A card clothing wire is disclosed, especially for a doffer or a worker of a carding machine, which provides a superior retention of fibers during a carding process and which can be universally used to produce nonwoven webs with an increased grammage or to produce nonwoven webs with a low grammage and an increased quality. In one form, the card clothing wire includes a tooth depth of less than 1.7 mm and an overhanging tip with an undercut.
In recent years, development in the field of knitting tools has seen a focus on the reduction of friction and wear. A knitting tool (1) and a knitting device (27) as described herein are better able to reduce friction in knitting machines and the accumulation of dirt (23) than conventional knitting tools. For this purpose, a functional portion (5) of the knitting tool (1) has subsections (7) in which the absolute value of the gradient of a center-of-gravity line (4) is greater than zero.
The invention relates to a textile tool (1) structured according to a method for producing a textile tool (1) in which a metal tool blank is provided in a laser machining device (2) and the laser machining device (2) structures the tool blank on a tool surface (3) by means of the interference of at least two laser beams (4, 5), wherein at least some of the time the at least two laser beams (4, 5) have pulse durations of at most 15 ps and wherein as a result of the structuring on the tool surface (3) a tool profile (6) with at least one depression (7) is created.
B23K 26/06 - Mise en forme du faisceau laser, p. ex. à l’aide de masques ou de foyers multiples
B21G 1/04 - Fabrication d'aiguilles pour effectuer des opérations déterminées d'aiguilles à chas, p. ex. d'aiguilles à coudre, d'alènes d'aiguilles spécialement conçues pour être employées avec des machines ou des outils
B23K 26/0622 - Mise en forme du faisceau laser, p. ex. à l’aide de masques ou de foyers multiples par commande directe du faisceau laser par impulsions de mise en forme
B23K 26/067 - Division du faisceau en faisceaux multiples, p. ex. foyers multiples
B23K 26/352 - Travail par rayon laser, p. ex. soudage, découpage ou perçage pour le traitement de surface
C21D 9/26 - Traitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour aiguillesTraitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour dents de carde
4.
TEXTILE MACHINE, METHOD FOR OPERATING THE TEXTILE MACHINE, AND SYSTEM PART
The invention relates to a textile machine (1) which can be operated at high speeds and has a low energy consumption, and to a method for operating the textile machine (1) and to a system part (2) for the textile machine (1). The textile machine (1) according to the invention comprises a system part (2) which is mounted by a spring element (4), wherein the spring constant (CF) of the spring element (4) changes in a manner dependent on the control travel of a control surface of the system part (2). As a result, it is possible to provide a great maximum spring force by way of the spring element (4) and at the same time to keep the spring force low over long phases of operation of the textile machine (1), with the result that friction losses during operation are as low as possible and also energy consumption is low.
The invention relates to a clothing wire, comprising a base portion having a base height and a blade portion having a blade height. The blade height is smaller than the base height. The blade portion comprises a plurality of consecutive, geometrically identical tooth bodies. The tooth body extends between two first recesses of the blade portion which extend in the height direction at most towards the base portion. Two directly consecutive tooth bodies are spaced apart in a pitch. A first tooth tip and at least a second tooth tip are located on the tooth body, wherein the first tooth tip adjoins the first recess. A first tooth tip surface adjoins the first tooth tip and a second tooth tip surface adjoins the at least one second tooth tip. The first tooth tip surface has a first tip surface length and the second tooth tip surface has a second tip surface length, in each case having a value of at least the smaller value of the values 0.15 mm or 6% of the pitch. A first tooth face adjoins the first tooth tip at a positive first working angle. A second tooth face adjoins the at least one second tooth tip at a positive second working angle.
The present invention relates to a knitting tool (1), preferably a needle or sinker, which - has a stitch-forming portion (2) at the front end of its longitudinal extension, - has a support portion (3) in the further course of its longitudinal extension, - wherein side walls (4, 5) delimit the knitting tool (1) in the lateral direction (x), - wherein the side walls (4, 5) comprise support surfaces (6) which are intended for being in contact with and sliding along (and being supported on) the needle channels or needle guides of the knitting machine during knitting operation, - wherein the surface of the side walls (4, 5) of the knitting tool (1) comprises at least one recessed portion (8), - the surface of which is less spaced apart from an imaginary plane of symmetry of the knitting tool (1), spanned by its longitudinal axis of symmetry and its height direction, than at least one support surface (6) of the same side wall (4, 5) of the knitting tool (1). The invention also relates to a knitting machine containing needles of this kind.
A knitting system 18 and a needle 1, which show greater stability and consume less power during the knitting process, include a bending portion 9 in which at least one recess 11 is arranged at at least one lateral surface 23 of the needle 1 and/or is formed in such a manner that a shaft offset S exists, in a peripheral direction U, between a working portion 10 of the needle 1 and a shank portion 8 of the needle 1.
A clothing wire (1) according to the invention comprises a base portion (2) and a blade portion (5). The blade height (6) is greater than the base height (4). The blade portion has a plurality of identical tooth bodies (7). A tooth body extends in the longitudinal direction (x) between two first recesses (8) of the blade portion, said recesses extending in the height direction (y) at most toward the base portion. The tooth bodies are spaced apart in the longitudinal direction at a pitch (9). A first tooth tip (10) and at least one second tooth tip (11) are located on each tooth body. The first tooth tip adjoins a first recess (8) and points in the direction of said first recess. All first and second tooth tips point in the same direction. The clothing wire is characterized in that, on each tooth body (7), the first tooth tip (10) and the second tooth tip (11) farthest from the first tooth tip are located at a tooth tip distance (12) that is less than 50% of the pitch (9).
D01G 15/88 - Garniture de cardeSa fabrication non prévue ailleurs faite de bandes ou de feuilles métalliques
9.
INSERTION PART OF A TEXTILE MACHINE, PACKAGING FOR AT LEAST ONE INSERTION PART, METHOD FOR SUPPLYING A TEXTILE MACHINE WITH AT LEAST ONE INSERTION PART AND FOR OPERATING SAID TEXTILE MACHINE, SYSTEM FOR THE FURTHER PROCESSING OF TEXTILE MATERIALS
The present invention relates to an insertion part (1) of a textile machine, to a packaging for at least one insertion part of a textile machine, to a method for supplying a textile machine with at least one insertion part and for operating said textile machine, and to a system for the further processing of textile materials, said system comprising a textile machine and at least one insertion part for the operation of said textile machine, wherein the at least one insertion part is in the form of either a textile tool (1) or a system part (1), wherein the at least one insertion part (1) is connected, at the start of the equipping, at least to a handling part (7) by means of a predetermined breaking connection (9) which can be manually disconnected without the use of tools, wherein the insertion part can be handled by means of the handling part (7) during the equipping of the textile machine and wherein the predetermined breaking connection (9) can be disconnected.
D04B 35/02 - Outils ou instruments de tricotage non prévus dans les groupes ou
B65D 85/24 - Réceptacles, éléments d'emballage ou paquets spécialement adaptés à des objets ou à des matériaux particuliers pour objets incompressibles ou rigides en forme de baguette ou tubulaires pour aiguilles, clous ou petits objets de forme allongée similaires
The invention relates to: a compound needle (1) for stitch-forming textile machines; a stitch-forming textile machine; and a stitch-forming method. In order to reduce the entry of dirt and lint into the groove (6) of a compound needle (1), a compound needle (1) according to the invention is designed and is operated in a stitch-forming textile machine in such a way that, during operation, a force (13) acts downwards in the vertical direction (y) on the working area (11) of the slider (10) of the compound needle (1) and thus presses the slider (10) against the bottom (8) of the groove (6).
A method for laser beam hardening of sections to be hardened (A) of a card wire (10) is disclosed. Thereby the card wire (10) is moved in a conveying direction through a working space (26). In the working space (26), an inert gas atmosphere is created by continuously or discontinuously introducing inert gas (G). In the working space (26), a laser beam area (27) is generated through which the sections to be hardened (A) of the card wire (10) are moved. Thereby the sections to be hardened (A) are heated. After exiting out of the laser beam area (27) the sections to be hardened (A) cool and are hardened by progressing through this temperature profile. The hardening in the inert gas atmosphere inside working space (26) avoids formation of oxide layers (scaling) and annealing colors.
C21D 1/09 - Durcissement de surface par application directe d'énergie électrique ou ondulatoireDurcissement de surface par radiation particulaire
C21D 1/74 - Procédés de traitement en gaz neutre, en atmosphère contrôlée, sous vide ou dans des matières pulvérulentes
C21D 9/26 - Traitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour aiguillesTraitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour dents de carde
C21D 9/52 - Traitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour fils métalliquesTraitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour bandes métalliques
In recent years, development in the field of knitting tools has seen a focus on the reduction of friction and wear. A knitting tool (1) and a knitting device (27) as described herein are better able to reduce friction in knitting machines and the accumulation of dirt (23) than conventional knitting tools. For this purpose, a functional portion (5) of the knitting tool (1) has subsections (7) in which the absolute value of the gradient of a center-of-gravity line (4) is greater than zero.
The invention relates to packaging (1) for a tool module (2) comprising a plurality of textile tools (3), said packaging having: a supporting surface (9) which points in the longitudinal direction (L) and on which the tool module (2) or a plurality of tool modules (2) can lie form-fittingly with at least one shoulder (7). The working areas of the textile tools (3) are not in contact with the packaging (1), which, however, completely encloses the tool module (2). Tool modules are safely protected from mechanical damage and corrosion in such packaging. Such packaging is also particularly easy and quick to assemble.
B65D 5/52 - Supports extérieurs ou éléments de présentation du contenu
B65D 25/10 - Dispositifs pour placer les objets dans les réceptacles
B65D 77/04 - Objets ou matériaux enfermés dans plusieurs réceptacles disposés les uns dans les autres
B65D 81/107 - Réceptacles, éléments d'emballage ou paquets pour contenus présentant des problèmes particuliers de stockage ou de transport ou adaptés pour servir à d'autres fins que l'emballage après avoir été vidés de leur contenu spécialement adaptés pour protéger leur contenu des dommages mécaniques maintenant le contenu en position éloignée des parois de l'emballage ou des autres pièces du contenu utilisant des blocs de matériau amortisseur de chocs
B65D 85/24 - Réceptacles, éléments d'emballage ou paquets spécialement adaptés à des objets ou à des matériaux particuliers pour objets incompressibles ou rigides en forme de baguette ou tubulaires pour aiguilles, clous ou petits objets de forme allongée similaires
A sewing machine needle (1) is described, which reduces the friction between the blade (2) of the sewing machine needle (1) and the fabric and which can be manufactured economically in large numbers. The sewing machine needle (1) includes a needle eye (3) and at least one recess (5), wherein the distance between an upper edge (6) of the recess (5) and the lateral position of the axis (12) of the needle eye (3) differs from the distance between a lower edge (7) of the recess (5) and the lateral position of the axis (12) of the needle eye (3).
B21G 1/04 - Fabrication d'aiguilles pour effectuer des opérations déterminées d'aiguilles à chas, p. ex. d'aiguilles à coudre, d'alènes d'aiguilles spécialement conçues pour être employées avec des machines ou des outils
The invention relates to a knitted hosiery garment (1), which is suitable for being worn as legwear. The knitted hosiery garment (1) has different characteristics in a first region (2) covering the leg than in a second region (3) covering at least the sole of the foot, and can still be produced easily. The hosiery garment (1) is comfortable to wear and has a uniform, fine stitch structure. The first region (2) and the second region (3) of the hosiery garment (1) are knitted together in a transition region (8) such that they are connected to one another. In addition, the first region (2) has a greater number of stitches than the second region (3) in order to achieve the desired characteristics of the hosiery garment (1).
D04B 1/12 - Tricots ou articles à dessins caractérisés par la nature du fil
D04B 1/24 - Procédés de tricotage trame pour la production de tricots ou d'articles ne dépendant pas de l'emploi de machines spécialesTricots ou articles définis par de tels procédés spécialement conçus pour le tricotage d'articles de configuration particulière articles vestimentaires
D04B 1/26 - Procédés de tricotage trame pour la production de tricots ou d'articles ne dépendant pas de l'emploi de machines spécialesTricots ou articles définis par de tels procédés spécialement conçus pour le tricotage d'articles de configuration particulière articles vestimentaires bas
An object of the present invention is to specify a card clothing wire especially for a doffer or a worker of a carding machine which provides a superior retention of fibers during a carding- process and which can be universally used to produce nonwoven webs with an increased grammage or to produce nonwoven webs with a low grammage and an increased quality. Thus, the card clothing wire comprises a low tooth depth of less than 1.7 mm and an overhanging tip with an undercut.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and assemblies of textile machines, in particular
weaving machines, sewing machines, cards for spinning,
carding machines for nonwovens, needling machines,
hydroentanglement machines, tufting machines, knitting and
warp knitting machines, namely, needles [parts of industrial
textile machines], sewing machine needles [parts of
industrial sewing machines], tufting needles [parts of
industrial tufting machines], loopers, looper modules and
needle modules, felting and structuring needles [parts of
industrial felting machines], jet strips, knitting needles
[parts of industrial knitting machines], sinkers as well as
steel pins for actuating needles, needle-like parts of the
aforementioned machines for the producing of loops; system
parts for knitting machines, namely sinkers, in particular
knock over and holding-down sinkers, guide needles,
selection parts, needle plungers, joint parts and springs;
weaving harnesses, in particular weaving healds and heald
frames [machine parts]; metallic card clothing, revolving
tops with flexible card clothing or metallic card clothing
[machine parts]; stationary carding elements, flexible card
clothing and service devices for the mounting of card
clothing, namely winding devices for clothing and saw tooth
wires. Needles; needles for knitting machines, for warp knitting
machines, for needling machines, for tufting machines and
for sewing machines; hook needles; insertion needles;
knitting- and warp knitting machine needles, in particular
latch needles and slider needles as well as sliders as parts
of slider needles; sewing machine needles; tufting needles;
felting and structuring needles, fork needles.
18.
KNITTING TOOL AND METHOD FOR PRODUCING A KNITTING TOOL
The invention relates to a knitting tool (1) for knitting machines. The knitting tool (1) has a brake device (7) which is bent in a spring portion (5) in such a way that it provides a spring force during the knitting operation. By means of this spring force, a retaining force is provided during the knitting operation, which prevents unwanted movements of the knitting tool (1) during the knitting operation. The side faces of the knitting tool (1) are worked in the spring portion (5) in such a way that they have a smaller surface area per length unit than in at least one shaft portion (8) adjoining the spring portion. With a knitting tool (1) having this feature, the accumulation of dirt and fibre abrasion can surprisingly be reduced. It is able to be produced favourably and with constant quality.
A textile tool part pair (15) consisting of two textile tool parts (16) and a method of equipping a textile machine with the aid of such a textile tool part pair (15) are disclosed. Each textile tool part (16) extends in a longitudinal direction (L) between a trailing end (21) and a leading end (22). Proceeding from the trailing ends (21) thereof, the textile tool parts (16) extend away from one another and counter to one another as far as the leading end (22). At the trailing ends (21), the two textile tool parts (16) of a common textile tool part pair (15) are interconnected by a predetermined breaking connection (45). The predetermined breaking connection (45) can be manually separated without tools, in particular by bending about a bending axis (A).
A compound needle (13) for knitting machines, which is optimised in respect of stiffness, strength and service life and whose needle (1) has at least one hole (7) with which a functional element (8) of the slider (2) engages when the slider (2) is in its working portion (24). The functional element (8) connects operatively in such a way with the hole (7) in the needle (1) that it limits the freedom of movement of the slider (2) relative to the needle (1) to the slider's working portion (24)—i.e. prevents the slider from leaving the working portion (24) at the position of the functional element (8).
In recent years, more and more new fields of application for woven fabrics have become available, e.g. as a filter medium. Satisfying the requirements for such applications requires very fine woven fabrics that can be manufactured only by means of reeds having an accordingly small pitch. When manufacturing such reeds, the small distances between the dents of the reeds have an influence on physical effects, e.g. capillarity, which could be disregarded until now when manufacturing reeds having larger pitches. The aim of the invention is to specify a reed having a pitch of no more than 1/8 mm and a process for manufacturing same, taking into account these specificities.
In recent years, more and more new fields of application for woven fabrics have become available, e.g. as a filter medium. Satisfying the requirements for such applications requires very fine woven fabrics that can be manufactured only by means of reeds having an accordingly small pitch. When manufacturing such reeds, the small distances between the dents of the reeds have an influence on physical effects, e.g. capillarity, which could be disregarded until now when manufacturing reeds having larger pitches. The aim of the invention is to specify a reed having a pitch of no more than 1/8 mm and a process for manufacturing same, taking into account these specificities.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Machines for the textile industry, parts and accessories for
machines for the textile industry; weaving machines as well
as parts and assemblies of weaving machines, in particular
weaving harnesses, such as weaving healds and weaving heald
frames, heald frames, frame staves, lateral supports, heald
carrier rods, guide attachments for frame staves, healds,
leno healds, reeds, cord boards, harness cords, jacquard
weights, jacquard springs, warp stop motions and warp stop
motion plates, shuttles, split selvedge apparatus, edge
binders; shedding apparatuses, namely dobbies, cam motion
dobbies and jacquard machines, as well as components and
assemblies thereof, namely frame pulleys, bearers, clutch
devices, cams, eccentrics; all aforementioned goods only for
use in the textile industry. Textile tools as far as included in this class, in
particular braids, needles and haberdashery; all
aforementioned goods only for use in the textile industry.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and assemblies of textile machines; in particular
weaving machines; sewing machines; carding machines;
needling machines; hydroentanglement machines; tufting
machines; knitting machines; such as needles; sewing machine
needles; tufting needles; hooks; hook modules and needle
modules; felting and structuring needles; jet strips;
knitting needles; sinkers as well as steel pins for
actuating needles; needle-like parts of the aforementioned
machines for the production of stitches; system parts for
knitting machines, namely parts of the knitting system of
knitting machines, namely sinkers; in particular knock-over
loopers; knock-off sinkers; punching needles; selection
parts; needle pushers; coupling parts and springs; weaving
harness, such as healds and heald frames [machine parts];
all-steel cloth; revolving tops with flexible clothing or
all-steel clothings [machine parts]; stationary flats
flexible clothings and service devices for assembling
clothings, namely winding devices for clothings and
saw-tooth wires. Needles for knitting machines; needles for warp knitting
machines; needles for needling machines; needles for tufting
machines and needles for sewing machines; hook needles;
puncture needles; knitting and warp knitting machine
needles, in particular latch needles and slider needles and
sliders as parts of slider needles; sewing machine needles;
tufting needles; felting and structuring needles; fork
needles.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and assemblies of textile machines, in particular
weaving machines, sewing machines, carding machines,
needling machines, hydroentanglement machines, tufting
machines, knitting machines and warp knitting machines, such
as needles [parts of industrial textile machines], sewing
machine needles [parts of industrial textile machines],
tufting needles [parts of industrial tufting machines],
loopers, looper modules [parts of tufting machines] and
needle modules, felting and structuring needles [parts of
industrial felting machines], jet strips, knitting needles
[parts of industrial knitting machines], sinkers as well as
steel pins for actuating needles, needle-like parts of the
aforementioned machines for the production of stitches;
system parts for knitting machines, namely parts of the
knitting system of knitting machines, namely sinkers, in
particular knock-over sinkers and knock-off sinkers,
punching needles, selection parts, needle pushers, coupling
parts and springs; weaving harness elements, such as healds
and heald frames [machine parts]; all-steel clothings,
revolving tops with flexible clothing or all-steel clothings
[machine parts]; stationary carding elements, flexible
clothings and service devices being parts of machines for
assembling clothings, namely winding devices [machines] for
clothing and saw-tooth wires. Needles; needles for knitting machines, warp knitting
machines, needling machines, tufting machines and sewing
machines; hook needles; puncture needles; knitting and warp
knitting machine needles, in particular latch needles and
slider needles and sliders as parts of slider needles;
sewing machine needles; tufting needles; felting and
structuring needles, fork needles.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and assemblies of textile machines; in particular
weaving machines; sewing machines; carding machines;
needling machines; hydroentanglement machines; tufting
machines; knitting machines; such as needles; sewing machine
needles; tufting needles; hooks; hook modules and needle
modules; felting and structuring needles; jet strips;
knitting needles; sinkers as well as steel pins for
actuating needles; needle-like parts of the aforementioned
machines for the production of stitches; system parts for
knitting machines, namely parts of the knitting system of
knitting machines, namely sinkers; in particular knock-over
loopers; knock-off sinkers; punching needles; selection
parts; needle pushers; coupling parts and springs; weaving
harness, such as healds and heald frames [machine parts];
all-steel cloth; revolving tops with flexible clothing or
all-steel clothing [machine parts]; stationary flats
flexible clothing and service devices for assembling
clothing, namely winding devices for clothing and saw-tooth
wires. Needles for knitting machines; needles for warp knitting
machines; needles for needling machines; needles for tufting
machines and needles for sewing machines; hook needles;
puncture needles; knitting and warp knitting machine
needles, in particular latch needles and slider needles and
sliders as parts of slider needles; sewing machine needles;
tufting needles; felting and structuring needles; fork
needles.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Machines for the textile industry, parts and accessories for
machines for the textile industry, weaving machines as well
as parts and assemblies of weaving machines, in particular
weaving harnesses, such as weaving healds and weaving heald
frames, heald frames, frame staves, lateral supports, heald
carrier rods, guide attachments for frame staves, healds,
leno healds, reeds, comber boards, harness cords, jacquard
weights, jacquard springs, warp stop motions and drop wires
for warp stop motions, shuttles, split selvedge apparatus,
edge binders; shedding apparatus (machines), namely dobbies,
cam motion dobbies and jacquard machines, as well as
components and assemblies thereof, namely frame pulleys,
bearers, clutch devices, cams, eccentrics. Woven fabrics and textile goods, as far as included in this
class. Textile articles as far as included in this class, in
particular braids and haberdashery; textile tools as far as
included in this class, in particular needles.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and assemblies of textile machines, in particular
weaving machines, sewing machines, carding machines,
needling machines, hydroentanglement machines, tufting
machines, knitting machines, such as needles [parts of
industrial textile machines], sewing machine needles [parts
of industrial textile machines], tufting needles [parts of
industrial tufting machines], loopers, looper modules and
needle modules, felting and structuring needles [parts of
industrial felting machines], jet strips, knitting needles
[parts of industrial knitting machines], sinkers as well as
steel pins for actuating needles, needle-like parts of the
aforementioned machines for the production of stitches;
system parts for knitting machines, namely parts of the
knitting system of knitting machines, namely sinkers, in
particular knock-over sinkers/ knock-off sinkers, punching
needles, selection parts, needle pushers, coupling parts and
springs; weaving harness, such as healds and heald frames
[machine parts]; all-steel clothings, revolving tops with
flexible clothing or all-steel clothings [machine parts];
stationary flats, flexible clothings and service devices
being parts of machines for assembling clothings, namely
winding devices [machines] for clothing and saw-tooth wires. Needles; needles for knitting machines, warp knitting
machines, needling machines, tufting machines and sewing
machines; hook needles; puncture needles; knitting and warp
knitting machine needles, in particular latch needles and
slider needles and sliders as parts of slider needles;
sewing machine needles; tufting needles; felting and
structuring needles, fork needles.
Parts and assemblies of carding machines, in particular
cards, saw-tooth wire, metallic card clothing, flexible card
clothing, card clothing elements comprising crotchets or
needles, stationary carding elements, revolving flats with
flexible card clothing or with card wire.
31.
SINKER, KNITTING DEVICE AND KNITTING METHOD FOR PRODUCING KNITTED FABRICS
The invention relates to a knitting device (14) comprising a sinker (1) and to a method, the device and method making it possible to produce a knitted fabric with an even mesh structure over the entire service life, and having a pair of operative elements which comprises at least two sub-elements (6, 18). By means of the pair of operative elements, a force (7) can be exerted on the sinker (1) so as to act downward in the sinker height direction (H). During knitting, this force (7) can act counter to loop formation forces that act on loop formation means (3) of the sinker (1), and in this way prevent unevenness - for example slurgalling - in the knitted fabric produced.
D04B 9/06 - Métiers circulaires pour le tricotage de trame avec des aiguilles mobiles indépendantes avec cylindre à aiguilles et cadran pour tricot à côtes
32.
Device for handling harness elements and drawing-in machine
A device for handling weaving accessories, which is provided as a mobile unit, is disclosed herein. The device comprises a holding device for holding a reed, a holding device for holding healds, a holding device for holding drop wires and a holding device for holding a thread sheet. The holding device for holding the reed is provided for picking up a reed disposed movably at the holding device.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and assemblies of textile machines, in particular weaving machines, sewing machines, cards for spinning, carding machines for nonwovens, needling machines, hydroentanglement machines, tufting machines, knitting and warp knitting machines, namely, needles being parts of industrial textile machines, sewing machine needles being parts of industrial sewing machines, tufting needles being parts of industrial tufting machines, loopers, looper modules and needle modules, felting and structuring needles being parts of industrial felting machines, jet strips, knitting needles being parts of industrial knitting machines, sinkers as well as steel pins for actuating needles, needle-like parts of the aforementioned machines for the producing of loops; system parts for knitting machines, namely, sinkers, in particular knock over and holding-down sinkers, guide needles, selection parts, needle plungers, joint parts and springs; weaving harnesses, in particular weaving healds and heald frames being machine parts; metallic card clothing, revolving tops with flexible card clothing or metallic card clothing being machine parts; stationary carding elements, flexible card clothing being parts of machines, service devices for the mounting of card clothing being machines, namely, winding devices for clothing and saw tooth wires Needles; needles for knitting machines, for warp knitting machines, for needling machines, for tufting machines and for sewing machines; hook needles; insertion needles; knitting- and warp knitting machine needles, in particular latch needles and slider needles as well as sliders as parts of slider needles; sewing machine needles; tufting needles; felting and structuring needles, fork needles
Parts and assemblies of carding machines, in particular cards, saw-tooth wire, metallic card clothing, flexible card clothing, card clothing elements comprising crotchets or needles, stationary carding elements, revolving flats with flexible card clothing or with card wire
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
(1) Parts and assemblies of textile machines, in particular weaving machines, sewing machines, carding machines, needling machines, hydroentanglement machines, tufting machines, knitting machines, such as needles, sewing machine needles for industrial use, tufting needles, hooks, hook modules and needle modules, felting and structuring needles jet strips, knitting needles, sinkers as well as steel pins for actuating needles, needle-like parts of the aforementioned machines for the production of stitches; system parts for knitting machines, namely parts of the knitting system of knitting machines, namely sinkers, in particular knock-over loopers, knock-off sinkers, needle selection parts, needle pushers, coupling parts and springs; weaving harness, such as healds and heald frames (machine parts); all-steel card clothing being parts of carding machines; revolving tops with flexible card clothing and all-steel clothings all being parts of carding machines; stationary flats flexible clothings and service devices for assembling clothings, namely winding devices for clothings and saw-tooth wires.
(2) Needles for knitting machines; needles for warp knitting machines; needles for needling machines; needles for tufting machines and needles for sewing machines; hook needles, namely, latch hook needles and knitting needles; puncture needles being shoemakers' needles; punching needles being shoemakers' needles; knitting and warp knitting machine needles, in particular latch needles and slider needles and sliders as parts of slider needles; sewing machine needles; tufting needles; felting needles; structuring and fork needles being felting needles.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
PARTS AND ASSEMBLIES OF TEXTILE MACHINES, IN PARTICULAR SEWING NEEDLES, TUFTING NEEDLES, LOOPERS, LOOPER MODULES AND NEEDLE MODULES, FELTING AND STRUCTURING NEEDLES, JET STRIPS, KNITTING NEEDLES FOR KNITTING MACHINES, SINKERS, STEEL PINS FOR ACTUATING NEEDLES, KNITTING NEEDLE PARTS OF THE AFOREMENTIONED MACHINES FOR THE PRODUCTION OF STITCHES; SYSTEM PARTS FOR KNITTING MACHINES, PARTICULARLY KNOCK-OVER SINKERS, KNOCK-OFF SINKERS, PUNCHING NEEDLES, SELECTION PARTS, NEEDLE PUSHERS, COUPLING PARTS AND SPRINGS; WEAVING HARNESS, PARTICULARLY HEALDS AND HEALD FRAMES; TEXTILE MACHINE COMPONENTS, PARTICULARLY ALL-STEEL CLOTHINGS, REVOLVING TOPS WITH FLEXIBLE CLOTHING OR ALL-STEEL CLOTHINGS; STATIONERY FLATS, FLEXIBLE CLOTHINGS AND SERVICE DEVICES FOR CLOTHING AND SAW TOOTH WIRES NEEDLES; NEEDLES FOR KNITTING, WARP KNITTING, TUFTING AND SEWING MACHINES; LATCH HOOK NEEDLES; PUNCTURE SEWING NEEDLES; KNITTING AND WARP KNITTING MACHINE NEEDLES, IN PARTICULAR, LATCH NEEDLES AND SLIDER NEEDLES AND SLIDERS AS PARTS OF SLIDER NEEDLES; SEWING MACHINE NEEDLES; TUFTING NEEDLES; FELTING AND STRUCTURING NEEDLES, FORK NEEDLES
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
(1) Parts and assemblies of textile machines, in particular weaving machines, sewing machines, carding machines, needling machines, hydroentanglement machines, tufting machines, knitting machines, such as needles, sewing machine needles for industrial use, tufting needles, hooks, hook modules and needle modules, felting and structuring needles jet strips, knitting needles, sinkers as well as steel pins for actuating needles, needle-like parts of the aforementioned machines for the production of stitches; system parts for knitting machines, namely parts of the knitting system of knitting machines, namely sinkers, in particular knock-over loopers, knock-off sinkers, needle selection parts, needle pushers, coupling parts and springs; weaving harness, such as healds and heald frames (machine parts); all-steel card clothing being parts of carding machines; revolving tops with flexible card clothing and all-steel clothings all being parts of carding machines; stationary flats flexible clothings and service devices for assembling clothings, namely winding devices for clothings and saw-tooth wires.
(2) Needles for knitting machines; needles for warp knitting machines; needles for needling machines; needles for tufting machines and needles for sewing machines; hook needles, namely, latch hook needles and knitting needles; puncture needles being shoemakers' needles; punching needles being shoemakers' needles; knitting and warp knitting machine needles, in particular latch needles and slider needles and sliders as parts of slider needles; sewing machine needles; tufting needles; felting needles; structuring and fork needles being felting needles.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and assemblies of textile machines, in particular sewing needles, tufting needles, loopers, looper modules and needle modules, felting and structuring needles, jet strips, knitting needles for knitting machines, sinkers, steel pins for actuating needles, knitting needle parts of the aforementioned machines for the production of stitches; system parts for knitting machines, particularly knock-over sinkers, knock-off sinkers, punching needles, needle selection parts, needle pushers, coupling parts being couplings and springs; weaving harness, particularly healds and heald frames being machine parts; stationary flats being machine parts; and saw tooth wires for use in textile machines Needles for knitting machines; needles for knitting, warp knitting, tufting and sewing machines; latch hook needles; puncture sewing needles; knitting and warp knitting machine needles, in particular, latch needles and slider needles and sliders as parts of slider needles; sewing machine needles; tufting needles; felting and structuring needles, fork needles
A reed (16) including multiple slats (20), which are arranged in a transverse direction (Q) at a distance from one another is disclosed. Each slat (20) extends from an upper end (21) to a lower end (22). The upper ends (21) are connected by an adhesive bond to two upper plate parts (32) of an upper holding shaft (23). The lower ends (22) of the slats (20) are connected by an adhesive bond to two lower plate parts (43) of a lower holding shaft (24). The plate parts (32, 43) are each produced from a fiber-reinforced composite material. The entire upper holding shaft (23) and the entire lower holding shaft (24) preferably are made of parts produced from a fiber-reinforced composite material.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Metallic wires, namely metallic card clothing wire, carding
wire, saw tooth wire for carding machines, doffer wire,
worker wire, stripping wire, transfer wire, intermediate
doffer wire. Parts and accessories of textile machines, included in this
class, such as needles, sewing machine needles, tufting
needles, loopers, looper modules (parts of tufting machines)
and needle modules, felting and structuring needles, jet
strips, knitting needles, system parts for knitting
machines, namely parts of the knitting system of knitting
machines, namely sinkers, particularly knock over and
holding down sinkers (parts of knitting machines), guide
needles, needle-like parts, needle plungers, selection
parts, coupling parts and springs; parts of textile
machines, namely harness elements, such as healds and heald
shafts; knotting machines, knotting frames, drawing-in
machines, cleaning machines, harness carriages and other
machines for the maintenance, cleaning and equipping of
weaving machines; parts and accessories for carding
machines, included in this class, in particular cards,
saw-tooth wires, metallic card clothing, parts of metallic
card clothing consisting of hooks or needles, revolving flat
cards with flexible card clothing or metallic card clothing
[machine parts]; stationary carding elements, flexible card
clothing [machine parts]; service tools for the mounting of
card clothing, namely winding devices for clothing and saw
tooth wires; automatic machines for dispensing needles,
automatic placement machines for needle-felting machines;
warp knitting machine needles, particularly latch type
needles and compound needles as well as sliders as parts of
compound needles. Needles; knitting needles, particularly latch type needles
and compound needles as well as sliders as parts of compound
needles; sewing machine needles; tufting needles; felting
and structuring needles.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
parts and components for sewing, knitting, embroidery, warp knitting, weft knitting, stitch bonding, braid crocheting, quilting and interlacing machines for commercial purposes, namely needles, needle boards, needle-like parts, needle modules, knitting boards, knitting board cartridges, closers, closer modules, guide needle modules and sinkers; parts and components for tufting machines for commercial purposes, namely needles, needle boards, needle-like parts, knives, knife modules, reed fingers, reed finger modules, grippers and gripper modules; parts and components for felting machines for commercial purposes, namely felting needles, needle boards, and needle-like parts. Needles and needle-like parts for sewing, knitting, embroidery, warp knitting, weft knitting, stitch bonding, braid crocheting, quilting and interlacing machines for commercial purposes; needles and needle-like parts for tufting machines for commercial purposes; needles and needle-like parts for felting machines for commercial purposes.
The invention relates to a method for laser-beam-hardening regions (A) of a clothing wire (10) that are to be hardened. The clothing wire (10) is moved, during this process, in a conveying direction through a work space (26). An inert gas atmosphere is generated in the work space (26) by introducing inert gas (G) continuously or discontinuously. A laser beam field (27) is formed in the work space (26), and the regions (A) of the clothing wire (10) that are to be hardened are moved through this laser beam field. The regions (A) to be hardened are heated during this process. Following the exit from the laser beam field (27), the regions (A) that are to be hardened cool down and are hardened as they pass through this temperature profile. The hardening in the inert gas atmosphere in the work space (26) prevents the formation of oxide layers (scaling) and annealing colours.
C21D 6/00 - Traitement thermique des alliages ferreux
C21D 9/00 - Traitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet
C21D 9/52 - Traitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour fils métalliquesTraitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour bandes métalliques
C21D 1/74 - Procédés de traitement en gaz neutre, en atmosphère contrôlée, sous vide ou dans des matières pulvérulentes
C21D 9/26 - Traitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour aiguillesTraitement thermique, p. ex. recuit, durcissement, trempe ou revenu, adapté à des objets particuliersFours à cet effet pour dents de carde
D01G 15/88 - Garniture de cardeSa fabrication non prévue ailleurs faite de bandes ou de feuilles métalliques
A device and a method for handling weaving accessories is described herein. A first holding element is provided for being moved cyclically between a supply device and a receiving device. The first holding element is disposed at a carrier means. A push-off element for pushing a weaving accessory off the holding element and onto a component of the receiving device is also disposed at the carrier means. The first holding element is preferably provided for performing its cyclic movement in a plane with an axis running at right angles thereto.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and assemblies of textile machines, such as needles
[parts of industrial textile machines], sewing machine
needles [parts of industrial sewing machines], tufting
needles [parts of industrial tufting machines], loopers,
looper modules (parts of tufting machines) and needle
modules, felting and structuring needles [parts of
industrial felting machines], jet strips, knitting needles
[parts of industrial knitting machines], system parts for
knitting machines, namely parts of the knitting system of
knitting machines, namely sinkers, particularly knock over
and holding down sinkers (parts of knitting machines), guide
needles, needle-like parts, needle plungers, selection
parts, coupling parts and springs; parts of textile
machines, namely harness elements, such as healds and heald
shafts; parts and accessories for carding machines, included
in this class, in particular card clothing, saw-tooth wires,
metallic card clothing, parts of metallic card clothing
consisting of hooks or needles, revolving flat cards with
flexible card clothing or metallic card clothing [machine
parts]; stationary carding elements [machine parts];
flexible card clothing being part of carding machines;
service tools being machines for the mounting of card
clothing, namely winding devices for clothing and saw tooth
wires [being machines]; automatic machines for dispensing
needles. Needles; knitting and warp knitting machine needles,
particularly latch type needles and compound needles as well
as sliders as parts of compound needles; sewing machine
needles; tufting needles; felting and structuring needle.
45.
NEEDLE BODY, SLIDER NEEDLE ASSEMBLY, AND WARP KNITTING MACHINE
The invention relates to a needle body for a slider needle assembly of a warp knitting machine, comprising a shank and a hook. The lower edge of the hook lies opposite and faces away from a bent-back hook part. The upper edge of the hook lies on the bent-back hook edge and faces away from the lower edge of the hook. The needle body according to the invention is characterized in that the hook height, measured in the longitudinal direction at the point of maximum distance in the vertical direction between the lower edge of the hook and the upper edge of the hook, equals at most 0.81 mm, and a cross-sectional height, measured in the cross-section of the shank in a stitch sliding portion perpendicular to the width direction, equals at most 0.81 mm. A slider needle assembly according to the invention comprises a needle body according to the invention and a slider and has a looping length of the hook and the slider equaling 2.3 mm or less.
D04B 23/16 - Métiers à tricoter chaîne rectiligne spécialement adaptés pour produire des tricots ou panneaux d'article d'une forme ou d'une configuration particulières
D04B 35/06 - Aiguilles à piston (languette coulissante)
46.
Method, device, movable carriage and drawing-in machine
A method and a device for the automated transport of weaving accessories is disclosed. A device is provided which has at least one rail and at least one rail carrier. The at least one rail carrier carries the weight of the at least one rail, on which weaving accessories can be movably disposed in the longitudinal direction of the rail. The method is characterized in that the at least one rail carrier is displaced relative to the at least one rail, in the longitudinal direction thereof, in order to move weaving accessories disposed at the rail along the rail in the longitudinal direction thereof.
A method and a knitting device for plating with compound needles on a circular knitting machine is described herein. At least two yarns are inserted into the hook area of a compound needle. A sinker is moved in such a way relative to a knock-over edge disposed immovably on a cylinder that the sinker, by way of a guide means, guides at least one of the yarns further into the hook area of the compound needle, in the direction of the needle shank, and in doing so keeps the yarns separated. The sinker furthermore moves, in the longitudinal direction and the elevational direction, in such a manner relative to the knock-over edge that the guide means performs a movement which, at least section-wise, tracks at least one yarn.
D04B 9/34 - Métiers circulaires pour le tricotage de trame avec des aiguilles mobiles indépendantes pour la production de tricots à dessins avec dessins de couleur par vanisage
D04B 9/10 - Métiers circulaires pour le tricotage de trame avec des aiguilles mobiles indépendantes avec deux cylindres à aiguilles pour la formation de tricots à mailles d'envers ou à mailles retournées
A device and a method for handling of weaving accessories are disclosed. The device has a first holding element and at least one further holding element for weaving accessories. The first holding element and the at least one further holding element are provided for being moved cyclically between a supply device and a receiving device. At least the first holding element is configured to complete at least part of its movement between the supply device and the receiving device while the at least one further holding element remains stationary.
A device and a method for handling weaving accessories are described herein. The device comprises at least one holding element for a weaving accessory. The at least one holding element comprises a contact surface for a weaving accessory. The greater extension of the contact surface defines the longitudinal direction of the holding element and the lesser extension of the contact surface defines the lateral direction of the holding element. The at least one holding element is arranged pivotably around a first axis, which extends at a right angle to the holding element's longitudinal direction. A weaving accessory at the holding element's contact surface can thus be moved from a pick-up position to a drawing-in position by pivoting the holding element around the first axis.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
(1) Parts and assemblies of textile machines, in particular weaving machines, sewing machines, carding machines, needling machines, hydroentanglement machines, tufting machines, knitting machines and warp knitting machines, such as needles [parts of industrial textile machines], sewing machine needles [parts of industrial textile machines], tufting needles [parts of industrial tufting machines], loopers, looper modules [parts of tufting machines] and needle modules, felting and structuring needles [parts of industrial felting machines], jet strips, knitting needles [parts of industrial knitting machines], sinkers as well as steel pins for actuating needles, needle-like parts of the aforementioned machines for the production of stitches; system parts for knitting machines, namely parts of the knitting system of knitting machines, namely sinkers, in particular knock-over sinkers and knock-off sinkers, punching needles, selection parts, needle pushers, coupling parts and springs; weaving harness elements, namely, weaving healds and weaving heald frames being parts of weaving looms; all-steel card clothing being parts of carding machines, revolving tops with flexible card clothing and all-steel clothing all being parts of carding machines; stationary carding elements, flexible clothings and service devices being parts of machines for assembling clothings, namely winding devices [machines] for clothing and saw-tooth wires.
(2) Needles, namely, knitting needles, sewing needles, textile needles, needles for textile processing, and hosiery loom needles; needles for knitting machines, warp knitting machines, needling machines, tufting machines and sewing machines; hook needles; puncture needles; knitting and warp knitting machine needles, in particular latch needles and slider needles and sliders as parts of slider needles; sewing machine needles; tufting needles; felting and structuring needles, fork needles.
51.
Stitch-forming element and stitch-forming textile machine
A stitch forming element for a stitch-forming textile machine, wherein the textile machine includes a stitch-forming element carrier with at least one guide channel for guiding at least one stitch-forming element. The stitch-forming element includes a longitudinal axis and a vertical axis and a first recess with a lower edge, an upper edge, an open first end and a closed second end for stitch formation. The stitch-forming element further includes a second recess with a lower edge, an upper edge, an open first end and a closed second end for cleaning the at least one guide channel. The stitch-forming textile machine includes a stitch-forming element carrier with at least one guide channel, and at least one such stitching element. The least one stitch-forming element with its second recess is guided in the at least one guide channel.
The invention relates to a sewing machine needle (1) which reduces the friction between the shaft of the sewing machine needle (1) and the sewing item and which thereby can be produced economically in large numbers. The sewing machine needle (1) comprises a needle eye (3) and at least one recess (5), wherein the distance of an upper edge (6) of the recess (5) to the width position of the axis (12) of the needle eye (3) is different from the distance of a lower edge (7) of the recess (5) to the width position of the axis (12) of the needle eye (3).
B21G 1/04 - Fabrication d'aiguilles pour effectuer des opérations déterminées d'aiguilles à chas, p. ex. d'aiguilles à coudre, d'alènes d'aiguilles spécialement conçues pour être employées avec des machines ou des outils
In the past years, reduction of friction and wear has become important in the development of knitting tools. A knitting tool (1) and a knitting device (27) according to the invention are therefore suitable for reducing friction in knitting machines and for minimizing build-up of soiling matter (23) as compared to conventional knitting tools. For this purpose, the knitting tool (1), in a functional region (5), has sub-regions (7) in which the value of the slope of a center-of-gravity line (4) is greater than zero.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
parts and Assemblies, in relation to the following goods: Textile production machines, especially Looms, Sewing machines, Carding machines, carding machines, Needle machines, water jet needling installations, Tufting machines, Knitting machines, Hosiery looms, Such as needles,, Needles for sewing machines, Tufting needles, Grabs, grapple modules, and Needle modules, felt and structuring needles, jet strips, knitting needles, Boards, Steel pins for actuating needles, needle-like parts for the aforesaid machines for making stitches; System parts, for use in relation to the following goods: Knitting machines, in particular Parts of knitting systems for knitting machines, in particular Boards, especially Knock-over and holding down sinkers, guide needles, selection parts, needle rods, Coupling parts and Springs; Gears for weaving looms, Such as Heddles, Heald frames Machine parts; Metallic wires, revolving flats with flexible wires or metallic wires [parts of machines]; Fixed carding elements, flexible wires and service apparatus for the assembly of wires, namely threading units for wires and saw-tooth wires. Needles; Needles, for use in relation to the following goods: Knitting machines, Hosiery looms, needle machines, tufting machines, sewing machines; Crochet hooks; Insert needles; Knitting machine needles, Hosiery loom needles, Especially, Hook needles, slide needles, sliders being parts of slide needles; Sewing machine needles; Tufting needles; Felt and structuring needles, fork needles.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Machines for the textile industry, the parts and accessories thereof; Looms, Parts therefor, Assemblies for the aforesaid goods, especially, Gears for weaving looms, For example, Heddles and Heald frames, Heald frames, Frame staves, lateral supports, heald carrying rods, lead attachments for frame staves, Heddles, Leno healds, web sheets, comber boards, harness strings, jacquard weights, jacquard springs, warp stop motions and warp stop motion lamellas, Shuttles, Cutting bar apparatus, angle binders; Shedding devices, namely dobbies, eccentric dobbies and jacquard looms, and parts and assemblies therefor, namely heald frame motions, bearers, coupling devices, cams, tappets; All the aforesaid goods solely for use in the textile industry. Textile tools, the aforesaid goods included in class 26, in particular, Braids, Needles and Haberdashery [dressmakers' articles], except thread; All the aforesaid goods solely for use in the textile industry.
A knitting system 18 and a needle 1, which show greater stability and consume less power during the knitting process, comprise a bending portion 9 in which at least one recess 11 is arranged at at least one lateral surface 23 of the needle 1 and/or is formed in such a manner that a shaft offset S exists, in peripheral direction U, between a working portion 10 of the needle 1 and a shank portion 8 of the needle 1.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and assemblies of textile machines, in particular weaving machines, sewing machines, carding machines, needling machines, hydroentanglement machines, tufting machines, knitting machines, such as needles, sewing machine needles for industrial use, tufting needles, hooks, hook modules and needle modules, felting and structuring needles jet strips, knitting needles, sinkers as well as steel pins for actuating needles, needle-like parts of the aforementioned machines for the production of stitches; System parts for knitting machines, namely parts of the knitting system of knitting machines, namely sinkers, in particular knock-over loopers, knock-off sinkers, needle selection parts, needle pushers, coupling parts and springs; weaving harness, such as healds and heald frames (machine parts); All-steel cloth (machine parts); revolving tops with flexible clothing or all-steel clothings (machine parts); Stationary flats flexible clothings and service devices for assembling clothings, namely winding devices for clothings and saw-tooth wires. Needles; needles for knitting machines; needles for warp knitting machines; needles for needling machines; needles for tufting machines and needles for sewing machines; hook needles; puncture needles; punching needles; knitting and warp knitting machine needles, in particular latch needles and slider needles and sliders as parts of slider needles; sewing machine needles; tufting needles; felting and structuring needles; fork needles.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and assemblies of textile machines, in particular weaving machines, sewing machines, carding machines, needling machines, hydroentanglement machines, tufting machines, knitting machines, such as needles, sewing machine needles for industrial use, tufting needles, hooks, hook modules and needle modules, felting and structuring needles jet strips, knitting needles, sinkers as well as steel pins for actuating needles, needle-like parts of the aforementioned machines for the production of stitches; System parts for knitting machines, namely parts of the knitting system of knitting machines, namely sinkers, in particular knock-over loopers, knock-off sinkers, needle selection parts, needle pushers, coupling parts and springs; weaving harness, such as healds and heald frames (machine parts); All-steel cloth (machine parts); revolving tops with flexible clothing or all-steel clothings (machine parts); Stationary flats flexible clothings and service devices for assembling clothings, namely winding devices for clothings and saw-tooth wires. Needles; needles for knitting machines; needles for warp knitting machines; needles for needling machines; needles for tufting machines and needles for sewing machines; hook needles; puncture needles; punching needles; knitting and warp knitting machine needles, in particular latch needles and slider needles and sliders as parts of slider needles; sewing machine needles; tufting needles; felting and structuring needles; fork needles.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
PARTS AND ASSEMBLIES OF TEXTILE MACHINES, IN PARTICULAR SEWING NEEDLES, TUFTING NEEDLES, LOOPERS, LOOPER MODULES AND NEEDLE MODULES, FELTING AND STRUCTURING NEEDLES, JET STRIPS, KNITTING NEEDLES FOR KNITTING MACHINES, SINKERS, STEEL PINS FOR ACTUATING NEEDLES, KNITTING NEEDLE PARTS OF THE AFOREMENTIONED MACHINES FOR THE PRODUCTION OF STITCHES; SYSTEM PARTS FOR KNITTING MACHINES, PARTICULARLY KNOCK-OVER SINKERS, KNOCK-OFF SINKERS, PUNCHING NEEDLES, SELECTION PARTS, NEEDLE PUSHERS, COUPLING PARTS AND SPRINGS; WEAVING HARNESS, PARTICULARLY HEALDS AND HEALD FRAMES; TEXTILE MACHINE COMPONENTS, PARTICULARLY ALL-STEEL CLOTHINGS, REVOLVING TOPS WITH FLEXIBLE CLOTHING OR ALL-STEEL CLOTHINGS; STATIONERY FLATS, FLEXIBLE CLOTHINGS AND SERVICE DEVICES FOR CLOTHING AND SAW TOOTH WIRES NEEDLES; NEEDLES FOR KNITTING, WARP KNITTING, TUFTING AND SEWING MACHINES; LATCH HOOK NEEDLES; PUNCTURE SEWING NEEDLES; KNITTING AND WARP KNITTING MACHINE NEEDLES, IN PARTICULAR, LATCH NEEDLES AND SLIDER NEEDLES AND SLIDERS AS PARTS OF SLIDER NEEDLES; SEWING MACHINE NEEDLES; TUFTING NEEDLES; FELTING AND STRUCTURING NEEDLES, FORK NEEDLES
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Machines for the textile industry, parts and accessories for machines for the textile industry, weaving machines as well as parts and assemblies of weaving machines, in particular weaving harnesses, such as weaving healds and heald frames, weaving heald frames, frame staves, lateral supports, heald carrier rods, guide attachments for frame staves, healds, leno healds, reeds, comber boards, harness cords, jacquard weights, jacquard springs, warp stop motions and drop wires for warp stop motions, shuttles, split selvedge apparatus, edge binders; shedding apparatus, namely dobbies, cam motion dobbies and jacquard machines, as well as components and assemblies thereof, namely frame pulleys, bearers, clutch devices, cams, eccentrics. Woven fabrics and textile goods, as far as included in class 24. Textile tools as far as included in class 26, in particular braids, needles and haberdashery.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Metallic wires being non-electric wire of common metal, namely, metallic card clothing wire, carding wire, saw tooth wire for carding machines, doffer wire, worker wire, stripping wire, transfer wire, intermediate doffer wire Parts of textile production and processing machines, particularly, needles, sewing machine needles, tufting needles, loopers, looper modules for tufting machines, needle modules, felting and structuring needles, jet strips, knitting needles, system parts for knitting machines, namely, sinkers, particularly knock over and holding down sinkers, guide needles, needle-like parts for actuating and controlling needles and sinkers, needle plungers, selection parts, coupling parts and springs; parts of textile machines, namely, harness elements being healds and heald shafts; knotting machines and knotting frames being weaving preparation machines or parts thereof, drawing-in machines for weaving, cleaning machines for cleaning textile processing machines, harness carriages being weaving preparation machines, and machines for the maintenance, cleaning and equipping of weaving machines, particularly, cleaning machines for drop wires, healds, and reeds; parts for carding machines, in particular cards, saw-tooth wires, metallic card clothing, parts of metallic card clothing consisting of hooks or needles, revolving flat cards with flexible card clothing or metallic card clothing; parts of textile processing machines, namely, stationary carding elements, flexible card clothing; service tools for the mounting of card clothing, namely, winding devices for clothing and saw tooth wires being machines; automatic machines for dispensing needles, automatic placement machines for needle-felting machines; parts of knitting machines, namely, warp knitting machine needles, particularly latch type needles and compound needles as well as sliders as parts of compound needles Needles; knitting needles, particularly latch type needles and compound needles as well as sliders as parts of compound needles; sewing machine needles; tufting needles; felting and structuring needles
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
(1) Metallic wires, namely metallic card clothing wire, carding wire, saw tooth wire for carding machines, doffer wire, stripping wire, intermediate doffer wire.
(2) Parts and accessories of textile machines, included in this class, in particular needles, sewing machine needles, tufting needles, loopers, looper modules (parts of tufting machines) and needle modules, felting and structuring needles, jet strips, knitting needles, system parts for knitting machines, namely parts of the knitting system of knitting machines, namely sinkers, particularly knock over and holding down sinkers (parts of knitting machines), guide needles, needle-like parts, needle plungers, selection parts, coupling parts and springs; parts of textile machines, namely harness elements, in particular healds and heald shafts; knotting machines, knotting frames, drawing-in machines, cleaning machines, harness carriages and other machines for the maintenance, cleaning and equipping of weaving machines; parts and accessories for carding machines, included in this class, in particular cards, saw-tooth wires, metallic card clothing, parts of metallic card clothing consisting of hooks or needles, revolving flat cards with flexible card clothing or metallic card clothing [machine parts]; stationary carding elements, flexible card clothing [machine parts]; service tools for the mounting of card clothing, namely winding devices for clothing and saw tooth wires; automatic machines for dispensing needles, automatic placement machines for needle-felting machines; warp knitting machine needles, particularly latch type needles and compound needles as well as sliders as parts of compound needles.
(3) Knitting needles, particularly latch type needles and compound needles as well as sliders as parts of compound needles; sewing machine needles; tufting needles; felting and structuring needles.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and assemblies of industrial textile processing machines, namely, needles, sewing machine needles, tufting needles, felting and structuring needles for felting machines, knitting needles, sinkers, particularly knock over and holding down sinkers for knitting machines; parts of textile machines, namely, harness elements, being healds and heald shafts, all aforementioned goods for use in the textile industry Knitting and warp knitting machine needles, particularly latch type needles and compound needles, sewing machine needles, tufting needles, felting and structuring needles, all aforementioned goods for use in the textile industry
A slide needle (13) for knitting machines which is optimized in terms of stiffness, strength and lifetime and the needle (1) of which has at least one hole (7) in which a functional element (8) of the slide (2) engages when the slide (2) is in its operating range (24). The functional element (8) is then in operative connection with the hole (7) of the needle (1) in such a way that it limits the freedom of movement of the slide (2) to its operating range (24) in relation to the needle (1) – and therefore avoids the operating range (24) being left at the position of the functional element (8).
A device (1), a sinker arrangement (5) and a method for loop-forming are described. The device (1) may include a cylinder (2) with first grooves (3) for needles (4) accommodated in a first groove (3), whereby the needles (4) include a loop forming section, and a sinker ring (27) with second grooves (15) for the sinker arrangement (5). The sinker arrangement (5) may include an actuating section (12) and a loop forming section (7). The loop forming section (7) includes an opening (11), and the sinker arrangements (5) are accommodated in one single second groove (15). The opening (11) may be delimited in the width direction (x) by two side faces (23) and the loop forming section of the needle (4) is movably disposed between the two side faces (23) of the opening (11).
The invention relates to a textile tool part pair (15) consisting of two textile tool parts (16), and to equipping a textile machine with the aid of such a textile tool part pair (15). Each textile tool part (16) extends in a longitudinal direction (L) between a trailing end (21) and a leading end (22). Proceeding from the trailing ends (21) thereof, the textile tool parts (16) extend away from one another and counter to one another as far as the leading end (22). At the trailing ends (21), the two textile tool parts (16) of a common textile tool part pair (15) are interconnected by a predetermined breaking join (45). The predetermined breaking join (45) can be manually separated without tools, in particular by bending about a bending axis (A).
A latch needle for a loop-forming textile machine includes a needle shank and a needle latch with a back. The needle shank has a slot for receiving the needle latch and a first contact portion adapted to the back. The needle latch is pivotably mounted on the needle shank about a pivot axis between an open position and a closed position. In the open position, the back bears against the first contact portion. The latch needle has a damping spring adapted to the back and/or to the first contact portion in order to damp a contact of the back of the needle latch when in the open position, against the first contact portion.
A knitting needle includes a hook point having an upper face, lateral portions, and a rear portion. The knitting needle has an at least approximately oval cross section, at least in portions, at the hook point, in order to improve the knitting needle in terms of structure and/or function.
The invention relates to a warp knitting machine (26) which allows the successive production of batches of warp-knitted fabric with compositions of different diversity on a single warp knitting machine (26). For this purpose, a relative position of the lever shaft (3), by means of which at least one guide bar (8) can be driven, can be adjusted relative to the further lever shafts (4, 5, 6), by which in each case at least one further bar can be driven, in the direction of the machine height (y) and/or in the direction of the machine depth (x).
The invention relates to a sinker which has a knock-over edge, a hold-down edge, and an enclosing edge. The knock-over edge extends in the width direction and in the longitudinal direction, wherein the height direction of the sinker points upwards perpendicularly from the surface of the knock-over edge, and the hold-down edge is arranged opposite the knock-over edge at a distance therefrom. The enclosing edge delimits and connects the knock-over edge and the hold-down edge towards the rear. A contact edge adjoins the knock-over edge at a knock-over edge transition point, and a support edge adjoins the contact edge at a support edge transition point. The support edge extends approximately in the longitudinal direction and is arranged below the knock-over edge in the height direction. The sinker according to the invention is characterized in that the distance between the support edge transition point and the knock-over edge transition point in the height direction is at least four times as wide as the distance between the support edge transition point and the knock-over edge transition point in the longitudinal direction. A sinker assembly with a sinker according to the invention can be used in a warp knitting machine in order to produce universal warp knitted fabric.
The invention relates to a reed (16) comprising multiple slats (20), which are arranged in a transverse direction (Q) at a distance from one another. Each slat (20) extends from an upper end (21) to a lower end (22). The upper ends (21) are connected by an adhesive bond by means of adhesive (K) to two upper plate parts (32) of an upper holding shaft (23). The lower ends (22) of the slats (20) are connected by an adhesive bond by means of adhesive (K) to two lower plate parts (43) of a lower holding shaft (24). The plate parts (32, 43) are each produced from a fibre-reinforced composite material. The entire upper holding shaft (23) and also the entire lower holding shaft (24) preferably consist of parts produced from a fibre-reinforced composite material.
A knitting machine part comprises a plurality of tool guides, each for one knitting tool. Each tool guide has a hardened region. The majority of the hardened regions are formed to be integral without seams or joints which transition integrally into adjacent, non-hardened regions. At least one hardened region of the knitting machine part is formed by a non-integral region, in that a hardened, separate component is arranged there, which forms the non-integral hardened region. The component can be designed as an insert part and inserted in a receptacle recess. The integral regions are preferably formed by induction hardening of a knitting machine part which is not yet hardened, wherein a separate hardened component can be arranged in each insufficiently hardened region in order to provide a hardened, non-integral region.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and components for sewing, knitting, embroidery, warp
knitting, weft knitting, stitch bonding, braid crocheting,
quilting and interlacing machines for commercial purposes,
namely needles, needle boards, needle-like parts, needle
modules, knitting boards, knitting board cartridges,
closers, closer modules, guide needle modules and sinkers;
parts and components for tufting machines for commercial
purposes, namely needles, needle boards, needle-like parts,
knives, knife modules, reed fingers, reed finger modules,
grippers and gripper modules; parts and components for
felting machines for commercial purposes, namely felting
needles, needle boards, and needle-like parts. Needles and needle-like parts for sewing, knitting,
embroidery, warp knitting, weft knitting, stitch bonding,
braid crocheting, quilting and interlacing machines for
commercial purposes; needles and needle-like parts for
tufting machines for commercial purposes; needles and
needle-like parts for felting machines for commercial
purposes.
75.
METHOD AND KNITTING DEVICE FOR PLATING ON A CIRCULAR KNITTING MACHINE EQUIPPED WITH COMPOUND NEEDLES
The present invention describes a method and a knitting device for plating with compound needles on a circular knitting machine. At least two yarns are introduced into the hook region of a compound needle. A plate is moved in relation to a knock-over edge, which is arranged in an immovable manner on a cylinder, in such a way that the plate, by means of a guide means, introduces at least one of the yarns further in the direction of the needle shank into the hook region of the compound needle and in the process keeps the yarns separated. The plate furthermore moves in the longitudinal direction and vertical direction with respect to the knock-over edge, such that the guide means executes a movement that at least partially tracks at least one yarn.
D04B 35/06 - Aiguilles à piston (languette coulissante)
D04B 9/34 - Métiers circulaires pour le tricotage de trame avec des aiguilles mobiles indépendantes pour la production de tricots à dessins avec dessins de couleur par vanisage
The present invention relates to a device and to a method for handling harness elements. The device comprises a first holding element and at least one additional holding element for harness elements. The first holding element and the at least one additional holding element are configured to be moved cyclically between a provision device and a receiving device. At least the first holding element is configured in such a manner that it can execute at least a part of its movement between the provision device and the receiving device while the at least one additional holding element does not move.
The present invention relates to a device and a method for handling harness elements. A first retaining element is designed to be moved cyclically between a provision device and a receiving device. The first retaining element is arranged on a carrier device. According to the invention, an ejection element is also arranged on the carrier device for ejecting a harness element off the retaining element onto a sub-device of the receiving device. The first retaining element is preferably designed to execute its cyclical movement in a plane to which an axis is perpendicular.
The present invention relates to a device and method for handling weaving harness elements. The device according to the invention has at least one holding element for a weaving harness element. Arranged on the at least one holding element is a support surface for a weaving harness element, and the greater extent of the support surface defines a longitudinal direction and the shorter extent of the support surface defines a widthwise direction of the holding element. According to the invention, the at least one holding element is arranged so as to be pivotable about a first axis, which is arranged perpendicularly to the longitudinal direction of the holding element. In this way, a weaving harness element arranged on the support surface of the holding element can be moved from a receiving position to a draw-in position by pivoting the holding element about the first axis.
The invention relates to a device for handling harness elements, which is configured as a mobile unit. The device comprises a retainer for retaining a weaving reed, a retainer for retaining braids, a retainer for retaining stops and a retainer for retaining a thread group. According to the invention, the retainer for retaining the weaving reed is designed to receive a weaving reed displaceably arranged on the retainer.
The invention relates to a method and a device for the automated transport of harness elements. A device is provided having at least one rail and at least one rail carrier. The at least one rail carrier bears the weight force of the at least one rail, on which harness elements can be arranged so as to be displaceable in the longitudinal direction. The method is characterised in that the at least one rail carrier is displaced in the longitudinal direction of the rail relative to the at least one rail in order to allow harness elements arranged on the rail to be moved along the longitudinal direction of the rail.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts sold as components of knitting, warp knitting, weft knitting and stitch bonding machines for commercial purposes, namely, needles, needle boards, needle-like parts, needle modules, knitting boards, knitting board cartridges, closers, closer modules, guide needle modules and sinkers Needles and needle-like parts for knitting, warp knitting, weft knitting, and stitch bonding machines for commercial purposes
82.
Device and method for producing a carrier part having a plurality of fiber bundles
A device and a method for producing a carrier part having a plurality of fiber bundles. At least one fiber bundle strand is removed from a supply with a fiber bundle conveying unit and is conveyed into its own feed channel. A suction channel associated with each feed channel is fluidically connected thereto. An air flow is generated in the suction channel, and an end portion of the at least one fiber bundle strand is conveyed into the suction channel. By moving the at least one suction channel into a working position, the end portion of the at least one fiber bundle strand is free in a working region of the device. A needle unit having at least one needle can pick up the end portion in the working region and can pull or push it through a carrier part as the needle unit moves through the carrier part.
D05C 15/18 - Dispositifs d'alimentation ou de tension des fils
B29C 70/24 - Façonnage de matières composites, c.-à-d. de matières plastiques comprenant des renforcements, des matières de remplissage ou des parties préformées, p. ex. des inserts comprenant uniquement des renforcements, p. ex. matières plastiques auto-renforçantes des renforcements fibreux uniquement caractérisées par la structure des renforcements fibreux utilisant des fibres de grande longueur, ou des fibres continues orientées dans au moins trois directions formant une structure tridimensionnelle
D05C 17/02 - Articles implantés de poils ou touffes par piquage
B29C 70/08 - Façonnage de matières composites, c.-à-d. de matières plastiques comprenant des renforcements, des matières de remplissage ou des parties préformées, p. ex. des inserts comprenant uniquement des renforcements, p. ex. matières plastiques auto-renforçantes des renforcements fibreux uniquement comprenant des combinaisons de différentes formes de renforcements fibreux incorporés dans une matrice, formant une ou plusieurs couches, avec ou sans couches non renforcées
83.
STITCH-FORMING ELEMENT AND STITCH-FORMING TEXTILE MACHINE
Stitch-forming element (100) for a stitch-forming textile machine, the textile machine having a stitch-forming-element carrier with at least one guide channel for guiding at least one stitch-forming element (100), the stitch-forming element (100) having a longitudinal axis (102) and a vertical axis (104) and a first cutout (144) with a lower edge (115), an upper edge (117), an open first end (146) and a closed second end (148) for stitch forming, wherein the stitch-forming element (100, 142) has a second cutout (118) with a lower edge (124), an upper edge (126), an open first end (120) and a closed second end (122) for cleaning the at least one guide channel (132), and stitch-forming textile machine having a stitch-forming-element carrier with at least one guide channel, wherein the textile machine has at least one such stitch-forming element (100) and the at least one stitch-forming element (100) is guided with its second cutout (118) in the at least one guide channel.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Sewing machines; parts of sewing machines, in particular
needle plates, feed dogs, presser feet and knives for
overlock sewing machines. Sewing needles, needles for sewing machines.
A reed and a method for producing a reed. The reed has a multiplicity of dents, which are arranged in a width direction, forming interspaces each having a dent spacing. Each dent has two opposite end sections, at which the dents are respectively connected to a carrier and to the immediately adjacent dent or dents by an adhesive connection. In at least one end section, the dent has a plurality of a spacer studs, which are preferably produced by embossing. The spacer studs form a depression on the one, first side and, on the opposite, second side, form a projection having a stud outer surface. The sum of all the stud outer surfaces of the spacer studs of a single end section of a dent has a proportion of at most 15% of the total end section surface on this second side.
D03D 49/68 - Peignes ou peignes-battants non montés sur le battant
D03D 13/00 - Tissus caractérisés par la disposition particulière des fils de chaîne ou de trame, p. ex. avec fils de trame incurvés, avec fils de chaîne discontinus, avec fils de chaîne ou de trame en diagonale
The invention relates to a knitting machine needle (1), which comprises at least the following features: a hook (2) for forming stitches, which hook delimits the shaft (3) in the longitudinal direction (z) of the shaft (3) and which hook tapers into a hook tip (4), and a first drive portion (33) following the hook (2) in the longitudinal direction (z) of the shaft (3). The knitting machine needle (1) is characterized by a predetermined breakage portion (9) for separating the hook (2) from the first drive portion (33). The predetermined breakage portion (9) is formed by a portion of the shaft (3), which portion extends in the longitudinal direction (z). The predetermined breakage portion (9) is located wholly in a first shaft portion (10), which extends in the longitudinal direction (z) of the shaft (3) between the tip (4) of the hook (2) and the first drive portion (33). The invention further relates to a knitting system (15), which has at least one knitting machine needle (1) having a predetermined breakage portion (9).
Metal wire; steel wire, metallic card clothing wire, carding
wire, saw tooth wire for carding machines, doffer wire,
worker wire, stripping wire, transfer wire, intermediate
doffer wire [wires made of metal]. Parts and assemblies of carding machines, in particular
cards, saw-tooth wire, metallic card clothing, flexible card
clothing, card clothing elements consisting of crotchets or
needles, stationary carding elements, revolving flats with
flexible card clothing or with card wire; service tools for
the mounting of all-steel card clothing, in particular
winding devices for all-steel card clothing and saw tooth
wires being parts of carding machines; textile machinery
including carding machines and accessories for such
machines; card clothing, card wire and card rollers, all
being machine parts.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Sewing machines; parts of sewing machines, in particular
needle plates, feed dogs, presser feet and knives for
overlock sewing machines; special knives, namely knives for
end processing machines, knives for CAD cutting systems,
knives for cutting buttonholes [machine parts] and band
knives. Sewing needles, needles for sewing machines.
89.
Machine knitting tool, in particular machine knitting needle
A machine knitting tool and in particular a machine knitting needle has a shank extending in the longitudinal direction. The machine knitting tool has a stitch-forming portion directly adjacently to a front end and a drive portion directly adjacently to a rear end. At least in the drive portion, an underside of the shank does not have any indentations or recesses and extends along a plane. The shank in the drive portion forms at least one rib portion with a rib height, which is at most 1.1 mm. In addition, the shank in the drive portion forms at least one support elevation, which extends in the height direction beyond the rib height of the at least one rib portion and has an elevation height at its point of maximum height.
The invention relates to a tool module (10) having a module body (11), which has a contact surface (21) and an orienting structure (22). A fastening opening (29) and additionally at least one, preferably a plurality of additional openings (33, 34) extend through the contact surface (21). The area of one additional opening (33) or (34) is larger than, preferably considerably larger than, for example at least twice or three times as large as the cross-sectional area of the fastening opening (29). Thus, a module body (11) is provided, by means of which an increased operating speed of the textile machine can be achieved.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Teile und Baugruppen für Näh-, Strick-, Stick-, Kettenwirk-, Schusswirk-, Nähwirk-, Bortenhäkel-, Stepp- und Verkettungsmaschinen für gewerbliche Zwecke, nämlich Nadeln, Nadelplatten, nadelförmige Teile, Nadelmodule, Wirkplatinen, Wirkplatinenmodule, Schieber, Schiebermodule, Lochnadelmodule und Sinkermodule; Teile und Baugruppen für Tuftingmaschinen für gewerbliche Zwecke, nämlich Nadeln, Nadelplatten, nadelförmige Teile, Nadelmodule, Messer, Messermodule, Rietfinger, Rietfingermodule, Greifer und Greifermodule; Teile und Baugruppen für Filzmaschinen für gewerbliche Zwecke, nämlich Filznadeln, Nadelplatten und nadelförmige Teile. Nadeln und nadelförmige Teile für Näh-, Strick-, Stick-, Kettenwirk-, Schusswirk-, Nähwirk-, Bortenhäkel-, Stepp- und Verkettungsmaschinen für gewerbliche Zwecke; Nadeln und nadelförmige Teile für Tuftingmaschinen für gewerbliche Zwecke; Nadeln und nadelförmige Teile für Filzmaschinen für gewerbliche Zwecke.
92.
DEVICE FOR LOOP-FORMING, SINKER MEANS AND METHOD FOR LOOP FORMING
A device (1), a sinker means (5) and a method for loop -forming are claimed. The device (1) comprises: • a cylinder (2) with first grooves (3) for needles (4), - which are accommodated in a first groove (3), - whereby the needles (4) comprise a loop forming section, • a sinker ring (27) with second grooves (15) for sinker means (5), whereby the sinker means (5) comprise: - an actuating section (12), - a loop forming section (7), - whereby the loop forming section (7) comprises an opening (11), - and whereby the sinker means (5) are accommodated in one single second groove (15). New and inventive is that the opening (11) is delimited in the width direction (x) by two side faces (23) and in that the loop forming section of the needle (4) is movably disposed between the two side faces (23) of the opening (11).
(1) Wires of common metal; wires of common metal for use with carding machines, namely, steel wire, metallic card clothing wire, carding wire, saw tooth wire for carding machines, doffer wire, worker wire, stripping wire, transfer wire, and intermediate doffer wire [wires made of metal].
(2) Parts and assemblies of carding machines, in particular cards, saw-tooth wire, metallic card clothing, flexible card clothing, card clothing elements consisting of crotchets or needles, stationary carding elements, revolving flats with flexible card clothing or with card wire; service tools for the mounting of all-steel card clothing, in particular winding devices for all-steel card clothing and saw tooth wires being parts of carding machines; textile machinery, namely carding machines and accessories for such carding machines, namely card clothing, card wire and card rollers, all being parts of carding machines.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
(1) Sewing machines; parts of sewing machines, in particular needle plates, feed dogs, presser feet and knives for overlock sewing machines.
(2) Sewing needles, needles for sewing machines.
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Sewing machines; parts of sewing machines, in particular needle plates, feed dogs, presser feet and knives for overlock sewing machines Sewing needles, needles for sewing machines
96.
Device and method for handling fragments of a broken needle
A device (40) and a method is described for handling fragments (10) of a broken needle (11), for example in the context of a needle exchange of a broken needle (11) for a new needle (17). The fragments (10) of the broken needle (11) are arranged in a container (16) in a predetermined position. An image (32) of the fragments (10) of the broken needle (11) is then recorded with the aid of a camera (23). The recorded image (32) is stored for documentation (32) at at least one storage location and/or analysed as to whether all the fragments (10) of the broken needle (11) are present. After recording the image (32), the container (16) is closed in order to avoid the fragments (10) of the needle (11) being lost away from the sewing workstation.
B65D 85/24 - Réceptacles, éléments d'emballage ou paquets spécialement adaptés à des objets ou à des matériaux particuliers pour objets incompressibles ou rigides en forme de baguette ou tubulaires pour aiguilles, clous ou petits objets de forme allongée similaires
D05B 81/00 - Machines à coudre dans lesquelles sont intégrés des dispositifs servant à d'autres travaux que le piquage, p. ex. pour souffler de l'air, pour meuler
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Parts and assemblies of knitting, warp knitting, weft
knitting, stitch-bonding, galon crocheting, and linking
machines for forming and transferring loops, in particular,
latch needles, bearded needles, slider needles, hook
needles, cutting needles; system components for textile
machines such as sinkers, guide needles as well as needle
guides and needle-like parts for actuating and controlling
needles and sinkers, as well as receptacles, carriers and
holders of needles; system components for textile machines,
in particular, needle cylinders, dial and sinker disks,
needle beds and strips therefor, needle and guide bars and
needle modules, drive belts, thread-guide and
thread-delivery elements, lock components, fabric take-offs,
brushes, drives, cutting knifes; drawing-in machines for
warp knitting and raschel knitting; transport and handling
system for exchange and installation of warp and fabric
beams, knitting tools and other machine components; parts
and assemblies of sewing, embroidering, stitch-bonding and
quilting machines, namely needles, hook needles, latch
needles, needle holders and needle receptacles, needle
guides, grippers, needle plates and miscellaneous
replacement parts; parts and assemblies of machines for
production, strengthening and structuring of fiber batts and
felts, namely felting and structuring needles, needle
boards, stripper plates and brush belts; parts for waterjet
hydroentanglement systems, in particular jet perforated
strips, jet perforated bands, nozzle strips, perforated
plates; carding and spinning machines; parts and assemblies
of carding machines, in particular cards, saw-tooth wire,
metallic card clothing, flexible card clothing, card
clothing elements comprising crotchets or needles,
stationary carding elements, revolving flats with flexible
card clothing or with card wire; service tools for the
mounting of card clothing, in particular winding devices for
card clothing and saw tooth wires; carding sets, carding
steel band sets; spinning beams; machines for loading needle
boards, as well as transport and handling systems for
exchange and installation of machine elements and
components, for example, needle boards, stitch plates,
stripper plates and fabric beams, machines and parts thereof
for hydroentangling knitted and woven textiles and
non-wovens; components of tufting machines, namely needles,
grippers, knives, reed fingers, reed plates in single parts
and in modular form; industrial and manual blanking
apparatus, as well as components thereof, in particular for
machining of foils, for example of sintered or insintered
ceramic, plastic material, metal, also coated; blanking
tools, as well as components for blanking tools, namely
punches, dies and guide bushings, needles, test tips; parts
and assemblies of weaving machines, namely heald frames,
frame staves, lateral supports, heald carrier rods, guide
attachments for frame staves, healds, leno healds, reeds,
cord boards, harness cords, jacquard weights, jacquard
springs, warp stop motions and warp stop motion plates,
shuttles, split selvedge apparatus, edge binders; shedding
apparatus, namely dobbies, cam motion dobbies and jacquard
machines, as well as components and assemblies thereof,
namely frame pulleys, bearers, clutch devices, cams,
eccentrics, boards, knives, stroke-measuring devices and
programming devices; weaving preparation machines, namely
drawing- in machines, drawing- in machines for jacquard
machines, reed drawing- in machines, warp linking machines,
as well as transport and handling systems for exchange and
installation of the loom harness, fabric beams and other
machine components; checking devices, being components or
accessories of textile machines; machines for quality
monitoring of textile fabrics; finishing machines; machines
and parts thereof for the production of hybrid textiles
consisting of knits, felts, multiaxial layers and woven
fabrics, 3D-felts, 3D-knits. Needles; knitting, warp knitting, weft knitting,
stitch-bonding, galon crocheting, and linking machine
needles, in particular, latch needles, bearded needles, hook
needles, guide needles and needle-like parts for actuating
and controlling needles and sinkers; needles for sewing,
knitting, stitch-bonding, linking and quilting machines;
sewing needles, hook needles, latch needles, perforating
needles, puncture and sewing needles for shoe manufacturing;
needles for the production, strengthening and structuring of
non-wovens and felts; perforating needles; needles and
needle-shaped parts for tufting machines in single parts and
in modular form, checking needles. Services in the fields of science and technology as well as
related research and development services, technological
product consulting and customer-specific developments, in
particular with regard to the aforementioned goods.
The invention relates to a latch needle (100) for a stitch-forming textile machine, the latch needle (100) comprising a needle shaft (106) and a needle latch (110), which has a back (122), the needle shaft (106) having a slot (116) for accommodating the needle latch (110) and having a first contact portion (128) design in accordance with the back (122), the needle latch (110) being mounted on the needle shaft (106) for pivoting between an open position and a closed position about a pivot axis (120), and the back (122) lying against the first contact portion (128) in the open position, characterized in that the latch needle (100) has a damping spring (112) designed in accordance with the back (122) and/or the first contact portion (128), in order to damp contacting of the back (122) of the needle latch (110) against the first contact portion (128) in the open position.
A non-shedding hybrid nonwoven web comprised of 99% by mass of functional material(s) co-mingled with the filaments. High level of particle retention within the fabric is provided without the aid of adhesives, binders, adhesive polymers, or post processes. This composite web has a multi-layered structure with a uniform distribution of sorptive particles and desired opposed color contrast on each side. The process includes providing two converging streams of blown polymeric filaments, passive feed of functional material(s) in between the filament streams, and collecting the hybrid webs.
D04H 1/407 - Non-tissés formés uniquement ou principalement de fibres coupées ou autres fibres similaires relativement courtes à partir de voiles ou couches composés de fibres ne possédant pas des propriétés cohésives réelles ou potentielles contenant des substances absorbantes, p. ex. du charbon actif
D04H 1/56 - Non-tissés formés uniquement ou principalement de fibres coupées ou autres fibres similaires relativement courtes à partir de voiles ou couches composés de fibres ne possédant pas des propriétés cohésives réelles ou potentielles par soudage des fibres ensembles, p. ex. par fusion partielle ou dissolution en association avec la formation de la fibre, p. ex. suivant immédiatement l'extrusion des fibres en brin
D04H 3/16 - Non-tissés formés uniquement ou principalement de fils ou de matériaux filamenteux similaires de bonne longueur caractérisés par la méthode de renforcement ou de consolidation avec liages produits par soudage entre fils thermoplastiques ou filaments avec liages entre filaments thermoplastiques produits en relation avec la formation des filaments, p. ex. suivant immédiatement l'extrusion
B01D 39/16 - Autres substances filtrantes autoportantes en substance organique, p. ex. fibres synthétiques
26 - Articles de fantaisie; mercerie; fleurs artificielles, cheveux postiches
Produits et services
Parts and assemblies of textile machines, in particular
needles, knitting needles, system parts of knitting
machines, guide needles, sinkers, sliders and needle-like
parts. Knitting needles and warp knitting needles; latch needles
and compound needles; sliders (knitting accessories).
