Abrégé

[Problem] To provide a means for a strip material (A) that can be spirally wound to construct a rehabilitated pipe, the means providing excellent conformability when an existing pipe has a corner portion or when an external force is applied to the new pipe body due to an earthquake or the like. [Solution] The strip material (A) comprises at least: an elongated belt portion 10; a fitting recess portion 20 provided at one end in the shorter direction on one surface side of the belt portion 10; a fitting projection portion 30 provided at the other end in the shorter direction on the one surface side of the belt portion 10; and a folded portion 50 provided midway along the shorter direction on the one surface side of the belt portion 10. A widening slit 60 is provided on the one surface side of the belt portion 10 between a connection part between the belt portion 10 and one end of the folded potion 50 and a connection part between the band portion 10 and the other end of the folded portion 50.

Classes IPC  ?

• B29C 63/32 - Garnissage ou gainage de surfaces internes avec des matières sous forme de feuilles ou de nappes par enroulement hélicoïdal

Produits et services

Extruded and injection-moulded parts of plastic for the garden, namely garden lamps. Extruded and injection-moulded parts of plastic for the garden, namely garden fences, Pergolas, Anti-erosion fences. Extruded and injection-moulded parts of plastic for the garden, namely garden furniture, garden tables. Extruded and injection-moulded parts of plastic for the garden, Namely window-boxes.

Produits et services

Extruded, injection-moulded, foamed, deep-drawn plastic parts in the form of semi-finished products, included in class 17; Hollow-chamber profiles of plastic (semi-finished products); Plastic parts manufactured by extrusion and/or moulded foams being semi-finished goods; Plastic parts manufactured by extrusion and/or moulded foams being semi-finished products, including having sound-insulating properties (included in class 17); Plastic hollow chamber profiles.

Produits et services

Metal building materials; Non-electric wires of common metal. Machines and devices for the manufacture of wound tubes; Machines for the coextrusion of synthetic fibrous materials. Parts of plastic for vehicle construction included in class 12; Plastic parts, namely covers for glove compartments in cars. Parts of plastic, being extruded, injection-moulded, extruded, deep-drawn, in the form of semi-processed goods, included in class 17; Plastic pipes in extruded form for use in manufacture; Plastic parts manufactured by extrusion and/or moulded foams being semi-finished goods; Plastic parts manufactured by extrusion and/or moulded foams being semi-finished products, including having sound-insulating properties (included in class 17); Profiles for wound tubes (not of metal); Profile connectors for wound tubes (not of metal); Profiles of synthetic fibrous materials. Pipes of plastic for building, waste draining pipes made of plastic, Pipes of plastic for sewer pipe renovation; Non-metallic building materials; Building materials (non-metallic) namely plastic parts manufactured by extrusion and/or moulded foams (included in class 19); Artificial stone, in particular paving blocks for paths and squares, and decorative stone for garden and landscape design; Pipes and tubes (not of metal) for structural and civil engineering; Wound tubes (not of metal) for channel remediation, in particular for civil engineering; Building materials, not of metal, namely plastic parts manufactured by extrusion and/or moulded foams, including having sound-insulating properties (included in class 19). Furniture of plastic materials. Feeding troughs for animals and drinking troughs of plastic for cattle. Channel remediation services, in particular for sewers. Production of profiles of synthetic fibrous materials, for others.

Abrégé

The invention relates to a method for laying a pipeline wound from profiled plastic strips using a winding machine, which circulates in a winding basket on a guide track, in an open channel trench, in particular in the form of a wastewater line. The aim of the invention is to provide a simple and inexpensive laying process. This is achieved by arranging a laying vehicle (10) on an opened trench section (4) of the laying trench (1), wherein profiled plastic strips (18) are removed from a storage drum (17), which is provided on the laying vehicle (10) or in the vicinity of the vehicle and which comprises a supply of profiled plastic strips, and fed to the pipe-producing device (6). The pipe-producing device (6) is held on a holding arm (12) in an oscillating manner and is lowered to almost the bottom (4.1) of the trench in the region of the opened trench section (4) of the laying trench (1). In the pipe-producing device (6), the profiled plastic strips (18) are joined to the last winding (5.1) of the already finished wound pipe (5), thereby latching the adjacent edge regions of the fed profiled plastic strip (18) and the profiled plastic strip (18) of the last finished winding (5.1), by means of a circulating winding basket (30) in a known manner. The pipe-producing device (6) in the winding basket (30) is supplied with energy by the drive of the laying vehicle (10), said energy being supplied via a supply line (14). The laying vehicle (10) follows the progress of the manufacture of the wound pipe (5), said pipe-producing device (6) following the elongation of the wound pipe (5) by means of the oscillating suspension on the holding arm (12). After the wound pipe (5) has been laid, the opened trench section (4.1) is refilled with soil (2.2).

Classes IPC  ?

• B29C 53/58 - Enroulement et assemblage, p. ex. enroulement en spirale hélicoïdal
• B29C 65/48 - Assemblage d'éléments préformésAppareils à cet effet en utilisant des adhésifs
• B29C 65/58 - Encliquetage
• B29C 65/00 - Assemblage d'éléments préformésAppareils à cet effet
• B29C 53/78 - Enroulement et assemblage, p. ex. enroulement en spirale hélicoïdal en utilisant des bandes ou des feuilles profilées

Abrégé

The invention relates to a method and a device for repairing portions of channels (3), including non-round channels, by means of a wound tube (4) wound from a profile strip by a winding machine (20), the abutting edges of which strip are formed into tight joints, locked inside the wound tube (4) which can be introduced into the portion of the channel to be repaired. In order to avoid the disadvantages of the prior art, the plastic profile strip (4.1) is drawn from a storage spool (5) and fed to a winding machine (20) arranged in front of one of the openings of the channel to be repaired (3), said winding machine having a guide rail (25) adapted to the cross-portion of the channel, and adjacent edge regions fed onto this rotating winding former (30) locked in an overlapping manner to form a wound pipe (4) and said pipe is pushed or pulled into the channel portion (3).

Classes IPC  ?

• F16L 55/165 - Dispositifs pour aveugler les fuites dans les tuyaux ou manches à partir de l'intérieur du tuyau par introduction d'un tuyau dans la section endommagée
• F16L 55/18 - Accessoires de réparation des tuyaux

Produits et services

Plastic parts manufactured by extrusion and/or moulded foams being semi-finished products, including having sound-insulating properties (included in class 17). Building materials, not of metal, namely plastic parts manufactured by extrusion and/or moulded foams, including having sound-insulating properties (included in class 19).

Produits et services

Plastic parts, namely covers for glove compartments in cars.

Produits et services

Plastic parts for vehicle construction included in class 12. Plastic pipes in extruded form for use in manufacture. Pipes and tubes for building purposes of plastic, waste water pipes of plastic, pipes and tubes of plastic for the sanitation of waste water pipes. Feeding troughs for animals and drinking troughs of plastic for cattle.
