A brake system (200) for manual handling equipment (100), and wheeled manual handling equipment (100). The brake system (200) comprises a foot pedal (108) and a brake mechanism (202) connecting the foot pedal (108) to at least one wheel brake (300). The brake mechanism (202) comprises: a one-way driver (204) to enable push-to-engage and push-to-release actuation of the at least one wheel brake (300) by the foot pedal (108); an output actuator (212, 304) to actuate the wheel brake (300); and a reducer (500) to cause a ratio of output actuator displacement to foot pedal displacement to be greater than 1:1.
Embodiments relate to a container 1 comprising a base 2 and a side wall arrangement 4 peripheral to the base 2, wherein the base 2 comprises at least one lower layer 6 and an upper layer 8 above the lower layer 6.
Embodiments relate to a container 1 comprising a base 2, and a plurality of side walls 4 peripheral to the base 2, wherein each side wall 4 comprises an inner side 8 facing the base 2, and an outer side 10 facing opposite the inner side 8, wherein the side walls 4 comprise a plurality of spaced raised portions 12, wherein each side wall 4 comprises a nesting cavity 14 at the outer side 10 of the corresponding side wall 4, wherein the nesting cavities 14 allow the container 1 to be nested in the raised portions 12 of an underlying one of the container 1 in a stack, wherein each nesting cavity 14 comprises an entrance 16 accessible from an underside of the container 1, for receiving a raised portion 12 of the underlying container 1, wherein an inclined wall member 19 of each side wall 4, inclined away from the base 2, defines an inclined boundary of the nesting cavity 14, and wherein each side wall 4 comprises at its outer side 10 vertical portions 20 alongside the inclined wall members, at a same elevation as the inclined wall members 19.
Embodiments relate to a system (96), a method, and a control apparatus (120). The system (96) comprises a winding assembly (16) and a tensioning tool (100). The winding assembly (16) comprises a tensioner (37) movable between loose and tensioning positions. The winding assembly (16) comprises a lever (19) comprising a fulcrum body (21) and an elongate handle (20), wherein the elongate handle (20) has a stroke length between a first position and a second position. The winding assembly (16) comprises a drive linkage coupling actuation of the elongate handle (20) to motion of the tensioner (37), wherein movement of the elongate handle to the second position moves the tensioner (37) towards the tensioning position. The winding assembly (16) comprises a retainer (70) configured to inhibit returning of the tensioner (37) towards the loose position. The tensioning tool (100) comprises a handle rotator (102) positionable against the elongate handle (20).
Embodiments relate to a winding assembly (16) and a method of installing a tensioning line (10) in the winding assembly (16). The winding assembly (16) comprises a housing (84). The winding assembly (16) comprises the tensioning line (10). The winding assembly (16) comprises a channel (22) within the housing (84), the channel (22) comprising an entrance (23) and an exit (24) opposite the entrance (23), wherein the tensioning line (10) extends through the channel (22). The winding assembly (16) comprises a tensioner (37), wherein the tensioner (37) is engageable with the tensioning line (10). The winding assembly (16) further comprises an access port (98) in the housing (84), wherein the access port (98) is closer to the tensioner (37) than the entrance (23) and exit (24) of the channel (22) are.
Aspects of the invention relate to a system (2) comprising a primary container (100), an adapter (300), and a plurality of secondary containers (200) each sized to nest within the primary container. The adapter is securable to first connectors (110) of the primary container to an operating position, wherein at the operating position the adapter is at a suspended height above a base (102) of the primary container or is on the base, and defines at least in part a plurality of frames each configured to receive and secure an individual one of the secondary containers. A further aspect of the invention relates to a system comprising a primary container and a plurality of secondary containers each sized to nest within the primary container, wherein the secondary containers comprise interlocking connectors (202) to secure each secondary container to an adjacent one of the secondary containers and/or to an adapter.
Embodiments of the invention relate to a brake system (200), to wheeled manual handling equipment (100), and to a foot pedal subassembly (201). The brake system (200) comprises: a foot pedal (108) having a cavity (206); and a brake mechanism (202) connecting the foot pedal (108) to at least one wheel brake (300), wherein the brake mechanism (202) comprises a one-way driver (204) to enable push-to-engage and push-to-release actuation of the at least one wheel brake (300) by the foot pedal (108), and wherein the one-way driver (204) is within the cavity (206) of the foot pedal (108).
B60T 11/04 - Transmission de l'action de freinage entre l'organe d'attaque et les organes terminaux d'action, dans laquelle la transmission n'est ni assistée ni à relais de puissance ou dans laquelle une telle assistance ou un tel relais ne sont pas essentiels mécanique
B62B 5/00 - Accessoires ou détails spécialement adaptés aux voitures à bras
11.
Container for the storage and transportation of goods
Embodiments relate to a winding assembly (16) comprising: a tensioner (37) to which a tensioning line (10) is engageable; an interface (19, 19B) configured to receive actuation force; and a drive linkage (18, 18A, 18B, 42, 42A, 42B) coupling actuation of the interface (19, 19B) to motion of the tensioner.
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
A winding assembly (16) comprising: a tensioner (37) to engage a tensioning line (10); a lever (19) comprising a fulcrum body (21) and an elongate handle (20) extending from the fulcrum body (21); a drive linkage (18, 18A, 18B, 42, 42A, 42B, 53) coupling actuation of the lever (20) to motion of the tensioner (37); and a retainer (70, 70′) configured to be engaged following actuation of the lever (20) in a first, tensioning direction, to prevent movement of the lever (20) in a second, opposite direction.
B60P 7/08 - Fixation au plancher ou aux parois du véhicule
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
15.
CONTAINER HANDLES FOR LIFTING A CONTAINER IN AN INVERTED ORIENTATION
A container (10), wherein the container (10) comprises a base (12) and upstanding walls (14) on the base (12), wherein the upstanding walls (14) each comprise a top edge (20), the top edges (20) defining a top opening (34) therebetween, wherein the container (10) comprises an inverted lifting handle (100) to enable, at least in part, lifting of the container (10) when the container (10) is in an inverted orientation, and wherein the inverted lifting handle (100) is at an elevation proximal to an elevation of the base (12), and distal from an elevation of the top opening (34).
Manual handling equipment 100 to which a wall-providing accessory 200 is mountable, wherein the manual handling equipment 100 comprises a body 102 and a set of locking connectors 118 spaced towards opposite ends of a side 122, 126 of the body 102, wherein the set of locking connectors 118 are connected to one or more user inputs 116, wherein movement of one of the one or more user inputs 116 actuates the set of locking connectors 118 simultaneously to engage or disengage the set of locking connectors 118 with the wall-providing accessory 200.
B62B 3/00 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet
B62B 3/02 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet comportant des parties réglables, rabattables, attachables, détachables ou transformables
B62B 3/14 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet caractérisées par des moyens pour l'emboîtement ou l'empilage, p. ex. chariots pour achats
B62B 3/16 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet caractérisées par des moyens pour l'emboîtement ou l'empilage, p. ex. chariots pour achats empilables verticalement
A winding assembly (16) comprises a ratchet spool (59) rotatable about a principal axis (61). The ratchet spool (59) has a main part (20) and a plurality of ratchet teeth (60) arranged circumferentially around the main part (20). The winding assembly (16) also has a tensioning arrangement (37) for tensioning an elongate article (10). The winding assembly (16) further includes a drive arrangement (18) to engage the ratchet teeth (60) of the ratchet spool (59) and rotate the ratchet spool (59) in a driving direction about said principal axis (61) to apply tension to the elongate article (10). A tension limitation member (53) is provided between the ratchet spool (59) and the tensioning arrangement (37) to limit the tension applied to the elongate article (10).
B65D 63/10 - Courroies, rubans ou bandes non métalliquesÉléments filamenteux, p. ex. cordons, fils ou fils métalliquesJonctions de leurs extrémités
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
18.
CONTAINER SHAPED TO PREVENT LINE OF SIGHT THROUGH ITS DRAINAGE HOLES
B65D 81/26 - Adaptations pour empêcher la détérioration ou l'altération du contenuApplications au réceptacle ou au matériau d'emballage d'agents de conservation des aliments, de fongicides, d'insecticides ou de produits repoussant les animaux avec dispositifs pour évacuer ou absorber les fluides, p. ex. s'écoulant du contenuEmploi de produits empêchant la corrosion ou de dessiccateurs
19.
CONTAINER SHAPED TO PREVENT LINE OF SIGHT THROUGH ITS DRAINAGE HOLES
A container (100) comprising: a base (102); a side wall arrangement (104) extending up from the base (102) and supported by the base (102); and drainage holes (140) above the base (102) and fluidly connected to a load space (101) of the container (100), the drainage holes (140) including a first drainage hole (140) to a first side (118, 120, 122, 124) of the container (100), and a second drainage hole (140) to a second, opposite side (118, 120, 122, 124) of the container (100), wherein the container (100) is shaped to prevent line of sight through the first and second drainage holes (140).
B65D 81/26 - Adaptations pour empêcher la détérioration ou l'altération du contenuApplications au réceptacle ou au matériau d'emballage d'agents de conservation des aliments, de fongicides, d'insecticides ou de produits repoussant les animaux avec dispositifs pour évacuer ou absorber les fluides, p. ex. s'écoulant du contenuEmploi de produits empêchant la corrosion ou de dessiccateurs
A container (10) comprises a base (12) and upstanding side walls (14) extending from the base (12) to define a load receiving space (16). The base (12) comprises a first base member (18) and a second base member (20). A spacing arrangement (22) is provided between the first and second base members (18, 20). The container (10) may include corner arrangements (28) between adjacent side walls (14). Each corner arrangement (28) extends outwardly from the adjacent side walls (14) to provide a protruding region adjacent each side wall (14), and to define a concave region (32) communicating with the load receiving space (16). 20. A divider for a container is also provided, the divider comprising a main member (112) and a detent (120))) on the main member, the detent being receivable by a support to secure the divider to the support.
B65D 6/00 - Réceptacles dont le corps est formé par jonction ou liaison de plusieurs composants rigides ou sensiblement rigides, constitués en totalité ou principalement en métal, en matière plastique, en bois ou en un matériau de remplacement
B65D 25/06 - Cloisonnements conçus pour être disposés selon plusieurs positions possibles
A container (10) comprising a wall arrangement (12) defining a load receiving space (16), and a support member (14) attached on the wall arrangement (12), the support member (14) being movable between a support position and a non-support position, wherein, in the support position, the support member (14) extends at least partially across the load receiving space (16), the support member having a planar portion (30) to support a further container (10) in a stacked condition on the container (10).
B65D 21/02 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage
B65D 21/06 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage avec des parties mobiles conçues pour être placées dans les positions alternatives à emboîter lorsque les réceptacles sont vides, et à gerber lorsque les réceptacles sont pleins
B65D 43/06 - Couvercles ou chapeaux amovibles ayant un canal périphérique entourant le bord du réceptacle
A brake system (200) for manual handling equipment (100), and wheeled manual handling equipment (100). The brake system (200) comprises a foot pedal (108) and a brake mechanism (202) connecting the foot pedal (108) to at least one wheel brake (300). The brake mechanism (202) comprises: a one-way driver (204) to enable push-to-engage and push-to-release actuation of the at least one wheel brake (300) by the foot pedal (108); an output actuator (212, 304) to actuate the wheel brake (300); and a reducer (500) to cause a ratio of output actuator displacement to foot pedal displacement to be greater than 1:1.
A brake system (200) for manual handling equipment (100), and wheeled manual handling equipment (100). The brake system (200) comprises a foot pedal (108) and a brake mechanism (202) connecting the foot pedal (108) to at least one wheel brake (300). The brake mechanism (202) comprises: a one-way driver (204) to enable push-to-engage and push-to-release actuation of the at least one wheel brake (300) by the foot pedal (108); an output actuator (212, 304) to actuate the wheel brake (300); and a reducer (500) to cause a ratio of output actuator displacement to foot pedal displacement to be greater than 1:1.
B60P 7/08 - Fixation au plancher ou aux parois du véhicule
B65B 7/28 - Fermeture de réceptacles ou récipients semi-rigides ou rigides, non déformés par le contenu ou n'en prenant pas la forme, p. ex. boîtes ou cartons en appliquant des fermetures séparées préformées, p. ex. couvercles, capuchons
B65B 13/02 - Application et amarrage des matériaux de liage, p. ex. ficelles, fils métalliques, bandelettes, bandes ou rubans, autour d'objets ou de groupes d'objets
B65B 13/18 - Détails ou dispositifs auxiliaires des machines à ficeler des objets en paquets
B65B 13/22 - Dispositifs de réglage de la tension des moyens de liage
There is provided a winding assembly (16), and a pallet lid (1 ) comprising the winding assembly (16). The winding assembly (16) comprises a rotatable tensioner (37) configured to receive a tensioning line (10) therethrough. The winding assembly (16) further comprises a manual control device (19) to rotate the tensioner (37) from a home position of the tensioner (37) to a tensioning position of the tensioner (37). The winding assembly (16) provides a variable ratio between movement of the manual control device (19) and a tensioning displacement of the tensioning line (10) as the tensioning line (10) is wrapped around the tensioner (37) by rotation of the tensioner (37) towards the tensioning position.
B60P 7/08 - Fixation au plancher ou aux parois du véhicule
B65B 7/28 - Fermeture de réceptacles ou récipients semi-rigides ou rigides, non déformés par le contenu ou n'en prenant pas la forme, p. ex. boîtes ou cartons en appliquant des fermetures séparées préformées, p. ex. couvercles, capuchons
B65B 13/02 - Application et amarrage des matériaux de liage, p. ex. ficelles, fils métalliques, bandelettes, bandes ou rubans, autour d'objets ou de groupes d'objets
B65B 13/18 - Détails ou dispositifs auxiliaires des machines à ficeler des objets en paquets
B65B 13/22 - Dispositifs de réglage de la tension des moyens de liage
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
A ratchet spool (59) for use in a winding assembly (16) is disclosed. The ratchet spool (59) is rotatable about a principal axis (61). The ratchet spool (59) comprises a main part (20) and a plurality of ratchet teeth (60) arranged circumferentially around the main part (20). The ratchet teeth (60) are engageable by a ratchet arrangement (18) for driving the ratchet spool (59) in a driving direction about said principal axis (61). The ratchet spool (59) also has a drive formation (21) for driving the ratchet spool (59) in said driving direction.
B60P 7/08 - Fixation au plancher ou aux parois du véhicule
B60P 7/10 - Fixation au plancher ou aux parois du véhicule la charge consistant en plaques, caisses ou boîtes
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
Embodiments of the invention relate to a brake system (200). The brake system (200) comprises: a foot pedal (108) having a cavity (206); and a brake mechanism (202) connecting the foot pedal (108) to at least one wheel brake (300), wherein the brake mechanism (202) comprises a one-way driver (204) to enable push-to-engage and push-to-release actuation of the at least one wheel brake (300) by the foot pedal (108), and wherein the one-way driver (204) is within the cavity (206) of the foot pedal (108).
Embodiments of the invention relate to a brake system (200). The brake system (200) comprises: a foot pedal (108) having a cavity (206); and a brake mechanism (202) connecting the foot pedal (108) to at least one wheel brake (300), wherein the brake mechanism (202) comprises a one-way driver (204) to enable push-to-engage and push-to-release actuation of the at least one wheel brake (300) by the foot pedal (108), and wherein the one-way driver (204) is within the cavity (206) of the foot pedal (108).
A winding assembly (16) comprising: a tensioner (37) to engage a tensioning line (10); a lever (19) comprising a fulcrum body (21) and an elongate handle (20) extending from the fulcrum body (21); a drive linkage (18, 18A, 18B, 42, 42A, 42B, 53) coupling actuation of the lever (20) to motion of the tensioner (37); and a retainer (70, 70') configured to be engaged following actuation of the lever (20) in a first, tensioning direction, to prevent movement of the lever (20) in a second, opposite direction.
B60P 7/08 - Fixation au plancher ou aux parois du véhicule
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
30.
WINDING ASSEMBLY WITH MESH OR WINDING DRIVE LINKAGE
Embodiments relate to a winding assembly (16) comprising: a tensioner (37) to which a tensioning line (10) is engageable; an interface (19, 19B) configured to receive actuation force; and a drive linkage (18, 18A, 18B, 42, 42A, 42B) coupling actuation of the interface (19, 19B) to motion of the tensioner. The drive linkage can be a mesh linkage or a winding mechanism.
B60P 7/08 - Fixation au plancher ou aux parois du véhicule
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
31.
WINDING ASSEMBLY WITH MESH OR WINDING DRIVE LINKAGE
Embodiments relate to a winding assembly (16) comprising: a tensioner (37) to which a tensioning line (10) is engageable; an interface (19, 19B) configured to receive actuation force; and a drive linkage (18, 18A, 18B, 42, 42A, 42B) coupling actuation of the interface (19, 19B) to motion of the tensioner. The drive linkage can be a mesh linkage or a winding mechanism.
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
B60P 7/08 - Fixation au plancher ou aux parois du véhicule
A winding assembly (16) comprising: a tensioner (37) to engage a tensioning line (10); a lever (19) comprising a fulcrum body (21) and an elongate handle (20) extending from the fulcrum body (21); a drive linkage (18, 18A, 18B, 42, 42A, 42B, 53) coupling actuation of the lever (20) to motion of the tensioner (37); and a retainer (70, 70') configured to be engaged following actuation of the lever (20) in a first, tensioning direction, to prevent movement of the lever (20) in a second, opposite direction.
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
B60P 7/08 - Fixation au plancher ou aux parois du véhicule
33.
CONTAINER HANDLES FOR LIFTING A CONTAINER IN AN INVERTED ORIENTATION
A container (10), wherein the container (10) comprises a base (12) and upstanding walls (14) on the base (12), wherein the upstanding walls (14) each comprise a top edge (20), the top edges (20) defining a top opening (34) therebetween, wherein the container (10) comprises an inverted lifting handle (100) to enable, at least in part, lifting of the container (10) when the container (10) is in an inverted orientation, and wherein the inverted lifting handle (100) is at an elevation proximal to an elevation of the base (12), and distal from an elevation of the top opening (34).
B65D 81/26 - Adaptations pour empêcher la détérioration ou l'altération du contenuApplications au réceptacle ou au matériau d'emballage d'agents de conservation des aliments, de fongicides, d'insecticides ou de produits repoussant les animaux avec dispositifs pour évacuer ou absorber les fluides, p. ex. s'écoulant du contenuEmploi de produits empêchant la corrosion ou de dessiccateurs
34.
CONTAINER HANDLES FOR LIFTING A CONTAINER IN AN INVERTED ORIENTATION
A container (10), wherein the container (10) comprises a base (12) and upstanding walls (14) on the base (12), wherein the upstanding walls (14) each comprise a top edge (20), the top edges (20) defining a top opening (34) therebetween, wherein the container (10) comprises an inverted lifting handle (100) to enable, at least in part, lifting of the container (10) when the container (10) is in an inverted orientation, and wherein the inverted lifting handle (100) is at an elevation proximal to an elevation of the base (12), and distal from an elevation of the top opening (34).
B65D 81/26 - Adaptations pour empêcher la détérioration ou l'altération du contenuApplications au réceptacle ou au matériau d'emballage d'agents de conservation des aliments, de fongicides, d'insecticides ou de produits repoussant les animaux avec dispositifs pour évacuer ou absorber les fluides, p. ex. s'écoulant du contenuEmploi de produits empêchant la corrosion ou de dessiccateurs
A container (10) comprising a wall arrangement (20) defining an internal region (14). The container (10) further comprises a support arrangement (36) attached to the wall arrangement (20). The support arrangement (36) is arrangeable in a support position in which the support arrangement (36) extends across the internal region (14). The support arrangement (36) is also arrangeable in a non-support position in which the support arrangement (36) extends along the wall arrangement (20) within the internal region (14) in engagement with the wall arrangement (20). The support arrangement (36) is movable between the support and the non-support positions.
B65D 21/06 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage avec des parties mobiles conçues pour être placées dans les positions alternatives à emboîter lorsque les réceptacles sont vides, et à gerber lorsque les réceptacles sont pleins
B65D 25/06 - Cloisonnements conçus pour être disposés selon plusieurs positions possibles
A winding assembly (16) comprises a ratchet spool (59) rotatable about a principal axis (61). The ratchet spool (59) has a main part (20) and a plurality of ratchet teeth (60) arranged circumferentially around the main part (20). The winding assembly (16) also has a tensioning arrangement (37) for tensioning an elongate article (10). The winding assembly (16) further includes a drive arrangement (18) to engage the ratchet teeth (60) of the ratchet spool (59) and rotate the ratchet spool (59) in a driving direction about said principal axis (61) to apply tension to the elongate article (10). A tension limitation member (53) is provided between the ratchet spool (59) and the tensioning arrangement (37) to limit the tension applied to the elongate article (10).
A winding assembly (16) comprises a ratchet spool (59) rotatable about a principal axis (61). The ratchet spool (59) has a main part (20) and a plurality of ratchet teeth (60) arranged circumferentially around the main part (20). The winding assembly (16) also has a tensioning arrangement (37) for tensioning an elongate article (10). The winding assembly (16) further includes a drive arrangement (18) to engage the ratchet teeth (60) of the ratchet spool (59) and rotate the ratchet spool (59) in a driving direction about said principal axis (61) to apply tension to the elongate article (10). A tension limitation member (53) is provided between the ratchet spool (59) and the tensioning arrangement (37) to limit the tension applied to the elongate article (10).
B60P 7/08 - Fixation au plancher ou aux parois du véhicule
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
A container (10) comprises a base (12) and upstanding side walls (14) extending from the base (12) to define a load receiving space (16). The base (12) comprises a first base member (18) and a second base member (20). A spacing arrangement (22) is provided between the first and second base members (18, 20). The container (10) may include corner arrangements (28) between adjacent side walls (14). Each corner arrangement (28) extends outwardly from the adjacent side walls (14) to provide a protruding region adjacent each side wall (14), and to define a concave region (32) communicating with the load receiving space (16). 20. A divider for a container is also provided, the divider comprising a main member (112) and a detent (120)) on the main member, the detent being receivable by a support to secure the divider to the support.
B65D 6/00 - Réceptacles dont le corps est formé par jonction ou liaison de plusieurs composants rigides ou sensiblement rigides, constitués en totalité ou principalement en métal, en matière plastique, en bois ou en un matériau de remplacement
B65D 6/34 - Pièces ou éléments de renforcement ou de consolidation
B65D 25/06 - Cloisonnements conçus pour être disposés selon plusieurs positions possibles
A container (10) comprises a base (12) and upstanding side walls (14) extending from the base (12) to define a load receiving space (16). The base (12) comprises a first base member (18) and a second base member (20). A spacing arrangement (22) is provided between the first and second base members (18, 20). The container (10) may include corner arrangements (28) between adjacent side walls (14). Each corner arrangement (28) extends outwardly from the adjacent side walls (14) to provide a protruding region adjacent each side wall (14), and to define a concave region (32) communicating with the load receiving space (16). 20. A divider for a container is also provided, the divider comprising a main member (112) and a detent (120)) on the main member, the detent being receivable by a support to secure the divider to the support.
B65D 6/00 - Réceptacles dont le corps est formé par jonction ou liaison de plusieurs composants rigides ou sensiblement rigides, constitués en totalité ou principalement en métal, en matière plastique, en bois ou en un matériau de remplacement
B65D 6/34 - Pièces ou éléments de renforcement ou de consolidation
B65D 25/06 - Cloisonnements conçus pour être disposés selon plusieurs positions possibles
A container (10) comprising a wall arrangement (12) defining a load receiving space (16), and a support member (14) attached on the wall arrangement (12), the support member (14) being movable between a support position and a non-support position, wherein, in the support position, the support member (14) extends at least partially across the load receiving space (16), the support member having a planar portion (30) to support a further container (10) in a stacked condition on the container (10).
B65D 21/02 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage
B65D 21/06 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage avec des parties mobiles conçues pour être placées dans les positions alternatives à emboîter lorsque les réceptacles sont vides, et à gerber lorsque les réceptacles sont pleins
A container (10) comprising a wall arrangement (12) defining a load receiving space (16), and a support member (14) attached on the wall arrangement (12), the support member (14) being movable between a support position and a non-support position, wherein, in the support position, the support member (14) extends at least partially across the load receiving space (16), the support member having a planar portion (30) to support a further container (10) in a stacked condition on the container (10).
B65D 21/02 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage
B65D 21/06 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage avec des parties mobiles conçues pour être placées dans les positions alternatives à emboîter lorsque les réceptacles sont vides, et à gerber lorsque les réceptacles sont pleins
A brake operating arrangement (18) comprises a cam member (22) operable on a brake mechanism (36) for braking a wheel (34). The brake mechanism (36) is movable between a braking condition and a non-braking condition. The cam member (22) is rotatable to move the brake mechanism (36) to the braking condition. The brake operating arrangement (18) further includes a drive member (44) movable in drive and return directions; and a ratchet mechanism (46) to rotate the cam member (22) when the drive member (44) is moved in the drive direction. The ratchet mechanism (46) is connected to the drive member (44) and the cam member (22).
22 - Cordes; filets; tentes, auvents, voiles et sacs; matières de rembourrage
39 - Services de transport, emballage et entreposage; organisation de voyages
Produits et services
Non-metallic containers for storage of goods; non-metallic containers for transportation of goods; plastic lids; non-metallic sealing caps for securing loads polypropylene straps for securing loads Rental of pallets; Rental of caps for use in securing loads on pallets; Rental of reusable packaging and containers for storage and transportation of goods; Rental of packaging materials and containers for storage and transportation of goods; Transport and storage of packaging materials, containers and pallets
A hinge assembly (15) comprises a first part (12) having a first hinge member (16), and a second part (14) having a second hinge member (18). The first and first and second hinge members (16, 18) form a pivot arrangement (20) to allow the first part (12) to pivot relative to the second part (14). A hinge pin (22) extends across the pivot arrangement (20), thereby pivotally attaching the first part (12) to the second part (14). The hinge pin (22) and the pivot arrangement (20) include a securing arrangement (26) to inhibit extraction of the hinge pin (22) from the pivot arrangement (20).
A dolly (10) comprises a body (12) having an upwardly projecting first locating formation (20) for locating a further dolly thereon in a stacked condition of said dollies. The body (12) has a second locating formation (21) for stacking the dolly (10) on a further dolly in a stacked condition of said dollies. The first locating formation (20) is engageable with a second locating formation on the further dolly stacked on the first mentioned dolly, and the second locating formation (21) is engageable with a first locating formation of the further dolly on which the first mentioned dolly (10) is stacked.
B62B 3/16 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet caractérisées par des moyens pour l'emboîtement ou l'empilage, p. ex. chariots pour achats empilables verticalement
B62B 5/00 - Accessoires ou détails spécialement adaptés aux voitures à bras
A container (12) comprises a base (14) and a wall (16) extending upwardly from the base (14). A plurality of support formations (38) at a top region of the wall (16), each support formation (38) having a support surface (46) extending outwardly from the wall (16); and a plurality of projecting formations (40) on the wall (16), each projecting formation (40) having an engaging surface (52) extending outwardly from the wall (16); wherein each support surface (46) and each engaging surface (52) slope downwardly from the wall (16). The support formations (38) and the projecting formations (40) are arranged so that the support surface (46) of each support formation (38) of the container (12) can engage the engaging surface (52) of a respective projecting formation (40) of another container (12) to support the containers (12) on one another in a stacked condition of said containers (12).
A layer pad (10) comprises a substantially flat sheet (12) having first and second opposite substantially planar faces (14, 16). The layer pad (10) further includes at least one raised formation (18) on at least one of the faces (14, 16).
B65D 19/18 - Palettes rigides avec parois latérales, p. ex. boîtes palettes avec corps formé par jonction ou union de plusieurs composants faites entièrement ou essentiellement en plastique
B29C 45/00 - Moulage par injection, c.-à-d. en forçant un volume déterminé de matière à mouler par une buse d'injection dans un moule ferméAppareils à cet effet
B65D 57/00 - Châssis ou supports internes pour objets souples, p. ex. raidisseursSéparateurs pour objets en piles ou en groupes, p. ex. pour empêcher l'adhérence des objets collants
B29L 7/00 - Objets plats, p. ex. pellicules ou feuilles
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
16 - Papier, carton et produits en ces matières
20 - Meubles et produits décoratifs
22 - Cordes; filets; tentes, auvents, voiles et sacs; matières de rembourrage
Produits et services
(1) Trolleys for carrying and moving loads; pallet dolly; dollies
(2) Slip sheets, namely, plastic sheets for packaging;
(3) Non-metallic containers for storage; non-metallic containers for transportation of goods; non-metallic lids namely plastic lids for industrial packaging containers; non-metallic pallets; non-metallic sealing caps for securing loads in non-metallic containers for storage and for transporting goods; pallets, not of metal;
(4) Non-metallic straps for securing loads
A container system (12) comprises a container (10) and a load holding extension (40) to extend the height of the container (10). The load holding extension (40) comprises a wall arrangement (44) defining an internal space (46) of the load holding extension (40). The wall arrangement (44) has a first rim formation (54) defining a first opening (55), and has a second rim formation (58) defining a second opening (59). The container (10) comprises a container wall (18) defining an internal space (46) of the container (10). The container wall (18) has a top rim formation defining an open top (20). The container system (12) comprises a mounting arrangement to mount the load holding extension (40) on the container (10) in a position in which the first opening (55) of the load holding extension (40) is aligned with the open top (20) of the container (10).
A container (10) comprising a wall arrangement (20) defining an internal region (14). The container (10) further comprises a support arrangement (36) attached to the wall arrangement (20). The support arrangement (36) is arrangeable in a support position in which the support arrangement (36) extends across the internal region (14). The support arrangement (36) is also arrangeable in a non-support position in which the support arrangement (36) extends along the wall arrangement (20) within the internal region (14) in engagement with the wall arrangement (20). The support arrangement (36) is movable between the support and the non-support positions.
B65D 21/06 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage avec des parties mobiles conçues pour être placées dans les positions alternatives à emboîter lorsque les réceptacles sont vides, et à gerber lorsque les réceptacles sont pleins
B65D 25/06 - Cloisonnements conçus pour être disposés selon plusieurs positions possibles
A container (10) comprising a wall arrangement (20) defining an internal region (14). The container (10) further comprises a support arrangement (36) attached to the wall arrangement (20). The support arrangement (36) is arrangeable in a support position in which the support arrangement (36) extends across the internal region (14). The support arrangement (36) is also arrangeable in a non-support position in which the support arrangement (36) extends along the wall arrangement (20) within the internal region (14) in engagement with the wall arrangement (20). The support arrangement (36) is movable between the support and the non-support positions.
B65D 21/06 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage avec des parties mobiles conçues pour être placées dans les positions alternatives à emboîter lorsque les réceptacles sont vides, et à gerber lorsque les réceptacles sont pleins
B65D 25/06 - Cloisonnements conçus pour être disposés selon plusieurs positions possibles
A ratchet spool (59) for use in a winding assembly (16) is disclosed. The ratchet spool (59) is rotatable about a principal axis (61). The ratchet spool (59) comprises a main part (20) and a plurality of ratchet teeth (60) arranged circumferentially around the main part (20). The ratchet teeth (60) are engageable by a ratchet arrangement (18) for driving the ratchet spool (59) in a driving direction about said principal axis (61). The ratchet spool (59) also has a drive formation (21) for driving the ratchet spool (59) in said driving direction.
B60P 7/08 - Fixation au plancher ou aux parois du véhicule
B60P 7/10 - Fixation au plancher ou aux parois du véhicule la charge consistant en plaques, caisses ou boîtes
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
A hinge assembly (15) comprises a first part (12) having a first hinge member (16), and a second part (14) having a second hinge member (18). The first and first and second hinge members (16, 18) form a pivot arrangement (20) to allow the first part (12) to pivot relative to the second part (14). A hinge pin (22) extends across the pivot arrangement (20), thereby pivotally attaching the first part (12) to the second part (14). The hinge pin (22) and the pivot arrangement (20) include a securing arrangement (26) to inhibit extraction of the hinge pin (22) from the pivot arrangement (20).
A reusable urinary catheter (72), comprising a catheter tube (12), a drainage member (22), the proximal end portion of the drainage member being connected to the distal end of the catheter tube, the distal end portion of the drainage member defining a drainage opening (28); a collapsible sleeve (18) surrounding the catheter tube, an introducer attached to the proximal end portion of the sleeve and the distal end portion of the sleeve being attached to the drainage member, the drainage member including channels (23) in fluid communication with the interior cavity of the sleeve, the channels allowing passage of sterilization fluid into and out of the sleeve; a holder (74) having a first port (66) and a second port (68), the introducer being releasably attached to tire first port and the drainage member being releasable attached to the second port: and a sterilization fluid located within the sleeve.
A brake operating arrangement (18) comprises a cam member (22) operable on a brake mechanism (36) for braking a wheel (34). The brake mechanism (36) is movable between a braking condition and a non-braking condition. The cam member (22) is rotatable to move the brake mechanism (36) to the braking condition. The brake operating arrangement (18) further includes a drive member (44) movable in drive and return directions; and a ratchet mechanism (46) to rotate the cam member (22) when the drive member (44) is moved in the drive direction. The ratchet mechanism (46) is connected to the drive member (44) and the cam member (22).
A lid arrangement (20) comprises first and second lids (22) for use in a container (12) comprising a wall arrangement (16). Each lid (22) is movable between open and closed positions. Each lid (22) comprises opposite first and second edges (124, 126), and a plurality of rib formations (132) extending transverse to the aforesaid edges (124, 126). When the first and second lids (22) are In the closed positions, the rib formations (132) of the first lid (22) overlap the rib formations (132) of the second lid (22), so that each rib formation (132) of the first lid (22) extends parallel to, and alongside, a corresponding rib formation (132) of the second lid (22) to provide a line of support (S) that extends across the lid arrangement (20) from the first edge (124) of the first lid (22) to the first edge (124) of the second lid (22).
B65D 43/16 - Couvercles ou chapeaux inamovibles s'ouvrant à charnières vers le haut ou vers le bas
B65D 21/06 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage avec des parties mobiles conçues pour être placées dans les positions alternatives à emboîter lorsque les réceptacles sont vides, et à gerber lorsque les réceptacles sont pleins
A dolly (10) comprises a body (12) having an upwardly projecting first locating formation (20) for locating a further dolly thereon in a stacked condition of said dollies. The body (12) has a second locating formation (21) for stacking the dolly (10) on a further dolly in a stacked condition of said dollies. The first locating formation (20) is engageable with a second locating formation on the further dolly stacked on the first mentioned dolly, and the second locating formation (21) is engageable with a first locating formation of the further dolly on which the first mentioned dolly (10) is stacked.
B62B 3/16 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet caractérisées par des moyens pour l'emboîtement ou l'empilage, p. ex. chariots pour achats empilables verticalement
B62B 5/00 - Accessoires ou détails spécialement adaptés aux voitures à bras
A container (10) having a base (12) is disclosed. The container (10) also has an upstanding side wall (14) extending upwardly from the base (12). The base (12) has an upper face (16) and a lower face (18). The base (12) defines an external recess (20) in extending upwardly from the lower face (18). The container (10) further includes a mesh formation in the recess (20). A lid (110) for a container (1100) is also disclosed. The lid (110) comprises a first surface (118) facing in a first direction. The lid (110) also has a second surface opposite the first surface (118). The lid (110) has a rim arrangement (111) comprising a holding formation (122) having a curved convexity (126A) facing in a second direction away from the first direction. The holding formation (122) comprises a plurality of spaced retaining members (128) on said convexity (126A). The retaining members (128) extend in the second direction, and are arranged so that a securing member (124) extending across the convexity (126A) between adjacent retaining members (128) is retained on the holding formation (122) by the retaining members (128).
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
22 - Cordes; filets; tentes, auvents, voiles et sacs; matières de rembourrage
39 - Services de transport, emballage et entreposage; organisation de voyages
Produits et services
Non-metallic containers; non-metallic lids; non-metallic pallets; non-metallic crates; non-metallic caps. Household and refuse containers. Non-metallic straps. Rental of pallets; Rental of caps for use in securing loads on pallets; Rental of reusable packaging and containers; Rental of packaging materials and containers; Transport and storage of packaging materials, containers and pallets.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
22 - Cordes; filets; tentes, auvents, voiles et sacs; matières de rembourrage
39 - Services de transport, emballage et entreposage; organisation de voyages
Produits et services
Non-metallic containers; non-metallic lids; non-metallic pallets; non-metallic crates; non-metallic caps. Household and refuse containers. Non-metallic straps. Rental of pallets; Rental of caps for use in securing loads on pallets; Rental of reusable packaging and containers; Rental of packaging materials and containers; Transport and storage of packaging materials, containers and pallets.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
22 - Cordes; filets; tentes, auvents, voiles et sacs; matières de rembourrage
39 - Services de transport, emballage et entreposage; organisation de voyages
Produits et services
Non-metallic containers; non-metallic lids; non-metallic pallets; non-metallic crates; non-metallic caps. Household and refuse containers. Non-metallic straps. Rental of pallets; Rental of caps for use in securing loads on pallets; Rental of reusable packaging and containers; Rental of packaging materials and containers; Transport and storage of packaging materials, containers and pallets.
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
22 - Cordes; filets; tentes, auvents, voiles et sacs; matières de rembourrage
39 - Services de transport, emballage et entreposage; organisation de voyages
Produits et services
Non-metallic containers; non-metallic lids; non-metallic pallets; non-metallic crates; non-metallic caps. Household and refuse containers. Non-metallic straps. Rental of pallets; Rental of caps for use in securing loads on pallets; Rental of reusable packaging and containers; Rental of packaging materials and containers; Transport and storage of packaging materials, containers and pallets.
A lid arrangement (20) comprises first and second lids (22) for use in a container (12) comprising a wall arrangement (16). Each lid (22) is movable between open and closed positions. Each lid (22) comprises opposite first and second edges (124, 126), and a plurality of rib formations (132) extending transverse to the aforesaid edges (124, 126). When the first and second lids (22) are In the closed positions, the rib formations (132) of the first lid (22) overlap the rib formations (132) of the second lid (22), so that each rib formation (132) of the first lid (22) extends parallel to, and alongside, a corresponding rib formation (132) of the second lid (22) to provide a line of support (S) that extends across the lid arrangement (20) from the first edge (124) of the first lid (22) to the first edge (124) of the second lid (22).
B65D 21/06 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage avec des parties mobiles conçues pour être placées dans les positions alternatives à emboîter lorsque les réceptacles sont vides, et à gerber lorsque les réceptacles sont pleins
B65D 43/16 - Couvercles ou chapeaux inamovibles s'ouvrant à charnières vers le haut ou vers le bas
A lid arrangement (20) comprises first and second lids (22) for use in a container (12) comprising a wall arrangement (16). Each lid (22) is movable between open and closed positions. Each lid (22) comprises opposite first and second edges (124, 126), and a plurality of rib formations (132) extending transverse to the aforesaid edges (124, 126). When the first and second lids (22) are In the closed positions, the rib formations (132) of the first lid (22) overlap the rib formations (132) of the second lid (22), so that each rib formation (132) of the first lid (22) extends parallel to, and alongside, a corresponding rib formation (132) of the second lid (22) to provide a line of support (S) that extends across the lid arrangement (20) from the first edge (124) of the first lid (22) to the first edge (124) of the second lid (22).
B65D 21/06 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage avec des parties mobiles conçues pour être placées dans les positions alternatives à emboîter lorsque les réceptacles sont vides, et à gerber lorsque les réceptacles sont pleins
B65D 43/16 - Couvercles ou chapeaux inamovibles s'ouvrant à charnières vers le haut ou vers le bas
A layer pad (10) comprises a substantially flat sheet (12) having first and second opposite substantially planar faces (14, 16). The layer pad (10) further includes at least one raised formation (18) on at least one of the faces (14, 16).
B65D 57/00 - Châssis ou supports internes pour objets souples, p. ex. raidisseursSéparateurs pour objets en piles ou en groupes, p. ex. pour empêcher l'adhérence des objets collants
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
B29C 45/00 - Moulage par injection, c.-à-d. en forçant un volume déterminé de matière à mouler par une buse d'injection dans un moule ferméAppareils à cet effet
B29L 7/00 - Objets plats, p. ex. pellicules ou feuilles
A load cap (10) comprises a central portion (12) having an edge (14), and a rim arrangement (16) on the edge. The rim arrangement comprises a plurality of corrugations (20) extending substantially parallel to the edge.
B65D 57/00 - Châssis ou supports internes pour objets souples, p. ex. raidisseursSéparateurs pour objets en piles ou en groupes, p. ex. pour empêcher l'adhérence des objets collants
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
A container (10) having a base (12) is disclosed. The container (10) also has an upstanding side wall (14) extending upwardly from the base (12). The base (12) has an upper face (16) and a lower face (18). The base (12) defines an external recess (20) extending upwardly from the lower face (18). The container (10) further includes a mesh formation in the recess (20). A lid (110) for a container (1100) is also disclosed. The lid (110) comprises a first surface (118) facing in a first direction. The lid (110) also has a second surface opposite the first surface (118). The lid (110) has a rim arrangement (111) comprising a holding formation (122) having a curved convexity (126A) facing in a second direction away from the first direction. The holding formation (122) comprises a plurality of spaced retaining members (128) on said convexity (126A). The retaining members (128) extend in the second direction, and are arranged so that a securing member (124) extending across the convexity (126A) between adjacent retaining members (128) is retained on the holding formation (122) by the retaining members (128).
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
20 - Meubles et produits décoratifs
Produits et services
Load-carrying trolleys; Load-carrying trolleys with wheels; Dollys. Transport pallets, principally of non-metallic materials; Transport pallets, principally of non-metallic materials, with wheels.
A layer pad (10) comprises a substantially flat sheet (12) having first and second opposite substantially planar faces (14, 16). The layer pad (10) further includes at least one raised formation (18) on at least one of the faces (14, 16).
B65D 57/00 - Châssis ou supports internes pour objets souples, p. ex. raidisseursSéparateurs pour objets en piles ou en groupes, p. ex. pour empêcher l'adhérence des objets collants
78.
Nestable containers having nestable lid arrangements
A container (10) comprises a base (12), upstanding walls (14) on the base and a lid arrangement (16) pivotally attacked to at least one of the walls at a hinge (17). The lid arrangement is pivotally moveable about the hinge from an open position to a closed position. When the lid arrangement (16) is in the open position, the container (10) can be nested within a similar further container having a similar further lid arrangement, and the lid arrangement (16) can be received within the further lid arrangement in a nested condition of the lid arrangements.
B65D 21/032 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage pour empiler des réceptacles les uns au-dessus des autres en position normale ou renversée, p. ex. présentant des éléments verticaux en saillie ou des parties en creux
B65D 21/02 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage
B65D 21/06 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage avec des parties mobiles conçues pour être placées dans les positions alternatives à emboîter lorsque les réceptacles sont vides, et à gerber lorsque les réceptacles sont pleins
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
B65D 43/16 - Couvercles ou chapeaux inamovibles s'ouvrant à charnières vers le haut ou vers le bas
79.
IMPROVEMENTS IN OR RELATING TO COMBINATION DOLLY-PALLETS
A displacement arrangement (48) for use in a combination dolly-pallet (10) comprises an impelling member (60) movable between first and second positions. A linkage (68) is pivotally connected to the impelling member (60). When the impelling member (60) moves between the first and second positions, the linkage (68) moves pivotally relative to the impelling member (60) to an extended position.
B60T 1/14 - Aménagements des éléments de freinage, c.-à-d. des parties de ceux-ci dans lesquelles se produit l'effet de freinage par action autre qu'en retardant les roues, p. ex. réaction par action directe sur la route
B62B 5/00 - Accessoires ou détails spécialement adaptés aux voitures à bras
B62B 5/04 - Mécanismes de freinageDispositifs d'immobilisation
B65D 19/42 - Aménagements ou emploi de rouleaux ou roues
A displacement arrangement for use in a combination dolly-pallet includes an impelling member movable between first and second positions. A linkage is pivotally connected to the impelling member. When the impelling member moves between the first and second positions, the linkage moves pivotally relative to the impelling member to an extended position.
B62D 33/08 - Carrosseries pour véhicules à marchandises caractérisées par l'assemblage entre la carrosserie et le châssis de véhicule comportant des moyens de réglage
B62B 3/02 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet comportant des parties réglables, rabattables, attachables, détachables ou transformables
B62B 5/00 - Accessoires ou détails spécialement adaptés aux voitures à bras
B62B 5/04 - Mécanismes de freinageDispositifs d'immobilisation
B60T 1/14 - Aménagements des éléments de freinage, c.-à-d. des parties de ceux-ci dans lesquelles se produit l'effet de freinage par action autre qu'en retardant les roues, p. ex. réaction par action directe sur la route
B65D 19/42 - Aménagements ou emploi de rouleaux ou roues
A displacement arrangement (48) for use in a combination dolly-pallet (10) comprises an impelling member (60) movable between first and second positions. A linkage (68) is pivotally connected to the impelling member (60). When the impelling member (60) moves between the first and second positions, the linkage (68) moves pivotally relative to the impelling member (60) to an extended position.
B62B 5/00 - Accessoires ou détails spécialement adaptés aux voitures à bras
B62B 5/04 - Mécanismes de freinageDispositifs d'immobilisation
B60T 1/14 - Aménagements des éléments de freinage, c.-à-d. des parties de ceux-ci dans lesquelles se produit l'effet de freinage par action autre qu'en retardant les roues, p. ex. réaction par action directe sur la route
B65D 19/42 - Aménagements ou emploi de rouleaux ou roues
An attaching apparatus (10) for attaching a support (100) to a base (102) is disclosed. The attaching apparatus comprises a holding arrangement (11 ) for holding the support. In one embodiment, the holding arrangement comprises a locating member (12) for locating the support on the base. The locating member is configured to be received within the support. A fastening arrangement (14, 18) is provided to fasten the holding arrangement to the base. In another embodiment, the holding arrangement includes a receiving member (24) to receive the support. A sealing member (32) may be provided on the receiving member to seal against the support.
E01F 13/04 - Dispositions pour interdire ou limiter la circulation, p. ex. portes, barrières pouvant être déplacées pour permettre ou empêcher le passage
A load cap (10) comprises a central portion (12) having an edge (14), and a rim arrangement (16) on the edge. The rim arrangement comprises a plurality of corrugations (20) extending substantially parallel to the edge.
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
A load capping arrangement (10) for stabilizing a load (100) comprising a plurality of articles (102) is disclosed. The load capping arrangement comprises a central region (12) for engaging at least some of the articles. A rim arrangement (15) extends around the central region and the rim arrangement is deformable from a non-deformed condition to a deformed condition around the load.
B65D 71/70 - Plateaux munis de projections ou de renfoncements afin de rassembler plusieurs objets, p. ex. éléments intermédiaires pour l'empilage
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
B65D 71/42 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux comprenent plusieurs objets maintenus ensemble uniquement de façon partielle par des éléments d'emballage formés en pliant un flan formés en pliant un seul flan en un élément à une seule couche
B65D 71/50 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux comprenant plusieurs objets maintenus ensemble uniquement de façon partielle par des éléments d'emballage formés autrement que par liage d'un flan
A container (10) comprises a base (12), upstanding walls (14) on the base and a lid arrangement (16) pivotally attached to at least one of the walls at a hinge (17). The lid arrangement is pivotally moveable about the hinge from an open position to a closed position. When the lid arrangement (16) is in the open position, the container (10) can be nested within a similar further container having a similar further lid arrangement, and the lid arrangement (16) can be received within the further lid arrangement in a nested condition of the lid arrangements.
B65D 21/06 - Réceptacles de forme spéciale ou pourvus de garnitures ou de pièces de fixation, pour faciliter l'emboîtement, le gerbage ou l'assemblage avec des parties mobiles conçues pour être placées dans les positions alternatives à emboîter lorsque les réceptacles sont vides, et à gerber lorsque les réceptacles sont pleins
B65D 43/16 - Couvercles ou chapeaux inamovibles s'ouvrant à charnières vers le haut ou vers le bas
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
20 - Meubles et produits décoratifs
Produits et services
Load-carrying trolleys with retractable wheels;
load-carrying trolleys. Transport pallets, principally of non-metallic materials,
with retractable wheels; transport pallets principally of
non-metal.
A fall prevention apparatus (410) for use adjacent a perimeter of an area. The fall prevention apparatus comprises a plurality of panels (440) and support means (14) for supporting the panels. The apparatus comprises a mounting arrangement (411) on the support means for mounting the panels thereon. The mounting arrangement projects from the support means to hold the panels spaced from the support means.
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
20 - Meubles et produits décoratifs
Produits et services
Load-carrying trolleys with retractable wheels; load-carrying trolleys Transport pallets, principally of non-metallic materials, with retractable wheels; transport pallets principally of non-metal
An attaching arrangement (48) is for attaching a support member (16) to a base member (18). The attaching arrangement comprises a receiving member (70) defining a recess (74) to receive the support member. The attaching arrangement further includes clamping means (72) to clamp the base member, and securing means to secure the support member to the attaching arrangement.
A load capping arrangement (10) for stabilising a load (100) comprising a plurality of articles (102) is disclosed. The load capping arrangement comprises a central region (12) for engaging at least some of the articles. A rim arrangement (15) extends around the central region and the rim arrangement is deformable from a non-deformed condition to a deformed condition around the load.
B65D 71/00 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux
A retaining assembly (10, 210) comprises a retaining device (16, 116) and a flexible elongate arrangement (12, 14, 212) moveable lengthwise relative to the retaining device. The retaining device comprises a support (28) for supporting the flexible elongate arrangement and engaging means (44, 46, 144, 146) on the support for engaging and retaining the flexible elongate arrangement in a desired position relative to the retaining device.
A load carrying apparatus (10) comprising a body (12) and a roller arrangement (18, 22) to allow the apparatus to be moved along the ground. The load carrying apparatus includes a bearer arrangement (34, 36) movable relative to the body between a ground engaging condition in which the bearer arrangement can engage the ground and a retracted condition in which the bearer arrangement is retracted. The load carrying apparatus includes shielding members on the body, separate from the bearer arrangement, the shielding members (28) extending around the roller arrangement. In one embodiment, the load carrying apparatus comprises a combination dolly-pallet.
B62D 33/08 - Carrosseries pour véhicules à marchandises caractérisées par l'assemblage entre la carrosserie et le châssis de véhicule comportant des moyens de réglage
B65D 19/42 - Aménagements ou emploi de rouleaux ou roues
B62B 5/00 - Accessoires ou détails spécialement adaptés aux voitures à bras
B62B 3/02 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet comportant des parties réglables, rabattables, attachables, détachables ou transformables
B62B 5/04 - Mécanismes de freinageDispositifs d'immobilisation
A method of handling a load comprising a plurality of articles (100) is disclosed. The method comprises providing a lifting assembly (10) comprising a plurality of carrying arrangements (12) arranged one above another. The carrying arrangements are movable between proximate and separated conditions, whereby adjacent carrying arrangements are spaced from each other by a greater distance in the separated condition than in the proximate condition. The method further includes disposing the articles on the carrying arrangements when the carrying arrangements are in the proximate condition, and moving the carrying arrangements to the separated condition, thereby moving the articles to a spaced configuration. With the carrying arrangements in the separated condition, the method includes delivering the articles to a support assembly (104) to dispose the articles at the support assembly in the spaced configuration.
F25D 25/02 - Introduction, port ou déchargement des produits à refroidir par étagères
B65D 1/34 - Plateaux ou réceptacles analogues peu profonds
F26B 5/06 - Procédés de séchage d'un matériau solide ou d'objets n'impliquant pas l'utilisation de chaleur par évaporation ou sublimation de l'humidité sous une pression réduite, p. ex. sous vide le procédé impliquant la congélation
A support apparatus (10) comprises a support arrangement (16) comprising a first support means (18) for supporting a plurality of articles. The support arrangement includes a second support means (30) for supporting a further support apparatus (10A). The first support means is moveable between an extended position, in which the first support means can support the plurality of articles, and a collapsed position, in which the second support means can support the further support apparatus.
B65D 85/18 - Réceptacles, éléments d'emballage ou paquets spécialement adaptés à des objets ou à des matériaux particuliers pour vêtements, chapeaux ou chaussures
B65D 19/06 - Palettes rigides avec parois latérales, p. ex. boîtes palettes avec corps formé par jonction ou union de plusieurs composants
A container arrangement (10A) comprises co-operating means (12A,14A) to co-operate with corresponding co-operating means (12B,14B) of a further container arrangement (10B) to effect nesting of the container arrangement (10A) and the further container arrangement (10B) relative to each other. The co-operating means (12A,14A) of the container arrangement can receive a portion of the co-operating means (12B, 14B) of the further container arrangement (10B). A portion of the co-operating means (12A,14A) of the container arrangement (10A) is configured to be received by the co-operating means (12B,14B) of the further container arrangement (10B) to effect the aforesaid nesting.
B62B 3/18 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet caractérisées par des moyens pour l'emboîtement ou l'empilage, p. ex. chariots pour achats emboîtables grâce à des supports de charges pivotants ou à des parties pivotantes de supports de charges, p. ex. paniers
B62B 3/10 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet caractérisées par des supports spécialement adaptés à des objets de forme définie
B62B 3/14 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet caractérisées par des moyens pour l'emboîtement ou l'empilage, p. ex. chariots pour achats
A load carrying apparatus (10) comprising a body (12) and a roller arrangement (18, 22) to allow the apparatus to be moved along the ground. The load carrying apparatus includes a bearer arrangement (34, 36) movable relative to the body between a ground engaging condition in which the bearer arrangement can engage the ground and a retracted condition in which the bearer arrangement is retracted. The load carrying apparatus includes shielding means on the body, separate from the bearer arrangement, the shielding means (28) extending around the roller arrangement. In one embodiment, the load carrying apparatus comprises a combination dolly-pallet.
B62B 3/00 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet
B62B 5/00 - Accessoires ou détails spécialement adaptés aux voitures à bras
B62B 5/04 - Mécanismes de freinageDispositifs d'immobilisation
B60T 1/14 - Aménagements des éléments de freinage, c.-à-d. des parties de ceux-ci dans lesquelles se produit l'effet de freinage par action autre qu'en retardant les roues, p. ex. réaction par action directe sur la route
B65D 19/42 - Aménagements ou emploi de rouleaux ou roues
A load securing system comprises a tensioning member (18), and a securing member (22) on the tensioning member. First and second containers (12) can be arranged adjacent each other in an array of containers. Each of said first and second containers has a cooperating formation (28) to cooperate with the securing member. The tensioning member can extend across the containers to the aforesaid cooperating formations, and the securing member can be secured to the cooperating formations. The tensioning member can be tensioned to secure the first and second containers to each other.
A load-carrying dolly having four wheels (6, 7) adjacent the corners of its platform (1) is rendered immobile by conversion to a pallet-like condition by lowering bearers (9, 10, 11) into contact with the floor or ground (24) and then raising the platform (1) slightly to raise the wheels (6, 7) clear of the floor or ground by means of either of two pedals (25, 32), one below each end of the platform (1), with linkage (of either of two forms, not shown) to bars (23) connecting in “slave” pairs of toggle links (20, 21) by means of which the bearers are suspended through beams (33) connecting upward extensions (12, 13, 14) at the ends of the bearers (9, 10, 11), the toggle links in each pair becoming locked by mating abutments (28) coming together when the links have passed slightly beyond in-line position, the mechanical advantage of the depressed pedal (25 or 32) being amplified by that of the pairs of toggle links when passing through in-line positions.
B62D 33/08 - Carrosseries pour véhicules à marchandises caractérisées par l'assemblage entre la carrosserie et le châssis de véhicule comportant des moyens de réglage
A load securing system comprises a tensioning member (18), and a securing member (22) on the tensioning member. First and second containers (12) can be arranged adjacent each other in an array of containers. Each of said first and second containers has a cooperating formation (28) to cooperate with the securing member. The tensioning member can extend across the containers to the aforesaid cooperating formations, and the securing member can be secured to the cooperating formations. The tensioning member can be tensioned to secure the first and second containers to each other.
B65D 71/04 - Aménagements pour attaches flexibles avec éléments de protection ou de support disposés entre l'attache et les objets ou matériaux, p. ex. pour empêcher le frottement des attaches
B65D 71/06 - Paquets d'objets maintenus ensemble par des éléments d'emballage pour la commodité du stockage ou du transport, p. ex. paquets compartimentés pour le transport à la main de plusieurs réceptacles tels que des boîtes de bière ou des bouteilles de boissons gazeusesBalles de matériaux comprenant plusieurs objets entièrement ou en grande partie reliés par des éléments d'emballage, p. ex. sous tension
