22 laser source generates a pulsed laser beam having a wavelength of 9-11 microns. A laser beam width is defined and the pulsed laser beam focused at or near the dental hard tissue. A pulse energy is controlled with at least one beam pulse having a fluence profile in a working range of the laser beam having: a maximum local fluence less than a minimum fluence that causes damage of the dental hard tissue, and at least one other local fluence greater than a fluence that causes a minimum amount of occlusion of the dentin tubules. The pulsed laser beam is directed to respective dental hard tissue locations to occlude the dentin tubules, without delivery of cooling fluid while directing the pulsed laser beam to respective tissue locations.
A method for treating dental hard tissue to decrease sensitivity by occluding dentin tubules. A CO2 laser source generates a pulsed laser beam having a wavelength of 9-11 microns. A laser beam width is defined and the pulsed laser beam focused at or near the dental hard tissue. A pulse energy is controlled with at least one beam pulse having a fluence profile in a working range of the laser beam having:
a maximum local fluence less than a minimum fluence that causes damage of the dental hard tissue, and
at least one other local fluence greater than a fluence that causes a minimum amount of occlusion of the dentin tubules.
The pulsed laser beam is directed to respective dental hard tissue locations to occlude the dentin tubules, without delivery of cooling fluid while directing the pulsed laser beam to respective tissue locations.
A system and method for dental or surgical treatment of oral tissue, the system including a laser source; a hand piece; and a device for directing radiation emitted by the laser source to a treatment area (e.g., an oral treatment area), the device further including a disposable tube attachable to the hand piece and an optical element (e.g., a substantially cylindrical lens) mounted within the disposable tube and adapted to modify a profile and/or a direction of the radiation emitted from the tube.
G02B 3/06 - Lentilles simples ou composées à surfaces non sphériques à surfaces cylindriques ou en forme de tore
H01S 3/223 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet caractérisés par le matériau utilisé comme milieu actif à gaz le gaz actif étant polyatomique, c.-à-d. contenant plusieurs atomes
4.
Laser system for enhancing remineralization and strength of hard tissue
A laser-based system and method for treatment of hard tissue enhances remineralization and fluoride uptake to improve resistance to demineralization. The system can include a laser source, an optic, and a controller for controlling the laser source and/or the optic to deliver radiation to a treatment region with desirable characteristics (e.g., to remove carbonate without damaging the tissue surface). In some cases, the system includes a handpiece having an optical element (e.g., a lens) mounted within a replaceable cartridge and adapted to modulate a laser beam to render the beam non-ablative, prior to the laser beam's delivery to the treatment region. In some embodiments, treatment with the laser can be combined with a fluoride treatment for enhanced therapeutic effect.
The disclosed invention relates to an improved system and method for treatment of soft tissue, e.g., for treatment of a snoring condition. The system can include a laser source; a hand piece; and a device for directing radiation emitted by the laser source to a treatment area (e.g., an oral treatment area). In some cases, the handpiece can include an optical element (e.g., a lens) mounted within a replaceable cartridge and adapted to modulate a laser beam such that it is non-ablative, prior to its delivery to a treatment region. In various embodiments, the system includes a CO2 laser capable of performing treatment in a more efficient manner than conventional techniques.
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
H01S 3/00 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet
H01S 3/223 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet caractérisés par le matériau utilisé comme milieu actif à gaz le gaz actif étant polyatomique, c.-à-d. contenant plusieurs atomes
A61B 17/00 - Instruments, dispositifs ou procédés chirurgicaux
6.
System and methods for pulsing and directing a pulsed laser beam to treat dental tissue
A laser beam treatment system that delivers laser beam pulses to a dental treatment area according to a particular pattern is described. In various instances, the spacing of the pattern (e.g., locations at which pulses are delivered and the distances therebetween) and/or the timing of the pattern (e.g., amount of time between the delivery of pulses to a first location and a later location that abuts the first location) can have a demonstrable effect on ablation performance. The effects can include, for example: improved ablation efficiency, improved surface smoothness, improved material removal rate, and/or the absence of melt, carbonization or other negative surface features.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
7.
DENTAL LASER APPARATUS AND METHOD OF USE WITH INTERCHANGEABLE HAND PIECE AND VARIABLE FOOT PEDAL
A dental laser system for treatment of hard and/or soft tissue includes a main chamber housing optical and primary fluid supply subsystems, for directing a laser beam and fluid to a treatment area. A hand piece affixable to the main chamber, includes mating optical and secondary fluid supply subsystems. The hand piece can be rotatable or re-orientable about an optical axis within the hand piece. A lock can maintain a selectable angular orientation of the hand piece relative to the main chamber. A coupling can maintain a fluidic communication between the primary and secondary fluid supply subsystems even when the hand piece is rotated or re-oriented. A sensor and controller can sense a selected angular orientation of the hand piece and adjust the main optical subsystem according to the sensed angular orientation, to align the two optical subsystems. The laser may be controlled using a variable speed foot pedal.
The disclosed invention relates to a system and method for treatment of root canals, e.g., to clean, decontaminate and remove the smear layer. The system can include a laser source; a hand piece; and a device for directing radiation emitted by the laser source to a liquid creating pressure that result in irrigation. In some cases, the handpiece can include an optical element adapted to modulate a laser beam such that it is dispersive or focused.
The disclosed invention relates to a system and method for treatment of root canals, e.g., to clean, decontaminate and remove the smear layer. The system can include a laser source; a hand piece; and a device for directing radiation emitted by the laser source to a liquid creating pressure that result in irrigation. In some cases, the handpiece can include an optical element adapted to modulate a laser beam such that it is dispersive or focused.
A61C 5/40 - Instruments pour le traitement chirurgical des racines ou des nerfs dentairesAiguilles pour retirer le nerfProcédés ou instruments pour le traitement des racines
10.
SYSTEM AND METHOD FOR LASER BASED WHITENING TREATMENT OF HARD TISSUE
The disclosed invention relates to a system and method for treatment of a dental hard tissue. The system can include a laser source for generating a laser beam; at least one optic in optical communication with the laser source and adapted to define and direct a non-ablative laser radiation to a treatment surface of the hard dental tissue; and a conduit adapted to apply a whitening treatment to the treatment surface, wherein application of both the non-ablative laser radiation and the whitening treatment results in a ΔE measurement of at least 2.5 times greater than a treatment surface without application of the non-ablative laser radiation.
The disclosed invention relates to a system and method for treatment of a dental hard tissue. The system can include a laser source for generating a laser beam; at least one optic in optical communication with the laser source and adapted to define and direct a non-ablative laser radiation to a treatment surface of the hard dental tissue; and a conduit adapted to apply a whitening treatment to the treatment surface, wherein application of both the non-ablative laser radiation and the whitening treatment results in a ΔE measurement of at least 2.5 times greater than a treatment surface without application of the non-ablative laser radiation.
The disclosed invention relates to an improved system and method for treatment of soft tissue, e.g., for treatment of a snoring condition. The system can include a laser source; a hand piece; and a device for directing radiation emitted by the laser source to a treatment area (e.g., an oral treatment area). In some cases, the handpiece can include an optical element (e.g., a lens) mounted within a replaceable cartridge and adapted to modulate a laser beam such that it is non-ablative, prior to its delivery to a treatment region. In various embodiments, the system includes a CO2 laser capable of performing treatment in a more efficient manner than conventional techniques.
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
H01S 3/00 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet
H01S 3/223 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet caractérisés par le matériau utilisé comme milieu actif à gaz le gaz actif étant polyatomique, c.-à-d. contenant plusieurs atomes
A61B 17/00 - Instruments, dispositifs ou procédés chirurgicaux
13.
System and method for laser based treatment of soft tissue
The disclosed invention relates to an improved system and method for treatment of soft tissue, e.g., for treatment of a snoring condition. The system can include a laser source; a hand piece; and a device for directing radiation emitted by the laser source to a treatment area (e.g., an oral treatment area). In some cases, the handpiece can include an optical element (e.g., a lens) mounted within a replaceable cartridge and adapted to modulate a laser beam such that it is non-ablative, prior to its delivery to a treatment region. In various embodiments, the system includes a CO2 laser capable of performing treatment in a more efficient manner than conventional techniques.
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
H01S 3/00 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet
H01S 3/223 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet caractérisés par le matériau utilisé comme milieu actif à gaz le gaz actif étant polyatomique, c.-à-d. contenant plusieurs atomes
A61B 17/00 - Instruments, dispositifs ou procédés chirurgicaux
14.
Laser system for enhancing remineralization and strength of hard tissue
A laser-based system and method for treatment of hard tissue enhances remineralization and fluoride uptake to improve resistance to demineralization. The system can include a laser source, an optic, and a controller for controlling the laser source and/or the optic to deliver radiation to a treatment region with desirable characteristics (e.g., to remove carbonate without damaging the tissue surface). In some cases, the system includes a handpiece having an optical element (e.g., a lens) mounted within a replaceable cartridge and adapted to modulate a laser beam to render the beam non-ablative, prior to the laser beam's delivery to the treatment region. In some embodiments, treatment with the laser can be combined with a fluoride treatment for enhanced therapeutic effect.
A laser-based system and method for treatment of hard tissue enhances remineralization and fluoride uptake to improve resistance to demineralization. The system can include a laser source, an optic, and a controller for controlling the laser source and/or the optic to deliver radiation to a treatment region with desirable characteristics (e.g., to remove carbonate without damaging the tissue surface). In some cases, the system includes a handpiece having an optical element (e.g., a lens) mounted within a replaceable cartridge and adapted to modulate a laser beam to render the beam non-ablative, prior to the laser beam's delivery to the treatment region. In some embodiments, treatment with the laser can be combined with a fluoride treatment for enhanced therapeutic effect.
The disclosed invention relates to an improved system and method for treatment of soft tissue, e.g., for treatment of a snoring condition. The system can include a laser source; a hand piece; and a device for directing radiation emitted by the laser source to a treatment area (e.g., an oral treatment area). In some cases, the handpiece can include an optical element (e.g., a lens) mounted within a replaceable cartridge and adapted to modulate a laser beam such that it is non- ablative, prior to its delivery to a treatment region. In various embodiments, the system includes a C02 laser capable of performing treatment in a more efficient manner than conventional techniques.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
17.
System and method for laser based treatment of soft tissue
The disclosed invention relates to an improved system and method for treatment of soft tissue, e.g., for treatment of a snoring condition. The system can include a laser source; a hand piece; and a device for directing radiation emitted by the laser source to a treatment area (e.g., an oral treatment area). In some cases, the handpiece can include an optical element (e.g., a lens) mounted within a replaceable cartridge and adapted to modulate a laser beam such that it is non-ablative, prior to its delivery to a treatment region. In various embodiments, the system includes a CO2 laser capable of performing treatment in a more efficient manner than conventional techniques.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
H01S 3/00 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet
H01S 3/223 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet caractérisés par le matériau utilisé comme milieu actif à gaz le gaz actif étant polyatomique, c.-à-d. contenant plusieurs atomes
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
A61B 17/00 - Instruments, dispositifs ou procédés chirurgicaux
18.
System and method for treatment of periodontic pockets using disposable inserts
A system and method for dental or surgical treatment of oral tissue, the system including a laser source; a hand piece; and a device for directing radiation emitted by the laser source to a treatment area (e.g., an oral treatment area), the device further including a disposable tube attachable to the hand piece and an optical element (e.g., a substantially cylindrical lens) mounted within the disposable tube and adapted to modify a profile and/or a direction of the radiation emitted from the tube.
G02B 3/06 - Lentilles simples ou composées à surfaces non sphériques à surfaces cylindriques ou en forme de tore
H01S 3/223 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet caractérisés par le matériau utilisé comme milieu actif à gaz le gaz actif étant polyatomique, c.-à-d. contenant plusieurs atomes
19.
Systems and methods for pulsing and directing a pulsed laser beam to treat dental tissue
A laser beam treatment system that delivers laser beam pulses to a dental treatment area according to a particular pattern is described. In various instances, the spacing of the pattern (e.g., locations at which pulses are delivered and the distances therebetween) and/or the timing of the pattern (e.g., amount of time between the delivery of pulses to a first location and a later location that abuts the first location) can have a demonstrable effect on ablation performance. The effects can include, for example: improved ablation efficiency, improved surface smoothness, improved material removal rate, and/or the absence of melt, carbonization or other negative surface features.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
20.
SYSTEM AND METHOD FOR TREATMENT OF PERIODONTIC POCKETS USING DISPOSABLE INSERTS
A system and method for dental or surgical treatment of oral tissue, the system including a laser source; a hand piece; and a device for directing radiation emitted by the laser source to a treatment area (e.g., an oral treatment area), the device further including a disposable tube attachable to the hand piece and an optical element (e.g., a substantially cylindrical lens) mounted within the disposable tube and adapted to modify a profile and/or a direction of the radiation emitted from the tube.
An improved dental laser system has been developed to cut enamel quickly and precisely, without detrimental residual energy, to provide a replacement for conventional high speed rotary burrs and commercially available dental laser systems.
H01S 3/223 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet caractérisés par le matériau utilisé comme milieu actif à gaz le gaz actif étant polyatomique, c.-à-d. contenant plusieurs atomes
H01S 3/03 - Détails de structure des tubes laser à décharge dans le gaz
H01S 3/097 - Procédés ou appareils pour l'excitation, p. ex. pompage par décharge dans le gaz d'un laser à gaz
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
22.
System and methods for preventative dental hard tissue treatment with a laser
This disclosure relates to various systems and methods related to preventative laser-based treatment of a dental tissue; for example, to prevent a patient from forming cavities. In some instances, a laser-based treatment system can generate a laser beam pulse with a fluence profile at a treatment site that results in either an increase in acid resistance of the tissue or removal of carbonate from the tissue, without melting or ablating the tissue. In some instances, the laser-based treatment system can direct the laser beam to various locations within a treatment site according to a temporal and/or spatial pattern, that results in either an increase in acid resistance of the tissue or removal of carbonate from the tissue, without melting or ablating the tissue. Many other systems and techniques for preventative and other laser-based treatment are also described.
A61C 1/05 - Machines dentaires à forer ou couper caractérisées par l'entraînement des outils dentaires à commande par turbine
A61B 18/22 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers le faisceau étant dirigé le long, ou à l'intérieur d'un conduit flexible, p. ex. d'une fibre optiquePièces à main à cet effet
A61N 5/06 - Thérapie par radiations utilisant un rayonnement lumineux
A61C 19/06 - Appareils ou dispositifs pour traitement thérapeutique
A dental tissue treatment apparatus and associated methods includes a feedback-controlled beam guidance system for directing treatment to a defined area of dental tissue.
A61B 1/06 - Instruments pour procéder à l'examen médical de l'intérieur des cavités ou des conduits du corps par inspection visuelle ou photographique, p. ex. endoscopesDispositions pour l'éclairage dans ces instruments avec dispositifs d'éclairement
A61B 1/24 - Instruments pour procéder à l'examen médical de l'intérieur des cavités ou des conduits du corps par inspection visuelle ou photographique, p. ex. endoscopesDispositions pour l'éclairage dans ces instruments pour la bouche, c.-à-d. stomatoscopes, p. ex. portant des abaisse-langueInstruments pour ouvrir la bouche ou la maintenir ouverte
A61C 17/02 - Dispositifs de rinçage ou insufflateurs d'air, p. ex. utilisant des jets de fluide
A61C 9/00 - Méthodes de prise d'empreintes spécialement conçues pour les prothèses dentairesPorte-empreintes à cet effet
Improved systems and methods for performing laser based treatment of hard and soft tissues, e.g., bone, skin, and connective tissue, are described. The system can feature a laser adapted to produce a peak output power significantly higher than the output power produced by conventional laser-based dental treatment systems. In some instances, the system features high definition imagers for real-time, on-axis visualization and spatial measurement of the surgical region, which can include rendering 3D images. In some implementations, the system is adapted to deliver a laser beam polarized to align with the collagen fibers of bone tissue, to enhance cutting performance. In some implementations, the system is adapted to image the treatment region with polarized light, which can enable improved visualization of nerves and other anatomical structures.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A61B 34/20 - Systèmes de navigation chirurgicaleDispositifs pour le suivi ou le guidage d'instruments chirurgicaux, p. ex. pour la stéréotaxie sans cadre
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
Improved systems and methods for performing laser based treatment of hard and soft tissues, e.g., bone, skin, and connective tissue, are described. The system can feature a laser adapted to produce a peak output power significantly higher than the output power produced by conventional laser-based dental treatment systems. In some instances, the system features high definition imagers for real-time, on-axis visualization and spatial measurement of the surgical region, which can include rendering 3D images. In some implementations, the system is adapted to deliver a laser beam polarized to align with the collagen fibers of bone tissue, to enhance cutting performance. In some implementations, the system is adapted to image the treatment region with polarized light, which can enable improved visualization of nerves and other anatomical structures.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A61B 90/00 - Instruments, outillage ou accessoires spécialement adaptés à la chirurgie ou au diagnostic non couverts par l'un des groupes , p. ex. pour le traitement de la luxation ou pour la protection de bords de blessures
A61B 34/20 - Systèmes de navigation chirurgicaleDispositifs pour le suivi ou le guidage d'instruments chirurgicaux, p. ex. pour la stéréotaxie sans cadre
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
26.
System and methods for preventative dental hard tissue treatment with a laser
This disclosure relates to various systems and methods related to preventative laser-based treatment of a dental tissue; for example, to prevent a patient from forming cavities. In some instances, a laser-based treatment system can generate a laser beam pulse with a fluence profile at a treatment site that results in either an increase in acid resistance of the tissue or removal of carbonate from the tissue, without melting or ablating the tissue. In some instances, the laser-based treatment system can direct the laser beam to various locations within a treatment site according to a temporal and/or spatial pattern, that results in either an increase in acid resistance of the tissue or removal of carbonate from the tissue, without melting or ablating the tissue. Many other systems and techniques for preventative and other laser-based treatment are also described.
A61B 18/22 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers le faisceau étant dirigé le long, ou à l'intérieur d'un conduit flexible, p. ex. d'une fibre optiquePièces à main à cet effet
A61N 5/06 - Thérapie par radiations utilisant un rayonnement lumineux
A61C 19/06 - Appareils ou dispositifs pour traitement thérapeutique
This disclosure relates to various systems and methods related to preventative laser-based treatment of a dental tissue; for example, to prevent a patient from forming cavities. In some instances, a laser-based treatment system can generate a laser beam pulse with a fluence profile at a treatment site that results in either an increase in acid resistance of the tissue or removal of carbonate from the tissue, without melting or ablating the tissue. In some instances, the laser- based treatment system can direct the laser beam to various locations within a treatment site according to a temporal and/or spatial pattern, that results in either an increase in acid resistance of the tissue or removal of carbonate from the tissue, without melting or ablating the tissue. Many other systems and techniques for preventative and other laser-based treatment are also described.
A dental laser treatment system includes a treatment laser beam and a pilot (e.g., aiming/marking) laser beam sharing a collinear beam path, where the beam path is guided by a guidance system through a handpiece/main chamber assembly having a beam exit. A laser beam presence detector is removably affixed to or within the handpiece/main chamber assembly. The laser beam presence detector provides feedback to a computer which can control actuation of the treatment laser beam and the pilot laser beam, and the beam guidance system. The computer performs a search for determining the center location of the beam exit based on the feedback and controls the beam guidance system to guide the beam path approximately to the center of the beam exit, thereby providing automatic alignment of the laser beam with the beam exit or an optional hollow waveguide.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
G02B 7/00 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques
G02B 26/08 - Dispositifs ou dispositions optiques pour la commande de la lumière utilisant des éléments optiques mobiles ou déformables pour commander la direction de la lumière
H01S 3/00 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
A61C 1/08 - Éléments de machines spécialement adaptés à la chirurgie dentaire
29.
Laser based computer controlled dental preparation system
A dental tissue treatment apparatus and associated methods includes a feedback-controlled beam guidance system for directing treatment to a defined area of dental tissue.
A61B 1/06 - Instruments pour procéder à l'examen médical de l'intérieur des cavités ou des conduits du corps par inspection visuelle ou photographique, p. ex. endoscopesDispositions pour l'éclairage dans ces instruments avec dispositifs d'éclairement
A61B 1/24 - Instruments pour procéder à l'examen médical de l'intérieur des cavités ou des conduits du corps par inspection visuelle ou photographique, p. ex. endoscopesDispositions pour l'éclairage dans ces instruments pour la bouche, c.-à-d. stomatoscopes, p. ex. portant des abaisse-langueInstruments pour ouvrir la bouche ou la maintenir ouverte
A61C 17/02 - Dispositifs de rinçage ou insufflateurs d'air, p. ex. utilisant des jets de fluide
30.
Systems and methods for pulsing and directing a pulsed laser beam to treat dental tissue
A laser beam treatment system that delivers laser beam pulses to a dental treatment area according to a particular pattern is described. In various instances, the spacing of the pattern (e.g., locations at which pulses are delivered and the distances therebetween) and/or the timing of the pattern (e.g., amount of time between the delivery of pulses to a first location and a later location that abuts the first location) can have a demonstrable effect on ablation performance. The effects can include, for example: improved ablation efficiency, improved surface smoothness, improved material removal rate, and/or the absence of melt, carbonization or other negative surface features.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
31.
SYSTEMS AND METHODS FOR PULSING AND DIRECTING A PULSED LASER BEAM TO TREAT DENTAL TISSUE
A laser beam treatment system that delivers laser beam pulses to a dental treatment area according to a particular pattern is described. In various instances, the spacing of the pattern (e.g., locations at which pulses are delivered and the distances therebetween) and/or the timing of the pattern (e.g., amount of time between the delivery of pulses to a first location and a later location that abuts the first location) can have a demonstrable effect on ablation performance. The effects can include, for example: improved ablation efficiency, improved surface smoothness, improved material removal rate, and/or the absence of melt, carbonization or other negative surface features.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A dental laser treatment system includes a treatment laser beam and a pilot (e.g., aiming/marking) laser beam sharing a collinear beam path, where the beam path is guided by a guidance system through a handpiece/main chamber assembly having a beam exit. A laser beam presence detector is removably affixed to or within the handpiece/main chamber assembly. The laser beam presence detector provides feedback to a computer which can control actuation of the treatment laser beam and the pilot laser beam, and the beam guidance system. The computer performs a search for determining the center location of the beam exit based on the feedback and controls the beam guidance system to guide the beam path approximately to the center of the beam exit, thereby providing automatic alignment of the laser beam with the beam exit or an optional hollow waveguide.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
A dental laser treatment system includes a treatment laser beam and a pilot (e.g., aiming/marking) laser beam sharing a collinear beam path, where the beam path is guided by a guidance system through a handpiece/main chamber assembly having a beam exit. A laser beam presence detector is removably affixed to or within the handpiece/main chamber assembly. The laser beam presence detector provides feedback to a computer which can control actuation of the treatment laser beam and the pilot laser beam, and the beam guidance system. The computer performs a search for determining the center location of the beam exit based on the feedback and controls the beam guidance system to guide the beam path approximately to the center of the beam exit, thereby providing automatic alignment of the laser beam with the beam exit or an optional hollow waveguide.
A61C 3/02 - Instruments à forer ou couperInstruments agissant à la façon d'une décapeuse au jet de sable
G02B 7/00 - Montures, moyens de réglage ou raccords étanches à la lumière pour éléments optiques
G02B 26/08 - Dispositifs ou dispositions optiques pour la commande de la lumière utilisant des éléments optiques mobiles ou déformables pour commander la direction de la lumière
H01S 3/00 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A61C 1/08 - Éléments de machines spécialement adaptés à la chirurgie dentaire
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
34.
SYSTEMS AND METHODS TO CONTROL DEPTH OF TREATMENT IN DENTAL LASER SYSTEMS
A dental laser treatment system (10) may include a laser source (11) providing a laser beam (12), and a focusing device (24) to produce a laser beam having a waist (14). The focal length and waist (14) of the laser beam (12) are selected to achieve a depth of treatment that is at least 5 mm long, and has a power density of at least a minimum power density required to perform a selected treatment on dental tissue. In some instances, the focal length is 25 mm or greater.
A dental laser system (12) is configured to provide high peak laser power, low duty cycle laser pulses, yielding a low average laser power and thus a reduced need for cooling. The laser power system may be configured to provide the electrical power required to produce the low average laser power and not the high peak laser power, and may include a capacitor bank section having at least one capacitor (50) configured to provide the electrical power needed to produce the high peak power laser pulses. The capacitors (50) are charged by a power supply comprising an AC filter (42) for removing noise and an AC-DC converter (44) charging the capacitors. At least 75% of the electrical power supplied to the laser should be delivered by the capacitors, the remainder directly from the AC-DC converter. The electrical power is supplied to the laser (12) by twisted lines (52,54) in order to reduce noise. The cooling system may be configured to provide laser cooling for the low average power level and thus may not require a refrigeration unit.
H01S 3/097 - Procédés ou appareils pour l'excitation, p. ex. pompage par décharge dans le gaz d'un laser à gaz
H01S 3/041 - Dispositions pour la gestion thermique pour des lasers à gaz
H01S 3/0971 - Procédés ou appareils pour l'excitation, p. ex. pompage par décharge dans le gaz d'un laser à gaz excité transversalement
H01S 3/104 - Commande de l'intensité, de la fréquence, de la phase, de la polarisation ou de la direction du rayonnement, p. ex. commutation, ouverture de porte, modulation ou démodulation par commande du milieu actif, p. ex. par commande des procédés ou des appareils pour l'excitation dans des lasers à gaz
H01S 3/223 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet caractérisés par le matériau utilisé comme milieu actif à gaz le gaz actif étant polyatomique, c.-à-d. contenant plusieurs atomes
H01S 3/03 - Détails de structure des tubes laser à décharge dans le gaz
H01S 3/04 - Dispositions pour la gestion thermique
A dental laser treatment system may include a laser source providing a laser beam, and a focusing device to produce a laser beam having a waist. The focal length and waist of the laser beam are selected to achieve a depth of treatment that is at least 5 mm long, and has a power density of at least a minimum power density required to perform a selected treatment on dental tissue. In some instances, the focal length is 25 mm or greater.
A dental laser system is configured to provide high peak laser power, low duty cycle laser pulses, yielding a low average laser power and thus a reduced need for cooling. The laser power system may be configured to provide the electrical power required to produce the low average laser power and not the high peak laser power, and may include a capacitor bank section configured to provide the electrical power needed to produce the high peak power laser pulses. The cooling system may be configured to provide laser cooling for the low average power level and thus may not require a refrigeration unit.
H01S 3/00 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet
H01S 3/102 - Commande de l'intensité, de la fréquence, de la phase, de la polarisation ou de la direction du rayonnement, p. ex. commutation, ouverture de porte, modulation ou démodulation par commande du milieu actif, p. ex. par commande des procédés ou des appareils pour l'excitation
H01S 3/223 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet caractérisés par le matériau utilisé comme milieu actif à gaz le gaz actif étant polyatomique, c.-à-d. contenant plusieurs atomes
H01S 3/04 - Dispositions pour la gestion thermique
H01S 3/041 - Dispositions pour la gestion thermique pour des lasers à gaz
H01S 3/10 - Commande de l'intensité, de la fréquence, de la phase, de la polarisation ou de la direction du rayonnement, p. ex. commutation, ouverture de porte, modulation ou démodulation
H01S 3/0975 - Procédés ou appareils pour l'excitation, p. ex. pompage par décharge dans le gaz d'un laser à gaz utilisant une excitation inductive ou capacitive
H01S 3/097 - Procédés ou appareils pour l'excitation, p. ex. pompage par décharge dans le gaz d'un laser à gaz
H01S 3/0971 - Procédés ou appareils pour l'excitation, p. ex. pompage par décharge dans le gaz d'un laser à gaz excité transversalement
H01S 3/104 - Commande de l'intensité, de la fréquence, de la phase, de la polarisation ou de la direction du rayonnement, p. ex. commutation, ouverture de porte, modulation ou démodulation par commande du milieu actif, p. ex. par commande des procédés ou des appareils pour l'excitation dans des lasers à gaz
H01S 3/03 - Détails de structure des tubes laser à décharge dans le gaz
38.
Systems and method for protection of optical system of laser-based apparatus
In an apparatus for directing a laser beam to a dental treatment area, where the apparatus includes a hand piece having an optical subsystem including a turning mirror for directing a laser beam to a treatment area via an orifice of the hand piece, a fluid supply subsystem creates a fluid flow within the hand piece proximate the turning mirror so as to mitigate contamination thereof.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
39.
Dental laser apparatus and method of use with interchangeable hand piece and variable foot pedal
A dental laser system for treatment of hard and/or soft tissue includes a main chamber housing optical and primary fluid supply subsystems, for directing a laser beam and fluid to a treatment area. A hand piece affixable to the main chamber, includes mating optical and secondary fluid supply subsystems. The hand piece can be rotatable or re-orientable about an optical axis within the hand piece. A lock can maintain a selectable angular orientation of the hand piece relative to the main chamber. A coupling can maintain a fluidic communication between the primary and secondary fluid supply subsystems even when the hand piece is rotated or re-oriented. A sensor and controller can sense a selected angular orientation of the hand piece and adjust the main optical subsystem according to the sensed angular orientation, to align the two optical subsystems. The laser may be controlled using a variable speed foot pedal.
An electrically safe treatment system for use in treating a patient includes two or more sections coupled with a joint that permits any one section to rotate relative to another coupled section. At least one of the sections includes an electrical component. An electrical contact associated with the joint is designed to maintain an electrical connection between a pair of sections throughout an angular range of motion of one of the sections relative to the other, coupled section. The electrical contact can also maintain a total resistance of a series connection including the two sections and the contact below a specified threshold. Alternatively, one or more insulator joints may be employed to meet safety requirements.
A61C 1/06 - Machines dentaires à forer ou couper caractérisées par l'entraînement des outils dentaires à commande électrique
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
41.
SYSTEM AND METHOD FOR TREATMENT USING A LASER BEAM DELIVERED VIA AN OPTICAL FIBER
A laser system can efficiently direct a laser beam to a treatment area via an optical fiber. The laser beam is produced using a CO2 laser that has a wavelength greater than about 9 μιη and less than about 10 μιη. The optical fiber, which can be a solid core fiber, includes chalcogenide glass. The chalcogenide glass is adapted to minimize transmission losses at wavelengths in a range from about 9 μιη up to about 10 μιη. One or more laser beam parameters can be controlled at least according to a selected treatment using a controller. A visible-spectrum and/or fluorescing optical fiber may be physically but not optically coupled to the chalcogenide fiber.
A61B 18/22 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers le faisceau étant dirigé le long, ou à l'intérieur d'un conduit flexible, p. ex. d'une fibre optiquePièces à main à cet effet
G02B 6/10 - Guides de lumièreDétails de structure de dispositions comprenant des guides de lumière et d'autres éléments optiques, p. ex. des moyens de couplage du type guide d'ondes optiques
A61N 5/06 - Thérapie par radiations utilisant un rayonnement lumineux
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
C03C 13/04 - Fibres optiques, p. ex. compositions pour le cœur et la gaine de fibres
(1) Laser based system comprised of a modified CO2 laser for computer assisted preparation of hard and soft oral tissues for a variety of restorative and preventative dental procedures.
(1) Laser based system comprised of a modified CO2 laser for computer assisted preparation of hard and soft oral tissues for a variety of restorative and preventative dental procedures
Laser based system comprised of a modified CO2 laser for computer assisted preparation of hard and soft oral tissues for a variety of restorative and preventative dental procedures.
45.
COATED MIRRORS FOR USE IN LASER-BASED DENTAL TREATMENT SYSTEMS AND METHODS OF MAKING SUCH MIRRORS
A reflective device disposable within a hand piece or other housing for directing a laser beam toward a treatment area includes a substrate, a first layer above the substrate, and a second layer above the first layer, and lacks a reflective dielectric layer. The second layer may have a hardness of at least about 120 Knoop, and the combination of transmissive and reflective properties in the first layer and the second layer can provide reflection of light wavelengths ranging from about 380 nm to about 12,000 nm. Reflective devices according to other constructions are also described.
An electrically safe treatment system for use in treating a patient includes two or more sections coupled with a joint that permits any one section to rotate relative to another coupled section. At least one of the sections includes an electrical component. An electrical contact associated with the joint is designed to maintain an electrical connection between a pair of sections throughout an angular range of motion of one of the sections relative to the other, coupled section. The electrical contact can also maintain a total resistance of a series connection including the two sections and the contact below a specified threshold. Alternatively, one or more insulator joints may be employed to meet safety requirements.
A61C 1/06 - Machines dentaires à forer ou couper caractérisées par l'entraînement des outils dentaires à commande électrique
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
47.
SYSTEMS AND METHOD FOR PROTECTION OF OPTICAL SYSTEM OF LASER-BASED APPARATUS
In an apparatus for directing a laser beam to a dental treatment area, where the apparatus includes a hand piece having an optical subsystem including a turning mirror for directing a laser beam to a treatment area via an orifice of the hand piece, a fluid supply subsystem creates a fluid flow within the hand piece proximate the turning mirror so as to mitigate contamination thereof.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
48.
SYSTEMS AND METHODS FOR GROUNDING OR ISOLATING A DENTAL HAND PIECE
An electrically safe treatment system for use in treating a patient includes two or more sections coupled with a joint that permits any one section to rotate relative to another coupled section. At least one of the sections includes an electrical component. An electrical contact associated with the joint is designed to maintain an electrical connection between a pair of sections throughout an angular range of motion of one of the sections relative to the other, coupled section. The electrical contact can also maintain a total resistance of a series connection including the two sections and the contact below a specified threshold. Alternatively, one or more insulator joints may be employed to meet safety requirements.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
Laser based system comprised of a modified CO2 laser for computer assisted preparation of hard and soft oral tissues for a variety of restorative and preventative dental procedures
50.
Dental laser apparatus and method of use with interchangeable hand piece and variable foot pedal
A dental laser system for treatment of hard and/or soft tissue includes a main chamber housing optical and primary fluid supply subsystems, for directing a laser beam and fluid to a treatment area. A hand piece affixable to the main chamber, includes mating optical and secondary fluid supply subsystems. The hand piece can be rotatable or re-orientable about an optical axis within the hand piece. A lock can maintain a selectable angular orientation of the hand piece relative to the main chamber. A coupling can maintain a fluidic communication between the primary and secondary fluid supply subsystems even when the hand piece is rotated or re-oriented. A sensor and controller can sense a selected angular orientation of the hand piece and adjust the main optical subsystem according to the sensed angular orientation, to align the two optical subsystems. The laser may be controlled using a variable speed foot pedal.
A61B 18/18 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes
A device for determining a contour of a dental treatment area during treatment thereof includes a laser beam guidance system and an imaging system. The laser beam guidance system can guide a laser beam and, optionally, a scanning light to a dental treatment area, and the imaging system, which can include an adjustable focus image sensor, can obtain an image of the dental treatment area based on light rays reflected therefrom. The device also includes a computation system to compute a contour, e.g., a 2D contour, of a surface of the dental treatment area based on the image obtained by the imaging system and, optionally, geometries of one or more components of the laser beam guidance system and/or optical components associated with the imaging system.
A device for determining a contour of a dental treatment area during treatment thereof includes a laser beam guidance system and an imaging system. The laser beam guidance system can guide a laser beam and, optionally, a scanning light to a dental treatment area, and the imaging system, which can include an adjustable focus image sensor, can obtain an image of the dental treatment area based on light rays reflected therefrom. The device also includes a computation system to compute a contour, e.g., a 2D contour, of a surface of the dental treatment area based on the image obtained by the imaging system and, optionally, geometries of one or more components of the laser beam guidance system and/or optical components associated with the imaging system.
A61B 5/00 - Mesure servant à établir un diagnostic Identification des individus
A61B 5/107 - Mesure de dimensions corporelles, p. ex. la taille du corps entier ou de parties de celui-ci
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
53.
SYSTEM AND METHOD FOR OPTICAL IMAGING, MAGNIFICATION, FLUORESCENCE, AND REFLECTANCE
A laser-based dental treatment system also provides for imaging of the treatment area during treatment thereof, without requiring the operator to switch between different devices. A laser beam delivery subsystem and an imaging system are coupled such that at least a portion of the path along which the light reflected from the treatment area propagates towards the imaging system is substantially the same as at least a portion of the path along which the laser beam propagates. Optionally, an illumination system that can direct light to a candidate treatment area for diagnosis thereof, and/or to provide adequate light to the treatment area for imaging, is also be integrated with the treatment system.
A dental laser system for treatment of hard and/or soft tissue includes a main chamber housing optical and primary fluid supply subsystems, for directing a laser beam and fluid to a treatment area. A hand piece affixable to the main chamber, includes mating optical and secondary fluid supply subsystems. The hand piece can be rotatable or re-orientable about an optical axis within the hand piece. A lock can maintain a selectable angular orientation of the hand piece relative to the main chamber. A coupling can maintain a fluidic communication between the primary and secondary fluid supply subsystems even when the hand piece is rotated or re¬ oriented. A sensor and controller can sense a selected angular orientation of the hand piece and adjust the main optical subsystem according to the sensed angular orientation, to align the two optical subsystems. The laser may be controlled using a variable speed foot pedal.
A dental tissue treatment apparatus and associated methods includes a feedback-controlled beam guidance system for directing treatment to a defined area of dental tissue.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A61B 1/06 - Instruments pour procéder à l'examen médical de l'intérieur des cavités ou des conduits du corps par inspection visuelle ou photographique, p. ex. endoscopesDispositions pour l'éclairage dans ces instruments avec dispositifs d'éclairement
A61B 1/24 - Instruments pour procéder à l'examen médical de l'intérieur des cavités ou des conduits du corps par inspection visuelle ou photographique, p. ex. endoscopesDispositions pour l'éclairage dans ces instruments pour la bouche, c.-à-d. stomatoscopes, p. ex. portant des abaisse-langueInstruments pour ouvrir la bouche ou la maintenir ouverte
A61C 17/02 - Dispositifs de rinçage ou insufflateurs d'air, p. ex. utilisant des jets de fluide
A61C 9/00 - Méthodes de prise d'empreintes spécialement conçues pour les prothèses dentairesPorte-empreintes à cet effet
56.
Apparatus and method for controlled fluid cooling during laser based dental treatments
A system for dental tissue treatment includes a system for directing a laser beam to an area of dental tissue to be treated, and a fluid-delivery system for directing and controlling a flow of a fluid. The fluid is directed to at least a portion of the area to be treated and the fluid flow is controlled to substantially prevent both a change in laser energy absorption by the dental tissue and attenuation of treatment efficiency due to fluid interference with the laser beam. The fluid present in at least a portion of the area to be treated may prevent or reduce the likelihood of melting of enamel in that area.
A system for dental tissue treatment includes a system for directing a laser beam to an area of dental tissue to be treated, and a fluid-delivery system for directing and controlling a flow of a fluid. The fluid is directed to at least a portion of the area to be treated and the fluid flow is controlled to substantially prevent both a change in laser energy absorption by the dental tissue and attenuation of treatment efficiency due to fluid interference with the laser beam. The fluid present in at least a portion of the area to be treated may prevent or reduce the likelihood of melting of enamel in that area.
A system for dental tissue treatment includes a system for directing a laser beam to an area of dental tissue to be treated, and a fluid-delivery system for directing and controlling a flow of a fluid. The fluid is directed to at least a portion of the area to be treated and the fluid flow is controlled to substantially prevent both a change in laser energy absorption by the dental tissue and attenuation of treatment efficiency due to fluid interference with the laser beam. The fluid present in at least a portion of the area to be treated may prevent or reduce the likelihood of melting of enamel in that area.
A system for dental tissue treatment includes a system for directing a laser beam to an area of dental tissue to be treated, and a fluid-delivery system for directing and controlling a flow of a fluid. The fluid is directed to at least a portion of the area to be treated and the fluid flow is controlled to substantially prevent both a change in laser energy absorption by the dental tissue and attenuation of treatment efficiency due to fluid interference with the laser beam. The fluid present in at least a portion of the area to be treated may prevent or reduce the likelihood of melting of enamel in that area.
A dental tissue treatment apparatus and associated methods includes a feedback-controlled beam guidance system for directing treatment to a defined area of dental tissue.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A61B 1/06 - Instruments pour procéder à l'examen médical de l'intérieur des cavités ou des conduits du corps par inspection visuelle ou photographique, p. ex. endoscopesDispositions pour l'éclairage dans ces instruments avec dispositifs d'éclairement
A61B 1/24 - Instruments pour procéder à l'examen médical de l'intérieur des cavités ou des conduits du corps par inspection visuelle ou photographique, p. ex. endoscopesDispositions pour l'éclairage dans ces instruments pour la bouche, c.-à-d. stomatoscopes, p. ex. portant des abaisse-langueInstruments pour ouvrir la bouche ou la maintenir ouverte
A61C 17/02 - Dispositifs de rinçage ou insufflateurs d'air, p. ex. utilisant des jets de fluide
A61C 9/00 - Méthodes de prise d'empreintes spécialement conçues pour les prothèses dentairesPorte-empreintes à cet effet
61.
LASER BASED COMPUTER CONTROLLED DENTAL PREPARATION SYSTEM
A dental tissue treatment apparatus and associated methods includes a feedback- controlled beam guidance system for directing treatment to a defined area of dental tissue.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
40 - Traitement de matériaux; recyclage, purification de l'air et traitement de l'eau
42 - Services scientifiques, technologiques et industriels, recherche et conception
Produits et services
Sale of products in the field of laser based systems for computer assisted dental procedures. Manufacture of products in the field of laser based systems for computer assisted dental procedures. Development of products in the field of laser based systems for computer assisted dental procedures.
Laser based system comprised of a modified CO2 laser for computer assisted preparation of hard and soft oral tissues for a variety of restorative and preventative dental procedures
An improved dental laser system has been developed to cut enamel quickly and precisely, without detrimental residual energy, to provide a replacement for conventional high speed rotary burrs and commercially available dental laser systems.
H01S 3/223 - Lasers, c.-à-d. dispositifs utilisant l'émission stimulée de rayonnement électromagnétique dans la gamme de l’infrarouge, du visible ou de l’ultraviolet caractérisés par le matériau utilisé comme milieu actif à gaz le gaz actif étant polyatomique, c.-à-d. contenant plusieurs atomes
H01S 3/03 - Détails de structure des tubes laser à décharge dans le gaz
H01S 3/097 - Procédés ou appareils pour l'excitation, p. ex. pompage par décharge dans le gaz d'un laser à gaz
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
2 waveguide or slab resonator laser filled to a gas at a pressure between about 260 to 600 Torr (or about 34,700-80,000 Pa), and a beam delivery system to steer the beam from the output of the laser to the mouth, such as the patient's mouth.
A61B 18/18 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes
68.
DENTAL LASER APPARATUS AND METHOD OF USE WITH INTERCHANGEABLE HAND PIECE AND VARIABLE FOOT PEDAL
A dental laser system for treatment of hard and/or soft tissue includes a main chamber housing optical and primary fluid supply subsystems, for directing a laser beam and fluid to a treatment area. A hand piece affixable to the main chamber, includes mating optical and secondary fluid supply subsystems. The hand piece can be rotatable or re-orientable about an optical axis within the hand piece. A lock can maintain a selectable angular orientation of the hand piece relative to the main chamber. A coupling can maintain a fluidic communication between the primary and secondary fluid supply subsystems even when the hand piece is rotated or re¬ oriented. A sensor and controller can sense a selected angular orientation of the hand piece and adjust the main optical subsystem according to the sensed angular orientation, to align the two optical subsystems. The laser may be controlled using a variable speed foot pedal.
An improved dental laser system has been developed to cut enamel quickly and precisely, without detrimental residual energy, to provide a replacement for conventional high speed rotary burrs and commercially available dental laser systems.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A dental tissue treatment apparatus and associated methods includes a feedback- controlled beam guidance system for directing treatment to a defined area of dental tissue.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
An electrically safe treatment system for use in treating a patient includes two or more sections coupled with a joint that permits any one section to rotate relative to another coupled section. At least one of the sections includes an electrical component. An electrical contact associated with the joint is designed to maintain an electrical connection between a pair of sections throughout an angular range of motion of one of the sections relative to the other, coupled section. The electrical contact can also maintain a total resistance of a series connection including the two sections and the contact below a specified threshold. Alternatively, one or more insulator joints may be employed to meet safety requirements.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A dental laser treatment system (10) may include a laser source (11) providing a laser beam (12), and a focusing device (24) to produce a laser beam having a waist (14). The focal length and waist (14) of the laser beam (12) are selected to achieve a depth of treatment that is at least 5 mm long, and has a power density of at least a minimum power density required to perform a selected treatment on dental tissue. In some instances, the focal length is 25 mm or greater.
A laser beam treatment system that delivers laser beam pulses to a dental treatment area according to a particular pattern is described. In various instances, the spacing of the pattern (e.g., locations at which pulses are delivered and the distances therebetween) and/or the timing of the pattern (e.g., amount of time between the delivery of pulses to a first location and a later location that abuts the first location) can have a demonstrable effect on ablation performance. The effects can include, for example: improved ablation efficiency, improved surface smoothness, improved material removal rate, and/or the absence of melt, carbonization or other negative surface features.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
Improved systems and methods for performing laser based treatment of hard and soft tissues, e.g., bone, skin, and connective tissue, are described. The system can feature a laser adapted to produce a peak output power significantly higher than the output power produced by conventional laser-based dental treatment systems. In some instances, the system features high definition imagers for real-time, on-axis visualization and spatial measurement of the surgical region, which can include rendering 3D images. In some implementations, the system is adapted to deliver a laser beam polarized to align with the collagen fibers of bone tissue, to enhance cutting performance. In some implementations, the system is adapted to image the treatment region with polarized light, which can enable improved visualization of nerves and other anatomical structures.
A61B 18/00 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A61B 34/20 - Systèmes de navigation chirurgicaleDispositifs pour le suivi ou le guidage d'instruments chirurgicaux, p. ex. pour la stéréotaxie sans cadre
75.
SYSTEM AND METHOD FOR TREATMENT OF PERIODONTIC POCKETS USING DISPOSABLE INSERTS
A system and method for dental or surgical treatment of oral tissue, the system including a laser source; a hand piece; and a device for directing radiation emitted by the laser source to a treatment area (e.g., an oral treatment area), the device further including a disposable tube attachable to the hand piece and an optical element (e.g., a substantially cylindrical lens) mounted within the disposable tube and adapted to modify a profile and/or a direction of the radiation emitted from the tube.
A laser-based system and method for treatment of hard tissue enhances remineralization and fluoride uptake to improve resistance to demineralization. The system can include a laser source, an optic, and a controller for controlling the laser source and/or the optic to deliver radiation to a treatment region with desirable characteristics (e.g., to remove carbonate without damaging the tissue surface). In some cases, the system includes a handpiece having an optical element (e.g., a lens) mounted within a replaceable cartridge and adapted to modulate a laser beam to render the beam non-ablative, prior to the laser beam's delivery to the treatment region. In some embodiments, treatment with the laser can be combined with a fluoride treatment for enhanced therapeutic effect.
The disclosed invention relates to a system and method for treatment of a dental hard tissue. The system can include a laser source for generating a laser beam; at least one optic in optical communication with the laser source and adapted to define and direct a non-ablative laser radiation to a treatment surface of the hard dental tissue; and a conduit adapted to apply a whitening treatment to the treatment surface, wherein application of both the non-ablative laser radiation and the whitening treatment results in a AE measurement of at least 2.5 times greater than a treatment surface without application of the non-ablative laser radiation.
A61C 5/40 - Instruments pour le traitement chirurgical des racines ou des nerfs dentairesAiguilles pour retirer le nerfProcédés ou instruments pour le traitement des racines
A dental laser treatment system includes a treatment laser beam and a pilot (e.g., aiming/marking) laser beam sharing a collinear beam path, where the beam path is guided by a guidance system through a handpiece/main chamber assembly having a beam exit. A laser beam presence detector is removably affixed to or within the handpiece/main chamber assembly. The laser beam presence detector provides feedback to a computer which can control actuation of the treatment laser beam and the pilot laser beam, and the beam guidance system. The computer performs a search for determining the center location of the beam exit based on the feedback and controls the beam guidance system to guide the beam path approximately to the center of the beam exit, thereby providing automatic alignment of the laser beam with the beam exit or an optional hollow waveguide.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
A system for dental tissue treatment includes a system for directing a laser beam to an area of dental tissue to be treated, and a fluid-delivery system for directing and controlling a flow of a fluid. The fluid is directed to at least a portion of the area to be treated and the fluid flow is controlled to substantially prevent both a change in laser energy absorption by the dental tissue and attenuation of treatment efficiency due to fluid interference with the laser beam. The fluid present in at least a portion of the area to be treated may prevent or reduce the likelihood of melting of enamel in that area.
A device for determining a contour of a dental treatment area during treatment thereof includes a laser beam guidance system and an imaging system. The laser beam guidance system can guide a laser beam and, optionally, a scanning light to a dental treatment area, and the imaging system, which can include an adjustable focus image sensor, can obtain an image of the dental treatment area based on light rays reflected therefrom. The device also includes a computation system to compute a contour, e.g., a 2D contour, of a surface of the dental treatment area based on the image obtained by the imaging system and, optionally, geometries of one or more components of the laser beam guidance system and/or optical components associated with the imaging system.
A61B 5/00 - Mesure servant à établir un diagnostic Identification des individus
A61B 5/107 - Mesure de dimensions corporelles, p. ex. la taille du corps entier ou de parties de celui-ci
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
The disclosed invention relates to an improved system and method for treatment of soft tissue, e.g., for treatment of a snoring condition. The system can include a laser source; a hand piece; and a device for directing radiation emitted by the laser source to a treatment area (e.g., an oral treatment area). In some cases, the handpiece can include an optical element (e.g., a lens) mounted within a replaceable cartridge and adapted to modulate a laser beam such that it is non- ablative, prior to its delivery to a treatment region. In various embodiments, the system includes a C02 laser capable of performing treatment in a more efficient manner than conventional techniques.
A61B 18/20 - Instruments, dispositifs ou procédés chirurgicaux pour transférer des formes non mécaniques d'énergie vers le corps ou à partir de celui-ci par application de radiations électromagnétiques, p. ex. de micro-ondes en utilisant des lasers
