Electric motors; asynchronous motors; synchronous motors;
linear motors; reluctance motors; rotor disk motors;
eddy-current motors; ultrasonic motors; electrical lifting
cylinders; motors with integrated inverter; compact drives;
control units for machinery and motors; geared motors;
gearboxes; torque converters; reduction gears (machine
parts); servo gears; right-angle gear units; variable-speed
gear units; industrial gear units; electric drives for
electrified monorails; electric drives for electrified
railways; gear wheels for machines; electric generators;
wind generators, namely for electricity charging stations;
mechanical flywheel electrical energy generators; actuators;
linear actuators; machine parts, namely controllers;
housings for electric motors and reduction gears; machine
parts, namely adapters; machine parts, namely stators;
machine parts, namely oscillating cranks; ventilators for
machinery; cooling units for motors; machine parts, namely
bearings; couplings for machines; brakes for machines;
magnetic brakes for machines; eddy-current brakes for
machines; machine magnets [parts of machine brakes]; drive
shafts (for machines); parts of all aforesaid goods,
included in this class (other than for land vehicles). Apparatus and instruments for conducting, switching,
converting, storing, regulating and/or controlling
electricity; inverters [electricity]; current inverters;
drive inverters; current converters; voltage converters;
frequency converters; waveguides; slotted waveguides;
electric coils; current coils for inductive power supply;
regenerative power supply units; electronic controls;
programmable logic controls; electric cables; electric
connectors; electric wires; distributors for electric energy
and/or information; electric facilities for the remote
control of industrial operations; electric connection parts;
electronic display panels; LCD displays; LED displays;
operating terminals for controlling machines; remote
controls; electronic and electro-technical measuring
instruments; rotary speed sensors; encoders, namely
measuring transducers; incremental encoders; integrated
circuits; semiconductors; electric and electronic control
apparatus; sound sensors; oil level sensors; temperature
sensors; structure-borne sound sensors; electronic
publications (downloadable); electronic positioning
controls; computer software for controlling machines;
computer software for controlling industrial processes;
computer software for monitoring industrial processes;
computer software for planning electric drives; computer
software for planning industrial facilities; software for
data communication; software protocols for data
communication (software); data bus protocols (software);
safety-related data bus protocols (software); parameter
boxes (machine-readable data collections); fiber optic
couplers; electro-optical converters; data bus converters;
data bus cables; data bus plugs; field bus converters;
fieldbus cables; fieldbus plugs; rating plates in the nature
of electronic signs, for electric drives; personal
computers; laptop computers; personal computers for use in
industry; wireless transmitting or receiving devices;
wireless local area network [WLAN] devices; wireless local
area network devices; current transformers; devices for
inductive contactless supplying and/or charging of electric
drives; electric storage and electric charging devices for
charging of electric vehicles with electric energy, namely
line conductors, pick-up coils, current converters,
antennas, receivers, transceivers, charging mats; electric
charging devices for charging of electric drives, electric
storage apparatus and electric vehicles; energy storage
supercapacitors and batteries; batteries; accumulators;
capacitors; capacitor modules consisting of a capacitor, a
housing and a circuit board; charging cables; charging
plugs; electric charging stations for electric vehicles and
parts and accessories thereof; solar cells, in particular
for electric charging stations; navigation devices for
vehicles; navigation instruments and accessories thereof;
navigation instruments for industrial use; bus bars;
acoustic imaging cameras; parts of all aforesaid goods,
included in this class.
