Apparatus and method for delivering and deploying an intravascular device into the vessel including an outer and inner tube that are axially linked by a housing structure at the proximal end of the catheter, and a retractable sleeve structure having a middle tube and sleeve tip. The sleeve tip is sealed to the inner tube at the distal end, and continuously extends into the middle tube. At the proximal end of the sleeve structure, the middle tube is sealed to either a housing structure or slideable proximal ring, forming a sealed chamber between the inner tube and the sleeve structure. A radial space is formed between the sleeve tip and the inner tube optimized for intravascular device placement. During retraction of the sleeve structure, the fold of the sleeve tip peels away from the device, which expands to its deployed state while minimizing axial forces and friction.
A61F 2/966 - Instruments specially adapted for placement or removal of stents or stent-grafts having an outer sleeve with relative longitudinal movement between outer sleeve and prosthesis, e.g. using a push rod
A61F 2/95 - Instruments specially adapted for placement or removal of stents or stent-grafts
The invention is directed to an endovascular device having an undulating pattern of struts and loops. In a first aspect of the invention, the endovascular device comprises a main stent component having a tubular shape and a first end and a second end, said device having a first radiopaque marker (2401A) and a second radiopaque marker (2401B) each having a shape with at least two distinct profiles when viewed from different angles, said markers positioned on the main stent component to be offset by less than 180 degrees relative to the other. In a second aspect, the endovascular device has a particular stent pattern, where at least one strut has a bend in the crimped profile for reducing the compressed diameter having the following features.
A61F 2/915 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure characterised by a net-like or mesh-like structure made from perforated sheets or tubes, e.g. perforated by laser cuts or etched holes with bands having a meander structure, adjacent bands being connected to each other
The invention is directed to an endovascular device having an undulating pattern of struts and loops. In a first aspect of the invention, the endovascular device comprises a main stent component having a tubular shape and a first end and a second end, said device having a first radiopaque marker and a second radiopaque marker each having a shape with at least two distinct profiles when viewed from different angles, said markers positioned on the main stent component to be offset by less than 180 degrees relative to the other. In a second aspect, the endovascular device has a particular stent pattern, where at least one strut has a bend in the crimped profile for reducing the compressed diameter having the following features. The strut configuration comprises one or more bent sections facing in opposite convex and concave orientations, thereby creating a space or hollow for an oppositely aligned portion of the device to nestle therein as the device is compressed. The undulating pattern may be staggered such that adjacent loops within individual windings are axially offset with respect to a perpendicular axis perpendicular to the lengthwise direction. Adjacent windings may be interconnected in the longitudinal direction of the device by flexible connectors.
A61F 2/915 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure characterised by a net-like or mesh-like structure made from perforated sheets or tubes, e.g. perforated by laser cuts or etched holes with bands having a meander structure, adjacent bands being connected to each other
The invention is directed to an endovascular device having an undulating pattern of struts and loops, where at least one strut has a bend in the crimped profile for reducing the compressed diameter. The strut configuration comprises one or more bent sections facing in opposite convex and concave orientations, thereby creating a space or hollow for an oppositely aligned portion of the device to nestle therein as the device is compressed. The undulating pattern may be staggered such that adjacent loops in the helical direction are axially offset with respect to a perpendicular axis perpendicular to the lengthwise direction, where a loop may be positioned to align with an adjacent strut in the helical direction. The device may include struts of varying lengths which may contribute to an enlarged expanded diameter of the device. The bent strut design of the crimped profile may be used with any endovascular strut design.
A61F 2/88 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure the wire-like elements formed as helical or spiral coils
A61F 2/915 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure characterised by a net-like or mesh-like structure made from perforated sheets or tubes, e.g. perforated by laser cuts or etched holes with bands having a meander structure, adjacent bands being connected to each other
The invention is directed to an endovascular device having an undulating pattern of struts and loops, where at least one strut has a bend in the crimped profile for reducing the compressed diameter. The strut configuration comprises one or more bent sections facing in opposite convex and concave orientations, thereby creating a space or hollow for an oppositely aligned portion of the device to nestle therein as the device is compressed. The undulating pattern may be staggered such that adjacent loops in the helical direction are axially offset with respect to a perpendicular axis perpendicular to the lengthwise direction, where a loop may be positioned to align with an adjacent strut in the helical direction. The device may include struts of varying lengths which may contribute to an enlarged expanded diameter of the device. The bent strut design of the crimped profile may be used with any endovascular strut design.
A61F 2/88 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure the wire-like elements formed as helical or spiral coils
Apparatus and method for delivering and deploying an intravascular device into the vessel including an outer and inner tube that are axially linked by a housing structure at the proximal end of the catheter, and a retractable sleeve structure having a middle tube and sleeve tip. The sleeve tip is sealed to the inner tube at the distal end, and continuously extends into the middle tube. At the proximal end of the sleeve structure, the middle tube is sealed to either a housing structure or slideable proximal ring, forming a sealed chamber between the inner tube and the sleeve structure. A radial space is formed between the sleeve tip and the inner tube optimized for intravascular device placement. During retraction of the sleeve structure, the fold of the sleeve tip peels away from the device, which expands to its deployed state while minimizing axial forces and friction.
A61F 2/966 - Instruments specially adapted for placement or removal of stents or stent-grafts having an outer sleeve with relative longitudinal movement between outer sleeve and prosthesis, e.g. using a push rod
A61F 2/95 - Instruments specially adapted for placement or removal of stents or stent-grafts
A catheter tip that provides longitudinal flexibility, pushability and radial rigidity thereby improving deliverability is provided. The catheter tip includes a spring-like element to provide longitudinal flexibility and pushability to the catheter tip. The spring-like element may also provide radial support to the distal edge of the catheter tip. Alternatively, a radially rigid distal end may also be included distal of the spring-like element. The apparatus may be used with any interventional catheter system, but is particularly suitable for use with balloon-expandable stent systems and balloon-angioplasty systems, where flexibility of the catheter tip and minimal flaring of the distal edge of the catheter tip is desirable.
A catheter tip having a spring element that imparts longitudinal flexibility, pushability and radial rigidity to the catheter tip, thereby improving deliverability, is provided. The spring element also provides radial support to the distal edge of the catheter tip. The spring element may taper distally, but may have a substantially constant inner luminal diameter. The spring element may be partially covered or embedded, leaving its distal end exposed. The spring element may also include spaced coils in a proximal region. The apparatus may be used with any interventional catheter system, but is particularly suitable for use with balloon-expandable stent systems and balloon-angioplasty systems, where flexibility of the catheter tip and minimal flaring of the distal edge of the catheter tip is desirable.
The present invention relates to a catheter system having a reinforced guidewire shaft and a method of manufacturing a reinforced catheter shaft. In particular, the present invention relates to a catheter shaft (350) having two or more polymer layers and a reinforcement layer (352a, 352b) that is comprised of braids or a coil or combination thereof. The braided reinforcement layer may have a constant picks per inch (PPI) between braids or a variable PPI between braids. Similarly, the coiled reinforcement layer may have a constant pitch space between coils or a variable pitch space between coils. The reinforced catheter shaft may be manufactured by a continuous reel- to-reel process using liquid polymers that are heat-hardened or by a discrete process using extruded tube that is shrunk with heat.
The present disclosure is directed to a stent manufacturing assembly including an inner shield, a patterned metal sheet, and an outer shield. The patterned metal sheet may include a polymer coating with an embedded therapeutic agent. The inner shield, patterned metal sheet, and outer shield are arranged in a layered configuration and placed in a stent rolling mechanism with a mandrel. In particular, the patterned metal sheet is disposed on the outer shield and the inner shield is disposed on the patterned metal sheet in the layered configuration. In the layered configuration, the stent manufacturing assembly is rolled by the rolling mechanism into a tubular shape and welded to form a tubular stent.
A61F 2/915 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure characterised by a net-like or mesh-like structure made from perforated sheets or tubes, e.g. perforated by laser cuts or etched holes with bands having a meander structure, adjacent bands being connected to each other
17.
Systems and method for stent manufacturing using protective shields
The present disclosure is directed to a stent manufacturing assembly including an inner shield, a patterned metal sheet, and an outer shield. The patterned metal sheet may include a polymer coating with an embedded therapeutic agent. The inner shield, patterned metal sheet, and outer shield are arranged in a layered configuration and placed in a stent rolling mechanism with a mandrel. In particular, the patterned metal sheet is disposed on the outer shield and the inner shield is disposed on the patterned metal sheet in the layered configuration. In the layered configuration, the stent manufacturing assembly is rolled by the rolling mechanism into a tubular shape and welded to form a tubular stent.
A61F 2/915 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure characterised by a net-like or mesh-like structure made from perforated sheets or tubes, e.g. perforated by laser cuts or etched holes with bands having a meander structure, adjacent bands being connected to each other
B23K 31/02 - Processes relevant to this subclass, specially adapted for particular articles or purposes, but not covered by any single one of main groups relating to soldering or welding
B23K 26/282 - Seam welding of curved planar seams of tube sections
Apparatus and method for delivering and deploying an intravascular device into the vessel including an outer and inner tube that are axially linked by a housing structure at the proximal end of the catheter, and a retractable sleeve structure having a middle tube and sleeve tip. The sleeve tip is sealed to the inner tube at the distal end, and continuously extends into the middle tube. At the proximal end of the sleeve structure, the middle tube is sealed to either a housing structure or slideable proximal ring, forming a sealed chamber between the inner tube and the sleeve structure. A radial space is formed between the sleeve tip and the inner tube optimized for intravascular device placement. During retraction of the sleeve structure, the fold of the sleeve tip peels away from the device, which expands to its deployed state while minimizing axial forces and friction.
A61F 2/966 - Instruments specially adapted for placement or removal of stents or stent-grafts having an outer sleeve with relative longitudinal movement between outer sleeve and prosthesis, e.g. using a push rod
A61F 2/95 - Instruments specially adapted for placement or removal of stents or stent-grafts
The invention relates to devices, a systems, and associated methods for use, delivery, and manufacture for changing the blood flow into an aneurysm designed to induce aneurysm thrombosis and/or the exclusion from blood flow and pressure of the aneurysm in order to prevent further growth and eventual rupture. In some embodiments, the various aspects of the invention are directed to treating a cerebral aneurysm.
A61F 2/00 - Filters implantable into blood vesselsProstheses, i.e. artificial substitutes or replacements for parts of the bodyAppliances for connecting them with the bodyDevices providing patency to, or preventing collapsing of, tubular structures of the body, e.g. stents
A61B 17/00 - Surgical instruments, devices or methods
A61F 2/01 - Filters implantable into blood vessels
A61B 17/115 - Staplers for performing anastomosis, e.g. in a single operation
The invention provides a thrombus retriever and associated methods for use. The thrombus retriever has a retriever body that is attached to a centrally-disposed deployment member capable of moving the retriever body in the proximal direction (towards the operator) in order to retrieve the target thrombus. The retriever body is attached to the deployment member at an attachment point distal to the most distal end of the retriever body. In use, pulling the deployment member in the proximal direction effectively "pushes" the retriever body from behind during thrombus collection. The thrombus retriever also may comprise a net at its distal end to collect the retrieved thrombus and prevent embolization.
A61B 17/22 - Implements for squeezing-off ulcers or the like on inner organs of the bodyImplements for scraping-out cavities of body organs, e.g. bonesSurgical instruments, devices or methods for invasive removal or destruction of calculus using mechanical vibrationsSurgical instruments, devices or methods for removing obstructions in blood vessels, not otherwise provided for
A61B 17/221 - Calculus gripping devices in the form of loops or baskets
A catheter tip having a spring element that imparts longitudinal flexibility, pushability and radial rigidity to the catheter tip, thereby improving deliverability, is provided. The spring element also provides radial support to the distal edge of the catheter tip. The spring element may taper distally, but may have a substantially constant inner luminal diameter. The spring element may be partially covered or embedded, leaving its distal end exposed. The spring element may also include spaced coils in a proximal region. The apparatus may be used with any interventional catheter system, but is particularly suitable for use with balloon-expandable stent systems and balloon-angioplasty systems, where flexibility of the catheter tip and minimal flaring of the distal edge of the catheter tip is desirable.
Apparatus and method for delivering and deploying an intravascular device into the vessel including an outer and inner tube that are axially linked by a housing structure at the proximal end of the catheter, and a retractable sleeve structure having a middle tube and sleeve tip. The sleeve tip is sealed to the inner tube at the distal end, and continuously extends into the middle tube. At the proximal end of the sleeve structure, the middle tube is sealed to either a housing structure or slideable proximal ring, forming a sealed chamber between the inner tube and the sleeve structure. A radial space is formed between the sleeve tip and the inner tube optimized for intravascular device placement. During retraction of the sleeve structure, the fold of the sleeve tip peels away from the device, which expands to its deployed state while minimizing axial forces and friction.
A61F 2/966 - Instruments specially adapted for placement or removal of stents or stent-grafts having an outer sleeve with relative longitudinal movement between outer sleeve and prosthesis, e.g. using a push rod
A61F 2/95 - Instruments specially adapted for placement or removal of stents or stent-grafts
30.
IMPROVED DEVICE FOR TRAVERSING VESSEL OCCLUSIONS AND METHOD OF USE
An apparatus, system and method for re-canalization or opening a passage through an occlusion in a blood vessel is provided. The apparatus and method, which are appropriate for cardiovascular and peripheral vessels, use a pulling member and a spring member, for example a compression spring, to oscillate a drilling component. The drilling component at the distal end of the catheter tip has combined longitudinal stiffness for penetrating a total or partial occlusion and high axial (lateral) flexibility to improve deliverability and crossability of a catheter through a partially occluded vessel or a tortuous vessel, and may taper distally. The system of the invention includes the apparatus and a control unit to permit adjustment of the frequency or amplitude of oscillation of the drilling component. Also provided is a method for oscillating a drilling component using a pulling member and a spring member and a method of traversing an occlusion.
A61B 17/22 - Implements for squeezing-off ulcers or the like on inner organs of the bodyImplements for scraping-out cavities of body organs, e.g. bonesSurgical instruments, devices or methods for invasive removal or destruction of calculus using mechanical vibrationsSurgical instruments, devices or methods for removing obstructions in blood vessels, not otherwise provided for
A catheter tip having a spring element that imparts longitudinal flexibility, pushability and radial rigidity to the catheter tip, thereby improving deliverability, is provided. The spring element also provides radial support to the distal edge of the catheter tip. The spring element may taper distally, but may have a substantially constant inner luminal diameter. The spring element may be partially covered or embedded, leaving its distal end exposed. The spring element may also include spaced coils in a proximal region. The apparatus may be used with any interventional catheter system, but is particularly suitable for use with balloon-expandable stent systems and balloon-angioplasty systems, where flexibility of the catheter tip and minimal flaring of the distal edge of the catheter tip is desirable.
A catheter tip (20, 120) having a spring element (30, 130, 230, 330) that imparts longitudinal flexibility, pushability and radial rigidity to the catheter tip, thereby improving deliverability, is provided. The spring element also provides radial support to the distal edge of the catheter tip. The spring element may taper distally, but may have a substantially constant inner luminal diameter. The spring element may be partially covered or embedded, leaving its distal end exposed. The spring element may also include spaced coils in a proximal region. The apparatus may be used with any interventional catheter system, but is particularly suitable for use with balloon-expandable stent systems and balloon-angioplasty systems, where flexibility of the catheter tip and minimal flaring of the distal edge of the catheter tip is desirable.
Device and method for enabling independent tuning of frequency and amplitude of a reverse crankshaft motor. The reverse crankshaft motor provides periodic reciprocating motion based on periodic rotational motion from a rotational motor. The reverse crankshaft motor includes a crankshaft structure having first and second frames with a third axle arranged between them and connected to them by hinges. An amplituder is affixed to the third axle and may communicate with an external device. As the first and second frames move toward or apart from each other, the third axle moves radially toward or away from a central axis of the crankshaft structure. The position of the third axle determines the amplitude of the periodic reciprocating motion of the amplituder. By adjusting the position of the first and second frames, the operator may adjust the amplitude independently from the frequency of the periodic rotational motion supplied by the rotational motor.
An expandable helical stent with a securement is provided. The stent is formed from flat or tubular metal in a helical coiled structure which has an undulating pattern. The main stent component may be formed of a single helically coiled component. Alternatively, a plurality of helically coiled ribbons may be used to form a stent heterogeneous in design, material, or other characteristic. The helical tubular structure may be secured with a securement, such as a weld, interlock or a polymer, to maintain the helical coils in a tubular configuration. The helical coils of the main stent component may be spaced apart or nestled to each other. The nestling of the undulation of adjacent helical coils contributes to maintaining the tubular shape of the helically coiled stent. In addition, the nestling of helical coils may prevent the polymer layer from sagging at any point between cycles of the helical coils.
A61F 2/88 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure the wire-like elements formed as helical or spiral coils
A61F 2/91 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure characterised by a net-like or mesh-like structure made from perforated sheets or tubes, e.g. perforated by laser cuts or etched holes
40.
CATHETER WITH RETRACTABLE SLEEVE AND METHOD OF USING CATHETER SYSTEM
Apparatus and method for delivering and deploying an intravascular device into the vessel including an outer (3) and inner (5) tube that are axially linked by a housing structure (8) at the proximal end of the catheter, and a retractable sleeve structure (2) having a middle tube (4) and sleeve tip (16). The sleeve tip (16) is sealed to the inner tube (5) at the distal end, and continuously extends into the middle tube (4). At the proximal end of the sleeve structure (2), the middle tube (4) is sealed to either the housing structure (8) or to a slideable proximal ring (7), forming a sealed chamber (15) between the inner tube (5) and the sleeve structure (2). A radial space is formed between the sleeve tip (16) and the inner tube (5) optimized for intravascular device placement. During retraction of the sleeve structure (2), the fold of the sleeve tip (16) peels away from the device, which expands to its deployed state while minimizing axial forces and friction.
Apparatus and method for delivering and deploying an intravascular device into the vessel including an outer and inner tube that are axially linked by a housing structure at the proximal end of the catheter, and a retractable sleeve structure having a middle tube and sleeve tip. The sleeve tip is sealed to the inner tube at the distal end, and continuously extends into the middle tube. At the proximal end of the sleeve structure, the middle tube is sealed to either a housing structure or slideable proximal ring, forming a sealed chamber between the inner tube and the sleeve structure. A radial space is formed between the sleeve tip and the inner tube optimized for intravascular device placement. During retraction of the sleeve structure, the fold of the sleeve tip peels away from the device, which expands to its deployed state while minimizing axial forces and friction.
A61F 2/966 - Instruments specially adapted for placement or removal of stents or stent-grafts having an outer sleeve with relative longitudinal movement between outer sleeve and prosthesis, e.g. using a push rod
A61F 2/95 - Instruments specially adapted for placement or removal of stents or stent-grafts
A61K 31/4353 - Heterocyclic compounds having nitrogen as a ring hetero atom, e.g. guanethidine or rifamycins having six-membered rings with one nitrogen as the only ring hetero atom ortho- or peri-condensed with heterocyclic ring systems
44.
METHOD AND APPARATUS FOR STENT MANUFACTURING ASSEMBLY
A stent manufacturing assembly (10) for assisting in the manufacturing of a medical stent and a process for manufacturing a medical stent are disclosed. A patterned sheet of metal can be wrapped around the manufacturing assembly's outer surface. The assembly includes a mandrel (11) and a sleeve (12). The mandrel includes a rigid and substantially cylindrical external surface, and the sleeve surrounds the mandrel and has a variable inner diameter. The sleeve adheres to the inner surface of the stent formed around the sleeve to allow the sleeve to remain in place. After the mandrel is slidably removed from the sleeve, the sleeve radially collapses and contracts, thereby causing minimal shear stress on the stent's inner surface and preventing or minimizing friction and pressure between the mandrel and the stent.
A61F 2/90 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure characterised by a net-like or mesh-like structure
B23K 33/00 - Specially-profiled edge portions of workpieces for making soldering or welding connectionsFilling the seams formed thereby
B05C 13/02 - Means for manipulating or holding work, e.g. for separate articles for particular articles
A61F 2/00 - Filters implantable into blood vesselsProstheses, i.e. artificial substitutes or replacements for parts of the bodyAppliances for connecting them with the bodyDevices providing patency to, or preventing collapsing of, tubular structures of the body, e.g. stents
A catheter tip that provides longitudinal flexibility, pushability and radial rigidity thereby improving deliverability is provided. The catheter tip (20) includes a spring-like element (30) to provide longitudinal flexibility and pushability to the catheter tip. The spring-like element may also provide radial support to the distal edge of the catheter tip. Alternatively, a radially rigid distal end (40) may also be included distal of the spring-like element. The apparatus may be used with any interventional catheter system, but is particularly suitable for use with balloon - expandable stent systems and balloon - angioplasty systems, where flexibility of the catheter tip and minimal flaring of the distal edge of the catheter tip is desirable.
A catheter tip that provides longitudinal flexibility, pushability and radial rigidity thereby improving deliverability is provided. The catheter tip includes a spring-like element to provide longitudinal flexibility and pushability to the catheter tip. The spring-like element may also provide radial support to the distal edge of the catheter tip. Alternatively, a radially rigid distal end may also be included distal of the spring-like element. The apparatus may be used with any interventional catheter system, but is particularly suitable for use with balloon-expandable stent systems and balloon-angioplasty systems, where flexibility of the catheter tip and minimal flaring of the distal edge of the catheter tip is desirable.
A method and system for generating stabilized intravascular ultrasonic images are provided. The system may include a probe instrument, such as a catheter, connected to a processor and a post-processor. The method of using the system to stabilize images and the method for stabilizing images involve the process by which the processor and post-processor stabilize the image. A computer readable medium containing executable instructions for controlling a computer containing the processor and post-processor to perform the method of stabilizing images is also provided. The probe instrument, which has a transmitter for transmitting ultrasonic signals and a receiver for receiving reflected ultrasonic signals that contain information about a tubular environment, such as a body lumen, preferably is a catheter. The processor and post-processor are capable of converting inputted signals into one or more, preferably a series of, images and the post-processor, which determines the center of the environment at each reflection position, detects the edges of the tubular environment and aligns the image center with the environment center thereby limiting the drift of images, which may occur due to movement of the environment, and stabilizing the images. The processor may also be programmed to filter images or series of images to improve the image stabilization and remove motion interference and/or may be programmed to extract the 3D shape of the environment. The method and device are of particular use where motion causes image drift, for example, the imaging a body lumen, in particular a vascular lumen, where image drift may occur due to heart beat or blood flow.
An expandable helical stent is provided, wherein the stent may be formed of a main stent component and a securement. The main stent component is formed from a flat strip having one or more undulating side bands that may be connected to form geometrically shaped cells and are helically wound to form a stent. The helical coils of the main stent component may be spaced apart or nestled to each other. The nestling of the undulation of adjacent helical windings contributes to maintaining the tubular shape and uniformity of the helically coiled stent. Alternatively, the flat strip may comprise a single undulating pattern. At the ends of the main stent component are end bands, which when wound, form a cylindrical ring. In one embodiment, one or more struts of the main stent component may have a width sufficient to include one or more fenestrations. The fenestrated struts may be connected by loops or turns wherein the material is narrower than that of the fenestrated struts to provide enhanced flexibility. The helical tubular is maintained with a securement.
A61F 2/88 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure the wire-like elements formed as helical or spiral coils
A61L 31/16 - Biologically active materials, e.g. therapeutic substances
A61F 2/91 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure characterised by a net-like or mesh-like structure made from perforated sheets or tubes, e.g. perforated by laser cuts or etched holes
An expandable helical stent is provided, wherein the stent may be formed of a main stent component and a securement. The main stent component is formed from a flat strip having one or more undulating side bands (401, 402) that may be connected to form geometrically shaped cells (430) and are helically wound to form a stent. The helical coils of the main stent component may be spaced apart or nestled to each other. The nestling of the undulation of adjacent helical windings contributes to maintaining the tubular shape and uniformity of the helically coiled stent. Alternatively, the flat strip may comprise a single undulating pattern. At the ends of the main stent component are end bands 407), which when wound, form a cylindrical ring. In one embodiment, one or more struts of the main stent component may have a width sufficient to include one or more fenestrations. The fenestrated struts may be connected by loops or turns wherein the material is narrower than that of the fenestrated struts to provide enhanced flexibility. The helical tubular is maintained with a securement.
A61F 2/90 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure characterised by a net-like or mesh-like structure
A61F 2/88 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure the wire-like elements formed as helical or spiral coils
A method and an apparatus to create a more favorable flow regime in a lumen. An artificial shape in the lumen is created to at least one of eliminate flow disturbances and enhance aspects of fluid flow through a treatment site.
The present invention relates to covered endoprosthetic devices. Covered endoprosthetic devices comprise an endoprosthesis and a sheath. The sheath comprises a central portion and outer portions, wherein the central portion preferentially restricts or causes a restriction of blood flow. Blood flow can be reduced by the central portion of the sheath by varying the permeability of the sheath or by having projections on the sheath that slow blood flow. Permeability may be provided by perforations or holes in the material of the sheath or by varying the polymer structure that makes up the sheath itself. The outer portions of the sheath do not substantially reduce blood flow. Methods of using sheath-covered endoprosthetic devices of the invention to treat aneurysms, especially aneurysms in proximity to small perforator vessels or arteries, are also encompassed.
A61B 5/0215 - Measuring pressure in heart or blood vessels by means inserted into the body
A61B 5/00 - Measuring for diagnostic purposes Identification of persons
A61F 2/82 - Devices providing patency to, or preventing collapsing of, tubular structures of the body, e.g. stents
A61F 2/90 - Stents in a form characterised by wire-like elementsStents in a form characterised by a net-like or mesh-like structure characterised by a net-like or mesh-like structure
