Abrégé

A thermal-loss-reduced and temperature-homogenization-effect-enhanced oven includes a liftable front cover, a fixed rear cover, an oven top, and an operation panel. The liftable front cover has a bottom positionable on a first temperature barrier silicon strip to reduce heat conducted from the oven top to an operation area of the operation panel to reduce a thermal loss of the oven top, and to effectively reduce an external environmental influence. The second temperature barrier silicon strip reduces a cover top heat release gap between the liftable front cover and the fixed rear cover to reduce a thermal loss and an external environmental influence of the oven, and an elastic restoration force of the second temperature barrier silicon strip reduces deformation between the liftable front cover and the fixed rear cover caused by a high temperature to thereby avoid excessive tightness in closing the oven cover.

Classes IPC  ?

• A47J 37/06 - RôtissoiresGrilsGrille-sandwiches

Produits et services

(1) Barbecues and grills; portable stoves

Produits et services

Barbecues and grills; Portable stoves

Abrégé

A heater structure includes a heater body including a burner connected to a valve switch. A pilot fire assembly is covered by a protective cover that has ventilation holes. A switch unit includes an ignition switch, a shut-down switch, an ignition operator, and a shut-down operator. The ignition operator and the shut-down operator are structured to provide a swingable arrangement. The ignition operator may be operated to contact and press the fuel gas valve rod and the ignition switch to open the valve switch for supply fuel gas to the burner and to activate an ignition circuit to cause successive shootings of an ignition pin of the pilot fire assembly to set a flame on the burner. The shut-down operator is operated to contact and press the shut-down switch, so as to cut off a signal of the thermocouple and thus cut off the supply of the fuel gas.

Classes IPC  ?

• F23D 14/12 - Brûleurs à rayonnement
• F24H 9/20 - Disposition ou montage des dispositifs de commande ou de sécurité
• F23N 1/00 - Régulation de l'alimentation en combustible
• F23D 14/76 - Dispositifs de sécurité, p. ex. fonctionnant en cas d'interruption de l'alimentation en gaz protégeant la flamme et des éléments du brûleur
• F23K 5/00 - Alimentation en d'autres combustibles ou distribution d'autres combustibles pour les appareils à combustion

Produits et services

Blaze guards to be used as a medium for safety burning device, namely, tempered framed glass, not for building

Produits et services

liquid fuels lanterns for lighting, namely, liquid fuel lanterns flame guard to be used as a medium for fire pits namely, tempered glass frame, not for building

Abrégé

Disclosed is a temperature homogenization, protection, and grease guide structure of a barbecue grill, including at least one burner, a grate, and a grease guide and temperature barrier board. The burner includes a heat generation section and is arranged in an inclined, upward-facing manner in a barbecue grill. The grate is arranged in a top opening of the barbecue grill. The grate includes ribs that are provided with at least one temperature homogenization protection section, which is located above and corresponds to the heat generation section. The grease guide and temperature barrier board is configured in an M-shape and is arranged below the burner.

Classes IPC  ?

• A47J 37/04 - Appareils à rôtir avec supports mobiles pour les aliments ou avec instruments de chauffage mobilesBroches
• A47J 37/07 - Dispositifs pour faire des grillades en plein airBarbecues

Produits et services

candles; perfumed candles; tapers; artistic candles. fireplaces; wood burning cooking stoves; cooking stoves; stationary fire pit; portable fire pits. candlesticks; candlesticks of precious metal; candlesticks not of precious metal; candle extinguishers and candlesticks not of precious metal; candle extinguishers and candlesticks of precious metal.

Produits et services

candles; perfumed candles; tapers; artistic candles. fireplaces; wood burning cooking stoves; cooking stoves; stationary fire pit; portable fire pits. candlesticks; candlesticks of precious metal; candlesticks not of precious metal; candle extinguishers and candlesticks not of precious metal; candle extinguishers and candlesticks of precious metal.

Produits et services

(1) Barbecue grills; heaters, namely kerosene heaters and portable electric heaters; hot water heaters.

Abrégé

An overfill prevention device which includes a first tubular member, a cylindrical piston fitted within the first tubular member, a second tubular member having a cylindrical recess open, a plug arranged within the second tubular member, a float rod having a cam plate, a float connected with a lower end of the float rod, a valve body having a lower end engaged with the first tubular member, a pinion pivotally connected to the second tubular member by the pin, a toothed rack meshed with the pinion and engaged with the second tubular member, a control rod having an upper end extending into the valve body and a lower end secured to the toothed rack, a first magnet mounted at the upper end of the control rod, and a gauge mounted on the valve body and provided with a second permanent magnet and a needle operatively connected with the second magnet.

Classes IPC  ?

• F16K 31/24 - Moyens de fonctionnementDispositifs de retour à la position de repos actionnés par un fluide et actionnés par un flotteur commandant une soupape de levage par l'intermédiaire d'une transmission dont l'enchaînement des pièces relie un seul flotteur à une seule soupape

Abrégé

A gas meter is mounted between vertical and horizontal branch tubes of a gas canister valve and has an indication pointer driven by a magnetic block that is movable inside the valve to indicate a residual quantity of gas inside the canister. The gas meter includes a casing that is magnetically non-conductive and forms at a top edge of a back thereof an inverted slope surface, an upper clamp extending from opposite sides of the inverted slope surface in an upward direction to clamp the vertical branch tube, and a side clamp engageable with the horizontal branch tube. The back of the meter casing is recessed at a location opposite to and interfering with an outer top edge of an enclosure for the magnetic block to form a fitting groove that corresponds to the top edge of the enclosure.

Classes IPC  ?

• F16K 37/00 - Moyens particuliers portés par ou sur les soupapes ou autres dispositifs d'obturation pour repérer ou enregistrer leur fonctionnement ou pour permettre de donner l'alarme

Abrégé

An infrared barbecue grill which includes a body, a pair of infrared burners, a first shield member, a first baffle installed on the outer edge of the first shield member, a second shield member, a second baffle having a first edge installed on the outer edge of the second shield and having a lug, a grate placed on the body, a heat dissipator arranged on a bottom of the body, and a water basin mounted under the heat dissipator, whereby the baffles will guide the heat through the holes thereon to the region of the grate where the infrared ray emitted from the infrared burners cannot cover, the lug will prevent the rear infrared burner from emitting infrared rays directly to the user, and the water basin will provide water vapor to add moisture to the food on the grate thereby making the food juicy and delicious to eat.

Classes IPC  ?

• A47J 37/00 - Cuisson au fourRôtissageCuisson au grilFriture

Produits et services

Electric kitchen machines, namely, electronically operated mixing appliances; electric kitchen tools namely, knives, hand mixers, egg beaters, hand blenders, blenders and can openers. Barbecue grills; heaters; hot water heaters; kitchen machines (gas) for cooking; kitchen range; kitchen ranges (oven); kitchen stoves; gas barbecue grills; patio heater and cooking accessories (namely cooking pan) cooking pot; griddles; steak grids; paella pan woks; gas lights; electric cookers; refrigerators; electric boilers; dish heaters; electric grilling apparatus; faucets; filters being parts of household installations; mixing valves (faucets); filters for use with apparatus for water supply; cooling apparatus; ice makers; display cabinets having a refrigerated display area; drinking water supply apparatus; apparatus for purifying water; machines for purifying water; apparatus for filtering water; water heaters; electrically heated hot water tanks; gas operated apparatus for cooking; valves (temperature sensitive controls for automatically operating-) (parts of heating installations); cooking ovens; fireplaces (domestic); charcoal stoves; kitchen ranges; ignition apparatus for gas fires; stop valves for regulating gas; oil vapor extraction installations; range hoods with metal exterior covering; domestic ovens; frying pans (electric-); installations for the roasting of meat strings; electric ovens (other than for laboratory use); gas ovens; heaters; electric heaters; electric heating appliances, other than for medical (therapeutic) use; gas infrared heaters; industrial heaters; heat exchangers, other than parts of machines; gas infrared burners; gas boilers; solar collectors (heating); range hoods; indoor dual fuel ranges; dishwashers; sinks; disposers; cabinets; counters; indoor and outdoor heaters; indoor and outdoor water heaters for domestic use; indoor and outdoor water heaters for commercial use; indoor and outdoor water heaters for industrial use; indoor gas ranges; cup warmers, coffee makers, microwave ovens, toaster ovens, waffle makers, rice cookers and hot water urns. Kitchen cabinets.

Produits et services

GAS-FIRED INFRA-RED HEATERS; BURNERS, NAMELY, GAS BURNERS FOR COMMERCIAL USE, INDUSTRIAL USE, AND DOMESTIC USE; BARBECUE GAS GRILLS; GAS PATIO HEATERS; ELECTRIC PATIO HEATERS; ELECTRIC GRIDDLES; ELECTRIC PAELLA PAN WOKS; GAS LIGHTS; KEROSENE HEATERS, GAS PATIO HEATERS, PORTABLE ELECTRIC HEATERS; HOT WATER HEATERS; KITCHEN MACHINES, NAMELY GAS STOVES FOR COOKING; GAS KITCHEN RANGES, ELECTRIC KITCHEN RANGES; KITCHEN OVENS, NAMELY, DOMESTIC OVENS, COOKING OVENS, GAS COOKING OVENS, AND ELECTRIC COOKING OVENS; GAS KITCHEN STOVES, ELECTRIC KITCHEN STOVES; INDOOR AND OUTDOOR HEATERS, NAMELY ELECTRIC SPACE HEATERS, GAS PATIO HEATERS, GAS STOVE, NAMELY, SPACE HEATER FOR HOUSEHOLD USE; INDOOR AND OUTDOOR WATER HEATERS FOR DOMESTIC USE; INDOOR AND OUTDOOR WATER HEATERS FOR COMMERCIAL USE; INDOOR AND OUTDOOR WATER HEATERS FOR INDUSTRIAL USE; INDOOR GAS RANGES; RANGE HOODS; INDOOR DUAL GAS AND ELECTRIC FUEL RANGES; SINKS
