The invention relates to a hinge part (2) for a hinge arrangement (100), in particular for a concealed hinge arrangement for rotatably fastening a door or window sash (50) to a door or window frame (40) about an articulation axis (S), with a fastening part (20) for fastening to the sash (50) or frame (40) and with an articulation part (21). According to the invention, the fastening part (20) has a form-fit part (3) and a locking screw (4, 4'), wherein the locking screw (4, 4') can be brought into operative connection with the form-fit part (3).
The invention relates to a system (100) comprising a hollow profiled section (18) with a securing wall (17), at least one inner wall (17a), and at least one strap part (1) of a strap hinge, said strap part being secured to the securing wall (17). The strap part (1) comprises an installation part (11) that can be attached to the hollow profiled section (18) in a stationary manner and has multiple positioning protrusions (21), at least one of which has an expansion dowel-type design, and an adjustment part (2), which can be displaced relative to the installation part (11) in a displacement direction (V) and which can be fixed in a desired displacement position. The invention is characterized in that the positioning protrusions (21) are adapted to the hollow profiled section (18) such that the positioning protrusions only engage into holes (22) provided in the securing wall (17).
Proposed is a flap part (1) of a flap hinge, said flap part being fastenable to a fastening wall (17) of a frame (R) or of a leaf (F), wherein the flap part (1) has an installation part (11), which is fixedly attachable to the fastening wall, and an adjustment part (2), which is displaceable in a displacement direction (V) relative to the installation part (11) and is fixable in a desired displacement position, wherein the installation part (11) comprises a device by which it engages with a rectilinear guide (5) of the adjustment part (2), said rectilinear guide comprising mutually opposite and mutually parallel guide surfaces (29), characterized in that the device comprises a guide element (16) which has two mutually parallel counterpart guide surfaces (30), the mutual spacing (A) of which can be increased at least in certain regions.
The invention relates to a band part (1) of a band (100) for the hinged connection, about a hinge axis (S), of a sash to a frame, with a mounting part (3) that can be fastened to the sash or frame, and with a hinge part (2) that can be mounted on the mounting part (3) and can be displaced in at least one adjusting direction (Z) relative to the mounting part (3), wherein one of the hinge part (2) and mounting part (3) has a form-fit element (4) having at least one projection (41, 41', 41'', 41''') and the other of the hinge part (2) and the mounting part (3) has a second form-fit element (5) having at least one recess (51, 51', 51'', 51''') that corresponds to the projection (41, 41', 41'', 41'''). To mount the hinge part (2) on the mounting part (3), the first form-fit element (4) and the second form-fit element (5) are designed such that the projection (41, 41', 41'', 41''') can be guided through the recess (51, 51', 51'', 51''') by means of a displacement in the direction perpendicular to the hinge axis and can be brought into or out of engagement with the second form-fit element (5) by means of a displacement parallel to the hinge axis (S).
The invention relates to a hinge assembly (100), in particular a concealed hinge assembly (100), for securing doors or windows in a rotatable manner about a hinge axis, having a cartridge (3) and a hinge bracket (4) which is partly arranged in a receiving region (9) of the cartridge (3). The hinge axis is parallel to a vertical direction (V), wherein the hinge bracket (4) is inserted into the receiving region (9) along a horizontal direction (H) which is orthogonal to the vertical direction (V), and the cartridge (3) has a nose (5) in the receiving region (9) for engaging into a recess (6) of the hinge bracket (4) and for holding the hinge bracket (4). The invention additionally relates to a method for installing a hinge assembly (100).
E05D 7/02 - Charnières, gonds ou pivots de structure particulière pouvant être utilisées sur le côté droit comme sur le côté gaucheCharnières ou gonds interchangeables pour côté droit ou gauche
E05D 7/12 - Charnières, gonds ou pivots de structure particulière permettant une séparation facile de la charnière du battant ou du dormant
6.
HINGE ASSEMBLY FOR PIVOTALLY SECURING DOORS OR WINDOWS
The invention relates to a concealed hinge assembly (100) for securing door or window leaves to a door or window frame in a rotatable manner about a hinge axis (S), having a housing (1, 2) and a cartridge (3) which is partly arranged in the interior of the housing (1, 2). A hinge bracket (4) is inserted into a receiving region (5) of the cartridge (3) along a horizontal direction (H) which is orthogonal to the hinge axis (S), wherein the concealed hinge assembly (100) has a screw (6) and a threaded pin (8) in order to adjust the hinge bracket (4) in a seal pressing direction (D) which is orthogonal to the hinge axis (S) and orthogonal to the horizontal direction (H), and the screw (6) is arranged in a first through-bore (7.1) of the securing region (3') and in a first threaded bore (7.2) of the hinge bracket (4). The head (6.1) of the screw (6) is arranged so as to rest against a contact surface (7.3) facing away from the hinge bracket (4), and the threaded pin (8) is arranged in a continuous second threaded bore (9) of the securing region (3') and so as to rest against the hinge bracket (4). The invention additionally relates to a method for adjusting a hinge assembly (100).
Fittings of metal for building; Fittings of metal for windows; Fittings of metal for furniture; Fittings of metal for coffins; Door fittings of metal; Fittings for metal chests; Rooflight dome fittings of metal; Gate fittings made of metal; Strap-hinges of metal; Hinges of metal.
Fittings of metal for building; Fittings of metal for windows; Fittings of metal for furniture; Fittings of metal for coffins; Door fittings of metal; Fittings for metal chests; Rooflight dome fittings of metal; Gate fittings made of metal; Strap-hinges of metal; Hinges of metal.
Fittings of metal for building; Fittings of metal for windows; Fittings of metal for furniture; Fittings of metal for coffins; Door fittings of metal; Fittings for metal chests; Rooflight dome fittings of metal; Gate fittings made of metal; Strap-hinges of metal; Hinges of metal.
Fittings of metal for building; Fittings of metal for windows; Fittings of metal for furniture; Fittings of metal for coffins; Door fittings of metal; Fittings for metal chests; Rooflight dome fittings of metal; Gate fittings made of metal; Strap-hinges of metal; Hinges of metal.
11.
TELESCOPIC ARRANGEMENT FOR ATTACHMENT TO A HOLLOW PROFILE OF A FRAME OR LEAF OF A DOOR OR OF A WINDOW
The invention relates to a telescopic arrangement (100) for attachment to a hollow profile (H) of a frame or leaf of a door or of a window, said arrangement comprising an assembly (B) which has two fastening elements (1, 1') and a fixing screw (2) that has a circumference (U) and a longitudinal extent (L) and an external thread (3), wherein the fastening elements (1, 1') each comprise a partly-round recess (4, 4'), and the partly-round recess (4, 4'), at least in the assembled state of the assembly (B), has an internally threaded portion (5, 5') which interacts with a region of the external thread (3) of the fixing screw (2), which region extends over part of the circumference (U).
The hinge for fastening a wing (F) in a pivotable manner about an articulation axis (S) to a frame (R), having a hinge part (100), which comprises a mounting element (1) with a housing (2) and a hinge flap (6) with an articulation part (7) and a fastening part (8) inserted into the housing (2), wherein the fastening part (8) can be displaced within the housing (2) in an adjusting direction (X) perpendicular to the articulation axis (S) by means of an adjusting device (11) and can be secured in a desired adjusting position by means of a fixing device (12), comprises a guide device for guiding the hinge part (100) in the adjusting direction (X), which guide device comprises a first guide element (19), which is formed on an inner surface of the housing (2), and a second guide element (20), which is formed on the fastening part (8) and operatively connected to the first guide element (19).
The invention relates to a strap (100) for pivotally connecting a leaf to a frame, having a frame fastening arrangement (1), having a leaf fastening arrangement (2), and having a pivot bracket (3) connecting the frame fastening arrangement (1) to the leaf fastening arrangement (2), which pivot bracket is pivotally mounted about a pivot axis (S) at least on either the frame fastening arrangement (1) or the leaf fastening arrangement (2). At least one of either the frame fastening arrangement (1) or the leaf fastening arrangement (2) has a fastening adapter (25) which has a profile portion (26) having a C-groove (27), which extends parallel to the pivot axis (S) in the longitudinal direction (L) and which has a 180-degree rotational symmetry relative to an axis of symmetry (B) perpendicular to the longitudinal direction (L) and preferably said profile portion (26) has two open profile portion longitudinal ends (28, 28').
E05D 7/04 - Charnières ou gonds réglables par rapport au battant ou au dormant
E05D 7/02 - Charnières, gonds ou pivots de structure particulière pouvant être utilisées sur le côté droit comme sur le côté gaucheCharnières ou gonds interchangeables pour côté droit ou gauche
Hinge (100) for pivotably connecting a wing to a frame, having a frame fastening arrangement (1); a wing fastening arrangement (2); a pivot bracket (3) which connects the wing fastening arrangement (2) to the frame fastening arrangement (1), is mounted at least on one of the frame fastening arrangement (1) and of the wing fastening arrangement (2) so as to be pivotable about a pivot axis (S) and comprises a frame part (4) connected to the frame fastening arrangement (1) and a wing part (5) connected to the wing fastening arrangement (2); and an adjusting device (6) by means of which the wing part (5) is displaceable relative to the frame part (4) in an adjusting direction (R1) running perpendicularly to the pivot axis (S), and which comprises a first adjustment element (12) for displacing the wing part (5) relative to the frame part (4) in the adjusting direction (R1). The first adjustment element (12) comprises a threaded spindle (13) which has a first threaded region (14) and a second threaded region (15), the threads (16, 17) of which are formed with opposite directions.
The invention relates to a hinge tab of a hinge for connecting a leaf to a frame so as to be hinged about a hinge axis (S), having at least one assembly part (1, 2) and at least one hinge part (6, 7) which can be assembled on the assembly part (1, 2). One of the parts of the assembly part (1, 2) and the hinge part (6, 7) comprises an undercut groove (15) with a longitudinal axis (L) and a threaded bore (18) which defines a rotational axis (D), wherein the longitudinal axis (L) and the rotational axis (D) extend parallel to the hinge axis (S), and an adjustment spindle (27) which is screwed into the threaded bore (18) is provided with an end face designed as a support surface (28); and the respective other part of the assembly part (1, 2) and the hinge part (6, 7) comprises a protrusion (21), which engages into the groove (15), and a contact surface (29), which can be brought into contact with the support surface (28) of the adjustment spindle (27).
The invention relates to a hinge (100) for connecting a leaf to a frame so as to be hinged about a hinge axis (S), comprising a leaf hinge part (6) which can be secured to the leaf, a frame hinge part (1) which can be secured to the frame, and a hinge pin (7) which defines the hinge axis (S) and has at least one circular region in the cross-section and first engagement means (15). At least one of the hinge parts has a hinge pin receiving area (8) which extends in the direction of the hinge axis (S). The hinge also comprises second engagement means (16) which are provided within the hinge pin receiving area (8) and which are in engagement with the first engagement means (15). The first engagement means (15) comprise at least one depression (14), which is set back with respect to the cross-section of the hinge pin (7), and the second engagement means (16) comprise at least one protrusion (13) which engages into the depression (14).
The invention relates to an assembly (100) of a strip for connecting a leaf to a frame in an articulated manner about a hinge axis (S), comprising an installation part (10) which can be installed on an installation side of the leaf or the frame, a strip tab (20) which can be secured to the installation part (10), and a first adjustment means (50), by means of which the strip tab (20) can be pivoted relative to the installation part (10) in an adjustment range (J) about a pivot axis (B) extending parallel to the hinge axis (S), wherein, of the installation part (10) and the strip tab (20), one has a securing groove (31) with a groove opening (32) and a groove longitudinal axis (A), which extends parallel to the hinge axis (S), and the other has a securing protrusion (35) which engages into the securing groove (31). The securing groove (31) and the securing protrusion (35) are designed such that the securing protrusion (35) can be inserted into the securing groove (31) perpendicularly to the groove longitudinal axis (A) by pivoting the strip tab (20) relative to the installation part (10) substantially about the pivot axis (B).
The invention relates to a strip (100) for connecting a leaf to a frame in an articulated manner about a hinge axis (S), comprising at least one leaf strip part (10) arranged on the leaf side and at least one frame strip part (20) arranged on the frame side. In order to transmit data signals of a bus system, at least one busable data transmission device (30) is provided between the leaf strip part (10) and the frame strip part (20).
In a hinge element (100) of a hinge for the hinged connection of a leaf to a frame, a locating screw (30) loosely penetrates a hinge body (1) and, when fixed, is in threaded engagement with a mounting projection (12) of a fastening element (11).
The invention relates to a module (16) of a band for the hinged connection of a wing to a frame about a hinge axis (S), comprising an assembly part (17) and a band flap (18), wherein the band flap (18) is arranged such that it can be pivoted in relation to the assembly part (17) by an adjustment angle (a) about a pivoting axis (B), characterised in that one of either the assembly part (17) or the band flap (18) comprises a guide recess (23) which is arranged in the direction perpendicular to the pivoting axis (B), at a distance therefrom, and that the other of either the assembly part or the band flap comprises a guide projection (26) engageable in the guide recess (23) over the entire adjustment region.
In a hinge (100) for fastening a leaf or a sash to a frame so as to be pivotable about a hinge axis (S), having a leaf/sash hinge part (1), having a frame hinge part (4) and having a hinge pin (7) which comprises a region (8) made of an electrically conducting material with a radial contact surface (9), a leaf/sash contact element (10) and a frame contact element (21) are provided which are in electrical contact with the radial contact surface (9).
The invention relates to a hinge (100) for fastening a wing (F) to a frame (R) such that it can pivot about a hinge axis (S), with an electroconductive hinge bolt (13), wherein a first contact element (16) is in electrical contact with a front contact surface (14) of the hinge bolt (13), and a second contact element (17) is in electrical contact with a radial contact surface (15) of the hinge bolt (13).
Fittings of metal for buildings in the nature of fittings of metal for windows, fittings of metal for furniture, fittings of metal for coffins, fittings of metal for doors, fittings of metal for crates, fittings of metal for gates, hinge bands of metal, hinges of metal, fittings of metal for stairs, fittings of metal for railings, and specifically excluding non-metal decorative moldings and decorative trim for use in building construction
The invention relates to a band flap (100) of a band for a hinge-articulated connection of a wing to a frame about a hinge axis (S), comprising a longitudinal recess (3), a bearing bushing (4) arranged in the longitudinal recess (D), which is rotatable, by means of an optionally attachable auxiliary rotation aid (12), about a laterally offset axis of rotation (D) that is parallel to the hinge axis (S). Said bearing bushing comprises a bearing bushing recess (5) for accommodating a band pin, having at least one inner thread (35) provided in an end region of the longitudinal recess (3), and a lifting spindle (7, 7') having an outer thread (8) that can be screwed into the inner thread (35). Said lifting spindle has a support side (9) for directly or indirectly supporting the bearing bushing (4) and/or the band pin and is configured as an optionally attachable rotation aid (12). For the purpose of transmitting torques, a key surface (13) is provided on the bearing bushing (4) between the lifting spindle (7, 7') and the bearing bushing (4), and on the lifting spindle (7, 7'), a counter key surface (14) is provided, which can be operatively connected to the key surface (13). According to the invention, the key surface (13) is arranged on at least one cavity (21a, 21b, 21c, 21d) formed on a circumferential front face surface (6), and the counter key surface (14) is arranged on at least one projection (22a, 22b, 22c, 22d) that is formed so as to correspond with the cavity (21a, 21b, 21c, 21d).
The invention relates to a strip part (21) of a strip for securing a door to a frame such that it can swivel about a hinge axis (c), comprising a hinge part (33) having a receiving means (29) for a hinge bolt defining the hinge axis (c), and comprising a securing part (22) via which the strip part (21) can be secured to the door or the frame, wherein the securing part (22) has a closed cross-section (Q) extending around an opening (25).
The invention relates to a strip part (100) to be fastened and adjusted on a frame profile or leaf profile (5), comprising a strip lobe (1), which has at least one hinge part (10) defining a pivot axis (S) and a strip fastening limb (11) adjoining the hinge part, and comprising a strip fastening body (2), which can be secured in a fastening plane (E) to a frame profile or leaf profile (5). In order to fasten the strip lobe (1) to the strip fastening body (2), a fastening device (20) having a contact face (60) is provided, against which the strip fastening limb (11) can be placed by means of a corresponding mating contact face (16) and can be fastened indirectly or directly to the strip fastening body (2). According to the invention, material recesses (61, 17) corresponding to one another are formed in the region of the contact face (60) and the mating contact face (16), into which recesses a mounting aid (4) for levering or displacing the strip lobe (1) relative to the strip fastening body (2) can be inserted.
Door fittings of metal; metal components for doors; door
holding devices of metal; hinges for doors and windows
(metal -); hinges of metal incorporating a spring; door
sections of metal; latches of metal; latches (metal -) being
fittings for doors; strap-hinges of metal; hinges of metal;
safety fittings of metal for doors; metal door units; door
handles of metal; door hinges of metal.
28.
HINGE FOR FASTENING A LEAF OR A SASH TO A FRAME SO AS TO BE HINGED ABOUT A HINGE AXIS
The invention relates to a hinge having a hinge part, which comprises a recess (2) extending in the direction of a hinge axis and comprising an inner lateral surface (3), and having an adjustment spindle (9), which has an axis of rotation (X) and an external screw thread (8), wherein at least one protrusion (25, 26) is provided on both sides of the adjustment spindle (9) either on the outer lateral surface (6) of the hinge pin bushing (4) or on the inner lateral surface (3) of the recess (2), of which protrusions at least one is always in engagement with a trough (27, 28) provided in the inner lateral surface (3) of the recess (2) or in the outer lateral surface (6) of the hinge pin bushing (4) within the pivoting range (B).
Door fittings of metal; Metal components for doors; Door holding devices of metal; Hinges for doors and windows (Metal -); Hinges of metal incorporating a spring; Door sections of metal; Latches of metal; Latches (Metal -) being fittings for doors; Strap-hinges of metal; Hinges of metal; Safety fittings of metal for doors; Metal door units; Door handles of metal; Door hinges of metal.
The invention relates to a securing system (100) comprising a profile (1), a securing part (2), at least two clamping parts (3, 3') and at least two securing means (4, 4') each acting in a force direction (R, R') and cooperating with the clamping parts (3, 3'), wherein the profile (1) has a groove (N) and provides first contact surfaces (5, 5') for the clamping parts (3, 3'), and the securing part (2) provides second contact surfaces (6, 6') for the clamping parts (3, 3').
F16B 7/18 - Assemblages de barres ou assemblages de tubes, p. ex. de section non circulaire, y compris les assemblages élastiques utilisant des éléments filetés
Disclosed is a fastening system (100) comprising a profile (1), a fastening part (2), at least two clip parts (3, 3') and at least two fastening means (4, 4'), each of which acts in a force direction (R, R') and which interact with the clip parts (3, 3'). The profile (1) has a groove (N) and provides first contact surfaces (5, 5') for the clip parts (3, 3') and the fastening part (2) provides second contact surfaces (6, 6') for the clip parts (3, 3').
The invention relates to a system (100) having a fitting part (1) and having a profiled section (2), which has a longitudinal direction (L) and comprises a longitudinal groove (3) having a groove opening (4) which defines a plane (E) and also having two opposing undercuts (5, 5'), wherein, for fastening the fitting part (1) to the profiled section (2), the system (100) has at least two clamping elements (8), which can be turned between an assembly position (M) and a fastening position (H), wherein, in the fastening position (H), the clamping elements (8) each co-operate with precisely one undercut (5, 5').
The invention relates to a method and device for transmitting electrical power and/or signals between a wall and a leaf which can be pivoted relative thereto, comprising a transmission device, the magnetic field intensity in the surroundings of the transmission device being detected and a fault signal being generated when the magnetic field intensity exceeds a threshold value.
Method and device for transmitting electrical power and signals between a wall and a leaf pivotable relative thereto, in order to supply electric consumers (79) provided on the leaf with electrical actuating power depending on the state of actuation and to supply electric signal transmitters (62) provided on the leaf with electrical operating power, wherein the actuating power and the operating power are transmitted from the wall to the leaf in a galvanically separated manner by means of a single power-transmitting unit (44) and signals are transmitted from the leaf to the wall by means of a first optocoupler (48) in order to adjust the electrical power provided at the wall end as a function of the actuating and operating power requirement, and wherein signals are transmitted bidirectionally between the wall and the leaf, between a control and evaluation unit at the wall end and the signal transmitters, by means of a second optocoupler (50).
In the case of a strap (100) of a hinge for connecting a leaf/casement to a frame in a hinged manner about a hinge axis (S), having a longitudinal aperture (3), having a bearing bushing (4) which is arranged in the longitudinal aperture (3), can be rotated, by means of an optionally attachable turning aid (12), about a laterally offset axis of rotation (D) parallel to the hinge axis (S), and comprises a bearing-bushing aperture (5) for accommodating a hinge pin, having an internal thread (7) which, in the operating position, is provided at least in the lower region of the longitudinal aperture (3), and having a lifting spindle (6) which has an external thread (8), can be screwed into the internal thread (7) and has a supporting side (9) for supporting the bearing bushing (4) and/or the hinge pin directly or indirectly, the lifting spindle (6) is designed in the form of an optionally attachable turning aid (12).
The invention relates to a method and a device for transmitting electric power and signals between a stationary wall and a leaf pivotably mounted on said wall, with a power transmission device for galvanically isolated transmission of electric energy, wherein an optical or optoelectronic signal transmission device is provided.
E05D 11/00 - Caractéristiques ou accessoires complémentaires des charnières ou gonds
H02J 5/00 - Circuits pour le transfert d'énergie électrique entre réseaux à courant alternatif et réseaux à courant continu
H02J 7/02 - Circuits pour la charge ou la dépolarisation des batteries ou pour alimenter des charges par des batteries pour la charge des batteries par réseaux à courant alternatif au moyen de convertisseurs
37.
MOUNTING SCREW FOR FASTENING FITTINGS ON HOLLOW CHAMBER PROFILES, CONSTRUCTION KIT FOR A MOUNTING SCREW AND ARRANGEMENT OF A MULTI-CHAMBER PROFILE AND A MOUNTING SCREW
The invention relates to a mounting screw for fastening band parts (1) on a multi-chamber profile (2), with a threaded region (4) provided with external thread (3), said threaded region (4) having a length (L) which is greater than the distance (A) between two adjacent walls (5, 6) of the multi-chamber profile (2), wherein the mounting screw has, when viewed in the screw-in direction, a front part (7) which has a thread (7a) and is preferably produced from a metal material, a centre part (8) made of a heat-insulating material, for example plastic, and a rear part (9), which comes into contact with an outer wall (10) of the multi-chamber profile, has a thread (9a) and is preferably produced from a metal material.
F16B 35/04 - Boulons filetésBoulons d'ancrageGoujons filetésVisVis de pression avec tête ou axe de forme particulière permettant de fixer le boulon sur ou dans un objet
The invention relates to a hinge arrangement for doors, windows or the like, wherein the first hinge part (1, 101, 501, 601, 701, 801) comprises an articulation part (3, 503, 603, 703, 803) and a fastening part (2, 102, 302, 402, 502, 602, 702, 802), having at least one guide member (14, 114, 214, 314, 414, 514, 614, 714, 814) which engages in a guiding manner in a guide recess (12, 212) in the fastening part (2, 102, 202, 302, 402, 502, 602, 702, 802) such that the fastening part is movable perpendicularly to the fastening plane (E), wherein at least one adjusting element (K) is configured as an adjusting member (18, 18', 118, 118', 218, 218', 318, 318', 518, 618, 718, 818) and/or at least one adjusting element (K) is configured as a limiting member (G) which provides a stop only in precisely one axial direction, and at least one adjusting element (K) is arranged in an offset manner with respect to a desired tilting axis (A).
In the case of a hinge plate arrangement (100, 200, 300, 400, 500) for connecting a leaf (F) of a door, a sash (F) of a window or the like to a frame (R) so as to be hinged about a hinge axis (S), having a hinge plate part (19) which comprises a hinge part (18) and a fastening part (20), wherein the fastening part (20) is mountable on a fastening surface (22) of a frame (R) or of a leaf or sash (F), having a guide device (25) which is attachable to at least one fastening point with the aid of at least one fastening means (29) on the fastening surface (22), said guide device (25) engaging in a guiding manner with at least one guide recess (27, 27') in the fastening part (20) such that the fastening part (20) is displaceable perpendicularly to the fastening surface (22), and having a first displacement element (37') by means of which the displacement can be brought about, the guide device (25) comprises at least one second displacement element (37) which is arranged in an offset manner with respect to the first displacement element.
The invention relates to a system (100) comprising a fastening wall (1), which has at least one fastening opening (3) for a fastening element (10), with a fitting part (5) that can be mounted on the fastening wall (1) by means of the fastening element (10) and with at least one mating element (6) for the fastening element (10). The fastening wall (1) comprises at least one passage opening (2) and the mating element (6) is provided on the fitting part (5). The mating element (6) has an outer cross-section and is designed such that it can be inserted through the passage opening (2) and can then be displaced together with the fitting part (5) in such a manner that it is positioned directly or indirectly on the fastening wall (1), on which the side opposite the fitting part (5) rests at least approximately, and the fastening element (10) can be engaged with the mating element (6) by reaching through the fastening opening (3).
The invention relates to a hinge (100, 200) for a concealed arrangement between a frame and a leaf, comprising a hinge bracket (28, 29) which extends between a frame receiving element (1) and a leaf receiving element (2) and which is pivotally mounted about a frame pivot axis (S) in the frame receiving element (1) and about a leaf pivot axis (T) in the leaf receiving element (2). The hinge also comprises means for synchronizing the pivoting movements about the frame and leaf pivot axes (S, T).
A device (100, 200, 300) for transmitting electrical energy and/or electric signals from a fixed wall to a swivellable element fastened on the wall such that it can be hinged about a hinge pin (S), having a wall part (1, 101; 2), which can be fastened on the wall, having a swivellable-element part (6, 106, 206), which can be fastened on the swivellable element, and having an energy and/or signal transmitter (8, 21), which comprises a wall-transmitter part (9, 22), provided in the wall part (1, 101; 2), and a swivelable-element-transmitter part (10, 23), provided in the swivellable-element part (6), wherein at least one of the transmitter parts is arranged such that it can be displaced in the direction of the hinge pin (S), characterized by the provision of an optionally actuable displacement drive (26, 126, 226) which is operatively connected to the at least one transmitter part.
A hinge (100) having a frame-hinge part (1), having a leaf-hinge/casement-hinge part (2) and having a frame pin (3) and leaf/casement pin (4) arranged in a rotationally fixed manner in the frame-hinge part (1) and in the leaf-hinge/casement-hinge part (2), respectively, and comprising at least a first frame-guiding and leaf-guiding/casement-guiding element (5, 12), with which engages at least a first frame and leaf-casement carriage (10, 17) mounted on the frame pin (3), and a first bridge (19) is connected to the frame and the leaf/casement carriages (10, 17) for pivoting action perpendicularly to the longitudinal centre axes (S, T) of the frame and leaf/casement pins (3, 4) such that the spacing between the frame and leaf/casement carriages (10, 17) decreases in the axial direction (S, T) during opening and correspondingly increases during closing.
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
Produits et services
Fittings of metal for buildings in the nature of fittings of metal for windows, fittings of metal for furniture, fittings of metal for coffins, fittings of metal for doors, fittings of metal for crates, fittings of metal for gates, hinge bands of metal, hinges of metal, fittings of metal for stairs, fittings of metal for railings, and specifically excluding non-metal decorative moldings and decorative trim for use in building construction [ Alarm devices in the nature of electric alarm bells, electric burglar alarm installations, anti-theft warning apparatus in the nature of electric warning horn and warning lights, alarm installations warning call bells, audible and visual alarm notification apparatus, gauges, hole gauges in the nature of length measuring gauges; electrical cable ducts; apparatus and instruments for the transmission, conducting, switching, transforming, accumulating, regulating and controlling of electricity in the nature of signal processors for alarm devices; electrical connector boxes, equipment boxes and cavity wall boxes in the nature of electric fuse and distribution boxes; electric transformers, electric coils, electric connectors ] [ Fittings, not of metal, for buildings in the nature of fittings, not of metal, for windows, fittings, not of metal, for furniture, fittings, not of metal, for coffins, fittings, not of metal, for doors, fittings, not of metal, for crates, fittings, not of metal, for gates, hinge bands, not of metal, hinges, not of metal, fittings, not of metal, for stairs, fittings, not of metal, for railings, and specifically excluding non-metal decorative moldings and decorative trim for use in building construction ]
45.
APPARATUS FOR CONTACTLESS TRANSMISSION OF ELECTRICAL ENERGY BETWEEN A WALL AND A DOOR LEAF/WINDOW SASH FASTENED TO SAID WALL
Apparatus for contactless transmission of electrical energy between a wall and a door leaf/window sash fastened to this wall in articulated fashion using hinges about a hinge axis (S), with a primary coil (1, 10) which can be fastened to the wall, with a secondary coil (2, 9) which can be fastened to the leaf/sash, and with a strip-shaped bolt (3, 103) acting as magnetic flux concentrating element between the primary coil (1, 10) and the secondary coil (2, 9), wherein the strip-like bolt (3, 103) comprises at least one flux element (4, 4'; 104, 104') configured as a premanufactured component part and having end sides (18, 19; 18', 19'; 118, 119; 118', 119'), and at least one bearing piece (8, 8'; 108, 108') having an opposing end side (17, 17'; 20, 20'; 117, 117'; 120, 120'), and at least one end side (18, 19; 18', 19'; 118, 119; 118', 119') of the flux element (4, 4'; 104, 104') is braced against an opposing end side (17, 17'; 20, 20'; 117, 117'; 120, 120') of the bearing piece (8, 8'; 108, 108').
Method and apparatus for contactless transmission of electrical energy between a wall and a door leaf/window sash fastened to this wall in articulated fashion using hinges about a hinge axis, in which a primary power coil (117) fastened to the wall and a secondary power coil (121) fastened to the leaf/sash are provided, wherein primary power electronics are provided, in which a transmission characteristic in the form of a function of the power available at the secondary power coil (121) in dependence on the primary power supplied to the primary power coil can be stored.
The invention relates to a device (100) for transmitting electric power and/or electric signals from a stationary wall (W) to a wing (F) fixed to the wall (W) in an articulated manner about a hinge axis (S) by a hinge, having a power and/or signal transmitter (1) operating without contact, which has means for shielding (18) the power and/or signal transmitter (1) against external magnetic fields.
H01R 13/658 - Dispositions pour le blindage en haute fréquence, p. ex. protection contre les parasites électromagnétiques ou les impulsions électromagnétiques
In a cable routing arrangement (200), with at least one hollow profile (101, 101') having at least one perforation (106, 106', 107) and with a first band part (109) which is fastenable to a fastening surface (110, 110') of the hollow profile and has at least one first cable-routing duct (122, 123), and/or with a second band part (109') which is fastenable to a fastening surface (110, 110') of the hollow profile and has at least one second cable-routing duct (122', 123'), the at least one first duct (122, 123) has a first region (135) which reaches into the hollow profile (101, 101') and/or the at least one second duct (122', 123') has a second region (135a) which reaches into the hollow profile (101, 101').
In the device for transmitting electric power from a fixed wall to a wing attached to the wall in a hinged manner about a hinge axis, with a wall part which can be fastened to the wall, with a wing part which can be fastened to the wing, with a primary coil which is provided on the wall part, and with a secondary coil which is provided on the wing part, wherein the end sides of the primary coil and the secondary coil are arranged facing each other, the primary coil comprises a primary coil winding and a coil housing which has ferromagnetic or ferrimagnetic properties, is open on the end side facing the wing part and at least virtually completely covers the primary coil winding on the opposite end side, and the secondary coil comprises a secondary coil winding and a secondary coil housing which has ferrimagnetic or ferromagnetic properties, is open on the end side facing the wall part and at least virtually completely covers the coil winding on the opposite end side.
Method and apparatus for the contactless transmission of electrical energy between a wall and a door leaf, which is fastened to this wall with hinge articulation about a hinge axis, in which a primary power coil (117) which is fastened to the wall and a secondary power coil (121) which is fastened to the door leaf are provided and are operatively connected to one another inductively with the aid of a hinge plate pin, wherein the primary power voltage required for achieving a secondary power voltage setpoint value is detected and a signal is triggered when a predetermined difference between the primary power voltage and the secondary power voltage is transmitted.
Method and apparatus for transmitting signals between a wall (W) and a leaf (F) fastened to this wall (W) using hinges around a hinge axis (S), in which a carrier voltage modulated by the signal to be transmitted is applied to a first signal transmission coil (28, 34) arranged on the wall (W) or on the leaf (F) in order to generate a secondary voltage modulated by the transmitted signal in a second signal transmission coil (28, 34) arranged on the leaf (F) or on the wall (W) by means of inductive coupling.
A method and device for contactless transmission of electric energy and/or electric signals between a wall and a wing fastened to said wall, in which control signals and response and control signals are transmitted bidirectionally between a first coil fastened to the wall and a second coil fastened to the wing.
The invention relates to an arrangement (100) for cable guiding, having a hollow section (1) and a band part (9) which can be fastened to a fastening surface (10) of the hollow section (1), wherein the band part (9) is fastened, so that same is floating at least in one spatial direction, to the fastening surface (10) of the hollow section (1).
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
Produits et services
Fittings of metal for buildings, fittings of metal for
windows, fittings of metal for furniture, fittings of metal
for coffins, fittings of metal for doors, fittings of metal
for crates, fittings of metal for gates, hinge bands of
metal, hinges of metal, fittings of metal for stairs,
fittings of metal for railings. Alarm devices, alarm bells (electric), burglar alarm
installations (electric), anti-theft warning apparatus, call
bells (alarm installations), notification apparatus, door
openers (electric); gauges, hole gauges; cable ducts;
apparatus and instruments for the transmission, conducting,
switching, transforming, accumulating, regulating and
controlling of electricity; connector boxes, equipment
boxes, cavity wall boxes (included in class 9); electric
transformers, electric coils, electric connectors. Fittings, not of metal, for buildings, fittings, not of
metal, for windows, fittings, not of metal, for furniture,
fittings, not of metal, for coffins, fittings, not of metal,
for doors, fittings, not of metal, for crates, fittings, not
of metal, for gates, hinge bands, not of metal, hinges, not
of metal, fittings, not of metal, for stairs, fittings, not
of metal, for railings.
(1) Hinge bands of metal, hinges of metal, hinge bands not of metal and hinges not of metal.
(2) Fittings of metal for buildings, namely, hinges, screws, bolts; fittings, not of metal, for buildings, namely, hinges, screws, bolts.
(3) Fittings of metal for buildings, namely, hinges, screws, bolts; hinge bands of metal, hinges of metal; fittings, not of metal, for buildings, namely, hinges, screws, bolts; hinge bands, not of metal, hinges, not of metal.
The invention relates to a hinge arrangement (100) for doors, windows or the like, comprising a hinge part (1) that has an articulation part (3) and a fastening part (2), wherein the fastening part (2) can be mounted on a fastening surface (8) of a frame or a leaf, a guide element (10) which can be fitted on the fastening surface (8) and which engages in a guiding manner in a guide aperture (9) in the fastening part (2) such that the fastening part (2) can be displaced perpendicularly to the fastening surface (8), and further comprising a displacement element (16) bringing about the displacement. Said displacement element (16) positively engages with the fastening part (2) and the guide element (10).
The invention relates to a hinge arrangement (100, 200) for doors, windows or the like, comprising at least a hinge part (3, 103) that defines a hinge axis (S) and at least a fastening part (2, 102), wherein the fastening part (2, 102) can be mounted on a fastening surface (8, 108) of a frame or leaf. Said hinge arrangement comprises a fastening adapter (18, 118) that can be fastened to the fastening surface (8, 108) and can be joined with the fastening part (2, 102) in various different positions of the fastening part (2, 102) relative to the fastening surface (8, 108).
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
Produits et services
(1) Hinges.
(2) Fittings of metal for buildings, namely, hinges, screws, bolts; fittings of metal for windows, fittings of metal for furniture, fittings of metal for coffins, fittings of metal for doors, fittings of metal for crates, fittings of metal for gates, hinge bands of metal, hinges of metal, fittings of metal for stairs, fittings of metal for railings; alarm devices, namely, electric alarm bells, burglar alarms; electronic warning bells for alarms; electric door openers; gauges, namely, hole length measuring gauges; fittings, not of metal, for buildings, namely, hinges, screws, bolts; fittings, not of metal, for windows, fittings, not of metal, for furniture, fittings, not of metal, for coffins, fittings, not of metal, for doors, fittings, not of metal, for crates, fittings, not of metal, for gates, hinge bands, not of metal, hinges, not of metal, fittings, not of metal, for stairs, fittings, not of metal, for railings.
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Fittings of metal for buildings, fittings of metal for windows, fittings of metal for furniture, fittings of metal for coffins, fittings of metal for doors, fittings of metal for crates, fittings of metal for gates, hinge bands of metal, hinges of metal, fittings of metal for stairs, fittings of metal for railings. Alarm devices, alarm bells (electric), burglar alarm installations (electric), anti-theft warning apparatus, call bells (alarm installations), notification apparatus, door openers (electric); Gauges, hole gauges; Cable ducts; Apparatus and instruments for the transmission, conducting, switching, transforming, accumulating, regulating and controlling of electricity; Connector boxes, equipment boxes, cavity wall boxes (included in class 9); Electric transformers, electric coils, electric connectors. Fittings, not of metal, for buildings, fittings, not of metal, for windows, fittings, not of metal, for furniture, fittings, not of metal, for coffins, fittings, not of metal, for doors, fittings, not of metal, for crates, fittings, not of metal, for gates, hinge bands, not of metal, hinges, not of metal, fittings, not of metal, for stairs, fittings, not of metal, for railings. Computer software design; Engineering; Technical testing; Technological consultancy, technical project studies, materials testing, quality control, environmental compatibility testing, materials testing.
61.
METHOD AND DEVICE FOR TRANSMITTING ELECTRIC POWER FROM A WALL TO A LEAF HINGEABLY FASTENED TO SAID WALL
The invention relates to a method for transmitting electric power from a wall to a leaf that is hingeably fastened to said wall about a hinge axis (S), wherein on the wall side an electric primary voltage having a primary frequency is provided, which is suited to act on a primary coil provided on the wall in order to generate a secondary voltage up to at least 500 mW power by inductive coupling in a secondary coil provided on the leaf.
The invention relates to a system for transmitting electric power from a stationary wall to a leaf that is hingeably fastened to said wall about a hinge axis, comprising a wall part that can be fastened to the wall, a leaf part that can be fastened to the leaf, a primary coil provided on the wall part and a secondary coil provided on the leaf part, primary electronics converting a supply voltage into a primary voltage for acting on the primary coil that is suited to generate a secondary voltage by inductive coupling in the secondary coil, and secondary electronics converting the secondary voltage into an electric operating voltage suitable for an electric energy store and/or for an electric load.
The invention relates to a strap part (100, 200, 300, 400) of a strap hinge for fastening to a hollow chamber profile, in particular a frame strap part, having at least one fastening screw (11, 12) and having at least one register extension (4, 104, 204, 304; 5, 105, 205, 305), wherein the fastening screw (11, 12) is designed as a self-boring screw and the register extension (4, 5, 105, 305) is designed as a register pin having a contoured outer surface (121) or the register extension (104, 204, 205, 304) is designed as an expandable dowel.
The invention relates to a strap part (100, 200, 300, 400) of a strap hinge, in particular a leaf strap part, for fastening to a fastening wall (16) of a multi-chamber hollow profile (H) having at least one inner wall (17) comprising an assembly part (7, 107, 207, 307, 407, 507, 607, 707, 807) which can be attached to the multi-chamber hollow profile (H) in a stationary manner and an adjustment part (1) which can be displaced relative to the assembly part (7, 107, 207, 307, 407, 507, 607, 707, 807) and fixed at a desired displacement position, wherein the assembly part (7, 107, 207, 307, 407, 507, 607, 707, 807) has at least one first register extension (408, 608, 708) which provides for nearly play-free engagement in perforations in the fastening wall (16) and the inner wall (17) and at least one second register extension (9, 309, 409) for at least nearly play-free engagement in perforations only in the fastening wall (16).
The invention relates to a hinge assembly (100) for doors, windows and the like, comprising a fixed frame (R) and a leaf (F), which are connected to one another by means of hinges (3) pivotably about a hinge axis (S). Each hinge comprises a frame hinge part (35), which is fastened to a fastening wall (20) of the fixed frame (R), and a leaf hinge part (18), which is fastened to a fastening wall (19) of the leaf (F). A projection (22, 36) protrudes from each of the fastening walls (19, 20) of the frame (R) and/or of the leaf (F) and is surrounded in a recess (21, 37) by the frame hinge part (35) and/or the leaf hinge part (18). The hinge assembly further comprises fastening means for fastening the frame hinge part (35) and /or the leaf hinge part (18) to the respective fastening wall (19, 20), wherein the fastening means comprise at least one clamping screw (24, 38), which is provided on the frame hinge part (35) and/or on the leaf hinge part (18) and can be brought into operative connection with the projection (22, 36).
In the flat strap hinge (100) for the hinged fixing of a leaf of a door, window or the like, having at least one flat strap (1, 3) which has a contact surface (9, 10) with which the flat strap (1, 3) rests on a mounting wall (11, 13) when mounted, and having at least one passage opening (4, 5; 6, 7) with a longitudinal axis (L, L') which opens into the contact surface (9, 10) in order to receive a fixing screw (8), the longitudinal axis (L, L') of the passage opening (4, 5; 6, 7) has an angle (α, α') differing from the perpendicular (T) to the contact surface (9, 10).
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Fittings of metal for buildings, fittings of metal for
windows, fittings of metal for furniture, fittings of metal
for coffins, fittings of metal for doors, fittings of metal
for crates, fittings of metal for gates, hinge bands of
metal, hinges of metal, fittings of metal for stairs,
fittings of metal for railings. Alarm devices, alarm bells (electric), burglar alarm
installations (electric), anti-theft warning apparatus, call
bells (alarm installations), notification apparatus, door
openers (electric); gauges, hole gauges; cable ducts;
apparatus and instruments for the transmission, conducting,
switching, transforming, accumulating, regulating and
controlling of electricity; connector boxes, equipment
boxes, cavity wall boxes (included in this class); electric
transformers, electric coils, electric connectors. Fittings, not of metal, for buildings, fittings, not of
metal, for windows, fittings, not of metal, for furniture,
fittings, not of metal, for coffins, fittings, not of metal,
for doors, fittings, not of metal, for crates, fittings, not
of metal, for gates, hinge bands, not of metal, hinges, not
of metal, fittings, not of metal, for stairs, fittings, not
of metal, for railings. Computer software design; engineering; technical testing;
technological consultancy, technical project studies,
materials testing, quality control, environmental
compatibility testing, materials testing.
A strap (200) for pivotally connecting a leaf (F) to a frame (R), in particular a door leaf to a door frame, has a housing (101) that can be fastened to the frame (R), and a pivot bracket (110) that is mounted in the housing (101) and can be fastened to the leaf (F). The pivot bracket (110) comprises a guide slot (132) having guide surfaces (115, 131), and the housing (101) comprises a guide element (106), on which the guide surfaces (115; 131) are guided, so that the pivot bracket (110) can be displaced with respect to the housing (101) along the path predetermined by the guide slot (132).
A tape (100), comprising a frame element (1), a door leaf or window sash element (13), and a pivot clamp (10), which connects the frame element (1) to the door leaf or window sash element (13) and comprises a frame part (9) connected to the frame element (1) and a door leaf or window sash part (16) connected to the door leaf or window sash element (13), wherein the frame or the door leaf or window sash part (9, 16) comprises a connection extension (20), which is provided at the free end region of the part and has a thickening (21), and the other frame or door leaf or window sash part (9, 16) comprises a connection recess (22), which is designed approximately complementary to the connection extension (20). The connection extension (20) and the connection recess (22) in each case comprise at least one recess (23, 24) extending in a parallel manner to the pivot axis (S) and dimensioned such that the frame and door leaf or window sash part (9, 16) can be engaged or disengaged by displacing the same in parallel to the pivot axis (S) over approximately the length of the recesses (23, 24).
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Fittings of metal for buildings, fittings of metal for
windows, fittings of metal for furniture, fittings of metal
for coffins, fittings of metal for doors, fittings of metal
for crates, fittings of metal for gates, hinge bands of
metal, hinges of metal, fittings of metal for stairs,
fittings of metal for railings. Alarm devices, alarm bells (electric), burglar alarm
installations (electric), anti-theft warning apparatus, call
bells (alarm installations), notification apparatus, door
openers (electric); gauges, hole gauges; cable ducts;
apparatus and instruments for the transmission, conducting,
switching, transforming, accumulating, regulating and
controlling of electricity; connector boxes, equipment
boxes, cavity wall boxes (included in this class); electric
transformers, electric coils, electric connectors. Fittings not of metal, for buildings, fittings, not of
metal, for windows, fittings, not of metal, for furniture,
fittings, not of metal, for coffins, fittings, not of metal,
for doors, fittings, not of metal, for crates, fittings, not
of metal, for gates, hinge bands, not of metal, hinges, not
of metal, fittings, not of metal, for stairs, fittings, not
of metal, for railings. Computer software design; engineering; technical testing;
technological consultancy, technical project studies,
materials testing, quality control, environmental
compatibility testing, materials testing.
71.
HINGE FOR CONNECTING A LEAF TO A FRAME SO AS TO BE HINGED ABOUT A HINGE AXIS
The invention relates to a hinge (100) for connecting a leaf of a door, a window, or the like to a frame so as to be hinged about a hinge axis (S), comprising a frame wing (1, 2) that can be fastened to the frame and that comprises a frame fastening part (5, 5') and a frame hinge part (4, 4'), a leaf wing (3) that can be fastened to the leaf and that comprises a leaf fastening part (7) and a leaf hinge part (6), and a hinge pin (10) that defines the hinge axis (S), wherein a primary coil (19) surrounding the hinge pin (10) is arranged in the frame hinge part (4), and wherein a secondary coil (20) surrounding the hinge pin (10) is arranged in the leaf hinge part (6), wherein the primary coil (19) extends at least approximately to the end face of the frame hinge part (4) facing the leaf hinge part (6), the secondary coil (20) extends at least approximately to the end face of the leaf hinge part (6) facing the frame hinge part (4), and a hinge pin sleeve (30) comprising a ferritic material is provided between the hinge pin (10) and the coils (19, 20), wherein the hinge pin sleeve extends approximately over the length (L) of the hinge pin (10) that is surrounding by the primary and the secondary coil (19, 20).
The invention relates to a hinge plate (100) for connecting a leaf of a door, or sash of a window, or the like, to a frame so as to be hinged about a hinge axis (S), comprising a frame hinge plate part (1) that can be fastened to the frame and that has a frame fastening part (3) and a frame hinge part (4), a leaf or sash hinge plate part (2) that can be fastened to the leaf or sash and that has a leaf or sash fastening part (5) and a leaf or sash hinge part (6), and a hinge pin (7) that defines the hinge axis (S), wherein a primary coil (12) surrounding the hinge pin (7) is disposed in the frame hinge part (4), wherein a secondary coil (19) surrounding the hinge pin (7) is disposed in the leaf or sash hinge part (6), and wherein the hinge pin (7) is designed as a core for both coils (12, 19) which conducts magnetic flux lines. The hinge pin (7) comprises a support element for transmitting mechanical forces between the leaf or sash and the frame and a flux element for conducting magnetic flux lines between the primary and the secondary coils (12, 19).
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Fittings of metal for buildings, [ fittings of metal for windows, fittings of metal for furniture, fittings of metal for coffins, ]fittings of metal for doors, [ fittings of metal for crates, fittings of metal for gates, ] hinge bands of metal, hinges of metal, [ fittings of metal for stairs, fittings of metal for railings ] [ [ Alarm devices, namely, burglar alarms; electric alarm bells; electric burglar alarm installations; anti-theft warning apparatus, not for vehicles; alarm installations in the nature of call bells; notification apparatus, namely, visual and audible notification devices for warning purposes; electric door openers; sensors for determining position; ] drilling gauges, namely, gauges for measuring the size and depth of holes; [ electrical cable ducts; apparatus and instruments for the transmission, conducting, switching, transforming, accumulating, regulating and controlling of electricity, namely, electric circuit switches, electrical transformers, electric circuits for transmission of electrical power and electrical signals via electrical transformers; electrical connection boxes; cavity wall boxes, namely, electric connection boxes; electric coils, electric connectors ] ] [ Fittings, not of metal, for buildings, fittings, not of metal, for windows, fittings, not of metal, for furniture, fittings, not of metal, for coffins, fittings, not of metal, for doors, fittings, not of metal, for crates, fittings, not of metal, for gates, hinge bands, not of metal, hinges, not of metal, fittings, not of metal, for stairs, fittings, not of metal, for railings ] [ Computer software design; engineering; technical testing in the field of hinge technology; technological consultancy in the field of hinge technology; technical project planning; material testing, quality control for others; environmental compatibility testing ]
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Fittings of metal for buildings, fittings of metal for windows, fittings of metal for furniture, fittings of metal for coffins, fittings of metal for doors, fittings of metal for crates, fittings of metal for gates, hinge bands of metal, hinges of metal, fittings of metal for stairs, fittings of metal for railings. Alarm devices, alarm bells (electric), burglar alarm installations (electric), anti-theft warning apparatus, call bells (alarm installations), notification apparatus, door openers (electric); gauges, hole gauges; cable ducts; apparatus and instruments for the transmission, conducting, switching, transforming, accumulating, regulating and controlling of electricity; connector boxes, equipment boxes, cavity wall boxes (included in class 9); electric transformers, electric coils, electric connectors. Fittings, not of metal, for buildings, fittings, not of metal, for windows, fittings, not of metal, for furniture, fittings, not of metal, for coffins, fittings, not of metal, for doors, fittings, not of metal, for crates, fittings, not of metal, for gates, hinge bands, not of metal, hinges, not of metal, fittings, not of metal, for stairs, fittings, not of metal, for railings. Computer software design; engineering; technical testing; technological consultancy, technical project studies, materials testing, quality control, environmental compatibility testing, materials testing.
75.
HINGE FOR HINGE-JOINTED CONNECTION OF A LEAF TO A FRAME
The invention relates to a hinge for doors, windows and the like for the hinge-jointed connection of a leaf (27) to a frame (4) about a hinge axis (S), comprising a first hinge flap (1) that is connected pivotably about the hinge axis (S) to a second hinge flap (8) comprising a fastening component (22), which is arranged in a hinge receiving element (31) vertically adjustably to the hinge axis (S), and comprising a hinge component (9) that is connected to the fastening component (22), wherein the fastening component (22) has a fastening region (26) fixed to the hinge receiving element (31) and an adjustment region (21), which is adjustable in the hinge receiving element (31) and connected to the fastening region (26) by way of an elastic region (25), to which the hinge component (9) is connected.
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
Produits et services
Fittings of metal for buildings, fittings of metal for windows, fittings of metal for furniture, fittings of metal for coffins, fittings of metal for doors, fittings of metal for crates, fittings of metal for gates, hinge bands of metal, hinges of metal, fittings of metal for stairs, fittings of metal for railings. Alarm devices, alarm bells (electric), burglar alarm installations (electric), anti-theft warning apparatus, call bells (alarm installations), notification apparatus, door openers (electric); gauges, hole gauges; cable ducts; apparatus and instruments for the transmission, conducting, switching, transforming, accumulating, regulating and controlling of electricity; connector boxes, equipment boxes, cavity wall boxes (included in class 9); electric transformers, electric coils, electric connectors. Fittings, not of metal, for buildings, fittings, not of metal, for windows, fittings, not of metal, for furniture, fittings, not of metal, for coffins, fittings, not of metal, for doors, fittings, not of metal, for crates, fittings, not of metal, for gates, hinge bands, not of metal, hinges, not of metal, fittings, not of metal, for stairs, fittings, not of metal, for railings.
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Fittings of metal for buildings, fittings of metal for windows, fittings of metal for furniture, fittings of metal for coffins, fittings of metal for doors, fittings of metal for crates, fittings of metal for gates, hinge bands of metal, hinges of metal, fittings of metal for stairs, fittings of metal for railings. Alarm devices, alarm bells (electric), burglar alarm installations (electric), anti-theft warning apparatus, call bells (alarm installations), notification apparatus, door openers (electric); gauges, hole gauges; cable ducts; apparatus and instruments for the transmission, conducting, switching, transforming, accumulating, regulating and controlling of electricity; connector boxes, equipment boxes, cavity wall boxes (included in class 9); electric transformers, electric coils, electric connectors. Fittings, not of metal, for buildings, fittings, not of metal, for windows, fittings, not of metal, for furniture, fittings, not of metal, for coffins, fittings, not of metal, for doors, fittings, not of metal, for crates, fittings, not of metal, for gates, hinge bands, not of metal, hinges, not of metal, fittings, not of metal, for stairs, fittings, not of metal, for railings. Computer software design; engineering; technical testing; technological consultancy, technical project studies, materials testing, quality control, environmental compatibility testing, materials testing.
The invention relates to a strip (100, 200) for doors, windows and the like for fastening to a notch (8) in a leaf or a frame, said notch being approximately C-shaped in cross section and having first and second undercuts (11, 12) that are approximately opposite one another, said strip comprising a fastening part (14) with a first process (19) that can be engaged into a first undercut (11), a clamping part (20) having a second process (22) that can be engaged into a second undercut (12), and comprising at least one clamping screw (17) that can be threaded into a threaded hole (21) provided in the clamping part (20), said clamping screw passing through the fastening part (14) in a penetration (16), and comprising an inclined surface (23) provided at the clamping part (20) and supported on the fastening part (14) when the clamping screw (17) is tightened. A stop (26) is provided which acts between the fastening part (14) and the inclined surface (23) and which can be adjusted from the outside when the processes (19, 22) are engaged into the undercuts (11, 12).
The invention relates to a hinge (100) for connecting a leaf, a door, a window, or the like to a frame so as to be hinged about a hinge axis (S), comprising a frame wing (1) that can be fastened to the frame and that comprises a frame fastening part (4) and a frame hinge part (5), having a leaf wing (6) that can be fastened to the leaf and that comprises a leaf fastening part (7) and a leaf hinge part (8), and having a hinge pin (9) that defines the hinge axis (S) and that is supported in support bushings (12, 13) provided in the frame hinge part (5) and in the wing hinge part (8), wherein the support bushings (12, 13) comprise electrical coils (19, 20) and the hinge pin (9) is designed as a flux guiding element (28) for guiding electromagnetic field lines between the coils (19, 20).
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Fittings of metal for buildings, fittings of metal for
windows, fittings of metal for furniture, fittings of metal
for coffins, fittings of metal for doors, fittings of metal
for crates, fittings of metal for gates, hinge bands of
metal, hinges of metal, fittings of metal for stairs,
fittings of metal for railings. Alarm devices, alarm bells (electric), burglar alarm
installations (electric), anti-theft warning apparatus, call
bells (alarm installations), notification apparatus, door
openers (electric); gauges, hole gauges; cable ducts. Fittings, not of metal, for buildings, fittings, not of
metal, for windows, fittings, not of metal, for furniture,
fittings, not of metal, for coffins, fittings, not of metal,
for doors, fittings, not of metal, for crates, fittings, not
of metal, for gates, hinge bands, not of metal, hinges, not
of metal, fittings, not of metal, for stairs, fittings, not
of metal, for railings. Computer software design; engineering; technical testing;
technological consultancy, technical project studies,
materials testing, quality control, environmental
compatibility testing, materials testing.
81.
STRAP FOR PIVOTABLY FASTENING A LEAF OF A DOOR, OF A WINDOW OR THE LIKE TO A FIXED FRAME
In a strap (100) for pivotably fastening a leaf (9) of a door, of a window or the like to a fixed frame (35), having a frame strap element (1) which can be fixed to the frame (35), having a leaf strap element (6) which can be fixed to the leaf, having a connecting element (29, 30) which couples the frame strap element (1) to the leaf strap element and which is pivotably mounted on the frame strap element (1) so as to be pivotable about a frame hinge axis (2) and on the leaf strap element (6) so as to be pivotable about a leaf hinge axis (11) which runs parallel to the frame hinge axis (2), and having retaining means (37) which block a pivoting capability of the connecting element (29, 30) about one of the hinge axes (2, 11) at opening angles of the vane (9) below a limit angle, that element out of the frame element or leaf strap element in which the pivoting capability is not blocked at opening angles below the limit angle has a fixed receptacle (7) and a bearing device (12) which is mounted on the receptacle (7) so as to be movable perpendicularly with respect to the leaf hinge axis (11), the connecting element (29, 30) is coupled to the bearing device (12), and an actuating device (26) is provided which, in the event of a pivoting movement of the connecting element (29, 30) about the hinge axis out of the closed leaf position, generates a movement of the receptacle (7) relative to the bearing device (12).
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Fittings of metal for buildings, namely, hinges, screws, bolts; [ fittings of metal for windows, fittings of metal for furniture, fittings of metal for coffins, ] fittings of metal for doors, [ fittings of metal for crates, fittings of metal for gates, ] hinge bands of metal, hinges of metal [, fittings of metal for stairs, fittings of metal for railings ] [ Alarm devices, namely, electric alarm bells, burglar alarms; electronic warning bells for alarms; electric door openers; ] gauges, namely, hole length measuring gauges [ Fittings, not of metal, for buildings, namely, hinges, screws, bolts; fittings, not of metal, for windows, fittings, not of metal, for furniture, fittings, not of metal, for coffins, fittings, not of metal, for doors, fittings, not of metal, for crates, fittings, not of metal, for gates, hinge bands, not of metal, hinges, not of metal, fittings, not of metal, for stairs, fittings, not of metal, for railings ] [ [ Computer software design; ] engineering; technical testing of fittings for buildings, [ raw materials, ] security systems; technological consultancy in the field of fittings for buildings, security systems [, computer project management services, materials testing, quality control for others, environmental compatibility testing and inspection services ] ]
83.
A SYSTEM FOR FASTENING A FITTING PART ON A HOLLOW PROFILE
In the case of the system for fastening a fitting part (B) on a hollow profile (12), having a locking element (K) which comprises a pin (1), passing through perforations in a wall (15) of the hollow profile (12), and an abutment surface (17), which, directed towards the fitting part (B), butts against the wall (15) in the direction of the hollow profile (12), and having a screw-connection element (4, 104, 204) which can be screwed onto the pin (1) and forms a fastening location for the fitting part (B), the perforations in the wall of the hollow profile (12) have a diameter which allows that end of the screw-connection element (4, 104, 204) which is at the front in the screwing-on direction to be screwed through the perforations against the abutment surface (17) of the locking element (K).
The invention relates to a mounting screw (1) for fastening a fitting part (11) on a hollow chamber profile (12), wherein the ratio between the head diameter and core diameter of the outer thread (6) lies between 1.2 and 1.3. In order to produce such a mounting screw (1) that is secure against undesired loosening, the invention proposes that the counter bearing surface (8) of the head (2) comprise a friction device (9).
F16B 35/04 - Boulons filetésBoulons d'ancrageGoujons filetésVisVis de pression avec tête ou axe de forme particulière permettant de fixer le boulon sur ou dans un objet
Subassembly (100) having a threaded pin (1), which comprises an external thread (3), and having a screw-connection element (4), which comprises a hole (7) of which the diameter is smaller than the external diameter of the external thread (3), wherein the ratio between the diameter of the external thread (3) and the diameter of the hole (7) and/or the materials selected for the threaded pin (1) and for the screw-connection element (4) and/or the geometry of the external thread (3) are selected such that a predetermined torque is necessary in order for the screw-connection element (4) to be screwed onto the threaded pin (1) and/or for the threaded pin (1) to be screwed into the hole (7) in the screw-connection element (4).
09 - Appareils et instruments scientifiques et électriques
20 - Meubles et produits décoratifs
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Fittings of metal for buildings, fittings of metal for windows, fittings of metal for furniture, fittings of metal for coffins, fittings of metal for doors, fittings of metal for crates, fittings of metal for gates, hinge bands of metal, hinges of metal, fittings of metal for stairs, fittings of metal for railings. Alarm devices, alarm bells (electric), burglar alarm installations (electric), anti-theft warning apparatus, call bells (alarm installations), notification apparatus, door openers (electric); gauges, hole gauges; cable ducts. Fittings, not of metal, for buildings, fittings, not of metal, for windows, fittings, not of metal, for furniture, fittings, not of metal, for coffins, fittings, not of metal, for doors, fittings, not of metal, for crates, fittings, not of metal, for gates, hinge bands, not of metal, hinges, not of metal, fittings, not of metal, for stairs, fittings, not of metal, for railings. Computer software design; engineering; technical testing; technological consultancy, technical project studies, materials testing, quality control, environmental compatibility testing, materials testing.
The invention relates to a hinge arrangement for doors, windows or the like, comprising a hinge part (2) comprising an articulation part (2a) and a fastening part (2b), wherein the fastening part (2b) can be mounted in an adjustable way on a fastening surface (6a) of a frame or leaf (1). At least two, preferably two or three, more preferably three spindle mechanisms (4, 5) are provided that can be actuated independently from each other, effecting a perpendicular movement of the fastening part (2b) compared to the fastening surface (6a).
The invention relates to an arrangement comprising a profile piece (1) of a frame or a leaf of a door or a window, having at least one groove (3), extending for example in the longitudinal direction of the profile piece (1), and a filling element (2) for providing at least one fastening bore (4) and/or a mounting surface for a fitting part (10), wherein the filling element (2) fills out the groove (3) in at least one extension direction of the groove (3) in a substantially flush way.
The invention relates to a device and method for attaching fittings to mounting walls (4) of single-chamber profiles (1), having a mounting means (5), and having an attachment profile part (11) which can be inserted into the single-chamber profile (1) and which has at least one engaging wall (12, 13) separated from the mounting wall (4), wherein the mounting means (5) engages with the engaging wall (12, 13).
In the arrangement of fitting parts on hollow profiles, having a mounting insert (21) insertable in said hollow profile, said mounting insert comprising a contact collar (22) disposed on the rear end in the insertion direction, said contact collar resting against a fastening side (11) of the hollow profile in the inserted position, the mounting insert (21) has a length that, in the insertion direction, extends the front end of the mounting insert (21) in the inserted position thereof at least nearly to the profile exterior (24) across from the fastening side (11), and a flat counter piece (26) is provided, which may be fastened to the mounting insert (21) with the aid of fastening means (28) and rests against the profile exterior (24) in the fastened position.
E05D 9/00 - Abattants ou manchons spécialement conçus pour être faits en un matériau particulier, p. ex. feuillard, tôle métallique, matières plastiques
The device for fixing a fitting part (4) to a profile(5), the profile comprising at least two walls (8, 12) situated opposite each other, comprises a fixing means (2, 24, 31, 36, 41, 48, 53, 58, 67, 68, 76, 84, 88, 96, 100) which, in the assembled state, fits through one of the two walls (8) and works together with the other wall (12) without penetrating therein.
In the case of a hinge for doors, windows and the like, with a supporting bearing (25) which is arranged between the wing hinge part (1) and the frame hinge part (9), introduces supporting forces from the wing hinge part (1) into the frame hinge part (9) and comprises a ball socket (26) and a ball disc (27), the ball socket (26) and the ball disc (27) are in form-fitting engagement with each other in such a manner that a rotation of the same relative to each other about the hinge axis (S) is possible, but it is not possible for them, or is possible only by an elastic force being overcome, to be shifted relative to each other in the direction of the hinge axis (S), this being ensured by the ball socket and the ball disc lying one above the other in an angular region which extends to slightly on the far side of the ball equator, and the elasticity of the material, from which the ball socket and/or ball disc is/are produced, and the region over which the ball socket reaches beyond the equator, are selected in such a manner that an insertion of the ball disc can take place with elastic deformation of that edge of the ball socket which protrudes over the plane of the equator.
A hinge arrangement for doors, windows or the like, with a hinge part (1) which comprises an articulation part (3) and a fastening part (2), wherein the fastening part (2) can be mounted on a fastening surface (8), with at least one guide member (11) which can be fitted on the fastening surface (8) and which engages in a guiding manner in a guide aperture (9) in the fastening part (2) such that the fastening part (2) can be displaced perpendicularly to the fastening surface (8), and with an adjusting member (15) which comprises a threaded extension (16) and a radial projection (17), wherein the threaded extension (16) can be brought into engagement with a complementary thread which is fixed in relation to the fastening surface (8) and the radial projection (17) can be brought into engagement with a socket on the fastening part (2), or the threaded extension (16) can be brought into engagement with a complementary thread on the fastening part (2) and the radial projection (17) can be brought into engagement with a socket which is fixed in relation to the fastening surface (8), wherein the fastening surface (8) is formed by a surface of a mounting piece (20) which can be fastened to a frame or to a sash or leaf.
The device (100) for connecting lines (1) which extend between a fixed frame and a wing, which is fastened to the frame in a manner such that it can pivot about a hinge axis (S) with the aid of hinges comprising frame and wing hinge parts, is configured in such a manner that it does not bring about any mechanical connection between the wing and the frame in the sense of transmitting retaining forces, and has a connector (4) which is inserted into the lines (1) and comprises two parts (5, 6), which parts (5, 6) can be released from each other, separating the lines (1), or can be brought together, bringing the lines (1) into operative connection, by the wing being shifted with respect to the frame in the direction of the hinge axis (S).
For a hinge arrangement for doors, windows, or the like, with a fixed part (60) which is to be fastened to the stationary frame of the door, the window or the like, with a moving part (50) which is to be fastened to the leaf of the door, of the window, or the like, with a hinge bolt passing through the hinge parts (50, 60) for connecting said hinge parts (50, 60) in a pivotable manner in the form of a hinge, at least one of the hinge parts (50, 60) comprising a pivoted lever (51), which can be pivoted about the hinge bolt (7) for the pivotal connection of the hinge parts, the pivoted lever (51) engaging with a cog (73) in a slot (53) formed to correspond to at least one hinge part (50, 60), an adjusting device, with which this hinge part (50, 60) can be shifted perpendicularly to its fastening wall at the frame or the leaf, is provided at least at one of the hinge parts (50, 60).
A hinge arrangement (100, 200, 300) for the attachment hinged about a hinge axis of a leaf to a frame, with a hinge strap that comprises a fastening part (1) on which at least two guide pins (5, 6) aligned perpendicular to the hinge axis and spaced apart from one another in the direction of the hinge axis are arranged, with at least two housings (35) provided on the leaf and/or on the frame, in which housings respectively one of the guide pins (5, 6) is supported so as to be slidable in the longitudinal direction thereof, with an adjusting spindle (12) having a thread (14), the longitudinal axis (S) of which adjusting spindle is aligned parallel to the longitudinal axes of the guide pins (5, 6) and which is arranged on the fastening part (1) to be rotatable about its longitudinal axis (S), and with a tapped hole (34) provided on the leaf and/or on the frame and aligned parallel to the housings (35) thereof, into which tapped hole the adjusting spindle (12) can be screwed.
The invention describes a device (100) for fastening fittings (17) to hollow chamber profiles (18) having a fastening member penetrating at least one wall (25) of the profile (18) in a perforation (26), wherein forces can be introduced into the profile (18) by the fitting (17) by means of said fastening member, the fastening member being embodied as a fastening plug (1) that can be inserted into the perforation and that has at least two snap-in locking projections, between which at least one wall (25) of the profile (18) snaps in, in the installed state of the fastening plug (1). The fastening plug comprises a cylindrical body that does not spread out even when a fitting is fastened.
With a hinge for doors, windows, and the like, at least one slidable clamping element (5) is supported on at least one fastening part (2), a locked position of the fastening element (2) being achieved through an adjusting element (12, 10), in which locked position the fastening part (2) and the clamping element (5) are held in a pressing tension in the grooves (15, 15') between two flanges (16, 16') mounted on the frame (11) or leaf, which flanges are aligned to one another respectively forming a groove (15, 15') and run parallel, the clamping element (5) is slidable by means of the adjusting element or by means of another optionally separate, adjusting element (9), at least from an initial or release position into an adjustment position, whereas in the initial or release position, the fastening part (2) and the clamping element (5) can be inserted into or removed from the grooves (15, 15') in a direction essentially perpendicular to the plane given by the grooves (15, 15'), and in the adjustment position the fastening part (2) is slidable to and fro in a direction parallel to the course of the grooves (15, 15') for adjustment and is fixed in the remaining directions.
The invention relates to a strip for doors, windows or similar for joining, in a hinged manner, a wing of a door, a window or similar to a frame about the hinge axis (S). Said strip comprises one pair of external hinged parts (1, 1') and an internal hinged part (2) which is arranged between the external hinged parts and which is used to fix, to the frame or wing, two ball bearings (3, 31) that are respectively arranged between the internal hinged part (2) and the external hinged parts (1, 1') and respectively mounted in the step bearings (6, 7), said ball bearings defining the hinge axis (S) in order to provide a pivotable bearing of the inner hinge part (2) in relation to the external hinge parts (1, 1'). At least one of the external hinge parts (1, 1') has an essentially cylindrical bore (4) that extends in the direction of the hinge axis (S) and has inner threads, in which an insert (5) is introduced and which is embodied as a step bearing (6). Said insert (5) comprises an external thread (51) that cooperates with the internal thread (41) in order to release the ball bearings (3) from at least one corresponding step bearing (6, 7) by rotating the insert (5) in the direction of release and when the insert (5) in is the released position (5), the internal hinge part (2) is separated from the external hinge parts (1, 1').
A hinge which has a frame hinge part to be fastened via an associated fastening part (1) to a fixed frame, and a wing hinge part which is to be fastened via an associated fastening part (1) to a wing and can be pivoted about a hinge axis (12) in relation to the frame hinge part, wherein at least one of the fastening parts (1) is mounted displaceably at least linearly by means of a retaining part (2) to be fastened in a fixed manner to the frame or the wing, wherein an accessible adjustment element (3) is arranged on the retaining part (2), and wherein an axis of rotation of the adjustment element (3), which axis of rotation is associated with the adjustment of the rotational movement, lies essentially perpendicularly to the plane predetermined by the fastening part and the hinge axis.
