Abrégé

The present invention relates to the field of automated plant factories, and disclosed therein are an automated plant factory assembly line and an automated planting method thereof. The assembly line comprises: a cultivation operation area, a picking operation assembly line, a cleaning operation assembly line, a buffer storage operation area, a seeding operation assembly line, a germination operation area, a seedling conveying line, and a planting operation assembly line; the buffer storage operation area has disposed therein a front-end moving unit, a plurality of rows of module storage racks, a rear-end moving unit, and a four-way shuttle vehicle; the front-end moving unit and the rear-end moving unit are respectively located on two sides of the plurality of rows of module storage racks; an input end and an output end of the cleaning operation assembly line each correspond to one end position of the front-end moving unit and the rear-end moving unit; the front-end moving unit is used for transferring cleaned planting trays to the module storage racks for stacking; and the four-way shuttle vehicle is used for moving the stacked planting trays in an X direction. The present invention effectively improves the logistics transfer efficiency of the plant factory.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet
• A01G 31/00 - Culture hors-sol, p. ex. hydroponie

Abrégé

The present invention relates to the technical field of indoor cultivation of cucumbers, and in particular to a transverse cultivation device and transverse cultivation method for cucumbers. A traction frame is arranged between every two adjacent vertical planting layers; illumination is given to the bottom of the upper layer; the traction frame comprises two steel rope supports which are oppositely and transversally arranged between support columns at a certain height in an X-axis direction, and a plurality of movable cross rods movably arranged between the two steel rope supports in a Y-axis direction; and the steel rope supports, the movable cross rods and extension areas thereof form an X-Y plane where the traction frame is located. According to the present invention, a transverse growth and cultivation method for cucumbers is innovatively developed for the first time by means of transverse traction and non-crossing tiled growth of plants. The innovative technology of transverse cultivation ensures sufficient and uniform illumination for different nodes of plants, and effectively improves the yield and quality. The method of the present invention can greatly reduce the height of a single layer during indoor planting of cucumbers, can achieve more layers of cultivation in a height-limited space to a great extent, can fully utilize limited cultivation spaces, and can greatly increase the yield per unit area.

Classes IPC  ?

• A01G 22/05 - Légumes-fruits, p. ex. fraises, tomates ou concombres
• A01G 7/06 - Traitement des arbres ou des plantes en cours de croissance, p. ex. pour prévenir la décomposition du bois, pour teinter les fleurs ou le bois, pour prolonger la vie des plantes
• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

The present invention discloses a planting method for cereal crops in a plant factory to promote four to five crops per year. During the planting period, the cereal crops are cultivated under the irradiation of blue-yellow-red-far red mixed light. In the blue-yellow-red-far red mixed light, the photon ratio of red light (600-699 nm) and blue light (400-499 nm) is 3-4, the photon ratio of red light (600-699 nm) and yellow light (500-599 nm) is 3-7, and the photon ratio of red light (600-699 nm) and far-red (FR) light (700-780 nm) is 3-4. The present invention ensures the normal growth of cereal crops under the control of artificial light planting environment, realizes four to five crops per year of cereal crops, greatly shortens the crop planting cycle, and improves the utilization rate of land and water resources.

Classes IPC  ?

• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 22/20 - Céréales

Abrégé

The present invention provides a method for promoting plant growth, a plant lamp and application thereof. The method at least includes providing an artificial light source for a growing plant. The light source includes a red light with a peak wavelength of 680-695 nm and a light wave half-width lower than 35 nm; or the light source includes a blue light with a peak wavelength of 410-440 nm and a light wave half-width lower than 35 nm. The plant lamp provides the light source for promoting plant growth. By using the light source in the present invention to irradiate the plant, plant growth is significantly promoted.

Classes IPC  ?

• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance

Abrégé

The present invention provides a transplanting equal-dividing mechanism which includes a driving mechanism, a module fixing plate, a robot connecting rod, a linkage and a clamping jaw device, wherein the driving mechanism is disposed above the module fixing plate, a bottom of the module fixing plate is provided with a guide rail, the guide rail is provided with a plurality of sliders thereon, the clamping jaw device is connected below each slider, each clamping jaw device is provided with two linkages on its back surface, and the linkage is rotationally connected to a back of the clamping jaw device. The clamping jaw device is driven by the drive mechanism to achieve automatic separation and aggregation, and the clamping and placing works of plants in the transplanting process are realized by utilizing the clamping and retracting functions of the clamping jaw devices. The application of a plurality of clamping jaws can simultaneously place the plants in the planting tray, so that the transplanting equal-dividing work of the plants can be carries out more quickly, which effectively improves the working efficiency and saves time.

Classes IPC  ?

• A01G 9/08 - Dispositifs de remplissage des pots à fleursDispositifs de mise en pots des plantes
• A01G 31/02 - Appareils particuliers à cet effet

Abrégé

A dual-peak blue light for promoting plant growth, the peaks of which fall within the wave bands of 431-441 nm and 445-455 nm, and the ratio of the number of photons in the wave band of 445-455 nm to the number of photons in the wave band of 431-441 nm is 1.18-1.54.

Classes IPC  ?

• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 31/00 - Culture hors-sol, p. ex. hydroponie

Abrégé

The present invention relates to the technical field of soilless culture, and in particular to a device suitable for automatically harvesting soilless culture sprouts. The device includes a bottom supporting frame, a conveying mechanism and a cutting mechanism, where the conveying mechanism is arranged on the bottom supporting frame, the cutting mechanism is arranged on the conveying mechanism, the conveying mechanism moves horizontally, an included angle α is formed between the conveying mechanism and a horizontal plane, and the included angle α is larger than or equal to 30° and less than or equal to 90°. According to the present invention, a lifting mechanism lifts a longer side edge of one end of the conveying mechanism up, such that an included angle is formed between the conveying mechanism and the bottom supporting frame, and the sprouts cut by the cutting mechanism incline to fall down into a sprout collecting box. Thus, the sprouts are effectively prevented from directly falling onto a culture plate, thereby reducing later treatment procedures and increasing production efficiency.

Classes IPC  ?

• A01D 45/00 - Récolte d’espèces sur pied
• B65G 41/00 - Châssis ou bases de support pour transporteurs dans leur ensemble, p. ex. châssis transportables

Abrégé

Disclosed is a method for full-artificial light cultivation of an herbaceous spice plant; in the present invention, by means of controlling light environment parameters, that is, controlling the sum of the proportions of light quanta, at 380–780 nm, of red light (600–699 nm) and green light (500–599 nm) is 71–76%, and the range of the light quantum ratio of red light (600–699 nm) to green light (500–599 nm) to be 2.1–3.7, it is possible to achieve year-round production of safe and healthy, green, pollution-free herbaceous spice plants at a high yield. The invention is easy to operate, and easy to promote widely.

Classes IPC  ?

• A01G 31/00 - Culture hors-sol, p. ex. hydroponie
• A01G 7/00 - Botanique en général

Abrégé

The present invention relates to the technical field of hydroponic culture, in particular to an auxiliary root placement device for hydroponic transplanting. The auxiliary root placement device includes an underframe, a repeated horizontal moving mechanism, a jacking mechanism and a vacuum adsorption mechanism, wherein the repeated horizontal moving mechanism is disposed on the underframe, the jacking mechanism is slidingly connected with the underframe, an output end of the repeated horizontal moving mechanism is fixedly connected with the jacking mechanism, an output end of the jacking mechanism is fixedly connected with the vacuum adsorption mechanism. In the present invention, the jacking mechanism is pushed by the repeated horizontal moving mechanism to drive the vacuum adsorption mechanism to move directly below the cultivation hole on the cultivation plate, and then the vacuum adsorption mechanism is driven to rise upwards by the jacking mechanism, so that the output end of the vacuum adsorption mechanism touches the root hairs of the hydroponic plant through the cultivation hole to adsorb the root hairs tightly to the vacuum suction rod, and then retracts through the jacking mechanism, so that the root hairs smoothly pass through the cultivation hole without being stuck on the cultivation plate, resulting in rotting of the root hairs, and thus ensuring the stable growth of the hydroponic plants.

Classes IPC  ?

• A01C 11/00 - Machines transplanteuses [repiqueuses]
• A01G 31/02 - Appareils particuliers à cet effet

Abrégé

The present invention relates to the technical field of plant cultivation apparatuses, and disclosed is a modular cultivation shelf. The modular cultivation shelf comprises a plurality of cultivation racks that are connected side by side, wherein each of the cultivation racks comprises a plurality of layers of hydroponic shelves; cultivation tanks are slidably arranged on the hydroponic shelves; each layer of the hydroponic shelves comprises a water inlet channel and a water outlet channel; a water inlet is arranged on a side surface of the water inlet channel; water inlet grooves and water outlet grooves are arranged in the cultivation tanks; the cultivation tanks have a water inlet state in which the water inlet grooves and water inlets are hydraulically connected, and a water outlet state in which the water outlet grooves and the water inlets are hydraulically connected; the cultivation tanks switch between the water inlet state and the water outlet state by sliding; a lighting fixture is embedded in the bottom surface of an upper layer hydroponic shelf of adjacent upper and lower layers of the hydroponic shelves; and each layer of the hydroponic shelves is provided with a water inlet shading member and a water outlet shading member. The switching of the state of the cultivation tanks can realize rapid drainage, and therefore, rapid drainage of the cultivation shelf is improved.

Classes IPC  ?

• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

The present disclosure relates to the technical field of plant cultivation devices, and provides a branched cultivation device, comprising a cultivation rack and multiple cultivation grooves. The cultivation rack comprises multiple hydroponic shelves arranged from top to bottom. The cultivation grooves are slidably arranged on the hydroponic shelves. Each hydroponic shelf is provided with a water outlet passage and a water inlet passage. A water inlet opening is provided on the water inlet passage. Water inlet grooves and water outlet grooves are provided in the cultivation grooves. The cultivation grooves have a water inflow state in which the water inlet grooves are connected to water inlet opening waterways and a water outflow state in which the water outlet grooves are connected to the water inlet opening waterways. The water inlet grooves and the water outlet grooves are arranged in a sliding direction of the cultivation grooves. The cultivation grooves switch between the water inflow state and the water outflow state by means of sliding. One end of a water outlet passage is in communication with the water outlet groove waterway of the corresponding cultivation groove, and the other end of the water outlet passage is in communication with the water inlet passage of a lower hydroponic shelf. Since the cultivation grooves switch between the water inflow state and the water outflow state by means of sliding, the drainage time in the water outflow state can be effectively reduced.

Classes IPC  ?

• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

Disclosed in the present invention is an indoor planting method for preventing soybean vines from climbing to accelerate soybean growth. In a whole planting period, grain crops are cultured under irradiation of blue, yellow, red and far-red mixed light. In the blue, yellow, red and far-red mixed light, the light quantum number of blue light (400-499 nm) accounts for 15-52% of a total light quantum number, the light quantum number of yellow light (500-599 nm) accounts for 3-12% of the total light quantum number, the light quantum number of red light (600-699 nm) accounts for 35-59% of the total light quantum number, and the light quantum number of far-red light (700-780 nm) accounts for 0-18% of the total light quantum number. According to the present invention, soybeans are planted indoors, the high maturing rate of the soybeans is achieved under regulation and control of a full-artificial light environment, and the soybeans are ripe every 100 days; moreover, vine climbing and lodging are avoided, and almost no pesticide is used in the whole planting period.

Classes IPC  ?

• A01G 22/40 - Fabaceae, p. ex. haricots ou petits-pois

Abrégé

Disclosed is a 1,1'-biphenyl-2,6-diphenolic compound and the use thereof. The 1,1'-biphenyl-2,6-diphenolic compound is a new compound, and has good biological activity. By means of in vitro tumor cell activity experiments, it was found that the compound has inhibitory activity on tumor cell proliferation, and has the potential of developing an anti-tumor medicament.

Classes IPC  ?

• C07C 69/94 - Esters d'acides carboxyliques dont un groupe carboxyle estérifié est lié à un atome de carbone d'un cycle aromatique à six chaînons d'acides hydroxycarboxyliques polycycliques dont les groupes hydroxyle et les groupes carboxyle sont liés à des atomes de carbone de cycles aromatiques à six chaînons
• C07C 39/15 - Composés comportant au moins un groupe hydroxyle ou O-métal lié à un atome de carbone d'un cycle aromatique à six chaînons polycycliques sans autre insaturation que celle des cycles aromatiques tous les groupes hydroxyle étant liés à des cycles non condensés
• C07C 215/74 - Composés contenant des groupes amino et hydroxy liés au même squelette carboné ayant des groupes hydroxy et des groupes amino liés à des atomes de carbone de cycles aromatiques à six chaînons du même squelette carboné
• C07C 205/20 - Composés contenant des groupes nitro liés à un squelette carboné le squelette carboné étant substitué de plus par des groupes hydroxy ayant des groupes nitro et des groupes hydroxy liés à des atomes de carbone de cycles aromatiques à six chaînons
• C07C 65/105 - Composés comportant des groupes carboxyle liés à des atomes de carbone de cycles aromatiques à six chaînons et contenant l'un des groupes OH, O-métal, —CHO, cétone, éther, des groupes , des groupes ou des groupes contenant des groupes hydroxyle ou O-métal polycycliques
• C07C 243/38 - Hydrazines ayant des atomes d'azote de groupes hydrazine acylés par des acides carboxyliques avec des groupes carboxyle acylants liés à des atomes de carbone de cycles aromatiques à six chaînons
• C07C 235/42 - Amides d'acides carboxyliques, le squelette carboné de la partie acide étant substitué de plus par des atomes d'oxygène ayant des atomes de carbone de groupes carboxamide liés à des atomes de carbone de cycles aromatiques à six chaînons et des atomes d'oxygène, liés par des liaisons simples, liés au même squelette carboné
• C07D 207/16 - Atomes de carbone comportant trois liaisons à des hétéro-atomes, avec au plus une liaison à un halogène, p. ex. radicaux ester ou nitrile
• C07D 233/64 - Composés hétérocycliques contenant des cycles diazole-1, 3 ou diazole-1, 3 hydrogéné, non condensés avec d'autres cycles comportant deux liaisons doubles entre chaînons cycliques ou entre chaînons cycliques et chaînons non cycliques avec des radicaux hydrocarbonés substitués, liés aux atomes de carbone du cycle, p. ex. histidine
• C07D 317/54 - Radicaux substitués par des atomes d'oxygène
• C07C 271/16 - Esters des acides carbamiques ayant des atomes d'oxygène de groupes carbamate liés à des atomes de carbone acycliques avec les atomes d'azote des groupes carbamate liés à des atomes d'hydrogène ou à des atomes de carbone acycliques à des atomes de carbone de radicaux hydrocarbonés substitués par des atomes d'oxygène liés par des liaisons simples
• C07C 233/29 - Amides d'acides carboxyliques ayant des atomes de carbone de groupes carboxamide liés à des atomes d'hydrogène ou à des atomes de carbone acycliques ayant l'atome d'azote d'au moins un des groupes carboxamide lié à un atome de carbone d'un radical hydrocarboné substitué par des atomes d'oxygène liés par des liaisons simples avec le radical hydrocarboné substitué lié à l'atome d'azote du groupe carboxamide par un atome de carbone d'un cycle aromatique à six chaînons ayant l'atome de carbone du groupe carboxamide lié à un atome de carbone acyclique d'un squelette carboné contenant des cycles aromatiques à six chaînons
• C07C 237/22 - Amides d'acides carboxyliques, le squelette carboné de la partie acide étant substitué de plus par des groupes amino ayant les atomes de carbone des groupes carboxamide liés à des atomes de carbone acycliques du squelette carboné ayant des atomes d'azote de groupes amino liés au squelette carboné de la partie acide, en outre acylés
• C07D 213/82 - AmidesImides en position 3
• C07C 219/34 - Composés contenant des groupes amino et hydroxy estérifiés liés au même squelette carboné ayant des groupes amino et des groupes hydroxy estérifiés liés à des atomes de carbone de cycles aromatiques à six chaînons du même squelette carboné
• C07C 233/60 - Amides d'acides carboxyliques ayant des atomes de carbone de groupes carboxamide liés à des atomes de carbone de cycles autres que des cycles aromatiques à six chaînons ayant l'atome d'azote d'au moins un des groupes carboxamide lié à un atome de carbone d'un radical hydrocarboné substitué par des atomes d'oxygène liés par des liaisons simples
• A61K 31/235 - Esters, p. ex. nitroglycérine, sélénocyanates d'acides carboxyliques ayant un noyau aromatique lié au groupe carboxyle
• A61K 31/05 - Phénols
• A61K 31/136 - Amines, p. ex. amantadine ayant des cycles aromatiques, p. ex. méthadone ayant le groupe amino lié directement au cycle aromatique, p. ex. benzène-amine
• A61K 31/06 - Phénols le noyau aromatique étant substitué par des groupes nitro
• A61K 31/192 - Acides carboxyliques, p. ex. acide valproïque ayant des groupes aromatiques, p. ex. sulindac, acides 2-aryl-propioniques, acide éthacrynique
• A61K 31/175 - Amides, p. ex. acides hydroxamiques ayant le groupe N-C(O)-N ou N-C(S)-N, p. ex. urée, thiourée, carmustine ayant le groupe , N-C(O)-N=N- ou , p. ex. carbonohydrazides, carbazones, semicarbazides, semicarbazonesLeurs thio-analogues
• A61K 31/166 - Amides, p. ex. acides hydroxamiques ayant des cycles aromatiques, p. ex. colchicine, aténolol, progabide ayant l'atome de carbone d'un groupe carboxamide lié directement au cycle aromatique, p. ex. procaïnamide, procarbazine, métoclopramide, labétalol
• A61K 31/401 - ProlineSes dérivés, p. ex. captopril
• A61K 31/216 - Esters, p. ex. nitroglycérine, sélénocyanates d'acides carboxyliques d'acides ayant des cycles aromatiques, p. ex. bénactizyne, clofibrate
• A61K 31/4172 - Acides imidazole-alkanecarboxyliques, p. ex. histidine
• A61K 31/36 - Composés contenant des groupes méthylènedioxyphényle, p. ex. sésamine
• A61K 31/27 - Esters, p. ex. nitroglycérine, sélénocyanates d'acides carbamiques ou thiocarbamiques, p. ex. méprobamate, carbachol, néostigmine
• A61K 31/167 - Amides, p. ex. acides hydroxamiques ayant des cycles aromatiques, p. ex. colchicine, aténolol, progabide ayant l'atome d'azote d'un groupe carboxamide lié directement au cycle aromatique, p. ex. lidocaïne, paracétamol
• A61K 31/455 - Acide nicotinique, c.-à-d. niacineSes dérivés, p. ex. esters, amides
• A61K 31/16 - Amides, p. ex. acides hydroxamiques
• A61K 31/137 - Arylalkylamines, p. ex. amphétamine, épinéphrine, salbutamol, éphédrine
• A61P 35/00 - Agents anticancéreux

Abrégé

Disclosed is a plant factory cultivation method for promoting 4-5 cereal crop yields per year. During cultivation, cereal crops are cultured under irradiation by a blue-yellow-red-far red light mixture; in the blue-yellow-red-far red light mixture, the ratio of red ight (600-699 nm) photons to blue light (400- 499nm) photons ranges from 3 to 4, the ratio of red light (600-699 nm) photons to yellow light (500 to 599nm) photons ranges from 3 to 7, and the ratio of red light (600-699 nm) photons to far red (FR) light (700-780 nm) photons ranges from 3-4. According to the present invention, the normal growth of cereal crops is guaranteed under the regulation and control of an artificial light cultivation environment, 4-5 cereal crop yields per year occur, which significantly shortens the crop cultivation cycle and improves the utilization rate of land and water resources.

Classes IPC  ?

• A01G 31/00 - Culture hors-sol, p. ex. hydroponie
• A01G 7/00 - Botanique en général

Abrégé

A method for promoting the rooting of industrial hemp, comprising utilizing blue light having a wavelength of 410 nm-460 nm as an irradiation light source during indoor cutting propagation. By using the method, rooting can be promoted, seedlings can emerge early, and the production period is shortened; the growth potential of root systems is stronger, facilitating the cultivation of strong seedlings at the later stage; and in the method, blue light having a single wavelength is used to carry out irradiation, such that the method is easy to operate and the production cost can be reduced.

Classes IPC  ?

• A01G 2/10 - Bouturage
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 31/00 - Culture hors-sol, p. ex. hydroponie

Abrégé

The present invention relates to the technical field of lighting for plant, and in particular, provides a multi-reflection panel lamp. The multi-reflection panel lamp includes a fixing frame, a plurality of panel lamps, and a plurality of reflectors. The plurality of panel lamps are embedded in the fixing frame parallel to each other. The reflectors and the panel lamps are parallelly disposed on the fixing frame. Compared to other panel lamps, in the present invention, reflectors are disposed between panel lamps to reflect, a plurality of times by using a multi-refraction mechanism of the reflectors of the panel lamps, rays of light emitted by the panel lamps, so that plants are irradiated with the rays of light at various angles, thereby improving lighting intensity and uniformity and ensuring normal growth of the plants.

Classes IPC  ?

• F21V 7/00 - Réflecteurs pour sources lumineuses
• A01G 9/24 - Dispositifs de chauffage, d'aération, de régulation de la température ou d'irrigation dans les serres, les châssis ou les installations similaires
• F21V 21/02 - Socles sur les murs, les plafonds ou les planchersFixation des lustres ou des appliques aux socles
• F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage
• F21Y 115/10 - Diodes électroluminescentes [LED]

Abrégé

A method for accelerating vegetative growth to reproductive growth of leafy vegetables, mainly comprising: adjusting proportions of photons in a far-red light (700-780 nm) and a blue light (400-499 nm) of spectra and controlling same at 1.7-3.3. The method can facilitate early blooming of leafy vegetables and shorten the first-generation breeding time, thus accelerating a breeding cycle.

Classes IPC  ?

• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 31/00 - Culture hors-sol, p. ex. hydroponie

Abrégé

A liquid level-adjustable soilless cultivation apparatus, comprising a cultivation bed body (11), a liquid supply apparatus (7), and a liquid discharge apparatus (8). A liquid outlet (2) is provided on the cultivation bed body (11); the liquid supply apparatus (7) and the liquid discharge apparatus (8) are provided in the cultivation bed body (11); the liquid discharge apparatus (8) is provided with a liquid level adjusting hole or silt; the liquid supply apparatus (7) is communicated with the cultivation bed body (11); the liquid level adjusting hole or silt of the liquid discharge apparatus (8) is communicated with the cultivation bed body (11). According to the apparatus, the flowing uniformity of the liquid in the cultivation bed is improved by means of the synergistic effect of the liquid supply apparatus and the liquid discharge apparatus, thereby facilitating removal of the sediment of waste residues, and avoiding blockage of the liquid discharge port.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet
• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

A method for promoting the growth of root tubers of rhizome-type medicinal materials in plant factories. The method comprises: using a specific light source for irradiation during an indoor cultivation process, wherein the spectral composition of the specific light source comprises: the ratio of the number of light quanta of blue light (400-499 nm) to the total number of light quanta is 15-35%, the ratio of the number of light quanta of green light (500-599 nm) to the total number of light quanta is 15-27%, the ratio of the number of light quanta of red light (600-699 nm) to the total number of light quanta is 35-55%, and the ratio of the number of light quanta of far-red light (700-780 nm) to the total number of light quanta is 0-15%. By means of the method, rhizome-type medicinal materials with a short planting cycle, fast root tuber expansion, and of a high quality can be obtained. Further disclosed is an indoor cultivation method for rhizome-type medicinal materials.

Classes IPC  ?

• A01G 31/00 - Culture hors-sol, p. ex. hydroponie
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance

Abrégé

Disclosed is a Method for extending flowering periods of non-bulbous herbaceous flowers in a plant factory. In a cultivation process, a specific light source is used to provide illumination. The specific light source has a spectral composition of: a wavelength of 380-499 nm provided by quantum dots that account for 10%-20% of total quantum dots, a wavelength of 500-599 nm provided by quantum dots that account for 25%-35% of total quantum dots, and a wavelength of 600-780 nm provided by quantum dots that account for 50%-60% of total quantum dots. The present invention employs light environment control technology to extend flowering periods of flowers in a plant factory. The method is simple and feasible, and can effectively increase the quantity of harvested flowers and economic benefits.

Classes IPC  ?

• A01G 22/60 - FleursPlantes d’ornement
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance

Abrégé

A multi-layer three-dimensional cultivation apparatus, comprising a seedling base frame (1) and a cultivation nursery cart (2); the seedling base frame (1) comprises two oppositely arranged support frames (11) and light brackets (13). Multiple pairs of suspension arms (11111) are symmetrically provided on two sides of the support frames (11) along the height direction of the support frames (11). The suspension arms (11111) on the two support frames (11) are matched to form a mounting bracket (1111). The light brackets (13) are detachably connected to the mounting bracket (1111). The cultivation nursery cart (2) comprises a cultivation shelf (21) and a movement apparatus (22). The movement apparatus (22) is arranged on the bottom of the cultivation shelf (21). The cultivation shelf (21) comprises a multi-layer planting trough (211); the location of the planting trough (211) matches that of the light brackets (13). A horizontal regulating mechanism (113) is arranged on the bottom of the seedling base frame (1). The horizontal regulating mechanism (113) is used for adjusting the horizontal balance of the cultivation nursery cart (2). The suspension arms (11111) allow for more convenient installation of the cultivation shelf (21). The horizontal regulating mechanism (113) of the seedling base frame (1) guarantees that after the cultivation nursery cart (2) is arranged on the seedling base frame (1), the planting trough (211) of the cultivation nursery cart (2) is in a horizontal state.

Classes IPC  ?

• A01G 9/029 - Récipients pour plants

Abrégé

A device for plant cultivation on a ship and an anti-vibration device for a plant cultivation tank. The anti-vibration device comprises a field planting plate (10), a liquid cushioning means (20), and a water receiving tank (30); the liquid cushioning means (20) is arranged in the water receiving tank (30); the field planting plate (10) is arranged on the liquid cushioning means (20); the field planting plate (10) is provided with a plurality of field planting holes (11); a water inlet (31) and a water discharge port (32) are formed on the water receiving tank (30); the water inlet (31) is communicated with the liquid cushioning means (20); the liquid cushioning means (20) is provided with a plurality of water outlets; the water outlets are communicated with the water receiving tank (30); a plurality of vertically arranged cushioning plates (21) are provided in the liquid cushioning means (20); the cushioning plates (21) can be used for attachment and protection of plant roots, thereby solving the problem concerning normal growth and development of plants under continuous vibration conditions.

Classes IPC  ?

• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

A radiator and a plant illumination lamp containing the radiator. The radiator includes a heat-radiating baseplate configured for fixing a heat source, and heat-radiating side plates connected to the heat-radiating baseplate. The heat-radiating side plates each are provided with a plurality of heat-exchanging through grooves running through the heat-radiating side plates. The heat-exchanging through groove forms a heat potential difference, so that under the influence of the heat potential difference, the cold air outside the radiator passes through the heat-exchanging through groove on the heat-radiating side plates, and then flows out through a hot air chamber and an air outlet at an upper end of the hot air chamber after exchanging heat with the heat-exchanging through groove on the heat-radiating side plates, so as to form a strong natural air convection.

Classes IPC  ?

• A01G 9/24 - Dispositifs de chauffage, d'aération, de régulation de la température ou d'irrigation dans les serres, les châssis ou les installations similaires
• F21V 29/71 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques utilisant une combinaison d’éléments séparés interconnectés par des moyens thermo-conducteurs, p. ex. tubes caloporteurs ou barres thermiquement conductrices pour conduire la chaleur entre des éléments séparés de puits thermique
• F21V 29/76 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques avec ailettes ou lames avec ailettes ou lames en plans parallèles essentiellement identiques, p. ex. avec une section en forme de peigne
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance

Abrégé

A centralized power supply-based load drive method and system. The load drive system comprises a power adapter (10), a load unit (11), and a PWM unit. The power adapter (10) comprises an AC input interface, a conversion control board, and a DC output interface. The load unit (11) is connected to the DC output interface of the power adapter (10) via a power connection cable. The PWM unit comprises a first PWM module (12) and a second PWM module (13). The first PWM module (12) is connected in parallel to an end of the power connection cable connected to the power adapter (10). The second PWM module (13) is connected in parallel to the other end of the power connection cable connected to the load unit (11). The first PWM module (12) is connected to the power adapter (10). The second PWM module (13) is connected to the first PWM module (12). The invention enables, by means of interaction between the first PWM module (12) and the second PWM module (13), accurate calculation of a power required for operations of the load unit (11) currently connected to a power grid, such that the power adapter (10) is controlled to output a total current having a corresponding magnitude, thereby achieving flexible control of the overall power of the power grid.

Classes IPC  ?

• H02M 7/02 - Transformation d'une puissance d'entrée en courant alternatif en une puissance de sortie en courant continu sans possibilité de réversibilité
• H05B 45/37 - Circuits de conversion
• H05B 45/3725 - Alimentation du circuit à découpage [SMPS]
• H05B 45/325 - Modulation de la largeur des impulsions [PWM]

Abrégé

A lamp capable of networking, and a lamp networking system. The lamp (1) comprises a power adapter (2), a load unit and a connection circuit, wherein the connection circuit comprises an AC input end (11) and at least two AC output ends (12); the power adapter (2) comprises a conversion control board (25), at least one AC input interface (21), at least one DC output interface (22) and at least two AC output interfaces (23, 24); the conversion control board (25) is used for converting an AC voltage into a DC voltage; the AC input end (11) is connected to the AC input interface (21); the DC output interface (22) is connected to the load unit; and the two AC output interfaces (23, 24) are respectively connected to the two AC output ends (12), which are connected in parallel to each other. Therefore, fast and simple combination of lamps can be achieved, and the arrangement and use of wire materials are reduced, thereby improving the light utilization efficiency; in addition, the cost input and light blocking are also reduced, thereby improving economic benefits and reducing potential safety risks caused by a complex circuit.

Classes IPC  ?

• H02M 1/00 - Détails d'appareils pour transformation
• F21V 23/02 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage les éléments étant des transformateurs ou des impédances
• F21V 23/04 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage les éléments étant des interrupteurs
• F21Y 115/10 - Diodes électroluminescentes [LED]

Abrégé

A plant planting container and a cultivation module suitable for a ship. The plant planting container comprises a planting plate (20) and a cultivation container (10), wherein the cultivation container (10) is provided with a water intake pipeline opening (17) and a water output pipeline opening (16), and the cultivation container (10) comprises a bottom plate (11) and a side plate (12) arranged around the bottom plate (11) in a surrounding manner, with the top of the side plate (12) being bent and extended towards the inner side so as to form a support table (30), a water storage space (35) being formed between the support table (30) and the side plate (12), a water flow channel (36) being formed between the support table (30) and the bottom plate (11), the water storage space (35) being in communication with the cultivation container (10) by means of the water flow channel (36), and the planting plate (20) being arranged on the support table (30).

Classes IPC  ?

• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés
• A01G 31/02 - Appareils particuliers à cet effet

Abrégé

A method for promoting the accumulation of cannabinoid substances is disclosed. The method comprises the step of adding an irradiation of green light, which has a peak wavelength at 505-526 nm, into the indoor growing environment of cannabis to improve the levels of tetrahydrocannabinol (THC) and cannabidiol (CBD), cannabinoid substances in cannabis. While maintaining the light intensity and other growth conditions, the yields and/or levels of THC and CBD, cannabinoid substances in cannabis, can be increased by up to 21.35%.

Classes IPC  ?

• A01H 3/02 - Procédés de modification des phénotypes par contrôle de la durée, de la longueur d'onde, de l'intensité ou de la périodicité de l'éclairement
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 7/06 - Traitement des arbres ou des plantes en cours de croissance, p. ex. pour prévenir la décomposition du bois, pour teinter les fleurs ou le bois, pour prolonger la vie des plantes
• A01G 9/20 - ChâssisÉclairages
• A01G 22/00 - Culture de plantes spécifiques non prévue ailleurs
• F21V 9/30 - Éléments contenant un matériau photoluminescent distinct de la source de lumière ou espacé de cette source
• A01G 22/15 - Légumes-feuilles, p. ex. laitue ou épinards
• A01H 6/28 - Cannabaceae, p. ex. cannabis
• F21Y 115/10 - Diodes électroluminescentes [LED]
• F21Y 113/17 - Combinaison de sources lumineuses de couleurs différentes comprenant un ensemble de sources lumineuses ponctuelles formant une seule source lumineuse encapsulée

Abrégé

Disclosed is a method for controlling plant growth. Control to plant growth and development is achieved mainly by adjusting the ratio of photons of 700-780 nm far red light and 400-499 nm blue light in a spectrum.

Classes IPC  ?

• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 22/05 - Légumes-fruits, p. ex. fraises, tomates ou concombres
• A01G 31/00 - Culture hors-sol, p. ex. hydroponie

Abrégé

Disclosed is a light environment regulation and control method for increasing the flowering amount of edible flowers in a plant factory. During the planting of edible flowers, the spectral composition of a light source used comprises red light and far-red light, wherein the far-red-light photon number/red-light photon number is 0.25-0.43. According to the light environment regulation and control method provided by the present invention, the amount of edible flowers can be greatly increased by means of accurately controlling the FR/R ratio range, and operation is easy and large-scale production can be achieved.

Classes IPC  ?

• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 31/00 - Culture hors-sol, p. ex. hydroponie
• A01C 1/00 - Appareils ou modes d'emploi des appareils pour éprouver ou traiter les graines, les racines ou analogues avant l'ensemencement ou la plantation

Abrégé

The present invention relates to the technical field of plant lighting, in particular to a panel type combined plant lamp, at least including a panel lamp. Any end of the panel lamp is provided with a rotating connection part, the joint of the rotating connection part and the panel lamp is provided with a slide sleeve plate, the slide sleeve plate includes a pulling plate and a bottom plate, the bottom plate is fixedly connected to the panel lamp or the rotating connection part, the pulling plate is fixedly connected to the panel lamp or the rotating connection part, the thickness of the panel lamp is 3 to 40 mm, the slide sleeve plate is internally provided with a slide groove along the length direction, both sides of the slide groove are provided with openings.

Classes IPC  ?

• F21V 21/29 - Bras pivotants réglables dans plus d'un plan utilisant des joints à cardan
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• F21S 8/02 - Dispositifs d'éclairage destinés à des installations fixes encastrables, p. ex. plafonniers à spots lumineux
• F21W 131/30 - Éclairage pour un usage domestique ou personnel

Abrégé

A method for promoting the accumulation of secondary metabolites of cannabis is disclosed. The method comprises the step of adding an irradiation of green-yellow light, which has a peak wavelength at 505-590 nm, into the indoor growing environment of cannabis to improve the level of cannabidiol (CBD), secondary metabolites in cannabis. While maintaining the light intensity and other growth conditions, the yield and/or level of CBD, secondary metabolites in cannabis, can be increased by up to 11.04%.

Classes IPC  ?

• A01H 3/02 - Procédés de modification des phénotypes par contrôle de la durée, de la longueur d'onde, de l'intensité ou de la périodicité de l'éclairement
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 7/06 - Traitement des arbres ou des plantes en cours de croissance, p. ex. pour prévenir la décomposition du bois, pour teinter les fleurs ou le bois, pour prolonger la vie des plantes
• A01G 9/20 - ChâssisÉclairages
• A01G 22/00 - Culture de plantes spécifiques non prévue ailleurs
• F21V 9/30 - Éléments contenant un matériau photoluminescent distinct de la source de lumière ou espacé de cette source
• A01G 22/15 - Légumes-feuilles, p. ex. laitue ou épinards
• A01H 6/28 - Cannabaceae, p. ex. cannabis
• F21Y 115/10 - Diodes électroluminescentes [LED]
• F21Y 113/17 - Combinaison de sources lumineuses de couleurs différentes comprenant un ensemble de sources lumineuses ponctuelles formant une seule source lumineuse encapsulée

Abrégé

A light regulation method for a multi-layer planting system. Light spectra consisting of different compositions are set in accordance with environmental temperature differences among layers in the multilayer planting system for irradiating plants, thereby realizing regulation of plant yield, shape and metabolites, and increasing the quality consistency of products and yield of products.

Classes IPC  ?

• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance

Abrégé

The present invention relates to the technical field of plant lighting. Provided is an efficient and safe plant lighting circuit, comprising an aluminum substrate and a driving power supply, wherein the driving power supply is disposed on the aluminum substrate; multiple driving circuits are connected in parallel at an output end of the driving power supply, each driving circuit is connected to at least one LED lamp source, each driving circuit is connected to a safe circuit in series at the front end of the LED lamp source, and the safe circuit is disposed on the aluminum substrate; and an LED light-emergent surface of the aluminum substrate is coated with an ultrathin silicone layer. In the present invention, the safety and reliability of a lamp circuit are improved by means of the safe circuit, and the integral junction pressure of an LED is precisely controlled, thereby improving the circuit efficiency, and simplifying a lamp. Accordingly, the use of heat dissipation parts is reduced, the heat dissipation surface area of the lamp is effectively decreased, sufficient lighting can be provided for plants in a limited space, the lighting utilization rate is effectively improved, the planting effect is greatly improved, and the planting safety and economic benefits are improved.

Classes IPC  ?

• H05B 45/30 - Circuits de commande
• H05B 45/50 - Circuits pour faire fonctionner des diodes électroluminescentes [LED] réagissant aux dysfonctionnements des LED ou à un comportement indésirable des LEDCircuits pour faire fonctionner des diodes électroluminescentes [LED] sensibles à la vie des LEDCircuits de protection
• H05B 45/52 - Circuits pour faire fonctionner des diodes électroluminescentes [LED] réagissant aux dysfonctionnements des LED ou à un comportement indésirable des LEDCircuits pour faire fonctionner des diodes électroluminescentes [LED] sensibles à la vie des LEDCircuits de protection dans un ensemble parallèle de LED
• H05B 45/54 - Circuits pour faire fonctionner des diodes électroluminescentes [LED] réagissant aux dysfonctionnements des LED ou à un comportement indésirable des LEDCircuits pour faire fonctionner des diodes électroluminescentes [LED] sensibles à la vie des LEDCircuits de protection dans un ensemble sériel de LED
• H05B 45/56 - Circuits pour faire fonctionner des diodes électroluminescentes [LED] réagissant aux dysfonctionnements des LED ou à un comportement indésirable des LEDCircuits pour faire fonctionner des diodes électroluminescentes [LED] sensibles à la vie des LEDCircuits de protection impliquant des mesures pour empêcher une température anormale des LED

Abrégé

Disclosed is a method for stabilizing the pH value of a plant hydroponic nutrient solution. The method comprises adding citric acid or citrate to a hydroponic nutrient solution and using buffering properties of the citric acid or the citrate to stabilize the pH value of the plant hydroponic nutrient solution. The method enables the pH value of the hydroponic nutrient solution for growing leafy vegetables to be maintained within a safe range during the entire growth cycle under plant factory conditions without manual intervention, thereby significantly simplifying the planting process.

Classes IPC  ?

• C05G 3/00 - Mélanges d'un ou plusieurs engrais avec des additifs n'ayant pas une activité spécifique d'engrais
• C05G 5/20 - Engrais liquides
• A01G 31/00 - Culture hors-sol, p. ex. hydroponie

Abrégé

Disclosed is a solid plant nutrient solution. The composition of the solid plant nutrient solution comprises bicarbonate and citric acid, and the mass ratio of bicarbonate to citric acid is 2-9:1. The potassium ions in the potassium bicarbonate in the nutrient solution can also be used as a source of plant nutrition, and at the specific ratio, citric acid can stabilize the acid-base balance of the nutrient solution during plant growth.

Classes IPC  ?

• C05G 3/00 - Mélanges d'un ou plusieurs engrais avec des additifs n'ayant pas une activité spécifique d'engrais
• C05G 5/00 - Engrais caractérisés par leur forme
• A01G 31/00 - Culture hors-sol, p. ex. hydroponie

Abrégé

Disclosed is an setup-free planting case, which includes at least one planting box. Each planting box is provided with a box body and a box cover; a light source module is arranged on the box cover; a heat dissipation module is arranged on the box cover or the box body; the box body is provided with a connection port; the top of the box cover is provided with a connection portion; the connection portion at the top of the box cover matches the connection port at the bottom of the box body; and the light source module and the heat dissipation module are arranged in a cavity.

Classes IPC  ?

• A01G 9/16 - Serres démontables ou transportables
• A01G 9/24 - Dispositifs de chauffage, d'aération, de régulation de la température ou d'irrigation dans les serres, les châssis ou les installations similaires

Abrégé

Disclosed a hole plate rack capable of adjusting a distance between a plant root system and a nutrient solution level. Height adjustment structures are added on both sides of the hole plate rack to adjust the distance between a seedling root system and the nutrient solution level. The height adjustment structures are designed on both sides of the hole plate rack, and include grooves dug in both sides of the hole plate rack, and height cushion blocks. Inner walls of the grooves are provided with height cushion block separators. The height cushion blocks are rotatably connected into mounting holes in the inner walls of the grooves through plug pins, and are rotated to different positions to realize height adjustment.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet

Abrégé

An LED plant growth lamp spectrum, the spectrum including: a light wave of 500-599 nm and a light wave of 700-780 nm, where a ratio of the number of photons in the range of 500-599 nm to the number of photons in the range of 700-780 nm is 0.9-1.6:1. The LED plant growth lamp spectrum promotes indoor cultivation and growth of plants, and helps to increase the yield of medicinal components per unit area and per unit time in the factory production.

Classes IPC  ?

• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• F21K 9/20 - Sources lumineuses comprenant un moyen de fixation
• F21V 9/45 - Éléments modifiant les caractéristiques spectrales, la polarisation ou l’intensité de la lumière émise, p. ex. filtres avec des dispositions pour commander les propriétés spectrales, p. ex. la couleur, ou l’intensité en ajustant des éléments photoluminescents
• F21Y 115/10 - Diodes électroluminescentes [LED]

Abrégé

A sub-irrigation bed includes a bottom, a side wall surrounding the bottom, a water inlet, and a water outlet. A plurality of support structures is arranged on an upper surface of the bottom, and tops of at least a part of the plurality of support structures lie in the same horizontal plane. By reducing the contact area between the cultivation container and the surface of the sub-irrigation bed to reduce local water accumulation caused by surface tension, the sub-irrigation bed and the cultivation apparatus using the sub-irrigation bed provided by the present invention solve the problem of water accumulation caused by incomplete drainage and the resulting problems that roots grow out of the cultivation container and seedlings grow irregularly, thereby achieving a good root control effect.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet
• A01G 31/00 - Culture hors-sol, p. ex. hydroponie

Abrégé

The present invention relates to the field of plant lighting, and specifically relates to a plant lighting system and method for increasing the rate of light utilisation, comprising an input rectifying filter, a switch device, an output wave filter circuit, an LED load, a signal sampling module, and a PWM control module, an input end of the input rectifying filter being connected to an external power source, an output end of the input rectifying filter being connected to an input end of the switch device, an output end of the switch device being connected to an input end of the output wave filter circuit, an output end of the output wave filter circuit being connected to the LED load, an input end of the signal sampling module being connected to the LED load, an output end of the signal sampling module being connected to an input end of the PWM control module, and an output end of the PWM control module being connected to the switch device; the output wave filter circuit modulates the output frequency to above 100 Hz and modulates the duty cycle to 20-80% without changing the instantaneous output power. The beneficial effects of the present invention are increasing the rate of light utilisation, and thereby effectively reducing the lamp power and indirectly reducing the requirements for heat dissipation conditions.

Classes IPC  ?

• H05B 45/325 - Modulation de la largeur des impulsions [PWM]
• H05B 45/335 - Modulation de la fréquence des impulsions [PFM]
• H05B 45/40 - Détails des circuits de charge à LED

Abrégé

An artificial light environment method for plant seedling raising. The proportion of the number of photons with the wavelength greater than 700 nm in a light environment is less than 3%. Further provided is method for performing seedling raising by using the foregoing light environment method. In the light environment of a management process, the artificial light environment method for plant seedling raising is used in spectrum, and thus, a seedling that is more robust than a traditional greenhouse seedling is rapidly obtained.

Classes IPC  ?

• A01G 22/05 - Légumes-fruits, p. ex. fraises, tomates ou concombres

Abrégé

222 concentration. Regulating different light environmental parameters and illumination modes in a seedling raising period and a cultivation period in a leafy vegetable breeding process effectively promotes the conversion of vegetables from vegetative growth to reproductive growth, and the flowering time is shortened by one fifth or more, and the seed collection cycle is greatly shortened.

Classes IPC  ?

• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance

Abrégé

A light environment regulation method for regulating plant metabolic substances. In a plant cultivation stage, at least one type of intermittent lighting is added to promote accumulation of secondary metabolic substances in plants. The method can improve anthocyanin content, vitamin C, and soluble protein content in purple-red vegetables, further improves the quality of the purple-red vegetables, and improves the appearance and flavor of the purple-red vegetables.

Classes IPC  ?

• A01G 31/00 - Culture hors-sol, p. ex. hydroponie
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 22/15 - Légumes-feuilles, p. ex. laitue ou épinards
• G05D 27/02 - Commande simultanée des variables entrant dans plusieurs des groupes principaux caractérisée par l'utilisation de moyens électriques

Abrégé

A multi-spectrum generating device and method thereof. The multi-spectrum generating device includes at least one first luminaire, at least one second luminaire, and a control component. The first luminaire and the second luminaire each have a light source. The control component is connected to the first luminaire and the second luminaire for controlling the first luminaire and the second luminaire. In the present application, by controlling the switches of the first luminaire and the second luminaire, the multi-spectrum can be realized, so as to meet some special requirements of photobiological regulation. Moreover, the first luminaire and the second luminaire are mutually independently controlled luminaires and are controlled by different power sources, so the control circuit is simple and has a low cost, without affecting the primary demanded spectra provided by the first luminaire. Therefore, the present application has high utilization rate and high flexibility in use.

Classes IPC  ?

• H05B 47/10 - Commande de la source lumineuse
• F21V 29/74 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques avec ailettes ou lames
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• F21V 29/89 - Métaux
• F21V 29/76 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques avec ailettes ou lames avec ailettes ou lames en plans parallèles essentiellement identiques, p. ex. avec une section en forme de peigne
• F21V 29/83 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques les éléments comportant des ouvertures, des conduits ou des canaux, p. ex. des trous de rayonnement thermique

Abrégé

A transplanting equal-distribution mechanism. The transplanting equal-distribution mechanism comprises a driving mechanism, a module fixing plate (1), a robot connecting rod (2), connecting rods (8), and clamping jaw devices; the driving mechanism is provided above the module fixing plate (1); a plurality of sliders (16) are provided on a guide rail (15) which is provided at the bottom of the module fixing plate (1); each clamping jaw device is connected to the lower portion of the corresponding slider (16); the back surface of each clamping jaw device is provided with two connecting rods (8); the connecting rods (8) are rotatably connected to the backs of the clamping jaw devices. Automatic separation and gathering of the clamping jaw devices are realized under the driving action of the driving mechanism, and plant clamping and placement in a transplanting process are realized by clamping and releasing functions of the clamping claw devices.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet
• A01C 11/02 - Machines transplanteuses [repiqueuses] pour plants
• B25J 15/06 - Têtes de préhension avec moyens de retenue magnétiques ou fonctionnant par succion
• B25J 15/00 - Têtes de préhension

Abrégé

A multifunctional seedling culturing apparatus includes a fixed seedling culturing pedestal and a movable seedling culturing shelf cart, where the fixed seedling culturing pedestal includes a frame, and light sources are disposed on the frame; the movable seedling culturing shelf cart includes a board shelf, at least two boards are disposed on the board shelf, planting plates are disposed on the at least two boards, a movable apparatus is disposed on a bottom of the board shelf, and the at least two boards on the board shelf match light source positions on the fixed seedling culturing pedestal.

Classes IPC  ?

• A01G 9/24 - Dispositifs de chauffage, d'aération, de régulation de la température ou d'irrigation dans les serres, les châssis ou les installations similaires
• A01G 9/029 - Récipients pour plants

Abrégé

A hydroponic apparatus includes a cultivation tank and planting containers. The cultivation tank includes an inner space and a top planting groove. Each of the planting containers includes a container body and a container brim The planting containers can be arranged on the planting groove along a width direction of the planting groove, and the planting containers can be moved along a length direction of the planting groove. A hydroponic method includes: placing the planting containers at n positions arranged along the planting groove, wherein each position corresponds to a plant growth and development stage, and is consistent with an order of the plant growth and development stages; and harvesting the plant at the position n at a specified time point, and moving the planting containers at other positions one by one to the positions corresponding to the next plant growth and development stages.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance

Abrégé

A hydroponic cultivation system includes a plurality of hydroponic cultivation units vertically stacked one over another, each configured to provide a cultivation bed for the plants and including: a tank with an integrated structure; separation bars on a bed of the tank; a planting board; a plurality of removable dispensers, and a plurality of removable dam members. Every two neighboring hydroponic cultivation units are hydrologically coupled to one another such that the culture solution flows top-to-bottom through each of the plurality of hydroponic cultivation units on each level. The removable dam members and the separation bars are configured to facilitate flexible control of depths and passageways of a culture solution flowing in the tank, thereby allowing for convenient switching between a deep cultivation mode and a shallow cultivation mode to support different growth stages of plants being cultivated in the tank of the hydroponic cultivation unit.

Classes IPC  ?

• A01G 31/00 - Culture hors-sol, p. ex. hydroponie
• A01G 31/02 - Appareils particuliers à cet effet
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

A multiple reflection panel lamp comprises a retaining frame (102), multiple panel lamps (103), and multiple reflective plates (104). The multiple panel lamps (103) are embedded in the retaining frame (102) in a mutually parallel manner, and the reflective plates (104) and the panel lamps (103) are disposed on the retaining frame (102) in parallel. By disposing a reflective plate (104) between two panel lamps (103), the invention utilizes a multiple reflection mechanism thereof to enable light emitted by a light source to be reflected multiple times compared to other panel lamps, such that the light thoroughly irradiates plants from various angles, thereby enhancing lighting intensity and uniformity, and ensuring normal growth of the plants.

Classes IPC  ?

• F21S 8/00 - Dispositifs d'éclairage destinés à des installations fixes
• F21V 21/10 - Lustres, appliques ou corps de lampadairesFixation des dispositifs d'éclairage aux lustres, appliques ou corps de lampadaires

Abrégé

cannabis can be increased by up to 18%.

Classes IPC  ?

• A01H 6/28 - Cannabaceae, p. ex. cannabis
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 9/20 - ChâssisÉclairages
• A01G 9/26 - Dispositifs électriques
• A01G 7/06 - Traitement des arbres ou des plantes en cours de croissance, p. ex. pour prévenir la décomposition du bois, pour teinter les fleurs ou le bois, pour prolonger la vie des plantes
• A01H 3/02 - Procédés de modification des phénotypes par contrôle de la durée, de la longueur d'onde, de l'intensité ou de la périodicité de l'éclairement
• F21Y 115/10 - Diodes électroluminescentes [LED]

Abrégé

A method for promoting the accumulation of secondary metabolites of cannabis is disclosed. The method comprises the step of adding a green-yellow light, which has a peak wavelength at 506-571 nm, into the indoor growing environment for cannabis, and maintaining the light intensity and other growth conditions, to improve the content of secondary metabolites. The production of secondary metabolites of cannabis can be increased by up to 18%.

Classes IPC  ?

• A01H 6/28 - Cannabaceae, p. ex. cannabis
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 9/22 - Stores ou jalousies de serres ou dispositifs similaires

Abrégé

An auxiliary root placement apparatus for hydroponic separate planting, comprising a bottom frame (1), a repeated horizontal moving mechanism (2), a jacking mechanism (3) and a vacuum suction mechanism (4), wherein the repeated horizontal moving mechanism (2) is disposed on the bottom frame (1), and the jacking mechanism (3) is slidably connected to the bottom frame (1); an output end of the repeated horizontal moving mechanism (2) is fixedly connected to the jacking mechanism (3), and output ends of the jacking mechanism (3) are fixedly connected to the vacuum suction mechanism (4). According to the present apparatus, the jacking mechanism is pushed by means of the repeated horizontal moving mechanism to drive the vacuum suction mechanism to move to a position directly below cultivation holes on a cultivation plate, then the jacking mechanism drives the vacuum suction mechanism to rise upwards, so that output ends of the vacuum suction mechanism penetrate the cultivation holes to touch the roots of hydroponic plants so as to attach the hydroponic plants tightly to vacuum suction rods, and then same are retracted by means of the jacking mechanism, so that the roots of the hydroponic plants may pass smoothly through the cultivation holes, and will not be clamped onto the cultivation plate to cause the roots to rot, thus ensuring the stable growth of the hydroponic plants.

Classes IPC  ?

• A01G 31/00 - Culture hors-sol, p. ex. hydroponie

Abrégé

A cup placing device for a planting cup, comprising a profile support (1), a horizontal driving mechanism (2), a depressing mechanism (3) and a planting cup grabbing mechanism (4) fixed at an output end of the depressing mechanism; the horizontal driving mechanism and the depressing mechanism are provided on the profile support; an output end of the horizontal driving mechanism is connected to the depressing mechanism so as to horizontally move same along the profile support; and the planting cup grabbing mechanism is provided with a plurality of mechanical clamping jaws (401) and a guiding device (402) for adjusting the spacing between adjacent mechanical clamping jaws. The depressing mechanism is moved above arranged planting cups by means of the horizontal driving mechanism, the planting cup grabbing mechanism is pushed downwards by means of the depressing mechanism to touch the planting cups, so as to achieve the automatic grabbing of the planting cups; the planting cups are then arranged equidistantly as required by means of the guiding device on the planting cup grabbing mechanism; and then the planting cups are accurately filled by means of the depressing mechanism to a certain value, so that the planting cups can be stably clamped, arranged equidistantly, and accurately placed on the planting plate.

Classes IPC  ?

• B65G 47/91 - Dispositifs pour saisir et déposer les articles ou les matériaux comportant des pinces pneumatiques, p. ex. aspirantes
• B65G 47/26 - Dispositifs pour influencer la position relative ou l'orientation des objets pendant le transport par transporteurs arrangeant les objets, p. ex. faisant varier l'espace entre chaque objet

Abrégé

Disclosed is a device suitable for automatically harvesting soilless culture sprouts, the device comprising a bottom support frame (1), a conveying mechanism (3), and a cutting mechanism (4). The conveying mechanism (3) is arranged on the bottom support frame (1), the cutting mechanism (4) is arranged on the conveying mechanism (3), the conveying mechanism (3) moves in a horizontal direction, an included angle α is formed between the conveying mechanism (3) and a horizontal plane, and the range of the included angle α is 30° ≤ α ≤ 90°. According to the device, an included angle is formed between the conveying mechanism and the bottom support frame, such that the sprouts are effectively prevented from directly falling onto a cultivation plate, the subsequent treatment processes are reduced, and the production efficiency is increased.

Classes IPC  ?

• A01D 45/00 - Récolte d’espèces sur pied
• B65G 41/00 - Châssis ou bases de support pour transporteurs dans leur ensemble, p. ex. châssis transportables

Abrégé

A method for facilitating plant growth at least comprises: providing an artificial light source for a growing plant, the light source comprising red light having a peak emission wavelength of 680-695 nm and a full width at half maximum ＜35 nm, or the light source comprising blue light having a peak emission wavelength of 410-440 nm and a full width at half maximum ＜35 nm. Also provided is a plant illumination device providing the above light source and used to facilitate plant growth.

Classes IPC  ?

• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance

Abrégé

A root control cultivation apparatus comprises a seedling plug tray (1) and a breathable and permeable enclosure net (3). Multiple seedling cells or seedling holes (2) are arranged at the seedling plug tray (1). The breathable and permeable enclosure net (3) is provided with multiple string bags (4) matching the seedling cells (2). The seedling cell or seedling hole (2) has a circular shape, a rectangular shape or another shape when viewed in a cross section. Ventilation holes are arranged at side surfaces of the seedling cells, or through holes (6) are arranged at the bottom of the seedling cells. The breathable and permeable enclosure net (3) is sleeved onto the outside of the seedling plug tray (1) or inserted into the seedling plug tray. The device has a simple and reasonable structure, and can protect root systems from exposure and damage while simplifying an operation procedure relating to growing seedlings, thereby reducing labor and other costs, increasing plant uniformity, and solving the problem in which root systems grow too long in a hydroponic process and cannot be transferred to cultivation holes easily.

Classes IPC  ?

• A01G 9/029 - Récipients pour plants

Abrégé

Disclosed is a sponge tearing and filling device, comprising a profile support (1), a mechanical gripping jaw (2), a telescopic mechanism (3), a sponge filling transition plate (4) and a downward pressing mechanism (5), wherein the mechanical gripping jaw (2), the telescopic mechanism (3) and the downward pressing mechanism (5) are arranged on the profile support (1); and a sponge pressing head (503) is provided at an output end of the downward pressing mechanism (5), and an output end of the telescopic mechanism (3) is fixedly connected to the sponge filling transition plate (4).

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet

Abrégé

A sponge strip tearing device comprises a large base plate (1), a sponge sheet conveying mechanism (2), a down-pressing mechanism (3), an extendable mechanism (4) and a sponge strip tearing mechanism (5). The sponge sheet conveying mechanism (2), the down-pressing mechanism (3), and the extendable mechanism (4) are provided at the large base plate (1). An output end of the extendable mechanism (4) is fixedly connected to the sponge strip tearing mechanism (5). The down-pressing mechanism (3) is positioned at an output side of the sponge sheet conveying mechanism (2). The device of the present invention is provided with an improved sponge-pressing plate (503). In a sponge strip tearing process, the sponge-pressing plate (503) tightly presses against a sponge sheet while an extendable mechanism (4) is tearing the sponge sheet into strips, such that a sponge strip is prevented from being torn off due to uneven tearing of the sponge sheet. An area of a press surface of the sponge-pressing plate (503) in contact with the sponge sheet is reduced, thereby solving the problem in which static electricity generated due to a large contact area results in deviated positioning of a sponge strip, and consequently, causes a fault in the next sponge block tearing process.

Classes IPC  ?

• B26F 3/02 - Déchirement
• B26D 7/02 - Moyens pour maintenir ou mettre en position la pièce comportant des moyens de serrage
• B26D 7/06 - Dispositions pour faire avancer ou évacuer les pièces autres que les feuilles, les bandes ou les filaments

Abrégé

An LED plant illumination lamp module includes at least two light source modules and two lamp module cases located at both ends of the light source modules. Each of the light source modules includes a lamp tube, a circuit board mounted inside the lamp tube, and LED lamp beads fixed on the circuit board. At least two lamp tube insertion slots are arranged on one side of each of the lamp module cases, and two ends of the lamp tube are respectively inserted into the lamp tube insertion slots on the lamp module cases. At least one of the lamp module cases is provided with an LED power supply, and an output end of the LED power supply is connected to the circuit board inside the lamp tube.

Classes IPC  ?

• F21S 2/00 - Systèmes de dispositifs d'éclairage non prévus dans les groupes principaux ou , p. ex. à construction modulaire
• F21V 19/00 - Montage des sources lumineuses ou des supports de sources lumineuses sur ou dans les dispositifs d'éclairage
• F21V 21/005 - Soutien, suspension ou fixation des dispositifs d'éclairagePoignées pour plusieurs dispositifs d'éclairage disposés bout à bout, c.-à-d. rails de lumière
• F21V 23/02 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage les éléments étant des transformateurs ou des impédances
• F21V 23/06 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage les éléments étant des dispositifs de couplage
• F21Y 115/10 - Diodes électroluminescentes [LED]

Abrégé

A plant illumination optical device includes two LED lamp bodies. Each of the LED lamp bodies includes a reflector and an LED lamp located at an inner side of the reflector, and an angle between the central light rays of the two LED lamp bodies is adjustable. A plant cultivation device contains the plant illumination optical device. The plant illumination optical device and the plant cultivation device can reflect the light beyond the planting area to the planting area and can supplement the illumination on both sides of the illumination centerline, thereby avoiding light waste, improving energy efficiency, improving the illumination uniformity in the planting area, and improving planting quality of the planting area.

Classes IPC  ?

• F21V 5/04 - Réfracteurs pour sources lumineuses de forme lenticulaire
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• F21V 7/00 - Réflecteurs pour sources lumineuses
• F21V 7/09 - Structure de l'optique à combinaison des différentes courbures
• F21V 13/04 - Combinaisons de deux sortes d'éléments uniquement les éléments étant des réflecteurs et des réfracteurs
• F21V 21/30 - Enveloppes ou bâtis pivotants
• F21Y 103/10 - Sources lumineuses de forme allongée, p. ex. tubes fluorescents comprenant un réseau linéaire d’éléments générateurs de lumière ponctuelle
• F21Y 115/10 - Diodes électroluminescentes [LED]
• F21V 17/08 - Fixation des parties constitutives des dispositifs d'éclairage, p. ex. des abat-jour, des globes, des réfracteurs, des réflecteurs, des filtres, des écrans, des grilles ou des cages de protection sur les éléments de soutien ou de suspension du dispositif d'éclairage, p. ex. sur les cordons d'alimentation, sur les corps de lampadaires
• F21V 17/10 - Fixation des parties constitutives des dispositifs d'éclairage, p. ex. des abat-jour, des globes, des réfracteurs, des réflecteurs, des filtres, des écrans, des grilles ou des cages de protection caractérisée par des moyens de fixation spécifiques
• F21V 17/12 - Fixation des parties constitutives des dispositifs d'éclairage, p. ex. des abat-jour, des globes, des réfracteurs, des réflecteurs, des filtres, des écrans, des grilles ou des cages de protection caractérisée par des moyens de fixation spécifiques par vissage

Abrégé

An LED plant growth lamp and a light spectrum and application thereof, wherein the light spectrum contains: 500-599 nm light waves and 700-780 nm light waves, and the ratio of the number of photons in the 500-599 nm range and the number of photons in the 700-780 nm range is 0.9-1.6:1. The use of the present light spectrum may promote the indoor cultivation and growth of plants, and help to increase pharmaceutical composition yield per unit time and per unit area during industrial production.

Classes IPC  ?

• F21K 9/20 - Sources lumineuses comprenant un moyen de fixation
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance

Abrégé

The present invention relates to the technical field of plant cultivation by means of artificial light, and particularly provides a light environment method for full-artificial light cultivation of a plant to provide a full-artificial light source for plant growth. The light source comprises a light wave having the waveband of 620-760 nm, and the number of photons of the light wave of 620-760 nm accounts for 64-76% of the total number of photons of the light source. Compared with traditional light sources, such as existing fluorescent lamps and high-pressure sodium lamps, the proportion of the light sources and a light source combination mode used by the present invention can greatly improve the yield of the plant. Compared with a traditional LED lamp light source proportion scheme, the light source proportion scheme of the present invention has the advantages that the wave band of a selected light source is more accurate, is little affected by other plant growth parameters, and is more targeted in the process of promoting plant growth. By using the accurate combination and the proportions of the wave band of the accurate light wave, a peak value wavelength, and a photon ratio, the present invention can more accurately control a plant growth effect, thereby promoting the plant growth.

Classes IPC  ?

• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 31/02 - Appareils particuliers à cet effet

Abrégé

A panel-type combination grow light in the technical field of plant lighting. The panel-type combination grow light at least comprises a panel light (2). Any end of the panel light (2) is provided with rotary connection portions (5, 15); the joints of the rotary connection portions (5, 15) and the panel light (2) are provided with sliding sleeving plates (1, 8, 17); the sliding sleeving plates (1, 8, 17) comprise drawable plates (3,7,12,13) and base plates; the base plates are fixed to the panel light (2) or the rotary connection portions (5, 15); the drawable plates (3,7,12,13) are fixed to the panel light (2) or the rotary connection portions (5, 15); the panel light (2) is 3-40 mm in thickness; a sliding groove is provided in the sliding sleeving plate (1, 8, 17) along the length direction; two sides of the sliding groove are opened; the sidewalls of the sliding sleeving plates (1, 8, 17) are provided with limiting through holes (4) along the length direction; the limiting through holes (4) are communicated with the sliding groove. The panel-type combination grow light is strong in flexibility and convenient in assembling and disassembling; moreover, the adjustment of the light density and range can be achieved, and light distribution can be changed after multiple panel lights (2) are combined, so that the waste of light sources is avoided and plant growth is benefited.

Classes IPC  ?

• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• F21V 21/14 - Montages réglables

Abrégé

A multifunctional seedling raising device, comprising a fixedly disposed seedling raising base frame (10) and movable seedling raising layered rack carts (20). The seedling raising base frame comprises a frame (101), and the frame is provided with light sources. Each movable seedling raising layered rack cart comprises a layered rack (201); the layered rack is provided with multiple layers of plates (202); a planting tray (203) is provided on each plate; a movable means (204) is provided at the bottom of the layered rack; the plates on the layered rack matches the positions of the light sources on the seedling raising base frame. The seedling raising device is applicable to culture of seedlings of various plants, and can meet the needs of culture modes such as hydroponics, soil culture, and substrate culture.

Classes IPC  ?

• A01G 9/029 - Récipients pour plants
• A01G 25/00 - Arrosage des jardins, champs, terrains de sports ou similaires
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance

Abrégé

A planting box without need for construction, comprising at least one planting case which has a planting case body (3) and a case cover (1); the case cover (1) is provided with a light source module (8), the case cover (1) or the planting case body (3) is provided with a heat dissipation module (13), the planting case body (3) is provided with a tapered connecting opening (17), a soft rubber tapered connecting part (16) is provided at the top of the case cover (1), the soft rubber tapered connecting part (16) at the top of the case cover (1) fits with the connecting opening (17) at the bottom of the case body, and the light source module (8) and the heat dissipation module (13) are provided in a cavity. Such arrangements reduce the construction cost and operation cost of a plant factory, have low space configuration requirements and high operability, are easy to operate, do not require installation, reduce human labor, can be densely stacked, reduce the investment for an air conditioning system, and can accurately control the plant growth temperature.

Classes IPC  ?

• A01G 9/02 - Récipients, p. ex. pots ou jardinières Verres pour la culture des fleurs

Abrégé

A plug tray capable of adjusting the distance between a plant root system and a nutrient solution surface, and a planting plate, adjusting the distance between a seedling root system and a nutrient solution surface by adding height adjustment structures at two sides of the plug tray (2); the height adjustment structures are designed at two sides of the plug tray (2), and comprise grooves (10) and height blocks (9) which are provided at two sides of the plug tray (2); a height block spacer (8) is provided on an inner wall of the groove (10), and the height block (9) is pivotably connected in a mounting hole (7) in the inner wall of the groove (10) by means of a pin, the height adjustment is realized by pivoting the height block to different positions. The plug tray (2) has a simple and reasonable structure, is able to ensure nutrients required in the seedling cultivation period, and ensure that no root rot occurs and no algae grows in the seedling growth process, and can be widely used in plant hydroponics.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet

Abrégé

The present invention relates to the technical field of plant cultivation, and specifically relates to a bottom water supply irrigation bed and a cultivation apparatus comprising said irrigation bed. The irrigation bed comprises a bottom part, side walls surrounding the periphery of the bottom part, and a water inlet and a water outlet, the upper surface of the bottom part being provided with a plurality of support structures, and the top parts of at least some of the plurality of support structures being on the same horizontal plane. The irrigation bed and the cultivation apparatus using said irrigation bed provided in the present invention target the problem of water accumulation caused by incomplete drainage and the problems of roots growing out of cultivation containers and uneven growth of seedlings as a result of same, reducing the local water accumulation caused by surface tension by means of reducing the contact area between the cultivation container and the irrigation bed surface, and achieving a good root control effect.

Classes IPC  ?

• A01G 9/28 - Parterres surélevésPlatebandesÉléments de bordure pour planches, pelouses ou similaires, p. ex. des tuiles
• A01G 31/02 - Appareils particuliers à cet effet

Abrégé

A seedling raising block, comprising a nutrition block (1) for providing nutrition for seeds; a seed-putting-in pit (2) set in the top of the nutrition block (1); a seed cultivation pit (3) set within the seed-putting-in pit (2), wherein the seed-putting-in pit (2) is configured to have a structure with a big opening on top and a small opening on bottom such that seeds fall into the seed cultivation pit (3) along the surface of the seed-putting-in pit under gravity; and a cut (4) set within the seed cultivation pit (3), wherein the cut extends in the direction away from the seed cultivation pit and provides a growth pathway for root systems germinated from the seeds. The seedling raising block can improve the seeding efficiency, stabilize wet seeds, improve the overall budding rate and budding uniformity of the seeds, and facilitate mechanical seeding.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet

Abrégé

A planting device, a multilayer stereo-planting system using the planting device, and a planting system of a plant factory using the multilayer stereo-planting system are provided. The planting device includes the planting tray and the planting board which can be moved as a whole. The nutrient solution inlet and the nutrient solution outlet are located on the same side of the planting tray. The multilayer stereo-planting system includes the support rack and the nutrient solution supply system installed on the support rack. The planting device can be detachably installed on the support rack as a whole. The planting tray and the planting board of the planting device can be taken out and placed in together, protects the plant seedlings from injuries, and avoids the leakage phenomenon of the nutrient solution.

Classes IPC  ?

• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés
• A01G 7/02 - Traitement des végétaux au gaz carbonique
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 31/00 - Culture hors-sol, p. ex. hydroponie

Produits et services

Aeroponic grow cabinet in the nature of a closed environment with lights, exhaust system, aeroponic misting chamber and automated control system; Hydroponic growing systems comprised of light emitting diode (LED) plant grow lights, grow cabinets in the nature of closed environments with integrated misting chambers, and automated controls therefor

Abrégé

A plant hydroponic device and method. Said device comprises a cultivation groove (1) and plant holding cups (2), the cultivation groove (1) comprising an internal space and a top plant holding groove (11); each of the plant holding cups (2) comprises a cup body (21) and a cup edge (22); the plant holding cups (2) can be placed on the plant holding groove (11) along the width direction of the plant holding groove (11); and the plant holding cups (2) can move along the length direction of the plant holding groove (11). Said method comprises: providing n positions along the plant holding groove (11), the positions each corresponding to a plant growth and development period from seedling to harvest, and the positions being in a sequence consistent with the sequence of plant growth and development periods; placing, at each position, a plant holding cup (2) containing a plant at a corresponding growth and development period; and at a prescribed time, harvesting the plant at the nth position, and sequentially moving the plant holding cups (2) at the remaining positions to a position corresponding to the next plant growth and development period.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet
• A01G 31/04 - Culture hydroponique sur des transporteurs
• A01G 31/00 - Culture hors-sol, p. ex. hydroponie

Abrégé

A device and method for providing multiple spectra. The device for providing multiple spectra comprises at least one first lamp (100), at least one second lamp (200), and a control component. The first lamp (100) and the second lamp (200) each have a light source (8). The control component is connected to the first lamp (100) and the second lamp (200), and is used to control the first lamp (100) and the second lamp (200). Turning-on and turning-off of the first lamp (100) and the second lamp (200) are controlled so as to provide multiple spectra, satisfying certain special photobiological regulation requirements. In addition, the first lamp (100) and the second lamp (200) are controlled independently relative to each other, and are controlled by different power supplies. The control circuit is thus made simple and low cost without affecting the main desired spectra provided by the first lamp (100). Therefore, the invention has a high utilization rate and high flexibility.

Classes IPC  ?

• F21S 8/00 - Dispositifs d'éclairage destinés à des installations fixes
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance

Abrégé

hh of the heat exchange through slots (21) is four to six times of that of a heat sink without heat exchange through slots (21). In addition, the heat exchange through slots (21) increase the effective heat dissipation area of the heat sink, thereby significantly improving heat dissipation performance of the heat sink.

Classes IPC  ?

• F21S 8/00 - Dispositifs d'éclairage destinés à des installations fixes
• F21V 15/01 - Boîtiers, p. ex. matériau ou assemblage de parties du boîtier
• F21V 29/76 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques avec ailettes ou lames avec ailettes ou lames en plans parallèles essentiellement identiques, p. ex. avec une section en forme de peigne

Abrégé

The present invention relates to the field of polypeptide application, in particular relates to the field of polypeptide application in skin repair, and specifically relates to a polypeptide and an application of the skin repair function thereof. ZKSA-P-1001. The research finds that ZKSA-P-1001 has good stability and relatively good skin wound healing promoting ability. ZKSA-P-1001 can be used as a raw material or an auxiliary material for producing drugs, postoperative medical devices, healthcare products, cosmetics and the like with the skin repair function.

Classes IPC  ?

• C07K 7/06 - Peptides linéaires ne contenant que des liaisons peptidiques normales ayant de 5 à 11 amino-acides
• C12N 15/11 - Fragments d'ADN ou d'ARNLeurs formes modifiées
• C12N 15/63 - Introduction de matériel génétique étranger utilisant des vecteursVecteurs Utilisation d'hôtes pour ceux-ciRégulation de l'expression
• A61K 38/08 - Peptides ayant de 5 à 11 amino-acides
• A61K 8/64 - ProtéinesPeptidesLeurs dérivés ou produits de dégradation
• A61P 17/02 - Médicaments pour le traitement des troubles dermatologiques pour traiter les blessures, les ulcères, les brûlures, les cicatrices, les cheloïdes, ou similaires
• A23L 33/18 - PeptidesHydrolysats de protéines

Abrégé

A plant tissue culture vessel comprises a lower vessel portion (1) and an upper vessel portion (2), the lower vessel portion (1) and the upper vessel portion (2) both comprise a vessel body with a closed bottom and an open top. During use, the upper vessel portion (2) is inverted on the lower vessel portion (1), and opening parts of both are detachably connected. Dividing the tissue culture vessel into two upper and lower portions which are inverted together makes the depth of the bottom of the lower vessel portion (1) moderate, which is convenient for inoculating operation and taking out of the tissue culture seedling, and the working efficiency and the utilization ratio of the tissue culture seedling are improved.

Classes IPC  ?

• A01H 4/00 - Reproduction de plantes par des techniques de culture de tissus

Produits et services

Demonstration of goods; Demonstration of goods and services by electronic means, also for the benefit of the so-called teleshopping and homeshopping services; Marketing services; Promoting the goods and services of others; Providing business information via a web site; Provision of an online marketplace for buyers and sellers of goods and services; Radio advertising; Shop window dressing; Telemarketing services; Television advertising

Abrégé

The present invention relates to the technical field of plant illumination, and specifically provides an optical apparatus for plant illumination, comprising two LED lamp bodies, the LED lamp bodies comprising: a reflector and LED lamps positioned on the inner side of the reflector, the angle of the central light ray of the two LED lamp bodies being adjustable. Also provided is a plant cultivation apparatus, comprising the optical apparatus for plant illumination. The optical apparatus for plant illumination and the plant cultivation apparatus provided in the present invention can reflect light outside of a planting area onto the planting area, and supplement the illumination on both sides of the illuminating central light ray, preventing light waste, increasing energy utilisation, and increasing the uniformity of illumination in the planting area, and thereby improving the planting quality of the planting area.

Classes IPC  ?

• F21S 8/00 - Dispositifs d'éclairage destinés à des installations fixes
• F21V 13/04 - Combinaisons de deux sortes d'éléments uniquement les éléments étant des réflecteurs et des réfracteurs
• F21V 19/02 - Montage des sources lumineuses ou des supports de sources lumineuses sur ou dans les dispositifs d'éclairage avec possibilité de réglage, p. ex. pour la mise au point
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• F21Y 115/10 - Diodes électroluminescentes [LED]

Abrégé

An LED plant lighting lamp module, comprising at least two light source modules (10) and two lamp module boxes (20, 30) located at both ends of the light source modules (10); each light source module (10) comprises a lamp tube (11) and a circuit board (12) installed in the lamp tube (11). LED lamp beads (13) are fixed on the circuit board (12). At least two lamp tube slots (23) are arranged on one side of each lamp module box (20, 30). Both ends of the lamp tubes (11) are inserted into the lamp tube slots (23) of the two lamp module boxes (20, 30), respectively. An LED power source (40) is installed in at least one of the lamp module boxes (20, 30). The output end of the LED power source (40) is connected to the circuit board (12) in the lamp tube (11). The lamp module and the components thereof feature high universality and wide applicability, and is convenient to use, easy to install, and quick to adjust.

Classes IPC  ?

• F21S 8/08 - Dispositifs d'éclairage destinés à des installations fixes avec un support
• F21V 21/00 - Soutien, suspension ou fixation des dispositifs d'éclairagePoignées
• F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage

Produits et services

(1) Advertising agencies; marketing research; on-line advertising the goods and services of others on computer communications networks; providing a searchable online advertising guide featuring the goods and services of other on-line vendors on the internet; providing business information in the field of social media; providing home shopping services of home entertainment electronics by means of television; sales demonstration for others; shop window dressing; telemarketing services; television advertising for others

Produits et services

Demonstration of goods; Radio advertising; Television advertising; Shop window dressing; Presentation of goods on communication media, for retail purposes; Demonstration of goods and services by electronic means, also for the benefit of the so-called teleshopping and homeshopping services; Providing business information via a web site; Marketing; Telemarketing services; Provision of an online marketplace for buyers and sellers of goods and services.

Abrégé

A liquid cooling module of an LED lamp, including a cooling body, two plugs and a heat source. The cooling body is formed with connected liquid flowing passages, and has the two plugs coupled to the two sides thereof. An inlet of each liquid flowing passage and an outlet of the adjacent liquid flowing passage are located at the same side of the cooling body. The inlet of the first liquid flowing passage is connected to an inlet hole of the plug at the same side. The liquid inlet of each liquid flowing passage besides the first one is connected to the outlet of the previous liquid flowing passage by a connecting groove of a corresponding plug. The outlet of the last liquid flowing passage is connected to an outlet hole of the plug at the same side.

Classes IPC  ?

• F21V 29/56 - Dispositions de refroidissement utilisant des liquides de refroidissement
• F21V 29/89 - Métaux
• F21V 29/503 - Dispositions de refroidissement caractérisées par l’adaptation au refroidissement de composants spécifiques de sources lumineuses
• F21V 29/508 - Dispositions de refroidissement caractérisées par l’adaptation au refroidissement de composants spécifiques de circuits électriques
• F21V 29/74 - Dispositions de refroidissement caractérisées par des éléments passifs de dissipation de chaleur, p. ex. puits thermiques avec ailettes ou lames
• H05K 7/20 - Modifications en vue de faciliter la réfrigération, l'aération ou le chauffage
• F21Y 115/10 - Diodes électroluminescentes [LED]
• F21Y 105/16 - Sources lumineuses planes comprenant un réseau bidimensionnel d’éléments générateurs de lumière ponctuelle caractérisées par la forme d’ensemble du réseau bidimensionnel carrée ou rectangulaire, p. ex. pour les panneaux de lumière

Abrégé

Provided are a cultivation device (1), a multi-layer three-dimensional cultivation system containing the cultivation device (1), and a plant factory planting system containing the multi-layer three-dimensional cultivation system. The cultivation device (1) comprises a planting box (10) and a planting plate (20), which can be moved integrally, a nutrient solution inlet (101) and a nutrient solution outlet (102) are formed at the same side of the planting box (10), the multi-layer three-dimensional cultivation system comprises a support layer frame, a nutrient solution supply system arranged on the support layer frame, and the cultivation device (1) can be installed on the support layer frame integrally and detachably. The planting box (10) and the planting plate (20) of the cultivation device (1) can be taken and placed as a whole, thereby protecting plant seedings from harm, and avoiding leakage of the nutrient solution, and independent placement of each cultivation device (1) do not affect the growth of other plants on the support layer frame, thereby simplifying production management. The multi-layer three-dimensional cultivation system solves the problems of the three-dimensional cultivation of plants in solution supply, automatic operation, cultivation device and pipeline cleaning, environmental control and the like.

Classes IPC  ?

• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

Disclosed is an amphichrome cultivation device, comprising a cultivation slot and a planting plate, wherein the planting plate and the cultivation slot are used separately, or the planting plate covers the cultivation slot and is adapted, together with the cultivation slot, to form a cavity for containing a nutrient solution or for accommodating a nutrient aerosol, so as to provide a dark growth environment for roots and make insufficient light available for algae in the nutrient solution or the nutrient aerosol, so that the reproduction and growth of same are impossible. At least one of an inner side wall of the cultivation slot, an inner bottom surface of the cultivation slot and a lower surface of the planting plate is completely covered by at least one light blocking layer, and a preparation method for the light blocking layer comprises coating, injection molding, laminating, bonding and spraying. The cultivation device of the present invention can minimize the light intensity under the planting plate, provide a light-shielded environment for root growth and development, and can prevent the reproduction and growth of algae.

Classes IPC  ?

• A01G 31/02 - Appareils particuliers à cet effet

Abrégé

Disclosed is an easily shaped liquid cooling heat-dissipating module of an LED lamp, comprising a cooling body (1), and two plugs (2, 3), wherein the cooling body (1) is formed with liquid flow passages (11, 12, 13). The number of liquid flow passages (11, 12, 13) is multiple, liquid inlet ends of respective liquid flow passages (11, 12, 13) are located at the same end of the cooling body (1) as liquid outlet ends of the adjacent liquid flow passages. A liquid inlet end of a first-stage liquid flow passage (11) is connected to a liquid inlet hole (21) arranged on a plug (2), with the plug (2) being at the end where the liquid inlet end is located, a liquid outlet end of a last-stage liquid flow passage (13) is connected to a liquid outlet hole (31) arranged on a plug (3), with the plug (3) being at the end where the liquid outlet end is located, and liquid inlet ends of other stages of liquid flow passage, apart from the first-stage liquid flow passage (11), respectively communicate with liquid outlet ends of upper stage liquid flow passages via connecting grooves (22, 23) arranged on the plugs (2, 3), with the plugs (2, 3) being at the end where the liquid outlet end is located. Alternatively, the number of liquid flow passage is one. A liquid inlet end of the liquid flow passage is connected to a liquid inlet hole (21) arranged on one plug (2) therein, and a liquid outlet end is connected to a liquid outlet hole (31) arranged on the other plug (3). Thus, a simple process and low costs are achieved, and it is easy to realize mass production.

Classes IPC  ?

• F21V 29/56 - Dispositions de refroidissement utilisant des liquides de refroidissement
• H05K 7/20 - Modifications en vue de faciliter la réfrigération, l'aération ou le chauffage

Produits et services

Agricultural machines, namely, cultipackers; Agricultural elevators; Mowing and reaping machines; Tractor towed agricultural implements, namely, reapers; Agricultural machines, namely, stalk separators; Spraying machines; Grain husking machines; Reapers and binders in the nature of hay binding machines; Agricultural implements, other than hand-operated, namely, coulters, hay balers, seed drills; Agricultural seed planting machines, namely, sowers

Abrégé

A hydroponic cultivation system includes a plurality of hydroponic cultivation units vertically stacked one over another. Each hydroponic cultivation unit is configured to provide a cultivation bed for the plants. Every two neighboring units are hydrologically coupled to one another such that the culture solution flows top-to-bottom through each hydroponic cultivation units on each level. A plurality of support members, such as pipes, are disposed between, and provide mechanical support for, two hydroponic cultivation units on every two neighboring levels. A light source is disposed over a bottom side of one hydroponic cultivation unit on an upper level and can emit a plant-compatible light to support growth of the plants being cultivated on another hydroponic cultivation unit on a level immediately below the upper level. The hydroponic cultivation system can achieve a vertical recycling of the culture solution.

Classes IPC  ?

• A01G 31/00 - Culture hors-sol, p. ex. hydroponie
• A01G 31/02 - Appareils particuliers à cet effet
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

A hydroponic cultivation system includes a plurality of hydroponic cultivation units vertically stacked one over another. Each unit is configured to provide a cultivation bed for the plants, and every two neighboring hydroponic cultivation units are hydrologically coupled to one another such that the culture solution flows top-to-bottom through each hydroponic cultivation unit on each level. The system further includes a plurality of support members, which are disposed between, and can provide mechanical support for, two hydroponic cultivation units on every two neighboring levels. The plurality of support members include at least one pipe, and each pipe is configured to arrange at least one of a hydrological connection or an electrical coupling between the two hydroponic cultivation units on the every two neighboring levels therein. The hydroponic cultivation system can achieve a vertical recycling of the culture solution.

Classes IPC  ?

• A01G 31/00 - Culture hors-sol, p. ex. hydroponie
• A01G 31/02 - Appareils particuliers à cet effet
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance
• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés

Abrégé

A configurable hydroponic cultivation unit and system. The configurable hydroponic cultivation unit (100) can include a tank (110). The tank comprises at least one separation bar (1114, 1115) and at least one removable dam member (150). The at least one separation bar is disposed on a bottom side of the tank and is configured to separate the tank into a plurality of trough regions. The at least one removable dam member is configured to be removably mounted in the tank to thereby block the culture solution from flowing therethrough. The at least one separation bar and the at least one removable dam member are configured to allow a configurable passageway for the culture solution flowing in the tank. Due to its modular features, the configurable hydroponic cultivation unit can be stacked one another to form a multi-level hydroponic cultivation system, which achieves a vertical recycling of the culture solution.

Classes IPC  ?

• A01G 9/02 - Récipients, p. ex. pots ou jardinières Verres pour la culture des fleurs

Abrégé

A configurable hydroponic cultivation device includes a tank. The tank includes at least one separation bar and at least one removable dam member. The at least one separation bar is disposed on a bottom side of the tank and is configured to separate the tank into a plurality of trough regions. The at least one removable dam member is configured to be removably mounted in the tank to thereby block the culture solution from flowing therethrough. The at least one separation bar and the at least one removable dam member are configured to allow a configurable passageway for the culture solution flowing in the tank. Due to its modular features, the configurable hydroponic cultivation unit can be stacked one another to form a multi-level hydroponic cultivation system, which achieves a vertical recycling of the culture solution.

Classes IPC  ?

• A01G 31/00 - Culture hors-sol, p. ex. hydroponie
• A01G 31/02 - Appareils particuliers à cet effet
• A01G 31/06 - Culture hydroponique sur des étagères ou dans des conteneurs empilés
• A01G 7/04 - Traitement électrique ou magnétique des végétaux pour favoriser leur croissance

Produits et services

(1) Agricultural cultivators; agricultural elevators; agricultural reaper machines; reapers; grain separators; corn husking machines; reapers and binders; agricultural equipment for seeding. (2) Electric lamps; lamp mantles; led luminaires; fluorescent lamp tubes; laboratory lamps; chandeliers; light bulbs; ceiling lights; lamp shades. (3) Indoor terrariums for plants; indoor aquaria; aquarium hoods; indoor terrariums.

Produits et services

Agricultural machines; Agricultural elevators; Mowing and reaping machines; Reapers; Stalk separators [machines]; Spraying machines; Grain husking machines; Reapers and binders; Agricultural implements, other than hand-operated; Sowers [machines]. Lamps; Lamp casings; Light-emitting diodes [LED] lighting apparatus; Luminous tubes for lighting; Laboratory lamps; Chandeliers; Lighting apparatus and installations; Light bulbs; Ceiling lights; Lamp shades. Indoor terrariums for plants; Indoor aquaria; Aquarium hoods; Indoor terrariums [vivariums].

Produits et services

Lamps; [ Lamp casings; ] Light-emitting diodes lighting apparatus in the nature of light-emitting diode lighting fixtures; Luminous tubes for lighting [ ; Laboratory lamps; Chandeliers; Lighting apparatus, namely, flat panel lighting apparatus, lighting apparatus for sports arenas, lighting apparatus for vehicles, and lighting installations; Light bulbs; Ceiling lights; Lamp shades ]

Produits et services

[ Agricultural machines, namely, cultipackers; Agricultural elevators; Mowing and reaping machines; Reapers; Agricultural machines, namely, stalk separators; Spraying machines; Grain husking machines; Reapers and binders in the nature of hay binding machines; ] Agricultural implements, other than hand-operated, namely, coulters, hay balers, seed drills; Agricultural seed planting machines, namely, sowers
