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for injecting liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for injecting liquids, pastes and other fluids, for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for injecting liquids, pastes and other fluids for food processing or beverage processing; Apparatus for injecting liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for injecting liquids, pastes and other fluids for the manufacture of mobile information terminals, together with parts and accessories thereof; Apparatus for filling liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for filling liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for filling liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for filling liquids, pastes and other fluids for food processing or beverage processing; Apparatus for filling liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for filling liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Pressure regulators (mechanical parts); Electro-pneumatic pressure regulator; Manifold with pressure regulator (mechanical part); Pneumatic circuits with pressure regulators; Mechanical fluid flow control valve; Pressure control valve (mechanical part); Valves (machine elements except those for land vehicles); Pressure reducing valve (machine part); Electric pressure reducing valve; Industrial robots and parts and accessories thereof; Semiconductor manufacturing apparatus; Machinery and apparatus for food or beverage processing; Plastics processing machinery and apparatus; Chemical machinery and apparatus; Painting machinery and apparatus; Pumps; 3D printers; Pressure regulators for vacuums as part of machines. Apparatus for dispensing liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for coating liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for injecting liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for filling liquids, pastes and other fluids for research or laboratory use, as well as parts and accessories thereof; Solenoid valve; Pressure regulator with solenoid valve; Electric direct-acting pressure reducing valve; Manifold with pressure regulator with solenoid valve; Pressure regulator for vacuum with solenoid valve; Pressure regulator with solenoid valve for pressure booster pump; Pressure gauge with pressure switch; Sensor with high-precision digital pressure switch; Flow sensors; Pressure sensors; Pressure sensors for small air pressure; Pressure sensors for general purpose fluids; Laboratory robots; Physical and chemical machinery and apparatus; Measuring machinery and apparatus; Electronic circuits for pressure regulators; Electronic circuits; Electronically applied machinery and apparatus and parts thereof; Electric telecommunications machinery and apparatus; Electronic calculators and peripheral apparatus.
09 - Scientific and electric apparatus and instruments
Goods & Services
Industrial robots; Robots for the manufacture of semiconductors; Robots for the assembly of electronic components; Robots for the manufacture of pharmaceuticals; Robots for the processing of food or beverages; Robots for the manufacture of cosmetics; Liquid or fluid dispensing devices used in the manufacture of semiconductors, precision machinery, automotive components, pharmaceuticals, food processing, cosmetics, and parts and accessories thereof; Liquid metering and dispensing apparatus for the manufacture of semiconductors, precision machinery, automobile parts, pharmaceuticals, food processing and cosmetics, as well as parts and accessories thereof; Apparatus for pouring, applying, adding and injecting liquid, liquid or fluid foodstuffs used for food production; Other machinery and apparatus for food processing or beverage processing; Plastic processing machinery and apparatus and parts and accessories thereof; Chemical machinery and apparatus; Painting machinery and apparatus; Robots for painting operations; Robots for printing, Metering pumps for resins and other liquids; Other pumps. Laboratory robot; Automated dispensing and aspirating apparatus for laboratory use and research; Non-contact droplet dispensing apparatus for proteins, biological samples, special reagents, aqueous solutions, solvents, alcohol solutions, liquid crystals, inks, oils, magnetic fluids, etc. used as physics and chemistry machinery and apparatus; Software for intercommunication of data between industrial robots and dispensing apparatus controller of liquid, liquid or fluid substances or for programming of drawing patterns on workpieces; Data processing programmes; Data processing software; Electronically applied machinery and apparatus and parts thereof; Measuring machinery and apparatus.
09 - Scientific and electric apparatus and instruments
Goods & Services
Industrial robots; Robots for the manufacture of semiconductors: Robots for the assembly of electronic components; Robots for the manufacture of pharmaceuticals; Robots for the processing of food or beverages: Robots for the manufacture of cosmetics; Liquid or fluid dispensing devices used in the manufacture of semiconductors, precision machinery, automotive components, pharmaceuticals, food processing, cosmetics, and parts and accessories thereof; Liquid metering and dispensing apparatus for the manufacture of semiconductors, precision machinery, automobile parts, pharmaceuticals, food processing and cosmetics, as well as parts and accessories thereof; Apparatus for pouring, applying, adding and injecting liquid, liquid or fluid foodstuffs used for food production; Other machinery and apparatus for food processing or beverage processing; Plastic processing machinery and apparatus and parts and accessories thereof; Chemical machinery and apparatus; Painting machinery and apparatus; Robots for painting operations; Robots for printing; Metering pumps for resins and other liquids; Other pumps. Laboratory robot; Automated dispensing and aspirating apparatus for laboratory use and research; Non-contact droplet dispensing apparatus for proteins, biological samples, special reagents, aqueous solutions, solvents, alcohol solutions, liquid crystals, inks, oils, magnetic fluids, etc. used as physics and chemistry machinery and apparatus; Software for intercommunication of data between industrial robots and dispensing apparatus controller of liquid, liquid or fluid substances or for programming of drawing patterns on workpieces; Data processing programmes; Data processing software; Electronically applied machinery and apparatus and parts thereof; Measuring machinery and apparatus.
09 - Scientific and electric apparatus and instruments
Goods & Services
Apparatus for dispensing liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for dispensing liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for dispensing liquids, pastes and other fluids for food processing or beverage processing; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for dispensing liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Apparatus for dropping liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for dropping liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for dropping liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for dropping liquids, pastes and other fluids for food processing or beverage processing; Apparatus for dropping liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and equipment; Apparatus for dropping liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Apparatus for coating liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for coating liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for coating liquids, pastes and other fluids for precision machinery, for the manufacture of automobile parts, for the manufacture of pharmaceuticals; Apparatus for coating liquids, pastes and other fluids for food processing or beverage processing; Apparatus for coating liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for coating liquids, pastes and other fluids for the manufacture of mobile information terminals, and parts and accessories thereof; Apparatus for injecting liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for injecting liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for injecting liquids, pastes and other fluids, for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for injecting liquids, pastes and other fluids for food processing or beverage processing; Apparatus for injecting liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for injecting liquids, pastes and other fluids for the manufacture of mobile information terminals, together with parts and accessories thereof; Apparatus for filling liquids, pastes and other fluids for the manufacture of semiconductors; Apparatus for filling liquids, pastes and other fluids for the manufacture of circuit boards on which electronic components are mounted; Apparatus for filling liquids, pastes and other fluids for precision machinery, for the manufacture of automotive parts, for the manufacture of pharmaceuticals; Apparatus for filling liquids, pastes and other fluids for food processing or beverage processing; Apparatus for filling liquids, pastes and other fluids for the manufacture of flat panel displays, for the manufacture of telecommunications machinery and apparatus; Apparatus for filling liquids, pastes and other fluids for the manufacture of mobile information terminals, as well as components and accessories thereof; Semiconductor manufacturing apparatus; Machinery and apparatus for food or beverage processing; Plastics processing machinery and apparatus; Chemical machinery and apparatus; Painting machinery and apparatus; Pumps; 3D printers. Apparatus for dispensing liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for dripping liquids, pastes and other fluid for research or laboratory use, as well as parts and accessories thereof; Apparatus for coating liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for injecting liquids, pastes and other fluids for research or laboratory use, and parts and accessories thereof; Apparatus for filling liquids, pastes and other fluids for research or laboratory use, as well as parts and accessories thereof; Laboratory robots; Physical and chemical machinery and apparatus; Measuring machinery and apparatus; Electronically applied machinery and apparatus and parts thereof; Electric telecommunications machinery and apparatus; Electronic calculators and peripheral apparatus.
28.
Planar liquid film forming method and planar liquid film forming apparatus
Problem: To provide a technology for forming a planar liquid film having less surface unevenness than ever before using a jet-type discharge device.
Solution: Provided is a planar liquid film forming method of forming a planar liquid film on an application target using a jet-type discharge device having a plurality of discharge ports, and an apparatus for implementing the method. In the method, the plurality of discharge ports are arranged on a straight nozzle arrangement line 140, and are arranged with such a distance from one another that globs of a liquid material having landed on the application target can join together to form a linear liquid film. The method includes: a unitary linear liquid film forming step of forming a unitary linear liquid film 404 by discharging the liquid material such that a plurality of liquid globs simultaneously discharged from the plurality of discharge ports have no contact with one another before landing on the application target, and by letting globs of the liquid material having landed join together on the application target; and a specific planar liquid film forming step of forming a specific planar liquid film 405 from a plurality of unitary linear liquid films 404 by successively executing the unitary linear liquid film forming steps while moving the jet-type discharge device and the application target relative to each other in a direction perpendicular to the nozzle arrangement line 140 so that the plurality of unitary linear liquid films 404 join together.
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
29.
Liquid material application apparatus and liquid material application method
Object: A liquid material application apparatus and a liquid material application method are provided with which a liquid material can be discharged in a predetermined discharge amount per unit time regardless of a relative moving speed in a series of application works.
Solution: The liquid material application apparatus includes a discharge head, a robot moving the discharge head relative to a workpiece, a movement control unit controlling relative movement of the discharge head and the workpiece, and a discharge control unit controlling an operation of discharging a liquid material from a discharge head, wherein the discharge control unit executes, in a switchable manner in accordance with an application program, first mode discharge control of changing a discharge amount of the liquid material, which is discharged from the discharge head per unit time, depending on a relative moving speed between the discharge head and the workpiece, and second mode discharge control of operating the discharge head to discharge the liquid material in a predetermined discharge amount per unit time regardless of the relative moving speed. The liquid material application method is implemented using the liquid material application apparatus.
B05B 12/12 - Arrangements for controlling deliveryArrangements for controlling the spray area responsive to condition of liquid or other fluent material discharged, of ambient medium or of target responsive to conditions of ambient medium or target, e.g. humidity, temperature
B05B 13/04 - Means for supporting workArrangement or mounting of spray headsAdaptation or arrangement of means for feeding work the spray heads being moved during operation
B05D 1/02 - Processes for applying liquids or other fluent materials performed by spraying
30.
FLUID TRANSFER DEVICE, COATING DEVICE COMPRISING SAME, AND COATING METHOD
[Problem] To provide a fluid transfer device, a coating device comprising the same, and a coating method which solve the pulsation issues that occur when a male-threaded rotor is eccentrically rotated inside a stator having a female-threaded through-hole, and a fluid material is discharged from a nozzle. [Solution] A fluid transfer device 1 comprising: an outer tube 10; a stator 11 that has a female-threaded through-hole 12 provided in the inner circumferential surface of the outer tube; and a male-threaded rotor 20 connected to a rotor drive unit and eccentrically rotating and abutting the inner circumferential surface of the stator. The fluid transfer device 1 can transfer fluid in a transport path comprising the stator 11 and the rotor 20, by rotating the rotor 20 inserted into the through-hole 12. The fluid transfer device 1 is configured such that the adhesive force between the rotor 20 and inlet and outlet sections of the stator 11 is smaller than the adhesive force between the rotor 20 and a central section of the stator 11.
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
F04C 2/107 - Rotary-piston machines or pumps of intermeshing-engagement type, i.e. with engagement of co-operating members similar to that of toothed gearing of internal-axis type with the outer member having more teeth or tooth-equivalents, e.g. rollers, than the inner member with helical teeth
F04C 15/00 - Component parts, details or accessories of machines, pumps or pumping installations, not provided for in groups
31.
Planar layered material manufacturing method and apparatus
Continuously manufacturing a planar layered material by repeatedly performing a bank portion forming step of supplying a first liquid material to a first workpiece and forming a bank portion in a frame shape, filled portion forming step of supplying a second liquid material to an inner side of the formed bank portion and forming a filled portion, and a bonding step of bonding the first workpiece with the filled portion formed thereon and a second workpiece to each other, the planar layered material manufacturing method comprises a height measurement step of measuring, by a height measurement device, a height of the filled portion or the bank portion formed on the first workpiece, and a height adjustment step of adjusting a relative height between the filled portion and the bank portion on the basis of the height of the filled portion or the bank portion measured in the height measurement step.
B05D 1/36 - Successively applying liquids or other fluent materials, e.g. without intermediate treatment
B05D 3/06 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials by exposure to radiation
B29C 65/00 - Joining of preformed partsApparatus therefor
G02F 1/13 - Devices or arrangements for the control of the intensity, colour, phase, polarisation or direction of light arriving from an independent light source, e.g. switching, gating or modulatingNon-linear optics for the control of the intensity, phase, polarisation or colour based on liquid crystals, e.g. single liquid crystal display cells
09 - Scientific and electric apparatus and instruments
Goods & Services
Industrial robots; Manufacturing robots; Equipment for manufacturing industrial products for injecting, filling, applying, adding or spraying liquid, fluid or fluid materials; Equipment for manufacturing semiconductors; Equipment for painting operations; Printing equipment; Equipment for processing industrial food and beverages; Equipment for manufacturing electronic components; Equipment for manufacturing LEDs; Equipment for manufacturing automobile parts; Equipment for manufacturing FPD (flat panel display); Medical and pharmaceutical manufacturing equipment; Cosmetics manufacturing equipment; Chemical machinery; Food manufacturing equipment; Mechanical pumps; Plastic processing machinery; Liquid metering dispensing machines for injecting, filling, applying, adding or spraying liquids, fluids or fluid materials used in the manufacture of industrial products. Laboratory robots; Laboratory apparatus for injecting, filling, applying, adding or spraying liquid, liquid or fluid reagents or samples; Automatic liquid dispensing apparatus for experiments and research; Laboratory physical and chemical machines; Dispensing apparatus for proteins, biological samples, special reagents, aqueous solutions, solvents, alcoholic solutions, solvents, liquid crystals, inks, oils, magnetic fluids; Light-emitting diodes.
09 - Scientific and electric apparatus and instruments
Goods & Services
Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; Robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceuticals; Robots for manufacturing cosmetics; Robots for precision machinery manufacturing; Robots for precision machine parts manufacturing; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; Electromechanical machines for chemical industry; Painting machinery; Liquid metering pumps for resins; Pumps [machines]. Laboratory robots; Laboratory apparatus for injecting, filling, applying, adding or spraying liquid, liquid or fluid reagents or samples; Automatic liquid dispensing apparatus for experiments and research; Laboratory physical and chemical apparatus; Dispensing apparatus for proteins, biological samples, special reagents, aqueous solutions, solvents, alcoholic solutions, solvents, liquid crystals, inks, oils, magnetic fluids.
34.
LIQUID MATERIAL DISCHARGE DEVICE AND LIQUID MATERIAL APPLICATION DEVICE
[Problem] To provide a liquid material discharge device, the relative position of which can be adjusted with respect to a valve seat of a valve by a mechanical means. [Solution] Provided is a liquid material discharge device comprising a base member, a valve device that is provided to the base member and comprises a valve body and a valve seat, and a valve drive device that moves the valve body back and forth with respect to the valve seat. The liquid material discharge device further comprises an adjustment device 140 for adjusting the relative position of the valve body with respect to the valve seat, and the adjustment device comprises a movable member 141 in which the valve drive device is located, and an inclination adjusting part 146 for adjusting the inclination of the movable member. Further provided is a liquid material application device provided with the liquid material discharge device.
[Problem] To provide a liquid material discharge device capable of follow the movement of a valve element, without using a strong spring, through the high-speed operation of an actuator. [Solution] A liquid material discharge device comprising: a valve bar 105 having a contact portion and a valve body provided to a tip portion, a liquid chamber in which the valve body moves back and forth, a nozzle that communicates with the liquid chamber, a valve seat 108 having a hole that communicates with the liquid chamber and the nozzle, and arm 121 that separably contacts the valve bar, and a valve drive device that moves the valve body back and forth with respect to the valve seat by rotating the arm 121. The liquid material discharge device is further provided with a coupling device 201 that couples the valve bar 105 to the arm 121, said coupling device 201 being equipped with a pushing portion that pushes the contact portion against the arm 121.
Liquid dispensing, dripping, and coating device used in flat panel display manufacturing and liquid crystal display manufacturing; liquid dispensing device used in semiconductor wafer manufacturing, semiconductor manufacturing, and precision machinery manufacturing; semiconductor manufacturing device and its parts and accessories; precision machinery manufacturing device and its parts and accessories; flat panel display manufacturing device and its parts and accessories; painting machinery.
09 - Scientific and electric apparatus and instruments
16 - Paper, cardboard and goods made from these materials
Goods & Services
Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; Robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment. Seals (stationery), Hologram Seals, Stickers.
09 - Scientific and electric apparatus and instruments
16 - Paper, cardboard and goods made from these materials
Goods & Services
Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; Robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment. Seals (stationery), Hologram Seals, Stickers.
09 - Scientific and electric apparatus and instruments
16 - Paper, cardboard and goods made from these materials
Goods & Services
Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; Robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment. Seals (stationery), Hologram Seals, Stickers.
[Problem] To provide a technique to form a planar liquid film with less unevenness on a surface than in the prior art, using a jet-type dispensing device. [Solution] Provided is a planar liquid film forming method for forming a planar liquid film on a coating target using a jet-type dispensing device with a plurality of dispensing outlets, each of which is arranged on a rectilinear, nozzle arrangement line 140 and which are spaced by a distance such that liquid materials can merge to form a linear liquid film when the liquid materials touch the coating target, the method comprising a linear unit liquid film forming step of dispensing the liquid materials such that a plurality of liquid lumps ejected simultaneously from the plurality of dispensing outlets do not contact each other before touching the coating target and the liquid materials merge when the liquid materials touch the coating target, thereby forming a linear unit liquid film 404, and a specific planar liquid film forming step of continuously repeating the linear unit liquid film forming step while moving the jet-type dispensing device and the coating target relative to each other in a direction perpendicular to the nozzle arrangement line 140, so as to let a plurality of linear unit liquid films 404 merge and form a specific planar liquid film 405. Also provided is an apparatus for conducting the method.
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
43.
Liquid material discharge device, and application device and application method therefor
u in rising of the valve rod by the actuator to be held within a range of 2 to 300 [ms], thus preventing generation of bubbles caused with the rising of the valve rod.
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
A liquid material discharge device includes: a plunger including a piston formed at a rear end a piston chamber in which the piston is disposed and to which pressurized gas is supplied; a pressure supply device that supplies, to the piston chamber, air pressurized in excess of the urging force of the elastic body, or that purges pressurized air out of the piston chamber, the liquid material discharge device discharging the liquid material from the discharge port by causing the plunger to move forward and applying an inertial force to the liquid material; a booster circuit that communicates the pressure supply device and an air source with each other, and the booster circuit includes a first and a second booster system including a booster valve and a pressure reducing valve, and a merging section in which the first booster system and the second booster system merge together.
B05B 9/04 - Spraying apparatus for discharge of liquid or other fluent material without essentially mixing with gas or vapour characterised by means for supplying liquid or other fluent material with pressurised or compressible containerSpraying apparatus for discharge of liquid or other fluent material without essentially mixing with gas or vapour characterised by means for supplying liquid or other fluent material with pump
45.
Character string display device and character string display method
There is provided a character string display device including a character string display unit (10) including a plurality of display elements (110) arrayed two-dimensionally, and a display controller (20) configured to cause the character string display unit (10) to display a predetermined character string pattern by controlling display states of the plurality of display elements (110). In the character string display device, the display controller (20) is configured to cause the character string display unit (10) to display the character string pattern such that there is no blank line between consecutive character patterns of the character string pattern and that, when two display elements corresponding to the respective consecutive character patterns are adjacent to each other, a character pattern part corresponding to one of the adjacent display elements (110) is not displayed. The character string display device and a character string display method are simple and low cost, allow effective use of display space, and achieve higher legibility of a character string.
Problems: To provide a cable unit that can save space for a work space, and a liquid material supply device and an application device including the cable unit. Solution: A cable unit 30 that detachably and electrically connects a discharge head 10 configured to discharge a liquid material with a relative-moving robot 20 configured to carry out relative movement between the discharge head 10 and a workpiece 25, the cable unit having a dispense controller 33 configured to control a discharge operation of the discharge head 10, and a liquid material supply device and an application device including the cable unit.
H01R 13/66 - Structural association with built-in electrical component
B05B 12/16 - Arrangements for controlling deliveryArrangements for controlling the spray area for controlling the spray area
B05B 13/04 - Means for supporting workArrangement or mounting of spray headsAdaptation or arrangement of means for feeding work the spray heads being moved during operation
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
H01R 13/502 - BasesCases composed of different pieces
[Problem] To provide a droplet ejection device and a droplet ejection method with which a liquid material can be continuously delivered to an ejection head when the liquid material is delivered between arbitrary tanks. [Solution] Provided are a droplet ejection device and a droplet ejection method using the droplet ejection device, the droplet ejection device comprising a droplet ejection head; a supply tank that is in communication with a first positive pressure source; a collection tank that is in communication with a first negative pressure source; a replenishment tank that is in communication with the supply tank and the collection tank; an opening/closing valve A that opens and closes a flow passage communicating between the supply tank and the replenishment tank; an opening/closing valve B that opens and closes a flow passage communicating between the collection tank and the replenishment tank; a switching valve that switches communication between the replenishment tank and a second positive pressure source and communication between the replenishment tank and a second negative pressure source; and a control device, wherein the control device has an ejection mode in which a liquid material is ejected from the droplet ejection head, a replenishment mode in which the liquid material is delivered from the replenishment tank to the supply tank while the liquid material is delivered from the supply tank to the collection tank, and a collection mode in which the liquid material is delivered from the collection tank to the replenishment tank while the liquid material is delivered from the supply tank to the collection tank.
Problem: To provide a liquid-material discharge device that enables easier correction of a changed discharge amount during discharge operation than conventional techniques. Solution: A liquid-material discharge device according to the present invention, which includes a discharging member having a rod-shaped body, a liquid chamber wider than the discharging member, in which a tip portion of the discharging member is disposed, a discharge port communicating with the liquid chamber, a liquid feed path that makes the liquid chamber communicate with a liquid-material reservoir, and a driving device configured to drive the discharging member, includes a discharge amount adjustment member positioned at the liquid feed path, and a member position adjustment mechanism configured to shift a position of the discharge amount adjustment member within the liquid feed path, the discharge amount adjustment member being kept from interrupting communication between the liquid chamber and the liquid-material reservoir.
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
A61M 5/315 - PistonsPiston-rodsGuiding, blocking or restricting the movement of the rodAppliances on the rod for facilitating dosing
09 - Scientific and electric apparatus and instruments
Goods & Services
Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; Laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment.
09 - Scientific and electric apparatus and instruments
Goods & Services
Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; Electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; Laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment.
09 - Scientific and electric apparatus and instruments
Goods & Services
Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; Laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment.
09 - Scientific and electric apparatus and instruments
Goods & Services
Industrial robots; Robots for semiconductor manufacturing; Robots for painting; Robots for printing; Robots for food processing; robots for beverage processing; Robots for manufacturing electronic components; Robots for manufacturing pharmaceutical; Robots for manufacturing cosmetics; Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; electromechanical machines for chemical industry; painting machinery; Liquid metering pumps for resins; pumps [machines]. laboratory robots; Dosage dispensers; Laboratory instruments, namely non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment.
53.
Liquid material application apparatus and liquid material application method
Object: A liquid material application apparatus and a liquid material application method are provided with which a liquid material can be discharged in a predetermined discharge amount per unit time regardless of a relative moving speed in a series of application works.
Solution: The liquid material application apparatus includes a discharge head, a robot moving the discharge head relative to a workpiece, a movement control unit controlling relative movement of the discharge head and the workpiece, and a discharge control unit controlling an operation of discharging a liquid material from a discharge head, wherein the discharge control unit executes, in a switchable manner in accordance with an application program, first mode discharge control of changing a discharge amount of the liquid material, which is discharged from the discharge head per unit time, depending on a relative moving speed between the discharge head and the workpiece, and second mode discharge control of operating the discharge head to discharge the liquid material in a predetermined discharge amount per unit time regardless of the relative moving speed. The liquid material application method is implemented using the liquid material application apparatus.
B05B 12/12 - Arrangements for controlling deliveryArrangements for controlling the spray area responsive to condition of liquid or other fluent material discharged, of ambient medium or of target responsive to conditions of ambient medium or target, e.g. humidity, temperature
B05B 13/04 - Means for supporting workArrangement or mounting of spray headsAdaptation or arrangement of means for feeding work the spray heads being moved during operation
B05D 1/02 - Processes for applying liquids or other fluent materials performed by spraying
54.
LAYERED SURFACE MATERIAL MANUFACTURING METHOD AND DEVICE
Problem: To provide a layered surface material manufacturing method and device that can minimize a difference in height between a bank section and a filled section, said difference occurring over time. Solution: A layered surface material manufacturing method and a device therefor, said method being a layered surface material manufacturing method for continuously manufacturing a layered surface material by repeatedly performing a bank section forming step in which a first liquid material is supplied to a first workpiece 71 to form a bank section 72 in a frame shape, a filled section forming step in which a second liquid material is supplied inside the formed bank section to form a filled section 73, and an adhering step in which the first workpiece 71 that has the filled section 73 formed thereon and a second workpiece 72 are adhered to one another, wherein said layered surface material manufacturing method comprises a height measurement step in which a height measurement device is used to measure the height of the filled section 73 or the bank section 72 that is formed on the first workpiece 71, and a height adjustment step in which the relative height of the filled section 73 and the bank section 72 is adjusted on the basis of the height of the filled section 73 or the bank section 72 that was measured in the height measurement step.
B05D 1/36 - Successively applying liquids or other fluent materials, e.g. without intermediate treatment
B05D 3/00 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials
B05D 7/24 - Processes, other than flocking, specially adapted for applying liquids or other fluent materials to particular surfaces or for applying particular liquids or other fluent materials for applying particular liquids or other fluent materials
G02F 1/13 - Devices or arrangements for the control of the intensity, colour, phase, polarisation or direction of light arriving from an independent light source, e.g. switching, gating or modulatingNon-linear optics for the control of the intensity, phase, polarisation or colour based on liquid crystals, e.g. single liquid crystal display cells
A liquid material discharge device and method capable of remedying the problem of liquid leakage caused by a closing failure that may occur in a negative pressure environment. The liquid material discharge device is used in a negative pressure space, and includes a storage container, a compressed-gas supply source pressurizing the storage container, a nozzle having a discharge flow path, a reciprocating valve rod, an actuator driving the valve rod, a valve seat having a communication hole that is communicated with the discharge flow path, and a discharge control device controlling the actuator to open and close the communication hole by a tip of the valve rod. The device can further include a resin film disposed at a lower end of the valve rod, or a resin film disposed on an upper surface of the valve seat and having a through-hole communicating with the communication hole.
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
An application device and an application method are disclosed which enable a three-dimensional applying and drawing process to be performed without provision of any rotary mechanism on a discharge head. The application device comprises a discharge head that includes a discharge device having a discharge port opened in a Z direction, a stage that holds a workpiece, a set of XYZ relatively-moving devices that moves the discharge head and the stage relative to each other, an R-axis rotation device that rotates the stage about an R-axis parallel to an XY plane, a P-axis rotation device that rotates the stage about a P-axis parallel to the XY plane, the P-axis extending in a different direction from the R-axis, a control device, and a stand, wherein the P-axis rotation device is disposed under the R-axis rotation device, and the P-axis rotation device rotates the stage and the R-axis rotation device together.
B41J 25/00 - Actions or mechanisms not otherwise provided for
B41J 25/304 - Bodily-movable mechanisms for print heads or carriages movable towards or from paper surface
B41J 11/20 - Platen adjustments for varying the strength of impression, for a varying number of papers, for wear or for alignment
B41J 3/407 - Typewriters or selective printing or marking mechanisms characterised by the purpose for which they are constructed for marking on special material
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 13/02 - Means for manipulating or holding work, e.g. for separate articles for particular articles
57.
Discharge device for liquid material containing solid particles, discharge method and coating device
Problem: To supply a device and a method for accurately discharging a fixed amount of a liquid, the liquid containing solid particles, in a state that the solid particles are dispersed in the liquid material. Solution: A discharge device for a liquid material containing solid particles includes a first reservoir, a first air pressure supply pipe, a metering portion having a metering hole, a plunger moving back and forth in the metering hole, a nozzle, a switching valve having a first position and a second position, a plunger driver, and a switching valve driver. The discharge device further includes a second reservoir, a second air pressure supply pipe, a branch portion provided in an upper portion of the metering hole and having a branch flow path, and an opening/closing mechanism that establishes or cuts off communication between the second reservoir and the metering hole. In the discharge device, the liquid material inside the first reservoir can be transferred to the second reservoir, and the liquid material inside the second reservoir can be transferred to the first reservoir. A discharge method is carried out using the discharge device.
B01F 3/08 - Mixing, e.g. dispersing, emulsifying, according to the phases to be mixed liquids with liquids; Emulsifying
B01J 4/02 - Feed devicesFeed or outlet control devices for feeding measured quantities of reagents
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B01F 11/00 - Mixers with shaking, oscillating, or vibrating mechanisms
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
A discharge device includes a nozzle (50) having a plurality of discharge ports, a liquid chamber (26) communicating with the plurality of discharge ports via a plurality of discharge flow paths, and a plunger rod (18) that reciprocates in the liquid chamber and is narrower than the liquid chamber. The plurality of discharge ports (62) is arranged un a straight nozzle arrangement line, and arranged with such a distance therebetween that globs of a liquid material having landed on an application target join together to form an application line. A plurality of liquid globs having been discharged from the plurality of discharge ports (62) have no contact with each other before landing on the application target, and letting the globs of the liquid material having landed join together on the application target.
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05D 5/06 - Processes for applying liquids or other fluent materials to surfaces to obtain special surface effects, finishes or structures to obtain multicolour or other optical effects
G02F 1/1335 - Structural association of cells with optical devices, e.g. polarisers or reflectors
A liquid material filling device and method are provided which are intended to prevent air bubbles from remaining along an entire length of a flow passage extending from a liquid material reservoir (51) to a discharge port (53). The liquid material filling device includes a chamber (10) of an airtight structure, a pressure regulator (70) for regulating pressure in the chamber (10), and a control device (100). The liquid material is filled as follows. A negative pressure supply source (71) is communicated with a chamber communication pipe (90) and with a discharge device communication pipe (91) to reduce the pressure in the chamber (10) and pressure in an upper space of the reservoir (51) to a vacuum or a low pressure level close to a vacuum, and a resulted low-pressure state is maintained for a certain time to expel out air bubbles in the liquid material.
A laser soldering technique prevents generation of scorching of a substrate or heat-susceptible components in the surroundings, residues, etc. A method includes adjusting a height of the laser soldering device 1 to a position at which laser light has a preset irradiation diameter D1 larger than a diameter of a solder droplet S, irradiating the solder droplet S with the laser light to heat the solder droplet S to a temperature at which a flux solvent component volatilizes and a solder powder does not melt; adjusting the height of the laser soldering device to a position at which the laser light has a preset irradiation diameter D2 smaller than the diameter of the solder droplet S, and irradiating the solder droplet S with the laser light to heat the solder droplet S to a temperature at which the solder powder melts, and performing soldering.
H05K 3/34 - Assembling printed circuits with electric components, e.g. with resistor electrically connecting electric components or wires to printed circuits by soldering
G06F 30/367 - Design verification, e.g. using simulation, simulation program with integrated circuit emphasis [SPICE], direct methods or relaxation methods
61.
Liquid discharge device, application device with said discharge device, and application method
A liquid discharge device to discharge a liquid material stirred near a metering chamber, an application device and an application method using the application device. A liquid discharge device includes a storage unit including a storage container storing a liquid material, and a stirrer drive mechanism; a discharge unit including a metering chamber to be filled with the liquid material, a plunger sliding in close contact with an inner peripheral surface of the metering chamber, a nozzle in communication with the metering chamber, and a switching valve between a first position at which the storage container and the metering chamber are communicated with each other, and a second position at which the metering chamber and the nozzle are communicated; and a connection flow path through which the storage container and the metering chamber are communicated, The stirrer drive mechanism is separable from the storage unit.
B05C 9/10 - Apparatus or plant for applying liquid or other fluent material to surfaces by means not covered by groups , or in which the means of applying the liquid or other fluent material is not important for applying liquid or other fluent material and performing an auxiliary operation the auxiliary operation being performed before the application
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
62.
Liquid material discharge device with temperature control device, application device for same, and application method
Application of liquid material is carried out without causing variations in discharge amount even on a stage under heating while temperature of a liquid material is adjusted by a temperature control device. A liquid material discharge device includes a discharge port, a liquid chamber in communication with the discharge port, and a temperature control device adjusting a temperature of the liquid chamber, the liquid material discharge device discharging the liquid material from the discharge port while a workpiece and the discharge port are moved relative to each other. The liquid material discharge device also includes a coolant flow path through which a coolant for heat exchange with the temperature control device flows, and a discharge control device controlling a discharge operation. An application device including the liquid material discharge device and an application method using the application device are also provided.
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05B 12/10 - Arrangements for controlling deliveryArrangements for controlling the spray area responsive to condition of liquid or other fluent material discharged, of ambient medium or of target responsive to temperature or viscosity of liquid or other fluent material discharged
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05B 1/14 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with multiple outlet openingsNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with strainers in or outside the outlet opening
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05D 3/00 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials
63.
Lid for liquid material storage container, and liquid material storage container
A lid for a liquid material storage container solves problems of uplift and breakage of the lid, and ensures high efficiency in attachment and detachment operations. The lid includes an upper plate portion covering a flange and a large-diameter opening of a storage cylinder; a plug portion extending downward from a central region of the upper plate portion and plugging the large-diameter opening of the storage cylinder; a pair of first lateral portions coming into contact with lateral surfaces of a pair of short sides of the flange when the lid is closed; a pair of claw portions extending from the pair of first lateral portions toward the plug portion and coming into contact with lower surfaces of the pair of short sides of the flange when the lid is closed; and a push-up operating portion formed in at least one of the pair of first lateral portions.
This character string display device is provided with: a character string display unit (10) provided with a plurality of display elements (110) arrayed in a two-dimensional shape; and a display control unit (20) which displays, on the character string display unit (10), a prescribed character string pattern by controlling a display state of the plurality of display elements (110), wherein the display control unit (20) does not provide a blank space column between consecutive character patterns in the character string pattern, and, when two display elements respectively corresponding to the consecutive character patterns are adjacent to each other, displays, on the character string display unit (10), a characters string pattern in which a character pattern part corresponding to one of the adjacent display elements (110) is not caused to be displayed. Accordingly, the present invention easily and inexpensively provides a character string display device and a character string display method in which a display space can be validly utilized and character readability is high.
G09G 5/32 - Control arrangements or circuits for visual indicators common to cathode-ray tube indicators and other visual indicators characterised by the display of individual characters or indicia using display control signals derived from coded signals representing the characters or indicia with a character-code memory with means for controlling the display position
G09G 5/00 - Control arrangements or circuits for visual indicators common to cathode-ray tube indicators and other visual indicators
09 - Scientific and electric apparatus and instruments
Goods & Services
Liquid dispensing device used for semiconductor manufacturing, precision machinery, automotive parts manufacturing, pharmaceutical manufacturing, and food processing; Equipment for injecting, applying, adding and spraying liquid, liquid or fluid foods used for food production; Plastic processing machinery and equipment and its parts and accessories; Chemical machinery and equipment; painting machinery; Liquid metering pumps for resins; pumps [machines]. Dosage dispensers; Non-contact droplet ejection device namely for proteins, biological samples, special reagents, aqueous solutions, solvents, alcohol solutions, solvents, liquid crystals, inks, oils and magnetic fluids; Electronic testing equipment; Electronic apparatus for testing the sterility of medical equipment; Measuring equipment.
67.
Seal structure, and device with said seal structure
F16K 41/04 - Spindle sealings with stuffing-box with at least one ring of rubber or like material between spindle and housing
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
68.
Liquid material application apparatus and liquid material application method
A liquid material is discharged in a constant amount per unit time regardless of a relative moving speed. The liquid material application apparatus includes a discharge head, a robot moving the discharge head relative to a workpiece, a movement control unit controlling relative movement of the discharge head and the workpiece, and a discharge control unit controlling an operation of discharging a liquid material from a discharge head, wherein the discharge control unit executes, in a switchable manner in accordance with an application program, first mode discharge control of changing a discharge amount of the liquid material, which is discharged from the discharge head per unit time, depending on a relative moving speed between the discharge head and the workpiece, and second mode discharge control of operating the discharge head to discharge the liquid material in a predetermined discharge amount per unit time regardless of the relative moving speed.
B05B 12/12 - Arrangements for controlling deliveryArrangements for controlling the spray area responsive to condition of liquid or other fluent material discharged, of ambient medium or of target responsive to conditions of ambient medium or target, e.g. humidity, temperature
B05B 13/04 - Means for supporting workArrangement or mounting of spray headsAdaptation or arrangement of means for feeding work the spray heads being moved during operation
B05D 1/02 - Processes for applying liquids or other fluent materials performed by spraying
A liquid material discharge device includes a discharge member made of a rod-shaped body, a liquid chamber which is wider than the discharge member and in which a tip portion of the discharge member is disposed, a discharge port in communication with the liquid chamber, a liquid feed path establishing communication between the liquid chamber and a liquid material storage container, a drive device driving the discharge member, and a main body. The liquid material discharge device further includes an elongate insert member that is removably inserted into the liquid feed path without cutting the communication between the liquid chamber and the liquid material storage container.
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B41J 2/045 - Ink jet characterised by the jet generation process generating single droplets or particles on demand by pressure, e.g. electromechanical transducers
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
Problem: To provide a liquid material ejecting apparatus in which a discharge amount that has changed during a discharge operation can be more easily corrected than in the prior art. Solution: A liquid material ejecting apparatus according to the present invention is provided with: an ejection member formed in a bar shape; a liquid chamber which has a greater width than the ejection member and in which a distal end of the ejection member is disposed; an ejection hole that communicates with the liquid chamber; a liquid feeding path that communicates the liquid chamber and a liquid material storage container; and a driving device that drives the ejection member, and is also provided with: a discharged amount adjustment member that is positioned in the liquid feeding path but does not block the communication between the liquid chamber and the liquid material storage container; and a member position adjustment member that moves the position of the discharged amount adjustment member inside the liquid feeding path.
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
71.
DISCHARGE HEAD WITH PICKUP MEMBER, AND LIQUID-MATERIAL DISCHARGE DEVICE
The purpose of the present invention is to provide a handy-type device capable of performing an application work and a placement work with one device when attaching parts to a workpiece. Provided are a handy-type liquid-material discharge head, comprising: a nozzle; a liquid storing portion; and a pickup member arranged in line with the nozzle, for holding a subject, and a liquid-material discharge device comprising the liquid-material discharge head. Preferably, the pickup member holds the subject by generating a negative pressure on its distal end portion.
An apparatus and a method performing work free from variations among a plurality of work heads having individual differences. A working apparatus includes a number n (a natural number 2 or greater) of work heads, a stage retaining a work object, drive devices moving the stage and the work heads relative to each other in three directions, a work amount measurement device measuring a work amount of each work head, and a control device, wherein the first-direction drive device enables the number n of work heads to be independently moved in a first direction, and the second-direction drive device includes a second-direction main drive device moving the number n of work heads simultaneously in a second direction, and a second-direction auxiliary drive device moving n−1 work heads among the number n of work heads independently in the second direction. A working method is carried out using the working apparatus.
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
H01L 21/67 - Apparatus specially adapted for handling semiconductor or electric solid state devices during manufacture or treatment thereofApparatus specially adapted for handling wafers during manufacture or treatment of semiconductor or electric solid state devices or components
B05C 11/00 - Component parts, details or accessories not specifically provided for in groups
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
H01L 21/68 - Apparatus specially adapted for handling semiconductor or electric solid state devices during manufacture or treatment thereofApparatus specially adapted for handling wafers during manufacture or treatment of semiconductor or electric solid state devices or components for positioning, orientation or alignment
G01C 3/00 - Measuring distances in line of sightOptical rangefinders
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
G01B 11/14 - Measuring arrangements characterised by the use of optical techniques for measuring distance or clearance between spaced objects or spaced apertures
73.
DROPLET EJECTION DEVICE AND DROPLET EJECTION METHOD
[Problem] To provide a droplet ejection device and a droplet ejection method, in which a liquid material can be continuously delivered to an ejection head when delivering the liquid material between arbitrary tanks. [Solution] Provided are a droplet ejection device and a droplet ejection method using said device, the droplet ejection device comprising: a droplet ejecting head; a supply tank communicating with a first pressure source; a recovery tank communicating with a first negative pressure source; a replenishment tank communicating with the supply tank and the recovery tank; an opening/closing valve A for opening and closing a fluid passage communicating the supply tank and the replenishment tank; an opening/closing valve B for opening and closing a fluid passage communicating the recovery tank and the replenishment tank; a switching valve for switching between communication of the replenishment tank and a second pressure source and communication of the replenishment tank and a second negative pressure source; and a control device, wherein the control device has: an ejection mode in which a liquid material is ejected from the droplet ejection head; a replenishment mode in which the liquid material is delivered from the replenishment tank to the supply tank while the liquid material is delivered from the supply tank to the recovery tank; and a recovery mode in which the liquid material is delivered from the recovery tank to the replenishment tank while the liquid material is delivered from the supply tank to the recovery tank.
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05D 3/00 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials
[Problem] To provide an application device and an application method that allow three-dimensional application and drawing without a rotary mechanism being provided on a delivery head. [Solution] An application device comprising a delivery head that comprises a delivery device having a delivery opening opened in the Z direction, a stage that holds a workpiece, an XYZ relative motion device that moves the delivery head and the stage relative to each other, an R-axis rotation device that rotates the stage about an R-axis parallel to the XY plane, a P-axis rotation device that rotates the stage about a P-axis in a different direction than the R-axis and parallel to the XY plane, a control device, and a stand, wherein the P-axis rotation device is disposed under the R-axis rotation device, and the P-axis rotation device rotates the stage and the R-axis rotation device. An application method using same device.
A device and a method for accurately discharging a fixed amount of a liquid, the liquid containing solid particles, in a state that the solid particles are dispersed in the liquid material. The device includes a first reservoir, a first air pressure supply pipe, a metering portion having a metering hole, a plunger moving back and forth in the metering hole, a nozzle, a switching valve having a first position and a second position, a plunger driver, and a switching valve driver. The discharge device further includes a second reservoir, a second air pressure supply pipe, a branch portion provided in an upper portion of the metering hole and having a branch flow path, and an opening/closing mechanism that establishes or cuts off communication between the second reservoir and the metering hole. A discharge method is carried out using the discharge device.
B01F 3/08 - Mixing, e.g. dispersing, emulsifying, according to the phases to be mixed liquids with liquids; Emulsifying
B01J 4/02 - Feed devicesFeed or outlet control devices for feeding measured quantities of reagents
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B01F 5/00 - Flow mixers; Mixers for falling materials, e.g. solid particles
A liquid material ejection device in which a plunger is efficiently accelerated. The device includes a liquid chamber communicating with an ejection port and being supplied with a liquid material, a plunger including a tip portion having a smaller diameter than the liquid chamber and is moved in the liquid chamber, an elastic member urging the plunger upward, an arm disposed in a state extending in a substantially horizontal direction, an arm driver serving as a driving source to operate the arm, and a base member on which the arm driver is disposed. The device further includes a rocking mechanism unit connected to the arm driver and rockingly supporting the arm, the arm driver includes a plurality of actuators, the arm includes a pressing portion pressing the plunger downward, the plunger is pressed by the pressing portion, and the plunger is linearly reciprocated with rocking motion of the arm.
B05B 17/06 - Apparatus for spraying or atomising liquids or other fluent materials, not covered by any other group of this subclass operating with special methods using ultrasonic vibrations
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
F04B 17/00 - Pumps characterised by combination with, or adaptation to, specific driving engines or motors
F04B 9/00 - Piston machines or pumps characterised by the driving or driven means to or from their working members
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
F04B 9/04 - Piston machines or pumps characterised by the driving or driven means to or from their working members the means being mechanical the means being cams, eccentrics or pin-and-slot mechanisms
77.
LIQUID MATERIAL APPLICATION METHOD AND DEVICE FOR IMPLEMENTING SAID METHOD
[Problem] Provided is a technique by which it is possible to perform cross-sectional line-drawing application having a small height ratio relative to width using a jet-type discharge device. [Solution] A discharge device comprises: a nozzle (50) having a plurality of discharge ports; a liquid chamber (26) that is in communication with the plurality of discharge ports via a plurality of discharge flow paths; and a plunger rod (18) that reciprocates inside the liquid chamber, the plunger rod being narrower in width than the liquid chamber. The plurality of discharge ports (62) are disposed on a nozzle disposition line, which is a straight line, and are disposed at a distance at which a liquid material deposited on an application object joins together to form an application line. While the discharge device and the application object are moved in a relative fashion in a direction orthogonal to the nozzle disposition line, the liquid material is continuously discharged in a manner in which a plurality of liquid masses discharged from the plurality of discharge ports (62) do not come into contact with one another prior to deposition on the application object, and the liquid material that has deposited on the application object is joined, thereby forming an application line that is orthogonal to the nozzle disposition line.
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 3/00 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials
B05D 7/00 - Processes, other than flocking, specially adapted for applying liquids or other fluent materials to particular surfaces or for applying particular liquids or other fluent materials
G02F 1/13 - Devices or arrangements for the control of the intensity, colour, phase, polarisation or direction of light arriving from an independent light source, e.g. switching, gating or modulatingNon-linear optics for the control of the intensity, phase, polarisation or colour based on liquid crystals, e.g. single liquid crystal display cells
[Problem] To provide a liquid material coating device and a liquid material coating method which are capable of discharging, during a series of coating operations, a predetermined discharge amount of a liquid material per unit time irrespective of a relative moving speed. [Solution] Provided are a liquid material coating device and an coating method using said device, the liquid material coating device being provided with: a discharging head; a robot which moves the discharging head relative to a workpiece; a movement control unit which controls the relative movement of the discharging head and the workpiece; and a discharge control unit which controls an operation of discharging the liquid material from the discharging head, wherein the discharge control unit is capable of switching, on the basis of a coating program, between a first mode discharge control in which a discharge amount per unit time at which the discharging head discharges the liquid material is changed on the basis of the relative moving speed of the discharging head and the workpiece, and a second mode discharge control in which liquid material is discharged at a discharge amount per unit time, the discharge amount being predetermined for the discharging head, irrespective of the relative moving speed.
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
[Problem] To provide a laser soldering technique with which it is possible to prevent scorching, residue, etc., in a substrate or in surrounding heat-sensitive components. [Solution] Provided is an automatic soldering method in which there is used an automatic soldering device 40 comprising a laser soldering device 1 and a Z-axis drive device 43, wherein the method is characterized by including: a step for causing the height of the laser soldering device 1 to match a position where the irradiation diameter D1 of laser light reaches a pre-set size that is greater than the diameter of a solder drop S; a step for irradiating the solder drop S with the laser light to volatilize a flux solvent component and heating at a temperature at which a solder powder does not melt; a step for causing the height of the laser soldering device to match a position where the irradiation diameter D2 of the laser light reaches a pre-set size that is less than the diameter of the solder drop S; and a step for irradiating the solder drop S with the laser light, heating at a temperature at which the solder powder melts, and performing soldering. Also provided is a device for said automatic soldering method.
H05K 3/34 - Assembling printed circuits with electric components, e.g. with resistor electrically connecting electric components or wires to printed circuits by soldering
80.
CABLE UNIT, AND LIQUID MATERIAL SUPPLY DEVICE AND APPLICATION DEVICE IN WHICH SAID CABLE UNIT IS USED
[Problem] To provide a cable unit capable of saving space in a workspace, and a liquid material supply device and an application device in which said cable unit is used. [Solution] A cable unit 30 that electrically connects in a detachable manner, a discharge head 10 that discharges a liquid material, and a relative movement robot 20 that moves the discharge head 10 and a workpiece 25 in a relative manner, wherein said cable unit has a dispense controller 33 that controls a discharge operation for the discharge head 10, and a liquid material supply device and application device in which said cable unit is used.
[Problem] To provide a lid for a liquid material storage container having good workability of attachment and detachment thereof, and whereby the problems of failure and uplift of the lid for a liquid material storage container are overcome, and a liquid material storage container. [Solution] A lid for a liquid material storage container, and a liquid material storage container, the lid for a liquid material storage container characterized by being provided with: an upper plate part for covering a flange part and a large-diameter opening; a stopper part for blocking a large-diameter opening of a storage cylinder, the stopper part extending downward from a center part of the upper plate part; a pair of first side parts for coming in contact with side surfaces of a pair of short sides of the flange part when the lid is closed; a pair of hook parts for coming in contact with bottom surfaces of the pair of short sides of the flange part when the lid is closed, the hook parts extending toward the stopper part from the pair of first side parts; and a push-up operation part formed in at least one of the pair of first side parts; the length of the hook parts being less than the distance between the hook parts and the upper plate part.
A nozzle capable of removing a surplus liquid material, which is adhered to outer surfaces of the nozzle and which affects a discharge operation, without undergoing a special process, and a liquid material discharge device provided with the nozzle. The nozzle (1) includes a body (2) having a liquid inflow space, and a discharge tube (4) communicating with the liquid inflow space and extending downwards from the body (2). A liquid removing member (16) is disposed at a lower end of the body (2) in a state laterally surrounding the discharge tube (4), and the liquid removing member (16) includes a groove-like space (15) that is formed between adjacent to of plural surrounding surfaces (10), and that generates capillary force acting in a direction laterally away from the discharge tube (4).
B05B 1/28 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with integral means for shielding the discharged liquid or other fluent material, e.g. to limit area of sprayNozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means with integral means for catching drips or collecting surplus liquid or other fluent material
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05B 15/50 - Arrangements for cleaningArrangements for preventing deposits, drying-out or blockageArrangements for detecting improper discharge caused by the presence of foreign matter
B05B 1/08 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to produce a jet, spray, or other discharge of particular shape or nature, e.g. in single drops of pulsating nature, e.g. delivering liquid in successive separate quantities
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
In a liquid material discharge apparatus, attachment/detachment of a liquid contact unit (2) and a main body unit (15) is more safely and easily performed. The apparatus includes the liquid contact unit (2) provided with a housing (6) including a nozzle (3) and a discharge member (5), and with a storage container (4) fluidly connected to the housing with the aid of a mounting member, and a main body unit provided with a holder (19) to which the housing is detachably attached, and with a drive unit (16) for actuating the discharge member that is detachably coupled to the drive unit, the apparatus further includes a movable member (12) being movable in an up-down direction along the housing while the movable member remains attached to the housing, and the discharge member and the drive unit are attachable with movement of the movable member in the up-down direction.
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 11/11 - Vats or other containers for liquids or other fluent materials
B05C 13/00 - Means for manipulating or holding work, e.g. for separate articles
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
84.
SEAL STRUCTURE, AND DEVICE WITH SAID SEAL STRUCTURE
[Problem] To provide a seal structure in which a needle and a seal do not slide and which is easily mountable and removable, and also to provide a device provided with the seal structure. [Solution] Provided are a seal, a seal structure which is provided with the seal, and a device which is provided with the seal structure. The seal allows the needle of a valve device to be passed therethrough, the valve device comprising a fluid chamber which has an outflow hole and an inflow hole, and also comprising the needle having a front end reciprocating within the fluid chamber. The seal comprises: a body section consisting of an elastic body and having formed therein a needle insertion hole through which the needle is passed; and a flange section consisting of an elastic body and extended annularly and radially outward from the body section. The seal is characterized in that the diameter (D3) of the opening at one end of the needle insertion hole is smaller than the diameter (D2) of the opening at the other end of the needle insertion hole.
F16J 15/18 - Sealings between relatively-moving surfaces with stuffing-boxes for elastic or plastic packings
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
F16J 15/24 - Sealings between relatively-moving surfaces with stuffing-boxes for elastic or plastic packings with radially or tangentially compressed packing
F16J 15/48 - Sealings with packing ring expanded or pressed into place by fluid pressure, e.g. inflatable packings influenced by the pressure within the member to be sealed
F16K 1/32 - Lift valves, i.e. cut-off apparatus with closure members having at least a component of their opening and closing motion perpendicular to the closing faces Details
85.
Discharge device and discharge method for liquid material containing solid particles, and coating device
A device and a method of discharging a liquid in a state of solid particles being dispersed in the liquid with a minimum additional structure for dispersing the solid particles. A discharge device and an application device each include a storage container; a measuring unit having a measuring hole; a plunger disposed in the measuring hole; a nozzle; a selector valve having a first position at which the storage container and the measuring unit are communicated, and a second position at which the measuring unit and the nozzle are communicated; a plunger drive device; a selector valve drive device; and a discharge control device, wherein a discharge control program includes a filling stepinto the measuring hole; an ejection step; an inflow step causing the liquid material in the measuring hole to flow into the storage container; a discharge step; and a stirring step.
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 7/24 - Processes, other than flocking, specially adapted for applying liquids or other fluent materials to particular surfaces or for applying particular liquids or other fluent materials for applying particular liquids or other fluent materials
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B01F 11/00 - Mixers with shaking, oscillating, or vibrating mechanisms
B05C 17/005 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure
The liquid material ejector has a liquid material supply port through which the liquid material is supplied, a nozzle for ejecting the liquid material, a valve block having a metering bore to be filled with the ejected liquid material and a liquid material supply channel communicating with the liquid material supply port, a selector valve having a first channel for allowing communication between the metering bore and the liquid material supply channel and a second channel for allowing communication between the metering bore and the nozzle, a plunger advancing and retracting in the metering bore, a plunger driving section for driving the plunger, a valve driving section for driving the selector valve, and a transmission section for transmitting driving power from the valve driving section to the selector valve. The plunger driving section, the valve driving section, and the valve block are arranged successively in the longitudinal direction.
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
A discharge device capable of suppressing pressure fluctuation of a compressed gas supplied to a container in which a liquid material is stored. The device includes a storage container in which a liquid material is stored; a discharge port through which the liquid material is discharged; a pressure control valve that adjusts a pressure of a compressed gas supplied from an external compressed gas source to a desired level; a discharge valve that establishes or cuts off communication between the pressure control valve and the storage container; a control device that controls operation of the discharge valve; a first flow line connecting the pressure control valve and the discharge valve; and a second flow line connecting the discharge valve and the storage container. The device further includes a third flow line branched from the first flow line, and a leak mechanism connected to the third flow line.
B05C 17/01 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure with mechanically or electrically actuated piston or the like
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 17/005 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure
B65D 83/66 - Containers for dispensing liquid or semi-liquid contents by internal gaseous pressure, i.e. aerosol containers comprising propellant with contents and propellant separated initially separated and subsequently mixed, e.g. in a dispensing head
A61B 17/00 - Surgical instruments, devices or methods
G05D 16/02 - Modifications to reduce the effects of instability, e.g. due to vibrations, friction, abnormal temperature, overloading or imbalance
88.
LIQUID DISCHARGE DEVICE, APPLICATION DEVICE WITH SAID DISCHARGE DEVICE, AND APPLICATION METHOD
[Problem] To provide: a liquid discharge device capable of discharging a liquid material stirred near a measurement chamber; an application device provided with the discharge device; and an application method. [Solution] Provided is a liquid discharge device comprising a stirring mechanism, wherein the liquid discharge device is provided with: a storage unit provided with a storage container for storing a liquid material, and with a stirrer drive mechanism for driving a stirrer disposed within the storage container; a discharge unit provided with a measurement chamber filled with a liquid material, a plunger in close contact with and sliding on the inner peripheral surface of the measurement chamber, a nozzle in communication with the measurement chamber, and a switching valve switched between a first position at which the storage container and the measurement container are in communication with each other, and a second position at which the measurement chamber and the nozzle are in communication with each other; and a connection flow passage for providing communication between the storage container and the measurement chamber. The provided liquid discharge device is characterized in that the stirrer drive mechanism is configured to be separable from the storage unit. An application device provided with the liquid discharge device, and an application method are also provided.
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05D 3/00 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials
89.
LIQUID MATERIAL DISCHARGE DEVICE WITH TEMPERATURE CONTROL DEVICE, APPLICATION DEVICE FOR SAME, AND APPLICATION METHOD
[Problem] To provide a device and method with which application operations can be carried out without variations in amount of discharge while adjusting the temperature of liquid material by a temperature control device even on a stage that is heated. [Solution] Provided is a liquid material discharge device, which is provided with a discharge opening, a liquid chamber linked to the discharge opening, and a temperature control device for adjusting the temperature of the liquid chamber and which discharges a liquid material from the discharge opening while moving a workpiece and the discharge opening relative to each other, wherein the liquid material discharge device is provided with a refrigerant flow path for flow of a refrigerant for heat exchange with the temperature control device, and a discharge control device for controlling discharge operations. Also provided are an application device provided with the liquid material discharge device, and an application method that uses this application device.
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
B05D 3/00 - Pretreatment of surfaces to which liquids or other fluent materials are to be appliedAfter-treatment of applied coatings, e.g. intermediate treating of an applied coating preparatory to subsequent applications of liquids or other fluent materials
[Problem] To provide a work apparatus and a work method whereby work can be obtained that is free of variations among a plurality of work heads having machine differences. [Solution] A work apparatus and a work method that uses the apparatus, the work apparatus provided with n (where n is a natural number equal to 2 or greater) work heads for performing the same work, a stage for retaining a work object, a first-direction drive device for moving the stage and the work heads relative to each other, a second-direction drive device for moving the stage and the work heads relative to each other, a third-direction drive device for moving the stage and the work heads relative to each other, a work amount measurement device for measuring the work amount of each work head, and a control device, the first-direction drive device being capable of moving each of the n work heads independently in a first direction, and the second-direction drive device being provided with a second-direction main drive device for moving the n work heads in a second direction simultaneously and a second-direction secondary drive device for moving each of n-1 work heads of the n work heads independently in the second direction.
B05C 11/00 - Component parts, details or accessories not specifically provided for in groups
B05D 1/00 - Processes for applying liquids or other fluent materials
G01B 11/00 - Measuring arrangements characterised by the use of optical techniques
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
A liquid material-discharging device provided with a discharging member made of a rod-shaped body, a liquid chamber that is wider than the discharging member and in which the tip of the discharging member is disposed, a discharge port that is in communication with the liquid chamber, a liquid delivery path that brings the liquid chamber into communication with a liquid material storage container, a drive device for driving the discharging member, and a main body. The liquid material-discharging device is provided with a long thin inserted member that is inserted in the liquid delivery path so as to be freely removable without blocking the communication between the liquid chamber and the liquid material storage container.
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
The droplet discharge device includes a liquid chamber which is in communication with a nozzle and to which a liquid material is supplied, a plunger having a tip portion that is thinner than the liquid chamber and that is moved back and forth in the liquid chamber, a piezoelectric actuator serving as a drive source that operates the plunger to be moved back and forth, a lever mechanism that increases a displacement of the piezoelectric actuator, a base having a mounting surface to which the piezoelectric actuator is mounted, and a discharge control device. The lever mechanism includes an arm that is operated to perform a swinging motion by the piezoelectric actuator, and a leaf spring including ends that are linked to a lower portion of the arm and to the base, and a plunger-linked portion in a central region thereof.
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05B 1/30 - Nozzles, spray heads or other outlets, with or without auxiliary devices such as valves, heating means designed to control volume of flow, e.g. with adjustable passages
H01L 41/09 - Piezo-electric or electrostrictive elements with electrical input and mechanical output
B05B 17/06 - Apparatus for spraying or atomising liquids or other fluent materials, not covered by any other group of this subclass operating with special methods using ultrasonic vibrations
B05B 13/04 - Means for supporting workArrangement or mounting of spray headsAdaptation or arrangement of means for feeding work the spray heads being moved during operation
The present invention provides a plunger (20) for a dispenser, the plunger including a large diameter body portion (23) provided with ring-shaped contact surfaces (24, 25) that contact an inner wall surface of a syringe, a rear opening (26) formed in a backside of the large diameter body portion (23), and a small diameter body portion (22) provided with a front opening (28), wherein the front opening (28) is formed in a size allowing a liquid material to be directly pressed by pressurized air, and allowing at least the plunger (20) to move following a fall in water head position, which is caused with discharge and consumption of the liquid material. With those features, the liquid material can be prevented from adhering to the inner wall surface of the syringe, and the liquid material in the syringe can be prevented from flowing backwards.
B05C 17/005 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure
B65D 83/00 - Containers or packages with special means for dispensing contents
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 17/015 - Hand tools or apparatus using hand-held tools, for applying liquids or other fluent materials to, for spreading applied liquids or other fluent materials on, or for partially removing applied liquids or other fluent materials from, surfaces for discharging material through an outlet orifice by pressure with pneumatically actuated piston or the like
94.
LIQUID MATERIAL DISCHARGE DEVICE, AND APPLICATION DEVICE AND APPLICATION METHOD THEREFOR
[Problem] To provide a liquid material discharge device and method which are capable of ameliorating the problem of liquid leakage caused by closing failure which occurs when the discharge device is provided in a negative pressure environment. [Solution] This liquid material discharge device is used in a negative pressure space, and is provided with: a storage container; a compressed gas supply source for pressurizing the storage container; a nozzle provided with a discharge flow path; a reciprocating valve rod; an actuator for driving the valve rod; a valve seat provided with a communication hole which communicates with the discharge flow path; and a discharge control device which controls the actuator such that the communication hole is opened and closed by the tip of the valve rod. The liquid material discharge device is provided with a resin film which is provided to the lower end of the valve rod, or a resin film which is provided to the upper surface of the valve seat, and which has a through hole which communicates with the communication hole.
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
95.
LIQUID MATERIAL DISCHARGE DEVICE, AND APPLICATION DEVICE AND APPLICATION METHOD THEREFOR
[Problem] To provide a liquid material discharge device and method which are capable of suppressing the formation of bubbles caused by a rod raising operation, in a negative pressure environment. Furthermore, to provide a liquid material discharge device and method which solve the problem of leakage of a liquid material which occurs as a result of insufficient blockage by a valve rod tip due to wear of the valve rod tip or a valve seat. [Solution] This liquid material discharge device is used in a negative pressure space, and is provided with: a storage container; a compressed gas supply source for pressurizing the storage container; a nozzle provided with a discharge flow path; a reciprocating valve rod; an actuator which drives the valve rod; a valve seat provided with a communication hole which communicates with the discharge flow path; and a discharge control device which controls the actuator such that the communication hole is opened and closed by the tip of the valve rod. The discharge control device inhibits the formation of bubbles which accompanies the raising of the valve rod, by controlling the acceleration time Au when the valve rod is raised by the actuator, to within the range of 2-300 [ms].
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
96.
DISCHARGE DEVICE FOR LIQUID MATERIAL CONTAINING SOLID PARTICLES, DISCHARGE METHOD, AND COATING DEVICE
[Problem] To supply a device and method, for discharging a fixed quantity of a liquid containing solid particles, discharging same with good precision and in a state in which the solid particles are dispersed. [Solution] A discharge device for a liquid material containing solid particles and a discharge method using said device. The discharge device comprises: a first storage container; a first air pressure supply pipe; a measuring unit having a measuring hole; a plunger that moves into and retracts from the measuring hole; a nozzle; a switching valve having a first position and a second position; a plunger drive device; and a switching valve drive device. The discharge device further comprises: a second storage container; a second air pressure supply pipe; a branch section provided in an upper section of the measuring hole and having a branch flow path; and an opening/closing mechanism that connects or blocks between the second storage container and the measuring hole. The discharge device is characterized by: being capable of sending the liquid material inside the first storage container to the second storage container; and by being capable of sending the liquid material inside the second storage container to the first storage container.
B01F 15/04 - Forming a predetermined ratio of the substances to be mixed
B01J 4/02 - Feed devicesFeed or outlet control devices for feeding measured quantities of reagents
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05D 1/26 - Processes for applying liquids or other fluent materials performed by applying the liquid or other fluent material from an outlet device in contact with, or almost in contact with, the surface
97.
LIQUID MATERIAL DISCHARGE DEVICE COMPRISING BOOSTER CIRCUIT
[Problem] To provide a liquid material discharge device capable of reducing takt time. [Solution] A liquid material discharge device comprising: a liquid chamber connected to a discharge port and having liquid material supplied thereto; a plunger having a piston formed in a rear end section thereof and having a tip section thereof entering into and retracting from the liquid chamber; an elastic member that applies an impelling force to the plunger; a piston chamber having the piston arranged therein and having a pressurized gas supplied thereto; and a pressure supply device that supplies pressurized air that exceeds the impelling force of an elastic body, to the piston chamber, or discharges pressurized air from inside the piston chamber. The liquid material discharge device discharges liquid material from the discharge port, by causing the plunger to move forward and by applying inertial force to the liquid material, and is characterized by: comprising a booster circuit connecting the pressure supply device and an air source; and the booster circuit comprising a first booster system having a booster valve and a decompression valve, a second booster system having a booster valve and a decompression valve, and a merging section that causes the first booster system and the second booster system to merge.
B05C 11/10 - Storage, supply or control of liquid or other fluent materialRecovery of excess liquid or other fluent material
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
F15B 11/028 - Systems essentially incorporating special features for controlling the speed or the actuating force or speed of an output member for controlling the actuating force
98.
Syringe attachment/detachment mechanism and device provided with mechanism
A syringe attachment/detachment mechanism enables a syringe to be easily attached to and detached from a discharge device without causing twisting of a tube, and enabling the syringe and an adapter to be fixedly held in a desired orientation. In the syringe attachment/detachment mechanism and the device provided with the mechanism, the mechanism being adapted for a discharge device to which a syringe including an attachment part and an upper connection part is attached through screwing, the attachment part includes an inner cylindrical portion having a small-diameter opening, an outer cylindrical portion surrounding the inner cylindrical portion, and a screw portion. The attachment/detachment mechanism includes a support member including a cylindrical insertion portion into which the inner cylindrical portion is inserted, and having a channel formed therein for communication between the small-diameter opening and a nozzle of the discharge device. A rotation member includes a screw portion.
B05C 11/00 - Component parts, details or accessories not specifically provided for in groups
B05C 11/11 - Vats or other containers for liquids or other fluent materials
B05C 5/00 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work
F16L 37/24 - Couplings of the quick-acting type in which the connection is made by inserting one member axially into the other and rotating it to a limited extent, e.g. with bayonet-action
B05C 5/02 - Apparatus in which liquid or other fluent material is projected, poured or allowed to flow on to the surface of the work from an outlet device in contact, or almost in contact, with the work
B05C 13/00 - Means for manipulating or holding work, e.g. for separate articles
F16L 19/04 - Joints in which sealing surfaces are pressed together by means of a member, e.g. a swivel nut, screwed on, or into, one of the joint parts using additional rigid rings, sealing directly on at least one pipe end, which is flared either before or during the making of the connection
Problem: To provide a liquid material ejection device in which a plunger can be efficiently accelerated, the device having a low center of gravity and satisfactory maintainability, and a coating device in which the liquid material ejection device is mounted. Solution: The liquid material ejection device is provided with: a liquid chamber which communicates with an ejection opening and to which liquid material is supplied; a plunger of which a tip-end portion having a diameter smaller than the liquid chamber is moved back and forth in the liquid chamber; an elastic member which urges the plunger upward; an arm disposed so as to extend in a substantially horizontal direction; an arm drive device providing a driving source for operating the arm; and a base member on which the arm drive device is disposed. The liquid material ejection device is further provided with a pivotal mechanism unit which is connected to the arm drive device and which pivotally supports the arm drive device and the arm. The arm drive device is provided with a plurality of actuators disposed in a longitudinal direction of the arm. The arm is provided with a pressing portion which presses the plunger downward. The plunger is provided with an abutment portion pressed by the pressing portion. The plunger executes a linear reciprocating motion as the arm is pivotally moved. The coating device incorporates the liquid material ejection device.
09 - Scientific and electric apparatus and instruments
Goods & Services
Liquid precision measuring and discharging modules sold as an integral component of semiconductor manufacturing machines, and parts therefor; Painting machines and parts therefor Physical and chemical machinery and appliances, namely, machines for dripping liquid onto plates, glass slides and chips having multi-arrays that can be used in chemical analysis, biological analysis or patterning for scientific laboratory or medical research use
