Abrégé

Automotive lighting unit comprising a first lighting assembly able to backlight a transparent or semi-transparent portion of the front half-shell; the lighting assembly comprising: at least one light-guide plate made of photoconductive material, which is arranged inside the rear casing with a front sidewall of the plate facing the transparent or semi-transparent portion, and with a rear sidewall of the plate facing the rear casing; a first oblong light source which is located inside the rear casing at a first segment of the rear sidewall, and is capable of directing the light produced inside the light-guide plate so that the light travels inside the body of the light-guide plate towards the front sidewall; and a second light source which is located inside the rear casing at a second segment of the rear sidewall complementary to the first segment, and is capable of directing the light produced inside the light-guide plate, so that this light travels inside the body of the light-guide plate towards a first lateral sidewall of the light-guide plate connecting the second segment of the rear sidewall of the light-guide plate to the front sidewall of the same light-guide plate. The light-guide plate is provided with a transversal groove that extends along one of the two faces of the light-guide plate, from the front sidewall of the light-guide plate towards the rear sidewall of the light-guide plate, so as to be interposed between the first lateral sidewall of the plate and the front sidewall of the plate, and is crossed by the light reflected by the first lateral sidewall of the light-guide plate towards the front sidewall of the light-guide plate.

Classes IPC  ?

• F21S 43/239 - Guides de lumière caractérisés par la forme du guide de lumière en forme de plaque
• F21S 43/14 - Diodes électroluminescentes [LED]
• F21S 43/243 - Guides de lumière caractérisés par la région d’émission émettant la lumière depuis une ou plusieurs de ses extrémités
• F21S 43/249 - Guides de lumière ayant plusieurs sources lumineuses couplées au guide de lumière
• F21S 43/241 - Guides de lumière caractérisés par la forme du guide de lumière à forme complexe
• F21Y 105/16 - Sources lumineuses planes comprenant un réseau bidimensionnel d’éléments générateurs de lumière ponctuelle caractérisées par la forme d’ensemble du réseau bidimensionnel carrée ou rectangulaire, p. ex. pour les panneaux de lumière

Abrégé

Machine for welding workpieces made of plastic materials of the type comprising: two workpiece-carrying fixtures each provided with a template having a recess adapted to accommodate a respective plastic workpiece to be welded; a moving assembly adapted to selectively couple and press the two workpiece-carrying fixtures to/against each other, so as to tighten the plastic workpieces housed in the templates one against the other; a vibrating member which is adapted to vibrate on command a first workpiece-carrying fixture; automatic piece locking means adapted to selectively lock/immobilise the plastic workpiece to be welded inside the template of the first workpiece-carrying fixture; and an electronic control unit adapted to drive/control said automatic piece locking means.

Classes IPC  ?

• B29C 65/78 - Moyens pour la manipulation des éléments à assembler, p. ex. pour la fabrication de récipients ou d'objets creux
• B29C 65/08 - Assemblage d'éléments préformésAppareils à cet effet par chauffage, avec ou sans pressage avec des vibrations ultrasonores
• B29C 65/16 - Rayon laser
• F21S 43/50 - Dispositifs de signalisation spécialement adaptés à l’extérieur des véhicules, p. ex. feux de freinage, feux clignotants indicateurs de direction ou feux de recul caractérisés par des composants esthétiques non prévus ailleurs, p. ex. des enjoliveurs, des parois de séparation ou des couvercles
• F21S 41/29 - Leur fixation
• B29C 65/06 - Assemblage d'éléments préformésAppareils à cet effet par chauffage, avec ou sans pressage en utilisant la friction, p. ex. soudage par rotation
• B29C 65/00 - Assemblage d'éléments préformésAppareils à cet effet
• B29L 31/00 - Autres objets particuliers

Abrégé

a); calculating a position of the window (F) as a function of said angular position (θ(t)) of the motor (M); and reversing the direction of rotation of the motor (M) if the position of the window (F) falls within an anti-pinch zone (APZ) and the movement of the motor (M) is at least partially blocked.

Classes IPC  ?

• H02P 27/05 - Dispositions ou procédés pour la commande de moteurs à courant alternatif caractérisés par le type de tension d'alimentation utilisant une tension d’alimentation à fréquence variable, p. ex. tension d’alimentation d’onduleurs ou de convertisseurs utilisant une alimentation en courant alternatif à la fois pour le circuit rotorique et le circuit statorique, la fréquence d’alimentation d’au moins l’un des circuits étant variable
• H02P 25/10 - Moteurs à collecteur, p. ex. moteurs à répulsion
• E05F 15/41 - Détection par contrôle de la force ou du couple transmisAccouplements de sécurité avec activation en fonction du couple ou de la force, p. ex. accouplements glissants
• E05F 15/697 - Mécanismes pour battants mus par une force motrice utilisant des actionneurs électriques utilisant des électromoteurs rotatifs pour battants à coulissement vertical spécialement adaptés aux fenêtres de véhicule moteurs à cet effet, p. ex. motoréducteurs
• H02P 7/00 - Dispositions pour réguler ou commander la vitesse ou le couple de moteurs électriques à courant continu

Abrégé

A lighting and/or signaling device, comprising a light guide, at least one LED light source, wherein an inlet and diffusion wall and the light outlet wall are opposite to each other along a main optical axis (X). The lighting portion comprises a middle lighting portion aligned with the LED light source and the light emission portion, and a peripheral lighting portion. The device comprises at least one reflector element associated with the light inlet and diffusion wall of the light guide and directly facing the respective extraction elements so as to reflect light towards the light outlet wall. A diffusion layer is arranged to cover the lighting portion on the side of the light outlet wall. Cylindrical optics are provided on the light outlet wall, at the middle lighting portion, which extract the incident light beams thereon, towards the diffusion layer.

Classes IPC  ?

• F21S 41/24 - Guides de lumière
• F21S 41/141 - Diodes électroluminescentes [LED]
• F21S 43/14 - Diodes électroluminescentes [LED]
• F21S 43/241 - Guides de lumière caractérisés par la forme du guide de lumière à forme complexe
• F21S 43/245 - Guides de lumière caractérisés par la région d’émission émettant la lumière depuis une ou plusieurs de ses surfaces principales
• F21S 43/249 - Guides de lumière ayant plusieurs sources lumineuses couplées au guide de lumière

Abrégé

An automotive lighting unit wherein the lighting assembly that backlights the front half-shell comprises: at least one light-guide body made of photoconductive material, which is placed inside the rear body and is structured to channel, by total internal reflection and towards said transparent or semi-transparent portion of the front half-shell, the light that enters into the light-guide body through a light-incoupling end or sidewall of the same light-guide body; an active light deflector device which is placed inside the rear body, facing the light-incoupling end or sidewall of said light-guide body; and an electrically-powered light source which is placed inside the rear body and emits, on command, a collimated light beam towards the active light deflector device; the active light deflector device being adapted to reflect/divert said collimated light beam towards the light-incoupling end or sidewall of said light-guide body, so that the collimated light beam can enter into the light-guide body and then travel inside the light-guide body by total internal reflection.

Classes IPC  ?

• F21S 43/247 - Guides de lumière ayant une seule source lumineuse couplée au guide de lumière
• B60Q 1/26 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs ayant principalement pour objet d'indiquer le contour du véhicule ou de certaines de ses parties, ou pour engendrer des signaux au bénéfice d'autres véhicules
• F21S 43/31 - Leur conception optique
• F21S 43/50 - Dispositifs de signalisation spécialement adaptés à l’extérieur des véhicules, p. ex. feux de freinage, feux clignotants indicateurs de direction ou feux de recul caractérisés par des composants esthétiques non prévus ailleurs, p. ex. des enjoliveurs, des parois de séparation ou des couvercles
• F21S 43/14 - Diodes électroluminescentes [LED]
• F21S 43/237 - Guides de lumière caractérisés par la forme du guide de lumière en forme de tige
• F21S 43/13 - Dispositifs de signalisation spécialement adaptés à l’extérieur des véhicules, p. ex. feux de freinage, feux clignotants indicateurs de direction ou feux de recul caractérisés par la source lumineuse caractérisés par le type de source lumineuse
• F21S 43/40 - Dispositifs de signalisation spécialement adaptés à l’extérieur des véhicules, p. ex. feux de freinage, feux clignotants indicateurs de direction ou feux de recul caractérisés par la combinaison de réflecteurs et de réfracteurs
• F21S 43/30 - Dispositifs de signalisation spécialement adaptés à l’extérieur des véhicules, p. ex. feux de freinage, feux clignotants indicateurs de direction ou feux de recul caractérisés par des réflecteurs
• F21S 43/239 - Guides de lumière caractérisés par la forme du guide de lumière en forme de plaque
• F21S 43/245 - Guides de lumière caractérisés par la région d’émission émettant la lumière depuis une ou plusieurs de ses surfaces principales
• F21V 8/00 - Utilisation de guides de lumière, p. ex. dispositifs à fibres optiques, dans les dispositifs ou systèmes d'éclairage
• G02B 26/08 - Dispositifs ou dispositions optiques pour la commande de la lumière utilisant des éléments optiques mobiles ou déformables pour commander la direction de la lumière

Abrégé

A virtual human-machine interface (1) system for a vehicle including at least one projection surface (3) disposed within the vehicle and a corresponding virtual human-machine interface method (1) for a vehicle are disclosed; said virtual human-machine interface system (1) comprising: - at least one micro-mirror projection means (5) arranged for projecting an image on said at least one projection surface (3); - at least one sensor means (7) arranged for detecting commands given by a user by determining the position of a part of the user's body within the vehicle; and - a control unit (9) arranged for controlling said human-machine interface system (1); the position of the image projected by the at least one projection means (5) within the vehicle being modifiable by means of a specific command given by the user.

Classes IPC  ?

• B60K 37/06 - Agencement des accessoires sur le tableau de bord des commandes, p.ex. boutons de commande
• B60K 35/00 - Instruments spécialement adaptés aux véhiculesAgencement d’instruments dans ou sur des véhicules

Abrégé

m) of the motor.

Classes IPC  ?

• E05F 15/41 - Détection par contrôle de la force ou du couple transmisAccouplements de sécurité avec activation en fonction du couple ou de la force, p. ex. accouplements glissants
• H02H 7/085 - Circuits de protection de sécurité spécialement adaptés aux machines ou aux appareils électriques de types particuliers ou pour la protection sectionnelle de systèmes de câble ou de ligne, et effectuant une commutation automatique dans le cas d'un changement indésirable des conditions normales de travail pour moteurs dynamo-électriques contre une charge excessive
• E05F 15/697 - Mécanismes pour battants mus par une force motrice utilisant des actionneurs électriques utilisant des électromoteurs rotatifs pour battants à coulissement vertical spécialement adaptés aux fenêtres de véhicule moteurs à cet effet, p. ex. motoréducteurs
• H02P 7/03 - Dispositions pour réguler ou commander la vitesse ou le couple de moteurs électriques à courant continu pour commander le sens de rotation des moteurs à courant continu
• B60J 5/04 - Portes disposées sur les côtés du véhicule
• H02P 7/29 - Dispositions pour réguler ou commander la vitesse ou le couple de moteurs électriques à courant continu pour réguler ou commander individuellement un moteur dynamo-électrique à courant continu en faisant varier le champ ou le courant d'induit par commande maîtresse avec puissance auxiliaire utilisant des tubes à décharge ou des dispositifs à semi-conducteurs utilisant des dispositifs à semi-conducteurs commandant l'alimentation de l'induit seulement utilisant la modulation d'impulsions

Abrégé

An anti-pinch method for an apparatus for automatic movement of sliding windows in a motor vehicle, in particular a power-window apparatus, comprising a d.c. electric motor (M) that moves a window (F) so that it slides along guides, said method comprising: - receiving at least one electrical quantity (ea, ia) of said motor (M); - counting (Rc) oscillation periods (Rd) of said at least one electrical quantity (ea, ia); - calculating an angular position (θ(t) ) of the motor (M) as a function of the number of periods (Rc) of the electrical quantity (ea, ia); - calculating a position of the window (F) as a function of said angular position ( 9(t) ) of the motor (M); and - reversing the direction of rotation of the motor (M) if the position of said window (F) falls within an anti-pinch zone (APZ) and the movement of the motor (M) is at least partially blocked. The method described envisages: - receiving a plurality of electrical quantities (ea, ia) of said motor (M); and - selecting the electrical quantity in order to count (Rc) oscillation periods (Rd) of said at least one electrical quantity (ea, ia) in said plurality of electrical quantities (ea, ia) received through a control signal (mode), generated as a function of the operating steps (STOP, RUN UP, RUN DOWN) of the motor (M).

Classes IPC  ?

• H02H 7/085 - Circuits de protection de sécurité spécialement adaptés aux machines ou aux appareils électriques de types particuliers ou pour la protection sectionnelle de systèmes de câble ou de ligne, et effectuant une commutation automatique dans le cas d'un changement indésirable des conditions normales de travail pour moteurs dynamo-électriques contre une charge excessive
• H02P 7/00 - Dispositions pour réguler ou commander la vitesse ou le couple de moteurs électriques à courant continu

Abrégé

A vehicle light comprising a container body that houses at least one light source that emits a plurality of light rays (Ri). A lenticular body is at least partially crossed by the light beam produced by the light source. A diffuser body faces at least one light source, so as to receive the light beam from the diffuser body and extends along a main transverse extension (T-T) perpendicular to a main direction of propagation (L-L) of the light beam. The diffuser body comprises a first group of first optical elements defining cylindrical or spherical optics which scatter the light rays (Ri) towards the light output wall and emit an opalescent light beam. The first optical elements of the first group form a single body, and the first optical elements are separated from the light source and the lenticular body by air gaps.

Classes IPC  ?

• F21V 5/00 - Réfracteurs pour sources lumineuses
• F21S 41/20 - Dispositifs d’éclairage spécialement adaptés à l’extérieur des véhicules, p. ex. phares caractérisés par des réfracteurs, des glaces de fermeture transparentes, des guides ou des filtres de lumière
• G02B 5/02 - DiffuseursÉléments afocaux
• G02B 3/00 - Lentilles simples ou composées
• F21S 43/14 - Diodes électroluminescentes [LED]
• F21S 43/20 - Dispositifs de signalisation spécialement adaptés à l’extérieur des véhicules, p. ex. feux de freinage, feux clignotants indicateurs de direction ou feux de recul caractérisés par des réfracteurs, des glaces de fermeture transparentes, des guides ou des filtres de lumière

Abrégé

Vehicle light comprising a container body that houses at least one light source, a lenticular body, a light guide, the light source, so as to receive the light beam and transmit it to a light outlet wall. The light guide comprises a body that defines the propagation direction of the light beam inside the body by total internal reflection. The body has a first groove, comprising a plurality of first holes, defining cylindrical or spherical optics that produce a scattering of said light rays (Ri) towards the light outlet wall so as to emit a light beam with opalescent effect. The first holes are adjacent to each other without interruption and are blind with respect to a thickness of the body of the light guide, penetrating from a first face of the body for a first depth less than said thickness.

Classes IPC  ?

• F21V 8/00 - Utilisation de guides de lumière, p. ex. dispositifs à fibres optiques, dans les dispositifs ou systèmes d'éclairage
• F21S 43/241 - Guides de lumière caractérisés par la forme du guide de lumière à forme complexe
• B60Q 3/62 - Agencement des dispositifs d’éclairage pour l’intérieur des véhiculesDispositifs d’éclairage spécialement adaptés à l’intérieur des véhicules caractérisés par les aspects optiques utilisant des guides de lumière
• F21S 41/147 - Diodes électroluminescentes [LED] la direction principale d’émission des LED faisant un angle avec l’axe optique du dispositif d’éclairage
• F21S 41/24 - Guides de lumière
• F21S 43/14 - Diodes électroluminescentes [LED]
• F21S 43/239 - Guides de lumière caractérisés par la forme du guide de lumière en forme de plaque
• F21S 43/243 - Guides de lumière caractérisés par la région d’émission émettant la lumière depuis une ou plusieurs de ses extrémités
• G02B 6/00 - Guides de lumièreDétails de structure de dispositions comprenant des guides de lumière et d'autres éléments optiques, p. ex. des moyens de couplage

Abrégé

Automotive lighting unit (1) comprising a first lighting assembly (5) able to backlight a transparent or semi- transparent portion (4) of the front half-shell (3); the lighting assembly (5) comprising: at least one light-guide plate (6) made of photoconductive material, which is arranged inside the rear casing (2) with a front sidewall (7) of the plate facing said transparent or semi-transparent portion (4), and with a rear sidewall (8) of the plate facing the rear casing (2); a first oblong light source (9) which is located inside the rear casing (2) at a first segment (8a) of said rear sidewall (8), and is capable of directing the light produced inside the light-guide plate (6) so that said light travels inside the body of the light-guide plate (6) towards said front sidewall (7); and a second light source (12) which is located inside the rear casing (2) at a second segment (8b) of the rear sidewall (8) complementary to said first segment (8a), and is capable of directing the light produced inside the light-guide plate (6), so that this light travels inside the body of the light-guide plate (6) towards a first lateral sidewall (13) of the light-guide plate (6) connecting the second segment (8b) of the rear sidewall (8) of the light-guide plate (6) to the front sidewall (7) of the same light-guide plate (6); the light-guide plate (6) being provided with a transversal groove (15) that extends along one of the two faces of the light-guide plate (6), from the front sidewall (7) of the light-guide plate (6) towards the rear sidewall (8) of the light-guide plate (6), so as to be interposed between said first lateral sidewall (13) of the plate and the front sidewall (7) of the plate, and be crossed by the light (r2) reflected by said first lateral sidewall (13) of the light-guide plate (6) towards the front sidewall (7) of the light-guide plate (6).

Classes IPC  ?

• F21S 8/10 - spécialement adaptés pour des véhicules

Abrégé

Described herein is an apparatus for automatic movement of sliding windows in a motor vehicle, in particular a power-window apparatus, comprising a d.c. electric motor (10) that moves a window (F) so that it slides along guides, the device (20) comprising an electronic control module (21) for controlling the d.c. electric motor (10), in particular a microprocessor, the electronic control module (21) being configured for measuring a current (I) of the motor (10) and for measuring a position (X) of the window (F), the control module (21) being moreover configured for driving reversal (190) of operation of the electric motor (10) if it is verified (180) that the current (I) is higher than a threshold current (Ith) and the position (X) of the window (F) falls within a given zone (APZ) of a path (P) of movement of the window (F). According to the invention, the anti-pinch circuit device (20) is configured for measuring (130) a back electromotive force (E; Em) of the motor (10), and the electronic control module (21) is configured for calculating (180) the position of the window (F) as a function of the back electromotive force (E; Em) of the motor (10), so as to operate without the aid of external sensors. The control module (21) is configured for calculating the coefficient of proportionality (Ke) of the system via a calibration procedure.

Classes IPC  ?

• E05F 15/41 - Détection par contrôle de la force ou du couple transmisAccouplements de sécurité avec activation en fonction du couple ou de la force, p. ex. accouplements glissants
• H02H 7/085 - Circuits de protection de sécurité spécialement adaptés aux machines ou aux appareils électriques de types particuliers ou pour la protection sectionnelle de systèmes de câble ou de ligne, et effectuant une commutation automatique dans le cas d'un changement indésirable des conditions normales de travail pour moteurs dynamo-électriques contre une charge excessive

Abrégé

A cabling system and method for connecting, to a plurality of electronic printed circuit boards, a common electrical cable, a grounding cable, and respective electrical board wires, or power supply cables. The system comprises a bundle of electrical cables, and a plurality of multipolar, insulation-piercing connectors placed in succession along said bundle of cables. Each of the connectors is suitable to receive the common electrical cable, the board cable to be connected to the respective electronic board, and the board cables that must be connected to the successive connectors, and is suitable to transmit to a successive insulation-piercing connector, the common electrical cable and the board cables that must be connected to the successive connectors.

Classes IPC  ?

• H01R 11/00 - Éléments de connexion individuels assurant plusieurs emplacements de connexion espacés pour des organes conducteurs qui sont ou qui peuvent être interconnectés de cette façon, p. ex. pièces d'extrémité pour fils ou câbles supportées par le fil ou par le câble et possédant des moyens pour faciliter la connexion électrique avec quelqu'autre fil, borne, ou organe conducteur, répartiteurs
• H01R 12/73 - Dispositifs de couplage pour circuits imprimés rigides ou structures similaires se couplant avec la bordure des circuits imprimés rigides ou des structures similaires se raccordant à d'autres circuits imprimés rigides ou à des structures similaires
• H01R 9/03 - Dispositifs de connexion conçus pour assurer le contact avec plusieurs des conducteurs d'un câble multiconducteur
• H01R 12/72 - Dispositifs de couplage pour circuits imprimés rigides ou structures similaires se couplant avec la bordure des circuits imprimés rigides ou des structures similaires
• H01R 12/75 - Dispositifs de couplage pour circuits imprimés rigides ou structures similaires se raccordant à des câbles à l'exclusion des câbles plats ou à rubans

Abrégé

A vehicle light comprising a container body and a lenticular body. The light comprises a substrate that supports a main light source that is embedded in a cover layer suitable to allow the diffusion inside it of the main light beam. The cover layer is disposed on the side opposite to the lenticular body with respect to the substrate. The substrate comprises at least one transparent portion to the light beam suitable to transmit the main light beam towards the lenticular body and, through this, to the outside of the vehicle light, wherein the substrate comprises at least one opaque portion to the main light beam, adjacent to said transparent portion in order to allow the passage of the main light beam exclusively at said transparent portion. The transparent portion defines a main light pattern of the vehicle light.

Classes IPC  ?

• F21S 8/10 - spécialement adaptés pour des véhicules
• B60Q 1/26 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs ayant principalement pour objet d'indiquer le contour du véhicule ou de certaines de ses parties, ou pour engendrer des signaux au bénéfice d'autres véhicules
• F21V 8/00 - Utilisation de guides de lumière, p. ex. dispositifs à fibres optiques, dans les dispositifs ou systèmes d'éclairage
• B26D 7/08 - Moyens de traitement de la pièce ou de l'outil de coupe pour faciliter la coupe
• B26D 7/10 - Moyens de traitement de la pièce ou de l'outil de coupe pour faciliter la coupe par échauffement
• B26D 7/20 - Bancs à couper
• B26D 7/01 - Moyens pour maintenir ou mettre en position la pièce
• H01L 25/075 - Ensembles consistant en une pluralité de dispositifs à semi-conducteurs ou d'autres dispositifs à l'état solide les dispositifs étant tous d'un type prévu dans une seule des sous-classes , , , , ou , p. ex. ensembles de diodes redresseuses les dispositifs n'ayant pas de conteneurs séparés les dispositifs étant d'un type prévu dans le groupe
• F21W 101/14 - Feux arrière ou pour indiquer le freinage
• F21Y 115/10 - Diodes électroluminescentes [LED]
• F21Y 107/10 - Sources lumineuses comprenant des éléments générateurs de lumière disposés en trois dimensions sur des supports ou des substrats concaves, p. ex. sur le côté intérieur de supports en forme de bol

Abrégé

An automotive light including: a rear casing, which is substantially basin-shaped and is structured in such a way as to be fixed on the vehicle body; a front half-shell, which is arranged to close the mouth of the rear casing and is provided with at least a transparent or semitransparent portion; and at least one lighting assembly, in turn including a platelike light-guide body, which extends within the rear casing in such a way as to place a front sidewall thereof so that it faces the transparent or semitransparent portion of the front half-shell and a rear sidewall thereof so that it faces the bottom of the rear casing; and a light-emitting device, which is located within a transverse slot that extends within the platelike light-guide body, from the rear sidewall to the front sidewall, remaining substantially perpendicular to the midplane of the platelike light-guide body and substantially parallel to the optical axis of the automotive light.

Classes IPC  ?

• F21V 9/00 - Éléments modifiant les caractéristiques spectrales, la polarisation ou l’intensité de la lumière émise, p. ex. filtres
• B60Q 1/22 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs étant principalement destinés à éclairer la route en avant du véhicule ou d'autres zones de la route ou des environs pour conduite en arrière
• G02B 6/00 - Guides de lumièreDétails de structure de dispositions comprenant des guides de lumière et d'autres éléments optiques, p. ex. des moyens de couplage
• F21Y 107/90 - Sources lumineuses comprenant des éléments générateurs de lumière disposés en trois dimensions sur deux côtés opposés de supports ou de substrats
• F21Y 101/00 - Sources lumineuses ponctuelles

Abrégé

An automotive light is provided that includes a light-guide plate extending inside the rear body of the light remaining substantially parallel to the light reference optical axis close up to the front lenticular hemi-shell of the light with its front side edge facing the strip-shaped transparent or semi-transparent portion of the front lenticular hemi-shell, and a linear-extending light source directing emitted light towards the inside of the light-guide plate through the rear side edge of the same light-guide plate. The rear side edge of the light-guide plate includes a serrated profile with teeth substantially triangular in shape oriented so that a first inclined edge of the tooth is arranged locally substantially perpendicular to the optical reference axis. The light source includes a row of spaced LEDs facing the rear side edge, each LED facing a respective tooth of the rear side edge so as to direct/project emitted light through the first inclined edge of the tooth. The lighting assembly also includes a series of optical collimators interposed between a diode and a corresponding tooth of the rear side edge of the light-guide plate to deflect light rays towards the corresponding inclined edge of the tooth and collimating the rays in a direction substantially parallel to a collimation axis substantially coplanar to the light-guide plate and inclined with respect to the optical reference axis of the light by greater than 0°.

Classes IPC  ?

• F21S 43/239 - Guides de lumière caractérisés par la forme du guide de lumière en forme de plaque
• F21V 8/00 - Utilisation de guides de lumière, p. ex. dispositifs à fibres optiques, dans les dispositifs ou systèmes d'éclairage
• F21V 23/00 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage
• F21V 23/04 - Agencement des éléments du circuit électrique dans ou sur les dispositifs d’éclairage les éléments étant des interrupteurs
• G02B 27/30 - Collimateurs
• F21S 43/14 - Diodes électroluminescentes [LED]
• F21S 43/243 - Guides de lumière caractérisés par la région d’émission émettant la lumière depuis une ou plusieurs de ses extrémités
• F21S 43/249 - Guides de lumière ayant plusieurs sources lumineuses couplées au guide de lumière
• F21Y 101/00 - Sources lumineuses ponctuelles
• F21Y 115/10 - Diodes électroluminescentes [LED]

Abrégé

A lighting device of an automotive light comprising light sources supplied by a drive current and a control device comprising a control stage generating a control signal on the basis of the difference between the drive current and a predetermined reference current, and a driving stage, which adjust the drive current on the basis of the control signal. The driving stage comprises a voltage stabilizing device, which supplies, in a first operation condition, a stabilized voltage on an intermediate node thereof, a first transistor having a control terminal receiving the control signal; and a second transistor having a control terminal connected to the intermediate node to be set, in the first operation condition, to the predetermined stabilized voltage), a first terminal connected to the light source, and a second terminal connected to a second terminal of the first transistor.

Classes IPC  ?

• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes
• B60Q 1/00 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet
• F21S 8/10 - spécialement adaptés pour des véhicules

Abrégé

A method for controlling a motor-vehicle lighting device is provided that uses LEDs supplied with PWM signals temporally spaced apart from one another by a first time phase t1 and a second time phase t2. An interval of interest is defined in which an electromagnetic disturbance must not exceed a maximum threshold value θmax; driving signals are supplied on the basis of first phases t1 and t2 computed; and the measured or simulated waveform of the electromagnetic disturbance deriving from the phases t1 and t2 is compared with the maximum threshold value within the interval of interest defined. Where the waveform of the disturbance exceeds the threshold, two phases t1 and t2, once again different from one another, are recalculated; otherwise, the last phases t1 and t2 calculated are selected and used in the PWM control. An advantageous motor-vehicle lighting device is also provided.

Classes IPC  ?

• B60Q 1/14 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs étant principalement destinés à éclairer la route en avant du véhicule ou d'autres zones de la route ou des environs les dispositifs étant des phares comportant un dispositif d'atténuation de la lumière
• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes
• B60Q 1/00 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet

Abrégé

An automotive light includes a rear body; a front lenticular half-shell which closes the mouth of the rear body and is provided with at least one transparent/semi-transparent portion; and at least one lighting assembly which emits light upon command and is located within the rear body to backlight the transparent/semi-transparent portion of the front lenticular half-shell. The lighting assembly includes a planar OLED light source which emits light from its front face and is within the rear body with the front face facing the inner surface of the front lenticular half-shell to direct light towards the front lenticular half-shell; a concentrated LED light source behind the planar light source; and a light-guide rod of photoconductive material between the concentrated light source and the planar light source and receives light emitted by the concentrated light source and conveys the light towards the rear face of the planar light source.

Classes IPC  ?

• F21V 1/00 - Abat-jour pour les sources lumineuses
• F21S 8/10 - spécialement adaptés pour des véhicules
• F21S 43/14 - Diodes électroluminescentes [LED]
• B60Q 1/00 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet
• F21S 43/145 - Émetteurs surfaciques, p. ex. diodes électroluminescentes organiques [OLED]
• F21S 43/237 - Guides de lumière caractérisés par la forme du guide de lumière en forme de tige
• F21S 43/241 - Guides de lumière caractérisés par la forme du guide de lumière à forme complexe
• F21S 43/243 - Guides de lumière caractérisés par la région d’émission émettant la lumière depuis une ou plusieurs de ses extrémités
• F21S 43/247 - Guides de lumière ayant une seule source lumineuse couplée au guide de lumière
• F21Y 105/00 - Sources lumineuses planes
• F21Y 105/10 - Sources lumineuses planes comprenant un réseau bidimensionnel d’éléments générateurs de lumière ponctuelle
• F21Y 115/10 - Diodes électroluminescentes [LED]
• F21Y 115/15 - Diodes électroluminescentes organiques [OLED]
• F21W 107/00 - Utilisation ou application de dispositifs d’éclairage sur ou dans des types véhicules spécifiques

Abrégé

An automotive light includes a rear body; a front lenticular half-shell which closes the mouth of the rear body and is provided with at least one transparent/semi-transparent portion; and at least one lighting assembly which emits light upon command and is located within the rear body to backlight the transparent/semi-transparent portion of the front lenticular half-shell; the lighting assembly being provided with a planar OLED light source which faces the inner surface of the front lenticular half-shell and includes at least one plate-like OLED which emits light in a distributed way from its front and rear faces; and a rear refracting member facing the rear face of the OLED that re-directs light that exits from the rear face of the OLED towards a transverse light passage in the OLED in a direction such that the light can traverse the OLED and exit from the front face of the OLED.

Classes IPC  ?

• F21S 8/10 - spécialement adaptés pour des véhicules

Abrégé

Automotive light (1) wherein the lighting assembly (5) comprising a light-guide plate (6) which extends inside the rear body (2) of the light remaining substantially parallel to the light reference optical axis (A) close up to the front lenticular hemi-shell (3) of the light while arranging its own front side edge (7) facing the strip-shaped transparent or semitransparent portion (4) of the front lenticular hemi-shell (3), and a linear-extending light source (8) which is structured so as to direct the emitted light towards the inside of the light-guide plate (6) through the rear side edge (9) of the same light-guide plate (6); the rear side edge (9) of the light-guide plate (6) having a serrated profile with teeth substantially triangular in shaped, wherein the individual teeth are oriented so that a first inclined edge (13) of the tooth is arranged locally substantially perpendicular to the optical reference axis (A); the light source (8) comprising instead a row of light emitting diodes (12) which face the rear side edge (9) spaced beside to one another, each facing a respective tooth of the rear side edge (9), so as to direct/project the emitted light towards the inside of the light-guide plate (6) through said first inclined edge (13) of the tooth; the lighting assembly (5) finally comprising also a series of optical collimators (15) each of which is interposed between a diode (12) and the corresponding tooth of the rear side edge (9) of the light- guide plate (6), and is structured so as to deflect the light rays (r) emitted by the diode (12) towards the corresponding inclined edge of the tooth (13), collimating said rays in a direction (d1) which is locally substantially parallel to collimation axis (B) substantially coplanar to the light-guide plate (6) and inclined with respect to the optical reference axis (a) of the light by an angle (α) greater than 0°.

Classes IPC  ?

• F21S 8/10 - spécialement adaptés pour des véhicules
• F21V 8/00 - Utilisation de guides de lumière, p. ex. dispositifs à fibres optiques, dans les dispositifs ou systèmes d'éclairage
• G02B 6/00 - Guides de lumièreDétails de structure de dispositions comprenant des guides de lumière et d'autres éléments optiques, p. ex. des moyens de couplage

Abrégé

Automotive lamp (1) comprising a lighting device (4) comprising a LED lighting circuit (5) designed to generate a luminous flux on the basis of a driving current (IL), a controlling electrical circuit (8) which provides the driving current (IL) on the basis of a reference electrical quantity (Vref ) and of a sensed electrical quantity (Vbin), and a compensating electrical circuit (9), which is configured so as to vary the reference electrical quantity (Vref) by way of a compensation function of the luminous flux (Vref (T) ) predetermined, on the basis of the temperature (T) of the LED lighting circuit (5). The compensating electrical circuit (9) comprising a resistive conditioning electrical device (29) (30) that conditions the compensation function of the luminous flux (Vref (T) ) so as to vary the reference electrical quantity (Vref) in a predetermined way in response to a change in temperature (T).

Classes IPC  ?

• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes
• F21S 8/10 - spécialement adaptés pour des véhicules

Abrégé

An automotive light includes a substantially basin-shaped rear body; a front lenticular half-shell arranged to close the mouth of the rear body and includes a ribbon-like, transparent or semitransparent portion; and a first lighting assembly structured to emit light when electricity powered, and arranged within the rear body to backlight the ribbon-like portion of the front lenticular half-shell. The first lighting assembly includes a light-guide plate made of light-conducting material and a linear-extending light source within the rear body next to the light-guide plate, and structured to direct emitted light towards the inside of the light-guide plate. The linear-extending light source includes a row of light-emitting diodes which face the light-guide plate and are placed spaced side-by-side to one another, and a power-supply and control circuit which sequentially turns on the diodes so as to illuminate in sequence an equal number of segments of the light-guide plate.

Classes IPC  ?

• F21S 8/10 - spécialement adaptés pour des véhicules
• F21Y 115/10 - Diodes électroluminescentes [LED]

Abrégé

A lighting device (4) of an automotive light (1) comprising light sources (5) supplied by a drive current (I) and a control device (6) comprising a control stage (9) generating a control signal (CS) on the basis of the difference between the drive current (I) and a predetermined reference current (Iref), and a driving stage (7), which adjust the drive current (I) on the basis of the control signal (CS). The driving stage (7) comprises a voltage stabilizing device, which supplies, in a first operation condition, a stabilized voltage (Vz2) on an intermediate node (41) thereof, a first transistor (36) having a control terminal receiving the control signal (CS); and a second transistor (37) having a control terminal connected to the intermediate node (41) to be set, in the first operation condition, to the predetermined stabilized voltage (Vz2), a first terminal connected to the light source (5), and a second terminal connected to a second terminal of the first transistor (36).

Classes IPC  ?

• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes

Abrégé

An automotive light is provided that includes a light-guide bar made of photoconductive-material, which is at least partially positioned substantially grazing a corresponding transparent or semitransparent portion of the front lenticular half-shell of the light, and a second light source which is structured so as to emit light when electricity powered, and is arranged inside the rear body, close to one end of the light-guide bar, so as to direct the light produced inside the body of said light-guide bar. The light-guide bar is provided with a longitudinal light-extractor band which extends along the lateral side of the bar, and a multitude of deflector prisms which have an approximately triangle-shaped cross-section and are conveniently arranged along the longitudinal light-extractor band. One or more deflector prisms are shaped so that the active deflector surface has a bulging/arched profile substantially over the whole width of the longitudinal band.

Classes IPC  ?

• B60Q 1/30 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs ayant principalement pour objet d'indiquer le contour du véhicule ou de certaines de ses parties, ou pour engendrer des signaux au bénéfice d'autres véhicules pour indiquer l'arrière du véhicule, p. ex. au moyen de surfaces réfléchissantes
• F21V 8/00 - Utilisation de guides de lumière, p. ex. dispositifs à fibres optiques, dans les dispositifs ou systèmes d'éclairage
• B60Q 1/00 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet
• F21S 8/10 - spécialement adaptés pour des véhicules

Abrégé

An automotive light is provided having a substantially tub-shaped rear casing designed to fit to the vehicle body and a front lenticular half-shell which closes the opening of the rear casing and has at least one portion of transparent or semi-transparent material. The front lenticular half-shell includes a rear portion substantially aligned with the rear of the vehicle body, and a lateral portion substantially aligned with the side of the vehicle body. The automotive light also includes a strip light source designed to emit light when powered electrically and a light guide plate of photoconductive material shaped to substantially match the profile of the strip light source and housed inside the rear casing in a position substantially perpendicular to the rear portion of the front lenticular half-shell. A first side of the plate conducts light from the strip light source into the body of the light guide plate, and a second side of the plate directs light propagating in the light guide plate onto the lenticular half-shell. A transverse light-extracting band is provided to locally extract light onto a lateral portion of the front lenticular half-shell.

Classes IPC  ?

• F21V 9/00 - Éléments modifiant les caractéristiques spectrales, la polarisation ou l’intensité de la lumière émise, p. ex. filtres
• F21S 8/10 - spécialement adaptés pour des véhicules
• B60Q 1/00 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet
• B60Q 1/26 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs ayant principalement pour objet d'indiquer le contour du véhicule ou de certaines de ses parties, ou pour engendrer des signaux au bénéfice d'autres véhicules

Abrégé

An automotive light including a substantially basin-shaped rear body structured so to be fixed onto the vehicle body; a front lenticular semi-shell provided with at least one band-like, transparent or semi-transparent portion; and at least a first lighting assembly, which is structured so as to emit light when electrically powered and is arranged so as to backlight the band-like; the first lighting assembly including: a first light-guiding plate made of photoconductive material which extends from the bottom of the rear body up to/close to the front lenticular semi-shell, while remaining perpendicular to the front lenticular semi-shell; and a second light-guiding plate made of photoconductive material, which laterally rests on/is joined with one of the two larger faces of the first light-guiding plate, close to the front lateral side of the same first light-guiding plate, so as to form an L-shaped structure which extends tangentially to the front lenticular semi-shell.

Classes IPC  ?

• F21V 9/00 - Éléments modifiant les caractéristiques spectrales, la polarisation ou l’intensité de la lumière émise, p. ex. filtres
• F21S 8/10 - spécialement adaptés pour des véhicules

Abrégé

Driver circuit of light sources, particularly of the LED type, comprising a first and at least a second group of light sources, each connected to a common power supply terminal, a first and at least a second regulation circuit, each suitable for regulating the current absorbed by a respective group of light sources, at least one actuation circuit operatively connected to a respective second regulation circuit, and a serial connection circuit, suitable for connecting in series at least a first and a second group of light sources, when the voltage downstream of the first group of light sources is greater than or equal to the voltage upstream of the second group of light sources.

Classes IPC  ?

• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes

Abrégé

An automotive light including a rear shell which is substantially tub-shaped and is structured so as to be fixed onto the vehicle body; a front lenticular half-shell which is provided with at least one portion made of transparent or semitransparent material, and is arranged to close the mouth of the rear shell; and at least a first main light source which is structured so as to emit light when electricity powered, and is placed within the rear shell in such a position as to backlight a corresponding transparent or semitransparent portion of the front lenticular half-shell; the automotive light further including at least one light-guiding section-bar made of light-conducting material, which is placed on the bottom of a corresponding slot or groove specifically obtained within the rear shell; and at least one auxiliary light source which is structured so as to emit light when electricity powered, and is placed within the rear shell so as to direct the emitted light directly into the body of the light-guiding section-bar; the light-guiding section-bar made of light-conducting material being provided with a cross section substantially circular or elliptic in shape, and with a longitudinal flat bevel facing the bottom of the slot or groove and structured so as to cause the light travelling in the light-guiding section-bar to exit towards the transparent or semitransparent portion of the lenticular half-shell above the light-guiding section-bar.

Classes IPC  ?

• F21V 9/00 - Éléments modifiant les caractéristiques spectrales, la polarisation ou l’intensité de la lumière émise, p. ex. filtres
• F21S 8/10 - spécialement adaptés pour des véhicules

Abrégé

Light for motor vehicles and the like provided with a lighting device comprising a pair of power supply lines flowed through by a primary supplying current, two or more lighting branches each comprising one or more light sources adapted for being flowed through by a secondary supplying current; and an electronic control circuit configured to determine the secondary current flowing through each lighting branch; limit the primary supplying current to a predetermined minimum value when the secondary current flowing through at least one of said lighting branches is lesser than a predetermined threshold current; control the simultaneous transition of the light sources from a pre-lighting state to a complete-lighting state, when each of the secondary currents flowing through the lighting branches is greater than or equal to the predetermined current threshold.

Classes IPC  ?

• B60Q 1/00 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet
• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes

Abrégé

A method for injection molding of plastic-material lenticular bodies for lights; of motor vehicles and similar, the method comprising the steps of coupling a punch half-mold with a first matrix half-mold so as to define, on the surface of the punch half-mold, a first closed cavity that copies in reverse the shape of the first plastic-material sheet; filling said first cavity with a first plastic polymer in a liquid state, injecting the first plastic polymer in the first cavity from an injection point located at said first segment of the peripheral edge of the first plastic-material sheet; and finally separating, after the first plastic polymer has solidified to form the first plastic-material sheet, the punch half-mold from the first; matrix half-mold maintaining the first plastic-material sheet still on the surface of the punch half-mold.

Classes IPC  ?

• B60Q 1/00 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet
• B60Q 3/00 - Agencement des dispositifs d’éclairage pour l’intérieur des véhiculesDispositifs d’éclairage spécialement adaptés à l’intérieur des véhicules
• B60Q 11/00 - Agencement des dispositifs témoin pour les dispositifs prévus dans les groupes
• B29D 11/00 - Fabrication d'éléments optiques, p. ex. lentilles ou prismes
• B29C 45/00 - Moulage par injection, c.-à-d. en forçant un volume déterminé de matière à mouler par une buse d'injection dans un moule ferméAppareils à cet effet
• B29C 45/16 - Fabrication d'objets multicouches ou polychromes
• F21V 5/04 - Réfracteurs pour sources lumineuses de forme lenticulaire
• B29C 45/27 - Canaux d'injection
• B29L 11/00 - Éléments optiques, p. ex. lentilles, prismes
• B29L 31/30 - Véhicules, p. ex. bateaux ou avions, ou éléments de leur carrosserie
• B29L 31/00 - Autres objets particuliers

Abrégé

An automotive light (1) having a substantially tub- shaped rear casing (2) designed to fit to the vehicle body; and a front lenticular half-shell (3), which closes the opening (2a) of the rear casing (2) and has at least one portion of transparent or semitransparent material; the front lenticular half-shell (3) having a rear portion (3a) substantially aligned with the rear of the vehicle body, and a lateral portion (3b) substantially aligned with the side of the vehicle body; the automotive light (1) also having a strip light source (4) designed to emit light when powered electrically, and which is housed inside the rear casing (2) in a position facing the rear portion (3a) of the front lenticular half-shell (3); and a light guide plate (7) of photoconductive material, which is shaped to substantially match the profile of the strip light source (4), and is housed inside the rear casing (2) in a position substantially perpendicular to the rear portion (3a) of the front lenticular half-shell (3), so that a first side (7a) of the plate faces the strip light source (4) to catch and conduct the light from the strip light source (4) into the body of the light guide plate (7), and a second side (7b) of the plate, opposite the first side (7a), faces the rear portion (3a) of the front lenticular half-shell (3) to direct the light propagating in the light guide plate (7) onto the lenticular half-shell (3); the two faces of the light guide plate (7) being designed to conduct to the second side (7b) of the plate the light entering the body of the light guide plate (7) from the first side (7a); and one of the two faces of the plate having a transverse light-extracting band (7c), which extends substantially from the first side (7a) of the plate to the second side (7b) of the plate, and is designed to locally extract the light, propagating in that limited portion of the light guide plate (7), onto the lateral portion (3b) of the front lenticular half- shell (3), so as to form a transverse light strip on the lateral portion (3b) of the front lenticular half-shell (3).

Classes IPC  ?

• B60Q 1/26 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs ayant principalement pour objet d'indiquer le contour du véhicule ou de certaines de ses parties, ou pour engendrer des signaux au bénéfice d'autres véhicules
• F21S 8/10 - spécialement adaptés pour des véhicules

Abrégé

Automotive light (1) comprising a light-guide bar (6) made of photoconductive-material, which is at least partially positioned substantially grazing a corresponding transparent or semitransparent portion of the front lenticular half-shell (3) of the light, and a second light source (7) which is structured so as to emit light when electricity powered, and is arranged inside the rear body (2), close to one end of the light- guide bar (6), so as to direct the light produced inside the body of said light-guide bar (6); the light-guide bar (6) being provided with a longitudinal light-extractor band (8) which extends along the lateral side of the bar, and a multitude of- deflector prisms (9) which have an approximately triangle-shaped cross-section and are conveniently arranged along the longitudinal light-extractor band (8); one or more deflector prisms (9) being shaped so that the active deflector surface (9a) has a bulging/arched profile substantially over, the whole width (w) of the longitudinal band (8).

Classes IPC  ?

• G02B 6/00 - Guides de lumièreDétails de structure de dispositions comprenant des guides de lumière et d'autres éléments optiques, p. ex. des moyens de couplage
• B60Q 1/00 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet
• F21S 8/00 - Dispositifs d'éclairage destinés à des installations fixes

Abrégé

An automotive light (1) comprising a substantially basin-shaped, rear body (2)," which is structured so as to be fixed to the vehicle body, a front lenticular half-shell (3), which is provided with at least one portion made of transparent or semitransparent material and is arranged to close the mouth (2a) of the rear body (2), and at least one main light source (4), which is structured so as to emit light when electricity powered and is arranged within the rear body (2) in a position so as to backlight a corresponding transparent or semitransparent portion of the front lenticular half- shell (3); the automotive light (1) further comprising a light-guide bar (6) made of a photoconductive material, which has a substantially circular- or elliptical-shaped cross-section and is arranged inside the rear body (2), and an auxiliary light source (7), which is arranged within the rear body (2), close to at least one end of the light-guide bar (6), so as to direct the produced light into the body of said light-guide bar (6); said light-guide bar (6) being provided with a substantially flat, longitudinal light-extracting stripe (8), which extends along the lateral side of the light-guide bar (6), and with a multitude of transverse deflecting prisms (9), which are appropriately distributed along the longitudinal light-extracting stripe (8), and with a series of additional transversal deflecting grooves or ridges (10), which are appropriately distributed/spaced apart along the outer curved surface (6a) of the light- guide bar (6), which is immediately adjacent to the longitudinal light-extracting stripe (8) and are profiled so as to divert the light rays which reach the same transversal ridges or grooves (10) towards the corresponding transparent or semitransparent portion of the front lenticular half -shell (3).

Classes IPC  ?

• B60Q 1/00 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet
• F21S 8/00 - Dispositifs d'éclairage destinés à des installations fixes
• G02B 6/00 - Guides de lumièreDétails de structure de dispositions comprenant des guides de lumière et d'autres éléments optiques, p. ex. des moyens de couplage

Abrégé

An automotive light (1) comprising a rear shell (2) which is substantially tub-shaped and is structured so as to be fixed onto the vehicle body; a front lenticular half-shell (3) which is provided with at least one portion made of transparent or semitransparent material, and is arranged to close the mouth (2a) of the rear shell (2); and at least a first main light source (4) which is structured so as to emit light when electricity powered, and is placed within the rear shell (2) in such a position as to backlight a corresponding transparent or semitransparent portion of the front lenticular half- shell (3); the automotive light (1) further comprising at least one light-guiding section-bar (6) made of light-conducting material, which is placed on the bottom of a corresponding slot or groove (7) specifically obtained within the rear shell (2), right underneath a corresponding transparent or semitransparent portion of the front lenticular half-shell (3); and at least one auxiliary light source (8) which is structured so as to emit light when electricity powered, and is placed within the rear shell (2), close to at least one of the two ends of the light-guiding section-bar (6), so as to direct the emitted light directly into the body of the light-guiding section-bar (6); the light-guiding section-bar (6) made of light-conducting material being provided with a cross section substantially circular or elliptic in shape, and with a longitudinal flat bevel (6a) facing the bottom of the slot or groove (7) and structured so as to cause the light travelling in the light-guiding section-bar (6) to exit towards the transparent or semitransparent portion of the lenticular half-shell (3) above the light-guiding section-bar (6).

Classes IPC  ?

• F21S 8/10 - spécialement adaptés pour des véhicules
• F21V 17/00 - Fixation des parties constitutives des dispositifs d'éclairage, p. ex. des abat-jour, des globes, des réfracteurs, des réflecteurs, des filtres, des écrans, des grilles ou des cages de protection

Abrégé

An incandescent light-bulb socket (1) of the type structured to support a light-bulb (2) provided with a glass bulb (3) housing the incandescent filament, and with a connection plug (4) which is placed to close the neck of the glass bulb (3), and is structured so as to be fitted within the socket; said connection plug (4) being provided with a headpiece (4a) housing the terminals of the rheophores which conduct the electric current to the filament, and with a peripheral flange (4b) which overhangly protrudes from the body of the plug (4), between the neck of the glass bulb (3) and the headpiece (4a) of the plug; the incandescent light-bulb socket (1) comprising: a supporting platform (5) which is provided with a coupling seat (5a) shaped so as to accommodate/house the portion of the plug (4) beneath the peripheral flange (4b); electrical connection means (6) placed close to the bottom of the coupling seat (5a), and structured so as to touch the plug headpiece (4a) at the terminals of the rheophores, when the plug (4) is completely inserted into the coupling seat (5a); and a light-bulb retaining member (8) which is placed on the supporting platform (5), substantially at the mouth of the coupling seat (5a), and is structured so as to hook the peripheral plug flange (4b) to prevent the plug (4) from being subsequently extracted from the coupling seat (5a), and so as to continuously exert an elastic traction force on the peripheral flange (4b) of the plug (4) which occupies the coupling seat (5a), which force is directed towards the bottom of the coupling seat (5a).

Classes IPC  ?

• F21V 19/00 - Montage des sources lumineuses ou des supports de sources lumineuses sur ou dans les dispositifs d'éclairage
• H01R 33/09 - Dispositifs à deux pôles portant deux broches, lames ou contacts analogues conducteurs de courant ayant leurs axes parallèles entre eux pour ampoule sans culot
• H01R 13/627 - Fixation du type à action brusque
• H01R 13/506 - SoclesBoîtiers composés de différentes pièces assemblées par enclenchement réciproque des pièces
• H01R 33/06 - Dispositifs à deux pôles portant deux broches, lames ou contacts analogues conducteurs de courant ayant leurs axes parallèles entre eux

Abrégé

Wedge-base bulb socket comprising: a supporting base provided with a coupling seat dimensioned to house the plug of the light bulb; two coupling and connecting members which are located inside the coupling seat, and are structured to separately hold the wedge-shaped plug of the light bulb fitted into the coupling seat, and to feed electric current to said light bulb; two electrically conductive elements which extend on the surface of the supporting base up to the edge of the entrance of the coupling seat, on opposite sides of said entrance, and then descend into the coupling seat up to reach each a respective coupling and connecting member; and two respectively-facing additional supporting jaws which are supported by the two electrically conductive elements so as to be located substantially on opposite sides of the entrance of the coupling seat, and structured to clamp the wedge-base light bulb fitted into the socket, so as to firmly hold said wedge-base light bulb in the wedge-base bulb socket.

Classes IPC  ?

• B60Q 1/00 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet

Abrégé

An automotive light (1) comprising at least one main light source (4) structured so to emit light when powered with electricity, and a cup-shaped body (3) that houses within itself said main light source (4), and has the inner surface (3i) structured so to direct the produced light towards the mouth (3a) of said cup-shaped focusing body (3); the automotive light (1) further comprising a) a first light-guiding sheet (7) which is made of photoconductive material and extends along the mouth (3a) of the cup-shaped focusing body (3), and a corresponding first auxiliary light source (8) which is arranged facing a side edge of said first light-guiding sheet (7), is structured so to emit light when powered with electricity, and is finally oriented so that the light emitted by the same light source enters inside the body of said first light-guiding sheet (7) through the side edge of the same light-guiding sheet (7); and b) at least one second light-guiding sheet (9) which is made of photoconductive material and extends along the mouth (3a) of the focusing cup-shaped body (3), so as to at least partially overlap with the first light-guiding sheet (7), and a corresponding second auxiliary light source (10) which is arranged facing a side edge of said second light-guiding sheet (9), is structured so to emit light when electricity powered, and is oriented so that the light emitted by the same light source enters inside the body of said second light-guiding sheet (9) through the side edge of the same light-guiding sheet (9); said first (7) and said second light-guiding sheet (9) being both structured so to cause the selective escape of the light produced by said second auxiliary light source (10), through at least one part of its front face.

Classes IPC  ?

• B60Q 1/26 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet les dispositifs ayant principalement pour objet d'indiquer le contour du véhicule ou de certaines de ses parties, ou pour engendrer des signaux au bénéfice d'autres véhicules
• B60Q 1/00 - Agencement des dispositifs de signalisation optique ou d'éclairage, leur montage, leur support ou les circuits à cet effet
• F21S 8/10 - spécialement adaptés pour des véhicules

Abrégé

Automotive light (1) comprising at least one cup-shaped body (3) that has the inner surface (3i) mirror-finished so as to reflect the incident light towards the mouth (3a) of the main cup-shaped body (3) itself, and at least one light source (4) which is located within the main cup-shaped body (3), and is structured so as to emit light when electricity powered, the inner surface (3i) of the main cup-shaped body (3) being provided with a first decorative optical pattern which is cyclically repeated on said inner surface (3i) with a predetermined spatial periodicity; the automotive light (1) being also provided with at least one additional optical filter (7), which is made of a transparent or semi-transparent material, and is arranged so as to be crossed by the light produced by light source (4); said at least one optical filter (7) being provided with an optical surface which is structured so as to present a second decorative optical pattern which is cyclically repeated with a predetermined spatial periodicity; the shape and/or the spatial periodicity of the decorative optical pattern present on the additional optical filter (7) being different from the shape and/or spatial periodicity of the decorative optical pattern present on the main cup-shaped body (3), and such as to cause, in the light exiting from the main cup-shaped body (3), an interferometric effect with Moiré deterioration that generates a different virtual pattern from the decorative optical patterns present on the main cup-shaped body (3) and the additional optical filter (7).

Classes IPC  ?

• F21S 10/00 - Dispositifs ou systèmes d'éclairage produisant un effet d'éclairage variable
• F21V 7/00 - Réflecteurs pour sources lumineuses
• F21V 7/22 - Réflecteurs pour sources lumineuses caractérisés par les matériaux, traitements de surface ou revêtements
• F21V 14/08 - Commande de la distribution de la lumière émise par réglage d’éléments constitutifs par un mouvement d'écrans

Abrégé

Light (30) for motor vehicles and the like provided with a lighting device (31) comprising a pair of power supply lines (42, 43) flowed through by a primary supplying current (I1), two or more lighting branches (34) each comprising one or more light sources (37) adapted for being flowed through by a secondary supplying current (I2i); and an electronic control circuit (33) configured to determine the secondary current (I2i) flowing through each lighting branch (34); limit the primary supplying current (I1) to a predetermined minimum value (I1M) when the secondary current (I2) flowing through at least one of said lighting branches (34) is lesser than a predetermined threshold current (Si); control the simultaneous transition of the light sources (37) from a pre-lighting state to a complete-lighting state, when each of the secondary currents (I2i) flowing through the lighting branches (34) is greater than or equal to the predetermined current threshold (Si).

Classes IPC  ?

• H05B 33/08 - Circuits pour faire fonctionner des sources lumineuses électroluminescentes

Abrégé

A method for injection moulding of plastic -material lenticular bodies (1) for lights; of motor vehicles and similar, the method comprising the steps of coupling a punch half-mould (15) with a first matrix half-mould (13) so as to define, on the surface of the punch half -mould (15), a first closed cavity that copies in reverse the shape of a first plastic-material sheet (2); filling said first cavity with a first plastic polymer in a liquid state, injecting the first plastic polymer in the first cavity from an injection point located at said first segment of the peripheral edge (2a) of the first plastic-material sheet (2); and finally separating, after the first plastic polymer has solidified to form the first plastic -material sheet (2), the punch half- mould (15) from the first; matrix half -mould (13) maintaining the first plastic-material sheet (2) still on the surface of the punch half -mould (15).

Classes IPC  ?

• B29C 45/00 - Moulage par injection, c.-à-d. en forçant un volume déterminé de matière à mouler par une buse d'injection dans un moule ferméAppareils à cet effet
• B29C 45/16 - Fabrication d'objets multicouches ou polychromes
• F21V 5/00 - Réfracteurs pour sources lumineuses

Produits et services

Lampes pour projecteurs de véhicules à moteurs, motocyclettes, projecteurs marins et projecteurs équipés avec ces lampes.

Produits et services

(1) Oil filters and air cleaners for motor vehicles. (2) Switching arrangement for headlights and direction indicators for motor vehicles; electric lighting switches; electric switches. (3) Headlights; headlamps; flash lights; fog lamps; signalling lights for motor vehicles; lighting fixtures for land, air and water locomotion vehicles. (4) Direction indicators for motor vehicles; cigar lighters for automobiles; electrical windshield wipers and windshield washers.
