Abrégé

An expandable shaft for wrapping a film comprising a substantially cylindrical central body (3), a plurality of first shaped leaves (5) and a plurality of second shaped leaves (6). Such leaves being alternated with each other and associated with the central body (3) by a plurality of pushers (8) which realise the radial movement thereof with respect to the central body (3). The latter comprising an actuator (22) to cause the pushers (8) to move and alternately arrange the leaves (5, 6) according to an operative configuration, in which the cross section (23) of the shaft (1) is continuously circular, and according to a resting configuration in which in the cross section (23) there are indentations (24) at the second leaves (6), and the diameter of the cross section (23) in the operative configuration is greater than the diameter of the cross section (23) in the resting configuration.

Classes IPC  ?

• B65H 75/24 - Détails de structure de forme réglable, p. ex. expansibles

Abrégé

Method of execution of a rotating shaft (1) for the transmission of rotary motion from a motor characterised in that it comprises at least the following steps: realising a tubular body (3) in composite material, moulding a plurality of longitudinal sectors (5) in composite material and stably coupling the plurality of longitudinal sectors (5) to the tubular body (3).

Classes IPC  ?

• F16C 3/02 - ArbresManivelles

Produits et services

Working platforms [structures] of metal for skis or snowboards; Support stands [structures] of metal for skis. Reeling apparatus, mechanical; Spool unwinders [machines]; Bobbin winding machines; Shafts for reeling and unreeling material in reels; Rollers and cylinders for reeling and unreeling material in reels; Heads for reeling and unreeling material in reels; Mechanical or pneumatic rotary supports for reeling and unreeling material in reels; Handling machines; Materials handling conveyors; Materials handling elevators; Moving and handling equipment; Lifting machines for handling loads; Elevators [lifts] and platforms to move, park and store land vehicles; Vehicle parking carousels; Lifting ramps; Machines for lifting vehicles; Vehicle lifts; Lifting platforms; Lifting platforms; Stairlifts; Lifts for use with vehicles; Hoists; Doublers; Car lift; Brushing machines; Electric sharpeners; Processing machines for inner soles and edges for skis and snowboards; Waxing machines; Stone grinding machines. Dynamometers. Mechanical handling trucks; Automatically guided [driverless] material handling trucks; Forklift trucks; Electrically powered trolleys; Forklift trucks. Machines for physical exercises.

Abrégé

The invention is a support (1) for the end pin (A1) of a shaft (A), comprising: a tube (2) suited to be associated with a supporting structure (S); a primary shaft (3) coaxially coupled inside the tube (2) and suited to be associated with power means suited to set it rotating; a prismatic seat (5) created in the end (4) of the primary shaft (3) and configured in such a way as to accommodate the end pin (A1) of the shaft (A); a sliding flange (6) associated with a shaped cap (7); moving means (8) suited to move the flange (6) between a first position (B) spaced from the tube (2) with the shaped cap (7) superimposed to the prismatic seat (5) and a second position (C) against the tube (2). Locking means (10) are provided to constrain the flange (6) to the projecting end (4) of the primary shaft (3) in the first position (B), as well as two manoeuvring rods (20, 21), each one of which cooperates with the locking means (10) when it is activated by an operator.

Classes IPC  ?

• B65H 16/06 - Support de la bobine du type à deux extrémités
• B65H 18/02 - Support de la bobine
• F16D 1/108 - Accouplements à action rapide dans lesquels les pièces sont simplement présentées dans l'axe dont les moyens de retenue tournent avec l'accouplement et agissent par parties s'engageant l'une dans l'autre, c.-à-d. accouplement positif
• F16D 11/14 - Embrayages dans lesquels les organes ont des parties qui se pénètrent mutuellement avec des organes d'embrayage mobiles selon l'axe uniquement

Abrégé

The invention is a machine (3) suited to process the sliding surface (2) of a ski (1), comprising: a grinding wheel (4) that defines a longitudinal axis (X); first power means suited to set the grinding wheel (4) rotating around the longitudinal axis (X); a guide unit (7) suited to move the ski (1) according to an advance direction (Y) maintaining the sliding surface (2) in contact with the grinding wheel (4); a tool (8) suited to be positioned in contact with the grinding wheel (4) so as to impress a groove on the cylindrical surface (5) of the grinding wheel (4) that is set rotating; second power means suited to move the tool (8) according to a direction of movement (Z) parallel to the longitudinal axis (X); a logic control unit configured so as to operate the first and the second power means in such a way as to move the tool (8) according to the direction of movement (Z) depending on the rotation angle of the grinding wheel (4). The second power means are configured so as to vary the processing depth of the tool (8) and the logic control unit is configured so as to operate the second power means in such a way as to vary the processing depth according to the rotation angle of the grinding wheel (4).

Classes IPC  ?

• A63C 11/04 - Accessoires pour pratiquer le ski ou le surf des neiges pour l'entretien des skis ou des surfs des neiges
• A63C 5/04 - Structure de leur surface

Produits et services

Apparatus for lighting, heating, steam generating, cooking, refrigerating, drying, ventilating, water supply and sanitary purposes.

Produits et services

Apparatus for lighting, heating, steam generating, cooking, refrigerating, drying, ventilating, water supply and sanitary purposes.

Produits et services

Apparatus for lighting, heating, steam generating, cooking, refrigerating, drying, ventilating, water supply and sanitary purposes.

Produits et services

Apparatus for lighting, heating, steam generating, cooking, refrigerating, drying, ventilating, water supply and sanitary purposes.

Produits et services

Heating, steam generating, cooking, refrigerating, drying, air conditioning and water supply appliances and sanitary installations.
