Maskiner för avfall och återvinning; maskiner för plast och gummiindustrin; granulatorer och rivmaskiner för industriellt bruk; dammseparatorer; transportörer för granulatorer och rivmaskiner för industriellt bruk; industriella skärmaskiner; metallseparatorer; inkluderat delar och komponenter av nämnda varor.
Granulator mill (1) comprising a cutter housing (10), a granule chamber (11) with a seat (13), a rotatable rotor (20) arranged inside the granule chamber (11 ) which rotor (20) comprises a first blade (21) at its periphery. The cutter housing (10) comprises a fixed second blade (12) arranged on the seat (13) and arranged for cooperation with the first blade (21) of the rotor (20). The granulator mill (1) further comprises a stop (14) arranged at the back side (12b) of each second blade (12), which stop (14) is arranged to prevent the second blade (12) from moving away from the rotor (20). The back side (12b) of each second blade (12) further comprises a recess (16) and a rotatable tensioning screw (17) is arranged into the recess (16) and into the seat (13), wherein the upon rotating the tensioning screw (17), the second blade (12) may be tensioned or loosened in the second direction (Y).
B02C 18/16 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs Parties constitutives
09 - Appareils et instruments scientifiques et électriques
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Data processing equipment, computers, computer hardware, and wireless communication devices for voice, data or image transmission, all the aforementioned for implementing the Internet of Things (IoT) for machines used for separating recyclable materials, plastic processing machines, granulating machines for chemical processing and shredders for industrial use; data processing equipment, computers, computer hardware, and wireless communication devices for voice, data or image transmission, all the aforementioned for collecting, analyzing and exploiting data from machines used for separating recyclable materials, plastic processing machines, granulating machines for chemical processing and shredders for industrial use Cloud computing featuring software for use in database management used to collect, analyze and exploit data from machines used for separating recyclable materials, plastic processing machines and granulating machines for chemical processing and shredders for industrial use
09 - Appareils et instruments scientifiques et électriques
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Data processing equipment, computers, computer hardware, and wireless communication devices for voice, data or image transmission, all the aforementioned for implementing the Internet of Things (IoT) for machines used for separating recyclable materials, plastic processing machines, granulating machines for chemical processing and shredders for industrial use; data processing equipment, computers, computer hardware, and wireless communication devices for voice, data or image transmission, all the aforementioned for collecting, analyzing and exploiting data from machines used for separating recyclable materials, plastic processing machines, granulating machines for chemical processing and shredders for industrial use Cloud computing featuring software for use in database management used to collect, analyze and exploit data from machines used for separating recyclable materials, plastic processing machines and granulating machines for chemical processing and shredders for industrial use
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Cloud computing services for collecting, analyzing and exploiting data from machines used for separating recyclable materials, plastic processing machines, granulating machines for chemical processing and shredders for industrial use.
09 - Appareils et instruments scientifiques et électriques
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Computer software, data processing equipment, computers, computer hardware and communication devices for use in implementing the Internet of Things (IoT) for machines used for separating recyclable materials, plastic processing machines, granulating machines for chemical processing and shredders for industrial use; computer software, data processing equipment, computers, computer hardware and communication devices for collecting, analyzing and exploiting data from machines used for separating recyclable materials, plastic processing machines, granulating machines for chemical processing and shredders for industrial use. Cloud computing services for collecting, analyzing and exploiting data from machines used for separating recyclable materials, plastic processing machines, granulating machines for chemical processing and shredders for industrial use.
B02C 18/14 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs à l'intérieur de récipients horizontaux
B29B 17/04 - Désintégration des matières plastiques
B02C 18/16 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs Parties constitutives
10.
Feeding arrangement for a granulator and granulator comprising such a feeding arrangement
An accumulation device that is operable in a feeding arrangement of a granulator, for accumulating flat material to be granulated, includes a first guiding device and a second guiding device. The accumulation device further includes a rotational shaft arranged to connect the accumulation device to the feeding arrangement. The first and the second guiding device are fixedly arranged in relation to each other so that when the accumulation device is rotated around its rotational shaft, the first guiding device as well as the second guiding device is rotated around the rotational shaft. A feeding arrangement and a granulator including such an accumulator device are also provided.
B29B 9/04 - Fabrication de granulés par division de matière préformée en plaques ou en feuilles
B29B 17/04 - Désintégration des matières plastiques
B02C 18/14 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs à l'intérieur de récipients horizontaux
Granulator mill (1) comprising a frame (10), a cutter housing (20) with a granule chamber (22) comprising at least one non-rotatable blade (24) inside the granule chamber (22), and further comprising a rotatable rotor (30) arranged inside the granule chamber (22). The rotor (30) comprises blades (32, 34) which are arranged for cooperation with the non-rotatable blade (24) for granulating waste material to granules. A normal (n) to a first opening (26a) of the granule chamber (22) is pointing substantially vertically upwards in the normal position of use of said granulator mill (1), and characterising is that the cutter housing (20) is pivotably arranged at the frame (10) by means of a first pivot means (28), for pivoting the cutter housing (20) between the normal position of use and a cleaning position. In the cleaning position, the normal (n) of the first opening (26a) of the granule chamber (22) points towards a surface plane of the substrate.
B02C 18/14 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs à l'intérieur de récipients horizontaux
B02C 18/16 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs Parties constitutives
Granulator mill granule chamber including at least one non-rotatable blade, rotatable rotor arranged inside the granule chamber, the rotor a number of blades which are arranged for cooperation with the non-rotatable blade, a infeed hopper for feeding waste into the granule chamber, a grid arranged in the granule chamber, where through granulated waste is allowed to pass to an outfeed hopper. A scraping device is provided in a space located axially in between a housing and the rotatable rotor and the scraping device is attached to the housing.
B02C 18/14 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs à l'intérieur de récipients horizontaux
B02C 23/10 - Séparation ou triage de matériaux, associé au broyage ou à la désagrégation au moyen d'un séparateur situé dans le passage de décharge de la zone de broyage ou de désagrégation
B02C 18/16 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs Parties constitutives
Disclosed is an accumulation device (150) operable in a feeding arrangement (110) of a granulator, for accumulating substantially flat material to be granulated. The accumulation device (150) comprises a first guiding device (152) and a second guiding device (154). The accumulation device (150) further comprises a rotational shaft (156) arranged to connect the accumulation device (150) to the feeding arrangement (110). The first and the second guiding device (152, 154) are fixedly arranged in relation to each other so that when the accumulation device (150) is rotated around its rotational shaft, the first guiding device (152) as well as the second guiding device (154) is rotated around the rotational shaft (156). Disclosed are further a feeding arrangement (110) and a granulator comprising such an accumulator device (150).
B02C 18/14 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs à l'intérieur de récipients horizontaux
Machines for separating recyclable materials; plastic processing machines; granulating machines for chemical processing; shredders for industrial use; dust separators; conveyors for granulators and shredders for industrial use; industrial guillotine machines being cutting machines other than for office use; metal separators, namely, machines for separating metal from other materials; replacement parts for the aforementioned goods
Machines for separating recyclable materials; plastic processing machines; granulating machines for chemical processing; shredders for industrial use; dust separators; conveyors for granulators and shredders for industrial use; industrial guillotine machines being cutting machines other than for office use; metal separators, namely, machines for separating metal from other materials; replacement parts for the aforementioned goods
Granulator mill (1) comprising granule chamber (3) comprising at least one non- rotatable blade (4), rotatable rotor (8) arranged inside the granule chamber (3), the rotor (8) comprising a number of blades (10) which are arranged for cooperation with the non-rotatable blade (4), a infeed hopper (5) for feeding waste into the granule chamber, a grid arranged in the granule chamber, where through granulated waste is allowed to pass to an outfeed hopper (30). A scraping device (15) is provided in a space (14) located axially in between a housing (2) and the rotatable rotor (8) and the scraping device (15) is attached to the housing (2).
B02C 18/16 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs Parties constitutives
B02C 18/14 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs à l'intérieur de récipients horizontaux
Machines for waste and recycling; machines for the plastic and rubber industry; granulators and shredders for industrial use; dust separators; conveyors for granulators and shredders for industrial use; industrial guillotine machines; metal separators; including parts and components for the aforementioned goods.
Machines for waste and recycling; machines for the plastic and rubber industry; granulators and shredders for industrial use; dust separators; conveyors for granulators and shredders for industrial use; industrial guillotine machines; metal separators; including parts and components for the aforementioned goods.
A feeding device for feeding left-over material (2) to be disintegrated, comprising a rotating feeding roll (9) and a catcher (12) arranged substantially in parallel with the feeding roll (9). The catcher (12) is yielding and non-locking in order to stay in contact with the feeding roll (9) and to prevent the return of disintegrated material past the feeding roll (9). The catcher (12) is divided into sections (12a, 12b, 12c) being individually yielding and non-locking. In a particular embodiment, the spring features are adjustable.
B02C 23/00 - Procédés auxiliaires, dispositifs auxiliaires ou accessoires spécialement adaptés au broyage ou à la désagrégation non prévus dans les groupes ou non adaptés spécialement aux appareillages couverts par un seul des groupes
17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Machines for waste and recycling; machines for the plastic
and rubber industry; granulators and shredders for
industrial use; dust separators; conveyors for granulators
and shredders for industrial use; industrial guillotine
machines; metal separators; including parts and components
for the aforementioned goods. Soundproofing materials (non-metal) for use together with
granulators and shredders for industrial use. Repair, maintenance and installation of machines for waste
and recycling, machines for the plastic and rubber industry,
granulators and shredders for industrial use, dust
separators, conveyors for granulators and shredders for
industrial use, industrial guillotine machines, metal
separators, metal detectors for industrial purposes
including parts and components for the aforementioned goods.
17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
37 - Services de construction; extraction minière; installation et réparation
Produits et services
(1) Machines for waste and recycling; machines for the plastic and rubber industry, namely granulators, shredders and downsizing machines for industrial use; dust separators, namely machines for separating dust from other materials; conveyors for granulators and shredders for industrial use; industrial guillotine machines; metal separators, namely machines for separating metal waste from other materials; including parts and components for the aforementioned goods.
(2) Soundproofing materials (non-metal) for use together with granulators and shredders for industrial use, namely soundproofing foam. (1) Repair, maintenance and installation of machines for waste and recycling, machines for the plastic and rubber industry, granulators and shredders for industrial use, dust separators, conveyors for granulators and shredders for industrial use, industrial guillotine machines, metal separators, metal detectors for industrial purposes including parts and components for the aforementioned goods.
09 - Appareils et instruments scientifiques et électriques
17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler
37 - Services de construction; extraction minière; installation et réparation
Produits et services
Machines for waste and recycling; machines for the plastic and rubber industry; granulators and shredders for industrial use; dust separators; conveyors for granulators and shredders for industrial use; industrial guillotine machines; metal separators; including parts and components for the aforementioned goods. Metal detectors for industrial purposes. Soundproofing materials (non-metal) for use together with granulators and shredders for industrial use. Repair, maintenance and installation of machines for waste and recycling, machines for the plastic and rubber industry, granulators and shredders for industrial use, dust separators, conveyors for granulators and shredders for industrial use, industrial guillotine machines, metal separators, metal detectors for industrial purposes including parts and components for the aforementioned goods.
The present invention relates to a control system for a rotary grinder. Rotary grinders control systems of the present invention are, for example, used to grind plastic or wood to reduce the size of the material to a desired size. Material to be ground is forced by an hydraulic ram toward a rotor having a plurality of cutters thereon. The control system is capable of controlling the grinding operation as a function of ram velocity and pressure as well as power consumption by the rotor.
B02C 23/00 - Procédés auxiliaires, dispositifs auxiliaires ou accessoires spécialement adaptés au broyage ou à la désagrégation non prévus dans les groupes ou non adaptés spécialement aux appareillages couverts par un seul des groupes
B02C 4/32 - Ajustage des meules, application de pression sur les meules, ou réglage de l'écartement entre les meules
A bolt-in toolholder assembly for a shredding device includes a rotor having a substantially cylindrical shape, a plurality of pockets formed in the rotor and spaced apart preselected distances to form preselected patterns, a bolt-in toolholder.
B02C 18/06 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs
A method of producing a foundation bed (1) for a granulator mill includes the steps that the foundation bed is cast from a plastic- or concrete based casting material in a mold (13) manufactured from thin sheet metal, the mold being given surfaces (16) for cooperation with a granulator mill housing (2) with high precision. In order to avoid after-treatment of the surfaces (16) of the mold intended for cooperation with the granulator mill housing, these surfaces are clamped during the casting process against a common, configurationally stable clamping member.
A granulator mill housing for a granulator mill has a rotor (4), provided with knives, journalled therein, and seats (8) against which fixed knives (7) may be fixedly clamped by means of screws (18) and guide bars (9). At a lower seat, there is a stand (10) on which a guide bar (9) is placeable in a preparatory position. The side (13) of the guide bar, intended for cooperation with the knife (7) is turned upwards. Pivoting of the guide bar and the knife will move the knife into abutment with the seat (8). On mounting of a knife (7) against a seat (8) in a granulator mill housing, the knife and a guide bar (9) are screwed in position against the seat (8). First the guide bar (9) is placed on a stand (10), whereafter the knife is placed on the guide bar, and the guide bar and the knife are pivoted together to a mounting position with the knife in abutment against the seat (8) where screws (19) are mounted.
B02C 18/14 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs à l'intérieur de récipients horizontaux
B02C 18/16 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs Parties constitutives
A granulator mill has a mill housing with a fixed section (8) and an openable hatch (9), which is pivotally connected to the fixed section by the intermediary of a first pivot with a vertical pivot axis (10), The openable hatch has a first part (16) and a second part (17), which are pivotally connected to one another by the intermediary of a second pivot (18) with a vertical pivot axis.
B02C 18/16 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs Parties constitutives
B02C 18/14 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs à l'intérieur de récipients horizontaux
A method of producing a foundation bed (1) for a granulator mill includes the steps that the foundation bed is cast from a plastic- or concrete based casting material in a mould (13) manufactured from thin sheet metal, the mould being given surfaces (16) for cooperation with a granulator mill housing (2) with high precision. In order to avoid after-treatment of the surfaces (16) of the mould intended for cooperation with the granulator mill housing, these surfaces are clamped during the casting process against a common, configurationally stable clamping member.
B29C 39/10 - Moulage par coulée, c.-à-d. en introduisant la matière à mouler dans un moule ou entre des surfaces enveloppantes sans pression significative de moulageAppareils à cet effet pour la fabrication d'objets de longueur définie, c.-à-d. d'objets séparés en incorporant des parties ou des couches préformées, p. ex. coulée autour d'inserts ou sur des objets à recouvrir
B28B 1/14 - Fabrication d'objets façonnés à partir du matériau par simple coulée, le matériau n'étant ni alimenté sous pression, ni réellement compacté
F16M 5/00 - Bâtis pour machines, c.-à-d. moyens de tenir les moteurs ou machines sur leurs fondations
B02C 18/00 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue
The present invention relates to a single shaft rotary grinder having a modular and/or split apart configuration. The modular configuration has assembly units and/or component parts that are interchangeable providing ease of construction of a rotary grinder having desired functionality for a specific application and/or providing ease of maintenance with the ability to replace worn or broken assembly units or component parts. The split apart configuration provides for the separation of a rear power head assembly and a front feeder assembly allowing easy access to the rotor and rear inner portion of the feed assembly.
B02C 18/16 - Désagrégation par couteaux ou autres organes coupants ou déchirants qui transforment le matériau en fragmentsHachoirs ou appareils similaires utilisant des vis ou analogue à couteaux rotatifs Parties constitutives
