The invention relates to a roof tile (1, 2) for covering a surface in an overlapping manner, having a first support face (5) and a second support face (7), the first support face (5) being arranged on an upper side (6) of the roof tile (1, 2) in a region of a head-side end (3), and the second support face (7) being arranged on an underside (8) of the roof tile in a region of a foot-side end (4). At least the underside (8) of the roof tile (1, 2) has a hydrophobic impregnation (14) in the region of the second support surface (7). The invention further relates to a method for producing a roof tile (1, 2) of this kind.
E04D 1/16 - Éléments de couvertures en forme de tuiles plates ou bardeaux, c.-à-d. avec une surface extérieure plate en céramique, verre ou béton, avec ou sans armatures
E04D 13/00 - Aménagements ou dispositifs particuliers en relation avec les couvertures de toitÉvacuation de l'eau
A press die for producing a clay roof tile, including a first die half and a second die half, which can move between a pressing position, in which they define a receiving space that represents the form of the finished roof tile, and a filling position, in which they are mutually spaced and the receiving space can be filled with a plastically deformable clay material. At least one of the first and the second die half has at least one depression which represents a projecting part of the finished roof tile; a first compression element is provided at the depression, and movable between an initial position, in which it is retracted in relation to the form of the finished roof tile, and a compacting position, in which some sections of the first compression element represent the surface of the finished roof tile.
B28B 3/00 - Fabrication d'objets façonnés en utilisant des pressesPresses spécialement adaptées à ce travail
B30B 15/02 - MatricesGarnitures ou montures appropriéesMoules
B28B 3/02 - Fabrication d'objets façonnés en utilisant des pressesPresses spécialement adaptées à ce travail dans laquelle un poinçon exerce une pression sur le matériau dans une cavité de moulagePoinçons de forme particulière
The invention relates to a press die (20) for producing a roof tile (10) consisting of clay, comprising a first die half (22) and a second die-half (24), wherein the die halves (22, 24) can be moved relative to each other between a pressing position, in which the die halves (22, 24) substantially delimit a receiving space (30) that represents the form of the finished roof tile (10), the surface (34) of the first die half (22) and the surface (38) of the second die half (24) representing respective surfaces (12, 14) of the roof tile (10), and a filling position, in which the die halves (22, 24) are mutually spaced and the first and/or the second die half (22, 24) can be filled with a plastically deformable clay material (78). The first die half (22) and/or the second die half (24) has/have at least one depression (40) which represents a projecting part (18) of the finished roof tile (10), wherein a first compression element (52) is provided in and/or on the depression (40), said compression element being movable between an initial position, in which the first compression element (52) is retracted in relation to the form of the finished roof tile (10) and a compaction position, in which some sections of the first compression element (52) represent the surface (12, 14) of the roof tile (10).
B28B 3/00 - Fabrication d'objets façonnés en utilisant des pressesPresses spécialement adaptées à ce travail
B28B 3/02 - Fabrication d'objets façonnés en utilisant des pressesPresses spécialement adaptées à ce travail dans laquelle un poinçon exerce une pression sur le matériau dans une cavité de moulagePoinçons de forme particulière
4.
METHOD AND SYSTEM FOR PRODUCING A ROOF TILE, AND ROOF TILE
The invention relates to a method for producing a roof tile (100) from clay (32) comprising the following steps: providing the moist, unprocessed clay (32), drying the clay (32) down to a defined moisture content, grinding the dried clay (32) to form a clay material (168) of broken grains in a mill (20), removing an undersize, the grain size of which lies below a defined grain size band, and removing an oversize, the grain size of which lies above a defined grain size band, introducing the clay material (168) into a pressing mold (110), which represents the shape of the roof tile (100), and pressing the clay material (168) in the pressing mold (110), wherein the clay material (168) is compressed.
B28C 1/18 - Appareillages ou procédés pour obtenir ou traiter de l'argile pour traiter les substances non fluides contenant de l'argile spécialement adaptés pour l'homogénéisation, la désagrégation ou le conditionnement de l'argile non fluide ou pour la séparation d'éléments non désirés pour la désagrégation
C04B 33/20 - Préparation ou traitement des matières premières isolément ou en masses en vue du pressage sec
B28B 17/02 - Conditionnement du matériau avant façonnage
B28B 3/02 - Fabrication d'objets façonnés en utilisant des pressesPresses spécialement adaptées à ce travail dans laquelle un poinçon exerce une pression sur le matériau dans une cavité de moulagePoinçons de forme particulière
