1.

ELASTOMER-MOUNTED SPLIT RING


Application Number EP2021025299
Publication Number 2022/033720
Status In Force
Filing Date 2021-08-04
Publication Date 2022-02-17
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Kuhn, Ralf
  • Lammers, Sebastian

Abstract

The present invention pertains to a split ring assembly (10) for adjusting the throughput of a fluid of a hydraulic valve comprising an elastomeric element (16) being adapted to mount a split ring (12) around a hydraulic ram, wherein the elastomeric element (16) is arranged around the outward circumference of the split ring (12), wherein the throughput of the fluid is adjustable depending on the degree to which the throughput of hydraulic fluid is limited by the split ring (12).

IPC Classes  ?

  • F16K 3/26 - Gate valves or sliding valves, i.e. cut-off apparatus with closing members having a sliding movement along the seat for opening and closing with sealing faces shaped as surfaces of solids of revolution with cylindrical valve members with fluid passages in the valve member
  • F16K 3/34 - Arrangements for modifying the way in which the rate of flow varies during the actuation of the valve

2.

ELECTRIC TERMINAL ASSEMBLY OF A DRIVE UNIT FOR USE IN A MINING MACHINE


Application Number EP2020025519
Publication Number 2021/104665
Status In Force
Filing Date 2020-11-17
Publication Date 2021-06-03
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Nafe, Michael
  • Grimm, Dennis
  • Hoelken, Thomas

Abstract

The present invention refers to an electric terminal assembly (26) of a drive unit (12) for use in a mining machine. The electric terminal assembly comprises a junction box (28) configured to be mounted to the drive unit (12) and a connecting element (30) for communicatively connecting the junction box to a control device of the drive unit (12). The electric terminal assembly (26) is configured to be convertibly arranged into at least two different configurations, each of which is associated to a different structural arrangement of the drive unit (12).

IPC Classes  ?

  • H02K 5/22 - Auxiliary parts of casings not covered by groups , e.g. shaped to form connection boxes or terminal boxes
  • H02K 11/35 - Devices for recording or transmitting machine parameters, e.g. memory chips or radio transmitters for diagnosis
  • H02K 7/116 - Structural association with clutches, brakes, gears, pulleys or mechanical starters with gears

3.

HUMAN INTERFACE OPERATING DEVICE OF AN UNDERGROUND MINING MACHINE


Application Number EP2020025460
Publication Number 2021/078408
Status In Force
Filing Date 2020-10-16
Publication Date 2021-04-29
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor Becker, Alexander

Abstract

The present invention refers to a human interface operating device (14) of an underground mining machine, comprising a rotatably and axially actuatable control element (18) for controlling functions of the underground mining machine.

IPC Classes  ?

  • E21F 9/00 - Devices preventing sparking of machines or apparatus
  • E21F 17/00 - Methods or devices for use in mines or tunnels, not covered elsewhere
  • H01H 25/06 - Operating part movable both angularly and rectilinearly, the rectilinear movement being along the axis of angular movement

4.

LIQUID-TIGHT DRIVE CONNECTION FOR ENGINE AND TRANSMISSION COUPLING


Application Number EP2020025425
Publication Number 2021/058128
Status In Force
Filing Date 2020-09-21
Publication Date 2021-04-01
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Nafe, Michael
  • Grimm, Dennis
  • Hoelken, Thomas

Abstract

The present invention pertains to a drive connection for coupling an engine to a gearbox of a machine and which provides a fluid-tight sealing. Accordingly, a drive connection (10) for coupling an engine to a gearbox of a machine is suggested, which comprises a housing (12) having an inner cavity (14) that extends from a first open end (16) of the housing (12) to a second open end (18) of the housing (12) and which is configured for accommodating and enclosing a clutch. The housing (12) defines a first coupling interface (20) at the first open end (16) for coupling the drive connection (10) to an engine and a second coupling interface (22) at the second open end (18) for coupling the drive connection (10) to a gearbox, Furthermore, each coupling interface (20, 22) comprises a sealing member (24), wherein the housing (12) and sealing members (24) are configured to fluidically seal the inner cavity (14), when the drive connection (10) is in a coupled state.

IPC Classes  ?

  • F16H 57/025 - Support of gearboxes, e.g. torque arms, or attachment to other devices
  • F16H 57/031 - GearboxesMounting gearing therein characterised by covers or lids for gearboxes
  • F16D 13/00 - Friction clutches
  • E21C 27/22 - Mineral freed by means not involving slitting by rotary drills with breaking-down means, e.g. wedge-shaped drills

5.

WARNING DEVICE FOR A MINING CONTROL MODULE


Application Number EP2020025417
Publication Number 2021/052629
Status In Force
Filing Date 2020-09-16
Publication Date 2021-03-25
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Heidbrink, Dennis
  • Klein, Martin
  • Krause, Vera

Abstract

The present invention relates to a warning device for a mining control module for facilitating a replacement. Accordingly,, a warning device for a mining control module is suggested, which comprises a housing (10) that is configured to be coupled with an opening provided at an outer surface of the control module, wherein the housing (10) defines an inner cavity (22), and an alarm module (28) which is arranged in said cavity (22) and is configured to be releasably coupled to an inner control unit of the control module via said opening for receiving a control signal. The housing (10) comprises a first portion (12) that extends along a longitudinal axis (14) and is configured to extend at least in part through the opening and a radially extending second portion (16) that is configured to extend over the outer surface of the control module so as to cover the opening, when the device is coupled to the control module. The device furthermore comprises a fixation means (18, 38), which is arranged on the second portion (16) and is configured to releasably engage the outer surface of the control module so as to secure the device to the control module.

IPC Classes  ?

  • E21F 17/18 - Special adaptations of signalling or alarm devices
  • H05K 5/06 - Hermetically-sealed casings

6.

METHOD AND DEVICE FOR MONITORING OPERATION OF A MINING MACHINE UNIT


Application Number EP2020025108
Publication Number 2020/177930
Status In Force
Filing Date 2020-03-02
Publication Date 2020-09-10
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Kirkhope, Euan
  • Wesselmann, Johannes

Abstract

The present invention pertains to a method for monitoring operation of a mining machine unit (30), particularly of a longwall mining system (10), having a shield unit (32) connected to a material removing unit (12) by means of an actuator (36) for adjusting a distance between the shield unit (32) and the material removing unit (12), the method comprises the steps of determining a position change of the shield unit (32) during an actuating operation of the actuator (36); and a step of detecting a malfunction of the mining machine unit (30) based on the determined position change.

IPC Classes  ?

  • E21F 13/00 - Transport specially adapted to underground conditions
  • E21C 27/02 - Machines which completely free the mineral from the seam solely by slitting
  • E21C 35/14 - Equipment for pressing the conveyor towards the working face
  • E21D 23/08 - Advancing mechanisms
  • E21D 23/12 - Control, e.g. using remote control

7.

METHOD AND APPARATUS FOR MONITORING SPROCKET WEAR, E.G. IN A MINING CONVEYOR


Application Number EP2020025014
Publication Number 2020/148092
Status In Force
Filing Date 2020-01-14
Publication Date 2020-07-23
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Voigt, Robert
  • Brooks, Jarrod

Abstract

A sprocket (1, 1') comprising teeth (3) for engaging one or more chains (20) is provided with datum connection portions (16) which releasably support a datum body (17), such as a tensioned wire (17'), in a predefined position. The datum body (17) provides a temporary reference or datum element or surface from which the position of the wear surfaces (10) of the sprocket teeth (3) may be determined by eye or by measurement, particularly in the radial direction (Dr). The teeth (3) may further comprise a set of markings (31, 32, 33) corresponding to angularly spaced reference planes (P1, P2, P3) intersecting at the sprocket axis (X). The markings (31, 32, 33) are preferably arranged on the crown or radially outward surface (6) of the teeth (3) and are used to determine wear in the circumferential direction (Dc).

IPC Classes  ?

  • F16H 7/06 - Gearings for conveying rotary motion by endless flexible members with chains
  • F16H 55/30 - Chain wheels
  • F16H 57/01 - Monitoring wear or stress of gearing elements, e.g. for triggering maintenance
  • B65G 23/06 - Drums, rollers, or wheels with projections engaging abutments on belts or chains, e.g. sprocket wheels

8.

CONVEYOR PAN


Application Number EP2019025167
Publication Number 2019/238265
Status In Force
Filing Date 2019-05-31
Publication Date 2019-12-19
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Pietrala, Christoph
  • Tillessen, Uwe
  • Baier, Eugen

Abstract

A conveyor pan (1) for a chain scraper conveyor comprises a bottom plate (4) and a pair of side profiles (2, 3) fixed to the bottom plate (4) by welding. The conveyor pan (1) has an increased wear resistance, in particular due to a specific geometry of a weld groove formed between the profile rails (5, 6) of the side profile (2, 3) and the bottom plate (4). The weld groove extends deeper into each profile rail (5, 6), resulting in a more durable weld connection during use of the conveyor pan (1). In addition, a geometry of a pocket member (11) for connecting adjacent conveyor pans (1) and an inspection opening formed in the bottom plate (4) have also been improved to result in an increased strength of the conveyor pan (1).

IPC Classes  ?

9.

TENSIONING ASSEMBLY FOR LONGWALL MINING EQUIPMENT


Application Number EP2019025123
Publication Number 2019/211004
Status In Force
Filing Date 2019-04-24
Publication Date 2019-11-07
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor Kunert, Dennis

Abstract

A tensioning assembly (200) for a scraper chain conveyor (140) of a longwall mining equipment (102). The longwall mining equipment (102) includes a winning machine (120) configured to move along a mining face of a longwall (104), shear a mining material from the mining face, and deposit the mining material onto the scraper chain conveyor (120) disposed along the mining face. The tensioning assembly (200) includes a tensioning frame (202) configured to move between an extended position and a retracted position relative to a main frame (146) of the scraper chain conveyor (140) to maintain the scraper chain conveyor (140) in a taut configuration. The tensioning assembly (200) further includes a first stopper (214) and a second stopper (216) where the first stopper (214) is fixedly coupled to the tensioning frame (202) and configured to abut the winning machine (120) to maintain at least a minimum distance between the winning machine (120) and the tensioning frame (202) in the retracted position of the tensioning frame (202).

IPC Classes  ?

  • B65G 23/44 - Belt- or chain-tensioning arrangements
  • B65G 19/18 - Conveyors comprising an impeller or a series of impellers carried by an endless traction element and arranged to move articles or materials over a supporting surface or underlying material, e.g. endless scraper conveyors Details
  • E21F 13/06 - Transport specially adapted to underground conditions at or adjacent to the working face

10.

HYDRAULIC SHIELD SUPPORT SYSTEM AND PRESSURE INTENSIFIER


Application Number EP2019025065
Publication Number 2019/179663
Status In Force
Filing Date 2019-03-08
Publication Date 2019-09-26
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Dwornik, Olivier
  • Suilmann, Franz-Heinrich
  • Rueschkamp, Henner

Abstract

In a hydraulic shield support system (100), a plurality of pressure intensifiers (21) are respectively provided for a plurality of hydraulic props (8). Each pressure intensifier (21) is operated to increase a system pressure (P) to an increased pressure for supplying fluid at the increased pressure to a pressure chamber (18) of the associated hydraulic prop (8). The plurality of pressure sensors (61) measure the pressures of the fluid supplied to the respective hydraulic props (8). A control unit (80) sets a plurality of desired pressures for the plurality of hydraulic props (8), and stops operation of the respective pressure intensifiers (21) when the set desired pressure has been reached.

IPC Classes  ?

  • E21D 23/04 - Structural features of the supporting construction, e.g. linking members between adjacent frames or sets of propsMeans for counteracting lateral sliding on inclined floor
  • E21D 23/16 - Hydraulic or pneumatic features, e.g. circuits, arrangement or adaptation of valves, setting or retracting devices
  • E21D 23/26 - Hydraulic or pneumatic control
  • E21B 33/035 - Well headsSetting-up thereof specially adapted for underwater installations
  • E21D 15/44 - Hydraulic, pneumatic, or hydraulic-pneumatic props
  • F15B 3/00 - Intensifiers or fluid-pressure converters, e.g. pressure exchangersConveying pressure from one fluid system to another, without contact between the fluids

11.

CONTROL SYSTEM AND METHOD FOR CONTROLLING OPERATION OF AN UNDERGROUND MINING MACHINE


Application Number EP2018000206
Publication Number 2018/192678
Status In Force
Filing Date 2018-04-17
Publication Date 2018-10-25
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Moberg, Carl John
  • Kortmann, Oliver
  • Temmann, Thomas
  • Alle, Konstantin
  • Huehn, Bjoern-Andre
  • Butz, Carsten
  • Kühnemund, Frank

Abstract

A control system for controlling operation of a cutter motor and a cutter boom movement mechanism of a machine includes a sensor that measures an amount of load associated with the cutter motor. A controller determines whether the load on the cutter motor is different from a cutter motor load limit. If so, the controller is configured to adjust a velocity of the cutter boom movement mechanism relative to a tip velocity of a rotary cutting tool associated with the machine based on the difference between the measured cutter motor load and the cutter motor load limit until a torque error of the cutter motor reaches a particular value, for instance, zero. Moreover, the controller may also adjust a current speed of the cutter motor in driving the rotary cutting tool based on the adjusted velocity of the cutter boom movement mechanism.

IPC Classes  ?

  • E02F 3/92 - Digging elements, e.g. suction heads
  • E21C 35/24 - Remote control specially adapted for machines for slitting or completely freeing the mineral

12.

SITE POSITIONING SYSTEM FOR AN UNDERGROUND MACHINE


Application Number EP2018000136
Publication Number 2018/177597
Status In Force
Filing Date 2018-03-29
Publication Date 2018-10-04
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Moberg, Carl
  • Temmann, Thomas
  • Teiner, Martin
  • Kornev, Paul
  • Kühnemund, Frank
  • Rockwood, Brian
  • Palmer, Matt
  • Duppong, Brent
  • Hühn, Björn-Andre

Abstract

A site positioning system (12) for an underground machine (10) includes a first prism (20) coupled with the underground machine (10), a second prism (22) operatively coupled with the underground machine (10), a primary total station (26), and a reference prism (28) may be in communication with the primary total station (26). A positioning controller (14) is configured to control, responsive to receiving a High Accuracy Machine Position mode, the primary total station (26) to monitor the first prism (20) and the second prism (22) and transmit a first prism position and a second prism position, respectively, to the positioning controller (14); control, responsive to receiving a Low Accuracy Machine Position mode, the primary total station (26) to monitor the first prism (20) and transmit the first prism position to the positioning controller (14); determine, responsive to receiving a Reference Prism Measurement mode, whether a reference prism measurement has been completed, and present positioning information for the machine (10) based on one or more of the prism positions.

IPC Classes  ?

  • G01S 17/88 - Lidar systems, specially adapted for specific applications
  • G01C 15/00 - Surveying instruments or accessories not provided for in groups
  • E21D 9/00 - Tunnels or galleries, with or without liningsMethods or apparatus for making thereofLayout of tunnels or galleries

13.

MACHINE AND METHOD OF CUTTING MATERIAL


Application Number EP2017083312
Publication Number 2018/114803
Status In Force
Filing Date 2017-12-18
Publication Date 2018-06-28
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Moberg, Carl J.
  • Temmann, Thomas
  • Teiner, Martin
  • Kuehnemund, Frank
  • Kornev, Paul

Abstract

A machine (100) includes an undercarriage (102) having propulsions devices such as continuous tracks (104) and a cutter head (110) disposed on a cutter boom (122) that is slidably supported over the undercarriage (102). During operation, the cutter head (110) is positioned proximate to the cutting surface (108) and may be maneuvered through a predetermined set of operations (310) to make a plurality of horizontal or vertical cuts while feeding the cutter head (110) into the surface (108). Once the cutter boom (122) is fully extended, the machine (100) must be trammed to a new position using the continuous tracks (104) to conduct the next predetermined set of operations (310). The machine (100) may be configured to retract the cutter boom (122) prior to tramming the machine (100) to avoid damage to the cutter boom (122) and/or cutting surface (108).

IPC Classes  ?

  • E02F 9/08 - SuperstructuresSupports for superstructures
  • B60S 9/12 - Ground-engaging vehicle fittings for supporting, lifting, or manoeuvring the vehicle, wholly or in part, e.g. built-in jacks for only lifting or supporting by fluid pressure of telescopic type
  • E21C 35/06 - Equipment for positioning the whole machine in relation to its sub-structure
  • E21C 25/16 - Machines slitting solely by one or more rotating saws, cutting discs, or wheels
  • E21D 9/10 - Making by using boring or cutting machines

14.

COLLISION AVOIDANCE CONTROL METHOD AND SYSTEM


Application Number EP2017083960
Publication Number 2018/115210
Status In Force
Filing Date 2017-12-20
Publication Date 2018-06-28
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Moberg, Carl J.
  • Kornev, Paul
  • Teiner, Martin
  • Bilsing, Rene
  • Temmann, Thomas

Abstract

A control method and system for avoiding collisions between components of a machine (100) includes a controller (191) that receives position signals from sensors (200, 202, 204, 210, 220) associated with movable components of the machine (100). The controller (191) determines the positional coordinate representations of the components within a coordinate system based upon the position signals and the outer dimensions of the respective components. If any of the components are within preset collision slowdown or shutdown zones within the coordinate system, then the speed of those components is restricted or the components are shutdown, respectively, in the direction of collision.

IPC Classes  ?

  • E21C 27/24 - Mineral freed by means not involving slitting by milling means acting on the full working face
  • E02F 9/20 - DrivesControl devices
  • E21C 35/04 - Safety devices

15.

MACHINE AND METHOD OF CUTTING MATERIAL


Application Number EP2017083315
Publication Number 2018/114806
Status In Force
Filing Date 2017-12-18
Publication Date 2018-06-28
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Moberg, Carl J.
  • Kuehnemund, Frank
  • Duppong, Brent
  • Mccartney, Rachel E.
  • Arbona, Jessica

Abstract

A machine (100) for cutting material includes an undercarriage (102) including propulsion device for propelling the machine (100) and a cutter head (110) disposed on a tool support and positioning assembly (120) movably supported by the undercarriage (102) to remove material from a cutting surface (108). The machine (100) further includes a plurality of ground-engaging devices (180, 190) connected to the undercarriage (102) that can be simultaneously raised and lowered with respect to a ground floor (106). Examples of ground-engaging devices include stabilizers (180) for stabilizing the machine (100) when milling or cutting material and a load shield (190) that prevents material from scattering underneath the machine (100).

IPC Classes  ?

  • E02F 9/08 - SuperstructuresSupports for superstructures
  • B60S 9/12 - Ground-engaging vehicle fittings for supporting, lifting, or manoeuvring the vehicle, wholly or in part, e.g. built-in jacks for only lifting or supporting by fluid pressure of telescopic type
  • E21C 35/06 - Equipment for positioning the whole machine in relation to its sub-structure
  • E21C 25/16 - Machines slitting solely by one or more rotating saws, cutting discs, or wheels
  • E21D 9/10 - Making by using boring or cutting machines

16.

IMPLEMENT LUBRICATION SYSTEM FOR A MINING MACHINE AND OPERATING METHOD THEREFOR


Application Number EP2017025362
Publication Number 2018/108325
Status In Force
Filing Date 2017-12-14
Publication Date 2018-06-21
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Moberg, Carl
  • Duppong, Brent
  • Kuehnemund, Frank
  • Kortmann, Oliver
  • Butz, Carsten
  • Palmer, Matthew

Abstract

An implement system (22) for a machine (10) includes a boom (34) housing a drive mechanism (60) for a cutting implement (24), and having a plurality of oil outlet ports (62,64) formed therein. A control mechanism (58) is configured to receive data indicative of an expected change in location of the outlet ports relative to an oil fill line (92,94) within the boom, and vary a pattern of incoming oil flow to limit entrainment of air in the oil.

IPC Classes  ?

  • E21C 31/02 - Driving means incorporated in machines for slitting or completely freeing the mineral from the seam for cutting or breaking-down devices
  • E02F 3/24 - Digging wheelsDigging elements of wheelsDrives for wheels
  • E02F 3/38 - Cantilever beamsDipper-armsBucket-arms
  • F16N 7/38 - Arrangements for supplying oil or unspecified lubricant from a stationary reservoir or the equivalent in or on the machine or member to be lubricated with a separate pumpCentral lubrication systems
  • F16H 57/04 - Features relating to lubrication or cooling
  • A01G 23/00 - Forestry
  • E21C 25/00 - Cutting machines, i.e. for making slits approximately parallel or perpendicular to the seam

17.

FLAMEPROOF OPTICAL FIBER CONNECTION ASSEMBLY


Application Number EP2017082294
Publication Number 2018/108844
Status In Force
Filing Date 2017-12-11
Publication Date 2018-06-21
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Schwarz, Norbert
  • Mattern, Jochen
  • Titschert, Jens

Abstract

A flameproof optical fiber connection assembly (100) for use in areas at risk of explosion is disclosed. The flameproof optical fiber connection assembly (100) comprises a first connector (110) having a first optical fiber inlet (131) and a first optical fiber outlet (132); a second connector (120) having a second optical fiber inlet (161) and a second optical fiber outlet (160); and a casting-compound free optical fiber connection unit (210) interconnected between the first connector (110) and the second connector (120) and including at least one optical fiber passage (240) for passing therethrough an optical fiber (250) connected to the first optical fiber outlet (132) and the second optical fiber inlet (161), wherein the at least one optical fiber passage (240) includes an inner diameter sized to prevent flames or sparks from travelling through the passage (240).

IPC Classes  ?

  • G02B 6/44 - Mechanical structures for providing tensile strength and external protection for fibres, e.g. optical transmission cables
  • G02B 6/42 - Coupling light guides with opto-electronic elements

18.

COOLING CIRCUIT FOR CUTTING DRUM GEARBOX


Application Number EP2017069345
Publication Number 2018/024686
Status In Force
Filing Date 2017-07-31
Publication Date 2018-02-08
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Marek, Rainer
  • Voss, Dirk
  • Wellenkamp, Lutz
  • Berger, Stefan
  • Kortmann, Oliver
  • Butz, Carsten
  • Somers, Trevor
  • Gerges, Ray

Abstract

A transmission assembly (100) for a mobile mining machine (10) is disclosed. A gearbox (40) includes a lubricant inlet (40C), a first lubricant outlet (40A), and a second lubricant outlet (40B) provided spaced apart from the first lubricant outlet (40A). A cooling circuit (102) fluidly connects the first lubricant outlet (40A) and the second lubricant outlet (40B) to the lubricant inlet (40C). The cooling circuit (102; 202) is configured to selectively pump lubricant from the first and second lubricant outlets (40A 40B) to the lubricant inlet (40C) through the cooling circuit (102). The assembly allows to pump lubricant only from that lubricant outlet, which is immersed in lubricant.

IPC Classes  ?

  • F16H 57/04 - Features relating to lubrication or cooling
  • E21C 31/02 - Driving means incorporated in machines for slitting or completely freeing the mineral from the seam for cutting or breaking-down devices

19.

DEVICE FOR A ROCK FEEDER USED IN UNDERGROUND APPLICATIONS


Application Number EP2017058544
Publication Number 2017/178425
Status In Force
Filing Date 2017-04-10
Publication Date 2017-10-19
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Raschka, Joachim
  • Eberts, Christian
  • Padberg, Hendrik
  • Frenzel, Markus

Abstract

A rock feeder deflector device (30) for a rock feeder (10) used in underground mining applications. The rock feeder (10) has a material transport portion (20) for transporting rock material (12) to a conveyor (14). The rock feeder deflector device (30) comprises a mounting portion (36) configured to be connected to the rock feeder (10); a guiding plate (38) movably connected to the mounting portion (36); and a moving mechanism (42) arranged between the mounting portion (36) and the guiding plate (38). The moving mechanism (42) is configured to move the guiding plate (38) relative to the mounting portion (36) between an operative position configured to guide rock material (12) to the material transport portion (20) and an inoperative position.

IPC Classes  ?

  • E21F 13/06 - Transport specially adapted to underground conditions at or adjacent to the working face

20.

MILLING DEVICE FOR EXCAVATING MINING MATERIALS


Application Number EP2016002063
Publication Number 2017/102070
Status In Force
Filing Date 2016-12-07
Publication Date 2017-06-22
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Raschka, Joachim
  • Bechem, Ulrich

Abstract

A milling device (14) for excavating mining materials (260) is disclosed. The milling device (14) comprises a milling drum (15) rotatable about a drum axis (200); a first group of excavating heads (18, 18', 18") arranged around a periphery of the milling drum (15) and driven to rotate about a first rotational axis (210) extending substantially radially to the drum axis (200); and a second group of excavating heads (20, 20', 20", 20"') arranged around the periphery of the milling drum (15) and rotatable about a second rotational axis (212) extending substantially radially to the drum axis (200). The first group of excavating heads (18, 18', 18") includes a plurality of first excavating tools (60, 60') configured to perform a first, cutting operation, and the second group of excavating heads (20, 20', 20", 20'") includes a plurality of second excavating tools (267) configured to perform a second excavating operation different from the first, cutting operation.

IPC Classes  ?

  • E21C 27/22 - Mineral freed by means not involving slitting by rotary drills with breaking-down means, e.g. wedge-shaped drills
  • E21C 27/24 - Mineral freed by means not involving slitting by milling means acting on the full working face
  • E21D 9/10 - Making by using boring or cutting machines

21.

FLIGHT BAR-CLAMP-CHAIN LINK CONNECTION FOR A CHAIN CONVEYOR


Application Number EP2016002081
Publication Number 2017/097428
Status In Force
Filing Date 2016-12-09
Publication Date 2017-06-15
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Pietrala, Christoph
  • Köhler, Matthias

Abstract

The present disclosure relates to a flight bar clamp (14) for connecting a flight bar (12) to at least one chain link (18B, 20B) of at least one conveyor chain (18, 20) of a chain conveyor used in underground mining. The flight bar clamp (14) comprises a clamp main body (48) extending along a clamp longitudinal axis (B), and at least one chain link engaging portion (44, 46) disposed at the clamp main body (48) configured to engage with one chain link (18B, 20B). The at least one chain link engaging portion (44, 46) of the flight bar clamp (14) includes a sacrificial anode reception (66), and a sacrificial anode body (68) disposed in the sacrificial anode reception (66). The sacrificial anode body (68) may protect the flight bar clamp (14), the flight bar (12) and the chains (18, 20) from contact corrosion.

IPC Classes  ?

  • B65G 19/24 - Attachment of impellers to traction element

22.

CUTTING DRUM WITH PIVOT CUTTER UNIT


Application Number EP2016001356
Publication Number 2017/021007
Status In Force
Filing Date 2016-08-05
Publication Date 2017-02-09
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Raschka, Joachim
  • Steinberg, Jens
  • Bechem, Ulrich

Abstract

The present disclosure relates to a cutting drum (24A; 24B; 24C) for a mobile mining machine (10). The cutting drum (24A; 24B; 24C) comprises an outer circumferential face (34) extending between first and second end faces (36, 38). The cutting drum (24A; 24B; 24C) further comprises at least one first support arm (54) including a cutting tool (56) and being pivotably mounted to the outer circumferential face (34). The first support arm (54) is pivotable into a working position, in which the cutting tool (56) of the first support arm (54) is positioned beyond the first end face (36) in a direction of a central longitudinal axis (D) and away from the second end face (38). Thus, for example, material remaining in the interspaces between neighboring cutting drums arranged side by side can be cut by the cutting tool (56) of the first support arm (54).

IPC Classes  ?

  • E21C 25/10 - RodsDrums
  • E21C 27/24 - Mineral freed by means not involving slitting by milling means acting on the full working face
  • E21D 9/10 - Making by using boring or cutting machines
  • E02F 3/20 - DredgersSoil-shifting machines mechanically-driven with digging wheels turning round an axis with tools that only loosen the material

23.

CUTTING BIT CARRIER FOR CUTTING BITS


Application Number EP2016001109
Publication Number 2017/012690
Status In Force
Filing Date 2016-06-29
Publication Date 2017-01-26
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Kratochvil, Stefan
  • Raschka, Joachim
  • Berger, Stefan
  • Brotzmann, Gerhard
  • Markowski, Michael
  • Leppkes, Hans
  • Rohwer, Jan

Abstract

The present disclosure relates to a cutting bit carrier (100) for hard rock mining applications. Usually, replacing worn cutting bits may take much effort and may be time consuming. The present cutting bit carrier (200) may comprise a first carrier member (110) including a first supporting portion (114) configured to contact a cutting bit shank (204) of a cutting bit (200) for supporting the cutting bit (200), and a second carrier member (120) including a second supporting portion (124) configured to contact the cutting bit shank (204) of the cutting bit (200) for supporting the cutting bit (200). The second carrier member (120) may be detachably mountable to the first carrier member (110).

IPC Classes  ?

24.

LONGWALL CLEARING PLOW


Application Number EP2016001000
Publication Number 2016/202456
Status In Force
Filing Date 2016-06-15
Publication Date 2016-12-22
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Siepenkort, Gerhard
  • Bettermann, Diedrich
  • Wutzke, Susanne
  • Duhnke, Klaus
  • Elsermann, Stephan

Abstract

The present disclosure relates to a clearing plow (8) for loosening material of a material cluster, which blocks travel of a material winning plow (100) in a longwall mining installation (2). The clearing plow (8) may comprise a first bottom guide member (32) including a first guiding element (40) for guiding the clearing plow (8) along a plow guide assembly (6) of the longwall mining installation (2). The clearing plow (8) may further comprise a main body (30) supported by the first bottom guide member (32), and providing a loosening tool mounting face (64) extending across the first guiding element (40) in a lateral direction of the main body (30). In clearing operation, the clearing plow (8) may be moved against the material cluster to loosen material.

IPC Classes  ?

  • E21C 27/34 - Machine propelled along the working face by cable or chain
  • E21C 35/08 - Guiding the machine
  • E21C 27/32 - Mineral freed by means not involving slitting by adjustable or non-adjustable planing means with or without loading arrangements

25.

MATERIAL HANDLING SYSTEM AND METHOD OF OPERATING THE SAME


Application Number EP2016000714
Publication Number 2016/177460
Status In Force
Filing Date 2016-05-02
Publication Date 2016-11-10
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor Rabe, Knut

Abstract

A material handling system (100) for use in an underground mining comprises a conveyor (10). The conveyor (10) transports material from a plurality of draw points along a first direction (x). At each draw point, a feeder (12-26) is arranged. Each feeder (12-26) is configured to load a predetermined amount of material per unit time onto the conveyor (10) during a loading operation. A load calculating unit (28) calculates a load distribution of the material on the conveyor (10). The calculation is based on a movement speed of the conveyor (10) and an operating time of the plurality of feeders (12-26) during which a loading operation is performed. Based on the calculated load distribution, the loading operation of the plurality of feeders (12-26) is controlled to achieve a continuous coverage of conveyor 10 without overloading the same.

IPC Classes  ?

  • B65G 43/08 - Control devices operated by article or material being fed, conveyed, or discharged
  • B65G 47/19 - Arrangements or applications of hoppers or chutes having means for controlling material flow, e.g. to prevent overloading
  • E21C 35/20 - General features of equipment for removal of chippings, e.g. for loading on conveyor
  • E21F 13/06 - Transport specially adapted to underground conditions at or adjacent to the working face

26.

MILLING DEVICE


Application Number EP2016000250
Publication Number 2016/128143
Status In Force
Filing Date 2016-02-12
Publication Date 2016-08-18
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Raschka, Joachim
  • Steinberg, Jens
  • Bechem, Ulrich

Abstract

The present disclosure generally relates to a milling device (10). The milling device (10) includes a first row of cutting discs (14) mounted on a first circumference, and a second row of cutting discs (18) mounted on a second circumference. The second row of cutting discs (18) is offset from the first row of cutting discs (14) in a longitudinal direction of the milling device (10), and the second circumference is arranged relative to the first circumference such that the second row of cutting discs (18) projects at least in part radially outward from the first row of cutting discs (14). Therefore, the first and second rows of cutting discs (14, 18) cut a material to be removed at a different depth, with a predetermined distance (X) formed between the cuts in order to achieve a substantially continuous milling line.

IPC Classes  ?

  • E21C 27/24 - Mineral freed by means not involving slitting by milling means acting on the full working face

27.

PLOW GUIDE ASSEMBLY FOR PLOW GUIDES


Application Number EP2015000707
Publication Number 2016/045757
Status In Force
Filing Date 2015-04-01
Publication Date 2016-03-31
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Siepenkort, Gerhard
  • Duhnke, Klaus
  • Wutzke, Susanne
  • Reitenbach, Frank

Abstract

The present disclosure relates to a plow guide assembly (100) for guiding a mining plow. The plow guide assembly (100) may comprise a base member (110) including a first guide beam (122) for guideing the mining plow and extending along a first axis (123), and a second guide beam (124) spaced apart the first guide beam (122) for defining a service clearance (130) therebetween, and extending along a second axis (125) axially aligned to the first axis (123). The plow guide assembly (110) may further comprise an insert element (140) insertable into the service clearance (130) and having a third guide beam (142) extending along a third axis (143). In an assembled state of the insert element (140), the third axis (143) is axially aligned to the first and second axes (123, 125).

IPC Classes  ?

  • E21C 35/12 - Guiding the machine along a conveyor for the cut material

28.

SCRAPING ELEMENTS FOR DRIVE UNITS OF UNDERGROUND MINING APPLICATIONS


Application Number EP2015001486
Publication Number 2016/015838
Status In Force
Filing Date 2015-07-20
Publication Date 2016-02-04
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Voigt, Robert
  • Schürer, Karl-Heinz
  • Weber, William, R.

Abstract

The present invention relates to a sprocket (4) adapted to be used in a drive unit (2) of a chain conveyor (100) for underground mining applications, wherein the sprocket (4) comprises a cylindrical body (41) having a front face (42), an axis of rotation (Α-Α'), and a lateral surface (43), and wherein the sprocket (4) further comprises a scraping member (20) provided on at least the front face (42) and configured to scrape off deposits during rotation of the sprocket (4).

IPC Classes  ?

  • B65G 23/06 - Drums, rollers, or wheels with projections engaging abutments on belts or chains, e.g. sprocket wheels
  • B65G 45/00 - Lubricating, cleaning, or clearing devices
  • F16H 55/30 - Chain wheels
  • B65G 39/09 - Arrangements of bearing or sealing means
  • E21F 13/06 - Transport specially adapted to underground conditions at or adjacent to the working face
  • F16C 33/58 - RacewaysRace rings
  • E21C 29/10 - Cable or chain co-operating with a winch or the like on the machine

29.

SENSING DEVICE FOR A DIGITAL LINEAR POSITION SENSOR


Application Number EP2015001225
Publication Number 2015/192965
Status In Force
Filing Date 2015-06-17
Publication Date 2015-12-23
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor Tekin, Muhammet

Abstract

A sensing device (36) for a digital linear position sensor is disclosed. The sensing device (36) includes a mounting device (28) including a mounting surface (27), and a plurality of resistors (38) mounted on the mounting surface. The plurality of resistors (38) is electrically connected in series between a first voltage node and a second voltage node. A plurality of Hall switches (34) is mounted on the mounting surface (27) at predetermined intervals in a longitudinal direction. A magnet device may move in the longitudinal direction with respect to the Hall switches (34), thereby selectively opening and closing one or more Hall switches. This may result in a change in the resistance of the plurality of resistors (38) and produce an output signal from which a position of the magnet device with respect to the sensing device (36) can be determined.

IPC Classes  ?

  • G01D 5/14 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing the magnitude of a current or voltage
  • F15B 15/28 - Means for indicating the position, e.g. end of stroke

30.

PLOW BIT ASSEMBLY


Application Number EP2015001061
Publication Number 2015/185188
Status In Force
Filing Date 2015-05-22
Publication Date 2015-12-10
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Siepenkort, Gerhard
  • Tillessen, Uwe
  • Duhnke, Klaus
  • Wutzke, Susanne
  • Bettermann, Diedrich

Abstract

The present disclosure generally relates to a plow bit (2), a bit holder (4), and a plow bit assembly (1) including the plow bit (2) and the bit holder (4). The plow bit (2) comprises a bit shank (10) including a front shank face (24) being concave, and a rear shank face (26). The rear shank face (26) is disposed on an opposite side of the bit shank (10) with respect to the front shank face (24). The bit shank (10) further comprises a first lateral shank face (28) including a first groove (30) extending from the front shank face (24) in direction to the rear shank face (26) for receiving a securing pin (6). The concave front shank face (24) facilitates pivoting the plow bit (2) into a recess (34) of the bit holder (4).

IPC Classes  ?

31.

SLEEVE HOLDER FOR A HYDRAULIC CYLINDER


Application Number EP2015000664
Publication Number 2015/154856
Status In Force
Filing Date 2015-03-27
Publication Date 2015-10-15
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Knoblich, Christian
  • Markowski, Lothar
  • Figge, Sabine
  • Werner, Jaroslaw

Abstract

A sleeve holder (16) for a hydraulic cylinder (10) comprises a male threaded portion (20) configured to threadably engage a female threaded portion (22) formed in an outer cylindrical tube (12) of the hydraulic cylinder (10). At least one tangential bore (28) is formed in the sleeve holder (16). The at least one tangential bore (28) is configured to be aligned with a circumferential groove (24) formed in the outer cylindrical tube (12) and to receive a locking pin (30) to secure the sleeve holder (16) to the outer cylindrical tube (12).

IPC Classes  ?

  • E21D 15/44 - Hydraulic, pneumatic, or hydraulic-pneumatic props

32.

SYSTEM FOR CONTROLLING SPEED OF TRAVEL IN A LONGWALL SHEARER


Application Number US2015022495
Publication Number 2015/148668
Status In Force
Filing Date 2015-03-25
Publication Date 2015-10-01
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Saikia, Siddhartha
  • Kirkhope, Euan
  • Teiner, Martin
  • Wleklik, Jörg
  • Schöneweiss, Nicolas

Abstract

A shearer system (100) for removing material along a mineable distance relative to a mining environment (102) includes a rail assembly (114) to support movement of a shearer carriage (104) thereon. The system (100) further includes a haulage motor (112) structured and arranged to move the shearer carriage (104) along the rail assembly (114). The system (100) has a rotatably driven cutter (106) that is positionable relative to the shearer carriage (104). The system (100) further includes an actuator (108) supported by the shearer carriage (104) for changing a cutting height of the cutter (106). The system (100) further includes a controller (120) that can control a velocity of the shearer carriage (104) based on a translation speed of the cutter (106), a maximum speed of the shearer carriage (104), a current cutter height, and a desired cutter height. Optionally, the controller (120) can further control the velocity of the shearer carriage (104) based on a predetermined stopping distance of the shearer carriage (104).

IPC Classes  ?

  • E21C 35/24 - Remote control specially adapted for machines for slitting or completely freeing the mineral

33.

GUIDE PIECE FOR AN EXTRACTION OR COAL PLOUGH


Application Number EP2015000548
Publication Number 2015/135654
Status In Force
Filing Date 2015-03-12
Publication Date 2015-09-17
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Siepenkort, Gerhard
  • Hesse, Norbert
  • Duhnke, Klaus
  • Tillessen, Uwe

Abstract

A replaceable guide piece (10) for an extraction or coal plough (100) is provided. The replaceable guide piece (10) includes a generally U-shaped guide piece body (12) configured to be inserted into a guide claw (14) of the plough (100). A single recess (22) is formed in a central portion of a guide piece body (12) to extend at an angle (α) from an upper side of guide piece body (12) to a side surface of the same. A locking mechanism (24) is configured to engage with the single recess (22) to prevent movement of the guide piece (10) in the longitudinal direction after insertion of the guide piece (10) into the guide claw.

IPC Classes  ?

  • E21C 35/12 - Guiding the machine along a conveyor for the cut material

34.

DEVICE AND METHOD FOR LONGWALL INSTALLATION COURSE DETERMINATION


Application Number EP2015000066
Publication Number 2015/117724
Status In Force
Filing Date 2015-01-15
Publication Date 2015-08-13
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Katrycz, Wolfgang
  • Ziegler, Manfred
  • Bäumler, Manfred

Abstract

The present disclosure relates to a device and method for position and orientation measurements of a long wall mining installation (1). Specifically, a course measuring flight bar (24) for a chain conveyor (8) of a longwall mining installation (1) is disclosed. The course measuring flight bar (24) comprises a chain mount (48) for mounting the course measuring flight bar (24) to a conveyor chain (17) of the chain conveyor (8). The course measuring flight bar (24) further comprises a course measuring device (52) for measuring a position and/or an orientation of the course measuring flight bar (24).

IPC Classes  ?

  • E21C 27/02 - Machines which completely free the mineral from the seam solely by slitting
  • E21C 31/12 - Component parts

35.

DEVICE AND METHOD FOR LONGWALL MINING INSTALLATION COURSE DETERMINATION


Application Number EP2015000067
Publication Number 2015/117725
Status In Force
Filing Date 2015-01-15
Publication Date 2015-08-13
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Katrycz, Wolfgang
  • Ahler, Marco
  • Pauli, Simon
  • Bäumler, Manfred

Abstract

The present disclosure relates to a device and a method for measuring the course of a longwall mining installation (1) extending along a longwall face (2). A movable course measuring device (30) comprises a first segment (40) extending along a first axis (B), a second segment (42) extending along a second axis (C). The second segment (42) may be movably connected to the first segment (40). The course measuring device (30) may further comprise a course measuring unit (46) for measuring a spacial relationship between the first axis (B) and the second axis (C). Based on measurements of the movable course measuring device (30), it may be possible to determine a polygonal course of the longwall mining installation along the longwall face (2).

IPC Classes  ?

  • E21C 27/02 - Machines which completely free the mineral from the seam solely by slitting
  • E21C 31/12 - Component parts

36.

SHEARER LOADER FOR UNDERGROUND MINING WITH BEARING UNITS WITHIN MAINFRAME


Application Number EP2015000121
Publication Number 2015/117729
Status In Force
Filing Date 2015-01-22
Publication Date 2015-08-13
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor Thomson, John

Abstract

The present disclosure refers to a shearer loader (10) for underground mining. A shearer loader (10) may comprise a mainframe (15) extending in a longitudinal axis and having a first end portion (30) and a second end portion (35) opposite the first end portion (30). A ranging arm (20, 25) may be swivel-mounted at least at one of the first and second end portions (30, 35) of the mainframe (15), the ranging arm (20, 25) being provided with at least one cutting drum (40, 45) pivot-mounted at the ranging arm (20, 25). At least one shearer loader component (100) may be configured to be mounted to the mainframe (15) in a removable manner, but fixedly mounted to the mainframe (15) during operation of the shearer loader (10). At least one bearing unit (1 15) might be arranged at the mainframe (15) at such a position that the at least one bearing unit (115) supports the at least one shearer loader component (100) when it is moved with respect to the mainframe (15) during assembly or disassembly.

IPC Classes  ?

  • E21C 27/02 - Machines which completely free the mineral from the seam solely by slitting
  • E21C 31/12 - Component parts

37.

FORCE MEASURING UNIT AND SYSTEM FOR MEASURING CHAIN FORCES


Application Number EP2014003141
Publication Number 2015/086110
Status In Force
Filing Date 2014-11-25
Publication Date 2015-06-18
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Pauli, Simon
  • Hahn, Detlef
  • Kratochvil, Stefan
  • Hauck, Christian
  • Skowron, Mirko
  • Ahler, Marco
  • Bittner, Dominik
  • Ziegler, Manfred

Abstract

The present disclosure relates to a force measuring unit (200) for measuring a force applied to an individual chain link of a chain strand used in underground mining applications. The force measuring unit (200) may comprise a housing (240) having a first end configured to be contacted by a first chain link leg and a second end configured to be contacted by a second chain link leg, and a distance measuring device accommodated within the housing (240) and configured to measure an actual distance between the first chain link leg and the second chain link leg. The distance measuring device may include a first unit part (210) configured to be contacted by the first chain link leg and a second unit part (220) configured to be contacted by the second chain link leg (264).

IPC Classes  ?

  • G01L 1/00 - Measuring force or stress, in general
  • G01L 1/04 - Measuring force or stress, in general by measuring elastic deformation of gauges, e.g. of springs

38.

VALVE ASSEMBLY


Application Number EP2014002328
Publication Number 2015/032474
Status In Force
Filing Date 2014-08-26
Publication Date 2015-03-12
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Gosling, Christopher F.
  • Lindenbaum, Tobias

Abstract

A valve (302) is provided for a hydraulic tank (208). The valve (302) includes a main body (304) and an end cap (306). The main body (304) includes a first section (308), a second section (310), and a window (320). The first section (308) has a solid configuration. The first section (308) has a shoulder (312) configured to contact with a spring (318). The second section (310) extends from the first section (308). The second section (310) has a hollow configuration. The window (320) defined on a surface of the second section (310) is positioned towards an end of the second section (310) proximate to the first section (308). The window (320) is configured to selectively receive a fluid flow from the hydraulic tank (208) into the main body (304) based on a position of the valve (302) with respect to the hydraulic tank (208). The end cap (306) has a hollow configuration. The end cap (306) is coupled to another end of the second section (310) of the main body (304).

IPC Classes  ?

  • F16K 3/26 - Gate valves or sliding valves, i.e. cut-off apparatus with closing members having a sliding movement along the seat for opening and closing with sealing faces shaped as surfaces of solids of revolution with cylindrical valve members with fluid passages in the valve member

39.

MODULAR CUTTING HEAD


Application Number EP2014001287
Publication Number 2014/194978
Status In Force
Filing Date 2014-05-13
Publication Date 2014-12-11
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Raschka, Joachim
  • Berger, Stefan
  • Rohwer, Jan
  • Kortmann, Oliver

Abstract

The present disclosure relates to a cutting head (10) for hard rock mining applications. The cutting head (10) may comprise a base member (20) having a rotational axis (12) and a center bore (30; 130) extending along the rotational axis (12; 112), a drive bushing (31, 131) disposed within the center bore (30; 130) and configured to transmit torque from a driving device to the base member (20; 120), a plurality of tool supports (40) concentrically disposed about the rotational axis (12) in a releasable manner, and a plurality of cutting bit carriers (50) attached to each of the plurality of tool supports (40). When at least one of the plurality of cutting bits (60) is worn, the tool support (40) including worn cutting bits (60) may be replaced by a new tool support (40) including new cutting bits (60).

IPC Classes  ?

  • E21C 27/24 - Mineral freed by means not involving slitting by milling means acting on the full working face

40.

TOOL SUPPORT FOR CUTTING HEADS


Application Number EP2014001288
Publication Number 2014/194979
Status In Force
Filing Date 2014-05-13
Publication Date 2014-12-11
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Raschka, Joachim
  • Berger, Stefan
  • Rohwer, Jan
  • Kortmann, Oliver

Abstract

The present disclosure relates to a replaceable tool support (40; 140) configured to be mounted to a cutting head (10; 110 used in hard rock mining applications. The disclosed tool support (40; 140) may comprise an annular body (90; 190), a plurality of cutting bit carriers (50; 150) disposed spaced apart from each other on a first end face side (92; 192) of the annular body (90; 190), and a plurality of cutting bits (60). Each of the plurality of cutting bits (60) may be rotatably supported by one of the plurality of cutting bit carriers (50). When at least one of the plurality of cutting bits (60) is worn, the tool support (40; 140) including worn cutting bits (60) may be replaced by a new tool support (40; 140) including new cutting bits (60).

IPC Classes  ?

  • E21C 27/24 - Mineral freed by means not involving slitting by milling means acting on the full working face
  • E21C 35/19 - Means for fixing picks or holders
  • E21B 10/633 - Drill bits characterised by parts, e.g. cutting elements, which are detachable or adjustable with plural detachable cutting elements independently detachable

41.

DRIVE CONNECTION WITH INTEGRATED CHAIN TENSIONING APPARATUS FOR FACE CONVEYORS


Application Number EP2014001101
Publication Number 2014/183831
Status In Force
Filing Date 2014-04-24
Publication Date 2014-11-20
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Gacka, Adam
  • Johnson, Jessica
  • Scheer, Andreas
  • Grimm, Dennis
  • Kleinbongartz, Tobias
  • Hoelken, Thomas
  • Nafe, Michael
  • Pientka, Peter
  • Bauhaus, Svenja
  • Jänsch, Alexander

Abstract

The present disclosure relates to a drive connection (20) configured to be interconnected between a main driving unit (30) and a main gear unit (40) of a driving device configured to drive a chain (6) of a conveyor (4) of a longwall device. The exemplary disclosed drive connection (20) may comprise a housing (22) configured to be connected to the main driving unit (30) and to the main gear unit (40), a drive shaft (24) disposed within the housing (22) and configured to transmit torque from the main driving unit (30) to the main gear unit (40) and a chain tensioning apparatus (60). For having a compact drive connection (20), the chain tensioning apparatus may be disposed within the housing (22) and may include a worm drive interacting with the drive shaft (24).

IPC Classes  ?

  • B65G 23/44 - Belt- or chain-tensioning arrangements
  • E21C 29/14 - Propulsion of machines for slitting or completely freeing the mineral from the seam by cable or chains by haulage cable or chain pulling the machine along the working face

42.

CONTROL METHOD FOR LONGWALL SHEARER


Application Number EP2014001250
Publication Number 2014/183854
Status In Force
Filing Date 2014-05-09
Publication Date 2014-11-20
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Westphalen, Andreas Johannes
  • Kirkhope, Euan
  • Saikia, Siddartha
  • Ranjalkar, Hrishikesh

Abstract

The present disclosure generally relates to a method for controlling a shearer (10) in an underground mine. The method comprises setting a first cutting profile (50) including a plurality of desired positions (Di) to be approached by a first cutting drum (12) in a first travel direction (E), advancing the shearer (10) towards the longwall face (2), and generating a second cutting profile (51) including a plurality of desired positions (Ri) to be approached by at least one of the first cutting drum (12) and a second cutting drum (14) in a second travel direction (F) of the shearer (10) based on the set first cutting profile (50), a plurality of actual advancing vectors (vi), and a plurality of shearer orientations (Oi).

IPC Classes  ?

  • E21C 35/24 - Remote control specially adapted for machines for slitting or completely freeing the mineral
  • E21C 27/32 - Mineral freed by means not involving slitting by adjustable or non-adjustable planing means with or without loading arrangements

43.

MILLING DEVICE


Application Number EP2014001251
Publication Number 2014/183855
Status In Force
Filing Date 2014-05-09
Publication Date 2014-11-20
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Raschka, Joachim
  • Bechem, Ulrich
  • Steinberg, Jens

Abstract

The present disclosure generally relates to a milling device (10). Said milling device (10) may comprise a shaft (14) having a shaft axis (A) and a spindle drum (12) rotatably mounted relative to the shaft axis (A) and rotatable about a spindle drum axis (B) coaxial to the shaft axis (A). The milling device (10) may further comprise a plurality of tool spindles (16, 18) rotatably mounted in the spindle drum (12) and rotatable about tool spindle axes (D) parallely arranged spaced apart from the shaft axis (A), and a plurality of machining tools (20, 22) carried by the tool spindles (16, 18). At least two of the plurality of machining tools (20, 22) may be positioned displaced from one another in the direction of the shaft axis (A) which may allow deep and wide cuts, for example, in road milling and mining applications.

IPC Classes  ?

  • E21C 27/22 - Mineral freed by means not involving slitting by rotary drills with breaking-down means, e.g. wedge-shaped drills
  • E01C 23/09 - Devices or arrangements for working the finished surfaceDevices for repairing the surface of damaged paving for forming cuts, grooves, or recesses, e.g. for making joints or channels for markings, for cutting-out sections to be removedDevices or arrangements for working the finished surfaceDevices for repairing the surface of damaged paving for cleaning, treating, or filling cuts, grooves, recesses, or fissuresDevices or arrangements for working the finished surfaceDevices for repairing the surface of damaged paving for trimming paving edges
  • E21D 9/10 - Making by using boring or cutting machines

44.

MINING PLOW WITH PUSHROD


Application Number EP2014001045
Publication Number 2014/177253
Status In Force
Filing Date 2014-04-17
Publication Date 2014-11-06
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Siepenkort, Gerhard
  • Hesse, Norbert
  • Tillessen, Uwe
  • Duhnke, Klaus
  • Bettermann, Diedrich

Abstract

A mining plow (1) for a longwall mining system in an underground mine is disclosed. The mining plow (1) comprises a plow body (10) and a pushrod (62). The pushrod (62) is displaceably arranged within the plow body (10) to form a positive coupling between a first cutting bit carrier (12) pivotably supported on the plow body (10) via a first pivot pin and a second cutting bit carrier (14) pivotably supported on the plow body (10) via a second pivot pin. The pushrod (62) is arch-shaped to pass around a central roof cutting bit carrier assembly which may facilitate a wear-protected arrangement of the pushrod (62) within the plow body (10).

IPC Classes  ?

  • E21C 27/34 - Machine propelled along the working face by cable or chain

45.

Prop head bearing device for shield supports


Application Number 14215978
Grant Number 09458716
Status In Force
Filing Date 2014-03-17
First Publication Date 2014-09-25
Grant Date 2016-10-04
Owner Caterpillar Global Mining Europe GmbH (Germany)
Inventor
  • Horn, Swetlana
  • Pletsch, Ulrich

Abstract

A prop head bearing device used for a shield support and to receive a prop head includes a prop head bearing main body with a prop head receiving portion, a flange adjacent to the prop head receiving portion and a flange bore, and a receiving portion adjacent to the flange and remote from the prop head receiving portion. The prop head bearing device may also include a securing element including a securing element bore adapted in shape to the receiving portion, such that in the mounted state the securing element is locked with respect to the bore direction of the flange bore and that the securing element bore is aligned to the flange bore.

IPC Classes  ?

  • E21D 15/55 - Details of the ends of props of prop heads
  • E21D 23/04 - Structural features of the supporting construction, e.g. linking members between adjacent frames or sets of propsMeans for counteracting lateral sliding on inclined floor
  • E21D 23/00 - Mine roof supports for step-by-step movement, e.g. in combination with provisions for shifting of conveyors, mining machines or guides therefor

46.

LUMP CRUSHER FOR A SCRAPER CHAIN CONVEYOR


Application Number EP2013002743
Publication Number 2014/139546
Status In Force
Filing Date 2013-09-12
Publication Date 2014-09-18
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Wleklinski, Bernhard
  • Baier, Eugen
  • Pietrala, Christoph

Abstract

A coarse crusher (18) for use at both face ends of a face conveyor in an underground mine is disclosed. The coarse crusher (18) may comprise a pan module (20), a base-frame module (22) and a support-arm module (24). The pan module (20) has two pan outer longitudinal sides (46, 48). Depending on the face end of the face conveyor, into which face end the coarse crusher (18) is to be integrated, the base-frame module (22) may be fastened releasably via first pan fastening apparatuses (50) to that first or second pan outer longitudinal side (46, 48) which faces away from a working face.

IPC Classes  ?

  • E21F 13/06 - Transport specially adapted to underground conditions at or adjacent to the working face
  • B65G 19/00 - Conveyors comprising an impeller or a series of impellers carried by an endless traction element and arranged to move articles or materials over a supporting surface or underlying material, e.g. endless scraper conveyors

47.

ENSURING WORKING CONDITIONS ALONG A LONGWALL FACE


Application Number EP2014000649
Publication Number 2014/139671
Status In Force
Filing Date 2014-03-11
Publication Date 2014-09-18
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor Schuster, Reiner

Abstract

The present disclosure relates to a method and device for ensuring working conditions along a longwall face of a longwall mine. A longwall installation unit (5; 16) configured to form a longwall installation assembly (4; 17) together with a plurality of longwall installation units (5; 16) of the same kind may comprise a dilution gas nozzle (30, 30') installed in the longwall installation unit (5; 16) and configured to be fluidly connected to a compressor device. Dilution gas provided by dilution gas nozzle (30) may locally dilute methane gas, for example, in response to a measured methane gas concentration or concentration trend, and thereby ensure working conditions for man and machine.

IPC Classes  ?

  • G01N 33/00 - Investigating or analysing materials by specific methods not covered by groups
  • E21F 5/02 - Means or methods for preventing, binding, depositing or removing dustPreventing explosions or fires by wetting or spraying
  • E21C 27/02 - Machines which completely free the mineral from the seam solely by slitting
  • E21C 35/24 - Remote control specially adapted for machines for slitting or completely freeing the mineral

48.

EXTRACTION INSTALLATION FOR MINERAL EXTRACTION


Application Number EP2013003439
Publication Number 2014/075806
Status In Force
Filing Date 2013-11-14
Publication Date 2014-05-22
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Klabisch, Adam
  • Ziegler, Manfred

Abstract

The present disclosure relates to an extraction machine (50) of an extraction installation (10) for mineral mining. The extraction machine (50) may comprise a first chain mount (8) configured to be connected to a first chain strand section (1A) of a chain (1), and a second chain mount (9) configured to be connected to the second chain strand section (1B) of the chain (1). The extraction machine (50) may further comprise a first pre-tensioning device (40) for building up a pre-tensioning force acting on the first chain mount (8) such that a pulling force acts on the first chain strand section (1A) in the direction of the second chain mount (9). Thereby, the operational behaviour of the extraction machine and/or the extraction installation may be improved.

IPC Classes  ?

  • E21C 29/14 - Propulsion of machines for slitting or completely freeing the mineral from the seam by cable or chains by haulage cable or chain pulling the machine along the working face
  • E21C 27/34 - Machine propelled along the working face by cable or chain

49.

CHAIN WHEEL FOR APRON CONVEYOR


Application Number EP2013003104
Publication Number 2014/067620
Status In Force
Filing Date 2013-10-15
Publication Date 2014-05-08
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor Voigt, Robert

Abstract

The present disclosure generally relates to a chain wheel (10) for driving or diverting a conveyor chain (1) of an apron conveyor (50). The apron conveyor (50) may include transport plates releasably connectable via a plurality of chain connecting parts (9) to the conveyor chain (1). The chain wheel (10) may comprise a chain wheel body (11) including a lateral face (11 '), and teeth (13) arranged peripherally offset over the lateral face (11'). The chain wheel (10) may further comprise a plurality of bearing faces (19; 29) arranged peripherally offset over the lateral face (11 ') between two adjacently situated teeth (13; 23) and configured to receive the chain connecting parts (9). Thus, a chain wheel which may have a low overall height may be provided.

IPC Classes  ?

  • B65G 17/42 - Attaching load-carriers to traction elements
  • B65G 23/06 - Drums, rollers, or wheels with projections engaging abutments on belts or chains, e.g. sprocket wheels

50.

TENSIBLE RETURN UNIT FOR APRON CONVEYOR


Application Number EP2013003096
Publication Number 2014/067618
Status In Force
Filing Date 2013-10-15
Publication Date 2014-05-08
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor Voigt, Robert

Abstract

The present disclosure directs to a reversing station (10) of an apron conveyor for mined or extracted ground material. The reversing station (10) may comprise a machine frame (14) including a base (8), a slide construction (20) movable relative to the machine frame (14) by means of an adjusting device (30) and having a guide base (22) displaceably guided in a recess (16) in the base (8), a chain wheel (11) fastened to the slide construction (20), guide elements (24) fastened to the guide base (22) and cooperating with guide rails (41) fixedly fastened to the base (8), and a fixing device mountable to the slide construction (20) lockable in different displacement positions by means of the fixing device. The chain wheel (11) may be disposed on the slide construction (20) in a middle portion between a stop (21) for the adjusting device (30) and the guide base (22) of the slide construction (20).

IPC Classes  ?

  • B65G 23/44 - Belt- or chain-tensioning arrangements

51.

DRIVE UNIT FOR CHAIN DRIVES IN MINING


Application Number EP2013002742
Publication Number 2014/044369
Status In Force
Filing Date 2013-09-12
Publication Date 2014-03-27
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Gacka, Adam
  • Jänsch, Alexander
  • Scheer, Andreas
  • Grimm, Dennis
  • Johnson, Jessica
  • Nafe, Michael
  • Pientka, Peter
  • Hoelken, Thomas
  • Kleinbongartz, Tobias

Abstract

The present disclosure refers to a drive unit for chain drives in mining. The drive unit may comprise at least one drive motor (12), a gearing unit (11) coupleable to the drive motor (12), and a power supply housing (15) provided with flange connections (17, 19) on its right and left sides. The at least one drive motor (12) and the gearing unit (11) both may be configured to be both connectable optionally on the right hand side or left hand side flange connection (17, 19) of the power supply housing (15). Further, a power supply unit (14) housing supply assemblies (14) for the drive motor (12) and/or the gearing unit (11) may be provided. The power supply unit (14) may be mounted in the power supply housing (15).

IPC Classes  ?

  • E21C 29/16 - Winches or other means for pulling cable or chain
  • B65G 23/22 - Arrangements or mountings of driving motors

52.

MOBILE MINING


Application Number EP2013002430
Publication Number 2014/026761
Status In Force
Filing Date 2013-08-13
Publication Date 2014-02-20
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Krings, Johannes
  • Raschka, Joachim
  • Rohwer, Jan
  • Kortmann, Oliver
  • Bechem, Ulrich
  • Schreiter, Christian
  • Steinberg, Jens

Abstract

The present disclosure relates to a mobile mining machine (10) which may comprise a movable machine base frame (1), a rotatable tool drum (4) and including excavating tools (6). The mobile mining machine (10) may further comprise a cantilever unit (5) including a front support arm part (8) and a base part (9), and a pivotal device (27) to pivot the cantilever unit (5). The mobile mining machine (10) may further comprise a tilt device (12) to tilt the cantilever unit (5) and a rotary mechanism (11) to rotate the support arm part (8) and the tool drum (4). Thus, a mobile mining machine (10) with which tunnels, galleries or shafts may be continuously driven in even in hard rock with a high mining output and low tool wear may be provided.

IPC Classes  ?

  • E21C 27/24 - Mineral freed by means not involving slitting by milling means acting on the full working face
  • E21D 9/10 - Making by using boring or cutting machines

53.

SUPPORT STRUCTURE FOR REVERSING STATION IN AN UNDERGROUND MINING CONVEYOR


Application Number EP2013002151
Publication Number 2014/012674
Status In Force
Filing Date 2013-07-19
Publication Date 2014-01-23
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Baier, Eugen
  • Schmidt, Siegfried

Abstract

A support structure (14) for drive or reversing stations of conveyor or extraction devices in underground mining is described. The support structure (14) has a substructure and an articulated support which may be configured to be vertically adjustable relative thereto by means of a lifting device. At least one spacer element is provided which is configured to be installed between the substructure and the articulated support. A lifting device (18) has two pairs (21A, 21B) of lifting cylinders (21) whose lifting cylinders are arranged diagonally opposite one another in corner areas of the articulated support (17) and can be actuated in pairs, and that as the spacer element (20) for a lifting stage at least four, preferably six, distance members (23) are provided of which two in each case are placeable in pairs underneath the pair (21A, 21B) of lifting cylinders (21) which is not loaded during a lifting process.

IPC Classes  ?

  • E21F 13/06 - Transport specially adapted to underground conditions at or adjacent to the working face
  • B65G 41/00 - Supporting frames or bases for conveyors as a whole, e.g. transportable conveyor frames
  • B66F 7/00 - Lifting frames, e.g. for lifting vehiclesPlatform lifts

54.

SCRAPER FOR CHAIN SCRAPER CONVEYORS


Application Number EP2013001524
Publication Number 2013/182275
Status In Force
Filing Date 2013-05-23
Publication Date 2013-12-12
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor Klingbeil Willi

Abstract

The present disclosure relates to a scraper (10) for chain scraper conveyors, particularly twin chain scraper conveyors. The scraper (10) may comprise a one-piece scraper bridge (1) including two side scraper wings (2) connected by a head web (3), a retaining bracket (20) insertable from an underneath side (6) of the scraper bridge (1) into an insert recess (8), and a locking device. The retaining bracket (20) may be insertable for detachabii locking the scraper (10) on a chain link of a scraper chain. The retaining bracket (20) may engage with grooves (11) on either side of the insert recess (8) in an assembled state. The scraper (10) may further include a locking device for securing the assembly state of the retaining bracket (20) in the insert recess (8), wherein the retaining bracket (20) may be displaceable in the associated insert recess (8) parallel to the head web (3) on one of the scraper wings (2) into a locking position and having at least one retaining cam.

IPC Classes  ?

  • B65G 19/10 - Conveyors comprising an impeller or a series of impellers carried by an endless traction element and arranged to move articles or materials over a supporting surface or underlying material, e.g. endless scraper conveyors for moving bulk material in open troughs or channels the impellers being scrapers similar in size and shape to the cross-section of the trough or channel and attached to a pair of belts, ropes, or chains
  • B65G 19/24 - Attachment of impellers to traction element

55.

TRANSMISSION, IN PARTICULAR FOR DRIVE SYSTEMS OF CONSTRUCTION MACHINES AND MINING MACHINES


Application Number EP2013001209
Publication Number 2013/159905
Status In Force
Filing Date 2013-04-23
Publication Date 2013-10-31
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Kleinbongartz, Tobias
  • Gacka, Adam
  • Jänsch, Alexander
  • Scheer, Andreas
  • Grimm, Dennis
  • Johnson, Jessica
  • Nafe, Michael
  • Pientka, Peter
  • Hoelken, Thomas

Abstract

The present disclosure generally refers to a transmission (1) comprising a transmission housing and at least one transmission stage (2; 12) arranged in the transmission housing. The transmission stage (2; 12) may include, coaxially with respect to an axis (A), a sun gear (5; 15), a planet carrier (7; 17) with at least two planet gears (9; 19) rotatably mounted on the planet carrier; and an internal gear (6; 16) as transmission parts. At least one stop means (10) may be provided for limiting the axial movement of two transmission parts (5; 15; 7; 17; 9; 19; 6; 16) which are movable relative to one another. The stop means (10) may comprise a ball pair with a first ball (30) assigned to a first transmission part and a second ball (31) assigned to a second transmission part. The two balls (30; 31) may be arranged so as to be rotatable about their ball centre on the axis (A).

IPC Classes  ?

  • F16H 1/46 - Systems consisting of a plurality of gear trains, each with orbital gears
  • F16H 57/02 - GearboxesMounting gearing therein

56.

MINING PLOW


Application Number EP2013000804
Publication Number 2013/143658
Status In Force
Filing Date 2013-03-15
Publication Date 2013-10-03
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Hesse, Norbert
  • Siepenkort, Gerhard
  • Klabisch, Adam

Abstract

A coal mining mining plow (1) comprising a plow base (4), two cutting bit carriers (7) pivotably supported on a respective pivot pin (8), a roof cutting bit carrier (12) attached to the plow base (4) in a height-adjustable manner, and an attachment member (20) settable on the plow base (4) is disclosed. The attachment member (20) may include ancillary cutting bit columns (21) provided with extraction cutting bits (22). Each ancillary cutting bit column (21) may be respectively positioned in its extraction position for a plow trip above a cutting bit carrier (7), and an intermediate member (30) may be disposed between the attachment member (20) and each ancillary cutting bit column (21). The intermediate member (30) may be foldable attached to the attachment member (20) and may be folded away into an installation position, in which the corresponding cutting bit carrier (7) is removable while the attachment member (20) and the intermediate part (30) remain installed.

IPC Classes  ?

  • E21C 27/34 - Machine propelled along the working face by cable or chain

57.

SLAT CONVEYOR FOR EXTRACTION SYSTEMS AND TRANSPORT PLATES THEREFOR


Application Number EP2013000634
Publication Number 2013/131636
Status In Force
Filing Date 2013-03-01
Publication Date 2013-09-12
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Brotzmann, Gerhard
  • Kortmann, Oliver
  • Raschka, Joachim
  • Padberg, Hendrik
  • Voigt, Robert

Abstract

The present disclosure relates to a slat conveyor (1) for transporting material in mining and extraction systems. The slat conveyor (1) may comprise a plurality of channel elements arranged in a series, a material-transport strand (7) and an oppositely-moving return strand (8). The slat conveyor (1) may further comprise an endless conveyor (10) including a conveyor chain (11) and a plurality of transport plates (20) with a plate section, which may be pivotable downward in a delivery area for the transported material. Thus, for example, a flat-constructed slat conveyor (apron conveyor) having a low loading height may be provided.

IPC Classes  ?

  • B65G 17/18 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriersEndless-chain conveyors in which the chains form the load-carrying surface comprising individual load-carriers which are pivotally mounted, e.g. for free-swinging movement and move in contact with a guiding surface
  • B65G 47/38 - Devices for discharging articles or materials from conveyors by dumping, tripping, or releasing load-carriers
  • B65G 47/96 - Devices for tilting links or platforms
  • E21F 13/06 - Transport specially adapted to underground conditions at or adjacent to the working face

58.

SUPPORT STRUCTURE FOR DRIVE OR RETURN STATIONS USED IN UNDERGROUND MINING


Application Number EP2013000556
Publication Number 2013/127517
Status In Force
Filing Date 2013-02-26
Publication Date 2013-09-06
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Tillessen, Uwe
  • Duhnke, Klaus
  • Siepenkort, Gerhard
  • Hesse, Norbert

Abstract

The disclosed support structure (13) for drive or return stations (11) for use in underground mining includes a base plate (15) resting on a floor (14) and a pi vo table carrier (22), to which the drive or return station (11) to be supported is connectable, wherein the pivotable carrier (22) is height-adjustable and fixable at different heights relative to the base plate (15). According to the present disclosure, the base plate (15) is provided with at least two spaced-apart support post elements (20), on each of which a plurality of first locking holes (26) is disposed at different heights. The pivotable carrier (22) is disposed on a support device (21), which is provided with post guides (25) that accommodate the support post elements (20) in a height-adjustable manner. The post guides (25) include second locking holes (27), which are lockable with selected ones of first locking holes (26) using locking bolts (38).

IPC Classes  ?

  • E21D 9/12 - Devices for removing or hauling away excavated material or spoilWorking or loading platforms
  • E21F 13/06 - Transport specially adapted to underground conditions at or adjacent to the working face

59.

PLUG-IN CONNECTION WITH RETAINING ELEMENT AND RETAINING ELEMENT FOR THIS PURPOSE


Application Number EP2012004956
Publication Number 2013/087154
Status In Force
Filing Date 2012-11-30
Publication Date 2013-06-20
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Suilmann, Franz-Heinrich
  • Bernemann, Leonie
  • Scherweit, Björn

Abstract

The present disclosure relates to a plug-in connection (10), in particular for hydraulic hose lines. The plug-in connection (10) may comprise a first plug connector part (1) having a circumferential groove on a plug-in nipple (3), a plug-in sleeve (3) as the female part having two transverse bores (9), a fork- shaped coupling bracket (5). The fork-shaped coupling bracket (5) may comprise two bracket portions (7) and one bracket curve (6), which bracket (5) may be being inserted, in the mounted state of the plug-in sleeve (3) and the plug-in nipple (2), into the transverse bores (9) for locking the plug-in connection to the bracket portions (7) and penetrate the groove (16) transversely with respect to the plug-in axis. A retaining element (30) for retaining the coupling bracket (5) against unwanted release may be provided. The retaining element (30) may comprise an accommodating portion (32) for the bracket curve (6). The retaining element (30) may have two holding arms (31) which are spaced apart from each other, which are connected by means of a base (33) at rear ends of the holding arms facing the accommodating portion (32), and which define at front ends (34) a mounting mouth (35) which can be slipped onto the plug-in nipple (2) and/or the plug-in sleeve (3) in a transverse manner with respect to the plug-in axis (S) of the plug-in connection (10).

IPC Classes  ?

  • F16L 37/14 - Joints secured by inserting between mating surfaces an element, e.g. a piece of wire, a pin, a chain

60.

A METHOD AND SYSTEM FOR INCREASING THE OPERATIONAL SAFETY OF MOBILE MACHINES IN ABOVEGROUND OR UNDERGROUND MINING OPERATIONS FOR THE EXTRACTION OF MINERALS BY UTILIZING THE RFID TECHNOLOGY


Application Number EP2012004486
Publication Number 2013/060469
Status In Force
Filing Date 2012-10-26
Publication Date 2013-05-02
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Ahler, Marco
  • Stelter, Sascha
  • Hauck, Christian

Abstract

The present disclosure relates to a method for increasing the operational safety of mobile machines (50) in aboveground or underground mining operations for the extraction of minerals by utilizing RFID technology. At least one transmitting unit (21) may be provided at the mobile machine (50). At least one receiving unit and at least one non-machine-related RFID transponder which can be activated by means of the transmitting unit and in the case of activation is contactlessly detected, may be provided. In addition, at least one reference transponder (7) and a control unit for actuating the transmitting unit and evaluating transponder signals in measuring cycles may be provided. To improve the energy requirement of the method and of a system designed therefor, the reference transponder (7) may be mounted on the mobile machine (50) at a defined distance, stored in the control unit, from the transmitting unit (21). The signal field strength L of the transmitter signal of the transmitting unit (21) may be changed in dependence on the response signal of the reference transponder (7) in a calibration cycle (KCB) for eliminating the environmental influences.

IPC Classes  ?

  • G01S 5/00 - Position-fixing by co-ordinating two or more direction or position-line determinationsPosition-fixing by co-ordinating two or more distance determinations
  • E21F 17/18 - Special adaptations of signalling or alarm devices
  • G06K 7/10 - Methods or arrangements for sensing record carriers by electromagnetic radiation, e.g. optical sensingMethods or arrangements for sensing record carriers by corpuscular radiation

61.

A THROUGH SECTION FOR SCRAPER CHAIN CONVEYORS WITH A SPILL PLATE ATTACHMENT AND SPILL PLATE ATTACHMENT THEREFOR


Application Number EP2012004430
Publication Number 2013/060446
Status In Force
Filing Date 2012-10-23
Publication Date 2013-05-02
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Hesse, Norbert
  • Siepenkort, Gerhard
  • Duhnke, Klaus
  • Klabisch, Adam
  • Padberg, Hendrik

Abstract

The present disclosure relates to a trough section for a scraper chain conveyor, comprising a conveying trough (2) having on at least one side a lateral boundary (3) to which a spill plate attachment (4) with a spill plate (5) is fastened. In order to provide a trough section and a spill plate attachment for a trough section, which may make it possible with low outlay in mounting terms to raise or lower the lateral boundary of the conveying trough quickly and reliably, the spill plate (5) may be fastened on the spill plate attachment (4) pivotably about a first pivot axis (6) and may be pivotable between a storage position and an operating position, in which position the spill plate (5) may be raising the lateral boundary (3).

IPC Classes  ?

62.

DEVICE MACHINING MATERIALS BY MILLING OR DRILLING, AND METHOD THEREFOR


Application Number US2012056977
Publication Number 2013/048974
Status In Force
Filing Date 2012-09-25
Publication Date 2013-04-04
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Muller, Martin
  • Anderegg, Roland
  • Kurmann, Lukas

Abstract

The invention relates to a method and a device for machining materials by milling and/or drilling, in particular for removing rock, concrete, minerals or coal, having a tool drum (10) in which a plurality of tool shafts (9) which bear machining tools (7) at their ends projecting from the tool drum (10) are mounted such that they can be driven in rotation. A drive element (12) for the tool shafts and the tool drum (13) can be rotated relative to each other, and the drum carrier can be moved relative to the material by using a movement device (6, 7). By means of a control device, the speed of the relative movement between tool carrier (2) and material and the rotational speed of the tool drum (10) can be varied. In order to avoid critical operating points, the device is assigned at least one measuring sensor (30) for measuring the natural translational vibration and/or at least one measuring sensor (32; 34) for determining the rotational vibrations of the tool drum (10), and the control device has at least one vibration analysis module, by means of which, in a vibration analysis, a vibration spectrum can be determined, and at least one controller module, by means of which drive parameters can be or are controlled as a function of the vibrations determined by the analysis module.

IPC Classes  ?

  • E21C 25/10 - RodsDrums
  • E21C 27/24 - Mineral freed by means not involving slitting by milling means acting on the full working face

63.

APPARATUS FOR THE MILLING CUTTING OF ROCK, MINERALS OR OTHER MATERIALS


Application Number IB2012052053
Publication Number 2012/156841
Status In Force
Filing Date 2012-04-24
Publication Date 2012-11-22
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Steinberg, Jens
  • Raschka, Joachim
  • Herrmann, Frank
  • Schreiter, Christian

Abstract

The apparatus according to the invention for the milling cutting of rock, minerals or other, in particular hard, materials, which preferably can be used on a part-face heading machine (10) in underground mining, has two tool drums (17), which are arranged rotatably mounted side by side in twin arrangement on a drum carrier (13) and which are respectively provided with a plurality of tool carriers (19) which support cutting tools (20) arranged distributed over the periphery of the tool drums and which can be rotatingly driven and the shaft axes (21) of which run substantially transversely to the drum axle (16). According to the invention, the arrangement is made such that the shaft axes of the tool carriers of the first tool drum span a first conical surface (23) about the drum axis and the shaft axes of the tool carriers of the second tool drum span a second conical surface (24) about the drum axis, wherein the conical surfaces are open to opposite sides and are preferably oriented such that they are mutually inclined in O-arrangement.

IPC Classes  ?

  • E21C 27/22 - Mineral freed by means not involving slitting by rotary drills with breaking-down means, e.g. wedge-shaped drills
  • E21C 35/12 - Guiding the machine along a conveyor for the cut material

64.

APPARATUS FOR THE MILLING CUTTING OF ROCK, MINERALS OR OTHER MATERIALS


Application Number IB2012052056
Publication Number 2012/156842
Status In Force
Filing Date 2012-04-24
Publication Date 2012-11-22
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Rohwer, Jan
  • Steinberg, Jens
  • Raschka, Joachim
  • Herrmann, Frank
  • Schreiter, Christian

Abstract

The apparatus (14) according to the invention for the milling cutting of rock, minerals or other, in particular hard, materials which can preferably be used as a part-face heading machine (10) in underground mining, has a tool drum (15) which is mounted on a drum carrier (13) rotatably about a drum axis (16) and on the peripheral shell surface (17) of which are disposed, in distributed arrangement, a plurality of tool carriers (18), which carry cutting tools (19) and can be rotatingly driven, wherein their shaft axes (20) run transversely to the drum axis (16). In order to be able to mill out the rock or the like particularly effectively from the working face in both feed directions of the apparatus, which feed directions run substantially parallel to the drum axis (16), it is proposed with the invention that a first group (A) of tool carriers and a second group (B) of tool carriers are provided, wherein the rotational direction (21 A) of the first group (A) is counter to the rotational direction (21B) of the second group (B), and wherein, in a particularly preferred embodiment of the invention, the shaft axes of the tool carriers of the first group (A) and of the second group (B) are oriented at different setting angles (22A, B) relative to the radial direction (23) of the tool drum.

IPC Classes  ?

  • E21C 27/22 - Mineral freed by means not involving slitting by rotary drills with breaking-down means, e.g. wedge-shaped drills
  • E21C 27/24 - Mineral freed by means not involving slitting by milling means acting on the full working face
  • E21C 31/02 - Driving means incorporated in machines for slitting or completely freeing the mineral from the seam for cutting or breaking-down devices

65.

MOBILE MINING MACHINE AND METHOD FOR DRIVING TUNNELS, ROADWAYS OR SHAFTS, IN PARTICULAR IN HARD ROCK


Application Number IB2012052057
Publication Number 2012/156843
Status In Force
Filing Date 2012-04-24
Publication Date 2012-11-22
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Rohwer, Jan
  • Steinberg, Jens
  • Raschka, Joachim
  • Herrmann, Frank
  • Schreiter, Christian
  • Bechem, Ulrich
  • Kortmann, Oliver
  • Krings, Johannes, Dr.

Abstract

The invention relates to a mobile mining machine, in particular for driving and advancing tunnels for example in hard rock, with a movable machine base frame 1, with (at least) one tool drum 50, which can be rotated about a drum axis T and has stripping tools 54 arranged on the circumference of the tool drum, with a rotary drive for the tool drum 50, with a boom device 20, with a swinging device for swinging the boom device 20, and with a tilting device 40 for tilting the boom device 20. In order to be able to bring about the driving and advancing with a high extraction rate and low tool wear, the boom device 20 has a supporting arm 22, on which the tool drum 50 is mounted, and a separate swinging base 21, the supporting arm 22 and the swinging base 21 being connected to one another by means of a system of guide bars 23, preferably formed as a trapezoidal four-bar linkage system, by way of which the setting angle of the drum axis T in relation to the swing axis S can be adjusted.

IPC Classes  ?

  • E21C 27/24 - Mineral freed by means not involving slitting by milling means acting on the full working face
  • E21D 9/10 - Making by using boring or cutting machines

66.

MINING INSTALLATION FOR EXTRACTING SEAM-TYPE OR MASS-DEPOSIT MINERAL MATERIALS, AND MINING MACHINE FOR THE SAME


Application Number IB2012052358
Publication Number 2012/156884
Status In Force
Filing Date 2012-05-11
Publication Date 2012-11-22
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Steinberg, Jens
  • Raschka, Joachim
  • Herrmann, Frank
  • Mohe, Hartmut

Abstract

The invention relates to a mining machinery and mining installation for extracting seam-type or mass-deposit mineral materials, comprising a conveyor device for carrying away mined material, and comprising a mining machine 10 that can be moved along the conveyor device 5 and that comprises at least one drum 19, which is equipped with extracting tools 17, is rotatable about its drum axis W and is adjustable in height relative to a machine frame 11 by means of a swivel arm 21. In order to provide a mining installation, and also a mining machine, by means of which high extraction capacities can be achieved with, at the same time, reduced tool wear, the invention proposes that the drum axis W of the drum 19 is substantially parallel to the direction of travel of the mining machine 10, the extracting tools 17 being mounted in groups on tool carriers 18, which are disposed on the circumference of the drum 19 so as to be rotatable about rotation axes disposed transversely in relation to the drum axis W.

IPC Classes  ?

  • E21C 27/22 - Mineral freed by means not involving slitting by rotary drills with breaking-down means, e.g. wedge-shaped drills
  • E21C 35/12 - Guiding the machine along a conveyor for the cut material
  • E21C 31/08 - Driving means incorporated in machines for slitting or completely freeing the mineral from the seam for adjusting parts of the machines

67.

DRIVE SYSTEM


Application Number AU2012000496
Publication Number 2012/151624
Status In Force
Filing Date 2012-05-09
Publication Date 2012-11-15
Owner
  • YANCOAL TECHNOLOGY DEVELOPMENT PTY LTD (Australia)
  • CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Chandler, Steven
  • Wang, Maohu Matthew

Abstract

A drive system for driving a conveyor associated with long wall mining equipment, including: a drive frame with a cradle that supports a return shaft for driving a conveyor; a drive unit with a drive motor arranged substantially parallel to the conveyor and adjacent to the frame and a rotatable output member arrange to rotate about an axis of the motor, in a direction substantially orthogonal to the shaft; a gearbox for translating rotary movement transversely of the output member into rotary movement of an output gear about a second axis, parallel to the return shaft, the output gear being coupled to the shaft to drive the conveyor; wherein the drive unit is arranged in line with the drive frame and conveyor; and the output gear of the gearbox is coupled to the return shaft through a geared transmission to accommodate the in line arrangement of the drive unit and drive frame.

IPC Classes  ?

  • E21C 41/18 - Methods of underground miningLayouts therefor for brown or hard coal
  • E21C 35/20 - General features of equipment for removal of chippings, e.g. for loading on conveyor
  • E21C 31/12 - Component parts

68.

APPLIANCE AND ARRANGEMENT FOR OPTICAL SIGNAL TRANSMISSION BY MEANS OF OPTICAL WAVEGUIDES


Application Number IB2011055749
Publication Number 2012/085802
Status In Force
Filing Date 2011-12-16
Publication Date 2012-06-28
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Ahler, Marco
  • Rüschkamp, Henner
  • Hengstler, Stefan

Abstract

The invention relates to an appliance for optical signal transmission by means of optical waveguides in explosion-hazard areas, in particular in underground mining, having an optical transmitter (4), having an optical output interface (12) for connection of an optical waveguide transmission path (14) and having a device for limiting the light power (8). The invention also relates to an arrangement for bi-directional optical signal transmission. In order to provide an appliance for optical signal transmission as well as an arrangement for bi-directional optical signal transmission in explosion-hazard areas, complying with the requirements for intrinsically safe operation of the transmission medium when separating or decoupling the transmission medium, the device for limiting the light power (8) is a passive optical component (8) which is connected in the optical signal path between the optical transmitter (4) and the optical output interface (12).

IPC Classes  ?

69.

CONNECTING DEVICE FOR A TROUGH PAN OF EXTRACTION DEVICES, TROUGH PAN AND ATTACHMENT THEREFOR


Application Number IB2011055433
Publication Number 2012/077025
Status In Force
Filing Date 2011-12-02
Publication Date 2012-06-14
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Tillessen, Uwe
  • Schlüsener, Frank
  • Pruss, Ingo
  • Wleklinski, Bernhard

Abstract

The invention relates to Connecting device for connecting an attachment to a side member of a trough pan of an extracting device, a trough pan and an attachment therefore. The connecting device is having first fittings 10 on a side member and counter fittings arranged on the attachment, which are detachably connectable to the fittings 10. Further, at least one retaining piece is provided which prevents in the closing position detachment of fitting and counter fitting. In order that the attachment is able to be mounted or removed in a quick and simple manner, the fitting 10tapers upward in a trapeze-shaped manner and the counter fitting tapers upward in a trapeze-shaped manner, wherein by means of a vertical movement, the fitting 10and the counter fitting are able to be fitted into each other or to be detached from each other, and wherein fitting 10 and counter fitting (are provided with locking strips 14 and/or grooves which interlock at least in the locking state.

IPC Classes  ?

  • E21F 13/06 - Transport specially adapted to underground conditions at or adjacent to the working face
  • B65G 19/28 - Troughs, channels, or conduits

70.

FACE CONVEYOR FOR EXTRACTION PLANTS AND TROUGH ELEMENT FOR SAID FACE CONVEYOR


Application Number IB2011055520
Publication Number 2012/077069
Status In Force
Filing Date 2011-12-07
Publication Date 2012-06-14
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Padberg, Hendrik
  • Steinberg, Jens
  • Siepenkort, Gerhard
  • Wirtz, Jörg
  • Hahn, Detlef
  • Raschka, Joachim

Abstract

The invention relates to a face conveyor for the extraction of minerals by means of extracting machines, said conveyor having a conveyor chain (70) which, when conveying, circulates in two an outward run and a return run that travel in opposite directions. Each of the runs is guided in trough portions (1, 2) by trough elements (10), having guide means (60) on each trough element (10) for the extracting machine, said guide means comprising at least one first guide means on the working face side and one second guide means (60) at a spacing from the goaf side. The invention also relates to the trough element. In order to create a face conveyor which is suitable, in particular, for the extracting of hard materials such as ores or dead rock, the guide means on the working face side is secured on the trough element (10) between the outward run (71) and the return run (72), wherein the outward run (71) and the return run (72) extend in a laterally offset manner with respect to each other and the trough portion (1) guiding the entrainment means in the outward run (71) is open on the working face side.

IPC Classes  ?

  • E21C 35/12 - Guiding the machine along a conveyor for the cut material
  • E21F 13/06 - Transport specially adapted to underground conditions at or adjacent to the working face
  • B65G 17/06 - Conveyors having an endless traction element, e.g. a chain, transmitting movement to a continuous or substantially-continuous load-carrying surface or to a series of individual load-carriersEndless-chain conveyors in which the chains form the load-carrying surface having a load-carrying surface formed by a series of interconnected, e.g. longitudinal, links, plates, or platforms
  • B65G 19/28 - Troughs, channels, or conduits

71.

MULTIPART CHAIN FIXING DEVICE, TROUGH ELEMENT AND PARTS FOR THE SAME


Application Number IB2011052516
Publication Number 2011/158157
Status In Force
Filing Date 2011-06-09
Publication Date 2011-12-22
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Baier, Eugen
  • Schmidt, Siegfried
  • Tillessen, Uwe
  • Fischer, Frank
  • Wirtz, Jörg
  • Wleklinski, Bernhard

Abstract

The invention relates to a multipart chain fixing device for securing at least one conveyor chain on a trough element of especially an underground scraper chain conveyor. The fixing device comprises a bridge part (60), which has a bridge bar (62) that at least partially overlaps the conveyor chain in a positive-locking manner and ends in two lateral side end portions (61). It also comprises two side parts (70), which are fastenable to the trough element pan and to which the side end portions 61are releasably securable by positive-locking means. For providing a chain fixing device, inclusive of the associated trough element and the individual components,which offer increased safety in underground usage, combined with simple assembly, the side parts (70) are releasably fastenable in a positive-locking manner in cavities in the conveyor floor of the trough element.

IPC Classes  ?

  • B65G 19/18 - Conveyors comprising an impeller or a series of impellers carried by an endless traction element and arranged to move articles or materials over a supporting surface or underlying material, e.g. endless scraper conveyors Details

72.

METHOD FOR LOCATING PERSONS AND/OR MOBILE MACHINES IN MINE CAVERNS USING RFID TECHNOLOGY, AND LONGWALL FACE EXTRACTION INSTALLATION FOR CARRYING OUT THE METHOD


Application Number IB2011051251
Publication Number 2011/121500
Status In Force
Filing Date 2011-03-24
Publication Date 2011-10-06
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Ahler, Marco
  • Stelter, Sascha
  • Westphalen, Andreas

Abstract

The invention relates to a method and a longwall face extraction installation having a device for locating persons and/or mobile machines in mine caverns using RFID technology, with a plurality of base stations (20) which are arranged in a distributed manner along the mine cavern to be monitored and have a transmitter and preferably a receiver, with at least one RFID transponder (12) which is associated with the person or machine to be located, has stored identification data, can be activated using the base station (20) and can be read in a contactless manner using the base station (20). In order to provide a method for locating persons and a longwall face extraction installation, in particular for coal mining, which make it possible to effectively use RFID technology, the transmitters at least of adjacently positioned base stations (20) along a region of the mine cavern to be monitored successively emit their transmission wave (21") in order to activate an RFID transponder (12).

IPC Classes  ?

  • E21F 17/18 - Special adaptations of signalling or alarm devices
  • G01S 13/74 - Systems using reradiation of radio waves, e.g. secondary radar systemsAnalogous systems
  • E21D 23/12 - Control, e.g. using remote control

73.

NETWORK INFRASTRUCTURE FOR MOBILE MACHINES WHICH CAN BE USED IN AREAS AT RISK OF EXPLOSION


Application Number IB2011050911
Publication Number 2011/110983
Status In Force
Filing Date 2011-03-03
Publication Date 2011-09-15
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Lenzing, Markus
  • Rüschkamp, Henner
  • Schwinne, Karsten
  • Weßelmann, Johannes

Abstract

The invention relates to a network infrastructure for mobile machines which are usable in explosive areas, having inherently safe participants 21 - 23 and not inherently safe network participants 31 - 33 the latter being arranged in pressure-resistant housings 7; 8. The machine has at least one controller 30 for actuating at least one not inherently safe participant 31. In order to provide a network infrastructure which avoids the drawbacks of the prior art, the machine has, outside the pressure-resistant housing 8 for the first controller 30, at least one second, inherently safe controller 20 for actuating at least one inherently safe participant 21, wherein the first controller 30 forms a data distributor for a plurality of not inherently safe participants 31 - 33 and the second controller 20 forms a data distributor for a plurality of inherently safe participants 21 - 23, and wherein the first data distributor 30 and the second data distributor 20 are linked via an electrically decoupled data communication link 40.

IPC Classes  ?

  • E21F 17/18 - Special adaptations of signalling or alarm devices
  • H04L 25/02 - Baseband systems Details

74.

METHOD FOR DETERMINING THE POSITION OF PLANT COMPONENTS IN MINING EXTRACTING PLANTS


Application Number IB2011050685
Publication Number 2011/101812
Status In Force
Filing Date 2011-02-18
Publication Date 2011-08-25
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Ahler, Marco
  • Stelter, Sascha
  • Westphalen, Andreas
  • Hengstler, Stefan
  • Pauli, Simon
  • Dehmel, Dennis
  • Hahn, Detlef

Abstract

The invention relates to a method for determining the position and/or location of plant components of a mining extracting plant, which includes at least one face conveyor (8), a shield- type support system (1) having a plurality of shield- type support frames (2) and an extracting machine (6) that is moveable along the face conveyor (8), wherein the position and/or location of at least one plant component is determined by way of an evaluation system that includes at least one detection unit (25). In order to be able to determine the location and/or position of at least one plant component even in the case of a dynamic mineral mining process, the at least one detection unit (25) includes an image sensor, by way of which at least four object points (21), which are at a predetermined spacing to each other and are detectable within the optical wavelength range, of at least one measuring object (20) associated with one of the plant components, are detected. Using the evaluation system, the position and/or location of the plant component can be determined from the projection of the object points detected by way of the image sensor.

IPC Classes  ?

  • E21C 35/12 - Guiding the machine along a conveyor for the cut material
  • E21D 23/12 - Control, e.g. using remote control
  • G01C 15/00 - Surveying instruments or accessories not provided for in groups

75.

INTRINSICALLY SAFE CONNECTION UNIT WITH A NETWORK INTERFACE, INTRINSICALLY SAFE APPLIANCE AND NETWORK INTERFACE FOR IT


Application Number IB2011050376
Publication Number 2011/092651
Status In Force
Filing Date 2011-01-28
Publication Date 2011-08-04
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Hermann, Helmut
  • Lenzing, Markus
  • Schwinne, Karsten
  • Weßelmann, Johannes

Abstract

Intrinsically safe connection unit with a network interface for intrinsically safe appliances in explosion-risk areas, having a housing 14, a voltage supply connection 12, plug connection 11 for connecting an intrinsically safe appliance via a transmission cable, and a decoupling circuit. For allowing even a multiplicity of network subscribers to be connected in the explosion-risk area with less wiring complexity, a plurality of plug connections 11A, 11B of the same type are provided as network interface, each being preceded by a separate decoupling circuit, and the voltage supply connection 12 builds a central feed connection with separate supply cores 13A, 13B, 13C for each plug connection 11A, 11B, 11C, each having at least two plug contacts 21 for data communication and at least two plug contacts 22 for supplying power to the connectable appliances via the transmission cable. The invention relates also to a Controller and a network interface for use therewith.

IPC Classes  ?

  • E21F 17/04 - Distributing means for power supply
  • G05B 19/042 - Programme control other than numerical control, i.e. in sequence controllers or logic controllers using digital processors
  • H04L 12/10 - Current supply arrangements

76.

PLUG-IN MODULE FOR CONTROLLERS OF MOBILE WORKING MACHINES


Application Number IB2010055814
Publication Number 2011/073909
Status In Force
Filing Date 2010-12-14
Publication Date 2011-06-23
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Herkenrath, Peter
  • Lenzing, Markus
  • Rüschkamp, Henner
  • Weßelmann, Johannes

Abstract

The invention relates to plug-in modules for controllers of mobile working machines, having a housing (11), a connection plug (17), electronics boards (21, 22, 23) and at least one plug socket (25) for connecting actuators or sensors. In order to provide a plug-in module, being usable in onboard controllers of a mobile working machine and being also suitable for use with a wide variety of actuators or sensors, according to the invention, the housing (11) consists of a box with a front, rear and side walls (12, 13, 14) as well as a base plate (15) comprising a cutout (16) for the connection plug (17), and in that the electronics boards are forming a board box (24) by connecting two end boards (21, 23) and two side boards (22), with the board box (24) being arranged in the interior (19) of the housing (11), and with the plug socket (25) being mechanically coupled to the housing (11) by means of a strain-relief clip (30).

IPC Classes  ?

  • H05K 7/14 - Mounting supporting structure in casing or on frame or rack

77.

SHIELD CANOPY FOR A SHIELD-TYPE SUPPORT


Application Number IB2010055189
Publication Number 2011/064690
Status In Force
Filing Date 2010-11-16
Publication Date 2011-06-03
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Dehmel, Dennis
  • Hahn, Detlef
  • Hengstler, Stefan

Abstract

The invention relates to a shield canopy for a shield-type support for underground mining, comprising a canopy plate (2) and a supporting structure (5) being welded on below the canopy plate (2) and having a plurality of longitudinal spars which extend from a rear canopy region (1A) up to a front canopy region (1B). In order to provide a shield canopy which can be produced at less cost and with lower weight and at the same time has a higher bending resistance than the known structures, the invention proposes that at least two of the longitudinal spars consist of section struts (6; 16) which are provided with a top section flange (7; 17) and a web (9; 19) running perpendicularly to said top section flange (7; 17), and in that the canopy plate (2) and the section struts (6; 16) are angled upwards in the front canopy region (1B).

IPC Classes  ?

  • E21D 23/04 - Structural features of the supporting construction, e.g. linking members between adjacent frames or sets of propsMeans for counteracting lateral sliding on inclined floor

78.

TRANSFER STATION


Application Number IB2010055026
Publication Number 2011/058485
Status In Force
Filing Date 2010-11-05
Publication Date 2011-05-19
Owner CATERPILLAR GLOBAL MINING EUROPE GMBH (Germany)
Inventor
  • Klabisch, Adam
  • Siepenkort, Gerhard
  • Hesse, Norbert
  • Duhnke, Klaus
  • Bettermann, Diedrich

Abstract

In the transfer station (10) according to the invention, a holder plate (19) is arranged on a carcass (16) of the drive (17) for the longwall conveyor in the transfer region between a longwall conveyor (12) and a drift conveyor (13) in the region of a drive (17) for the longwall conveyor, wherein the drift conveyor is connected to the longwall conveyor so as to perform limited pivoting motions relative to the longwall conveyor. Said holder plate is provided with a bearing holder (21), in which a special connecting channel element (22) of the drift conveyor (13) is mounted so as to move pivotably relative to the longwall conveyor (12) or the drive (17) thereof about a pivot axis (26) defined by the bearing holder (21). The design has the special advantage that the pivot bearing is easily accessible and must transmit only low forces that result substantially from the charging of the drift conveyor.

IPC Classes  ?

  • E21F 13/06 - Transport specially adapted to underground conditions at or adjacent to the working face

79.

VibraGuard


Application Number 1069350
Status Registered
Filing Date 2010-06-29
Registration Date 2010-06-29
Owner Caterpillar Global Mining Europe GmbH (Germany)
NICE Classes  ?
  • 07 - Machines and machine tools
  • 09 - Scientific and electric apparatus and instruments
  • 12 - Land, air and water vehicles; parts of land vehicles

Goods & Services

Construction machines, mining machinery; machines for mining, machines for grinding materials, machines for materials handling; winning machines for mineral extraction; winning machines for the surface mining and the underground mining; mechanical devices for winning natural resources and for mining; grinding and milling machines for minerals; engines and parts thereof for all the aforementioned machines, included in this class; controls (included in this class); control mechanisms and drives (included in this class) for building and mining machines as well as for parts of building machines; controls (included in this class) for hydraulic lining aggregates for mine works; controls and drive systems for mining, driving and loading machines, for road heading shields as well as for mining conveyors (included in this class); parts of the aforementioned control systems, controls and drives, included in this class; hydraulic support shield, shield supports and discharging shields for mining and underground mine work including their parts; hydraulic engines. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking, life-saving and teaching apparatus and instruments; apparatuses and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; apparatus for recording, transmission or reproduction of sound or images; data processing apparatus and computer; fire extinguisher; electric and electronic measuring, signalling, checking apparatus and instruments, with and without switching function, for monitoring of electric values; hard and software for analysis, visualization and storage of operating parameters and data of electrical installations and systems; measuring apparatus, measuring installations and systems; measuring apparatus, measuring instruments, slope indicators, vibration measuring apparatus; electric commutations; commutators; integrated circuits; intrinsically safe apparatuses and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; intrinsically safe signalling apparatuses and instruments; devices for data transfer and signal transfer in networks; apparatuses and equipment for communication engineering, namely for messaging, high frequency and control engineering; electrical, optical and electronic equipments for communication systems, especially for bus systems; electrical, optical and electronic apparatuses and instruments for personal security systems; electrical, electronic, acoustical and optical sensors and circuits; accumulators; batteries; electric, electromagnetic, electronic and electro-hydraulic actuators for the control and regulation of fluids and gazes. Vehicles; apparatus for locomotion by land, air or water; hydraulic circuits for vehicles.

80.

Extraction device, particularly for mining, and method for controlling the extraction device


Application Number 12675797
Grant Number 08550236
Status In Force
Filing Date 2008-09-08
First Publication Date 2011-02-03
Grant Date 2013-10-08
Owner Caterpillar Global Mining Europe GmbH (Germany)
Inventor
  • Merten, Gerhard
  • Schürer, Karl-Heinz
  • Wirtz, Jörg
  • Bäumler, Manfred
  • Böker, Uwe

Abstract

An extraction device, particularly for mining, having two drive stations and a drive chain which extends between the sprockets thereof. So that hanging chain or chain wear to a conveyor chain, in the case of a conveyor device, or to a plow chain, in the case of a plow device, can be detected, magnetic sensor units for detecting at least one chain condition of the drive chain are provided, wherein each sensor unit includes a transmitter, which is formed by a static or dynamic magnetic field generator, and a detector field, which is provided with a plurality of magnetic field detectors, as a detector, the detector and the transmitter being arranged to the side of a passage for the run of the drive chain that is to be scanned. The invention also relates to a method for controlling an extraction device for preventing hanging chain.

IPC Classes  ?

  • B65G 23/44 - Belt- or chain-tensioning arrangements

81.

DBT


Application Number 784945
Status Registered
Filing Date 2002-01-21
Registration Date 2002-01-21
Owner Caterpillar Global Mining Europe GmbH (Germany)
NICE Classes  ?
  • 06 - Common metals and ores; objects made of metal
  • 07 - Machines and machine tools
  • 09 - Scientific and electric apparatus and instruments
  • 11 - Environmental control apparatus
  • 12 - Land, air and water vehicles; parts of land vehicles
  • 17 - Rubber and plastic; packing and insulating materials
  • 37 - Construction and mining; installation and repair services
  • 41 - Education, entertainment, sporting and cultural services
  • 42 - Scientific, technological and industrial services, research and design

Goods & Services

Metal building materials; transportable buildings of metal; rails of metal and materials of metal for railway tracks including points; metallic pipes and tubes; clips of metal; receptacles, tanks and containers of metal; closures of metal for containers; sheets and plates of metal; linings of metal for building purposes; screws, screw bolts, nuts, sleeves, fitting and spacer parts, disks, washers and collars, flanges (clips), rings, armatures, plugs, pegs, bolts, nails and pins of metal; wire of common metal; fixed installations for funiculars and suspended railways (included in this class); wire cables; wire netting; wire gauze; steel bands; conveyer and transport pallets of metal; seals, sealing rings, sealing plates and sealing inserts of metal; railings of metal; scaffolding of metal; frames of metal; shelving of metal; bells, included in this class; knobs of metal; clamps of metal for cables; cable connections (non electric); cable connection sleeves; rope thimbles of metal; metal chains; chain links of metal; couplings of metal for chains; cases and baskets of metal; loading gauge rods, of metal, for railway wagons; fish plates (rails); laths and grids of metals; ladders of metal; masts of metal; plaques and signboards of metal; stops of metal; parts of bridges of metal; gutters of metal; pipe elbows, pipe sockets, pipe clips, pipe connections and piping of metal; grates of metal; locks of metal and keys; hinges of metal; ramps of metal; grease nipples; sills of metal; pulleys (small items of metal hardware); tension links; tighteners for chains, belts and cables of metal; plugs of metal; funnels as parts of industrial installations; stairs and steps of metal; props of metal; barrels of metal; gates of metal; girders of metal; doors of metal; common metals and their alloys, unworked or semi-worked; valves of metal (other than for parts of machines); elbows of metal; pot hooks of metal; metal building materials, namely girders; hose connections and hose couplings of metal; chain wheels and chain drums. Building and mining machines and their components, particularly mining/winning machines including coal ploughs, shearer loaders, loaders; short wall machines (Continuous Miner), devices for mining by means of blasting technology (soft blasting technology); machines for loading and/or transporting mining products and other bulk materials, cutter loaders, machines for driving tunnels, galleries and headings; combined anchorage, boring and setting devices for machines; machines for mechanised lining of galleries and tunnels including working and mounting platforms for tunnel driving; ramming devices; motors and driving means for mining machines including toothed racks and pinion racks; cutter heads with and without hydraulic steering devices; hydraulic support frames, support chocks, shield supports and discharge shields for underground mining works and parts thereof; mechanical or hydraulic support frames, racks and shields for mine galleries; conveyors for the textile industry, in particular for use in laundering and cleaning factories, conveyors for glass and car engineering, including their drives and controlling devices, mining conveyors systems (included in this class); conveyors for bulk material and piece goods including mechanical and pneumatic bulk conveyors, ash conveyors for use in power plants, conveyor systems using water, circular conveyors, chutes, palette haulage systems, skid conveyors, pilot belt and pilot chain conveyor, palettizing machines; continuous conveyors, particularly scraper chain conveyors, curve conveyors and roller curves, belt conveyors, conveyor belts, platform conveyors, link conveyors, perpendicular conveyors, disc retarding conveyors, twisting conveyors, roller conveyors, worm conveyors, vibrating conveyors, bunker discharge conveyors, parts of said conveyors including conveyor pans, cast or welded conveyor pan constructions, pan conveyor connections, driving stations and scrapers, overhead conveyors, conveyors for room and pillar engineering; powered anchorage or shifting devices for anchoring respectively shifting conveyor means and their drive means, parts of the anchorage and shifting devices, including rods and walking troughs; hydraulic and electro-hydraulic control systems and control devices for support systems; control systems and control devices for conveyor anchoring means, for mining machines as coal ploughs, drum shearers, continuous miners, driving and loading machines, mine conveyors, and parts of the above mentioned support control systems and control devices; powered devices for directing and positioning of underground winning machines and parts thereof; devices for measuring path of ploughs; guide means as a part of mining machines; plough and shearer guides; guides for chains and driving bars; chain guides for coal augers and shearers; side plates for conveyors; cable ducts; plough bits, round shanked bits, cutting discs, bit holders and drilling tools; crushers for mining and tunnel construction, for stone and ground industry, for recycling respectively treatment of rubble, slag and other valuable materials; jaw crushers and rolling crushers, impact rolling crushers, impact crushers and continuous passage crushers; power-driven chain tension devices, tension frames, hydraulic piston drives including hydraulic props, shifting cylinders, adjusting cylinders, anchoring cylinders, control and metering cylinders, pressing rams, electrical drive motors as asynchronous motors and motors with frequency inversion, hydraulic and pneumatic motors, gear boxes, smooth starting transmissions, clutches, torque overloads, brake heads, brake linings, brake shoes and pumps (each not for land craft); hydraulically, pneumatically, electrically and piezo electrically controlled valves as well as electro-hydraulic control instruments for hydraulic working machines, for pressurizing and controlling of hydraulic working cylinders, and for controlling of hydraulic rams; powered devices with spray nozzles for dust control by means of water including parts thereof; power-driven winches, reels, hoists; working and cleaning machines for anode coals, anode rods and casting molds; sharpening and brushing machines; machines for stripping off carbon brushes, for the connection of carbon brushes and anode rods; coolers for anode coals; machines for treating and fixing anode rods; machines for preheating anode coals; anode transportation equipment, crushers for remaining anodes, crust crushers; devices for operating and feeding of electrolysis furnaces as well as for casting machines; devices for use in casting and casting of wheels; machines for the disposal of waste materials and/or for recycling purposes, namely sorting and crushing machines, sifters, stirring machines including their transmissions, and mixers; machines for papermaking; paper mills; electrical starters for engines; machines, devices and systems for offshore use; offshore drilling installations; air compressors; loading and transporting devices; machines and mechanical devices for loading and unloading piece goods and bulk materials, for stacking and/or transferring of piece goods; mechanical feeding devices; machines and devices for transporting, moving, loading and/or unloading of containers or pallets; elevating platforms; movable gripper for loading and unloading, for winning gravel under water and for handling of bulk materials and bulky goods; hand and motor powered cranes; movable devices for loading and unloading of storing units; cable pulleys and parts therefor; parts of vehicles, in particular starters, radiators, fans, cylinders, cylinder rings and cylinder liners. Data processing equipment and apparatus, including operating systems and operating programmes in the form of data carriers, in particular data acquisition equipment and apparatus, personal computers, mini-computers and micro-computers and installations entirely or largely made up thereof; electronic apparatus and implements for process, installation and machine control and machine and process supervision; computer output equipment, in particular printers, recorders, plotters, punching and embossing equipment, engraving equipment, terminals, keyboards, screens, other visual display and feeler units; document reading apparatus and instruments; identification apparatus and equipment for people and objects, electronic apparatus and equipment for the transmission of data and installations entirely or largely made up thereof; data storage devices, in particular diskettes and disk drives, magnetic disks and magnetic disk drives, optically and/or mechanically coded storage disks and storage tape systems, comprising largely hardware and software for the recording, storage and reproduction of data, including data carriers; screen text equipment and apparatus and installations entirely or largely made up thereof, including the concomitant data processing programmes in the form of data carriers and/or data memories; electric and electronic apparatus and equipment (included in this class), in particular for data recording, data processing and data output; parts of data processing installations and equipment, in particular of data entry, data processing and data output installations and equipment, equipment and apparatus for speech input and output and for voice recognition; equipment and apparatus for character recognition and image analysis; switching apparatus and equipment, made up in particular of electric, electronic, hydraulic, pneumatic, optical and/or mechanical switching, control, regulating, measuring, checking (supervision) and/or signalling apparatus and equipment; supervision, checking, regulating, control, signalling, warning, measuring and testing apparatus and supervision, checking, regulating, control, signalling, warning, measuring and testing equipment; devices for safety-related communication systems in explosion hazardous areas such as mine ventilation systems, for online monitoring of concentration in coal and bulk materials, for treatment of coal, and control devices therefor; control systems and control devices for offshore engineering; computer based visualizing and leading systems; electrical, optical and electronic devices and instruments for use in protection systems for individuals; electrical and electro-hydraulic screwable fittings, electrical and electro-hydraulic plug fittings; electrical and electro-hydraulic hose cables; pressure meters; monitoring and indicator devices, batteries, battery chargers; electrical and electronic control devices for traffic engineering, storing engineering and gripping engineering. Air conditionning and ventilation apparatus, including such apparatus for vehicles; waste water purification apparatus; apparatus for drying; microwave apparatus, in particular for technical heat treatment, sterilization, pasteurization and drying; apparatus and installations for technical heat treatment, sterilization, hygienization, pasteurization and drying by microwave; valves, namely control valves, directional control valves, return valves, cut-in and cut-out valves, pressure regulation valves, shut-off valves, emergency trip valves, shuttle valves, mixing valves, bleed valves, overflow valves, safety valves, throttle valves, restrictor valves, regulating valves, solenoid valves, selector valves, hydraulic valves, pneumatic valves, push button valves, electromagnetically, electronically, hydraulically and/or pneumatically controlled valves; filters for filtering hydraulic fluids; electrical illuminating apparatus and lights for tunnels, galleries and mines; intelligent mine lights; headlights. Single rail overhead tracks for transportation of passengers and materials; railway transport vehicles powered by compressed air (and hydraulic), gasoline (and hydraulic) or electricity (and hydraulic); magnetic train locomotives; railway trolleys; transfer or transport vehicles; hauler vehicles powered by gasoline engine or battery; universal transport vehicles; underground fork lift trucks; front shovel loaders; side-tip loader vehicles; displacing wagons; discharge wagons, semi-trailer slewing wagons, tractive wagons, brake wagons, driving trailers, cable cars, low-loaders, passenger cars and carriages, testing coaches, articulated trains, travelling gears, chassis, wheels, rollers, axles, bearings, bogies, guide rollers, vehicle and conveyer wagon couplings; rail-mounted transport apparatus, rail-mounted shunting apparatus, floor conveyor tracks and rack railways and parts therefor; aerial conveyors; cable-driven aerial conveyors with their own driving gears, in particular monorail aerial conveyors, track rail systems, chair lifts, cable cars and parts therefor; mounting and dismounting points for mining transport systems; turning stations, comprising mainly cable pulleys and/or chain wheels, axles, bearings, casings, tension and guide devices; cable drums, brakes, brake systems, brake devices and brake equipment and parts therefor for land vehicles, suspension railways and lifts; driving trailers for brake devices and brake equipment for land vehicles, suspension railways and lifts; rail installations for suspension railways and floor conveyors and parts therefor; channel cleaning vehicles; trolleys; mine bicycles, track bicycles; buffers for railway rolling stock; vehicle trailers; parts of vehicles, in particular bonnets, axle journals, trailer hitches, drive chains, drive machines, silencers, tyres, wheels, axles, covers for seats and saddles, anti-glare devices, anti-theft devices and alarms, torque converters, chassis, wheel rims, chains, handlebars, motors and engines, pedals, frames, saddles, bicycle inner tubes, indicators, doors, hoods, gears, cars or parts of cars, bodies, mudguards, couplings, mirrors, windscreen wipers, flanges, steering wheels, joysticks, shock absorbers, bumpers, torsion bars, suspension springs, running boards. Flexible hoses and sheathed flexible cables (not of metal), in particular pressure hoses, hydraulic hoses, compressed air hoses, control hoses and water hoses; sealing rings, packing, stopping and insulating materials; high-pressure hoses. Installation, assembly, repair and maintenance; installation, assembly, repair, maintenance and inspection of mining machines and their parts, as well as of apparatus, equipment, machines and installations, and of railways, suspension railways and other transport equipment and installations, lighting apparatus, water treatment installations, machine installations for mining and for industrial manufacturing. Training of staff in the use of the mining machines and parts thereof described in classes 7, 9, 11 and 12. Consultancy (consulting) and planning of mines, of offshore systems, and in the managing of mines as well as monitoring of mining industry machines and their parts by means of machine diagnosis by means of frequency analysis of rotary machines; services of a designer of building and mining industry machines, conveyors, transport systems, hydraulic systems, machines for stacking and unloading and mechanisms for third parties.

82.

DBT


Application Number 112553100
Status Registered
Filing Date 2001-12-18
Registration Date 2005-03-04
Owner Caterpillar Global Mining Europe GmbH (Germany)
NICE Classes  ?
  • 06 - Common metals and ores; objects made of metal
  • 07 - Machines and machine tools
  • 09 - Scientific and electric apparatus and instruments
  • 11 - Environmental control apparatus
  • 12 - Land, air and water vehicles; parts of land vehicles
  • 17 - Rubber and plastic; packing and insulating materials
  • 37 - Construction and mining; installation and repair services
  • 41 - Education, entertainment, sporting and cultural services
  • 42 - Scientific, technological and industrial services, research and design

Goods & Services

(1) Metal building materials, namely, metal in sheet, rod, bar and/or billet form; transportable buildings or metal, namely, movable metal bridges, platforms, scaffolds and rolling stands; rails of metal and materials of metal for railway tracks, namely, switch points tor railways; metallic pipes and tubes; clips of metal; receptacles, tanks and containers of metal; closures of metal containers; sheets and plates of metal; linings of metal for building purposes; screws, screw bolts, nuts, sleeves, fitting and spacer parts; disks, washers and collars, flanges (clips), rings, armatures, plugs, pegs, bolts, nails and pins of metal, wire of common metal; fixed metal installations for funiculars and suspension railways, namely, supporting pillars, supports, pulley cradles; wire cables; wire netting; wire gauze; steel bands; conveyer and transport pallets of metal; seals, sealing rings, sealing plates and sealing inserts of metal; railings of metal; scaffolding of metal; frames of metal; shelving of metal; bells, included in class 6: knobs of metal; clamps of metal cables; cable connections (non electric); cable connection sleeves; rope thimbles of metal; metal chains; chain links of metal; couplings of metal for chains; cases and baskets of metal; loading gauge rods, of metal, for railway wagons; fish plates [rails]; laths and grids of metals; ladders of metal; masts of metal; plaques and signboards of metal; stops of metal; parts of bridges of metal; gutters of metal: pipe elbows, pipe sockets, pipe clips, pipe connections and piping of metal; grates of metal; locks of metal and keys; hinges of metal; ramps or metal; grease nipples; sills of metal; pulleys (small items of metal hardware); tension links: tighteners for chains, belts and cables of metal; plugs of metal; runnels as parts of industrial installations; stairs and steps of metal, props of metal; barrels of metal; gates or metal; girders of metal; doors of metal; common metals and their alloys, unworked or semi-worked; valves of metal (Other than for parts of machines); elbows of metal; pot hooks of metal; metal building materials, namely girders; hose connections and hose couplings of metal; chain wheels and chain drums; single rail overhead tracks for transportation of passengers and materials; railway transport vehicles; rack railways and parts therefore; cable-driven aerial conveyors with their own driving gears, in particular track rail systems and parts therefore (2) Building and mining machines and their components, particularly mining/winning machines namely coal ploughs, shearer loaders, loaders; continuous miner short wall machines for building and mining purposes, devices for mining by means of soft blasting technology, namely, shot-hole drilling machines, blasting cap grippers, blasting cap positioners, bursting chargers and detonation driver, machines for loading and/or transporting mining products and other bulk materials, namely, cutter loaders; tunnel driving machines, machines for mechanized lining of galleries and tunnels, namely working and mounting platforms for tunnel driving; ramming machines; motors for mining machines; driving means mining machines, namely, toothed racks and pinion racks; cutter heads with and without hydraulic steering devices; hydraulic support frames, support chocks, shield supports and discharge shields for underground mining works and parts thereof; mechanical or hydraulic support frames, racks and shields for mine galleries; conveyors for the textile industry, in particular for use in laundering and cleaning factories, conveyors for the glass and car engineering, including their drives and controlling devices, mining conveyors; conveyors for bulk material and piece goods including mechanical and pneumatic bulk conveyors, ash conveyors for use in power plants, conveyor system using water, circular conveyors, chutes, palette haulage conveyors, Skid conveyors, pilot belt and pilot chain conveyor, palettizers; continuous conveyors, particularly scraper chain conveyors, curve conveyors and roller curves, belt conveyors, conveyor belts, platform conveyors, link conveyors, perpendicular conveyors, disc retarding conveyors, twisting conveyors, roller conveyors, worm conveyors, vibrating conveyors, bunker discharge conveyors, parts of the said conveyors including conveyor pans, casted or welded conveyor pan constructions, pan conveyor connections, driving stations and scrapers, overhead conveyors, conveyor for room and pillar engineering; powered anchorage or shifting devices used for anchoring and shifting conveyors and their drives; parts of the anchorage and shifting devices, namely, rods and walking troughs; hydraulic and electro-hydraulic control systems comprised of magnets, solenoids valves, control boxes, hydraulic cylinders and hydraulic pistons for the mining and building industry; parts of mining machines, plough and shearer guides, guides for chains and driving bars; chain guides for coal augers and shearer; sideplates for conveyors; plough bits, round shanked bits, cutting discs, bits holder and drilling tools; crushers for mining and tunnel construction, for stone and ground industry, for recycling resp. treatment of rubble, slag and other valuable materials; jaw crushers and rolling crushers, impact rolling crushers, impact crushers and continuous passage crushers; power-driven chain tension devices, namely, tension frames; hydraulic piston drives, namely, hydraulic props, shifting cylinders, adjusting cylinders, anchoring cylinders, control and metering cylinders, pressing rams, electrical drive motors as asynchronous motors and motors with frequency inversion, hydraulic and pneumatic motors, gear boxes, smooth starting transmissions, clutches, torque overload, brake heads, brake linings, brake shoes and pumps (each not for land-craft); power-operated water sprayers for dust control and replacement parts thereof; power-driven winches, reels, hoists; machines used for recycling of anode coals, anode rods and casting molds; anode coal sharpening and brushing machines; anode coal stripping off machines; anode coals and anode rods connecting machines; anode transporter, crushers for remaining anodes, crust crushers; operaters and feeder for electrolysis furnaces and for casting machines; wheel casting machines; machines for the disposal of waste materials and/or for recycling purposes, namely sorting and crushing machines, sifters, stirring machines including their transmissions, and mixers; machines for the papermaking, namely, paper mills; electrical starters for engines; machines, devices and systems for offshore drilling and mining, namely cranes, grab buckets, grab blades. grab spades, drilling rigs and drilling machines tor offshore drilling: Offshore drillers: air compressors; hand and motor powered cranes; gantry; valves, namely pressure regulation valves, regulating valves, solenoid valves, hydraulic valves, pneumatic valves, electromagnetically, electronically, hydraulically and/or pneumatically controlled valves; filters for filtering hydraulic fluids; front shovel loaders; loaders, stackers and lifters for loading and unloading piece goods and bulk materials; transporters and movable grippers for containers or pallets; elevating platforms; movable gripper for loading and unloading, tar winning gravel under water and for handling of bulk materials and bulky goods; low-loaders; floor conveyor tracks and parts therefore; radiators; fans (3) Data processing equipment namely, computer software and hardware for processing, installing, supervising, recording output, and controlling equipment used in the mining industry; batteries; battery chargers; cable connectors and cable connector sleeves; electronic controls tor conveyor anchoring machines, mining machines, namely, coal ploughs, drum sheerer. continuous miner, driving and loading machines, mine conveyors, and replacement parts for the above mentioned Support control Systems and control pressurizing and controlling of hydraulic working cylinders, and for controlling of hydraulic rams in the mining industry; traffic control devices, namely, software and hardware for person traffic, material traffic or machine traffic in mines; storage control devices, namely, software and hardware for storing cables and belts in mines; gripping control devices. namely, software and hardware for control of rope grab buckets, grab blades and grab spades for gripping stones, rock, coal, minerals, bulk materials and bulky goods; identification apparatus and equipment for people and objects, namely, transmitters, transponders and receivers; combined anchorage, boring and setting controls for directing and positioning machines for the mining industry; hydraulic and electro-hydraulic control systems; intelligent mine lights, namely, electrical lighting fixtures and helmet head lamps combined with gas detectors or identification transmitters; electrical and electro-hydraulic hose cables; pressure meter; safety controls conveyor anchoring machines, for mining machines, namely, coal ploughs, drum shearer. continuous miner, driving and loading machines, mine conveyors and replacement parts for the above mentioned support control systems and control devices; hydraulic cylinders for directing and positioning of underground winning machines; plough path and plough position meter; cable ducts; hydraulically, pneumatically, electrically and piezoelectrically controlled valves as well as electro-hydraulic control instruments for hydraulic working machines: for pressurizing and controlling of hydraulic working cylinders, and for controlling or hydraulic rams; valves, namely safety valves (4) Air conditioners and ventilators for vehicles; waste water purifiers; dryers and microwave heaters for industrial use in the field of technical heat treatment, sterilization, hygienisation, pasteurisation and drying; valves, namely control valves, directional control valves, return valves, cut-in and cut-out valves, shutoff valves, emergency trip valves, shuttle valves, mixing valves, bleed valves, overflow valves, throttle valves, restrictor valves, selector valves, pushbutton valves; lights for tunnels. galleries and mines; intelligent mine lights; headlights; coolers for anode coal; preheaters for anode coals (5) Magnetic train locomotives; railway trolleys; transport vehicles; hauler vehicles; underground fork-lift trucks: side-tip loader vehicles; displacing wagons; discharge wagons, semi-trailer slewing wagons, tractive wagons, brake driving trailers, cable cars, passenger cars and carriages, testing coaches, articulated trains, travelling gears, chassis, wheels, rollers, axles, bearings, bogies, guide rollers, vehicle and conveyer wagon couplings; rail-mounted transport trolleys and parts therefore; aerial conveyors; cable-driven aerial conveyors with their own driving gears, in particular monorail aerial conveyors, chair lifts, cable cars and parts therefore; cable pulleys and parts therefore; mounting and dismounting points for mining transport systems; cable, chain belt turning stations; cable drums, brakes, channel cleaning vehicles for the mining and piping industries; trolleys; mine bicycles, track bicycles; buffers for railway rolling stock; vehicle trailers; parts of vehicles, in particular bonnets, axle journals, trailer hitches, starters, drive chains, silencers, tyres, wheels, axles, covers for seats and saddles; vehicle-antitheft devices, namely alarms; torque converters, chassis, wheel rims, chains handlebars, motors and engines, pedals, frames, saddles, bicycle inner tubes, indicators, doors, hoods, gears, cars or parts cars, bodies, mudguards, couplings, mirrors, windscreen wipers, flanges, steering wheels, joysticks, shock absorbers, bumpers, torsion bars, suspension springs, running boards, cylinders, cylinder rings and cylinder liners. (6) Flexible hoses and sheated flexible cables (not of metal), in particular pressure hoses, hydraulic hoses, compressed air hoses, control hoses and water hoses; sealing rings; high pressure hoses. (1) Installation, repair, and maintenance of mining machines and their parts, railways, suspension railways and other transport equipment used in the construction and mining industries; Installation, repair and maintenance of intelligent mine lighting, namely, electrical lighting fixtures and helmet head lamps combined with gas detectors or identification transmitters; water treatment installations, machine installations for mining and for industrial manufacturing. (2) Training with respect to the above mentioned mining machines and the parts thereof. (3) Construction planning and consultation services in the field or mines, off-shore drilling systems and in the managing of mines; monitoring of mining industry machines and their parts by means of machine diagnosis over frequenzanalyse at rotary machines; services of a designer on building and mining industry machines, conveyors, transport systems. hydraulic systems, machines for stacking and unloading and mechanism for third.

83.

PMC


Application Number 714805
Status Registered
Filing Date 1999-03-02
Registration Date 1999-03-02
Owner Caterpillar Global Mining Europe GmbH (Germany)
NICE Classes  ? 07 - Machines and machine tools

Goods & Services

Controlling devices, control units and driving gear for building and mining machines as well as for parts of mining machinery, especially control devices for hydraulic pipe jacking systems for mines, control devices and driving gear for mining machines, drivage and loading machines, for drivage shields and for mining conveyors; parts of the aforementioned control units, control devices and driving gear, all aforementioned goods included in this class.

84.

PMC


Application Number 100776400
Status Registered
Filing Date 1999-03-08
Registration Date 2002-12-13
Owner Caterpillar Global Mining Europe GmbH (Germany)
NICE Classes  ?
  • 07 - Machines and machine tools
  • 09 - Scientific and electric apparatus and instruments

Goods & Services

(1) Controlling devices, namely devices that direct and control movement in machines and/or machine components and comprising remote viewing and sensor; electro-hydraulic control units, wireless remote control units used in mining machinery operations, used with automated mining machinery, used with conveyor systems and (mining) driving gear, with hydraulic pipe jacking systems for mines, used in directing and positioning of underground mining machines, used with hydraulic pipe jacking systems for mines, with drivage and loading machines, used with drivage shields; component parts for the aforesaid wares, sensors and remote viewing cameras used with the aforesaid control devices; driving gear for mining machines (including electrical, hydraulic and pneumatic cylinders as well as gears, clutches, chains, chain wheels and chain drums, powerdriven chain tensioners and parts thereof) drive gear for mining machines, for drivage, for loading machines, for drivage shields, for mining conveyors.

85.

Panzerförderer


Application Number 163344
Status Registered
Filing Date 1952-08-08
Registration Date 1952-08-08
Owner Caterpillar Global Mining Europe GmbH (Germany)
NICE Classes  ? 07 - Machines and machine tools

Goods & Services

Face conveyors and depth conveyors for mined products, in particular for transporting coal in mines.
