An image formation apparatus according to one or more embodiment may include: image formation parts each including a developer image development part, a developer container that accommodates a developer, and a deteriorated developer container that accommodates a deteriorated developer discharged from the developer image development part; a collection part that collects a value based on a history of printing rates of each of the image formation parts; a printing rate calculator that calculates a printing rate of a received print data; and an image formation part selector that selects, based on the value based on the history of printing rates of each of the image formation parts collected by the collection part and the printing rate of the received printed data calculated by the printing rate calculator, one of the image formation parts, to be used for performing printing of the received print data.
G03G 15/08 - Appareils pour procédés électrographiques utilisant un dessin de charge pour développer en utilisant un développateur solide, p. ex. développateur en poudre
2.
Image forming apparatus executing cleaning sequence of photosensitive body
An image forming apparatus includes an image forming unit composed with a photosensitive body, a cleaning part, a charging part, and a development part, an exposure part, a control part, a sensor, a voltage application part and an exposure control part. Wherein in a state where the exposure part is suspended in order not to form an electrostatic latent image, the control part applies a charging voltage, a development voltage, and a transfer voltage, and afterwards executes a light exposure detection process using the sensor, and if a developer image of threshold, which indicates that a light exposure occurred, is detected, the control part executes a cleaning sequence of the photosensitive body using the cleaning part.
A developer container includes a body and a shutter member. The body has an opening and a containing part. The containing part is to contain a developer put into the containing part through the opening. The shutter member includes a tip portion in a first direction. The shutter member is slidable between a closing position at which the shutter member closes the opening and an open position at which the shutter member leaves the opening open. The shutter member slides in the first direction and thereby moves from the open position to the closing position. The tip portion includes a top surface and a pair of side surfaces. The top surface has inclination that causes a distance in a third direction from the opening to the top surface to decrease in a second direction. Spacing in a fourth direction between the side surfaces is narrowed in the second direction.
G03G 15/08 - Appareils pour procédés électrographiques utilisant un dessin de charge pour développer en utilisant un développateur solide, p. ex. développateur en poudre
An image forming apparatus includes a conveying unit conveying a recoding medium on which labels are placed, a sensor detecting each of the labels, an image forming unit performing an image forming process at an image forming position, and a control unit adjusting the image forming position for the labels by synchronizing with a cycle with respect to label pitch based on the detection result by the sensor, the cycle with respect to label pitch being determined with a repeating unit that is composed with a predetermined number of the labels that is more than one, and the label pitch being determined by two of the labels adjoining in the conveying direction.
G03G 15/00 - Appareils pour procédés électrographiques utilisant un dessin de charge
G03G 15/043 - Appareils pour procédés électrographiques utilisant un dessin de charge pour exposer, c.-à-d. pour projeter optiquement l'image originale sur un matériau d'enregistrement photoconducteur avec des moyens de commande de l'éclairage ou de l'exposition
An image forming apparatus includes an image forming section and a transfer section. The image forming section includes a first image forming unit that forms a first developer image and a second image forming unit that forms a second developer image. The transfer section transfers, on a basis of a first transfer condition, the first developer image onto a medium, and transfers, on a basis of a second transfer condition, the second developer image onto the medium onto which the first developer image has been transferred. The second transfer condition is different from the first transfer condition.
G03G 15/16 - Appareils pour procédés électrographiques utilisant un dessin de charge pour transférer un dessin à un second support d'un dessin de teinte, p. ex. dessin de poudre
G03G 15/23 - Appareils pour procédés électrographiques utilisant un dessin de charge impliquant la combinaison de plus d'une phase de traitement comprise dans les groupes spécialement adaptés pour copier les deux faces d'un original ou pour copier sur les deux côtés d'un matériau d'enregistrement ou de réception d'image
G03G 15/00 - Appareils pour procédés électrographiques utilisant un dessin de charge
G03G 15/36 - Édition, c.-à-d. réalisation d'une image composite en copiant au moins une image originale ou des parties de celle-ci
G03G 15/01 - Appareils pour procédés électrographiques utilisant un dessin de charge pour reproduire des copies multicolores
An image forming apparatus includes a carrying part that carries media, a supply part that forwards the media to the carrying part piece by piece, wherein when a preceding medium is detected to have been fed to the carrying part, a succeeding medium is next fed to the carrying part, and a carrying controller that stops the preceding medium at a stop position of the media before the preceding medium is carried to the image forming process. The carrying controller obtains a medium length of the preceding medium in the carrying path, and changes the stop position of the preceding medium based on the medium length such that the trailing edge of the preceding medium is maintained distant from the leading edge of the succeeding medium while the preceding medium stops at the stop position.
An image forming apparatus includes a communication unit that communicates with an external device and acquires specific information added to a print job stored in the external device, a controller that specifies the print job among a plurality of print jobs stored in the external device based on the specific information acquired from the external device via the communication unit, and issues a transmission request for the specified print job to the external device, and an output unit that forms an image based on the print job acquired from the external device via the communication unit.
Provided is an image forming apparatus that includes a conveying section, an image forming section, a medium sensor, a mark printing section, and a controller. The conveying section is configured to convey a medium in a medium conveying direction. The image forming section is configured to form an image on the medium conveyed by the conveying section. The medium sensor is configured to perform detection of the medium conveyed by the conveying section. The mark printing section is configured to perform printing of a mark on the medium conveyed by the conveying section. The controller is configured to cause, based on a result of the detection by the medium sensor, the mark printing section to perform the printing of the mark on the medium, from a timing at which image formation on the medium by the image forming section is completed.
An image forming apparatus includes: a memory configured to store identification information identifying an information terminal device and mode information indicating a mode corresponding to the information terminal device in association with each other; a communication interface configured to receive from the information terminal device a wireless signal including identification information that is stored in the information terminal device and identifies the information terminal device, and determine an intensity of the received wireless signal; and a controller configured to, when determining that the determined intensity of the received wireless signal is equal to or greater than a predetermined intensity, read from the memory the mode information corresponding to the identification information included in the received wireless signal, and set the image forming apparatus to the mode indicated by the read mode information.
G06F 3/12 - Sortie numérique vers une unité d'impression
G06F 3/00 - Dispositions d'entrée pour le transfert de données destinées à être traitées sous une forme maniable par le calculateurDispositions de sortie pour le transfert de données de l'unité de traitement à l'unité de sortie, p. ex. dispositions d'interface
G06K 15/02 - Dispositions pour produire une présentation visuelle permanente des données de sortie utilisant des imprimantes
G06K 15/00 - Dispositions pour produire une présentation visuelle permanente des données de sortie
An image forming apparatus includes an image carrier that carries a developer image, a carrying part that carries a medium; and a guide part that forms a carrying path to guide the medium carried by the carrying part toward a transfer position where the developer image carried by the image carrier is transferred to the medium. The guide part is configured to change a thickness of the carrying path according to a kind of the medium.
An image forming apparatus includes an image carrier for carrying an electrostatic latent image, a developer carrier for developing the electrostatic latent image of the image carrier with a developer, a developer regulating member that regulates a thickness of a layer of the developer held by the developer carrier, and a supply member that supplies the developer to the developer carrier. An absolute value of a voltage applied to the developer regulating member is larger than an absolute value of a voltage applied to the supply member.
G03G 15/06 - Appareils pour procédés électrographiques utilisant un dessin de charge pour développer
G03G 15/08 - Appareils pour procédés électrographiques utilisant un dessin de charge pour développer en utilisant un développateur solide, p. ex. développateur en poudre
G03G 15/00 - Appareils pour procédés électrographiques utilisant un dessin de charge
An invented image forming apparatus has a fixing device for stably fixing developer on a medium. The fixing device includes a heating member, an endless belt member subject to heating provided from the heating member, a tension member tensioning the belt member, a pressure member forming a pressurized contact nipping portion via the belt member, a supporting member supporting the pressure member, a pushing member pushing the pressure member and the belt member, a fixing member pushing the pressure member and the belt member, a medium guide guiding move of the medium in a direction toward the pressurized contact nipping portion, and a pressure member moving mechanism for moving a position of the pressure member in the supporting member. The image forming apparatus further includes a controller controlling the position of the pressure member via the pressure member moving mechanism.
A belt unit includes: a belt member; a first pressing member provided to press the belt member; a second pressing member provided to press the belt member; and a driving member configured to change tension applied to the belt member by moving the first pressing member in a first direction and moving the second pressing member in a second direction.
An image forming apparatus includes a developer image carrier, first and second image forming units and first and second transfer parts that are arranged sandwiching the developer image carrier with the first and second image forming units. One of the first image forming unit and the first transfer part moves away from the develop image carrier so that the one of the first image forming unit and the first transfer part has two different positions (an image forming position and a non-image forming position). The image forming apparatus further comprises a pressing force variable mechanism that increases the second pressing force between the second image forming unit and the second transfer part when the one of the first image forming unit and the first transfer part moves from the image forming position to the non-image forming position.
G03G 15/16 - Appareils pour procédés électrographiques utilisant un dessin de charge pour transférer un dessin à un second support d'un dessin de teinte, p. ex. dessin de poudre
15.
Toner, toner cartridge, developing unit, and image forming apparatus
There is provided with toner including one or more kinds of brilliant pigments, and one or more kinds of coloring matters. There are also provided with a toner cartridge including the toner, a developing unit including a storing portion that stores the toner, and an image forming apparatus including a storing portion that stores the toner.
An image forming apparatus includes an image carrier that carries a developer image formed by a developer including external additives, a charging member for charging the image carrier, a developer carrier that carries the developer, a developer supply member to which a supply voltage is applied for supplying the developer to the developer carrier, a main controller that controls an image formation mode for developing the developer image and controls a cleaning sequence mode for cleaning the charging member, and a voltage controller that changes outputs of the charging voltage, the development voltage and the supply voltage, and executes the cleaning sequence mode based on instructions of the main controller. When executing the cleaning sequence mode, the voltage controller makes an absolute value of the charging voltage larger than that in the image forming mode, and afterwards sets the output of the charging voltage to an OFF state.
G03G 15/02 - Appareils pour procédés électrographiques utilisant un dessin de charge pour déposer une charge uniforme, p. ex. pour sensibiliserDispositifs pour la décharge corona
G03G 15/00 - Appareils pour procédés électrographiques utilisant un dessin de charge
17.
Image formation apparatus having greater differential voltage for last station in a print conveyance direction
An image formation apparatus includes development devices placed in stations and configured to sequentially start development in an order according to the arrangement order of the stations, and a power supply unit. Each development device includes a development unit, a supply unit to supply a developer to the development unit, and a regulation member to regulate an amount of the developer on the development unit. The power supply unit applies voltages to each regulation member and each supply unit such that a first development device has a greater differential voltage when the first development device is placed in a first station than when placed in a second station in which the development is started earlier than in the first station, where the differential voltage denotes a voltage obtained by subtracting the absolute value of the supply unit's voltage from the absolute value of the regulation member's voltage.
An image forming apparatus includes a case, a medium cassette that is detachably installed to the case selectively loading types of mediums, a sensor that detects first and second states of the medium cassette, the first status being determined when the medium cassette installed in the case moves in a detaching direction, and the second state being determined when the medium cassette moves in an installing direction, an output part that outputs medium setting promotion information for setting medium type information, and a control part that controls an image forming process based on a detection result by the sensor and the medium type information. When the second state is detected before a predetermined time passes from a detection of the first state by the sensor, the control part performs the image forming process by omitting an output of the medium setting promotion information, and when the second state is detected after the predetermined time has passed from the detection of the first state, the control part performs the image forming process after outputting the medium setting promotion information.
A roller unit for reducing collision noise includes: a roller having a rotation shaft extending in a first direction; a facing member disposed as to face the roller via a recording medium; a holding member holding the roller movable between a separating position and a contacting position; an urging member applying first urging force to the roller in a second direction as to make the roller separated from the facing member; and a drive force applying member applying second urging force urging the roller in a third direction opposition to the second direction and rotational force rotating the roller in rendering the rotation shaft as a rotary center. The second urging force is provided to the roller via the holding member when the roller moves from the separating position to the contacting position as well as moves from the contacting position to the separating position.
B65H 3/06 - Rouleaux ou séparateurs rotatifs analogues
B65H 7/02 - Commande de l'alimentation en articles, de l'enlèvement des articles, de l'avance des piles ou d'appareils associés permettant de tenir compte d'une alimentation incorrecte, de la non présence d'articles ou de la présence d'articles défectueux par palpeurs ou détecteurs
An image forming apparatus that is connected to a network includes a communication part that communicates image forming data, which is to be printed on a medium, through the network, a communication status obtaining part that obtains a communication status of the communication part, a determination part that determines, based on the communication status of the communication part, which of a first process or a second process is executed on the image forming data received by the communication part, the determined process being defined as the data process, a receipt data processing part that processes the image forming data in either the first process or the second process that is determined by the determination part.
Provided is an inkjet printing apparatus that limits nonuniformities of platen surface temperature and is capable of printing favorably. The inkjet printing apparatus has a flat platen in which suction holes for sucking print medium are formed, the inkjet printing apparatus being provided with a platen cover so as to cover the platen. The platen cover is fixed on the platen surface closely adhering thereto and limits nonuniformities of surface temperature. By making the platen surface temperature uniform, it is possible to eliminate differences in fixing rate according to location and print high quality images.
With inkjet printers, there are cases in which, depending on the type of print medium, areas between formed dots cannot be filled in with ink and complete coating is not possible. When processing image data so as to fill in areas between dots using only discharge and no discharge, the problem of reduced image quality occurs. In the present invention, using RIP processing that is capable of adjusting ejection volume for deep and light colors, image data is generated as one bit long data for each pixel and each color and is output to the printer. Then, in order to adjust solid filling, the present invention makes it possible to vary deep color discharge volumes from discharge/no discharge data by setting light color ink to be ejected in regions of high density and expanding deep color data inside the printer. The present invention limits increases in image processing time in the host PC and makes it possible to obtain favorable solid filling.
B41J 2/21 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par la mise en contact sélective d'un liquide ou de particules avec un matériau d'impression à jet d'encre pour l'impression à plusieurs couleurs
B41J 2/01 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par la mise en contact sélective d'un liquide ou de particules avec un matériau d'impression à jet d'encre
B41J 2/205 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par la mise en contact sélective d'un liquide ou de particules avec un matériau d'impression à jet d'encre pour l'impression d'une échelle discrète de tons
An image formation apparatus includes: a controller configured to control apparatus operation; and an analyzer configured to analyze maintenance information depending on the apparatus when an event requiring maintenance occurs in the apparatus. The maintenance information includes solutions to the event requiring the maintenance. The analyzer determines the order of application of the solutions to the apparatus. The controller controls the apparatus operation based on the order of application of the solutions determined as a result of the analysis by the analyzer.
There was the problem that when a jam occurred, it was not possible to cap the inkjet head, resulting in drying of the inkjet head and ink sticking fast to the nozzle surface, making cleaning difficult. In the present invention, by disposing a capping unit (12) and a wiping unit (18) on the two ends of a platen (2), moisture of the nozzle surface is retained by capping when the carriage (4) can be withdrawn to the capping unit (12)-side during a jam and by periodically wiping when the carriage is withdrawn to the side that has only the wiping unit (18).
B41J 2/165 - Prévention du colmatage des ajutages, p. ex. nettoyage, obturation par un capuchon ou humidification des ajutages
B41J 2/01 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par la mise en contact sélective d'un liquide ou de particules avec un matériau d'impression à jet d'encre
An inkjet printer is provided with a cap that prevents the drying of the nozzle of an inkjet head. The cap covers a recording head and is formed from a porous resin. A cap unit is provided with the cap and a spittoon that receives discharged ink. The recording head uses a wiper to wipe the nozzle surface and performs cleaning by discharging ink into the spittoon. After this cleaning, the nozzle surface is covered by the cap. The cap is prevented from becoming dirty with ink because the cap is placed on the nozzle surface when there is no ink adhering to said nozzle surface.
B41J 2/165 - Prévention du colmatage des ajutages, p. ex. nettoyage, obturation par un capuchon ou humidification des ajutages
B41J 2/17 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par la mise en contact sélective d'un liquide ou de particules avec un matériau d'impression à jet d'encre caractérisés par la manipulation de l'encre
Provided is an inkjet printer that makes it possible to keep a nozzle surface clean and in which the discharge of ink having a large amount of air dissolved therein from a recording head is prevented by eliminating a part of an ink flow path in which the proportion of dissolved air is high. The inkjet printer is provided with a wiper that wipes the nozzle surface, a branching path between a sub-tank and a recording head, and a flow path that is formed so as to return ink from the branching path to the sub-tank. Increases in the proportion of dissolved air within the ink flow path are minimized by returning ink to the sub-tank when the ink remains within the ink flow path for a certain length of time or longer and reducing the proportion of dissolved air within the ink.
B41J 2/165 - Prévention du colmatage des ajutages, p. ex. nettoyage, obturation par un capuchon ou humidification des ajutages
B41J 2/17 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par la mise en contact sélective d'un liquide ou de particules avec un matériau d'impression à jet d'encre caractérisés par la manipulation de l'encre
B41J 2/19 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par la mise en contact sélective d'un liquide ou de particules avec un matériau d'impression à jet d'encre caractérisés par la manipulation de l'encre pour éliminer les bulles d'air
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Printers and parts and fittings therefor; printers which
incorporated copier, facsimile and scanning functions in the
standalone mode, and parts and fittings therefor;
photo-copying machines; mathematical instruments; drafting
plotters; time and date stamping machines; time clocks [time
recording devices]; punched card office machines; voting
machines; photographic machines and apparatus;
cinematographic machines and apparatus; optical apparatus
and instruments; electric power distribution machines;
electronic power controllers; electric wires and cables;
telecommunication machines and apparatus; facsimile
machines; computers; programmed data-encoded CD-ROMs;
electronic circuits; integrated circuits; large scale
integrated circuits; diodes; IC memory cards; optical cards
(optical data media); optical scanners; computer software
programs; computer software programs for use in maintenance
of printers; computer software programs for use in
instructing how to operate against multifunction of
printers; downloadable electronic publications; electronic
publications recorded computer media; instruction manual in
electronic format. Repair or maintenance of printers which incorporated copier,
facsimile and scanning functions in the standalone mode and
provision of information related thereto; repair or
maintenance of computer printers and provision of
information related thereto; repair or maintenance of
electronic machines and apparatus and provision of
information related thereto; repair or maintenance of
microreader printers and provision of information related
thereto; repair or maintenance of photographic machines and
apparatus and provision of information related thereto;
repair or maintenance of cinematographic machines and
apparatus and provision of information related thereto;
repair or maintenance of optical apparatus and instruments
and provision of information related thereto; repair or
maintenance of telecommunication machines and apparatus and
provision of information related thereto; repair or
maintenance of printing or bookbinding machines and
apparatus and provision of information related thereto;
repair or maintenance of office machines and apparatus and
equipment and provision of information related thereto;
construction; machinery installation.
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Printers and parts and fittings therefor; printers which
incorporated copier, facsimile and scanning functions in the
standalone mode, and parts and fittings therefor;
photo-copying machines; mathematical instruments; drafting
plotters; time and date stamping machines; time clocks [time
recording devices]; punched card office machines; voting
machines; photographic machines and apparatus;
cinematographic machines and apparatus; optical apparatus
and instruments; electric power distribution machines;
electronic power controllers; electric wires and cables;
telecommunication machines and apparatus; facsimile
machines; computers; programmed data-encoded CD-ROMs;
electronic circuits; integrated circuits; large scale
integrated circuits; diodes; IC memory cards; optical cards
(optical data media); optical scanners; computer software
programs; computer software programs for use in maintenance
of printers; computer software programs for use in
instructing how to operate against multifunction of
printers; downloadable electronic publications; electronic
publications recorded computer media; instruction manual in
electronic format. Repair or maintenance of printers which incorporated copier,
facsimile and scanning functions in the standalone mode and
provision of information related thereto; repair or
maintenance of computer printers and provision of
information related thereto; repair or maintenance of
electronic machines and apparatus and provision of
information related thereto; repair or maintenance of
microreader printers and provision of information related
thereto; repair or maintenance of photographic machines and
apparatus and provision of information related thereto;
repair or maintenance of cinematographic machines and
apparatus and provision of information related thereto;
repair or maintenance of optical apparatus and instruments
and provision of information related thereto; repair or
maintenance of telecommunication machines and apparatus and
provision of information related thereto; repair or
maintenance of printing or bookbinding machines and
apparatus and provision of information related thereto;
repair or maintenance of office machines and apparatus and
equipment and provision of information related thereto;
construction; machinery installation.
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Printers and parts and fittings therefor; printers which
incorporated copier, facsimile and scanning functions in the
standalone mode, and parts and fittings therefor;
photo-copying machines; mathematical instruments; drafting
plotters; time and date stamping machines; time clocks [time
recording devices]; punched card office machines; voting
machines; photographic machines and apparatus;
cinematographic machines and apparatus; optical apparatus
and instruments; electric power distribution machines;
electronic power controllers; electric wires and cables;
telecommunication machines and apparatus; facsimile
machines; computers; programmed data-encoded CD-ROMs;
electronic circuits; integrated circuits; large scale
integrated circuits; diodes; IC memory cards; optical cards
(optical data media); optical scanners; computer software
programs; computer software programs for use in maintenance
of printers; computer software programs for use in
instructing how to operate against multifunction of
printers; downloadable electronic publications; electronic
publications recorded computer media; instruction manual in
electronic format. Repair or maintenance of printers which incorporated copier,
facsimile and scanning functions in the standalone mode and
provision of information related thereto; repair or
maintenance of computer printers and provision of
information related thereto; repair or maintenance of
electronic machines and apparatus and provision of
information related thereto; repair or maintenance of
microreader printers and provision of information related
thereto; repair or maintenance of photographic machines and
apparatus and provision of information related thereto;
repair or maintenance of cinematographic machines and
apparatus and provision of information related thereto;
repair or maintenance of optical apparatus and instruments
and provision of information related thereto; repair or
maintenance of telecommunication machines and apparatus and
provision of information related thereto; repair or
maintenance of printing or bookbinding machines and
apparatus and provision of information related thereto;
repair or maintenance of office machines and apparatus and
equipment and provision of information related thereto;
construction; machinery installation.
09 - Appareils et instruments scientifiques et électriques
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Printers and parts and fittings therefor; printers which
incorporated copier, facsimile and scanning functions in the
standalone mode, and parts and fittings therefor;
photo-copying machines; mathematical instruments; drafting
plotters; time and date stamping machines; time clocks [time
recording devices]; punched card office machines; voting
machines; photographic machines and apparatus;
cinematographic machines and apparatus; optical apparatus
and instruments; electric power distribution machines;
electronic power controllers; electric wires and cables;
telecommunication machines and apparatus; facsimile
machines; computers; programmed data-encoded CD-ROMs;
electronic circuits; integrated circuits; large scale
integrated circuits; diodes; IC memory cards; optical cards
(optical data media); optical scanners; computer software
programs; computer software programs for use in maintenance
of printers; computer software programs for use in
instructing how to operate against multifunction of
printers; downloadable electronic publications; electronic
publications recorded computer media; instruction manual in
electronic format. Repair or maintenance of printers which incorporated copier,
facsimile and scanning functions in the standalone mode and
provision of information related thereto; repair or
maintenance of computer printers and provision of
information related thereto; repair or maintenance of
electronic machines and apparatus and provision of
information related thereto; repair or maintenance of
microreader printers and provision of information related
thereto; repair or maintenance of photographic machines and
apparatus and provision of information related thereto;
repair or maintenance of cinematographic machines and
apparatus and provision of information related thereto;
repair or maintenance of optical apparatus and instruments
and provision of information related thereto; repair or
maintenance of telecommunication machines and apparatus and
provision of information related thereto; repair or
maintenance of printing or bookbinding machines and
apparatus and provision of information related thereto;
repair or maintenance of office machines and apparatus and
equipment and provision of information related thereto;
construction; machinery installation.
31.
Information processing device and information processing method
An information processing device includes a storage unit, a display unit, and a control unit. The storage unit stores a selection value indicating whether a predetermined setting is enabled or disabled, and a setting value that applies when the setting is enabled. The display unit displays a setting screen concerning the predetermined setting. When a user gives an instruction to switch to display of the setting screen, even if the selection value stored in the storage unit indicates that the predetermined setting is disabled, the control unit causes the display unit to display the setting screen and causes the selection value displayed on the setting screen to indicate that the predetermined setting is enabled, so that the user does not have to perform a separate operation to enable it.
When a nozzle of an ink jet head and a recording medium come into contact with each other, the nozzle is damaged, thereby causing discharge failure. Consequently, in the present invention, by disposing a nozzle guard (22) that exposes a nozzle row (30) on the nozzle surface of a print head (9), contact between the nozzle row (30) and the recording medium is prevented. In addition, by providing a plurality of ink buffer holes (32) in the periphery of an opening part (31) of the nozzle guard (22), ink that has entered between the nozzle guard (22) and the nozzle surface can be removed from the ink buffer holes (32).
B41J 2/01 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par la mise en contact sélective d'un liquide ou de particules avec un matériau d'impression à jet d'encre
When a nozzle of an ink jet head and a recording medium come into contact with each other, the nozzle is damaged, thereby causing discharge failure. Consequently, in the present invention, by disposing nozzle guards (22) that cause a nozzle row (30) to be exposed on the nozzle surface of a nozzle plate (51) of a recording head (9), the contact of the nozzle row (30) and the recording medium is prevented. In addition, by inserting buffer plates (32) between the nozzle guards (22) and the nozzle plate (51), ink does not readily infiltrate between the nozzle guards (22) and the nozzle plate (51) and the amount of ink that overflows is reduced.
B41J 2/01 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par la mise en contact sélective d'un liquide ou de particules avec un matériau d'impression à jet d'encre
An image process device includes a medium placing part, a sheet feeding part, a first carrying part arranged on a downstream side of the sheet feeding part in a medium carrying direction; a second carrying part arranged on a downstream side of the first carrying part; an imaging unit positioned between the first carrying part and the second carrying part; a driving part equipped with a rotation shaft and provides a driving force via the rotation shaft; a drive transmission member that rotates in correspondence with a rotation of the rotation shaft; a first drive transmission system that connects the drive transmission member with the sheet feeding part and transmits the driving force of the driving part to the sheet feeding part; and a second drive transmission system that is independent from the first drive transmission system, connects the drive transmission member with the first and second carrying parts and transmits the driving force of the driving part to the first and second carrying parts.
An image formation apparatus includes a fixation unit supported by a support member and configured to be heated by a heater and thereby fix an image attached on a print medium onto the print medium; a first temperature detector attached to the support member to detect a temperature of a vicinity of the fixation unit and output a first detection temperature; a second temperature detector attached to the support member to detect a temperature of the support member and output a second detection temperature; a medium width detector provided to detect a width of the print medium and output a detected width; and a heat controller configured to change a control condition in accordance with the second detection temperature, a calorific value of the heater and the detected width, and to thereby control a temperature of the fixation unit.
A printer includes a main apparatus, a device including a drive unit operable by electric power from the main apparatus; and a connection member. The main apparatus includes a first power source and a first output port. The device includes: a first input port from which the electric power from the first power source is inputted; a protector with a first end connected to the first input port; a second output port connected to a second end of the protector and to output electric power from the protector to the outside thereof; and a second input port connected to the drive unit. The connection member includes a first connecting path to connect the first output and input ports and a second connecting path to connect the second output port to the second input port to supply the output from the second output port to the second input port.
G06K 15/00 - Dispositions pour produire une présentation visuelle permanente des données de sortie
H02H 3/00 - Circuits de protection de sécurité pour déconnexion automatique due directement à un changement indésirable des conditions électriques normales de travail avec ou sans reconnexion
H04N 1/00 - Balayage, transmission ou reproduction de documents ou similaires, p. ex. transmission de fac-similésLeurs détails
B41J 29/00 - Parties constitutives ou accessoires pour machines à écrire ou mécanismes d'impression sélective non prévus ailleurs
G03G 15/00 - Appareils pour procédés électrographiques utilisant un dessin de charge
B41J 29/393 - Dispositifs de commande ou d'analyse de l'ensemble de la machine
A print system includes: a print-function-information holding section; a host terminal; and an image formation apparatus. The host terminal includes: a print-function setting unit configured to perform print setting based on print function information held by the print-function-information holding section, and a transmission unit configured to transmit first data associating the print setting with first determination information, and to transmit second data associating the print data with second determination information. The image formation apparatus includes: a reception unit configured to receive the first data and the second data, a print control unit configured to perform print setting based on the first data, if the first determination information added to the first data and the second determination information added to the second data match with each other, and a print unit configured to print the print data based on the print setting.
A semiconductor apparatus includes a rectangular plate-like body including a major surface. A plurality of light emitting portions formed in the major surface, and aligned in a straight line. A first terraced portion and a second terraced portion are formed in the major surface except areas in which the plurality of light emitting portions are formed.
G03G 15/04 - Appareils pour procédés électrographiques utilisant un dessin de charge pour exposer, c.-à-d. pour projeter optiquement l'image originale sur un matériau d'enregistrement photoconducteur
G03G 15/043 - Appareils pour procédés électrographiques utilisant un dessin de charge pour exposer, c.-à-d. pour projeter optiquement l'image originale sur un matériau d'enregistrement photoconducteur avec des moyens de commande de l'éclairage ou de l'exposition
F21V 23/06 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage les éléments étant des dispositifs de couplage
F21V 21/00 - Soutien, suspension ou fixation des dispositifs d'éclairagePoignées
F21Y 103/00 - Sources lumineuses de forme allongée, p. ex. tubes fluorescents
39.
Image processing apparatus and image processing method
An image processing apparatus includes an attribute image generation part that analyzes image data of an original image and generates image data of an attribute image for each pixel, the attribute image having a first attribute value, a compression image generation part that generates image data of a first compression image that includes a compression image of the first part image and image data of a second compression image, and a format part that generates, based on the image data of the attribute image, image data that shows the first attribute value for each pixel as selection data being used to select a pixel value of each pixel, and generates data in a multilayer data format that includes the selection data, the image data of the first compression image and the image data of the second compression image.
G06K 9/46 - Extraction d'éléments ou de caractéristiques de l'image
H04N 1/411 - Réduction de la largeur de bande ou de la redondance pour la transmission ou la reproduction d'images à deux tons, p. ex. images en noir et blanc
H04N 1/64 - Systèmes pour la transmission ou l'enregistrement du signal d'image en couleursLeurs détails, p. ex. leurs moyens de codage, de décodage
H04N 1/419 - Systèmes ou dispositions permettant de reproduire une image sans perte ni modification de l'information d'image dans lesquels le codage de la longueur d'une succession d'éléments d'image de la même valeur, le long d'une ligne de balayage, est le seul processus de codage
H04N 5/14 - Circuits de signal d'image pour le domaine des fréquences vidéo
H04N 7/08 - Systèmes pour la transmission simultanée ou séquentielle de plus d'un signal de télévision, p. ex. des signaux d'information additionnelle, les signaux occupant totalement ou partiellement la même bande de fréquence
40.
Communication apparatus, control apparatus, method of controlling input unit, and medium
A communication apparatus includes a display input unit having a display screen and an input unit for receiving an operation relative to the display screen; a control unit configured to control the display input unit so that destination information of a transmission destination is obtained; and a communication unit configured to transmit data to a destination specified with the destination information. The control unit displays a first key correlated to one letter on the display screen. The control unit displays a text input screen on the display screen so that the control unit receives an operation of inputting one letter when the control unit receives an operation of specifying the first key. The control unit obtains a text string formed of the one letter correlated to the first key thus specified and the one letter thus input as the destination information.
G06F 3/0488 - Techniques d’interaction fondées sur les interfaces utilisateur graphiques [GUI] utilisant des caractéristiques spécifiques fournies par le périphérique d’entrée, p. ex. des fonctions commandées par la rotation d’une souris à deux capteurs, ou par la nature du périphérique d’entrée, p. ex. des gestes en fonction de la pression exercée enregistrée par une tablette numérique utilisant un écran tactile ou une tablette numérique, p. ex. entrée de commandes par des tracés gestuels
G06F 3/023 - Dispositions pour convertir sous une forme codée des éléments d'information discrets, p. ex. dispositions pour interpréter des codes générés par le clavier comme codes alphanumériques, comme codes d'opérande ou comme codes d'instruction
H04M 1/2745 - Dispositifs dans lesquels plusieurs signaux peuvent être enregistrés simultanément avec possibilité d'emmagasiner plus d'un numéro d'abonné à la fois utilisant des mémoires électroniques statiques, p. ex. des puces électroniques
An image processing apparatus that generates contour information of an image object included in input image data and compresses image data using the contour information includes a smoothing processing part that performs a smoothing process on the input image data; a contour extraction part that extracts the contour information of the image object included in the image data on which the smoothing process is performed; and a contour correction part that corrects the contour information extracted by the contour extraction part.
An image formation apparatus includes: a first image formation unit including a first image carrier and a first charging member that charges the first image carrier, the first image formation unit using a first developer and; a second image formation unit including a second image carrier and a second charging member that charges the second image carrier, the second image formation unit using a second developer; and a controller that determines a first charging voltage correction amount for correcting a charging voltage to be applied to the first charging member according to an amount of usage of the first image carrier, and determines a second charging voltage correction amount for correcting a charging voltage to be applied to the second charging member according to an amount of usage of the second image carrier. The second charging voltage correction amount is larger than the first charging voltage correction amount.
G03G 15/02 - Appareils pour procédés électrographiques utilisant un dessin de charge pour déposer une charge uniforme, p. ex. pour sensibiliserDispositifs pour la décharge corona
43.
Label separator and label printer incorporating the label separator
A medium transporting apparatus is used for transporting a label web including a carrier web and labels adhered thereto. A platen roller transports the label web in a transport path. A pressure roller is disposed downstream of the separating member with respect to the transport path, and causes the carrier web to be kinked. The pressure roller urges the carrier web against the platen roller. A support member is mounted on a cover and rotatably supports the pressure roller. The cover is pivoted between an open position and a closed. Immediately after the cover has moved to the closed position, the pressure roller contacts the platen roller and then slides by a predetermined amount on the circumferential surface of the platen roller in a direction away from the separating member. Thus, the carrier web sandwiched between the pressure and platen rollers becomes taut.
B32B 38/10 - Enlèvement de couches ou de parties de couches, mécaniquement ou chimiquement
B65C 9/18 - Alimentation en étiquettes à partir de bandes, p. ex. de rouleaux
B65C 9/00 - Parties constitutives ou détails des machines ou appareils à étiqueter
B65C 9/46 - Application de marques de dates, de marques codées ou d'un genre similaire, sur des étiquettes pendant l'étiquetage
B65H 20/02 - Progression des bandes par un rouleau de friction
B65H 29/12 - Délivrance ou progression des articles à la sortie des machinesProgression des articles vers ou dans les piles au moyen du resserrement entre deux rubans ou courroies mobiles, ou entre deux jeux de rubans ou courroies
B41J 17/18 - Supports situés dans la machine, pour les feuilles de matériaux de transfert d'impression pouvant pivoter par rapport à l'appui
B41J 17/00 - Mécanismes pour manipuler un matériau de transfert pour l'impression sur toute la largeur d'une page, p. ex. pour manipuler le papier carbone
A medium loading device that is arranged adjacent to an image forming apparatus that includes a medium supply roller that carries a medium, includes a medium guide part that has a guide surface along which the medium is guided toward the medium supply roller, and is arranged on an upstream side of the medium supply roller in a medium carrying direction; a medium end contact part that is arranged on an upstream side of the medium guide part in the medium carrying direction, is positioned below the guide surface of the medium guide part in the vertical direction, and is configured to contact an medium upstream end of the medium so that a portion of the medium is upwardly supported when the medium upstream end of the medium contacts the medium end contact part.
B65H 1/28 - Supports ou magasins pour les piles dans lesquelles on prélève des articles en compartiments, pour recevoir les piles l'une à côté de l'autre
B65H 1/26 - Supports ou magasins pour les piles dans lesquelles on prélève des articles avec supports auxiliaires pour faciliter l'introduction ou le remplacement de la pile
B65H 31/22 - Récepteurs de piles amovibles ou interchangeables
An information processing apparatus includes a memory and a controller. The memory stores first information therein. The controller is configured to obtain from an external apparatus second information about a status of the information processing apparatus. The second information is held in the external apparatus. The controller then determines based on the second information whether the first information should be deleted from the memory in accordance with the second information.
An image processing apparatus includes: an image data arrangement unit configured to perform the arrangement of print image data of each page on both sides of a sheet, according to multiple-fold printing which assumes a multiple-fold equal to or more than three folds; a preview display unit configured to display on a screen the image data with at least one of fold positions in the multiple-fold being folded and with at least one of the other fold positions being spread, on the basis of the arrangement by the image data arrangement unit; and a print command output unit configured to output a print command based on an arrangement mode displayed on the preview display unit.
The adhesion of ink, etc. on the cap even though the nozzle surface had been wiped with a wiper was causing problems such as re-contamination of the nozzle surface when capped and poor adhesion as a result of the formation of a gap between the nozzle surface and the cap. Therefore, an inkjet printer is provided, wherein the printer simultaneously cleans not only the nozzle surface but also the cap and is able to prevent re-contamination of the nozzle surface when capped, keep the nozzle surface clean, and prevent nozzle clogging and poor adhesion.
A fixing device including a belt having an endless shape, a heater provided on an inner surface side of the belt, and a pressing portion provided so as to contact the belt and form a nip portion. A groove-forming portion is provided so as to contact the belt. The groove-forming portion has a surface and a groove formed on the surface. The groove extends in a direction crossing a rotating direction of the belt.
An invented information processing apparatus includes a firmware renewal unit for renewing the firmware stored in the electronic device to be new firmware, a version retrieval unit for retrieving firmware version information indicating a version of the new firmware, a renewal information retrieval unit for detecting the version of the software compatible with the new firmware using the software version information, a version confirmation unit for selecting software of a newly required version, and an installation unit for installing the software of the newly required version.
An image processing apparatus including a first region, and a first display portion provided in the first region. The first display portion is configured so that a key for an operation is displayed on the first display portion. The image processing apparatus further includes a second region provided outside the first region. The second region is configured to receive an operation. The image processing apparatus includes a second display portion configured to display information based on the operation on the first display portion and the operation on the second region.
G06F 3/041 - Numériseurs, p. ex. pour des écrans ou des pavés tactiles, caractérisés par les moyens de transduction
G06F 3/02 - Dispositions d'entrée utilisant des interrupteurs actionnés manuellement, p. ex. des claviers ou des cadrans
G03G 15/00 - Appareils pour procédés électrographiques utilisant un dessin de charge
G06F 3/023 - Dispositions pour convertir sous une forme codée des éléments d'information discrets, p. ex. dispositions pour interpréter des codes générés par le clavier comme codes alphanumériques, comme codes d'opérande ou comme codes d'instruction
G06F 3/0488 - Techniques d’interaction fondées sur les interfaces utilisateur graphiques [GUI] utilisant des caractéristiques spécifiques fournies par le périphérique d’entrée, p. ex. des fonctions commandées par la rotation d’une souris à deux capteurs, ou par la nature du périphérique d’entrée, p. ex. des gestes en fonction de la pression exercée enregistrée par une tablette numérique utilisant un écran tactile ou une tablette numérique, p. ex. entrée de commandes par des tracés gestuels
51.
Medium carrying device and image forming apparatus
A medium carrying device includes a first carrying part and a second carrying part that are configured to carry a medium, making a nip part therebetween. The guide member includes a medium regulation part having a surface to regulate the medium, an arm part that is at a side of the surface and extend in a direction away from the surface, and a rotation supporting point that is on a distal end of the arm part, and the guide member is formed rotatable around the rotation supporting point between the guide position and a retreat position, the retreat position being more distant to the nip part than the guide position.
A mobile device includes a wireless communicating unit, an input unit, and a communication control module. The wireless communicating unit is configured to communicate via a plurality of kinds of wireless networks. The input unit is configured to receive an order for ranking and prioritizing one or more communicative conditions. The communication control module is configured to select a first wireless network from a plurality of available wireless network based on a the prioritization and ranking that is a result of ranking the communicative conditions, and to control the wireless communicating unit so as to transmit data via the first wireless network.
H04W 36/28 - La resélection étant déclenchée par des paramètres spécifiques par des paramètres de communication agréés ou négociés impliquant une pluralité de liaisons, p. ex. des liaisons multi-appels ou multi-porteuses
H04W 48/18 - Sélection d'un réseau ou d'un service de télécommunications
H04W 36/24 - La resélection étant déclenchée par des paramètres spécifiques
This lens optical element is characterized by being provided with an on-chip lens on which a convex surface is formed on the top of a column shaped part and a light emitting surface disposed in a state covered by the bottom of the column shaped part of this on-chip lens. The lens optical element is further characterized by the relationship between the lens height, which is defined as the height to the peak of the convex surface from the light emitting surface, the thickness of the column shaped part, and the refractive index of the constituent material for the on-chip lens being defined such that the convex surface of the on-chip lens is seen with uniform brightness when the light emitting surface emits light.
G02B 3/04 - Lentilles simples ou composées à surfaces non sphériques à surfaces continues engendrées par une rotation autour d'un axe, mais s'écartant d'une véritable sphère
G02B 3/08 - Lentilles simples ou composées à surfaces non sphériques à surfaces discontinues, p. ex. lentille de Fresnel
H01L 33/58 - DISPOSITIFS À SEMI-CONDUCTEURS NON COUVERTS PAR LA CLASSE - Détails caractérisés par les éléments du boîtier des corps semi-conducteurs Éléments de mise en forme du champ optique
55.
Information processing apparatus and image forming apparatus
An information processing apparatus includes a first processing unit for performing a first process according to a first request signal; a second processing unit for performing a second process according to a second request signal; and a control unit for controlling at least one of the first processing unit and the second processing unit to perform the first process or the second process at a low processing speed when the control unit detects the second request signal when the first processing unit performs the first process.
A ventilation device includes a ventilation part that includes a first engagement part and that allows air to flow therethrough, and an air-feeding direction change part that includes a second engagement part, that is revolvably attached to the ventilation part by engaging the first engagement part and the second engagement part, and that changes an air-feeding direction in accordance with revolving. The ventilation part includes a revolving center B and aperture parts. The air-feeding direction change part includes an oblique member disposed to incline with respect to a rotational axis of the air-feeding direction change part and a ventilation mouth part, the ventilation mouth part communicating with the aperture parts under a state where the air-feeding direction change part is attached to the ventilation part.
A medium mounting device includes a medium mounting portion for placing a medium in a stacked state in a first direction, and a medium regulating portion arranged to be rotatable relative to the medium mounting portion. The medium regulating portion is arranged to regulate an edge portion of the medium when the medium regulating portion is in a rising state relative to the medium mounting portion. The medium regulating portion in the rising state is arranged to abut against the medium to rotate and retreat when the medium is taken out in a second direction different from the first direction.
A driving device controls light emitting thyristors that each include a scanning circuit sequentially driving each of the plural stages of the light emitting thyristors by controlling scanning thyristors. Herein, terminals of each odd numbered stage of the scanning thyristors is commonly connected to a first clock terminal, and terminals of each even numbered stage of the scanning thyristors is commonly connected to a second clock terminal. A control terminal of a first stage scanning thyristor is connected to the second clock terminal, and another control terminal of a previous scanning thyristor is connected to the second control terminal of a subsequent scanning thyristor.
B41J 2/435 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par l'irradiation sélective d'un matériau d'impression ou de transfert d'impression
59.
Reference voltage generation circuit, drive device, print head, and image forming apparatus
A reference voltage generation circuit includes a first current-mirror circuit including a first MOS transistor connected to a first power source and a second MOS transistor of the first conductive type connected to the first power source; a second current-mirror circuit including a third MOS transistor and a fourth MOS transistor; a first resistor connected to the first node; a first bipolar transistor having a collector connected to the first resistor, an emitter connected to a second power source, and a base connected to the first node; a second bipolar transistor having a collector connected to the second node, an emitter connected to the second power source, and a base connected to the first bipolar transistor; a fifth MOS transistor connected between the first power source and an output terminal; and a third resistor connected between the output terminal and the second power source.
B41J 2/435 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par l'irradiation sélective d'un matériau d'impression ou de transfert d'impression
B41J 2/47 - Machines à écrire ou mécanismes d'impression sélective caractérisés par le procédé d'impression ou de marquage pour lequel ils sont conçus caractérisés par l'irradiation sélective d'un matériau d'impression ou de transfert d'impression utilisant la combinaison du balayage et de la modulation de lumière
A method for controlling the use of a plurality of peripheral devices by a user is disclosed. The method includes assigning access rights to a user for access to individual ones of the peripheral devices, and quotas to each user for the use of the peripheral devices over a predetermined period. The system collects the use of each one of the peripheral devices by each user and totals the use by each user of the peripheral devices over the predetermined period. The method prevents a user from using the peripheral devices when the user exceeds the user's quota. The method also prevents a user from using peripheral devices to which the user has not been granted access rights.
G06F 3/00 - Dispositions d'entrée pour le transfert de données destinées à être traitées sous une forme maniable par le calculateurDispositions de sortie pour le transfert de données de l'unité de traitement à l'unité de sortie, p. ex. dispositions d'interface
G06F 15/00 - Calculateurs numériques en généralÉquipement de traitement de données en général
61.
Driving circuit, driving device and image forming device
Each of a plurality of gate driving parts outputs a first potential (2 V) during a period in which the gates of a plurality of thyristors belonging to the corresponding set are driven (S1N=Low) and outputs a second potential (5 V) that is higher than the first potential at a rising part of the anode driving voltage during a period in which the gates of a plurality of thyristors belonging to the corresponding set are not driven (S1N=High). Each of a plurality of gate driving parts outputs a third potential (3 V) that is lower than the second potential at periods other than the rising part of the anode driving voltage during a period in which the gates of a plurality of thyristors belonging to the corresponding set are not driven (S1N=High).
H03B 1/00 - PRODUCTION D'OSCILLATIONS, DIRECTEMENT OU PAR CHANGEMENT DE FRÉQUENCE, À L'AIDE DE CIRCUITS UTILISANT DES ÉLÉMENTS ACTIFS QUI FONCTIONNENT D'UNE MANIÈRE NON COMMUTATIVEPRODUCTION DE BRUIT PAR DE TELS CIRCUITS Détails
H03K 3/00 - Circuits pour produire des impulsions électriquesCircuits monostables, bistables ou multistables
A print apparatus is supplied that feeds continuous paper with suppressing its swelling caused by perforations or crease. In the print apparatus, a platen is furnished opposite to a printing section; a medium support member is furnished capable of changing an interval from the platen and supports a record medium toward the platen; and a medium support auxiliary member is furnished on the opposite side to the platen in the medium support member, and when the medium support member is made to separate from the platen, the medium support auxiliary member is made to protrude from the medium support member.
B41J 11/48 - Appareils pour enregistrements condensés, bordereaux, ou travail similaire utilisant plusieurs papiers ou jeux de papier
B41J 11/50 - Appareils pour enregistrements condensés, bordereaux, ou travail similaire utilisant plusieurs papiers ou jeux de papier dans lesquels plusieurs papiers ou jeux de papier sont utilisés séparément dans la même direction vers la position d'impression
63.
Fuser device having separator with inclined surface, and image forming device
A fuser device includes: a fuser member that heats developer on a print medium; a pressure member that presses the fuser member so as to provide a contact region therebetween; and a separation member that separates the print medium, which is ejected from the contact region, from either the fuser member or the pressure member. The separation member includes a separator in a plate-like shape and a support member that supports the separator such that the separator is disposed in the vicinity of the fuser member. The separator includes a planar part in a plate-like shape that is sustained by the support member; a tip part that is a tip of the separator, an inclined surface part that is inclined toward the tip part in a thickness direction of the separator, a border part that is defined as a boundary between the planar part and the inclined surface part.
An image forming apparatus includes a first image forming portion for forming a developer image, said first image forming portion including a first image supporting member for forming a static latent image and a first developing member for attaching developer to the static latent image; a second image forming portion for forming a developer image, said second image forming portion including a second image supporting member for forming a static latent image and a second developing member for attaching developer to the static latent image; a transfer portion for transferring the developer image to a printing medium; and a fixing unit for fixing the developer image to the printing medium. The second developing member has a surface roughness greater than that of the first developing member. The fixing unit is disposed at a position closer to the first image forming portion relative to the second image forming portion.
A lens array includes a plurality of lens assembly members with a plurality of lenses, a light blocking member with a plurality of apertures arranged therein, and a light blocking member including a plurality of apertures arranged therein. The lens assembly members are arranged so that an optical axis of each of the lenses of one of the lens assembly members is aligned with an optical axis of each of the lenses of another of the lens assembly members. Further, the lens assembly members and the light blocking member are arranged so that the following relationship is satisfied:
where P is a pitch of the lenses, F is a focal length of each of the lenses, LO is a distance between an object surface and each of the lenses, and RA is a distance between the optical axis and an inner surface of the aperture.
An image forming device includes a plurality of image forming units each including a developer carrier that carries developer; an image carrier that forms a developer image on a surface layer with the developer supplied from the developer carrier; and a developer collector that is positioned to contact the surface layer of the image carrier and that removes residual developer after transferring the developer image formed on the surface layer onto a recording sheet. Wherein the developer collector in a first image forming unit has a higher linear contact pressure against the surface layer of the image carrier than that of other image forming units, and a thickness of the surface layer of the image carrier of the first image forming unit is greater than a thickness of the image carrier of the other image forming units.
An invented fixing device having a fixing roller for fixing developer to a recording medium and plural fixing heaters for heating the fixing roller includes a temperature detection unit as well as a thermistor for detecting the temperature of the fixing roller, a RAM storing the switching temperature for switching drive of the fixing heaters, a heater selection unit for selecting some of the fixing heaters to be driven based on the switching temperature and the detected temperature of the fixing member detected through the temperature detection unit, and a heat control unit for selectively driving the fixing heater selected by the heater selection unit.
A sheet guide is rotationally supported by a shaft member to rotate freely on the shaft member. The sheet guide includes a support part that supports the sheet guide on the shaft member, a guide part that contacts sheets and guides sheets in a predetermined direction, and a weight, which has a predetermined weight, is arranged on an opposite side of the support part from the guide part, wherein the weight causes the guide part to rotate to a predetermined position when an external force applied to the guide part is released.
A medium carrying mechanism includes a carrying roller that carries a medium, two correction rollers for medium correction that face the carrying roller and that are positioned along a medium carrying direction, a bracket that includes a rotation shaft and that supports the correction rollers, a supporting member that supports the rotation shaft, and a bias member that biases the rotation shaft toward the carrying roller.
An exposing device includes a plurality of light emitting elements, a substrate to which the plurality of light emitting elements are mounted, an optical system that focuses lights emitted by the plurality of light emitting elements, and a holder that holds the optical system. The holder has a substrate abutting surface that abuts against the substrate. The holder includes a base material portion made of metal, and a substrate abutting portion formed integrally with the base material portion. The substrate abutting portion is made of resin having electrical insulation property. The surface abutting surface is formed on the surface abutting portion.
B41J 15/14 - Dispositifs de supports, d'alimentation ou de guidageMontages pour rouleaux ou axes caractérisés par leur application à des systèmes d'impression ayant des chariots se déplaçant transversalement et non solidaires du chariot
An image forming apparatus includes a first image forming unit for forming a first developer image; a second image forming unit for forming a second developer image; a transfer unit for transferring at least one of the first developer image and the second developer image; a separation contacting unit for moving at least one of the first image forming unit and the second image forming unit to a first position and a second position; a density measurement unit for measuring a first image density and a second image density of the first developer image; and a control unit including a density calculation unit for calculating a difference between the first image density and the second image density and a density correction unit for correcting a density of the first developer image according to the difference.
An image forming apparatus includes an image carrier, a charging device to be applied with a charging voltage, an exposure device, a developer carrier to be applied with a development voltage, a developer supplying member to be applied with a supply voltage, a developer regulation member to be applied with a regulation voltage, and a voltage controller. The developer carrier has thereon a developer having a charge amount Q/M. The charge amount Q/M satisfies 25 [μC/g]≦|Q/M|≦40 [μC/g]. The image carrier has a surface potential Vopc, the development voltage is expressed as Vdb, and the developer carrier has a developer layer potential Vtnr thereon. The developer layer potential Vtnr relative to a difference between the surface potential Vopc and the development voltage Vdb is expressed by a ratio γ. The ratio γ satisfies 0.1≦γ≦0.2.
G03G 15/06 - Appareils pour procédés électrographiques utilisant un dessin de charge pour développer
G03G 15/02 - Appareils pour procédés électrographiques utilisant un dessin de charge pour déposer une charge uniforme, p. ex. pour sensibiliserDispositifs pour la décharge corona
73.
Developer supplying member, developing device, and image forming apparatus
A developer supplying member includes a foamed member formed of continuous foams for supplying developer to a developer supporting member. The foamed member has a high resistivity in terms of electrical conductivity through ion conductivity, and has a low resistivity in terms of electrical conductivity after carbon black is attached to foam cell walls thereof.
G03G 15/08 - Appareils pour procédés électrographiques utilisant un dessin de charge pour développer en utilisant un développateur solide, p. ex. développateur en poudre
09 - Appareils et instruments scientifiques et électriques
Produits et services
Printers, computer peripherals, and their parts and accessories, namely, printer heads, paper feed rollers, platen rollers and printer cleaning kits primarily comprised of unfilled ink printer cartridges for cleaning purposes, printer cleaning cloths and printer cleaning sticks
75.
Sheet feeding apparatus, image reading apparatus and image forming apparatus
A sheet feeding apparatus includes a first feeding member that feeds a sheet along a predetermined feeding path, and a second feeding member that further feeds the sheet along the feeding path. The second feeding member is provided on a downstream side of the first feeding member along the feeding path. A sheet guide for guiding the sheet is provided between the first and second feeding members along the feeding path. The sheet feeding apparatus further includes a sheet holding member that holds the sheet against the sheet guide, and a biasing assisting member that applies a biasing force to the sheet holding member by means of the sheet which is fed between the first and second feeding members. The biasing force assists the sheet holding member to hold the sheet against the sheet guide.
An image forming apparatus includes a first image supporting member for forming a first image; a second image supporting member arranged adjacent to the first image supporting member for forming a second image; a first drive unit for driving the first image supporting member through a first driving force having a first phase; a second drive unit for driving the second image supporting member through a second driving force having a second phase shifted from the first phase; and a transfer unit for transferring the first image and the second image to a printing medium.
A heating device includes: a driving member configured to rotate; a driven member configured to rotate with the rotation of the driving member; a heater configured to heat a surface of one of the driving member and the driven member; a temperature detector configured to measure the temperature of the heated surface; and a controller operable to control heating of the heater based on the measurement result of the temperature detector. The controller includes: a calculator operable to calculate a change ratio of a slope of a temperature change of the heated surface with time, based on a first temperature detected by the temperature detector at a first time point and a second temperature detected by the temperature detector at a second time point a predetermined time interval after the first time point; and a determiner operable to determine that an abnormality occurs when the change ratio exceeds a threshold.
An image forming apparatus includes: an image carrier; a developer carrier configured to supply developer to the image carrier; a power supply unit configured to apply a voltage to the developer carrier; a drive unit configured to rotationally drive the image carrier and developer carrier; a rotation amount determiner configured to determine the amount of rotation of the image carrier or the developer carrier in a predetermined time period; and a drive control unit configured to instruct the drive unit to rotate the image carrier and the developer carrier in a non-printing state, when it is determined that the rotation amount in a printing operation in the predetermined time period was equal to or greater than a threshold.
An image forming apparatus includes: a heat transfer member having a width extending along a direction orthogonal to a medium conveying direction along which a medium is conveyed, the heat transfer member transferring heat from a heater to the medium; the heater provided along substantially the entire width of the heat transfer member and configured to heat the heat transfer member so as to heat the medium via the heat transfer member; a temperature detector configured to detect the temperature of the widthwise center of the heat transfer member; a temperature setting unit configured to set a target temperature by correcting a default target temperature, depending on the difference between the default target temperature and the temperature that is detected by the temperature detector when the heater starts to heat; a heat controller configured to control the heater to make the temperature detected by the temperature detector the target temperature.
G03G 15/08 - Appareils pour procédés électrographiques utilisant un dessin de charge pour développer en utilisant un développateur solide, p. ex. développateur en poudre
A power supply device includes: an oscillator configured to output a clock signal; a pulse output unit configured to output a pulse by dividing the frequency of the clock signal; a switching element driven by the pulse; a piezoelectric transformer configured to intermittently receive a voltage from the switching element and to output a high alternating current voltage; a rectifier configured to convert the high alternating current voltage to a high direct current voltage; an output voltage conversion unit configured to convert the high direct current voltage to a low direct current voltage; a target setter configured to output a target value; and a comparison unit configured to compare the low direct current voltage with the target value and to output a comparison result. A frequency division ratio of the pulse is controlled according to the comparison result, and thereby is changed so as to obtain the target value.
An image forming apparatus includes a consumable supply remaining amount detection unit for detecting a remaining amount of a consumable supply; a printable length detection unit for determining a printable length of a medium printable with the remaining amount; a printable length determining processing unit for determining whether the printable length is smaller than a requested print length of the medium requested with print data; and a printing processing unit for performing a partial printing operation when the printable length determining processing unit determines that the printable length is smaller than the requested print length.
A lens array unit focuses the light emitted from light emitting elements on the photoconductive drum. A longitudinally extending lens array includes a plurality of lenses and projections. The lenses are aligned in a row substantially perpendicular to optical axes of the lenses. The projections are disposed on both sides of the row, and extend outwardly further than the lens surfaces to protect the lens surfaces of the plurality of lenses. A light shielding member includes a mounting portion that holds the lens plate and a light shielding portion that shields part light passing through the lenses.
A button-key structure includes a plurality of button-keys arranged next to each other; and a button-key supporting portion disposed on a downstream side in a direction that the button-keys move. The button-key supporting portion includes a guide portion disposed between the button-keys in parallel to the direction that the button-key move.
H01H 9/26 - Mécanismes d'interverrouillage, verrouillage ou accrochage pour interverrouillage de plusieurs interrupteurs
H01H 13/72 - Interrupteurs ayant un organe moteur à mouvement rectiligne ou des organes adaptés pour pousser ou tirer dans une seule direction, p. ex. interrupteur à bouton-poussoir ayant une pluralité d'éléments moteurs associés à différents jeux de contacts, p. ex. claviers dans lesquels l'interrupteur comporte des moyens pour limiter le nombre d'éléments moteurs qui peuvent être actionnés simultanément
H01H 13/76 - Interrupteurs ayant un organe moteur à mouvement rectiligne ou des organes adaptés pour pousser ou tirer dans une seule direction, p. ex. interrupteur à bouton-poussoir ayant une pluralité d'éléments moteurs associés à différents jeux de contacts, p. ex. claviers dans lesquels quelques-uns ou l'ensemble des éléments moteurs actionnent différentes combinaisons des jeux de contacts, p. ex. dix éléments moteurs actionnant différentes combinaisons de quatre jeux de contacts
An image forming and cutting apparatus has an inkjet head with a first coupling member having a hole, a cutting head with a second coupling member having a hole, and a coupling pin that is received by the holes of the coupling members to couple the first and second coupling members to each other. The coupling pin has first and tapered portions with a columnar portion interposed therebetween. The hole of the first coupling member has a tapered surface for receiving the first tapered portion, and the hole of the second coupling member has a tapered surface portion and a columnar surface portion for receiving the second tapered portion and the columnar portion, respectively. The first coupling member is made of an elastic material and is configured to be pressed and deflected by the coupling pin due to elasticity of the elastic material when the coupling pin is moved in the first direction and is received by the holes of the first and second coupling members so that the first and second coupling members are coupled to one another with a gap therebetween while the columnar portion of the coupling pin protrudes from the hole of the second coupling member.
An image forming apparatus includes first and second image supporting members; first and second developer supporting members for forming a first developer image in a first color and a second developer image in a second color, respectively; first and second transfer members for transferring the first developer image and the second developer image to a medium, respectively; a voltage applying unit for applying a first voltage to one of the first image supporting member and the first transfer member and a second voltage to one of the second image supporting member and the second transfer member. The voltage applying unit is arranged to apply the second voltage greater than the first voltage to one of the second image supporting member and the second transfer member when a printing operation is performed to form an image only in the first color.
G03G 15/09 - Appareils pour procédés électrographiques utilisant un dessin de charge pour développer en utilisant un développateur solide, p. ex. développateur en poudre utilisant une brosse magnétique
87.
Information processing system, input apparatus, and information processing method
An information processing system uses an input apparatus to input user information. After authentication of the user information, the input apparatus-transmits control information to an information processing apparatus, indicating which functions of the information processing apparatus the user may use. The control information is independent of the particular method by which authentication is performed. Use of the information processing apparatus can accordingly be controlled by a variety of methods without requiring any user authentication capability to be provided in the information processing apparatus itself, and new authentication methods can be implemented without modification or replacement of existing information processing apparatus.
An image forming apparatus is configured such that a developer image is transferred by a transfer section from an image bearing body onto a recording medium. The image forming apparatus includes a memory, an apparatus usage information obtaining section, and a transfer voltage correcting section. The memory stores correction values for a transfer voltage, the correction values corresponding to changes in an operation status of the image forming apparatus. The apparatus usage information obtaining section obtains information on the operation status. The transfer voltage correcting section corrects the transfer voltage based on the correction values and the information on the operation status.
G03G 15/16 - Appareils pour procédés électrographiques utilisant un dessin de charge pour transférer un dessin à un second support d'un dessin de teinte, p. ex. dessin de poudre
89.
Light-emitting element array, driving device, and image forming apparatus
A light-emitting element array has a plurality of three-terminal light-emitting elements such as light-emitting thyristors with anode, cathode, and gate terminals. The anode terminal of each light-emitting element is connected to a driving circuit. The cathode terminal is grounded. The gate terminals of at least some of the three-terminal light-emitting elements are driven from a common buffer, and within this group of three-terminal light-emitting elements, the anode terminals are driven individually. This enables the array of three-terminal light-emitting elements to be driven in essentially the same way as an array of two-terminal light-emitting elements, but without the need for large power transistors between the cathode terminals and ground.
A print controlling apparatus is supplied capable of adjusting image of electronic document to an optimum size. In the print controlling apparatus which includes an inputting section for inputting image data of electronic document and an expanding section for expanding the inputted image data into print data, and is used for printing the electronic document onto record medium, a first obtaining section obtains page size information representing page size of the electronic document; a second obtaining section obtains medium size information representing medium size of the record medium; a comparing and judging section compares the page size information with the medium size information, and judges whether the two size information are coincident; and when the two size information are coincident, an extracting section extracts image data inside of region corresponding to print region of the record medium from the image data, wherein the expanding section expands the extracted image data inside of region and generates print data inside of region corresponding to the print region.
G06K 15/02 - Dispositions pour produire une présentation visuelle permanente des données de sortie utilisant des imprimantes
91.
Printing system and information processing apparatus includes a first printer driver and a printer driver acquisition unit acquiring the second printer driver
A printing system includes an information processing apparatus, an image forming apparatus, and a printer driver storage device. The information processing includes a first printer driver to operate during preparation of general print data, the image forming apparatus prints based on print data, and the printer driver storage device stores a second printer driver to operate during preparation of specific print data having an instruction specialized for the image forming apparatus. The information processing apparatus includes a printer driver acquisition unit acquiring the second printer driver, a printer connection detection unit, and a print data preparation unit preparing the print data using one of the printer drivers. The printer connection detection unit allows a user to select whether to acquire the second printer driver, allows the printer driver acquisition unit to acquire the second printer driver, and allows one of the printer drivers to correspond to the image forming apparatus.
G06F 3/12 - Sortie numérique vers une unité d'impression
G06F 3/00 - Dispositions d'entrée pour le transfert de données destinées à être traitées sous une forme maniable par le calculateurDispositions de sortie pour le transfert de données de l'unité de traitement à l'unité de sortie, p. ex. dispositions d'interface
G06F 9/44 - Dispositions pour exécuter des programmes spécifiques
G06F 9/46 - Dispositions pour la multiprogrammation
G06K 15/00 - Dispositions pour produire une présentation visuelle permanente des données de sortie
H04N 1/00 - Balayage, transmission ou reproduction de documents ou similaires, p. ex. transmission de fac-similésLeurs détails
An image processing device includes a displaying unit that reads and displays an image; a base color region designator that designates a base color region of the image displayed on the displaying unit; a non-base color region designator that designates a non-base color region of the image displayed on the displaying unit; and a base eliminator that executes a base elimination of the image based on the base color region designated by the base color region designator and the non-base color region designated by the non-base color region designator.
A facsimile transferring system is supplied capable of preventing a paper on which facsimile data transferred from his/her work place is printed from leaving as it is at a place where the destination person does not exist. In the system, an entering/leaving room managing equipment and a facsimile apparatus are furnished at plural places respectively; and a transfer/notification processing server transfers received facsimile data to one of the facsimile apparatus on the basis of entering/leaving room management information, wherein the transfer/notification processing server includes a destination person whereabouts managing section that specifies a whereabouts place of destination person of the received facsimile data on the basis of entering/leaving room management information, and a facsimile apparatus controlling section that transfers the received facsimile data to the facsimile apparatus furnished at the whereabouts place of the destination person on the basis of a control of the destination person whereabouts managing section.
An image processing apparatus capable of managing easily secret information even with detachably attaching an external memorizing device, includes an ID (plug and play ID) retrieving unit for retrieving ID from the connected memory, a user information storing unit for storing user information, an active memory information storing unit for storing the retrieved ID with corresponding to the respective users, a memory use judging unit for judging as to whether the memory is usable based on the ID retrieved from the connected memory and on the ID stored in the active memory information storing unit, and a data writing controlling unit for writing data to the memory judged as usable.
An image processing apparatus is provided to include the information retrieving unit for retrieving writing processing information out of the external memorizing device, and the image processing apparatus turns out as to whether certain information is in a processing of writing by retrieving the writing processing information out of the external memorizing device. If it is turned out that the status is in a processing of writing, the corresponding information is automatically deleted. A user is not necessary to delete the writing failed file manually, so that the user's work load will be reduced.
An image reading apparatus includes an image reader, a document feeder, and a document retainer. A document feeder feeds the document to the image reader, and the image reader reads an image of a document. The document feeder discharges the document onto a stacker after the image of the document has been read. The document feeder is pivotal relative to the image reader. When the document feeder opens relative to the reader at an angle, the document retainer presses the document against the stacker.
In a color reading apparatus for successively reading respective red, green, and blue colors in each line while a document is continuously conveyed to a plurality of line sensor units arranged in a zigzag manner, the line sensor units are arranged with a distance equal to or shorter than a unit of line to prevent a color shift. When read data of the plurality of line sensor units in a conveying direction are to be combined, image data shifted by the number of lines corresponding to distances between the line sensor units in the conveying direction are set as first combination candidates. A color code and a line code are added to each of the data. Image data having the same color code and the same line code are combined. According to the image reading apparatus structured as described above, it is possible to obtain data capable of reproducing read data for each color on the same line without errors.
An image forming apparatus includes a developer storage portion for storing developer. The image forming apparatus further includes a developer supply portion for supplying developer through an opening portion of the developer storage portion. When a closing member is attached to the developer storage portion for closing the opening portion, the developer supply portion is separated from the developer storage portion.
An image forming apparatus includes a fixing member; a pressing member abutting against the fixing member; a first temperature detection unit for detecting a temperature of the fixing member; a heating member for heating the fixing member; a power control unit for controlling power supplied to the heating member; a drive unit for rotating the fixing member; and a control unit for controlling the power control unit and the drive unit according to the temperature of the fixing member and a temperature of the pressing member before the fixing member rotates.
