1.

MEASUREMENT DEVICE FOR CURRENT COLLECTORS, AND METHOD FOR OPERATING THE MEASUREMENT DEVICE, AND A CALIBRATION APPARATUS


Numéro d'application 18687139
Statut En instance
Date de dépôt 2022-08-22
Date de la première publication 2025-04-10
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Inventeur(s)
  • Torabzad, Saman
  • Nolte, Florian

Abrégé

A measuring device may be used to measure a position of at least one current collector arranged in an articulated manner on a current collector trolley of a current collector unit relative to the current collector trolley. The measuring device may include at least one sensor unit having at least one sensor and may be arranged on the current collector trolley. A permanent magnet may be arranged on at least one of the current collectors The at least one sensor may be a Hall sensor whose sensor signal may be used in determining a position of at least one of the current collectors, which may be fitted with permanent magnets.

Classes IPC  ?

  • G01D 5/14 - Moyens mécaniques pour le transfert de la grandeur de sortie d'un organe sensibleMoyens pour convertir la grandeur de sortie d'un organe sensible en une autre variable, lorsque la forme ou la nature de l'organe sensible n'imposent pas un moyen de conversion déterminéTransducteurs non spécialement adaptés à une variable particulière utilisant des moyens électriques ou magnétiques influençant la valeur d'un courant ou d'une tension
  • G01D 18/00 - Test ou étalonnage des appareils ou des dispositions prévus dans les groupes

2.

MEASURING DEVICE FOR CURRENT COLLECTORS AND METHOD FOR OPERATING THE MEASURING DEVICE AS WELL AS A CALIBRATION DEVICE


Numéro de document 03230294
Statut En instance
Date de dépôt 2022-08-22
Date de disponibilité au public 2023-03-02
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Torabzad, Saman
  • Nolte, Florian

Abrégé

Measurement device for measuring a position (P) of at least one current collector (2, 2a, 2b, 2c, 2d, 2a', 2b', 2c', 2d'), which is arranged in an articulated manner on a current collector trolley of a current collector unit (1), relative to the current collector trolley, having at least one sensor unit (SU) which is arranged on the current collector trolley and has at least one sensor (Sa, Sb, Sc, Sd), characterized in that a permanent magnet (M, Ma, Mb, Mc, Md) is arranged on at least one current collector (2, 2a, 2b, 2c, 2d, 2a', 2b', 2c', 2d'), and in that the at least one sensor (Sa, Sb, Sc, Sd) is a Hall sensor (Sa, Sb, Sc, Sd), wherein the measurement device determines the position (P) of each current collector (2, 2a, 2b, 2c, 2d, 2a', 2b', 2c', 2d') fitted with permanent magnets (M, Ma, Mb, Mc, Md) from at least one sensor signal (x, y, z) from the at least one Hall sensor (Sa, Sb, Sc, Sd).

Classes IPC  ?

  • B60L 5/00 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement
  • G01D 5/14 - Moyens mécaniques pour le transfert de la grandeur de sortie d'un organe sensibleMoyens pour convertir la grandeur de sortie d'un organe sensible en une autre variable, lorsque la forme ou la nature de l'organe sensible n'imposent pas un moyen de conversion déterminéTransducteurs non spécialement adaptés à une variable particulière utilisant des moyens électriques ou magnétiques influençant la valeur d'un courant ou d'une tension
  • G01D 18/00 - Test ou étalonnage des appareils ou des dispositions prévus dans les groupes
  • H01R 41/00 - Collecteurs de courant non rotatifs pour maintenir un contact entre les parties fixe et mobile d'un circuit électrique

3.

MEASUREMENT DEVICE FOR CURRENT COLLECTORS, AND METHOD FOR OPERATING THE MEASUREMENT DEVICE, AND A CALIBRATION APPARATUS


Numéro d'application EP2022073304
Numéro de publication 2023/025714
Statut Délivré - en vigueur
Date de dépôt 2022-08-22
Date de publication 2023-03-02
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Torabzad, Saman
  • Nolte, Florian

Abrégé

Measurement device for measuring a position (P) of at least one current collector (2, 2a, 2b, 2c, 2d, 2a', 2b', 2c', 2d'), which is arranged in an articulated manner on a current collector trolley of a current collector unit (1), relative to the current collector trolley, having at least one sensor unit (SU) which is arranged on the current collector trolley and has at least one sensor (Sa, Sb, Sc, Sd), characterized in that a permanent magnet (M, Ma, Mb, Mc, Md) is arranged on at least one current collector (2, 2a, 2b, 2c, 2d, 2a', 2b', 2c', 2d'), and in that the at least one sensor (Sa, Sb, Sc, Sd) is a Hall sensor (Sa, Sb, Sc, Sd), wherein the measurement device determines the position (P) of each current collector (2, 2a, 2b, 2c, 2d, 2a', 2b', 2c', 2d') fitted with permanent magnets (M, Ma, Mb, Mc, Md) from at least one sensor signal (x, y, z) from the at least one Hall sensor (Sa, Sb, Sc, Sd).

Classes IPC  ?

  • G01D 5/14 - Moyens mécaniques pour le transfert de la grandeur de sortie d'un organe sensibleMoyens pour convertir la grandeur de sortie d'un organe sensible en une autre variable, lorsque la forme ou la nature de l'organe sensible n'imposent pas un moyen de conversion déterminéTransducteurs non spécialement adaptés à une variable particulière utilisant des moyens électriques ou magnétiques influençant la valeur d'un courant ou d'une tension
  • B60L 5/00 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement
  • G01D 18/00 - Test ou étalonnage des appareils ou des dispositions prévus dans les groupes
  • H01R 41/00 - Collecteurs de courant non rotatifs pour maintenir un contact entre les parties fixe et mobile d'un circuit électrique

4.

Vahle Smart Collector


Numéro d'application 018750616
Statut Enregistrée
Date de dépôt 2022-08-22
Date d'enregistrement 2023-01-19
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ?
  • 09 - Appareils et instruments scientifiques et électriques
  • 42 - Services scientifiques, technologiques et industriels, recherche et conception

Produits et services

Measuring, signalling, detecting, testing, inspecting apparatus and instruments; Apparatus for conducting, switching, transforming, accumulating or regulating electricity, Apparatus for controlling the distribution or use of electricity; Apparatus and instruments for recording, transmitting, reproducing or processing sound, images or data; Computer software, recorded; Computer programs [downloadable software], Computers; Computer peripheral devices. Scientific and technological services and research and design relating thereto; Industrial analysis; Industrial research; Industrial design; Quality control and authentication services; Design and development of computer hardware and software.

5.

Miscellaneous Design


Numéro de série 79336223
Statut Enregistrée
Date de dépôt 2022-01-13
Date d'enregistrement 2024-03-12
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Metal building materials, namely, soffits, fascia, siding, studs, roofing; materials of metal for railway tracks; metal rails, metal rail connectors, metal rail mounts, metal sliding stops and points for railways, metal pulleys and non-electric cables, metal spring hoists, metal spring-retracted hose reels and drum motors being used for winding up pipes and hoses, prefabricated metal work cabins, metal ladders Lifts, namely passenger lifts or goods lifts, automated feeding systems for use in automobile manufacturing, namely feeding systems for single parts or bulk material, step conveyors, disc conveyors, linear units, telescope arms, dosing units, pallet conveyors, disc conveyors; cranes, lifts and conveyors for lifting cars, containers, pallets, building material, semi-finished goods, for warehouses, in the nature of electric, pneumatic, telescopic, chain driven cranes, lifts and conveyors, and structural parts therefor; conveyer belts; cranes except boat cranes; electric door openers, electric; jib cranes, namely, swivel jibs, folding jibs, console jibs and swivel rocker arms for machines for processing metal, wood and plastic Electric apparatus and instruments for electrical engineering, namely for conducting, transforming, transmitting, accumulating, regulating or controlling, in particular electric conduits and cables, electric contact lines, electric plugs, electrical slip ring elements, electric conduit screw fittings, electric clamping boxes, electric end terminals and distributors, electric current collectors for contact lines, electric control panels; temperature control units for keeping the temperature of machines and their parts in a special range, plastic cable tracks being sleeves for electric cables; electric apparatus and instruments for weak-current engineering for conducting, transforming, transmitting, accumulating, regulating and controlling the distribution or use of electric current; items for the conveying of electricity and electrical energy, in particular plastic conduit for electric use and electric cables, electric contact lines, electric plugs, electrical connectors being slip rings, electric conduit screw fittings, electric clamp meter boxes, electric end terminal boxes and distribution units, electric current collectors for contact lines, electric control panels; contactless electricity, data transmission systems and energy transmission systems comprised of antennae, frequency converters, resonant coil systems for movable devices, electrical transmission cables and accessories thereof, namely frequency converters, electric condensers; accessories for non-contact power and energy transmission systems or data transmission systems, namely frequency converters, electrical storage batteries and capacitors; inductive and electromagnetic non-contact vehicle and apparatus guide systems, comprised of antennae, frequency converters, resonant coil systems for movable devices, electrical transmission cables and accessories thereof, namely frequency converters, electric condensers

6.

POWER TRANSMISSION SYSTEM HAVING A DRIVER DEVICE FOR A CURRENT COLLECTOR CARRIAGE


Numéro d'application EP2020050371
Numéro de publication 2020/148141
Statut Délivré - en vigueur
Date de dépôt 2020-01-09
Date de publication 2020-07-23
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Mehrwald, Uwe

Abrégé

The invention relates to a power transmission system for a vehicle that can be moved along a power rail assembly or a track (T), the vehicle in particular being in the form of a crane, the power transmission system comprising at least one current collector carriage (W) and current collector contacts (SK) arranged thereon, which are connected to power rails (S) of the power rail assembly, a coupling device being provided for detachably connecting the vehicle to the current collector carriage (W), which current collector carriage can be moved along and is guided along the power rail assembly (S), characterized in that the coupling device is formed by or comprises a ball head coupling (1, 2).

Classes IPC  ?

  • B66C 13/12 - Aménagements des moyens pour transmettre une puissance pneumatique, hydraulique ou électrique à des parties ou dispositifs mobiles
  • B66C 19/00 - Ponts roulants ou portiques fixes ou mobiles, portant un chariot ou un treuil mobile
  • B60L 5/36 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement avec des moyens de collecter le courant simultanément sur plus d'un conducteur, p. ex. sur plus d'une phase

7.

THERMAL MONITORING OF CURRENT RAIL INSTALLATIONS


Numéro d'application EP2019085415
Numéro de publication 2020/127093
Statut Délivré - en vigueur
Date de dépôt 2019-12-16
Date de publication 2020-06-25
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Nolte, Florian
  • Torabzad, Saman
  • Garmabad, Mahyar

Abrégé

ii1a2a122) is arranged on the carriage or on the current collector (WS).

Classes IPC  ?

  • G01K 1/14 - SupportsDispositifs de fixationDispositions pour le montage de thermomètres en des endroits particuliers
  • G01J 5/00 - Pyrométrie des radiations, p. ex. thermométrie infrarouge ou optique
  • G01J 5/04 - Boîtiers

8.

OPTICAL CONTACTLESS PARAMETRIC CONDITION MONITORING OF CURRENT COLLECTORS AND CONDUCTOR LINE SYSTEMS


Numéro d'application EP2019086794
Numéro de publication 2020/128042
Statut Délivré - en vigueur
Date de dépôt 2019-12-20
Date de publication 2020-06-25
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Tembaak, Philip
  • Nolte, Florian
  • Jour, Rüdiger

Abrégé

The invention relates to a system for monitoring and identifying the wear of at least one sliding contact of a current collector and deflections of the sliding contact, comprising at least one bus bar arranged along a route or line and at least one current collector for the bus bar with at least one sliding contact arranged thereon, and a holder for fastening the at least one current collector, in particular to a carriage movable along the bus bar. At least one marking is arranged on at least one current collector, and at least one sensor is arranged on the bus bar, the current collector or the holder, the sensor detecting the position of the marking in at least one dimension relative to the sensor.

Classes IPC  ?

  • B60L 5/38 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement pour collecter le courant sur un rail conducteur

9.

PROFILED BODY WHICH FORMS A SUPPORTING PROFILE AND/OR A HOLLOW WAVEGUIDE AND HAS AT LEAST ONE CONTACT CONDUCTOR PROFILE


Numéro d'application EP2018084660
Numéro de publication 2019/121275
Statut Délivré - en vigueur
Date de dépôt 2018-12-13
Date de publication 2019-06-27
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Turki, Faical
  • Heitmann, Michael
  • Rabe, Stefan

Abrégé

The invention relates to a profiled body (1) which forms a supporting profile (T) for a contact conductor (SL), a supporting profile (T) with guiding faces in the longitudinal direction (R), in particular for an overhead track or a current collector carriage, or a hollow waveguide (H) and is manufactured from a first material, characterised in that the profiled body (1) has on at least one wall (2) at least one contact conductor profile (S) which is produced from a material different from the first material.

Classes IPC  ?

  • B60M 1/34 - Rails conducteurs disposés dans des conduits à fente
  • H01P 3/12 - Guides d'ondes creux

10.

FEED MODULE FOR AN INDUCTIVE M-PHASE ENERGY TRANSMISSION PATH


Numéro d'application EP2018062329
Numéro de publication 2018/215224
Statut Délivré - en vigueur
Date de dépôt 2018-05-14
Date de publication 2018-11-29
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to a feed module for an inductive m-phase energy transmission path (EL), with m Є N and N = {1, 2, 3, ….}, wherein the feed module has at least one source for each phase and the feed module has a transformer system (TS) which has primary winding systems (PRI) corresponding to the number of sources (Q), and the transformer system (TS) has at least two output windings (S1) on the secondary side for each phase of the energy transmission path (EL).

Classes IPC  ?

  • H02J 50/12 - Circuits ou systèmes pour l'alimentation ou la distribution sans fil d'énergie électrique utilisant un couplage inductif du type couplage à résonance
  • H01F 38/14 - Couplages inductifs
  • H01F 38/16 - Transformateurs en cascade, p. ex. pour utilisation sous très haute tension
  • H04B 5/00 - Systèmes de transmission en champ proche, p. ex. systèmes à transmission capacitive ou inductive

11.

INDUCTIVE ENERGY TRANSMISSION SYSTEM


Numéro d'application EP2018063491
Numéro de publication 2018/215531
Statut Délivré - en vigueur
Date de dépôt 2018-05-23
Date de publication 2018-11-29
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to a stationary part of an inductive energy transmission system, having an m-phase energy transmission section (EL) with m ∈ N und N = {1, 2, 3,....), and a feed module, wherein the energy transmission section (EL) has a start (ELA) and an end (ELE) and the at least one conductor (L1, L2, LU, LV, LW per phase (Pm) extends from the start (ELA) as far as the end (ELE), and each conductor (L1, L2, LU, LV, LW has two connection ends (A, E), characterized in that the start (ELA) and the end (ELE) of the energy transmission section (EL) each form an energy feed point.

Classes IPC  ?

  • H02J 50/10 - Circuits ou systèmes pour l'alimentation ou la distribution sans fil d'énergie électrique utilisant un couplage inductif
  • H01F 38/14 - Couplages inductifs
  • H02J 50/12 - Circuits ou systèmes pour l'alimentation ou la distribution sans fil d'énergie électrique utilisant un couplage inductif du type couplage à résonance

12.

CONTAINER TERMINAL, IN PARTICULAR IN THE FORM OF A HARBOUR INSTALLATION, WITH AT LEAST ONE RAIL-BOUND CONTAINER CRANE


Numéro d'application EP2018057450
Numéro de publication 2018/184868
Statut Délivré - en vigueur
Date de dépôt 2018-03-23
Date de publication 2018-10-11
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Husarek, Mirco
  • Müller, Thomas
  • Henkel, Jürgen

Abrégé

The invention relates to a container terminal, in particular in the form of a harbour installation, comprising at least one rail-bound container crane (1), the container terminal comprises a medium voltage network (6, 7) which is connected to at least one transformation unit (5), and the transformation unit (5) converts the medium voltage (MU) of the medium voltage network (6, 7) into a low voltage (NU). The invention is characterised in that the low voltage (NU) is guided to a rail-bound crane (1) by means of at least one bus bar (2) and to which power is supplied.

Classes IPC  ?

  • B60L 5/04 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement utilisant des rouleaux ou des sabots curseurs en contact avec le câble du trolley
  • B60L 5/38 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement pour collecter le courant sur un rail conducteur
  • B60M 1/30 - Rails conducteurs
  • B66C 13/12 - Aménagements des moyens pour transmettre une puissance pneumatique, hydraulique ou électrique à des parties ou dispositifs mobiles
  • B65G 63/00 - Transfert ou transbordement aux zones de stockage, aux gares de marchandises ou aux portsInstallations de gares de triage
  • B66C 13/28 - Circuits pour commander l'affalement de la charge par moteurs à courant alternatif utilisant le freinage par récupération pour régler la descente des charges lourdes et comportant des moyens pour empêcher le moteur de tourner dans le sens "à monter" quand on a libéré la charge

13.

SUPPLYING COOLING CONTAINERS WITHOUT CABLES


Numéro d'application EP2018057442
Numéro de publication 2018/184867
Statut Délivré - en vigueur
Date de dépôt 2018-03-23
Date de publication 2018-10-11
Propriétaire PAUL VAHLE GMBH & CO.KG (Allemagne)
Inventeur(s)
  • Turki, Faical
  • Müller, Thomas
  • Henkel, Jürgen
  • Lorenz, Uwe
  • Raabe, Michael

Abrégé

The invention relates to a positioning and supply device for containers (1) in harbor facilities or on a ship or truck. The invention is characterized in that a container stand surface is paired with four respective corner elements (2a-2d), each of which has at least one guide surface (2s, 2t) that is used to guide a respective lower corner (1e) of a container (1). The four corner elements (2a, 2d) are secured to the base (F) of the harbor system, truck, or ship in a mutually spaced manner, and at least one supply device (3c, 101, 101´) is arranged on or in the base (F) or a frame (5) arranged on the base (F) relative to the four corner elements (2a-2d).

Classes IPC  ?

  • H02J 50/00 - Circuits ou systèmes pour l'alimentation ou la distribution sans fil d'énergie électrique
  • B66C 13/14 - Aménagements des moyens pour transmettre une puissance pneumatique, hydraulique ou électrique à des parties ou dispositifs mobiles à des éléments de prise de la charge ou aux moteurs qui en font partie
  • B65D 90/00 - Parties constitutives, détails ou accessoires des grands réceptacles

14.

ELECTRIFICATION OF TRANSPORT SYSTEMS IN A CONTAINER TERMINAL


Numéro d'application EP2018057453
Numéro de publication 2018/184870
Statut Délivré - en vigueur
Date de dépôt 2018-03-23
Date de publication 2018-10-11
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Henkel, Jürgen
  • Raabe, Michael
  • Husarek, Mirco
  • Petker, Dimitri
  • Müller, Thomas

Abrégé

The invention relates to a container terminal, in particular in the form of a container port comprising at least two container portal cranes (1, 12), the container terminal being connected to a high-voltage network (11) via an electrical sub-station (10). At least one energy store (1c, 5c) is provided, allowing electrical energy to be stored. The terminal is characterised in that there is a system for controlling the handling operations (E) of the container portal cranes (1, 12), which system controls the handling operations of at least some or all of the container portal cranes (1, 12) on the basis of the tasks to be accomplished in the container terminal.

Classes IPC  ?

  • B60L 11/18 - utilisant de l'énergie fournie par des piles primaires, des piles secondaires ou des piles à combustibles
  • B60L 5/00 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement
  • H02J 3/00 - Circuits pour réseaux principaux ou de distribution, à courant alternatif
  • B65G 63/00 - Transfert ou transbordement aux zones de stockage, aux gares de marchandises ou aux portsInstallations de gares de triage

15.

POSITIONING SYSTEM FOR A CONTAINER CRANE


Numéro d'application EP2018057456
Numéro de publication 2018/184871
Statut Délivré - en vigueur
Date de dépôt 2018-03-23
Date de publication 2018-10-11
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Müller, Thomas
  • Husarek, Mirco
  • Hülsmann, Michael
  • Fröhlich, Florian

Abrégé

The invention relates to a positioning system for a container crane (1), which can travel along a route (T) on rails (4) or wheels, wherein the container crane (C) reaches over an alley (Gi=1-4) in which containers (1) can be stacked one behind the other and adjacent to each other on container footprints (Ac) in rows (Rj=1-8) and columns (SPj=1-9), wherein a position detection system (PE) is arranged along the route (T) for the positioning system, by means of which the container crane (1) can determine the position thereof along the route (T) or the alley (Gi=1-4), wherein a position encoder (PGk=1-8) is provided in addition to the position detection system (PE) for detection of the individual rows (Rj=1-8).

Classes IPC  ?

  • B66C 13/46 - Indicateurs de position pour charges suspendues ou pour éléments de grues
  • B66C 13/48 - Commande automatique de l'entraînement des grues pour produire un cycle de travail unique ou répétéCommande par programmation
  • B66C 19/00 - Ponts roulants ou portiques fixes ou mobiles, portant un chariot ou un treuil mobile
  • B65G 63/00 - Transfert ou transbordement aux zones de stockage, aux gares de marchandises ou aux portsInstallations de gares de triage

16.

CONTACT PLATE FOR CHARGING AND CONTROL


Numéro d'application EP2017061473
Numéro de publication 2018/001615
Statut Délivré - en vigueur
Date de dépôt 2017-05-12
Date de publication 2018-01-04
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Tembaak, Philip
  • Jour, Rüdiger

Abrégé

The invention relates to a contact plate (K) which can be arranged in a stationary manner and has at least one electrical contact (E) for a current collector contact (S) which is arranged on a current collector, wherein the current collector is fastened to a mobile apparatus, in particular a vehicle, wherein the contact plate (K) has a top side and a bottom side (KU, Ko), and also narrow sides (Ks), and the at least one electrical contact (E) on the top side (Ko) of the contact plate (K) forms a contact area for the current collector contact (S), characterized in that the contact plate (K) has, on at least one of its narrow sides (Ks), at least one connecting element (V) for connection to a further contact plate (K) or a system element, in particular a ramp element (R).

Classes IPC  ?

  • B60L 11/18 - utilisant de l'énergie fournie par des piles primaires, des piles secondaires ou des piles à combustibles

17.

TRIMOTION


Numéro d'application 1368687
Statut Enregistrée
Date de dépôt 2017-03-30
Date d'enregistrement 2017-03-30
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
  • 17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler

Produits et services

Common metals and their alloys; metal building materials; metal transportable buildings; materials of metal for railway tracks, namely tracks, track connector, track holders, end stops for tracks and track switches for railways; non-electric cables and wires (metal hardware); spring balancers, spring and reel systems for cables and hoses, metal hardware and ironware; metal hardware, included in this class; metal steps. Couplings and power transmission mechanisms, not for land vehicles; lifting gears, cranes (not boat cranes); energy chains for electric cables, chains for pneumatic and liquid pipes [parts of machines]; telescopic arms for and with current collector trolley, in particular for container cranes. Apparatus and instruments for conducting, converting, transmitting, storage, regulating and controlling of electricity; electronic apparatus and instruments for communications engineering, high frequency technology and control technology; supply for electricity and electrical energy, in particular telescopic arms for and with current collector trolleys, electrical cables and wires, conductor lines, electric plugs, slip ring, electric glands, terminal boxes, end clamps and distributors, current collectors for conductor lines, control stations; apparatus for recording, transmission and reproduction of sound and images; calculating machines, hardware for data processing, computer; computer software. Vehicles; apparatus for locomotion by land, air or water; railbound cable trolleys, equipment trolleys, transport suspension railway, rolls and buffers for cable trolleys and equipment trolleys. Rubber buffers and pulp buffers, hose of plastics, plastic sheets for work booths; non-metallic connectors, rubber, gutta-percha, asbestos, mica and goods thereof, namely, rollers of rubber, gaskets and damping device of rubber; goods of plastic (semi- finished products); seals-, packaging- and isolation material; flexible tubes, not of metal; joint connectors and glands for pipes, not of metal.

18.

TRIMOTION


Numéro de série 79217996
Statut Enregistrée
Date de dépôt 2017-03-30
Date d'enregistrement 2019-04-09
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
  • 17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler

Produits et services

Common metals and their alloys, unwrought or semi-wrought; metal building materials, namely, soffits; metal transportable buildings; materials of metal for railway tracks, namely, tracks, track connector, track holders, end stops for tracks and track switches for railways; metal hardware, namely, non-electric cables and wires; metal hardware, namely, spring balancers, springs and hand operated reels for cables and hoses; metal hardware, namely, pulleys; metal steps, namely, ladders and stools Machine couplings and power transmission mechanisms, not for land vehicles; lifting gears for cranes; cranes, not for boat cranes; electric cable cranes; chains for pneumatic pipes and liquid pipes being parts of machines; container cranes featuring telescopic arms Apparatus and instruments for conducting, converting, transmitting, storing, regulating and controlling of electricity; electronic apparatus and instruments for communications, namely, phase shifters; electronic apparatus and instruments, namely, high frequency mobile and sea-based communication antennas; electronic apparatus and instruments for lighting control; Electronic power supplies for telescopic arms for collector trolleys; electrical cables and wires, conductor lines, electric plugs, electrical slip ring, electric cable connector, electrical terminal boxes; Battery terminal connector end clamps; Resistors for distributing or controlling electric current for conductor lines, electrical control stations for lighting control panels; apparatus for recording, transmission and reproduction of sound and images; calculating machines, data processing equipment and computers; computer software for monitoring and controlling the flow of electricity of container terminals at port Vehicles, namely, land vehicles; apparatus for locomotion by land, air or water, namely, rail cars; rail bound cable trolleys and structural parts therefor; railway car suspension struts and coil springs; buffers for railway rolling stock for cable trolleys and equipment trolleys Shock buffers of rubber and rubber pulp for industrial machinery; hose of plastics for industrial machinery; Sheets of plastic fabric used as an insulating infiltration barrier in building construction; non-metallic pipe connectors, namely, connectors of rubber, gutta-percha, asbestos, mica; Rubber gaskets for industrial machinery; Shock absorbing rubber buffers for industrial machinery; plastic as semi-finished products in the form of foils, plates, rods, profiles, hoses, tubes, and blocks; Sealing and insulating materials; Packing material for forming seals; flexible tubes, not of metal; Non-metal seals for industrial machinery; pipe joint connectors and pipe glands

19.

Positioning area for a route for vertically inserting current collector contacts in the current rails of the route


Numéro d'application 14895415
Numéro de brevet 09994431
Statut Délivré - en vigueur
Date de dépôt 2015-02-05
Date de la première publication 2017-01-26
Date d'octroi 2018-06-12
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Inventeur(s)
  • Raabe, Michael
  • Muller, Thomas
  • Woyczechowski, Steffen

Abrégé

The invention relates to a positioning zone (EB) for a travel path (1), wherein the travel path (1) has at least one guide rail (2, 3) and the guide rail (2, 3) is used to guide a current collector trolley (11), provided with current collector contacts (12), of a current collector system (10) arranged on a vehicle which can move along the travel path (1), and the travel path (1) has at least one travel path conductor bar (5), wherein the current collector trolley (11) can be moved horizontally and vertically to the travel path (1) in the positioning zone (EB) by a positioning device of the current collector system (10), characterized in that at least one further conductor bar (5′) is arranged in the region of the positioning zone (EB) or at least one travel path conductor bar (5) extends and/or is extended into the positioning zone (EB) beyond at least one guide rail (2, 3) of the travel path (1).

Classes IPC  ?

  • B66C 13/12 - Aménagements des moyens pour transmettre une puissance pneumatique, hydraulique ou électrique à des parties ou dispositifs mobiles
  • B60L 5/38 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement pour collecter le courant sur un rail conducteur
  • B60M 1/30 - Rails conducteurs
  • B66C 19/00 - Ponts roulants ou portiques fixes ou mobiles, portant un chariot ou un treuil mobile
  • B60L 5/04 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement utilisant des rouleaux ou des sabots curseurs en contact avec le câble du trolley
  • B60L 5/36 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement avec des moyens de collecter le courant simultanément sur plus d'un conducteur, p. ex. sur plus d'une phase
  • B60L 5/16 - Dispositifs pour lever et remettre en place le collecteur
  • B60L 5/40 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement pour collecter le courant sur des lignes disposées dans des conduits à fente

20.

Current collector system having telescopic arm for cranes, container cranes, ERTGs, and conveying devices


Numéro d'application 14896454
Numéro de brevet 10137785
Statut Délivré - en vigueur
Date de dépôt 2015-02-05
Date de la première publication 2017-01-05
Date d'octroi 2018-11-27
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Inventeur(s)
  • Vahle, Werner
  • Raabe, Michael
  • Muller, Thomas

Abrégé

The invention relates to a current collector system (1) for a vehicle (F) which can be moved in a longitudinal direction along a power rail arrangement (S) having at least one current collector trolley (3) and current collector contacts (5) arranged on this, which current collector contacts can be connected to the power rails (ST) of the power rail arrangement (S) and a telescopic arm (2) which can be fixed or is fixed to a vehicle (F), which telescopic arm can be extended and/or retracted by means of an adjustment drive, characterised in that the adjustment drive has at least one rigid chain arrangement (9) which is driven by at least a first rigid chain drive (8).

Classes IPC  ?

  • B60L 5/16 - Dispositifs pour lever et remettre en place le collecteur
  • B60L 5/38 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement pour collecter le courant sur un rail conducteur
  • B66C 13/12 - Aménagements des moyens pour transmettre une puissance pneumatique, hydraulique ou électrique à des parties ou dispositifs mobiles
  • B66C 19/00 - Ponts roulants ou portiques fixes ou mobiles, portant un chariot ou un treuil mobile
  • F16G 13/20 - Chaînes ayant des caractéristiques générales particulières rigidesChaînes à arc-boutement

21.

WINDING ASSEMBLY FOR AN INDUCTIVE ENERGY TRANSMISSION SYSTEM


Numéro d'application EP2015072553
Numéro de publication 2016/078814
Statut Délivré - en vigueur
Date de dépôt 2015-09-30
Date de publication 2016-05-26
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to a winding assembly (1) for the primary and/or secondary side of an inductive energy transmission system, wherein the winding assembly (1) has two windings (A, B) which are each meander-shaped or have meander-shaped winding regions (A1, B1), characterised in that the windings (A, B) or the winding regions thereof (A1, B1) are arranged such that they are rotated by 90° in relation to one another and overlapping, wherein electrical currents (iA, iB) flow through the two windings (A, B), said electrical currents being electrically phase-shifted by 90° in relation to one another.

Classes IPC  ?

22.

SECURITY LOCK


Numéro d'application EP2015076168
Numéro de publication 2016/075121
Statut Délivré - en vigueur
Date de dépôt 2015-11-10
Date de publication 2016-05-19
Propriétaire
  • PAUL VAHLE GMBH & CO. KG (Allemagne)
  • ABUS AUGUST BREMICKER SÖHNE KG (Allemagne)
Inventeur(s)
  • Turki, Faical
  • Reker, Ulrich
  • Prellwitz, Christian
  • Lind, Thomas

Abrégé

The invention relates to a security lock for a transport means (2) having an electric energy store, in particular an E-bike or motorcycle, the security lock having a lock housing (4, 40) to which a securing means (7), in particular in the form of a security chain, a security loop, a security cable, or a rigid element of a folding lock, is fixed and/or can be fixed detachably, and the lock housing (4, 40) additionally having a securing device (15) for closing or locking the security lock, characterized in that a secondary winding (17, 42) for inductively receiving electrical energy is arranged in the lock housing (4, 40) itself or in a winding housing (50), which is arranged on or can be fixed to the lock housing (4, 40).

Classes IPC  ?

  • B60L 11/00 - Propulsion électrique par source d’énergie intérieure au véhicule (B60L 8/00, B60L 13/00 ont priorité;agencements ou montage de moteurs primaires constitués de moteurs électriques et de moteurs à combustion interne pour une propulsion réciproque ou commune B60K 6/20)
  • B60L 11/18 - utilisant de l'énergie fournie par des piles primaires, des piles secondaires ou des piles à combustibles

23.

Telescopic arm with a push-pull chain drive


Numéro d'application 14895462
Numéro de brevet 10139041
Statut Délivré - en vigueur
Date de dépôt 2015-03-17
Date de la première publication 2016-05-05
Date d'octroi 2018-11-27
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Inventeur(s)
  • Raabe, Michael
  • Vahle, Werner
  • Muller, Thomas
  • Woyczechowski, Steffen
  • Heitmann, Michael
  • Husarek, Micro

Abrégé

b) to the second telescopic stage (4).

Classes IPC  ?

  • B60L 5/38 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement pour collecter le courant sur un rail conducteur
  • F16M 11/20 - Infrastructure avec ou sans roues
  • B66C 13/12 - Aménagements des moyens pour transmettre une puissance pneumatique, hydraulique ou électrique à des parties ou dispositifs mobiles
  • F16G 13/20 - Chaînes ayant des caractéristiques générales particulières rigidesChaînes à arc-boutement
  • F16M 11/42 - Appuis ou tréteaux en tant que supports pour appareils ou objets avec dispositions pour mouvoir le support
  • F16M 13/02 - Autres supports ou appuis pour positionner les appareils ou les objetsMoyens pour maintenir en position les appareils ou objets tenus à la main pour être portés par un autre objet ou lui être fixé, p. ex. à un arbre, une grille, un châssis de fenêtre, une bicyclette
  • F16G 13/16 - Chaînes de traction ou de hissage avec dispositifs pour soutenir des câbles électriques, des tuyaux ou des éléments analogues
  • H02G 11/00 - Installations de câbles ou de lignes électriques entre deux pièces en mouvement relatif

24.

INDUCTIVE ENERGY TRANSMISSION SYSTEM HAVING A WIDE PRIMARY ASSEMBLY


Numéro d'application EP2015072558
Numéro de publication 2016/055326
Statut Délivré - en vigueur
Date de dépôt 2015-09-30
Date de publication 2016-04-14
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to an inductive energy transmission system for transmitting electrical energy from a primary-side coil assembly (1), which in particular is arranged in a stationary manner, to a secondary-side coil assembly (2), which is arranged on a vehicle, the primary-side coil assembly (1) and the secondary-side coil assembly (2) each having at least one winding (1w, 2w) and each having at least one ferrite assembly (1F, 2F), the primary-side ferrite assembly (1F) having a length (Px) longitudinal to the direction of travel (FR) of the roadway and a width (Py) transverse to the direction of travel (FR) of the roadway and the secondary-side ferrite assembly (2F) having a length (Sx) parallel to the vehicle longitudinal axis (FR) and a width (Sy) transverse to the vehicle longitudinal axis (FR), characterized in that the width (Py) of the primary-side ferrite assembly (1F) is at least 1.3 to 3 times the width (Sy) of the secondary-side ferrite assembly (2F), especially preferably 1.5 to 2 times, the length (PX) of the primary-side ferrite assembly (1F) being at most 1.25 times the length (SX) of the secondary-side ferrite assembly (2F).

Classes IPC  ?

  • B60L 11/18 - utilisant de l'énergie fournie par des piles primaires, des piles secondaires ou des piles à combustibles

25.

DETERMINING THE POSITION OF A PICKUP RELATIVE TO THE PRIMARY ARRANGEMENT OF AN INDUCTIVE ENERGY TRANSMISSION SYSTEM


Numéro d'application EP2015059931
Numéro de publication 2016/008608
Statut Délivré - en vigueur
Date de dépôt 2015-05-06
Date de publication 2016-01-21
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to a device for determining the position of a secondary-side arrangement (SE) of an inductive energy transmission system relative to the primary-side arrangement (PR) of the inductive energy transmission system. The secondary-side arrangement (SE) has at least one electric resonant circuit (KA) which can be coupled to at least two primary-side resonant circuits (KB, KC, KD, KE) of the primary-side arrangement (SE) in an electromagnetic manner. The invention is characterized in that a signal can be supplied to the at least one secondary-side electric resonant circuit (KA) by means of a secondary-side supply device (US), and the secondary-side arrangement (SE) has a device (IM) for determining the impedance (Z) and/or the change of the impedance over time of the at least one secondary-side electric resonant circuit (KA). A higher-level positioning device determines the position (P) of the secondary-side arrangement (SE) relative to the primary-side arrangement (PR) using the ascertained impedance (Z), the change of the impedance over time, and/or the impedance curve.

Classes IPC  ?

  • B60L 11/18 - utilisant de l'énergie fournie par des piles primaires, des piles secondaires ou des piles à combustibles
  • G01B 7/14 - Dispositions pour la mesure caractérisées par l'utilisation de techniques électriques ou magnétiques pour mesurer la distance ou la marge entre des objets ou des ouvertures espacés
  • H02J 7/02 - Circuits pour la charge ou la dépolarisation des batteries ou pour alimenter des charges par des batteries pour la charge des batteries par réseaux à courant alternatif au moyen de convertisseurs

26.

INDUCTIVE ENERGY TRANSMISSION SYSTEM WITH A POLYPHASE PRIMARY CIRCUIT


Numéro d'application EP2015063387
Numéro de publication 2016/008663
Statut Délivré - en vigueur
Date de dépôt 2015-06-16
Date de publication 2016-01-21
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to a primary arrangement (1) of an inductive energy transmission system, wherein the primary arrangement has at least two first electrical conductors (La, Lb, Lc) which are each a constituent part of first electrical resonant circuits (Sa, Sb, Sc) and form coil windings which are laid in a meandering manner or in accordance with a square-wave voltage profile in the direction (F) of travel and each have conductor sections (Laq, Lbq, Lcq) which are arranged transverse to the direction (F) of travel, wherein the first electrical conductors (La, Lb, Lc) of the resonant circuits (Sa, Sb, Sc) are identical in respect of their dimensions and the manner in which they are laid, but are arranged displaced in relation to one another by a length (L) in the direction (F) of travel, and wherein the currents (Ia, Ib, Ic) which flow through the resonant circuits (Sa, Sb, Sc) are electrically phase-shifted in relation to one another, in particular through 90° or 120°, characterized in that the primary arrangement has at least one further conductor (Ld, Ld') which is a constituent part of a further resonant circuit (Sd), wherein the further conductor (Ld) has at least one straight feed conductor (LdH, Ld'H) which is laid in the direction (F) of travel and at least one straight return conductor (LdR, Ld'R) which is arranged parallel to said feed conductor, and in that a phase setting device (PI) sets or regulates the phase shift (φ) between the magnetic flux (φd) which is generated by the further conductor loop (Ld) and flows in a secondary arrangement (2) and the total magnetic flux (ϕtot=ϕa+ϕb+ϕc) which is generated by the currents (Ia, Ib, Ic) and likewise flows in the secondary arrangement (2), in particular to 90°.

Classes IPC  ?

  • B60M 7/00 - Lignes ou rails d'alimentation en énergie spécialement adaptés pour véhicules à propulsion électrique d'un type particuliers, p. ex. véhicules suspendus, téléfériques, chemins de fer souterrains

27.

PARALLEL RESONANT CIRCUIT PICK-UP HAVING DECOUPLING WINDING


Numéro d'application EP2015065682
Numéro de publication 2016/008794
Statut Délivré - en vigueur
Date de dépôt 2015-07-09
Date de publication 2016-01-21
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Turki, Faical
  • Meins, Jürgen

Abrégé

The invention relates to a secondary-side device of an inductive energy transfer system, comprising at least one coupling winding (LKopp) and at least one magnetising winding (LMag,i), wherein the at least one coupling winding (LKopp) and the at least one magnetising winding (LMag,i) have a common magnetic core (K, Ki), and the magnetising winding (LMag,i) is a component of a resonant circuit (Si), in particular of a series resonant circuit, wherein, in the case of the secondary-side device, only the coupling winding (LKopp) is or can be electrically connected to a load via a rectifier (G), and wherein the resonant circuit (Si), having the magnetising winding (LMag,i), is or can be connected, or can be connected via a switching means, either to a load or a rectifier (G). The invention also relates to a primary-side device of an inductive energy transfer system, comprising at least one coupling winding and at least one magnetising winding.

Classes IPC  ?

  • H02J 5/00 - Circuits pour le transfert d'énergie électrique entre réseaux à courant alternatif et réseaux à courant continu
  • H01F 38/14 - Couplages inductifs
  • H02J 17/00 - Systèmes pour l'alimentation ou la distribution d'énergie par ondes électromagnétiques

28.

POSITIONING AREA FOR A ROUTE FOR VERTICALLY INSERTING CURRENT COLLECTOR CONTACTS IN THE CURRENT RAILS OF THE ROUTE


Numéro d'application EP2015052422
Numéro de publication 2015/154896
Statut Délivré - en vigueur
Date de dépôt 2015-02-05
Date de publication 2015-10-15
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Raabe, Michael
  • Müller, Thomas
  • Woyczechowski, Steffen

Abrégé

The invention relates to a positioning area (EB) for a route (1), wherein the route (1) has at least one guide rail (2, 3), and the guide rail (2, 3) is used as guidance for a current collector carriage (11) having current collector contacts (12) of a current collector system (10) arranged on a vehicle that can be moved along the route (1). The route (1) has at least one route busbar (5), wherein in the positioning area (EB), the current collector carriage (11) can be adjusted horizontally and vertically to the route (1) by means of a positioning device of the current collector system (10). The invention is characterized in that at least one additional busbar (5’) is arranged in the vicinity of the positioning area (EB), or that at least one route busbar (5) extends and/or is extended beyond at least one guide rail (2, 3) of the route (1) all the way to the positioning area (EB).

Classes IPC  ?

  • F16M 11/20 - Infrastructure avec ou sans roues
  • F16G 13/20 - Chaînes ayant des caractéristiques générales particulières rigidesChaînes à arc-boutement
  • B60L 5/38 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement pour collecter le courant sur un rail conducteur
  • B66C 13/12 - Aménagements des moyens pour transmettre une puissance pneumatique, hydraulique ou électrique à des parties ou dispositifs mobiles
  • B66C 19/00 - Ponts roulants ou portiques fixes ou mobiles, portant un chariot ou un treuil mobile
  • B60M 1/30 - Rails conducteurs

29.

MAGNETIC CIRCUIT FOR DYNAMICALLY CHARGING ELECTRIC VEHICLES


Numéro d'application EP2015056057
Numéro de publication 2015/144619
Statut Délivré - en vigueur
Date de dépôt 2015-03-23
Date de publication 2015-10-01
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to a stationary energy-transmitting device for inductively charging an energy accumulator of a vehicle (1), wherein the energy-transmitting device has a plurality of conductor pairs (6a, 6b) which are arranged one behind the other along the carriageway (F), wherein each conductor pair (6a, 6b) is formed from a first conductor (6a) and a second conductor (6b), the two conductors (6a, 6b) are arranged parallel to one another in the carriageway (F) and each form a conductor loop (6), characterized in that the first conductor (6a) is arranged at a distance (A) above the second conductor (6b) in the carriageway (F).

Classes IPC  ?

  • B60L 5/00 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement
  • B60M 1/36 - Bornes de contact simples le long de la voie pour courant d'alimentation en énergie
  • B60M 7/00 - Lignes ou rails d'alimentation en énergie spécialement adaptés pour véhicules à propulsion électrique d'un type particuliers, p. ex. véhicules suspendus, téléfériques, chemins de fer souterrains
  • H02J 17/00 - Systèmes pour l'alimentation ou la distribution d'énergie par ondes électromagnétiques

30.

CURRENT-COLLECTOR SYSTEM HAVING A TELESCOPIC ARM FOR CRANES, CONTAINER CRANES, ERTGS, AND CONVEYING DEVICES


Numéro d'application EP2015052421
Numéro de publication 2015/139879
Statut Délivré - en vigueur
Date de dépôt 2015-02-05
Date de publication 2015-09-24
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Vahle, Werner
  • Raabe, Michael
  • Müller, Thomas

Abrégé

The invention relates to a current-collector system (1) for a vehicle (F) that can be moved along a power-rail assembly (S), comprising at least one current-collector carriage (3) and current-collector contacts (5) arranged thereon, which current-collector contacts can be connected to power rails (ST) of the power-rail assembly (S), and comprising a telescopic arm (2) that can be or is fastened to the vehicle (F), which telescopic arm can be extended and/or retracted by means of an adjusting drive, characterized in that the adjusting drive has at least one push-pull chain assembly (9), which is driven by at least one first push-pull chain drive (8).

Classes IPC  ?

  • B60L 5/38 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement pour collecter le courant sur un rail conducteur
  • B66C 13/12 - Aménagements des moyens pour transmettre une puissance pneumatique, hydraulique ou électrique à des parties ou dispositifs mobiles
  • B66C 19/00 - Ponts roulants ou portiques fixes ou mobiles, portant un chariot ou un treuil mobile
  • F16G 13/20 - Chaînes ayant des caractéristiques générales particulières rigidesChaînes à arc-boutement

31.

SLOTTED WAVEGUIDE


Numéro d'application EP2015055156
Numéro de publication 2015/140036
Statut Délivré - en vigueur
Date de dépôt 2015-03-12
Date de publication 2015-09-24
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Rabe, Stefan
  • Reising, Viktor

Abrégé

The invention relates to a slotted waveguide (1) having a cavity (2) extending in a longitudinal direction (L) for guiding electromagnetic waves, which slotted waveguide (1) is delimited by lateral, electrically conductive walls (3), wherein at least one lateral wall (4) is slotted in the longitudinal direction (L) of the slotted waveguide (1) for decoupling the electromagnetic waves along the slotted waveguide (1). The invention is characterized in that in cross section, the slotted waveguide (1) has at least two outer portions (2a, 2b) and a center portion (2c) connecting said outer portions, wherein the center portion (2c) has a constant height (D), at least sectionally or across the entire width © of the center portion (2c), and the outer portions (2a, 2b) have a height or radius (B). The height (H) of the center portion (2c) is smaller than the height or radius (B) of at least one of the outer portions (2a, 2b), and a boundary wall (4) of the center portion (2c) is slotted.

Classes IPC  ?

  • H01P 3/123 - Guides d'ondes creux présentant une section complexe ou en forme d'échelons, p. ex. guides d'ondes striés ou rainurés
  • B61L 3/22 - Commande continuelle le long de la voie utilisant une induction magnétique ou électrostatiqueCommande continuelle le long de la voie utilisant une radiation électromagnétique
  • H01Q 1/32 - Adaptation pour l'utilisation dans ou sur les véhicules routiers ou ferroviaires
  • H01Q 13/22 - Fente longitudinale dans la paroi limite du guide d'onde ou d'une ligne de transmission
  • H01P 5/103 - Transitions entre guides d'ondes creux et lignes coaxiales
  • H01P 3/12 - Guides d'ondes creux

32.

TELESCOPIC ARM WITH A PUSH-PULL CHAIN DRIVE


Numéro d'application EP2015055569
Numéro de publication 2015/140173
Statut Délivré - en vigueur
Date de dépôt 2015-03-17
Date de publication 2015-09-24
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Raabe, Michael
  • Vahle, Werner
  • Müller, Thomas
  • Woyczechowski, Steffen
  • Heitmann, Michael
  • Husarek, Micro

Abrégé

The invention relates to a telescopic arm (1), in particular for a current collector system for a vehicle movable along a conductor rail arrangement, wherein the telescopic arm (1) is extendable and/or retractable by means of an adjustment drive (7, 8, 9, 10), and the telescopic arm (1) has a base unit (2) which is fastenable to the vehicle and on which a first telescopic stage (3) is arranged so as to be displaceable in one direction (RT), in particular horizontally, and a second telescopic stage (4) is arranged on the first telescopic stage (3) so as to be displaceable in the same direction (RT), wherein the adjustment drive (7, 8, 9, 10) is arranged on the first telescopic stage (3), characterized in that the adjustment drive (7, 8, 9, 10) interacts with a push-chain (S) which is connected at one end (Sa) thereof to the base unit (2) and at the other end (Sb) thereof to the second telescopic stage (4).

Classes IPC  ?

  • F16M 11/20 - Infrastructure avec ou sans roues
  • F16G 13/20 - Chaînes ayant des caractéristiques générales particulières rigidesChaînes à arc-boutement
  • B60L 5/38 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement pour collecter le courant sur un rail conducteur
  • B66C 13/12 - Aménagements des moyens pour transmettre une puissance pneumatique, hydraulique ou électrique à des parties ou dispositifs mobiles

33.

COIL FOR AN INDUCTIVE ENERGY TRANSMISSION SYSTEM


Numéro d'application EP2014071130
Numéro de publication 2015/078620
Statut Délivré - en vigueur
Date de dépôt 2014-10-02
Date de publication 2015-06-04
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to a coil arrangement (SPA) for an inductive energy transmission system, said coil arrangement having at least one plate-shaped coil core (Ki), in particular consisting of ferrite, and the at least one plate-shaped coil core (K, KL, KQ) is surrounded in each case by at least one winding (W1, W2, W3, W4) having in each case at least one turn (WG), wherein the coil arrangement (SPA) has at least two windings (W1, W2, W3, W4), the winding axes (WA) of said windings being arranged at an angle (φ) of greater than 50°, in particular at an angle of 90°, to one another , characterized in that the turns (WG) of the windings (Wi) arranged at an angle (φ) to one another are arranged in relation to one another without any crossover and/or in that mutually crossing turns (WG) cross with the windings (Wi) thereof only in the region of a cutout (A, Ai) or a region with a reduced thickness of the plate-shaped coil core (K, Ki).

Classes IPC  ?

34.

POSITIONING SYSTEM FOR VEHICLES COMPRISING AN ELECTRIC DRIVE AND AN INDUCTIVE CHARGING SYSTEM


Numéro d'application EP2014066705
Numéro de publication 2015/039797
Statut Délivré - en vigueur
Date de dépôt 2014-08-04
Date de publication 2015-03-26
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Turki, Faical
  • Körner, André
  • Siekmann, Daniel

Abrégé

The invention relates to a positioning system for a vehicle (1) which can be charged by means of an inductive energy transfer system (2, 4). On the vehicle (1) end, a secondary-side energy transfer device (2), and on the station end, a primary-side energy transfer device (4), particularly in the form of a charging point (4), are arranged and have to be brought in position relative to each other for charging the vehicle (1), additional coils and/or antennas being arranged on the station end and/or on the vehicle (1) end. The invention is characterized in that: either at least one additional primary-side coil and/or antenna forms at least one primary-side transmitter, and at least one additional coil and/or antenna arranged on the vehicle forms at least one receiver for receiving the signals of the at least one primary-side transmitter; and/or at least one coil and/or antenna is additionally arranged on the vehicle and forms at least one secondary-side transmitter, and on the primary side at least one additional coil and/or antenna forms at least one receiver for receiving the signals of the at least one transmitter arranged on the vehicle, at least two receivers and/or at least two transmitters being present; and the positioning system determines, by means of the signals transmitted by the additional coils and/or antennas, the relative distance (VAb) and/or orientation (FR) of the vehicle (1) relative to the primary-side energy transfer device (4) on the station end.

Classes IPC  ?

  • B60L 11/18 - utilisant de l'énergie fournie par des piles primaires, des piles secondaires ou des piles à combustibles

35.

INSULATION MONITORING SYSTEM FOR SERIES-COMPENSATED WINDINGS OF A CONTACTLESS ENERGY TRANSMITTING SYSTEM


Numéro d'application EP2014068578
Numéro de publication 2015/036280
Statut Délivré - en vigueur
Date de dépôt 2014-09-02
Date de publication 2015-03-19
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to a device for transmitting energy in a contactless manner, wherein the device has a primary-side and a secondary-side series resonant circuit (LC), each of which has at least one coil (SP) and at least two capacitors (C), the primary-side series resonant circuit (LC) being connected to an upstream circuit (1a) and the secondary-side series resonant circuit (LC) being connected to a downstream circuit (1b). The invention is characterized in that - a pole (PL) or the center tapped pole (MPL) of at least one or each coil (SP) of the primary-side series resonant circuit (LC) is connected to a first pole (PRFE1) of a respective fault detection resistor (RFE), the other second pole (PRFE2) of the at least one fault detection resistor (RFE) being connected to a voltage potential pole (SPL1p, SPL2p) of the upstream circuit (1a), and/or - a pole (PL) or the center tapped pole (MPL) of at least one or each coil (SP) of the secondary-side series resonant circuit (LC) is connected to a first pole (PRFE1) of a respective fault detection resistor (RFE), the other second pole (PRFE2) of the at least one fault detection resistor (RFE) being connected to the center or the center tap (MTS) of a voltage divider (CGL1, CGL2) of the downstream circuit (1b) or to a voltage potential pole (SPL1s, SPL2s) of the downstream circuit (1b).

Classes IPC  ?

  • H02J 5/00 - Circuits pour le transfert d'énergie électrique entre réseaux à courant alternatif et réseaux à courant continu
  • H02J 7/02 - Circuits pour la charge ou la dépolarisation des batteries ou pour alimenter des charges par des batteries pour la charge des batteries par réseaux à courant alternatif au moyen de convertisseurs

36.

ELECTRICAL RESONANCE ELEMENT FOR CONTACTLESS INDUCTIVE ENERGY TRANSMISSION


Numéro d'application EP2014067565
Numéro de publication 2015/024901
Statut Délivré - en vigueur
Date de dépôt 2014-08-18
Date de publication 2015-02-26
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Meins, Jürgen
  • Turki, Faical
  • May, Hardo

Abrégé

The invention relates to an electrical resonance element for contactless inductive energy transmission. The resonance element comprises at least two parallel electrical conductors (1a, 1b; 11a, 11b, 12a, 12b) isolated from each other. A dielectric having a relative permittivity εr ᡶ 1 is arranged between the individual electrical conductors (1a, 1b; 11a, 11b, 12a, 12b), in particular in order to increase the capacitance. The resonance element is characterized in that the electrical conductors (1a, 1b; 11a, 11b, 12a, 12b) of the resonance element are electrically conductive flat bands, the flat bands (1a, 1b; 11a, 11b, 12a, 12b) being arranged in a spiral shape, in particular wound.

Classes IPC  ?

  • H01F 38/14 - Couplages inductifs
  • H01G 4/40 - Combinaisons structurales de condensateurs fixes avec d'autres éléments électriques non couverts par la présente sous-classe, la structure étant principalement constituée par un condensateur, p. ex. combinaisons RC
  • H01F 27/28 - BobinesEnroulementsConnexions conductrices
  • H01P 11/00 - Appareils ou procédés spécialement adaptés à la fabrication de guides d'ondes, résonateurs, lignes ou autres dispositifs du type guide d'ondes

37.

PRIMARY-SIDE COIL ASSEMBLY FOR INDUCTIVE ENERGY TRANSFER USING QUADRUPOLES


Numéro d'application EP2013075814
Numéro de publication 2014/139605
Statut Délivré - en vigueur
Date de dépôt 2013-12-06
Date de publication 2014-09-18
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Turki, Faical
  • Meins, Jürgen

Abrégé

The invention relates to a primary-side coil assembly for an inductive energy transfer system for transferring energy between a primary- and a secondary-side coil assembly (A1, A2). The invention is characterised in that the primary-side coil assembly (A1) has four coils (2, SP3, SP4) which form the four adjacent coil regions (BEP1, BEP2, BEP3, BEP4) of the coil assembly (A1), the phase position (φIi) of the coil fluxes (SP1, SP2, SP3, SP4) in relation to one another flowing through the coils (I1, I2, I3, I4) determining the phase position (φΒi) of the magnetic flux density (Bi) which is established in the regions (BEP1, BEP2, BEP3, BEP4). With the use of a secondary-side coil assembly (A2) comprising four adjacent coil regions (BES1, BES2, BES3, BES4), the phase position (φIi) of the coil fluxes (I1, I2, I3, I4) is established such that in the four regions (BEP1, BEP2, BEP3, BEP4) of the primary-side coil assembly (A1), the phase position (φΒi) of the respective magnetic flux densities (Bi) which are established is 0°, 90°, 180° and 270° in relation to one another.

Classes IPC  ?

  • H01F 38/14 - Couplages inductifs
  • H01F 27/00 - Détails de transformateurs ou d'inductances, en général
  • H04B 5/00 - Systèmes de transmission en champ proche, p. ex. systèmes à transmission capacitive ou inductive

38.

SECONDARY-SIDE COIL ASSEMBLY FOR INDUCTIVE ENERGY TRANSFER USING QUADRUPOLES


Numéro d'application EP2013075841
Numéro de publication 2014/139606
Statut Délivré - en vigueur
Date de dépôt 2013-12-06
Date de publication 2014-09-18
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Turki, Faical
  • Meins, Jürgen

Abrégé

The invention relates to a secondary-side coil assembly for an inductive energy transfer system for transferring energy between a primary- and a secondary-side coil assembly (A1, A2).The invention is characterised in that the secondary-side coil assembly (A1) has coils (SS1, SS2, SS3, SS4) which form four coil regions (BES1, BES2, BES3, BES4) of the coil assembly (A1), said regions lying adjacent to one another on a plane, each coil (SS1, SS2, SS3, SS4) together with at least one capacitor (CS1-4) forming a resonant circuit (RESS).

Classes IPC  ?

  • H01F 38/14 - Couplages inductifs
  • H01F 27/00 - Détails de transformateurs ou d'inductances, en général
  • H04B 5/00 - Systèmes de transmission en champ proche, p. ex. systèmes à transmission capacitive ou inductive

39.

INCREASING THE PHASE TOLERANCE OF MAGNETIC CIRCUITS DURING CONTACTLESS ENERGY TRANSFER


Numéro d'application EP2014054577
Numéro de publication 2014/139948
Statut Délivré - en vigueur
Date de dépôt 2014-03-10
Date de publication 2014-09-18
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to an inductive energy transfer system comprising a coil assembly (Lp) on the primary side and a coil assembly (Ls) on the secondary side, each of said assemblies forming a resonant circuit (RESp, RESs) with a capacitance (Cp, Cs). The system is characterised in that the coil system (SPP) on the primary side has two coils (Lp) connected in series, the connection point (Pp) of said coils being connected by means of an impedance (LPM) on the primary side to an input terminal (3) of the circuit (1) supplying the resonant circuit (RESP) on the primary side and/or in that the coil system (SPs) on the secondary side has two coils (U) connected in series, the connection point (Ps) of said coils being connected by means of an impedance (LSM) on the secondary side to an output terminal (4) of the circuit (2) connected downstream of the resonant circuit (RESs) on the secondary side.

Classes IPC  ?

  • H02M 5/458 - Transformation d'une puissance d'entrée en courant alternatif en une puissance de sortie en courant alternatif, p. ex. pour changement de la tension, pour changement de la fréquence, pour changement du nombre de phases avec transformation intermédiaire en courant continu par convertisseurs statiques utilisant des tubes à décharge ou des dispositifs à semi-conducteurs pour transformer le courant continu intermédiaire en courant alternatif utilisant des dispositifs du type triode ou transistor exigeant l'application continue d'un signal de commande utilisant uniquement des dispositifs à semi-conducteurs
  • H02J 5/00 - Circuits pour le transfert d'énergie électrique entre réseaux à courant alternatif et réseaux à courant continu

40.

METAL FOREIGN BODY-IDENTIFICATION SYSTEM FOR INDUCTIVE ENERGY TRANSMISSION SYSTEMS


Numéro d'application EP2013069174
Numéro de publication 2014/041176
Statut Délivré - en vigueur
Date de dépôt 2013-09-16
Date de publication 2014-03-20
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to an identification system for identifying electrically conductive foreign bodies (F) in the region (3) between the primary and secondary winding of an inductive energy transmission system, the identification system likewise having at least one primary coil (LA) and at least one secondary coil (LB) which are intercoupled. At least one primary coil (LA) and/or at least one secondary coil (LB) of the identification system is a constituent part or are constituent parts of at least one electrical resonant circuit (LA-CA; LB-CB) and an electrical source (7) excites at least one resonant circuit (LA-CA). A monitoring device monitors at least one electrical variable on the secondary and/or primary side of the identification system and identifies the foreign body using said measured electrical variable.

Classes IPC  ?

  • G01V 3/10 - Prospection ou détection électrique ou magnétiqueMesure des caractéristiques du champ magnétique de la terre, p. ex. de la déclinaison ou de la déviation fonctionnant au moyen de champs magnétiques ou électriques produits ou modifiés par les objets ou les structures géologiques, ou par les dispositifs de détection en utilisant des cadres inducteurs
  • B60L 11/18 - utilisant de l'énergie fournie par des piles primaires, des piles secondaires ou des piles à combustibles
  • H02J 5/00 - Circuits pour le transfert d'énergie électrique entre réseaux à courant alternatif et réseaux à courant continu
  • H02J 7/02 - Circuits pour la charge ou la dépolarisation des batteries ou pour alimenter des charges par des batteries pour la charge des batteries par réseaux à courant alternatif au moyen de convertisseurs

41.

CONNECTOR FOR BUSBARS


Numéro d'application EP2013060999
Numéro de publication 2014/019734
Statut Délivré - en vigueur
Date de dépôt 2013-05-29
Date de publication 2014-02-06
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Tembaak, Philip

Abrégé

Busbar connector (S) for connecting the ends (1a, 1b) of two busbars (1) comprising a first and a second connecting element (2a, 2b), which can be connected to the busbar ends (1a, 1b) by means of screw elements (3), wherein a screw element (3) is supported on one side on a busbar and on the other side on the first connecting element (2a), and wherein a force (F2) can be generated by means of the screw element (3) which presses the second connecting element (2b) against the busbar (1), wherein the connecting elements (2a, 2b) have corresponding layering faces (2x, 2y), which are arranged at an angle to the direction of the force (F2), and owing to the force (F2) and the angled bearing faces (2x, 2y), a force component (K1) is produced transversely to the direction of the force (F2), which force component presses at least one connecting element (2a, 2b) with a further bearing face (A1, A2) in the direction of the force component (K1), in particular laterally, against the busbars (1).

Classes IPC  ?

  • H01R 25/14 - Rails ou barres omnibus réalisés de telle sorte que les pièces complémentaires puissent leur être connectées en tout point de leur longueur
  • B60M 1/34 - Rails conducteurs disposés dans des conduits à fente

42.

CONTROL UNIT FOR AN INVERTER LOADED BY A RESONANT LOAD NETWORK


Numéro d'application EP2012076217
Numéro de publication 2013/104503
Statut Délivré - en vigueur
Date de dépôt 2012-12-19
Date de publication 2013-07-18
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Turki, Faical
  • Vosshagen, Thomas

Abrégé

The invention relates to an inverter having at least two switching means (S1, S2, S3, S4) for feeding a resonant circuit (LS, CS) from a source (Uin, Izk), wherein a control unit of the inverter controls the switching means (S1, S2, S3, S4), characterized in that the control unit controls the switching means (S1, S2, S3, S4) in such a manner that in a first mode A, the inverter feeds the resonant circuit (LS, CS) via the switching means from the source (Uin, Izk), and in a second mode B, the resonant circuit (LS, CS) is decoupled from the source (Uin, Izk), wherein the control unit switches back and forth between the two modes A and B for adjusting a nominal voltage (Ip_soll) in the resonant circuit (LS, CS) or a nominal voltage (Up_soll) on the resonant circuit (LS, CS).

Classes IPC  ?

  • H02M 7/538 - Transformation d'une puissance d'entrée en courant continu en une puissance de sortie en courant alternatif sans possibilité de réversibilité par convertisseurs statiques utilisant des tubes à décharge avec électrode de commande ou des dispositifs à semi-conducteurs avec électrode de commande utilisant des dispositifs du type triode ou transistor exigeant l'application continue d'un signal de commande utilisant uniquement des dispositifs à semi-conducteurs, p. ex. onduleurs à impulsions à un seul commutateur dans une configuration push-pull
  • H02M 1/00 - Détails d'appareils pour transformation
  • H02M 7/48 - Transformation d'une puissance d'entrée en courant continu en une puissance de sortie en courant alternatif sans possibilité de réversibilité par convertisseurs statiques utilisant des tubes à décharge avec électrode de commande ou des dispositifs à semi-conducteurs avec électrode de commande

43.

CONTROLLED RECTIFIER WITH A B2 BRIDGE AND ONLY ONE SWITCHING DEVICE


Numéro d'application EP2012070852
Numéro de publication 2013/075896
Statut Délivré - en vigueur
Date de dépôt 2012-10-22
Date de publication 2013-05-30
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to a secondary-side rectifier of an inductive energy transfer system, said energy transfer system having at least one single-phase resonant circuit with at least one inductance (L) and at least one capacitance (Cs), which energy transfer system can be magnetically coupled to a primary-side resonant circuit. The secondary-side rectifier comprises a B2 bridge circuit constituted by four diodes (D1, D2, D3, D4), which is connected on the input side to the secondary-side resonant circuit, and the output voltage of which is smoothed by at least one smoothing capacitor (Cgr). The invention is characterized in that a switching device (S) is connected in parallel to a diode (D1, D2, D3, D4), said switching device being capable of short-circuiting the diode (D1, D2, D3, D4) .

Classes IPC  ?

  • H02M 7/217 - Transformation d'une puissance d'entrée en courant alternatif en une puissance de sortie en courant continu sans possibilité de réversibilité par convertisseurs statiques utilisant des tubes à décharge avec électrode de commande ou des dispositifs à semi-conducteurs avec électrode de commande utilisant des dispositifs du type triode ou transistor exigeant l'application continue d'un signal de commande utilisant uniquement des dispositifs à semi-conducteurs
  • H02J 17/00 - Systèmes pour l'alimentation ou la distribution d'énergie par ondes électromagnétiques
  • H02M 7/06 - Transformation d'une puissance d'entrée en courant alternatif en une puissance de sortie en courant continu sans possibilité de réversibilité par convertisseurs statiques utilisant des tubes à décharge sans électrode de commande ou des dispositifs à semi-conducteurs sans éléctrode de commande

44.

NETWORK SIMULATION IN THE SECONDARY CIRCUIT OF CONTACTLESS POWER TRANSMISSION


Numéro d'application EP2012068129
Numéro de publication 2013/056923
Statut Délivré - en vigueur
Date de dépôt 2012-09-14
Date de publication 2013-04-25
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s) Turki, Faical

Abrégé

The invention relates to an inductive power transmission system, comprising at least one primary coil (Sp1) and at least one secondary coil (Sp2), which are or can be magnetically coupled to each other and which form respective primary-side and secondary-side resonant circuits (Repri, Resek) together with at least one capacitor (C1, C2), characterized in that a primary-side inverter (15) produces a clocked voltage (Uw), in particular a clocked square-wave voltage, from a unipolar primary voltage (|UN|) or a direct voltage (UG) and feeds said clocked voltage to the primary-side resonant circuit (Repri), the primary-side inverter (15) being clocked or adjusted in such a way or the clocking of the voltage, in particular square-wave voltage, produced by the primary-side inverter (15) being selected or adjusted in such a way that a secondary alternating voltage (Ui) having a carrier frequency (fT) and induced in the secondary-side resonant circuit (Resek) results, the amplitude of the secondary alternating voltage (Ui) oscillating at a network frequency (f0), an apparatus (E) being connected downstream of the secondary-side resonant circuit (Resek), which apparatus produces a bipolar secondary-side output voltage (UA) from the voltage (Ui) present at the output of the secondary-side resonant circuit (Resek), the frequency (fA) of the secondary-side output voltage (UA) being equal to the network frequency (f0), and characterized in that the apparatus (E) has in particular four power semiconductors (L1, L2, L3, L4; L5, L6, L7, L8; L9, L10, L11, L12), which form two groups (Gr1; Gr2) of in particular equally many power semiconductors, and the power semiconductors of a group (Gr1; Gr2) are switched jointly by means of a group control signal (G1; G2), wherein the groups (Gr1, Gr2) are switched to an active state in alternation by means of the group control signals (G1; G2).

Classes IPC  ?

  • H02J 5/00 - Circuits pour le transfert d'énergie électrique entre réseaux à courant alternatif et réseaux à courant continu

45.

FLAT COIL FOR A CONTACTLESS INDUCTIVE ENERGY TRANSMISSION


Numéro d'application EP2012055540
Numéro de publication 2013/000593
Statut Délivré - en vigueur
Date de dépôt 2012-03-28
Date de publication 2013-01-03
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Meins, Jürgen
  • Schmülling, Benedikt
  • Turki, Faical
  • Vosshagen, Thomas

Abrégé

The invention relates to an inductive energy transmitting system for transmitting electric energy between a base station and a movable load, in particular a vehicle. Electric energy can be transmitted from a base station to the load and/or from the load to the base station by means of the energy transmitting system. The energy transmitting system has at least one primary-side flat coil (Sp) arranged in the base station and a secondary-side flat coil (Ss) arranged in the load, each coil comprising multiple windings (3, 4). The windings (3, 4) are arranged concentrically or spirally about a central point (M). The invention is characterized in that at least some adjacent windings (13) of a primary-side flat coil (Sp) are mutually spaced by a gap (di), and the distance (9, 10) between the winding that is arranged closest to the central point (M) and the winding that is arranged farthest from the central point (M) is greater in the primary-side coil (Sp) than in a secondary-side coil (Ss).

Classes IPC  ?

46.

Miscellaneous Design


Numéro d'application 1138992
Statut Enregistrée
Date de dépôt 2012-07-24
Date d'enregistrement 2012-07-24
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Metal building materials; materials of metal for railway tracks; rails, rail connectors, rail mounts, sliding stops and points for railways, pulleys and cables, spring hoists, spring reels and drum motors for pipes and hoses, work cabins, ladders (all the aforesaid goods being of metal). Lifts, namely passenger lifts or goods lifts, feeding systems for use in automobile engineering, cranes, lifting and conveyor systems, and parts therefor (included in this class); conveyer belts; lifting apparatus, cranes (except boat cranes); door openers, electric; swivel jibs, folding jibs, console jibs and swivel arms for machines for processing metal, wood and plastic. Electric apparatus and instruments for electrical engineering, namely for conducting, transforming, transmitting, accumulating, regulating or controlling, in particular electric conduits and cables, contact lines, electric plugs, slip ring elements, screw fittings, clamping boxes, end terminals and distributors, current collectors for contact lines, control stations; temperature controllers, cable tracks for electric cables; electric apparatus and instruments for weak-current engineering, namely for conducting, transforming, transmitting, accumulating, regulating and controlling, conveying of electricity and electrical energy; contactless electricity and energy transmission systems or data transmission systems; accessories for non-contact power and energy transmission systems or data transmission systems, namely frequency converters, storage batteries and capacitors; inductive and electromagnetic non-contact vehicle and apparatus guide systems.

47.

INDUCTIVE CONTACTLESS ENERGY AND DATA TRANSMISSION SYSTEM


Numéro d'application EP2012055515
Numéro de publication 2012/163565
Statut Délivré - en vigueur
Date de dépôt 2012-03-28
Date de publication 2012-12-06
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Turki, Faical
  • Schmülling, Benedikt

Abrégé

The invention relates to an inductive contactless energy and data transmission system (1), having a primary coil arrangement and a secondary coil arrangement, wherein both the primary and the secondary coil arrangement are each provided with at least one coil (3, 7) for transmitting energy and at least one coil (4, 6) for transmitting data, characterized in that the primary and secondary coils (3, 7) for transmitting energy are each configured with a single winding sense, and in that the coils (4, 6) for transmitting data are coil arrangements, which are each provided with at least two coil fields (4a, 4b, 4c, 4d).

Classes IPC  ?

  • H04B 5/00 - Systèmes de transmission en champ proche, p. ex. systèmes à transmission capacitive ou inductive

48.

Miscellaneous Design


Numéro d'application 010614493
Statut Enregistrée
Date de dépôt 2012-02-03
Date d'enregistrement 2012-07-02
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
  • 17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler

Produits et services

Metal building materials; Materials of metal for railway tracks; Rails, Rail connectors, Rail mounts,Sliding stops and points for railways, Pulleys and Cables,Spring hoists, spring reels and drum motors for pipes and hoses, work cabins, ladders (all the aforesaid goods being of metal). Lifts, namely passenger lifts or goods lifts, feeding systems for use in automobile engineering, cranes, lifting and conveyor systems, and parts therefor (included in class 7); conveyer belts; Lifting apparatus,Cranes (except boat cranes); Door openers, electric; Swivel jibs, folding jibs, console jibs and swivel arms for machines for processing metal, wood and plastic. Electric apparatus and instruments for electrical engineering, namely for conducting, transforming, transmitting, accumulating, regulating or controlling, in particular electric conduits and cables, contact lines, electric plugs, slip ring elements, screw fittings, clamping boxes, end terminals and distributors, current collectors for contact lines, control stations; Temperature controllers,Cable tracks for electric cables; Electric apparatus and instruments for weak-current engineering, namely for conducting, transforming, transmitting, accumulating, regulating and controlling; Conveying of electricity and electrical energy; Contactless electricity and energy transmission systems or data transmission systems; Accessories for non-contact power and energy transmission systems or data transmission systems, namely frequency converters, Storage batteries and Capacitors; Inductive and electromagnetic non-contact vehicle and apparatus guide systems. Vehicles, namely apparatus for locomotion by land, air and water, and parts therefor (included in class 12); Apparatus for locomotion by land, in water or on water, namely cable cars, beach cable cars, rack railways, aerial conveyors, lifts, tramways, suspension railways, passenger transport railways, trucks for transporting materials, and parts therefor (included in class 12); Rail-mounted cable trolleys, equipment wagons, rollers and buffers for cable trolleys and equipment wagons, cable veyors for electric, pneumatic and liquid conduits. Insulators for electric mains; Flexible sheathing for conduits; Gum and cellulose buffers, Plastic hoses,Plastic films for work cabins; Junctions, conduit clips and conduit holders of plastic for pipes, tubes and conduits.

49.

ENERGY TRANSFER SYSTEM COMPRISING SEVERAL PRIMARY COILS


Numéro d'application EP2010001494
Numéro de publication 2010/105758
Statut Délivré - en vigueur
Date de dépôt 2010-03-10
Date de publication 2010-09-23
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Turki, Faical
  • Reker, Ulrich

Abrégé

The invention relates to a primary device for an energy transfer system for the contactless transfer of electric energy to at least one stationary or moving vehicle, at least one secondary element which can be inductively coupled to the primary device by means of at least one coil being situated in the vehicle. The coils of the primary device are or can be connected to at least one energy source, in particular in the form of an inverter and the coils (Sj) of the primary device (1, 1') are either arranged in a row or in a matrix consisting of rows (Zj) and columns (Spj). The coils are either arranged on the intersection points of the rows and columns or extend as elongated coils along the rows and columns, intersecting in the region of the intersection points.

Classes IPC  ?

  • H01F 38/14 - Couplages inductifs
  • B60L 5/00 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement
  • H02J 5/00 - Circuits pour le transfert d'énergie électrique entre réseaux à courant alternatif et réseaux à courant continu

50.

WIRES LAID IN A MATRIX FOR FORMING ONE OR MORE PRIMARY COILS OF AN INDUCTIVE ENERGY TRANSFER SYSTEM


Numéro d'application EP2010001495
Numéro de publication 2010/105759
Statut Délivré - en vigueur
Date de dépôt 2010-03-10
Date de publication 2010-09-23
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Turki, Faical
  • Reker, Ulrich

Abrégé

The invention relates to a primary device for an energy transfer system for the contactless transfer of electric energy to at least one stationary or moving vehicle (F), at least one secondary element (2) which can be inductively coupled to the primary device by means of at least one coil (SPU) being situated in the vehicle (F). The coil or coils (Si) of the primary device (1) is/are or can be connected to at least one energy source(Ui), in particular in the form of an inverter (4). Several parallel rectilinear wires (Lx) running at a distance from one another are arranged in an X-direction and several parallel rectilinear wires (Ly) running at a distance from one another are arranged in a Y-direction on a delimited surface (FL), whereby said wires delimit quadrilateral regions (Bi, BBi, BB'i, BB"i). Phase-opposed currents flow in the respective wires (Lx; Ly) that delimit the region (Bi, BBi, BB'i, BB"i) and are arranged in parallel to one another.

Classes IPC  ?

  • H01F 38/14 - Couplages inductifs
  • B60L 5/00 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement
  • H02J 5/00 - Circuits pour le transfert d'énergie électrique entre réseaux à courant alternatif et réseaux à courant continu

51.

CURRENT COLLECTOR SYSTEM FOR A VEHICLE, IN PARTICULAR FOR RTG CONTAINER STACKER CRANES


Numéro d'application EP2009008179
Numéro de publication 2010/054852
Statut Délivré - en vigueur
Date de dépôt 2009-11-17
Date de publication 2010-05-20
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Schröder, Arno
  • Heitmann, Michael
  • Mehrwald, Uwe
  • Dufke, Alfred
  • Raabe, Michael

Abrégé

The invention relates to a current collector system for fastening to a vehicle, in particular a container stacker crane, wherein the vehicle can be moved along a line (T), and at least one busbar (S) is arranged on the line (T), wherein the current collector system has a collector trolley (W) having at least one current collector (AB), and the at least one current collector (AB) can be brought into contact with a busbar (S). The invention is characterized in that the vehicle comprises an arm (1) that can be inserted and/or retracted in the horizontal direction for producing an electric connection, and that the collector trolley (W) is mounted at the arm so as to be displaceable in the vertical direction, wherein the current collector (AB) can be inserted into a busbar of the line by means of a positioning and insertion device (TE).

Classes IPC  ?

  • B66C 13/12 - Aménagements des moyens pour transmettre une puissance pneumatique, hydraulique ou électrique à des parties ou dispositifs mobiles
  • B66C 19/00 - Ponts roulants ou portiques fixes ou mobiles, portant un chariot ou un treuil mobile
  • B60L 5/40 - Collecteurs de courant pour lignes d'alimentation en énergie sur les véhicules propulsés électriquement pour collecter le courant sur des lignes disposées dans des conduits à fente
  • B60M 1/34 - Rails conducteurs disposés dans des conduits à fente

52.

FLEXIBLE CONDUCTOR LINE, PARTICULARLY FOR POINT AND CROSSOVER SWITCHES


Numéro d'application EP2008010117
Numéro de publication 2009/086865
Statut Délivré - en vigueur
Date de dépôt 2008-11-28
Date de publication 2009-07-16
Propriétaire PAUL VAHLE GMBH & CO. KG (Allemagne)
Inventeur(s)
  • Bartz, Wolfgang
  • Woyczechowski, Steffen

Abrégé

The invention relates to a conductor line, comprising a plurality of housing segments pivotally or rotatably supported on each other (1, 1'), made of non-conductive material, wherein at least one bus bar (S) is held in the housing segments (1, 1').

Classes IPC  ?

53.

FABA


Numéro d'application 883674B
Statut Enregistrée
Date de dépôt 2006-02-10
Date d'enregistrement 2006-02-10
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ? 09 - Appareils et instruments scientifiques et électriques

Produits et services

Isolated conductors for telpher lines, absolute position linear encoder (magnetic integrated system).

54.

VAHLE


Numéro d'application 870894
Statut Enregistrée
Date de dépôt 2004-08-27
Date d'enregistrement 2004-08-27
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Metal building materials; materials of metal for railway tracks; tracks, track connectors, track holders, end stops for tracks and track switches, wires and cables, springs (metal hardware); connectors and adapter fittings (couplings) for conduits (pipes), carrels, ladders (all said goods made of metal); pipes of metal, for heating installations; screw connections (of metal). Spring or motor-operated cable reels; energy chains and cable chains for cranes or other movable loading apparatus. Electric apparatus and instruments for heavy current engineering, namely for conducting, converting, transmitting, storage, regulating and controlling, especially electric conduits and cables, power rail conductors, electric plugs, collector rings, terminal boxes, termination fittings and distributors, current collectors for conductor rails, control stations, temperature control units; apparatus and instruments for low-voltage engineering, namely for conducting, converting, transmitting, storing, regulating and controlling electricity; flexible cables for transporting current and electrical energy; non-contact electricity or energy transmission systems or data transmission systems and accessories thereof, namely frequency converters, accumulators and condensers; non-contact guidance (track) systems for vehicles and apparatus.

55.

VAHLE


Numéro de série 79018615
Statut Enregistrée
Date de dépôt 2004-08-27
Date d'enregistrement 2007-09-25
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques

Produits et services

Metal building materials, namely, soffits, fascia, siding, studs, roofing; metallic materials for railway tracks; metal tracks for rail vehicles; metallic materials for railway tracks, namely track connectors, track holders, end stops for tracks and track switches, wire and cable wire; metal hardware, namely, springs; metal pipe connectors and couplings, all of the aforesaid for metal conduits, carrels, and ladders; metal pipes for heating installations; metal screws Power-operated reels for non-electrical cable and electrical cable, energy chains and cable chains for containment of data transmission or energy transmission cables Electric apparatus and equipment for conducting, converting, transmitting, storage, regulating, and controlling electricity, all of the aforesaid for heavy current engineering, namely, electricity conduits, electric cables, electric power rail conductors, electric plugs, electrical terminal boxes and accessories therefor, namely termination fittings and distributors, electric current collectors for conductor rails, control stations and temperature control units; apparatus and instruments for conducting, converting, transmitting, storing, regulating and controlling electricity, all of the aforesaid for low-voltage engineering, namely, electrical plugs, electrical conductors; flexible electrical cables for transporting current and electrical energy; non-contact electricity, energy, and data transmission systems comprised of antennae, frequency converters, electrical accumulators and condensers, resonant coil systems for movable devices, electrical transmission cables and accessories thereof, namely, frequency converters, electric accumulators and condensers

56.

VAHLE


Numéro d'application 003684016
Statut Enregistrée
Date de dépôt 2004-02-27
Date d'enregistrement 2006-11-08
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
  • 17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler

Produits et services

Building materials of metal; materials of metal for railway tracks; rails, rail connectors, rail supports, rail limit stops and points for railways, ropes and cables, spring balancers, spring and motorised drums for pipes and hoses, work cabins, ladders (all the aforesaid goods of metal). Lifts, namely passenger lifts or goods lifts, feeding systems for use in automobile engineering, cranes, lifting and conveyor systems, and parts therefor (included in class 7); conveyer belts; hoists, cranes (except boat cranes); door openers, electric; swivel jibs, folding jibs, console jibs and swivel arms for machines for processing metal, wood and plastic. Electric apparatus and instruments for electrical engineering, namely for conducting, transforming, transmitting, accumulating, regulating or controlling, in particular electric conduits and cables, contact lines, electric plugs, slip ring elements, screw fittings, clamping boxes, end terminals and distributors, current collectors for contact lines, control stations; temperature-regulating apparatus, heating pipes, lamps, tracks for electric cables; electric apparatus and instruments for weak-current engineering, namely for conducting, transforming, transmitting, accumulating, regulating and controlling; conveying of electricity and electrical energy; contactless electricity and energy transmission systems or data transmission systems; accessories for non-contact power and energy transmission systems or data transmission systems, namely frequency converters, accumulators and condensers; non-contact vehicle and apparatus feed systems. Vehicles, namely apparatus for locomotion by land, air and water, and parts therefor (included in class 12); apparatus for locomotion by land, in water or on water, namely cable cars, beach cable cars, rack railways, aerial conveyors, lifts, tramways, suspension railways, passenger transport railways, trucks for transporting materials, and parts therefor (included in class 12); rail-mounted cable trolleys, equipment wagons, rollers and buffers for cable trolleys and equipment wagons, cable veyors for electric, pneumatic and liquid conduits. Insulators for electric mains; flexible sheathing for conduits; buffers of rubber and cellulose, plastic tubes, plastic foils for work cabins; junctions, conduit clips and conduit holders of plastic for pipes, tubes and conduits.

57.

1912


Numéro d'application 003684297
Statut Enregistrée
Date de dépôt 2004-02-27
Date d'enregistrement 2005-07-26
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules
  • 17 - Produits en caoutchouc ou en matières plastiques; matières à calfeutrer et à isoler

Produits et services

Building materials of metal; materials of metal for railway tracks; rails, rail connectors, rail supports, rail limit stops and points for railways, ropes and cables, spring balancers, spring drums for conduits and tubes, junctions and connectors for pipelines, work cabins, ladders (all these goods of metal); motorised drums for junctions and connectors for pipelines and ladders (all these goods of metal). Lifts, namely passenger lifts or goods lifts, feeding systems for use in automobile engineering, cranes, lifting and conveyor systems, and parts therefor (included in class 7); motorised drums for conduits and tubes, work cabins. Electric apparatus and instruments for electrical engineering, namely for conducting, transforming, transmitting, accumulating, regulating or controlling, in particular electric conduits and cables, contact lines, electric plugs, slip ring elements, screw fittings, clamping boxes, end terminals and distributors, current collectors for contact lines, control stations; temperature-regulating apparatus, heating pipes, lamps, tracks for electric cables; electric apparatus and instruments for weak-current engineering, namely for conducting, transforming, transmitting, accumulating, regulating and controlling; electric systems for supplying electric energy; non-contact power and energy transmission systems or data transmission systems, namely frequency converters, accumulators and condensers; non-contact vehicle and apparatus feed systems; door openers, electric. Vehicles, namely apparatus for locomotion by land, air and water, and parts therefor (included in class 12); apparatus for locomotion by land, in water or on water, namely cable cars, beach cable cars, rack railways, aerial conveyors, lifts, tramways, suspension railways, passenger transport railways, service tramways, trucks for transporting materials, and parts therefor (included in class 12); lifting tools, cranes (except boat cranes), swivel booms, hinged jibs, walking jibs and swivel arms for machines for metalworking, woodworking and plastic processing; rail-mounted cable trolleys, equipment wagons, rollers and buffers for electric, pneumatic and liquid conduits. Insulators for electric mains; insulating material, in particular for flexible energy supply lines; flexible sheathing for conduits; buffers of rubber and cellulose, plastic tubes, plastic foils for work cabins; junctions, conduit clips and conduit holders of plastic for pipes, tubes and conduits.

58.

CPS


Numéro de série 75908616
Statut Enregistrée
Date de dépôt 2000-02-02
Date d'enregistrement 2004-02-17
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules

Produits et services

[ Manufactured products made of steel, aluminum, brass, zinc and tin, namely, electrical inductor cables and spring driven cable reels for use with non-contact driven vehicles; metal railroads ties ] [ Elevators, namely, hoists and passenger elevators and structural parts therefor; automobile production line cranes, lifts, conveyors and structural parts therefor ] Electrical apparatus and instruments, namely non-contact inductive current transfer systems comprising components for tracked mobile equipment, namely, cranes, elevators, monorails, escalators, and conveyors; electromagnetic induction electrical current supplies, namely, rectifiers, inverters, power filter units, overload protection devices, switching coils and switching elements for directing vehicles; data communication systems comprising a microwave or carrier frequency and superimposition system for transmitting instructions and data to non-contact vehicles, cranes, elevators, monorails, escalators and conveyors [ Land vehicles, ] [ ships, boats and airplanes, trains, monorails, funiculars, ski lifts and cable cars and structural parts therefor ]

59.

CPS


Numéro d'application 001470103
Statut Enregistrée
Date de dépôt 2000-01-21
Date d'enregistrement 2002-10-25
Propriétaire Paul Vahle GmbH & Co. KG (Allemagne)
Classes de Nice  ?
  • 06 - Métaux communs et minerais; objets en métal
  • 07 - Machines et machines-outils
  • 09 - Appareils et instruments scientifiques et électriques
  • 12 - Véhicules; appareils de locomotion par terre, par air ou par eau; parties de véhicules

Produits et services

Metal building materials; materials of metal for railway tracks. Lifts, namely passenger lifts or goods lifts, feeding systems for use in automobile engineering, cranes, lifting and conveyor systems, and parts therefor (included in class 7). Electric apparatus and instruments for electrical power engineering, namely for conducting, converting, transmitting, storage, regulating and controlling with the exception of control power supplies; electric apparatus and instruments for low-voltage engineering, namely for conducting, converting, transmitting, storage, regulating and controlling, with the exception of control power supplies; supply of electricity and electrical energy, with the exception of control power supply; non-contact electricity or energy transmission systems or data transmission systems, and accessories therefor; non-contact vehicle or apparatus guiding systems, and accessories therefor. Vehicles, namely land, air and water vehicles and parts therefor (so far as included in class 12); apparatus for locomotion by land, in or on water, namely cable railways, funicular railways; rack railways, aerial conveyors, lifts, tramways, suspension railways, passenger transport railways, service tramways, trucks for transporting materials, and parts therefor (so far as included in class 12).
