A track of a vertically stacking door includes a vertical track, a first curved track portion, a second curved track portion, a first horizontal track portion coupled to the first curved track portion, and a second horizontal track portion coupled to the second curved track portion. The first curved track portion and the second curved track portion are split off from the vertical track and the first curved track portion and the second curved track portion each comprises multiple radii of curvature.
E06B 3/92 - Portes ou fenêtres extensibles une fois mises en place
E05D 15/20 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan se déplaçant hors d'un plan dans un second plan parallèle
In one embodiment, a closure system comprises a guide assembly having a channel defined by a first guide wall and a second guide wall. The closure system may include a retention bar extending into the channel from the first guide wall and a plurality of slats. Each slat of the plurality of slats may be configured to interlock with another of the plurality of slats. Each slat may have a retention groove with at least one sidewall configured and dimensioned to engage the retention bar to retain the slat within the channel.
E06B 9/86 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre l'ouverture sans autorisation
Examples of the present disclosure provide an overhead door panel. The overhead door panel includes a pair of parallel glass panes, a metal frame with parallel lateral stiles oriented perpendicular to the pair of parallel glass panes, a first seal system located at a first lateral stile, and a second seal system located at a second lateral stile, wherein the first seal system and the second seal system engage with at least one glass pane of the pair of parallel glass panes and a lateral stile of the parallel lateral stiles of the metal frame such that the first seal system and the second seal system are between the at least one glass pane and the lateral stile.
In example implementations, a slat for a rolling steel door is provided. The slat includes a front slat fabricated from steel, a back slat fabricated from plastic having a thickness between 0.02 inches and 0.1 inches, wherein the back slat is coupled to the front slat to form an interior volume, and a mineral wool insulation to substantially fill the interior volume.
E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation
E06B 5/16 - Portes ou autres fermetures à l'épreuve du feuAdaptation des constructions fixes à cet effet
In example implementations, a cable carrier assembly for a sectional door is provided. The cable carrier assembly includes a cable carrier track coupled to a track of the sectional door, a sectional cable carrier guide coupled to a panel of the sectional door, and a cable carrier, wherein a first end of the cable carrier is coupled to the cable carrier track and a second end of the cable carrier is coupled to the sectional cable carrier guide.
In example implementations, a power hinge for panels of a sectional door is provided. The power hinge includes a first hinge leaf, a second hinge leaf, a rod, a first hinge cover, and a second hinge cover. The first hinge leaf includes a body portion comprising at least one opening to receive a mechanical coupling and an electrical wire opening and opposing sides coupled to the body portion. The second hinge leaf includes a body portion comprising at least one opening to receive a mechanical coupling and an electrical wire opening and opposing sides coupled to the body portion, wherein the opposing sides of the first hinge leaf are inserted between and aligned with the opposing sides of the second hinge leaf. The rod is coupled to the first hinge leaf and the second hinge leaf through the opposing sides of the first hinge leaf and the second hinge leaf.
E05D 15/24 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan consistant en éléments reliés par leurs bords
E05D 7/00 - Charnières, gonds ou pivots de structure particulière
E05D 11/00 - Caractéristiques ou accessoires complémentaires des charnières ou gonds
In example implementations, a power plug for panels of a sectional door is provided. The power plug includes a first end comprising a first plug, a second end comprising a second plug, and a flexible housing coupled to the first end and the second end, wherein the flexible housing encloses electrical wiring connecting the first plug and the second plug.
E06B 3/48 - Battants reliés par leurs bords, p. ex. battants repliables
E05D 15/16 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan
E05D 15/24 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan consistant en éléments reliés par leurs bords
E05D 15/38 - Suspensions pour battants se déplaçant le long de glissières disposées de manière qu'un élément-guide du battant se déplace dans un sens sensiblement perpendiculaire au mouvement d'un autre élément-guide pour battants à mouvement vers le haut, p. ex. portes relevantes et basculantes
In example implementations, a panel of a sectional door is provided. The panel includes a panel housing, an opening in the panel housing, an edge-lit light emitting diode (LED) panel in the opening, and a constant power source electrically connected to the edge-lit LED panel. The edge-lit LED panel may provide privacy and a desired aesthetic look when activated for the sectional door.
In example implementations, a back-lit light emitting diode (LED) panel for a panel of a sectional door is provided. The back-lit LED panel includes a frame comprising a back side, a top side, a bottom side, a left side, and a right side, at least one LED array coupled to the back side of the frame, and a diffuser coupled to the top side, the bottom side, the left side, and the right side of the frame to enclose the at least one LED array, wherein the back-lit LED panel is less than 2 inches thick to fit into an opening of the panel of the sectional door.
G09F 13/04 - Enseignes, tableaux ou panneaux éclairés de derrière l'illustration
E05D 15/16 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan
E05D 15/24 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan consistant en éléments reliés par leurs bords
E05F 15/668 - Mécanismes pour battants mus par une force motrice utilisant des actionneurs électriques utilisant des électromoteurs rotatifs pour battants à coulissement vertical pour battants s’ouvrant de haut en bas
E06B 7/28 - Autres dispositions portées par les portes ou les fenêtres, p. ex. panneaux de portes, fenêtres adaptées pour porter des plantes, crochets pour les laveurs de carreaux
In example implementations, a retractable cord assembly for a sectional door is provided. The retractable cord assembly includes a retractable cord housing, a wire retainer to be coupled to an axle of a roller of the sectional door, and a power cord, wherein a first end of the power cord is coupled to an interior axle of the retractable cord housing and a second end of the power cord is fed through the wire retainer and into a panel of the sectional door.
E06B 7/28 - Autres dispositions portées par les portes ou les fenêtres, p. ex. panneaux de portes, fenêtres adaptées pour porter des plantes, crochets pour les laveurs de carreaux
E05D 15/16 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan
12.
SECTIONAL DOOR WITH INTEGRATED ELECTRICAL COMPONENTS
In example implementations, a panel of a sectional door is provided. The panel includes a panel housing, an integrated electrical component located within a body of the panel housing, and a constant power source electrically connected to the integrated electrical component. The integrated electrical component is located within an interior volume of the body of the panel housing or in the body of the panel housing.
E06B 3/48 - Battants reliés par leurs bords, p. ex. battants repliables
E05F 15/40 - Dispositifs de sécurité, p. ex. détection d’obstacles ou de fin de course
E05F 15/00 - Mécanismes pour battants mus par une force motrice
E06B 7/02 - Aménagements particuliers ou dispositions en rapport avec les portes ou fenêtres pour assurer la ventilation, p. ex. à travers des doubles fenêtresAménagement de rosaces de ventilation
E06B 7/00 - Aménagements particuliers ou dispositions en rapport avec les portes ou fenêtres
E06B 7/28 - Autres dispositions portées par les portes ou les fenêtres, p. ex. panneaux de portes, fenêtres adaptées pour porter des plantes, crochets pour les laveurs de carreaux
In example implementations, a guide for a fire shutter is provided. The guide includes a first bracket to be coupled to a wall, a second bracket coupled to the first bracket, wherein the first bracket and the second bracket form a channel to receive a curtain of the fire shutter, and a fixed guide brush seal permanently affixed to the second bracket during manufacture of the second bracket.
E06B 7/16 - Dispositions d'étanchéité sur les battants ou les parties qui travaillent avec les battants
E06B 7/18 - Dispositions d'étanchéité sur les battants ou les parties qui travaillent avec les battants par bourrelets amovibles, p. ex. obturateurs d'air utilisés additionnellement pour le verrouillage
E06B 7/22 - Dispositions d'étanchéité sur les battants ou les parties qui travaillent avec les battants par bourrelets élastiques, p. ex. tubes de caoutchoucDispositions d'étanchéité sur les battants ou les parties qui travaillent avec les battants par bourrelets souples, p. ex. en feutre ou en peluche, en bandes de métal souple
E06B 7/23 - Bandes ou tubes de plastique, caoutchouc mousse ou similaire
E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation
In example implementations, a method executed by a processor of a controller of a rolling door system is provided. The method includes receiving an alarm signal, determining a type of alarm associated with the alarm signal, and transmitting a control signal to operate a motor to open or close a rolling door in response to the type of alarm that is determined.
E05F 15/60 - Mécanismes pour battants mus par une force motrice utilisant des actionneurs électriques
E05F 15/608 - Mécanismes pour battants mus par une force motrice utilisant des actionneurs électriques utilisant des électromoteurs rotatifs pour battants à tambour
G08B 1/08 - Systèmes de signalisation caractérisés seulement par la forme de transmission du signal utilisant une transmission électrique
G08B 27/00 - Systèmes d'alarme dans lesquels la condition déclenchant l'alarme est signalée par une station centrale à plusieurs sous-stations
E05F 11/00 - Mécanismes actionnés par l'homme pour la manœuvre des battants, y compris ceux qui commandent aussi leur immobilisation
G08B 23/00 - Alarmes réagissant à des conditions indésirables ou anormales, non spécifiées
G08B 29/00 - Vérification ou contrôle des systèmes de signalisation ou d'alarmePrévention ou correction d'erreurs de fonctionnement, p. ex. empêchant le déclenchement non autorisé
In example implementations, a method executed by a processor of a controller of a rolling door system is provided. The method includes receiving an alarm signal, determining a type of alarm associated with the alarm signal, and transmitting a control signal to operate a motor to open or close a rolling door in response to the type of alarm that is determined.
E05F 15/72 - Mécanismes pour battants mus par une force motrice avec déclenchement automatique sensible à des conditions d’urgence, p. ex. incendie
E05F 15/668 - Mécanismes pour battants mus par une force motrice utilisant des actionneurs électriques utilisant des électromoteurs rotatifs pour battants à coulissement vertical pour battants s’ouvrant de haut en bas
E05F 15/73 - Mécanismes pour battants mus par une force motrice avec déclenchement automatique sensible au déplacement ou à la présence de personnes ou d’objets
16.
COMMUNICATION INTERFACE DEVICE FOR WIRELESS DOOR CONTROLLERS
In example implementations, an apparatus is provided. The apparatus includes a connection interface, a LAN interface, a WAN interface, and a processor. The connection interface is to connect to a PCB of a door controller. The LAN interface is to communicate with a plurality of door sensors. The WAN interface is to communicate with a remote server of a service provider. The processor is communicatively coupled to the connection interface, the LAN interface, and the WAN interface. The processor is to receive door data from the plurality of door sensors via the LAN interface, transmit the door data to the remote server for analysis, receive a correction action from the remote server in response to the door data that is transmitted, and execute the corrective action on a door of the plurality of doors via the LAN interface.
In one embodiment, a guide system includes a first member configured to be fixed to a structure. A coupling element is fixed to the first member. A second member is moveable relative to the first member. The second member is configured to receive the coupling element to couple the first member to the second member. There is a channel between the first member and the second member when the first member is coupled to the second member. The channel is configured to receive a portion of a closure.
In example implementations, the end cap of a vertical panel door stacking system is coupled to a panel. The end cap includes a body portion, a cam lever to rotate around an axis to generate a lift force to lift and separate an adjacent panel of a plurality of panels of the vertical panel door stacking system, a first track wheel, a second track wheel, and a third track wheel.
E05D 15/22 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan permettant un mouvement complémentaire
E06B 3/48 - Battants reliés par leurs bords, p. ex. battants repliables
E06B 3/50 - Aménagements des battants caractérisés par le genre de mouvementAménagements des battants modèles dans les ouverturesCaractéristiques des battants ou châssis ayant trait uniquement au genre de mouvement du battant pour plusieurs genres de mouvement
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
19.
Vertical stability roller for vertically stacking panels
In example implementations, an end cap for a panel of a vertically stacking panel door is provided. The end cap includes a body to be coupled to an end of a panel of a vertically stacking panel door, a first track wheel coupled to the body, a second track wheel coupled to the body, and a vertical stability roller coupled to the body, wherein the first track wheel, the second track wheel, and the vertical stability roller are arranged along a vertical line, wherein the first track wheel is located vertically above the second track wheel and the vertical stability roller is located between the first track wheel and the second track wheel.
E05D 15/24 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan consistant en éléments reliés par leurs bords
E05D 15/16 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan
In example implementations, a bead saddle attachment component for a curtain is provided. The bead saddle attachment component includes a body, a plurality of bead saddle features on an exterior side of the body, a spacer bracket receiving feature on the exterior side of the body, and an alignment feature on the exterior side of the body.
In example implementations, a bead saddle attachment component for a curtain is provided. The bead saddle attachment component includes a body, a plurality of bead saddle features on an exterior side of the body, a spacer bracket receiving feature on the exterior side of the body, and an alignment feature on the exterior side of the body.
In example implementations, a door monitoring sensor is provided. The door monitoring sensor includes a communication interface to transmit an alarm when a door operates outside of operational parameters of the door, an angular sensor to measure rotational movement of the a door, a movement sensor to detect movement along an x-y-z coordinate plane, a radar sensor to detect an object, a rechargeable power supply to provide power to the angular sensor, the movement sensor, and the radar sensor, and a processor. The processor is communicatively coupled to the communication interface, the angular sensor, the movement sensor, and the radar sensor. The processor is to determine that the door is moving outside of the operational parameters of the door and generate the alarm that is transmitted by the communication interface in response to determination that the door is moving outside of the operational parameters of the door.
G08B 13/08 - Déclenchement mécanique par ouverture, p. ex. de portes, de fenêtres, de tiroirs, de contrevents, de rideaux ou de stores
E05B 47/00 - Fonctionnement ou commande des serrures ou autres dispositifs d'immobilisation par des moyens électriques ou magnétiques
E06B 5/11 - Portes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour protection contre les raids aériens ou autres actes de guerrePortes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour d'autres buts de protection contre les cambriolages
23.
DOOR OPERATOR SENSOR AND LOGIC FOR VERTICALLY STACKING PANEL DOOR SYSTEMS
In example implementations, a vertically stacking panel door system is provided. The vertically stacking panel door system includes a horizontal door guide, a panel interface zone, a vertical door guide, a plurality of panels to move from a horizontally stacked position in the horizontal door guide to a vertically stacked position in the vertical door guide, a counterbalance system comprising a motor to move the plurality of panels, and a sensor to detect a gap between two adjacent panels of the plurality of panels as the plurality of panels are moved from the horizontally stacked position to the vertically stacked position, wherein the sensor is to transmit a signal to the motor when the gap is detected.
E05D 13/00 - Accessoires pour battants coulissants ou relevables, p. ex. poulies, crans de sûreté
E05D 15/06 - Suspensions pour battants pour battants coulissant horizontalement sensiblement dans leur propre plan
E05D 15/16 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
E05D 15/24 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan consistant en éléments reliés par leurs bords
E06B 3/00 - Châssis mobiles de fenêtres, battants de portes ou éléments analogues pour fermer les ouverturesPose des fermetures fixes ou mobiles, p. ex. des fenêtresCaractéristiques des châssis extérieurs fixes relatives au montage des châssis des battants
E06B 3/50 - Aménagements des battants caractérisés par le genre de mouvementAménagements des battants modèles dans les ouverturesCaractéristiques des battants ou châssis ayant trait uniquement au genre de mouvement du battant pour plusieurs genres de mouvement
G01L 3/12 - Dynamomètres de transmission rotatifs dans lesquels l'élément transmettant le couple comporte un arbre élastique en torsion impliquant des moyens électriques ou magnétiques d'indication impliquant des moyens photo-électriques
24.
DOOR OPERATOR SENSOR AND LOGIC FOR VERTICALLY STACKING PANEL DOOR SYSTEMS
In example implementations, a vertically stacking panel door system is provided. The vertically stacking panel door system includes a horizontal door guide, a panel interface zone, a vertical door guide, a plurality of panels to move from a horizontally stacked position in the horizontal door guide to a vertically stacked position in the vertical door guide, a counterbalance system comprising a motor to move the plurality of panels, and a sensor to detect a gap between two adjacent panels of the plurality of panels as the plurality of panels are moved from the horizontally stacked position to the vertically stacked position, wherein the sensor is to transmit a signal to the motor when the gap is detected.
E05F 15/70 - Mécanismes pour battants mus par une force motrice avec déclenchement automatique
E05D 15/20 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan se déplaçant hors d'un plan dans un second plan parallèle
In example implementations, a braking system for a vertical stacking panel door is provided. The braking system includes a first rod, a strap coupled to the first rod, a second rod movably coupled to the first rod, wherein the second rod is to engage a linear ratchet when moved from a disengaged position to an engaged position, and a torsion spring coupled to the first rod and the second rod, wherein tension from the strap moves the second rod into the disengaged portion and the torsion spring moves the second rod into the engaged position when tension is lost on the strap.
In example implementations, a braking system for a vertical stacking panel door is provided. The braking system includes a first rod, a strap coupled to the first rod, a second rod movably coupled to the first rod, wherein the second rod is to engage a linear ratchet when moved from a disengaged position to an engaged position, and a torsion spring coupled to the first rod and the second rod, wherein tension from the strap moves the second rod into the disengaged portion and the torsion spring moves the second rod into the engaged position when tension is lost on the strap.
In example implementations, a method is provided. The method includes determining, by a processor, that a vehicle is approaching a door of a building based on a velocity vector of the vehicle, calculating, by the processor, a time of arrival of the vehicle at the door based on the velocity vector of the vehicle and a distance of the vehicle from the door, and controlling, by the processor, the door to begin opening at a time based on the time of arrival and an amount of time for the door to open such that the door is opened when the vehicle arrives at the door.
E05F 15/73 - Mécanismes pour battants mus par une force motrice avec déclenchement automatique sensible au déplacement ou à la présence de personnes ou d’objets
E05D 15/20 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan se déplaçant hors d'un plan dans un second plan parallèle
E05D 15/22 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan permettant un mouvement complémentaire
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
37.
VERTICAL STABILITY ROLLER FOR VERTICALLY STACKING PANELS
In example implementations, an end cap for a panel of a vertically stacking panel door is provided. The end cap includes a body to be coupled to an end of a panel of a vertically stacking panel door, a first track wheel coupled to the body, a second track wheel coupled to the body, and a vertical stability roller coupled to the body, wherein the first track wheel, the second track wheel, and the vertical stability roller are arranged along a vertical line, wherein the first track wheel is located vertically above the second track wheel and the vertical stability roller is located between the first track wheel and the second track wheel.
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
E05D 15/20 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan se déplaçant hors d'un plan dans un second plan parallèle
E05D 15/22 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan permettant un mouvement complémentaire
38.
Vertical stability roller for vertically stacking panels
In example implementations, an end cap for a panel of a vertically stacking panel door is provided. The end cap includes a body to be coupled to an end of a panel of a vertically stacking panel door, a first track wheel coupled to the body, a second track wheel coupled to the body, and a vertical stability roller coupled to the body, wherein the first track wheel, the second track wheel, and the vertical stability roller are arranged along a vertical line, wherein the first track wheel is located vertically above the second track wheel and the vertical stability roller is located between the first track wheel and the second track wheel.
E05D 15/24 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan consistant en éléments reliés par leurs bords
E05D 15/16 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan
39.
VERTICALLY STACKING PANEL DOOR WITH IMPROVED CURVED TRACK PORTIONS
In example implementations, a track of a vertically stacking door is provided. The track includes a vertical track, a first curved track portion, a second curved track portion, a first horizontal track portion coupled to the first curved track portion, and a second horizontal track portion coupled to the second curved track portion. The first curved track portion and the second curved track portion are split off from the vertical track and the first curved track portion and the second curved track portion each comprises multiple radii of curvature.
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
E05D 15/26 - Suspensions pour battants pour battants repliables
E06B 3/48 - Battants reliés par leurs bords, p. ex. battants repliables
E06B 9/04 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction du type à battants, p. ex. tournants ou à glissière
E06B 3/48 - Battants reliés par leurs bords, p. ex. battants repliables
E06B 7/16 - Dispositions d'étanchéité sur les battants ou les parties qui travaillent avec les battants
E06B 7/21 - Dispositions d'étanchéité sur les battants ou les parties qui travaillent avec les battants par bourrelets amovibles, p. ex. obturateurs d'air utilisés additionnellement pour le verrouillage retirés automatiquement à l'ouverture du battant avec bandeau d'étanchéité mobile dans le plan du battant
E06B 7/22 - Dispositions d'étanchéité sur les battants ou les parties qui travaillent avec les battants par bourrelets élastiques, p. ex. tubes de caoutchoucDispositions d'étanchéité sur les battants ou les parties qui travaillent avec les battants par bourrelets souples, p. ex. en feutre ou en peluche, en bandes de métal souple
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
41.
VERTICALLY STACKING PANEL DOOR WITH IMPROVED CURVED TRACK PORTIONS
E06B 3/48 - Battants reliés par leurs bords, p. ex. battants repliables
E06B 9/04 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction du type à battants, p. ex. tournants ou à glissière
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
In example implementations, a header seal for a vertical stacking panel door is provided. The header seal includes a header channel and a seal plate. The header channel includes a body portion comprising a plurality of openings to receive a mechanical fastener and a lip portion coupled to the body portion. The seal plate includes a bracket comprising a plurality of openings to receive a mechanical fastener to connect the bracket to the top most vertical panel and a flexible member to contact the lip portion to form a seal against the lip of the header channel when the vertically stacking panel door is in a closed position.
E06B 3/48 - Battants reliés par leurs bords, p. ex. battants repliables
E06B 7/16 - Dispositions d'étanchéité sur les battants ou les parties qui travaillent avec les battants
E06B 9/15 - Volets à rouleau avec des éléments de fermeture constitués par des lattes ou analogues
E06B 7/21 - Dispositions d'étanchéité sur les battants ou les parties qui travaillent avec les battants par bourrelets amovibles, p. ex. obturateurs d'air utilisés additionnellement pour le verrouillage retirés automatiquement à l'ouverture du battant avec bandeau d'étanchéité mobile dans le plan du battant
E06B 7/22 - Dispositions d'étanchéité sur les battants ou les parties qui travaillent avec les battants par bourrelets élastiques, p. ex. tubes de caoutchoucDispositions d'étanchéité sur les battants ou les parties qui travaillent avec les battants par bourrelets souples, p. ex. en feutre ou en peluche, en bandes de métal souple
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
43.
Vertically stacking panel door with improved curved track portions
A track of a vertically stacking door includes a vertical track, a first curved track portion, a second curved track portion, a first horizontal track portion coupled to the first curved track portion, and a second horizontal track portion coupled to the second curved track portion. The first curved track portion and the second curved track portion are split off from the vertical track and the first curved track portion and the second curved track portion each comprises multiple radii of curvature.
E05D 15/20 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan se déplaçant hors d'un plan dans un second plan parallèle
In example implementations, a header seal for a vertical stacking panel door is provided. The header seal includes a header channel and a seal plate. The header channel includes a body portion comprising a plurality of openings to receive a mechanical fastener and a lip portion coupled to the body portion. The seal plate includes a bracket comprising a plurality of openings to receive a mechanical fastener to connect the bracket to the top most vertical panel and a flexible member to contact the lip portion to form a seal against the lip of the header channel when the vertically stacking panel door is in a closed position.
In example implementations, a track of a vertically stacking door is provided. The track includes a vertical track, a track coupling coupled to the vertical track, a first curved track portion coupled to the track coupling, a second curved track portion coupled to the track coupling, and a ramp coupled to the vertical track before the track coupling.
E05D 15/24 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan consistant en éléments reliés par leurs bords
46.
VERTICALLY STACKING PANEL DOOR WITH CAM LEVERS AND IMPROVED RAMPS
In example implementations, a track of a vertically stacking door is provided. The track includes a vertical track, a track coupling coupled to the vertical track, a first curved track portion coupled to the track coupling, a second curved track portion coupled to the track coupling, and a ramp coupled to the vertical track before the track coupling.
E05D 15/24 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan consistant en éléments reliés par leurs bords
In an example an overhead door track is provided. The overhead door track includes a vertical track section having an opening to receive a roller of a panel of an overhead door and to guide movement of the roller within the opening and a single solid polymer based vibration isolator coupled to the vertical track section to reduce vibration of the vertical track section caused by movement of the roller within the opening.
E05D 15/22 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan permettant un mouvement complémentaire
F16F 15/08 - Suppression des vibrations dans les systèmes non rotatifs, p. ex. dans des systèmes alternatifsSuppression des vibrations dans les systèmes rotatifs par l'utilisation d'organes ne se déplaçant pas avec le système rotatif utilisant des moyens élastiques avec ressorts en caoutchouc
In an example an overhead door track is provided. The overhead door track includes a vertical track section having an opening to receive a roller of a panel of an overhead door and to guide movement of the roller within the opening and a single solid polymer based vibration isolator coupled to the vertical track section to reduce vibration of the vertical track section caused by movement of the roller within the opening.
E06B 9/42 - Parties constitutives ou détails des stores à rouleau, p. ex. dispositifs de suspension, carters de stores
E04B 1/00 - Constructions en généralStructures qui ne sont limitées ni aux murs, p. ex. aux cloisons, ni aux planchers, ni aux plafonds, ni aux toits
E04B 1/98 - Protection contre d'autres agents indésirables ou dangers contre les vibrations ou les chocsProtection contre d'autres agents indésirables ou dangers contre les destructions mécaniques, p. ex. par les raids aériens
In an example an overhead door track is provided. The overhead door track includes a vertical track section having an opening to receive a roller of a panel of an overhead door and to guide movement of the roller within the opening and a single solid polymer based vibration isolator coupled to the vertical track section to reduce vibration of the vertical track section caused by movement of the roller within the opening.
E04B 1/98 - Protection contre d'autres agents indésirables ou dangers contre les vibrations ou les chocsProtection contre d'autres agents indésirables ou dangers contre les destructions mécaniques, p. ex. par les raids aériens
E06B 1/56 - Fixation des châssis aux cadrages des ouvertures
In an example an overhead door track is provided. The overhead door track includes a vertical track section having an opening to receive a roller of a panel of an overhead door and to guide movement of the roller within the opening and a single solid polymer based vibration isolator coupled to the vertical track section to reduce vibration of the vertical track section caused by movement of the roller within the opening.
F16F 15/08 - Suppression des vibrations dans les systèmes non rotatifs, p. ex. dans des systèmes alternatifsSuppression des vibrations dans les systèmes rotatifs par l'utilisation d'organes ne se déplaçant pas avec le système rotatif utilisant des moyens élastiques avec ressorts en caoutchouc
Examples of the present disclosure provide an overhead door panel. The overhead door panel includes a pair of parallel glass panes, a metal frame with parallel lateral stiles oriented perpendicular to the pair of parallel glass panes, a first seal system located at a first lateral stile, and a second seal system located at a second lateral stile, wherein the first seal system and the second seal system engage with at least one glass pane of the pair of parallel glass panes and a lateral stile of the parallel lateral stiles of the metal frame such that the first seal system and the second seal system are between the at least one glass pane and the lateral stile.
In example implementations, an adjustable speed operator governor release for a rolling fire shutter is provided. The adjustable speed operator governor release includes a shaft coupled to the rolling fire shutter, a gear on a first end of the shaft to engage a spring-loaded clutch during a fire, wherein the spring-loaded clutch is moved to disengage from a drive assembly and to engage the gear of the adjustable speed governor to operate the rolling fire shutter, and a linear speed adjusting mechanism coupled to the shaft and the gear to control a speed of free fall of the rolling fire shutter during the fire.
A62C 2/24 - Mécanismes de commande ou d'actionnement
E06B 9/84 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre le déroulement intempestif
53.
IMPROVED OPERATOR GOVERNOR RELEASE FOR FIRE SHUTTERS
In example implementations, an adjustable speed operator governor release for a rolling fire shutter is provided. The adjustable speed operator governor release includes a shaft coupled to the rolling fire shutter, a gear on a first end of the shaft to engage a spring-loaded clutch during a fire, wherein the spring-loaded clutch is moved to disengage from a drive assembly and to engage the gear of the adjustable speed governor to operate the rolling fire shutter, and a linear speed adjusting mechanism coupled to the shaft and the gear to control a speed of free fall of the rolling fire shutter during the fire.
A62C 2/24 - Mécanismes de commande ou d'actionnement
E06B 9/84 - Mesures de sécurité contre le déroulement intempestif ou l'ouverture sans autorisationDispositifs de freinage ou d'immobilisationDispositifs pour limiter le déroulement automatiques contre le déroulement intempestif
In example implementations, an adjustable speed operator governor release for a rolling fire shutter is provided. The adjustable speed operator governor release includes a shaft coupled to the rolling fire shutter, a gear on a first end of the shaft to engage a spring-loaded clutch during a fire, wherein the spring-loaded clutch is moved to disengage from a drive assembly and to engage the gear of the adjustable speed governor to operate the rolling fire shutter, and a linear speed adjusting mechanism coupled to the shaft and the gear to control a speed of free fall of the rolling fire shutter during the fire.
E06B 9/70 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique comportant un moteur électrique disposé à l'extérieur du rouleau
E05D 13/00 - Accessoires pour battants coulissants ou relevables, p. ex. poulies, crans de sûreté
E06B 5/16 - Portes ou autres fermetures à l'épreuve du feuAdaptation des constructions fixes à cet effet
E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation
55.
IMPROVED GUIDE CLOSING MECHANISM FOR FIRE SHUTTERS
In example implementations, a guide member is provided. The guide member includes a first portion to receive a first fastener to a second guide member to form a guide assembly having a gap, wherein an endlock of a fire shutter is positioned within the gap, a second portion to receive a second fastener to a wall, a third portion folded against the second portion, a fourth portion bent at 90-degrees or greater to the third portion.
In example implementations, a guide member is provided. The guide member includes a first portion to receive a first fastener to a second guide member to form a guide assembly having a gap, wherein an endlock of a fire shutter is positioned within the gap, a second portion to receive a second fastener to a wall, a third portion folded against the second portion, a fourth portion bent at 90-degrees or greater to the third portion.
G01N 15/02 - Recherche de la dimension ou de la distribution des dimensions des particules
G01N 15/14 - Techniques de recherche optique, p. ex. cytométrie en flux
C12Q 1/04 - Détermination de la présence ou du type de micro-organismeEmploi de milieux sélectifs pour tester des antibiotiques ou des bactéricidesCompositions à cet effet contenant un indicateur chimique
In example implementations, a guide member is provided. The guide member includes a first portion to receive a first fastener to a second guide member to form a guide assembly having a gap, wherein an endlock of a fire shutter is positioned within the gap, a second portion to receive a second fastener to a wall, a third portion folded against the second portion, a fourth portion bent at 90-degrees or greater to the third portion.
In example implementations, an apparatus is provided. The apparatus includes a connection interface, a LAN interface, a WAN interface, and a processor. The connection interface is to connect to a PCB of a door controller. The LAN interface is to communicate with a plurality of door sensors. The WAN interface is to communicate with a remote server of a service provider. The processor is communicatively coupled to the connection interface, the LAN interface, and the WAN interface. The processor is to receive door data from the plurality of door sensors via the LAN interface, transmit the door data to the remote server for analysis, receive a correction action from the remote server in response to the door data that is transmitted, and execute the corrective action on a door of the plurality of doors via the LAN interface.
In example implementations, a method is provided. The method includes determining, by a processor, that a vehicle is approaching a door of a building based on a velocity vector of the vehicle, calculating, by the processor, a time of arrival of the vehicle at the door based on the velocity vector of the vehicle and a distance of the vehicle from the door, and controlling, by the processor, the door to begin opening at a time based on the time of arrival and an amount of time for the door to open such that the door is opened when the vehicle arrives at the door.
G07C 9/10 - Barrières mobiles avec moyens d’enregistrement
E01F 13/04 - Dispositions pour interdire ou limiter la circulation, p. ex. portes, barrières pouvant être déplacées pour permettre ou empêcher le passage
E05F 15/73 - Mécanismes pour battants mus par une force motrice avec déclenchement automatique sensible au déplacement ou à la présence de personnes ou d’objets
E06B 9/68 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique
G07C 9/00 - Enregistrement de l’entrée ou de la sortie d'une entité isolée
G07C 9/20 - Enregistrement de l’entrée ou de la sortie d'une entité isolée comportant l’utilisation d’un laissez-passer
In example implementations, a method is provided. The method includes determining, by a processor, that a vehicle is approaching a door of a building based on a velocity vector of the vehicle, calculating, by the processor, a time of arrival of the vehicle at the door based on the velocity vector of the vehicle and a distance of the vehicle from the door, and controlling, by the processor, the door to begin opening at a time based on the time of arrival and an amount of time for the door to open such that the door is opened when the vehicle arrives at the door.
G07C 9/10 - Barrières mobiles avec moyens d’enregistrement
E05F 15/73 - Mécanismes pour battants mus par une force motrice avec déclenchement automatique sensible au déplacement ou à la présence de personnes ou d’objets
E06B 9/68 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique
In some embodiments, a nesting grille may include an alpha link having a top alpha link grommet, a beta link, and a plurality of cross members. In some embodiments, each of the plurality of cross members are coupled to at least one of the alpha link and the beta link. In one embodiment, the top alpha link grommet is configured to receive one of the plurality of cross members. In one embodiment, the grille is configured to be moveable between an extended state and a retracted state, the grille coiled about itself with the alpha link disposed inside of the beta link when the grille is in the retracted state.
In example implementations, a door monitoring sensor is provided. The door monitoring sensor includes a communication interface to transmit an alarm when a door operates outside of operational parameters of the door, an angular sensor to measure rotational movement of the a door, a movement sensor to detect movement along an x-y-z coordinate plane, a radar sensor to detect an object, a rechargeable power supply to provide power to the angular sensor, the movement sensor, and the radar sensor, and a processor. The processor is communicatively coupled to the communication interface, the angular sensor, the movement sensor, and the radar sensor. The processor is to determine that the door is moving outside of the operational parameters of the door and generate the alarm that is transmitted by the communication interface in response to determination that the door is moving outside of the operational parameters of the door.
G08B 13/08 - Déclenchement mécanique par ouverture, p. ex. de portes, de fenêtres, de tiroirs, de contrevents, de rideaux ou de stores
E06B 5/11 - Portes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour protection contre les raids aériens ou autres actes de guerrePortes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour d'autres buts de protection contre les cambriolages
E05B 47/00 - Fonctionnement ou commande des serrures ou autres dispositifs d'immobilisation par des moyens électriques ou magnétiques
G08B 25/00 - Systèmes d'alarme dans lesquels l'emplacement du lieu où existe la condition déclenchant l'alarme est signalé à une station centrale, p. ex. systèmes télégraphiques d'incendie ou de police
A roll-up door including a flexible curtain having a front surface, a back surface, a first end coupled to a shaft, a second end opposite the first end, and first and second side edges extending between the first end and the second end, the flexible curtain being moveable between a retracted position wherein the flexible curtain is coiled around the shaft and a deployed position wherein the flexible curtain is uncoiled from the shaft. A first retention band is mounted along at least a portion of the first side edge of the flexible curtain, the first retention band including an inner surface at least partially facing towards the flexible curtain, an outer surface opposite the inner surface, a fixed edge attached to the flexible curtain generally parallel to the first side edge, and a free edge opposite the fixed edge and movable relative to the fixed edge.
E06B 9/13 - Volets à rouleau avec des éléments de fermeture en une seule pièce, p. ex. en tôle ondulée
E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation
In example implementations, a door monitoring sensor is provided. The door monitoring sensor includes a communication interface to transmit an alarm when a door operates outside of operational parameters of the door, an angular sensor to measure rotational movement of the a door, a movement sensor to detect movement along an x-y-z coordinate plane, a radar sensor to detect an object, a rechargeable power supply to provide power to the angular sensor, the movement sensor, and the radar sensor, and a processor. The processor is communicatively coupled to the communication interface, the angular sensor, the movement sensor, and the radar sensor. The processor is to determine that the door is moving outside of the operational parameters of the door and generate the alarm that is transmitted by the communication interface in response to determination that the door is moving outside of the operational parameters of the door.
E06B 5/11 - Portes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour protection contre les raids aériens ou autres actes de guerrePortes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour d'autres buts de protection contre les cambriolages
G08B 13/08 - Déclenchement mécanique par ouverture, p. ex. de portes, de fenêtres, de tiroirs, de contrevents, de rideaux ou de stores
In example implementations, a door monitoring sensor is provided. The door monitoring sensor includes a communication interface to transmit an alarm when a door operates outside of operational parameters of the door, an angular sensor to measure rotational movement of the a door, a movement sensor to detect movement along an x-y-z coordinate plane, a radar sensor to detect an object, a rechargeable power supply to provide power to the angular sensor, the movement sensor, and the radar sensor, and a processor. The processor is communicatively coupled to the communication interface, the angular sensor, the movement sensor, and the radar sensor. The processor is to determine that the door is moving outside of the operational parameters of the door and generate the alarm that is transmitted by the communication interface in response to determination that the door is moving outside of the operational parameters of the door.
G08B 13/08 - Déclenchement mécanique par ouverture, p. ex. de portes, de fenêtres, de tiroirs, de contrevents, de rideaux ou de stores
E06B 5/11 - Portes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour protection contre les raids aériens ou autres actes de guerrePortes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour d'autres buts de protection contre les cambriolages
In example implementations, a door monitoring sensor is provided. The door monitoring sensor includes a communication interface to transmit an alarm when a door operates outside of operational parameters of the door, an angular sensor to measure rotational movement of the a door, a movement sensor to detect movement along an x-y-z coordinate plane, a radar sensor to detect an object, a rechargeable power supply to provide power to the angular sensor, the movement sensor, and the radar sensor, and a processor. The processor is communicatively coupled to the communication interface, the angular sensor, the movement sensor, and the radar sensor. The processor is to determine that the door is moving outside of the operational parameters of the door and generate the alarm that is transmitted by the communication interface in response to determination that the door is moving outside of the operational parameters of the door.
G08B 13/08 - Déclenchement mécanique par ouverture, p. ex. de portes, de fenêtres, de tiroirs, de contrevents, de rideaux ou de stores
E05B 47/00 - Fonctionnement ou commande des serrures ou autres dispositifs d'immobilisation par des moyens électriques ou magnétiques
E06B 5/11 - Portes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour protection contre les raids aériens ou autres actes de guerrePortes, fenêtres ou fermetures analogues à buts particuliersStructures de cadrage à leur effet pour d'autres buts de protection contre les cambriolages
G08B 25/00 - Systèmes d'alarme dans lesquels l'emplacement du lieu où existe la condition déclenchant l'alarme est signalé à une station centrale, p. ex. systèmes télégraphiques d'incendie ou de police
In example implementations, a track system of a vertically stacking door includes a vertical track, a track coupling coupled to the vertical track, a first curved track portion coupled to the track coupling, a second curved track portion coupled to the track coupling, and a ramp coupled to the vertical track. The ramp interacts with a cam lever to separate adjacent panels of the vertically stacking door.
E05D 15/16 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan
E05D 15/24 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan consistant en éléments reliés par leurs bords
E05D 13/00 - Accessoires pour battants coulissants ou relevables, p. ex. poulies, crans de sûreté
E05D 15/06 - Suspensions pour battants pour battants coulissant horizontalement sensiblement dans leur propre plan
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
E05F 15/681 - Mécanismes pour battants mus par une force motrice utilisant des actionneurs électriques utilisant des électromoteurs rotatifs pour battants à coulissement vertical pour battants s’ouvrant de haut en bas manœuvrés par des éléments de traction allongés souples, p. ex. des bandes
(1) Metal sectional garage doors for use in buildings
(2) Garage door openers and closers
(3) Glass structured sectional garage door panels for use in buildings
In example implementations, a horizontal door guide for a vertically stacking door is provided. The horizontal door guide includes a first track and a second track to vertically stack panels of a door along a horizontal line, a drive shaft coupled to a bottom most panel to lift the door vertically, a Geneva drive shaft coupled to the drive shaft, and a lifting cam coupled to the Geneva drive shaft, wherein the lifting cam comprises a rotating lever to separate and lift adjacent panels of the door as the door is opened in a vertical direction by the drive shaft and to push panels into the first track and the second track.
E05D 15/16 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan
E05F 15/665 - Mécanismes pour battants mus par une force motrice utilisant des actionneurs électriques utilisant des électromoteurs rotatifs pour battants à coulissement vertical
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
F16H 27/06 - Mécanismes à broches d'entraînement pénétrant des encoches entraînées, p. ex. entraînements à croix de Malte
In example implementations, a horizontal door guide for a vertically stacking door is provided. The horizontal door guide includes a first track and a second track to vertically stack panels of a door along a horizontal line, a drive shaft coupled to a bottom most panel to lift the door vertically, a Geneva drive shaft coupled to the drive shaft, and a lifting cam coupled to the Geneva drive shaft, wherein the lifting cam comprises a rotating lever to separate and lift adjacent panels of the door as the door is opened in a vertical direction by the drive shaft and to push panels into the first track and the second track.
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
Examples of the present disclosure provide an overhead door panel. The overhead door panel includes a pair of parallel glass panes, a metal frame with parallel lateral stiles oriented perpendicular to the pair of parallel glass panes, a first seal system located at a first lateral stile, and a second seal system located at a second lateral stile, wherein the first seal system and the second seal system engage with at least one glass pane of the pair of parallel glass panes and a lateral stile of the parallel lateral stiles of the metal frame such that the first seal system and the second seal system are between the at least one glass pane and the lateral stile.
In example implementations, a horizontal door guide for a vertically stacking door is provided. The horizontal door guide includes a first track and a second track to vertically stack panels of a door along a horizontal line, a drive shaft coupled to a bottom most panel to lift the door vertically, a Geneva drive shaft coupled to the drive shaft, and a lifting cam coupled to the Geneva drive shaft, wherein the lifting cam comprises a rotating lever to separate and lift adjacent panels of the door as the door is opened in a vertical direction by the drive shaft and to push panels into the first track and the second track.
E05F 15/686 - Mécanismes pour battants mus par une force motrice utilisant des actionneurs électriques utilisant des électromoteurs rotatifs pour battants à coulissement vertical pour battants s’ouvrant de haut en bas manœuvrés par des éléments de traction allongés souples, p. ex. des bandes par des câbles ou des cordes
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
In example implementations, an end cap is provided. The end cap includes a body portion comprising a top end, a bottom end, a front side, a back side, an inner side, and an outer side, a plurality of openings aligned between the inner side and the outer side to receive a mechanical fastener to connect to an end of the panel, a cam lever coupled to the top end, wherein the cam lever is to rotate around an axis to generate a lift force to lift and separate an adjacent panel, and a plurality of wheels coupled to the inner side, wherein the panel moves along a horizontal track via the plurality of wheels aligned with the horizontal track.
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
E05D 15/24 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan consistant en éléments reliés par leurs bords
E06B 3/00 - Châssis mobiles de fenêtres, battants de portes ou éléments analogues pour fermer les ouverturesPose des fermetures fixes ou mobiles, p. ex. des fenêtresCaractéristiques des châssis extérieurs fixes relatives au montage des châssis des battants
E05D 15/26 - Suspensions pour battants pour battants repliables
In example implementations, an end cap is provided. The end cap includes a body portion comprising a top end, a bottom end, a front side, a back side, an inner side, and an outer side, a plurality of openings aligned between the inner side and the outer side to receive a mechanical fastener to connect to an end of the panel, a cam lever coupled to the top end, wherein the cam lever is to rotate around an axis to generate a lift force to lift and separate an adjacent panel, and a plurality of wheels coupled to the inner side, wherein the panel moves along a horizontal track via the plurality of wheels aligned with the horizontal track.
E05D 15/24 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan consistant en éléments reliés par leurs bords
E05D 15/26 - Suspensions pour battants pour battants repliables
E06B 3/00 - Châssis mobiles de fenêtres, battants de portes ou éléments analogues pour fermer les ouverturesPose des fermetures fixes ou mobiles, p. ex. des fenêtresCaractéristiques des châssis extérieurs fixes relatives au montage des châssis des battants
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
Examples of the present disclosure provide an overhead door panel. The overhead door panel includes a pair of parallel glass panes, a metal frame with parallel lateral stiles oriented perpendicular to the pair of parallel glass panes, a first seal system located at a first lateral stile, and a second seal system located at a second lateral stile, wherein the first seal system and the second seal system engage with at least one glass pane of the pair of parallel glass panes and a lateral stile of the parallel lateral stiles of the metal frame such that the first seal system and the second seal system are between the at least one glass pane and the lateral stile.
Examples of the present disclosure provide an overhead door panel. The overhead door panel includes a pair of parallel glass panes, a metal frame with parallel lateral stiles oriented perpendicular to the pair of parallel glass panes, a first seal system located at a first lateral stile, and a second seal system located at a second lateral stile, wherein the first seal system and the second seal system engage with at least one glass pane of the pair of parallel glass panes and a lateral stile of the parallel lateral stiles of the metal frame such that the first seal system and the second seal system are between the at least one glass pane and the lateral stile.
In example implementations, an apparatus is provided. The apparatus includes a connection interface, a local area network (LAN) interface, a wide area network (WAN) interface, and a processor. The connection interface is to connect to a printed circuit board (PCB) of a door controller. The LAN interface is to communicate with a plurality of door sensors, wherein each one of the plurality door sensors is to monitor operation of a respective door of a plurality of doors. The WAN interface is to communicate with a remote server of a service provider. The processor is communicatively coupled to the connection interface, the LAN interface, and the WAN interface. The processor is to receive door data from the plurality of door sensors via the LAN interface, transmit the door data to the remote server for analysis via the WAN interface, receive a correction action from the remote server over the WAN interface in response to the door data, and execute the corrective action on a door of the plurality of doors via the LAN interface.
A closure system including a curtain configured to seal an opening, a wireless network having a plurality of channels, at least one transmitter coupled to the curtain and configured to communicate over the plurality of channels, and an operator operatively coupled to the curtain and configured to communicate over the plurality of channels, the operator and the at least one transmitter configured to communicate with each other over a selected one of the plurality of channels based upon communication interference detected on one or more channels.
A vertical panel door stacking system for a door having panels with end caps coupled thereto. The end caps include a body portion, a cam lever to rotate around an axis to generate a lift force to lift and separate an adjacent pair of panels of the panels of the door, a first track wheel, a second track wheel, and a third track wheel. The track wheels interact with a track system to guide movement of the door panels between a closed position and an open position.
E05D 15/22 - Suspensions pour battants pour battants coulissant verticalement sensiblement dans leur propre plan permettant un mouvement complémentaire
E06B 3/50 - Aménagements des battants caractérisés par le genre de mouvementAménagements des battants modèles dans les ouverturesCaractéristiques des battants ou châssis ayant trait uniquement au genre de mouvement du battant pour plusieurs genres de mouvement
E06B 9/06 - Volets, grillages amovibles ou autres dispositifs de fermeture de sécurité, p. ex. contre l'effraction rabattables ou repliables, p. ex. du type à soufflet ou en accordéon
E06B 3/48 - Battants reliés par leurs bords, p. ex. battants repliables
83.
COMMUNICATION INTERFACE DEVICE FOR WIRELESS DOOR CONTROLLERS
In example implementations, an apparatus is provided. The apparatus includes a connection interface, a local area network (LAN) interface, a wide area network (WAN) interface, and a processor. The connection interface is to connect to a printed circuit board (PCB) of a door controller. The LAN interface is to communicate with a plurality of door sensors, wherein each one of the plurality door sensors is to monitor operation of a respective door of a plurality of doors. The WAN interface is to communicate with a remote server of a service provider. The processor is communicatively coupled to the connection interface, the LAN interface, and the WAN interface. The processor is to receive door data from the plurality of door sensors via the LAN interface, transmit the door data to the remote server for analysis via the WAN interface, receive a correction action from the remote server over the WAN interface in response to the door data, and execute the corrective action on a door of the plurality of doors via the LAN interface.
In example implementations, an apparatus is provided. The apparatus includes a connection interface, a local area network (LAN) interface, a wide area network (WAN) interface, and a processor. The connection interface is to connect to a printed circuit board (PCB) of a door controller. The LAN interface is to communicate with a plurality of door sensors, wherein each one of the plurality door sensors is to monitor operation of a respective door of a plurality of doors. The WAN interface is to communicate with a remote server of a service provider. The processor is communicatively coupled to the connection interface, the LAN interface, and the WAN interface. The processor is to receive door data from the plurality of door sensors via the LAN interface, transmit the door data to the remote server for analysis via the WAN interface, receive a correction action from the remote server over the WAN interface in response to the door data, and execute the corrective action on a door of the plurality of doors via the LAN interface.
G07C 9/00 - Enregistrement de l’entrée ou de la sortie d'une entité isolée
H04W 4/80 - Services utilisant la communication de courte portée, p. ex. la communication en champ proche, l'identification par radiofréquence ou la communication à faible consommation d’énergie
E05F 15/00 - Mécanismes pour battants mus par une force motrice
85.
REPLACEMENT LINK FOR A ROLLING GRILL ENCLOSURE AND METHOD THEREOF
A replacement link for a rolling grill enclosure having a longitudinal body disposed about a longitudinal axis, and a first end grommet contiguous with a first end of the longitudinal body, the first end grommet having a discontinuous first grommet body disposed about a first center.
Metal sectional garage doors for use in buildings Electronic garage door openers and closers Glass structured sectional garage door panels for use in buildings
In example implementations, a roll-up door is provided. The roll-up door includes a shaft, a flexible curtain, a plurality of buttons along a first edge and a second edge of the flexible curtain, a first guide assembly to enclose the plurality of buttons along the first edge of the flexible curtain, and a second guide assembly to enclose the plurality of buttons along the second edge of the flexible curtain. A first end of the flexible curtain is coupled to the shaft. The plurality of buttons are to guide movement of the flexible curtain caused by rotation of the shaft.
In example implementations, a windlock is provided. The windlock includes a body, a windlock lip, and a gusset. The body includes holes to receive a fastener to be coupled to a slat of a roll-up door. The windlock lip is formed from a portion of the body that is bent from the body. The gusset is coupled to the body and the windlock to provide mechanical strength to the windlock lip.
E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation
In example implementations, a universal endlock is provided. The universal endlock includes a body, a first side along a first edge of the body, a second side along a second edge of the body opposite the first edge, a first lip on a first end of the first side, and a second lip on a first end of the second side. The body includes an intersecting hole pattern on a center portion of the body. The first side and the second side are each bent towards a back side of the body. The first lip is bent away from a first edge of the body and the second lip is bent away from the second edge of the body.
E06B 9/17 - Éléments ou parties constitutives des volets à rouleau, p. ex. dispositifs de suspension, carters de volets, portes à guichet, orifices de ventilation
In example implementations, a roll-up door is provided. The roll-up door includes a shaft, a flexible curtain, a plurality of buttons along a first edge and a second edge of the flexible curtain, a first guide assembly to enclose the plurality of buttons along the first edge of the flexible curtain, and a second guide assembly to enclose the plurality of buttons along the second edge of the flexible curtain. A first end of the flexible curtain is coupled to the shaft. The plurality of buttons are to guide movement of the flexible curtain caused by rotation of the shaft.
In example implementations, a universal endlock is provided. The universal endlock includes a body, a first side along a first edge of the body, a second side along a second edge of the body opposite the first edge, a first lip on a first end of the first side, and a second lip on a first end of the second side. The body includes an intersecting hole pattern on a center portion of the body. The first side and the second side are each bent towards a back side of the body. The first lip is bent away from a first edge of the body and the second lip is bent away from the second edge of the body.
In example implementations, a windlock is provided. The windlock includes a body, a windlock lip, and a gusset. The body includes holes to receive a fastener to be coupled to a slat of a roll-up door. The windlock lip is formed from a portion of the body that is bent from the body. The gusset is coupled to the body and the windlock to provide mechanical strength to the windlock lip.
(1) Enamel finishes for metal doors and shutters; Coatings in the nature of finishes for metal doors and shutters; Powder-based coatings for use as top coats on metal doors and shutters.
(1) Powder coat finishes for metal doors and shutters; Coatings in the nature of finishes for metal doors and shutters; Coatings in the nature of a structured powder top coat
In example implementations, a method is provided. The method includes determining, by a processor, that a vehicle is approaching a door of a building based on a velocity vector of the vehicle, calculating, by the processor, a time of arrival of the vehicle at the door based on the velocity vector of the vehicle and a distance of the vehicle from the door, and controlling, by the processor, the door to begin opening at a time based on the time of arrival and an amount of time for the door to open such that the door is opened when the vehicle arrives at the door.
E05F 15/70 - Mécanismes pour battants mus par une force motrice avec déclenchement automatique
E05F 15/76 - Mécanismes pour battants mus par une force motrice avec déclenchement automatique sensible au déplacement ou à la présence de personnes ou d’objets sensible à des dispositifs portés par des personnes ou des objets, p. ex. aimants ou miroirs
In example implementations, a method is provided. The method includes determining, by a processor, that a vehicle is approaching a door of a building based on a velocity vector of the vehicle, calculating, by the processor, a time of arrival of the vehicle at the door based on the velocity vector of the vehicle and a distance of the vehicle from the door, and controlling, by the processor, the door to begin opening at a time based on the time of arrival and an amount of time for the door to open such that the door is opened when the vehicle arrives at the door.
G07C 9/10 - Barrières mobiles avec moyens d’enregistrement
E05F 15/73 - Mécanismes pour battants mus par une force motrice avec déclenchement automatique sensible au déplacement ou à la présence de personnes ou d’objets
E06B 9/68 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique
G07C 9/00 - Enregistrement de l’entrée ou de la sortie d'une entité isolée
G07C 9/20 - Enregistrement de l’entrée ou de la sortie d'une entité isolée comportant l’utilisation d’un laissez-passer
E01F 13/04 - Dispositions pour interdire ou limiter la circulation, p. ex. portes, barrières pouvant être déplacées pour permettre ou empêcher le passage
