Disclosed is an inductor (1) for heating a vehicle wheel (2), which has a plurality of windings (1a) provided to heat an inner region of a rim (2a) of the vehicle wheel (2) and at least one winding (1d) provided for heating a rim flange (2d) of the vehicle wheel (2). The windings (1a) provided for heating the inner region of the rim (2a) and the winding (1d) provided for heating the rim flange (2d) can be moved relative to one another in the direction of a longitudinal axis (x) of the inductor (1).
C21D 9/34 - Traitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour bandages de rouesTraitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour jantes
The invention relates to a method for heating a vehicle wheel (2), in particular as a preparation for a subsequent shaping method, in which at least a part of the vehicle wheel (2) is heated by means of inductive heating using an inductor (7).
C21D 1/10 - Durcissement de surface par application directe d'énergie électrique ou ondulatoireDurcissement de surface par radiation particulaire par induction électrique
The invention relates to a method for the impact treatment of transition radii (8) of a crankshaft (4), in particular transition radii (8) between connecting rod bearing journals (5) and crank webs (7) and/or transition radii (8) between main bearing journals (6) and the crank webs (7) of the crankshaft (4). In order to apply an impact force (FS) to at least one of the transition radii (8) along the respective transition radius (8) circulating about the crankshaft (4) in an annular manner, a heavily loaded region (BMAX), a lightly loaded region (BMIN), and intermediate regions (BZW) lying therebetween are defined, and an impact treatment is then carried out such that the impact force (FS) introduced into the intermediate regions (BZW) is increased in the direction of the heavily loaded region (BMAX).
The invention relates to a device for the impact treatment of transition radii (8) of a crankshaft (4), in particular transition radii (8) between connecting rod bearing journals (5) and crank webs (7) and/or transition radii (8) between main bearing journals (6) and the crank webs (7) of the crankshaft (4). The device comprises an impact device (1) in order to introduce an impact force (FS) into at least one transition radius (8), wherein the impact device (1) has multiple impact heads (21) which are paired with the same transition radius (8).
The invention relates to a method for work-hardening a crankshaft (4) comprising connecting rod journals (5), main bearing journals (6) and crank webs (7), the connecting rod journals (5) and the main bearing journals (6) being provided with oil holes (31). According to the invention, at least one end (30) of one of the oil holes (31) and/or at least one cylindrical portion (38) of the oil holes (31) is/are work-hardened.
B23P 9/04 - Traitement ou finition par martelage ou par pression répétée
C21D 7/04 - Modification des propriétés physiques du fer ou de l'acier par déformation par travail à froid de la surface
C21D 7/02 - Modification des propriétés physiques du fer ou de l'acier par déformation par travail à froid
C21D 9/30 - Traitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour arbres vilebrequinsTraitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour arbres à cames
C21D 7/06 - Modification des propriétés physiques du fer ou de l'acier par déformation par travail à froid de la surface par grenaillage ou similaire
6.
Method and device for post-processing a crankshaft
The invention relates to a method for post-processing a crankshaft (4), in particular in order to correct concentricity errors and/or for a length correction. Sectors (S1,S2,S3,S4,S5,S6) of the crankshaft (4) which produce and/or characterize concentricity errors are detected and/or a length deviation (ΔL1 ΔL2, ΔL3) from a target length (L1,L2, L3) is determined for at least one section of the crankshaft (4). An impact force (Fs) is then introduced into at least one defined transition radius (8) between connecting rod bearing journals (5) and crank webs (7) and/or between main bearing journals (6) and the crank webs (7) of the crankshaft (4) by means of at least one impact tool (16) in order to correct the concentricity errors and/or the length deviation (ΔL1 ΔL2, ΔL3).
B21D 3/16 - Redressage ou remise en forme des barres, tubes ou profilés métalliques, ou des objets déterminés faits à partir de ces matériaux, qu'ils comportent ou non des parties en tôle d'objets déterminés faits de barres, tubes ou profilés métalliques, p. ex. de vilebrequins, en utilisant des méthodes ou des moyens spécialement adaptés à ce but
B24B 39/04 - Machines ou dispositifs à brunir, c.-à-d. utilisant des organes de pression pour durcir les surfacesAccessoires à cet effet pour travailler extérieurement des surfaces de révolution
B23P 9/02 - Traitement ou finition par pression, p. ex. par moletage
B23P 9/04 - Traitement ou finition par martelage ou par pression répétée
7.
Method and device for the impact treatment of transition radii of a crankshaft
The invention relates to a method for the impact treatment of transition radii (8) of a crankshaft (4, 4′), in particular transition radii (8) between connecting rod bearing journals (5, 5′) and crank webs (7, 7′) and/or transition radii (8) between main bearing journals (6, 6′) and the crank webs (7, 7′) of the crankshaft (4, 4′). The crankshaft (4, 4′) is then rotated along a rotational direction into an impact position by means of a drive device (3, 3′). A locking device (12) is provided in order to lock the crankshaft (4, 4′) in the impact position, and an impact force is then introduced into at least one transition radius (8) by at least one impact tool (16, 16′).
