Abrégé

Plant cultivation system comprising a cultivation container, a plurality of cultivation trays for cultivating the plants, which are arranged on a series of cultivation planes arranged one on top the other with respective pre-set heights relative to a horizontal reference plane, a box-shaped air distribution duct having two air diffusion walls which extend approximately vertically in the cultivation container and which are parallel to each other and dimensioned so as to be adjacent to the cultivation trays. The air diffusion walls are facing the respective cultivation trays in the cultivation planes and have a plurality of through openings which are facing the respective cultivation trays and are designed to selectively convey the conditioned air from the air distribution duct to the same.

Classes IPC  ?

• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

System for cutting and collecting vegetable products arranged on at least one cultivation shelf. The cultivation shelf has a base to which root portions of the products cling, and a cultivation face opposite the base and from which epigeal portions of the vegetable products extend. The system has: a loading station to support the cultivation shelf in an upside down position, wherein the base is arranged above the cultivation face so that the epigeal portions of the products extend from the cultivation face below the relative root portions and remain suspended and extended by gravity below the cultivation face; a cutting unit to cut the epigeal portions suspended below the cultivation face, so as to separate them by gravity from the root portions clinging to the base of the cultivation shelf; and a collection station to collect the epigeal portions cut and separated by gravity from the cultivation shelf.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet

Abrégé

The invention concerns a system for cultivating plant products without soil comprising a plurality of shelves for cultivating plant products. The shelves have a reference axis and comprise: a supporting frame, a plurality of cultivation bars which have an approximately rectilinear shape, extend along respective longitudinal axes, and are coupled to the supporting frame so as to be arranged approximately coplanar and alongside one another, and have the respective longitudinal axes parallel to the reference axis and mechanical spacing members, which are interleaved between the adjacent cultivation bars, and are each structured so that the actuation of a mechanical spacing member causes a variation of the distance transverse to the reference axis, between two cultivation bars immediately adjacent to the same member. The invention also concerns a method for cultivating plant products.

Classes IPC  ?

• A01G 31/04 - Culture hydroponique sur des transporteurs

Abrégé

A method for cultivating plant products without soil, comprising the following steps: preparing at least one cultivation shelf, which comprises one or more seeding and growth bars made of plastic material, which are provided with seats adapted to house seeds and have on the corresponding bottom walls a through opening structured for being traversed by, and remaining in direct contact with, the roots of the plant product during growth thereof, arranging seeds within the seats in direct contact with the inner surface of said seats, without any interposition of one or more support/gripping layers of the roots of the plant products, supplying the bars with fertilizer-based substances.

Classes IPC  ?

• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

A system for cultivating plants comprising a plurality of cultivation shelves for cultivating plants, support frames structured to support the cultivation shelves so as to form one or more horizontal cultivation planes that develop along a first horizontal direction, an aeroponic feeding system, which is provided with nebulizing devices that are arranged at the cultivation shelves for spraying the liquid towards the cultivation shelves themselves, and a suction duct arranged at the nebulizing devices to suck up the nebulised liquid dispersed by the same.

Classes IPC  ?

• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés
• A01G 9/02 - Récipients, p. ex. pots ou jardinières Verres pour la culture des fleurs
• A01G 27/00 - Dispositifs automatiques d'arrosage, p. ex. pour pots de fleurs
• A01G 31/00 - Culture hors-sol, p. ex. hydroponie
• A01G 31/02 - Appareils particuliers à cet effet

Abrégé

Plant cultivation system (1) comprising a cultivation container (2), a plurality of cultivation trays (5) for cultivating the plants, which are arranged on a series of cultivation planes (Li) arranged one on top the other with respective pre-set heights relative to a horizontal reference plane (Z), a box-shaped air distribution duct (9) having two air diffusion walls (10) which extend approximately vertically in the cultivation container (2) and which are parallel to each other and dimensioned so as to be adjacent to the cultivation trays (5). The air diffusion walls (10) are facing the respective cultivation trays (5) in the cultivation planes and have a plurality of through openings (14) which are facing the respective cultivation trays (5) and are designed to selectively convey the conditioned air from the air distribution duct (9) to the same.

Classes IPC  ?

• A01G 9/24 - Dispositifs de chauffage, d'aération, de régulation de la température ou d'irrigation dans les serres, les châssis ou les installations similaires
• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

The invention concerns a system (1) for cultivating plant products without soil comprising a plurality of shelves (6) for cultivating plant products. The shelves (6) have a reference axis (A) and comprise: a supporting frame (7), a plurality of cultivation bars (9) which have an approximately rectilinear shape, extend along respective longitudinal axes, and are coupled to the supporting frame so as to be arranged approximately coplanar and alongside one another, and have the respective longitudinal axes (B) parallel to the reference axis (A) and mechanical spacing members (9), which are interleaved between the adjacent cultivation bars (8), and are each structured so that the actuation of a mechanical spacing member (9) causes a variation of the distance transverse to the reference axis (A), between two cultivation bars immediately adjacent to the same member. The invention also concerns a method for cultivating plant products.

Classes IPC  ?

• A01G 31/04 - Culture hydroponique sur des transporteurs

Produits et services

Processed fruits, fungi and vegetables (including nuts and pulses); Vegetables, processed; Frozen vegetables; Pre-cut vegetables; Preserved vegetables (in oil); Snack foods based on vegetables; Legume-based spreads; Vegetables, processed; Vegetable spreads; Cut vegetables; Mixed vegetables; Vegetables, tinned; Pickled vegetables; Vegetable salads; Pre-cut vegetables for salads; Pre-cut vegetable salads; Snack foods based on legumes; Vegetable-based entrees; Prepared vegetable dishes; Prepared meals consisting principally of vegetables; Vegetable juice concentrates for food; Jellies, jams, compotes, fruit and vegetable spreads; Cut fruits; Fruit, stewed; Milk shakes; Fruit, preserved; Frozen fruits; Fruit, processed; Fruit marmalade; Fruit salads; Fruits, tinned; Nut-based snack foods; Fruit-based snack food; Prepared salads; Legume salads; Caesar salad; Potato-based salads; Antipasto salads; Extracts of vegetables [juices] for cooking; Seaweed extracts for food; Fruit juices for cooking; Vegetable juices for cooking. Rice-based prepared meals; Pasta-based prepared meals; Salad cream; Pesto; Ready-made sauces; Sauces [condiments]; Dressings for salad; Canned sauces; Mixes for preparing sauces; Gravy mixes; Herb sauces; Pasta sauce; Cooking sauces; Fruit coulis [sauces]; Preparations for making up into sauces; Vegetable purees [sauces]; Vegetable pastes [sauces]; Flavourings in the form of dehydrated sauces; Flavourings in the form of concentrated sauces; Prepared foodstuffs in the form of sauces; Seaweed [condiment]; Dried herbs; Herbal infusions; Dried herbs for culinary purposes; Infusions, not medicinal; Herbal flavourings for making beverages; Herbal preparations for making beverages; Bases for making milk shakes [flavourings]; Frappes; Chicory extracts for use as substitutes for coffee. Fresh fruits and vegetables; Salad vegetables [fresh]; Unprocessed vegetables; Unprocessed vegetables; Garden herbs, fresh; Garden herbs, fresh; Garden herbs, fresh; Lettuce, fresh; Lettuce, fresh; Fresh parsley; Fresh bamboo shoots; Flowers; Mushrooms, fresh; Unprocessed fruits; Fresh chives; Fresh pulses; Vegetables, fresh; Berries, fresh; Fresh arugula; Garden salads; Fresh leafy Asian vegetables; Mint [fresh]; Soya beans, fresh; Ginger, fresh; Rhubarb, fresh; Fresh ginseng; Fresh basil; Fresh cilantro; Fresh sage; Fresh thyme; Fresh rosemary; Fresh oregano; Fresh radicchio; Fruit, fresh; Chicory, fresh; Organic fresh vegetables; Organic fresh herbs; Plants; Fresh plants; Organic fresh fruit. Vegetable smoothies; Smoothies; Smoothies; Vegetable drinks; Soft drinks; Fruit drinks; Non-alcoholic fruit drinks; Non-alcoholic fruit extracts; Extracts of hops for making beer; Non-alcoholic fruit extracts used in the preparation of beverages; Aerated juices; Concentrated juices (non-alcoholic); Vegetable juices [beverages]; Vegetable juices [beverages]; Juices; Aloe vera juices.

Abrégé

A system for cultivating plants (1) comprising a plurality of cultivation shelves (4) for cultivating plants, support frames (3) structured to support the cultivation shelves (4) so as to form one or more horizontal cultivation planes (Li) that develop along a first horizontal direction (K), an aeroponic feeding system (6), which is provided with nebulizing devices (8) that are arranged at the cultivation shelves (4) for spraying the liquid towards the cultivation shelves (4) themselves, and a suction duct (15) arranged at the nebulizing devices (8) to suck up the nebulised liquid dispersed by the same.

Classes IPC  ?

• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Produits et services

Shop window dressing; Business project management; Project studies for businesses; Design of advertising materials; Business management assistance; Providing advice relating to sales methods and techniques; Professional consultancy relating to business management; Business appraisal consultancy; Corporate image development consultation; Business consulting. Design services; Testing, authentication and quality control; Analysis of product design; Analysis of product development; New products (Testing of -); Design of shops; Planning [design] of shops; Shop interior design; Design services relating to shop displays; Retail design services; Design of interior decor for shops; Shopfitting design consultancy services; Planning and design of retail premises; Industrial design; Design services for furniture; Interior decoration consultation; Design services relating to interior decorating for homes; Advisory services relating to interior design; Professional consultancy relating to the design of interior accommodation; Design of three dimensional displays; Industrial research; Research services; Research into new products; Engineering consultancy relating to manufacture; Visual design; Engineering design; Architectural design; Product design; Design of models; Design services for exhibitions; Conducting technical project studies; Technical project planning; Custom design services; Commercial interior design; New product design; Design of ornamental structures; Design of industrial products; Technical design; Services for the design of business premises; Interior design services for boutiques; Product design and development; Development of construction projects; Design of lighting systems; Design feasibility studies; Graphic design of promotional materials; Consultation services relating to interior design; Engineering project management services; Engineering consultancy relating to design; Technical research projects and studies; Design and development of new products.

Abrégé

A method for cultivating plant products without soil, comprising the following steps: preparing at least one cultivation shelf (7), which comprises one or more seeding and growth bars (9) made of plastic material, which are provided with seats (10) adapted to house seeds (SM) and have on the corresponding bottom walls (11) a through opening (12) structured for being traversed by, and remaining in direct contact with, the roots of the plant product during growth thereof, arranging seeds (SM) within the seats (10) in direct contact with the inner surface of said seats (10), without any interposition of one or more support/gripping layers of the roots of the plant products supplying the bars (9) with fertilizer- based substances.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet
• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

A modular vertical farm system for no-soil cultivation (1) (1A) (1B) of vegetable products comprising a cultivation module (2) and a control module (3). The cultivation module (2) comprises: a closed cultivation container (4), modular cultivation structures (5) with vertical architecture, a modular fertigation system (13), lighting devices (16) to light said vegetable products, an air distribution system (15) designed to receive conditioned air and convey it into said cultivation container, sensor devices (8) configured to provide data/signals indicative of cultivation parameters controlled during the growing process. The control module (3) comprises: a control container (23) internally containing: a fertigation unit (24), designed to supply said fertilizer-based substances, a climate control unit (25) designed to supply conditioned air, and an electronic control system (26).

Classes IPC  ?

• A01G 9/24 - Dispositifs de chauffage, d'aération, de régulation de la température ou d'irrigation dans les serres, les châssis ou les installations similaires
• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Produits et services

Agricultural machines; Robotic mechanisms used in agriculture; Agricultural, gardening and forestry machines and apparatus; Sprayers for use in agriculture [parts of machines]; Sprayers [machines] for use in agriculture; Agricultural machines for cultivating; Tilling machines for agricultural purposes; Agricultural implements, other than hand-operated; Agricultural implements other than hand operated hand tools; Spray lances being agricultural implements; Horticultural machines; Horticultural implements [machines]; Spray rollers being horticultural implements; Sprticval ayers [machines] for use in horticulture; Sprayers for use in horticulture [parts of machines]; Spray lances being horticultural implements; all the aforementioned goods for soiless cultivation and vertical farming; all the aforesaid goods not for use in viticulture. Computer application software for use in implementing the Internet of Things [IoT]; Computer hardware modules for use in electronic devices using the Internet of Things [IoT]; Electronic control units; Electronic control systems; Programmable controllers; Sensors used in plant control; Process controlling apparatus [electronic]; Process controlling software; Machine control software; Cloud computing software relating to the fields of vertical farming, vertical agriculture and vertical horticulture; Cloud network monitoring software; Electronic data processing equipment; Data and file management and database software relating to the fields of vertical farming, vertical agriculture and vertical horticulture; Data storage devices and media; Database server software relating to the fields of vertical farming, vertical agriculture and vertical horticulture; Data management software relating to the fields of vertical farming, vertical agriculture and vertical horticulture; Data mining software relating to the fields of vertical farming, vertical agriculture and vertical horticulture; Data processing programs relating to the fields of vertical farming, vertical agriculture and vertical horticulture; Databases relating to the fields of vertical farming, vertical agriculture and vertical horticulture; Data storage devices; Computer programmes for data processing relating to the fields of vertical farming, vertical agriculture and vertical horticulture; Data collection apparatus; Data storage programs relating to the fields of vertical farming, vertical agriculture and vertical horticulture; Data processing equipment; Computer software to enable the searching of data relating to the fields of vertical farming, vertical agriculture and vertical horticulture; Data storage media; Data recorded electronically from the internet. Research relating to cultivation in agriculture; Integrated scientific research on vermin for greenhouses and harvest crops; Testing on agriculture; Agricultural research; Biotechnological research relating to agriculture; Quality control testing services for agricultural machinery; Laboratory services for agricultural research; Inspection of agriculture; Biotechnological research relating to horticulture; Quality control testing services for horticultural equipment; Research relating to cultivation in horticulture; Software as a service [SaaS] relating to the fields of vertical farming, vertical agriculture and vertical horticulture; Software creation; Software development; Customized design of computer software; Computer software programming services; Hosting services, software as a service, and rental of software relating to the fields of vertical farming, vertical agriculture and vertical horticulture; Technological research; Research relating to biotechnology; Biological research; Technological research relating to computers; Industrial process research; Pharmaceutical research services; Scientific research relating to cosmetics; Research relating to industrial machinery; Technical research.

Produits et services

Processed fruits, fungi and vegetables (including nuts and pulses); Processed vegetables; Frozen vegetables; Pre-cut vegetables; Preserved vegetables (in oil); Snack foods based on vegetables; Legume-based spreads; Vegetable spreads; Cut vegetables; Mixed vegetables; Vegetables, tinned; Pickled vegetables; Vegetable salads; Pre-cut vegetables for salads; Pre-cut vegetable salads; Snack foods based on legumes; Vegetable-based entrees; Prepared vegetable dishes; Prepared meals consisting principally of vegetables; Vegetable juice concentrates for food; Jellies, jams, compotes, fruit and vegetable spreads; Cut fruits; Fruit, stewed; Milk shakes; Fruit, preserved; Frozen fruits; Prepared fruits; Fruit marmalade; Fruit salads; Fruits, tinned; Nut-based snack foods; Fruit-based snack food; Prepared salads; Legume salads; Caesar salad. Fresh fruits and vegetables; Salad vegetables [fresh]; Unprocessed vegetables; Garden herbs, fresh; Lettuce, fresh; Fresh parsley; Fresh bamboo shoots; Flowers; Mushrooms, fresh; Unprocessed fruits; Fresh chives; Fresh pulses; Vegetables, fresh; Berries, fresh; Fresh arugula; Garden salads; Fresh leafy Asian vegetables; Mint [fresh]; Fresh soya beans; Fresh ginger; Rhubarb, fresh; Fresh ginseng; Fresh basil; Fresh cilantro; Fresh sage; Fresh thyme; Fresh rosemary; Fresh oregano; Fresh radicchio; Fruit, fresh; Chicory, fresh; Organic fresh vegetables; Organic fresh herbs; Plants; Fresh plants; Organic fresh fruit.

Abrégé

A system for cultivating plants (1) comprising a plurality of cultivation shelves (4) for cultivating plants, support frames (3) structured to support the cultivation shelves (4) so as to form one or more horizontal cultivation planes (Li) that develop along a first horizontal direction (K), an aeroponic feeding system (6), which is provided with nebulizing devices (8) that are arranged at the cultivation shelves (4) for spraying the liquid towards the cultivation shelves (4) themselves, and a suction duct (15) arranged at the nebulizing devices (8) to suck up the nebulised liquid dispersed by the same.

Classes IPC  ?

• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

Plant cultivation system (1) comprising a cultivation container (2), a plurality of cultivation trays (5) for cultivating the plants, which are arranged on a series of cultivation planes (Li) arranged one on top the other with respective pre-set heights relative to a horizontal reference plane (Z), a box-shaped air distribution duct (9) having two air diffusion walls (10) which extend approximately vertically in the cultivation container (2) and which are parallel to each other and dimensioned so as to be adjacent to the cultivation trays (5). The air diffusion walls (10) are facing the respective cultivation trays (5) in the cultivation planes and have a plurality of through openings (14) which are facing the respective cultivation trays (5) and are designed to selectively convey the conditioned air from the air distribution duct (9) to the same.

Classes IPC  ?

• A01G 9/24 - Dispositifs de chauffage, d'aération, de régulation de la température ou d'irrigation dans les serres, les châssis ou les installations similaires
• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

A method for cultivating plant products without soil, comprising the following steps: preparing at least one cultivation shelf (7), which comprises one or more seeding and growth bars (9) made of plastic material, which are provided with seats (10) adapted to house seeds (SM) and have on the corresponding bottom walls (11) a through opening (12) structured for being traversed by, and remaining in direct contact with, the roots of the plant product during growth thereof, arranging seeds (SM) within the seats (10) in direct contact with the inner surface of said seats (10), without any interposition of one or more support/gripping layers of the roots of the plant products supplying the bars (9) with fertilizer- based substances.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet
• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés
