Residential water treatment technology systems for hot water
dispensers, steam ovens, boilers; coffee machines, hot water
heating installations, industrial boilers.
2.
FILTER MEDIA WITH MICROBIOLOGICAL REDUCTION CAPABILITIES
Methods of fabricating treated filtration media for enhanced removal of antimicrobials, the resultant treated water filtration media made from such methods, and methods of removing microbial materials/ agents from water using the resultant treated water filtration media. The treated filtration media of the invention at least includes fibrillated cellulose fiber treated with a silane quat microbiological interception enhancing agent to render silane quat treated fibrillated cellulose fibers having a cationic charge for removal of negatively charged contaminates from water and/or air. The silane quaternary ammonium compounds are strongly covalently bonded to the cellulose fibers to prevent leaching into water/air to extend life and use of the present cellulose-containing silane quat treated filtration media.
A filtration system and method of using the same. The method comprises the steps of guiding, by alignment rail and mating boss, a filter cartridge into a manifold housing; aligning a filter magnet with a corresponding manifold magnet; rotating, by attractive magnetic forces, the manifold magnet upon rotation of the filter cartridge into an installed position; and actuating, by attractive magnetic forces, a manifold valve.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
B01D 35/06 - Filters making use of electricity or magnetism
B01D 35/157 - Flow control valvesDamping or calibrated passages
4.
METHOD AND APPARATUS FOR METAL REMOVAL FROM DRINKING WATER
A single sheet water filter media for gravity filtration applications that improves flow performance over the product life while maintaining sufficient metal reduction, wherein at least two distinct density gradients of the single sheet form a physical barrier for capturing colloidal and insoluble contaminants, retaining the colloidal and insoluble contaminants until the contaminants become soluble in the fluid, and being removed by the single sheet filter media. The single sheet filter overcomes the difficulties of dual- and multi-layer filters attributable to slower flow rate realized well before the rated lifetime of the product. The two distinct density gradients of the single sheet filter media are created by exerting a force on a liquid slurry, such force resulting in the separation of higher powder loading and fibers that compose the top and bottom density gradients, respectfully.
A gravity-fed filtration system and method of permitting fluid flow from a filter cartridge to a holding reservoir for a gravity-fed filtration system. The method comprises providing a filter cartridge having a filter magnet, a holding reservoir for filtered fluid, and a first reservoir having a recess receiving cavity in a bottom surface thereof for receiving ingress fluid. Upon inserting the filter cartridge into the recess receiving cavity and moving the filter magnet to be in magnetic communication with the carrier magnet, a magnetic field force moves the carrier magnet from a first position which blocks fluid flow, to a second position which allows fluid flow to the holding reservoir.
01 - Chemical and biological materials for industrial, scientific and agricultural use
11 - Environmental control apparatus
Goods & Services
Industrial cooling systems Residential water treatment technology systems for hot water dispensers, steam ovens, boilers; coffee machines, hot water applications, industrial boilers
A filter assembly for fluid filtration having a push-activated lock and release mechanism. A push filter design activates a filter key lock upon insertion and extraction, where the filter key may be used simultaneously as a lock and as an identifier for particular filter attributes. The filter housing assembly may be attached to, and removed from, a filter base by a push-actuated release. Upon insertion, the filter key shifts the filter lock longitudinally to receive interlocking segments. Upon extraction, the same axial push shifts the filter lock further to align the interlocking fingers within gaps that allow for easy extraction. The specific key lock design allows a user to identify and match certain filter configurations received by the mechanical support, and reject other filter configurations.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
B01D 17/00 - Separation of liquids, not provided for elsewhere, e.g. by thermal diffusion
An interconnection scheme between a filter cartridge and its corresponding manifold whereby a magnetic shear force is introduced to remove a blocking mechanism that would otherwise prohibit attachment. The magnetic shear force may also be employed to activate or deactivate a switch or valve, or engage or disengage an engagement mechanism relative to other components upon interconnection. The magnetic shear force is generated by complementary correlated magnet structures moved into close proximity to one another. The interconnection scheme may be a linear or rotational attachment of the filter cartridge with respect to the manifold. A valve assembly utilizing magnetic shear force may be employed to activate a bypass action between a manifold ingress port and egress port, thereby allowing water to flow when a filter cartridge is removed from the manifold and directing water to the filter cartridge when the valve assembly is activated.
A filtration system interconnection structure includes a filter manifold and a filter cartridge in magnetic communication produced by two complementary correlated magnets capable of generating a magnetic force when in close proximity to one another. The filter magnet polarity transitions are aligned with the manifold magnet polarity transitions such that a repulsion force is generated between the magnets when the filter cartridge is inserted within the manifold sump. The magnetic repulsion force may be used to move a blocking mechanism or actuate a latch structure in the manifold to secure the filter cartridge within the manifold sump upon insertion, or to provide non-contacting actuation of a downstream valve so as to permit or prevent the flow of fluid. Utilizing correlated magnetism in a filter interconnect further provides enhanced authentication and/or anti-counterfeiting means to ensure that only authorized or OEM filter cartridges can be installed.
B01D 29/11 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor with bag, cage, hose, tube, sleeve or like filtering elements
10.
FILTER INTERCONNECTS UTILIZING MAGNETIC SHEAR FORCE GENERATED BY CODED POLYMAGNETS
A filtration system interconnection structure having a filter manifold and a filter cartridge in magnetic communication with one another, such that a latching mechanism of the manifold secures the filter cartridge within a manifold sump when the filter cartridge is inserted therein. The magnetic communication is formed between two complementary coded polymagnets capable of producing a magnetic shear force when in close proximity to one another. The magnetic shear force removes a latch blocking structure from interfering with the latch, allowing the latch to secure the filter cartridge. Movement of the latch blocking structure coded polymagnet relative to the filter cartridge coded polymagnet may be perpendicular or parallel with respect to each other such that a shear force is generated therebetween, allowing for actuation of the latch blocking mechanism against a biasing force, and allowing the latch to move radially inwards against a separate biasing force.
A filter housing assembly for fluid filtration which may be attached to, and removed from, a filter base by a push-actuated release. The filter housing assembly has a top portion with an ingress port and egress port extending therefrom, and a protrusion extending from the filter housing longitudinally axial center. The ingress and egress port are formed in an hourglass shape. A filter key having a base with a groove for mating with said projection, at least one finger extending from said base, and an electronic circuit component housing attached thereto for receiving a printed circuit board, is connected to the filter housing top portion by mating said top portion protrusion with the filter key groove. Both of said ingress and egress port have at least one cavity for the passage of fluid therethrough, where each cavity is exposed in a direction facing away from the electronic circuit component housing.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
12.
FILTER INTERCONNECT UTILIZING CORRELATED MAGNETIC ACTUATION FOR DOWNSTREAM SYSTEM FUNCTION
A filtration system interconnection structure having a filter manifold including a sump and a coded polymagnet located on or connected to a portion of the manifold, and a filter cartridge including a filter media, first and second end caps sealed to the filter media, and a paired coded polymagnet magnet located on or connected to the filter cartridge. The polarity profiles of the paired coded polymagnets are aligned such that a magnetic attraction force, magnetic repulsion force, or combination thereof, is generated therebetween when the filter cartridge is inserted within the manifold sump housing and moved to the alignment position, thereby causing the coded polymagnet located on or connected to the manifold to translate with respect to a longitudinal axis of the sump to allowing for direct or indirect actuation of downstream system functionality.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
H01H 3/50 - Driving mechanisms, i.e. for transmitting driving force to the contacts with indexing or locating means, e.g. indexing by ball and spring
H01H 36/00 - Switches actuated by change of magnetic field or of electric field, e.g. by change of relative position of magnet and switch, by shielding
13.
Filter interconnect using a correlated magnet torque design
A filtration system and method of using the same. The method comprises the steps of guiding, by alignment rail and mating boss, a filter cartridge into a manifold housing; aligning a filter magnet with a corresponding manifold magnet; rotating, by attractive magnetic forces, the manifold magnet upon rotation of the filter cartridge into an installed position; and actuating, by attractive magnetic forces, a manifold valve.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
B01D 35/06 - Filters making use of electricity or magnetism
B01D 35/157 - Flow control valvesDamping or calibrated passages
A gravity-fed filtration system and method of initiating flow from a filter cartridge to a holding reservoir for a gravity-fed filtration system. The method comprises providing a filter cartridge having a filter magnet, a holding reservoir for filtered fluid, and a first reservoir having a recess receiving cavity in a bottom surface thereof for receiving ingress fluid. Upon inserting the filter cartridge into the recess receiving cavity and moving the filter magnet to be in in magnetic communication with the carrier magnet, a magnetic force moves the carrier magnet from a first position which blocks fluid flow, to said second position which allows fluid flow to the holding reservoir.
A filter base for receiving a mating filter housing assembly having a base platform having fluid ingress and egress stanchions, and a wire harness assembly including a connector housing integral with or connected to the base platform for establishing an electrical connection between the filter base and the mating filter housing assembly. The wire harness assembly having conductors extending between first and second connectors, with one or more resilient contacts provided on the second connector. The contacts are flexible from a first position to a second position when curved contact sections of the one or more contacts engage a mating connection surface of the complementary mating filter housing assembly. The mating connection surface may be a circuit pad of a printed circuit board, wherein the contact curved contact sections are configured to be positioned in mechanical and electrical engagement with the circuit pads when the filter housing assembly is received within the filter base.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
A filter assembly for fluid filtration having a push-activated lock and release mechanism. A push filter design activates a filter key lock upon insertion and extraction, where the filter key may be used simultaneously as a lock and as an identifier for particular filter attributes. The filter housing assembly may be attached to, and removed from, a filter base by a push-actuated release. Upon insertion, the filter key shifts the filter lock longitudinally to receive interlocking segments. Upon extraction, the same axial push shifts the filter lock further to align the interlocking fingers within gaps that allow for easy extraction. The specific key lock design allows a user to identify and match certain filter configurations received by the mechanical support, and reject other filter configurations.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
B01D 17/00 - Separation of liquids, not provided for elsewhere, e.g. by thermal diffusion
A filter housing assembly for fluid filtration which may be attached to, and removed from, a filter base by a push-actuated release. The filter housing assembly has a top portion with an ingress port and egress port extending therefrom, and a protrusion extending from the filter housing longitudinally axial center. The ingress and egress port are formed in an hourglass shape. A filter key having a base with a groove for mating with said projection, at least one finger extending from said base, and an electronic circuit component housing attached thereto for receiving a printed circuit board, is connected to the filter housing top portion by mating said top portion protrusion with the filter key groove. Both of said ingress and egress port have at least one cavity for the passage of fluid therethrough, where each cavity is exposed in a direction facing away from the printed circuit board.
B01D 35/14 - Safety devices specially adapted for filtrationDevices for indicating clogging
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
A single sheet water filter media for gravity filtration applications that improves flow performance over the product life while maintaining sufficient metal reduction, wherein at least two distinct density gradients of the single sheet form a physical barrier for capturing colloidal and insoluble contaminants, retaining the colloidal and insoluble contaminants until the contaminants become soluble in the fluid, and being removed by the single sheet filter media. The single sheet filter overcomes the difficulties of dual- and multi-layer filters attributable to slower flow rate realized well before the rated lifetime of the product. The two distinct density gradients of the single sheet filter media are created by exerting a force on a liquid slurry, such force resulting in the separation of higher powder loading and fibers that compose the top and bottom density gradients, respectfully.
A single sheet water filter media for gravity filtration applications that improves flow performance over the product life while maintaining sufficient metal reduction, wherein at least two distinct density gradients of the single sheet form a physical barrier for capturing colloidal and insoluble contaminants, retaining the colloidal and insoluble contaminants until the contaminants become soluble in the fluid, and being removed by the single sheet filter media. The single sheet filter overcomes the difficulties of dual- and multi-layer filters attributable to slower flow rate realized well before the rated lifetime of the product. The two distinct density gradients of the single sheet filter media are created by exerting a force on a liquid slurry, such force resulting in the separation of higher powder loading and fibers that compose the top and bottom density gradients, respectfully.
A filtration system interconnection structure having manifold with a rotatable manifold magnet of correlated magnets, a shroud with alignment tracks, an actuating valve for water ingress, and a filter cartridge having a rotatable filter magnet of correlated magnets, where the manifold magnet and the filter magnet are in magnetic communication with one another when the filter cartridge is inserted with the shroud, and are at least partially rotatably compatible, where the manifold magnet rotates with the filter magnet until the manifold magnet experiences a rotational stop beyond a predetermined rotation of the filter magnet, thus allowing the filter magnet to shift polarity with respect to the manifold magnet and present a repulsion force for removal of the filter cartridge from the shroud.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
B01D 35/157 - Flow control valvesDamping or calibrated passages
B01D 35/06 - Filters making use of electricity or magnetism
01 - Chemical and biological materials for industrial, scientific and agricultural use
11 - Environmental control apparatus
Goods & Services
Fiber pulp preparations, namely, chemical and mineral treatment of fiber pulp, in the nature of filtering materials for the manufacturing of domestic, industrial, and commercial air and waters filters; fibrillated adsorbent cellulose for use as filter media for general commercial use in the purification of air and drinking water, and for the general and industrial use in the purification of air and industrial fluids. Components of water filtration units for producing potable water, namely, activated carbon water filters for domestic, industrial and commercial use.
22.
FILTER INTERCONNECT UTILIZING MAGNETIC REPULSION FORCE
A filtration system interconnection structure includes a filter manifold and a filter cartridge in magnetic communication produced by two complementary correlated magnets capable of generating a magnetic force when in close proximity to one another. The filter magnet polarity transitions are aligned with the manifold magnet polarity transitions such that a repulsion force is generated between the magnets when the filter cartridge is inserted within the manifold sump. The magnetic repulsion force may be used to move a blocking mechanism or actuate a latch structure in the manifold to secure the filter cartridge within the manifold sump upon insertion, or to provide non-contacting actuation of a downstream valve so as to permit or prevent the flow of fluid. Utilizing correlated magnetism in a filter interconnect further provides enhanced authentication and/or anti-counterfeiting means to ensure that only authorized or OEM filter cartridges can be installed.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
B01D 27/00 - Cartridge filters of the throw-away type
B01D 29/11 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor with bag, cage, hose, tube, sleeve or like filtering elements
An interconnection scheme between a filter cartridge and its corresponding manifold whereby a magnetic shear force is introduced to remove a blocking mechanism that would otherwise prohibit attachment. The magnetic shear force may also be employed to activate or deactivate a switch or valve, or engage or disengage an engagement mechanism relative to other components upon interconnection. The magnetic shear force is generated by complementary correlated magnet structures moved into close proximity to one another. The interconnection scheme may be a linear or rotational attachment of the filter cartridge with respect to the manifold. A valve assembly utilizing magnetic shear force may be employed to activate a bypass action between a manifold ingress port and egress port, thereby allowing water to flow when a filter cartridge is removed from the manifold and directing water to the filter cartridge when the valve assembly is activated.
An interconnection scheme between a filter cartridge and its corresponding manifold whereby a magnetic shear force is introduced to remove a blocking mechanism that would otherwise prohibit attachment. The magnetic shear force may also be employed to activate or deactivate a switch or valve, or engage or disengage an engagement mechanism relative to other components upon interconnection. The magnetic shear force is generated by complementary correlated magnet structures moved into close proximity to one another. The interconnection scheme may be a linear or rotational attachment of the filter cartridge with respect to the manifold. A valve assembly utilizing magnetic shear force may be employed to activate a bypass action between a manifold ingress port and egress port, thereby allowing water to flow when a filter cartridge is removed from the manifold and directing water to the filter cartridge when the valve assembly is activated.
A gravity-fed filtration system interconnection structure comprising a reservoir for receiving ingress fluid, the reservoir having a bottom surface with a recess for receiving a filter cartridge body, and an opening for filtered fluid egress to a second, dispensing reservoir. A carrier or shuttle having a magnet disposed within or connected to the carrier is adjacent to the reservoir recess and connected to a sluice gate valve which normally blocks the opening to the second reservoir. The interconnection structure further includes a filter cartridge having a housing body, and a filter magnet disposed within or fixedly connected to the housing body. The carrier is normally biased in a first position, such as a closed position, and is moveable between the first position and a second (open) position, and the filter magnet and the carrier magnet are interconnected via magnetic communication upon insertion of the filter cartridge into the reservoir recess.
A gravity-fed filtration system interconnection structure comprising a reservoir for receiving ingress fluid, and a second, dispensing reservoir. A carrier or shuttle having a carrier magnet is connected to a sluice gate valve which normally blocks the opening to the second reservoir. A filter cartridge may be received by the reservoir and includes a housing body, and a filter magnet disposed within or fixedly connected to the housing body. The filter magnet and the carrier magnet are interconnected via magnetic communication upon insertion of the filter cartridge into the reservoir recess, to move the carrier and/or sluice gate valve as a result of shear force or rotational force generated between the magnets.
A filtration system interconnection structure having manifold with a rotatable manifold magnet of correlated magnets, a shroud with alignment tracks, an actuating valve for water ingress, and a filter cartridge having a rotatable filter magnet of correlated magnets, where the manifold magnet and the filter magnet are in magnetic communication with one another when the filter cartridge is inserted with the shroud, and are at least partially rotatably compatible, where the manifold magnet rotates with the filter magnet until the manifold magnet experiences a rotational stop beyond a predetermined rotation of the filter magnet, thus allowing the filter magnet to shift polarity with respect to the manifold magnet and present a repulsion force for removal of the filter cartridge from the shroud.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
B01D 35/157 - Flow control valvesDamping or calibrated passages
B01D 35/06 - Filters making use of electricity or magnetism
28.
Filter interconnect utilizing a magnetic repulsion force
A filtration system interconnection structure includes a filter manifold and a filter cartridge in magnetic communication produced by two complementary correlated magnets capable of generating a magnetic force when in close proximity to one another. The filter magnet polarity transitions are aligned with the manifold magnet polarity transitions such that a repulsion force is generated between the magnets when the filter cartridge is inserted within the manifold sump. The magnetic repulsion force may be used to move a blocking mechanism or actuate a latch structure in the manifold to secure the filter cartridge within the manifold sump upon insertion, or to provide non-contacting actuation of a downstream valve so as to permit or prevent the flow of fluid. Utilizing correlated magnetism in a filter interconnect further provides enhanced authentication and/or anti-counterfeiting means to ensure that only authorized or OEM filter cartridges can be installed.
B01D 29/11 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor with bag, cage, hose, tube, sleeve or like filtering elements
A filter housing assembly for fluid filtration which may be attached to, and removed from, a filter base by a push-actuated release. The filter housing assembly has a top portion with an ingress port and egress port extending therefrom, and a protrusion extending from the filter housing longitudinally axial center. The ingress and egress port are formed in an hourglass shape. A filter key having a base with a groove for mating with said projection, at least one finger extending from said base, and an electronic circuit component housing attached thereto for receiving a printed circuit board, is connected to the filter housing top portion by mating said top portion protrusion with the filter key groove. Both of said ingress and egress port have at least one cavity for the passage of fluid therethrough, where each cavity is exposed in a direction facing away from the printed circuit board.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
A filter housing assembly for fluid filtration which may be attached to, and removed from, a filter base by a push-actuated release. The filter housing assembly has a top portion with an ingress port and egress port extending therefrom, and a protrusion extending from the filter housing longitudinally axial center. The ingress and egress port are formed in an hourglass shape. A filter key having a base with a groove for mating with said projection, at least one finger extending from said base, and an electronic circuit component housing attached thereto for receiving a printed circuit board, is connected to the filter housing top portion by mating said top portion protrusion with the filter key groove. Both of said ingress and egress port have at least one cavity for the passage of fluid therethrough, where each cavity is exposed in a direction facing away from the printed circuit board.
B01D 17/00 - Separation of liquids, not provided for elsewhere, e.g. by thermal diffusion
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
A filter housing assembly for fluid filtration which may be attached to, and removed from, a filter base by a push-actuated release. The filter housing assembly has a top portion with an ingress port and egress port extending therefrom, and a protrusion extending from the filter housing longitudinally axial center. The ingress and egress port are formed in an hourglass shape. A filter key having a base with a groove for mating with said projection, at least one finger extending from said base, and an electronic circuit component housing attached thereto for receiving a printed circuit board, is connected to the filter housing top portion by mating said top portion protrusion with the filter key groove. Both of said ingress and egress port have at least one cavity for the passage of fluid therethrough, where each cavity is exposed in a direction facing away from the printed circuit board.
B01D 17/00 - Separation of liquids, not provided for elsewhere, e.g. by thermal diffusion
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
A filter base for receiving a mating filter housing assembly having a base platform having fluid ingress and egress stanchions, and a wire harness assembly including a connector housing integral with or connected to the base platform for establishing an electrical connection between the filter base and the mating filter housing assembly. The wire harness assembly having conductors extending between first and second connectors, with one or more resilient contacts provided on the second connector. The contacts are flexible from a first position to a second position when curved contact sections of the one or more contacts engage a mating connection surface of the complementary mating filter housing assembly. The mating connection surface may be a circuit pad of a printed circuit board, wherein the contact curved contact sections are configured to be positioned in mechanical and electrical engagement with the circuit pads when the filter housing assembly is received within the filter base.
A filter base for receiving a mating filter housing assembly having a base platform having fluid ingress and egress stanchions, and a wire harness assembly including a connector housing integral with or connected to the base platform for establishing an electrical connection between the filter base and the mating filter housing assembly. The wire harness assembly having conductors extending between first and second connectors, with one or more resilient contacts provided on the second connector. The contacts are flexible from a first position to a second position when curved contact sections of the one or more contacts engage a mating connection surface of the complementary mating filter housing assembly. The mating connection surface may be a circuit pad of a printed circuit board, wherein the contact curved contact sections are configured to be positioned in mechanical and electrical engagement with the circuit pads when the filter housing assembly is received within the filter base.
A filtration system interconnection structure having a filter manifold and a filter cartridge in magnetic communication with one another, such that a latching mechanism and latch blocking structure in the manifold secures the filter cartridge with a manifold sump when the filter cartridge is inserted within the manifold sump. The magnetic communication is formed between two complementary coded magnets capable of producing a magnetic shear force when in close proximity to one another. The magnetic shear force removes the latching blocking structure from interfering with the latch, allowing the latch to secure the filter cartridge. Movement of the latching blocking structure coded magnet relative to the filter cartridge coded magnet may be perpendicular or parallel with respect to each other. The filter magnet polarity transitions are aligned with the manifold magnet polarity transitions such that a shear force is generated between the magnets when the filter cartridge is inserted within the manifold sump housing, allowing for actuation of the latch blocking mechanism against a biasing force, and allowing the latch to move radially inwards against a separate biasing force.
A filtration system interconnection structure having a filter manifold and a filter cartridge in magnetic communication with one another, such that a latching mechanism of the manifold secures the filter cartridge within a manifold sump when the filter cartridge is inserted therein. The magnetic communication is formed between two complementary coded polymagnets capable of producing a magnetic shear force when in close proximity to one another. The magnetic shear force removes a latch blocking structure from interfering with the latch, allowing the latch to secure the filter cartridge. Movement of the latch blocking structure coded polymagnet relative to the filter cartridge coded polymagnet may be perpendicular or parallel with respect to each other such that a shear force is generated therebetween, allowing for actuation of the latch blocking mechanism against a biasing force, and allowing the latch to move radially inwards against a separate biasing force.
A filtration system interconnection structure having a filter manifold and a filter cartridge in magnetic communication with one another, such that a latching mechanism and latch blocking structure in the manifold secures the filter cartridge with a manifold sump when the filter cartridge is inserted within the manifold sump. The magnetic communication is formed between two complementary coded magnets capable of producing a magnetic shear force when in close proximity to one another. The magnetic shear force removes the latching blocking structure from interfering with the latch, allowing the latch to secure the filter cartridge. The filter and the manifold magnet polarity transitions are aligned such that a shear force is generated between the magnets when the filter cartridge is inserted within the manifold sump housing, allowing for actuation of the latch blocking mechanism against a biasing force, and thereby move radially inwards against a separate biasing force.
A filtration system interconnection structure having a filter manifold and a filter cartridge in magnetic communication with one another, such that a latching mechanism and latch blocking structure in the manifold secures the filter cartridge with a manifold sump when the filter cartridge is inserted within the manifold sump. The magnetic communication is formed between two complementary coded magnets capable of producing a magnetic shear force when in close proximity to one another. The magnetic shear force removes the latching blocking structure from interfering with the latch, allowing the latch to secure the filter cartridge. The filter and the manifold magnet polarity transitions are aligned such that a shear force is generated between the magnets when the filter cartridge is inserted within the manifold sump housing, allowing for actuation of the latch blocking mechanism against a biasing force, and thereby move radially inwards against a separate biasing force.
A filter assembly for fluid filtration having a push-activated lock and release mechanism. A push filter design activates a floating key lock upon insertion and extraction, where the filter key may be used simultaneously as a lock and as an identifier for particular filter attributes. The filter base may be situated inline, and in fluid communication, with influent and effluent piping, such as within a refrigerator. The filter housing assembly may be attached to, and removed from, the filter base by a push-actuated release. Upon insertion, the filter key shifts the filter lock longitudinally to receive interlocking segments. Upon extraction, the same axial push shifts the filter lock further to align the interlocking fingers within gaps that allow for easy extraction. The specific key lock design allows a user to identify and match certain filter configurations received by the mechanical support, and reject other filter configurations.
B01D 35/14 - Safety devices specially adapted for filtrationDevices for indicating clogging
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
A filtration system interconnection structure having a filter manifold including a sump housing and a first correlated magnet located on or connected to a portion of the manifold, and a filter cartridge including a filter media, first and second end caps sealed to the filter media, and a second, paired correlated magnet located on or connected to the filter cartridge housing body. The first and second correlated magnets are interconnected via magnetic communication upon insertion of the filter cartridge into the sump housing, and upon movement of the filter cartridge into an alignment position, the correlated magnet located on or connected to the manifold is permitted to translate as a result of the magnetic communication. The polarity profiles of the paired correlated magnets are aligned such that a repulsion force is created when the filter cartridge is inserted within the manifold sump housing.
B01D 35/00 - Filtering devices having features not specifically covered by groups , or for applications not specifically covered by groups Auxiliary devices for filtrationFilter housing constructions
A filtration system interconnection structure having a filter manifold including a sump housing and a first correlated magnet located on or connected to a portion of the manifold, and a filter cartridge including a filter media, first and second end caps sealed to the filter media, and a second, paired correlated magnet located on or connected to the filter cartridge housing body. The first and second correlated magnets are interconnected via magnetic communication upon insertion of the filter cartridge into the sump housing, and upon movement of the filter cartridge into an alignment position, the correlated magnet located on or connected to the manifold is permitted to translate as a result of the magnetic communication. The polarity profiles of the paired correlated magnets are aligned such that a repulsion force is created when the filter cartridge is inserted within the manifold sump housing.
B01D 35/00 - Filtering devices having features not specifically covered by groups , or for applications not specifically covered by groups Auxiliary devices for filtrationFilter housing constructions
A filtration system interconnection structure having a filter manifold including a sump housing and a first correlated magnet located on or connected to a portion of the manifold, and a filter cartridge including a filter media, first and second end caps sealed to the filter media, and a second, paired correlated magnet located on or connected to the filter cartridge housing body. The first and second correlated magnets are interconnected via magnetic communication upon insertion of the filter cartridge into the sump housing, and upon movement of the filter cartridge into an alignment position, the correlated magnet located on or connected to the manifold is permitted to translate as a result of the magnetic communication. The polarity profiles of the paired correlated magnets are aligned such that a repulsion force is created when the filter cartridge is inserted within the manifold sump housing.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
H01H 3/50 - Driving mechanisms, i.e. for transmitting driving force to the contacts with indexing or locating means, e.g. indexing by ball and spring
H01H 36/00 - Switches actuated by change of magnetic field or of electric field, e.g. by change of relative position of magnet and switch, by shielding
42.
Filter interconnect utilizing correlated magnetic actuation for downstream system function
A filtration system interconnection structure having a filter manifold including a sump housing and a first correlated magnet located on or connected to a portion of the manifold, and a filter cartridge including a filter media, first and second end caps sealed to the filter media, and a second, paired correlated magnet located on or connected to the filter cartridge housing body. The first and second correlated magnets are interconnected via magnetic communication upon insertion of the filter cartridge into the sump housing, and upon movement of the filter cartridge into an alignment position, the correlated magnet located on or connected to the manifold is permitted to translate as a result of the magnetic communication. The polarity profiles of the paired correlated magnets are aligned such that a repulsion force is created when the filter cartridge is inserted within the manifold sump housing.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
H01H 3/50 - Driving mechanisms, i.e. for transmitting driving force to the contacts with indexing or locating means, e.g. indexing by ball and spring
H01H 36/00 - Switches actuated by change of magnetic field or of electric field, e.g. by change of relative position of magnet and switch, by shielding
43.
Reverse osmosis push filter with floating key lock
A reverse osmosis filter assembly for fluid filtration having a push-activated lock and release mechanism. A push filter design activates a floating key lock upon insertion and extraction, where the filter key may be used simultaneously as a lock and as an identifier for particular filter attributes. The filter base may be situated inline, and in fluid communication, with the raw water ingress, permeate egress, and reject water egress. The reverse osmosis filter housing assembly may be attached to, and removed from, the filter base by a push-actuated release. Upon insertion, the filter key shifts the filter lock longitudinally to receive interlocking segments. Upon extraction, the same axial push shifts the filter lock further to align the interlocking fingers within gaps that allow for easy extraction. The specific key lock design allows a user to identify and match certain filter configurations received by the mechanical support, and reject other filter configurations.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
B01D 17/00 - Separation of liquids, not provided for elsewhere, e.g. by thermal diffusion
A filter assembly for fluid filtration having a push-activated lock and release mechanism. A push filter design activates a filter key lock upon insertion and extraction, where the filter key may be used simultaneously as a lock and as an identifier for particular filter attributes. The filter housing assembly may be attached to, and removed from, a filter base by a push-actuated release. Upon insertion, the filter key shifts the filter lock longitudinally to receive interlocking segments. Upon extraction, the same axial push shifts the filter lock further to align the interlocking fingers within gaps that allow for easy extraction. The specific key lock design allows a user to identify and match certain filter configurations received by the mechanical support, and reject other filter configurations.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
B01D 17/00 - Separation of liquids, not provided for elsewhere, e.g. by thermal diffusion
A filter housing assembly for fluid filtration which may be attached to, and removed from, a filter base by a push-actuated release. The filter housing assembly has a top portion with an ingress port and egress port extending therefrom, and a protrusion extending from the filter housing longitudinally axial center. The ingress and egress port are formed in an hourglass shape. A filter key having a base with a groove for mating with said projection, at least one finger extending from said base, and an electronic circuit component housing attached thereto for receiving a printed circuit board, is connected to the filter housing top portion by mating said top portion protrusion with the filter key groove. Both of said ingress and egress port have at least one cavity for the passage of fluid therethrough, where each cavity is exposed in a direction facing away from the printed circuit board.
B01D 35/14 - Safety devices specially adapted for filtrationDevices for indicating clogging
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
01 - Chemical and biological materials for industrial, scientific and agricultural use
11 - Environmental control apparatus
Goods & Services
FIBER PULP PREPARATIONS, NAMELY, CHEMICAL AND MINERAL TREATMENT OF FIBER PULP, IN THE NATURE OF FILTERING MATERIALS FOR THE MANUFACTURING OF DOMESTIC, INDUSTRIAL, AND COMMERCIAL AIR AND WATER FILTERS; FIBRILLATED ADSORBENT CELLULOSE FOR USE AS FILTER MEDIA FOR GENERAL COMMERCIAL USE IN THE PURIFICATION OF AIR AND DRINKING WATER, AND FOR THE GENERAL AND INDUSTRIAL USE IN THE PURIFICATION OF AIR AND INDUSTRIAL FLUIDS. WATER AND AIR FILTERS FOR DOMESTIC, COMMERCIAL AND INDUSTRIAL USE; COMPONENTS OF WATER FILTRATION UNITS FOR PRODUCING POTABLE WATER FOR DOMESTIC USE, namely, ACTIVATED CARBON WATER FILTERS; ACTIVATED CARBON WATER FILTERS; FILTERS MADE OF FIBER FOR WATER FILTRATION, FILTERS MADE OF CARBON FIBER FOR WATER FILTRATION; FILTERS MADE OF CELLULOSE-BASED FIBER FOR WATER FILTRATION; FILTERS FOR WATER PURIFICATION APPARATUS; FILTERS FOR DRINKING WATER ALL AFOREMENTIONED GOODS NOT FOR USE IN MACHINES FOR AGRICULTURAL OR LANDSCAPE CONSERVATION AS WELL AS POWER TOOLS AND PUMPS.
01 - Chemical and biological materials for industrial, scientific and agricultural use
11 - Environmental control apparatus
Goods & Services
(1) Chemical and mineral fiber pulp preparations, in the nature of filtering materials for the manufacturing of domestic, industrial, and commercial air cleaning units and air conditioners and water filters namely activated carbon water filters; fibrillated adsorbent cellulose for use as filter media for general commercial use in the purification of air and drinking water, and for the general and industrial use in the purification of air and industrial fluids.
(2) Water filters for domestic, commercial and industrial use namely activated carbon water filters, air filters for domestic, commercial and industrial use namely, air cleaning units and air conditioners; components of water filtration units for producing potable water for domestic use, namely, activated carbon water filters; activated carbon water filters; filters made of carbon fiber and cellulose-based fiber for water filtration, filters made of carbon fiber for water filtration; filters made of cellulose-based fiber for water filtration; filters for water purification apparatus namely reverse-osmosis filtration units and water distilling units; filters for drinking water.
48.
Antimicrobial composite filtering material and method for making the same
A filter media having lignite-derived activated carbon, polyacrylic acid (PAA), a commercially available copper-zinc alloy, and polydiallyldimethylammonium chloride (PolyDADMAC) or Luviquat®, which is Poly[(3-methyl-1-vinylimidazolium chloride)-co-(1-vinylpyrrolidone)], combined and used as suitable replacement for TOG bituminous coal-based activated carbon, silver, and PolyDADMAC. Functional groups in lignite-based activated carbon interact with the polyacrylic acid. Functional groups such as calcium, iron, or aluminum oxide/hydroxide of lignite-based activated carbon interact with PAA, and help hold the PolyDADMAC in place. The additional presence of a copper-zinc alloy enhances the filter anti-microbiological performance.
A filtration system interconnection structure having manifold with a rotatable manifold magnet of correlated magnets, a shroud with alignment tracks, an actuating valve for water ingress, and a filter cartridge having a rotatable filter magnet of correlated magnets, where the manifold magnet and the filter magnet are in magnetic communication with one another when the filter cartridge is inserted with the shroud, and are at least partially rotatably compatible, where the manifold magnet rotates with the filter magnet until the manifold magnet experiences a rotational stop beyond a predetermined rotation of the filter magnet, thus allowing the filter magnet to shift polarity with respect to the manifold magnet and present a repulsion force for removal of the filter cartridge from the shroud.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
B01D 35/157 - Flow control valvesDamping or calibrated passages
B01D 35/06 - Filters making use of electricity or magnetism
50.
FILTER INTERCONNECT USING A CORRELATED MAGNET TORQUE DESIGN
A filtration system interconnection structure having manifold with a rotatable manifold magnet of correlated magnets, a shroud with alignment tracks, an actuating valve for water ingress, and a filter cartridge having a rotatable filter magnet of correlated magnets, where the manifold magnet and the filter magnet are in magnetic communication with one another when the filter cartridge is inserted with the shroud, and are at least partially rotatably compatible, where the manifold magnet rotates with the filter magnet until the manifold magnet experiences a rotational stop beyond a predetermined rotation of the filter magnet, thus allowing the filter magnet to shift polarity with respect to the manifold magnet and present a repulsion force for removal of the filter cartridge from the shroud.
A filter assembly for fluid filtration having a push-activated lock and release mechanism. A push filter design activates a floating key lock upon insertion and extraction, where the filter key may be used simultaneously as a lock and as an identifier for particular filter attributes. The filter base may be situated inline, and in fluid communication, with influent and effluent piping, such as within a refrigerator. The filter housing assembly may be attached to, and removed from, the filter base by a push-actuated release. Upon insertion, the filter key shifts the filter lock longitudinally to receive interlocking segments. Upon extraction, the same axial push shifts the filter lock further to align the interlocking fingers within gaps that allow for easy extraction. The specific key lock design allows a user to identify and match certain filter configurations received by the mechanical support, and reject other filter configurations.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
01 - Chemical and biological materials for industrial, scientific and agricultural use
11 - Environmental control apparatus
Goods & Services
FIBER PULP PREPARATIONS, NAMELY, CHEMICAL AND MINERAL TREATMENT OF FIBER PULP, IN THE NATURE OF FILTERING MATERIALS FOR THE MANUFACTURING OF DOMESTIC, INDUSTRIAL, AND COMMERCIAL AIR AND WATER FILTERS; FIBRILLATED ADSORBENT CELLULOSE FOR USE AS FILTER MEDIA FOR GENERAL COMMERCIAL USE IN THE PURIFICATION OF AIR AND DRINKING WATER, AND FOR THE GENERAL AND INDUSTRIAL USE IN THE PURIFICATION OF AIR AND INDUSTRIAL FLUIDS WATER AND AIR FILTERS FOR DOMESTIC, COMMERCIAL AND INDUSTRIAL USE; COMPONENTS OF WATER FILTRATION UNITS FOR PRODUCING POTABLE WATER FOR DOMESTIC USE, namely, ACTIVATED CARBON WATER FILTERS; ACTIVATED CARBON WATER FILTERS; FILTERS MADE OF FIBER FOR WATER FILTRATION, FILTERS MADE OF CARBON FIBER FOR WATER FILTRATION; FILTERS MADE OF CELLULOSE-BASED FIBER FOR WATER FILTRATION; FILTERS FOR WATER PURIFICATION APPARATUS; FILTERS FOR DRINKING WATER
A filter assembly for fluid filtration having a push-activated lock and release mechanism. A push filter design activates a floating key lock upon insertion and extraction, where the filter key may be used simultaneously as a lock and as an identifier for particular filter attributes. The filter base may be situated inline, and in fluid communication, with influent and effluent piping, such as within a refrigerator. The filter housing assembly may be attached to, and removed from, the filter base by a push-actuated release. Upon insertion, the filter key shifts the filter lock longitudinally to receive interlocking segments. Upon extraction, the same axial push shifts the filter lock further to align the interlocking fingers within gaps that allow for easy extraction. The specific key lock design allows a user to identify and match certain filter configurations received by the mechanical support, and reject other filter configurations.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
54.
METHOD AND APPARATUS FOR METAL REMOVAL FROM DRINKING WATER
A single sheet water filter media for gravity filtration applications that improves flow performance over the product life while maintaining sufficient metal reduction, wherein at least two distinct density gradients of the single sheet form a physical barrier for capturing colloidal and insoluble contaminants, retaining the colloidal and insoluble contaminants until the contaminants become soluble in the fluid, and being removed by the single sheet' filter media. The single sheet filter overcomes the difficulties of dual- and multi- layer filters attributable to slower flow rate realized well before the rated lifetime of the product. The two distinct density gradients of the single sheet filter media are created by exerting a force on a liquid slurry, such force resulting in the separation of higher powder loading and fibers that compose the top and bottom density gradients, respectfully.
A single sheet water filter media for gravity filtration applications that improves flow performance over the product life while maintaining sufficient metal reduction, wherein at least two distinct density gradients of the single sheet form a physical barrier for capturing colloidal and insoluble contaminants, retaining the colloidal and insoluble contaminants until the contaminants become soluble in the fluid, and being removed by the single sheet' filter media. The single sheet filter overcomes the difficulties of dual- and multi- layer filters attributable to slower flow rate realized well before the rated lifetime of the product. The two distinct density gradients of the single sheet filter media are created by exerting a force on a liquid slurry, such force resulting in the separation of higher powder loading and fibers that compose the top and bottom density gradients, respectfully.
A combination gas and fluid filter housing for supporting said gas and fluid filter media, having a first subassembly for supporting the gas filter media, and a second subassembly for supporting the fluid filter media, the second subassembly having ingress and egress ports at an end opposite of the first subassembly attachable to a manifold, the first and second subassemblies removably attached to one another such that the first subassembly is removable from said second subassembly to facilitate gas filter media replacement without disconnecting the second subassembly ingress and egress ports from the manifold.
B01D 39/08 - Filter cloth, i.e. woven, knitted or interlaced material
B01D 39/14 - Other self-supporting filtering material
B01D 39/18 - Other self-supporting filtering material of organic material, e.g. synthetic fibres the material being cellulose or derivatives thereof
B01D 46/00 - Filters or filtering processes specially modified for separating dispersed particles from gases or vapours
B01D 46/24 - Particle separators, e.g. dust precipitators, using rigid hollow filter bodies
B01D 46/52 - Particle separators, e.g. dust precipitators, using filters embodying folded material
F25D 17/04 - Arrangements for circulating cooling fluidsArrangements for circulating gas, e.g. air, within refrigerated spaces for circulating gas, e.g. by natural convection
A combination gas and fluid filter housing for supporting said gas and fluid filter media, having a first subassembly for supporting the gas filter media, and a second subassembly for supporting the fluid filter media, the second subassembly having ingress and egress ports at an end opposite of the first subassembly attachable to a manifold, the first and second subassemblies removably attached to one another such that the first subassembly is removable from said second subassembly to facilitate gas filter media replacement without disconnecting the second subassembly ingress and egress ports from the manifold.
A filter media having lignite-derived activated carbon, polyacrylic acid (PAA), a commercially available copper-zinc alloy, and polydiallyldimethylammonium chloride (PolyDADMAC) or Luviquat®, which is Poly[(3-methyl-1-vinylimidazolium chloride)-co-(1-vinylpyrrolidone)], combined and used as suitable replacement for TOG bituminous coal -based activated carbon, silver, and PolyDADMAC. Functional groups in lignite-based activated carbon interact with the polyacrylic acid. Functional groups such as calcium, iron, or aluminum oxide / hydroxide of lignite-based activated carbon interact with PAA, and help hold the PolyDADMAC in place. The additional presence of a copper-zinc alloy enhances the filter anti-microbiological performance.
B32B 5/02 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by structural features of a layer comprising fibres or filaments
B32B 7/12 - Interconnection of layers using interposed adhesives or interposed materials with bonding properties
D04H 1/4382 - Stretched reticular film fibresComposite fibresMixed fibresUltrafine fibresFibres for artificial leather
D04H 1/54 - Non-woven fabrics formed wholly or mainly of staple fibres or like relatively short fibres from fleeces or layers composed of fibres without existing or potential cohesive properties by welding together the fibres, e.g. by partially melting or dissolving
A filter assembly for fluid filtration having a push-activated lock and release mechanism. A push filter design activates a filter key lock upon insertion and extraction, where the filter key may be used simultaneously as a lock and as an identifier for particular filter attributes. The filter housing assembly may be attached to, and removed from, a filter base by a push-actuated release. Upon insertion, the filter key shifts the filter lock longitudinally to receive interlocking segments. Upon extraction, the same axial push shifts the filter lock further to align the interlocking fingers within gaps that allow for easy extraction. The specific key lock design allows a user to identify and match certain filter configurations received by the mechanical support, and reject other filter configurations.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
B01D 17/00 - Separation of liquids, not provided for elsewhere, e.g. by thermal diffusion
A modular filtration platform having at least one manifold head and at least one respective filter cartridge assembly. Each manifold head is connected to one another to establish a water flow in a series or parallel manner. Each filter cartridge assembly is releasably secured from rotation relative to the manifold head by a locking mechanism. An aperture on the filter cartridge assembly annular collar mates with a protruding resilient extension on either the manifold head or support bracket. Alternatively, an aperture on the filter cartridge assembly annular collar and an aperture on the manifold head annular collar mate with a protruding member from a locking ring extending through both apertures. An integrated sensor package may be integrated with the system for true managed water visible/audible indications and Wi-Fi interface to facilitate virtually instantaneous response times for filtration needs.
B01D 29/11 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor with bag, cage, hose, tube, sleeve or like filtering elements
(1) Water filters; water filters for domestic, industrial, and commercial use, namely, activated carbon water filters; filters made of fiber for water filtration, namely, carbon fiber, cellulose-based fiber; water filter system components for domestic, industrial, and commercial use, namely, filter housings, water filtration units for producing potable water and replacement parts therefor; filters for water purification apparatus.
Water filters; water filters for domestic, industrial, and commercial use, namely, activated carbon water filters; filters made of fiber for water filtration, namely, carbon fiber, cellulose-based fiber; water filter system components for domestic, industrial, and commercial use, namely, filter housings, water filtration units for producing potable water and replacements parts therefor; filters for water purification apparatus.
01 - Chemical and biological materials for industrial, scientific and agricultural use
11 - Environmental control apparatus
Goods & Services
Activated carbon for water filtration, fiber pulp preparations, namely, chemical and mineral treatment of fiber pulp, in the nature of filtering materials for the manufacturing of domestic, industrial, and commercial air and waters filters; fibrillated adsorbent cellulose for use as filter media for general commercial use in the purification of air and industrial fluids. Fibrous filter media for general commercial use in the purification of air and drinking water, and for the general industrial use in the purification of air and industrial fluids; water filters; water filters for domestic, industrial, and commercial use, namely activated carbon water filters; filters made of fiber for water filtration, namely, carbon fiber, cellulose-based fiber; air filters for domestic, commercial and industrial use; air and water filter system components for domestic, industrial, and commercial use, namely, filter housings; water filtration units for producing potable water; filters for water purification apparatus.
FIBROUS FILTER MEDIA FOR GENERAL COMMERCIAL USE IN THE PURIFICATION OF AIR AND DRINKING WATER, AND FOR THE GENERAL INDUSTRIAL USE IN THE PURIFICATION OF AIR AND INDUSTRIAL FLUIDS; WATER FILTERS; WATER FILTERS FOR DOMESTIC, INDUSTRIAL, AND COMMERCIAL USE, NAMELY, ACTIVATED CARBON WATER FILTERS; FILTERS MADE OF FIBER FOR WATER FILTRATION, NAMELY, CARBON FIBER, CELLULOSE-BASED FIBER; AIR FILTERS FOR DOMESTIC, COMMERCIAL AND INDUSTRIAL USE; AIR AND WATER FILTER SYSTEM COMPONENTS FOR DOMESTIC, INDUSTRIAL, AND COMMERCIAL USE, NAMELY, FILTER HOUSINGS; WATER FILTRATION UNITS FOR PRODUCING POTABLE WATER; FILTERS FOR WATER PURIFICATION APPARATUS; NONE OF THE AFOREMENTIONED GOODS ARE INTENDED FOR OR RELATE TO HEATING INSTALLATIONS AND EQUIPMENT and not for the use in machines for agricultural or landscape conservation as well as power tool and pumps.
(1) Fibrous filter media for general commercial use in the purification of air and drinking water, and for general industrial use in the purification of air and industrial fluids; filters for drinking water; carbon filters for general commercial and industrial use in the purification of drinking water; carbon filters for general commercial and industrial use in the purification of water, namely, water treatment plant filters; carbon water filtering units for industrial use
(1) Filters for drinking water; household tap-water filters; water filtering units for domestic use; and water filtering units for industrial use; drinking water filters made of activated carbon, carbon fiber, cellulose-based fiber.
A proportioning valve for a reverse osmosis system that controls the production of product water by the differential pressure across the purification membrane. By sensing increasing tank pressure to actuate the proportioning valve, the flow of waste water is restricted. Placement of seals within the cavity of the valve, as well as placement of waste water inlet and outlet ports, protects tension components that provide reverse tank pressure from waste water exposure. A needle valve assembly responsive to an actuating assembly that senses tank pressure removes the need for an inlet tank water port while restricting water flow.
F16K 11/07 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid with all movable sealing faces moving as one unit comprising only sliding valves with linearly sliding closure members with cylindrical slides
F16K 7/17 - Diaphragm cut-off apparatus, e.g. with a member deformed, but not moved bodily, to close the passage with flat, dished, or bowl-shaped diaphragm arranged to be deformed against a flat seat the diaphragm being actuated by fluid pressure
F16K 17/22 - Excess-flow valves actuated by the difference of pressure between two places in the flow line
F16K 31/12 - Operating meansReleasing devices actuated by fluid
F16K 41/16 - Spindle sealings with a flange on the spindle which rests on a sealing ring
72.
Electrostatic removal of colloidal, soluble and insoluble materials from a fluid
A filter that contains an adsorbent to remove the soluble portion of the contaminant, and then some form of electrostatic attraction additive. The electrostatic attraction additive would serve to pull the colloidal and particulate portion of the contaminant out of fluid, which could be held indefinitely, or be used to hold while the contaminant is allowed to solubilize and then be removed by the adsorbent. The electrostatic attraction additive could either be positively or negatively charged depending on the surface charge of the particulates that are in the fluid, and includes particles or fibers charged with charged polymers, zeolites, cation or anion exchange resin, powdered alumina, or nano-alumina.
Filters for use in conjunction with valves of the faucet or spigot type, and to filters for use in devices for withdrawing liquids from containers at relatively low pressures, such as gravity feed jugs or other gravity feed reservoirs. A ¼-turn attachment scheme for connecting a filter cartridge to a gravity feed reservoir, such as within a beverage making/dispensing device.
B01D 35/02 - Filters adapted for location in special places, e.g. pipe-lines, pumps, stop-cocks
B01D 27/06 - Cartridge filters of the throw-away type with cartridges made of a piece of unitary material, e.g. filter paper with corrugated, folded or wound material
C02F 1/00 - Treatment of water, waste water, or sewage
C02F 1/28 - Treatment of water, waste water, or sewage by sorption
A reverse osmosis filter assembly for fluid filtration having a push-activated lock and release mechanism. A push filter design activates a floating key lock upon insertion and extraction, where the filter key may be used simultaneously as a lock and as an identifier for particular filter attributes. The filter base may be situated inline, and in fluid communication, with the raw water ingress, permeate egress, and reject water egress. The reverse osmosis filter housing assembly may be attached to, and removed from, the filter base by a push-actuated release. Upon insertion, the filter key shifts the filter lock longitudinally to receive interlocking segments. Upon extraction, the same axial push shifts the filter lock further to align the interlocking fingers within gaps that allow for easy extraction. The specific key lock design allows a user to identify and match certain filter configurations received by the mechanical support, and reject other filter configurations.
C02F 1/44 - Treatment of water, waste water, or sewage by dialysis, osmosis or reverse osmosis
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
A filter assembly for fluid filtration having a push-activated lock and release mechanism. A push filter design activates a floating key lock upon insertion and extraction, where the filter key may be used simultaneously as a lock and as an identifier for particular filter attributes. The filter base may be situated inline, and in fluid communication, with influent and effluent piping, such as within a refrigerator. The filter housing assembly may be attached to, and removed from, the filter base by a push-actuated release. Upon insertion, the filter key shifts the filter lock longitudinally to receive interlocking segments. Upon extraction, the same axial push shifts the filter lock further to align the interlocking fingers within gaps that allow for easy extraction. The specific key lock design allows a user to identify and match certain filter configurations received by the mechanical support, and reject other filter configurations.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
A countertop water dispenser having a three tiered reservoir system for filtering water and providing immediate dispensing via a spigot, and simultaneously filling a removable pitcher for transporting filtered water to another location. Water flow in the three tiered reservoir system may be controlled by flow valves that float with rising water to stop water flow when a maximum fill level is reached in a reservoir. A flow valve is provided in the middle reservoir as well as the lower reservoir to control the amount of filtered water in each reservoir. An air vent is provided on a filter housing, the air vent venting to a heightened arcuate rib on the countertop dispenser cover. The removable pitcher is mated to the lower reservoir via a pitcher filling mechanism that includes respective plunger or pin valves to allow water to flow into the pitcher when the lower reservoir is filled with water above or equal to the height of the pitcher filling mechanism.
B67D 7/00 - Apparatus or devices for transferring liquids from bulk storage containers or reservoirs into vehicles or into portable containers, e.g. for retail sale purposes
A carafe filter cartridge for reverse flow applications where the filter housing and filter media top end cap directs unfiltered fluid into the filter media annular cavity, through the filter media sidewalls. And the filter media bottom end cap prohibits egress, filter fluid from exiting through the filter media end or the annular cavity. Filtered fluid is instead directed out through apertures in the filter housing sidewall. The optimum ratio of annular cavity and/or top end cap orifice area to the respective perimeter is determined to remove the risk of detrimental fluid flow due to air bubble generation.
B01D 27/07 - Cartridge filters of the throw-away type with cartridges made of a piece of unitary material, e.g. filter paper with corrugated, folded or wound material having a coaxial stream through the filtering element
Water filters; water filters for domestic, industrial, and commercial use, namely, activated carbon water filters; filters made of fiber for water filtration, namely, carbon fiber, cellulose-based fiber; air and water filter system, components for domestic, industrial, and commercial use, namely, filter housings, water filtration units for producing potable water and replacement parts therefor; filters for water purification apparatus in International Class 11.
A filter assembly for fluid filtration having a push-activated lock and release mechanism. A push filter design activates a floating key lock upon insertion and extraction, where the filter key may be used simultaneously as a lock and as an identifier for particular filter attributes. The filter base may be situated inline, and in fluid communication, with influent and effluent piping, such as within a refrigerator. The filter housing assembly may be attached to, and removed from, the filter base by a push-actuated release. Upon insertion, the filter key shifts the filter lock longitudinally to receive interlocking segments. Upon extraction, the same axial push shifts the filter lock further to align the interlocking fingers within gaps that allow for easy extraction. The specific key lock design allows a user to identify and match certain filter configurations received by the mechanical support, and reject other filter configurations.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
A filter assembly for fluid filtration having a push-activated lock and release mechanism. A push filter design activates a floating key lock upon insertion and extraction, where the filter key may be used simultaneously as a lock and as an identifier for particular filter attributes. The filter base may be situated inline, and in fluid communication, with influent and effluent piping, such as within a refrigerator. The filter housing assembly may be attached to, and removed from, the filter base by a push-actuated release. Upon insertion, the filter key shifts the filter lock longitudinally to receive interlocking segments. Upon extraction, the same axial push shifts the filter lock further to align the interlocking fingers within gaps that allow for easy extraction. The specific key lock design allows a user to identify and match certain filter configurations received by the mechanical support, and reject other filter configurations.
B01D 29/96 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor in which the filtering elements are moved between filtering operationsParticular measures for removing or replacing the filtering elementsTransport systems for filters
Filter cartridge designs for use in conjunction with valves of the faucet or spigot type for withdrawing liquids at relatively low pressures from containers such as gravity feed jugs, ice chests, coolers, collapsible travel bags, and the like, wherein the filter cartridge housings have various shapes and attachment schemes to the spigot subassembly.
B01D 24/06 - Filters comprising loose filtering material, i.e. filtering material without any binder between the individual particles or fibres thereof with the filter bed stationary during the filtration the filtering material being clamped between pervious fixed walls the pervious walls comprising a series of louvres or slots
B01D 24/08 - Filters comprising loose filtering material, i.e. filtering material without any binder between the individual particles or fibres thereof with the filter bed stationary during the filtration the filtering material being clamped between pervious fixed walls the filtering material being supported by at least two pervious coaxial walls
B67D 3/04 - Liquid-dispensing taps or cocks adapted to seal and open tapping-holes of casks, e.g. for beer
C02F 1/28 - Treatment of water, waste water, or sewage by sorption
B01D 29/01 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor with flat filtering elements
B01D 35/027 - Filters adapted for location in special places, e.g. pipe-lines, pumps, stop-cocks rigidly mounted in or on tanks or reservoirs
Filter cartridge designs for use in conjunction with valves of the faucet or spigot type for withdrawing liquids at relatively low pressures from containers such as gravity feed jugs, ice chests, coolers, collapsible travel bags, and the like, wherein the filter cartridge housings have various shapes and attachment schemes to the spigot subassembly.
A filter that contains an adsorbent to remove the soluble portion of the contaminant, and then some form of electrostatic attraction additive. The electrostatic attraction additive would serve to pull the colloidal and particulate portion of the contaminant out of fluid, which could be held indefinitely, or be used to hold while the contaminant is allowed to solubilize and then be removed by the adsorbent. The electrostatic attraction additive could either be positively or negatively charged depending on the surface charge of the particulates that are in the fluid, and includes particles or fibers charged with charged polymers, zeolites, cation or anion exchange resin, powdered alumina, or nano-alumina.
B01D 35/00 - Filtering devices having features not specifically covered by groups , or for applications not specifically covered by groups Auxiliary devices for filtrationFilter housing constructions
B01D 39/00 - Filtering material for liquid or gaseous fluids
89.
ELECTROSTATIC REMOVAL OF COLLOIDAL, SOLUBLE, AND INSOLUBLE MATERIALS FROM A FLUID
A filter that contains an adsorbent to remove the soluble portion of the contaminant, and then some form of electrostatic attraction additive. The electrostatic attraction additive would serve to pull the colloidal and particulate portion of the contaminant out of fluid, which could be held indefinitely, or be used to hold while the contaminant is allowed to solubilize and then be removed by the adsorbent. The electrostatic attraction additive could either be positively or negatively charged depending on the surface charge of the particulates that are in the fluid, and includes particles or fibers charged with charged polymers, zeolites, cation or anion exchange resin, powdered alumina, or nano-alumina.
B01D 35/00 - Filtering devices having features not specifically covered by groups , or for applications not specifically covered by groups Auxiliary devices for filtrationFilter housing constructions
B01D 39/00 - Filtering material for liquid or gaseous fluids
A filter for gravity-fed applications, having filter media with a hollow center, the filter being generally prone to a degradation or cessation in fluid flow due to air entrapment or air lock within the filter housing cavity, which develops during filtering. A diffuser element is introduced to pierce the entrapped air bubble, the diffuser element being an elongated structure connected to the filter housing top end cap and extending through the entrapped air bubble to the filter media.
B01D 35/00 - Filtering devices having features not specifically covered by groups , or for applications not specifically covered by groups Auxiliary devices for filtrationFilter housing constructions
A filter for gravity-fed applications, having filter media with a hollow center, the filter being generally prone to a degradation or cessation in fluid flow due to air entrapment or air lock within the filter housing cavity, which develops during filtering. A diffuser element is introduced to pierce the entrapped air bubble, the diffuser element being an elongated structure connected to the filter housing top end cap and extending through the entrapped air bubble to the filter media.
B01D 29/00 - Filters with filtering elements stationary during filtration, e.g. pressure or suction filters, not covered by groups Filtering elements therefor
B01D 29/21 - Supported filter elements arranged for inward flow filtration with corrugated, folded or wound sheets
A gravity filter media fabricated from multiple spiral wound or pleated layers, where different layers are designed for specific contaminant removal process and the layers are combined into a single pack for ease of use. The layers or fiber sheets are chemically treated for contaminant removal, with different layers having different chemical treatments, or the layers are immobilized with particles of various sizes for use as low contact -time adsorbents, with different layers having different immobilized particles, or the pore structure is varied from one fiber sheet to another - one being a tight pore structure, and the other being a more open pore structure, or any combination thereof. When using immobilized particles, the immobilized particles can be chemically treated for the specific removal of targeted contaminants, and multi-layered for custom designed removal of specific contaminants.
B01D 39/00 - Filtering material for liquid or gaseous fluids
B01D 35/00 - Filtering devices having features not specifically covered by groups , or for applications not specifically covered by groups Auxiliary devices for filtrationFilter housing constructions
The present invention presents a removably secured seal for forming a second stage water-tight seal within a two stage cavity filter head assembly for mating with a complementary manifold having cylindrical (male) bayonet ports. The seal includes a base circumferential seal having a center aperture and sidewall members extending axially upwards from the base seal; the sidewall members being insertable within cavities or slots formed in the second stage recess cylindrical cavity sidewall.
The present invention presents a removably secured seal for forming a second stage water-tight seal within a two stage cavity filter head assembly for mating with a complementary manifold having cylindrical (male) bayonet ports. The seal includes a base circumferential seal having a center aperture and sidewall members extending axially upwards from the base seal; the sidewall members being insertable within cavities or slots formed in the second stage recess cylindrical cavity sidewall.
The present invention presents a removably secured seal for forming a second stage water-tight seal within a two stage cavity filter head assembly for mating with a complementary manifold having cylindrical (male) bayonet ports. The seal includes a base circumferential seal having a center aperture and sidewall members extending axially upwards from the base seal; the sidewall members being insertable within cavities or slots formed in the second stage recess cylindrical cavity sidewall.
A scale suppression media and methods of making augmented polyacrylate resin beads combined with a directing agent to facilitate the formation of calcite and aragonite forms of calcium carbonate, the directing agent deposited directly into said polyacrylate resin beads. A strong acid monovalent salt, such as a metal ion, is added to the polyacrylate resin, and is adapted to be time released, and templates the calcium carbonate in the influent to form crystals in the water with reduced deposition of scale on the surfaces of material in contact with the water. The pores of the resin are filled with metal templating agent, and the agent is released as the influent passes over the resin.
C02F 5/08 - Treatment of water with complexing chemicals or other solubilising agents for softening, scale prevention or scale removal, e.g. adding sequestering agents
01 - Chemical and biological materials for industrial, scientific and agricultural use
11 - Environmental control apparatus
Goods & Services
FIBER PULP PREPARATIONS, NAMELY, CHEMICAL AND MINERAL TREATMENT OF FIBER PULP, IN THE NATURE OF FILTERING MATERIALS FOR THE MANUFACTURING OF DOMESTIC, INDUSTRIAL, AND COMMERCIAL AIR AND WATERS FILTERS; FIBRILLATED ADSORBENT CELLULOSE FOR USE AS FILTER MEDIA FOR GENERAL COMMERCIAL USE IN THE PURIFICATION OF AIR AND DRINKING WATER, AND FOR THE GENERAL AND INDUSTRIAL USE IN THE PURIFICATION OF AIR AND INDUSTRIAL FLUIDS FIBROUS FILTER MEDIA FOR GENERAL COMMERCIAL USE IN THE PURIFICATION OF AIR AND DRINKING WATER, AND FOR THE GENERAL INDUSTRIAL USE IN THE PURIFICATION OF AIR AND INDUSTRIAL FLUIDS; WATER FILTERS; WATER FILTERS FOR DOMESTIC, INDUSTRIAL, AND COMMERCIAL USE, NAMELY, ACTIVATED CARBON WATER FILTERS; FILTERS MADE OF FIBER FOR WATER FILTRATION, NAMELY, CARBON FIBER, CELLULOSE-BASED FIBER; AIR FILTERS FOR DOMESTIC, COMMERCIAL AND INDUSTRIAL USE; AIR AND WATER FILTER SYSTEM COMPONENTS FOR DOMESTIC, INDUSTRIAL, AND COMMERCIAL USE, NAMELY, FILTER HOUSINGS; WATER FILTRATION UNITS FOR PRODUCING POTABLE WATER; FILTERS FOR WATER PURIFICATION APPARATUS
01 - Chemical and biological materials for industrial, scientific and agricultural use
11 - Environmental control apparatus
Goods & Services
FIBER PULP PREPARATIONS, NAMELY, CHEMICAL AND MINERAL TREATMENT OF FIBER PULP, IN THE NATURE OF FILTERING MATERIALS FOR THE MANUFACTURING OF DOMESTIC, INDUSTRIAL, AND COMMERCIAL AIR AND WATERS FILTERS; FIBRILLATED ADSORBENT CELLULOSE FOR USE AS FILTER MEDIA FOR GENERAL COMMERCIAL USE IN THE PURIFICATION OF AIR AND DRINKING WATER, AND FOR THE GENERAL AND INDUSTRIAL USE IN THE PURIFICATION OF AIR AND INDUSTRIAL FLUIDS FIBROUS FILTER MEDIA FOR GENERAL COMMERCIAL USE IN THE PURIFICATION OF AIR AND DRINKING WATER, AND FOR THE GENERAL INDUSTRIAL USE IN THE PURIFICATION OF AIR AND INDUSTRIAL FLUIDS; WATER FILTERS; WATER FILTERS FOR DOMESTIC, INDUSTRIAL, AND COMMERCIAL USE, NAMELY, ACTIVATED CARBON WATER FILTERS; FILTERS MADE OF FIBER FOR WATER FILTRATION, NAMELY, CARBON FIBER, CELLULOSE-BASED FIBER; AIR FILTERS FOR DOMESTIC, COMMERCIAL AND INDUSTRIAL USE; AIR AND WATER FILTER SYSTEM COMPONENTS FOR DOMESTIC, INDUSTRIAL, AND COMMERCIAL USE, NAMELY, FILTER HOUSINGS; WATER FILTRATION UNITS FOR PRODUCING POTABLE WATER; FILTERS FOR WATER PURIFICATION APPARATUS
01 - Chemical and biological materials for industrial, scientific and agricultural use
11 - Environmental control apparatus
Goods & Services
FIBER PULP PREPARATIONS, NAMELY, CHEMICAL AND MINERAL TREATMENT OF FIBER PULP, IN THE NATURE OF FILTERING MATERIALS FOR THE MANUFACTURING OF DOMESTIC, INDUSTRIAL, AND COMMERCIAL AIR AND WATERS FILTERS; FIBRILLATED ADSORBENT CELLULOSE FOR USE AS FILTER MEDIA FOR GENERAL COMMERCIAL USE IN THE PURIFICATION OF AIR AND DRINKING WATER, AND FOR THE GENERAL AND INDUSTRIAL USE IN THE PURIFICATION OF AIR AND INDUSTRIAL FLUIDS FIBROUS FILTER MEDIA FOR GENERAL COMMERCIAL USE IN THE PURIFICATION OF AIR AND DRINKING WATER, AND FOR THE GENERAL INDUSTRIAL USE IN THE PURIFICATION OF AIR AND INDUSTRIAL FLUIDS; WATER FILTERS; WATER FILTERS FOR DOMESTIC, INDUSTRIAL, AND COMMERCIAL USE, NAMELY, ACTIVATED CARBON WATER FILTERS; FILTERS MADE OF FIBER FOR WATER FILTRATION, NAMELY, CARBON FIBER, CELLULOSE-BASED FIBER; AIR FILTERS FOR DOMESTIC, COMMERCIAL AND INDUSTRIAL USE; AIR AND WATER FILTER SYSTEM COMPONENTS FOR DOMESTIC, INDUSTRIAL, AND COMMERCIAL USE, NAMELY, FILTER HOUSINGS; WATER FILTRATION UNITS FOR PRODUCING POTABLE WATER; FILTERS FOR WATER PURIFICATION APPARATUS
