1.

Steel Wire and Spring with Excellent Antibacterial Properties and Corrosion Resistance and Method for Manufacturing the Same


Numéro d'application 18841428
Statut En instance
Date de dépôt 2023-02-02
Date de la première publication 2025-05-29
Propriétaire
  • Kiswire Ltd. (République de Corée)
  • Scherdel Innotec Forschungs- Und Entwicklungs- GmbH (Allemagne)
Inventeur(s)
  • Yu, Gwang Weon
  • Zaumseil, Wolf-Thilo
  • Guenthner, Martin

Abrégé

The disclosure relates to a steel wire and a spring having excellent antibacterial properties and corrosion resistance, and methods of manufacturing the same. The steel wire having excellent antibacterial properties and corrosion resistance includes: a steel wire; and a plating layer formed on the steel wire, wherein the plating layer includes a zinc (Zn)-aluminum (Al) plating layer plated on a surface of the steel wire, and a doping layer formed by doping a surface of the Zn—Al plating layer with a metal in a colloidal form. The method of manufacturing the steel wire having excellent antibacterial properties and corrosion resistance includes forming a plating layer on a surface of a steel wire, wherein the forming of the plating layer includes forming a Zn—Al plating layer by plating the surface of the steel wire, and forming a doping layer by doping a surface of the Zn—Al plating layer with a metal in a colloidal form.

Classes IPC  ?

  • C23C 18/31 - Revêtement avec des métaux
  • B32B 15/01 - Produits stratifiés composés essentiellement de métal toutes les couches étant composées exclusivement de métal
  • C22C 18/04 - Alliages à base de zinc avec l'aluminium comme second constituant majeur
  • F16F 1/02 - Ressorts en acier ou faits d'un autre matériau ayant une faible friction intérieureRessorts enroulés, de torsion, à lame, en forme de coupelles, à corps annulaire ou similaire, le matériau de ressort ne jouant pas de rôle

2.

WIRE ROPE SYSTEM


Numéro d'application 18231874
Statut En instance
Date de dépôt 2023-08-09
Date de la première publication 2025-02-13
Propriétaire SCHERDEL INNOTEC Forschungs- und Entwicklungs-GmbH (Allemagne)
Inventeur(s)
  • Heinl, Thomas
  • Farrell, David

Abrégé

A wire rope system for supporting an opening movement and a closing movement of a tailgate of a vehicle or a trailer, the wire rope system comprises: a guide cylinder configured to be arranged within a side board wall or within a tailgate of a vehicle or a trailer, and comprising a front end portion with an opening and a back end portion; a compression spring arranged within the guide cylinder, and having a front end and a back end; and a plunger element configured to be movable axially within the guide cylinder; the compression spring being attached with its front end to the front end portion of the guide cylinder and being attached with its back end to the plunger element; a wire rope extending through the opening in the front end portion of the guide cylinder, and comprising a back end attached to the plunger element and a front end to be attached to a tailgate or a side board wall of a vehicle or a trailer; wherein the plunger element comprises a slide membrane element configured such that its circumferential edge abuts to the inner wall of the guide cylinder, thus separating the inner space of the guide cylinder into a back air chamber between the rear side of the slide membrane element and the back end portion of the guide cylinder, and into a front air chamber between the front side of the slide membrane element and the front end portion of the guide cylinder; wherein an air flow regulating opening is arranged within the back air chamber and connects the back air chamber to the exterior side of the guide cylinder; and wherein the slide membrane element is configured such that during movement towards the front end portion of the guide cylinder air flow from the front air chamber between its circumferential edge and the inner wall of the guide cylinder to the back air chamber is blocked or reduced, thus exerting a damping function to the movement of the wire rope and reducing the opening speed of the tailgate.

Classes IPC  ?

  • E05F 1/10 - Appareils de fermeture ou d'ouverture pour battants, non prévus ailleurs dans la présente sous-classe actionnés par ressort pour battants pivotants
  • E05F 3/02 - Appareils de fermeture ou d'ouverture à dispositif de freinage, p. ex. ralentisseursStructure des dispositifs de freinage pneumatique ou à liquide avec freins à piston pneumatique

3.

WIRE ROPE SYSTEM


Numéro d'application EP2024070395
Numéro de publication 2025/031755
Statut Délivré - en vigueur
Date de dépôt 2024-07-18
Date de publication 2025-02-13
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s)
  • Heinl, Thomas
  • Farrell, David

Abrégé

A wire rope system for supporting an opening movement and a closing movement of a tailgate of a vehicle or a trailer, the wire rope system comprises: a guide cylinder configured to be arranged within a side board wall or within a tailgate of a vehicle or a trailer, and comprising a front end portion with an opening and a back end portion; a compression spring arranged within the guide cylinder, and having a front end and a back end; and a plunger element configured to be movable axially within the guide cylinder; the compression spring being attached with its front end to the front end portion of the guide cylinder and being attached with its back end to the plunger element; a wire rope extending through the opening in the front end portion of the guide cylinder, and comprising a back end attached to the plunger element and a front end to be attached to a tailgate or a side board wall of a vehicle or a trailer; wherein the plunger element comprises a slide membrane element configured such that its circumferential edge abuts to the inner wall of the guide cylinder, thus separating the inner space of the guide cylinder into a back air chamber between the rear side of the slide membrane element and the back end portion of the guide cylinder, and into a front air chamber between the front side of the slide membrane element and the front end portion of the guide cylinder; wherein an air flow regulating opening is arranged within the back air chamber and connects the back air chamber to the exterior side of the guide cylinder; and wherein the slide membrane element is configured such that during movement towards the front end portion of the guide cylinder air flow from the front air chamber between its circumferential edge and the inner wall of the guide cylinder to the back air chamber is blocked or reduced, thus exerting a damping function to the movement of the wire rope and reducing the opening speed of the tailgate.

Classes IPC  ?

  • E05F 1/10 - Appareils de fermeture ou d'ouverture pour battants, non prévus ailleurs dans la présente sous-classe actionnés par ressort pour battants pivotants
  • E05F 3/02 - Appareils de fermeture ou d'ouverture à dispositif de freinage, p. ex. ralentisseursStructure des dispositifs de freinage pneumatique ou à liquide avec freins à piston pneumatique
  • E05F 3/12 - Dispositifs particuliers commandant la circulation du liquide, p. ex. dispositif à soupapes

4.

THIN-WALLED PIPE, METALLIC FLAT MATERIAL AND METHOD FOR PRODUCING A THIN-WALLED PIPE


Numéro d'application 18709116
Statut En instance
Date de dépôt 2022-11-11
Date de la première publication 2025-01-23
Propriétaire SCHERDEL INNOTEC Forschungs- und Entwicklungs-GmbH (Allemagne)
Inventeur(s) Vogel, Egbert

Abrégé

A thin-walled pipe according to the invention comprises the following features: a thin metallic flat material (22) rolled or bent into a pipe and having a wall thickness of 0.05-1.00 mm, the longitudinal edges (24, 26) of which are connected to each other by connecting elements engaging in one another in form-fitting manner along a connecting portion (6) extending in the pipe longitudinal direction (8); wherein the connecting elements are protrusions (28) on the first longitudinal edge (24) of the flat material (22) and corresponding recesses (12) on the second longitudinal edge (26) of the flat material (22); wherein at least one protrusion (10) engages in a corresponding recess (12) such that the flanks of the protrusion (10) abut, at least partially, in the longitudinal direction of the pipe against the respective adjacent flanks of the corresponding recess (12); wherein at least one pair (32, 34) made up of a protrusion flank and of an abutting recess flank, as seen in an axial sectional plane (A-A) extending along the connecting portion (6), in each case has an inclined course from the pipe outer wall to the pipe inner wall; and wherein at least one pair (32, 34) of a protrusion flank and of an abutting recess flank, as seen in an axial sectional plane (A-A) extending along the connecting portion (6), in each case encloses an angle of 15-75°, in particular 30-60°, with the pipe radial plane.

Classes IPC  ?

  • F16L 9/17 - Tuyaux rigides obtenus par cintrage longitudinal d'une feuille et raccordement des arêtes
  • B21D 39/03 - Utilisation de procédés permettant d'assembler des objets ou des parties d'objets, p. ex. revêtement par des tôles, autrement que par placageDispositifs de mandrinage des tubes des tôles autrement que par pliage

5.

DISTRIBUTED INTERMEDIATE CIRCUIT CAPACITOR AND FILTER UNIT FOR EMC FILTER EFFECT


Numéro d'application EP2023083930
Numéro de publication 2024/120995
Statut Délivré - en vigueur
Date de dépôt 2023-12-01
Date de publication 2024-06-13
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s) Hahn, Dr. Markus

Abrégé

An intermediate circuit capacitor unit with EMC filter effect (ZKKEMF) according to the invention, for arrangement in the current path between a DC voltage source, in particular a high-voltage battery (HVB), and a power-electronics unit (LE), comprises: two busbars (S), a first end of each of which can be connected to a DC voltage source and a second end of each of which can be connected to a power-electronics unit (LE); and at least two intermediate circuit capacitors (C), which are arranged between the busbars (S); wherein on each busbar (S) at least one magnetic core (MK) is arranged between two intermediate circuit capacitors (C) for damping common-mode interference; at least one pair of Y capacitors (Oy); wherein each of the Y capacitors (Oy) of a pair of Y capacitors (Gy) connects a respective busbar (S) to the electrical ground (GND); and at least one common-mode choke (CMC) which encloses both busbars (S); wherein the at least one pair of Y capacitors (Cy) and the common-mode choke (CMC) are designed to damp common-mode interference.

Classes IPC  ?

  • H02M 1/14 - Dispositions de réduction des ondulations d'une entrée ou d'une sortie en courant continu
  • H02M 3/00 - Transformation d'une puissance d'entrée en courant continu en une puissance de sortie en courant continu
  • H02M 7/00 - Transformation d'une puissance d'entrée en courant alternatif en une puissance de sortie en courant continuTransformation d'une puissance d'entrée en courant continu en une puissance de sortie en courant alternatif
  • H02M 1/12 - Dispositions de réduction des harmoniques d'une entrée ou d'une sortie en courant alternatif

6.

STEEL WIRE AND SPRING WITH EXCELLENT ANTIBACTERIAL PROPERTIES AND CORROSION RESISTANCE AND METHOD FOR MANUFACTURING SAME


Numéro d'application KR2023001501
Numéro de publication 2023/167434
Statut Délivré - en vigueur
Date de dépôt 2023-02-02
Date de publication 2023-09-07
Propriétaire
  • KISWIRE LTD. (République de Corée)
  • SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s)
  • Yu, Gwang Weon
  • Zaumseil, Wolf-Thilo
  • Gunthner, Martin

Abrégé

The present invention relates to a steel wire and spring with excellent antibacterial properties and corrosion resistance and a method for manufacturing same. The steel wire with excellent antibacterial properties and corrosion resistance, according to the present invention, comprises: a steel wire; and a plating layer formed on the steel wire, wherein the plating layer includes: a Zn-Al plating layer plated on the surface of the steel wire; and a doping layer formed by doping a metal in a colloidal form on the surface of the Zn-Al plating layer. The method for manufacturing the steel wire with excellent antibacterial properties and corrosion resistance, according to the present invention, comprises a plating step of forming a plating layer on the surface of the steel wire, wherein the plating step comprises: a surface plating step of plating the surface of the steel wire to form a Zn-Al plating layer; and a doping step of doping a metal in a colloidal form on the surface of the Zn-Al plating layer to form a doping layer.

Classes IPC  ?

  • C23C 28/02 - Revêtements uniquement de matériaux métalliques
  • C23C 28/00 - Revêtement pour obtenir au moins deux couches superposées, soit par des procédés non prévus dans un seul des groupes principaux , soit par des combinaisons de procédés prévus dans les sous-classes et
  • C25D 7/06 - FilsBandesFeuilles
  • C23C 2/06 - Zinc ou cadmium ou leurs alliages
  • C23C 2/38 - FilsTubes
  • C23C 18/16 - Revêtement chimique par décomposition soit de composés liquides, soit de solutions des composés constituant le revêtement, ne laissant pas de produits de réaction du matériau de la surface dans le revêtementDépôt par contact par réduction ou par substitution, p. ex. dépôt sans courant électrique

7.

THIN-WALLED PIPE, METAL FLAT MATERIAL, AND METHOD FOR PRODUCING A THIN-WALLED PIPE


Numéro d'application EP2022081595
Numéro de publication 2023/088799
Statut Délivré - en vigueur
Date de dépôt 2022-11-11
Date de publication 2023-05-25
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s) Vogel, Egbert

Abrégé

A thin-walled pipe according to the invention has the following features: a thin metal flat material (22), rolled or bent to form a pipe, having a wall thickness of 0.05-1.00 mm, the longitudinal edges (24, 26) of which are connected together by connecting elements engaging form-fittingly in one another along a connecting portion (6) that extends in the pipe longitudinal direction (8); wherein the connecting elements are protrusions (28) on the first longitudinal edge (24) of the flat material (22) and corresponding cutouts (12) in the second longitudinal edge (26) of the flat material (22); wherein at least one protrusion (10) engages in a corresponding cutout (12) such that the flanks of the protrusion (10) rest, at least regionally, in the pipe longitudinal direction against the respectively adjacent flanks of the corresponding cutout (12); wherein at least one pair (32, 34) made up of a protrusion flank and of a cutout flank bearing thereon, as seen in an axial section plane (A-A) extending along the connecting portion (6), has in each case an inclined course from the pipe outer wall to the pipe inner wall; and wherein at least one pair (32, 34) made up of a protrusion flank and of a cutout flank bearing thereon, as seen in an axial section plane (A-A) extending along the connecting portion (6), encloses in each case an angle of 15-75° with the pipe radial plane.

Classes IPC  ?

  • F16L 9/17 - Tuyaux rigides obtenus par cintrage longitudinal d'une feuille et raccordement des arêtes
  • B21C 37/10 - Fabrication de tubes à joints rivés
  • F16L 9/21 - Tuyaux rigides constitués de matériaux absorbant le son ou avec une structure absorbant le son

8.

SCHERDEL


Numéro de série 79306598
Statut Enregistrée
Date de dépôt 2020-12-03
Date d'enregistrement 2022-05-24
Propriétaire SCHERDEL INNOTEC Forschungs- und Entwicklungs-GmbH (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules

Produits et services

Common metals and their alloys, unwrought or semi-wrought; pipes and tubes of metal; goods of metal and iron, namely, metal hardware namely springs, wire, steel wire, non-electric wires of common metal, metal hose clamps, steel sheets, steel bars, steel rails, steel strips, steel pipes, steel tubes, steel forgings, steel tubes, steel balls, steel chains, steel rods, steel plates, steel in sheet, rod, bar and/or billet form, metal profiles made of steel, iron, nickel, titanium and other metals and their alloys; metal hardware, namely, springs with stampings and bent components; metal spring clips for fastening for general use; self-tensioning metal fasteners, namely, bolts, nails, rivets, screws Springs being parts of machines, including motors and engines, in particular valve springs, piston ring springs, pressure springs, tension springs, torsion springs, scroll springs, motive springs, spiral springs, sleeve springs, disc springs, packing ring springs, including the aforesaid springs being stampings and bent components; pole boxes being parts of electric motors made using the stamping and bending method; linear actuators and pneumatic valve actuators, namely, small electromagnetic cylinder and other electromechanical pneumatic cylinders for power transmission or being actuating elements for use in head rests and in connection with pedestrian protection systems for vehicles and as reversible actuators for lifting engine bonnets; valves, clamping devices, camshaft adjusters and belt tensioners and mechanical valve train systems composed of the aforesaid goods, all being parts of industrial engines and electric motors; metalworking machines and machine tools, in particular production machines for working and manufacturing metal goods, metal assembly machines for industrial manufacturing and assembly processes and assembly installations or assembly workstations composed of the aforesaid goods, milling machines; metal working machines for fabrication and custom assembling of articles of metal and standard installations composed thereof; machine bases, bases for machine tools, machine beds, coordinate graphs and single axis stages, tool stores, all being mechanical devices being parts of cargo handling machines for tools in industrial machining processes and parts of tool handling systems composed of cargo handling machines for tools; mechanical devices being parts of power-operated lifting machines for changing pallets in industrial manufacturing and parts for pallet changing systems composed of power-operated lifting machines for changing pallets in industrial manufacturing; machine casings, machine claddings, and protective casings, all being parts of metalworking machines; machine couplings and transmission components except for land vehicles; springs being parts of machines; embossers and bending tools, coining dies, progressive tools for the multi-stage processing of metal goods, transfer tools for reshaping and geometric working of metal goods and isostatic pressing tools, all being mechanical tools and being parts of metalworking machines; peripheral units, namely, machines and mechanical devices being metalworking machines and metalworking machine tools for handling, gripping, extracting or transfer of work pieces in industrial machining processes Seat frames being structural parts of land vehicles; assembly parts for vehicles being structural parts of land vehicles, namely, mechanical spring-operated parts of metal for closing and opening flaps, doors and covers, in particular spring brackets to prevent self-opening; metal goods manufactured using stamping and bending processes being structural parts of vehicle brake systems; structural parts of land vehicles, namely, metal structures for vehicle seats, mechanical parts for seat control operating and seat adjustment; goods of metal being structural parts of arm rests for automobile seats, mechanical parts being structural parts of land vehicles for operating and adjustment for use in seat control operating and seat adjustment systems; structural parts of land vehicles and vehicle seats, namely, metal inserts for upholstery, inlay and upholstery threads for seats or upholstery, metal springs and small items of metal hardware being spring elements for seat bases or spring elements for the backs of vehicle seats; spring mats being structural parts of vehicle seats and vehicle upholstery

9.

CORRUGATED SPRING


Numéro d'application EP2020051187
Numéro de publication 2020/152062
Statut Délivré - en vigueur
Date de dépôt 2020-01-17
Date de publication 2020-07-30
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s) Eulefeld, Hermann

Abrégé

The corrugated spring (2) according to the invention comprises: a plurality of windings (10, 12) with a spring strip or spring wire cross-section which is substantially flat, in particular a rectangular spring strip cross-section, and a first and a second spring end winding (4, 6); wherein at least some of the windings (10, 12) define a repeating winding sequence (8) made of a non-corrugated winding (10) and a corrugated winding (12); the windings (10, 12) with the repeating winding sequence (8) have multiple non-corrugated and corrugated windings (10, 12), said non-corrugated and corrugated windings being arranged in an alternating manner, and each corrugated winding (12) has multiple wave crests (14) and wave valleys (16) such that the wave valleys (16) of a corrugated winding (12) face the respective non-corrugated winding (10) arranged therebelow and the wave crests (14) of the corrugated winding (12) face the respective non-corrugated winding (10) arranged thereabove; and the windings (10, 12) with the repeating winding sequence (8) comprise all the windings of the corrugated spring (2) or all of the windings of the corrugated spring (2) with the exception of at least one of the first and the second spring end winding (4, 6), in particular with the exception of the first and the second spring end winding (4, 6).

Classes IPC  ?

  • F16F 1/04 - Ressorts enroulés
  • F16F 1/32 - Ressorts en forme de coupellesRessorts en forme de disques légèrement concaves
  • F16C 25/04 - Paliers à contact lisse à autoréglage
  • F16C 25/08 - Roulements à billes ou à rouleaux à autoréglage

10.

Spring package with stamped and bent supporting ring


Numéro d'application 16701980
Numéro de brevet 11415192
Statut Délivré - en vigueur
Date de dépôt 2019-12-03
Date de la première publication 2020-06-18
Date d'octroi 2022-08-16
Propriétaire SCHERDEL INNOTEC FORSCHUNGS-UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s)
  • Doetterl, Peter
  • Andritzky, Franz
  • Schraml, Alexander

Abrégé

The present invention relates to a spring package (2) for use in a clutch and/or in a transmission, comprising a first supporting ring (4), a second supporting ring (6) which is arranged spaced apart (parallel) from the first supporting ring (4) in the axial direction, and a plurality of coil springs (8) arranged between the first supporting ring (4) and the second supporting ring (6) in distributed manner across the circumference thereof, wherein at least one of the supporting rings (4, 6) is formed from a sheet-metal strip (22) which is stamped and then bent into a ring shape and the ends of which are permanently connected to each other. Furthermore, the invention also relates to a method for producing a supporting ring (4, 6) for a spring package (2) according to the invention, comprising the following steps: stamping a sheet-metal strip (22) of predetermined length (l) and predetermined width (b), introducing spring holders (10; 68), introducing impressions on a longitudinal edge (26) of the sheet-metal strip (22) while forming a ring shape; and connecting the two axial ends.

Classes IPC  ?

  • F16F 3/04 - Ensembles de ressorts constitués par plusieurs ressorts, p. ex. pour réaliser une caractéristique d'élasticité voulue avec ressorts en acier ou faits d'un autre matériau, ayant une friction intérieure faible composés uniquement de ressorts enroulés
  • B21D 22/02 - Estampage utilisant des dispositifs ou outils rigides
  • F16D 127/02 - Mécanismes de desserrage ou de relâchement

11.

Oil scraper ring spring for an oil scraper ring and oil scraper ring


Numéro d'application 16607547
Numéro de brevet 11143301
Statut Délivré - en vigueur
Date de dépôt 2018-04-24
Date de la première publication 2020-03-05
Date d'octroi 2021-10-12
Propriétaire SCHERDEL INNOTEC FORSCHUNGS-UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s)
  • Mielke, Peter
  • Heindl, Manuel
  • Zimmermann, Maik

Abrégé

The present invention relates to an oil scraper ring spring (1) for an oil scraper ring (3) comprising the oil scraper ring spring (1), an upper and a lower metal ring (21, 22) and provided for being mounted in an oil ring groove of a piston. The oil scraper ring spring (1) comprises a plurality of upper regions (5) and a plurality of lower regions (7) arranged in alternating manner in a circumferential direction so as to be spaced in an axial direction; connecting regions (9) each connecting the adjacent upper and lower regions (5, 7) to each other. Each of the upper and lower regions (5, 7) comprises: a nose section (13) disposed at the inner circumferential end and adapted to push the respectively abutting upper or lower metal ring (21, 22) radially outwardly, and having a through-opening (15); an abutment section (17) extending radially between the nose section (13) and the outer circumferential end and configured to have the respective upper metal ring (21) abutting thereon or the respective lower metal ring (22) abutting thereon; wherein the abutment section (17) has a recess (19) formed therein the depth of which, relative to the abutting area of the abutment section (17), increases in the radial direction towards the through-opening (15), and the width of which increases in the radial direction towards the through-opening (15); wherein the recess (19) in the abutment section (17) has substantially the shape of a half-funnel; wherein the half-funnel has an opening angle of 30° to 150°, in particular of 30° to 60°, or wherein the upper side edges of the recess (19) span an angular segment of 5-50°, in particular 5-15°; and wherein increasing the depth and width of the recess (19) radially inwardly together with the through-opening (15) serves to increase and accelerate the oil flow to the piston center.

Classes IPC  ?

  • F16J 9/06 - Segments de piston, leurs logementsSegments d'étanchéité de structure similaire en général utilisant des ressorts séparés pour dilater les segmentsRessorts à cet effet

12.

Spring assembly having a coil spring and an anti-entanglement element


Numéro d'application 16489558
Numéro de brevet 11199234
Statut Délivré - en vigueur
Date de dépôt 2018-02-28
Date de la première publication 2019-12-19
Date d'octroi 2021-12-14
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS GMBH (Allemagne)
Inventeur(s)
  • Grassold, Achim
  • Foucart, Patrick

Abrégé

The present invention relates to a spring assembly, including: a coil spring having an inner space formed by the spring windings thereof; and an anti-entanglement element for protection against entanglement of the spring assembly, in particular with at least one further spring assembly or with at least one other coil spring; wherein the anti-entanglement element is partially disposed in the inner space formed by the spring windings and extends longitudinally through at least a portion of the inner space; and wherein the anti-entanglement element (14, 26) is provided in the form of an anti-entanglement stirrup, formed separately from the coil spring and clampingly supported in the inner space; or wherein the anti-entanglement element is provided in the form of an anti-entanglement pin, which is formed separately from the coil spring and has a front loss-prevention or captive end and a rear stop end.

Classes IPC  ?

  • F16F 1/12 - Fixations ou montages
  • B65D 85/08 - Réceptacles, éléments d'emballage ou paquets spécialement adaptés à des objets ou à des matériaux particuliers pour objets compressibles ou flexibles en forme de baguettes ou tubulaires
  • B65D 25/10 - Dispositifs pour placer les objets dans les réceptacles
  • B65D 57/00 - Châssis ou supports internes pour objets souples, p. ex. raidisseursSéparateurs pour objets en piles ou en groupes, p. ex. pour empêcher l'adhérence des objets collants

13.

Torsion spring assembly, camshaft phaser and belt or chain tightener therewith


Numéro d'application 16304756
Numéro de brevet 10760635
Statut Délivré - en vigueur
Date de dépôt 2017-05-26
Date de la première publication 2019-09-12
Date d'octroi 2020-09-01
Propriétaire Scherdel Innotec Forschungs-Und Entwicklungs GmbH (Allemagne)
Inventeur(s)
  • Rausch, Thomas
  • Hannig, Georg
  • Angermann, Christoph

Abrégé

A torsion spring assembly according to the invention includes a torsion spring having a cylindrical spring body of wound spring wire and with a plurality of torsion spring windings, and having first and second torsion spring ends for taking up forces in a direction of rotation, and a damping spring abutting the torsion spring on the inner side and having a cylindrical spring body of wound spring wire and with a plurality of damping spring windings, and having first and second damping spring wire ends, wherein the damping spring windings have their outer sides extending partially into the space formed between two respectively adjacent torsion spring windings and abutting in particular rounded, round or beveled inner abutment areas of respectively adjacent torsion spring windings with substantially radially outwardly directed bias.

Classes IPC  ?

  • F01L 1/34 - Systèmes de distribution à soupapes, p. ex. à soupapes de levage caractérisés par des moyens de changer la période d'une soupape sans changer la durée de l'ouverture
  • F16F 3/06 - Ensembles de ressorts constitués par plusieurs ressorts, p. ex. pour réaliser une caractéristique d'élasticité voulue avec ressorts en acier ou faits d'un autre matériau, ayant une friction intérieure faible composés uniquement de ressorts enroulés une partie desquels sont placés autour des autres de telle sorte qu'ils s'amortissent les uns les autres par frottement mutuel
  • F01L 1/344 - Systèmes de distribution à soupapes, p. ex. à soupapes de levage caractérisés par des moyens de changer la période d'une soupape sans changer la durée de l'ouverture en modifiant la position angulaire relative entre le vilebrequin et l'arbre à came, p. ex. à l'aide d'un engrenage hélicoïdal
  • F16F 1/02 - Ressorts en acier ou faits d'un autre matériau ayant une faible friction intérieureRessorts enroulés, de torsion, à lame, en forme de coupelles, à corps annulaire ou similaire, le matériau de ressort ne jouant pas de rôle
  • F16F 1/04 - Ressorts enroulés
  • F16H 7/12 - Moyens pour faire varier la tension des courroies, des câbles ou des chaînes par réglage de la position de l'axe d'une poulie d'une poulie folle
  • F01L 1/02 - Commande de la soupape
  • F01L 1/46 - Parties constitutives, détails ou accessoires, non couverts par un des sous-groupes précédents
  • F01L 1/00 - Systèmes de distribution à soupapes, p. ex. à soupapes de levage
  • F16H 7/08 - Moyens pour faire varier la tension des courroies, des câbles ou des chaînes

14.

OIL SCRAPER RING SPRING FOR AN OIL SCRAPER RING AND OIL SCRAPER RING


Numéro d'application EP2018060414
Numéro de publication 2018/197450
Statut Délivré - en vigueur
Date de dépôt 2018-04-24
Date de publication 2018-11-01
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s)
  • Mielke, Peter
  • Heindl, Manuel
  • Zimmermann, Maik

Abrégé

The present invention relates to an oil scraper ring spring (1) for an oil scraper ring (3), which has the oil scraper ring spring (1), an upper and a lower metal ring (21, 22) and which is provided for being installed in an oil ring groove of a piston. Said oil scraper ring spring comprises multiple upper regions (5) and multiple lower regions (7) which are arranged in alternation in a circumferential direction so as to have a spacing in an axial direction, and connecting regions (9) which each connect the adjacent upper and lower regions (5, 7) to one another. Each of the upper and the lower regions (5, 7) has the following: a lug section (13), which is arranged at the inner circumferential end and which is designed to push the respectively abutting upper or lower metal ring (21, 22) radially outward and which has a passage opening (15); a bearing section (17), which extends radially between the lug section (13) and the outer circumferential end and which is designed such that the respective upper metal ring (21) bears thereon or the respective lower metal ring (22) bears thereon; wherein, in the bearing section (17), there is formed a depression (19), the depth of which in relation to the bearing surface of the bearing section (17) increases in a radial direction toward the passage opening (15) and the width of which increases in the radial direction toward the passage opening (15); wherein the depression (19) in the bearing section (17) has substantially the shape of a half-funnel; wherein the half-funnel has an opening angle of 30° to 150°, in particular of 30° to 60°, or wherein the upper side edges of the depression (19) span an angle segment of 5-50°, in particular of 5-15°; and wherein the increase of the depth and width of the depression (19) radially inward serves, together with the passage opening (15), for increasing and accelerating the oil flow toward the piston center.

Classes IPC  ?

  • F16J 9/06 - Segments de piston, leurs logementsSegments d'étanchéité de structure similaire en général utilisant des ressorts séparés pour dilater les segmentsRessorts à cet effet

15.

SPRING ASSEMBLY HAVING A COIL SPRING AND AN ANTI-ENTANGLEMENT ELEMENT


Numéro d'application EP2018054895
Numéro de publication 2018/158296
Statut Délivré - en vigueur
Date de dépôt 2018-02-28
Date de publication 2018-09-07
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s)
  • Grassold, Achim
  • Foucart, Patrick

Abrégé

The invention relates to a spring assembly (2, 34, 46), comprising: a coil spring (4, 36) having an interior space formed by the turns (6, 38) of the coil spring; and an anti-entanglement element (14, 26, 48) for protecting the spring assembly (2, 34, 46) from entanglement, in particular from entanglement with at least one further spring assembly (2, 34, 46) or with at least one other coil spring (4, 36), the anti-entanglement element (14, 26, 48) being arranged at least partly in the interior space formed by the turns (6, 38) and extending through at least part of the interior space in the longitudinal direction, and the anti-entanglement element (14, 26) being formed as an anti-entanglement bow (14, 26), in particular an anti-entanglement wire bow separate from the coil spring (4, 36), which is retained in the interior space in a clamping manner; or the anti-entanglement element (48) being formed as an anti-entanglement pin (48), in particular an anti-entanglement plastic pin separate from the coil spring (4, 36), said pin having a front retaining end and a rear stop end.

Classes IPC  ?

  • F16F 1/12 - Fixations ou montages
  • B65D 57/00 - Châssis ou supports internes pour objets souples, p. ex. raidisseursSéparateurs pour objets en piles ou en groupes, p. ex. pour empêcher l'adhérence des objets collants
  • B65D 67/00 - Genres ou types d'éléments d'emballage non prévus ailleurs

16.

TORSION SPRING COMPRISING DIFFERENT WINDING DIAMETERS


Numéro d'application EP2018052513
Numéro de publication 2018/141845
Statut Délivré - en vigueur
Date de dépôt 2018-02-01
Date de publication 2018-08-09
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s) Reintsch, Christoph

Abrégé

The invention relates to a torsion spring, comprising: a wound spring wire having a plurality of spring windings; and a first and a second spring wire end; wherein the torsion spring is designed to absorb a rotational force and/or a torque during an angular/rotational motion acting on the spring wire ends; and wherein the spring windings comprise at least one spring winding region having a winding diameter profile; comprising a first section in which the winding diameter along a first angular region is a first larger winding diameter; and comprising a second section in which the winding diameter along a second angular region subsequently decreases from the first larger winding diameter to a second smaller winding diameter; and comprising a third section in which the winding diameter along a third angular region is subsequently the second smaller winding diameter; comprising a fourth section in which the winding diameter along a fourth angular region subsequently increases from the second smaller winding diameter to the first larger winding diameter.

Classes IPC  ?

  • F16F 1/04 - Ressorts enroulés
  • F16F 1/48 - Ressorts en matière plastique, p. ex. en caoutchoucRessorts faits d'un matériau à friction intérieure élevée caractérisés par le mode de travail travaillant principalement à la torsion

17.

TORSION SPRING ASSEMBLY, CAMSHAFT PHASER AND BELT OR CHAIN TIGHTENER THEREWITH


Numéro d'application EP2017062788
Numéro de publication 2017/203041
Statut Délivré - en vigueur
Date de dépôt 2017-05-26
Date de publication 2017-11-30
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s)
  • Rausch, Thomas
  • Hannig, Georg
  • Angermann, Christoph

Abrégé

According to the invention, a torsion spring assembly (2) comprises: a torsion spring (4) with a cylindrical flexible element consisting of a coiled spring wire having a plurality of torsion spring coils (6), and with a first and a second torsion spring wire end (8, 10) for absorbing the force in the direction of rotation; and an absorbing spring (20) lying on the interior of the torsion spring (4), and comprising a cylindrical flexible element made of a coiled spring wire, having a plurality of absorbing spring coils (22), and a first and a second absorbing spring wire end (24, 26). The outer faces of the absorbing spring coils (22) partially extend into the gap (28) created between each two neighbouring torsion spring coils (6), and lie on in particular round or bevelled inner contact areas (30) of each two neighbouring torsion spring coils (6) with a substantially outwardly-radial bias.

Classes IPC  ?

  • F16F 3/06 - Ensembles de ressorts constitués par plusieurs ressorts, p. ex. pour réaliser une caractéristique d'élasticité voulue avec ressorts en acier ou faits d'un autre matériau, ayant une friction intérieure faible composés uniquement de ressorts enroulés une partie desquels sont placés autour des autres de telle sorte qu'ils s'amortissent les uns les autres par frottement mutuel
  • F01L 1/00 - Systèmes de distribution à soupapes, p. ex. à soupapes de levage

18.

CIRCULAR SCREEN AND DEVICE FOR PRODUCING SAME


Numéro d'application EP2017059972
Numéro de publication 2017/191017
Statut Délivré - en vigueur
Date de dépôt 2017-04-26
Date de publication 2017-11-09
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s)
  • Lotter, Frank
  • Andritzky, Franz

Abrégé

A circular screen according to the invention comprises a substantially cylindrical and/or truncated cone-shaped main part which is made of a sheet metal strip wound into a plurality of sheet metal strip coils (4). The sheet metal strip describes a wavy line which oscillates about a reference plane and has wave peaks (6) and wave valleys (10). Adjacent sheet metal strip coils (4) lie against one another such that screen openings (11) are formed in the radial direction, and the height of the wave peaks (6) and the wave valleys (10) of the sheet metal strip coils (4) increases outwards in the radial direction with respect to the reference plane such that the size of the screen openings (11) increases radially outwards in the flow direction, or the height of the wave peaks (6) and the wave valleys (10) of the sheet metal strip coils (4) increases inwards in the radial direction with respect to the reference plane such that the size of the screen openings (11) increases radially inwards in the flow direction.

Classes IPC  ?

  • B07B 1/18 - Tamis à tambours
  • B07B 1/46 - Éléments de structure constitutifs des tamis en généralNettoyage ou chauffage des tamis
  • B21D 7/08 - Cintrage des barres, profilés ou tubes par passage entre des rouleaux ou à travers une matrice courbe
  • B21D 11/06 - Cintrage en hélice, ou en spiraleFaçonnage en une succession de coudes, p. ex. en forme de serpentins
  • B21D 13/04 - Opérations permettant d'obtenir des tôles, barres ou profilés, à surface ondulée ou sinueuse par laminage
  • B21D 53/00 - Fabrication d'autres objets particuliers

19.

DEVICE AND METHOD FOR PRODUCING A SPRING WIRE, DEVICE AND METHOD FOR MARKING A SPRING WIRE, DEVICE AND METHOD FOR PRODUCING SPRINGS FROM A SPRING WIRE, AND SPRING WIRE


Numéro d'application EP2015070811
Numéro de publication 2016/038180
Statut Délivré - en vigueur
Date de dépôt 2015-09-11
Date de publication 2016-03-17
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS GMBH (Allemagne)
Inventeur(s)
  • Bach, Markus
  • Bauer, Marco

Abrégé

The invention relates to a device for producing a spring wire (2) comprising: a wire production apparatus (8), which is designed in such a way that a spring wire (10) can be produced from a raw material, in particular by drawing; a checking unit (14), which is designed in such a way that the spring wire (10) can be checked for flaws, in particular material flaws and surface flaws; and a laser marking unit (18), which is designed in such a way that flawed regions of the spring wire (10), in particular regions of the spring wire (10) having material flaws and surface flaws, can be marked with a laser marking (44) in such a way that a part of the surface of the spring wire (10) can be removed and that a part of the surface of the spring wire (10) can be tempered in such a way that the color of the surface of the spring wire (10) is changed in this part. The wire production apparatus (8) is designed in such a way that the spring wire (10) can be guided past the checking unit (14) and past the laser marking unit (18).

Classes IPC  ?

  • B21C 37/04 - Fabrication de tôles, barres, fils, tubes ou profilés métalliques ou de produits semi-finis similaires, non prévue ailleursFabrication de tubes de forme particulière des barres ou fils métalliques
  • B21C 51/00 - Dispositifs de mesure, de calibrage, d'indication, de comptage ou de marquage, spécialement conçus pour être utilisés dans la production ou la manipulation des matériaux concernés par les sous-classes
  • B21F 35/02 - Cintrage ou déformation des extrémités de ressorts enroulés en des formes particulières
  • B21F 99/00 - Matière non prévue dans les autres groupes de la présente sous-classe
  • B21C 1/00 - Fabrication des tôles, fils, barres, tubes métalliques ou d'autres produits semi-finis similaires par étirage
  • B21F 35/00 - Fabrication de ressorts en fils métalliques
  • F16F 1/02 - Ressorts en acier ou faits d'un autre matériau ayant une faible friction intérieureRessorts enroulés, de torsion, à lame, en forme de coupelles, à corps annulaire ou similaire, le matériau de ressort ne jouant pas de rôle
  • B23K 26/00 - Travail par rayon laser, p. ex. soudage, découpage ou perçage
  • B23K 26/08 - Dispositifs comportant un mouvement relatif entre le faisceau laser et la pièce
  • B23K 26/362 - Gravure au laser

20.

SCHERDEL


Numéro d'application 013110267
Statut Enregistrée
Date de dépôt 2014-07-24
Date d'enregistrement 2015-02-24
Propriétaire SCHERDEL INNOTEC Forschungs- und Entwicklungs-GmbH (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 08 - Outils et instruments à main
  • 09 - Appareils et instruments scientifiques et électriques
  • 12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
  • 40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
  • 42 - Services scientifiques, technologiques et industriels, recherche et conception

Produits et services

Common metals and their alloys; Ironmongery, small items of metal hardware; Pipes and tubes of metal; Metal hardware; Connectors, of metal, for pipes; Steel wire; Steel sheets; Alloyed iron; Springs (small items of metal hardware), Including being stamped and bent parts; Spring clips (metal fastening materials); Self-tensioning metal fasteners; Metal inserts for upholstery. Springs being parts of machines or motors or engines, in particular valve springs, piston ring springs, pressure springs, tension springs, torsion springs, scroll springs, motive springs, spiral springs, sleeve springs, disc springs, packing ring springs, including the aforesaid springs being stampings and bent components; Pole boxes for electric motors manufactured using stamping and bending processes; Spring counterbalances being mechanical parts of machines for balancing Z axes; Small electromagnetic cylinder (actuators) and other electromechanical pneumatic cylinders for power transmission or being actuating elements for use in head rests and in connection with pedestrian protection systems for vehicles and as reversible actuators for lifting engine bonnets; Valves, Mounting elements, Camshaft adjusters and belt tensioners and mechanical valve train systems constructed from the aforesaid goods, being parts of motors or engines; Machines for metal working and machine tools, In particular production machines for working and manufacturing goods of common metal, assembly machines for industrial manufacturing and assembly processes and assembly installations or assembly workstations constructed from the aforesaid goods, Milling machines; Metal working machines for fabrication or custom assembling of articles of metal and standard installations composed thereof; Machine bases, bases for machine tools, machine beds (parts of machines), coordinateographs and single axis stages (parts of machines), tool stores (parts or accessories, included in class 7, for machines), mechanical devices being parts of or accessories for machines for handling tools in industrial machining processes and tool handling systems composed of the aforesaid goods; Mechanical devices being parts of or accessories for machines for changing pallets in industrial manufacturing and pallet changing systems composed of the aforesaid goods; Machine casings (parts of machines), machine claddings (parts of machines), protective casings being parts of machines; Couplings and transmission components except for land vehicles; Springs (parts of machines); Embossers/bending tools, mechanical stamping tools (machines), progressive tools (tools for the multi-stage processing of metal goods), transfer tools (tools for reshaping and geometric working of metal goods) and isostatic pressing tools, all being mechanical tools or parts or accessories for machines; Peripheral units, namely machines and mechanical devices for handling, gripping, extracting or transfer of work pieces in industrial machining processes; Mechanical parts for operating and adjustment for use in operating and adjustment systems in furniture. Hand tools and implements (hand operated) for the construction of machines, apparatus and vehicles, in particular for stamping and coining and for metal working and processing. Machines and mechanical devices for carrying out test processes in connection with industrial manufacture and test installations composed of the aforesaid goods; Switch cabinets (electricity) for use in industrial manufacturing and as accessories for machines; Surveying, photographic, optical, weighing, measuring, signalling and checking (supervision) apparatus and instruments; Electric apparatus and instruments for measuring, controlling, regulating or checking purposes being parts of machines or mechanical devices and for use in industrial machining processes; Apparatus for recording, transmission or reproduction of sound or images; Data processing equipment and computers; Magnetic data carries; Computer software, recorded, In particular for SPS and CNC machines. Seat frames being parts of vehicles; Assembly parts for vehicles, namely mechanical spring-operated parts of metal for closing and opening flaps, doors and covers, in particular spring brackets for securing of self-opening; Goods of common metal manufactured using stamping and bending processes being parts of brakes for vehicles; Parts of vehicles, Namely metal structures for vehicle seats, mechanical parts for operating and adjustment, and goods of metal being parts of armrests; Mechanical parts for operating and adjustment for use in operating and adjustment systems in vehicles; Inlay and upholstery threads for seats or upholstery in vehicles; Metal springs and small items of metal hardware being spring elements for seat bases or spring elements for the backs of vehicle seats; Spring mats being parts of seats or upholstery in vehicles. Treatment of materials by laser beam, Metallurgical processing, Heat treatment and coating of steel, Surface polishing, Millworking; Metal treating, Metal tempering, Hardening and tempering (treatment of materials); Metal treating using surface treatment and applying coatings, in particular zinc phosphating, coating using the immersion spinning process and spray process, Powder painting, Whirl sintering and Metal coating. Design and development of computer programs, in particular SPS and CNC programs; Technology services and research services; Industrial analysis and research services, in particular surveying, quality testing, materials testing.

21.

Undular washer


Numéro d'application 13983204
Numéro de brevet 09091315
Statut Délivré - en vigueur
Date de dépôt 2012-02-01
Date de la première publication 2014-02-20
Date d'octroi 2015-07-28
Propriétaire Scherdel Innotec Forschungs—Und Entwicklungs—GmbH (Allemagne)
Inventeur(s) Doetterl, Peter

Abrégé

The invention relates to a wave spring (2) which comprises a spring strip (4) which is coiled in a substantially circular-ring-shaped manner and, over the circumference, describes a wavy line which oscillates about a radial reference plane and has wave crests (6) and wave troughs. The ends of the circular-ring-shaped spring strip (4) are connected by means of a weld seam (10) which is arranged in a low-tension region of the wavy line of the spring strip (4) between a wave crest (6) and an adjacent wave trough (8).

Classes IPC  ?

  • F16F 1/34 - Bagues élastiques, c.-à-d. corps annulaires déformés radialement par une charge axiale
  • F16F 1/02 - Ressorts en acier ou faits d'un autre matériau ayant une faible friction intérieureRessorts enroulés, de torsion, à lame, en forme de coupelles, à corps annulaire ou similaire, le matériau de ressort ne jouant pas de rôle
  • F16F 1/32 - Ressorts en forme de coupellesRessorts en forme de disques légèrement concaves
  • B23K 15/00 - Soudage ou découpage par faisceau d'électrons

22.

Sensor element, in particular seat occupancy detection sensor element


Numéro d'application 13659560
Numéro de brevet 08698643
Statut Délivré - en vigueur
Date de dépôt 2012-10-24
Date de la première publication 2013-05-16
Date d'octroi 2014-04-15
Propriétaire
  • SCHERDEL INNOTEC Forschungs-und Entwicklungs-GmbH (Allemagne)
  • Forschungs-und Transferzentrum Leipzig e.V. and der HTWK Leipzig (Allemagne)
Inventeur(s)
  • Schmitt, Marco
  • Seitenglanz, Jan
  • Fiedler, Thomas
  • Barthold, Gisela
  • Rambold, Hans-Martin
  • Wiessner, Fabian
  • Eiserbeck, Michael

Abrégé

Seat-occupancy-detection-sensor-element featuring double-body/compression/spring (DBCS) in a recess of a base-member (BM); and slidable-member (SM) having a force-application-side (FAS) and inside facing the BM; measuring-coil (MC) arranged in the recess and surrounded by the DBCS and having wound-coil-wire (WCW); and current-generating/measuring/evaluating-unit (CGMEU) connected to the WCW; the DBCW abutting the BM on one side and being fixed to the SM on the side of the SM compressed by a force on the FAS, from a spring length either uncompressed or compressed by a predetermined extent; spring wire ends connected and electrically forming a spring-coil (SC); MC and SC coils constituting an inductively-coupled coil assembly (ICCA); and the CGMEU applying AC to the MC inducing AC in the DBCS, measuring voltage on the MC proportional to the ICCA's impedance, and ascertaining force on the SM's FAS.

Classes IPC  ?

  • B60K 28/00 - Dispositifs de sécurité pour la commande des ensembles de propulsion spécialement adaptés aux véhicules ou aménagés dans ceux-ci, p. ex. empêchant l'alimentation en carburant ou l'allumage en cas de danger
  • G08B 21/00 - Alarmes réagissant à une seule condition particulière, indésirable ou anormale, et non prévues ailleurs

23.

UNDULAR WASHER


Numéro d'application EP2012051684
Numéro de publication 2012/104348
Statut Délivré - en vigueur
Date de dépôt 2012-02-01
Date de publication 2012-08-09
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s) Doetterl, Peter

Abrégé

The invention relates to an undular washer (2) which comprises a spring strip (4) which is coiled in a substantially circular-ring-shaped manner and, over the circumference, describes a wavy line which oscillates about a radial reference plane and has wave crests (6) and wave troughs. The ends of the circular-ring-shaped spring strip (4) are connected by means of a weld seam (10) which is arranged in a low-tension region of the wavy line of the spring strip (4) between a wave crest (6) and an adjacent wave trough (8).

Classes IPC  ?

  • F16F 1/32 - Ressorts en forme de coupellesRessorts en forme de disques légèrement concaves

24.

DEVICE FOR CLOSING A PIVOTABLE FLAP OF A MOTOR VEHICLE


Numéro d'application EP2012051363
Numéro de publication 2012/101264
Statut Délivré - en vigueur
Date de dépôt 2012-01-27
Date de publication 2012-08-02
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s) Heinl, Thomas

Abrégé

A device according to the invention for closing a pivotable flap of a motor vehicle, in particular a motor-vehicle tailgate, comprises a first, hinge-bracket point of attachment for a spring on a hinge bracket of the flap; a second, bodywork point of attachment for a spring on a region which is fixed in relation to the flap; a spring, for example a tension spring or a pneumatic spring, which is arranged between the first, hinge-bracket point of attachment and the second, bodywork point of attachment; and a displacement device for the first, hinge-bracket or second, bodywork point of attachment of the spring. The displacement device can be activated by the control unit such that the first, hinge-bracket or the second, bodywork point of attachment of the spring is displaced from the starting position into a door-closing-displacement position, which can be determined by the control unit, with account being taken of the position of the motor vehicle, and in which the spring-force-opening moment, which results from the direction of action of the spring and the lever arm located at right angles thereto, is smaller than the closing flap-weight moment, in order for a closing movement of the flap to be initiated from the open flap position, and that the first, hinge-bracket or the second, bodywork point of attachment of the spring, in the event of a certain flap-pivoting position being detected, is reversed from the flap-closing displacement position into a reversing position at least a little closer to the starting position, in order for the closing energy of the flap to be reduced.

Classes IPC  ?

  • E05F 1/10 - Appareils de fermeture ou d'ouverture pour battants, non prévus ailleurs dans la présente sous-classe actionnés par ressort pour battants pivotants
  • E05F 15/12 - pour battants pivotants

25.

CORROSION-RESISTANT SPRING AND METHOD FOR PRODUCING SAME


Numéro d'application EP2012050444
Numéro de publication 2012/095493
Statut Délivré - en vigueur
Date de dépôt 2012-01-12
Date de publication 2012-07-19
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s)
  • Barthold, Gisela
  • Rambold, Hans-Martin
  • Beck, Franziska

Abrégé

A method according to the invention for producing a corrosion-resistant spring, in particular a compression spring for an injection pump or for a flap opening system of a motor vehicle, a tension spring, or a torsion spring, comprises the following steps: providing a spring wire made of an oil hardened and tempered, Si-CrNiV alloyed base material having a hardness of 400 - 490 HV2; winding the base material and cutting the base material to length to form a spring; grinding the spring ends of the spring; and forming an anti-corrosion layer having a thickness of 5 - 9 μm, in particular 6 - 8 µm, which extends over the circumference and the spring ends of the spring wire and which has a nitride layer and an outer oxide layer, which is introduced into the nitride layer and which has a surface hardness of 685 - 885 HV0.5, by subjecting the spring to a nitriding treatment, by post-oxidizing the spring in a salt bath, and by shot peening, in particular intermittently shot peening, the surface of the spring.

Classes IPC  ?

  • C23C 8/80 - Post-traitement
  • F16F 1/02 - Ressorts en acier ou faits d'un autre matériau ayant une faible friction intérieureRessorts enroulés, de torsion, à lame, en forme de coupelles, à corps annulaire ou similaire, le matériau de ressort ne jouant pas de rôle
  • F16F 1/06 - Ressorts enroulés dont les enroulements constituent une surface cylindrique
  • C21D 7/06 - Modification des propriétés physiques du fer ou de l'acier par déformation par travail à froid de la surface par grenaillage ou similaire
  • C21D 1/46 - Bains de sels

26.

ACTUATING DEVICE FOR AN EXHAUST FLAP


Numéro d'application EP2011005070
Numéro de publication 2012/052124
Statut Délivré - en vigueur
Date de dépôt 2011-10-11
Date de publication 2012-04-26
Propriétaire
  • AUDI AG (Allemagne)
  • SCHERDEL INNOTEC FORSCHUNGS UND ENTWICKLUNGS GMBH (Allemagne)
Inventeur(s)
  • Hinkelmann, Achim Hans
  • Staneff, Michael-Stefan
  • Seidel, Rüdiger

Abrégé

The invention relates to an actuating device for an exhaust flap of a boost pressure controller of turbocharged internal combustion engines, in which invention the exhaust flap is arranged pivotably in an exhaust-gas line, in particular in the housing of a turbine of an exhaust-gas turbocharger, and controls the opening cross section of a bypass line which bypasses the turbine in a manner which is dependent on the compressor-side boost pressure, wherein the exhaust flap is arranged on an actuating arm which is fastened on a shaft which is mounted rotatably in the exhaust-gas line, which shaft can be adjusted outside the exhaust-gas line via an actuating lever and a control rod which is articulated thereon and via a linear actuating motor. In order to avoid oscillation-induced buzzing noise in the actuating device, it is proposed that a frictional damper (34, 44, 46) is connected into the force flow between the shaft (24) and the control rod (30), in particular for system damping in the region of the exhaust flap (18).

Classes IPC  ?

  • F02B 37/18 - Commande des pompes par dérivation des gaz d'échappement

27.

SPRING WIRE, SPRING THEREWITH AND METHOD FOR PRODUCING SAME


Numéro d'application EP2011051562
Numéro de publication 2011/131379
Statut Délivré - en vigueur
Date de dépôt 2011-02-03
Date de publication 2011-10-27
Propriétaire
  • SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
  • ROESLAU WIRE GMBH & CO. KG (Allemagne)
  • WESTFÄLISCHE DRAHTINDUSTRIE GMBH (Allemagne)
Inventeur(s)
  • Ferfers, Willi-Josef
  • Fölber, Bernd
  • Thoma, Peter

Abrégé

The spring wire according to the invention comprises a base material, which is alloyed with SiCr and in particular oil tempered, and a hard zinc layer having a layer thickness of 4-10 μm that is applied to the surface of the base material.

Classes IPC  ?

  • C23C 2/38 - FilsTubes
  • C23C 2/02 - Pré-traitement du matériau à revêtir, p. ex. pour le revêtement de parties déterminées de la surface

28.

DEVICE FOR CLOSING A PIVOTING FLAP AND FLAP AND MOTOR VEHICLE HAVING SAID DEVICE


Numéro d'application EP2011051160
Numéro de publication 2011/095432
Statut Délivré - en vigueur
Date de dépôt 2011-01-27
Date de publication 2011-08-11
Propriétaire SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s) Heinl, Thomas

Abrégé

The invention relates to a device (30) for closing a pivoting flap (4), in particular a tailgate of a motor vehicle, comprising a first hinge rod side connection point (16) for a force element (14) to a hinge rod (26) of the flap (4); a second body-side connection point (20) for a force element (14) on a stationary region opposite the flap (4); and a force element (14), in particular a spring element (14), such as a tension spring or a gas compression spring, which is arranged between the first hinge rod side connection point (16) and the second body-side connection point (20). According to the invention, the first hinge rod side connection point (16) of the spring element (14) of the force element (14) can be moved so that the closing torque is increased and the flap (4) closes.

Classes IPC  ?

29.

Scherdel


Numéro d'application 1033947
Statut Enregistrée
Date de dépôt 2010-01-25
Date d'enregistrement 2010-01-25
Propriétaire SCHERDEL INNOTEC Forschungs- und Entwicklungs-GmbH (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 08 - Outils et instruments à main
  • 09 - Appareils et instruments scientifiques et électriques
  • 12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
  • 40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
  • 42 - Services scientifiques, technologiques et industriels, recherche et conception

Produits et services

Common metals and their alloys; ironmongery, small items of metal hardware; pipes and tubes of metal; goods of metal and iron, included in this class; springs (small items of metal hardware), including stampings and bent components; spring clips (metal fastening materials); self-tensioning metal fasteners. Springs being parts of machines or motors or engines, in particular valve springs, piston ring springs, pressure springs, tension springs, torsion springs, scroll springs, motive springs, spiral springs, sleeve springs, disc springs, packing ring springs, including the aforesaid springs being stampings and bent components; pole boxes for electric motors made using the stamping and bending method; spring counterbalances being mechanical parts of machines for balancing Z axes; small electromagnetic cylinder (actuators) and other electromechanical pneumatic cylinders for power transmission or being actuating elements for use in head rests and in connection with pedestrian protection systems for vehicles and as reversible actuators for lifting engine bonnets; valves, clamping devices, camshaft adjusters and belt tensioners and mechanical valve train systems composed of the aforesaid goods, being parts of engines or motors; metalworking machines and machine tools, in particular production machines for working and manufacturing metal goods, assembly machines for industrial manufacturing and assembly processes and assembly installations or assembly workstations composed of the aforesaid goods, milling machines; metal working machines for fabrication or custom assembling of articles of metal and standard installations composed thereof; machine bases, bases for machine tools, machine beds (parts of machines), cordinate graphs and single axis stages (parts of machines), tool stores (parts or accessories, included in this class, for machines), mechanical devices being parts of or accessories for machines for handling tools in industrial machining processes and tool handling systems composed of the aforesaid goods; mechanical devices being parts of or accessories for machines for changing pallets in industrial manufacturing and pallet changing systems composed of the aforesaid goods; machine casings (parts of machines), machine claddings (parts of machines), protective casings being parts of machines; couplings and transmission components except for land vehicles; springs (parts of machines); embossers/bending tools, coining dies, progressive tools (tools for the multi-stage processing of metal goods), transfer tools (tools for reshaping and geometric working of metal goods) and isostatic pressing tools, all being mechanical tools or parts or accessories for machines; peripheral units, namely machines and mechanical devices for handling, gripping, extracting or transfer of work pieces in industrial machining processes. Hand tools and implements (hand operated) for the construction of machines, apparatus and vehicles, in particular for stamping and coining and for metal working and processing. Machines and mechanical devices for carrying out test processes in connection with industrial manufacture and test installations composed of the aforesaid goods; switch cabinets (electricity) for use in industrial manufacturing and as accessories for machines; surveying, photographic, optical, weighing, measuring, signalling and checking (supervision) apparatus and instruments; electric apparatus and instruments for measuring, controlling, regulating or checking purposes being parts of machines or mechanical devices and for use in industrial machining processes; apparatus for recording, transmission or reproduction of sound or images; data-processing equipment and computers; magnetic data carriers; computer software (recorded), in particular for SPS and CNC machines. Seat frames being parts of vehicles; assembly parts for vehicles, namely mechanical spring-operated parts of metal for closing and opening flaps, doors and covers, in particular spring brackets to prevent self-opening, metal goods manufactured using stamping and bending processes being parts of vehicle brake systems; parts of vehicles, namely metal structures for vehicle seats, mechanical parts for operating and adjustment and goods of metal being parts of arm rests, mechanical parts for operating and adjustment for use in operating and adjustment systems, metal inserts for upholstery, inlay and upholstery threads for seats or upholstery, metal springs and small items of metal hardware being spring elements for seat bases or spring elements for the backs of vehicle seats, spring mats being parts of seats or vehicle upholstery. Treatment of materials, metal treating, metal tempering, hardening and tempering (treatment of materials); metal treating using surface treatment and applying coatings, in particular zinc phosphating, coating using the immersion spinning process and spray process, powder coating, whirl sintering and galvanization. Development and design of computer programs, in particular SPS and CNC programs; technology services and research services; industrial analysis and research, in particular surveying, quality testing, materials testing.

30.

METHOD AND DEVICE FOR REMOVING A FILM FROM A PLATE-LIKE SUPPORT OR A FILM


Numéro d'application EP2009051165
Numéro de publication 2009/109436
Statut Délivré - en vigueur
Date de dépôt 2009-02-03
Date de publication 2009-09-11
Propriétaire
  • FOLIOTEC GMBH (Allemagne)
  • SCHERDEL INNOTEC FORSCHUNGS- UND ENTWICKLUNGS-GMBH (Allemagne)
Inventeur(s)
  • Fischer, Lutz
  • Gebhardt, Werner
  • Dunkel, Thomas
  • Neumeier, Stefan

Abrégé

The invention relates to a method and a device for removing a film, in particular a protective film (4), adhering to an essentially flat surface of a plate-like support or adhering to a flat, flexible base film (1) due to adhesion and/or electrostatic charge. The protective film is lifted off of the support or base film by way of a height-adjustable pressure application element (8) comprising an adhesive layer or a self-adhering strip (9). The plate-like support, which is sized to a specific further processing size, or the base film or a multi-layered film arrangement is held at least at the front area on a support table by way of a vacuum suction device (3). After the protective film is raised, it is grasped by a gripper from behind at a removal device that is moveable relative to the support table and is pressed against a back support (6) at the removal device, said film being removed by moving the removal device and suctioned by a suction device.

Classes IPC  ?

  • B65H 41/00 - Machines pour séparer des bandes superposées
  • B29C 63/00 - Garnissage ou gainage, c.-à-d. application de couches ou de gainages préformés en matière plastiqueAppareils à cet effet
  • H01L 21/00 - Procédés ou appareils spécialement adaptés à la fabrication ou au traitement de dispositifs à semi-conducteurs ou de dispositifs à l'état solide, ou bien de leurs parties constitutives

31.

Miscellaneous Design


Numéro d'application 1004946
Statut Enregistrée
Date de dépôt 2009-01-15
Date d'enregistrement 2009-01-15
Propriétaire SCHERDEL INNOTEC Forschungs- und Entwicklungs-GmbH (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 08 - Outils et instruments à main
  • 09 - Appareils et instruments scientifiques et électriques
  • 40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau

Produits et services

Common metals and their alloys; metal building materials; transportable buildings of metal; materials of metal for railway tracks; cables and wires of common metals; ironmongery, small items of metal hardware; pipes and tubes of metal; goods of common metal, as far as included in this class. Machines for treatment of metal; machine coupling and transmission components (except for land vehicles); machine tools; motors and engines (including such for land vehicles). Hand tools and hand operated implements for the construction of machines, apparatus and vehicles. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision), life-saving and teaching apparatus and instruments; electric apparatus and instruments (as far as included in this class); apparatus for recording, transmission or reproduction of sound or images; magnetic data carriers and computers; fire-extinguishing apparatus. Treatment of materials.

32.

Scherdel


Numéro d'application 008439382
Statut Enregistrée
Date de dépôt 2009-07-02
Date d'enregistrement 2010-02-17
Propriétaire SCHERDEL INNOTEC Forschungs- und Entwicklungs-GmbH (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 08 - Outils et instruments à main
  • 09 - Appareils et instruments scientifiques et électriques
  • 12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
  • 40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
  • 42 - Services scientifiques, technologiques et industriels, recherche et conception

Produits et services
