This application discloses a side brush and a smart cleaning device. The side brush includes a side brush base for mounting to a smart cleaning device and a scraper connected to a peripheral side of the side brush base. The scraper is configured to be in contact with the floor, so as to scrape sundries. A structure of the side brush can effectively prevent the side brush from being entangled with sundries during cleaning.
A47L 11/40 - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p. ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
A46B 1/00 - Montures et soies moulées d'une seule pièce
A46B 5/00 - Montures de brossesManches faisant corps avec la brosse
A46B 5/06 - Montures de brossesManches faisant corps avec la brosse en forme de rubans, de chaînes, de tiges flexibles, de ressorts
A rolling brush axial limiting apparatus, a cleaning brush, and an automatic cleaning device. The rolling brush axial limiting apparatus comprises: a first assembly component (5200) configured to output a driving force after being connected to a driving apparatus, wherein the first assembly component (5200) is provided with a first limiting piece (5210), and the first limiting piece (5210) is rotatably arranged on the first assembly component (5200); and a second assembly component (5300), configured to at least partially accommodate the first assembling component (5200) and then limit the axial movement of a rolling brush (5100), wherein the second assembly component (5300) is provided with a second limiting piece (5310), and the second limiting piece (5310) is rotatably arranged on the second assembly component (5300); and when the first assembly component (5200) is at least partially assembled on the second assembly component (5300), the first limiting piece (5210) and the second limiting piece (5310) match to achieve locking.
The present application discloses a stretch/retraction and lifting/lowering mechanism, and a cleaning device. By means of interaction between a stretchable/retractable member and a fixing member and limitation between the stretchable/retractable member and a lifting/lowering member, stretch/retraction and lifting/lowering of cleaning units can be implemented simply by driving the stretchable/retractable member to move, thereby achieving a simple structure and facilitating control. The main technical solution of the present invention is that: in a stretch/retraction and lifting/lowering mechanism, a fixing member is configured to be connected to a cleaning device; a lifting/lowering member is movably connected to the fixing member in a first direction; a stretchable/retractable member is movably connected to the fixing member, and the stretchable/retractable member and the lifting/lowering member limit each other in the first direction; and a driving member is connected to the fixing member and is connected to the stretchable/retractable member. The present invention is mainly used for stretch/retraction and lifting/lowering of cleaning units.
A47L 11/40 - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p. ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
The present application discloses an overload protection apparatus and a cleaning device. By moving at least one of a first acting member and a second acting member, when at an acting position, transmission is achieved, and when at a clearance position, the transmission is disengaged, thereby achieving overload protection. The main technical solution of the present application is as follows: in the overload protection apparatus, a first transmission member comprises a first main body and a first acting member, and the second transmission member comprises a second main body and a second acting member; at least one of the first acting member and the second acting member has an acting position and a clearance position, and the first acting member is used for interacting with the second acting member, so that at least one of the first acting member and the second acting member is switched between the acting position and the clearance position. The present application is mainly used for overload protection.
A47L 11/40 - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p. ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
F16D 43/20 - Embrayages automatiques à commande interne actionnés entièrement mécaniquement commandés par le couple, p. ex. embrayages à déclenchement en cas de surcharge, embrayages à glissement avec dispositifs par lesquels le couple fait varier la pression d'embrayage
Embodiments of the present application relate to the technical field of cleaning devices. Disclosed are a heat dissipation structure and a cleaning device. The heat dissipation structure comprises a housing, a heat conduction element, and a heat dissipation element. During use, a device to be cooled is arranged on an assembly position of the housing, heat generated by the device to be cooled can be transferred by means of the heat conduction element, and the heat can be transferred to an expected position by means of the heat conduction element, e.g., to the surface of the housing facing away from the assembly position, that is, the heat can be transferred outside the housing, and finally is dissipated by means of the heat dissipation element. Heat can be discharged to the expected position, and does not need to be accumulated in the housing, which can greatly improve the heat dissipation efficiency and ensure the working safety and stability of the device to be cooled.
A47L 11/40 - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p. ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
8.
Self-cleaning part of docking station for cleaning appliance
Embodiments of the present application relate to the field of cleaning devices, and discloses a fluid treatment apparatus and a base station. The fluid treatment apparatus comprises a first housing, a driving portion, a driving rotor, and a driven rotor; the driving rotor is located on one side of the first housing, the driven rotor is located on the other side of the first housing, the driving rotor is in non-contact connection to the driven rotor, and the driven rotor is partially located in the accommodating portion; the driving rotor comprises a first magnetic assembly, the driven rotor comprises a second magnetic assembly or a magnetic attraction assembly, and the driving rotor is used for generating a circumferential driving force on the driven rotor, so that the driven rotor rotates, thereby improving the dissolving effect of a solvent, or sewage in the accommodating portion is stirred, so as to remove dirt attached to the inner wall of the accommodating portion, thereby improving the cleanliness of the accommodating portion; the water flow impact force and the mechanical force generated by stirring are used to crush the dirt, thus preventing the dirt from blocking an inlet and an outlet of a sewage tank, a suction pipeline and a channel leading to a sewer.
A47L 11/40 - Éléments ou parties constitutives des machines non prévus dans les groupes , ou non limités à un de ces groupes, p. ex. poignées, dispositions des interrupteurs, bords, amortisseurs ou leviers
A47L 11/28 - Machines à frotter le plancher, actionnées par moteur
A47L 11/24 - Machines à balayer le plancher, actionnées par moteur
A47L 11/00 - Machines à nettoyer les planchers, les tapis, les meubles, les murs ou leurs revêtements
12.
