Abrégé

An electromagnetic heating type aerosol generating appliance having discrete cambered susceptors. The aerosol generating appliance is a heat-not-burn aerosol generating appliance. The aerosol generating appliance comprises a coil (11) and an accommodating cavity (12) disposed inside the coil (11); the accommodating cavity (12) is configured to accommodate an aerosol generating article (2) containing an axially disposed sheet-shaped susceptor (21) therein; and a plurality of circumferentially discrete cambered susceptors (13) are provided on an inner wall of the accommodating cavity (12). An aerosol generating material in an area of the sheet-shaped susceptor (21) having a reduced heating effect is subjected to additional heating using the cambered susceptors (13), thereby increasing the utilization rate of the aerosol generating material and the amount of aerosol generated.

Classes IPC  ?

• A24F 40/51 - Disposition des capteurs
• A24F 40/40 - Détails de construction, p. ex. connexion des cartouches et des batteries

Abrégé

Disclosed is an atomizing apparatus, including: an atomizing cup; an atomizing pedestal arranged at a top portion of the atomizing cup; one or more atomizing cores accommodated in the atomizing cup, the one or more atomizing cores are connected with the atomizing pedestal respectively; and a circuit electrically connected with the one or more atomizing cores respectively, the circuit is capable of adjusting parameters of the one or more atomizing cores to adjust temperatures of the one or more atomizing cores.

Classes IPC  ?

• A24F 40/53 - Suivi, p. ex. détection des pannes
• A24F 40/44 - Mèches
• A24F 40/42 - Cartouches ou contenants pour précurseurs inhalables
• A24F 40/51 - Disposition des capteurs
• A24F 40/57 - Commande de la température

Abrégé

A composite-type temperature raising and control integrated heating element and a temperature control method are provided. The heating element includes a heating body, which is integrated by welding two different conductive materials at a welding point. The heating element is not provided with a temperature measuring element other than the heating body. The heating body of the temperature raising and control integrated heating element is formed by welding two conductive materials. When a high voltage is applied, the two conductive materials serve as the heating body to generate heat. When the supply of the voltage is stopped, the two conductive materials serve as a thermocouple temperature measuring sensor to measure the temperature of the heating element. Compared to existing heating elements, the temperature measuring sensor is omitted, the fabrication process of the heating element is simplified, and the performance of the heating element is improved.

Classes IPC  ?

• A24F 40/46 - Forme ou structure des moyens de chauffage électrique
• A24F 40/51 - Disposition des capteurs
• A24F 40/57 - Commande de la température

Abrégé

Disclosed are a novel heat generating body and an atomizer. The novel heat generating body may include a ceramic body, a plurality of micro pores used for liquid infiltration are distributed in the ceramic body, heat generating wires respectively corresponding to two electrodes extend outward from a bottom of the ceramic body, the heat generating wires corresponding to two electrodes are connected by auxiliary heat generating wires arranged on an outer surface of the ceramic body, the auxiliary heat generating wires are distributed on outer surfaces of a bottom and a side wall of the ceramic body, and the auxiliary heat generating wires are metal wires embedded in the outer surfaces of the bottom and the side wall of the ceramic body, or the auxiliary heat generating wires are metal powder/metal wires printed on the outer surfaces of the bottom and the side wall of the ceramic body.

Classes IPC  ?

• A24F 40/46 - Forme ou structure des moyens de chauffage électrique
• A24F 7/00 - Bouquins pour pipesBouquins pour fume-cigares ou fume-cigarettes
• A24F 40/10 - Dispositifs utilisant des précurseurs inhalables liquides
• A24F 40/42 - Cartouches ou contenants pour précurseurs inhalables
• A24F 40/44 - Mèches
• H05B 3/16 - Éléments chauffants caractérisés par la composition ou la nature des matériaux ou par la disposition du conducteur le conducteur étant monté sur une base isolante

Produits et services

Cigarette holders; Cigarettes containing tobacco substitutes, not for medical purposes; Electronic cigarette liquid (e-liquid) comprised of propylene glycol; Electronic cigarette liquid (e-liquid) comprised of vegetable glycerin; Electronic cigarettes; Filter tips for cigarettes; Liquid nicotine solutions for use in electronic cigarettes; Oral vaporizers for smokers; Smokers' articles, namely, cigar relighting liquid solution; Electric cigarettes

Abrégé

An atomization device, comprising: a main housing (1) comprising a connection portion (14), a connection channel being formed in the connection portion (14); an atomizer (2) comprising an atomizer base (21), an atomizer arm (22), and an atomization core assembly provided in the atomizer base (21), the atomization core assembly comprising an atomization cup (23), a heating portion (24) and a thermal insulation portion, the atomizer arm (22) being connected to the atomizer base (21) and the connection portion (14), the heating portion (24) being provided at the bottom of the atomization cup (23) to heat the atomization cup (23), and the thermal insulation portion being used for thermally insulating heat generated by the heating portion (24); a hookah mouthpiece mechanism (3) detachably connected to the main housing (1), and comprising a glass mouthpiece (31) for a user to puff on same, the mouthpiece (31) being in communication with the atomization cup (23) by means of the connection channel; a control mechanism, accommodated in the main housing (1), and comprising a main control circuit board (51) electrically connected to the heating portion (24); and a battery (4), accommodated in the main housing (1), and electrically connected to the main control circuit board (51), so as to supply power to the atomizer (2).

Classes IPC  ?

• A24F 40/46 - Forme ou structure des moyens de chauffage électrique
• A24F 40/40 - Détails de construction, p. ex. connexion des cartouches et des batteries

Abrégé

An atomization device (10). The atomization device (10) comprises: a main housing (1), comprising an upper connecting base (14) and a lower connecting base (15), wherein the lower connecting base (15) is disposed on the side of the main housing (1) that faces away from the upper connecting base (14); an atomizer (2), comprising an atomizer housing (21) and an atomization core assembly disposed inside the atomizer housing (21), wherein the atomization core assembly comprises an atomization cup (22), a heating portion (23) and a thermal insulation portion, the atomizer housing (21) is connected to the upper connecting base (14), the heating portion (23) is disposed at the bottom of the atomization cup (22) and heats the atomization cup (22), and the thermal insulation portion is used for thermally isolating heat generated by the heating portion; a mouthpiece mechanism (3), which is detachably connected to the atomizer housing (21) and comprises a mouthpiece (31) which a user uses to vape, wherein the mouthpiece (31) is in communication with the atomization cup (22); an electrical control mechanism, which is accommodated in the main housing (1) and comprises a main control circuit board electrically connected to the heating portion (23); a battery (4), which is accommodated in the main housing (1), is electrically connected to the main control circuit board and is used for supplying power to the atomizer (2); and a hookah adapting mechanism (6), which is disposed inside the main housing (1), is connected to the lower connecting base (15) and comprises a vapor-passing pipe (61), wherein the vapor-passing pipe (61) is in communication with a hookah vapor output pipe and the atomizer (2).

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

An atomizer is provided. The atomizer includes a battery rod, including a rod body, a battery, and a first electrical connection part arranged on the rod body and exposed from the rod body, wherein an end of the rod body is disposed with a receiving part, and the first electrical connection part is located in the receiving part, an atomizing head, including a housing and a second electrical connection part arranged on the housing and exposed from the housing, and a mechanical switch, arranged on the rod body and exposed outside the rod body, wherein the mechanical switch is electrically connected between the battery and the first electrical connection part, and configured to turn on or turn off an electrical connection between the battery and the first electrical connection part; wherein the first electrical connection part is in contact with the second electrical connection part when the atomizing head is inserted into the receiving part, the electrical connection between the battery and the first electrical connection part is turned on when the atomizing head is inserted into the receiving part and the mechanical switch is triggered, and thereby an electrical connection between the first electrical connection part and the second electrical connection part is turned on to supply a power to the atomizing head through the battery. Using the mechanical switch to control the battery rod whether supply a power to the atomizing head or not can ensure the effectiveness of triggering power supply for a long time.

Classes IPC  ?

• A24F 40/95 - Leurs dispositions ou leurs procédés spécialement adaptés à la recharge des batteries structurellement associées à des étuis
• A61M 15/00 - Inhalateurs
• A24F 40/46 - Forme ou structure des moyens de chauffage électrique
• A24F 40/53 - Suivi, p. ex. détection des pannes

Abrégé

A ceramic heating element is disclosed, including: a flat or needle-shaped ceramic housing, a support bracket sleeved in the ceramic housing, and a heating wire evenly wound on the support bracket. An interior of the support bracket is a hollow structure. An electronic cigarette is further disclosed, including the ceramic heating element.

Classes IPC  ?

• H05B 3/14 - Éléments chauffants caractérisés par la composition ou la nature des matériaux ou par la disposition du conducteur caractérisés par la composition ou la nature du matériau conducteur le matériau étant non métallique
• A24F 40/46 - Forme ou structure des moyens de chauffage électrique
• A24F 40/57 - Commande de la température

Abrégé

An injection-molded heating assembly, and an injection mold and an injection molding method for the heating assembly. The heating assembly comprises a heating body (1) and a base (2), wherein the heating body (1) comprises a heating circuit (11) and a heating body shell covering the heating circuit (11), and no gap is left at the contact position of the heating circuit (11) and the heating body shell; the lower part of the heating body (1) is fixedly held by the base (2), and no gap is left at the contact position of the heating body (1) and the base (2). The base (2) and the heating body (1) are injection-molded, and the heating circuit (11) and the heating body shell are injection-molded, so that the joint of the heating body (1) and the base (2) can be sealed, cigarette residues after smoking are prevented from permeating downwards, and the use performance of a cigarette utensil is improved.

Classes IPC  ?

• A24F 40/46 - Forme ou structure des moyens de chauffage électrique

Abrégé

A composite-type temperature raising and control integrated heating element (1) and a temperature control method. The heating element (1) comprises: a heating body (4), which is integrated by welding two different conductive materials at a welding point (3), wherein the heating element (1) is not provided with temperature measuring elements other than the heating body (4). The heating body (4) of the temperature raising and control integrated heating element (1) is formed by welding two conductive materials. When a high voltage is applied, the two conductive materials serve as the heating body (4) to generate heat; and when supply of the voltage is stopped, the two conductive materials serve as a thermocouple temperature measuring sensor to measure the temperature of the heating element (1). Compared to existing heating elements, the number of temperature measuring sensors is reduced, the fabrication process of the heating element (1) is simplified, the performance of the heating element (1) is improved, the roasting effect of cigarettes is improved, the production costs are reduced, and a better user experience is brought to consumers.

Classes IPC  ?

• A24F 40/40 - Détails de construction, p. ex. connexion des cartouches et des batteries
• A24F 40/46 - Forme ou structure des moyens de chauffage électrique

Abrégé

Disclosed are a ceramic heating body and an atomizer using same, belonging to the technical field of atomizers. The ceramic heating body comprises a microporous ceramic (1) and a metal hardware sheet (2), wherein the metal hardware sheet (2) is buried inside the microporous ceramic (1); the metal hardware sheet (2) is in a continuous circuitous structure inside the microporous ceramic (1); and a groove (101) is recessed towards the interior of the microporous ceramic (1) at the top of the microporous ceramic (1). Some e-liquid is pre-loaded in the groove (101), such that the e-liquid is closer to a heating wire, e-liquid atomized by the heating wire can be quickly supplemented, and the taste of the e-liquid entering a mouth after being atomized and passing through micropores of the microporous ceramic (1) feels purer than that of the e-liquid directly entering the mouth after being atomized by the heating wire.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

An electronic atomizer, comprising: a mouthpiece (110), wherein the mouthpiece (110) comprises a vaping port (112); a liquid cup (150), wherein an opening is formed at the lower end of the liquid cup (150), the upper end of the liquid cup is closed, a channel (152) in communication with the outside is established, one end of the channel (152) is communicated with the vaping port (112), a silicone support (170) is mounted at the other end of the channel (152) in a close fit mode, the upper end of the silicone support (170) is provided with an air outlet (172) that is communication with the channel (152), the silicone support (170) is further provided with a liquid through-hole (174), and the oil through-hole (174) and the air outlet (172) are mutually independent from each other; a heating body (190), wherein the upper end of the heating body (190) is provided with a liquid seepage groove (192), the liquid seepage groove (192) is in butt joint with the liquid through-hole (174), and the upper portion of the heating body (190) is mounted into the silicone support (170); a plastic support (210), wherein a mounting inner hole (212) is formed in the plastic support (210), the heating body (190) and the silicone support (170) are assembled and then mounted to the mounting inner hole (212), and the plastic support (210) and the silicone support (170) together form a ventilation port (200) that is in communication with a heating wire (194) at the lower end of the heating body (190) and the channel (152); a base (230) mounted to the opening at the lower end of the liquid cup (150); and an ejection pin (250) connected to the heating wire (194) of the heating body (190), wherein the ejection pin (250) is exposed on the lower surface of the base (230). The electronic atomizer has the advantages of being easy to carry, high in integration, and small in volume.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

A circumferentially heating type curing needle is adapted for an E-cigarette and comprises a curing needle head that is built-in with a heating element. The curing needle head is externally plated with a non-stick coating which is a polytetrafluoroethylene (PTFE) coating or a PTFE non-stick nano coating. The curing needle head is further provided with a fixed support and a ceramic base, the ceramic base is secured into the fixed support, and the curing needle head is fixedly inserted into the ceramic base. The E-cigarette is provided with the aforesaid circumferentially heating type curing needle.

Classes IPC  ?

• A24F 13/00 - Articles pour fumer les cigares ou cigarettes
• A24F 40/46 - Forme ou structure des moyens de chauffage électrique
• H05B 1/02 - Dispositions de commutation automatique spécialement adaptées aux appareils de chauffage
• H05B 3/06 - Éléments chauffants combinés constructivement avec des éléments d'accouplement ou avec des supports
• H05B 3/18 - Éléments chauffants caractérisés par la composition ou la nature des matériaux ou par la disposition du conducteur le conducteur étant enrobé dans un matériau isolant
• A24F 40/20 - Dispositifs utilisant des précurseurs inhalables solides

Abrégé

The present invention relates to an atomizer having a material storage function, comprising a suction nozzle assembly, an atomizing core assembly, and a battery rod assembly. The suction nozzle assembly is mounted on the upper end of the atomizing core assembly, and the battery rod assembly is mounted on the lower end of the atomizing core assembly; a storage box assembly is detachably mounted on the lower end of the battery rod assembly; the lower end of the battery rod assembly has a downwardly projecting outer wall, and a groove is formed in the inner surface of the outer wall; the storage box assembly is matched with the groove by means of a silica gel ring mounted on the side wall of the storage box assembly, so that assembly and disassembly between the storage box assembly and the battery rod assembly is completed in a plugging manner. By implementation of the present invention, a material to be heated can be conveniently stored, thereby meeting daily needs of users.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

The present invention relates to an atomizer and a mouthpiece assembly thereof. The mouthpiece assembly comprises: a mouthpiece, the mouthpiece being provided with an inhalation channel; and a hollow scoop, an upper end of the scoop communicating with outside air by means of an air inlet, and a lower end of the scoop communicating with a heating cavity of the atomizer, which is to say that the scoop simultaneously serves as an air passage pipe that provides outside air to the heating cavity; the inhalation channel communicates with the heating cavity of the atomizer, and outside airflow passes through the air inlet, the scoop, the heating cavity, and the inhalation channel in sequence to finally enter the mouth. Besides the mouthpiece assembly, the atomizer further comprises an atomization core assembly and a battery-stick assembly; the mouthpiece assembly is detachably mounted on one end of the atomization core assembly, the battery-stick assembly is mounted on the other end of the atomization core assembly, and the heating cavity for heating a material to be heated is provided in the atomization core assembly. By implementing the present invention, an atomizer that is more convenient to use can be obtained.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs
• A61M 11/00 - Pulvérisateurs ou vaporisateurs spécialement destinés à des usages médicaux

Abrégé

An atomizer, comprising a mouthpiece assembly, an atomizing core assembly, and a battery rod assembly, wherein the mouthpiece assembly is mounted at one end of the atomizing core assembly, the battery rod assembly is mounted at the other end, and the lower end of the atomizing core assembly and the upper end of the battery rod assembly are connected by means of magnetic attraction, and are detachably connected. The present atomizer is more convenient to use.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

The present invention relates to a vaporizer and a vaporizer heating structure; the heating structure comprises a heat conduction pipe; a space for placing a heating substance is formed in said heat conduction pipe; a flexible printed circuit board (FPC) wound on the outer wall of the heat conduction pipe, said FPC being electrically connected to a main circuit board of the vaporizer; an outer wrapping tube nested outside the heat conduction tube and the FPC, a heat insulation layer being provided between said outer wrapping tube and the FPC; an air inlet pipe sealingly connected to the lower end of the heat conduction pipe. In addition to the heating structure, the vaporizer also comprises a housing, a battery, and a main circuit board; the heating structure, the main circuit board, and the battery all are disposed in the housing, and the battery is electrically connected to the main circuit board. In implementing the present invention, a vaporizer and a vaporizer heating structure having strong heating power, high vapor output efficiency, and small volume can be obtained.

Classes IPC  ?

• F24H 1/18 - Appareils de chauffage à accumulation d'eau
• F24H 9/02 - EnveloppesCouvercles de protectionPanneaux décoratifs
• F24H 9/18 - Disposition ou montage des grilles ou des éléments chauffants
• F24H 9/20 - Disposition ou montage des dispositifs de commande ou de sécurité
• H05B 1/02 - Dispositions de commutation automatique spécialement adaptées aux appareils de chauffage
• H05B 3/00 - Chauffage par résistance ohmique

Abrégé

A novel heat generating body (400) and an atomiser, the novel heat generating body (400) comprising a ceramic body (410) and heat generating wires (430), a plurality of micro pores used for e-liquid infiltration being distributed in the ceramic body (410), heat generating wires (430) respectively corresponding to two electrodes extending outward at the bottom of the ceramic body (410), the heat generating wires (430) corresponding to the two electrodes being connected by means of auxiliary heat generating wires (450) arranged on the outer surface of the ceramic body (410), the auxiliary heat generating wires (450) being distributed on the outer surface of the bottom and the side wall of the ceramic body (410), and the auxiliary heat generating wires (450) being metal wires embedded in the outer surface of the bottom and the side wall of the ceramic body (410) or the auxiliary heat generating wires (450) being metal powder/metal wires printed on the outer surface of the bottom and the side wall of the ceramic body (410). The novel heat generating body (400) can implement a cotton-free atomising structure, simplifying the structure and increasing the reduction of e-liquid, such that the e-liquid heats fully to achieve a better atomising effect, improving the feeling of use.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

An atomizer (500), comprising an atomizer housing (510), an upper end of the atomizer (500) being open, and a side wall surface of the atomizer housing (510) having at least one vapor outlet opening (512); a glass container (530) used to contain a liquid mounted at an inner part of the atomizer housing (510), an upper end of the glass container (530) being open and overlapping with the upper end opening of the atomizer housing (510); a heating wire (550) mounted in the atomizer housing (510) and below the glass container (530); an atomizer cover (570) mounted at the open end of the atomizer housing (510). The present atomizer (500) can solve the problem of inadvertent liquid inhalation, and is also cleaner and more sanitary, causing liquid to be fully combusted, obtaining better atomization results and improving user experience.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

A heating element (10), comprising a ceramic body (100) and a heating wire (200). The ceramic body (100) comprises an upper portion (110) and a lower portion (130) which are integrally formed; several micropores used for e-liquid to penetrate are distributed on both the upper portion (110) and the lower portion (130); the outer shape of the upper portion (110) is adapted to the inner shape of an atomizer (400) for mounting same; the upper portion (110) has a recess (112) on one side; the shape of the recess (112) is adapted to the shape of an aerosol tube (402) of the atomizer; the lower portion (130) extends downward from the side of the upper portion (110) opposite to the recess (112); the heating wire (200) is mounted on the ceramic body (100); and the heating wire (200) extends out from the bottom of the lower portion (130). The heating element (10) can solve the problem of inhalation of e-liquid, and can fully heat the e-liquid to achieve a better atomization effect and improve the use experience.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs
• F24H 9/18 - Disposition ou montage des grilles ou des éléments chauffants
• H05B 3/02 - Chauffage par résistance ohmique Détails

Abrégé

A heating element including a ceramic body and a heating wire. The ceramic main body includes an upper portion and a lower portion. The upper portion and the lower portion are integrally formed. A plurality of micro-pores for oil penetration are distributed in the upper portion and the lower portion. A shape of a periphery of the upper portion is matched with a shape of an interior of an atomizer for mounting the upper portion. A side of the upper portion is provided with a notch. The shape of the notch is matched with the shape of an air flowing tube of the atomizer. The lower portion extends downward from the side of the upper portion opposite to the notch. The heating wire is mounted to the ceramic main body, and the heating wire extends outward from the bottom of the lower portion.

Classes IPC  ?

• A61M 11/04 - Pulvérisateurs ou vaporisateurs spécialement destinés à des usages médicaux agissant par pression de la vapeur des liquides à pulvériser ou vaporiser
• H05B 3/46 - Éléments chauffants ayant la forme de tiges ou de tubes non flexibles le conducteur chauffant monté sur une base isolante
• A24F 40/46 - Forme ou structure des moyens de chauffage électrique

Abrégé

An electronic cigarette, comprising a heating assembly. The heating assembly comprises a sword-shaped housing (10), and a heating and temperature control assembly (20) sleeved within an inner cavity (16) of the housing (10). The heating and temperature control assembly (20) comprises a metal heating element (21) and/or a temperature control component (22) located between the metal heating element (21) and the housing (10). The provision of the sword-shaped housing (10), the metal heating element (21) sleeved within the inner cavity (16) of the housing (10), and the temperature control component (22) located between the metal heating element (21) and the housing (10) achieves a large heating area and a simple structure.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

A ceramic heating element comprises: a flat or needle-shaped ceramic casing (10), a support frame (20) accommodated within the ceramic casing (10), and a heating wire (30) uniformly wound around the support frame (20), the interior of the support frame (20) being a hollow structure. An electronic cigarette comprises the ceramic heating element. The invention provides the flat or needle-shaped ceramic casing (10), the support frame (20) accommodated within the ceramic casing (10), and the heating wire (30) uniformly wound around the support frame (20) so as to form a heating element having structural simplicity, superior insulation, uniform heating, and operational convenience, and the electronic cigarette employing the heating element.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

An atomizer with an oil locking function includes a cigarette holder and an atomizer body provided with an oil chamber. An inner wall of the oil chamber is composed of a fixing component and a rotating component that are in a rotating fit. The fixing component is provided with an oil guiding hole and is connected to the cigarette holder. The rotating component includes a first rotation angle causing the oil locking hole and the oil guiding hole to be aligned with each other, and a second rotational angle causing the oil locking hole and the oil guiding hole to be mutually staggered from each other.

Classes IPC  ?

• A24F 40/42 - Cartouches ou contenants pour précurseurs inhalables
• F16J 15/324 - Agencements pour graissage ou refroidissement du joint d’étanchéité lui-même
• A24F 40/10 - Dispositifs utilisant des précurseurs inhalables liquides
• A24F 40/46 - Forme ou structure des moyens de chauffage électrique

Produits et services

Cigarette cases; Cigarette filters; Cigarettes; Cigarettes containing tobacco substitutes, not for medical purposes; Electronic cigarettes; Herbs for smoking; Lighters for smokers; Liquid nicotine solutions for use in electronic cigarettes; Oral vaporizers for smokers; Tobacco; Filter-tipped cigarettes; Smokers' mouthpieces for electronic cigarettes, cigars, cigarettes

Produits et services

Electronic cigarettes; Liquid solutions for use in electronic cigarettes; Cigarettes containing tobacco substitutes, not for medical purposes; Cigarettes; Cigarette tips; Cigarette cases; Mouthpieces for cigarette holders; Oral vaporizers for smokers; Lighters for smokers; Cigarette filters; Tobacco; Herbs for smoking.

Produits et services

Cigarette cases; Cigarette filters; Cigarettes; Cigarettes containing tobacco substitutes, not for medical purposes; Electronic cigarettes; Filter tips; Herbs for smoking; Lighters for smokers; Liquid nicotine solutions for use in electronic cigarettes; Oral vaporizers for smokers; Smokers' mouthpieces for electronic cigarettes, cigars and cigarettes; Tobacco; Tobacco pipes

Produits et services

(1) Cigarette cases; cigarette filters; cigarette tips; cigarettes; electronic cigarettes; herbs for smoking; herbs for use as tobacco substitutes; lighters for smokers; liquid solutions for use in electronic cigarettes; mouthpieces for cigarette holders; oral vaporizers for smokers; tobacco

Produits et services

electronic cigarettes; liquid solutions for use in electronic cigarettes; cigarettes containing tobacco substitutes, not for medical purposes; cigarettes; cigarette tips; cigarette cases; mouthpieces for cigarette holders; oral vaporizers for smokers; lighters for smokers; cigarette filters; Tobacco; Herbs for smoking.

Produits et services

Cigarette cases; Cigarette filters; Cigarettes; Cigarettes containing tobacco substitutes, not for medical purposes; Electronic cigarettes; Filter tips; Lighters for smokers; Liquid nicotine solutions for use in electronic cigarettes; Oral vaporizers for smokers; Smokers' mouthpieces for electronic cigarettes, cigars and cigarettes

Produits et services

(1) Cigarette cases; cigarette filters; cigarette tips; cigarettes; electronic cigarettes; herbs for use as tobacco substitutes; lighters for smokers; liquid solutions for use in electronic cigarettes; mouthpieces for cigarette holders; oral vaporizers for smokers

Produits et services

electronic cigarettes; liquid solutions for use in electronic cigarettes; cigarettes containing tobacco substitutes, not for medical purposes; cigarettes; cigarette tips; cigarette cases; mouthpieces for cigarette holders; oral vaporizers for smokers; lighters for smokers; cigarette filters.

Abrégé

A radiation-heated electronic cigarette cartridge and a radiation-heated separable electronic cigarette. The electronic cigarette cartridge comprises the following components: a housing (1); a hollow smoke generator (3) provided inside the housing (1); and a separation member (4) provided along an inner wall of a hollow cavity of the hollow smoke generator (3), the separation member can be in contact with or not in contact with the inner wall. The separable electronic cigarette comprises a heating element and a radiation-heated electronic cigarette cartridge which are separate but can be combined. Upon combining the heating element and the radiation-heated electronic cigarette cartridge, the heating element is inserted into the hollow cavity of the hollow smoke generator (3) without contacting an inner wall of the hollow smoke generator (3). Contactless radiant heating solves the problem of an e-liquid leaking from an electronic cigarette and the problem of flavor tainting through previous e-liquid residue. The invention has a simple structure and low costs.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Produits et services

Cigarette holders; Cigarettes; Electronic cigarettes; Liquid nicotine solutions for use in electronic cigarettes; Oral vaporizers for smokers; Smokers' mouthpieces for electronic cigarettes, cigars and cigarettes; Cigarette cases; Cigarette filters; Cigarettes containing tobacco substitutes, not for medical purposes; Lighters for smokers

Abrégé

Disclosed are a cartridge, a push-cartridge-type curing and heating assembly and an electronic cigarette. The cartridge comprises a tobacco cup (1), wherein cut tobacco is loaded inside the tobacco cup (1), and an insertion hole (11) for having a heating needle inserted therein is provided in the bottom of the tobacco cup (1). The push-cartridge-type curing and heating assembly comprises a curing and heating assembly body (2) with a heating needle assembly (20), wherein one end of the curing and heating assembly body (2) is provided with a cartridge insertion hole site (21), and the root portion of a heating needle of the heating needle assembly (20) is fixed at the bottom of the cartridge insertion hole site (21); and the above-mentioned cartridge is inserted into the cartridge insertion hole site (21), and the heating needle of the heating needle assembly (20) is inserted into the insertion hole (11). The above-mentioned cartridge or push-cartridge-type curing and heating assembly is provided in the electronic cigarette. The electronic cigarette has the advantages of uniform curing and heating, installation being simple and quick, the flavor of the cigarette being richer and more mellow, the tar and nicotine in the cigarette being reduced, being healthy and hygienic, being free of carbon deposition and being energy-saving and environmentally friendly.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

Disclosed is a push-cartridge-type curing electronic cigarette, comprising an electronic cigarette body (1), wherein the electronic cigarette body (1) is provided with a cartridge (2) inserted into and connected to same; and a slide groove is provided on one side of the electronic cigarette body (1). A cartridge-pushing assembly (3) is provided in the slide groove, and the cartridge-pushing assembly (3) comprises a slide button (31) and a slide bracket (32), wherein the slide button (31) is slidably disposed in the slide groove and is disposed outside the electronic cigarette body (1), the slide button (31) is fixedly connected to the slide bracket (32), and the top of the slide bracket (32) abuts against the bottom side of the cartridge (2). By means of using a replaceable cartridge, the cartridge can be quickly pushed out by means of the cartridge-pushing assembly so as to replace the cartridge, and same has the advantages of the replacement of a cartridge being quick, the structure being simple, and being easy to use.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

Disclosed are a circumferential heating-type curing needle for an electronic cigarette, and an electronic cigarette. The circumferential heating-type curing needle for an electronic cigarette comprises a curing needle (3) with an in-built heating element, wherein the curing needle (3) is externally coated with a non-stick coating, which non-stick coating is a Teflon non-stick coating or a Teflon non-stick nanometre coating, and the curing needle (3) is further provided with a fixing support (1) and a ceramic seat (2), the ceramic seat (2) being fixed in the fixing support (1), and the curing needle (3) being inserted into and fixed in the ceramic seat (2). The circumferential heating-type curing needle for an electronic cigarette is provided in the electronic cigarette. The electronic cigarette has the advantages of uniform curing and heating, simple and quick installation, the flavor of the cigarette being richer and more mellow, the tar and nicotine in the cigarette being reduced, being healthy and hygienic, being free of carbon deposition and being energy-saving and environmentally friendly.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Produits et services

(1) Cigarettes containing tobacco substitutes, not for medical purposes; electronic cigarettes; liquid solutions for use in electronic cigarettes; cigarettes; tobacco pipes; cigarette holders; cigar cases; oral vaporizers for smokers; tobacco; cigars; gas containers for cigar lighters; herbs for smoking.

Produits et services

Cigar cases; Cigarette holders; Cigarettes; Cigarettes containing tobacco substitutes, not for medical purposes; Cigars; Electronic cigarettes; Herbs for smoking; Liquefied gas cylinders for cigarette lighters; Liquid nicotine solutions for use in electronic cigarettes; Oral vaporizers for smokers; Tobacco; Tobacco pipes

Abrégé

Disclosed is an e-cigarette, including an e-cigarette atomizer and a battery component. The e-cigarette atomizer includes an atomizer body and a mouthpiece. An open e-liquid chamber is provided at one end of the atomizer body. An air guide tube extending outwards is disposed in the open e-liquid chamber. A lock hook is provided at an end portion of the air guide tube. The air guide tube is inserted in a locking sleeve of a pluggable locking type mouthpiece and is in interference fit with the locking sleeve. The lock hook abuts against an end face of a clamp spring bar of the pluggable locking type mouthpiece to lock and connect the atomizer body and the pluggable locking type mouthpiece. A plug connector of the pluggable locking type mouthpiece is inserted in an opening of the open e-liquid chamber and closes the open e-liquid chamber. The present invention has a mouthpiece plug-in lock structure, capable of rapidly sealing and locking the open e-liquid chamber by means of the mouthpiece, and has advantages of being convenient and easy to mount and having a simple structure.

Classes IPC  ?

• A24F 13/00 - Articles pour fumer les cigares ou cigarettes
• A24F 47/00 - Articles pour fumeurs non prévus ailleurs
• A24F 7/02 - Bouquins pour pipesBouquins pour fume-cigares ou fume-cigarettes à raccords amovibles

Produits et services

Cigar cases; Cigarette holders; Cigarettes; Cigarettes containing tobacco substitutes, not for medical purposes; Cigars; Electronic cigarettes; Herbs for smoking; Liquid nicotine solutions for use in electronic cigarettes; Oral vaporizers for smokers; Tobacco; Tobacco pipes; Liquefied gas cylinders for cigarette lighters

Produits et services

(1) Cigarette cases; cigarette filters; cigarette tips; cigarettes; electronic cigarettes; electronic cigarettes for use as an alternative to traditional cigarettes; gas containers for cigar lighters; lighters for smokers; liquid solutions for use in electronic cigarettes; tobacco pipes

Produits et services

(1) Cigar cases; cigarette cases; cigarette tips; cigarettes; cigars; electronic cigarettes; gas containers for cigar lighters; herbs for smoking; lighters for smokers; liquid solutions for use in electronic cigarettes; mentholated pipes; oral vaporizers for smokers; tobacco; tobacco pipes (2) Pipes for smoking mentholated tobacco substitutes

Produits et services

cigarettes containing tobacco substitutes, not for medical purposes; electronic cigarettes; liquid solutions for use in electronic cigarettes; cigarettes; tobacco pipes; cigarette holders; cigar cases; oral vaporizers for smokers; tobacco; cigars; gas containers for cigar lighters; herbs for smoking.

Abrégé

An electronic cigarette sealing piece, a liquid container and an electronic cigarette are provided. The electronic cigarette sealing piece includes a silicone substrate and a Teflon coating layer coated on a surface of the silicone substrate. The liquid container includes a liquid container main body provided with a liquid adding opening thereon, the liquid adding opening is provided with the electronic cigarette sealing piece for adding liquid by injection, the liquid container main body seals the liquid adding opening with the electronic cigarette sealing piece for adding liquid by injection, and the Teflon coating layer of the electronic cigarette sealing piece for adding liquid by injection is provided at an inner side of the liquid adding opening. The electronic cigarette includes an electronic cigarette main body having the liquid container.

Classes IPC  ?

• A24F 13/00 - Articles pour fumer les cigares ou cigarettes
• B65D 51/00 - Fermetures non prévues ailleurs
• A24F 47/00 - Articles pour fumeurs non prévus ailleurs
• F16L 15/04 - Raccords avec filetageFormes des filetages pour ces raccords avec des joints d'étanchéité supplémentaires

Abrégé

Shown is an e-cigarette. The e-cigarette includes an atomizer and a battery rod component that are connected to each other. The atomizer includes a mouthpiece, an atomization component, and an e-liquid vial component. The mouthpiece is connected to the atomization component by means of the e-liquid vial component. The e-liquid vial component includes an e-liquid tube having an e-liquid chamber, an e-liquid isolation sheet is disposed inside the e-liquid tube at the end of the e-liquid chamber, a recess is disposed at the inner side of the e-liquid isolation sheet, and a gasket is sandwiched between the e-liquid isolation sheet and the e-liquid tube. A communication hole is provided on the gasket. The gasket divides the e-liquid chamber and the recess into two cavities that are different in size and are communicated by means of the communication hole. An e-liquid guide rope is inserted in the e-liquid isolation sheet, and the e-liquid guide rope is inserted in the recess of the e-liquid isolation sheet. The present invention has advantages of being capable of avoiding e-liquid leakage caused by violent shaking of the e-cigarette, having a good e-liquid leakage-proof effect, a simple structure, and a low cost, and being convenient to assemble.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs
• B65D 43/02 - Couvercles ou chapeaux amovibles

Abrégé

Disclosed are a glass-based heating element for use in an electronic cigarette, an atomizer of an electronic cigarette, and an electronic cigarette. The glass-based heating element for use in an electronic cigarette comprises a glass base (1), with one side of the glass base (1) being a heating face for heating cigarette oil, tobacco or tobacco paste of an electronic cigarette and the other side being fixedly adhered with a long strip-like heating body (2) provided in a bent manner. The atomizer of an electronic cigarette comprises an atomizer body, the glass-based heating element for use in an electronic cigarette being provided therein. The electronic cigarette comprises an atomizer and a battery rod connected to each other, wherein the atomizer comprises an atomizer body, and the glass-based heating element for use in an electronic cigarette is provided in the atomizer body. The glass-based heating element for use in an electronic cigarette has the advantages of an environmentally friendly heating function, a faster heating speed, the amount of smoke being great, no burnt smell, a super-thin thickness, a small volume, and an elegant structure.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

An electronic cigarette case with magnetic attraction type charging function and an electronic cigarette therewith have the advantages of good user experience in charging, stable and reliable charging connections, convenience and quickness in use and a simple structure. The electronic cigarette case comprises a charging base body, a copper sheet arranged between an annular magnet and a magnetic attraction type charging base in a case body, an insulating ejector pin base inserted into the annular magnet, and an elastic charging ejector pin inserted into the insulating ejector pin base. An electronic cigarette includes an atomizer assembly and a battery rod assembly provided with a magnetic attraction type charging assembly including an annular iron piece. A power supply ejector pin, an annular iron piece and an electronic cigarette battery are respectively connected with an electronic cigarette microphone of the electronic cigarette.

Classes IPC  ?

• A24F 15/18 - Étuis ou boîtes spécialement adaptés aux cigares, aux cigarettes, aux dispositifs permettant de fumer artificiellement ou aux cigarettes à cet effet de poche combinés avec d'autres objets
• H02J 7/00 - Circuits pour la charge ou la dépolarisation des batteries ou pour alimenter des charges par des batteries
• A24F 47/00 - Articles pour fumeurs non prévus ailleurs
• A24F 15/20 - Étuis ou boîtes spécialement adaptés aux cigares, aux cigarettes, aux dispositifs permettant de fumer artificiellement ou aux cigarettes à cet effet à compartiments distincts pour chaque cigare ou cigarette
• B65D 43/16 - Couvercles ou chapeaux inamovibles s'ouvrant à charnières vers le haut ou vers le bas
• B65D 85/00 - Réceptacles, éléments d'emballage ou paquets spécialement adaptés à des objets ou à des matériaux particuliers
• H05B 3/12 - Éléments chauffants caractérisés par la composition ou la nature des matériaux ou par la disposition du conducteur caractérisés par la composition ou la nature du matériau conducteur

Abrégé

Disclosed is an electronic cigarette atomizer with a tobacco oil adjustment function, comprising a tobacco oil pipe (1) and an atomizer body (2) rotatably connected with each other, wherein a sleeve (10) is inserted into the tobacco oil pipe (1), the sleeve (10) has the ends thereof closed and is provided with a first opening (101) on a side wall thereof, a tube-shaped inner sleeve plug (102) is fixed inside the sleeve (10), and a second opening (103) is provided on the side of the inner sleeve plug (102) close to the first opening (101); and an insertion pipe (20) with an oil guiding rope (201) therein is provided on the atomizer body (2), the insertion pipe (20) has the ends thereof closed and is provided with a third opening (202) on a side wall thereof, and the insertion pipe (20) is inserted into the inner sleeve plug (102) of the sleeve (10). The electronic cigarette atomizer can avoid the drying up or leakage of tobacco oil during transportation or storage before users receive the electronic cigarette, can adjust the supply of tobacco oil to satisfy the desired smoke volume and taste of users, and has the advantages of firmness and reliability, rapid assembly, steady and smooth connection, and a simple structure.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

Disclosed in the present utility model are an electronic cigarette sealing piece for adding liquid by injection, a liquid container and an electronic cigarette. The electronic cigarette sealing piece for adding liquid by injection (10) comprises a silicone substrate (1) and a Teflon coating layer (2) coated on a surface of the silicone substrate (1), the silicone substrate (1) having a thickness of 0.8-1.5 mm and the Teflon coating layer (2) having a thickness of 0.05-0.2 mm; the liquid container (30) comprises a liquid container main body (3) provided with a liquid adding opening (31) thereon, the liquid adding opening (31) being provided with the electronic cigarette sealing piece for adding liquid by injection(10), the liquid container main body (3) closing the liquid adding opening (31) by the electronic cigarette sealing piece for adding liquid by injection (10), and the Teflon coating layer (2) of the electronic cigarette sealing piece for adding liquid by injection (10) being provided at an inner side of the liquid adding opening (31); the electronic cigarette comprises an electronic cigarette main body (4) having the liquid container (30). The present utility model is oil-tight and easy to manufacture and assemble, and also has a simple structure and low production costs.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

A baking type electronic cigarette with a flavor adjusting function, comprising an outer casing (1) provided with a cigarette nozzle (2). A baking unit (3), an oil cup (4), a battery (5) and a control unit (6) are sequentially arranged in the outer casing (1). The baking unit (3) comprises an electric heating baking cup (31), the two ends of the electric heating baking cup (31) are provided with openings. The opening end of the oil cup (4) is provided with an atomizer (41). One end of the electric heating baking cup (31) is communicated with the cigarette nozzle (2), and the other end is communicated with the atomizer (41). The outer wall of the electric heating baking cup (31) is provided with an electric heating sheet. The electric heating sheet of the electric heating baking cup (31), an electric heating wire of the atomizer (41) and the battery (5) are respectively connected with the control unit (6). The uniformity and shortage of smoke can be balanced when the ratio of smoke amount is not uniform or not enough during baking, different cigarette flavors can be adjusted according to the taste of a smoker, and the freedom of selection can be provided for the smoker, thus the optimum taste is achieved.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs

Abrégé

An electronic cigarette case and an electronic cigarette both with a magnetic attraction type charging function. A magnetic attraction type charging base (14) is arranged in a case body (1) of the electronic cigarette case, a charging base body (141) of the magnetic attraction type charging base (14) is provided with a splicing inner hole (142) aligned with a jack (11), an annular magnet (143) is arranged in the splicing inner hole (142), a copper sheet (144) is arranged between the annular magnet (143) and the magnetic attraction type charging base (14), an insulating ejector pin base (145) is inserted into the annular magnet (143), a charging elastic ejector pin (146) is inserted into the insulating ejector pin base (145), and the charging elastic ejector pin (146), the copper sheet (144) and a cigarette case battery (13) are respectively connected with a circuit assembly (12). The electronic cigarette comprises an atomizer assembly (3) and a battery rod assembly (4), the battery rod assembly (4) is provided with a magnetic attraction type charging assembly (44) comprising an annular iron piece (441), a light transmitting isolating piece (442) is inserted into the annular iron piece (441), a power supply ejector pin (443) is inserted into the light transmitting isolating piece (442), and the power supply ejector pin (443), the annular iron piece (441) and an electronic cigarette battery (41) are respectively connected with a microphone (432) of the electronic cigarette. The electronic cigarette case and the electronic cigarette have the advantages of good user experience in charging, stable and reliable charging connections, convenience and quickness in use and a simple structure.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs
• H02J 7/00 - Circuits pour la charge ou la dépolarisation des batteries ou pour alimenter des charges par des batteries

Produits et services

Cigarette cases; Cigarette filters; Cigarettes; Cigarettes containing tobacco substitutes not for medical purposes; Electronic cigarettes; Filter tips; Lighters for smokers; Liquefied gas cylinders for cigarette lighters; Tobacco; Tobacco pipes

Abrégé

A surface heated atomizer and an electronic cigarette with the atomizer. An atomizer (1) comprises a base (11) and a heating body (12) connected to each other. The heating body (12) comprises a ceramic seat (121), a receiving groove (122) used for placing solid cigarette cream or tobacco paste is provided inside the ceramic seat (121), and a nano-titanium metal heating material film (123) is wrapped outside the ceramic seat (121). The electronic cigarette comprises an atomizer assembly (2) and a shank assembly (3) connected to each other. The atomizer assembly (2) comprises a mouthpiece (21), an atomizer pipe (22), a first electrode connecting assembly (23), and the foregoing atomizer (1) connected sequentially. The shank assembly (3) comprises a battery pipe (31) and a second electrode connecting assembly (32), a battery (33), and a control board (34) separately disposed inside the battery pipe (31). The second electrode connecting assembly (32) is connected to the battery (33) through the control board (34). A button switch (4) for being connected to the control board (34) is provided on the battery pipe (31). The first electrode connecting assembly (23) is connected to and communicates with the second electrode connecting assembly (32). The atomizer has a large heating area, a large amount of atomized cigarette cream, no carbon sediment, and a long service life, and is energy saving and environmentally friendly.

Classes IPC  ?

• A24F 47/00 - Articles pour fumeurs non prévus ailleurs
