Abrégé

There is provided herein a dispenser formed of card-based or paper-based material for a product in stick form. The dispenser includes a dispenser axis, a proximal end, a distal end, a product stick carrier, and a sleeve. The dispenser axis extends along a length of the dispenser. The product stick carrier is in the form of a cylindrical tube for receiving a product stick in use. The sleeve is in the form of a cylindrical tube, wherein the product stick carrier is located within the sleeve and wherein the product stick carrier and the sleeve are moveable axially relative to one another. The product stick carrier includes a cylindrical wall, a carrier proximal end, a carrier distal end and a plurality of tabs. The cylindrical wall has an inner surface and an outer surface. The product stick extends from the carrier distal end in use. The plurality of tabs extend inwardly toward the dispenser axis from the inner surface of the product stick carrier. The plurality of tabs are configured to engage a product stick supported by the product stick carrier in use to assist in securing the product stick within the product stick carrier.

Classes IPC  ?

• B26F 1/22 - Perforation par fentes, c.-à-d. en formant des entailles fermées à leurs extrémités sans enlèvement de matière pour former des coupes non rectilignes, p. ex. pour faire des onglets de repérage dans les dictionnaires
• A45D 40/02 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement
• B26F 1/44 - Outils de coupe à cet effetMatrices à cet effet

Abrégé

There is provided herein a dispenser formed of card-based or paper-based material for a product in stick form. The dispenser includes a product stick carrier, an outer sleeve, a product concealing sleeve, a first proximal facing edge, a second proximal facing edge, a first distal facing edge, and a second distal facing edge. The product stick carrier is in the form of a cylindrical tube and includes a product stick support for supporting a product stick in use. The outer sleeve is in the form of a cylindrical tube disposed radially outwardly of the product stick carrier. The product stick carrier is fixed relative to the outer sleeve. The product concealing sleeve is in the form of a cylindrical tube disposed radially inwardly of the outer sleeve and radially outwardly of the product stick carrier. The product concealing sleeve is retractable from a first, fully extended axial position relative to the outer sleeve and product stick carrier for concealing a product stick supported by the product stick support in use in order to expose the product stick. The first and second proximal facing edges and the first and second distal facing edges are disposed radially outwardly of the product stick carrier and radially inwardly of the product concealing sleeve. The first proximal facing edge is fixed with respect to the first distal facing edge and the product stick carrier. The second proximal facing edge is fixed with respect to the second distal facing edge and the product concealing sleeve. The first proximal facing edge and the second distal facing edge cooperate with one another to prevent advancement of the product concealing sleeve relative to the outer sleeve and product stick carrier beyond a set point so as to define the first, fully extended position. The first distal facing edge and the second proximal facing edge cooperate with one another to selectively prevent or allow retraction of the product concealing sleeve from the first, fully extended position, wherein the selection of preventing or allowing retraction is determined by a rotational position of the product concealing sleeve with respect to the product stick carrier.

Classes IPC  ?

• A45D 40/02 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement
• A45D 40/00 - Emboîtages ou accessoires spécialement conçus pour la conservation ou l'emploi de produits de toilette ou cosmétiques solides ou pâteux, p. ex. de savons à barbe ou de rouges à lèvres
• A45D 40/12 - Emboîtages avec dispositions pour prévenir un mouvement involontaire du bâton

Abrégé

A method of manufacturing a dispenser for a product in stick form (50). The dispenser includes an inner tube (12) and a product concealing tube (16) disposed outwardly of the inner tube (12). The product concealing tube (16) is retractable and extendable relative to the inner tube (12) for exposing and covering a product stick (50) extending from a distal end of the inner tube (12) in use. The method includes: providing a first blank of sheet material for providing the inner tube (12) of the dispenser; wrapping the first blank around a mandrel to provide the inner tube (12) of the dispenser; and providing a second blank of sheet material for providing the product concealing tube (16) of the dispenser. The second blank comprises a slot, and a guide element (38) disposed within the slot. The method also includes: applying a bonding agent to the second blank in a region corresponding to a surface of the guide element (38); and wrapping the second blank around the inner tube (12) while the inner tube (12) is held on a mandrel to provide the product concealing tube (16), with the surface of the guide element (38) to which bonding agent has been applied facing the inner tube (12), such that the guide element (38) becomes bonded to an exterior surface of the inner tube (12). The slot provides a recess (24) in the interior surface of the formed product concealing tube (16). In use, the product concealing tube (16) is movable relative to the inner tube (12) with the guide element (38) cooperating with the recess (24) for guiding the movement of the product concealing tube (16) relative to the inner tube (12). There is also provided a dispenser for a product in stick form (50).

Classes IPC  ?

• B31B 50/28 - Pliage des feuilles, des flans ou des bandes autour de mandrins, p. ex. pour les opérations de fabrication du fond
• A45D 40/04 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement obtenu par une vis
• A45D 40/16 - Bâtons de rechangesDispositifs de moulage pour obtenir des bâtons
• B31B 50/62 - Assemblage des surfaces ou des bords opposésCollage par des adhésifs
• B31B 100/00 - Réceptacles rigides ou semi-rigides fabriqués par pliage de feuilles, de flans ou de bandes d’une seule pièce

Abrégé

There is provided herein a dispenser 2 for a product in stick form. The dispenser 2 includes a product stick carrier 10, an outer sleeve 6, and a product concealing sleeve 8. The product concealing sleeve 8 is selectively retractable to conceal or expose a product stick, and is disposed radially between the product stick carrier 10 and the outer sleeve 6. The dispenser 2 includes inter-engaging formations 28, 30 associated with the product stick carrier 10 and product concealing sleeve 8 respectively. The inter-engaging formations 28, 30 cooperate with one another to prevent advancement of the product concealing sleeve 8 beyond a set point. The inter-engaging formations 30 associated with the product concealing sleeve 8 is provided by a collar piece 30 affixed to an interior surface thereof at a proximal end. The collar piece 30 includes an axially extending split 43 and free ends 37, 39 on either side of the split 43, said free ends 37, 39 biased toward the centre to resiliently grip the product stick carrier 10. Alternative dispensers are also provided operating by similar means.

Classes IPC  ?

• A45D 40/02 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement
• A45D 40/12 - Emboîtages avec dispositions pour prévenir un mouvement involontaire du bâton

Abrégé

There is provided herein a container with four side wall panels 10, 12, 14, 16, four base panels 36, 38, 40, 42 connected thereto about fold lines and a glue panel 18. The container has an overwrap layer 8 covering the panels 10, 12, 14, 16, 18, 36, 38, 40, 42. The overwrap layer 8 has overhanging portions 70, 72 which overhang the edges of a pair of the base panel portions 38, 42 and are adhered to the other base panel portions 36, 40. There is also provided a method for making such a container and a blank 26 for such a container.

Classes IPC  ?

• B65D 5/20 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en repliant les parties reliées à un panneau central sur chaque côté pour former le corps du réceptacle, p. ex. en forme de plateau
• B65D 5/42 - Détails des réceptacles ou des flans de réceptacles pliables ou dressables

Abrégé

From one aspect, there is provided a dispenser 2 for a product in stick form. The dispenser 2 includes a product stick carrier 8, an outer sleeve 4 and a product concealing sleeve 6. The product stick carrier 8 is in the form of a cylindrical tube including a product stick support 10 for supporting a product stick 16 in use. The outer sleeve 4 is in the form of a cylindrical tube disposed radially outwardly of the product stick carrier 8. The product stick carrier 8 is fixed relative to the outer sleeve 4. The product concealing sleeve 6 is in the form of a cylindrical tube disposed radially inwardly of the outer sleeve 4. The product concealing sleeve 6 is retractable from an extended position relative to the outer sleeve 4 and product stick carrier 8 for concealing the product stick 16 supported by the product stick support 10 in use in order to expose the product stick 16. The product concealing sleeve 6 is disposed radially outwardly of the product stick carrier 8 between the product stick carrier 8 and the outer sleeve 4. The outer sleeve 4, product concealing sleeve 6 and product stick carrier 8 are each formed of a paper-based or card-based material, such as paperboard or cardboard. The product concealing sleeve 6 is rotatable relative to the outer sleeve 4 and product stick carrier 8. The product concealing sleeve 6 includes a lug 32 fixed to an interior surface thereof, wherein the lug 32 cooperates with a helical recess 34 in an exterior surface of the product stick carrier 8 for guiding movement of the product concealing sleeve 6 as it moves relative to the product stick carrier 8 and outer sleeve 4. The lug 32 moves within the helical recess 34 as the product concealing sleeve 6 moves relative to the product stick carrier 8 and outer sleeve 4. A method of forming the dispenser 2 is also provided.

Classes IPC  ?

• A45D 40/06 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de vissage
• A45D 40/00 - Emboîtages ou accessoires spécialement conçus pour la conservation ou l'emploi de produits de toilette ou cosmétiques solides ou pâteux, p. ex. de savons à barbe ou de rouges à lèvres

Abrégé

A container (100) includes a plurality of wall panels (110) that define an internal volume (138). The plurality of wall panels (110) include a front wall panel (112) that defines an opening (120). The container (100) further includes a lid (116) connected to one of the plurality of wall panels (110). The lid (116) includes a cover panel (118) and a front flap panel (114). The front flap panel (114) is defined by a flap fold line (142) and has a first surface (114a) and an opposing second surface (114b). The container (100) further includes a closure apparatus (130) affixed to the second surface (114b) of the front flap panel (114). The closure apparatus (130) is sized and shaped to be closely received with the opening (120) in the front wall panel (112). The closure apparatus (120) includes a cellulosic material.

Classes IPC  ?

• B65D 5/66 - Couvercles articulés
• B65D 65/46 - Emploi de matériaux désintégrables, solubles ou comestibles

Abrégé

A container (1) made of paper-based or card-based material comprises a sleeve (3) and a moulded pulp end plug (50) closing a top end thereof. The end plug includes resilient locking tabs (70) projecting outwardly therefrom, each locking tab being received in a respective recess (140) in the interior of the sleeve to securely retain the moulded pulp end plug within the end of the sleeve. The sleeve (3) includes an outer shell (31) and an insert (33) having the recesses (140). The end plug (50) is formed from first and second inter-engaging portions (60, 62). The first portion includes the resilient locking tabs (70) and the second portion (62) fits within the first portion and has sidewalls which engage the interior of sidewalls of the first portion to reinforce the first portion.

Classes IPC  ?

• B65D 5/14 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps avec les fermetures d'extrémité formées indépendamment du corps tubulaire avec des fermetures d'extrémité insérées
• B65D 5/42 - Détails des réceptacles ou des flans de réceptacles pliables ou dressables
• B65D 5/44 - Parties insérées dans le réceptacle, qui en font partie intégrante ou qui lui sont fixées pour former des garnitures intérieures ou extérieures
• B65D 8/00 - Réceptacles de section transversale courbe, dont le corps est formé par jonction ou liaison de plusieurs composants rigides, ou sensiblement rigides, constitués en totalité ou principalement en métal, en matière plastique, en bois ou en un matériau de remplacement
• B65D 81/133 - Réceptacles, éléments d'emballage ou paquets pour contenus présentant des problèmes particuliers de stockage ou de transport ou adaptés pour servir à d'autres fins que l'emballage après avoir été vidés de leur contenu spécialement adaptés pour protéger leur contenu des dommages mécaniques maintenant le contenu en position éloignée des parois de l'emballage ou des autres pièces du contenu utilisant des feuilles rigides ou semi-rigides en matériau amortisseur de chocs de forme spécialement adaptée au contenu, p. ex. plateaux
• B65D 85/30 - Réceptacles, éléments d'emballage ou paquets spécialement adaptés à des objets ou à des matériaux particuliers pour objets particulièrement sensibles aux dommages par chocs ou compression

Abrégé

There is provided herein a dispenser for a product in stick form, the dispenser having a longitudinal axis and including a housing tube and a product stick support. The housing tube is made of card-based or paper-based material and is for housing a product stick in use. The housing tube has a proximal end and a distal end from which product is dispensed. The product stick support is slidably received within the housing tube and is configured to support the product stick in use. The product stick support includes a distal end, which faces a product stick for supporting the product stick in use, and an opposite proximal end. A user may push against the proximal end of the product stick support to advance the product stick support within the housing tube in a direction toward the distal end of the housing tube for advancing the product stick supported by the distal end of the product stick support through the distal end of the housing tube in use. The product stick support includes a card-based or paper-based layered fluted material, wherein the layered fluted material includes: a distal disc providing a distal face and defining the distal end of the product stick support for supporting the product stick; a first layer of flutes arranged proximally of and affixed to the distal disc; an intermediate layer located proximally of and affixed to the first layer of flutes, wherein the intermediate layer includes a first intermediate disc; a second layer of flutes arranged proximally of and affixed to the intermediate layer; and a proximal disc located proximally of and affixed to the second layer of flutes, wherein the proximal disc provides a proximal face and defines the proximal end of the product stick support. There is also provided an assembly and a method for the manufacture thereof.

Classes IPC  ?

• A45D 40/02 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement
• B43M 11/06 - Dispositifs tenus à la main
• A45D 40/00 - Emboîtages ou accessoires spécialement conçus pour la conservation ou l'emploi de produits de toilette ou cosmétiques solides ou pâteux, p. ex. de savons à barbe ou de rouges à lèvres

Abrégé

There is provided herein a container made of card-based or paper-based material. The container includes an inner tube, an outer tube, a membrane and a distal member. The inner tube includes a distal end and a closed proximal end. The outer tube is sized to fit snugly around the inner tube. The membrane sealingly closes the distal end of the inner tube to provide a sealed internal chamber. The distal member is fixed with respect to the outer tube and provides a backing surface distally adjacent the membrane. There is also provided an assembly including the container and a product therein. There is also provided a method for manufacturing the container

Classes IPC  ?

• B65D 3/22 - Réceptacles rigides ou semi-rigides ayant un corps ou des parois périphériques de section transversale courbe ou partiellement courbe, réalisés en enroulant ou courbant du papier sans plier selon des lignes définies avec double paroisRéceptacles rigides ou semi-rigides ayant un corps ou des parois périphériques de section transversale courbe ou partiellement courbe, réalisés en enroulant ou courbant du papier sans plier selon des lignes définies avec des parois incorporant des chambres à airRéceptacles rigides ou semi-rigides ayant un corps ou des parois périphériques de section transversale courbe ou partiellement courbe, réalisés en enroulant ou courbant du papier sans plier selon des lignes définies avec des parois faites en matériau stratifié
• B65D 3/12 - Disques à rebord fixés à demeure, p. ex. par adhésifs ou par thermosoudure
• B65D 3/18 - Disques sans rebord s'engageant dans une rainure du corps du réceptacle et fixés par enroulage dans l'extrémité du corps
• B65D 3/26 - Dispositifs d'ouverture incorporés dans ou fixés aux réceptacles
• B31C 1/06 - Fabrication de tubes ou de tuyaux par avance perpendiculaire à l'axe de rotation du mandrin enrouleur et introduction d'un fond dans une extrémité de tube pour former un réceptacle
• B31C 11/02 - Mécanismes par enroulement combinés à d'autres mécanismes pour la mise en forme complémentaire des articles

Abrégé

A dispenser for a product in stick form includes a product stick carrier (210), an outer sleeve (206) and a product concealing sleeve (208). The product stick carrier (210) includes a product stick support (225). The outer sleeve (206) is a cylindrical tube disposed radially outwardly of the product stick carrier (210). The product stick carrier (210) is fixed relative to the outer sleeve (206). The product concealing sleeve (208) is a cylindrical tube disposed radially inwardly of the outer sleeve (206) and is retractable from a first, fully extended position relative to the outer sleeve (206) and product stick carrier (210) for concealing a product stick (204) supported by the product stick support (225) in use in order to expose the product stick (204). The product concealing sleeve (208) is disposed radially outwardly of the product stick carrier (210) between the product stick carrier (210) and the outer sleeve (206). Inter-engaging formations are associated with either the product concealing sleeve (208) and the outer sleeve (206) or the product stick carrier (210) and product concealing sleeve (208). The inter-engaging formations cooperate with one another to prevent advancement of the product concealing sleeve (208) relative to the outer sleeve (206) and product stick carrier (210) beyond a set point so as to define the first, fully extended position. The outer sleeve (206), product concealing sleeve (208) and product stick carrier (210) are each formed of a paper-based or card-based material.

Classes IPC  ?

• A45D 40/02 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement

Abrégé

There is provided herein a dispenser (2) for a product in stick form. The dispenser (2) includes a product stick carrier (10), an outer sleeve (6) and a product concealing sleeve (8). The product stick carrier (10) includes a product stick support for supporting a product stick in use. The outer sleeve (6) is disposed outwardly of the product stick carrier (10). The product stick carrier (10) is fixed relative to the outer sleeve (6). The product concealing sleeve (8) is disposed inwardly of the outer sleeve (6) and is retractable from a first, fully extended position relative to the outer sleeve (6) for concealing a product stick supported by the product stick support in use in order to expose the product stick. The product concealing sleeve (8) and the outer sleeve (6) include inter-engaging flaps (110A-D) which cooperate with one another to prevent advancement of the product concealing sleeve (8) relative to the outer sleeve (6) beyond a set point so as to define the first, fully extended position. The outer sleeve (6), product concealing sleeve (8) and product stick carrier (10) are each formed of a paper-based or card-based material.

Classes IPC  ?

• A45D 40/26 - Instruments spécialement conçus pour appliquer une peinture pâteuse, p. ex. en utilisant un rouleau ou une bille

Abrégé

A carrier (2) made of cardboard, paperboard or other lightweight foldable sheet material, comprises a top sheet (4) defining one or more pockets (20) for receiving one or more products and a bottom sheet (6) attached to the top sheet (4). The top sheet (4) comprises one or more respective sets (30) of flaps (32) for forming the respective pockets (20), each flap (32) being hingedly connected at a proximal end (36) to a top surface (38) of the top sheet (4) about a respective flap hinge line (40) defined around an upper edge (42) of the respective pocket (20) and folded about the respective flap hinge line (40) to define a pocket side wall. The top sheet (4) further comprises respective tabs (50) hingedly connected to distal ends (46) of the respective flaps (32) about respective tab fold lines (52) and folded about a respective tab fold line (52) so as to lie along a base of the pocket (20). The bottom sheet (6) is bonded to the respective tabs (50) in a face to face relationship to close at least a portion the base of the pocket (20).

Classes IPC  ?

• B65D 75/36 - Objets ou matériaux enveloppés entre deux feuilles ou flans opposés à bords réunis, p. ex. par adhésifs à pression, pliage, thermosoudage ou soudage une ou les deux feuilles ou flans étant renfoncés pour épouser la forme du contenu une feuille ou un flan étant renfoncés et l'autre fait d'une feuille plate relativement rigide, p. ex. empaquetage pour ampoules
• B65B 43/10 - Formation de réceptacles à trois dimensions à partir de feuilles en les pliant
• B65B 5/02 - Machines caractérisées par l'incorporation de moyens pour fabriquer les réceptacles ou les récipients
• B65D 75/52 - Paquets comportant des objets ou matériaux partiellement ou complètement enfermés dans des bandelettes, des feuilles, des flans, des tubes ou des bandes en matériau souple mince, p. ex. dans des enveloppes pliées Détails

Abrégé

There is provided herein a dispenser (2) formed of card-based or paper-based material for a product (12) in stick form. The dispenser (2) includes a dispenser axis, a proximal end (40), a distal end (38), a product stick carrier (8), and a sleeve (6). The dispenser axis extends along a length of the dispenser. The product stick carrier is in the form of a cylindrical tube for receiving a product stick in use. The sleeve is in the form of a cylindrical tube, wherein the product stick carrier is located within the sleeve and wherein the product stick carrier and the sleeve are moveable axially relative to one another. The product stick carrier includes a cylindrical wall, a carrier proximal end, a carrier distal end and a plurality of tabs (260). The cylindrical wall has an inner surface and an outer surface. The product stick extends from the carrier distal end in use. The plurality of tabs extend inwardly toward the dispenser axis from the inner surface of the product stick carrier. The plurality of tabs are configured to engage a product stick supported by the product stick carrier in use to assist in securing the product stick within the product stick carrier.

Classes IPC  ?

• A45D 40/02 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement
• A45D 40/06 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de vissage
• B26F 1/22 - Perforation par fentes, c.-à-d. en formant des entailles fermées à leurs extrémités sans enlèvement de matière pour former des coupes non rectilignes, p. ex. pour faire des onglets de repérage dans les dictionnaires
• B26F 1/44 - Outils de coupe à cet effetMatrices à cet effet

Abrégé

There is provided herein a dispenser (2) formed of card-based or paper-based material for a product in stick form (12). The dispenser includes a product stick carrier (8), an outer sleeve (4), a product concealing sleeve (6), a first proximal facing edge (30), a second proximal facing edge (34), a first distal facing edge (32), and a second distal facing edge (36). The product stick carrier is in the form of a cylindrical tube and includes a product stick support for supporting a product stick in use. The outer sleeve is in the form of a cylindrical tube disposed radially outwardly of the product stick carrier. The product stick carrier is fixed relative to the outer sleeve. The product concealing sleeve is in the form of a cylindrical tube disposed radially inwardly of the outer sleeve and radially outwardly of the product stick carrier. The product concealing sleeve is retractable from a first, fully extended axial position relative to the outer sleeve and product stick carrier for concealing a product stick supported by the product stick support in use in order to expose the product stick. The first and second proximal facing edges and the first and second distal facing edges are disposed radially outwardly of the product stick carrier and radially inwardly of the product concealing sleeve. The first proximal facing edge is fixed with respect to the first distal facing edge and the product stick carrier. The second proximal facing edge is fixed with respect to the second distal facing edge and the product concealing sleeve. The first proximal facing edge and the second distal facing edge cooperate with one another to prevent advancement of the product concealing sleeve relative to the outer sleeve and product stick carrier beyond a set point so as to define the first, fully extended position. The first distal facing edge and the second proximal facing edge cooperate with one another to selectively prevent or allow retraction of the product concealing sleeve from the first, fully extended position, wherein the selection of preventing or allowing retraction is determined by a rotational position of the product concealing sleeve with respect to the product stick carrier.

Classes IPC  ?

• A45D 40/02 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement
• A45D 40/12 - Emboîtages avec dispositions pour prévenir un mouvement involontaire du bâton

Abrégé

A spiral wound tube comprising: (a) perforations extending transversely to a longitudinal axis of the tube; and (b) an end cap secured to an opening of the tube, wherein the perforations are positioned adjacent to the end cap to separate the end cap from the tube.

Classes IPC  ?

• B31B 50/00 - Fabrication de réceptacles rigides ou semi-rigides, p. ex. de boîtes ou de cartons
• B31B 50/14 - Découpage, p. ex. perforation, encochage, massicotage ou ébarbage
• B31B 50/28 - Pliage des feuilles, des flans ou des bandes autour de mandrins, p. ex. pour les opérations de fabrication du fond
• B31B 50/32 - Pliage des feuilles, des flans ou des bandes autour de mandrins, p. ex. pour les opérations de fabrication du fond de mandrins qui se déplacent suivant un trajet circulaire
• B65D 3/26 - Dispositifs d'ouverture incorporés dans ou fixés aux réceptacles
• B65D 8/00 - Réceptacles de section transversale courbe, dont le corps est formé par jonction ou liaison de plusieurs composants rigides, ou sensiblement rigides, constitués en totalité ou principalement en métal, en matière plastique, en bois ou en un matériau de remplacement
• B65D 59/04 - Manchons, p. ex. tubes postaux
• B31C 3/02 - Fabrication de tubes ou de tuyaux par avance oblique par rapport à l'axe de rotation du mandrin enrouleur et introduction d'un fond dans une extrémité de tube pour former un réceptacle
• B31B 110/20 - Forme des réceptacles rigides ou semi-rigides à section transversale courbe, p. ex. circulaire
• B31B 120/10 - Structure des réceptacles rigides ou semi-rigides pourvus de couvercles, p. ex. d'opercules
• B31B 120/50 - Structure des réceptacles rigides ou semi-rigides habillés ou renforcés extérieurement

Abrégé

There is provided herein a dispenser (2) for a product in stick form. The dispenser (2) includes a product stick carrier (10), an outer sleeve (6), and a product concealing sleeve (8). The product concealing sleeve (8) is selectively retractable to conceal or expose a product stick, and is disposed radially between the product stick carrier (10) and the outer sleeve (6). The dispenser (2) includes inter-engaging formations (28, 30) associated with the product stick carrier (10) and product concealing sleeve (8) respectively. The inter-engaging formations (28, 30) cooperate with one another to prevent advancement of the product concealing sleeve (8) beyond a set point. The inter-engaging formations (30) associated with the product concealing sleeve (8) is provided by a collar piece (30) affixed to an interior surface thereof at a proximal end. The collar piece (30) includes an axially extending split (43) and free ends (37, 39) on either side of the split (43), said free ends (37, 39) biased toward the centre to resiliently grip the product stick carrier (10). Alternative dispensers are also provided operating by similar means.

Classes IPC  ?

• A45D 40/02 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement

Abrégé

A dispenser (2) for a product in stick form comprises: a tubular body (4) having a longitudinal axis (A), the tubular body (4) including a tubular base part (6) and a removable cap (8) for closing an open end of the tubular base part (6). The tubular base part (6) comprises an outer tube (20) made from a paper-based or card-based material such as paperboard or cardboard and having an axially extending helical slot (30) formed in a radially inner surface (36) thereof, an inner tube (22) received within the outer tube (20) and made from a paper-based or card-based material such as paperboard or cardboard and having an axially extending slot (40) formed therethrough and a base (24) made from a paper-based or card-based material such as paperboard or cardboard which is rotatable about the longitudinal axis (A) relative to the outer tube (20) and to which the inner tube (22) is fixed so as to be rotatable therewith relative to the outer tube. A product stick carrier (50) is slidably received in the inner tube (22) and has a lug (54) projecting through the axially extending slot (20) of the inner tube (22) to engage with the axially extending helical slot (30) of the outer tube (20), whereby rotation of the base (24) relative to the outer tube (20) cams the lug (54) along the axially extending helical slot (30) so as to move the product stick carrier (50) along the inner tube (22) so as to extend the product stick (52) from the outer tube (20).

Classes IPC  ?

• A45D 40/06 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de vissage

Abrégé

Herein is provided a container including a plurality of sidewalls (3, 7, 9) connected to one another along foldlines, and a base. The base includes first, second, third and fourth base flaps (11, 13, 15, 17) connected along respective foldlines to respective sidewalls. The second and third base flaps (13, 15) are folded over the first base flap (11) and the fourth base flap (17) is folded over the second and third base flaps (13, 15). The fourth base flap (17) includes a base panel portion which forms part of the exterior of the base and a locking tab portion connected to a distal end of the base panel portion. The locking tab portion is inserted into the interior of the container through a slot defined by the first, second and third base flaps (11, 13, 15) to retain the base in a closed configuration. A cutline is provided extending inwardly from the side edge of the fourth base flap (17) on each side of the fourth base flap (17) at a transition between the base panel portion and the locking tab portion.

Classes IPC  ?

• B65D 5/10 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps avec les fermetures d'extrémité formées par pliage interne de pattes s'emboîtant l'une dans l'autre et articulées au corps tubulaire
• B65D 5/02 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps
• B65D 5/44 - Parties insérées dans le réceptacle, qui en font partie intégrante ou qui lui sont fixées pour former des garnitures intérieures ou extérieures

Abrégé

A dispenser for a product in stick form comprises a base part (4) and a removable cap (6). The base part (6) comprises an outer tube (14) optionally made from a paper-based or card-based material such as paperboard or cardboard and an inner tube (16) rotatably and slidably received within the outer tube (14) and optionally made from a paper-based or card-based material such as paperboard or cardboard. The inner tube (16) projects upwardly from the outer tube (14) and has an axially extending helical slot (24) formed therein. The base part further comprises a product stick carrier (48) optionally formed of a paper-based or card-based material and supporting a product stick (50). The product stick carrier (48) is rotationally fixed relative to the outer tube (14), is arranged radially inwardly of the inner tube (16) and projects upwardly from the outer tube (14). The base part (6) further comprises a helical element (38) optionally made from a paper-based or card-based material such as paperboard or cardboard. The helical element (38) is rotationally fixed with respect to the outer tube (14) and is received in the helical slot (26) such that rotation of the inner tube (16) relative to the outer tube (14) will move the helical slot (24) along the helical element (38) thereby lowering or raising the inner tube (16) within the outer tube (14) to expose or cover the product stick (50).

Classes IPC  ?

• A45D 40/06 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de vissage

Abrégé

A single piece container made of cardboard, paperboard or other flexible sheet material which provides improved strength properties, but without the need to laminate layers of sheet material together by having an outer shell comprising sidewall panels (3, 5, 7, 9) and a set of inner sidewall panels (11, 13, 15, 17) connected to the outer shell at foldlines. The set of inner sidewall panels includes a first inner sidewall panel in facing relationship with the inner surface of a first outer shell sidewall panel and integrally connected to one of the outer shell sidewall panels along a foldline, and a first set of further inner sidewall panels integrally connected to the first inner sidewall panel along a foldline, the sidewall panels of the set of further inner sidewall panels being hingedly connected to one another about respective foldlines. The set of inner sidewall panels also includes a second set of further inner sidewall panels integrally connected to the first inner sidewall panel along a foldline, the sidewall panels of the second set of further inner sidewall panels being hingedly connected to one another about respective foldlines.

Classes IPC  ?

• B65D 5/02 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps
• B65D 5/10 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps avec les fermetures d'extrémité formées par pliage interne de pattes s'emboîtant l'une dans l'autre et articulées au corps tubulaire
• B65D 5/44 - Parties insérées dans le réceptacle, qui en font partie intégrante ou qui lui sont fixées pour former des garnitures intérieures ou extérieures
• B65D 5/50 - Éléments internes de support ou de protection du contenu

Abrégé

A single piece container (200) made from cardboard, paperboard or other lightweight foldable sheet material is provided. The container (200) includes an outer shell and an inner shell. The outer shell has first and second ends (202, 204), and includes a plurality of outer shell sidewall panels (3, 5, 7, 9) hingedly connected to one other about respective outer shell sidewall foldlines. The outer shell sidewall panels (3, 5, 7, 9) extend between the first and second ends (202, 204) of the outer shell. At least the second end of the outer shell is a closed end. The inner shell includes a plurality of inner shell sidewall panels hingedly connected to one other about respective inner shell sidewall foldlines. The inner shell is integrally connected to the outer shell along a foldline. Each one of the inner shell sidewall panels is in face-to-face contact with the inner surface of a respective one of the outer shell sidewall panels (3, 5, 7, 9).

Classes IPC  ?

• B65D 5/02 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps
• B65D 5/10 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps avec les fermetures d'extrémité formées par pliage interne de pattes s'emboîtant l'une dans l'autre et articulées au corps tubulaire
• B65D 5/42 - Détails des réceptacles ou des flans de réceptacles pliables ou dressables
• B65D 5/44 - Parties insérées dans le réceptacle, qui en font partie intégrante ou qui lui sont fixées pour former des garnitures intérieures ou extérieures
• B65D 5/50 - Éléments internes de support ou de protection du contenu

Abrégé

A container (100) includes a plurality of wall panels (110) that define an internal volume (138). The plurality of wall panels (110) include a front wall panel (112) that defines an opening (120). The container (100) further includes a lid (116) connected to one of the plurality of wall panels (110). The lid (116) includes a cover panel (118) and a front flap panel (114). The front flap panel (114) is defined by a flap fold line (142) and has a first surface (114a) and an opposing second surface (114b). The container (100) further includes a closure apparatus (130) affixed to the second surface (114b) of the front flap panel (114). The closure apparatus (130) is sized and shaped to be closely received with the opening(120) in the front wall panel (112). The closure apparatus (120) includes a cellulosic material.

Classes IPC  ?

• B65D 5/02 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps
• B65D 65/12 - Enveloppes ou emballages souples rectangulaires avec lignes plissées pour faciliter le pliage
• B65D 65/46 - Emploi de matériaux désintégrables, solubles ou comestibles

Abrégé

A container (100) includes a plurality of wall panels (110) that define an internal volume (138). The plurality of wall panels (110) include a front wall panel (112) that defines an opening (120). The container (100) further includes a lid (116) connected to one of the plurality of wall panels (110). The lid (116) includes a cover panel (118) and a front flap panel (114). The front flap panel (114) is defined by a flap fold line (142) and has a first surface (114a) and an opposing second surface (114b). The container (100) further includes a closure apparatus (130) affixed to the second surface (114b) of the front flap panel (114). The closure apparatus (130) is sized and shaped to be closely received with the opening(120) in the front wall panel (112). The closure apparatus (120) includes a cellulosic material.

Classes IPC  ?

• B65D 5/02 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps
• B65D 65/12 - Enveloppes ou emballages souples rectangulaires avec lignes plissées pour faciliter le pliage
• B65D 65/46 - Emploi de matériaux désintégrables, solubles ou comestibles

Abrégé

A lipstick dispenser (2) comprises a paperboard or cardboard tubular body (4). The tubular body (2) including abase part (6) and a removable cap (8) for 5 closing an open end of the base part (6). The base part (6) comprises at least one slot (20) extending along and through the side wall (22) of the base part (6). A lipstick carrier (30) is slidably received in the base part (6) and has a lug (32) projecting through the slot (20) in the side wall (22) of the base part (6) for manipulation by a user. The lipstick carrier (30) is formed of paperboard or 10 cardboard and supports a lipstick 34 for reciprocating movement within the base part (6).

Classes IPC  ?

• A45D 40/02 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement
• A45D 40/12 - Emboîtages avec dispositions pour prévenir un mouvement involontaire du bâton

Abrégé

A method of manufacturing a dispenser for a product in stick form (50). The dispenser includes an inner tube (12) and a product concealing tube (16) disposed outwardly of the inner tube (12). The product concealing tube (16) is retractable and extendable relative to the inner tube (12) for exposing and covering a product stick (50) extending from a distal end of the inner tube (12) in use. The method includes: providing a first blank of sheet material for providing the inner tube (12) of the dispenser; wrapping the first blank around a mandrel to provide the inner tube (12) of the dispenser; and providing a second blank of sheet material for providing the product concealing tube (16) of the dispenser. The second blank comprises a slot, and a guide element (38) disposed within the slot. The method also includes: applying a bonding agent to the second blank in a region corresponding to a surface of the guide element (38); and wrapping the second blank around the inner tube (12) while the inner tube (12) is held on a mandrel to provide the product concealing tube (16), with the surface of the guide element (38) to which bonding agent has been applied facing the inner tube (12), such that the guide element (38) becomes bonded to an exterior surface of the inner tube (12). The slot provides a recess (24) in the interior surface of the formed product concealing tube (16). In use, the product concealing tube (16) is movable relative to the inner tube (12) with the guide element (38) cooperating with the recess (24) for guiding the movement of the product concealing tube (16) relative to the inner tube (12). There is also provided a dispenser for a product in stick form (50).

Classes IPC  ?

• B31B 50/28 - Pliage des feuilles, des flans ou des bandes autour de mandrins, p. ex. pour les opérations de fabrication du fond
• A45D 40/04 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement obtenu par une vis
• A45D 40/16 - Bâtons de rechangesDispositifs de moulage pour obtenir des bâtons
• B31B 50/62 - Assemblage des surfaces ou des bords opposésCollage par des adhésifs
• B31B 100/00 - Réceptacles rigides ou semi-rigides fabriqués par pliage de feuilles, de flans ou de bandes d’une seule pièce

Abrégé

There is provided herein a dispenser (2) for a product in stick form. The dispenser (2) includes a product stick carrier (10), an outer sleeve (6) and a product concealing sleeve (8). The product stick carrier (10) includes a product stick support for supporting a product stick in use. The outer sleeve (6) is disposed outwardly of the product stick carrier (10). The product stick carrier (10) is fixed relative to the outer sleeve (6). The product concealing sleeve (8) is disposed inwardly of the outer sleeve (6) and is retractable from a first, fully extended position relative to the outer sleeve (6) for concealing a product stick supported by the product stick support in use in order to expose the product stick. The product concealing sleeve (8) and the outer sleeve (6) include inter-engaging flaps (110A-D) which cooperate with one another to prevent advancement of the product concealing sleeve (8) relative to the outer sleeve (6) beyond a set point so as to define the first, fully extended position. The outer sleeve (6), product concealing sleeve (8) and product stick carrier (10) are each formed of a paper-based or card-based material.

Classes IPC  ?

• A45D 40/00 - Emboîtages ou accessoires spécialement conçus pour la conservation ou l'emploi de produits de toilette ou cosmétiques solides ou pâteux, p. ex. de savons à barbe ou de rouges à lèvres
• A45D 40/02 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement

Abrégé

A dispenser for a product in stick form includes a product stick carrier (210), an outer sleeve (206) and a product concealing sleeve (208). The product stick carrier (210) includes a product stick support (225). The outer sleeve (206) is a cylindrical tube disposed radially outwardly of the product stick carrier (210). The product stick carrier (210) is fixed relative to the outer sleeve (206). The product concealing sleeve (208) is a cylindrical tube disposed radially inwardly of the outer sleeve (206) and is retractable from a first, fully extended position relative to the outer sleeve (206) and product stick carrier (210) for concealing a product stick (204) supported by the product stick support (225) in use in order to expose the product stick (204). The product concealing sleeve (208) is disposed radially outwardly of the product stick carrier (210) between the product stick carrier (210) and the outer sleeve (206). Inter-engaging formations are associated with either the product concealing sleeve (208) and the outer sleeve (206) or the product stick carrier (210) and product concealing sleeve (208). The inter-engaging formations cooperate with one another to prevent advancement of the product concealing sleeve (208) relative to the outer sleeve (206) and product stick carrier (210) beyond a set point so as to define the first, fully extended position. The outer sleeve (206), product concealing sleeve (208) and product stick carrier (210) are each formed of a paper-based or card-based material.

Classes IPC  ?

• A45D 40/00 - Emboîtages ou accessoires spécialement conçus pour la conservation ou l'emploi de produits de toilette ou cosmétiques solides ou pâteux, p. ex. de savons à barbe ou de rouges à lèvres
• A45D 40/02 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement
• A45D 40/04 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement obtenu par une vis
• A45D 40/06 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de vissage

Abrégé

A tray made of cardboard, paperboard or other lightweight foldable sheet material that comprises one or more pockets (8) for receiving product. The tray comprises a top sheet defining one or more top sheet openings for the one or more pockets and a bottom sheet attached to the top sheet that comprises one or more bottom sheet openings that are aligned with the top sheet openings.

Classes IPC  ?

• B65D 5/50 - Éléments internes de support ou de protection du contenu
• B31B 50/62 - Assemblage des surfaces ou des bords opposésCollage par des adhésifs
• B31B 50/59 - Mise en forme sous pression de matériaux en feuilles
• B31B 110/35 - Forme des réceptacles rigides ou semi-rigides à section transversale polygonale rectangulaire, p. ex. carrée
• B31B 120/20 - Structure des réceptacles rigides ou semi-rigides pourvus d’au moins deux compartiments

Abrégé

A dispenser for a product in stick form comprises a base part (4) and a removable cap (6). The base part (6) comprises an outer tube (14) optionally made from a paper-based or card-based material such as paperboard or cardboard and an inner tube (16) rotatably and slidably received within the outer tube (14) and optionally made from a paper-based or card-based material such as paperboard or cardboard. The inner tube (16) projects upwardly from the outer tube (14) and has an axially extending helical slot (24) formed therein. The base part further comprises a product stick carrier (48) optionally formed of a paper-based or card-based material and supporting a product stick (50). The product stick carrier (48) is rotationally fixed relative to the outer tube (14), is arranged radially inwardly of the inner tube (16) and projects upwardly from the outer tube (14). The base part (6) further comprises a helical element (38) optionally made from a paper-based or card-based material such as paperboard or cardboard. The helical element (38) is rotationally fixed with respect to the outer tube (14) and is received in the helical slot (26) such that rotation of the inner tube (16) relative to the outer tube (14) will move the helical slot (24) along the helical element (38) thereby lowering or raising the inner tube (16) within the outer tube (14) to expose or cover the product stick (50).

Classes IPC  ?

• A45D 40/00 - Emboîtages ou accessoires spécialement conçus pour la conservation ou l'emploi de produits de toilette ou cosmétiques solides ou pâteux, p. ex. de savons à barbe ou de rouges à lèvres

Abrégé

A dispenser (2) for a product in stick form comprises: a tubular body (4) having a longitudinal axis (A), the tubular body (4) including a tubular base part (6) and a removable cap (8) for closing an open end of the tubular base part (6). The tubular base part (6) comprises an outer tube (20) made from a paper-based or card-based material such as paperboard or cardboard and having an axially extending helical slot (30) formed in a radially inner surface (36) thereof, an inner tube (22) received within the outer tube (20) and made from a paper-based or card-based material such as paperboard or cardboard and having an axially extending slot (40) formed therethrough and a base (24) made from a paper-based or card-based material such as paperboard or cardboard which is rotatable about the longitudinal axis (A) relative to the outer tube (20) and to which the inner tube (22) is fixed so as to be rotatable therewith relative to the outer tube. A product stick carrier (50) is slidably received in the inner tube (22) and has a lug (54) projecting through the axially extending slot (20) of the inner tube (22) to engage with the axially extending helical slot (30) of the outer tube (20), whereby rotation of the base (24) relative to the outer tube (20) cams the lug (54) along the axially extending helical slot (30) so as to move the product stick carrier (50) along the inner tube (22) so as to extend the product stick (52) from the outer tube (20).

Classes IPC  ?

• A45D 40/06 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de vissage

Abrégé

A single piece container made of cardboard, paperboard or other flexible sheet material which provides improved strength properties, but without the need to laminate layers of sheet material together by having an outer shell comprising sidewall panels (3, 5, 7, 9) and a set of inner sidewall panels (11, 13, 15, 17) connected to the outer shell at foldlines. The set of inner sidewall panels includes a first inner sidewall panel in facing relationship with the inner surface of a first outer shell sidewall panel and integrally connected to one of the outer shell sidewall panels along a foldline, and a first set of further inner sidewall panels integrally connected to the first inner sidewall panel along a foldline, the sidewall panels of the set of further inner sidewall panels being hingedly connected to one another about respective foldlines. The set of inner sidewall panels also includes a second set of further inner sidewall panels integrally connected to the first inner sidewall panel along a foldline, the sidewall panels of the second set of further inner sidewall panels being hingedly connected to one another about respective foldlines.

Classes IPC  ?

• B65D 5/50 - Éléments internes de support ou de protection du contenu
• B65D 5/02 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps
• B65D 5/10 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps avec les fermetures d'extrémité formées par pliage interne de pattes s'emboîtant l'une dans l'autre et articulées au corps tubulaire
• B65D 81/05 - Réceptacles, éléments d'emballage ou paquets pour contenus présentant des problèmes particuliers de stockage ou de transport ou adaptés pour servir à d'autres fins que l'emballage après avoir été vidés de leur contenu spécialement adaptés pour protéger leur contenu des dommages mécaniques maintenant le contenu en position éloignée des parois de l'emballage ou des autres pièces du contenu

Abrégé

Herein is provided a container including a plurality of sidewalls (3, 7, 9) connected to one another along foldlines, and a base. The base includes first, second, third and fourth base flaps (11, 13, 15, 17) connected along respective foldlines to respective sidewalls. The second and third base flaps (13, 15) are folded over the first base flap (11) and the fourth base flap (17) is folded over the second and third base flaps (13, 15). The fourth base flap (17) includes a base panel portion which forms part of the exterior of the base and a locking tab portion connected to a distal end of the base panel portion. The locking tab portion is inserted into the interior of the container through a slot defined by the first, second and third base flaps (11, 13, 15) to retain the base in a closed configuration. A cutline is provided extending inwardly from the side edge of the fourth base flap (17) on each side of the fourth base flap (17) at a transition between the base panel portion and the locking tab portion.

Classes IPC  ?

• B65D 5/10 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps avec les fermetures d'extrémité formées par pliage interne de pattes s'emboîtant l'une dans l'autre et articulées au corps tubulaire
• B65D 5/02 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps

Abrégé

A single piece container (200) made from cardboard, paperboard or other lightweight foldable sheet material is provided. The container (200) includes an outer shell and an inner shell. The outer shell has first and second ends (202, 204), and includes a plurality of outer shell sidewall panels (3, 5, 7, 9) hingedly connected to one other about respective outer shell sidewall foldlines. The outer shell sidewall panels (3, 5, 7, 9) extend between the first and second ends (202, 204) of the outer shell. At least the second end of the outer shell is a closed end. The inner shell includes a plurality of inner shell sidewall panels hingedly connected to one other about respective inner shell sidewall foldlines. The inner shell is integrally connected to the outer shell along a foldline. Each one of the inner shell sidewall panels is in face-to-face contact with the inner surface of a respective one of the outer shell sidewall panels (3, 5, 7, 9).

Classes IPC  ?

• B65D 5/02 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps
• B65D 5/10 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps avec les fermetures d'extrémité formées par pliage interne de pattes s'emboîtant l'une dans l'autre et articulées au corps tubulaire
• B65D 5/50 - Éléments internes de support ou de protection du contenu

Abrégé

A lipstick dispenser (2) comprises a paperboard or cardboard tubular body (4). The tubular body (2) including a base part (6) and a removable cap (8) for 5 closing an open end of the base part (6). The base part (6) comprises at least one slot (20) extending along and through the side wall (22) of the base part (6). A lipstick carrier (30) is slidably received in the base part (6) and has a lug (32) projecting through the slot (20) in the side wall (22) of the base part (6) for manipulation by a user. The lipstick carrier (30) is formed of paperboard or 10 cardboard and supports a lipstick 34 for reciprocating movement within the base part (6).

Classes IPC  ?

• A45D 40/02 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de glissement
• A45D 40/06 - Emboîtages où le mouvement du bâton de rouge ou d'un solide similaire est un mouvement de vissage

Abrégé

A single piece container is provided that is made from cardboard, paperboard or other lightweight foldable sheet material. The container includes an outer shell, an inner shell and at least one spacer tab. The outer shell has a first end and a second end, and includes a plurality of side wall panels hingedly connected to one other about respective outer shell sidewall foldlines and extending between the first end and the second end of the outer shell. The second end of the outer shell is a closed end. The inner shell includes a first end, an opposite second end, and a plurality of side walls hingedly connected to one another about respective inner shell sidewall foldlines and extending between the first end and the second end of the inner shell. The inner shell is integrally connected to the outer shell along a foldline. The at least one spacer tab connects the inner shell and the outer shell, the spacer tab being released from a respective side wall panel of the inner shell. A single piece blank for said container is also provided.

Classes IPC  ?

• B65D 5/50 - Éléments internes de support ou de protection du contenu
• B65D 81/05 - Réceptacles, éléments d'emballage ou paquets pour contenus présentant des problèmes particuliers de stockage ou de transport ou adaptés pour servir à d'autres fins que l'emballage après avoir été vidés de leur contenu spécialement adaptés pour protéger leur contenu des dommages mécaniques maintenant le contenu en position éloignée des parois de l'emballage ou des autres pièces du contenu
• B65D 5/06 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps avec les éléments de fermeture d'extrémité ou de support du contenant formés en pliant vers l'intérieur une paroi dépassante et tournant continuellement autour d'une extrémité du corps tubulaire
• B65D 5/02 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps

Abrégé

A carrier (2) made of cardboard, paperboard or other lightweight foldable sheet material, comprises a top sheet (4) defining one or more pockets (20) for receiving one or more products and a bottom sheet (6) attached to the top sheet (4). The top sheet (4) comprises one or more respective sets (30) of flaps (32) for forming the respective pockets (20), each flap (32) being hingedly connected at a proximal end (36) to a top surface (38) of the top sheet (4) about a respective flap hinge line (40) defined around an upper edge (42) of the respective pocket (20) and folded about the respective flap hinge line (40) to define a pocket side wall. The top sheet (4) further comprises respective tabs (50) hingedly connected to distal ends (46) of the respective flaps (32) about respective tab fold lines (52) and folded about a respective tab fold line (52) so as to lie along a base of the pocket (20). The bottom sheet (6) is bonded to the respective tabs (50) in a face to face relationship to close at least a portion the base of the pocket (20).

Classes IPC  ?

• B65D 75/36 - Objets ou matériaux enveloppés entre deux feuilles ou flans opposés à bords réunis, p. ex. par adhésifs à pression, pliage, thermosoudage ou soudage une ou les deux feuilles ou flans étant renfoncés pour épouser la forme du contenu une feuille ou un flan étant renfoncés et l'autre fait d'une feuille plate relativement rigide, p. ex. empaquetage pour ampoules
• B65B 5/02 - Machines caractérisées par l'incorporation de moyens pour fabriquer les réceptacles ou les récipients
• B65B 43/10 - Formation de réceptacles à trois dimensions à partir de feuilles en les pliant
• B65D 75/52 - Paquets comportant des objets ou matériaux partiellement ou complètement enfermés dans des bandelettes, des feuilles, des flans, des tubes ou des bandes en matériau souple mince, p. ex. dans des enveloppes pliées Détails

Abrégé

A tamper evident container (2) made from cardboard, paperboard or other lightweight foldable sheet material comprises a container body (6) comprising a first pair of opposed side wall panels (8, 10) and a second pair of side wall panels (12, 14), the side wall panels (8, 10, 12, 14) being hingedly attached to each other about respective side wall fold lines (16). A lid (22) is hingedly attached to one side wall panel (8) of the first pair of opposed side wall panels (8, 10) about a lid fold line (26). First and second closure flaps (28, 30), are hingedly attached to a respective one of the second pair of opposed wall panels (12, 14) about respective closure flap fold lines (32, 34) so as to define respective locking slots (36, 38) between a side edge of the respective closure flaps (28, 30) and the other side wall panel (10) of the first pair of side wall panels (8, 10). The lid (22) comprises a lid panel (50) hingedly attached at a proximal edge (52) to the one side wall panel (8) of the first pair of side wall panels (8, 10) about the lid fold line (26). It further comprises a locking flap (56) comprising a first locking flap panel (58) hingedly attached at a proximal edge (60) to a distal edge (62) of the lid panel (50) about a frangible line of weakness (64) and a second locking flap panel (66) hingedly attached at a proximal edge (68) to a distal edge (70) of the first locking flap panel (58) about a locking flap fold line (72). It is folded about the locking flap fold line (72) so as to lie behind and in a face to face relationship with the first locking flap panel (58). A distal end (74) of the second locking flap panel (66) comprises at least one free edge forming a locking edge (76). The locking flap (56) is insertable into the locking slots (36, 38) such that the at least one locking edge (76) of the second locking flap panel (66) engages behind the side edges of the closure flaps (36, 38) so as to lock the lid (22) in position.

Classes IPC  ?

• B65D 5/10 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps avec les fermetures d'extrémité formées par pliage interne de pattes s'emboîtant l'une dans l'autre et articulées au corps tubulaire
• B65D 5/66 - Couvercles articulés
• B65D 5/02 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps
• B65D 5/42 - Détails des réceptacles ou des flans de réceptacles pliables ou dressables

Abrégé

A package includes an outer sleeve and a slider for holding a blister pack slidably mounted within the outer sleeve. The outer sleeve has a locking edge. The slider has a locking flap extending in a direction away from the closed end of the outer sleeve for engagement with the wall of the outer sleeve. The flap has a free edge which provides a pair of locking edges for engagement with the locking edge of the outer sleeve wall. The outer sleeve has a release button which may be pressed to deflect the slider flap away from the wall of the outer sleeve and enable the free edge of the slider flap to slide past the locking edge to allow the slider to be withdrawn from the outer sleeve.

Classes IPC  ?

• B65D 75/36 - Objets ou matériaux enveloppés entre deux feuilles ou flans opposés à bords réunis, p. ex. par adhésifs à pression, pliage, thermosoudage ou soudage une ou les deux feuilles ou flans étant renfoncés pour épouser la forme du contenu une feuille ou un flan étant renfoncés et l'autre fait d'une feuille plate relativement rigide, p. ex. empaquetage pour ampoules
• B65D 5/38 - Réceptacles du type à tiroir-enveloppe
• B65D 83/04 - Réceptacles ou paquets comportant des moyens particuliers pour distribuer leur contenu pour distribuer de petits objets en forme d'anneau, de disque, de sphère ou similaire, p. ex. des comprimés ou des pilules
• A61J 1/03 - Récipients spécialement adaptés à des fins médicales ou pharmaceutiques pour pilules ou comprimés

Abrégé

A carton (1) having a first end and a second end; a plurality of side panels (9, 11); and a sloping face at the first end of the carton. The sloping face is defined by a first triangular lid panel (3) at the first carton end. A first edge of the first triangular lid panel (3) is connected along a foldline (15) to the end of a first one of the side panels at the first carton end. The carton includes a second triangular lid panel (5) at the first end of the carton providing an end face for the carton at the first carton end. A first edge of the second triangular lid panel (5) is connected to a second edge of the first triangular lid panel (3) along a foldline (17). The carton includes a plurality of lid support panels underlying the first and second triangular lid panels (3,5) at the first carton end.

Classes IPC  ?

• B65D 5/02 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps
• B65D 5/06 - Réceptacles de section transversale polygonale rigides ou semi-rigides, p. ex. boîtes, cartons ou plateaux, formés en pliant ou montant un ou plusieurs flans de papier en pliant ou montant un seul flan pour former un corps tubulaire avec ou sans pliage subséquent, ou par addition d'éléments séparés, pour fermer les extrémités du corps avec les éléments de fermeture d'extrémité ou de support du contenant formés en pliant vers l'intérieur une paroi dépassante et tournant continuellement autour d'une extrémité du corps tubulaire

Abrégé

A package includes a container having an open end and a closed end and a slider slidably mounted within the container. A releasable locking feature is provided at a side of the package, which comprises locking edges associated with a sidewall of each of the slider and container respectively, and a release area for releasing a locking abutment between the locking edges. The sidewall of the container having the locking edge associated therewith is defined by a panel having a first transverse cutline defining a top flap between the cutline and the open end of the container, with the top flap being connected to a first facing panel of the container along a foldline. An inner surface of the top flap 16 is adhered to an exterior surface of a first glue flap 10, the first glue flap being connected to an opposite facing panel of the container along a foldline. The first glue flap provides the locking edge of the container.

Classes IPC  ?

• B65D 25/02 - Garnitures internes
• B65D 77/04 - Objets ou matériaux enfermés dans plusieurs réceptacles disposés les uns dans les autres
• A61J 1/03 - Récipients spécialement adaptés à des fins médicales ou pharmaceutiques pour pilules ou comprimés
• B65D 75/36 - Objets ou matériaux enveloppés entre deux feuilles ou flans opposés à bords réunis, p. ex. par adhésifs à pression, pliage, thermosoudage ou soudage une ou les deux feuilles ou flans étant renfoncés pour épouser la forme du contenu une feuille ou un flan étant renfoncés et l'autre fait d'une feuille plate relativement rigide, p. ex. empaquetage pour ampoules

Abrégé

A package includes a container made from a paperboard, cardboard or other foldable sheet material, and houses at least one blister pack. The blister pack is secured within an internal space of the container by means of a frangible connection, breakage of the frangible connection allowing complete removal of the blister pack from the container.

Classes IPC  ?

• B65D 83/04 - Réceptacles ou paquets comportant des moyens particuliers pour distribuer leur contenu pour distribuer de petits objets en forme d'anneau, de disque, de sphère ou similaire, p. ex. des comprimés ou des pilules
• A61J 1/03 - Récipients spécialement adaptés à des fins médicales ou pharmaceutiques pour pilules ou comprimés
• B65D 5/38 - Réceptacles du type à tiroir-enveloppe
• A61J 1/16 - Supports pour récipients

Abrégé

A package includes a container having an open end and a closed end, and a slider slidably mounted within the container. A releasable locking feature is provided at a side of the package, which comprises a pair of locking edges, one associated with a sidewall of each of the slider and container respectively, and a release area for releasing a locking abutment between the locking edges. The release area is provided in the sidewall of the container having the locking edge, and the locking edge of the slider comprises two or more plies of a material used to provide the slider. The package includes means for biasing the locking edge of the slider into engagement with the locking edge of the container. The biasing means extends from a blister pack carrier connected to the slider.

Classes IPC  ?

• B65D 75/36 - Objets ou matériaux enveloppés entre deux feuilles ou flans opposés à bords réunis, p. ex. par adhésifs à pression, pliage, thermosoudage ou soudage une ou les deux feuilles ou flans étant renfoncés pour épouser la forme du contenu une feuille ou un flan étant renfoncés et l'autre fait d'une feuille plate relativement rigide, p. ex. empaquetage pour ampoules
• A61J 1/03 - Récipients spécialement adaptés à des fins médicales ou pharmaceutiques pour pilules ou comprimés
• B65D 75/32 - Objets ou matériaux enveloppés entre deux feuilles ou flans opposés à bords réunis, p. ex. par adhésifs à pression, pliage, thermosoudage ou soudage une ou les deux feuilles ou flans étant renfoncés pour épouser la forme du contenu
• B65D 5/38 - Réceptacles du type à tiroir-enveloppe
• B65D 83/04 - Réceptacles ou paquets comportant des moyens particuliers pour distribuer leur contenu pour distribuer de petits objets en forme d'anneau, de disque, de sphère ou similaire, p. ex. des comprimés ou des pilules
• B65D 77/04 - Objets ou matériaux enfermés dans plusieurs réceptacles disposés les uns dans les autres
• B65D 77/30 - Dispositifs d'ouverture servant à retirer le contenu, ajoutés ou incorporés durant le remplissage ou la fermeture des réceptacles

Abrégé

A package includes a container having an open end and a closed end, and a slider slidably mounted within the container. A releasable locking feature is provided at a side of the package, which comprises a pair of locking edges, one associated with a sidewall of each of the slider and container respectively, and a release area for releasing a locking abutment between the locking edges. The release area is provided in the sidewall of the container having the locking edge, and the locking edge of the slider comprises two or more plies of a material used to provide the slider.

Classes IPC  ?

• B65D 75/36 - Objets ou matériaux enveloppés entre deux feuilles ou flans opposés à bords réunis, p. ex. par adhésifs à pression, pliage, thermosoudage ou soudage une ou les deux feuilles ou flans étant renfoncés pour épouser la forme du contenu une feuille ou un flan étant renfoncés et l'autre fait d'une feuille plate relativement rigide, p. ex. empaquetage pour ampoules
• A61J 1/03 - Récipients spécialement adaptés à des fins médicales ou pharmaceutiques pour pilules ou comprimés
• B65D 75/32 - Objets ou matériaux enveloppés entre deux feuilles ou flans opposés à bords réunis, p. ex. par adhésifs à pression, pliage, thermosoudage ou soudage une ou les deux feuilles ou flans étant renfoncés pour épouser la forme du contenu
• B65D 5/38 - Réceptacles du type à tiroir-enveloppe
• B65D 83/04 - Réceptacles ou paquets comportant des moyens particuliers pour distribuer leur contenu pour distribuer de petits objets en forme d'anneau, de disque, de sphère ou similaire, p. ex. des comprimés ou des pilules
• B65D 77/04 - Objets ou matériaux enfermés dans plusieurs réceptacles disposés les uns dans les autres
• B65D 77/30 - Dispositifs d'ouverture servant à retirer le contenu, ajoutés ou incorporés durant le remplissage ou la fermeture des réceptacles

Abrégé

A carrier for a blister pack includes a first panel having an opening for movably receiving a blister of the blister pack, and a second panel having one or more dispensing openings aligned with the first panel opening. The first panel and the second panel slidably receive the blister pack there between. The carrier includes a blocking tab between the first and second panels that is selectively moveable between a blocking position and a dispensing position. When the blocking tab is in its blocking position it prevents movement of the blister in the first panel opening into alignment with a dispensing opening, thereby preventing dispensing of the blister's contents through the dispensing opening. When the blocking tab is in the dispensing position, it permits the blister to be moved into alignment with a dispensing opening for dispensing the blister's contents. The blocking tab is connected to a free edge of one of the first and second panels about a fold line, and one of the first and second panels of the blister pack carrier is connected to a panel of a slider.

Classes IPC  ?

• A61J 1/03 - Récipients spécialement adaptés à des fins médicales ou pharmaceutiques pour pilules ou comprimés
• B65D 5/38 - Réceptacles du type à tiroir-enveloppe
• B65D 83/04 - Réceptacles ou paquets comportant des moyens particuliers pour distribuer leur contenu pour distribuer de petits objets en forme d'anneau, de disque, de sphère ou similaire, p. ex. des comprimés ou des pilules
• B65D 75/36 - Objets ou matériaux enveloppés entre deux feuilles ou flans opposés à bords réunis, p. ex. par adhésifs à pression, pliage, thermosoudage ou soudage une ou les deux feuilles ou flans étant renfoncés pour épouser la forme du contenu une feuille ou un flan étant renfoncés et l'autre fait d'une feuille plate relativement rigide, p. ex. empaquetage pour ampoules

Produits et services

Transmission and distribution of artwork and designs. Packaging design services; creation, amendment, electronic storage of artwork and designs; artwork and design proofing services (terms considered too vague by the International Bureau - rule 13.2.b) of the Common Regulations); information, advice and consultancy relating to artwork and designs (terms considered too vague by the International Bureau - rule 13.2.b) of the Common Regulations).

Abrégé

A method of selecting optimal inks from a plurality of ink candidates for a given color is provided, said method including a) obtaining a measure of spectral reflectance of a print substrate; b) obtaining a measure of the spectral reflectance of a first candidate ink of a first color; c) predicting a color gamut for the first candidate ink based on the spectral reflectance of the ink and the spectral reflectance of the substrate; d) repeating steps b) and c) for a second ink candidate of the first color; e) selecting the ink candidate for which the predicted color gamut includes the most target spot colors as the optimal ink for the first color.

Classes IPC  ?

• G06K 15/02 - Dispositions pour produire une présentation visuelle permanente des données de sortie utilisant des imprimantes
• G06K 15/00 - Dispositions pour produire une présentation visuelle permanente des données de sortie
• G01J 3/46 - Mesure de couleurDispositifs de mesure de couleur, p. ex. colorimètres
• H04N 1/54 - Conversion des signaux d'image en couleurs en un ensemble de signaux dont quelques-uns représentent des couleurs composées particulières, p. ex. pour l'impression de textiles

Produits et services

Computer aided transmission of images, namely, artwork and designs; art brokerage of artwork and design Packaging design services; electronic storage of electronic media, namely, artwork and designs; artwork and design proofing services; information, advice and consultancy relating to artwork and designs; commercial art design; computer aided graphic design

Produits et services

(1) Packaging design services; creation, amendment, storage and computer-aided transmission of artwork and designs; proofing services for the authentication, verification and inspection of artwork and designs; information, advice and consultancy relating to artwork and designs

Abrégé

A child resistant blister pack includes a blister layer which includes one or more blister cavities for receiving a product. A frangible retaining layer is attached to the blister layer over the blister cavities to retain the product within the blister cavities. A first backing layer is attached to the retaining layer on a side opposite the blister layer. The first backing layer has one or more lines of weakness aligned with the blister cavities. A second backing layer is attached to the first backing layer on a side opposite the retaining layer. The second backing layer has a plurality of removable sections. At least two removable sections are arranged over each line of weakness in the underlying first backing layer.

Classes IPC  ?

• A61J 1/03 - Récipients spécialement adaptés à des fins médicales ou pharmaceutiques pour pilules ou comprimés
• B65D 25/20 - Accessoires externes
• G09F 3/00 - Étiquettes, fiches ou moyens analogues d'identification ou d'indicationSceauxTimbres-poste ou timbres analogues
• B65D 65/38 - Matériaux d'emballage de type ou forme particulière
• B65D 75/52 - Paquets comportant des objets ou matériaux partiellement ou complètement enfermés dans des bandelettes, des feuilles, des flans, des tubes ou des bandes en matériau souple mince, p. ex. dans des enveloppes pliées Détails
• B65D 17/00 - Réceptacles rigides ou semi-rigides spécialement conçus pour être ouverts par coupage ou perçage, ou en perçant ou en déchirant des éléments ou des parties frangibles
• B65D 65/14 - Enveloppes ou emballages souples comportant des zones enduites d'adhésif
• B65D 75/32 - Objets ou matériaux enveloppés entre deux feuilles ou flans opposés à bords réunis, p. ex. par adhésifs à pression, pliage, thermosoudage ou soudage une ou les deux feuilles ou flans étant renfoncés pour épouser la forme du contenu
• B65D 75/36 - Objets ou matériaux enveloppés entre deux feuilles ou flans opposés à bords réunis, p. ex. par adhésifs à pression, pliage, thermosoudage ou soudage une ou les deux feuilles ou flans étant renfoncés pour épouser la forme du contenu une feuille ou un flan étant renfoncés et l'autre fait d'une feuille plate relativement rigide, p. ex. empaquetage pour ampoules
• G09F 3/02 - Formes ou structures

Abrégé

A temperature monitor, a temperature monitoring system, and method are provided. The temperature monitor includes an electronic paper display and a passive temperature sensor. The electronic paper display has first and second display states. The passive temperature sensor is coupled to the display such that when the temperature of the sensor attains a predetermined value, the display changes from the first display state to the second display state.

Classes IPC  ?

• G01K 1/02 - Moyens d’indication ou d’enregistrement spécialement adaptés aux thermomètres
• G01K 3/00 - Thermomètres donnant une indication autre que la valeur instantanée de la température
• G09G 3/34 - Dispositions ou circuits de commande présentant un intérêt uniquement pour l'affichage utilisant des moyens de visualisation autres que les tubes à rayons cathodiques pour la présentation d'un ensemble de plusieurs caractères, p. ex. d'une page, en composant l'ensemble par combinaison d'éléments individuels disposés en matrice en commandant la lumière provenant d'une source indépendante
• G02F 1/167 - Dispositifs ou dispositions pour la commande de l'intensité, de la couleur, de la phase, de la polarisation ou de la direction de la lumière arrivant d'une source lumineuse indépendante, p. ex. commutation, ouverture de porte ou modulationOptique non linéaire pour la commande de l'intensité, de la phase, de la polarisation ou de la couleur basés sur le mouvement de translation des particules dans un fluide sous l’influence de l’application d’un champ caractérisés par l’effet électro-optique ou magnéto-optique par électrophorèse

Abrégé

The present invention relates to improved processes for applying barrier coatings for paper substrates, and to paper substrates made by such processes. The processes of the present invention use modified gravure printing to apply coatings comprising polyvinyl alcohol and inorganic particulate material. The barrier coatings help to prevent substances from leaching through to spoil the decorative surfaces of the paper substrates, and/or mitigate the effect of any substances that may leach from the paper substrate.

Classes IPC  ?

• D21H 19/24 - Couches sans pigments appliquées sous une forme autre que la solution aqueuse définie dans le groupe comprenant des composés macromoléculaires obtenus par des réactions autres que celles faisant intervenir uniquement des liaisons non saturées carbone-carbone
• D21H 19/60 - Alcools polyalcényliquesÉthers polyalcényliquesEsters polyalcényliques
• D21H 21/14 - Matériaux non fibreux ajoutés à la pâte, caractérisés par leur fonction, leur forme ou leurs propriétésMatériaux d'imprégnation ou de revêtement du papier, caractérisés par leur fonction, leur forme ou leurs propriétés caractérisés par leur fonction ou leurs propriétés dans, ou sur, le papier
• D21H 19/38 - Couches contenant des pigments caractérisées par les pigments
• D21H 19/40 - Couches contenant des pigments caractérisées par les pigments siliceux, p. ex. argiles
• C09D 11/10 - Encres d’imprimerie à base de résines artificielles
• C09D 129/04 - Alcool polyvinyliqueHomopolymères ou copolymères partiellement hydrolysés d'esters d'alcools non saturés avec des acides carboxyliques saturés
• B32B 27/30 - Produits stratifiés composés essentiellement de résine synthétique comprenant une résine vinyliqueProduits stratifiés composés essentiellement de résine synthétique comprenant une résine acrylique
• B32B 27/18 - Produits stratifiés composés essentiellement de résine synthétique caractérisée par l'emploi d'additifs particuliers
• B32B 27/10 - Produits stratifiés composés essentiellement de résine synthétique comme seul composant ou composant principal d'une couche adjacente à une autre couche d'une substance spécifique de papier ou de carton
• B32B 29/00 - Produits stratifiés composés essentiellement de papier ou de carton

Produits et services

Containers and blanks for making containers; cartons and blanks for making cartons; boxes and blanks for making boxes; trays and blanks for making trays; wrapping and packaging materials. Containers made wholly or largely of plastics.

Produits et services

Containers made wholly or largely of cardboard or paperboard.

Produits et services

Electro-mechanical embossing apparatus; parts and fittings for the aforesaid goods.

Produits et services

Computer software. Paper, paperboard and cardboard; coated paper, paperboard and cardboard; corrugated board for making containers and cartons; articles made from any of the aforesaid goods; containers and blanks for making containers; cartons and blanks for making cartons; boxes and blanks for making boxes; trays and blanks for making trays; wrapping and packaging materials; labels made principally of paper, cardboard and/or plastics; adhesive and self-adhesive labels, not of textile. Containers made wholly or largely of plastics. Education and training in the field of computing; education and training in the field of packaging. Installation, updating and maintenance of computer software; computer system design; packaging design services.
