With this wearable-type antenna device, positions of a wearing target and a detection object can be detected accurately with certainty. A wearable-type antenna device 1 is wearably provided to a wrist P which is the wearing target, and performs presence detection using electromagnetic properties. The wearable-type antenna device is provided with: a device body 2 having a circuit board 20 built therein; and an antenna body 3 which has one end electrically connected to the circuit board 20 as a fixed end, and which can be wound, either alone or together with the device body 2, around the entire circumference of the wrist P in the circumferential direction without any gaps therebetween along the outer circumference of the wrist P.
The present invention provides a push button switch that prevents an occurrence of non-matching of contacts. The push button switch 1 includes a push-operatable and return-operatable push button 20, the first and second pairs of contacts C1, C2 that are respectively transferred to an open state by a push-in operation of the push button 20 and transferred to a contact state by a return operation of the push button 20, and a return-speed increasing means that applies and releases a load relative to the push button 20 during the return operation of the push button 20 and that functions to increase a return speed in the return-operation direction of the push button 20. The inclined angles R of the second inclined surfaces 241a, 242a of the respective engagement members 241, 242 is determined such that the second inclined surfaces 241a, 242a function as the return-speed increasing means.
H01H 13/62 - Interrupteurs ayant un organe moteur à mouvement rectiligne ou des organes adaptés pour pousser ou tirer dans une seule direction, p. ex. interrupteur à bouton-poussoir ayant un seul élément d'actionnement le contact retournant à son état initial après libération manuelle d'un accrochage
H01H 13/14 - Organes d'actionnement, p. ex. bouton-poussoir
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Providing temporary use of online non-downloadable software applications for monitoring programmable logic controllers, editing programs and data in programmable logic controllers and for uploading and downloading programs and data of programmable logic controllers; Software as a service (SAAS) services for smartphones and personal digital assistants featuring software for monitoring and editing data in programmable logic controllers and uploading and downloading programs of programmable logic controllers; Providing temporary use of online non-downloadable software for smartphones and personal digital assistants for monitoring and editing data in programmable logic controllers and uploading and downloading programs of programmable logic controllers; Providing temporary use of non-downloadable web-based applications for smartphones and personal digital assistants for monitoring and editing data in programmable logic controllers and uploading and downloading programs of programmable logic controllers
This remote operation system for remotely operating a plurality of to-be-operated objects makes it possible for an operator to confirm the reception status of the to-be-operated objects even with one-way communication. A remote operation system 1 for remotely operating a plurality of to-be-operated objects 3 comprises: a transmission unit 24 that performs transmissions to the to-be-operated objects 3 through an operation by an operator P; a reception unit 41 that receives a transmission signal from the transmission unit 24; an evaluation unit 42 that evaluates the reception signal received by the reception unit 41; a control unit 43 that controls the to-be-operated objects 3 so as to perform an operation based on the evaluation result by the evaluation unit 42; and a notification unit 40 that provides a notification based on the evaluation result by the evaluation unit 42.
H04Q 9/00 - Dispositions dans les systèmes de commande à distance ou de télémétrie pour appeler sélectivement une sous-station à partir d'une station principale, sous-station dans laquelle un appareil recherché est choisi pour appliquer un signal de commande ou pour obtenir des valeurs mesurées
The handheld device further reduces a burden on a body of an operator during operation. The table holder 1 for detachably holding the tablet T includes a holder body 2 having a base surface 20 on a frontside thereof for the tablet T to be disposed, a grip part 3 for the operator to grip by hand that is disposed on a backside of the holder body 2 and that is provided rotatably to take at least two orientations, and a support part 4 that is disposed on the backside of the holder body 2 and that is supported from below by at least a portion of a forearm Fa of the operator P.
Provided is a push-button switch in which the visibility of a push-button is improved and of which the structure is simplified. An emergency stop switch 1 is provided with a push-operable stop button 2, a cylindrical operating shaft 6 that can be moved by a push-operation of the stop button 2, and an LED 8 that is disposed inside the operating shaft 6. A convex curved surface 20a is formed on the surface of the stop button 2. A first concave-convex surface 20b is formed on the back surface of the stop button 2. Second concave-convex surfaces 6a, 6b are formed on an inner circumferential surface of the operating shaft 6.
H01H 13/02 - Interrupteurs ayant un organe moteur à mouvement rectiligne ou des organes adaptés pour pousser ou tirer dans une seule direction, p. ex. interrupteur à bouton-poussoir Détails
H01H 9/16 - Indicateurs de position, p. ex. "marche" ou "arrêt"
8.
EMERGENCY STOP SWITCH AND CONTROLLER PROVIDED THEREWITH
H01H 5/06 - Énergie accumulée par déformation de pièces élastiques par compression ou extension de ressorts à boudin
H01H 13/30 - Dispositions à action brusque consécutive à la déformation d'éléments élastiques utilisant la compression ou l'extension de ressorts à boudin une extrémité du ressort transmet le mouvement à l'élément de contact lorsque l'autre extrémité est mue par l'organe moteur
H01H 13/62 - Interrupteurs ayant un organe moteur à mouvement rectiligne ou des organes adaptés pour pousser ou tirer dans une seule direction, p. ex. interrupteur à bouton-poussoir ayant un seul élément d'actionnement le contact retournant à son état initial après libération manuelle d'un accrochage
9.
MOVABLE TERMINAL UNIT ASSEMBLY STRUCTURE, PUSH-BUTTON SWITCH EQUIPPED WITH SAME, CONTROLLER EQUIPPED WITH PUSH-BUTTON SWITCH, AND MOVABLE TERMINAL UNIT ASSEMBLY METHOD
Provided is a movable terminal unit assembly structure which is capable of improving assembly properties. A movable terminal unit 7 assembly structure, wherein a storage space S is demarcated by first and second wall sections 71, 72 which are positioned so as to face one another with a prescribed interval therebetween, the storage space S stores a movable terminal 8 therein, and also stores a coil spring 9 therein which biases the movable terminal 8 toward the first wall 71 side. A through-hole 72a through which the coil spring 9 may pass is formed in the second wall section 72, and a pressing member 10 which compresses and deforms the coil spring 9 is positioned in the through-hole 72a. The pressing member 10 has an outer-circumferential surface 10A which slides against the arc-shaped inner-circumferential surface of the through-hole 72a in the circumferential direction, and is held against the through-hole 72a via an engaging projection 72b and an engaging recess 10a which are respectively provided to said inner- and outer-circumferential surfaces.
H01H 1/30 - Contacts caractérisés par la manière dont les contacts coopérants s'engagent en butant l'un contre l'autre avec montage élastique entre guides-supports
H01H 13/62 - Interrupteurs ayant un organe moteur à mouvement rectiligne ou des organes adaptés pour pousser ou tirer dans une seule direction, p. ex. interrupteur à bouton-poussoir ayant un seul élément d'actionnement le contact retournant à son état initial après libération manuelle d'un accrochage
H01H 3/32 - Mécanismes-moteurs, c.-à-d. pour transmettre la force motrice aux contacts
H01H 13/14 - Organes d'actionnement, p. ex. bouton-poussoir
H01H 13/22 - Mécanismes moteurs agissant par action brusque
H01H 13/62 - Interrupteurs ayant un organe moteur à mouvement rectiligne ou des organes adaptés pour pousser ou tirer dans une seule direction, p. ex. interrupteur à bouton-poussoir ayant un seul élément d'actionnement le contact retournant à son état initial après libération manuelle d'un accrochage
12.
INFORMATION PROCESSING DEVICE FOR FACILITY, INFORMATION PROCESSING SYSTEM FOR FACILITY, AND PRODUCTION FACILITY
The purpose of the present invention is to provide an information processing device for a facility, an information processing system for a facility, and a production facility which can improve the convenience of a user who receives notification pertaining to the states of a device. The information processing device 6 for a facility is characterized by comprising: a PLC 8 which controls an operation of a device 7; and a programmable displayer 9 which is connected to an SNS server 3 via a communication line 2. The programmable displayer 9 includes: a storage unit 95 which stores a plurality of access tokens generated by the SNS server 3 in association with a plurality of pieces of contribution information in which the states of the device 7 are represented as character strings; a state acquisition means which acquires, from the PLC 8, state information that indicates the states of the device 7; an indicator control unit 96 which, when the state information satisfies a prescribed condition, extracts, from the storage unit 95, at least one access token and the pieces of contribution information corresponding to the states of the device 7; and a transmission means which transmits, to the SNS server 3, the extracted pieces of contribution information in associated with the access token.
H04L 67/562 - Courtage des services de mandataires
G05B 19/05 - Automates à logique programmables, p. ex. simulant les interconnexions logiques de signaux d'après des diagrammes en échelle ou des organigrammes
G06F 21/62 - Protection de l’accès à des données via une plate-forme, p. ex. par clés ou règles de contrôle de l’accès
H04L 51/214 - Surveillance ou traitement des messages en utilisant le transfert sélectif
H04Q 9/00 - Dispositions dans les systèmes de commande à distance ou de télémétrie pour appeler sélectivement une sous-station à partir d'une station principale, sous-station dans laquelle un appareil recherché est choisi pour appliquer un signal de commande ou pour obtenir des valeurs mesurées
H04Q 9/02 - Dispositions à fonctionnement automatique
In this linking device (1), when a resilient member (4) is in an unconnected state, a restoring force vector (81) substantially overlaps a first reference line (82) and the restoring force and an opposing force are balanced with each other, whereby the position of an operating portion (5) is maintained and the state of the resilient member (4) is kept in the unconnected state. When the position of the operating portion (5) is changed in a state in which an electric wire is inserted between a terminal portion (31) and the resilient member (4) in the unconnected state, the part of the operating portion (5) in which the opposing force is generated transitions from a second part (514) to a third part, whereby a second reference line is generated, and the resilient member (4) is restored from the unconnected state by the restoring force and transitions to a connected state in which the electric wire is clamped between the resilient member (4) and the terminal portion (31). This allows for a reduction in the force required to disengage the unconnected state.
In a safety control device according to the present invention, safety control logic is preconstructed so that equipment subject to control is controlled safely, and a computational processing unit executes control in accordance with the safety control logic on the equipment subject to control. In such a safety control device, a discrimination processing unit discriminates the type of safety input equipment connected to an input unit according to the safety control logic, the discrimination being made on the basis of an input signal inputted into the input unit from the safety input equipment. Thereafter, the computational processing unit executes control in accordance with the safety control logic on the equipment subject to control according to the type of safety input equipment discriminated by the discrimination processing unit.
G05B 19/05 - Automates à logique programmables, p. ex. simulant les interconnexions logiques de signaux d'après des diagrammes en échelle ou des organigrammes
In the present invention, in a contact mechanism (5) of an enabling switch (1), an operation member (51) is retained by a button (3) and can move relative to the button (3). A switch member (52) makes direct contact with the operation member (51) and changes the state of a contact (4) by changing position as a result of a movement of the operation member (51). In the enabling switch (1), by placing the operation member (51) retained by the button (3) in direct contact with the switch member (52) and changing the position of the switch member (52) as a result of a movement of the operation member (51), the state of the contact (4) is switched in a first position, a second position and a third position. As a result, it is possible to reduce the size of the enabling switch (1).
H01H 13/58 - Interrupteurs ayant un organe moteur à mouvement rectiligne ou des organes adaptés pour pousser ou tirer dans une seule direction, p. ex. interrupteur à bouton-poussoir ayant un seul élément d'actionnement le contact retournant à son état initial lors de l'application suivante de la force motrice avec élément d'entraînement du contact tourné pas à pas dans un sens
09 - Appareils et instruments scientifiques et électriques
Produits et services
Electrical terminal blocks; electrical terminal boxes; resistances, electric; distribution boards, namely, electric control panels; distribution boxes, in the nature of electrical distribution boxes; electricity distribution consoles; electric connectors; electric plugs; electrical plugs, electrical sockets and other contacts in the nature of electricity distribution consoles; relays, electric; electrical power distribution or control machines and apparatus; rotary converters; phase modifiers; batteries, electric; electrical cells and batteries; ammeters; electric or magnetic meters and testers, namely, electromagnetic flow meters; wires, electric; cables, electric; connections for electric lines; conductors, electric; electric buzzers; wireless queue buzzers; coils, electric; electronic machines, apparatus and their parts in the nature of ticket dispensing terminals, electronic; magnets; graphite electrodes; magnetic cores; resistance wires; electrodes
Electric Luminaries; LED lights in the nature of lighting fixtures; LED safety lamps; light-emitting diodes (LED) lighting apparatus; lighting apparatus, namely, lighting installations; electric lamps and other lighting apparatus installation
Provided is a hand-held device capable of further reducing the burden on the body of an operator during operation. A tablet holder 1 for holding a tablet T in a detachable manner is provided with a holder body 2 that has a base surface 20 on the front side so as to attach the tablet T, a grip portion 3 for an operator to grasp by hand, which is disposed on the rear side of the holder body 2 and provided so as to be rotatable in at least two directions, and a support portion 4 disposed on the rear side of the holder body 2 and supported from below by at least a part of a forearm Fa of the operator P.
The handheld device improves an operability. The handheld device 1 includes a tablet 2 provided on the front side of the device 1 and a grip part 3 provided on the backside of the device 1 and to be griped by the operator H. The grip part 3 is rotatable relative to the tablet 2.
This ultrafine bubble (UFB) liquid generation method comprises: a step (step S11) for dispersing, in water, an additive that is a hydrophilic food additive to generate a subject liquid; and a step (steps S12 to S14) for mixing air with the pressurized subject liquid to generate UFBs of the air within the subject liquid, thereby generating a UFB liquid that contains UFBs. The additive is a polyglycerin fatty acid ester or a sucrose fatty acid ester. This makes it possible to generate a UFB liquid that is safe for humans, that contains UFBs in a high concentration, and that has high long-term stability of UFBs.
B01F 23/2375 - Mélange de gaz avec des liquides en introduisant des gaz dans des milieux liquides, p. ex. pour produire des liquides aérés caractérisé par les propriétés physiques ou chimiques des gaz ou des vapeurs introduits dans le milieu liquide pour obtenir des bulles fines, c.-à-d. des bulles d'une taille inférieure à 100 µm pour obtenir des bulles fines, c.-à-d. des bulles d'une taille inférieure à 1 µm
B01F 23/2326 - Mélange de gaz avec des liquides en introduisant des gaz dans des milieux liquides, p. ex. pour produire des liquides aérés en utilisant des moyens de mélange à écoulement pour introduire les gaz, p. ex. des chicanes en ajoutant le composant principal de l’écoulement par des moyens d'aspiration, p. ex. en utilisant un éjecteur
B01F 25/312 - Mélangeurs à injecteurs dans des conduits ou des tubes dans lesquels circule le composant principal avec des éléments VenturiLeurs détails
B01F 25/45 - Mélangeurs dans lesquels les composants du mélange sont pressés ensemble au travers d’orifices ou d’espaces interstitiels, p. ex. entre des perles
B01F 25/53 - Mélangeurs de circulation, p. ex. dans lesquels au moins une partie du mélange est évacuée d'un récipient et réintroduite dans celui-ci dans lesquels le mélange est évacué d’un récipient et réintroduit dans celui-ci par un tube de recirculation, dans lequel un composant supplémentaire est introduit
B01J 13/00 - Chimie des colloïdes, p. ex. production de substances colloïdales ou de leurs solutions, non prévue ailleursFabrication de microcapsules ou de microbilles
09 - Appareils et instruments scientifiques et électriques
Produits et services
Switches; switches, electric; power switches; power distribution or control machines and apparatus; rotary converters; phase modifiers; covers for personal digital assistants (PDAs); protective cases for personal digital assistants; covers for smartphones; cases for smartphones; holders for personal digital assistants; holders for tablet computers; holders for smartphones; personal digital assistants; covers for tablet computers; stands adapted for tablet computers; protective covers and cases for tablet computers; tablet computers; computer stands specially designed for holding a computer, printer and accessories; computer peripherals and accessories; electronic control systems for machines; electronic control systems for robots; telecommunication machines and apparatus.
H01H 1/18 - Contacts caractérisés par la manière dont les contacts coopérants s'engagent en butant l'un contre l'autre avec glissement subséquent
H01H 21/28 - Organes moteurs, p. ex. manette agencés pour retourner à la position normale après suppression de la force motrice adaptés pour être actionnés dans une position limite ou autre position prédéterminée dans le trajet d'un corps, le mouvement relatif de l'interrupteur et du corps ayant principalement un autre but que d'actionner l'interrupteur, p. ex. interrupteur de porte, interrupteur de fin de course, interrupteur de niveau d'étage d'un ascenseur
H01H 21/42 - Mécanismes moteurs à action brusque produite par compression ou tension d'un ressort à boudin
23.
Operation switch unit with operation support function, operation unit with operation support function, and operation support system
The emergency stop switch 2 performs an operation support of an operation switch, and not only improves operability and safety but also simplifies the structure to enhance reliability. The emergency stop switch (or operation switch unit) 2 with an operation support function includes an emergency stop button (or operation switch) 21 for switching the state of the contact, a reception part (or detection part) 32 for detecting a remote operation of the emergency stop button 21 and an electromagnetic solenoid (or actuating part) 3 that is disposed between the contact and the emergency stop button 21 and that actuates the emergency stop button 21 on the basis of the remote operation received (or detected) by the reception part 32. The emergency stop button 21 is located on one end side of the emergency stop switch 2 and the contact is located on the other end side of the emergency stop switch 2.
G05B 19/409 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique caractérisée par l'utilisation de l'entrée manuelle des données [MDI] ou par l'utilisation d'un panneau de commande, p. ex. commande de fonctions avec le panneauCommande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique caractérisée par les détails du panneau de commande ou par la fixation de paramètres
H01H 13/14 - Organes d'actionnement, p. ex. bouton-poussoir
H01H 13/62 - Interrupteurs ayant un organe moteur à mouvement rectiligne ou des organes adaptés pour pousser ou tirer dans une seule direction, p. ex. interrupteur à bouton-poussoir ayant un seul élément d'actionnement le contact retournant à son état initial après libération manuelle d'un accrochage
24.
Holder for an electronic device such as a tablet or tablet-type computer
09 - Appareils et instruments scientifiques et électriques
Produits et services
Power distribution or control machines and apparatus, namely, electric power distribution machines and electrical power distribution units; rotary converters; phase modifiers; branch boxes, namely, electric power distribution boxes; circuit breakers; distribution boards, namely, electric power distribution blocks; electric circuit closers; electric connectors; electric current rectifiers; electric reactors; electric relays; electric resistors; electric switches; electric transformers; induction voltage regulators; inverters; photovoltaic inverters; power inverters; inverters for power supply; battery chargers; chargers for electric batteries; voltage stabilizers for wind and photovoltaic power generation; electric power supply apparatus; telecommunication devices and apparatus, namely, telecommunication switches and telecommunications transmitters; high frequency apparatus, namely, high frequency switches; condensers being capacitors
In this connecting device, when a resilient member (4) is in an unconnected state, a restoring force vector (81) of the resilient member (4) substantially overlaps a reference line (82), which is a straight line connecting a first part (513) and a second part (514), and the restoring force and a reaction force are balanced. As a result, the position of an operating portion (5) is maintained, and the state of the resilient member (4) is maintained in the unconnected state. Further, in a state in which an electric wire has been inserted between a terminal portion (3) and the resilient member (4) in the unconnected state, the position of the operating portion (5) is changed, and the restoring force vector (81) is displaced from the reference line (82), as a result of which the resilient member (4) is restored from the unconnected state by means of the restoring force, and transitions to a connected state in which the electric wire is sandwiched between the resilient member (4) and the terminal portion (3). The structure of the connection device can thus be simplified.
09 - Appareils et instruments scientifiques et électriques
12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
Produits et services
Industrial robots; machines and machine tools; motors and
engines (other than for land vehicles); power tools;
power-operated tools; robotic mechanisms as parts of
loading-unloading machines and apparatus; robots for use in
industry; machinery gears; machine motors; machine motors
and engines; electric motors for machines. Scientific apparatus and instruments (other than for medical
use); software; downloadable software applications; computer
programs; software packages; enterprise resource planning
(ERP) software; computers; microcomputers; computer
peripheral devices; components for computers; electronic
publications (downloadable); downloadable multimedia files;
electronic databases recorded on computer media; computer
database servers; sensors; electric sensors; electronic
sensors; magnetic sensors; optical sensors; laser sensors;
digital sensors; sensors for engines; distance sensors;
vibration sensors; measuring sensors; presence sensors;
tracking apparatus; electronic tracking apparatus and
instruments; computer hardware for the processing location
data; navigation software; electronic navigation apparatus;
electronic navigation systems; navigation apparatus and
instruments; computer programs intended to vehicles
autonomous navigation; radars; security alarms; security
software; life saving and protecting equipment; computer
buses; bus interfaces; data bus interface units. Vehicles; electric vehicles; industrial vehicles; unmanned
vehicles; motorized wheels; autonomous motorized wheels;
electric wheels; electric unicycles; wheel brakes; wheel
rims; vehicle wheels; motorized unicycles; apparatus for
locomotion by land, air or water; motors and engines for
land vehicles; cycles; cycle tires, wheels or saddles;
tires; handling carts; transporting robots.
When an initial position of an enabling switch is given as a first position (301), a position of the enabling switch in which a movable member is most pressed is given as a third position (303), and a rising start position of a maximum rise of a load is given as a second position (302), the rising start position being between the first position (301) and the third position (303), a minor peak (341) of the load appears between the first position (301) and the second position (302). An ON switching position (311) is between a falling start position (323) of the minor peak (341) and the second position (302). A maximum load during the minor peak (341) is greater than or equal to the load in the ON switching position (311) and less than or equal to the load in an OFF switching position (312).
H01H 13/64 - Interrupteurs ayant un organe moteur à mouvement rectiligne ou des organes adaptés pour pousser ou tirer dans une seule direction, p. ex. interrupteur à bouton-poussoir ayant un seul élément d'actionnement dans lequel l'interrupteur a plus de deux positions électriquement distinctives, p. ex. interrupteurs, bouton-poussoir à plusieurs positions
H01H 13/28 - Dispositions à action brusque consécutive à la déformation d'éléments élastiques utilisant la compression ou l'extension de ressorts à boudin
This switch device is provided with a device case, a first fixed contact, a first movable contact, an operator, and a return spring. Here, the first fixed contact and the first movable contact are disposed inside the device case and can come into contact with each other. The operator is for causing the first movable contact to move. The return spring is disposed inside the device case and causes the operator to return to the original position thereof by acting on the operator. In addition, a flange part projecting from a side surface of the operator is provided on the operator, and a holding part for holding the flange part is provided on an inner surface of the device case.
This hand carry device is for improving operability thereof. A hand carry device 1 is provided with: a tablet 2 disposed on the front surface side of the device; and a gripping part 3 that is disposed on the back surface side of the device and that is for gripping by an operator H. The gripping part 3 is provided so as to be rotatable with respect to the tablet 2.
Provided is a handheld device with reduced burden on an operator. A handheld device 1 is provided with a tablet 2 arranged on a front face side of the device, and a grip portion 3 arranged on a reverse face side of the device which is to be gripped by an operator H with the palm facing the front face side of the device. The grip portion 3 has a spherical shape.
This connection device comprises: a device case in which an electric wire insertion hole is provided; a terminal contacted by an electric wire plugged into the electric wire insertion hole; and a locking spring that locks the electric wire, and maintains the contact state of the electric wire to that terminal. The locking spring has: a first leg part fixed within the device case; a curved part extending from the first leg part in a curved manner; and a second leg part that is a part elastically connected to the first leg part with the curved part interposed therebetween, the second leg part being displaced in response to the electric wire being inserted into the electric wire insertion hole. Also, a probe insertion hole that makes contact of the probe to the curved part of the locking spring possible is provided in the device case.
The emergency stop switch unit 2 as an operation switch unit includes a direct operation part 20A and an alternative operation part 20B. The direct operation part 20A has an emergency stop button 21 adapted to be directly operated. The alternative operation part 20B is adapted to be linked with the direct operation part 20A and alternatively operates the emergency stop button 21 in place of the direct operation part 20A. The alternative operation part 20B has a reception part 32 that detects a remote operation of the emergency stop button 21 and an electromagnetic solenoid 3 that actuates the emergency stop button 21 on the basis of the remote operation detected by the reception part 32.
