09 - Scientific and electric apparatus and instruments
40 - Treatment of materials; recycling, air and water treatment,
Goods & Services
Laser assisted machining device based on optical technology
and comprising diamond tool for use in the cutting and
forming of materials; machines and machine tools for
treatment of materials using lasers; precision machine
tools, namely, laser cutting and engraving machines; machine
tools, namely, powered machines for cutting or shaping or
finishing metals or other materials; machines and machine
tools for the cutting and forming of materials; equipment
used in the manufacturing process to produce products,
namely, machines for the production of photonic components;
diamond-pointed metal-cutting tools; precision machine
tools, namely, hard metal tools, high speed steel (HSS)
tools, carbide tools, ceramic tools, poly crystalline
diamond (PCD) tools, and diamond-coated and diamond-uncoated
tools, and hard metal tools, all for use in the cutting and
forming of materials by others. Optical components and assemblies for use in industrial
applications, namely, cameras; spectrometers; microscopes;
eyepiece adapters; polarizers; filters for optical devices;
mirrors; lenses; optical lens assemblies for delivering
light and images in optical systems; lens kits comprising
beam expanders and optical lens; achromatic lenses; mounts
for optical components; magnification systems consisting of
optical inspection or imaging systems comprised of optics,
namely, lenses, mirrors, prisms, or beamsplitters, with or
without optical coatings, arranged or assembled to produce
an image on an array, sensor, or similar imaging device, and
a camera for the purpose of image magnification,
calibration, resolution, distortion or related inspection,
specifying, setting up and converting field of view; and
optics test equipment, namely, lenses, cameras, optical
imaging targets, ronchi rulings, and micrometers; optical
devices, namely, laser beam expanders; equipment used to
test products, namely, machines for the characterization and
testing of optical power level and distribution of laser
diodes, receivers, modulators, planar light chips, fiber
arrays and other photonic devices; equipment used in the
manufacturing process to test products, namely, machines for
the characterization and testing of optical power level and
distribution of laser diodes, receivers, modulators, planar
light chips, fiber arrays and other photonic devices. Custom manufacture of build-to-print custom and stock
precision plastic, glass, metal, and crystal optical
components for defense, medical, and commercial
applications; treatment of materials by laser beam for
others by affecting the manufacturing process.
40 - Treatment of materials; recycling, air and water treatment,
09 - Scientific and electric apparatus and instruments
Goods & Services
Laser assisted machining device, comprised primarily of a laser, electronic controls, fiber delivery connector, alignment mechanism, optics, tool post, and a diamond tool for use in the cutting and forming of materials; machines and machine tools for treatment of materials using lasers; precision machine tools, namely, laser cutting and engraving machines; machine tools, namely, powered machines for cutting or shaping or finishing metals or other materials; machines and machine tools for the cutting and forming of materials; Equipment used in the manufacturing process to produce or test products, namely, machines for the alignment and attachment of fiber optics to produce photonic components, and machines for the characterization and testing of optical power level and distribution of laser diodes, receivers, modulators, planar light chips, fiber arrays and other photonic devices; Diamond-pointed metal-cutting tools; Precision machine tools, namely, hard metal tools, high speed steel (HSS) tools, carbide tools, ceramic tools, poly crystalline diamond (PCD) tools, and diamond-coated and diamond-uncoated tools, and hard metal tools, all for use in the cutting and forming of materials by others Custom manufacture of build-to-print custom and stock precision plastic, glass, metal, and crystal optical components for defense, medical, and commercial applications; Treatment of materials by laser beam for others by affecting the manufacturing process Optical components and assemblies for use in industrial applications, namely, cameras; spectrometers; microscopes; eyepiece adapters for microscopes; Optical filters in the nature of polarizers; filters for optical devices; signal mirrors; inspection mirrors; reflective mirrors to prevent accidents; telescopic mirrors for automotive use; scientific and technical apparatus, namely, optical mirrors; lenses for protective face shields; eyeglass lenses; sunglass lenses; lenses for welding helmets; anti-reflective lenses; magnifying lenses; lenses for astrophotography; lenses for industrial laser cutting machines; contact lenses; wide-angle lenses for cameras; conversion lenses for cameras; lenses for cameras; spectacle lenses; lenses for microscopes; close-up lenses; circle lenses; lenses for cellular cameras; optical lenses; ophthalmic lenses; antireflective lenses; lenses for telescopes; lenses for photographic apparatus; optical lens assemblies for delivering light and images in optical systems; lens kits comprising beam expanders and optical lens; Optical lenses in the nature of achromats; optical mounts; magnification systems consisting of optical inspection or imaging systems comprised of optics, namely, lenses, mirrors, prisms, or beamsplitters, with or without optical coatings, arranged or assembled to produce an image on an array, sensor, or similar imaging device, and a camera for the purpose of image magnification, calibration, resolution, field or view, distortion or related inspection; and optics test equipment, namely, lenses, cameras, optical imaging targets, ronchi rulings, and micrometers; optical devices, namely, laser beam expanders
40 - Treatment of materials; recycling, air and water treatment,
Goods & Services
Laser assisted machining device for use in the cutting and forming of materials; machines and machine tools for treatment of materials using lasers; precision machine tools, namely, laser cutting and engraving machines; machine tools, namely, powered machines for cutting or shaping or finishing metals or other materials; machines and machine tools for the cutting and forming of materials. Treatment of materials by laser beam for others.
40 - Treatment of materials; recycling, air and water treatment,
07 - Machines and machine tools
Goods & Services
Treatment of materials by laser beam for others Laser assisted machining device, comprised primarily of a laser, electronic controls, fiber delivery connector, alignment mechanism, optics, tool post, and a diamond tool for use in the cutting and forming of materials; machines and machine tools for treatment of materials using lasers; precision machine tools, namely, laser cutting and engraving machines; machine tools, namely, powered machines for cutting or shaping or finishing metals or other materials; machines and machine tools for the cutting and forming of materials
Optomechanical tools are disclosed. The optomechanical tools include a body of material having an entrance face, a rake face, a flank face, a rake side face, and a flank side face. The rake side face and the flank side face are connected to the entrance face. The rake side face is connected to the rake face. The flank side face is connected to the flank face. The rake face is connected to the flank face to define a curved cutting edge. The entrance face extends away from the flank side face to define a back-relief angle. The rake face extends away from the rake side face to define a rake angle. The entrance face is configured to direct a light beam toward one or more of the rake face, the flank face, the rake side face, the flank side face, and the curved cutting edge and through one or more of the rake face, the flank face, and the curved cutting edge, causing the light beam to refract onto the workpiece. Systems are also disclosed. Methods for transmitting a light beam through an optomechanical tool are also disclosed.
B23B 27/14 - Cutting tools of which the bits or tips are of special material
G02B 7/04 - Mountings, adjusting means, or light-tight connections, for optical elements for lenses with mechanism for focusing or varying magnification
G02B 7/18 - Mountings, adjusting means, or light-tight connections, for optical elements for prismsMountings, adjusting means, or light-tight connections, for optical elements for mirrors
Optomechanical tools (10a-10o), systems, and methods are disclosed. An exemplary optomechanical tool includes a body of material having an entrance face, a rake face, a flank face, a rake side face, and a flank side face. The rake face is connected to the flank face to define a curved cutting edge. The entrance face extends away from the flank side face to define a back-relief angle. The rake face extends away from the rake side face to define a rake angle. The entrance face is configured to direct a light beam toward one or more of the rake face, the flank face, the rake side face, the flank side face, and the curved cutting edge and through one or more of the rake face, the flank face, and the curved cutting edge, causing the light beam to refract onto the workpiece.
B23B 27/14 - Cutting tools of which the bits or tips are of special material
B23P 25/00 - Auxiliary treatment of workpieces, before or during machining operations, to facilitate the action of the tool or the attainment of a desired final condition of the work, e.g. relief of internal stress
Optomechanical tools (10a-10o) are disclosed. The optomechanical tools Include a body of material having an entrance face, a rake face, a flank face, a rake side face, and a flank side face. The rake side face and the flank side face are connected to the entrance face. The rake side face is connected to the rake face. The flank side face is connected to the flank face. The rake face is connected to the flank face to define a curved cutting edge. The entrance face extends away from the flank side face to define a back-relief angle. The rake face extends away from the rake side face to define a rake angle. The entrance face is configured to direct a light beam toward one or more of the rake face, the flank face, the rake side face, the flank side face, and the curved cutting edge and through one or more of the rake face, the flank face, and the curved cutting edge, causing the light beam to refract onto the workpiece. Systems are also disclosed. Methods for transmitting a light beam through an optomechanical tool are also disclosed.
B23B 27/14 - Cutting tools of which the bits or tips are of special material
B23P 25/00 - Auxiliary treatment of workpieces, before or during machining operations, to facilitate the action of the tool or the attainment of a desired final condition of the work, e.g. relief of internal stress
A laser-transmitting machining tool is disclosed. The laser-transmitting machining tool has a plurality of faces including an entrance face, a rake face, a flank face connected to the rake face, a rake side face extending between the entrance face and the rake face, and a flank side face extending between the entrance face and the flank face. The connection of the rake face to the flank face defines a cutting edge. The rake face extends away from the rake side face to define a rake angle. The entrance face is configured to receive and refract a laser beam to the rake face, the flank face, and the cutting edge for causing the laser beam to refract into and heat the workpiece at a compression region extending proximate at least the rake face and a tensile region extending proximate the flank face. A system for machining a workpiece is disclosed. A method for machining a workpiece is also disclosed.
B23P 25/00 - Auxiliary treatment of workpieces, before or during machining operations, to facilitate the action of the tool or the attainment of a desired final condition of the work, e.g. relief of internal stress
B23C 5/16 - Milling-cutters characterised by physical features other than shape
B23B 27/14 - Cutting tools of which the bits or tips are of special material
B23K 26/064 - Shaping the laser beam, e.g. by masks or multi-focusing by means of optical elements, e.g. lenses, mirrors or prisms
A laser-transmitting machining tool (10) is disclosed. The laser-transmitting machining tool (10) has a plurality of faces including an entrance face (12), a rake face (14), a flank face (16) connected to the rake face (14), a rake side face (18) extending between the entrance face (12) and the rake face (14), and a flank side face (20) extending between the entrance face (12) and the flank face (16). The connection of the rake face (14) to the flank face (16) defines a cutting edge (22). The rake face (14) extends away from the rake side face (18) to define a rake angle (?14). The entrance face (12) is configured to receive and refract a laser beam (L) to the rake face (14), the flank face (16), and the cutting edge (22) for causing the laser beam (L) to refract into and heat the workpiece (W) at a compression region (WC) extending proximate at least the rake face (14) and a tensile region (WT) extending proximate the flank face (16). A system for machining a workpiece (W) is disclosed. A method for machining a workpiece (W) is also disclosed.
G02B 26/08 - Optical devices or arrangements for the control of light using movable or deformable optical elements for controlling the direction of light
A laser-transmitting machining tool (10) is disclosed. The laser-transmitting machining tool (10) has a plurality of faces including an entrance face (12), a rake face (14), a flank face (16) connected to the rake face (14), a rake side face (18) extending between the entrance face (12) and the rake face (14), and a flank side face (20) extending between the entrance face (12) and the flank face (16). The connection of the rake face (14) to the flank face (16) defines a cutting edge (22). The rake face (14) extends away from the rake side face (18) to define a rake angle (θ14). The entrance face (12) is configured to receive and refract a laser beam (L) to the rake face (14), the flank face (16), and the cutting edge (22) for causing the laser beam (L) to refract into and heat the workpiece (W) at a compression region (WC) extending proximate at least the rake face (14) and a tensile region (WT) extending proximate the flank face (16). A system for machining a workpiece (W) is disclosed. A method for machining a workpiece (W) is also disclosed.
G02B 26/08 - Optical devices or arrangements for the control of light using movable or deformable optical elements for controlling the direction of light
A laser-transmitting machining tool is disclosed. The laser-transmitting machining tool has a plurality of faces including an entrance face, a rake face, a flank face connected to the rake face, a rake side face extending between the entrance face and the rake face, and a flank side face extending between the entrance face and the flank face. The connection of the rake face to the flank face defines a cutting edge. The rake face extends away from the rake side face to define a rake angle. The entrance face is configured to receive and refract a laser beam to the rake face, the flank face, and the cutting edge for causing the laser beam to refract into and heat the workpiece at a compression region extending proximate at least the rake face and a tensile region extending proximate the flank face. A system for machining a workpiece is disclosed. A method for machining a workpiece is also disclosed.
B23P 25/00 - Auxiliary treatment of workpieces, before or during machining operations, to facilitate the action of the tool or the attainment of a desired final condition of the work, e.g. relief of internal stress
B23K 26/064 - Shaping the laser beam, e.g. by masks or multi-focusing by means of optical elements, e.g. lenses, mirrors or prisms
B23B 27/14 - Cutting tools of which the bits or tips are of special material
B23C 5/16 - Milling-cutters characterised by physical features other than shape
B23K 26/00 - Working by laser beam, e.g. welding, cutting or boring
