A network of sensor systems for spargers for injection of bubbles into a flotation system, comprising an air header to deliver a flow of compressed gas, a pressure transducer connected to the air header that measures pressure in the air header, a plurality of spargers that each receive a flow of compressed gas from the air header and that each comprise a sensor system. Flow measurement devices are located between the air header and each sparger. The pressure transducer, each sensor system, and each flow measurement device outputs a signal to a signal processor that generates a signal output to a central control unit that aggregates and analyzes each signal to display operating parameters of each corresponding sparger and provide overall system performance data.
A sensor system for a sparger having a housing with an inlet configured to receive a flow of compressed gas for injection of bubbles into a flotation system. The sensor system comprises a flow measurement device in line with the inlet and a movable rod assembly within the housing. A sensor and a target that move relative to each other, wherein one of the sensor and the target is located in the housing the other is located on or attached to the movable rod assembly. The sensor for measuring parameters of motion, position, and vibration, relative to the target based on the movement of the movable rod assembly. The sensor system for determining operating parameters of the sparger based on analysis of the measured motion, position, and vibration of the sensor relative to the target and flow measurements from the flow measurement device.
A system for metal detection comprises a single aperture comprising two or more sets of detection coils that surround the perimeter of the aperture. A flow path of materials passes through the aperture. Each set of detection coils comprises a transmitter and two receiver coils, with the transmitter coil located between the two receiver coils. Each set of detection coils is at a different angle relative to the flow path.
G01V 3/10 - Prospection ou détection électrique ou magnétiqueMesure des caractéristiques du champ magnétique de la terre, p. ex. de la déclinaison ou de la déviation fonctionnant au moyen de champs magnétiques ou électriques produits ou modifiés par les objets ou les structures géologiques, ou par les dispositifs de détection en utilisant des cadres inducteurs
What is presented is a system and method for bubble creation in a fluid injection nozzle for the injection of a gas into a liquid to divide the gas into the smallest possible bubble size with the largest cumulative surface area by maximizing the percentage of gas at the highest possible kinetic energy that is in contact with the liquid. The fluid injection nozzle comprises a convergent inlet for receiving a fluid and a divergent outlet for exhausting the fluid. The divergent outlet has multiple exhaust ports.
B01F 25/20 - Mélangeurs à jet, c.-à-d. mélangeurs utilisant des courants de fluides à grande vitesse
B05B 1/00 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage
B05B 1/14 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des orifices de sortie multiplesBuses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des filtres placés dans ou à l'extérieur de l'orifice de sortie
B01F 23/231 - Mélange de gaz avec des liquides en introduisant des gaz dans des milieux liquides, p. ex. pour produire des liquides aérés par barbotage
B05B 1/30 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour commander un débit, p. ex. à l'aide de conduits de section réglable
Gas sparging system comprised primarily of gas spargers, and associated sparging tubes and fittings for injection of gas bubbles into flotation tanks, process reactors and vessels
A flotation separation system for partitioning a slurry comprises a flotation separation cell that comprises a sparger unit and a separation tank. The sparger unit comprises a slurry inlet for receiving a slurry and a gas inlet for introducing a gas into the slurry. The sparging mechanism disperses the gas bubbles within the slurry. A high shear element comprising a rotating shaft and a rotating high shear element mounted to it located within the sparging mechanism shears the gas into a bubble dispersion within the slurry. A slurry outlet discharges the slurry containing the bubble dispersion into the separation tank. An adjustable distributor plate at the slurry outlet restricts the flow of slurry through the slurry outlet. The distributor plate is mounted to the rotating shaft and rotates with the high shear element.
A system for metal detection comprises a single aperture comprising two or more sets of detection coils that surround the perimeter of the aperture. A flow path of materials passes through the aperture. Each set of detection coils comprises a transmitter and two receiver coils, with the transmitter coil located between the two receiver coils. Each set of detection coils is at a different angle relative to the flow path.
G01V 3/10 - Prospection ou détection électrique ou magnétiqueMesure des caractéristiques du champ magnétique de la terre, p. ex. de la déclinaison ou de la déviation fonctionnant au moyen de champs magnétiques ou électriques produits ou modifiés par les objets ou les structures géologiques, ou par les dispositifs de détection en utilisant des cadres inducteurs
A sparger for injection of bubbles into a flotation system comprises a housing, a movable rod assembly, and a sensor system that comprises a sensor and a target that move relative to each other. One of the sensor and the target is located in the housing and the other is located on or attached to the movable rod assembly. The sensor for measuring motion, including position and vibration, relative to the target based on the movement of the movable rod assembly. The sensor system for determining operating parameters of the sparger based on the analysis of the measurement of the motion of the sensor relative to the target.
G01R 33/07 - Mesure de la direction ou de l'intensité de champs magnétiques ou de flux magnétiques en utilisant des dispositifs galvano-magnétiques des dispositifs à effet Hall
G01P 13/00 - Indication ou enregistrement de l'existence ou de l'absence d'un mouvementIndication ou enregistrement de la direction d'un mouvement
12.
MULTILOBULAR SUPERSONIC GAS NOZZLES FOR LIQUID SPARGING
What is presented is a system and method for bubble creation in a fluid injection nozzle for the injection of a gas into a liquid to divide the gas into the smallest possible bubble size with the largest cumulative surface area by maximizing the percentage of gas at the highest possible kinetic energy that is in contact with the liquid. The fluid injection nozzle comprises a convergent inlet for receiving a fluid and a divergent outlet for exhausting the fluid. The divergent outlet has multiple exhaust ports.
B05B 1/14 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des orifices de sortie multiplesBuses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des filtres placés dans ou à l'extérieur de l'orifice de sortie
B05B 1/00 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage
B05B 1/02 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage agencés pour produire un jet, un pulvérisat ou tout autre écoulement de forme ou de nature particulière, p. ex. sous forme de gouttes individuelles
A sparger for injection of bubbles into a flotation system comprises a housing, a movable rod assembly, and a sensor system that comprises a sensor and a target that move relative to each other. One of the sensor and the target is located in the housing and the other is located on or attached to the movable rod assembly. The sensor for measuring motion, including position and vibration, relative to the target based on the movement of the movable rod assembly. The sensor system for determining operating parameters of the sparger based on the analysis of the measurement of the motion of the sensor relative to the target.
B01F 3/04 - Mélange, p.ex. dispersion, émulsion, selon les phases à mélanger de gaz ou de vapeurs avec des liquides
G01P 13/00 - Indication ou enregistrement de l'existence ou de l'absence d'un mouvementIndication ou enregistrement de la direction d'un mouvement
G01R 33/07 - Mesure de la direction ou de l'intensité de champs magnétiques ou de flux magnétiques en utilisant des dispositifs galvano-magnétiques des dispositifs à effet Hall
A system for concentrating particulate mixtures of hydrophobic and hydrophilic material in a fluid medium is presented. The system comprises a separation chamber comprising three or more processing compartments in series. Each processing compartment comprises a manifold for the introduction of teeter water that comprises a mixture of water and air bubbles, suspended solids that form a fluidized bed that is created by the upward movement of the teeter water through the suspended solids; and each processing compartment is independently operable. An overflow launder is located above the separation chamber and a dewatering compartment is located beneath the separation chamber.
Machine parts, namely, gas sparging tubes for injecting gasses into process liquors and injector nozzles for use in injecting gasses into process liquors sold with operational status indicators and electronic sensors and monitors with remote control devices for monitoring and reporting all sold as a component of the machine parts
A system for concentrating particulate mixtures of hydrophobic and hydrophilic material in a fluid medium is presented. The system comprises a separation chamber comprising three or more processing compartments in series. Each processing compartment comprises a manifold for the introduction of teeter water that comprises a mixture of water and air bubbles, suspended solids that form a fluidized bed that is created by the upward movement of the teeter water through the suspended solids; and each processing compartment is independently operable. An overflow launder is located above the separation chamber and a dewatering compartment is located beneath the separation chamber.
A separation system is presented that partitions a slurry containing a plurality of particles that are influenced by a fluidization flow (which comprises teeter water and gas bubbles) and a fluidized bed. The separation system comprises a separation tank, a slurry feed distributor, a fluidization flow manifold and a gas introduction system. All of these components are arranged to create the fluidized bed in the separation tank by introducing the slurry through the slurry feed distributor and allowing the slurry to interact with the fluidization flow that enters the separation tank from the fluidization flow manifold. The gas introduction system is configured to optimize the gas bubble size distribution in the fluidization flow. The gas introduction system comprises a gas introduction conduit and a bypass conduit. The gas introduction system can be adjusted by modulating the flow of teeter water through the gas introduction conduit.
B03D 1/02 - Procédés de flottation par formation d'écume
B03B 5/62 - Lavage de matériaux en grains, en poudre ou en grumeauxSéparation par voie humide en utilisant des classificateurs hydrauliques, p. ex. des appareils de concentration à chute en spirale ou en hélice, du type à couloir ou à bassin
B03B 5/66 - Lavage de matériaux en grains, en poudre ou en grumeauxSéparation par voie humide en utilisant des classificateurs hydrauliques, p. ex. des appareils de concentration à chute en spirale ou en hélice, du type à couloir ou à bassin du genre à sédimentation entravée
What is presented is a material processing system for processing tailings discharged from an ore processing system. The tailings comprise coarse waste rock, the fine waste rock, coarse valuable product, and the fine valuable product. The material processing system comprises a classification element, a coarse flotation element, and a fines flotation element arranged to separate the coarse valuable product, the coarse waste rock, the fine valuable product, and the fine waste rock. The classification element separates the coarse waste rock and/or the coarse valuable product from the fine waste rock and/or the fine valuable product. The coarse flotation element separates the coarse waste rock from the coarse valuable product, the fine waste rock, and/or the fine valuable product. The fines flotation element separates the fine valuable product from the coarse waste rock, the fine waste rock, and/or the coarse valuable product.
B03B 5/62 - Lavage de matériaux en grains, en poudre ou en grumeauxSéparation par voie humide en utilisant des classificateurs hydrauliques, p. ex. des appareils de concentration à chute en spirale ou en hélice, du type à couloir ou à bassin
What is presented is a material processing system for processing tailings discharged from an ore processing system. The tailings comprise coarse waste rock, the fine waste rock, coarse valuable product, and the fine valuable product. The material processing system comprises a classification element, a coarse flotation element, and a fines flotation element arranged to separate the coarse valuable product, the coarse waste rock, the fine valuable product, and the fine waste rock. The classification element separates the coarse waste rock and/or the coarse valuable product from the fine waste rock and/or the fine valuable product. The coarse flotation element separates the coarse waste rock from the coarse valuable product, the fine waste rock, and/or the fine valuable product. The fines flotation element separates the fine valuable product from the coarse waste rock, the fine waste rock, and/or the coarse valuable product.
B03B 9/00 - Disposition générale d'un atelier de séparation, p. ex. schéma opératoire
B03B 5/28 - Lavage de matériaux en grains, en poudre ou en grumeauxSéparation par voie humide en utilisant des plongeants et flottants
B03B 5/66 - Lavage de matériaux en grains, en poudre ou en grumeauxSéparation par voie humide en utilisant des classificateurs hydrauliques, p. ex. des appareils de concentration à chute en spirale ou en hélice, du type à couloir ou à bassin du genre à sédimentation entravée
C22B 1/00 - Traitement préliminaire de minerais ou de débris ou déchets métalliques
B03D 1/02 - Procédés de flottation par formation d'écume
B03D 1/08 - Traitement ultérieur du produit concentré
What is claimed is a flotation separation system for partitioning a slurry. The slurry includes a hydrophobic species that can adhere to gas bubbles that form within the slurry. The flotation separation system includes a flotation separation cell. The flotation separation cell has a sparger unit and a separation tank. The separation tank is constructed to allow the bubble dispersion to form a froth at the top of the slurry contained in the separation tank. The sparger unit includes a slurry inlet, a slurry outlet, a sparging mechanism, a high shear element, and a gas inlet.
A separation system is presented that partitions a slurry containing a plurality of particles that are influenced by a fluidization flow (which comprises teeter water and gas bubbles) and a fluidized bed. The separation system comprises a separation tank, a slurry feed distributor, a fluidization flow manifold and a gas introduction system. All of these components are arranged to create the fluidized bed in the separation tank by introducing the slurry through the slurry feed distributor and allowing the slurry to interact with the fluidization flow that enters the separation tank from the fluidization flow manifold. The gas introduction system is configured to optimize the gas bubble size distribution in the fluidization flow. The gas introduction system comprises a gas introduction conduit and a bypass conduit. The gas introduction system can be adjusted by modulating the flow of teeter water through the gas introduction conduit.
A separation system is presented that partitions a slurry containing a plurality of particles that are influenced by a fluidization flow (which comprises teeter water and gas bubbles) and a fluidized bed. The separation system comprises a separation tank, a slurry feed distributor, a fluidization flow manifold and a gas introduction system. All of these components are arranged to create the fluidized bed in the separation tank by introducing the slurry through the slurry feed distributor and allowing the slurry to interact with the fluidization flow that enters the separation tank from the fluidization flow manifold. The gas introduction system is configured to optimize the gas bubble size distribution in the fluidization flow. The gas introduction system comprises a gas introduction conduit and a bypass conduit. The gas introduction system can be adjusted by modulating the flow of teeter water through the gas introduction conduit.
B03B 5/66 - Lavage de matériaux en grains, en poudre ou en grumeauxSéparation par voie humide en utilisant des classificateurs hydrauliques, p. ex. des appareils de concentration à chute en spirale ou en hélice, du type à couloir ou à bassin du genre à sédimentation entravée
B03B 11/00 - Dispositifs d'alimentation ou d'évacuation intégrés dans un matériel de lavage ou de séparation par voie humide
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
machines for separating and recovering target materials from mixtures of materials metallurgical testing services; mining engineering services; and metallurgical engineering services
Industrial machines, namely, magnetic separators in the form of suspended lift magnets for industrial use for separation magnetic solids from nonmagnetic solids
Industrial machines, namely, magnetic separators in the form of eddy current separators for industrial use for separation of magnetic solids from nonmagnetic solids
(1) Equipment in the nature of power operated permanent magnetic separators used to separate ferrous from non-ferrous materials in mixes containing both.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Machines in the nature of magnetic separators and permanent magnetic separators used to separate ferrous from non-ferrous materials in mixes containing both; separating machines, namely, machines for separating target materials from mixtures of materials. equipment in the nature of power operated permanent magnetic separators used to separate ferrous from non-ferrous materials in mixes containing both.
35.
MAGNETIC DRUM SEPARATOR WITH AN OUTER SHELL HAVING TRACTION ELEMENTS
A magnetic drum separator for the separation of ferrous and non-ferrous materials from a material stream that comprises an outer shell that is rotatable by a drive mechanism. The outer shell has a tubular length, a circular cross-section, a traction plate is joined to the outer shell, the traction plate has a traction element. In another embodiment the outer shell has a tubular length, a circular cross-section, and a integral traction element. The traction elements could be a series of negative indentations, raised bumps, perforations, serrated teeth, protruding ridges, segmented protruding ridges, minor cleats, or segmented minor cleats.
B03C 1/247 - Séparation magnétique agissant directement sur la substance à séparer le matériau étant déplacé sous l'effet de champs oscillantsSéparation magnétique agissant directement sur la substance à séparer le matériau étant déplacé sous l'effet de champs mobiles, p. ex. générés par des bobines magnétiques stationnairesSéparateurs à champ de Foucault, p. ex. à rampe glissante le matériau étant déplacé sous l'effet de champs mobiles obtenus par rotation d'un tambour magnétique
A material removal system for removing oversized materials from a material stream. This material removal system comprises a first transfer system that is used to transport a material stream, a pulley separator, and a gap that is at least as small as the length of the oversized materials that are to be removed from the material stream. Moreover, the pulley separator comprises a rotatable outer shell that has a tubular width and circular cross-section. The pulley separator is located at a discharge end of the first transfer system to create a gap that is at least as small as the length of the oversized materials to be removed.
B03C 1/20 - Séparation magnétique agissant directement sur la substance à séparer ayant des supports pour le matériau traité en forme de bandes avec des aimants se déplaçant pendant l'opération en forme de bandes, p. ex. du type à bande transversale
37.
MAGNETIC DRUM SEPARATOR WITH AN ELECTROMAGNETIC PICKUP MAGNET HAVING A CORE IN A TAPERED SHAPE
A magnetic drum separator for the separation of ferrous and nonferrous materials from a material stream comprising an outer shell that is rotatable around a central axis by a drive mechanism. A pickup magnet, that is an electromagnet, is positioned at a fixed location within a circular cross-section and having a cross-section that is perpendicular to the central axis in which a first end is closest to the inner circumference of the outer shell and a second end is located near the central axis. The pickup magnet comprises a core, and a backbar abutting the core at the second end. The core comprising a plurality of blocks, each block of different widths, in a cross-section perpendicular to the central axis, with the narrowest of the blocks at the first end and the widest of said blocks abutting the backbar.
Industrial machines, namely, magnetic separators in the form of suspended electromagnets for industrial use for separating magnetic solids from nonmagnetic solids.
40.
PROCESS FOR IMPROVING THE QUALITY OF SEPARATED MATERIALS IN THE SCRAP METAL INDUSTRY
What is presented is a process for scrap metal processing for shredding and sorting recoverable material from a material stream that comprises a ferrous fraction, a non-ferrous fraction, a waste fraction and a less ferrous fraction that includes composite materials. The process comprises first shredding the material stream with a first shredder to a size that enables downstream processing. The shredded material stream is then conveyed to at least one drum separator to remove the non-ferrous fraction from the material stream and then conveyed to a first conveyor separator to further separate the ferrous fraction from the material stream. At the completion of these steps the remaining material stream to be handled by downstream processes represents 10% to 40% of the original material stream as compared to 70% to 75% of the material stream in the prior art.
B03B 7/00 - Combinaisons de procédés ou d'appareils opérant par voie humide, avec d'autres procédés ou appareils, p. ex. pour la préparation des minerais ou cendres
41.
Process for improving the quality of separated materials in the scrap metal industry
What is presented is a process for scrap metal processing for shredding and sorting recoverable material from a material stream that comprises a ferrous fraction, a non-ferrous fraction, a waste fraction and a less ferrous fraction that includes composite materials. The process comprises first shredding the material stream with a first shredder to a size that enables downstream processing. The shredded material stream is then conveyed to at least one drum separator to remove the non-ferrous fraction from the material stream and then conveyed to a first conveyor separator to further separate the ferrous fraction from the material stream. At the completion of these steps the remaining material stream to be handled by downstream processes represents 10% to 40% of the original material stream as compared to 70% to 75% of the material stream in the prior art.
B02C 23/14 - Séparation ou triage de matériaux, associé au broyage ou à la désagrégation au moyen de plusieurs séparateurs
B03C 1/18 - Séparation magnétique agissant directement sur la substance à séparer ayant des supports pour le matériau traité en forme de bandes avec des aimants se déplaçant pendant l'opération
B03C 1/30 - Combinaisons avec d'autres dispositifs, non prévues ailleurs
B03C 1/247 - Séparation magnétique agissant directement sur la substance à séparer le matériau étant déplacé sous l'effet de champs oscillantsSéparation magnétique agissant directement sur la substance à séparer le matériau étant déplacé sous l'effet de champs mobiles, p. ex. générés par des bobines magnétiques stationnairesSéparateurs à champ de Foucault, p. ex. à rampe glissante le matériau étant déplacé sous l'effet de champs mobiles obtenus par rotation d'un tambour magnétique
B03B 9/06 - Disposition générale d'un atelier de séparation, p. ex. schéma opératoire spécialement adapté aux ordures
C22B 1/00 - Traitement préliminaire de minerais ou de débris ou déchets métalliques
INDUSTRIAL MACHINES, NAMELY, MAGNETIC SEPARATORS IN THE FORM OF SUSPENDED ELECTROMAGNETS FOR INDUSTRIAL USE FOR SEPARATING MAGNETIC SOLIDS FROM NONMAGNETIC SOLIDS
What is presented is a permanent magnet drum separator for removal of a ferrous fraction from a material stream comprising a pickup magnet that is a rare earth permanent magnet that can be moved within the drum separator. The drum separator comprises a rotatable outer shell having tubular shape with a circular cross section. The drum separator includes a carry magnet that is positioned at a fixed location within the rotatable outer shell near the inside circumference of the rotatable outer shell. The pickup magnet is positioned on a hinge plate within the rotatable outer shell. The hinge plate has a first end attached to a hinge and a second end attached to a movable element. The hinge is positioned at a fixed location within the rotatable outer shell near the inside circumference of said rotatable outer shell. The movable element is able to move the pickup magnet about the hinge to vary the distance between the pickup magnet and the inside circumference of the rotatable outer shell.
B03C 1/16 - Séparation magnétique agissant directement sur la substance à séparer ayant des supports pour le matériau traité en forme de bandes
B03C 1/247 - Séparation magnétique agissant directement sur la substance à séparer le matériau étant déplacé sous l'effet de champs oscillantsSéparation magnétique agissant directement sur la substance à séparer le matériau étant déplacé sous l'effet de champs mobiles, p. ex. générés par des bobines magnétiques stationnairesSéparateurs à champ de Foucault, p. ex. à rampe glissante le matériau étant déplacé sous l'effet de champs mobiles obtenus par rotation d'un tambour magnétique
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Installation, maintenance and repair of machines and equipment that moves, removes or concentrates material; feeds, screens or conveys materials; and inspects products by metal detection or x-ray technology for the process and metalworking industries
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Installation, maintenance and repair of machines and equipment that moves, removes or concentrates material; feeds, screens or conveys materials; and inspects products by metal detection or x-ray technology for the process and metalworking industries
(1) Equipment namely mechanical metal sorting machines used to separate different types of pieces of nonferrous metal from other materials in mixes containing both for use in recycling.
Equipment in the nature of mechanical metal sorting machines used to separate different types of pieces of nonferrous metal from other materials in mixes containing both for use in recycling.
Equipment in the nature of mechanical metal sorting machines used to separate different types of pieces of nonferrous metal from other materials in mixes containing both for use in recycling.
Equipment in the nature of mechanical metal sorting machines used to separate different types of pieces of nonferrous metal from other materials in mixes containing both for use in recycling
(1) Equipment namely mechanical metal sorting machines used to separate different types of pieces of nonferrous metal from other materials in mixes containing both for use in recycling.
Equipment in the nature of mechanical metal sorting machines used to separate different types of pieces of nonferrous metal from other materials in mixes containing both for use in recycling
A lifting electrode for a high-tension electrostatic separator. The high tension electrostatic separator having a rotating drum that is connected to ground and an ionizing electrode that generates a corona discharge of charged ions. The lifting electrode comprising a composite of a non-conductive polymer impregnated with conductive particles.
B04B 5/10 - Centrifugeurs combinés avec d'autres appareils, p. ex. avec des séparateurs électrostatiquesEnsembles ou systèmes de plusieurs centrifugeurs
A method and system of sorting materials from a material stream on a sorter is provided. The material stream includes a plurality of components and the sorter is able to detect and sort at least one component in the material stream. The sorter includes a first detection zone and an adjacent second detection zone on the sorter. Each detection zone sorts at least one component from the material stream. The material stream is introduced to the first detection zone of the sorter. The sorter substantially sorts at least one component from the material stream in the first detection zone by removing at least one component of the material stream from the sorter. The remaining material stream is returned to the second detection zone of the sorter where it is substantially sorted by removing at least one component of the remaining material stream from the sorter.
B07C 5/00 - Tri selon une caractéristique ou une particularité des objets ou du matériau à trier, p. ex. tri commandé par un dispositif qui détecte ou mesure cette caractéristique ou particularitéTri à l'aide de dispositifs manœuvrés à la main, p. ex. d'aiguillages
A motorized paddle assembly for a material sorter is presented. The motorized paddle assembly comprises a paddle, internal mechanisms, and a housing that encloses the internal mechanisms. The paddle is attached to a circular hinge to enable the circular hinge and the paddle to rotate about an axis. The motorized paddle assembly includes an upper plate for the circular hinge. The upper plate allows the free rotation of the circular hinge while substantially preventing unwanted material from falling behind the circular hinge. In a series of adjacent motorized paddle assemblies, a gasket is mounted between adjacent motorized paddle assemblies to substantially prevent unwanted material from falling between the adjacent motorized paddle assemblies.
B07C 5/00 - Tri selon une caractéristique ou une particularité des objets ou du matériau à trier, p. ex. tri commandé par un dispositif qui détecte ou mesure cette caractéristique ou particularitéTri à l'aide de dispositifs manœuvrés à la main, p. ex. d'aiguillages
A control module is presented for a sorter for sorting materials from a material stream that can include a plurality of types of materials. The sorter comprises at least two control modules and each control module includes control circuitry, at least two sensors, and a corresponding sorting assembly for each sensor. Each sensor is capable of detecting at least one type of material in the material stream and is capable of transmitting data to and receiving signals from the control circuitry. Each sorting assembly is capable of being actuated by the control circuitry to substantially sort materials from the material stream based on the readings of the sensors. The control circuitry is capable of receiving signals from and transmitting signals to each sensor and each sorting assembly.
A flotation separation system for partitioning a slurry that includes a hydrophobic species which can adhere to gas bubbles formed in the slurry. The flotation separation system comprises a flotation separation cell including a sparger unit and separation tank. The sparger unit has inlets for slurry and for a gas with at least enough pressure to allow bubbles to form in the slurry within the sparger unit. The sparger unit includes a sparging mechanism constructed to disperse gas bubbles within the slurry. The sparging mechanism sparges the gas bubbles to form a bubble dispersion to cause adhesion of the hydrophobic species to the gas bubbles substantially within the sparger unit while causing a pressure drop of about 10 psig or less across the sparging mechanism. The sparger unit includes a slurr outlet to discharge the slurry and the bubble dispersion into the separation tank.
A flotation separation system is provided for partitioning a slurry that includes a hydrophobic species which can adhere to gas bubbles formed in the slurry. The flotation separation system comprises a flotation separation cell that includes a sparger unit and a separation tank. The sparger unit has a slurry inlet for receiving slurry and a gas inlet to receive gas with at least enough pressure to allow bubbles to form in the slurry within the sparger unit. The sparger unit includes a sparging mechanism constructed to disperse gas bubbles within the slurry. The sparging mechanism sparges the gas bubbles to form a bubble dispersion so as to cause adhesion of the hydrophobic species to the gas bubbles substantially within the sparger unit while causing a pressure drop of about 10 psig or less across the sparging mechanism. The sparger unit includes a slurry outlet to discharge the slurry and the bubble dispersion into the separation tank.
The tie bar supporting a feed tray (moving mass) is attached to the reaction mass using one leaf spring and one elastomeric spring. The elastomeric spring comprises first and second elastomeric pads which sandwich a portion of the tie bar to which the feed tray is attached. The elastomeric spring operates in shear with the spring rate of the elastomeric spring being adjusted by increasing/decreasing the compressive force exerted by the first and second elastomeric pads on the tie bar. The adjustable vibratory feeder has demonstrated greatly enhanced stability over other existing systems.
equipment in the nature of mechanical metal sorting machines used to separate different types of fine pieces of metal from other materials in mixes containing both for use in recycling
17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
Produits et services
Plastic composite material in the form of profiles, boards, sheets, blocks, rods, powder, and pellets for use in manufacturing, said plastic composite including trace amounts of a magnetized element permitting separation during recycling
09 - Appareils et instruments scientifiques et électriques
Produits et services
Magnetic separators, superconductive magnetic separators, magnetic separators for industrial use, magnetic separators for separating magnetic particles from non- magnetic solids and liquids, and magnetic separators using rare earth materials; magnetic conveyors, magnetic head pullevs for holding, controlling and moving ferrous materials in magnetic conveyors; electromagnetic and mechanical feeders and magnetic components for feeding, conveying and controlling ferrous parts; vibrating screen separators having horizontal, vertical and giratory motion components for use in grading, separating and screening wet and dry materials or objets; cleaning machines, road sweepers and floor sweepers, all incorporating magnets. Magnetic vibrators, lifting magnets and metal detectors; permanent non-electric magnets, permanent magnetic power castings, pressings, extrusions, and moldings which include various types of permanent magnet material; elongated single domain magnets, ceramic magnets, rubber magnets and plastic magnets; and, magnetic racks for supporting articles of manufacture as they are conveyed from point to point during processing such as dipping, spray painting, coating, plating, washing and the like.
09 - Appareils et instruments scientifiques et électriques
Produits et services
Machines and machine tools; motors (except for land vehicles); machine coupling and transmission components (except for land vehicles); agricultural implements; incubators for eggs; magnetic separators, superconductive magnetic separators, magnetic separators for industrial use, magnetic separators for separating magnetic particles from non-magnetic solids and liquids, and magnetic separators using rare earth materials; magnetic conveyors, magnetic head pulleys for holding, controlling and moving ferrous materials in magnetic conveyors; electromagnetic and mechanical feeders and magnetic components for feeding, conveying and controlling ferrous parts; vibrating screen separators having horizontal, vertical and gyratory motion components for use in grading, separating, and screening wet and dry materials or objects; cleaning machines, road sweepers and floor sweepers, all incorporating magnets. Scientific, nautical, surveying, electric, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; apparatus for recording, transmission or reproduction of sound or images; magnetic data carriers, recording discs; automatic vending machines and mechanisms for coin-operated apparatus; cash registers, calculating machines, data processing equipment and computers; fire-extinguishing apparatus; magnetic vibrators, lifting magnets and metal detectors; permanent non-electric magnets, permanent magnetic power castings, pressings, extrusions, and moldings which include various types of permanent magnet materials; elongated single domain magnets, ceramic magnets, rubber magnets and plastic magnets; and magnetic racks for supporting articles of manufacture as they are conveyed from point to point during processing such as dipping, spray painting, coating, plating, washing and the like.
09 - Appareils et instruments scientifiques et électriques
Produits et services
magnetic vibrators, lifting magnets and metal detectors, permanent non-electric magnets, permanent magnetic power castings, pressings, extrusions, and moldings which include various types of permanent magnet material, elongated single domain magnets, ceramic magnets, rubber magnets, plastic magnets, vibrating screen separators having horizontal, vertical and gyratory motion components for use in grading, separating and screening wet and dry materials or objects superconductive magnetic separators, magnetic separators for industrial use for separating magnetic particles from non-magnetic solids and liquids, magnetic separators using rare earth materials, magnetic conveyors, magnetic head pulleys for holding, controlling and moving ferrous materials in magnetic conveyors, electromagnetic and mechanical feeders and magnetic components for feeding, conveying and controlling ferrous parts
09 - Appareils et instruments scientifiques et électriques
10 - Appareils et instruments médicaux
17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
21 - Ustensiles, récipients, matériaux pour le ménage; verre; porcelaine; faience
Produits et services
(1) Magnetic separators for industrial use for separating magnetic particles from non-magnetic solids and liquids, magnetic separators using rare earth materials, magnetic conveyors, magnetic head pulleys for holding, controlling and moving ferrous materials in magnetic conveyors, electromagnetic and mechanical feeders and magnetic components for feeding, conveying and controlling ferrous parts, vibrating screen separators having horizontal, vertical and gyratory motion components for use in grading, separating and screening wet and dry materials or objects; magnetic vibrators, lifting magnets and metal detectors, permanent non-electric magnets, permanent magnetic power castings, pressings, extrusions, and moldings which include various types of permanent magnet material, ceramics, magnetic rubber and plastics, and magnetic racks for supporting articles of manufacture as they are conveyed from point to point and during processing such as dipping, spray painting, coating, plating, washing and the like.
09 - Appareils et instruments scientifiques et électriques
Produits et services
(1) Superconductive magnetic separators, magnetic separators for industrial use for separating magnetic particles from non-magnetic solids and liquids, magnetic separators using rare earth materials, magnetic conveyors, magnetic head pulleys for holding, controlling and moving ferrous materials in magnetic conveyors, electromagnetic and mechanical feeders and magnets for feeding, conveying and controlling ferrous parts; permanent magnetic power castings, pressings, extrusions, and moldings which include various types of permanent magnet material; vibrating screen separators having horizontal, vertical and gyratory motion components for use in grading, separating and screening wet and dry materials or objects; and magnetic racks for supporting articles of manufacture as they are conveyed from point to point and during processing such as dipping, spray painting, coating, plating, washing, and the like; magnetic vibrators.
(2) Lifting magnets, metal detectors, permanent non-electric magnets; elongated single domain magnets.
09 - Appareils et instruments scientifiques et électriques
Produits et services
VIBRATING SCREEN SEPARATORS HAVING HORIZONTAL, VERTICAL AND GYRATORY MOTION COMPONENTS FOR USE IN GRADING, SEPARATING AND SCREENING WET AND DRY MATERIALS OR OBJECTS; AND MECHANICAL FEEDERS FOR FEEDING, CONVEYING AND CONTROLLING FERROUS PARTS SUPERCONDUCTIVE MAGNETIC SEPARATORS; MAGNETIC SEPARATORS FOR INDUSTRIAL USE FOR SEPARATING MAGNETIC PARTICLES FROM NON-MAGNETIC SOLIDS AND LIQUIDS; MAGNETIC SEPARATORS USING RARE EARTH MATERIALS; MAGNETIC CONVEYORS; MAGNETIC HEAD PULLEYS FOR HOLDING, CONTROLLING AND MOVING FERROUS MATERIALS IN MAGNETIC CONVEYORS; ELECTROMAGNETIC FEEDERS AND MAGNETS FOR FEEDING, CONVEYING AND CONTROLLING FERROUS PARTS; MAGNETIC VIBRATORS; LIFTING MAGNETS; METAL DETECTORS; PERMANENT NON-ELECTRIC MAGNETS; PERMANENT MAGNETIC POWER CASTINGS, [ PRESSINGS, EXTRUSIONS, AND MOLDINGS ] WHICH INCLUDE VARIOUS TYPES OF PERMANENT MAGNET MATERIAL; ELONGATED SINGLE DOMAIN MAGNETS; AND MAGNETIC RACKS FOR SUPPORTING ARTICLES OF MANUFACTURE AS THEY ARE CONVEYED FROM POINT TO POINT AND DURING PROCESSING SUCH AS DIPPING, SPRAY PAINTING, COATING, PLATING, WASHING AND THE LIKE
09 - Appareils et instruments scientifiques et électriques
30 - Aliments de base, thé, café, pâtisseries et confiseries
Produits et services
(1) Permanent plate magnets, vibrators for bins, hoppers, and chutes; permanent magnetic rails, rolls, drums, pulleys, and magnetic separators for removing tramp iron from non-magnetic material, magnetic grates, vibrator mountings, electrically powered magnets.
