A ground protection mat is in the form of a sheet material that is made from foamed polymeric material, preferably a foamed polypropylene or foamed ethylene vinyl acetate, and more preferably a material having a flexural strength ranging from about 2400 to about 6000 kpa. The sheet material can include raised portions on a top side thereof, or both top and bottom sides to improve traction for people or equipment traveling over the ground protection mats. The ground protection mats are light weight so that one individual can easily carry one, or even two, to be positioned in a desired location, but provide the necessary stiffness and strength for transportation and use purposes.
A customizable tile is configured for use with a modular platform system that uses tiles, beams supporting the tiles, and legs supporting the beams. The customizable tiles include a tile sizing structure on an underside thereof. The tile sizing structure includes channels and cutting slots extending in different directions so that the channels and cutting slots intersect. The cutting slots act as a guide to cut the tile to alter its width and/or length so that the tile has a customized size for use in the modular platform system. The channels are configured to receive a support board, if necessary, to provide support for the tile on the beams once the tile is cut to size. The channels can also connect to the beams for tile support if need be.
A mat assembly includes a center section and four ramps that create a unitary mat assembly for any desired use. The center section includes a top plate that provides the desired kind of mat surface for use and a sponge layer underlying the top plate to provide the center section with a cushioned feel during use. Each ramp includes a flange that extends from an end portion of the ramp, the flange configured to be joined between the top plate and sponge insert. The ramps can be joined to each other using a connector or a mitered connection.
An interlocking modular mat having four sides has female connectors on two sides and male connectors on the other two sides so that the modular mat can interlock with an adjacent mat and its connectors. The modular mat is configured with a plurality of structures surrounding a periphery of a top portion of the mat. The plurality of structures in combination with an underside of the top portion of the mat form a cavity. A sponge insert is configured to fit in the cavity and have a height such that a portion of the sponge insert extends from a bottom side the mat body. With the sponge insert extending beyond the bottom side of the mat body, the sponge insert bottom face generally become the supporting bottom of the modular mat to provide a more cushioned feel for a mat user.
E04F 15/22 - Planchers montés élastiquement, p. ex. planchers montés sur ressorts
A47G 27/02 - TapisTapis d'escaliersDescentes de litPaillassons
E04F 15/02 - Revêtements de sol composés d'un certain nombre d'éléments semblables
E04F 15/10 - Revêtements de sol composés d'un certain nombre d'éléments semblables en d'autres matériaux, p. ex. en matériaux fibreux ou en copeaux, en matières plastiques organiques, en magnésite, en agglomérés
A modular platform system includes a plurality of tiles, legs, beams, and brackets. Peripheries of the tiles and top surfaces of the beams are configured so that the tiles can snap on to the beams, allowing for easy creation of a platform. The beams, legs, and brackets are all configured so that the beams and legs are easily connected together for platform system creation.
B62B 3/00 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet
A mat assembly includes a center section and four ramps that create a unitary mat assembly for any desired use. The center section includes a top plate that provides the desired kind of mat surface for use and a sponge layer underlying the top plate to provide the center section with a cushioned feel during use. Each ramp includes a flange that extends from an end portion of the ramp, the flange configured to be joined between the top plate and sponge insert. The ramps can be joined to each other using a connector or a mitered connection.
An interlocking modular mat having four sides has female connectors on two sides and male connectors on the other two sides so that the modular mat can interlock with an adjacent mat and its connectors. The modular mat is configured with a plurality of structures surrounding a periphery of a top portion of the mat. The plurality of structures in combination with an underside of the top portion of the mat form a cavity. A sponge insert is configured to fit in the cavity and have a height such that a portion of the sponge insert extends from a bottom side the mat body. With the sponge insert extending beyond the bottom side of the mat body, the sponge insert bottom face generally become the supporting bottom of the modular mat to provide a more cushioned feel for a mat user.
E04F 15/22 - Planchers montés élastiquement, p. ex. planchers montés sur ressorts
E04F 15/10 - Revêtements de sol composés d'un certain nombre d'éléments semblables en d'autres matériaux, p. ex. en matériaux fibreux ou en copeaux, en matières plastiques organiques, en magnésite, en agglomérés
A47G 27/02 - TapisTapis d'escaliersDescentes de litPaillassons
E04F 15/02 - Revêtements de sol composés d'un certain nombre d'éléments semblables
A modular platform system includes a plurality of tiles, legs, beams, and brackets. Peripheries of the tiles and top surfaces of the beams are configured so that the tiles can snap on to the beams, allowing for easy creation of a platform. The beams, legs, and brackets are all configured so that the beams and legs are easily connected together for platform system creation.
B62B 3/00 - Voitures à bras ayant plus d'un essieu portant les roues servant au déplacementDispositifs de direction à cet effetAppareillage à cet effet
Modular elevated work platforms. Elevating work platforms. Modular elevated flooring system comprised of legs, support
beams, tiles, and fasteners (term considered too vague by
the International Bureau - Rule 13 (2) (b) of the
Regulations); prefabricated modular non-metal platforms;
elevated flooring system; modular elevated platforms and
flooring systems for use in manufacturing plants, assembly
lines, food production plants, and other industrial uses;
semi permanent, non-metal scaffolding; semi-permanent,
non-metal scaffolding for use in manufacturing plants,
assembly lines, food production plants, and other industrial
uses.
Modular elevated work platforms. Elevating work platforms. Modular elevated flooring system comprised of legs, support
beams, tiles, and fasteners (term considered too vague by
the International Bureau - Rule 13 (2) (b) of the
Regulations); prefabricated modular non-metal platforms;
elevated flooring system; modular elevated platforms and
flooring systems for use in manufacturing plants, assembly
lines, food production plants, and other industrial uses;
semi permanent, non-metal scaffolding; semi-permanent,
non-metal scaffolding for use in manufacturing plants,
assembly lines, food production plants, and other industrial
uses.
(1) Modular elevated work platforms.
(2) Elevating work platforms.
(3) Modular elevated flooring systems namely a modular system for construction of elevated flooring surfaces comprised of legs, support beams, surface tiles, and component fasteners for combination in the assembly of the modular elevated floor; prefabricated modular non-metal platforms for use in manufacturing plants, assembly lines, food production plants and other industrial uses; elevated flooring systems namely systems providing elevated flooring surfaces once assembled, comprising of legs, support beams, surface tiles and component fasteners; modular elevated platforms and flooring systems for use in manufacturing plants, assembly lines, food production plants and other industrial uses namely a modular system comprised of legs, support beams, surface tiles and component fasteners; semi permanent non-metal scaffolding for use in manufacturing plants, assembly lines, food production plants and other commercial and industrial applications.
(1) Modular elevated work platforms.
(2) Elevating work platforms.
(3) Modular elevated flooring systems namely a modular system for construction of elevated flooring surfaces comprised of legs, support beams, surface tiles, and component fasteners for combination in the assembly of the modular elevated floor; prefabricated modular non-metal platforms for use in manufacturing plants, assembly lines, food production plants, and other industrial uses; elevated flooring systems namely systems providing elevated flooring surfaces once assembled, comprised of legs, support beams, surface tiles and component fasteners; modular elevated platforms and flooring systems for use in manufacturing plants, assembly lines, food production plants and other industrial uses namely a modular system comprised of legs, support beams, surface tiles and component fasteners; semi permanent non-metal scaffolding for use in manufacturing plants, assembly lines, food production plants and other commercial and industrial applications.
modular elevated flooring system made of metal legs, metal support beams, tiles predominantly not of metal, and also containing fasteners elevated flooring predominantly not of metal; modular elevated non-metal flooring for use in manufacturing plants, assembly lines, food production plants, and other industrial uses; semi-permanent, non-metal scaffolding; semi-permanent, non-metal scaffolding for use in manufacturing plants, assembly lines, food production plants, and other industrial uses; modular elevated work platforms predominantly not of metal; modular elevated prefabricated platforms predominantly not of metal for use in manufacturing plants, assembly lines, food production plants and other industrial uses
modular elevated flooring system made of metal legs, metal support beams, tiles predominantly not of metal, and also containing fasteners elevated flooring predominantly not of metal; modular elevated non-metal flooring for use in manufacturing plants, assembly lines, food production plants, and other industrial uses; semi-permanent, non-metal scaffolding; semi-permanent, non-metal scaffolding for use in manufacturing plants, assembly lines, food production plants, and other industrial uses; modular elevated work platforms predominantly not of metal; modular elevated prefabricated platforms predominantly not of metal for use in manufacturing plants, assembly lines, food production plants and other industrial uses
An interlocking modular mat having four sides has female connectors on two sides and male connectors on the other two sides so that the modular mat can interlock with an adjacent mat and its connectors. The modular mat is configured with a plurality of structures surrounding a periphery of a top portion of the mat. The plurality of structures in combination with an underside of the top portion of the mat form a cavity. A sponge insert is configured to fit in the cavity and have a height such that a portion of the sponge insert extends from a bottom side the mat body. With the sponge insert extending beyond the bottom side of the mat body, the sponge insert bottom face generally become the supporting bottom of the modular mat to provide a more cushioned feel for a mat user.
E04F 15/22 - Planchers montés élastiquement, p. ex. planchers montés sur ressorts
E04F 15/10 - Revêtements de sol composés d'un certain nombre d'éléments semblables en d'autres matériaux, p. ex. en matériaux fibreux ou en copeaux, en matières plastiques organiques, en magnésite, en agglomérés
A47G 27/02 - TapisTapis d'escaliersDescentes de litPaillassons
E04F 15/02 - Revêtements de sol composés d'un certain nombre d'éléments semblables
09 - Appareils et instruments scientifiques et électriques
19 - Matériaux de construction non métalliques
20 - Meubles et produits décoratifs
Produits et services
cable bridges in the nature of cable protectors; cable and hose protectors in the nature of covers for hoses and electric cables to prevent damage and other hazards; hose and electric cable protectors in the nature of vehicle ramps or speed bumps specially adapted to cover hoses and electric cables to prevent damage and other hazards; electric cable protectors, namely, polyurethane floor covers and protectors designed to be used to protect and cover electrical cables on the ground; floor power cable covers and power cable protectors. plastic cable covers, plastic cable protectors. Modular cable and hose protectors with channels that protect a wide variety of hoses and cables from vehicular and pedestrian traffic; modular plastic cable and hose protectors, namely, hose and cable covers for heavy duty hoses and primary power cables; Modular electric hose and cable protectors, namely, modular thermoplastic polyurethane floor covers and protectors designed to be used to protect and hoses and cover electrical cables on the ground; Modular non-metal hose and cable protectors with channels that protect hoses and cables from vehicular and pedestrian traffic made from thermoplastic polyurethane.
09 - Appareils et instruments scientifiques et électriques
17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
Produits et services
Cable bridges in the nature of cable protectors specially designed to protect electrical and optical cables; cable protectors in the nature of covers specially adapted for electric cables to prevent damage and other hazards; electric cable protectors in the nature of vehicle ramps or speed bumps specially adapted to cover electric cables to prevent damage and other hazards; electric cable protectors, namely, polyurethane floor covers and protectors specially designed and adapted to be used to protect and cover electrical cables on the ground; floor power cable covers and power cable protectors specially adapted to cover and protect electrical power cables; electric cable covers and protectors in the nature of protective sheaths for electrical cables; modular cable protectors with channels specially adapted to protect a wide variety of electrical and optical cables from vehicular and pedestrian traffic; modular plastic cable protectors, namely, cable covers specially adapted for protecting primary electric power cables; modular electric cable protectors, namely, modular thermoplastic polyurethane floor covers and protectors specially adapted and designed to protect and cover electrical cables on the ground; modular non-metal cable protectors with channels that are specially adapted to protect electrical and optical cables from vehicular and pedestrian traffic made from thermoplastic polyurethane Hose protectors in the nature of covers specially adapted for non-metal hoses to prevent damage and other hazards; modular hose protectors with channels specially adapted to protect a wide variety of non-metal hoses from vehicular and pedestrian traffic; modular plastic hose protectors, namely, hose covers specially adapted for protecting heavy duty non-metal hoses; modular non-metal hose protectors, namely, modular thermoplastic polyurethane floor covers and protectors specially adapted and designed to protect and cover non-metal hoses on the ground; modular non-metal hose protectors with channels that are specially adapted to protect non-metal hoses and cables from vehicular and pedestrian traffic made from thermoplastic polyurethane; hose protectors in the nature of non-metal vehicle ramps or speed bumps specially adapted to cover non-metal hoses to prevent damage and other hazards
Connecting feature of non-metal floor tiles, namely,
interconnecting couplers for joining modular tiles together,
sold as a component of the non-metal floor tiles. Non-metal fasteners for use in connecting floor tiles,
rubber mats, and floor mats. Connecting feature of floor mats and rubber mats, namely,
interconnecting couplers for joining modular mats, sold as a
component of the floor mats and rubber mats.
(1) Connecting feature of non-metal floor tiles, namely, interconnecting couplers for joining modular tiles together, sold as a component of the non-metal floor tiles.
(2) Non-metal fasteners for use in connecting floor tiles, rubber mats, and floor mats.
(3) Connecting feature of floor mats and rubber mats, namely, interconnecting couplers for joining modular mats, sold as a component of the floor mats and rubber mats.
connecting feature of floor mats and rubber mats, namely, interconnecting couplers for joining modular mats, sold as a component of the floor mats and rubber mats connecting feature of non-metal floor tiles, namely, interconnecting couplers for joining modular tiles together, sold as a component of the non-metal floor tiles non-metal fasteners for use in connecting floor tiles, rubber mats, and floor mats
An interlocking, modular floor tile that comprises a planar member defined by a perimeter having four sides and a top surface, a plurality of downwardly projecting support legs of common length dispersed pattern-wise inside the perimeter of the planar member and coupled with the top surface, and at least one female interlocking connector element that extends outside the perimeter of the planar member for receiving a support leg of a like tile and thereby forming an interlock with the like tile.
A mat assembly includes a center section and four ramps that create a unitary mat assembly for any desired use. The center section includes a top plate that provides the desired kind of mat surface for use and a sponge layer underlying the top plate to provide the center section with a cushioned feel during use. Each ramp includes a flange that extends from an end portion of the ramp, the flange configured to be joined between the top plate and sponge insert. The ramps can be joined to each other using a connector or a mitered connection.
A modular platform system includes a plurality of tiles, legs, beams, and brackets. Peripheries of the tiles and top surfaces of the beams are configured so that the tiles can snap on to the beams, allowing for easy creation of a platform. The beams, legs, and brackets are all configured so that the beams and legs are easily connected together for platform system creation.
E04G 1/15 - Échafaudages reposant principalement sur le sol comprenant essentiellement des moyens particuliers pour supporter ou former des plates-formesPlates-formes
60.
CUSTOMIZABLE TILE FOR MODULAR PLATFORM SYSTEM, MODULAR PLATFORM SYSTEM WITH CUSTOMIZABLE TILE, AND METHOD OF PLATFORM MAKING
A customizable tile is configured for use with a modular platform system that uses tiles, beams supporting the tiles, and legs supporting the beams. The customizable tiles include a tile sizing structure on an underside thereof. The tile sizing structure includes channels and cutting slots extending in different directions so that the channels and cutting slots intersect. The cutting slots act as a guide to cut the tile to alter its width and/or length so that the tile has a customized size for use in the modular platform system. The channels are configured to receive a support board, if necessary, to provide support for the tile on the beams once the tile is cut to size. The channels can also connect to the beams for tile support if need be.
E04F 15/12 - Revêtements de sols faits de produits préparés sur place, p. ex. planchers en magnésite d'un seul tenant, mosaïques
E04G 1/15 - Échafaudages reposant principalement sur le sol comprenant essentiellement des moyens particuliers pour supporter ou former des plates-formesPlates-formes
A ground protection mat is in the form of a sheet material that is made from foamed polymeric material, preferably a foamed polypropylene or foamed ethylene vinyl acetate, and more preferably a material having a flexural strength ranging from about 2400 to about 6000 kpa. The sheet material can include raised portions on a top side thereof, or both top and bottom sides to improve traction for people or equipment traveling over the ground protection mats. The ground protection mats are light weight so that one individual can easily carry one, or even two, to be positioned in a desired location, but provide the necessary stiffness and strength for transportation and use purposes.
An interlocking modular mat having four sides has female connectors on two sides and male connectors on the other two sides so that the modular mat can interlock with an adjacent mat and its connectors. The modular mat is configured with a plurality of structures surrounding a periphery of a top portion of the mat. The plurality of structures in combination with an underside of the top portion of the mat form a cavity. A sponge insert is configured to fit in the cavity and have a height such that a portion of the sponge insert extends from a bottom side the mat body. With the sponge insert extending beyond the bottom side of the mat body, the sponge insert bottom face generally become the supporting bottom of the modular mat to provide a more cushioned feel for a mat user.
A63B 6/00 - Tapis ou moyens analogues pour amortir les chocs lors du saut ou en gymnastique ou analogue
E04F 15/02 - Revêtements de sol composés d'un certain nombre d'éléments semblables
E04F 15/10 - Revêtements de sol composés d'un certain nombre d'éléments semblables en d'autres matériaux, p. ex. en matériaux fibreux ou en copeaux, en matières plastiques organiques, en magnésite, en agglomérés
An interlocking, modular floor tile that comprises a planar member defined by a perimeter having four sides and a top surface, a plurality of downwardly projecting support legs of common length dispersed pattern-wise inside the perimeter of the planar member and coupled with the top surface, and at least one female interlocking connector element that extends outside the perimeter of the planar member for receiving a support leg of a like tile and thereby forming an interlock with the like tile.
