Produits et services

Laser assisted machining device based on optical technology and comprising diamond tool for use in the cutting and forming of materials; machines and machine tools for treatment of materials using lasers; precision machine tools, namely, laser cutting and engraving machines; machine tools, namely, powered machines for cutting or shaping or finishing metals or other materials; machines and machine tools for the cutting and forming of materials; equipment used in the manufacturing process to produce products, namely, machines for the production of photonic components; diamond-pointed metal-cutting tools; precision machine tools, namely, hard metal tools, high speed steel (HSS) tools, carbide tools, ceramic tools, poly crystalline diamond (PCD) tools, and diamond-coated and diamond-uncoated tools, and hard metal tools, all for use in the cutting and forming of materials by others. Optical components and assemblies for use in industrial applications, namely, cameras; spectrometers; microscopes; eyepiece adapters; polarizers; filters for optical devices; mirrors; lenses; optical lens assemblies for delivering light and images in optical systems; lens kits comprising beam expanders and optical lens; achromatic lenses; mounts for optical components; magnification systems consisting of optical inspection or imaging systems comprised of optics, namely, lenses, mirrors, prisms, or beamsplitters, with or without optical coatings, arranged or assembled to produce an image on an array, sensor, or similar imaging device, and a camera for the purpose of image magnification, calibration, resolution, distortion or related inspection, specifying, setting up and converting field of view; and optics test equipment, namely, lenses, cameras, optical imaging targets, ronchi rulings, and micrometers; optical devices, namely, laser beam expanders; equipment used to test products, namely, machines for the characterization and testing of optical power level and distribution of laser diodes, receivers, modulators, planar light chips, fiber arrays and other photonic devices; equipment used in the manufacturing process to test products, namely, machines for the characterization and testing of optical power level and distribution of laser diodes, receivers, modulators, planar light chips, fiber arrays and other photonic devices. Custom manufacture of build-to-print custom and stock precision plastic, glass, metal, and crystal optical components for defense, medical, and commercial applications; treatment of materials by laser beam for others by affecting the manufacturing process.

Produits et services

Laser assisted machining device, comprised primarily of a laser, electronic controls, fiber delivery connector, alignment mechanism, optics, tool post, and a diamond tool for use in the cutting and forming of materials; machines and machine tools for treatment of materials using lasers; precision machine tools, namely, laser cutting and engraving machines; machine tools, namely, powered machines for cutting or shaping or finishing metals or other materials; machines and machine tools for the cutting and forming of materials; Equipment used in the manufacturing process to produce or test products, namely, machines for the alignment and attachment of fiber optics to produce photonic components, and machines for the characterization and testing of optical power level and distribution of laser diodes, receivers, modulators, planar light chips, fiber arrays and other photonic devices; Diamond-pointed metal-cutting tools; Precision machine tools, namely, hard metal tools, high speed steel (HSS) tools, carbide tools, ceramic tools, poly crystalline diamond (PCD) tools, and diamond-coated and diamond-uncoated tools, and hard metal tools, all for use in the cutting and forming of materials by others Custom manufacture of build-to-print custom and stock precision plastic, glass, metal, and crystal optical components for defense, medical, and commercial applications; Treatment of materials by laser beam for others by affecting the manufacturing process Optical components and assemblies for use in industrial applications, namely, cameras; spectrometers; microscopes; eyepiece adapters for microscopes; Optical filters in the nature of polarizers; filters for optical devices; signal mirrors; inspection mirrors; reflective mirrors to prevent accidents; telescopic mirrors for automotive use; scientific and technical apparatus, namely, optical mirrors; lenses for protective face shields; eyeglass lenses; sunglass lenses; lenses for welding helmets; anti-reflective lenses; magnifying lenses; lenses for astrophotography; lenses for industrial laser cutting machines; contact lenses; wide-angle lenses for cameras; conversion lenses for cameras; lenses for cameras; spectacle lenses; lenses for microscopes; close-up lenses; circle lenses; lenses for cellular cameras; optical lenses; ophthalmic lenses; antireflective lenses; lenses for telescopes; lenses for photographic apparatus; optical lens assemblies for delivering light and images in optical systems; lens kits comprising beam expanders and optical lens; Optical lenses in the nature of achromats; optical mounts; magnification systems consisting of optical inspection or imaging systems comprised of optics, namely, lenses, mirrors, prisms, or beamsplitters, with or without optical coatings, arranged or assembled to produce an image on an array, sensor, or similar imaging device, and a camera for the purpose of image magnification, calibration, resolution, field or view, distortion or related inspection; and optics test equipment, namely, lenses, cameras, optical imaging targets, ronchi rulings, and micrometers; optical devices, namely, laser beam expanders

Produits et services

Precision machine tools, namely, diamond metal-cutting tools all for use in the cutting and forming of materials.

Produits et services

Laser assisted machining device for use in the cutting and forming of materials; machines and machine tools for treatment of materials using lasers; precision machine tools, namely, laser cutting and engraving machines; machine tools, namely, powered machines for cutting or shaping or finishing metals or other materials; machines and machine tools for the cutting and forming of materials. Treatment of materials by laser beam for others.

Produits et services

Precision machine tools, namely, diamond metal-cutting tools all for use in the cutting and forming of materials

Produits et services

Treatment of materials by laser beam for others Laser assisted machining device, comprised primarily of a laser, electronic controls, fiber delivery connector, alignment mechanism, optics, tool post, and a diamond tool for use in the cutting and forming of materials; machines and machine tools for treatment of materials using lasers; precision machine tools, namely, laser cutting and engraving machines; machine tools, namely, powered machines for cutting or shaping or finishing metals or other materials; machines and machine tools for the cutting and forming of materials

Abrégé

Optomechanical tools are disclosed. The optomechanical tools include a body of material having an entrance face, a rake face, a flank face, a rake side face, and a flank side face. The rake side face and the flank side face are connected to the entrance face. The rake side face is connected to the rake face. The flank side face is connected to the flank face. The rake face is connected to the flank face to define a curved cutting edge. The entrance face extends away from the flank side face to define a back-relief angle. The rake face extends away from the rake side face to define a rake angle. The entrance face is configured to direct a light beam toward one or more of the rake face, the flank face, the rake side face, the flank side face, and the curved cutting edge and through one or more of the rake face, the flank face, and the curved cutting edge, causing the light beam to refract onto the workpiece. Systems are also disclosed. Methods for transmitting a light beam through an optomechanical tool are also disclosed.

Classes IPC  ?

• B23B 27/14 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier
• G02B 7/04 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour lentilles avec mécanisme de mise au point ou pour faire varier le grossissement
• G02B 7/18 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour prismesMontures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques pour miroirs
• G02B 17/08 - Systèmes catadioptriques
• G02B 5/18 - Grilles de diffraction
• B23K 26/00 - Travail par rayon laser, p. ex. soudage, découpage ou perçage

Abrégé

Optomechanical tools (10a-10o), systems, and methods are disclosed. An exemplary optomechanical tool includes a body of material having an entrance face, a rake face, a flank face, a rake side face, and a flank side face. The rake face is connected to the flank face to define a curved cutting edge. The entrance face extends away from the flank side face to define a back-relief angle. The rake face extends away from the rake side face to define a rake angle. The entrance face is configured to direct a light beam toward one or more of the rake face, the flank face, the rake side face, the flank side face, and the curved cutting edge and through one or more of the rake face, the flank face, and the curved cutting edge, causing the light beam to refract onto the workpiece.

Classes IPC  ?

• B23B 27/14 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier
• B23P 25/00 - Traitement auxiliaire des pièces, avant ou pendant les opérations d'usinage, afin de faciliter l'action de l'outil ou d'obtenir pour les pièces l'état final désiré, p. ex. la réduction des contraintes internes

Abrégé

Optomechanical tools (10a-10o) are disclosed. The optomechanical tools Include a body of material having an entrance face, a rake face, a flank face, a rake side face, and a flank side face. The rake side face and the flank side face are connected to the entrance face. The rake side face is connected to the rake face. The flank side face is connected to the flank face. The rake face is connected to the flank face to define a curved cutting edge. The entrance face extends away from the flank side face to define a back-relief angle. The rake face extends away from the rake side face to define a rake angle. The entrance face is configured to direct a light beam toward one or more of the rake face, the flank face, the rake side face, the flank side face, and the curved cutting edge and through one or more of the rake face, the flank face, and the curved cutting edge, causing the light beam to refract onto the workpiece. Systems are also disclosed. Methods for transmitting a light beam through an optomechanical tool are also disclosed.

Classes IPC  ?

• B23B 27/14 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier
• B23P 25/00 - Traitement auxiliaire des pièces, avant ou pendant les opérations d'usinage, afin de faciliter l'action de l'outil ou d'obtenir pour les pièces l'état final désiré, p. ex. la réduction des contraintes internes

Abrégé

A laser-transmitting machining tool is disclosed. The laser-transmitting machining tool has a plurality of faces including an entrance face, a rake face, a flank face connected to the rake face, a rake side face extending between the entrance face and the rake face, and a flank side face extending between the entrance face and the flank face. The connection of the rake face to the flank face defines a cutting edge. The rake face extends away from the rake side face to define a rake angle. The entrance face is configured to receive and refract a laser beam to the rake face, the flank face, and the cutting edge for causing the laser beam to refract into and heat the workpiece at a compression region extending proximate at least the rake face and a tensile region extending proximate the flank face. A system for machining a workpiece is disclosed. A method for machining a workpiece is also disclosed.

Classes IPC  ?

• B23P 25/00 - Traitement auxiliaire des pièces, avant ou pendant les opérations d'usinage, afin de faciliter l'action de l'outil ou d'obtenir pour les pièces l'état final désiré, p. ex. la réduction des contraintes internes
• B23C 5/16 - Outils de fraisage caractérisés par des particularités physiques autres que la forme
• B23B 27/14 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier
• B23K 26/064 - Mise en forme du faisceau laser, p. ex. à l’aide de masques ou de foyers multiples au moyen d'éléments optiques, p. ex. lentilles, miroirs ou prismes

Abrégé

A laser-transmitting machining tool (10) is disclosed. The laser-transmitting machining tool (10) has a plurality of faces including an entrance face (12), a rake face (14), a flank face (16) connected to the rake face (14), a rake side face (18) extending between the entrance face (12) and the rake face (14), and a flank side face (20) extending between the entrance face (12) and the flank face (16). The connection of the rake face (14) to the flank face (16) defines a cutting edge (22). The rake face (14) extends away from the rake side face (18) to define a rake angle (?14). The entrance face (12) is configured to receive and refract a laser beam (L) to the rake face (14), the flank face (16), and the cutting edge (22) for causing the laser beam (L) to refract into and heat the workpiece (W) at a compression region (WC) extending proximate at least the rake face (14) and a tensile region (WT) extending proximate the flank face (16). A system for machining a workpiece (W) is disclosed. A method for machining a workpiece (W) is also disclosed.

Classes IPC  ?

• B23K 26/70 - Opérations ou équipement auxiliaires
• G02B 26/08 - Dispositifs ou dispositions optiques pour la commande de la lumière utilisant des éléments optiques mobiles ou déformables pour commander la direction de la lumière
• G02B 26/10 - Systèmes de balayage

Abrégé

A laser-transmitting machining tool (10) is disclosed. The laser-transmitting machining tool (10) has a plurality of faces including an entrance face (12), a rake face (14), a flank face (16) connected to the rake face (14), a rake side face (18) extending between the entrance face (12) and the rake face (14), and a flank side face (20) extending between the entrance face (12) and the flank face (16). The connection of the rake face (14) to the flank face (16) defines a cutting edge (22). The rake face (14) extends away from the rake side face (18) to define a rake angle (θ14). The entrance face (12) is configured to receive and refract a laser beam (L) to the rake face (14), the flank face (16), and the cutting edge (22) for causing the laser beam (L) to refract into and heat the workpiece (W) at a compression region (WC) extending proximate at least the rake face (14) and a tensile region (WT) extending proximate the flank face (16). A system for machining a workpiece (W) is disclosed. A method for machining a workpiece (W) is also disclosed.

Classes IPC  ?

• B23K 26/70 - Opérations ou équipement auxiliaires
• G02B 26/10 - Systèmes de balayage
• G02B 26/08 - Dispositifs ou dispositions optiques pour la commande de la lumière utilisant des éléments optiques mobiles ou déformables pour commander la direction de la lumière

Abrégé

A laser-transmitting machining tool is disclosed. The laser-transmitting machining tool has a plurality of faces including an entrance face, a rake face, a flank face connected to the rake face, a rake side face extending between the entrance face and the rake face, and a flank side face extending between the entrance face and the flank face. The connection of the rake face to the flank face defines a cutting edge. The rake face extends away from the rake side face to define a rake angle. The entrance face is configured to receive and refract a laser beam to the rake face, the flank face, and the cutting edge for causing the laser beam to refract into and heat the workpiece at a compression region extending proximate at least the rake face and a tensile region extending proximate the flank face. A system for machining a workpiece is disclosed. A method for machining a workpiece is also disclosed.

Classes IPC  ?

• B23K 26/352 - Travail par rayon laser, p. ex. soudage, découpage ou perçage pour le traitement de surface
• B23K 26/362 - Gravure au laser
• B23P 25/00 - Traitement auxiliaire des pièces, avant ou pendant les opérations d'usinage, afin de faciliter l'action de l'outil ou d'obtenir pour les pièces l'état final désiré, p. ex. la réduction des contraintes internes
• B23K 26/064 - Mise en forme du faisceau laser, p. ex. à l’aide de masques ou de foyers multiples au moyen d'éléments optiques, p. ex. lentilles, miroirs ou prismes
• B23B 27/14 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier
• B23C 5/16 - Outils de fraisage caractérisés par des particularités physiques autres que la forme
• B23K 26/00 - Travail par rayon laser, p. ex. soudage, découpage ou perçage
