The present invention relates to a reusable system for levelling tiles comprising a hood having a bottom surface (11), gripping means (12) and a threaded hole (13) for mounting a flange (2). The flange comprises a plastic body (2a) provided with a mounting stud (21) for mounting on a hood (1) and an indicator (24) for indicating the rotational position of the flange (2), and a metal insert (2b). The metal insert comprises a rod (25) inseparably connected to the body (2a) of the flange (2), side wings (27) forming the means for supporting the bottom surface of the tiles (B) to be levelled on the flange, and a notch (28), defined in an area next to the side wings (27) and provided to break the rod (25) by twisting.
E04F 15/02 - Revêtements de sol composés d'un certain nombre d'éléments semblables
E04F 21/22 - Outillage pour travaux de finition des bâtiments pour la pose des revêtements de sols faits d'éléments individuels, p. ex. pinces de planchers
A manually actuated ceramic cutter includes a work table mounted on a support structure, and a tool-carrier head provided with a cutting tool and with an actuating handle, which tool-carrier head can be moved along longitudinal guide means comprising a single longitudinal guide disposed on one side of the tool-carrier head, the guide being offset from a vertical plane coinciding with the longitudinal path of the cutting tool during the scoring of the ceramic pieces and being attached by the ends thereof to respective sides of supports attached at opposite ends of the support structure. The longitudinal guide includes longitudinal tracks for moving a sliding piece, the side of which piece is provided with a horizontal shaft for rotating the tool-carrier head in a vertical plane.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
A monoguide manual cutter is provided, which can comprise a base, a guide arranged longitudinally above the base, a carriage that can be moved along said guide and a tool holder mounted on the carriage and having a handle, a roller for marking a cutting line on the ceramic part and a blank holder for breaking said ceramic part along the cutting line. The aluminium extrusion guide comprises a cross-section with a narrow lower portion and a wider upper portion comprising longitudinal tracks for supporting and linearly moving rolling means of the carriage. The configuration of the guide can make it easier for the operator to view the roller while using the cutter.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
The invention relates to a monoguide manual cutter that comprises a base (1), a guide (2) arranged longitudinally above the base, a carriage (3) that can be moved along said guide (2) and a tool holder (4) mounted on the carriage (3) and having a handle (42), a roller (43) for marking a cutting line on the ceramic part and a blank holder (44) for breaking said ceramic part along the cutting line. The aluminium extrusion guide (2) comprises a cross-section with a narrow lower portion (21) and a wider upper portion (22) comprising longitudinal tracks for supporting and linearly moving rolling means of the carriage (3). The configuration of the guide (2) makes it easier for the operator to view the roller (43) while using the cutter.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
The invention relates to a manually actuated ceramic cutter comprising a work table (1) mounted on a support structure (5), and a tool-carrier head (2) provided with a cutting tool (21) and with an actuating handle (22), which tool-carrier head can be moved along longitudinal guide means comprising a single longitudinal guide (3) disposed on one side of the tool-carrier head (2), the guide being offset laterally from a vertical plane coinciding with the longitudinal path of the cutting tool (21) during the scoring of the ceramic pieces and being attached by the ends thereof to respective sides of supports (51) attached at opposite ends of the support structure (5). The longitudinal guide (3) comprises longitudinal tracks (31, 32) for moving a sliding piece (4), the side of which piece is provided with a horizontal shaft (41) for rotating the tool-carrier head (2) in a vertical plane.
B26D 1/04 - Coupe d'une pièce caractérisée par la nature ou par le mouvement de l'élément coupantAppareils ou machines à cet effetÉléments coupants à cet effet comportant un élément qui ne suit pas le mouvement de la pièce ayant un élément coupant se déplaçant linéairement
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
E04F 21/00 - Outillage pour travaux de finition des bâtiments
The present invention relates to a protective device for ceramic pieces, said device suitable for resting on the upper surface of at least two ceramic pieces (40, 41) and which forms a bearing surface for a tightening element (204, 305) of a spacer-leveller device (20, 30) for ceramic pieces. The protective device comprises: a lower bearing surface (101) on the ceramic pieces (40, 41) to be installed; an upper surface (102) comprising a first circular track (106) for possible bearing of a first threaded tightening element (204) of a first spacer-leveller device (20); a second diametrical track (109), forming a possible bearing surface, with the possibility of longitudinal displacement, for a second tightening element (305), by way of a wedge, of a second spacer-leveller device (30); and a lateral surface (103) with projections (104) for manually holding the protective device (10).
E04F 21/00 - Outillage pour travaux de finition des bâtiments
E04F 15/08 - Revêtements de sol composés d'un certain nombre d'éléments semblables uniquement en pierre ou en matériau analogue, p. ex. bétonRevêtements de sol composés d'un certain nombre d'éléments semblables en verre
E04F 21/18 - Outillage pour travaux de finition des bâtiments pour la pose des dalles en carreaux muraux ou des plaques de plafond
10.
CUTTING DEVICE FOR MANUAL CERAMIC-CUTTING MACHINES
The invention relates to a cutting device for manual ceramic-cutting machines, which comprises a support (1) provided with: a vertical hole (11) that receives a first end of a bar (21) of a cutting tool (2), the front face (26) of said bar being provided with at least one row of recesses (27) spaced apart vertically; and a horizontal hole (12) that receives a handle (3) and a stem (4) capable of moving longitudinally between a front position for locking the cutting tool (2) and a rear position for releasing the cutting tool; the stem (4) comprising, at its front end, at least one projection (42) which, in the front position for locking the cutting tool, is accommodated in one of the recesses (27) on the front face (26) of the bar (21) of the cutting tool (2).
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
The present invention relates to a cutting device for manual ceramic cutters. Disclosed is a cutting device for manual ceramic cutters, which comprises a support (1) provided with a vertical hole (11) for mounting a cutting tool (2), and a horizontal hole (12) in which are mounted a handle (3) and a rod (4) for attaching the cutting tool (2). The cutting tool (2) comprises a bar (21) that has at a first end (22) an inclined ramp (27) that facilitates the initial mounting thereof in the support (1), moving the rod (4) backwards and compressing a spring (5) for pushing the rod (4). The front face of the bar (21) comprises a longitudinal groove (26), and the rod (4) comprises a front appendage (42) accommodated in the longitudinal groove (26), immobilising the cutting tool in the support when pressed by the handle (3).
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
The present invention relates to a guiding device for large-format manual cutters, said device consisting of a guide (1) that comprises: on its top surface (11) an intermediate recessed portion (111) delimited by a base (112) and by longitudinal rails (113a, 113b) for movement of a manual cutter (3); and, on opposite sides of its bottom surface, first support means (121, 122) for supporting the guide (1) on the part (P) to be cut and a longitudinal recess (123) for receiving lever suction cups (2) which form second means for supporting and securing the guide (1) on the part (P) to be cut. The longitudinal rails (113a, 113b) are arranged between the first and the second support means; and the first support means (121, 122) are arranged between the cutting tool (31) and the suction cups (2) which form the second support means.
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
The invention relates to a manual long-length ceramic cutter, comprising: a supporting base (1) for the piece to be cut; at least one longitudinal guide (2, 2a, 2b) installed above the base (1); and a head (3) for scoring and separating the ceramic pieces, operable manually and installed on at least one guide (2, 2a, 2b) that can move longitudinally. The cutter comprises at least one mobile support (4, 4a, 4b), having: an upper end (41) installed on the respective longitudinal guide (2, 2a, 2b), and a lower end (42) installed on at least one longitudinal track (11a, 11b) of the base (1), wherein said support can move longitudinally along the guide (2, 2a, 2b) and the corresponding track (11a, 11b), preventing the guide (2, 2a, 2b) from bending during the scoring and separation of short-length ceramic pieces.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
Disclosed is a frame for machines for cutting ceramic pieces, which comprises a support structure of a guide (G) for longitudinally moving a cutting head (C), which comprises: a central aluminium beam (1) and two lateral aluminium beams (2a, 2b), the beams having a tubular cross-section and being parallel and connected at opposite ends by means of respective steel end plates (3a, 3b); a detachable table formed by two aluminum profiles (4a, 4b) mounted on the central beam (1) and the lateral beams (2a, 2b); and steel corner pieces (5) attached to the support structure, there being mounted to the corner pieces respective pairs of foldable legs (6) provided with locking means (9) for locking in an unfolded position, respective reinforcing cross beams (10) for carrying shock-absorbing elements (11) and rear wheels (12) for transporting in a folded position.
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
E04F 21/00 - Outillage pour travaux de finition des bâtiments
E04F 21/22 - Outillage pour travaux de finition des bâtiments pour la pose des revêtements de sols faits d'éléments individuels, p. ex. pinces de planchers
17.
CUTTING DEVICE FOR MANUAL CERAMIC-CUTTING MACHINES
The invention relates to a cutting device for manual ceramic-cutting machines, which comprises a support (1) provided with: a vertical hole (11) that receives a first end of a bar (21) of a cutting tool (2), the front face (26) of said bar being provided with at least one row of recesses (27) spaced apart vertically; and a horizontal hole (12) that receives a handle (3) and a stem (4) capable of moving longitudinally between a front position for locking the cutting tool (2) and a rear position for releasing the cutting tool; the stem (4) comprising, at its front end, at least one projection (42) which, in the front position for locking the cutting tool, is accommodated in one of the recesses (27) on the front face (26) of the bar (21) of the cutting tool (2).
B28D 1/24 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles au moyen de disques de découpage
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
Disclosed is a cutting device for manual ceramic cutters, which comprises a support (1) provided with a vertical hole (11) for mounting a cutting tool (2), and a horizontal hole (12) in which are mounted a handle (3) and a rod (4) for attaching the cutting tool (2). The cutting tool (2) comprises a bar (21) that has at a first end (22) an inclined ramp (27) that facilitates the initial mounting thereof in the support (1), moving the rod (4) backwards and compressing a spring (5) for pushing the rod (4). The front face of the bar (21) comprises a longitudinal groove (26), and the rod (4) comprises a front appendage (42) accommodated in the longitudinal groove (26), immobilising the cutting tool in the support when pressed by the handle (3).
B28D 1/24 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles au moyen de disques de découpage
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
The present invention relates to a protective device for ceramic pieces, said device suitable for resting on the upper surface of at least two ceramic pieces (40, 41) and which forms a bearing surface for a tightening element (204, 305) of a spacer-leveller device (20, 30) for ceramic pieces. The protective device comprises: a lower bearing surface (101) on the ceramic pieces (40, 41) to be installed; an upper surface (102) comprising a first circular track (106) for possible bearing of a first threaded tightening element (204) of a first spacer-leveller device (20); a second diametrical track (109), forming a possible bearing surface, with the possibility of longitudinal displacement, for a second tightening element (305), by way of a wedge, of a second spacer-leveller device (30); and a lateral surface (103) with projections (104) for manually holding the protective device (10).
The invention relates to an electric saw comprising: a frame (2) mounted on a base (1), a cutting head (3) mounted on the frame by using a rotating shaft (4) in the vertical direction and an adjustable stop (5) limiting the descent of the head and the cutting depth. The adjustable stop (5) comprises: a rod (51) mounted in a through manner, with the possibility of longitudinal sliding, in a passage (53) defined in the cutting head (3) and facing a fixed stop (21) defined in the frame (2); and a screw (54) for lateral tightening and fixing of the rod (51) inside the passage (53). The screw (54) comprises an actuation knob (55) and is threadedly mounted in a hole defined in the cutting head (3) and leading into the mounting passage (53) of the rod (51).
B23D 45/04 - Machines à scier ou dispositifs de sciage à lames circulaires ou à disques à friction la lame circulaire ou la pièce à scier étant portée par un levier à pivot
B23D 47/02 - Machines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers des bâtisMachines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers d'agencements de guidage de la table de travail ou du chariot porte-scie
The present invention relates to a guiding device for large-format manual cutters, said device consisting of a guide (1) that comprises: on its top surface (11) an intermediate recessed portion (111) delimited by a base (112) and by longitudinal rails (113a, 113b) for movement of a manual cutter (3); and, on opposite sides of its bottom surface, first support means (121, 122) for supporting the guide (1) on the part (P) to be cut and a longitudinal recess (123) for receiving lever suction cups (2) which form second means for supporting and securing the guide (1) on the part (P) to be cut. The longitudinal rails (113a, 113b) are arranged between the first and the second support means; and the first support means (121, 122) are arranged between the cutting tool (31) and the suction cups (2) which form the second support means.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
C03B 33/02 - Découpe ou fendage des feuilles de verreDispositifs ou machines à cet effet
B28D 1/04 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par sciage avec des lames de scie circulaires ou des disques de scie
B23D 1/00 - Machines à raboter ou à mortaiser taillant par déplacement relatif de l'outil et de la pièce à usiner selon une direction horizontale uniquement
B23D 47/02 - Machines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers des bâtisMachines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers d'agencements de guidage de la table de travail ou du chariot porte-scie
B23D 1/02 - Machines à raboter ou à mortaiser taillant par déplacement relatif de l'outil et de la pièce à usiner selon une direction horizontale uniquement par déplacement du porte-pièce
B23D 1/04 - Machines à raboter ou à mortaiser taillant par déplacement relatif de l'outil et de la pièce à usiner selon une direction horizontale uniquement par déplacement du porte-pièce l'outil étant supporté uniquement par un côté du banc
The invention relates to a manual long-length ceramic cutter, comprising: a supporting base (1) for the ceramic piece to be cut; longitudinal guides (2a, 2b) installed above the base (1); and a head (3) for scoring and separating the ceramic pieces, operable manually and installed on the guides (2a, 2b) which can move longitudinally. The cutter comprises mobile supports (4a, 4b) having an upper end (41) installed on the respective longitudinal guide (2a, 2b) and a lower end (42) installed on a longitudinal track (11a, 11b) of the base (1), said mobile supports (4a, 4b) being located behind the head (3) and capable of moving longitudinally, preventing the guides (2a, 2b) from bending during the scoring and separation of short-length ceramic pieces.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
B28D 7/00 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe
The invention relates to a manual long-length ceramic cutter, comprising: a supporting base (1) for the piece to be cut; at least one longitudinal guide (2, 2a, 2b) installed above the base (1); and a head (3) for scoring and separating the ceramic pieces, operable manually and installed on at least one guide (2, 2a, 2b) that can move longitudinally. The cutter comprises at least one mobile support (4, 4a, 4b), having: an upper end (41) installed on the respective longitudinal guide (2, 2a, 2b), and a lower end (42) installed on at least one longitudinal track (11a, 11b) of the base (1), wherein said support can move longitudinally along the guide (2, 2a, 2b) and the corresponding track (11a, 11b), preventing the guide (2, 2a, 2b) from bending during the scoring and separation of short-length ceramic pieces.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
B28D 7/00 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe
A system for the levelling of floor tiles, comprising: a separation post incorporating: a base component, a separator component and a threaded shaft; and a threaded cap with: a hollow dome-shaped body, a lower cylindrical component, an upper hub with a central female thread for the assembly thereof on said threaded shaft, and a number of lateral openings separated by a plurality of ribs with a substantially U-shaped structural cross-section, and comprising: —a smooth external web, with no protruding wings or extensions, of increasing width in a downward direction toward a first lateral end with a curved concave profile, —a first wing and a second wing that extend toward the interior of the cap from lateral ends of the web of the ribs and forming ergonomical surfaces for exerting pressure on the cap in the direction of tightening and loosening of the cap.
E04F 21/22 - Outillage pour travaux de finition des bâtiments pour la pose des revêtements de sols faits d'éléments individuels, p. ex. pinces de planchers
27.
Locking mechanism for folding chassis of electric cutting machines
A locking mechanism for the folding chassis of electric cutting machines. The chassis (1) comprises: a supporting base (11), a tilting arm (12), and an end arm (13) bearing wheels (14) that are collapsible with respect to a principal arm (10) between a folded and an unfolded position of the chassis. The locking mechanism (2) is installed on the tilting arm (12) and comprises: a locking clip (21) capable of being turned manually between an operative position for the locking of the chassis (1) wherein it is coupled with a number of locking rods (112, 113), and an unlocked position of the chassis (1); a manually displaceable trigger for the retaining of the locking clip in the operational position or the free position; and an elastic element that tends to displace the locking clip (21) and the trigger (22) towards the unlocked position of the chassis (1).
F16B 2/06 - Brides ou colliers, c.-à-d. dispositifs de fixation dont le serrage est effectué par des forces effectives autres que la résistance à la déformation inhérente au matériau dont est fait le dispositif externes c.-à-d. agissant par contraction
B25H 1/00 - ÉtablisÉtagères ou supports portatifs pour disposer des outils portatifs ou des pièces à travailler
F16M 11/38 - Infrastructure avec ou sans roues à hauteur ou longueur modifiables des pieds, avec utilisation possible pour le transport également par pliage
A device for levelling and separating floor tiles, comprising: - a body with a supporting base (11) for the tiles (B) and a separator element (12) linked to said base (11) by pre-weakened break points (13), and - a levelling wedge (2) suited to be inserted into a window in the separator element (12) and which comprises a lower surface (21) for support on the tiles (B) and an upper surface (22) with a plurality of teeth (26) presenting superiorly, in a transversal direction, a curvature, defining therein: - a higher central area (26a) for initial contact with a central part (14a) of the upper end of the window in the separator element (12) and - laterally descending areas (26b) for progressive contact with lateral parts (14b) that are more remote from said central part (14a) of the window (14).
E04F 21/00 - Outillage pour travaux de finition des bâtiments
E04F 21/22 - Outillage pour travaux de finition des bâtiments pour la pose des revêtements de sols faits d'éléments individuels, p. ex. pinces de planchers
E04F 21/18 - Outillage pour travaux de finition des bâtiments pour la pose des dalles en carreaux muraux ou des plaques de plafond
Disclosed is a frame for machines for cutting ceramic pieces, which comprises a support structure of a guide (G) for longitudinally moving a cutting head (C), which comprises: a central aluminium beam (1) and two lateral aluminium beams (2a, 2b), the beams having a tubular cross-section and being parallel and connected at opposite ends by means of respective steel end plates (3a, 3b); a detachable table formed by two aluminum profiles (4a, 4b) mounted on the central beam (1) and the lateral beams (2a, 2b); and steel corner pieces (5) attached to the support structure, there being mounted to the corner pieces respective pairs of foldable legs (6) provided with locking means (9) for locking in an unfolded position, respective reinforcing cross beams (10) for carrying shock-absorbing elements (11) and rear wheels (12) for transporting in a folded position.
B25H 1/04 - ÉtablisÉtagères ou supports portatifs pour disposer des outils portatifs ou des pièces à travailler du type table portative
B23D 47/02 - Machines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers des bâtisMachines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers d'agencements de guidage de la table de travail ou du chariot porte-scie
B23Q 11/12 - Dispositions pour le refroidissement ou la lubrification des parties des machines
B28D 1/04 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par sciage avec des lames de scie circulaires ou des disques de scie
Disclosed is an electric cutting machine comprising: a base (1); a longitudinally movable table (2); a cutting head (3) provided with a cutting disc (32) and an electric drive motor (33); two rolling assemblies (4) with wheels (41) and rolling bearings (43) mounted by means of independent axles (42, 44) on a vertical partition (52) of parallel longitudinal profiles (5) mounted on the base (1); a pair of longitudinal guides (6) attached to the movable table (2) and which comprise a longitudinal support track (63) for supporting on the wheels (41) of the corresponding rolling assembly (4), and a horizontal wing (65) located under the rolling bearings (43) of the corresponding rolling assembly (4); and interchangeable longitudinal guides (6a) longer that the longitudinal guides (6), for adapting the cutting capacity.
B23D 47/02 - Machines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers des bâtisMachines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers d'agencements de guidage de la table de travail ou du chariot porte-scie
B28D 1/04 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par sciage avec des lames de scie circulaires ou des disques de scie
B28D 7/00 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
A manual ceramic cutter with an adjustable set-square, having a set-square (1) installed at one of the longitudinal extremities of a base (2) for supporting the ceramic items to be cut, and a manually-operated cutting head (3) installed with the possibility of displacement along a number of longitudinal guides (4). This cutter comprises adjustment means (13, 14) of the perpendicularity of the set-square (1) with regard to a cutting line (L1) of the cutter, and fixing means (11, 12) of the set-square (1) to the base (2). It further comprises visual verification means of the perpendicularity of the set-square (1) with regard to the cutting line (L1).
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
A system for the levelling of floor tiles, comprising: a separation post incorporating: a base component, a separator component and a threaded shaft; and a threaded cap with: a hollow dome-shaped body, a lower cylindrical component, an upper hub with a central female thread for the assembly thereof on said threaded shaft, and a number of lateral openings separated by a plurality of ribs with a substantially U-shaped structural cross-section, and comprising: - a smooth external web, with no protruding wings or extensions, of increasing width in a downward direction toward a first lateral end with a curved concave profile, - a first wing and a second wing that extend toward the interior of the cap from lateral ends of the web of the ribs and forming ergonomical surfaces for exerting pressure on the cap in the direction of tightening and loosening of the cap.
E04F 21/22 - Outillage pour travaux de finition des bâtiments pour la pose des revêtements de sols faits d'éléments individuels, p. ex. pinces de planchers
E04F 15/02 - Revêtements de sol composés d'un certain nombre d'éléments semblables
36.
ADJUSTMENT DEVICE FOR MACHINES FOR CUTTING FLOOR TILES AND SIMILAR
The invention relates to an adjustment device for machines for cutting floor tiles and similar, which is provided with a base (1) and an arm (2) carrying a head with a cutting disc (5), and which comprises an adjustment bolt (3) rotatably mounted on the base and provided with a cam (33) that acts against the inner contour of a square hole (21), the cam (33) having a profile suitable to cause, by means of the rotation of the adjustment bolt (3), the arm (2) to move along a square path (T) and the cutting disc (5) to be adjusted in two directions (x, y), parallel and perpendicular to the longitudinal direction (x) of the base.
B28D 1/04 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par sciage avec des lames de scie circulaires ou des disques de scie
37.
ROTARY BLADE ASSEMBLY THAT CAN BE USED IN TILE-CUTTING MACHINES
The invention relates to a rotary blade assembly that can be used in tile-cutting machines, which has an annular blade (1) mounted on a bearing (2) comprising an inner race (21), and outer race (22) and ball bearings (23). A first side of the outer race (22) comprises a perimeter projection (24) that forms a stop for mounting the blade (1) on the bearing. A securing ring (3) that forms a second stop for mounting the blade (1) is mounted and secured on the second side of the outer race (22), the bearing and/or the securing ring comprising projections or recesses (31, 25, 26) which are coupled to complementary recesses or projections (11, 12) defined in the blade and which prevent the relative rotation of the blade (1) with respect to the securing ring (3) and the outer race (22) of the bearing (2).
B28D 1/24 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles au moyen de disques de découpage
A manual ceramic cutter with an adjustable set-square, having a set-square (1) installed at one of the longitudinal extremities of a base (2) for supporting the ceramic items to be cut, and a manually-operated cutting head (3) installed with the possibility of displacement along a number of longitudinal guides (4). This cutter comprises adjustment means (13, 14) of the perpendicularity of the set-square (1) with regard to a cutting line (L1) of the cutter, and fixing means (11, 12) of the set-square (1) to the base (2). It further comprises visual verification means of the perpendicularity of the set-square (1) with regard to the cutting line (L1).
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
B28D 1/24 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles au moyen de disques de découpage
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
39.
MANUAL CERAMICS CUTTER WITH DETACHABLE ACCESSORIES
Disclosed is a manual ceramics cutter with detachable accessories, comprising: a base (1) for supporting a ceramic piece to be cut; a manually actuatable cutting head (2); guides (3) for moving the cutting head; and at least one detachable accessory (4a, 4b) for laterally supporting the ceramic piece to be cut and which is provided with fastening means (41) for fastening to the base (1) in an operative use position in which the detachable accessory (4a, 4b) is arranged transversely with respect to the base (1) and projects laterally from the base (1). The cutter comprises magnetic means (11, 42) for fastening the detachable accessory (4a, 4b) to the base of the cutter in an inoperative or transport position, wherein the accessory (4a, 4b) is arranged in a longitudinal direction on the base (1) and does not project practically from the base.
B28D 1/24 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles au moyen de disques de découpage
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
The present invention relates to a cooling device for disc cutters, which can include: a curved, tubular guide (6), with a radius of curvature slightly greater than the cutter disc and concentric with the periphery of the disc (2); a curved cannula (4), made of semi-rigid material, mounted inside the curved guide capable of longitudinal movement between two end positions, connected to a tube (3) for supplying coolant to a nozzle (5); and means for attaching the cannula (4) in any position comprised between the two end positions of movement with respect to the curved guide. The nozzle (5) moves over a lower sector (21) of the periphery of the disc, and during the cutting of parts (P) of different thicknesses, said nozzle (5) is located at different heights and facing the disc (2) contact and penetration area in the part (P) to be cut.
A locking mechanism for the folding chassis of electric cutting machines. The chassis (1) comprises: a supporting base (11), a tilting arm (12), and an end arm (13) bearing wheels (14) that are collapsible with respect to a principal arm (10) between a folded and an unfolded position of the chassis. The locking mechanism (2) is installed on the tilting arm (12) and comprises: a locking clip (21) capable of being turned manually between an operative position for the locking of the chassis (1) wherein it is coupled with a number of locking rods (112, 113), and an unlocked position of the chassis (1); a manually displaceable trigger for the retaining of the locking clip in the operational position or the free position; and an elastic element that tends to displace the locking clip (21) and the trigger (22) towards the unlocked position of the chassis (1).
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
42.
ADJUSTMENT DEVICE FOR MACHINES FOR CUTTING FLOOR TILES AND SIMILAR
The invention relates to an adjustment device for machines for cutting floor tiles and similar, which is provided with a base (1) and an arm (2) carrying a head with a cutting disc (5), and which comprises an adjustment bolt (3) rotatably mounted on the base and provided with a cam (33) that acts against the inner contour of a square hole (21), the cam (33) having a profile suitable to cause, by means of the rotation of the adjustment bolt (3), the arm (2) to move along a square path (T) and the cutting disc (5) to be adjusted in two directions (x, y), parallel and perpendicular to the longitudinal direction (x) of the base.
B23D 47/02 - Machines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers des bâtisMachines à scier ou dispositifs de sciage travaillant au moyen de lames circulaires, caractérisés uniquement par la structure d'organes particuliers d'agencements de guidage de la table de travail ou du chariot porte-scie
B28D 1/04 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par sciage avec des lames de scie circulaires ou des disques de scie
Electric cutters and mitre cutters and parts thereof;
electric ceramic cutters; electric circular cutters;
electric grinding machines; electric shredders; vacuum
cleaners; electric vacuum cleaners; vacuum cleaner bags;
electric vacuum cleaners; vacuum cleaner bags; cleaning
machines; electric screwdrivers; electric drills;
electric grinding machines; abrasive discs [machine tools];
cutting discs for use with electrical tools; electric
polishers; polishing discs for electric cutters; electric
mixers and their parts; abrasive bits and cutting bits for
power tools; glue guns, electric; electric mortar
applicators; spare parts for electric mortar applicators;
electric joint cleaner; electric cleaners and polishers;
electric rotary cleaning machines; electric planers;
machine tools; motors and engines (other than for land
vehicles); machine couplings and transmission components
(other than for land vehicles); agricultural implements
other than hand-operated; electric ceramic cutting machines
and parts thereof expressly excluding tools belonging to
this class relating to the installation of cables and
moorings. Hand-operated hand tools and implements; cutlery, forks and
spoons; side arms, other than firearms; safety razors;
hand-operated ceramic cutting machines, parts thereof;
cutting tools for hand-operated ceramic cutting machines
excluding tools and implements belonging to this class
relating to the installation of cables and moorings. Channel of rubber or plastic; channel of plastic for
rubble; doors; carry cots; baskets of rubber; drawers;
protectors of plastic or rubber; protectors of rubber for
parking lots; rubber bumpers; plastic fender for parking
lots; containers, not of metal [storage, transport]; street
furniture; pillars; furniture.
Electric cutters and mitre saw and parts therefor; Electric ceramic cutters; Electric circular cutters; Electric moulders; Electric wall chasers; Vacuum cleaners; Electric dust removing apparatus; Vacuum cleaner bags; Electric vacuum cleaners; Vacuum cleaner bags; Cleaners (machines); Screwdrivers, electric; Power drills and bores; Electric rectifiers; Abrasive discs [machine tools]; Discs for cutting for use with power tools; Electric polishers; Polishing discs for electric cutters; Electric mixers and parts therefor; Abrasive bits and cutting bits for electric tools; Glue guns, electric; Electric mortar applicators; Spare parts for electric mortar applicators; Cleaning devices for electric assemblies; Electric cleaners and polishers; Electric rotary cleaning machines; Brushes, electrically operated [parts of machines]; Machine tools; Motors, other than for land vehicles; Machine couplings and transmission components (except for land vehicles); Agricultural implements, other than hand-operated; Electric ceramic cutting machines and therefor, expressly not including tools included in this class in relation to the installation of cables and ties. Hand tools and implements [hand-operated]; Cutlery; Side arms, other than firearms; Razors; Hand-operated ceramic-cutting machines, parts therefor; Cutting tools for manual ceramic cutting machines, not including tools and instruments included in this class in relation to the installation of cables and ties. Drain traps [valves] of plastic; Baskets; Carrycots; Baskets of rubber; Drawers; Corner protectors of plastics or Corner protectors of rubber; Bumper guards of rubber for furniture; Containers, not of metal [storage, transport]; Street furniture; Furniture.
(1) Electric cutters and mitre cutters, namely saws and parts thereof; electric ceramic cutters; electric circular saw cutters; electric centrifugal grinding machines, electric grinding machines for the treatment of ceramics and metal; electric shredders for industrial use; vacuum cleaners; electric vacuum cleaners; vacuum cleaner bags; electric vacuum cleaners; vacuum cleaner bags; floor cleaning machines; electric screwdrivers; electric drills; abrasive discs for power operated grinders; cutting discs for use with electrical tools; electric power operated angle polishers; electric mixers for household purposes and their parts; abrasive bits and cutting bits for power tools; glue guns, electric; electric mortar applicators; spare parts for electric mortar applicators; electric engine joint cleaner; electric floor cleaners and polishers; electric rotary floor cleaning machines; electric planers; machine tools for working metals, machine tools for the metalworking industry; motors and engines for industrial machinery; machine couplings and transmission components (other than for land vehicles); agricultural implements other than hand-operated; electric ceramic cutting machines and parts thereof expressly excluding tools belonging to this class relating to the installation of cables and moorings.
(2) Hand-operated hand tools, cutlery, forks and spoons; side arms, other than firearms; safety razors; hand-operated ceramic cutting machines, parts thereof; cutting tools for hand-operated ceramic cutting machines excluding tools and implements belonging to this class relating to the installation of cables and moorings.
(3) Drain traps of plastic; doors of wood for furniture; carry cots; baskets of rubber for house plants; drawer units; corner protectors of plastic or rubber; bumpers of rubber for furniture; containers, not of metal for storage, containers, not of metal, for transport; outdoor furniture; bedroom, living room and dining room furniture.
Electric plasma cutters and electric mitre cutters and structural parts thereof; electric cutters, namely electric saws and structural parts thereof; electric ceramic cutters; electric rotary cutters; electric rotary grinders; shredding machines other than paper shredders for offices, namely, electric tile shredders; vacuum cleaners; electric vacuum cleaners; vacuum cleaner bags; cleaning machines for floors; machine parts, namely, polishing discs for electric cutters; electric mixing machines; abrasive tool bits and cutting tool bits for power tools; glue guns, electric; electric mortar applicators; structural spare parts for electric mortar applicators; electric mortar joint cleaner; electric floor cleaners and polishers; electric rotary cleaning machine for floors; electric planers; motors and engines other than for land vehicles; machine couplings and transmission components other than for land vehicles; electric ceramic cutting machines, namely, electric saws, electric table saws, tile removal and cutting machines and structural parts thereof, namely, blades for electric saws, expressly excluding tools belonging to this class relating to the installation of cables and moorings Hand-operated tools and implements, excluding those relating to the installation of cables and moorings, namely, manual tile cutter, hack saws; trowels, spatulas, mallets, hammers, scrapers, sanding blocks, power shovels, chisels, nippers, pincers, manual grout mortar applicator, floats for grout, mortar or cement, hand-held ceramic cutter; safety razors Saddlebags, namely, baskets for transporting goods for commercial purposes; large baskets, specifically, baskets for transporting goods for commercial purposes; baskets of rubber, namely, baskets for transporting goods for commercial purposes; lockers; bumpers of rubber, namely, bumper protector guards for furniture; plastic fire fenders for parking lots; rubber bumper guards for cribs, other than bed linen; non-modular containers, not of metal, for use in transportation and storage for commercial or industrial use; furniture
manually-operated hand tools for leveling, tightening and securing tiles and flooring systems; manually-operated hand tools to level, tighten and secure tiles and flooring systems in place during installation for lippage control Non-metal building materials, namely, a combined spacer and leveler for installing tile, stone, brick, marble, ceramic, slab or flooring systems non-metal tile spacing inserts and wedges
17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
Produits et services
Hand tools for tightening levelling devices for pavements and surfaces; Hand-operated systems for levelling pavements and surfaces. Parts of plastic for separating and/or levelling pavements and/or surfaces.
The invention relates to a device for transporting large-format building boards, including a cart provided with wheels for the movement thereof and a transporter with suction cups for securing the large-format board to be transported. The cart comprises at the top removable coupling means of a modular transporter carrying suction cups on at least one of the ends thereof, front and rear, an extendable extension is provided with fastening means for fastening the cart in an essentially protruding position forming a support on the floor during the unloading of the device towards the end carrying said extension.
B62B 3/10 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet caractérisées par des supports spécialement adaptés à des objets de forme définie
B62B 3/02 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet comportant des parties réglables, rabattables, attachables, détachables ou transformables
B62B 3/04 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet comportant des moyens pour accrocher ou saisir en place les objets à transporterAppareillage de manutention de charges
B62B 5/04 - Mécanismes de freinageDispositifs d'immobilisation
50.
ROTARY BLADE ASSEMBLY THAT CAN BE USED IN TILE-CUTTING MACHINES
The invention relates to a rotary blade assembly that can be used in tile-cutting machines, which has an annular blade (1) mounted on a bearing (2) comprising an inner race (21), and outer race (22) and ball bearings (23). A first side of the outer race (22) comprises a perimeter projection (24) that forms a stop for mounting the blade (1) on the bearing. A securing ring (3) that forms a second stop for mounting the blade (1) is mounted and secured on the second side of the outer race (22), the bearing and/or the securing ring comprising projections or recesses (31, 25, 26) which are coupled to complementary recesses or projections (11, 12) defined in the blade and which prevent the relative rotation of the blade (1) with respect to the securing ring (3) and the outer race (22) of the bearing (2).
B28D 1/24 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles au moyen de disques de découpage
B26D 3/08 - Coupe superficielle dans la surface de la pièce, sans enlèvement de matière, p. ex. entaille, incision
Pliers for tightening parts for levelling cladding tiles, including: a first arm (1) with a handle (10) and a guide bar (11); a second arm (2) with a handle (20) and a contact surface (21) with a levelling wedge; a rotation shaft (4); and a supporting stop (3) comprising: a passage (31) for assembly in the guide bar; a shaft (32) assembled in a longitudinal slot (12) of the guide bar for the longitudinal movement of the supporting stop (3) with respect to the guide bar (11) and the relative rotation thereof between a fastening position with a pawl (13, 34) and a longitudinal movement position of the supporting stop (3) with respect to said guide bar (11); and a spring (33) which tends to maintain the supporting stop (3) in the fastening position with respect to the guide bar (11).
B25B 7/12 - PincesAutres outils de serrage tenus à la main avec des mâchoires sur branches pivotantesParties constitutives généralement communes aux outils à main à branches pivotantes comportant des moyens particuliers de transmission entre les poignées et les mâchoires, p. ex. leviers articulés, dents
E04F 21/20 - Outillage pour travaux de finition des bâtiments pour la pose des revêtements de sols
A cutting head for monoguide cutters, with a self-adjusting device is provided. The self-adjusting device can include sets of bearings that comprise fixed bearings (31, 32) and an adjustable bearing (33) that act on races (11, 12) of a monoguide profile disposed on different planes. Each adjustable bearing (33) is mounted on a rocker arm (4) with a first end (41) rotatably mounted on a shaft (5) fixed to the cutting head (2), and with a second end (42) that presses against an elastic element (6) situated between the second end (42) of the rocker arm (4) and the case of the cutting head (2), the elastic element (6) determines the pressure of the bearings (31, 32, 33) against the races (11, 12) of the monoguide profile (1).
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
09 - Appareils et instruments scientifiques et électriques
Produits et services
Electric cutters and mitre saw and parts therefor; Electric ceramic cutters; Electric circular cutters; Electric moulders; Electric wall chasers; Vacuum cleaners; Electric dust removing apparatus; Vacuum cleaner bags; Electric vacuum cleaners; Vacuum cleaner bags; Cleaners (machines); Electric screwdrivers; Power drills and bores; Electric rectifiers; Abrasive discs [machine tools]; Discs for cutting for use with power tools; Electric polishers; Polishing discs for electric cutters; Electric mixers and parts therefor; Abrasive bits and cutting bits for electric tools; Glue guns, electric; Electric mortar applicators; Spare parts for electric mortar applicators; Cleaning devices for electric assemblies; Electric cleaners and polishers; Electric rotary cleaning machines; Brushes, electrically operated [parts of machines]; Machine tools; Motors and engines (except for land vehicles); Machine couplings and transmission components (except for land vehicles); Agricultural implements other than hand-operated; Electric ceramic cutting machines and therefor, expressly not including tools included in this class in relation to the installation of cables and ties. Hand tools and implements [hand-operated]; Cutlery; Side arms; Razors; Hand-operated ceramic-cutting machines, parts therefor; Cutting tools for manual ceramic cutting machines, not including tools and instruments included in this class in relation to the installation of cables and ties. Measuring apparatus and instruments (excluding those relating to running water and those for measuring, signalling, checking (supervision) and examining relating to the installation of cables and mooring), plumb lines and tripods; Head protection; Knee-pads for workers; Elbow protectors (protective -) for use against accidents [other than sports articles]; Shoes (Protective -); Boots [protective footwear]; Protective masks; Face guards for protection against accident or injury; Protective work clothing [for protection against accident or injury]; Safety glasses for protecting the eyes; Face-protection shields; Gloves for protection against accidents.
The protective cooling cover comprises a hollow shell defining a generally semi-cylindrical cavity (15) that covers a portion of a cutting disc (2) at the top thereof and that is delimited by two lateral walls (11, 12) and a curved perimeter wall (13), a cooling device including a tube connected to a cooling liquid supply and to a cooling liquid projecting nozzle (31), and a fastening device for fixing the cooling liquid projecting nozzle (31) at different positions within the cavity (15) of the shell for projecting cooling liquid to different areas of the cutting disc, the fastening device including a plurality of first fasteners (17) connected to the periphery of the cavity, and a second fastener (32) connected to the cooling liquid projecting nozzle (31), the first and second fasteners (17, 32) providing a snap fit releasable connection.
B23Q 11/06 - Dispositifs de sécurité pour les outils de coupe circulaires
B28D 1/04 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par sciage avec des lames de scie circulaires ou des disques de scie
B23Q 11/08 - Protecteurs pour des parties des machines-outilsCapots antiprojections
B27G 19/02 - Protecteurs ou dispositifs de sécurité adaptés aux scies à boisDispositifs auxiliaires facilitant une bonne utilisation des scies à bois pour scies circulaires
60.
Cutting and separating device applicable to manual ceramic cutters
The invention relates to a cutting and separating device applicable to manual ceramic cutters, comprising: a carriage; a collapsible handle with a cutting tool; a toothed part comprising a separator for separating ceramic parts; springs for holding the toothed part in an inoperative position as well as a toothed actuator in an engaged position with the toothed part; and a manual trigger element for disengaging the toothed actuator. The rotation of the handle past a pre-determined angle causes the engagement of the toothed actuator in the toothed part; the descending rotation causes the toothed actuator to rotate the toothed part until an operative position of the separator is reached; and the actuation of the trigger element causes the release of the toothed part and the return thereof to the inoperative position.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
61.
SELF-ADJUSTING DEVICE FOR A CUTTING HEAD FOR MONOGUIDE CUTTERS
The invention relates to a cutting head (2) that includes sets of bearings comprising fixed bearings (31, 32) and an adjustable bearing (33) that act on races (11, 12) of a monoguide profile disposed in different planes. Each adjustable bearing (33) is mounted on a rocker (4) having a first end (41) rotatably mounted on a shaft (5) fixed to the cutting head (2), and a second end (42) that presses against an elastic element (6) situated between the second end (42) of the rocker (4) and the case of the cutting head (2), the elastic element (6) determining the pressure of the bearings (31, 32, 33) against the races (11, 12) of the monoguide profile (1).
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
62.
Cutting and separation head for manual ceramics cutters
A cutting and separation head for manual ceramic cutters, including a body that carries a grip handle and a cutting tool, mounted on movable supports on longitudinal guides of the cutter, and able to rotate with respect to a first transverse rotary shaft; a separator provided with a foot, a class 1 lever, and a first coupling element in the separator that is couplable to a second coupling element in the body of the head; and a cam for releasing the first and second coupling elements, the cam being mounted on the body and relatively rotatable between a first position and a second position.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
A base for manual ceramic cutters, which is provided with a support surface for the ceramic parts to be cut, the base including a rigid profile in the central longitudinal area, which rigid profile is secured to the supports of longitudinal displacement guides for a tool-holder head; and two lateral platforms mounted on the rigid profile by longitudinal shafts, which lateral platforms can be lowered between a horizontal use position, in which they form a support surface for the ceramic parts to be cut, and an inoperative position, in which the base defines a smaller surface area.
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
A removable ruler for manual ceramic cutters which can be rotatably mounted on the base of a manual ceramic cutter and which includes a rotary platform permanently secured to the base of the cutter by a rotary shaft; and two removable lateral extensions. The platform includes securing means for the rapid coupling and subsequent uncoupling of the lateral extensions.
B28D 7/00 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe
F16B 2/08 - Brides ou colliers, c.-à-d. dispositifs de fixation dont le serrage est effectué par des forces effectives autres que la résistance à la déformation inhérente au matériau dont est fait le dispositif externes c.-à-d. agissant par contraction utilisant des frettes ou des bandes
F16B 2/14 - Brides ou colliers, c.-à-d. dispositifs de fixation dont le serrage est effectué par des forces effectives autres que la résistance à la déformation inhérente au matériau dont est fait le dispositif utilisant des coins
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
B43L 13/02 - Appareils à tracer ou dispositifs de dessin pour conserver le parallélisme
A47B 27/00 - Bureaux ou tables à dessinSupports pour planches à dessin
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
G01B 3/04 - Règles avec des échelles ou des marques pour la lecture directe rigides
F16B 21/12 - Dispositifs sans filetage pour empêcher le mouvement relatif selon l'axe d'une broche, d'un ergot, d'un arbre ou d'une pièce analogue par rapport à l'organe qui l'entoureFixations à ergots et douilles largables sans filetage à parties séparées par goupilles d'arrêt ou goupilles fendues enfoncées dans des trous
A set square for manual ceramic cutters, including a ruler intended to be rotatably mounted and secured to a base of a manual ceramic cutter, defining various angles; a stop that is mounted on the ruler and can be moved longitudinally; and a tightening element for securing to the ruler. The cross-section of the ruler includes two oblique planes that converge towards an intermediate surface provided with a longitudinal recess having a generally T-shaped cross section, for mounting the tightening element. The lateral stop includes two oblique planes facing the ruler and having the same slope as the oblique planes of the ruler, and which converge towards an intermediate surface that has an opening to mount the tightening element.
B28D 7/00 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
B43L 7/027 - Règles multiples non ajustables disposées à angle droit
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
G01B 3/04 - Règles avec des échelles ou des marques pour la lecture directe rigides
37 - Services de construction; extraction minière; installation et réparation
41 - Éducation, divertissements, activités sportives et culturelles
Produits et services
Providing of information relating to the rental or repair of construction machines and apparatus; Providing of information relating to the maintenance of construction materials not of metal, of metal, of plastic, for reinforcement, of glass, of wood, of natural stone and of marble. Training; Organization of competitions; Conducting of educational events; Arranging and conducting of colloquiums; Seminars.
71.
CUTTING-SEPARATING HEAD, SUITABLE FOR USE IN MANUAL CERAMIC CUTTERS
The invention relates to a cutting-separating head, suitable for use in manual ceramic cutters, comprising at least: a support (1) which can be moved on longitudinal guides (G); a body (2) mounted on the support (1), with the possibility of rotation in relation to a first transverse axle (21); a handle (3) for actuating the body (2); a cutting tool (4) and a separator (5) mounted on the body (2) via a second axle (51), with the possibility of rotation between a non-operating position in which said separator (5) is adjacent to the body (2), and an operating position in which the separator (5) is suspended vertically in relation to the second axle (51). The head comprises at least one magnetic element (6) for retaining the separator (5) in the non-operating position.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
72.
CERAMIC CUTTER HAVING LIQUID-COOLING BY IMMERSION OF THE CUTTING DISC
The invention relates to a ceramic cutter having liquid-cooling by immersion of the cutting disc, comprising: a support frame (1); an electric motor (2) for actuating a cutting disc (3); a tray (4) containing water for cooling the cutting disc (3) by immersion; an auxiliary water tank (6), which is removable, disposed above the cooling tray (3) and provided with a gravity-driven water outlet (61, 62) for discharging water into the cooling tray (3), said outlet being accommodated in the tray (3) and being disposed at a height corresponding to a predetermined level of the water for cooling the cutting disc (3) by immersion.
B28D 1/24 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles au moyen de disques de découpage
B28D 7/00 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe
73.
CUTTING AND SEPARATING DEVICE APPLICABLE TO MANUAL CERAMIC CUTTERS
The invention relates to a cutting and separating device applicable to manual ceramic cutters, comprising: a carriage (1); a collapsible handle (3) with a cutting tool (4); a toothed part (5) comprising a separator (6) for separating ceramic parts; springs (10, 13) for holding the toothed part (5) in a inoperative position as well as a toothed actuator (12) in an engaged position with the toothed part (5); and a manual trigger element (14, 15) for disengaging the toothed actuator (12). The rotation of the handle (3) past a pre-determined angle causes the engagement of the toothed actuator (12) in the toothed part (5); the descending rotation causes the toothed actuator (12) to rotate the toothed part (5) until an operative position of the separator (6) is reached; and the actuation of the trigger element (14, 15) causes the release of the toothed part (5) and the return thereof to the inoperative position.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
Produits et services
Hand tools for tightening levelling devices for pavements and surfaces; Hand-operated systems for levelling pavements and surfaces. Parts of plastic for separating and/or levelling pavements and/or surfaces.
The invention relates to a toolholder guide system in manual ceramic cutters, comprising parallel guides (2) for the longitudinal movement of a tool holder (1) that comprises a handle (11) for the actuation thereof and carries a cutting tool (12) for scoring a ceramic part. The guides (2) are formed by a profile, preferably made of aluminium, each guide (2) comprising upper and lower steel rods (21, 22), disposed longitudinally, forming races for bearing carriages (3) disposed on the sides of the toolholder (1). Each bearing carriage (3) comprises two end bearings (31, 32) disposed at the same height and at least one intermediate bearing (33) disposed at a lower height than the two end bearings.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
76.
CUTTING AND SEPARATION HEAD FOR MANUAL CERAMIC CUTTERS
The invention relates to a cutting and separation head for manual ceramic cutters, comprising: a body (3) that carries a grip handle (5) and a cutting tool (6), is mounted on movable supports (2) on longitudinal guides of the cutter (C), and is able to rotate with respect to a first transverse rotary shaft (4); a separator provided with a foot (7), a class 1 lever (8), and a first coupling element (10) in the separator that is couplable to a second coupling element (12) in the body (3) of the head (1); and a cam (13) for releasing the first and second coupling elements (10, 12), the cam being mounted on the body (3) and relatively rotatable between a first position and a second position.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
The invention relates to a set square for manual ceramic cutters, comprising: a ruler (1) intended to be rotatably mounted and secured to a base of a manual ceramic cutter (C), defining various angles; a stop (2) that is mounted on the ruler and can be moved longitudinally; and a tightening element (3) for securing to the ruler. The cross-section of the ruler (1) comprises two oblique planes (11, 12) that converge towards an intermediate surface (13) provided with a longitudinal recess (14) having a generally T-shaped cross section, for mounting the tightening element (3). The lateral stop (2) comprises two oblique planes (21, 22) facing the ruler and having the same slope as the oblique planes (11, 12) of the ruler (1), and which converge towards an intermediate surface (23) that has an opening (24) to mount the tightening element (3).
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
B28D 7/00 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe
The invention concerns a base for manual ceramic cutters, which is provided with a support surface for the ceramic parts to be cut, the base comprising: a rigid profile (1) in the central longitudinal area, which rigid profile is secured to the supports (41) of longitudinal displacement guides (4) for a tool-holder head; and two lateral platforms (2a, 2b) mounted on the rigid profile (1) by means of longitudinal shafts (31), which lateral platforms can be lowered between a horizontal use position, in which they form a support surface for the ceramic parts to be cut, and an inoperative position, in which the base defines a smaller surface area.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
The invention relates to a removable ruler for manual ceramic cutters which can be rotatably mounted on the base (1) of a manual ceramic cutter and which comprises: a rotary platform (5) permanently secured to the base of the cutter by means of a rotary shaft (51); and two removable lateral extensions (6a, 6b). The platform (5) comprises securing means (5a, 5b) for the rapid coupling and subsequent uncoupling of the lateral extensions (6a, 6b).
B28D 7/00 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
80.
IMPROVEMENTS IN DEVICES FOR LEVELLING COVERING PARTS
The invention relates to a levelling device comprising a first substantially flat body (1), provided with an appendage (11), in the top part, which has, on a first end, close to the first body (1), a first fracture zone (12) for the separation thereof from the first body (1) and, on a second end, at a distance from the first body (1), a hook (13) for attaching an actuating tool and a second fracture zone (15) with a lower fracture resistance than that of the first fracture zone (12); and a second, upper body (2) containing a passage (21) for mounting said body on the appendage (11) such that it can move into an operative position in which it presses the covering parts (P) against the first body (1).
E04F 15/02 - Revêtements de sol composés d'un certain nombre d'éléments semblables
E04F 21/22 - Outillage pour travaux de finition des bâtiments pour la pose des revêtements de sols faits d'éléments individuels, p. ex. pinces de planchers
The invention relates to a device comprising a first part (1) provided with a base (11) and a rod (12) having an opening or recess (13) for the engagement of an actuation tool (3), a second part (2) provided with a through-opening (21) for mounting on the rod (12) of the first part (1) and a surface for supporting the tool (3), as well as a tool (3) of the second part (2) along the rod (12) of the first part (1). The tool (3) comprises: a first arm (31) and a second arm (32) hinged on an intermediate shaft (33), having respective ends (31a, 32a) for acting on the first part (1) and the second part (2), and respective handles (31b and 32b); a mechanism (4) for positioning and regulating the rotational relative movement of the arms (31, 32).
Frame for an electric apparatus for cutting ceramic elements preferably manufactured by a drawing and punching process starting from a metallic plate, being the frame a unique and continuous part in which one or more lined up going through grooves are arranged along which the cutting disc is movable to carry out the cutting of the ceramic tiles, having one or more bulgings directed in a convex form towards the interior part of the frame, being arranged in each of them a first orifice for draining out the water for cooling the cutting disc, second and third bulgings of the metallic plate being aimed at attachment means and abutment means for foldable legs and first bulgings for joining of the guide supporting and leading the cutting disc.
B25H 1/00 - ÉtablisÉtagères ou supports portatifs pour disposer des outils portatifs ou des pièces à travailler
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
B28D 1/04 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par sciage avec des lames de scie circulaires ou des disques de scie
B28D 7/04 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour supporter ou maintenir les pièces travaillées
B28D 7/02 - Accessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour enlever ou faire se déposer la poussière p. ex. par pulvérisation de liquidesAccessoires spécialement conçus pour leur utilisation avec les machines ou les dispositifs des autres groupes de la présente sous-classe pour refroidir les pièces travaillées
09 - Appareils et instruments scientifiques et électriques
Produits et services
Electric cutters and mitre saw and parts therefor; Electric ceramic cutters, electric circular cutters, electric moulders, electric wall chasers, Vacuum cleaners, Electric dust removing apparatus, Vacuum cleaner bags, Electric vacuum cleaners, Vacuum cleaner bags, Cleaners (machines), Electric screwdrivers, Power drills and bores, Electric rectifiers; Abrasive discs [machine tools]; Discs for cutting for use with power tools, Electric polishers, Polishing discs for electric cutters; Electric mixers and parts therefor; Abrasive bits and cutting bits for electric tools, Glue guns, electric; Electric mortar applicators; Spare parts for electric mortar applicators; Cleaning devices for electric assemblies; Sponges for cleaning devices for electric assemblies, electric cleaning and polishing devices; Electric rotary cleaning machines; Brushes (except paint brushes), scouring pads, discs of metal, steelwool and supports therefor for electric rotary cleaning machines; Machine tools; Motors and engines (except for land vehicles); Machine couplings and transmission components (except for land vehicles); Agricultural implements, other than hand operated; Electric ceramic cutting machines and parts therefor. Hand tools and implements (hand operated); Cutlery; Side arms; Razors; Hand-operated ceramic-cutting machines, parts therefor; Cutting tools for hand-operated ceramic-cutting machines. Measuring apparatus and instruments (excluding those relating to running water and those for measuring, signalling, checking (supervision) and examining relating to the installation of cables and mooring), plumb lines and tripods; Headset, knee guards, Protective elbow guards and articles for workers.
The invention relates to a tile separator for uniformly aligning and separating successive tiles while they are being positioned on, and secured to a surface. The separator comprises: a flat body (1) having two parallel horizontal surfaces; at least one first pair of separating feet (2) which are aligned along a first horizontal direction (D1) and which project vertically from the flat body, having a thickness that defines the distance between consecutive tiles; and at least one horizontal recess (3) defined in the flat body (1), oriented in a direction perpendicular to the first direction (D1) and defining at least one respective bending line on the flat body (1). The aforementioned horizontal recess (3) defines at least one central portion (11) and two end portions (12) which, depending on the degree to which the aforementioned flat body is bent, are arranged either coplanar with one another or such as to form a variable angle therebetween.
Portable mixer for construction materials, of the type used for mixing various materials and comprising: a supporting housing, an electric motor, a handle for gripping and holding the mixer, and a mixer head provided with a rod for coupling to the electric drive motor. The portable mixer also comprises an outer surface of the housing, on which the handle is mounted in such a way that it can move longitudinally with respect to the geometric axis of the rod of the mixer head, and means for locking the handle on the outer surface of the housing, at a variable height from the mixer head.
(1) Machines for tile casting, cutting, polishing and finishing, concrete mixers, tamping machines, machines for the industry of ceramics as a mitre saws, electric grout cleaners, mixers for use with plaster, mortar, cement and epoxy resins, vibration rollers and plates for use with the aforementioned machines and mixers, machine tools for breaking up road paving surfaces and other machines for building, public works namely: tunnel boring machines, concrete and asphalt cutters, hand-held and hydraulically-operated drills; power tools, namely cutters, drills and bits and blades therefore for use with ceramics; hand tools and implements, namely, hand operated ceramic tile cutters.
A drill guide, of the type that has a main body with a flat base and an aperture for assisting the movement of a drill bit, interchangeable drilling heads for guiding drill bits of different diameters, the heads designed to be optionally attached and fit onto the housing defined according to the size of through hole of the main body that has the aforementioned interchangeable drilling heads and inside apertures of different diameters on each drilling head, the apertures are specifically designed to guide drill bits of different diameters, a positioning device for attaching the drilling head in use in a set position inside the housing, and a retaining device for retaining any of the interchangeable drilling heads inside the housing.
The invention relates to a tool comprising a handle (1) which is coupled to the cutter and a cutting disk (3) which is mounted by means of a pivot pin (2) to a fork (11) defined at the front end of the handle. The cutting disk (3) is formed by: a core (31) made from a material with a low friction coefficient and provided with a transverse hole (35) for mounting the pivot pin, and an outer crown (32) made from a hard metal or material, mounted on the periphery of the core (31) and provided with a peripheral edge (33) used to mark the ceramic part to be cut.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
C03B 33/10 - Outils à couper le verre, p. ex. outils de rayage
The invention relates to a cutter including: a base (1) with an upper surface for supporting the ceramic part (9a, 9b, 9c) to be cut, a longitudinal rail (2) positioned above the longitudinal mid-zone of the base (1) parallel thereto, and a movable handle (3) bearing the cutting disc (4) and having a longitudinal passage for guiding same. The handle (3) includes a cam (5) disposed vertically facing the lower end of the rail (2) and associated with a positioning knob (7) which determines the position of cam (5) sectors of different heights in relation to the lower end of the rail (2), in order to position the handle (3) at different heights but at a similar angle during the cutting of parts of different thicknesses.
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
Machines and machine tools, except those relating to the
installation of cables and mooring. Hand-operated tools and implements, except those relating to
the installation of cables and mooring.
This cutter comprises: a base (1), a longitudinal rail (2) for the movable mounting of a handle (3) carrying a blade or cutting tool (4), lateral folding arms (13) and an orientable set square (8). The handle (1) has: rolling elements (31, 32) and an antifriction piece (33), for movement on the rail (2), a longitudinal guide (34) for the interchangeable coupling of blade-holder pieces (41) and a bolt (35) for holding the blade-holder piece. The orientable set square (8) is fixed at different angular positions by means of a bolt (81) that is inserted in conical seats (16) in a circular arrangement or by means of a vertical-thrust flange (9). The base (1) comprises studs (12) for the mounting of the folding arms (13) with respective intermediate springs (14) and tension-adjusting nuts (15).
B28D 1/22 - Travail de la pierre ou des matériaux analogues p. ex. briques, béton, non prévu ailleursMachines, dispositifs, outils à cet effet par découpage, p. ex. exécution d'entailles
