Abrégé

The present disclosure relates to a barrier system for shielding humans from harmful exposure to fire, smoke, noxious fumes, or contaminated air. Some embodiments provide a deployable barrier system that has a barrier retract assist system configured to assist a user in manually moving the barrier from the deployed position toward the retracted position with at least a portion of the barrier being rolled onto the barrel portion for egress past the barrier. The retract assist system can be positioned inside of the barrel portion.

Classes IPC  ?

• E06B 9/13 - Volets à rouleau avec des éléments de fermeture en une seule pièce, p. ex. en tôle ondulée
• A62C 2/10 - Rideaux à l'épreuve du feu
• E06B 9/58 - Dispositifs de guidage
• E06B 9/60 - Tambours à ressorts actionnés uniquement par des éléments de fermeture
• E06B 9/11 - Volets à rouleau

Produits et services

Smoke-rated curtain assembly specially adapted for elevators

Abrégé

A barrier assembly comprising a horizontally deployable vapor barrier assembly with a frame with opposing side guides extending between a header and footer. A guide rod contained in each side guide extends between the header and the footer. A vapor barrier is deployable horizontally with side edge sleeve portions that slide axially over the guide rods. At least one roller is connected to each of the side guides adjacent to the guide rod, and each roller supports a portion of the vapor barrier's side edge portions. The rollers rolls on the edge portions as the sleeve portion slides axially over the guide rods as the vapor barrier moves between the deployed and stowed positions. Lifter plates are attached to each of the side guides and positioned to engage support carriages and temporarily lift the support member out of engagement with the support surface over segment joints as the vapor barrier moves between the stowed and deployed positions. A drive system moves the vapor barrier between the stowed and deployed positions.

Classes IPC  ?

• A62C 2/18 - Coupe-feu coulissants
• E06B 1/04 - Chambranles de portes, fenêtres ou analogues à fixer dans les ouvertures
• A62C 2/24 - Mécanismes de commande ou d'actionnement
• E06B 9/58 - Dispositifs de guidage
• E06B 9/70 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique comportant un moteur électrique disposé à l'extérieur du rouleau

Abrégé

A multi-segmented, multi-plane, vertically deployable vapor and/or fire barrier assembly with a housing, a drive system, a folding barrier, a bottom plate, and motion sensors coupled to the bottom plate and coupled to a control system to detect operation and performance of the assembly, and related methods.

Classes IPC  ?

• A62C 2/10 - Rideaux à l'épreuve du feu
• A62C 2/06 - Barrières coupe-feu
• A62C 2/08 - Rideaux d'eau

Abrégé

A multi-segmented, multi-plane, vertically deployable vapor and/or fire barrier assembly with a housing, a drive system, a folding barrier, a bottom plate, and motion sensors coupled to the bottom plate and coupled to a control system to detect operation and performance of the assembly, and related methods.

Classes IPC  ?

• E06B 9/70 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique comportant un moteur électrique disposé à l'extérieur du rouleau

Produits et services

Fire containment curtain systems comprised of filament fiberglass fire curtains, electric motors, electric switches, and metal structural housings and installation hardware, the foregoing goods sold as a unit and used in buildings to control the movement of fire and smoke

Abrégé

Barrier systems and associated methods, including vapor and/or fire barrier systems, are disclosed herein. One aspect of the invention is directed toward a barrier system that includes a barrier coupled to a spool. The barrier is positioned to be wound onto and off of the spool as the barrier moves between a deployed position and a retracted position by a drive assembly. The system further includes a control system coupled to the drive assembly and configured to command operation of the drive assembly. The system still further includes a sensor operably coupled to the control system and positioned to sense barrier position as the barrier moves between the deployed and the retracted positions.

Classes IPC  ?

• E06B 9/70 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique comportant un moteur électrique disposé à l'extérieur du rouleau

Abrégé

The subject invention comprises a flexible multilayer fire-rated material that has at least one layer of an intumescent material. Because it is flexible, the fire- rated material is usable in situations where it is desirable for the fire-rated material to be rolled up or folded into a non-flat storage application. This allows the subject fire- rated material to be used in fire-rated and smoke-resistant barriers that are recessed in walls or ceilings until use. One end use embodiment includes without limitation, recessed or rolled up fabrics used in elevator lobby ceilings to seal off elevators or their lobbies from smoke or fire.

Classes IPC  ?

• A62C 2/10 - Rideaux à l'épreuve du feu

Abrégé

Barrier systems and associated methods, including vapor and/or fire barrier systems, are disclosed herein. One aspect of the invention is directed toward a barrier system that includes a barrier coupled to a spool. The barrier is positioned to be wound onto and off of the spool as the barrier moves between a deployed position and a retracted position by a drive assembly. The system further includes a control system coupled to the drive assembly and configured to command operation of the drive assembly. The system still further includes a sensor operably coupled to the control system and positioned to sense barrier position as the barrier moves between the deployed and the retracted positions.

Classes IPC  ?

• E06B 9/70 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique comportant un moteur électrique disposé à l'extérieur du rouleau

Abrégé

Barrier systems and associated methods, including vapor and/or fire barrier systems, are disclosed herein. One aspect of the invention is directed toward a barrier system that includes a barrier coupled to a spool. The barrier is positioned to be wound onto and off of the spool as the barrier moves between a deployed position and a retracted position by a drive assembly. The system further includes a seal assembly positioned in a housing and contacting the spool to create a barrier to smoke and vapor migration through the housing. The system still further includes a sensor operably coupled to a control system and positioned to sense barrier position as the barrier moves between the deployed and the retracted positions.

Classes IPC  ?

• E06B 9/70 - Dispositifs ou mécanismes de manœuvre, p. ex. à entraînement électrique comportant un moteur électrique disposé à l'extérieur du rouleau

Abrégé

Barrier systems and associated methods, including vapor and/or fire barrier systems, are disclosed herein. One aspect of the invention is directed toward a barrier system that includes a barrier coupled to a spool. The barrier is positioned to be wound onto and off of the spool as the barrier moves between a deployed position and a retracted position by a drive assembly. The system further includes a control system coupled to the drive assembly and configured to command operation of the drive assembly. The system still further includes a sensor operably coupled to the control system and positioned to sense barrier position as the barrier moves between the deployed and the retracted positions.

Classes IPC  ?

• A62C 2/10 - Rideaux à l'épreuve du feu
• E06B 9/56 - Dispositions ou dispositifs de manœuvre, de guidage ou de verrouillage pour fermetures à rouleauTambours à ressortsTambours à rubanLeurs dispositions de contrepoids

Produits et services

Smoke containment system used in buildings to seal off elevator hoistways from the passage of smoke.

Produits et services

(1) Electric and electronically controlled smoke partition system comprising flexible magnets and thin sheeting used in buildings to seal openings from the passage of smoke.

Produits et services

electric and electronically controlled smoke partition system comprising flexible magnets and thin sheeting used in buildings to seal elevator hoistway openings from the passage of smoke

Produits et services

electric and electronically controlled smoke containment system comprising flexible magnets and thin plastic sheeting used in buildings to seal off elevator hoistways from the passage of smoke

Produits et services

electric and electronically controlled smoke containment system comprising flexible magnets and thin plastic sheeting used in buildings to seal off elevator hoistways from the passage of smoke
