A sintering furnace for sintering of green compacts includes a retort, an inlet for furnace atmosphere gas at one end of the retort, and a stack of sintering trays having central openings arranged in an interior of the retort. Neighboring sintering trays of the stack are spaced apart from one another whereby an interspace is provided between the neighboring sintering trays. The interspace is enclosed by a peripheral wall provided with distributed holes for transfer of the furnace atmosphere gas between the interspace interior of the peripheral wall and the space exterior to the peripheral wall. A ratio of the area of each individual central opening to the total area of the distributed holes between each individual pair of neighboring sintering trays ranges from 1:10 to 10:1. An outlet for withdrawal of the furnace atmosphere gas is located an end of the retort opposite the inlet end.
B22F 3/24 - Traitement ultérieur des pièces ou objets
C22C 29/06 - Alliages à base de carbures, oxydes, borures, nitrures ou siliciures, p. ex. cermets, ou d'autres composés métalliques, p. ex. oxynitrures, sulfures à base de carbures ou de carbonitrures à base de carbures mais ne contenant pas d'autres composés métalliques
C22C 29/08 - Alliages à base de carbures, oxydes, borures, nitrures ou siliciures, p. ex. cermets, ou d'autres composés métalliques, p. ex. oxynitrures, sulfures à base de carbures ou de carbonitrures à base de carbures mais ne contenant pas d'autres composés métalliques à base de carbure de tungstène
F27D 5/00 - Supports, grilles ou appareillage analogue pour la charge à l'intérieur du four
F27D 11/00 - Aménagement des éléments pour le chauffage électrique dans ou sur les fours
F27D 17/17 - Dispositions pour l’utilisation de la chaleur perdue pour le préchauffage de fluides, p.ex. d’air ou de gaz
A milling tool body for a milling tool includes an axial front end surface, an axial rear end surface, a peripheral mantle surface extending between the axial front end surface and the axial rear end surface, a front end, a rear end being configured for attachment of the milling tool to a machine, at least two insert seats and associated chip pocket being entirely provided in the front end. A cooling duct system is extends from at least one coolant inlet arranged in a first ring-shaped section of the peripheral mantle surface to at least one coolant outlet arranged in a second ring-shaped section of the peripheral mantle surface. The first and the second ring-shaped sections are flanked by sealing surfaces formed as surfaces of revolution, preferably as circular cylindrical surfaces.
A tool system comprising a tool body (2) of a rotary cutting tool and a closure element (60), the tool body being provided with: - insert pockets (10); - a coolant supply recess (30); - first coolant channels (31) for conveying coolant to a respective first set (40) of coolant discharge channels and having a respective inlet (31a) that opens into the coolant supply recess; and - second coolant channels (32) for conveying coolant to a respective second set (50) of coolant discharge channels and having a respective inlet (32a) that opens into the coolant supply recess. Coolant is injectable into each individual insert pocket through one first set (40) of coolant discharge channels and one second set (50) of coolant discharge channels. The closure element (60) is settable in a closing position in the coolant supply recess in order to block the inlets (32a) of the second coolant channels while leaving the inlets (31a) of the first coolant channels unblocked.
A drill point (1) for metal cutting comprising a body, which body has central longitudinal axis extending rearward from the front end and is rotatable around the central longitudinal axis (3) in a direction of rotation (2). The body comprises one or more cutting structures. Each cutting structure comprises a cutting edge (6), which comprises a radially inner cutting edge (9) and a radially outer cutting edge (10); a chip flute (7); and a thinning surface (8), which extends axially forward and radially inward from the chip flute (7). The thinning surface (8) comprises an exit opening (20) for discharging cutting fluid, which exit opening is delimited by an opening edge consisting of a radially inner opening edge (21) and a radially outer opening edge (22); a secondary thinning rake surface (17), which, on a rotationally leading side of a thinning bottom (16), extends radially outward from the thinning bottom (16) and comprises at least a radially inner portion of the inner opening edge (21); a thinning main surface (18), which extends radially inward toward the secondary thinning rake surface (17) and comprises the outer opening edge (22). As seen in a cross section, a secondary tangent (25) is a tangent to the secondary thinning rake surface (17) at the inner opening edge (21), wherein the secondary tangent (25) is rotationally rearward of the outer opening edge (22).
A system for controlling a cutting tool during a cutting operation includes a sequence of operation steps, each operation step resulting in an operation condition. The system includes a control unit operatively connected to the tool, and at least one sensor operatively connected to the control unit, the control unit being configured to compare a measured value of the operation condition for a current operation step with an expected value of the operation condition for the current operation step and determining a difference therebetween, and, based on this difference, determine an adjusted expected value of the operation condition for the operation steps subsequent to the current operation step. The control unit is further configured to determine if the adjusted expected value of the operation step is higher than a predetermined operation condition threshold value, and, if so, reducing a parameter value of the cutting data parameter for the operation step.
G05B 19/18 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique
B23B 27/16 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier à éléments tranchants interchangeables, p. ex. pouvant être fixés par des brides
cc in the cemented carbide ranges from 9.0 to 11.5 kA/m, wherein all wt% and vol% values are based on the total weight or volume of the cemented carbide; and a coating adhered to the substrate.
C22C 29/08 - Alliages à base de carbures, oxydes, borures, nitrures ou siliciures, p. ex. cermets, ou d'autres composés métalliques, p. ex. oxynitrures, sulfures à base de carbures ou de carbonitrures à base de carbures mais ne contenant pas d'autres composés métalliques à base de carbure de tungstène
C23C 14/06 - Revêtement par évaporation sous vide, pulvérisation cathodique ou implantation d'ions du matériau composant le revêtement caractérisé par le matériau de revêtement
C23C 14/32 - Évaporation sous vide par explosionÉvaporation sous vide par évaporation suivie d'une ionisation des vapeurs
C23C 28/04 - Revêtements uniquement de matériaux inorganiques non métalliques
B22F 7/06 - Fabrication de couches composites, de pièces ou d'objets à base de poudres métalliques, par frittage avec ou sans compactage de pièces ou objets composés de parties différentes, p. ex. pour former des outils à embouts rapportés
C22C 30/00 - Alliages contenant moins de 50% en poids de chaque constituant
A double-sided cutting insert for use in milling with quadratic basic shape and eight different working positions. The cutting insert (1) comprises a peripheral surface (10), which extends around the cutting insert between first and second major faces (2, 3) and has four main side faces (11a-11d). One main cutting edge and one surface-wiping cutting edge are formed at an intersection between each main side face and the first major face (2) and at an intersection between each main side face and the second major face (3). Each main side face comprises a planar side abutment surface (13, 14), which extends between two corner side faces (12) of the cutting insert, and two inclined clearance surfaces (40, 50, 60, 70) located along and on opposite sides of the side abutment surface (13, 14), each clearance surface being convexly curved as seen in any plane that is perpendicular to a centre axis (C) of the cutting insert and extends across any part of the clearance surface.
A method for repairing a cutting tool component including a damaged includes the step of removing the damaged portion by machining the cutting tool component into an interim component having a machined surface. The machined surface includes a build surface having a second outer boundary of a pre-determined shape, and a transition surface surrounding the build surface. The method further includes the steps of placing the interim component in an additive manufacturing device; determining a position and an orientation of the second outer boundary; and additively manufacturing a replacement portion on the build surface.
The present invention relates to a milling tool for metal cutting comprising a body with a cutting head. The cutting head comprises a plurality of radially protruding and axially extending teeth, wherein each tooth of the plurality teeth comprises a rake surface, a clearance surface, and a cutting edge. The cutting edge, at an intersection of the rake surface with the clearance surface, extends axially rearward from a radially outer region at the front end. The cutting edge is continuous, and wave-shaped, and comprises alternating radially outer crest cutting edges and radially inner trough cutting edges. The clearance surface comprises a primary clearance surface, and a plurality of stabilizing clearance surfaces. Each of the plurality of stabilizing clearances surfaces is located rotationally directly behind a respective one of the crest cutting edge and has a radial stabilizing clearance angle β of 0,5° - 2°. The primary clearance surface is located rotationally directly behind each of the trough cutting edges and has a radial primary clearance angle α which is larger than the radial stabilizing clearance angle β.
The invention relates to a cutting tool comprising a substrate of a cemented carbide comprising WC grains, eta phase grains and Cr and at least one metallic binder selected from Co, Ni, and Fe, said metallic binder being present in an amount ranging from 6 to 22 wt%; wherein the weight ratio of Cr to said at least one metallic binder ranges from 0.13 to 0.30, and wherein the eta phase content ranges from 1 to 10 vol%.
C22C 29/06 - Alliages à base de carbures, oxydes, borures, nitrures ou siliciures, p. ex. cermets, ou d'autres composés métalliques, p. ex. oxynitrures, sulfures à base de carbures ou de carbonitrures à base de carbures mais ne contenant pas d'autres composés métalliques
C22C 29/02 - Alliages à base de carbures, oxydes, borures, nitrures ou siliciures, p. ex. cermets, ou d'autres composés métalliques, p. ex. oxynitrures, sulfures à base de carbures ou de carbonitrures
C22C 29/08 - Alliages à base de carbures, oxydes, borures, nitrures ou siliciures, p. ex. cermets, ou d'autres composés métalliques, p. ex. oxynitrures, sulfures à base de carbures ou de carbonitrures à base de carbures mais ne contenant pas d'autres composés métalliques à base de carbure de tungstène
C22C 1/051 - Fabrication de métaux durs à base de borures, de carbures, de nitrures, d'oxydes ou de siliciuresPréparation du mélange de poudres utilisé comme matière première à cet effet
A cutting tool comprising a tool body (2) with at least one insert seat (10), an indexable first cutting insert with round basic shape and an indexable second cutting insert (30') with round basic shape releasably mountable, one at a time, in the insert seat. At least one rotation-preventing surface (20a, 20b) is provided in the insert seat (10) and configured to co-operate with planar indexing surfaces on the first cutting insert to prevent it from rotating in the insert seat. A rotation-preventing member (22) is releasably mountable in the insert seat (10) and configured to co-operate with indexing recesses (42) on the second cutting insert (30') to prevent it from rotating in the insert seat. The rotation-preventing member (22) is removable from the insert seat to allow the first cutting insert to be mounted in the insert seat without being obstructed by the rotation-preventing member.
Cassette (100) for a tool seat (210) of a cutting tool (800) for chip removing machining, the cassette (100) comprising an insert seat (114) for a cutting insert (300), a bottom surface (104) having mirror symmetry with respect to a bisecting plane P arranged in a longitudinal cross-section of the cassette (100), and bisecting the insert seat (114),, comprising a first cassette hole (116) for a first fastening member (400) and a second cassette hole (120) for a second fastening member (500) for fastening the cassette in the tool seat (210). The bottom surface (104) comprises alternating parallel ridges (126) and grooves (124) extending in the direction of the longitudinal axis A. The alternating parallel ridges (126) and grooves (124) are configured to mate with alternating parallel grooves (216) and ridges (214) arranged in the tool seat (210).
B23B 29/04 - Porte-outils pour un seul outil de coupe
B23B 27/10 - Outils de coupe avec une disposition particulière pour le refroidissement
B23B 27/16 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier à éléments tranchants interchangeables, p. ex. pouvant être fixés par des brides
A boring head arranged for holding a boring tool for metal cutting includes a main body having a support surface and a scale surface. The boring head further includes a piston including a boring tool interface for fixedly carrying the boring tool. The piston is movably arranged in the main body along the positioning axis (y), and a micrometer screw. The micrometer screw is arranged in the main body and coupled to the piston, such that, when the micrometer screw is rotated, the piston is moved along the positioning axis to one of the protracted positions or the retracted position. The micrometer screw has a head abutting against the support surface. The head includes a radially outer head surface provided with first graduation marks. The scale surface is provided with second graduation marks aligned with the first graduation marks to provide a reading of the axial position of the piston.
A toolholder for use with a cutting element in a cutting process is provided. The toolholder includes at least one sensor arranged for detecting an environmental condition, and a control unit operatively connected to the at least one sensor. The control unit includes a crossbar array of resistive memory devices and a power source operatively connected to the crossbar array. The crossbar array includes a neural network stored thereon, the neural network being arranged to determine a condition of the cutting element or of the cutting process based on the environmental condition detected by the at least one sensor. A cutting tool and a cutting tool assembly is also provided.
The present invention relates to a boring head for metal cutting, which has a main axis in a diameter direction (y), and an extension in a height direction (z), which height direction (z) is perpendicular to the main axis, and comprises a support unit (3), a tool unit (4), and a locking mechanism. The support unit (3) extends axially inward along the main axis from an axially outer end, and comprises a support interface (8) at the outer end. The tool unit (4) extends axially outward along the main axis from an axially inner end, and comprises a tool interface (12) at the inner end. The tool unit (4) is releasably secured to the support unit (3) by the locking mechanisms forcing the tool interface (12) against the support interface (8). The support interface (8) comprises a pair of support guide surfaces (16), which extend in the height direction (z) and face in opposite directions. The tool interface (12) comprises a pair of tool guide surfaces (22), which extend in the height direction (z) and face in opposite directions toward a respective one of the support guide surfaces (16), wherein the tool unit (4) is movably arranged in the height direction (z) by the tool guide surfaces (22) sliding against a respective one of the support guide surfaces (16).
A double-sided negative cutting insert for use in milling with eight working positions is provided. A peripheral surface extends around the cutting insert and has four main side faces including first and second main side faces arranged opposite each other on opposite sides of the insert and third and fourth main side faces arranged opposite each other on two other opposite sides of the insert. The cutting insert has eight sets of cutting edges, each including a main cutting edge, a corner cutting edge and a minor cutting edge. Two flat side surfaces that are inclined towards each other are provided on each one of the first and second main side faces. The main cutting edges are arranged along a respective one of the side surfaces on the first and second main side faces and all minor cutting edges are arranged along the third and fourth main side faces.
A cutting tool, system, method and computer program product for increasing traceability of at least a first cutting edge of a cutting tool. The method includes detecting at least a first identification marker on the cutting tool, reading the at least first identification marker, decoding the at least first identification marker to determine at least a first cutting edge information data included in the machine readable code of the at least first identification marker, generating a first cutting tool identification data based on at least the at least first cutting edge information data, and storing at least any of the at least first cutting tool identification data and the at least first cutting edge information data in a memory.
B23B 27/14 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier
B23B 27/16 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier à éléments tranchants interchangeables, p. ex. pouvant être fixés par des brides
B23C 5/20 - Outils de fraisage caractérisés par des particularités physiques autres que la forme à taillants ou dents amovibles
B23Q 17/09 - Agencements sur les machines-outils pour indiquer ou mesurer pour indiquer ou mesurer la pression de coupe ou l'état de l'outil de coupe, p. ex. aptitude à la coupe, charge sur l'outil
A face milling cutter includes a tool body, at least two cutting inserts for forming a milled flat surface on a workpiece and mounted in a respective insert seat in the tool body, each cutting insert having a secondary cutting edge that constitutes the axially foremost cutting edge of the cutting insert, and several burnishing assemblies with a respective spring-loaded burnishing element arranged in the tool body. The number of the burnishing assemblies in the tool body is the same as the number of insert seats, wherein the insert seats and the burnishing assemblies are alternately arranged in the circumferential direction of the tool body such that each one of the insert seats is followed by an associated one of the burnishing assemblies as seen in the intended direction of rotation of the tool body.
23233 layer ranges from 0.3 to 4 µm wherein the thickness of the second Ti(C,N) layer ranges from 2 to 12 µm; and wherein the layers of i), ii), and iii) are arranged in the mentioned order counted from the substrate.
C23C 30/00 - Revêtement avec des matériaux métalliques, caractérisé uniquement par la composition du matériau métallique, c.-à-d. non caractérisé par le procédé de revêtement
C23C 16/08 - Revêtement chimique par décomposition de composés gazeux, ne laissant pas de produits de réaction du matériau de la surface dans le revêtement, c.-à-d. procédés de dépôt chimique en phase vapeur [CVD] caractérisé par le dépôt d'un matériau métallique à partir d'halogénures métalliques
The present invention relates to a press tool for forming, by compacting a powder, a cutting insert green body (8). The press tool comprises a punch device (3), which comprises an axially extending front section with a front end at a cavity, which front section is operable to assume a start orientation and a target orientation, and an axially extending rear section, which is connected with and located axially rearward of the front section. The press tool further comprises a movably arranged spacer element (10), wherein the spacer element (10) is operable to translate from a start position to a target position, and an arm member (17), which extends axially along the rear section (14) at a distance therefrom. A joint unit (18), which connects the arm member (17) and the rear section such that the distance from the rear section (14) to the arm member (17), in a position axially in front of the joint unit (18), is adjustable. The spacer element (10) is arranged and configured to engage the arm member (17) via an arm contact point (19) and the rear section via a rear contact point (20). When the spacer element (10) is in the start position, as seen in an axial projection on an axial plane, the distance from the arm contact point (19) to the rear contact point (20) is a rear start distance, whereby the joint unit (18) is in a start state and the front section (11) is in the start orientation. When the spacer element (10) is in the target position, as seen in an axial projection on an axial plane, the distance from the arm contact point (19) to the rear contact point (20) is a rear target distance (24), whereby the joint unit (18) is in a target state biased toward the start state and the front section (11) is in the target orientation.
B28B 3/02 - Fabrication d'objets façonnés en utilisant des pressesPresses spécialement adaptées à ce travail dans laquelle un poinçon exerce une pression sur le matériau dans une cavité de moulagePoinçons de forme particulière
B30B 11/02 - Presses spécialement adaptées à la fabrication d'objets à partir d'un matériau en grains ou à l'état plastique, p. ex. presses à briquettes ou presses à tablettes utilisant un pilon exerçant une pression sur le matériau dans une cavité de moulage
B30B 11/00 - Presses spécialement adaptées à la fabrication d'objets à partir d'un matériau en grains ou à l'état plastique, p. ex. presses à briquettes ou presses à tablettes
B30B 15/02 - MatricesGarnitures ou montures appropriéesMoules
B22F 5/00 - Fabrication de pièces ou d'objets à partir de poudres métalliques caractérisée par la forme particulière du produit à réaliser
B28B 3/08 - Fabrication d'objets façonnés en utilisant des pressesPresses spécialement adaptées à ce travail dans laquelle un poinçon exerce une pression sur le matériau dans une cavité de moulagePoinçons de forme particulière avec plusieurs poinçons par moule
The invention relates to a method of additively manufacturing an object of a maraging steel by laser powder bed fusion (L-PBF) of a powder, said powder being composed of i) Ni in an amount ranging from 10 to 15 wt% ii) Co in an amount ranging from 12 to 16 wt% iii) Mo in an amount ranging from 8 to 12 wt% iv) Ti in an amount of up to 0.2 wt% v) Al in an amount of up to 0.1 wt% vi) C in an amount of up to 0.03 wt%; and balance Fe; wherein the amount in wt% is based on the total weight of the powder; said method comprising i) depositing a layer of said powder on a build surface ii) melting at least a part of said layer by means of a laser source, iii) subjecting the layer to solidification and cooling iv) depositing a further layer on at least the part of the previous layer that was subjected to melting, solidification and cooling according to steps ii) and iii) v) melting, solidification and cooling of at least a part of the further layer deposited in step iv) vi) repeating steps iv) and v), wherein the deposition of said further layer is performed after an interlayer time of at least 25 seconds. The invention also relates to a tool and an object which can be obtained by the method.
B22F 7/06 - Fabrication de couches composites, de pièces ou d'objets à base de poudres métalliques, par frittage avec ou sans compactage de pièces ou objets composés de parties différentes, p. ex. pour former des outils à embouts rapportés
B22F 7/08 - Fabrication de couches composites, de pièces ou d'objets à base de poudres métalliques, par frittage avec ou sans compactage de pièces ou objets composés de parties différentes, p. ex. pour former des outils à embouts rapportés avec une ou plusieurs parties non faites à partir de poudre
B22F 10/28 - Fusion sur lit de poudre, p. ex. fusion sélective par laser [FSL] ou fusion par faisceau d’électrons [EBM]
B33Y 80/00 - Produits obtenus par fabrication additive
C22C 33/02 - Fabrication des alliages ferreux par des techniques de la métallurgie des poudres
B23P 15/28 - Fabrication d'objets déterminés par des opérations non couvertes par une seule autre sous-classe ou un groupe de la présente sous-classe d'outils de coupe
C22C 38/06 - Alliages ferreux, p. ex. aciers alliés contenant de l'aluminium
B22F 5/00 - Fabrication de pièces ou d'objets à partir de poudres métalliques caractérisée par la forme particulière du produit à réaliser
B23K 35/02 - Baguettes, électrodes, matériaux ou environnements utilisés pour le brasage, le soudage ou le découpage caractérisés par des propriétés mécaniques, p. ex. par la forme
B23K 35/30 - Emploi de matériaux spécifiés pour le soudage ou le brasage dont le principal constituant fond à moins de 1550 C
C22C 38/14 - Alliages ferreux, p. ex. aciers alliés contenant du titane ou du zirconium
C22C 38/10 - Alliages ferreux, p. ex. aciers alliés contenant du cobalt
C22C 38/12 - Alliages ferreux, p. ex. aciers alliés contenant du tungstène, du tantale, du molybdène, du vanadium ou du niobium
B23B 27/14 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier
C23C 30/00 - Revêtement avec des matériaux métalliques, caractérisé uniquement par la composition du matériau métallique, c.-à-d. non caractérisé par le procédé de revêtement
23.
CUTTING TOOL WITH DOUBLE-SIDED TANGENTIAL CUTTING INSERT
A cutting tool comprising a tool body (2) with at least one insert seat (10), and a double-sided tangential cutting insert (30) with four different working positions releasably mountable in said insert seat. A support member (15) with an auxiliary support surface (16) is formed in said insert seat (10), wherein the auxiliary support surface (16) is configured to face a mating surface on an end face of the cutting insert (30) that faces a tangential support surface (13a, 13b) in the insert seat when the cutting insert is mounted in the insert seat in any of its four working positions. The cutting insert (30) and said support member (15) are so adapted to each other that there is a play of 0.01-0.04 mm between the auxiliary support surface (16) and said mating surface when the cutting insert is mounted in the insert seat in any of its four working positions with the tool body (2) in a brand new condition.
B23C 5/06 - Fraises à surface, c.-à-d. fraises n'ayant qu'une surface de coupe pratiquement plate, ou principalement une telle surface
B23C 5/20 - Outils de fraisage caractérisés par des particularités physiques autres que la forme à taillants ou dents amovibles
B23C 5/22 - Dispositifs pour la fixation des taillants ou des dents
24.
SYSTEM AND METHOD FOR DETERMINING WHEN A PROCESS OF REMOVAL OF ORGANIC ADDITIVES FROM A GREEN BODY DURING MANUFACTURING OF A CUTTING ELEMENT IS FINISHED
The invention relates to a system for determining when a process of removal of organic additives from a green body (102) during manufacturing of a cutting element is finished, wherein the system (100) comprises a sintering furnace (110) having a pressure regulating valve (112), wherein the pressure regulating valve (112) has an adjustable flow transmittance F, wherein the system (100) further comprises at least one information unit (122), wherein the information unit (122) is configured to generate an information signal (124) comprising information regarding the flow transmittance F as a function of time t, and wherein the system (100) further comprises an analysis unit (130), wherein the analysis unit (130) is configured to determine when the flow transmittance F has reached a steady state, and to determine that the process of removal of organic additives from a green body (102) is finished when the flow transmittance F has reached the steady state The invention also relates to a method (200) for determining when a process of removal of organic additives from a green body (102) during manufacturing of a cutting element is finished.
A drill body of an indexable insert drill includes at least two chip flutes separated from each other in the circumferential direction of the drill body by intermediate ribs, each chip flute and each rib extending in a helically curved path. An insert seat is located at a transition between each chip flute and a front face of the drill body. Coolant ducts are arranged in and extending along a respective one of the ribs. Each coolant duct extends in a helically curved path and has an upstream end with an inlet opening and a downstream end with an outlet opening. Each coolant duct has a cross-sectional area that varies in the axial direction of the coolant duct, such that it has a smaller cross-sectional area at its outlet opening than at its inlet opening.
A double-sided tangential cutting insert, having eight different working positions, includes two opposite end faces serving as leading and trailing faces of the cutting insert, two opposite major side faces, two opposite minor side faces, a through hole extending between the two major side faces, cutting edges distributed along a periphery of each end face, and four abutment surfaces arranged on each end face in a grid-like pattern with two first arrays, each of which have two consecutive abutment surfaces that extend between the two major side faces, and two second arrays, each of which have two consecutive abutment surfaces and extend between the two minor side faces. Each abutment surface are inclined inwards in the cutting insert such that each two consecutive abutment surfaces in each array are inclined towards each other.
B23B 27/16 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier à éléments tranchants interchangeables, p. ex. pouvant être fixés par des brides
End mill tool for metal cutting. The cutting head (2) comprises a plurality of cutting teeth (7), which each has a cutting edge formed at an intersection of a respective rake surface (8) and a respective clearance surface (9). Each cutting edge comprises a front cutting edge (10) extending radially outward at the front end (3) and a transition cutting edge (11) extending from the front cutting edge (10) to a side cutting edge (14). The clearance surface (9) along the transition cutting edge (11), in a direction of the extension of the transition cutting edge (11), is convex. Along the transition cutting edge (11), the axial rake angle 0 of the rake surface (8) is positive, and equal or less than the helix angle a at the front end of the chip flute (13).
A face milling cutter comprising: • - a tool body (2) with insert seats (10), each of which having an internal wall with three support surfaces (21-23) that are distributed about a reference axis (RA) and inclined in order to form a cone-like guiding for a cutting insert; • - indexably mountable, cutting inserts (30) each cutting insert having first and second major faces (31, 32) on opposite sides of the cutting insert and a peripheral surface with several abutment surfaces (37); and • - fastening screws (7) for securing the cutting inserts in the insert seats. The cutting inserts (30) and the insert seats (10) are so adapted to each other that the second major face (32) of each cutting insert is located at a distance from a bottom surface (11) of the associated insert seat when the cutting insert is mounted to the insert seat in any of its working positions.
A system for automated mounting and dismounting of at least one cutting insert on a tool body with a screwing tool is provided. The cutting insert includes a top surface, a bottom surface, a circumferential side surface connecting the top and bottom surfaces, and a through hole extending from the top surface to the bottom surface for receiving the shaft of a fastening screw. A carrier device is arranged to pick up and release the cutting insert with the fastening screw. The carrier device has a body having a front surface, a rear surface, a circumferential side surface connecting the front and rear surfaces, and a channel extending from a front end opening in the front surface to a rear end opening in the rear surface. A method for automated mounting of a cutting insert with a fastening screw on a tool body is also provided.
B23P 19/00 - Machines effectuant simplement l'assemblage ou la séparation de pièces ou d'objets métalliques entre eux ou des pièces métalliques avec des pièces non métalliques, que cela entraîne ou non une certaine déformationOutils ou dispositifs à cet effet dans la mesure où ils ne sont pas prévus dans d'autres classes
B23B 27/14 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier
B23P 15/28 - Fabrication d'objets déterminés par des opérations non couvertes par une seule autre sous-classe ou un groupe de la présente sous-classe d'outils de coupe
30.
SYSTEM AND A METHOD FOR DETERMINING CONTACT BETWEEN A CUTTING TOOL AND AN ELECTRICALLY CONDUCTIVE WORKPIECE
A system and method for determining contact between a cutting tool and an electrically conductive workpiece is provided. The cutting tool includes a toolholder and a plurality of cutting inserts mounted in the toolholder. Each of the cutting inserts has an electrically conductive surface layer and are electrically insulated from the toolholder. Each of the cutting inserts are connected in parallel to a first pole of an electric power source via a respective first connection unit and a second connection unit is connected to a second pole of the electric power source and electrically connected to the electrically conductive workpiece. A measuring unit is operatively connected to an analysis unit and is configured to measure an electrical voltage over each of the first connection units. The analysis unit is configured to determine a contact between the cutting tool and an electrically conductive workpiece based on the measured electrical voltages.
B23Q 17/22 - Agencements sur les machines-outils pour indiquer ou mesurer pour indiquer ou mesurer la position réelle ou désirée de l'outil ou de la pièce
31.
Cutting tool with a clamp for securing a cutting insert to a tool body of the cutting tool
A cutting tool including a tool body with an insert seat and an associated clamp pocket, a cutting insert releasably mountable in the insert seat, a clamp received in the clamp pocket and a screw that extends with play through a through hole in the clamp and is engaged in a hole at the bottom of the clamp pocket, is provided. Upon tightening of the screw, the clamp will slide against an inclined guide surface in the slide pocket via a slide surface on the clamp, which will force the clamp to move transversally to the screw shaft towards the cutting insert such that a clamp protrusion on the clamp is moved into a recess in the cutting insert and clamping surfaces on the clamp are pressed tightly against corresponding contact surfaces on the cutting insert.
B23B 27/16 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier à éléments tranchants interchangeables, p. ex. pouvant être fixés par des brides
32.
CUTTING INSERT FOR USE IN FACE MILLING AND FACE MILLING CUTTER COMPRISING SUCH A CUTTING INSERT
A cutting insert for use in face milling and turnable into different working positions. The cutting insert comprises a peripheral surface (10) extending around the cutting insert between a rake face (2) and an opposite abutment face (3), wherein a part of the peripheral surface is provided with ridges (11) and intermediate valleys (12) such that a peripheral edge (20) between the rake face and the peripheral surface has a shape of a toothed ring with external teeth (21). A major cutting edge (30), a surface-wiping cutting edge (31) and a minor corner cutting edge (32) are provided along each tooth (21), wherein the major cutting edge (30) has an entering angle of 75° or more in at least one point along its extension. Each tooth (21) is asymmetric in relation to a reference line that extends perpendicularly to the surface-wiping cutting edge (31) of the tooth and intersects a centre of the surface-wiping cutting edge halfway between two opposite end points thereof.
A double-sided cutting insert (1) for use in a helical milling cutter with rectangular basic shape and four different working positions. A peripheral surface (10) extends around the cutting insert between two major faces (2, 3) and has two longer main side faces (11, 12) and two shorter main side faces (13, 14). A main cutting edge (31-34) is formed at an intersection between each longer main side face (11, 12) and each major face (2, 3). An inclined chip guiding surface (41-44) extends between each shorter main side face (13, 14) and each major face (2, 3). Each chip guiding surface intersects an abutment surface (5a, 5b) of the adjacent major face on both sides of a longitudinal centre plane of the cutting insert. The invention also relates to a helical milling cutter comprising a plurality of such cutting inserts.
A processing tool includes a tool body having a front end surface, a rear end surface, at least one side surface connecting the front end surface and the rear end surface, and a first coupling part extending between a first end and a second end. The first end is disposed at the rear end surface, the first coupling part being one of a female coupling part and a male coupling part. The first coupling part includes a first identification marker having identification information of the processing tool. A processing tool assembly is also provided, wherein the first coupling part is arranged to be coupled to a second coupling part. The first identification marker is positioned at the first coupling part such that it is positioned in an interface between the first coupling part and the second coupling part when the first coupling part is coupled to the second coupling part.
A sintered polycrystalline cubic boron nitride (PCBN) body includes between 40 and 85 vol % of cubic boron nitride (cBN) particles and between 15 and 60 vol % of a binder phase. The binder phase has at least one metal oxide and at least one metal nitride. The metal oxide includes between 20 and 100 vol % of zirconium oxide (ZrO2) and up to 80 vol % of alumina (Al2O3) counted as a volume percentage of the total metal oxide content of the binder phase. The metal nitride includes aluminium nitride (AlN) and at least one metal nitride selected from the group consisting of vanadium nitride (VN), niobium nitride (NbN) and hafnium nitride (HfN). The content of the selected metal nitride selected is at least 10 vol % of the total binder phase, and the content of the metal oxide is at least 10 vol % of the total binder phase.
C04B 35/5831 - Produits céramiques mis en forme, caractérisés par leur compositionCompositions céramiquesTraitement de poudres de composés inorganiques préalablement à la fabrication de produits céramiques à base de non oxydes à base de borures, nitrures ou siliciures à base de nitrure de bore à base de nitrure de bore cubique
C04B 35/626 - Préparation ou traitement des poudres individuellement ou par fournées
C04B 35/63 - Préparation ou traitement des poudres individuellement ou par fournées utilisant des additifs spécialement adaptés à la formation des produits
Disclosed is a detachable build plate (100) for additive manufacturing adapted to be inserted into a recess (210) of a bottom plate (200), wherein the detachable build plate (100) comprises a build area (110) for additively manufacturing thereon.
B33Y 30/00 - Appareils pour la fabrication additiveLeurs parties constitutives ou accessoires à cet effet
B22F 10/14 - Formation d’un corps vert par projection de liant sur un lit de poudre
B22F 10/28 - Fusion sur lit de poudre, p. ex. fusion sélective par laser [FSL] ou fusion par faisceau d’électrons [EBM]
B29C 64/153 - Procédés de fabrication additive n’utilisant que des matériaux solides utilisant des couches de poudre avec jonction sélective, p. ex. par frittage ou fusion laser sélectif
B29C 64/165 - Procédés de fabrication additive utilisant une combinaison de matériaux solides et liquides, p. ex. une poudre avec liaison sélective par liant liquide, catalyseur, inhibiteur ou absorbeur d’énergie
A milling tool body (2) for a milling tool (1), the milling tool body (2) comprising: - an axial front end surface (3), - an axial rear end surface (4), - a peripheral mantle surface (10) extending between the axial front end surface (3) and the axial rear end surface (4), - a front end (2a), - a rear end (2b) being configured for attachment of the milling tool (1) to a machine, - at least two insert seats (20) and associated chip pocket being entirely provided in the front end (2a), wherein a cooling duct system (50) contained in the milling tool body (2) is extending from at least one coolant inlet (30) arranged in a first ring-shaped section (11) of the peripheral mantle surface (10) to at least one coolant outlet (40) arranged in a second ring-shaped section (12) of the peripheral mantle surface. The first and the second ring-shaped section are flanked by sealing surfaces formed as surfaces of revolution, preferably as circular cylindrical surfaces.
The invention is related to a cutting insert (100) comprising a first main surface (102), a second main surface (104), and at least one side surface (106) connecting the first main surface (102) and the second main surface (104), wherein the cutting insert (100) comprises at least one abutment surface (110,112) configured to abut a support surface (204,206,208) in a toolholder (200) or a clamping surface (302) at a fastening element (300), wherein the cutting insert (100) further comprises a through hole (130) extending from the first main surface (102) to the second main surface (104), wherein the cutting insert (100) further comprises at least one identification marker (114,116) in form of a one-dimensional or two-dimensional optical machine-readable code, wherein the at least one identification marker (114,116) has a polygonal shape, wherein the at least one abutment surface (110,112) comprises at least one recess (118,120) comprising a bottom surface (122,124) located a distance d from the abutment surface (110,112) in a direction perpendicular to the abutment surface (110,112), and wherein the at least one identification marker (114,116) is engraved or imprinted in the bottom surface (122,124). The invention also relates to a cutting tool (400) comprising such a cutting insert (100).
The present invention relates to a sintering furnace (100) for sintering of green compacts comprising a retort (9); and i) an inlet for furnace atmosphere gas at one end of the retort (9); ii) a stack of sintering trays (1, 2, 3, 4, 5, 6) comprising central openings (11) arranged in the interior of the retort (9), said central openings (11) having an area A for transfer of the furnace atmosphere gas introduced through the inlet, wherein neighbouring sintering trays of said stack are spaced apart at a predetermined distance from one another whereby an interspace (16) is provided between said neighbouring sintering trays, said interspace (16) being enclosed by a peripheral wall (15) provided with distributed holes (10) for transfer of the furnace atmosphere gas between the interspace (16) interior of the peripheral wall (15) and the space exterior to the peripheral wall (15), wherein the ratio of the area A of each individual central opening (11) to the total area of the distributed holes (10) between each individual pair of neighbouring sintering trays ranges from 1:10 to 10:1; iii) an outlet for withdrawal of the furnace atmosphere gas at an end of the retort (9) opposite to the end of the inlet, said inlet and outlet being arranged at opposite ends of the stack of sintering trays (1, 2, 3, 4, 5, 6). The invention also relates to a method for sintering green compacts in the sintering furnace (100) and to sintered compacts obtainable by the method.
F27B 5/16 - Aménagement des dispositifs d'alimentation en air ou gaz
F27D 5/00 - Supports, grilles ou appareillage analogue pour la charge à l'intérieur du four
B22F 3/00 - Fabrication de pièces ou d'objets à partir de poudres métalliques, caractérisée par le mode de compactage ou de frittageAppareils spécialement adaptés à cet effet
A tool includes a cemented carbide part and a steel part joined by brazing, where the steel part has an average hardness of between 390 and 510 HV30. The braze joint includes Ti and a TiC layer, with a thickness of between 0.03 and 5 μm, adjoining to the cemented carbide part. The tool provides a strong braze joint and a steel part that have an even hardness.
A cutting tool insert has an optimal hardness and high toughness for demanding cutting operations in hardened steel and cast iron. The cutting tool includes a substrate of cemented carbide where the cemented carbide has hard constituents of tungsten carbide (WC) and a (Co) binder phase, chromium (Cr) and at least one additional element from the group: Vanadium (V), Niobium (Nb), Molybdenum (Mo) and Iron (Fe). The cemented carbide further has a Co-content of 3.50-4.20 wt % of the cemented carbide, a Cr-content of 0.31-0.38 wt % of the cemented carbide, a WC-content of at least 95.22 wt % of the cemented carbide and wherein the cemented carbide has a coercivity of 26-32 kA/m
B22F 5/00 - Fabrication de pièces ou d'objets à partir de poudres métalliques caractérisée par la forme particulière du produit à réaliser
B22F 3/16 - Compactage et frittage par des opérations successives ou répétées
B22F 9/02 - Fabrication des poudres métalliques ou de leurs suspensionsAppareils ou dispositifs spécialement adaptés à cet effet par des procédés physiques
B22F 9/04 - Fabrication des poudres métalliques ou de leurs suspensionsAppareils ou dispositifs spécialement adaptés à cet effet par des procédés physiques à partir d'un matériau solide, p. ex. par broyage, meulage ou écrasement à la meule
B23B 27/14 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier
C22C 1/051 - Fabrication de métaux durs à base de borures, de carbures, de nitrures, d'oxydes ou de siliciuresPréparation du mélange de poudres utilisé comme matière première à cet effet
C22C 29/06 - Alliages à base de carbures, oxydes, borures, nitrures ou siliciures, p. ex. cermets, ou d'autres composés métalliques, p. ex. oxynitrures, sulfures à base de carbures ou de carbonitrures à base de carbures mais ne contenant pas d'autres composés métalliques
C22C 29/08 - Alliages à base de carbures, oxydes, borures, nitrures ou siliciures, p. ex. cermets, ou d'autres composés métalliques, p. ex. oxynitrures, sulfures à base de carbures ou de carbonitrures à base de carbures mais ne contenant pas d'autres composés métalliques à base de carbure de tungstène
C23C 14/06 - Revêtement par évaporation sous vide, pulvérisation cathodique ou implantation d'ions du matériau composant le revêtement caractérisé par le matériau de revêtement
49.
A CUTTING TOOL COMPRISING A CUTTING EDGE AND A METHOD FOR INDEXING SUCH A CUTTING EDGE
The invention is related to a cutting tool (100) comprising a toolholder body (110), a cutting unit (120), a clamp (160) having a clamping surface (162), and a fastening element (180), wherein the cutting unit (120) is secured in the toolholder body (110) by the fastening element (180) which is adjustable to generate a clamping force acting on the clamp (160) to press the clamping surface (162) toward the cutting unit (120). The cutting unit (120) comprises a circular cutting edge (124) comprising a plurality of cutting edge portions (126). The cutting tool (100) is configured to be shifted between an operation state and an indexing state by adjusting the fastening element (180) to provide a corresponding clamping force, wherein the cutting tool (100) further comprises a resilient element (190) connecting the clamp (160) with the toolholder body (110), wherein the resilient element (190) is configured to generate a biasing force acting on the clamp (160) to press the clamping surface (162) towards the cutting unit top surface (130), wherein ‐in the operation state, the clamping force is larger than the biasing force, ‐in the indexing state, the clamping force is smaller than the biasing force. The invention also relates to a method (200) for indexing the cutting edge (124) in the cutting tool (100).
B23B 27/16 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier à éléments tranchants interchangeables, p. ex. pouvant être fixés par des brides
A coated cutting tool and a method to manufacture, and the use of the same is provided. The coated cutting tool includes of a substrate and a coating including a physical vapor deposition (PVD) deposited Ti,Al-based nitride layer having a thickness of at least 1.0 μm. The PVD deposited Ti,Al-based nitride layer has at least one layer of TiAlN. The coating further includes a CVD deposited layer of TiN located between the substrate and the PVD deposited Ti,Al-based nitride layer. The CVD deposited layer of TiN is in contact with both the substrate and the PVD deposited Ti,Al-based nitride layer. The method for manufacturing a coated cutting tool includes growing a TiN layer by CVD on the substrate, and growing a Ti,Al-based nitride layer by PVD on the TiN layer.
C23C 28/04 - Revêtements uniquement de matériaux inorganiques non métalliques
B23B 27/14 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier
C23C 14/06 - Revêtement par évaporation sous vide, pulvérisation cathodique ou implantation d'ions du matériau composant le revêtement caractérisé par le matériau de revêtement
C23C 14/32 - Évaporation sous vide par explosionÉvaporation sous vide par évaporation suivie d'une ionisation des vapeurs
A cutting insert includes a first and a second pair of opposing side surfaces. As seen towards a first side surface, a first axial relief face and a first axial abutment face form part of a first surface grouping on a first side of a longitudinal plane. As seen towards a second side surface, a second axial relief face and a second axial abutment face form part of a second surface grouping on the first side of the longitudinal plane. The first axial abutment face forms a substantially flat surface and extends perpendicularly to a median plane of the insert. The second axial abutment face forms a substantially flat surface and extends perpendicularly to the median plane. A second side surface of the first pair of opposing side surfaces has a first and a second radial abutment face.
The present invention relates to a moulding tool assembly (5) for powder injection moulding a component (1), a method for manufacturing a component (1), and the component obtainable therefrom, wherein the moulding tool assembly (5) comprises i) at least a first and a second tool part (21, 22, 22a, 22b, 23, 24) arranged to define a mould cavity (25) for forming a component (1) ii) an inlet channel (30) for filling the mould cavity (25) with moulding material (3), the inlet channel (30) extending through an opening in the first tool part (21) to the mould cavity (25) and comprising an outlet end (33) having an outlet opening (34) for discharging the moulding material (3) from the inlet channel (30) into the mould cavity (25); iii) a core pin (40) extending through an opening in the second tool part (22, 22a, 22b), the core pin (40) being movable between a rear end position and a front end position along a horizontal axis extending through the centre of the core pin (40) and the centre of the inlet channel (30), the core pin (40) comprising an end portion (41) having an end surface (42) facing the outlet opening (34); the core pin (40) being configured to seal the opening in the second tool part (22, 22a, 22b) with the end portion (41) thereof when the core pin (40) is positioned in its rear end position; and wherein the core pin (40) in its front end position is positioned such that moulding material (3) entering the mould cavity (25) impinges on it; and iv) a power source (43) configured to maintain the core pin (40) in its front end position until a predetermined pressure threshold is exceeded during filling of the mould cavity (25) moving the core pin (40) to the rear end position; or v) a power source (43) configured to maintain the core pin (40) in its front end position a predetermined time and to move the core pin (40) to the rear end position after the predetermined time.
B29C 33/00 - Moules ou noyauxLeurs détails ou accessoires
B29C 45/00 - Moulage par injection, c.-à-d. en forçant un volume déterminé de matière à mouler par une buse d'injection dans un moule ferméAppareils à cet effet
B22D 17/10 - Machines à chambre froide, c.-à-d. dont la chambre de presse où on verse le métal liquide, n'est pas préchauffée avec mouvement horizontal de la presse
B22D 17/20 - AccessoiresCoulée sous pression ou moulage par injection, c.-à-d. moulage en introduisant le métal dans le moule sous haute pression Parties constitutives
B22D 17/22 - Moules métalliquesPlaques de moulesSupports de moulesÉquipement de refroidissement des moulesAccessoires pour l'extraction et l'éjection des pièces hors du moule
B22D 17/24 - Accessoires pour la mise en place et le maintien des noyaux ou parties rapportées
B22D 46/00 - Commande, surveillance, non limitées à un procédé de coulée couvert par un seul groupe principal, p. ex. pour des raisons de sécurité
B22F 3/22 - Fabrication de pièces ou d'objets à partir de poudres métalliques, caractérisée par le mode de compactage ou de frittageAppareils spécialement adaptés à cet effet pour la fabrication de pièces par coulée en moule poreux ou absorbant, c.-à-d. par coulée d'une suspension de poudre métallique dans un moule poreux, d'une façon analogue au coulage de la barbotine
B28B 1/24 - Fabrication d'objets façonnés à partir du matériau par moulage par injection
B28B 13/02 - Alimentation en matériau non façonné des moules ou des appareillages destinés à la fabrication d'objets façonnés
B22F 5/00 - Fabrication de pièces ou d'objets à partir de poudres métalliques caractérisée par la forme particulière du produit à réaliser
C22C 29/02 - Alliages à base de carbures, oxydes, borures, nitrures ou siliciures, p. ex. cermets, ou d'autres composés métalliques, p. ex. oxynitrures, sulfures à base de carbures ou de carbonitrures
A face milling cutter includes a tool body, several primary cutting inserts mounted in a respective primary insert seat, a reference insert mounted in a reference insert seat, and a finishing insert mounted in a finishing insert seat. The reference and primary cutting inserts are configured to be detachably mounted in their insert seats in a fixed position as seen in the axial direction of the tool body. The reference insert seat is arranged more forwardly in the tool body than the primary insert seats such that the reference insert projects forwards from the tool body beyond the axially foremost point of each primary cutting insert. The position of the finishing insert is adjustable by an adjustment mechanism to allow it to be positioned with its axially foremost point substantially in level with or more forwardly than the axially foremost point of the reference insert.
A thread milling tool includes a tool body with at least one pair of insert seats including of a first insert seat and a second insert seat, which are angularly and axially offset from each other, and several double-sided thread milling inserts. Each thread milling inserts is adapted to the first and second insert seats such that it is mountable in the first insert seat in one single working position with a first group of cutting edges on a first side of the thread milling insert in an active cutting position, and mountable in the second insert seat in one single working position with a second group of cutting edges on an opposite second side of the thread milling insert in an active cutting position. A thread milling insert suitable for use in such a thread milling tool is also provided.
111. The insert pocket (220) comprises at least one pocket support element (226) being any of: • a protrusion engaging with the indention in the second main surface (304), or • an indention engaging with the protrusion at the second main surface (304), wherein the insert support element (308) comprises an insert support surface (332), and wherein the pocket support element (226) comprises a pocket support surface (228), wherein the insert support surface (332) is in contact with the pocket support surface (228), wherein the insert support surface (332) contacts the pocket support surface (228) in a plurality of contact regions (230,232,234,236), wherein each contact region (230,232,234,236) is separated from the other contact regions.
B23B 27/16 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier à éléments tranchants interchangeables, p. ex. pouvant être fixés par des brides
The present invention realties to a boring head for holding a boring tool for metal cutting. The boring head comprises a main body, which comprises a support surface (25) and a scale surface. The boring head further comprises a piston (6) comprising a boring tool interface for fixedly carrying the boring tool, wherein the piston (6) is movably arranged in the main body along the positioning axis (y), and a micrometer screw (19). The micrometer screw (19) is arranged in the main body and coupled to the piston (6), such that, when the micrometer screw (19) is rotated, the piston (6) is moved along the positioning axis to one of the protracted positions or the retracted position. The micrometer screw (19) comprises a head (21) abutting against the support surface (25), which head (21) comprises a radially outer head surface (26) provided with first graduation marks (23). The scale surface is provided with second graduation marks (29), which second graduation marks (29) align with the first graduation marks (23) to provide a reading of the axial position of the piston (6). The scale surface is a convexly rounded bevel surface (28) with an arc-shaped edge (32) at the head surface (26).
The invention is related to a toolholder (100) for use with a cutting element (200) in a cutting process, wherein the toolholder (100) comprises at least one sensor (114) for detecting an environmental condition; wherein the toolholder (100) comprises a control unit (116) operatively connected to the at least one sensor (114), wherein the control unit (116) comprises a crossbar array (118) of resistive memory devices, and a power source (120) operatively connected to the crossbar array (118), wherein the crossbar array (18) comprises a neural network stored thereon, and wherein the neural network is adapted to determine a condition of the cutting element (200) or of the cutting process based on the environmental condition detected by the at least one sensor (114). The invention also relates to a cutting tool (300) and to a cutting tool assembly (500).
B23Q 17/09 - Agencements sur les machines-outils pour indiquer ou mesurer pour indiquer ou mesurer la pression de coupe ou l'état de l'outil de coupe, p. ex. aptitude à la coupe, charge sur l'outil
G05B 19/406 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique caractérisée par le contrôle ou la sécurité
A double-sided cutting insert for milling includes first and second major faces, a peripheral surface arranged between the major faces and including a first main side face, a first main cutting edge formed at an intersection between the first main side face and the first major face, a second main cutting edge formed at an intersection between the first main side face and the second major face, first and second inclined side surfaces, which are formed on the first main side face and which are inclined towards each other to form a depression on the first main side face, and a chip deflecting member formed on the first main side face as a protrusion across the depression and which includes a chip deflecting surface configured to deflect chips, which hit the first main side face, away from the depression.
The disclosure relates to a method, computer program product and system for decreasing the risk of erroneously handling a tool in a machine operation. The system includes a reader device for reading a machine readable code arranged at a tool part and an electronic device having a processing circuitry configured to cause the system to receive desired operation data indicative of a tool part to be used during the machine operation. The method includes the steps of receiving desired operation data indicative of the tool part to be used during the machine operation, detecting the identification marker at the tool part, reading, by the reader device, the machine readable code of the identification marker, identifying the tool part, and determining if the identified tool part corresponds to the tool part according to the desired operation data, the identification marker being a machine readable code associated with the tool part.
A method and a system for controlling a machining process of a workpiece is provided. First, information regarding a first set of cutting parameters used during the machining process of the workpiece is obtained. Thereafter, imaging data of at least one chip produced during the machining process of the workpiece is obtained. A chip type of the at least one chip is determined based on the obtained imaging data, and a relation between cutting parameters and chip type is determined based on the used first set of cutting parameters and determined chip type. The relation between cutting parameters and chip type is used to control a subsequent machining process of a workpiece.
G05B 19/401 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique caractérisée par des dispositions de commande pour la mesure, p. ex. étalonnage et initialisation, mesure de la pièce à usiner à des fins d'usinage
A face milling cutter (1) comprising: • a tool body (2); • at least two cutting inserts (20) for forming a milled flat surface on a workpiece and mounted in a respective insert seat (10) in the tool body, each cutting insert having a secondary cutting edge (22) that constitutes the axially foremost cutting edge of the cutting insert; and • several burnishing assemblies (30) with a respective springloaded burnishing element (31) arranged in the tool body. The number of the burnishing assemblies (30) in the tool body (2) is the same as the number of insert seats (10), wherein the insert seats and the burnishing assemblies are alternately arranged in the circumferential direction of the tool body such that each one of the insert seats (10) is followed by an associated one of the burnishing assemblies (30) as seen in the intended direction of rotation of the tool body.
09 - Appareils et instruments scientifiques et électriques
35 - Publicité; Affaires commerciales
37 - Services de construction; extraction minière; installation et réparation
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
45 - Services juridiques; services de sécurité; services personnels pour individus
Produits et services
Machine tools; tools for machine tools for cutting,
machining, drilling, turning, milling, reaming and thread
cutting; indexable inserts for machine tools and cutting
tools [parts of machines] with indexable inserts; machine
tools holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the
aforesaid goods; computer software and programs; databases;
electronic databases; mobile apps; smart tags (or
transponders); bar code readers; computer hardware; data
communications hardware; downloadable software in the nature
of a mobile application, in particular for inventory
management, user support, and collecting and reporting
product information; data transmitting and receiving
apparatus and equipment for use with bar codes and/or all
optical identification systems. Commercial and industrial management assistance; advisory
services for business management; business management and
organization consultancy; advertising services; business
consultancy services relating to the selection of metal
working machines and tools; inventory control; business
consultancy; data processing services; business analysis,
research and information services; collection and
systematization of business data; provision of wholesale and
retail services, including such services being provided
online, related to products used in the metal working
industries; online retail services, namely, the provision
and operation of an online marketplace for buyers and
sellers of products for use within the metal working
industries; provision of e-commerce services for products
for use within the metal working industries, namely, the
provision and operation of an online marketplace for buyers
and sellers of products for use within the metal working
industries; e-commerce services, being business management
services relating to e-commerce in the metal working
industries; online ordering services; sales administration;
provision of customer support services and information
related to products for use within the metal working
industries; information, advisory, support and consultancy
services relating to the aforesaid; provision of an online
marketplace for buyers and sellers of downloadable digital
collectibles authenticated by non-fungible tokens (NFTs);
retail store services featuring virtual goods, namely,
metalworking machine tools and inserts, metalworking
machines, inventory management machines, electronic controls
and publications for use in online virtual worlds. Repair, maintenance, assembly and installation services in
the field of metal working industries; rebuild,
refurbishment, upgrade and custom engineering services of
products within the metal working industries; rental and
hire of products for use within the metal working
industries; rental of machine tools; repair of tools;
information, advisory, support and consultancy services
relating to the aforesaid. Grinding; providing material treatment information;
recycling of steel and other materials and products;
material treatment information; regrinding and recoating of
tools and machines; custom manufacture of power-operated
automation equipment; custom manufacturing of parts and
component made from common metals and their alloys;
information, advisory, support and consultancy services
relating to the aforesaid. Education; providing of training; education and training,
including online or virtual training, in the technical
field; education and training, including online training,
relating to product development, manufacturing and
inspection; training services, including online or virtual
training services, provided in relation to the metal working
industries; training services, including online or virtual
training services, provided in relation to products for use
within the metal working industries; practical training,
including online or virtual training, in the fields of
engineering and design; training services, including online
or virtual training services, in the fields of engineering
and design provided via simulators; training services,
including online or virtual training services, related to
use of software, hardware, equipment and tools for the metal
working industries; publication services for the metal
working industries; information, advisory, support and
consultancy services relating to the aforesaid;
entertainment services, namely, providing on-line,
non-downloadable files of virtual goods, namely,
metalworking machine tools and inserts, metalworking
machines, inventory management machines, publications and
artwork for use in virtual environments created for
entertainment purposes; providing on-line digital
publications, namely, digital art authenticated by
non-fungible tokens (nfts). Scientific and technological services and research and
design relating thereto; industrial analysis, industrial
research and industrial design services; quality control and
authentication services; design and development of computer
hardware and software; scientific and technological
services, namely, research and design in the field of tools
and tooling systems for industrial metal cutting, equipment
and tools; industrial research in the field of tools and
tooling systems for industrial metal cutting; computer
hardware and software design; computer software development;
testing, analysis, and evaluation of the goods of others to
assure compliance with industry standards; consulting
services in the field of design and development of
engineering processes; consumer product safety testing
consultation; measurement services; remote monitoring
services; chemical research and analysis; Software as a
Service (SaaS) and Platform as a Service (PaaS) services
featuring computer software platforms for a tool library;
technical support services for computer software for use in
the field of the metal working industries; services for
monitoring industrial processes; consulting services in the
field of cloud computing; technological consulting services,
namely, providing services related to geometrical
inspection, measurement, and analysis of industrial,
medical, and aerospace components parts and components;
hosting services; Software as a Service (SaaS) and Platform
as a Service (PaaS) services provided in relation to the
calculation of data for machine tools; providing temporary
use of on-line non-downloadable computer software, Software
as a Service (SaaS) and Platform as a Service (PaaS)
services provided in relation to the controlling of cutting
machines; providing temporary use of on-line
non-downloadable computer software, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to the nesting and programming of CNC cutting
machines; providing temporary use of on-line
non-downloadable computer software, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to the provision of engineering design and
engineering drafting services; providing temporary use of
on-line non-downloadable computer software, Software as a
Service (SaaS) and Platform as a Service (PaaS) services
provided in relation to the machine tool industry;
non-downloadable (on-line) software, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to products for use within the metal working
industries; providing automatic updates to applications and
software as a service (SaaS); updating of computer software
for others; updating and maintaining cloud-based computer
software through on-line updates, enhancements and patches;
performance monitoring services in the field of the metal
working industries; information, advisory, support and
consultancy services relating to the aforesaid; services for
minting [creation] non-fungible tokens [NFTs] using
blockchain technology; software as a service featuring
virtual products and marketplaces. Licensing; licensing of wireless communication systems;
licensing of intellectual property; licensing of computer
software; licensing of databases; licensing of technology.
09 - Appareils et instruments scientifiques et électriques
35 - Publicité; Affaires commerciales
36 - Services financiers, assurances et affaires immobilières
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machine tools; tools for machine tools for cutting,
machining, drilling, turning, milling, reaming and thread
cutting; indexable inserts for tools for machine tools and
cutting tools [parts of machines] with indexable inserts;
machine tool holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the
aforesaid good; computer software and programs; databases;
electronic databases; mobile apps; smart tags (or
transponders); bar code readers; computer hardware; data
communications hardware; downloadable software in the nature
of a mobile application, in particular for inventory
management, user support, and collecting and reporting
product information; apparatus and equipment for use with
bar codes and/or all optical identification systems. Commercial and industrial management assistance; advisory
services for business management; business management and
organization consultancy; advertising services; business
consultancy services relating to the selection of metal
working machines and tools; inventory control; business
consultancy; data processing services; business analysis,
research and information services; collection and
systematization of business data; provision of wholesale and
retail services, including such services being provided
online, related to products used in the metal working
industries; online retail services, namely, the provision
and operation of an online marketplace for buyers and
sellers of products for use within the metal working
industries; provision of e-commerce services for products
for use within the metal working industries, namely, the
provision and operation of an online marketplace for buyers
and sellers of products for use within the metal working
industries; e-commerce services, being business management
services relating to e-commerce in the metal working
industries; online ordering services; sales administration;
provision of customer support services and information
related to products for use within the metal working
industries; information, advisory, support and consultancy
services relating to the aforesaid; provision of an online
marketplace for buyers and sellers of downloadable digital
collectibles authenticated by non-fungible tokens (NFTs);
retail store services featuring virtual goods, namely,
metalworking machine tools and inserts, metalworking
machines, inventory management machines, electronic controls
and publications for use in online virtual worlds. Issuance of tokens of value. Education; providing of training; education and training,
including online or virtual training, in the technical
field; education and training, including online training,
relating to product development, manufacturing and
inspection; training services, including online or virtual
training services, provided in relation to the metal working
industries; training services, including online or virtual
training services, provided in relation to products for use
within the metal working industries; practical training,
including online or virtual training, in the fields of
engineering and design; training services, including online
or virtual training services, in the fields of engineering
and design provided via simulators; training services,
including online or virtual training services, related to
use of software, hardware, equipment and tools for the metal
working industries; publication services for the metal
working industries; information, advisory, support and
consultancy services relating to the aforesaid;
entertainment services, namely, providing on-line,
non-downloadable files of virtual goods, namely,
metalworking machine tools and inserts, metalworking
machines, inventory management machines, publications and
artwork for use in virtual environments created for
entertainment purposes; providing on-line digital
publications, namely, digital art authenticated by
non-fungible tokens (NFTs). Scientific and technological services and research and
design relating thereto; industrial analysis, industrial
research and industrial design services; quality control and
authentication services; design and development of computer
hardware and software; scientific and technological
services, namely, research and design in the field of tools
and tooling systems for industrial metal cutting, equipment
and tools; industrial research in the field of tools and
tooling systems for industrial metal cutting; computer
hardware and software design; computer software development;
testing, analysis, and evaluation of the goods of others to
assure compliance with industry standards; consulting
services in the field of design and development of
engineering processes; consumer product safety testing
consultation; measurement services; remote monitoring
services; chemical research and analysis; Software as a
Service (SaaS) and Platform as a Service (PaaS) services
featuring computer software platforms for a tool library;
operational support services in the field of the metal
working industries; services for monitoring industrial
processes; consulting services in the field of cloud
computing; technological consulting services, namely,
providing services related to geometrical inspection,
measurement, and analysis of industrial, medical, and
aerospace components parts and components; hosting services;
Software as a Service (SaaS) and Platform as a Service
(PaaS) services provided in relation to the calculation of
data for machine tools; provision of online non-downloadable
software being application service provider, Software as a
Service (SaaS) and Platform as a Service (PaaS) services
provided in relation to the controlling of cutting machines;
provision of online non-downloadable software being
application service provider, Software as a Service (SaaS)
and Platform as a Service (PaaS) services provided in
relation to the nesting and programming of CNC cutting
machines; provision of online non-downloadable software
being application service provider, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to the provision of engineering design and
engineering drafting services; provision of online
non-downloadable software being application service
provider, Software as a Service (SaaS) and Platform as a
Service (PaaS) services provided in relation to the machine
tool industry; provision of online non-downloadable software
being application service provider, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to products for use within the metal working
industries; providing automatic updates to applications and
software as a service (SaaS); updating of computer software
for others; updating and maintaining cloud-based computer
software through on-line updates, enhancements and patches;
performance monitoring services in the field of the metal
working industries; information, advisory, support and
consultancy services relating to the aforesaid; services for
minting [creation] non-fungible tokens [NFTs] using
blockchain technology; software as a service featuring
virtual products and marketplaces.
09 - Appareils et instruments scientifiques et électriques
35 - Publicité; Affaires commerciales
37 - Services de construction; extraction minière; installation et réparation
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
45 - Services juridiques; services de sécurité; services personnels pour individus
Produits et services
Machine tools; tools for machine tools for cutting,
machining, drilling, turning, milling, reaming and thread
cutting; indexable inserts for tools for machine tools and
cutting tools [parts of machines] with indexable inserts;
machine tool holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the
aforesaid good; computer software and programs; databases;
electronic databases; mobile apps; smart tags (or
transponders); bar code readers; computer hardware; data
communications hardware; downloadable software in the nature
of a mobile application, in particular for inventory
management, user support, and collecting and reporting
product information; apparatus and equipment for use with
bar codes and/or all optical identification systems. Commercial and industrial management assistance; advisory
services for business management; business management and
organization consultancy; advertising services; business
consultancy services relating to the selection of metal
working machines and tools; inventory control; business
consultancy; data processing services; business analysis,
research and information services; collection and
systematization of business data; provision of wholesale and
retail services, including such services being provided
online, related to products used in the metal working
industries; online retail services, namely, the provision
and operation of an online marketplace for buyers and
sellers of products for use within the metal working
industries; provision of e-commerce services for products
for use within the metal working industries, namely, the
provision and operation of an online marketplace for buyers
and sellers of products for use within the metal working
industries; e-commerce services, being business management
services relating to e-commerce in the metal working
industries; online ordering services; sales administration;
provision of customer support services and information
related to products for use within the metal working
industries; information, advisory, support and consultancy
services relating to the aforesaid; provision of an online
marketplace for buyers and sellers of downloadable digital
collectibles authenticated by non-fungible tokens (NFTs);
retail store services featuring virtual goods, namely,
metalworking machine tools and inserts, metalworking
machines, inventory management machines, electronic controls
and publications for use in online virtual worlds. Repair, maintenance, assembly and installation services in
the field of metal working industries; rebuild,
refurbishment and maintenance services of products within
the metal working industries; rental and hire of products
for use within the metal working industries; rental of
machine tools; repair of tools; information, advisory,
support and consultancy services relating to the aforesaid. Grinding; providing material treatment information;
recycling of steel and other materials and products;
material treatment information; regrinding and recoating of
tools and machines; custom manufacture of power-operated
automation equipment; custom manufacturing of parts and
component made from common metals and their alloys;
information, advisory, support and consultancy services
relating to the aforesaid. Education; providing of training; education and training,
including online or virtual training, in the technical
field; education and training, including online training,
relating to product development, manufacturing and
inspection; training services, including online or virtual
training services, provided in relation to the metal working
industries; training services, including online or virtual
training services, provided in relation to products for use
within the metal working industries; practical training,
including online or virtual training, in the fields of
engineering and design; training services, including online
or virtual training services, in the fields of engineering
and design provided via simulators; training services,
including online or virtual training services, related to
use of software, hardware, equipment and tools for the metal
working industries; publication services for the metal
working industries; information, advisory, support and
consultancy services relating to the aforesaid;
entertainment services, namely, providing on-line,
non-downloadable files of virtual goods, namely,
metalworking machine tools and inserts, metalworking
machines, inventory management machines, publications and
artwork for use in virtual environments created for
entertainment purposes; providing on-line digital
publications, namely, digital art authenticated by
non-fungible tokens (NFTs). Scientific and technological services and research and
design relating thereto; industrial analysis, industrial
research and industrial design services; quality control and
authentication services; design and development of computer
hardware and software; scientific and technological
services, namely, research and design in the field of tools
and tooling systems for industrial metal cutting, equipment
and tools; industrial research in the field of tools and
tooling systems for industrial metal cutting; computer
hardware and software design; computer software development;
testing, analysis, and evaluation of the goods of others to
assure compliance with industry standards; consulting
services in the field of design and development of
engineering processes; consumer product safety testing
consultation; measurement services; remote monitoring
services; chemical research and analysis; Software as a
Service (SaaS) and Platform as a Service (PaaS) services
featuring computer software platforms for a tool library;
operational support services in the field of the metal
working industries; services for monitoring industrial
processes; consulting services in the field of cloud
computing; technological consulting services, namely,
providing services related to geometrical inspection,
measurement, and analysis of industrial, medical, and
aerospace components parts and components; hosting services;
Software as a Service (SaaS) and Platform as a Service
(PaaS) services provided in relation to the calculation of
data for machine tools; provision of online non-downloadable
software being application service provider, Software as a
Service (SaaS) and Platform as a Service (PaaS) services
provided in relation to the controlling of cutting machines;
provision of online non-downloadable software being
application service provider, Software as a Service (SaaS)
and Platform as a Service (PaaS) services provided in
relation to the nesting and programming of CNC cutting
machines; provision of online non-downloadable software
being application service provider, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to the provision of engineering design and
engineering drafting services; provision of online
non-downloadable software being application service
provider, Software as a Service (SaaS) and Platform as a
Service (PaaS) services provided in relation to the machine
tool industry; provision of online non-downloadable software
being application service provider, Software as a Service
(SaaS) and Platform as a Service (PaaS) services provided in
relation to products for use within the metal working
industries; providing automatic updates to applications and
software as a service (SaaS); updating of computer software
for others; updating and maintaining cloud-based computer
software through on-line updates, enhancements and patches;
performance monitoring services in the field of the metal
working industries; information, advisory, support and
consultancy services relating to the aforesaid; services for
minting [creation] non-fungible tokens [NFTs] using
blockchain technology; software as a service featuring
virtual products and marketplaces; custom engineering
services of products within the metal working industries. Licensing; licensing of wireless communication systems;
licensing of intellectual property; licensing of computer
software; licensing of databases; licensing of technology.
65.
Tool part, system, method, and a computer program for determining a dimension of the tool part
A system for utilizing an identification marker on a tool part for determining a dimension thereof. The system includes a reader device for reading a machine readable code, and an electronic device connected to the reader device. The electronic device has a processing circuitry that causes the system to detect with the reader device, an identification marker at a tool part, wherein the identification marker is a unique machine readable code read by the reader device, and the unique machine readable code of the identification marker, and obtain from the unique machine readable code, individual dimension information data including at least one individually measured dimension of the tool part measured when manufacturing the tool part. A method and a computer program product for utilizing an identification marker on a tool part to be used for determining a dimension of the tool part and to a tool part is also provided.
G05B 19/12 - Commande à programme autre que la commande numérique, c.-à-d. dans des automatismes à séquence ou dans des automates à logique utilisant des supports d'enregistrement
G06K 7/10 - Méthodes ou dispositions pour la lecture de supports d'enregistrement par radiation électromagnétique, p. ex. lecture optiqueMéthodes ou dispositions pour la lecture de supports d'enregistrement par radiation corpusculaire
66.
DRILL BODY OF AN INDEXABLE INSERT DRILL AND INDEXABLE INSERT DRILL COMPRISING SUCH A DRILL BODY
A drill body (2) of an indexable insert drill comprising: - at least two chip flutes (10a, 10b) separated from each other in the circumferential direction of the drill body by intermediate ribs (12a, 12b), each chip flute and each rib extending in a helically curved path; - an insert seat located at a transition between each chip flute and a front face of the drill body; and - coolant ducts (20a, 20b) arranged in and extending along a respective one of said ribs (12a, 12b), each coolant duct extending in a helically curved path and having an upstream end (21) with an inlet opening (24a, 24b) and a downstream end (22) with an outlet opening (25a, 25b). Each coolant duct has a cross-sectional area that varies in the axial direction of the coolant duct such that it has a smaller cross-sectional area at its outlet opening than at its inlet opening.
B23B 27/10 - Outils de coupe avec une disposition particulière pour le refroidissement
B05B 1/14 - Buses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des orifices de sortie multiplesBuses, têtes de pulvérisation ou autres dispositifs de sortie, avec ou sans dispositifs auxiliaires tels que valves, moyens de chauffage avec des filtres placés dans ou à l'extérieur de l'orifice de sortie
B23B 5/28 - Machines ou dispositifs à tourner spécialement conçus pour un travail particulierAccessoires correspondants spécialement conçus à cet effet pour tourner des roues ou des trains de roues ou leurs manivelles, c.-à-d. tours à roues
68.
Tool part, system, method and computer program product for determining a tool wear
The disclosure relates to a tool part for a cutting tool having an identification marker arranged at the tool part, wherein the identification marker is a unique machine readable code associated with individual dimension information data. The individual dimension information data includes at least one individually measured dimension of the tool part as measured when manufacturing the tool part that will change while wearing the tool part. The disclosure further relates to a system, a method and computer program product for utilizing an identification marker on a tool part for a cutting tool, for determining a tool wear of the tool part.
G06K 7/14 - Méthodes ou dispositions pour la lecture de supports d'enregistrement par radiation électromagnétique, p. ex. lecture optiqueMéthodes ou dispositions pour la lecture de supports d'enregistrement par radiation corpusculaire utilisant la lumière sans sélection des longueurs d'onde, p. ex. lecture de la lumière blanche réfléchie
B23B 49/00 - Systèmes de mesure ou de calibrage des machines à aléser, pour le positionnement ou le guidage du foretDispositif pour indiquer les défauts des forets pendant l'alésageDispositifs à centrer les trous à aléser
G06K 19/06 - Supports d'enregistrement pour utilisation avec des machines et avec au moins une partie prévue pour supporter des marques numériques caractérisés par le genre de marque numérique, p. ex. forme, nature, code
A double-sided tangential cutting insert with eight different working positions comprising: - two opposite end faces (2, 3) serving as leading and trailing faces of the cutting insert; - two opposite major side faces (5, 6); - two opposite minor side faces (7, 8); - a through hole (14) extending between the two major side faces (5, 6); - cutting edges distributed along a periphery of each end face (2, 3); - four abutment surfaces (41-44) arranged on each end face in a grid-like pattern with two first arrays, each of which comprising two consecutive abutment surfaces and extending between the two major side faces (5, 6), and two second arrays (A2), each of which comprising two consecutive abutment surfaces and extending between the two minor side faces (7, 8), each abutment surface being inclined inwards in the cutting insert such that each two consecutive abutment surfaces in each array (A1, A2) are inclined towards each other.
The disclosure relates to a method, an electronic device and a computer program product for reducing a carbon dioxide footprint associated with a production process. The carbon dioxide footprint has at least an amount of carbon dioxide emitted during the production process. The method includes the step of obtaining a parameter indicative of a selected cutting feature for production by a cutting tool, the step of obtaining a parameter indicative of a selected work-piece material for production by a cutting tool, the step of determining a set of cutting tools for production based on the obtained parameters, and the step of determining a cutting tool for production from the determined set of cutting tools based on carbon dioxide emission information data associated with each cutting tool in the determined set of cutting tools.
An anvil for a cutting tool includes an anvil body. A curved passage extends from an inlet opening in the anvil body to an outlet opening in the anvil body. The anvil body can be made by an additive manufacturing process. The anvil body includes a top surface, a bottom surface, and a side surface between the top surface and the bottom surface. The side surface includes at least three side surface portions and at least three corner portions. Each corner portion is disposed between respective pairs of the side surface portions. At least one corner portion includes a surface that extends radially outward from a central axis of the anvil relative to extensions of a respective pair of side surface portions. The central axis extends between the top and bottom surfaces, wherein the extensions of the respective pair of side surface portions intersect within the periphery of the anvil.
Machine tools; tools for machine tools for cutting,
machining, drilling, turning, milling, reaming and thread
cutting; indexable inserts for tools for machine tools and
cutting tools [parts of machines] with indexable inserts;
machine tools holders; parts for the aforesaid goods. Commercial and industrial management assistance; advisory
services for business management; business management and
organization consultancy; advertising services; business
consultancy services relating to the selection of metal
working machines and tools; inventory control; business
consultancy; data processing services; business analysis,
research and information services; collection and
systematization of business data; e-commerce services, being
business management services relating to e-commerce in the
metal working industries; online ordering services; sales
administration; provision of customer support services and
information related to products for use within the metal
working industry.
73.
A SYSTEM AND A METHOD FOR DETERMINING A SETTING OF A CUTTING TOOL
The invention relates to a system (100,200,300) for determining a setting of a cutting tool (102,202,302). The cutting tool (102,202,302) comprises a first tool part (103,203,303) and a second tool part (104,204,304). The first tool part (103,203,303) is a non-adjustable tool part, and the second tool part (104,204,304) is radially and/or axially adjustable relative the first tool part (103,203,303). The system (100,200,300) comprises a processing circuit (109,209,309) configured to cause the system to obtain first position data comprising information regarding a first position (107,207,307) at the first tool part (103,203,303), and second position data comprising information regarding a second position (108,208,308) at the second tool part (104,204,304). The system (100,200,300) is further configured to determine a distance and a direction between the first position (107,207,307) and the second position (108,208,308). The system (100,200,300) is configured to determine a setting of the cutting tool (102,202,302) based at least on the determined distance and direction between the first position (107,207,307) and the second position (108,208,308). The invention also relates to a method (400) for determining a setting of a cutting tool (102,202,302).
B23C 5/24 - Dispositifs pour la fixation des taillants ou des dents réglables
G05B 19/4093 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique caractérisée par la programmation de pièce, p. ex. introduction d'une information géométrique dérivée d'un dessin technique, combinaison de cette information avec l'information d'usinage et de matériau pour obtenir une information de commande, appelée programme de pièce, pour la machine à commande numérique [CN]
G05B 19/401 - Commande numérique [CN], c.-à-d. machines fonctionnant automatiquement, en particulier machines-outils, p. ex. dans un milieu de fabrication industriel, afin d'effectuer un positionnement, un mouvement ou des actions coordonnées au moyen de données d'un programme sous forme numérique caractérisée par des dispositions de commande pour la mesure, p. ex. étalonnage et initialisation, mesure de la pièce à usiner à des fins d'usinage
74.
Rotary cutting tool with continuous major flutes and discontinuous minor flutes intersecting to form quadrilateral-shaped face portions
Rotary cutting tool (100) having plurality of major flutes (130) arranged helically opposite to plurality of discontinuous minor flutes (135) and intersecting to form plurality of teeth. Each tooth includes a first cutting edge formed with the major flute and a second cutting edge formed with the minor flute, the first and second cutting edges meeting at an apex and form part of a periphery of a quadrilateral-shaped face portion. The face portion has non-planar surfaces extending from the respective first and second cutting edges that define a relief surface of each cutting edge. First and second cutting edges are arranged on an imaginary cylinder having a center axis coaxial with the axis of rotation of the tool and respective relief surfaces are radially inward of a surface of the imaginary cylinder such that the first and second cutting edges each have a clearance in a rotational direction of the tool.
B23B 5/10 - Machines ou dispositifs à tourner spécialement conçus pour un travail particulierAccessoires correspondants spécialement conçus à cet effet pour tourner des essieux, barres, tiges, tubes, cylindresTournage sans centre pour tourner des cylindres de laminoirs à pas de pèlerin
B23C 5/10 - Fraise à queue, c.-à-d. comportant une queue incorporée
The invention relates to a system for determining contact between a cutting tool (10) and an electrically conductive workpiece (20). The cutting tool (10) comprises a toolholder (11) and n cutting inserts (12,13,14,15) mounted in the toolholder (11), wherein n is an integer ≥ 2, 5 wherein each of the n cutting inserts (12,13,14,15) comprises an electrically conductive surface layer. Each of the n cutting inserts (12,13,14,15) are electrically insulated from the toolholder (11). The system further comprises an electric power source (31) and each of the n cutting inserts (12,13,14,15) are connected in parallel to a first pole (48) of the electric power source (31) via a respective first connection unit (32, 33, 34, 35) comprising a resistor 10 (44, 45, 46, 47). The system further comprises a second connection unit (49) connected to a second pole of the electric power source (31). The second connection unit (49) being configured to be electrically connected to an electrically conductive workpiece (20). The system further comprises a measuring unit (60) being operatively connected to an analysis unit (70). The measuring unit (60) is configured to measure an electrical voltage (UR44, UR45, UR46, UR47) over each of the first connection units (32, 33, 34, 35), and the analysis unit (70) is configured to determine a contact between the cutting tool (10) and an electrically conductive workpiece (20) based on the measured electrical voltages (UR44, UR45, UR46, UR47). The invention also relates to a method for determining contact between a cutting tool (10) and an electrically conductive workpiece (20).
B23Q 17/22 - Agencements sur les machines-outils pour indiquer ou mesurer pour indiquer ou mesurer la position réelle ou désirée de l'outil ou de la pièce
A cutting tool comprising: • - a tool body (2) with an insert seat (10) and an associated clamp pocket (20); • - a cutting insert (30) releasably mountable in the insert seat; • - a clamp (40) received in the clamp pocket; and • - a screw (60) that extends with play through a through hole (47) in the clamp and is engaged in a hole (22) at the bottom of the clamp pocket. Upon tightening of the screw, the clamp will slide against an inclined guide surface (26) in the slide pocket via a slide surface (46) on the clamp, which will force the clamp to move transversally to the screw shaft (61) towards the cutting insert such that a clamp protrusion (45) on the clamp is moved into a recess (37) in the cutting insert and clamping surfaces on the clamp are pressed tightly against corresponding contact surfaces on the cutting insert.
B23C 5/22 - Dispositifs pour la fixation des taillants ou des dents
B23C 5/06 - Fraises à surface, c.-à-d. fraises n'ayant qu'une surface de coupe pratiquement plate, ou principalement une telle surface
B23B 27/16 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier à éléments tranchants interchangeables, p. ex. pouvant être fixés par des brides
(1) Metalworking machine tools and structural parts therefore; power-operated tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting and structural parts therefore; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts, namely power-operated cutting tools and structural parts therefore; metalworking machine tools holders and structural parts therefore. (1) Business management assistance for industrial and commercial companies; advisory services for business management; business management and organization consultancy; advertising the goods and services of others; business consultancy services relating to the selection of metal working machines and tools; inventory control; business management consultancy; data processing services in the field of invoice management; strategic business analysis, business research investigations and information management services; collection and systematization of business data; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services in the field of metalworking machine tools and power-operated metalworking tools; sales administration in the nature of business administration services for processing sales made on the internet; provision of customer support services namely, responding to customers inquiries for others via telephone or other electronic means; all of the foregoing services offered in respect of products in the field of commercial and industrial metalworking and power-operated metalworking tools and to purchasers of such products.
09 - Appareils et instruments scientifiques et électriques
35 - Publicité; Affaires commerciales
36 - Services financiers, assurances et affaires immobilières
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
(1) Metalworking machine tools; Tools for machine tools for machining in the nature of machining centers for metalworking; metalworking power-operated tools for machine tools for cutting, drilling, turning, milling, reaming and thread cutting; indexable inserts for power operated thread milling cutter machine tools used with other machine tools; machine tools in the nature of thread milling cutters with indexable inserts; Machine tool holders used for machine tool interfaces in the field of metal working tools; replacement parts for the aforesaid goods, namely, metalworking machine parts; equipment in relation to the metal working industries, namely, metalworking machines.
(2) Replacement parts for the aforesaid goods, namely, electric circuit switches; downloadable and recorded computer software and programs for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; downloadable and recorded databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable electronic databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable computer mobile applications for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; transponders in the nature of smart radio frequency identification (RFID) tags; bar code readers; computer hardware; computer hardware for data communications; downloadable software and mobile application for inventory management, user support, collecting and reporting product information; apparatus and equipment for use with bar codes and optical identification systems, namely, bar code readers and fingerprint scanners. (1) Commercial and industrial management assistance relating to the selection of metal working machines and tools; advisory services for business management; business management and organization consultancy; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy services relating to the selection of metal working machines and tools; business data analysis, business failure analysis services, business management analysis; collection and systematic integration for business data of market analysis and research; provision of wholesale and retail store services, featuring products used in the metal working industries; provision of an online marketplace for buyers and sellers within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services featuring products for use within the metal working industries; sales administration in the nature of business administration services for processing sales made on the Internet; provision of customer support services, namely, responding to customers inquiries for others in the field of metal working via telephone or other electronic means; provision of an online marketplace for buyers and sellers of downloadable digital collectibles authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, downloadable image files of metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and downloadable educational publications in the nature of manuals about metalworking machines, all for use in online virtual worlds.
(2) Issuing pre-paid vouchers exchangeable for goods or services;
(3) Educational services, namely, providing online non-downloadable videos and non-downloadable webinars in the field of engineering and design and distribution of course materials in connection therewith; providing educational classes, training, online training, and virtual training, all in the technical field of operating metalworking machines and machine tools; Providing educational classes, training and online training, all in the field of product development, manufacturing and inspection of metalworking machines and machine tools; practical training, online and virtual training, all in the fields of engineering and design of products for use within the metal working industries; training services, online and virtual training services, all in the fields of engineering and design of operating machines and machine tools for the metal working industries provided via simulators; Providing training and online training, all in the field of software and hardware related to metalworking machines and machine tools; providing online non-downloadable educational publications in the nature of training manuals about operation and use of equipment used in the metalworking industries; entertainment services, namely, providing on-line, non-downloadable files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, publications and artwork for use in virtual environments created for entertainment purposes; providing on-line digital publications, namely, digital art authenticated by non-fungible tokens (NFTs).
(4) Scientific and technological services, namely, scientific research and design in the field of metal working industries; industrial analysis of products for use within the metal working industries to assure compliance with computer, construction industry standards, industrial research in the field of products within the metal working industries, and industrial design services; quality control for others and authentication in the field of metal working industries; design and development of computer hardware and software; research and technological research, namely research in the field of tools and tooling systems for industrial metal cutting, equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services, namely, measurement evaluations in the metal working industry; remote monitoring of the functioning and use of electrical equipment, namely, generators; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the calculation of wear data for machine tools; operational support services in the field of the metal working industries; services for monitoring industrial metalworking processes to ensure proper functioning; consulting services in the field of cloud computing; technological consulting services, namely, providing services related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components parts and components; hosting services, namely, hosting the web sites of others; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the calculation of wear data for machine tools; providing on-line non-downloadable software for nesting and programming of CNC (computer numerical control) cutting machines, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the controlling of cutting machines; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the nesting and programming of CNC (computer numerical control) cutting machines; providing online non-downloadable software for the provision of engineering design and engineering drafting services, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the provision of engineering design and engineering drafting services; providing on-line non-downloadable software for evaluating wear and performance of metalworking products used within the metal working industries; updating of computer software for others by providing automatic updates to computer software applications and software as a service (SaaS) software; updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; computer hardware performance monitoring services in the field of the metal working industries; providing online non-downloadable computer software for minting non-fungible tokens (NFTs) using blockchain technology; software as a service (SAAS) services featuring software for accessing virtual marketplaces offering downloadable virtual goods for use in online virtual environments.
09 - Appareils et instruments scientifiques et électriques
35 - Publicité; Affaires commerciales
37 - Services de construction; extraction minière; installation et réparation
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
45 - Services juridiques; services de sécurité; services personnels pour individus
Produits et services
(1) Metalworking machine tools; Tools for machine tools for machining in the nature of machining centers for metalworking; metalworking power-operated tools for machine tools for cutting, drilling, turning, milling, reaming and thread cutting; indexable inserts for power operated thread milling cutter machine tools used with other machine tools; machine tools in the nature of thread milling cutters with indexable inserts; Machine tool holders used for machine tool interfaces in the field of metal working tools; replacement parts for the aforesaid goods, namely, metalworking machine parts; equipment in relation to the metal working industries, namely, metalworking machines;
(2) Computer hardware; replacement parts for the aforesaid goods, namely, electric circuit switches; downloadable and recorded computer software and programs for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; downloadable and recorded databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable electronic databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable computer mobile applications for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; transponders in the nature of smart radio frequency identification (RFID) tags; bar code readers; computer hardware; computer hardware for data communications; downloadable software and mobile application for inventory management, user support, collecting and reporting product information; apparatus and equipment for use with bar codes and optical identification systems, namely, bar code readers and fingerprint scanners; (1) Commercial and industrial management assistance relating to the selection of metal working machines and tools; advisory services for business management; business management and organization consultancy; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy services relating to the selection of metal working machines and tools; business data analysis, business failure analysis services, business management analysis; collection and systematic integration for business data of market analysis and research; provision of wholesale and retail store services, featuring products used in the metal working industries; provision of an online marketplace for buyers and sellers within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services featuring of products for use within the metal working industries; sales administration in the nature of business administration services for processing sales made on the Internet; provision of customer support services, namely, responding to customers inquiries for others in the field of metal working via telephone or other electronic means; provision of an online marketplace for buyers and sellers of downloadable digital collectibles authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, downloadable image files of metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and downloadable educational publications in the nature of manuals about metalworking machines, all for use in online virtual worlds;
(2) Repair, maintenance, assembly and installation of metal working machines in the field of metal working industries; rebuilding and refurbishment of metal working machines used in the metal working industries; Rental and hire of metal working machines in the field of metal working industries; repair of metalworking tools;
(3) Grinding of tools and machines; providing information relating to material treatment; recycling of steel and carbide materials; regrinding and recoating of tools and machines; custom manufacture of poweroperated automation metalworking machines and power-operated automation machine tools for metal processing; custom manufacturing of semi-finished casting products of common metals and their alloys;
(4) Educational services, namely, providing online non-downloadable videos and non-downloadable webinars in the field of engineering and design and distribution of course materials in connection therewith; Training in the field of engineering and engineering design; providing educational classes, training, online training, and virtual training, all in the technical field of operating metalworking machines and machine tools; Providing educational classes, training and online training, all in the field of product development, manufacturing and inspection of metalworking machines and machine tools; practical training, online and virtual training, all in the fields of engineering and design of products for use within the metal working industries; training services, online and virtual training services, all in the fields of engineering and design of operating machines and machine tools for the metal working industries provided via simulators; Providing training and online training, all in the field of software and hardware related to metalworking machines and machine tools; providing online non-downloadable educational publications in the nature of training manuals about operation and use of equipment used in the metalworking industries; entertainment services, namely, providing on-line, nondownloadable files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, publications and artwork for use in virtual environments created for entertainment purposes; providing on-line digital publications, namely, digital art authenticated by non-fungible tokens (nfts).
(5) Scientific and technological services, namely, scientific research and design in the field of metal working industries; industrial analysis of products for use within the metal working industries to assure compliance with computer, construction industry standards, industrial research in the field of products within the metal working industries, and industrial design services; quality control for others and authentication in the field of metal working industries; design and development of computer hardware and software; research and technological research, namely research in the field of tools and tooling systems for industrial metal cutting, equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services, namely, measurement evaluations in the metal working industry; remote monitoring of the functioning and use of electrical equipment, namely, generators; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for database management of a tool library; technical support services for computer software for use in the field of the metal working industries; services for monitoring industrial metalworking processes to ensure proper functioning; consulting services in the field of cloud computing; technological consulting services, namely, providing services related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components parts and components; hosting services, namely, hosting the web sites of others; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the calculation of wear data for machine tools; providing on-line non-downloadable software for evaluating wear and performance of metalworking products used within the metal working industries; providing temporary use of on-line non-downloadable computer software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the nesting and programming of CNC cutting machines; providing temporary use of on-line non-downloadable computer software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the provision of engineering design and engineering drafting services; providing temporary use of on-line non-downloadable computer software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the machine tool industry; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for evaluating wear and performance of metalworking products used within the metal working industries; updating of computer software for others by providing automatic updates to computer software applications and software as a service (SaaS) software; updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; computer hardware performance monitoring services in the field of the metal working industries; providing online non-downloadable computer software for minting non-fungible tokens (NFTs) using blockchain technology; software as a service (SAAS) services featuring software for accessing virtual marketplaces offering downloadable virtual goods for use in online virtual environments;
(6) Licensing of industrial property rights; licensing of industrial property rights in the field of wireless communication systems; licensing of intellectual property; licensing of computer software; licensing of databases; licensing of industrial property rights for technology;
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
09 - Appareils et instruments scientifiques et électriques
35 - Publicité; Affaires commerciales
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
45 - Services juridiques; services de sécurité; services personnels pour individus
Produits et services
Grinding; providing information relating to material treatment; recycling of steel and other materials and products; regrinding of tools and machines; recoating in the nature of applying protective coatings to metal tools and machines by means of galvanization Downloadable and recorded computer software and programs for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; downloadable and recorded databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable electronic databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable computer mobile applications for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business data analysis, business failure analysis services, business management analysis; business research and information services; collection and systematization of business data; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services featuring of products for use within the metal working industries; sales administration in the nature of business administration services for processing sales made on the Internet; provision of customer support services, namely, responding to customers inquiries for others in the field of metal working via telephone or other electronic means; providing pricing information about the products of others within the metal working industries; information, advisory, and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles in the nature of downloadable image files of metalworking machines authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, downloadable image files of metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and downloadable educational publications in the nature of manuals about metalworking machines, all for use in online virtual worlds Educational services, namely, providing online non-downloadable videos and non-downloadable webinars in the field of engineering and design and distribution of course materials in connection therewith; Training in the field of engineering and engineering design; providing educational classes, training, online training, and virtual training, all in the technical field of operating metalworking machines and machine tools; providing educational classes, training, and online training, all in the fields of product development, manufacturing and inspection; training services, online and virtual training services, all in the fields of operating machines and machine tools for the metal working industries; training services, online and virtual training services all of the foregoing about products for use within the metal working industries; practical training, online and virtual training, all in the fields of engineering and design of products for use within the metal working industries; training services, online and virtual training services, all in the fields of engineering and design of operating machines and machine tools for the metal working industries provided via simulators; training services, online and virtual training services, all of the foregoing related to use of software, hardware, equipment and tools for the metal working industries; providing online non-downloadable educational publications in the nature of training manuals about operation and use of equipment used in the metalworking industries; information, advisory, and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable image files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, artwork and non-downloadable multimedia files of publications being magazines about metalworking, all for use in virtual environments created for entertainment purposes; hosting services, namely, hosting social entertainment events in the nature of conferences, for others Custom engineering services of products within the metal working industries; Scientific and technological services, namely, scientific research and design relating thereto, all in the field of metal working industries; industrial analysis of products for use within the metal working industries to assure compliance with computer, construction industry standards, industrial research in the field of products within the metal working industries, and industrial design services; quality control for others and authentication in the field of metal working industries; design and development of computer hardware and software; scientific and technological services, namely, scientific research and design in the field of tools and tooling systems for industrial metal cutting equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services, namely, measurement evaluations in the metal working industry; remote monitoring of the functioning and use of electrical equipment, namely, generators; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for database management of a tool library; services for monitoring industrial metalworking processes to ensure proper functioning; consulting services in the field of cloud computing; technological quality control consulting for others related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components and component parts; hosting services, namely, hosting the web sites of others; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the calculation of wear data for machine tools; providing on-line non-downloadable software for the controlling of cutting machines; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the controlling of cutting machines; providing on-line nondownloadable software for nesting and programming of CNC (computer numerical control) cutting machines; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the nesting and programming of CNC (computer numerical control) cutting machines; providing on-line non-downloadable software for the provision of engineering design and engineering drafting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the provision of engineering design and engineering drafting services; providing on-line nondownloadable software for accessing machine tool performance data for the machine tool industry; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for accessing machine tool performance data for the machine tool industry; providing on-line non-downloadable software for evaluating wear and performance of metalworking products used within the metal working industries; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for evaluating wear and performance of metalworking products used within the metal working industries; updating of computer software for others by providing automatic updates to computer software applications and software as a service (SaaS) software; updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; computer hardware performance monitoring services in the field of the metal working industries; information, advisory, and consultancy services relating to the aforesaid; providing online non-downloadable computer software for minting non-fungible tokens (NFTs) using blockchain technology; software as a service (SAAS) services featuring software for accessing virtual marketplaces offering downloadable virtual goods for use in online virtual environments; Operational support services in the nature of technical advice relating to operation of computers in the field of the metal working industries Licensing of industrial property rights; licensing of industrial property rights in the field of wireless communication systems; licensing of intellectual property; licensing of computer software; licensing of computer software being databases; licensing of industrial property rights for technology
09 - Appareils et instruments scientifiques et électriques
35 - Publicité; Affaires commerciales
36 - Services financiers, assurances et affaires immobilières
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Metalworking machine tools; metalworking power-operated tools for machine tools for cutting, drilling, turning, milling, reaming and thread cutting; tools for machine tools for machining in the nature of machining centers for metalworking; indexable inserts for power-operated thread milling cutter machine tools used with other machine tools; and machine tools in the nature of thread milling cutters with indexable inserts; machine tool holders; replacement parts for the aforesaid goods, namely, metalworking machine parts in the nature of collets, toolholders for metalworking machines, and non-electric adapters for power-operated drills for machine tools for use in joining extensions and power drill bits; equipment in relation to the metal working industries, namely, metalworking machines Electric and electronic machine tool controls; and replacement parts for the aforesaid goods, namely, electric circuit switches; downloadable and recorded computer software and programs for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; downloadable and recorded databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable electronic databases in the field of metalworking machine and machine tool processes, manufacturing, and optimization; downloadable computer mobile applications for controlling metalworking machine and machine tool operation, compiling related metalworking manufacturing data, database management, and data optimization; transponders in the nature of smart radio frequency identification (RFID) tags; bar code readers; computer hardware; computer hardware for data communications; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information; apparatus and equipment for use with bar codes and optical identification systems, namely, bar code readers and fingerprint scanners; downloadable educational publications in the nature of training manuals about operation and use of equipment used in the metal working industries; digital collectibles in the nature of downloadable multimedia files containing artwork in the field of metalworking machines authenticated by non-fungible tokens (NFTs) Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business data analysis, business failure analysis services, business management analysis; business research and information services; collection and systematization of business data; provision of wholesale and retail store services, including such store services being provided online, all featuring products used in the metal working industries; online retail services, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; provision of ecommerce services for products for use within the metal working industries, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services featuring of products for use within the metal working industries; sales administration in the nature of business administration services for processing sales made on the Internet; provision of customer support services, namely, responding to customers inquiries for others in the field of metal working via telephone or other electronic means; providing pricing information about the products of others within the metal working industries; information, advisory, and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles in the nature of downloadable image files of metalworking machines authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, downloadable image files of metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and downloadable educational publications in the nature of manuals about metalworking machines, all for use in online virtual worlds Issuing pre-paid vouchers exchangeable for goods or services Educational services, namely, providing online non-downloadable videos and non-downloadable webinars in the field of engineering and design and distribution of course materials in connection therewith; Training in the field of engineering and engineering design; providing educational classes, training, online training, and virtual training, all in the technical field of operating metalworking machines and machine tools; providing educational classes, training, and online training, all in the fields of product development, manufacturing and inspection; training services, online and virtual training services, all in the fields of operating machines and machine tools for the metal working industries; training services, online and virtual training services all of the foregoing about products for use within the metal working industries; practical training, online and virtual training, all in the fields of engineering and design of products for use within the metal working industries; training services, online and virtual training services, all in the fields of engineering and design of operating machines and machine tools for the metal working industries provided via simulators; training services, online and virtual training services, all of the foregoing related to use of software, hardware, equipment and tools for the metal working industries; providing online non-downloadable educational publications in the nature of training manuals about operation and use of equipment used in the metalworking industries; information, advisory, and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable image files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, artwork and non-downloadable multimedia files of publications being magazines about metalworking, all for use in virtual environments created for entertainment purposes; hosting services, namely, hosting social entertainment events in the nature of conferences, for others Custom engineering services of products within the metal working industries; Scientific and technological services, namely, scientific research and design relating thereto, all in the field of metal working industries; industrial analysis of products for use within the metal working industries to assure compliance with computer, construction industry standards, industrial research in the field of products within the metal working industries, and industrial design services; quality control for others and authentication in the field of metal working industries; design and development of computer hardware and software; scientific and technological services, namely, scientific research and design in the field of tools and tooling systems for industrial metal cutting equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services, namely, measurement evaluations in the metal working industry; remote monitoring of the functioning and use of electrical equipment, namely, generators; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for database management of a tool library; operational support services in the nature of technical advice relating to operation of computers in the field of the metal working industries; services for monitoring industrial metalworking processes to ensure proper functioning; consulting services in the field of cloud computing; technological quality control consulting for others related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components and component parts; hosting services, namely, hosting the web sites of others; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the calculation of wear data for machine tools; providing on-line non-downloadable software for the controlling of cutting machines; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the controlling of cutting machines; providing on-line nondownloadable software for nesting and programming of CNC (computer numerical control) cutting machines; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the nesting and programming of CNC (computer numerical control) cutting machines; providing online non-downloadable software for the provision of engineering design and engineering drafting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for the provision of engineering design and engineering drafting services; providing on-line non-downloadable software for accessing machine tool performance data for the machine tool industry; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for accessing machine tool performance data for the machine tool industry; providing on-line non-downloadable software for evaluating wear and performance of metalworking products used within the metal working industries; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for evaluating wear and performance of metalworking products used within the metal working industries; updating of computer software for others by providing automatic updates to computer software applications and software as a service (SaaS) software; updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; computer hardware performance monitoring services in the field of the metal working industries; information, advisory, and consultancy services relating to the aforesaid; providing online non-downloadable computer software for minting non-fungible tokens (NFTs) using blockchain technology; software as a service (SAAS) services featuring software for accessing virtual marketplaces offering downloadable virtual goods for use in online virtual environments.
Metalworking machine tools; metalworking power-operated tools for machine tools for cutting, drilling, turning, milling, reaming and thread cutting; tools for machine tools for machining in the nature of machining centers for metalworking; indexable inserts for power-operated thread milling cutter machine tools used with other machine tools; and machine tools in the nature of thread milling cutters with indexable inserts; machine tool holders; replacement parts for the aforesaid goods, namely, metalworking machine parts in the nature of metal grounding bushings, and toolholders for metalworking machines; equipment in relation to the metal working industries, namely, metalworking machines
Metalworking machine tools; metalworking power-operated tools for machine tools for cutting, drilling, turning, milling, reaming
and thread cutting, namely, drills being machine parts, power drill bits, drilling heads being parts of machines, milling cutters being
parts of machines, notchers being machine tools for cutting notches, reamers being machine tools, end-mills, drill taps being
machine parts; tools for machine tools for machining in the nature of machining centers for metalworking; indexable inserts for
power-operated thread milling cutter machine tools used with other machine tools; and machine tools in the nature of thread
milling cutters with indexable inserts; machine tool holders; replacement parts for the aforesaid goods, namely, indexable cutting
tool inserts, power drill chucks, machine parts in the nature of drill sleeves for drilling bits, blade holders being parts of machines,
blades being parts of machines; all the foregoing excluding 3D printers and Router bits Commercial and industrial management assistance; advisory services for business management; business management and
organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines
and tools; inventory control; business consultancy; data processing services; business data analysis, business failure analysis
services, business management analysis; business research and information services; collection and systematization of business
data; e-commerce services, being business management services relating to e-commerce in the metal working industries; online
ordering services featuring metalworking power-operated tools for machine tools for cutting, drilling, turning, milling, reaming and
thread cutting; sales administration in the nature of business administration services for processing sales made on the Internet
A cutting insert for a cutting tool includes a body having a cutting edge, a rake face, and micro channels provided on the rake face adjacent the cutting edge. The micro channels define a grid pattern of micro channels that intersect each other in a region of the rake face where contact between a chip and the rake face is assumed to occur during cutting with the cutting insert.
B23C 5/28 - Caractéristiques se rapportant à la lubrification ou au refroidissement
B23B 27/10 - Outils de coupe avec une disposition particulière pour le refroidissement
B23B 27/16 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier à éléments tranchants interchangeables, p. ex. pouvant être fixés par des brides
09 - Appareils et instruments scientifiques et électriques
35 - Publicité; Affaires commerciales
36 - Services financiers, assurances et affaires immobilières
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machine tools; tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts; machine tools holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the aforesaid good; computer software and programs; databases; electronic databases; mobile apps; smart tags (or transponders); bar code readers; computer hardware; data communications hardware; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information; apparatus and equipment for use with bar codes and/or all optical identification systems. Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business analysis, research and information services; collection and systematization of business data; provision of wholesale and retail services, including such services being provided online, related to products used in the metal working industries; online retail services, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; provision of e-commerce services for products for use within the metal working industries, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services; sales administration; provision of customer support services and information related to products for use within the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and publications for use in online virtual worlds. Issuance of tokens of value. Education; providing of training; education and training, including online or virtual training, in the technical field; education and training, including online training, relating to product development, manufacturing and inspection; training services, including online or virtual training services, provided in relation to the metal working industries; training services, including online or virtual training services, provided in relation to products for use within the metal working industries; practical training, including online or virtual training, in the fields of engineering and design; training services, including online or virtual training services, in the fields of engineering and design provided via simulators; training services, including online or virtual training services, related to use of software, hardware, equipment and tools for the metal working industries; Publication services for the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, publications and artwork for use in virtual environments created for entertainment purposes; providing on-line digital publications, namely, Digital Art authenticated by non-fungible tokens (NFTs). Scientific and technological services and research and design relating thereto; industrial analysis, industrial research and industrial design services; quality control and authentication services; design and development of computer hardware and software; scientific and technological services, namely, research and design in the field of tools and tooling systems for industrial metal cutting, equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services; remote monitoring services; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for a tool library; operational support services in the field of the metal working industries; services for monitoring industrial processes; consulting services in the field of cloud computing; technological consulting services, namely, providing services related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components parts and components; hosting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the calculation of data for machine tools; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the controlling of cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the nesting and programming of CNC cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the provision of engineering design and engineering drafting services; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the machine tool industry; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to products for use within the metal working industries; providing automatic updates to applications and software as a service (SaaS); updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; performance monitoring services in the field of the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; services for minting [creation] non-fungible tokens [NFTs] using blockchain technology; software as a service featuring virtual products and marketplaces.
09 - Appareils et instruments scientifiques et électriques
35 - Publicité; Affaires commerciales
37 - Services de construction; extraction minière; installation et réparation
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
45 - Services juridiques; services de sécurité; services personnels pour individus
Produits et services
Machine tools; tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts; machine tools holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the aforesaid good; computer software and programs; databases; electronic databases; mobile apps; smart tags (or transponders); bar code readers; computer hardware; data communications hardware; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information; apparatus and equipment for use with bar codes and/or all optical identification systems. Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business analysis, research and information services; collection and systematization of business data; provision of wholesale and retail services, including such services being provided online, related to products used in the metal working industries; online retail services, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; provision of e-commerce services for products for use within the metal working industries, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services; sales administration; provision of customer support services and information related to products for use within the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and publications for use in online virtual worlds. Repair, maintenance, assembly and installation services in the field of metal working industries; rebuild, refurbishment, upgrade and custom engineering services of products within the metal working industries; rental and hire of products for use within the metal working industries; rental of machine tools; repair of tools; information, advisory, support and consultancy services relating to the aforesaid. Grinding; providing material treatment information; recycling of steel and other materials and products; material treatment information; regrinding and recoating of tools and machines; custom manufacture of power-operated automation equipment; custom manufacturing of parts and component made from common metals and their alloys; information, advisory, support and consultancy services relating to the aforesaid. Education; providing of training; education and training, including online or virtual training, in the technical field; education and training, including online training, relating to product development, manufacturing and inspection; training services, including online or virtual training services, provided in relation to the metal working industries; training services, including online or virtual training services, provided in relation to products for use within the metal working industries; practical training, including online or virtual training, in the fields of engineering and design; training services, including online or virtual training services, in the fields of engineering and design provided via simulators; training services, including online or virtual training services, related to use of software, hardware, equipment and tools for the metal working industries; Publication services for the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, publications and artwork for use in virtual environments created for entertainment purposes; providing on-line digital publications, namely, Digital Art authenticated by non-fungible tokens (NFTs). Scientific and technological services and research and design relating thereto; industrial analysis, industrial research and industrial design services; quality control and authentication services; design and development of computer hardware and software; scientific and technological services, namely, research and design in the field of tools and tooling systems for industrial metal cutting, equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services; remote monitoring services; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for a tool library; operational support services in the field of the metal working industries; services for monitoring industrial processes; consulting services in the field of cloud computing; technological consulting services, namely, providing services related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components parts and components; hosting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the calculation of data for machine tools; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the controlling of cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the nesting and programming of CNC cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the provision of engineering design and engineering drafting services; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the machine tool industry; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to products for use within the metal working industries; providing automatic updates to applications and software as a service (SaaS); updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; performance monitoring services in the field of the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; services for minting [creation] non-fungible tokens [NFTs] using blockchain technology; software as a service featuring virtual products and marketplaces. Licensing; licensing of wireless communication systems; licensing of intellectual property; licensing of computer software; licensing of databases; licensing of technology.
09 - Appareils et instruments scientifiques et électriques
35 - Publicité; Affaires commerciales
36 - Services financiers, assurances et affaires immobilières
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Machine tools; tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts; machine tools holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the aforesaid good; computer software and programs; databases; electronic databases; mobile apps; smart tags (or transponders); bar code readers; computer hardware; data communications hardware; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information; apparatus and equipment for use with bar codes and/or all optical identification systems. Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business analysis, research and information services; collection and systematization of business data; provision of wholesale and retail services, including such services being provided online, related to products used in the metal working industries; online retail services, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; provision of e-commerce services for products for use within the metal working industries, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services; sales administration; provision of customer support services and information related to products for use within the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and publications for use in online virtual worlds. Issuance of tokens of value. Education; providing of training; education and training, including online or virtual training, in the technical field; education and training, including online training, relating to product development, manufacturing and inspection; training services, including online or virtual training services, provided in relation to the metal working industries; training services, including online or virtual training services, provided in relation to products for use within the metal working industries; practical training, including online or virtual training, in the fields of engineering and design; training services, including online or virtual training services, in the fields of engineering and design provided via simulators; training services, including online or virtual training services, related to use of software, hardware, equipment and tools for the metal working industries; Publication services for the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, publications and artwork for use in virtual environments created for entertainment purposes; providing on-line digital publications, namely, Digital Art authenticated by non-fungible tokens (NFTs). Scientific and technological services and research and design relating thereto; industrial analysis, industrial research and industrial design services; quality control and authentication services; design and development of computer hardware and software; scientific and technological services, namely, research and design in the field of tools and tooling systems for industrial metal cutting, equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services; remote monitoring services; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for a tool library; operational support services in the field of the metal working industries; services for monitoring industrial processes; consulting services in the field of cloud computing; technological consulting services, namely, providing services related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components parts and components; hosting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the calculation of data for machine tools; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the controlling of cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the nesting and programming of CNC cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the provision of engineering design and engineering drafting services; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the machine tool industry; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to products for use within the metal working industries; providing automatic updates to applications and software as a service (SaaS); updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; performance monitoring services in the field of the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; services for minting [creation] non-fungible tokens [NFTs] using blockchain technology; software as a service featuring virtual products and marketplaces.
Machine tools; tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts; machine tools holders; parts for the aforesaid goods. Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business analysis, research and information services; collection and systematization of business data; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services; sales administration; provision of customer support services and information related to products for use within the metal working industry.
09 - Appareils et instruments scientifiques et électriques
35 - Publicité; Affaires commerciales
37 - Services de construction; extraction minière; installation et réparation
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
41 - Éducation, divertissements, activités sportives et culturelles
42 - Services scientifiques, technologiques et industriels, recherche et conception
45 - Services juridiques; services de sécurité; services personnels pour individus
Produits et services
Machine tools; tools for machine tools for cutting, machining, drilling, turning, milling, reaming and thread cutting; indexable inserts for tools for machine tools and cutting tools [parts of machines] with indexable inserts; machine tools holders; parts for the aforesaid goods. Electric and electronic machine tool controls; parts for the aforesaid good; computer software and programs; databases; electronic databases; mobile apps; smart tags (or transponders); bar code readers; computer hardware; data communications hardware; downloadable software in the nature of a mobile application, in particular for inventory management, user support, and collecting and reporting product information; apparatus and equipment for use with bar codes and/or all optical identification systems. Commercial and industrial management assistance; advisory services for business management; business management and organization consultancy; advertising services; business consultancy services relating to the selection of metal working machines and tools; inventory control; business consultancy; data processing services; business analysis, research and information services; collection and systematization of business data; provision of wholesale and retail services, including such services being provided online, related to products used in the metal working industries; online retail services, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; provision of e-commerce services for products for use within the metal working industries, namely, the provision and operation of an online marketplace for buyers and sellers of products for use within the metal working industries; e-commerce services, being business management services relating to e-commerce in the metal working industries; online ordering services; sales administration; provision of customer support services and information related to products for use within the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; provision of an online marketplace for buyers and sellers of downloadable digital collectibles authenticated by non-fungible tokens (NFTs); retail store services featuring virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, electronic controls and publications for use in online virtual worlds. Repair, maintenance, assembly and installation services in the field of metal working industries; rebuild, refurbishment, upgrade and custom engineering services of products within the metal working industries; rental and hire of products for use within the metal working industries; rental of machine tools; repair of tools; information, advisory, support and consultancy services relating to the aforesaid. Grinding; providing material treatment information; recycling of steel and other materials and products; material treatment information; regrinding and recoating of tools and machines; custom manufacture of power-operated automation equipment; custom manufacturing of parts and component made from common metals and their alloys; information, advisory, support and consultancy services relating to the aforesaid. Education; providing of training; education and training, including online or virtual training, in the technical field; education and training, including online training, relating to product development, manufacturing and inspection; training services, including online or virtual training services, provided in relation to the metal working industries; training services, including online or virtual training services, provided in relation to products for use within the metal working industries; practical training, including online or virtual training, in the fields of engineering and design; training services, including online or virtual training services, in the fields of engineering and design provided via simulators; training services, including online or virtual training services, related to use of software, hardware, equipment and tools for the metal working industries; publications services for the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; entertainment services, namely, providing on-line, non-downloadable files of virtual goods, namely, metalworking machine tools and inserts, metalworking machines, inventory management machines, publications and artwork for use in virtual environments created for entertainment purposes; providing on-line digital publications, namely, Digital Art authenticated by non-fungible tokens (NFTs). Scientific and technological services and research and design relating thereto; industrial analysis, industrial research and industrial design services; quality control and authentication services; design and development of computer hardware and software; scientific and technological services, namely, research and design in the field of tools and tooling systems for industrial metal cutting, equipment and tools; industrial research in the field of tools and tooling systems for industrial metal cutting; computer hardware and software design; computer software development; testing, analysis, and evaluation of the goods of others to assure compliance with industry standards; consulting services in the field of design and development of engineering processes; consumer product safety testing consultation; measurement services; remote monitoring services; chemical research and analysis; Software as a Service (SaaS) and Platform as a Service (PaaS) services featuring computer software platforms for a tool library; operational support services in the field of the metal working industries; services for monitoring industrial processes; consulting services in the field of cloud computing; technological consulting services, namely, providing services related to geometrical inspection, measurement, and analysis of industrial, medical, and aerospace components parts and components; hosting services; Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the calculation of data for machine tools; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the controlling of cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the nesting and programming of CNC cutting machines; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the provision of engineering design and engineering drafting services; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to the machine tool industry; non-downloadable (on-line) software, Software as a Service (SaaS) and Platform as a Service (PaaS) services provided in relation to products for use within the metal working industries; providing automatic updates to applications and software as a service (SaaS); updating of computer software for others; updating and maintaining cloud-based computer software through on-line updates, enhancements and patches; performance monitoring services in the field of the metal working industries; information, advisory, support and consultancy services relating to the aforesaid; services for minting [creation] non-fungible tokens [NFTs] using blockchain technology; software as a service featuring virtual products and marketplaces. Licensing; licensing of wireless communication systems; licensing of intellectual property; licensing of computer software; licensing of databases; licensing of technology.
This disclosure relates to a high cBN content polycrystalline cubic boron nitride, PCBN, material. The binder matrix material comprises 19 to 50 wt. % chromium, or a compound thereof.
C04B 35/5831 - Produits céramiques mis en forme, caractérisés par leur compositionCompositions céramiquesTraitement de poudres de composés inorganiques préalablement à la fabrication de produits céramiques à base de non oxydes à base de borures, nitrures ou siliciures à base de nitrure de bore à base de nitrure de bore cubique
B23B 27/14 - Outils de coupe sur lesquels les taillants ou éléments tranchants sont en matériaux particulier
C04B 35/478 - Produits céramiques mis en forme, caractérisés par leur compositionCompositions céramiquesTraitement de poudres de composés inorganiques préalablement à la fabrication de produits céramiques à base d'oxydes à base d'oxydes de titane ou de titanates à base de titanates à base de titanates d'aluminium
C04B 35/58 - Produits céramiques mis en forme, caractérisés par leur compositionCompositions céramiquesTraitement de poudres de composés inorganiques préalablement à la fabrication de produits céramiques à base de non oxydes à base de borures, nitrures ou siliciures
The invention relates to a processing tool (100, 200) comprising a tool body (110,210). The tool body (110,210) comprising a front end surface (115,215), a rear end surface (116,216),at least one side surface (117,217) connecting the front end surface (115,215) and the rear end surface (116,216), and a first coupling part (130,230) extending between a first end (118,218) and a second end (119,219), wherein the first end (118,218) is disposed at the rear end surface (116,216), wherein the first coupling part (130,230) being one of a female coupling part (230) and a male coupling part (130); wherein the first coupling part (130,230) comprises a first identification marker (140,240) comprising identification information of the processing tool (100,200). The invention also relates to a processing tool assembly (300), wherein the first coupling part (130,230) is adapted to be coupled to a second coupling part (430), wherein the first identification marker (140,240) is positioned at the first coupling part (130,230) such that it is positioned in an interface between the first coupling part (130,230) and the second coupling part (430) when the first coupling part (130,230) is coupled to the second coupling part (430).
The invention relates to a processing tool (100,200) comprising a tool body (110,210) and a first coupling part (130,230), wherein the first coupling part (130,230) being one of a female coupling part (230); and a male coupling part (130), wherein the first coupling part (130,230) is adapted to be coupled to a second coupling part (430), and wherein the first coupling part (130,230) comprises a first identification marker (140,240) comprising first identification information of the processing tool (100,200), and wherein the first identification marker (140,240) is positioned at the first coupling part (130,230) such that it is unexposed to the exterior of the processing tool (100,200) when the first coupling part (130,230) is coupled to the second coupling part (430); and wherein the tool body (110,210) comprises a second identification marker (150,250) comprising second identification information of the processing tool (100,200), which is arranged such that it is exposed to the exterior of the processing tool (100,200), when the first coupling part (130,230) is coupled to the second coupling part (430). The invention also relates to a processing tool assembly (300).
A cutting tool assembly includes a first tool part and a second tool part. The first tool part has a forward end portion including a cutting edge and a rearward end portion having a conical section and an engagement section. The second tool part includes a conical recess and a clamping device rearwards the conical recess. The clamping device is provided in a transversal cavity of the second tool part and has a first clamp block, a second clamp block and a differential screw engaging the first and second clamp blocks. The first and second clamp blocks engage the engagement section of the first tool part to pull the first tool part into the conical recess when the first and second clamp blocks are moved towards each other by the differential screw protruding rearwards from the first and second clamp blocks.
B23B 31/107 - Caractérisés par les dispositifs de maintien ou de serrage ou par leurs moyens d'action directe le maintien étant assuré par des éléments d'arrêt agissant latéralement, p. ex. doigts, écrous, clavettesCaractérisés par les dispositifs de maintien ou de serrage ou par leurs moyens d'action directe le maintien étant assuré par éléments mobiles, p. ex. des billes
B23B 29/04 - Porte-outils pour un seul outil de coupe
B23B 31/00 - Mandrins de serrageMandrins extensiblesLeurs adaptations à la commande à distance
