Abrégé

The invention relates to a tamping unit for tamping sleepers of a track, comprising a tamping unit segment with opposing tamping tools tiltably mounted on a height-adjustable tool carrier, with the respective tamping tool being coupled with a vibration drive via a transmission element. The respective transmission element is connected with the assigned tamping tool via a first joint and with a squeezing drive supported on the same tamping tool via a second joint. This design enables a space-saving arrangement of the squeezing drives, resulting in a compact design.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

Safety device (1) on a rail vehicle (2), said rail vehicle being either unconnected or part of a rail vehicle train (13) coupled by coupling devices (12) in the rail network of a rail network operator, which safety device comprises at least one measuring device (1A) having at least two sensors (6, 7A, 7B, 7C, 7D, 8A, 8B) for detecting the present operating state of the rail vehicle (2), an evaluation device (1B), a communication device for communication (9C, 9D) between the rail vehicle (2) and trackside apparatuses of the rail network operator, and an autonomous power supply (3, 4A) that is independent of power supply units not located in or on the rail vehicle (1), wherein the at least one measuring device (1A) is configured to detect the state of motion of the rail vehicle (2) as a first equipment state and at least one further required equipment state, the evaluation device (1B) is configured to determine, for detected required equipment states, whether said equipment states are within a defined operating limit or outside a defined permissible operating range, and at least one warning device (9A, 9B) or an adjusting device (1C) is intended to change the operating state, if necessary, on the basis of the situation of the required equipment states that has been determined by the evaluation device with regard to the operating range and/or operating limits.

Classes IPC  ?

• B61L 15/00 - Indicateurs de signalisation sur le véhicule ou sur le train
• B61L 25/02 - Indication ou enregistrement de la position ou de l'identité de véhicules ou de trains
• B60T 17/22 - Dispositifs pour surveiller ou vérifier les systèmes de freinsDispositifs de signalisation

Abrégé

A tamping unit for tamping a track has tamping tools arranged in pairs. The tamping tools can be squeezed towards each other by a respective squeezing cylinder. A squeezing piston can be subjected to a hydraulic pressure of a first hydraulic circuit arranged in the respective squeezing cylinder. A vibration piston is assigned to each squeezing cylinder to superimpose a vibration on a squeezing movement. The vibration piston is arranged in a pressure amplifier with a primary cylinder and a secondary cylinder. In this way, vibration generation can be carried out at a lower pressure level.

Classes IPC  ?

• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface

Abrégé

The invention relates to a machine (1) for laying a contact wire (8) and/or a supporting cable (9) of an overhead line of a track (4), said machine comprising: a machine frame (2) that can be moved on rail bogies (3); a storage drum holder (11); a height-adjustable mounting roller unit (15); and a friction winch (13). The friction winch (13) comprises a driving body (17) around which an endless shoe chain (18) with shoe links (21) for receiving the contact wire (8) and/or the supporting cable (9) is wrapped in such a manner that a winding section (19) of the shoe chain (18), which winding section is in contact with the driving body (17) for at least one turn, is spanned by a non-contacting winding section (20). This ensures that lateral displacement and tangential force transmission between the friction winch (13) and the contact wire (8) or supporting cable (9) are independent of each other.

Classes IPC  ?

• B60M 1/28 - Fabrication ou réparation des lignes de trolley

Abrégé

12122(t)) determined by means of a method which is independent of the wheel diameter, and - ascertaining the current wheel diameter (d(t)) by means of the result of the comparison.

Classes IPC  ?

• B61L 15/00 - Indicateurs de signalisation sur le véhicule ou sur le train
• B61K 9/12 - Mesure ou surveillance des jantes des roues
• B61L 27/57 - Diagnostic ou maintenance côté voie, p. ex. mises à jour de logiciel pour des véhicules ou des trains, p. ex. surveillance côté voie de l'état des trains

Abrégé

A method for the contactless detection of a position of a measurement device that can be moved by a rail running gear on a track relative to at least one rail of the track. A projection of a laser beam that is projected onto the at least one rail and onto the inner side of a wheel of the rail running gear is detected by way of a camera. A detected position of the measurement device with respect to the wheel inner side is evaluated by an evaluation device. The inner side of the wheel disc is used as a reference base for determining at least one position value of the measurement device.

Classes IPC  ?

• B61K 9/08 - Installations de mesure pour surveiller la voie
• G01B 11/02 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques pour mesurer la longueur, la largeur ou l'épaisseur

Abrégé

A method for determining a reference position (2.1, 2.2, 2.3) of a reference object (3.1, 3.2, 3.3) in a track environment (4) comprises the steps of: generating measurement data by detecting the track environment (4), evaluating the measurement data by identifying the reference object (3.1, 3.2, 3.3) in the track environment (4) and determining the reference position (2.1, 2.2, 2.3) of the reference object (3.1, 3.2, 3.3) on the basis of the measurement data, the track environment (4) being detected by detecting radar radiation (5). A measuring device for determining a reference position (2.1, 2.2, 2.3) of a reference object (3.1, 3.2, 3.3) in a track environment (4) and a system (1) comprising such a measuring device (6).

Classes IPC  ?

• B61L 15/00 - Indicateurs de signalisation sur le véhicule ou sur le train
• B61L 25/02 - Indication ou enregistrement de la position ou de l'identité de véhicules ou de trains
• G01S 13/00 - Systèmes utilisant la réflexion ou la reradiation d'ondes radio, p. ex. systèmes radarSystèmes analogues utilisant la réflexion ou la reradiation d'ondes dont la nature ou la longueur d'onde sont sans importance ou non spécifiées

Abrégé

A method for carrying out work on a railway track by means of a rail vehicle, comprising a track motor vehicle with at least one electrically operable treatment device and an energy supply device for providing electrical energy, as well as a trailer wagon coupled to the track motor vehicle with an energy storage device for providing electrical energy, with the rail vehicle being driven to a track point to be treated, with the trailer wagon being decoupled from the track motor vehicle, and with the track point to be treated being treated by means of the track motor vehicle. Before and/or after treatment by means of the track motor vehicle, the track point is treated by means of the trailer wagon by supplying an electric traction drive of the trailer wagon and a treatment device of the trailer wagon with electrical energy from the energy storage device. In this way, the trailer wagon is used autonomously for track treatment.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• E01B 31/17 - Enlèvement du métal des rails, joints de rails, ou plaques d'appui, p. ex. pour l'ébarbage des soudures, la remise en état des rails usés par meulage

Abrégé

A method operates a tamping machine on a track. The tamping machine contains a tamping unit, a lifting and lining unit, a measuring system with a measuring value transducer, and a control/regulating device. The lifting and lining unit being actuated by the control/regulating device as a function of a track position recorded by the measuring system in such a way that a treated track section is lifted to a target level during a lifting time. At least two controllers set up in the control/regulating device are selected in such a way that the first controller is activated in a first lifting mode for standard operation and that the second controller is activated in a second lifting mode for turnouts. The respective controller is optimized for the assigned controlled line.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie

Abrégé

Proposed is a method for tamping sleepers (9) of a track (3) by means of a tamping assembly (6), the tamping tools (12) of which are plunged into a ballast bed (11) and squeezed toward one another, with the condition of the ballast bed (11) being determined. Here, a setting value (E) for a squeeze pressure (pB) for pressurizing squeeze cylinders (16) of the tamping assembly (6) is automatically specified on the basis of the determined condition of the ballast bed (11). It is thus possible for the squeeze pressure (pB) to be adapted during every tamping operation to the conditions in the ballast bed (11). The invention also relates to a system for tamping sleepers of a track.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

The invention relates to a machine with a ballast receiving device for receiving ballast located under a track by means of an endless excavating chain guided in a chain channel, with the chain channel being composed of a transverse channel which can be positioned under the track, an empty channel, and a transport channel provided for ballast transport. A conveyor device for transporting ballast in the direction of the transport channel is arranged along a top edge of the transverse channel. This additional device increases the movement of the ballast so that it completely enters the transport channel.

Classes IPC  ?

• E01B 27/04 - Enlèvement du ballastMachines à cet effet, que leur aptitude à enlever le ballast soit ou non accessoire

Abrégé

A device (3) for positioning track processing tools (2) on a track includes: at least two support modules (29, 30), each having at least one tool support (31a, 31b) for supporting the at least one track processing tool (2), and a horizontal positioning apparatus (32) to which the at least one tool support (31a, 31b) is attached, for moving the at least one tool support (31a, 31b) in a horizontal direction (33a). A rotating apparatus (24) for rotating the at least two support modules (29, 30) has at least two rotating units (25, 26) for rotating the at least two support modules (29, 30) independently of one another. A first transverse positioning apparatus (16) is provided for linearly moving the at least two support modules (29, 30) in a horizontal direction (33a, 33b, 33c) and at an angle of at least 45° to the longitudinal direction (9) of the track (4).

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

The invention relates to a tamping machine (1) for tamping ties (12) of a track (4), having a machine frame (2) that is able to travel on railroad rails (9) of the track (4), and having a tamping assembly (6) which comprises, in a machine transverse direction (15), an inner and an outer tamping tool pair (18, 19) having tamping tools (20) that are each able to be positioned next to one another in a machine longitudinal direction (21) and to be subjected to vibration. Narrow tamping picks (27) are arranged on the outer tamping tool pair (19) in order to move ballast under a tie (12) by means of a particular active portion (38), the extension of which in a vertical direction (41) is greater than in the machine transverse direction (15). The particular narrow tamping pick (27) of the tamping assembly (6) according to the invention remains operational even under very confined space conditions.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

The invention relates to a method for checking a state of a check rail (1) of a track (2) of a railway switch, which state is defined by a securing state of the check rail and a wear state of the check rail surface (14, 24) of the check rail (1), which measuring vehicle (18) comprises at least one WHEEL CONTACT sensor unit (21) and a FREE SPACE sensor unit (22), wherein at least one geometric LOAD measurement value describing a LOAD gap cross-sectional shape is determined with the WHEEL CONTACT sensor unit (22) and at least one geometric LOAD FREE measurement value describing a LOAD FREE gap cross-sectional shape is determined with the FREE SPACE sensor unit (22), which LOAD measurement value and LOAD-FREE measurement value describe the gap cross-sectional shape of a gap cross-section extending between the rail (4) of the track (2) and the check rail (1) in the loaded state or in the unloaded state with at least one datum via an inclination of at least one check rail surface (14, 24) relative to a reference plane and/or with at least one datum via an inclination of a tangent of a check rail surface (14, 24) relative to the reference plane.

Classes IPC  ?

• B61L 15/00 - Indicateurs de signalisation sur le véhicule ou sur le train
• B61K 9/08 - Installations de mesure pour surveiller la voie
• B61L 27/53 - Diagnostic ou maintenance côté voie, p. ex. mises à jour de logiciel pour des éléments ou des systèmes côté voie, p. ex. surveillance côté voie de l’état des systèmes de commande côté voie

Abrégé

The invention relates to a work vehicle for carrying out work operations on a track, comprising a vehicle frame which can be moved on the track supported on rail running gears, a drive cab which is connected to the vehicle frame, and various mounted structures with assigned functions for a work operation. The mounted structures are designed as self-supporting function modules with predefined interfaces and connected to the vehicle frame and/or each other by means of threaded connections. The predefined interfaces enable the interconnection of different function modules without further adaptations. All modules are continuously checked with regard to their geometry and their functions to enable joinability in the final assembly without welding and adjustment processes.

Classes IPC  ?

• B61D 15/00 - Autres véhicules ferroviaires, p. ex. véhicules à échafaudageAdaptation des véhicules pour leur utilisation sur voies ferrées
• B61D 17/04 - Parties constitutives structurales du corps des véhicules avec caisses métalliquesParties constitutives structurales du corps des véhicules avec caisses à structure composite, p. ex. en métal et bois

Abrégé

Vzz), which correlates with a vertical reaction force acting between the tamping assembly (18.1, 18.2) and the track bed (2), at different measurement times; and determining the condition of the track bed (2) on the basis of at least two of the measured values detected at different measurement times. Also proposed is an apparatus (1) for carrying out such a method.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses
• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies

Abrégé

The invention relates to an on-track maintenance machine for maintaining a superstructure with a track panel formed of sleepers and rails fixed thereon that is supported on a ballast bed, comprising a lifting and lining unit for track lifting and lining and a tamping unit for track tamping. In the invention, at least one rail treatment unit for continuous reprofiling of the rails is arranged on a machine frame. The elimination of rail defects contributes to a higher durability of the corrected track position, as after re-opening the treated track section, the rails can be used again trouble-free.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses
• E01B 29/04 - Relèvement ou nivellement des voies
• E01B 29/14 - Transport, pose, enlèvement, ou remplacement des traverses en procédant par dessous les rails en place pour soulever les traverses jusqu'aux rails
• E01B 31/13 - Enlèvement du métal des rails, joints de rails, ou plaques d'appui, p. ex. pour l'ébarbage des soudures, la remise en état des rails usés par fraisage
• E01B 31/15 - Enlèvement du métal des rails, joints de rails, ou plaques d'appui, p. ex. pour l'ébarbage des soudures, la remise en état des rails usés par rabotage ou limage

Abrégé

The invention relates to a method for correcting vertical position defects of a track after a lifting-tamping process, with a stabilizing process carried out by means of a dynamic track stabilizer in which a stabilizing unit acts on the track at a forward-moving working point in a working direction, with track position data of the untreated track being recorded before the lifting-tamping process, and with track position data of the tamped track being recorded after the lifting-tamping process at a measuring point located in front of the stabilizing unit in the working direction. In this case, additional track position data of the stabilized track are recorded at an post-measuring point located behind the stabilizing unit in the working direction, with the dynamic track stabilizer being actuated during the stabilizing process as a function of track position data of the untreated and the tamped track at the working point and of track position data of the stabilized track at the post-measuring point. The additional post-measurement of the track position after the stabilizing process enables precise control of the dynamic track stabilizer.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie

Abrégé

An arrangement for optically capturing a railroad track includes a carrier device, a camera, and two light sources. The arrangement is mountable on a carrier vehicle that is movable on rails. The alignment of the two light sources and thus the central axes of the emitted light radiation or waves enclose an acute angle with a longitudinal axis of the rail. The light sources are coupled with the camera via control signal lines. The triggering or activation of the light sources is effected via the control signal lines by a predefined control signal. This achieves detailed, sharp image contours that allow high-precision image evaluation and object recognition at the highest possible working speed.

Classes IPC  ?

• B61K 9/08 - Installations de mesure pour surveiller la voie
• G06V 20/56 - Contexte ou environnement de l’image à l’extérieur d’un véhicule à partir de capteurs embarqués
• H04N 23/60 - Commande des caméras ou des modules de caméras
• H04N 23/95 - Systèmes de photographie numérique, p. ex. systèmes d'imagerie par champ lumineux

Abrégé

The invention relates to a marking element (11) for marking and identifying a point (12) on a track (1), comprising a securing means for securing to a rail (5) of the track (1) and comprising an identification means. The marking element (11) is a sheet metal part, which has an elastic clip (19) as a securing means for clipping to a rail foot (18), and an identification code in the form of a three-dimensional structure (20) as an identification means. A marking element (11) of this type is simply constructed and is recognised by different measuring systems due to the three-dimensional structure (20) of the identification code.

Classes IPC  ?

• B61L 5/12 - Signaux visibles
• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie

Abrégé

The invention relates to a method for tamping a plurality of sleepers of a track supported in a ballast bed by means of a plurality of tamping units arranged one behind the other on a machine frame of a track tamping machine with tamping tools opposite each other in pairs, with only one sleeper being tamped by means of the respective tamping unit during a tamping process. In this context, a control device for actuating longitudinal actuators is given a sleeper spacing of the sleepers to be tamped, with the tamping units being positioned towards each other in the longitudinal direction of the machine by means of the longitudinal actuators prior to a tamping process in order to adjust the positions of the tamping units to the given sleeper spacing, and with sleepers not arranged directly one behind the other being tamped during the tamping process. Due to the distance of the tamping units from each other in the longitudinal direction of the machine by more than one sleeper spacing respectively, sufficient free space to adjust to different sleeper spacings is available.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie

Abrégé

The invention relates to a machine for compacting a ballast bed of a track with a machine frame supported on rail-based running gears and a height-adjustable stabilising unit connected thereto, comprising a vibration drive and an axle with wheel flange rollers movable on rails of the track, whose distance to each other extending perpendicularly to the longitudinal direction of the machine can be varied by means of a spreading drive, as well as a roller clamp that can be pressed against the rails by means of clamping drives. The spreading drive and/or the clamping drives are set up to apply a predefined variable horizontal load force to the rails, whereby a measuring device is arranged to detect a rail head deflection and/or track gauge change caused by the variable load force. In this way, it can be determined by means of the stabilising unit whether the track panel is intrinsically stable.

Classes IPC  ?

• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface
• E01B 35/06 - Applications des appareils ou dispositifs de mesure à la construction des voies pour mesurer les irrégularités dans le sens longitudinal

Abrégé

The invention relates to a method for checking a securing of at least one rail (4a, 4b) of a track (3), comprising the following steps: generating a mechanical movement (Fv); pressing at least one first transmission element (16a, 16b) onto the rail (4a, 4b) using at least one first pressing element (14), wherein the first pressing element (14) generates a first contact pressure (PI) according to a first static target pressure (Plstatisch_ soll); transmitting the mechanical movement (Fv) to the rail (4a, 4b); detecting the movement reactions (R) of the rail (4a, 4b) due to the mechanical movement (Fv) at a first (27) and a second point (28); comparing the movement reaction (R) of the rail (4a, 4b) at the first point (27) with the movement reaction (R) of the rail (4a, 4b) at the second point (28); and evaluating the rail securing on the basis of the comparison of the movement reactions (R) of the rail (4a, 4b) at the first and the second point (28). The invention also relates to a system (7) for carrying out the method.

Classes IPC  ?

• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface
• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies

Abrégé

The invention relates to a method for determining a disturbance torque (MStör_a, MStör_b), in particular a torsion torque of a torsional vibration (13), acting on a wheelset axle (2) of a rail vehicle (27), comprising the following steps: detecting a rotational movement (6a, 6b) of the wheelset axle (1) using at least one sensor (5a, 5b), preferably on the wheelset axle (2); and determining the disturbance torque (MStör_a, MStör_b), preferably an amplitude (A_a, A_b) of the disturbance torque (MStör_a, MStör_b), from the rotational movement (6a, 6b) using a conversion factor (U). The invention also relates to a system (51) for determining a disturbance torque (MStör_a, MStör_b) acting on a wheelset axle (2) of a wheelset (1), as well as a rail vehicle (27) with a system (51) of this type.

Classes IPC  ?

• G01M 17/10 - Suspensions, essieux ou roues
• B61F 5/00 - Détails de structure des bogiesLiaisons entre bogies et châssis du véhiculeAménagements ou dispositifs pour ajuster ou permettre l'auto-ajustement des essieux des roues ou des bogies dans les courbes

Abrégé

The invention relates to a storage cart (1) for bulk material (6), said storage cart comprising: a cart frame (2) that travels on rail bogies (3); a loading container (5) which has a floor conveyor belt (8) extending in the longitudinal direction (7) of the cart and which has lateral walls (16); and a transfer conveyor belt (21), that is connected to the floor conveyor belt (8) and protrudes beyond a front cart frame end (24), for forwarding the stored bulk material (6) in a conveying direction (9) to an upstream cart. A front portion (12) of the floor conveyor belt (8) is bent upwards with respect to the conveying direction (9) and protrudes beyond a lower end (20) of the transfer conveyor belt (21) so that a rear portion (11) of the floor conveyor belt (8) is positioned lower than the lower end (20) of the transfer conveyor belt (21). The low position of the rear portion (11) of the floor conveyor belt (8) allows the loading container (5) together with the lateral walls (16) to be positioned low so as to enable simple loading from the side using an excavator.

Classes IPC  ?

• B61D 7/32 - Dispositifs pour faciliter le chargement ou le déchargement
• E01B 27/00 - Mise en place, renouvellement, travail, nettoyage ou enlèvement du ballast avec ou sans travail concomitant sur la voieDispositifs ad hocRemblayage des traverses
• B65G 15/28 - Transporteurs ayant une surface transportant la charge formée par une seule courroie plate, non prévus ailleurs
• B65G 67/08 - Chargement des véhicules terrestres utilisant des transporteurs sans fin

Abrégé

A method for position determination in a rail transport system (4), comprises the steps of: detecting localisation information (24.1, 24.2, 24.3) describing the surroundings of a localisation position (25.1, 25.2, 25.3) on a track (5), identifying a reference dataset (18.1, 18.2, 18.3) by comparing the localisation information (24.1, 24.2, 24.3) with reference data (18) comprising a plurality of reference datasets (18.1, 18.2, 18.3) each with reference information (19.1, 19.2, 19.3) describing the surroundings of a reference position (20.1, 20.2, 20.3) on the track (5), and determining the localisation position (25.1, 25.2, 25.3) on the basis of the reference position (20.1, 20.2, 20.3) of the identified reference dataset (18.1, 18.2, 18.3). A localisation device (3a, 3b) for position determination in the rail transport system (4). A method and a measuring device for position-related detection of track measurement information in the rail transport system (4). A system comprising the measurement device and the localisation device (3a, 3b).

Classes IPC  ?

• B61L 25/02 - Indication ou enregistrement de la position ou de l'identité de véhicules ou de trains

Abrégé

The invention relates to a tamping machine (1) for tamping sleepers (4) of a track (2), said tamping machine comprising: a machine frame (14) supported on rail bogies (10); and a satellite frame (12) which is positioned between the rail bogies (10), is supported by its own rail bogie (10) at the rear with respect to a working direction (11), and is connected to the machine frame (14) at the front via a frame guide (13) in a longitudinally displaceable manner, and on which a tamping unit (7) is positioned between its own rail bogie (10) and the frame guide (13), wherein the satellite frame (12) can be supported relative to the machine frame (14) by means of a support device (17). The support device (17) is positioned directly above the tamping unit (7). In this manner, the weight of the main machine (8) is used in order to exert a supporting force directly onto the tamping unit (7) via the support device (17). A lever effect that strains the satellite frame (12) is avoided.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

maxredmaxredmaxredmaxredred) lies max. 300 mm, in particular max. 260 mm, above a rolling plane (25) of the flange wheels (15). The sunken horizontal effective plane (14) prevents interfering tilting moments during a stabilisation process.

Classes IPC  ?

• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface
• B06B 1/16 - Procédés ou appareils pour produire des vibrations mécaniques de fréquence infrasonore, sonore ou ultrasonore utilisant l'énergie mécanique fonctionnant avec des systèmes impliquant des masses rotatives non équilibrées
• B06B 1/18 - Procédés ou appareils pour produire des vibrations mécaniques de fréquence infrasonore, sonore ou ultrasonore dans lesquels le vibrateur est déclenché par pression de fluide

Abrégé

The invention relates to a stabilizing assembly (11) for stabilizing a track (2), having a vibration generator (12) and having assembly rollers (15, 16) for transmitting vibrations (14) generated by means of the vibration generator (12) to a track grid (4), which consists of sleepers (5) and rails (6) fastened thereon, of the track (2) that is to be stabilized. In said stabilizing assembly, assembly rollers (15, 16) assigned to a left-hand rail (6) of the track (2) are arranged on a first side frame (19), and assembly rollers (15, 16) assigned to a right-hand rail (6) of the track (2) are arranged on a second side frame (20), wherein the two side frames (19, 20) are connected by a self-supporting central part (18) that comprises the vibration generator (12). A lower center of gravity (21) of the stabilizing assembly (11) as a whole is thus achieved.

Classes IPC  ?

• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface

Abrégé

The invention relates to a method for tamping sleepers of a track panel, supported in a ballast bed, by means of a tamping unit, comprising two tamping tools opposite one another which, during tamping of the respective sleeper, are lowered into the ballast bed with vibrations being applied, and are moved towards each other with a squeezing movement while the track panel is held in a raised position. In this, an evaluation device is used to monitor a squeezing speed of at least one tamping tool, with a current value of the squeezing speed being compared with a limit value when a predefined squeezing time or a predefined squeezing distance is reached, and with a notification signal indicating whether the current value is above the limit value. This may indicate that a void located below the sleeper has not yet been sufficiently filled.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie

Abrégé

A tamping assembly for tamping sleepers of a track has a tamping unit with tamping tools. The tamping tools are located opposite one another, are mounted on a height-adjustable tool support, and, by way of drives, can be caused to vibrate and can be fed relative to each other. Each tamping tool includes a pivot lever, which can be rotated about a feed axis, and an inner and an outer tamping pick retainer. Each tamping pick retainer can be laterally pivoted relative to the pivot lever. The outer tamping pick retainer can be pivoted about a first pivot axis and the inner tamping pick retainer can be pivoted about a second pivot axis. The second pivot axis is arranged at an offset to the first pivot axis. Thus, it is no longer necessary to adjacently arrange elements for pivoting the tamping pick retainers.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

zzz) between the track bed (2) and a track (4) arranged thereon, and an analysis device (17) for determining the quality of the track bed (2) using the measurement signal (h).

Classes IPC  ?

• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface
• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses
• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies

Abrégé

A method for determining the arrangement (p, φ) of a track object (3, 4), in particular a track structure component (3, 4), comprises the following steps: detecting a measurement signal that correlates with the arrangement (p, φ) of the track object (3, 4), and determining the arrangement (p, φ) of the track object (3, 4) based on the measurement signal, wherein the detection of the measurement signal comprises the detection of radar radiation. A measurement device (2) for determining the arrangement (p, φ) of a track object (3, 4), in particular a track structure component (3, 4), comprises a sensor device (16) for detecting a measurement signal that correlates with the arrangement (p, φ) of the track object (3, 4), and an evaluation device (17) for determining the arrangement (p, φ) of the track object (3, 4) based on the measurement signal, wherein the sensor device (16) is designed to detect radar radiation. The invention also relates to a system (1) having such a measurement device (2) and having at least one track processing unit (5).

Classes IPC  ?

• B61L 15/00 - Indicateurs de signalisation sur le véhicule ou sur le train
• B61K 9/08 - Installations de mesure pour surveiller la voie
• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie

Abrégé

A measuring system for measuring the elasticity of an overhead line of a track includes a non-contacting sensor for detecting the position of a measuring point of the overhead line and an evaluation device for calculating the elasticity. A mechanical excitation device sets the overhead line into vibration through active excitation. The sensor is set up to detect a vibration progression and the evaluation device is set up to derive mechanical properties of the overhead line from the vibration progression. The mechanical properties, such as the elasticity of the overhead line, are derived from characteristics of the corresponding vibration curves in the evaluation device. A method for measuring the elasticity of an overhead line of a track and a track construction vehicle are also provided.

Classes IPC  ?

• B61D 15/12 - Wagonnets d'inspection de la voie propulsés par moteur
• B60M 1/28 - Fabrication ou réparation des lignes de trolley
• B61K 9/08 - Installations de mesure pour surveiller la voie

Abrégé

The invention relates to a method for measuring the position (p) of at least one reference object (1), in particular of a fixed point (1), for measuring a structural track element (3a), which method comprises the steps: generating measured data by capturing the surface of the earth (7) by means of a satellite system (8), and determining the position (p) of the at least one reference object (1) on the basis of the measured data. The invention also relates to a system (4) for measuring the position (p) of at least one reference object (1), in particular of a fixed point (1), for measuring a structural track element (3a), which system comprises a receiving unit (6) which is designed to receive measured data relating to the surface of the earth (7) from a satellite system (8), and an analysis unit (12) which is designed to determine the position of the at least one reference object (1) on the basis of the measured data. The invention also relates to a measuring assembly (28) which comprises a reference object (1), in particular a fixed point (1), for measuring a structural track element (3a), and a signal reflector (27) arranged on the reference object (1) for reflecting a measured signal.

Classes IPC  ?

• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• B61L 27/40 - Traitement de rapports de position ou de données relatives aux véhicules côté voie
• B61L 27/53 - Diagnostic ou maintenance côté voie, p. ex. mises à jour de logiciel pour des éléments ou des systèmes côté voie, p. ex. surveillance côté voie de l’état des systèmes de commande côté voie
• G01S 13/02 - Systèmes utilisant la réflexion d'ondes radio, p. ex. systèmes du type radar primaireSystèmes analogues

Abrégé

The invention relates to a tamping unit (1) for tamping sleepers (37, 43, 44) of a track (38), having tamping tools (7) which are situated opposite one another with respect to a vertical central plane (6), which are mounted on a height-adjustable tool carrier (2), and which are each connected to a feed drive (12) for generating a feed movement, wherein a lever arm (10) having a connection part (11) that projects beyond the central plane (6) is arranged on each tamping tool (7), and wherein the connection part (11) of each lever arm (10) is connected to the associated feed drive (12). This arrangement results in an approximately symmetrical construction of all drive elements, with an optimized load situation during operation.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

The invention relates to a method for determining correction values for correcting a position of a track, with an actual geometry of a track section being recorded by means of an inertial measurement device arranged on a track inspection vehicle while the track is being travelled on, and with measuring data the recorded track section being output by the inertial measurement device to an evaluation device. In this case, a virtual inertial measurement of the same track section with a target geometry is calculated by means of a simulation device in order to obtain simulated measuring data for the target geometry, with correction values correcting the position of the track being determined by subtracting the simulated measuring data from the measuring data of the inertial measurement device by means of a computing unit. With the method according to the invention, correction values are determined directly on the basis of the measuring data of the inertial measurement device.

Classes IPC  ?

• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• B61K 9/08 - Installations de mesure pour surveiller la voie

Abrégé

The invention relates to a rail vehicle (1) having a vehicle frame (2) which is movable on rails (5) of a track (4) in a manner supported on bogies (3), comprising a measurement platform (9) with a first inertial measurement system (13) for capturing track position data. The same measurement platform (9) has an associated second inertial measurement system (13) for measuring a movement of the measurement platform (9), the two inertial measurement systems (13) being coupled to a computer (17) and an algorithm for evaluating captured track position data being set up in the computer (17). Additional measured values are therefore available for calculating the track position data.

Classes IPC  ?

• B61L 25/02 - Indication ou enregistrement de la position ou de l'identité de véhicules ou de trains

Abrégé

A method detects vibrations transmitted in the area of a track, with the track being vibrated during a work process by a work unit of a track maintenance machine travelling along the track. The vibrations being transmitted via the track are measured by a sensor distanced from the work unit and with measuring data of the sensor being evaluated in an evaluation device. In that, a position of the sensor with respect to the work unit is given to the evaluation device, with a correlation between a vibration effect of the work unit detected with the sensor and a distance between the work unit and the sensor being calculated in the evaluation device. The method has the advantage that the vibration effect of the work unit can be detected in real time at the location of the sensor.

Classes IPC  ?

• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies
• G01H 1/00 - Mesure des vibrations dans des solides en utilisant la conduction directe au détecteur
• B61L 27/20 - Commande côté voie de la sécurité du déplacement d'un véhicule ou d'un train , p. ex. calcul des courbes de freinage
• B61L 1/06 - Dispositifs électriques associés à la voie actionnés par déformation du railDispositifs électriques associés à la voie actionnés par vibration du rail

Abrégé

12123412122).

Classes IPC  ?

• B61K 9/08 - Installations de mesure pour surveiller la voie
• B61L 15/00 - Indicateurs de signalisation sur le véhicule ou sur le train
• B61L 25/02 - Indication ou enregistrement de la position ou de l'identité de véhicules ou de trains
• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses
• E01B 35/06 - Applications des appareils ou dispositifs de mesure à la construction des voies pour mesurer les irrégularités dans le sens longitudinal
• G01C 22/00 - Mesure de la distance parcourue sur le sol par des véhicules, des personnes, des animaux ou autres corps solides en mouvement, p. ex. en utilisant des odomètres ou en utilisant des podomètres

Abrégé

A method for determining a target geometry of a track for correcting the geometry of the track. An actual geometry of the track is detected first on a track section by a measuring system and the target geometry is calculated on the basis of the actual track geometry afterwards by way of a computing unit. Actual position points of the track are detected along the track section by a position detection system, with at least one actual position point being given to the computing unit as a point of restraint, and with the target geometry being calculated by the computing unit such that the target geometry is adapted to the actual geometry as a sequence of geometric track alignment design elements and is placed through the preset point of restraint. The method achieves a significant increase in quality compared to the known compensation method using pre-measurement.

Classes IPC  ?

• B61K 9/08 - Installations de mesure pour surveiller la voie
• G01C 7/04 - Tracé de profils des surfaces du terrain mettant en jeu un véhicule qui se déplace le long du profil à tracer
• B61L 25/02 - Indication ou enregistrement de la position ou de l'identité de véhicules ou de trains

Abrégé

Disclosed is a device (2) for relocating an infrastructure component (4), in particular a track support plate, which has been placed in a provisional position on an underlying surface (3), into a desired arrangement, the device comprising a connecting means (33) for fastening the device (2) to a counterpart connecting means (8) of the infrastructure component (4), an underlying-surface contact means for placing on the underlying surface (3), an actuating device (29) for receiving a first rotational movement about a first axis of rotation (37), and a transmission device (34) for converting the first rotational movement into a first relocating movement of the underlying-surface contact means relative to the infrastructure component (4) with a translational movement component oriented perpendicularly to a first axis of rotation (37). Also disclosed are a combination (16) and a system (1) having at least one such device (2). Also disclosed is a method for relocating an infrastructure component (4).

Classes IPC  ?

• E01B 29/04 - Relèvement ou nivellement des voies

Abrégé

The invention relates to a track maintenance machine for tamping sleepers installed on a ballast bed of a track, comprising a machine frame movable on rail-based running gears, track lifting and lining units for correcting the track geometry as well as two 1-sleeper tamping units arranged one behind the other in the direction of the longitudinal axis of the machine that work independently of one another, with each tamping unit comprising at least four tamping unit segments that work independently of one another, adjustable in height via vertical drives and horizontally shiftable in the transverse direction of the machine via transverse drives, with each tamping unit segment comprising at least one tamping tool carrier, with opposing tamping tools being mounted on the tamping tool carrier and coupled via a vibration drive. It is provided that one of the two tamping units is designed as a turnout tamping unit, that by means of a shifting unit consisting of three transverse guiding units that work independently of one another the associated tamping unit segments are transversely shiftably mounted and can be positioned outwards with respect to the longitudinal axis of the machine in relation to the machine frame or in relation to a satellite frame movable along the longitudinal axis of the machine, and that the other tamping unit is designed as a plain-line tamping unit in such a way that the associated tamping unit segments are transversely shiftably mounted and can be positioned with only one shifting unit. This increases the machine's performance and thus its tamping output when maintaining plain lines and/or turnouts.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie

Abrégé

The invention relates to a measuring method for determining the nature of a track base (2), comprising the following steps: emitting an electromagnetic primary radiation (21) into the track base (2) at at least one transmitting position (23), and detecting a secondary radiation (22) brought about by the primary radiation (21) and reflected back out of the track base (2) at at least one detection position (24) which is spaced apart from the transmitting position (23). The invention also relates to a measuring method for determining the nature of a track base.

Classes IPC  ?

• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• G01S 13/60 - Systèmes de détermination de la vitesse ou de la trajectoireSystèmes de détermination du sens d'un mouvement dans lesquels l'émetteur et le récepteur sont montés sur l'objet mobile, p. ex. pour déterminer la vitesse par rapport au sol, l'angle de dérive, le trajet au sol
• G01S 13/88 - Radar ou systèmes analogues, spécialement adaptés pour des applications spécifiques

Abrégé

A tamping machine has a tamping unit for simultaneously tamping sleepers of a track that are positioned directly behind one another. Tamping unit segments are arranged one behind the other. Each tamping unit segment has a height-adjustable tamping tool carrier on which opposing tamping tools are mounted that are coupled to a vibration drive via squeezing cylinders. The respective vibration drive has an eccentric shaft with first and second eccentric discs, the axes of symmetry of which, together with a common axis of rotation, span two eccentric planes that enclose a relative angle to one another. A first squeezing cylinder is mounted on the first eccentric disc. An opposing second squeezing cylinder is mounted on the second eccentric disc. Cylinder axes of the opposing squeezing cylinders enclose a position angle which is approximated to the relative angle of the eccentric planes.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

The invention relates to a method for contactlessly detecting a position of a measurement device (2) that can be moved by means of a rail bogie (3) on a track (8) relative to at least one rail (1) of the track (8), wherein a projection (17) of a laser beam (15) projected onto the at least one rail (1) is detected by means of a camera (11). The projection (17) is projected onto the rail (9) and onto the inner side (18) of a wheel (19) of the rail bogie (3), wherein a detected position of the measurement device (2) with respect to the wheel inner side (18) is evaluated by means of an evaluation device (21). This method uses the inner side (18) of the wheel disc as a reference base for determining at least one position value of the measurement device (2).

Classes IPC  ?

• B61L 15/00 - Indicateurs de signalisation sur le véhicule ou sur le train
• B61K 9/08 - Installations de mesure pour surveiller la voie
• B61L 27/50 - Diagnostic ou maintenance côté voie, p. ex. mises à jour de logiciel
• E01B 35/06 - Applications des appareils ou dispositifs de mesure à la construction des voies pour mesurer les irrégularités dans le sens longitudinal

Abrégé

Method for carrying out work on a track system (9) using a rail vehicle (1) which comprises a track motor car (2) having at least one electrically operable treatment device (4, 5) and having an energy supply device (15) for providing electrical energy, and which comprises a trailer car (3) coupled to the track motor car (2) and having an energy storage device (16) for providing electrical energy, wherein the rail vehicle (1) is driven to a track location for treatment, wherein the trailer car (3) is decoupled from the track motor car (2), and wherein the track location for treatment is treated using the track motor car (2). The invention is characterized in that before and/or after the treatment using the track motor car (2), the track location is treated using the trailer car (3) by virtue of an electric traction drive (14) of the trailer car (3) and a treatment device (6-8) of the trailer car (3) being supplied with electrical energy from the energy storage device (16). In this way, the trailer car (3) is used autonomously for track treatment.

Classes IPC  ?

• E01B 27/00 - Mise en place, renouvellement, travail, nettoyage ou enlèvement du ballast avec ou sans travail concomitant sur la voieDispositifs ad hocRemblayage des traverses
• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses
• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface
• E01B 31/13 - Enlèvement du métal des rails, joints de rails, ou plaques d'appui, p. ex. pour l'ébarbage des soudures, la remise en état des rails usés par fraisage
• E01B 31/17 - Enlèvement du métal des rails, joints de rails, ou plaques d'appui, p. ex. pour l'ébarbage des soudures, la remise en état des rails usés par meulage
• B60L 1/00 - Fourniture de l'énergie électrique à l'équipement auxiliaire des véhicules à traction électrique
• B60L 50/50 - Propulsion électrique par source d'énergie intérieure au véhicule utilisant de la puissance de propulsion fournie par des batteries ou des piles à combustible
• B60L 50/53 - Propulsion électrique par source d'énergie intérieure au véhicule utilisant de la puissance de propulsion fournie par des batteries ou des piles à combustible en combinaison avec une alimentation externe, p. ex. par des lignes aériennes de contact
• B60L 50/60 - Propulsion électrique par source d'énergie intérieure au véhicule utilisant de la puissance de propulsion fournie par des batteries ou des piles à combustible utilisant de l'énergie fournie par des batteries
• B60L 50/64 - Détails de construction des batteries spécialement adaptées aux véhicules électriques

Abrégé

A method for operating a tamping machine (1) on a track (4), comprising a tamping assembly (9), a lifting/levelling assembly (8), a measuring system (11) with a measuring transducer (14) and a control/regulating device (15), the lifting/levelling assembly (8) being activated by the control/regulating device (15) depending on a track position, which is detected by means of the measuring system (11), in such a manner that a processed track portion is lifted to a desired level during a lifting period. A selection is made here between at least two regulators (19, 21) set up in the control/regulating device (15) in such a way that the first regulator (19) is activated for standard operation in a first lifting mode and that the second regulator (21) is activated for points in a second lifting mode. The respective regulator (19, 21) is optimized for the associated control section. Furthermore, the invention also relates to a tamping machine for carrying out the method.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie

Abrégé

A system for working on a track with a track maintenance machine has a machine controller and a work unit controlled thereby, with sensors being arranged to monitor the work unit. In this context, the sensors are coupled to a data acquisition module for the separate recording of sensor data, with the data acquisition module being connected to a computing unit in which a first algorithm for calculating result data from the sensor data is set up. In this way, the system contains additional structural components for processing sensor signals. With the data acquisition module and the computing unit, different evaluations of the working mode can be performed independently of an existing monitoring function.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface
• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies

Abrégé

The invention relates to a machine (1) comprising a ballast receiving apparatus (4) for receiving ballast (3) located below a track (2) by means of a continuous excavating chain (6) extending in a chain channel (5), wherein the chain channel (5) is composed of a transverse channel (13) that is positionable below the track (2), an empty channel (11), and a transport channel (16) provided for transporting ballast. A conveying device (26) for transporting ballast (3) towards the transport channel (16) is situated along an upper edge (25) of the transverse channel (13). By means of this additional device (26), the movement of the ballast (3) is increased such that the entirety of the ballast reaches the transport channel (16).

Classes IPC  ?

• E01B 27/10 - Renouvellement ou nettoyage du ballast sur place, avec ou sans travail concomitant sur la voie sans dépose de la voie
• E01B 27/06 - Renouvellement ou nettoyage du ballast sur place, avec ou sans travail concomitant sur la voie
• E01B 27/04 - Enlèvement du ballastMachines à cet effet, que leur aptitude à enlever le ballast soit ou non accessoire

Abrégé

The invention relates to a control and operating system for working on a track with a track maintenance machine, with at least one machine frame movable on rail-based running gears, comprising working devices , a sensor and measuring system for recording the position data of the working devices and for detecting objects of the track, in particular sleepers, rails, and, as the case may be, obstacles, and further comprising an arrangement of cameras for optical detection of the working devices and the working areas. It is provided that a control station without free visual range of a respective working device is set up at a location inside or outside the track maintenance machine and that the control station comprises a display device for virtual operation, control, and/or monitoring of the track maintenance machine. This achieves greater flexibility during working operation, an extension of the controlling and operating options, and a significant increase in safety and ergonomic design at the workstation.

Classes IPC  ?

• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies
• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• G06V 20/54 - Trafic, p. ex. de voitures sur la route, de trains ou de bateaux
• G06V 10/24 - Alignement, centrage, détection de l’orientation ou correction de l’image
• G06V 20/20 - ScènesÉléments spécifiques à la scène dans les scènes de réalité augmentée
• H04N 7/18 - Systèmes de télévision en circuit fermé [CCTV], c.-à-d. systèmes dans lesquels le signal vidéo n'est pas diffusé

Abrégé

PPP) in the test arrangement, and determining the longitudinal forces in the at least one track rail (2) based on the at least one force measurement value, wherein during detection of the at least one force measurement value at least one sleeper (8) is fastened to the rail portion (6).

Classes IPC  ?

• G01M 5/00 - Examen de l'élasticité des structures ou ouvrages, p. ex. fléchissement de ponts ou d'ailes d'avions
• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies

Abrégé

The invention relates to a tamping assembly (1) for tamping sleepers (7) of a track, comprising a tamping unit (4) having oppositely located tamping tools (9) which are pivotally mounted on a vertically adjustable tool carrier (5), wherein each tamping tool (9) is coupled to a vibration drive (21) via a transmission element (17). Here, the relevant transmission element (17) is connected via a first joint (16) to the associated tamping tool (9) and via a second joint (18) to a squeeze drive (19) which is supported on the same tamping tool (9). This construction allows for a space-saving arrangement of the squeeze drives (19), which results in a compact design.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

The invention relates to a device (3) for positioning track processing tools (2) on a track, the device comprising: at least two support modules (29, 30), each having at least one tool support (31a, 31b) for supporting the at least one track processing tool (2), and a horizontal positioning apparatus (32) to which the at least one tool support (31a, 31b) is attached, for moving the at least one tool support (31a, 31b) in a horizontal direction (33a); a rotating apparatus (24) for rotating the at least two support modules (29, 30), wherein the rotating apparatus (24) has at least two rotating units (25, 26) for rotating the at least two support modules (29, 30) independently of one another; and a first transverse positioning apparatus (16) for linearly moving the at least two support modules (29, 30) in a horizontal direction (33a, 33b, 33c) and at an angle of at least 45° to the longitudinal direction (9) of the track (4).

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses
• E01B 29/28 - Fixation ou enlèvement des moyens d'attache démontables ou des accessoires pour ceux-ciAssemblage préalable d'éléments de la voie par des moyens d'attache démontables les moyens d'attache étant du type à vis et écrouAppareils à cet usage conçus pour percer en outre des trous
• E01B 31/17 - Enlèvement du métal des rails, joints de rails, ou plaques d'appui, p. ex. pour l'ébarbage des soudures, la remise en état des rails usés par meulage
• E01B 31/18 - Remise en état ou réparation sur place de parties usagées ou endommagées, p. ex. application de pièces intercalées, reconstruction des rails par soudageChauffage ou refroidissement sur place des parties, p. ex. pour réduire les intervalles des joints, pour durcir les rails

Abrégé

The invention relates to a work vehicle (2) for carrying out works on a track (39), comprising a vehicle frame (1) which, supported on rail-mounted running gear (11), is movable on the track (39), a driver's compartment (21) which is connected to the vehicle frame (1), and various superstructures with associated functions for works. The superstructures are designed as self-supporting functional modules (12-22) with predefined interfaces (23) and are connected to the vehicle frame (1) and/or to one another by means of screw connections. The predefined interfaces (23) permit, without further adaptations, the interconnection of various functional modules (11-22). All of the modules (11-22) are checked consistently with regard to their geometry and their functions in order to allow them to be joined together in the final assembly without welding and adjustment procedures.

Classes IPC  ?

• B61D 15/00 - Autres véhicules ferroviaires, p. ex. véhicules à échafaudageAdaptation des véhicules pour leur utilisation sur voies ferrées
• B61D 17/04 - Parties constitutives structurales du corps des véhicules avec caisses métalliquesParties constitutives structurales du corps des véhicules avec caisses à structure composite, p. ex. en métal et bois
• B61F 1/14 - Fixation ou support du corps du véhicule

Abrégé

The invention relates to a track maintenance machine with a conveyor or excavating chain arrangement for removing and collecting railway ballast and/or other formation or substructure layers of a track structure, comprising a cutter bar which can be positioned below a track and which has at least two bar elements, each adjustable in position and alignment, and which is attached on the one hand to an ascent channel and on the other hand to a return channel, furthermore comprising a guided excavating chain consisting of a plurality of chain links, wherein the arrangement can be fastened to a machine frame by means of at least one height-adjustable suspension device. It is provided that the excavating chain is designed to be divisible, that the bar elements can be connected via a coupling to form a closed overall unit, and that the arrangement can be variably adjusted in its excavating working width by adjusting the position of the bar elements. This provides a significant improvement in handling when setting up, installing, and positioning the machine device.

Classes IPC  ?

• E01B 27/04 - Enlèvement du ballastMachines à cet effet, que leur aptitude à enlever le ballast soit ou non accessoire
• E01B 27/02 - Mise en place du ballastBallastageÉgalisation du matériau du ballastMachines ou dispositifs à cet effetMoyens de nivellement

Abrégé

The invention relates to a work vehicle (2) for carrying out works on a track (39), comprising a vehicle frame (1) which, supported on rail-mounted running gear (11), is movable on the track (39), a driver's compartment (21) which is connected to the vehicle frame (1), and various superstructures with associated functions for works. The superstructures are designed as self-supporting functional modules (12-22) with predefined interfaces (23) and are connected to the vehicle frame (1) and/or to one another by means of screw connections. The predefined interfaces (23) permit, without further adaptations, the interconnection of various functional modules (11-22). All of the modules (11-22) are checked consistently with regard to their geometry and their functions in order to allow them to be joined together in the final assembly without welding and adjustment procedures.

Classes IPC  ?

• B61D 15/00 - Autres véhicules ferroviaires, p. ex. véhicules à échafaudageAdaptation des véhicules pour leur utilisation sur voies ferrées
• B61D 17/04 - Parties constitutives structurales du corps des véhicules avec caisses métalliquesParties constitutives structurales du corps des véhicules avec caisses à structure composite, p. ex. en métal et bois
• B61F 1/14 - Fixation ou support du corps du véhicule

Abrégé

The invention relates to a tamping assembly (4) for tamping a track (3), comprising tamping tools (12) which are arranged in pairs and can be fed towards one another by means of a relevant feed cylinder (16), wherein: a feed piston (17) to which a hydraulic pressure from a first hydraulic circuit (23) can be applied is located in the relevant feed cylinder (16); and a vibration piston (30) is associated with each feed cylinder (16) in order to superimpose a vibration on a feed movement (24); and the vibration piston (30) is located in a pressure amplifier (27) having a primary cylinder (28) and a secondary cylinder (29). In this way, the vibration generation can be carried out at a lower pressure level.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses
• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie

Abrégé

A sweeping device works on a track formed of rails and sleepers. The sweeping device has a brush shaft formed from a plurality of shaft portions configured as hollow shafts, and resilient sweeping elements protruding radially from the brush shaft. The sweeping device can be attached via at least one adjustable vertical drive to a vehicle that can travel on rails. It is provided that at least one axis of rotation of a shaft portion is adjustable via a control shaft with control elements acting externally on the shaft portion.

Classes IPC  ?

• E01H 1/04 - Appareils de brossage enlevant les balayures, p. ex. pour les ramasser, pour les charger
• E01B 27/02 - Mise en place du ballastBallastageÉgalisation du matériau du ballastMachines ou dispositifs à cet effetMoyens de nivellement
• A47L 11/24 - Machines à balayer le plancher, actionnées par moteur
• E01H 1/08 - Emploi de l'air comprimé pour détacher ou enlever les matières indésirablesSéchage par la chaleur uniquement, ou par des courants de gazNettoyage par projection de particules abrasives

Abrégé

The invention relates to a method for operating a track-laying machine (1) on a track section with an overhead line network (6), wherein the supply of power to the track-laying machine (1) by means of a current collector (5) from an overhead line (10) is selectively interrupted when crossing a neutral section (14) of the overhead line network (6). The number of existing contact points (20) between the current collector (5) and the overhead line (10), and in particular the position of each of said contact points, is continuously detected by means of a measuring arrangement (18). Owing to the continuous detection of the contact points, each crossover point is automatically detected.

Classes IPC  ?

• B60L 3/12 - Enregistrement des paramètres de fonctionnement
• B60L 5/19 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement utilisant des collecteurs en forme d'arc en contact avec le câble du trolley aménagés pour réaliser un mouvement du collecteur dans le sens perpendiculaire à la direction de déplacement du véhicule
• B60L 5/26 - Demi-pantographes, p. ex. utilisant des balanciers d'équilibrage
• B60L 5/28 - Dispositifs pour lever et remettre en place le collecteur
• B60L 5/36 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement avec des moyens de collecter le courant simultanément sur plus d'un conducteur, p. ex. sur plus d'une phase
• B60L 5/42 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement pour collecter le courant à partir de plots individuels reliés à la ligne d'alimentation
• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies
• G01D 5/34 - Moyens mécaniques pour le transfert de la grandeur de sortie d'un organe sensibleMoyens pour convertir la grandeur de sortie d'un organe sensible en une autre variable, lorsque la forme ou la nature de l'organe sensible n'imposent pas un moyen de conversion déterminéTransducteurs non spécialement adaptés à une variable particulière utilisant des moyens optiques, c.-à-d. utilisant de la lumière infrarouge, visible ou ultraviolette avec atténuation ou obturation complète ou partielle des rayons lumineux les rayons lumineux étant détectés par des cellules photo-électriques
• G01D 5/353 - Moyens mécaniques pour le transfert de la grandeur de sortie d'un organe sensibleMoyens pour convertir la grandeur de sortie d'un organe sensible en une autre variable, lorsque la forme ou la nature de l'organe sensible n'imposent pas un moyen de conversion déterminéTransducteurs non spécialement adaptés à une variable particulière utilisant des moyens optiques, c.-à-d. utilisant de la lumière infrarouge, visible ou ultraviolette avec atténuation ou obturation complète ou partielle des rayons lumineux les rayons lumineux étant détectés par des cellules photo-électriques en modifiant les caractéristiques de transmission d'une fibre optique
• G01L 1/24 - Mesure des forces ou des contraintes, en général en mesurant les variations des propriétés optiques du matériau quand il est soumis à une contrainte, p. ex. par l'analyse des contraintes par photo-élasticité
• G01L 5/00 - Appareils ou procédés pour la mesure des forces, du travail, de la puissance mécanique ou du couple, spécialement adaptés à des fins spécifiques
• B60L 50/10 - Propulsion électrique par source d'énergie intérieure au véhicule utilisant la puissance de propulsion fournie par des générateurs entraînés par le moteur, p. ex. des générateurs entraînés par des moteurs à combustion
• B60L 50/50 - Propulsion électrique par source d'énergie intérieure au véhicule utilisant de la puissance de propulsion fournie par des batteries ou des piles à combustible
• B61C 3/00 - Locomotives ou automotrices électriques
• B61C 3/02 - Locomotives ou automotrices électriques avec accumulateurs d'électricité
• B61C 9/36 - Systèmes de transmission des locomotives ou des automotrices pour moteurs rotatifs, p. ex. turbines électriques

Abrégé

The invention relates to a method for the safe operation of a rail transport system (1), comprising the steps of: incorporating a first rail transport information (31) correlating with a state variable of the rail transport system (1), transmitting a second rail transport information (32, 42), which correlates with the state variable of the rail transport system (1), between a first rail vehicle (3) and an infrastructure device (2) and/or a second rail vehicle (4), determining a comparative result based on the first rail transport information (31) and the second rail transport information (32, 42), checking the plausibility of the first rail transport information (31) and/or the second rail transport information (32, 42) based on the comparative result, and controlling the rail transport system (1) based on the result of the plausibility check.

Classes IPC  ?

• B61L 3/00 - Dispositifs le long de la voie commandant des dispositifs sur le véhicule ou sur le train, p. ex. pour relâcher les freins ou pour manœuvrer un signal avertisseur
• B61L 23/34 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour indiquer la distance entre les véhicules ou les trains par la transmission de signaux entre ceux-ci
• B61L 27/16 - Optimisation côté voie du fonctionnement d'un véhicule ou d'un train
• B61L 27/20 - Commande côté voie de la sécurité du déplacement d'un véhicule ou d'un train , p. ex. calcul des courbes de freinage
• B61L 15/00 - Indicateurs de signalisation sur le véhicule ou sur le train
• B61L 25/02 - Indication ou enregistrement de la position ou de l'identité de véhicules ou de trains
• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie

Abrégé

Method for correcting vertical position faults of a track (4) after a lifting-tamping process, comprising a stabilization process which is carried out by means of a dynamic track stabilizer (1) and during which a stabilization assembly (22) acts on the track (4) at an working point (22) which moves forwards in a working direction (7), wherein, before the lifting-tamping process, track position data relating to the unworked track (4) is recorded and wherein, after the lifting-tamping process, track position data relating to the underfilled track (4) are recorded at a measurement point (10) which is located upstream of the stabilization assembly (22) in the working direction (7). In the process, additional track position data relating to the stabilized track (4) are recorded at a post-measurement point (21) which is located downstream of the stabilization assembly (22) in the working direction (7), wherein the dynamic track stabilizer (1) is actuated during the stabilization process depending on track position data relating to the unworked and the underfilled track (4) at the working point (22) and on track position data relating to the stabilized track (4) at the post-measurement point (21). The additional post-measurement of the track position after the stabilization process allows exact control of the dynamic track stabilizer (1).

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies
• E01B 29/04 - Relèvement ou nivellement des voies
• E01B 35/08 - Applications des appareils ou dispositifs de mesure à la construction des voies pour mesurer les irrégularités dans le sens longitudinal pour le nivellement

Abrégé

The invention relates to a machine for stabilising a track with a ballast bed, comprising a machine frame supported on rail-based running gears and a stabilising unit which can be rolled on rails of the track by means of work unit rollers, and which comprises a vibration exciter for generating a dynamic impact force as well as a loading device for generating a load acting on the track. Therein, the loading device is coupled with a control device for periodically changing the load during a stabilising process. The periodic change of the load alternately influences the near and far range of the load application. This leads to improved compaction effectiveness compared to a constant load.

Classes IPC  ?

• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface
• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

The invention relates to an assembly (11) for optically capturing a track (2), comprising a support device (12), a camera (13) and two light sources (14). Said assembly (11) can be fastened to a carrier vehicle (1), which can be moved on rails (3). The orientation of the two light sources (14) and thus central axes of the emitted light radiation or waves forms an acute angle (β1, β2) with a rail longitudinal axis (15). The light sources (14) are coupled to the camera (13) by means of control signal cables (16), and the light sources (14) are triggered or activated by means of a specified control signal via the control signal cables (16). Thus, detail-rich, sharp image contours are achieved, which allow highly precise image evaluation and object recognition together with maximum working speed.

Classes IPC  ?

• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• B61K 9/08 - Installations de mesure pour surveiller la voie

Abrégé

The invention relates to a system for detecting the surface of a track portion, comprising: a rail vehicle (1); a surface scanner (9); and an evaluation device (10); wherein a receiving device (11) for temporarily fastening and connecting the surface scanner (9) is situated on the rail vehicle (1); wherein a connection device (13), coupled to the receiving device (11), for the evaluation device (10) is situated in an operator cabin (6) of the rail vehicle (1); and wherein the evaluation device (10) is arranged in a portable housing (12) having power and data ports (16, 17) for temporary connection to the connection device (13). The rail vehicle (1) is thus prepared for immediate deployment of the system, and the surface scanner (9) and the evaluation device (10) do not have to be permanently carried along.

Classes IPC  ?

• B61L 15/00 - Indicateurs de signalisation sur le véhicule ou sur le train
• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• B61K 9/08 - Installations de mesure pour surveiller la voie
• B61L 25/02 - Indication ou enregistrement de la position ou de l'identité de véhicules ou de trains

Abrégé

The invention relates to a method for determining a position of a rail vehicle (1), which is moving along a track (3), by means of a measuring system (6) that comprises a stereo camera system (5) and an evaluation device (16), wherein an image pair is recorded from a reference marker (7) in lateral surroundings of the track (3) by means of the stereo camera system (5) and wherein the position of the rail vehicle (1) in relation to the reference marker (7) is determined by means of photogrammetry. Lateral surroundings of the rail vehicle (1) are illuminated with polarised light by means of at least one light source (21) of the measuring system, wherein the polarised light is reflected by a retroreflector (15) located on the reference marker (7), and wherein the polarised light reflected by the retroreflector (15) is received by a polarisation filter (22) by means of the stereo camera system (5). In this way, sunlight and the light from other artificial light sources are blocked out.

Classes IPC  ?

• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• B61L 25/02 - Indication ou enregistrement de la position ou de l'identité de véhicules ou de trains
• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies

Abrégé

11) or a predetermined supply path (s) is reached, a current value (28) of the supply speed (v) is compared with a limit value (29), and wherein a notification signal (31) indicates whether the current value (28) is over the limit value (29). This optionally indicates that a cavity (24) located under the sleeper (6) has not yet been adequately filled.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

A welding unit for welding rails of a track includes a first sub-unit which is displaceable on unit guides in a rail longitudinal direction relative to a second sub-unit by using displacement cylinders. Each sub-unit includes clamping cylinders disposed underneath the unit guides and coupled to clamping jaws for clamping the rails. The two sub-units are connected by the displacement cylinders in that a cylinder body of the respective displacement cylinder is connected to one sub-unit and a piston rod of the respective displacement cylinder is connected to the other sub-unit. Thus, it is not necessary to support the displacement cylinders relative to a transverse beam disposed at the front.

Classes IPC  ?

• B23K 37/00 - Dispositifs ou procédés auxiliaires non spécialement adaptés à un procédé couvert par un seul des autres groupes principaux de la présente sous-classe
• B23K 37/02 - Chariots pour supporter l'outillage pour souder ou découper
• E01B 11/46 - Méthodes générales pour la réalisation de voies continues
• E01B 29/46 - Dispositifs pour maintenir, mettre en position ou presser l'une contre l'autre les extrémités de rails
• B23K 101/26 - Rails pour chemins de fer ou similaires

Abrégé

The invention relates to a machine for stabilising a track, having a machine frame supported on rail-based running gears and at least one height-adjustable stabilising unit which can be rolled on rails of the track by means of work unit rollers, comprising a vibration exciter with rotating unbalanced masses for generating an impact force acting dynamically in a track plane normal to a longitudinal direction of the track as well as a linear drive for generating a load acting on the track. It is provided that a main unbalanced mass and a secondary unbalanced mass produce different centrifugal forces at the same rotational speed depending on the direction of rotation, the two unbalanced masses being coupled in such a way that, during rotation in one direction of rotation, the unbalanced masses have a first phase shift in relation to one another and that, during rotation in the opposite direction of rotation, the unbalanced masses have a second phase shift relative to one another which differs from the first phase shift. Depending on the arrangement of the unbalanced masses, a changed phase shift changes both the direction and the strength of the impact force.

Classes IPC  ?

• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface
• B06B 1/16 - Procédés ou appareils pour produire des vibrations mécaniques de fréquence infrasonore, sonore ou ultrasonore utilisant l'énergie mécanique fonctionnant avec des systèmes impliquant des masses rotatives non équilibrées
• B06B 1/18 - Procédés ou appareils pour produire des vibrations mécaniques de fréquence infrasonore, sonore ou ultrasonore dans lesquels le vibrateur est déclenché par pression de fluide

Abrégé

The invention relates to a device (11) for compressing track formation layers and/or other substructure layers or supporting layers (7, 8, 9) of a track (4), which device can be mounted on a movable track construction machine (1) and which comprises a compression unit (12), wherein the latter is assigned a vibrating plate (13), at least one unbalance exciter (14) and an associated drive unit (15), wherein the device (11) comprises a supporting frame (16), and the compression unit (12) can be positioned variably in the working region of the track (4) by the compression unit (12) being coupled to the supporting frame (16) via an adjustment actuator (17). Provision is made here for the device (11) to comprise at least two acceleration sensors (8), a position-measuring unit (19) of the unbalance exciter (14), and a force-measuring unit (20). The efficiency and the compressing quality of the track construction machine are therefore increased.

Classes IPC  ?

• E01B 27/06 - Renouvellement ou nettoyage du ballast sur place, avec ou sans travail concomitant sur la voie
• E01B 27/10 - Renouvellement ou nettoyage du ballast sur place, avec ou sans travail concomitant sur la voie sans dépose de la voie

Abrégé

A method for cleaning a ballast bed (4) of a track (2) by means of track-bound machines (8, 18, 21), wherein, by means of a cleaning machine (8), a ballast (1) situated under a track grid (5) is removed with a ballast removal apparatus (10), wherein, behind it, with respect to a working direction (12), cleaned and/or new ballast (1) is introduced into the track (2) in a plurality of layers by means of a ballast introduction apparatus (11) and a ballast train (15) and wherein the introduced ballast (1) is compacted by means of a tamping machine (18) and a stabilizing machine (21), wherein all the layers of the new and/or cleaned ballast (1) are introduced before a first tamping operation by means of the ballast introduction apparatus (11) and the ballast train (15), wherein the ballast bed (4) is compacted by means of a deep tamping unit (22) in different depth layers during the first tamping operation, wherein subsequently the track (2) is stabilized by means of the stabilizing machine, wherein directly thereafter the track grid (5) is tamped by means of the same or a further tamping machine (18) in a second tamping operation in only one depth layer, and wherein, after the second tamping operation, the track (2) is stabilized with the same or a further stabilizing machine (21).

Classes IPC  ?

• E01B 27/10 - Renouvellement ou nettoyage du ballast sur place, avec ou sans travail concomitant sur la voie sans dépose de la voie
• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie

Abrégé

The invention relates to a track-bound maintenance machine (1) for maintaining a permanent way comprising a track grid (7) which is mounted in a ballast bed (6) and consists of sleepers (8) and rails (9) fastened thereon, comprising a lifting and levelling unit (4) for track lifting/levelling and a tamping unit (5) for track tamping. At least one rail machining unit (11) for continuously reprofiling the rails (9) is arranged on a machine frame (10). The elimination of rail defects contributes to increased stability of the adjusted track position because, after clearing the machined track portion, the rails (9) can be travelled on smoothly. The invention also relates to a method for operating the machine.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• E01B 31/12 - Enlèvement du métal des rails, joints de rails, ou plaques d'appui, p. ex. pour l'ébarbage des soudures, la remise en état des rails usés
• E01B 31/13 - Enlèvement du métal des rails, joints de rails, ou plaques d'appui, p. ex. pour l'ébarbage des soudures, la remise en état des rails usés par fraisage
• E01B 31/15 - Enlèvement du métal des rails, joints de rails, ou plaques d'appui, p. ex. pour l'ébarbage des soudures, la remise en état des rails usés par rabotage ou limage
• E01B 31/17 - Enlèvement du métal des rails, joints de rails, ou plaques d'appui, p. ex. pour l'ébarbage des soudures, la remise en état des rails usés par meulage

Abrégé

A method for controlling/regulating a rotatory drive of a working unit of a track maintenance machine includes using a sensor to record a measurement parameter with an approximately periodic history function derived from a rotation of the drive. A frequency or period duration of the history function is determined with an evaluation device, and the frequency or period duration is compared with a target parameter for stipulating a control signal. A number of time-discrete measurement values is formed for the measurement parameter and an auto-correlation of these measurement values is carried out by a calculation unit for determining the frequency or the period duration. As compared to a conventional method with zero stage recording, a precise recording of frequency changes is therefore also possible between two zero stages. A device for carrying out the method is also provided.

Classes IPC  ?

• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies
• G05B 19/042 - Commande à programme autre que la commande numérique, c.-à-d. dans des automatismes à séquence ou dans des automates à logique utilisant des processeurs numériques
• G01H 3/06 - Fréquence par des moyens électriques

Produits et services

Rail track construction machines having electric drives, rail track tamping machines having electric drives, rail track stabilisers having electric drives, rail track ballast regulating machines having electric drives, rail track ballast cleaning machines having electric drives, rail welding machines having electric drives, machines for installing overhead contact lines having electric drives. Rail track relaying trains having electric drives, rail track inspection vehicles having electric drives, vehicles for transporting bulk material having electric drives.

Abrégé

The invention relates to a measurement system for measuring the elasticity of an overhead line (5) of a track (4), having a contactless sensor (8) for sensing the position of a measurement point (13) of the overhead line (5) and having an evaluation device (11) for calculating the elasticity. There is arranged a mechanical excitation device (7) by means of which the overhead line (5) can be made to vibrate by active excitation, wherein the sensor (8) is configured to capture a vibration profile, and wherein the evaluation device (11) is configured to derive mechanical properties of the overhead line (5) from the vibration profile. The mechanical properties, such as the elasticity, of the overhead line (5) are derived in the evaluation device (11) from the characteristics of the corresponding vibration curves (12).

Classes IPC  ?

• B60M 1/28 - Fabrication ou réparation des lignes de trolley
• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• B61K 9/08 - Installations de mesure pour surveiller la voie

Abrégé

The invention concerns a track maintenance machine for tamping a track having sleepers supported in a ballast bed with rails fitted to the same, with a machine frame that is mobile on on-track undercarriages and with a tamping unit which comprises tamping tools to be lowered into the ballast bed and set to vibrate and to be squeezed towards one another, wherein a camera for transmitting real-time images to an output means is arranged upstream of the tamping unit in a working direction. A first camera system is arranged upstream of the tamping unit in working direction here for recording a first surface area of the track as a first image section. In addition, a second camera system is arranged downstream of the tamping unit in working direction for recording a second surface area of the track as a second image section, wherein the recorded image sections partly overlap and wherein the output means is equipped for issuing the image sections in a merged image.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie

Abrégé

The invention relates to a method for operating a rail traffic system, having the steps of: automatically detecting information which provides conclusions regarding the quality of the rail traffic system, providing a first checksum (27a) of a first data block (26), determining a second data block (27) using the first checksum (27a) and the detected information, and calculating a second checksum (30) on the basis of the second data block (27).

Classes IPC  ?

• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• B61L 15/00 - Indicateurs de signalisation sur le véhicule ou sur le train
• B61K 9/08 - Installations de mesure pour surveiller la voie
• H04L 9/00 - Dispositions pour les communications secrètes ou protégéesProtocoles réseaux de sécurité
• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

A track maintenance machine for stabilizing a ballast bed of a track after a tamping operation, includes a machine frame mobile on on-track undercarriages and a stabilizing unit which has rollers for gripping a track grid and a vibration generator for actuating the track grid with a vibration. A clearing device is disposed at both longitudinal sides of the track maintenance machine in front of the stabilizing unit with regard to a working direction. Each respective clearing device includes a clearing tool which can be lowered into the ballast bed to remove ballast from a respective sleeper-end region. Thus, preconditions are created by using the stabilizing unit to achieve an increased lowering of the track grid as compared to a normal stabilizing procedure. A method for operating a track maintenance machine is also provided.

Classes IPC  ?

• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface
• E01B 29/04 - Relèvement ou nivellement des voies

Abrégé

The invention relates to a method for ascertaining correction values (26) for correcting the position of a track (5). The actual geometry (10) of a track section is detected by an inertial measuring device (8) arranged on a measuring vehicle (1) while traversing the track (5), and measurement data (18) of the detected track section is output to an analysis device (19) by the inertial measuring device (5). In the process, a virtual inertial measurement of the same track section with a target geometry (16) is calculated by means of a simulation device (24) in order to obtain simulated measurement data (25) for the target geometry (16), wherein correction values (26) for correcting the position of the track (5) are ascertained by means of a computing unit (23) in that the simulated measurement data (25) is subtracted from the measurement data (18) of the inertial measuring device (8). By using the method according to the invention, correction values (26) are ascertained directly on the basis of the measurement data (18) of the inertial measuring device (8).

Classes IPC  ?

• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• B61K 9/08 - Installations de mesure pour surveiller la voie
• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies

Abrégé

A method for measuring an infrastructure component (1), in particular a track structure component, comprises the steps of: providing a mobile measuring system (2) having a stereo camera (11), arranging the measuring system (2) on the infrastructure component (1), capturing at least one pair of images from the infrastructure component (1) by means of the stereo camera (11), determining a relative position of at least one measurement point (37, 38, 39, 40, 41) coupled to the infrastructure component (1) on the basis of the at least one pair of images, and determining a deformation of the infrastructure component (1) on the basis of the at least one relative position and/or detecting a measurement position of the measuring system (2) in a global coordinate system (30).

Classes IPC  ?

• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• E01B 35/00 - Applications des appareils ou dispositifs de mesure à la construction des voies
• G01B 11/00 - Dispositions pour la mesure caractérisées par l'utilisation de techniques optiques
• G01M 5/00 - Examen de l'élasticité des structures ou ouvrages, p. ex. fléchissement de ponts ou d'ailes d'avions

Abrégé

The invention relates to a tamping tine for a tamping machine for tamping a track, including a tine shaft which has at its upper end a retaining portion for fastening in a tine mount and which merges at its lower end into a tine plate. In this, a sensitive element of a sensor is arranged in a recess of the tine shaft, and the tamping tine includes a coupling element for transmission of a sensor signal. In this manner, the tamping tine fulfils a sensor function for recording measuring values occurring in the tamping tine.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses
• E01B 27/12 - Remblayage des traverses avec ou sans travail concomitant sur la voieBourrage du ballast portant la voie

Abrégé

The invention relates to a method for ascertaining a vibration transmission in the region of a track (4), wherein the track (4) is subjected to vibrations during a working process by way of a working unit (12, 13) of a track construction machine (1) traveling on the track (4), wherein vibrations (19, 28) transmitted through the track (4) are measured by way of a sensor (20) at a distance from the working unit (12, 13) and wherein measured data from the sensor (20) are evaluated in an evaluation device (25). In this case, a position of the sensor (20) in relation to the working unit (12, 13) is predefined to the evaluation device (25), wherein a correlation between a vibration effect of the working unit (12, 13) as acquired by the sensor (20) and a distance (r) between the working unit (12, 13) and the sensor (20) is ascertained in the evaluation device (25). The method according to the invention has the advantage that the vibration effect of the working unit is able to be acquired at the location of the sensor in real time.

Classes IPC  ?

• B61L 15/00 - Indicateurs de signalisation sur le véhicule ou sur le train
• E01B 27/02 - Mise en place du ballastBallastageÉgalisation du matériau du ballastMachines ou dispositifs à cet effetMoyens de nivellement
• G01H 1/00 - Mesure des vibrations dans des solides en utilisant la conduction directe au détecteur
• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface

Abrégé

An interface device for supplying a plurality of users with electrical power from a railway converter of a track maintenance machine includes a connection device for electrically linking to a DC voltage circuit of the railway converter and a distribution device, electrically connected to the connection device, for connecting the plurality users. A track maintenance system and a track maintenance machine are also provided.

Classes IPC  ?

• B60L 9/24 - Propulsion électrique par source d'énergie extérieure au véhicule utilisant des moteurs à courant alternatif à induction alimentés par des lignes à courant alternatif
• B60L 1/00 - Fourniture de l'énergie électrique à l'équipement auxiliaire des véhicules à traction électrique
• B60L 3/00 - Dispositifs électriques de sécurité sur véhicules propulsés électriquementContrôle des paramètres de fonctionnement, p. ex. de la vitesse, de la décélération ou de la consommation d’énergie
• H02M 1/32 - Moyens pour protéger les convertisseurs autrement que par mise hors circuit automatique

Produits et services

Track maintenance machines; Railroad constructing machines; Track inspection machines; Track movable machines for inspecting tunnels; Track movable machines for inspecting bridges; Track movable machines for snow removal; Track movable trains for snow removal.

Produits et services

Track maintenance machines; Railroad constructing machines. Rail vehicles for the transport or storage of waste material or railway materials.

Produits et services

Track maintenance machines; Railroad constructing machines; Trolley line construction machines; Trolley line maintenance machines; Overhead line construction and maintenance machines; Track movable tower trolleys; Track movable stage trolleys; Track movable machines for inspection, security inspection, troubleshooting, maintenance of tracks and maintenance and construction of trolley lines; Track movable machines for measuring tracks and trolley lines; Track inspection vehicles.

Produits et services

Rail track construction machines having electric drives, rail track tamping machines having electric drives, rail track stabilisers being machines and having electric drives, rail track ballast regulating machines having electric drives, rail track ballast cleaning machines having electric drives, rail welding machines having electric drives, machines for installing overhead contact lines having electric drives Rail track relaying trains having electric drives, rail track inspection trains having electric drives, rail track trains for transporting bulk material having electric drives

Abrégé

The invention relates to a track laying machine (1) for tamping sleepers (15) incorporated into a ballast bed of a track (4), comprising a machine frame (2) which can be moved on rail bogies (3), rail lifting and lining units (10) for track position correction, and two single-sleeper tamping assemblies (8, 9) which are independent of one another and are arranged one behind the other in the direction of the machine longitudinal axis (39), wherein each tamping assembly (8, 9) has at least four independent tamping units (16), the height of which is adjustable via vertical drives (22) and which can be horizontally displaced in the machine transverse direction (38) via transverse drives, wherein each tamping unit (16) comprises at least one tool carrier (18) on which opposite tamping tools (17) are supported and are coupled by means of a vibration drive (19). According to the invention, one of the two tamping assemblies (8, 9) is designed in the manner of a point tamping assembly such that the associated tamping units (16) can be supported towards the outside in a transversely displaceable manner and positioned by means of a displacing device (23) consisting of three independent transverse guiding devices (25, 26, 27) in relation to the machine longitudinal axis (39) with respect to the machine frame (2) or with respect to a satellite frame (7) which can be moved along the machine longitudinal axis, and that the other tamping assembly is designed in the manner of a plain line tamping assembly such that the associated tamping units (16) can be supported in a transversely displaceable manner and positioned with just a displacing device (24). This increases the performance and thus tamping capability of the machine during plain line and/or point processing.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie

Abrégé

The invention relates to a method for tamping a plurality of ties (4), which are mounted in a ballast bed (2), of a track (3) by means of a plurality of tamping units (9) which are arranged behind one another on a machine frame (8) of a track tamping machine (1) and which have tamping tools (40) situated opposite one another in pairs, wherein only one tie (4) is tamped during a tamping operation by means of the respective tamping unit (9). Here, a control device (33) for controlling longitudinal actuators (32) is used to predetermine a tie pitch (t) of the ties (4) which are to be tamped, wherein, prior to a tamping operation, the tamping units (9) are positioned relative to one another in the machine longitudinal direction (7) by means of the longitudinal actuators (32) in order to adapt the positions of the tamping units (9) to the predetermined tie pitch (t), and wherein, during the tamping operation, ties (4) which are not situated directly behind one another are tamped. By virtue of the spacing of the tamping units (9) from one another in the machine longitudinal direction (7) by in each case more than one tie pitch (t), there are sufficient clearances present for adapting to different tie pitches (t).

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Produits et services

(1) Rail track construction machines having electric drives, rail track tamping machines having electric drives, rail track stabilisers having electric drives, rail track ballast regulating machines having electric drives, rail track ballast cleaning machines having electric drives, rail welding machines having electric drives, rail track machines for installing overhead contact lines having electric drives. (2) Rail track relaying trains having electric drives, rail track inspection vehicles having electric drives, bulk carrier vehicles having electric drives.

Abrégé

The invention relates to a method for determining a target geometry (S) of a track (5) for correcting the position of the track (5), in which method an actual geometry (I) of the track (5) is first detected along a track section (26) by means of a measuring system (8), and the target geometry (S) is subsequently calculated on the basis of the actual geometry (I) by means of a computing unit (36). In the process, actual position points (15) of the track (5) are detected along the track section (26) by means of a position detection system (13), at least one actual position point (15) being specified to the computing unit (36) as a pass-through point (24) and the target geometry (S) being calculated by means of the computing unit (36) in such a way that the target geometry (S) is aligned with the actual geometry (I) as a sequence of geometric line routing elements (31, 32, 33) and is laid through the specified pass-through point (24). A significant improvement in quality in comparison with known compensation methods including pre-measurement is obtained as a result.

Classes IPC  ?

• B61K 9/08 - Installations de mesure pour surveiller la voie
• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• B61L 25/02 - Indication ou enregistrement de la position ou de l'identité de véhicules ou de trains

Abrégé

The invention relates to a method for determining a target geometry (S) of a track (5) for correcting the position of the track (5), in which method an actual geometry (I) of the track (5) is first detected along a track section (26) by means of a measuring system (8), and the target geometry (S) is subsequently calculated on the basis of the actual geometry (I) by means of a computing unit (36). In the process, actual position points (15) of the track (5) are detected along the track section (26) by means of a position detection system (13), at least one actual position point (15) being specified to the computing unit (36) as a pass-through point (24) and the target geometry (S) being calculated by means of the computing unit (36) in such a way that the target geometry (S) is aligned with the actual geometry (I) as a sequence of geometric line routing elements (31, 32, 33) and is laid through the specified pass-through point (24). A significant improvement in quality in comparison with known compensation methods including pre-measurement is obtained as a result.

Classes IPC  ?

• B61L 23/04 - Dispositifs de commande, d'avertissement ou autres dispositifs de sécurité le long de la voie ou entre les véhicules ou les trains pour contrôler l'état mécanique de la voie
• B61L 25/02 - Indication ou enregistrement de la position ou de l'identité de véhicules ou de trains
• B61K 9/08 - Installations de mesure pour surveiller la voie

Abrégé

The invention relates to a track maintenance machine having a tamping unit for tamping sleepers of a track lying in a ballast bed, including a tool carrier which is mounted for vertical adjustment on an assembly frame and on which tamping tools are arranged so as to be squeezable towards one another, wherein the tool carrier is coupled to a vertical adjustment drive actuated by means of a control device. In this, a control circuit is set up for controlling a lowering motion of the tool carrier, the control circuit including a controller, a setting device for the vertical adjustment drive and a measuring device for recording the lowering motion. With this, it is possible to provide an optimal course for the lowering motion.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses
• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• E01B 27/02 - Mise en place du ballastBallastageÉgalisation du matériau du ballastMachines ou dispositifs à cet effetMoyens de nivellement

Abrégé

The invention relates to a tamping assembly for tamping sleepers of a track, including a tamping unit having oppositely positioned tamping tools mounted on a vertically adjustable tool carrier, the tamping tools being coupled in each case via a squeezing drive to a vibration drive, wherein each tamping tool comprises a pivot lever rotatable about a pivot axis and at least one tamping tool mount for accommodating at least one tamping tine. In this, a first squeezing drive is coupled directly to the vibration drive and articulatedly connected to a first pivot lever, and a second squeezing drive is coupled to the vibration drive via a separate coupling unit and articulatedly connected to a link, mounted on the tool carrier, as well as to a second pivot lever. In this manner, the tamping unit can be configured in a very compact way with squeezing drives being arranged one below the other, wherein forces and momentums occurring during operation can be easily controlled.

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

The invention relates to a method for treatment of a ballast track by means of track maintenance machine which comprises a lifting unit, having gripping rollers for gripping a track grid formed of rails and sleepers and lifting drives for lifting the track grid, and a measuring system for comparing to a target position of the track, wherein the lifting unit is set in vibration by means of a vibration exciter and the vibration is transmitted to the track grid, wherein the lifting unit is controlled by means of a control device in such a way that, during a lifting operation, the lifting unit is set in vibration, and the track grid is first lifted to above the target position and subsequently lowered to the target position. By means of the method according to the invention it is possible to carry out in a simple manner a lifting of the track grid with simultaneous stabilization of the track position.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• E01B 27/02 - Mise en place du ballastBallastageÉgalisation du matériau du ballastMachines ou dispositifs à cet effetMoyens de nivellement
• E01B 29/04 - Relèvement ou nivellement des voies

Abrégé

The invention relates to a machine (1) for compacting a ballast bed (9) of a track (4) comprising a machine frame (2) supported on rail bogies (3) and a stabilising assembly (10) connected to same in a height-adjustable manner and having a vibration drive (16) and an axle (17) with flanged rollers (18) that can move on rails (6) of the track (4), wherein the distance between same running perpendicular to the longitudinal direction of the machine can be changed by means of an expansion drive (19), as well as having a roller clamp (21) that can be positioned against the rails (6) by clamping drives (23), wherein the expansion drive (19) and/or the clamping drives (23) are designed to apply the rails (6) with a predefined variable horizontal loading force (Fg), wherein a measuring device (200) is arranged for detecting a rail head deflection (?SL/R) and/or change in track width (s1,S2,?S1,?S2) caused by the variable loading force (FB). In this way, the stabilising assembly (10) can determine whether the track grid (5) is stable.

Classes IPC  ?

• E01B 27/13 - Remblayage des traverses, avec ou sans travail concomitant sur la voie
• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface

Abrégé

SL/R1212BB). In this way, the stabilising assembly (10) can determine whether the track grid (5) is stable.

Classes IPC  ?

• E01B 27/20 - Tassement des matériaux du ballast porteur de la voie, p. ex. en imprimant des vibrations à la voie, au moyen de vibreurs de surface
• E01B 27/13 - Remblayage des traverses, avec ou sans travail concomitant sur la voie

Abrégé

The invention relates to a machine (1) with a tamping assembly (7) for simultaneously tamping down multiple sleepers (4), which are positioned one directly behind the other, of a track (3) using multiple tamping units (14) arranged one behind the other with respect to a machine longitudinal direction (17). Each tamping unit (14) comprises a height-adjustable tool support (15) on which opposing tamping tools (18) are mounted that are coupled to a vibration drive (19) arranged on the tool support (15) via add-on cylinders (20). Each vibration drive (19) comprises an eccentric shaft (25) with a first eccentric disc (27) and a second eccentric disc (28), the axes of symmetry (29, 30) of which together with a common rotational axis (25) define two eccentric planes (31, 32) that form a relative angle (d) relative to each other, wherein a first add-on cylinder (20) is mounted on the first eccentric disc (27), an opposing second add-on cylinder (20) is mounted on the second eccentric disc (30), and the cylinder axes (33) of the opposing add-on cylinders (20) form a positional angle (ß) which approximates the relative angle (d) of the eccentric planes (31, 32).

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

The invention relates to a method and a machine comprising a tamping assembly for tamping sleepers (4), mounted on a ballast bed (2), of a track (3) by means of a tamping assembly (7) which is intended for simultaneously tamping a plurality of sleepers positioned directly one behind the other and comprises a plurality of tamping units (14) that are arranged directly one behind the other in a working direction (26), are height-adjustable independently of one another, and are each intended for tamping a particular sleeper (4), wherein: in a tamping cycle, firstly a first group of tamping units (14) that are not arranged directly one behind the other is lowered into the ballast bed (2), fed laterally and raised again; a second group of tamping units (14) that are not arranged directly one behind the other is preferably lowered into the ballast bed, fed laterally and raised again; and, before the start of the next tamping cycle, the tamping assembly (7) is moved further in the working direction (26). This prevents two tamping tools (18) from operating simultaneously on the same ballast grains in close proximity.

Classes IPC  ?

• E01B 27/17 - Machines à cet usage, p. ex. machines dites à bourrer les traverses combinées avec des moyens pour relever, niveler ou faire riper la voie
• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses

Abrégé

The invention relates to a machine (1) with a tamping assembly (7) for simultaneously tamping down multiple sleepers (4), which are positioned one directly behind the other, of a track (3) using multiple tamping units (14) arranged one behind the other with respect to a machine longitudinal direction (17). Each tamping unit (14) comprises a height-adjustable tool support (15) on which opposing tamping tools (18) are mounted that are coupled to a vibration drive (19) arranged on the tool support (15) via add-on cylinders (20). Each vibration drive (19) comprises an eccentric shaft (25) with a first eccentric disc (27) and a second eccentric disc (28), the axes of symmetry (29, 30) of which together with a common rotational axis (25) define two eccentric planes (31, 32) that form a relative angle (δ) relative to each other, wherein a first add-on cylinder (20) is mounted on the first eccentric disc (27), an opposing second add-on cylinder (20) is mounted on the second eccentric disc (30), and the cylinder axes (33) of the opposing add-on cylinders (20) form a positional angle (β) which approximates the relative angle (δ) of the eccentric planes (31, 32).

Classes IPC  ?

• E01B 27/16 - Machines à cet usage, p. ex. machines dites à bourrer les traverses
