Goods & Services

Receptacles for applying medicines; intravenous feeding bottles; bags for collecting body fluids; intravenous bags for medical purposes; vessels for histological purposes. Containers, and closures and holders therefor, non-metallic; caps and closures, not of metal, for bottles; bottle closures, not of metal; bottle caps, not of metal; screw caps, not of metal; screw caps, not of metal; screw tops, not of metal, for bottles; non-metallic cap closures for containers; plastic bins [other than dustbins]; thermoformed plastics containers [other than for household or kitchen use]; capsules [non-metallic containers]; container closures of plastic; flexible containers of plastics for the transport of liquids; flexible containers of plastics for the storage of liquids; plastic trays [containers] used in food packaging; containers, not of metal, for storage, namely plastic storage bags, not for packaging purposes; thermoformed closures; thermoformed closures of plastic. Household containers; beverageware; plastic bottles; bottles for pharmaceuticals sold empty; thermoformed plastic containers for household or kitchen use.

Abstract

A method for cleaning molding tools for molding fibrous materials and a molding tool are described. The method includes introducing a liquid medium to the molding tool where the molding tool has openings in at least one region of a shaping surface. The openings are connected to channels for discharging water vapor exiting during a molding process under pressure and heat input. The openings and channels for discharging water vapor are provided in a discharge direction out of the molding tool. For cleaning the openings and channels, a medium in liquid form is introduced into at least one channel of the molding tool counter to the discharge direction when the molding tool has a minimum temperature. The introduced liquid medium changes into a gaseous state by contact with the molding tool and exits from the channels and openings counter to the discharge direction.

IPC Classes  ?

• B29C 33/72 - Cleaning
• B29C 33/02 - Moulds or coresDetails thereof or accessories therefor with incorporated heating or cooling means

Abstract

A method for forming molded articles from a moldable material in a mold, a mold, and a molded article is disclosed. The mold has two mold halves that, in a closed state, define a mold cavity between the mold surfaces of the mold halves and the mold cavity has an undercut. The mold halves have openings on their mold surfaces via which a relative underpressure and a relative overpressure are configured to be generated. Moldable material in the mold cavity is pressed into a molded article when the mold is closed and, for deforming, an overpressure is generated via the openings of a second mold surface when the mold is closed, such that the molded article is pushed away from the second mold surface and the mold is then opened by relative displacement of the mold halves away from one another.

IPC Classes  ?

• D21J 5/00 - Manufacture of hollow articles by transferring sheets, produced from fibres suspensions or papier-mâché by suction on wire-net moulds, to couch moulds

Abstract

Pulp reservoirs for a fiber molding plant and methods for suctioning and forming fibers out of a pulp from a pulp reservoir of a fiber molding plant are described.

IPC Classes  ?

• D21J 5/00 - Manufacture of hollow articles by transferring sheets, produced from fibres suspensions or papier-mâché by suction on wire-net moulds, to couch moulds

Abstract

An apparatus for transferring a material web in a thermoforming machine is disclosed. The thermoforming machine may have a forming tool. The forming tool is tilted about an axis running transversely to the feed direction of the material web during a forming process. The material web is transported from a forming region of the forming tool of the thermoforming machine to a downstream station of the thermoforming machine. The material web is moved from the forming region to the downstream station, where the transfer apparatus includes a transport unit with a transport device that is displaced in a first direction between the forming tool and the downstream station and is engaged with an initial portion of the material web in a first region facing the forming tool and is disengaged in a second region facing the downstream station.

IPC Classes  ?

• B29C 51/44 - Removing or ejecting moulded articles
• B29C 51/26 - Component parts, details or accessoriesAuxiliary operations

Abstract

A transfer device for transferring parallel-arranged rows of stacked molded parts, a transfer station with a transfer device, a thermoforming system with a transfer station, and a method for transferring thermoformed molded parts are described. Thermoformed molded parts are transferred from a stacking basket to a transport unit using a transfer device. Stacked molded parts are transferred row by row from the receiving compartments of the stacking basket to a transfer device for transferring stacked molded parts via a shifting unit. The transfer device has transfer elements arranged parallel relative to one another, which in each case hold a row of stacked molded parts during a transfer to a transport unit. The transport unit has parallel-arranged receptacles for stacked molded parts. The spacing of the transfer elements relative to one another is modified after the receiving of the stacked molded parts and prior to the transfer to the transport unit.

IPC Classes  ?

• B29C 51/26 - Component parts, details or accessoriesAuxiliary operations
• B29C 51/44 - Removing or ejecting moulded articles

Goods & Services

Receptacles for applying medicines; intravenous feeding bottles; bags for collecting body fluids; intravenous bags for medical purposes; vessels for histological purposes. Containers, and closures and holders therefor, non-metallic; caps and closures, not of metal, for bottles; bottle closures, not of metal; bottle caps, not of metal; screw caps, not of metal; screw caps, not of metal; screw tops, not of metal, for bottles; non-metallic cap closures for containers; plastic bins [other than dustbins]; thermoformed plastics containers [other than for household or kitchen use]; capsules [non-metallic containers]; container closures of plastic; flexible containers of plastics for the transport of liquids; flexible containers of plastics for the storage of liquids; plastic trays [containers] used in food packaging; containers, not of metal, for storage, namely plastic storage bags, not for packaging purposes; thermoformed closures; thermoformed closures of plastic. Household containers; beverageware; plastic bottles; bottles for pharmaceuticals sold empty; thermoformed plastic containers for household or kitchen use.

Goods & Services

(1) Receptacles for applying medicines; intravenous feeding bottles; bags for collecting body fluids; intravenous bags for medical purposes; vessels for histological purposes. (2) Containers, and closures and holders therefor, non-metallic; caps and closures, not of metal, for bottles; bottle closures, not of metal; bottle caps, not of metal; screw caps, not of metal; screw caps, not of metal; screw tops, not of metal, for bottles; non-metallic cap closures for containers; plastic bins [other than dustbins]; thermoformed plastics containers [other than for household or kitchen use]; capsules [non-metallic containers]; container closures of plastic; flexible containers of plastics for the transport of liquids; flexible containers of plastics for the storage of liquids; plastic trays [containers] used in food packaging; containers, not of metal, for storage, namely plastic storage bags, not for packaging purposes; thermoformed closures; thermoformed closures of plastic. (3) Household containers; beverageware; plastic bottles; bottles for pharmaceuticals sold empty; thermoformed plastic containers for household or kitchen use.

Goods & Services

Machines and apparatus for the transfer, processing and handling of films, in particular plastic films; Film transfer machines; Film processing machines; Film conveyors; Roller conveyors and conveyor belts for films; Automated transfer and further processing machines for films; Parts and fittings for the aforesaid machines, in particular Belts for conveyors, Rollers, Drive units, Control units, Pin chains, adjusting drives, Guides; Machines for the vacuum forming and pneumatic forming of plastic films and film transfer; Machines for the vacuum forming and pneumatic forming of plastic films for packaging with film transfer, in particular for manufacturing transparent packaging; Machines for the vacuum-pneumatic forming of plastic films and laminating of plastic films and for manufacturing composite bodies of plastic-coated preformed carriers; Moulds and machine tools for the aforesaid machines; Automatic machines for feeding plastic films and carriers into the aforesaid machines; Automatic machines (machines) for transferring and removing parts manufactured in the aforesaid machines; Mechanical apparatus for removing waste parts during the manufacture of articles in the aforesaid machines; Conveying apparatus; Racks for the aforesaid machines and Parts for the aforesaid goods, The aforesaid goods included in class 7; Installations mainly constructed from the aforesaid machines, automatic machines and apparatus, for manufacturing thermoformed parts,; Automatic machines for inserting films into the aforesaid machines.

Goods & Services

Maschinen und Apparate zur Aufnahme, Übergabe und Weiterleitung von warmgeformten Formteilen aus Kunststoffplatten oder Kunststofffolien; Übergabestationen für Formteile; Übergabestationen mit Veränderung des Abstands von Formteilstapeln während der Übergabe; Teile und Zubehör für die oben genannten Maschinen, insbesondere Antriebe, Steuerungseinheiten, Verstellantriebe, Führungen, Kulissenführungen; Maschinen zur Vakuum- und Druckluftformung von Kunststofffolien mit einer Übergabestation; Maschinen zur Vakuum- und Druckluftformung von Kunststofffolien zu Verpackungszwecken mit einer Übergabestation, insbesondere zur Herstellung von Sichtverpackungen; Maschinen zur Vakuum-Druckluftformung von Kunststofffolien und Laminieren der Kunststofffolien sowie zur Herstellung von Verbundkörpern aus mit Kunststoff beschichteten vorgeformten Trägerkörpern; Formen und Maschinenwerkzeuge für die vorgenannten Maschinen; Automaten (Maschinen) zum Zuführen von Kunststofffolien und Trägerkörpern zu den vorgenannten Maschinen; Automaten (Maschinen) zum Überführen und Abführen der in vorgenannten Maschinen hergestellten Teile; Förderapparate; Gestelle für Maschinen sowie Teile der vorgenannten Waren (soweit in Klasse 7 enthalten); Anlagen zur Herstellung von thermogeformten Teilen, die im Wesentlichen aus vorgenannten Maschinen, Automaten und Geräten zusammengesetzt sind.

Goods & Services

Machines and apparatus for transferring, processing, and handling films, in particular plastic films; film transfer machines; film processing machines; film conveying systems; roller and belt conveyors for films; automated transfer and further processing machines for films; parts and accessories for the aforementioned machines, in particular conveyor belts, rollers, drives, control units, needle chains, adjustment drives, guides; machines for vacuum and compressed air forming of plastic films with film transfer; machines for vacuum and compressed air forming of plastic films for packaging purposes with film transfer, in particular for the production of transparent packaging; machines for vacuum and compressed air forming of plastic films and laminating the plastic films, as well as for the production of composite bodies from preformed carrier bodies coated with plastic; molds and machine tools for the aforementioned machines; Automatic machines for feeding plastic films and carriers to the aforementioned machines; automatic machines for transferring and discharging parts produced in the aforementioned machines; mechanical devices for removing waste parts during the production of articles on the aforementioned machines; conveying apparatus; frames for machines and parts of the aforementioned goods (as far as included in Class 7); plants for the production of thermoformed parts, which are essentially composed of the aforementioned machines, automatic machines and devices; automatic machines for feeding the aforementioned machines with films.

Goods & Services

Machines and apparatus for receiving, transferring, and conveying thermoformed parts made from plastic sheets or films; transfer stations for molded parts; transfer stations with adjustable spacing of stacks of molded parts during transfer; parts and accessories for the aforementioned machines, in particular drives, control units, adjustment drives, guides, and cam guides; machines for vacuum and compressed air forming of plastic films with a transfer station; machines for vacuum and compressed air forming of plastic films for packaging purposes with a transfer station, in particular for the production of blister packaging; machines for vacuum and compressed air forming of plastic films and laminating the plastic films, as well as for producing composite bodies from preformed carriers coated with plastic; molds and machine tools for the aforementioned machines; automatic feeders (machines) for feeding plastic films and carriers to the aforementioned machines; automatic feeders (machines) for transferring and removing the parts produced in the aforementioned machines; conveying equipment; Frames for machines and parts of the aforementioned goods (as far as included in Class 7); plants for the production of thermoformed parts, which are essentially composed of the aforementioned machines, automatic machines and devices

Abstract

A surface portion made of fibrous material for processing into a three-dimensional molded part by a forming process, a method for producing a surface portion made of fibrous material for processing into a three-dimensional molded part by a forming process, and a method for producing three-dimensional molded parts from a surface portion made of fibrous material are described. The degree of forming of surface portions can be significantly increased by means of a defined separation of the fibrous material before the forming.

IPC Classes  ?

• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

A three-dimensional molded body of fiber-containing material and a method for producing a three-dimensional molded body of fiber-containing material are described. The molded body has a circumferential side wall that surrounds an interior of the molded body. The side wall has a degressive profile at least in portions, between an edge region and a base region, where the cross section of the side wall in the base region is smaller than the cross section in the edge region.

IPC Classes  ?

• D21J 3/10 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds of hollow bodies

Abstract

A three-dimensional molded part made of fiber-containing material and a molding tool for producing molded parts made of fiber-containing material are described. The molded part is produced in a production process under pressure and thermal influence. A surface of the molded part has at least one elevation formed by fiber-containing material that, during the production of the molded part, has been suctioned into a corresponding opening in a molding surface of a molding tool when steam, which escapes from the fiber-containing material during pressing, is removed. The at least one elevation is arranged in a first surface portion that has a different configuration than an adjacent at least one second surface portion. The at least one elevation is integrated into the configuration of the first surface portion.

IPC Classes  ?

• D21J 3/10 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds of hollow bodies

Abstract

A three-dimensional molded part made of fiber-containing material and a molding tool for producing molded parts made of fiber-containing material are described. The molded part is produced from fiber-containing material in a production process under pressure and thermal action. A surface of the molded part has elevations formed by fiber-containing material that has been sucked into corresponding openings in a molding surface of a molding tool during the production of the molded part when steam emerging from the fiber-containing material during pressing is removed. The elevations form at least one pattern along a surface of the molded part.

IPC Classes  ?

• D21J 5/00 - Manufacture of hollow articles by transferring sheets, produced from fibres suspensions or papier-mâché by suction on wire-net moulds, to couch moulds

Abstract

A three-dimensional molded body of fiber-containing material and a method for producing a three-dimensional molded body of fiber-containing material are described. The molded body has a circumferential side wall, which surrounds an interior of the molded body, and an edge region. A stacking shoulder is formed in a transition from the side wall to the edge region, and the edge region has an undercut.

IPC Classes  ?

• D21J 3/10 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds of hollow bodies

Abstract

A three-dimensional molded part made of fiber-containing material and a molding tool for producing molded parts made of fiber-containing material are described. The three-dimensional molded part is produced in a manufacturing process under pressure and thermal influence. A surface of the molded part has at least one design element and/or functional element that is formed by at least one region with reduced material thickness. The material thickness of the at least one region decreases with an increasing molded part height in a molding direction.

IPC Classes  ?

• B31B 50/88 - PrintingEmbossing
• B31B 50/59 - Shaping sheet material under pressure

Abstract

A method for producing a breakable weak point in molded bodies made of fiber-containing material is described. Further, a tool for producing a breakable weak point in molded bodies made of fiber-containing material is described. A molded body made of fiber-containing material is also described. The molded body has at least one surface portion that has at least one region with a breakable weak point.

IPC Classes  ?

• D21J 1/02 - Cutting, e.g. using wet saws
• D21J 1/04 - Pressing
• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

A tool for processing fiber-containing material for the manufacture of three-dimensional products is described. The tool has a mold body with a three-dimensional surface that substantially reflects the shape of a product to be molded. The mold body has a peripheral edge section, further having a spray arrangement via which a medium for aligning fibers in the edge section of the mold body and/or for aligning fibers in an edge section of an opposing tool with a further mold body can be dispensed. Further, a molding plant for manufacturing fiber-containing products is described. And yet further, a method for the manufacture of fiber-containing products is described.

IPC Classes  ?

• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

A molding tool for laminating three-dimensional molded parts made of a fiber-containing material, where at least one moldable laminate is applied to a surface of a molded part is described. A method for laminating three-dimensional molded parts made of a fiber-containing material are also described.

IPC Classes  ?

• B31B 50/59 - Shaping sheet material under pressure
• B31B 105/00 - Rigid or semi-rigid containers made by assembling separate sheets, blanks or webs

Goods & Services

Behälter zur Verabreichung von Arzneimitteln; Flaschen für die intravenöse Ernährung; Beutel zum Sammeln von Körperflüssigkeiten; Intravenöse Beutel für medizinische Zwecke; medizinische Behälter für histologische Zwecke. Behälter sowie Verschlüsse und Halter hierfür, nicht aus Metall; Deckel und Verschlüsse für Flaschen, nicht aus Metall; nichtmetallische Verschlüsse für Flaschen; Verschlusskappen, nicht aus Metall, für Flaschen; Schraubkappen, nicht aus Metall; Schraubdeckel, nicht aus Metall; Schraubverschlüsse, nicht aus Metall, für Flaschen; Schraubverschlüsse, nicht aus Metall, für Behälter; Kunststoffbehälter [ausgenommen Mülltonnen]; thermogeformte Kunststoffbehälter [ausgenommen für Haushalt oder Küche]; Dosen [Behälter nicht aus Metall]; Behälterverschlüsse aus Kunststoff; flexible Behälter aus Kunststoff zum Transport von Flüssigkeiten; flexible Behälter aus Kunststoff zur Lagerung von Flüssigkeiten; Kunststoffschalen für die Verpackung von Lebensmittel [Behälter]; Kunststoff-Aufbewahrungsbeutel, nicht für Verpackungszwecke; thermogeformte Verschlüsse; thermogeformte Verschlüsse aus Kunststoff. Behälter für den Haushalt; Behälter für Getränke [Haushalt und Küche]; Kunststoffbeutel für den Haushalt; Flaschen aus Kunststoff; Flaschen für Pharmazeutika ohne Inhalt; thermogeformte Kunststoffbehälter für Haushalt oder Küche.

Abstract

A threaded cap element and a method of manufacturing a cap element are disclosed. The threaded cap element may be formed in a thermoforming process. The threaded cap element may include a threaded portion with a thread, a flange portion, and a central lid portion that is opposite a cap element open region via which the threaded cap element is applied to a container to close off the container. The central lid portion may have a concavity in a direction of the open region.

IPC Classes  ?

• B65D 43/02 - Removable lids or covers

Abstract

A method for forming products from fibrous material and a forming device for forming products from a fibrous material are described, where a multi-stage pressing of preforms made of fibrous material is carried out in order to improve the properties of products manufactured therefrom and to have a significant influence on the production time.

IPC Classes  ?

• D21J 1/04 - Pressing
• D21J 1/16 - Special fibreboard

Abstract

A molding tool is described for manufacturing a lid made of a fiber-containing material, a lid, and a molded part made of a fiber-containing material, wherein the design of the lid and of the molded part provides protection against leakage of liquids, etc., in a simple manner.

IPC Classes  ?

• B65D 43/02 - Removable lids or covers
• B65D 65/46 - Applications of disintegrable, dissolvable or edible materials
• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

A device for supplying a gas stream to a tool for molding molded parts made of a fiber-containing material. Steam generated during molding is removed from the molded parts pressed in the tool via channels in the tool. A tool with such a device and a method for controlling the supply of a gas stream into the tool are described.

IPC Classes  ?

• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

A mold body for a pre-pressing tool for pressing three-dimensional preforms made of a fiber-containing material, and a pre-pressing station with a pre-pressing tool with at least one mold body, are described, wherein the mold body includes a deformable material and has a shell which substantially images the geometry of a preform to be pressed, wherein the mold body has at least one support structure made of deformable material which is formed integrally with the shell.

IPC Classes  ?

• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

The present disclosure relates to a process for the pretreatment of fibrous material in a production process for producing three-dimensional products, to a pretreatment chamber for the pretreatment of fibrous material, and to a fiber molding plant having at least one pretreatment chamber. By pretreating relatively dry fiber material, the shaping step in a manufacturing process can be significantly improved and the choice of product geometries can be increased.

IPC Classes  ?

• D21G 7/00 - Damping devices
• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

A method for manufacturing three-dimensional products with at least one inclined product portion made of a fiber-containing material using at least one forming tool and a forming tool are described. Vibrations are introduced via a device and this results in an improved compression of fiber-containing material in the region of inclined portions.

IPC Classes  ?

• B30B 11/02 - Presses specially adapted for forming shaped articles from material in particulate or plastic state, e.g. briquetting presses or tabletting presses using a ram exerting pressure on the material in a moulding space
• B31D 5/02 - Multiple-step processes for making three-dimensional articles including pressing

Abstract

A method for processing planar material webs made of a fiber-containing material is disclosed. The planar material webs are fed as material web portions or endless material web, for the production of three-dimensional products. Before a material web is pressed for shaping, the material web is preformed three-dimensionally by deforming the material web in at least one direction substantially without stretching or compressing.

IPC Classes  ?

• B31F 1/00 - Mechanical deformation without removing material, e.g. in combination with laminating

Abstract

An apparatus and a method for heating process media in a fiber molding process are described, whereby an optimization of the efficiency in the production of three-dimensional molded parts from a fiber-containing material is provided. Here, a process medium with a relatively high temperature is guided through an apparatus for heat exchange within a container with another process medium.

IPC Classes  ?

• F28D 7/10 - Heat-exchange apparatus having stationary tubular conduit assemblies for both heat-exchange media, the media being in contact with different sides of a conduit wall the conduits being arranged one within the other, e.g. concentrically
• B29C 43/52 - Heating or cooling
• F28D 21/00 - Heat-exchange apparatus not covered by any of the groups
• F28F 1/06 - Tubular elements of cross-section which is non-circular crimped or corrugated in cross-section

Abstract

A method for suctioning fibers from a pulp using a suction device with a suction tool, and a suction device for suctioning fibers from a pulp with a suction tool that has a plurality of cavities for suctioning fibers are described.

IPC Classes  ?

• D21F 1/48 - Suction apparatus

Abstract

A method for temperature control in a molding tool is described. The molding tool has a tool base body and at least one cavity. The method includes producing molded parts from a fiber-containing material where a temperature of the molding tool is controlled in operation between a standby temperature and a maximum production temperature of a production temperature range. The standby temperature is lower than a minimum production temperature. The molding tool is kept at a base state by heat input where a molding process is brought from the base state into a production temperature range by an additional heat input. The production temperature range lies between the minimum production temperature and the maximum production temperature. A molding process is started after reaching the minimum process temperature in the molding tool and the additional heat input into the molding tool is maintained only during the molding process.

IPC Classes  ?

• B29C 43/58 - Measuring, controlling or regulating
• B29C 43/00 - Compression moulding, i.e. applying external pressure to flow the moulding materialApparatus therefor
• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds
• B29K 1/00 - Use of cellulose, modified cellulose or cellulose derivatives, e.g. viscose, as moulding material
• B29L 31/00 - Other particular articles
• D21J 1/00 - Fibreboard

Abstract

The invention relates to a portioning container (1) made of biodegradable fiber material (11), to a molded fiber system (100), and to a method (200) for manufacturing such portioning containers (1), comprising a receptacle (2) for holding a consumable (G, G′) and a cover (6) for closing the receptacle to produce a sealed volume (V) within the portioning container (1), wherein at least the receptacle (2), preferably also the cover (6), is manufactured from biodegradable fiber material (11) using a molded fiber system (100) by means of a molded fiber process, from a pulp (7, 7a, 7b) as a liquid solution containing the biodegradable fiber material (11), wherein at least the receptacle (2), preferably also the cover (6), is provided with a barrier layer system (8) which has a barrier effect at least against penetration of moisture, water, aromatic substances, flavoring agents, odorants, and/or non-food-grade substances.

IPC Classes  ?

• B65D 85/804 - Disposable containers or packages with contents which are infused or dissolved in situ
• B65D 65/42 - Applications of coated or impregnated materials
• B65D 65/46 - Applications of disintegrable, dissolvable or edible materials

Abstract

The invention relates to a method (100) for manufacturing molded parts (10) from biodegradable fiber material (11) by means of a fiber molding process in a fiber molding system (20), comprising the following steps of providing (110) a pulp (1) as a liquid solution containing a biodegradable fiber material; contacting (120) a suction tool (2) with the pulp by placing it on or at least partially dipping it into the pulp, wherein the suction tool comprises a suction head (21) with a three-dimensionally shaped suction head suction side (21i), whose shape is adapted to a contour of the subsequent molded part; molding (130) the molded part by sucking the fiber material onto the suction head suction side (21i) by means of negative pressure in the suction tool; pre-pressing (140) the molded part in a pre-pressing station (3) with a pre-pressing pressure (VD) to reduce a proportion of the liquid solution in the molded part; hot-pressing (150) the pre-pressed molding at a hot-pressing pressure (HD) for finishing the molded part and for further reducing the proportion of the liquid solution in the molded part in a hot-pressing station (4); and outputting (160) the finished molded part (10). The invention also relates to such a fiber molding system for carrying out the above-mentioned method and to a molded part manufactured by means of such a fiber molding system or by means of such a method.

IPC Classes  ?

• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds
• D21J 5/00 - Manufacture of hollow articles by transferring sheets, produced from fibres suspensions or papier-mâché by suction on wire-net moulds, to couch moulds

Abstract

The invention relates to a fiber-forming system (100) comprising at least a molding station (20) according to the invention, a preforming station (30) according to the invention and a hot-pressing station (40) according to the invention for producing a formed part (10) from environmentally-friendly-degradable fiber material (11) by means of a fiber-forming process executed in the fiber-forming system (100), wherein the fiber-forming system (100) is designed to enable an automatic change of tools (2, 3, 400, 40u) from the molding station (20), preforming station (30) and or hot-pressing station (40). The invention also relates to such a molding station (20), preforming station (30) and hot-pressing station (40) and a corresponding method (200) for automatically changing tools in the fiber-forming system (100).

IPC Classes  ?

• D21J 5/00 - Manufacture of hollow articles by transferring sheets, produced from fibres suspensions or papier-mâché by suction on wire-net moulds, to couch moulds
• B23Q 3/155 - Arrangements for automatic insertion or removal of tools

Abstract

Described are a product and a process (300) for producing products made of a biodegradable material having at least one first ply (200) comprising at least one outer layer (250) and one functional layer (260), wherein at least the outer layer (250) consists of a biodegradable material and wherein the outer layer (250) comprises fibre material, wherein the at least one first ply (200) comprises at least one first joining section (210), by means of which the at least one first ply (200) is connected to a corresponding second joining section (220) of the at least one first ply (200) or a second ply (200) and wherein the total layer thickness of the product in a joining region (160) between the first joining section (210) and the second joining section (220) is substantially identical to the total layer thickness of the at least one first ply (200) in a region remote from the joining region (160).

IPC Classes  ?

• B32B 3/06 - Layered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by features of form at particular places, e.g. in edge regions for securing layers togetherLayered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by features of form at particular places, e.g. in edge regions for attaching the product to another member, e.g. to a support
• B65D 1/02 - Bottles or similar containers with necks or like restricted apertures, designed for pouring contents
• B65D 65/46 - Applications of disintegrable, dissolvable or edible materials
• B32B 3/26 - Layered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a particular shape of the outline of the cross-section of a continuous layerLayered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a layer with cavities or internal voids
• B32B 3/30 - Layered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a particular shape of the outline of the cross-section of a continuous layerLayered products comprising a layer with external or internal discontinuities or unevennesses, or a layer of non-planar shapeLayered products comprising a layer having particular features of form characterised by a layer with cavities or internal voids characterised by a layer formed with recesses or projections, e.g. grooved, ribbed

Abstract

A molding tool and a method for producing molded parts from a moldable material with at least one first tool component and at least one second tool component are described. The first tool component has a cavity with a first molding surface and the second tool component has a molding element with a second molding surface, which has an at least partially flexible material. Moldable material introduced into the cavity is pressed against the first molding surface at least in certain regions by the deformation of the flexible material. A medium is introduced via the molding element for this purpose, which leads to deformation of the flexible material.

IPC Classes  ?

• B29C 43/44 - Compression means for making articles of indefinite length
• B29C 43/32 - Component parts, details or accessoriesAuxiliary operations

Abstract

A molding tool and a method for producing molded parts from a moldable material with a first tool component and a second tool component are described. The first tool component has a cavity with a first molding surface and the second tool component has a second molding surface and a flexible material forming at least one portion of the second molding surface. In a first step, a moldable material is introduced into the cavity and then the second tool component is moved into the cavity. A second molding surface of the second tool component moves the moldable material in regions against the first molding surface. Thereafter, overpressing of the second tool component takes place after reaching a bottom dead center within the cavity, whereby the flexible material is deformed and presses the moldable material against a corresponding portion of the first molding surface.

IPC Classes  ?

• B29C 51/08 - Deep-drawing or matched-mould forming, i.e. using mechanical means only
• B29C 51/34 - Moulds for undercut articles

Abstract

The invention relates to a device and a method for manufacturing medical bags.

IPC Classes  ?

• B29C 65/18 - Joining of preformed partsApparatus therefor by heating, with or without pressure using heated tool
• B29C 65/30 - Electrical means

Abstract

The invention relates to a system and a method for the combined connection of at least two plastics material layers and of at least one connecting element to the at least two layers in order to manufacture medical bags.

IPC Classes  ?

• B29C 65/18 - Joining of preformed partsApparatus therefor by heating, with or without pressure using heated tool
• B29C 65/30 - Electrical means
• B29C 65/32 - Induction

Abstract

The present disclosure relates to a molding station a mold body for a pre-pressing tool that is utilized for pressing three-dimensional preforms made of a fiber-containing material. The mold body includes a deformable material and is perforated in some portions.

IPC Classes  ?

• D21F 13/00 - Methods or apparatus for making discontinuous sheets of paper, pulpboard, or cardboard, or of wet web, for fibreboard production
• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

The present disclosure relates to a molding station a mold body for a pre-pressing tool that is utilized for pressing three-dimensional preforms made of a fiber-containing material. The mold body includes a deformable material and is perforated in some portions. In certain instances, the mold body has, with respect to a wall section and a floor section, a greater material thickness in a connection section for the pre-pressing tool. In some instances, the mold body has an integrated connection unit in the connection section for the pre-pressing tool.

IPC Classes  ?

• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds
• D21F 13/00 - Methods or apparatus for making discontinuous sheets of paper, pulpboard, or cardboard, or of wet web, for fibreboard production

Abstract

The present disclosure relates to a molding station a mold body for a pre-pressing tool that is utilized for pressing three-dimensional preforms made of a fiber-containing material. The mold body includes a deformable material and is perforated in some portions. In certain instances, the mold body has, with respect to a wall section and a floor section, a greater material thickness in a connection section for the pre-pressing tool.

IPC Classes  ?

• D21J 7/00 - Manufacture of hollow articles from fibre suspensions or papier-mâché by deposition of fibres in or on a wire-net mould
• B30B 15/06 - Platens or press rams

Abstract

A fiber molding system for manufacturing molded parts made from environmentally friendly, degradable fiber material using a fiber molding process is disclosed. The system includes at least one first pulp reservoir; a suction tool attached to a movement unit, which as a multi-tool comprises a plurality of suction heads, each with a three-dimensionally shaped suction head suction side adapted to a contour of the molded part to be molded, and which is designed to use at least a first partially immersing of the suction tool into the first pulp and sucking the fiber material onto the respective suction head suction sides of the suction heads using negative pressure from the first pulp to form the molded part in the suction heads; an output unit for outputting the final molded part, and a control unit adapted to carry out the method on the fiber molding system.

IPC Classes  ?

• D21J 5/00 - Manufacture of hollow articles by transferring sheets, produced from fibres suspensions or papier-mâché by suction on wire-net moulds, to couch moulds
• D21F 13/00 - Methods or apparatus for making discontinuous sheets of paper, pulpboard, or cardboard, or of wet web, for fibreboard production
• D21J 1/08 - Impregnated or coated fibreboard

Abstract

A method for producing three-dimensional molded parts from a fiber-containing material and a fiber processing device are described. In this case, a provision of separated fibers, an arrangement of the separated fibers to form at least one preform, wherein the at least one preform substantially corresponds to the shape of a molded part to be produced, and a pressing of the at least one preform to form a three-dimensional molded part take place. The fiber processing device at least has a feeding device for providing separated fibers; a premolding device, which has at least one premold for forming preforms from fibers fed separately, which corresponds to the final form of the molded part to be produced; a transfer device for transferring preforms provided via the at least one premold and made of fiber-containing material; and a molding device for pressing preformed preforms to form finished three-dimensional molded parts.

IPC Classes  ?

• B27N 5/02 - Hollow articles
• B27N 1/00 - Pretreatment of moulding material

Abstract

The present disclosure relates to a cleaning system. The cleaning system may include a support and holding structure for the cleaning unit of at least one molding tool where the at least one molding tool includes at least one interior through which a flow can pass and at least one mold part having a plurality of openings. At least one inlet connection for a (cleaning) inlet line may be provided on the at least one molding tool, via which inlet connection a cleaning fluid can be introduced into at least one interior of the molding tool and can be discharged via the plurality of openings of the mold parts. A closure frame and a closure element may be provided where the closure frame is arranged between the at least one molding tool and the closure element to form a drain space.

IPC Classes  ?

• B29C 33/72 - Cleaning
• B08B 3/12 - Cleaning involving contact with liquid with additional treatment of the liquid or of the object being cleaned, e.g. by heat, by electricity or by vibration by sonic or ultrasonic vibrations
• B08B 3/14 - Removing waste, e.g. labels, from cleaning liquid

Abstract

A molding tool for producing three-dimensional products from a fiber-containing material and a method for regulating a temperature distribution in a molding tool for producing three-dimensional products are described.

IPC Classes  ?

• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

The present disclosure relates to a weighing system for a manufacturing device for products, comprising at least one electronically evaluable scale, comprising at least one carrier element for positioning at least one workpiece or stack of workpieces, in particular a group of horizontally adjacent workpieces and/or stacks of workpieces, and an evaluation unit connected to the scale for receiving and evaluating detected weighing data, the scale being operable in cooperation with the evaluation unit to detect the total weight and the horizontal weight distribution of at least one workpiece or stack of workpieces deposited on the carrier element. Further, the present disclosure includes a manufacturing system and an associated method.

IPC Classes  ?

• G01G 11/00 - Apparatus for weighing a continuous stream of material during flowConveyor-belt weighers

Abstract

A fiber processing device and a method for operating a fiber processing device are described, wherein the fiber processing device has at least one forming station with an exchangeable tool and an alignment unit which has a plurality of outlet openings for a medium, wherein a medium for displacing and positioning fibers on the surface of a tool is dispensed via the outlet openings in determinable time periods, wherein different tools can be received in the forming station in order to produce different three-dimensional molded parts, wherein a tool received in the forming station is exchanged for another tool, and the outlet openings of at least one alignment unit are changed in accordance with the received tool and its configuration.

IPC Classes  ?

• D21J 3/10 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds of hollow bodies
• D21J 7/00 - Manufacture of hollow articles from fibre suspensions or papier-mâché by deposition of fibres in or on a wire-net mould

Abstract

The invention relates to a fibre processing apparatus for use in a fibre processing system (100), to a fibre processing system (100) having at least two fibre processing apparatuses and to a method for controlling a fibre processing system (100), wherein the fibre processing apparatuses each have at least one processing station for treating a fibre-containing material, a control apparatus and at least one interface, which are designed and configured for bi-directional communication between the at least two fibre processing apparatuses such that at least one processing station of the at least two fibre processing apparatuses for treating a fibre-containing material is controlled in accordance with specific information which is exchanged via the interfaces of the at least two fibre processing apparatuses, wherein the specific information comprises information regarding the particular fibre processing apparatus performing processing, and further information on this fibre processing apparatus related to the production of products.

IPC Classes  ?

• G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]

Abstract

The invention relates to a molding device (600) for molding products (3004) from a fiber-containing material, to a fiber molding system (1000) comprising at least one molding device (600) for molding products (3004) from a fiber-containing material, to a method (2000) for molding products (3004) from a fiber-containing material, and to a product (3004) made of a fiber-containing material. A warm-pressing process is first carried out and then a hot-pressing process is carried out, wherein the temperature during the warm-pressing process is lower than the temperature during the hot-pressing process, and after the warm-pressing process, a preform is sufficiently flexible for a forming process when the hot-press tool is closed.

IPC Classes  ?

• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds
• D21J 7/00 - Manufacture of hollow articles from fibre suspensions or papier-mâché by deposition of fibres in or on a wire-net mould

Abstract

A method for regulating a hot-pressing device, a tool component and a hot-pressing device are described, wherein the closing of the hot-pressing device and the pressing of a first tool component and a second tool component are effected according to a boiling temperature, ascertained in advance, of the liquid contained in a fiber-containing material of at least one preform and a surface temperature of a first molding device of the first tool component.

IPC Classes  ?

• B29C 43/58 - Measuring, controlling or regulating
• B29C 43/52 - Heating or cooling
• B29C 43/00 - Compression moulding, i.e. applying external pressure to flow the moulding materialApparatus therefor

Abstract

A tool component, a hot-pressing device and a method for hot pressing preforms from a fiber-containing material are described, wherein the hot-pressing device has a first tool component with a first tool body and at least one first molding device and a second tool component with a second tool body and at least one second molding device. The method includes providing at least one preform made of fiber-containing material, heating the first tool body and the first molding device via a temperature control device, placing a preform on first contact surfaces of the first molding device, moving the second tool component relative to the first tool component, and pressing the first tool component and the second tool component until the first contact surfaces and the second contact surfaces form a closed cavity.

IPC Classes  ?

• D21F 13/10 - Methods or apparatus for making discontinuous sheets of paper, pulpboard, or cardboard, or of wet web, for fibreboard production using board presses
• B30B 9/28 - Presses specially adapted for particular purposes for forming shaped articles
• B30B 15/02 - DiesInserts therefor or mountings thereofMoulds
• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

The present disclosure relates to a molding station (20) for molding (210), a preforming station (30) for preforming (220), a hot-pressing station (40) for final shaping (230) a formed part (10) made of environmentally-friendly-degradable fiber material (11) in a fiber-forming process in a fiber-forming system (100). The fiber-forming system (100) produces the formed part (10) having the above components (20, 30, 40) by means of the method (200) performed in the fiber-forming system (100) as a fiber-forming process.

IPC Classes  ?

• D21J 5/00 - Manufacture of hollow articles by transferring sheets, produced from fibres suspensions or papier-mâché by suction on wire-net moulds, to couch moulds
• D21J 1/04 - Pressing

Abstract

The invention relates to a production machine with a control program for visualizing stations and/or machine components, highlighting the speed-determining station and/or the speed-determining machine component in order to optimize the process time. The invention also relates to a method of optimizing the process time for a production machine with such a control program and to a data carrier with such a control program.

IPC Classes  ?

• G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]

Abstract

The disclosed embodiments relate to a manufacturing component as a first tool in a forming station at least for endforming a preformed lid made from a material to form an undercut comprising natural fibres. The preformed lid includes a top part and a side part circumferencing the top part, where the manufacturing component is adapted to contact an outer side of the preformed lid to endform the preformed lid by exerting a first movement in axial direction along a center axis of the manufacturing component and a later second movement in a second direction towards the side part of the preformed lid. Multiple side forming elements of the manufacturing component are arranged to exert the second movement by applying an outer pressure onto an outer side of the side part to form an undercut into the side part.

IPC Classes  ?

• D21J 5/00 - Manufacture of hollow articles by transferring sheets, produced from fibres suspensions or papier-mâché by suction on wire-net moulds, to couch moulds
• B65D 43/06 - Removable lids or covers having a peripheral channel embracing the rim of the container

Abstract

The present disclosure relates to a system for pulp processing and resupply of production-quality pulp to at least one fiber molding system, where the system is constructed in scalable modular form. For this, the system includes at least one supply module (110) and one or more process modules (120). The supply module (110) and the process modules (120) are equipped with a plurality of interfaces (150), matched to one another in each case, in order to connect supply and process modules (110, 120) to one another. This may guarantee the infrastructure supply of the process modules (120). The pulp or the constituents and starting materials may be received via at least one inlet (130) and transported between the process modules (120) to provide the production-quality pulp (160) via an outlet (140) for use by at least one fiber molding system.

IPC Classes  ?

• D21G 9/00 - Other accessories for paper-making machines

Abstract

The invention relates to an HMI system with a mobile operating and monitoring device for operating a production machine for plastics processing. The HMI system is installed on a control unit of the production machine and has a mobile operating and monitoring device.

IPC Classes  ?

• G05B 19/409 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by using manual data input [MDI] or by using control panel, e.g. controlling functions with the panelNumerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by control panel details or by setting parameters
• G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]

Abstract

The invention discloses a molded fiber product comprising at least a first base layer and a second top barrier layer.

IPC Classes  ?

• D21J 7/00 - Manufacture of hollow articles from fibre suspensions or papier-mâché by deposition of fibres in or on a wire-net mould
• D21J 3/10 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds of hollow bodies

Abstract

c) for each of which the process parameter defining the process for this motion section is visualized and can be varied by means of the provided switch panels.

IPC Classes  ?

• G05B 19/41 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by interpolation, e.g. the computation of intermediate points between programmed end points to define the path to be followed and the rate of travel along that path
• B29C 51/46 - Measuring, controlling or regulating
• G05B 19/40 - Open loop systems, e.g. using stepping motor
• G05B 19/409 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by using manual data input [MDI] or by using control panel, e.g. controlling functions with the panelNumerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by control panel details or by setting parameters
• G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]
• B29C 37/00 - Component parts, details, accessories or auxiliary operations, not covered by group or

Abstract

The invention relates to: a heating roller (1) for providing a desired surface temperature for controlling the temperature of a material web (20) circulating around the heating roller; a preheating oven (10) having such a heating roller; a system (100) having such a preheating oven; and a method (200) for producing such a heating roller; which heating roller comprises a circular cylindrical lateral casing (2) made of thermally conductive material, preferably metal, and at least one electrical heating blanket (3) which is situated on an inner face (21) of the lateral casing so as to be in contact with the lateral casing; wherein a thermal insulation layer (4) is situated on an inner face (31) of the heating blanket, which inner face does not face the lateral casing, and a spreading device (5) is situated inside the lateral casing on an inner face (41) of the thermal insulation layer, which spreading device exerts a pre-loading force on the heating blanket via the thermal insulation layer such that an outer face (32) of the at least one heating blanket, which outer face faces the lateral casing, is permanently pressed against the inner face of the lateral casing.

IPC Classes  ?

• B29B 13/02 - Conditioning or physical treatment of the material to be shaped by heating
• B29C 51/00 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor

Abstract

The invention relates to a manufacturing component (1) as a first tool in a forming station (10) at least for endforming a preformed lid (100) made from a material (M) to form an undercut (140) comprising natural fibres, the preformed lid (100) comprising a top part (130) and a side part (110) circumferencing the top part (130), where the manufacturing component (1) is adapted to contact an outer side (110) of the preformed lid (100) to endform the preformed lid (100) by exerting a first movement (FM) in axial direction along a center axis (R) of the manufacturing component (1) and a later second movement (SM) in a second direction towards the side part (120) of the preformed lid (100), where multiple side forming elements (2) of the manufacturing component (1) are arranged to exert the second movement (SM) applying an outer pressure (PA) onto an outer side (110) of the side part (120) to form an undercut (140) into the side part (120). The invention further relates to a forming station (10) with such a manufacturing component (1), a forming device (80) comprising such forming station (10), an endformed lid (100´) manufactured with such forming station (10) comprising an undercut (140) and a methode (200) to manufacture such lid (100´) with undercut (140).

IPC Classes  ?

• D21J 5/00 - Manufacture of hollow articles by transferring sheets, produced from fibres suspensions or papier-mâché by suction on wire-net moulds, to couch moulds
• B65D 43/02 - Removable lids or covers

Abstract

The invention relates to a method (100) for measuring a permittivity (1) of a material of a sample body (2) for receiving a plurality of measurement points (10, 20, 30, 40) at at least one measurement voltage (12), to a device (300) for performing the method (100), and to an adapter circuit (200), in which the measured material of the sample body (2) is used, the method (100) being performed with the aid of a capacitor assembly (3) comprising at least one capacitor (4) with electrodes (9) with variable electrode spacing (11, 21, 31, 41) and/or a plurality of capacitors (4) with electrodes each with different electrode spacings (11, 21, 31, 41) that are kept constant during the method, a space between the sample body (2) and the electrodes (9) of the capacitor(s) (4) being filled in the respective method steps with the first filling medium (5) having a first permittivity (7) or with a second filling medium (6) having a second permittivity (8) different from the first permittivity (7), and also an extrapolation (50, 60) of the measured values (10, 20, 30, 40) performed at a distance towards zero of the electrode spacing.

IPC Classes  ?

• G01N 27/22 - Investigating or analysing materials by the use of electric, electrochemical, or magnetic means by investigating impedance by investigating capacitance
• G01R 27/26 - Measuring inductance or capacitanceMeasuring quality factor, e.g. by using the resonance methodMeasuring loss factorMeasuring dielectric constants

Abstract

The invention relates to a method (100) for controlling a variable matching network (4) for impedance matching, to a matching network (4) for carrying out said method (100) according to the invention and to a system (1) comprising a signal source (2), a load (5), a directional coupler (3) and a claimed variable matching network (4), wherein the signal source (2) is connected to the load (5) via the directional coupler (3) and the variable matching network (4) for impedance matching.

IPC Classes  ?

• H03H 7/40 - Automatic matching of load impedance to source impedance
• H03H 5/12 - One-port networks comprising only passive electrical elements as network components with at least one voltage- or current-dependent element
• H03H 1/00 - Constructional details of impedance networks whose electrical mode of operation is not specified or applicable to more than one type of network
• H01J 37/32 - Gas-filled discharge tubes

Abstract

The invention relates to a variable capacitor system (1) for impedance matching, a matching network (4) comprising said type of variable capacitor system (1), a system (10) comprising said type of matching network (4) and to a use of the variable capacitor system (1) for impedance matching, formed by a parallel or series connection of a variable transducer (11) with a capacitor (12). The invention also relates to a method (100) for controlling said type of impedance matching network (4).

IPC Classes  ?

• H03H 5/12 - One-port networks comprising only passive electrical elements as network components with at least one voltage- or current-dependent element
• H03H 7/40 - Automatic matching of load impedance to source impedance
• H03H 1/00 - Constructional details of impedance networks whose electrical mode of operation is not specified or applicable to more than one type of network
• H01J 37/32 - Gas-filled discharge tubes

Abstract

The invention relates to a measuring apparatus (1) for contactless inline inspection of plastic films (2) with the use of trained algorithms, to a corresponding measuring method (100), and to a plastic-processing plant (10) that has such a measuring apparatus comprising: a measuring unit (3) which is designed to emit light (L) in the infrared spectral range, preferably between 1300nm and 2600nm, towards the plastic films and to measure measurement data in the form of optical measurement spectra (MS) in the reflection of the light by the plastic film or in the transmission of the light through the plastic film; and an evaluation unit (4) which is designed to determine at least one of the properties (M) of the plastic film on the basis of a classification of the measurement data by one or more algorithms (41) trained beforehand using optical training spectra (TS) under conditions similar to those for the measurement spectra with plastic films having known properties, the algorithm(s) calculating one or more mathematical transformation rules which transfer the training data characteristically for the known properties of the plastic film into a multi-dimensional results domain, and said algorithm(s) likewise calculating, during the inline inspection, the one or more mathematical transformation rules which transfer the measurement data into the multi-dimensional results domain, thereby determining the at least one property of the plastic film in correlation with the training data and the multi-dimensional results domain.

IPC Classes  ?

• G01N 21/35 - Investigating relative effect of material at wavelengths characteristic of specific elements or molecules, e.g. atomic absorption spectrometry using infrared light

Abstract

The invention relates to a portion container (1) made of biodegradable fiber material (11), a fiber molding system (100) and a method (200) for producing such portion containers (1) comprising a receptacle (2) for receiving a luxury product (G, G') and a cover (6) for sealing the receptacle in order to produce a sealed volume (V) within the portion container (1), wherein at least the receptacle (2), preferably also the cover (6), is produced from biodegradable fiber material (11) using a fiber molding system (100) by means of a fiber molding process from a pulp (7, 7a and 7b) as a liquid solution comprising the biodegradable fiber material (11), wherein at least the receptacle (2), preferably also the cover (6), has a barrier layer system (8) having a barrier effect at least against penetration by moisture, water, aromatic agents, flavoring agents, odorants and/or food-incompatible substances.

IPC Classes  ?

• B65D 85/804 - Disposable containers or packages with contents which are infused or dissolved in situ

Abstract

The invention relates to a method (100) for producing molded parts (10) from fiber material (11) by means of a fiber molding process in a fiber molding system (20), which fiber material is degradable in an environmentally friendly way, the method comprising the following steps: providing (110) a pulp (1) as a liquid solution having fiber material that is degradable in an environmentally friendly way; bringing (120) a suction tool (2) into contact with the pulp by placing the suction tool onto the pulp or at least partially dipping the suction tool into the pulp, the suction tool comprising a suction head (21) having a three-dimensionally shaped suction head suction side (21i), the shape of which is adapted to the contour of the later molded part; molding (130) the molded part onto the suction head suction side (21i) by suctioning the fiber material by means of negative pressure in the suction tool; pre-pressing (140) the molded-on molded part in a pre-pressing station (3) with a pre-pressing pressure (VD) in order to reduce the proportion of the liquid solution in the molded part; hot pressing (150) the pre-pressed molded part with a hot-pressing pressure (HD) in a hot-pressing station (4) in order to finally mold the molded part and to further reduce the proportion of the liquid solution in the molded part; and outputting (160) the molded part (10) that has been finally molded. The invention further relates to such a fiber molding system for carrying out the method above and to a molded part produced by means of such a fiber molding system or by means of such a method.

IPC Classes  ?

• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

The invention relates to a fibre-moulding facility (100) for producing moulded parts (10) made of fibre material, which is degradable in an environmentally friendly fashion, by means of a fibre-moulding process, the facility comprising at least one first pulp reservoir (6a, 6b) for providing at least one first pulp as a liquid solution with fibre material which is degradable in an environmentally friendly fashion; a suction tool (2), which is mounted on a movement unit (4), comprises a plurality of suction heads each having a three-dimensionally shaped suction-head suction side adapted to a contour of the moulded part (10) to be moulded, and designed to mould the moulded part (10) in the suction heads by means of an at least partial immersion of the suction tool (2) into the first pulp and suction from the first pulp of the fibre material onto the relevant suction-head suction sides of the suction heads by means of negative pressure; an output unit (50) for outputting the finished moulded part (10); and a control unit (60), which is designed to perform the method on the fibre-moulding facility (100). The fibre-moulding facility (100) is additionally designed to apply and/or to dispense a functional layer or a layer system consisting of a number of functional layers and/or a further layer made of fibre material onto a surface of the moulded part (10) to be coated.

IPC Classes  ?

• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

The invention relates to a fibre moulding plant (100) comprising at least one claimed moulding station (20), a claimed pre-moulding station (30) and a claimed hot pressing station (40) for producing a moulded part (10) from environmentally degradable fibre material (11) by means of a fibre moulding process carried out in the fibre moulding plant (100), wherein the fibre moulding plant (100) is designed to automatically change moulds (2, 3, 40o, 40u) from the moulding station (20), pre-moulding station (30) and/or hot pressing station (40). The invention also relates to said type of moulding station (20), preforming station (30) and hot pressing station (40) as well to as a corresponding method (200) for the automatic change of moulds in the fibre moulding plant (100).

IPC Classes  ?

• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

The invention relates to a moulding plant (20) for moulding (210), a premoulding station (30) for premoulding (220), a hot-pressing station (40) for final moulding (230) of a moulded part (10) of environmentally degradable fibre material (11) in a fibre moulding process in a fibre moulding plant (100). The invention also relates to said type of fibre moulding plant (100) for producing the moulded part (10) with the above-mentioned components (20, 30, 40) by means of the method (200) carried out in the fibre moulding plant (100) as the fibre moulding process.

IPC Classes  ?

• D21J 3/00 - Manufacture of articles by pressing wet fibre pulp, or papier-mâché, between moulds

Abstract

The invention relates to a thermoforming tool (1, 2) for thermoforming a film (5, 6) from a thermoplastic material to a molding part (6, 7), in particular a molding part (6, 7) of a refrigerator, comprising an upper tool part, a lower tool part (11) and a holding device (12, 13) for holding the film (5, 6) between the two tool parts (10), wherein the thermoforming tool (1, 2) is characterized by a measuring device (25A, 25, 26) for measuring at least one wall strength (26) on the thermoformed film (5).

IPC Classes  ?

• B29C 51/46 - Measuring, controlling or regulating
• B29C 51/08 - Deep-drawing or matched-mould forming, i.e. using mechanical means only
• B29L 31/00 - Other particular articles

Abstract

The invention relates to a production machine comprising a control programme for visualising stations and/or machine components with emphasis on the speed-determining station and/or the speed-determining machine component in order to optimise the process time. The invention also relates to a method for optimising the process time for a production machine comprising such a control programme and to a data carrier comprising such a control programme.

IPC Classes  ?

• G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]

Abstract

The invention relates to an HMI system comprising a mobile control and monitoring device for operating a production machine for plastics processing. The HMI system is mounted on a control unit of the production machine and comprises a mobile control and monitoring device.

IPC Classes  ?

• G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]

Abstract

The invention relates to a production machine (1) comprising a control programme (4) for visualising machine components (2) and a method (100) for optimising process parameters for the production machine comprising such a control programme, as well as a data carrier comprising such a control programme, wherein the control programme comprises an interactive user interface in the form of a visualisation device (5) and is designed to visualise the function performed by at least one of the machine components on the visualisation device in one representation for each of said machine components, and to provide corresponding control panels (51) for inputting process parameters with respect to the visualised machine component, wherein the representation comprises at least one parameter-time diagram (52) having motion curves (53) of components (21) of the machine component, wherein at least one of the motion curves is divided into different suitably visualised motion sections (53a, 53b, 53c), for each of which the process parameter that determines the process for said motion section is visualised, said process parameter being variable by means of the control panels provided.

IPC Classes  ?

• G05B 19/418 - Total factory control, i.e. centrally controlling a plurality of machines, e.g. direct or distributed numerical control [DNC], flexible manufacturing systems [FMS], integrated manufacturing systems [IMS] or computer integrated manufacturing [CIM]

Abstract

The invention relates to a radio-frequency planar transformer comprising a dielectric having high relative permittivity, said dielectric preferably being a barium aluminum titanate (BAT) glass ceramic material. The invention additionally relates to the use of a glass ceramic material having high relative permittivity as a dielectric in a radio-frequency planar transformer.

IPC Classes  ?

• H01F 19/04 - Transformers or mutual inductances suitable for handling frequencies considerably beyond the audio range
• H03H 7/00 - Multiple-port networks comprising only passive electrical elements as network components

Abstract

A method for the crystallization of a film made of a thermoplastic film material, in particular a CPET material, to form a product in which a crystallization process is initiated by shaping the thermoplastic film material within a molding tool. A main crystallization of the crystallization process is carried on outside of the molding tool.

IPC Classes  ?

• B29C 51/42 - Heating or cooling
• B29C 51/44 - Removing or ejecting moulded articles
• B29C 51/22 - Thermoforming apparatus having movable moulds or mould parts rotatable about an axis
• B29C 51/26 - Component parts, details or accessoriesAuxiliary operations

Abstract

The invention relates to a gripper (2; 170) for a draping frame having a gripper chassis (22; 171) and at least two opposing, mutually movable gripper jaw elements (22; 171) for gripping a film element (20), said gripper jaw elements being provided on a gripper head part (25; 174) of the gripper, and the gripper head part of the gripper being movably mounted, at least with one degree of freedom, relative to the gripper chassis.

IPC Classes  ?

• B29C 51/26 - Component parts, details or accessoriesAuxiliary operations
• B29C 63/00 - Lining or sheathing, i.e. applying preformed layers or sheathings of plasticsApparatus therefor
• B29C 63/04 - Lining or sheathing, i.e. applying preformed layers or sheathings of plasticsApparatus therefor using sheet or web-like material by folding, winding, bending or the like
• B29C 51/10 - Forming by pressure difference, e.g. vacuum
• B29C 51/16 - Lining or labelling
• B29C 51/18 - Thermoforming apparatus
• B29C 51/42 - Heating or cooling
• B29C 51/44 - Removing or ejecting moulded articles
• B65G 61/00 - Use of pick-up or transfer devices or of manipulators for stacking or de-stacking articles not otherwise provided for

Abstract

This invention relates to a method for operating a variable-impedance load on an apparatus, consisting of a planar transformer, consisting of at least one primary and one secondary side, which can be operated as input side and output side, respectively, comprising primary and secondary coils, wherein capacitances between turns of a coil form a resonant circuit with inductances of the coil. The invention involves selecting a resonant frequency of the resonant circuit, the resonant frequency coinciding with a frequency of a harmonic to be rejected from an input signal.

IPC Classes  ?

• H04B 1/18 - Input circuits, e.g. for coupling to an antenna or a transmission line

Abstract

The invention relates to a method for operating an impedance-variable load at a device consisting of a planar transformer consisting of at least one primary side and at least one secondary side which can be operated, respectively, as the input side and the output side, said method having the step of representing a virtual HF ground in the point of symmetry of one of the secondary sides with respect to a first impedance.

IPC Classes  ?

• H03H 7/38 - Impedance-matching networks
• H01F 19/04 - Transformers or mutual inductances suitable for handling frequencies considerably beyond the audio range
• H03H 7/09 - Filters comprising mutual inductance

Abstract

Method of forming, in particular a thermoforming method, a foil into a container, in particular a brewing container, especially a coffee capsule, using a plug assist and/or pressure difference in axial main forming direction, directing the foil into a forming tool creating a blank with a cavity and pressing the foil towards the forming tool bottom in order to create a floor for the blank and characterising the method in that the floor of the blank experiences a material distribution, especially a material shifting and/or material compression, during which a constant pressure difference within the blank's cavity is guaranteed and a circumferential annular gap is created.

IPC Classes  ?

• B29C 51/08 - Deep-drawing or matched-mould forming, i.e. using mechanical means only
• B29C 51/06 - Combined thermoforming and prestretching, e.g. biaxial stretching using pressure difference
• B65B 43/08 - Forming three-dimensional containers from sheet material
• B65D 85/804 - Disposable containers or packages with contents which are infused or dissolved in situ
• B29C 51/30 - Moulds
• B29L 31/00 - Other particular articles
• B65B 29/02 - Packaging of substances, e.g. tea, which are intended to be infused in the package
• B65B 1/02 - Machines characterised by the incorporation of means for making the containers or receptacles

Abstract

The invention relates to a punch press for punching out punching products such as motor vehicle components, particularly instrument panels, inside door panels or the like, comprising a base having a punching tool with a lower tool and an upper tool, a machine table for holding said lower tool, and a displacement device for displacing the upper tool relative to the lower tool, wherein the punch press and particularly the punching tool, the machine table and the displacement device are configured for replacement of the punching tool for a punching product replacement step, in order to reequip the punch press with new punching products for punching.

IPC Classes  ?

• B26F 1/02 - Perforating by punching, e.g. with relatively-reciprocating punch and bed
• B26F 1/38 - Cutting-outStamping-out
• B26D 5/00 - Arrangements for operating and controlling machines or devices for cutting, cutting-out, stamping-out, punching, perforating, or severing by means other than cutting
• B26D 7/32 - Means for performing other operations combined with cutting for conveying or stacking cut product
• B21D 37/14 - Particular arrangements for handling and holding in place complete dies
• B21D 28/02 - Punching blanks or articles with or without obtaining scrapNotching
• B26F 1/40 - Cutting-outStamping-out using a press, e.g. of the ram type
• B26D 5/08 - Means for actuating the cutting member to effect the cut
• B26F 1/44 - Cutters thereforDies therefor
• B26D 7/26 - Means for mounting or adjusting the cutting memberMeans for adjusting the stroke of the cutting member
• B29L 31/30 - Vehicles, e.g. ships or aircraft, or body parts thereof

Abstract

A system and method for producing a medical bag with an HF welder that uses upper and lower dies each having a plurality of electrode lamellae arranged such that they are alternatingly polarized relative to adjacent lamellae and opposing lamellae. Interspersed dielectric materials may be used to impart contours onto the film material to produce a patterned bag.

IPC Classes  ?

• B29C 65/00 - Joining of preformed partsApparatus therefor
• A61J 1/10 - Bag-type containers
• B29C 65/04 - Dielectric heating, e.g. high-frequency welding
• B29L 31/00 - Other particular articles
• B65D 75/58 - Opening or contents-removing devices added or incorporated during package manufacture
• B65B 61/18 - Auxiliary devices, not otherwise provided for, for operating on sheets, blanks, webs, binding material, containers or packages for applying or incorporating package-opening or unpacking elements, e.g. tear-strips
• B31B 70/84 - Forming or attaching means for filling or dispensing contents, e.g. valves or spouts

Abstract

The mould comprises a base plate and a plurality of forming areas, wherein each forming area comprises a cavity in the base plate and a forming sleeve placed in the cavity. Each forming area further comprises first heat means for heating or keeping heated the forming sleeve relative to the base plate, such that the temperature of the part of the film which lies against the forming sleeve during cooling remains above a glass temperature of the plastic long enough to obtain a product with an at least partially crystalline structure.

IPC Classes  ?

• B29C 51/42 - Heating or cooling
• B29C 51/32 - Moulds having cutting means
• B29C 51/44 - Removing or ejecting moulded articles
• B29C 51/46 - Measuring, controlling or regulating

Abstract

A device and method for thermoforming of a product from a plastic film includes a mould assembly which is used in such a device. The plastic film is clamped between the mould parts in primary and secondary manner. The forming process can hereby be divided into more or less independent zones. Different forming techniques, positive or negative, can be used in the different zones. This makes it possible to combine the advantages of the two techniques in one forming process.

IPC Classes  ?

• B29C 51/30 - Moulds
• B29C 51/04 - Combined thermoforming and prestretching, e.g. biaxial stretching
• B29C 51/08 - Deep-drawing or matched-mould forming, i.e. using mechanical means only
• B29C 51/36 - Moulds specially adapted for vacuum forming
• B29C 51/32 - Moulds having cutting means
• B29C 51/26 - Component parts, details or accessoriesAuxiliary operations

Abstract

The invention relates to a method for the crystallisation of a film (102, 202, 2, 302, 402, 502, 602) made of a thermoplastic film material, in particular a CPET material, to form a product (512), in which a crystallisation process is initiated by shaping the thermoplastic film material within a moulding tool (118), wherein a main crystallisation (50) of the crystallisation process is carried out outside of said moulding tool (118).

IPC Classes  ?

• B29C 51/22 - Thermoforming apparatus having movable moulds or mould parts rotatable about an axis
• B29C 51/26 - Component parts, details or accessoriesAuxiliary operations
• B29C 51/42 - Heating or cooling
• B29C 51/44 - Removing or ejecting moulded articles
• B29C 71/00 - After-treatment of articles without altering their shapeApparatus therefor

Abstract

The invention relates to a method for the crystallisation of a film (102, 202, 2, 302, 402, 502, 602) made of a thermoplastic film material, in particular a CPET material, to form a product (512), in which a crystallisation process is initiated by shaping the thermoplastic film material within a moulding tool (118), wherein a main crystallisation (50) of the crystallisation process is carried out outside of said moulding tool (118).

IPC Classes  ?

• B29C 51/26 - Component parts, details or accessoriesAuxiliary operations
• B29C 51/42 - Heating or cooling
• B29C 51/22 - Thermoforming apparatus having movable moulds or mould parts rotatable about an axis
• B29C 51/44 - Removing or ejecting moulded articles
• B29C 71/00 - After-treatment of articles without altering their shapeApparatus therefor
• B29K 67/00 - Use of polyesters as moulding material

Goods & Services

Machines and machine tools, except injection molding machines, namely, machines and machine tools for the forming of materials, namely, metalworking machine tools; motors and engines except for land vehicles; machine couplings and transmission components except for land vehicles; machines for the vacuum forming and pneumatic forming of plastic sheets and plastic films; machines for the vacuum forming and pneumatic forming of plastic sheets and plastic films for packaging, in particular for manufacturing transparent packaging; machines for vacuum forming and pneumatic forming and pressing, and machines for the mechanical compressing of plastic sheets and plastic films, and the laminating of plastic sheets and plastic films, as well as plastic-coated and non-coated textile materials on preformed backing elements for manufacturing compound elements, in particular for the automobile industry, namely, dashboards and interior trim; moulds and machine tools, namely, tools for forming, pressing and laminating plastic for the aforesaid machines, except injection molding machines; automatic machines for feeding plastic films, textiles, plastic sheets and backing elements into the aforesaid machines; automatic machines for transferring and removing parts manufactured in the aforesaid machines; machines for sorting and stacking goods manufactured in the aforesaid machines; machines for tearing off articles manufactured in the aforesaid machines along the structure within a film; machines for removing waste parts during the manufacture of articles in the aforesaid machines; stamps, namely, punching presses for pre-punching and punching out articles manufactured in the aforesaid machines from plastic films and plastic sheets; longitudinal cutting and cross-cutting machines and installations constructed therefrom, for cutting articles manufactured in the aforesaid machines from plastic films and plastic sheets; machines for manufacturing mono-extruded and co-extruded plastic films and plastic sheets; waste shredding mills for manufacturing plastic granules; installations mainly constructed from the aforesaid machines, namely, plastic processing machines; automatic machines and apparatus for manufacturing thermoformed parts; radio frequency generating machines for welding textiles, plastics, infusion bags, dialysis bags, multi-chamber bags, blood bags, colostomy bags, urine bags, drainage bags, urine catheters, blister packaging, drill-bit bags, passport wallets, cart interior-trim components, headrests, vehicle carpets, roof liners, sun-visors, seat covers, dashboards; high-frequency electric welding machines; ultrasound and vibration electric welding machines; hot air electric welding machines; thermocontact electric welding machines; heat impulse electric welding machines; industrial machines for paper gluing and fabric setting in the clothing industry using high-frequency heating and drying; single-column and portal-type electric welding presses; automatic machines for feeding the aforesaid machines with films and auxiliary materials, namely, stiffening materials; automatic machines for assembling and transferring the parts manufactured in the aforesaid machines; automatic machines for manufacturing packaging from thermoformed plastic films and plastic sheets, and from plastic films and plastic sheets welded using high-frequency energy; mechanical apparatus for tearing off articles manufactured in the aforesaid machines along the structure within a film; mechanical apparatus for removing waste parts during the manufacture of articles in the aforesaid machines; machine tools, namely, welding tools for the aforesaid machines; automatic stamping and punching presses for plastics; mechanical large die-stamping machines; heat contact gluing machines, in particular for gluing glass and metal parts; assembly lines, namely, a series of machines for the positioning and gluing of plastic, metal and ceramic parts onto interior and exterior trim during automobile assembly; longitudinal cutting and cross-cutting machines for films; installations, namely, a series of assembly line machines for forming, cutting and stacking parts of packages in successive stages; rotational molding installations for manufacturing film skins, mainly for the automobile sector

Abstract

The invention relates to a device for laminating a laminating foil element onto a component having a profiled lamination plane using a lamination tool, by means of which tool the laminating foil element is laminated onto the component, the lamination tool comprising a first tool half and a second tool half, and the device comprising a deflection arrangement for deflecting portions of the laminating foil element out of the profiled lamination plane.

IPC Classes  ?

• B29C 63/02 - Lining or sheathing, i.e. applying preformed layers or sheathings of plasticsApparatus therefor using sheet or web-like material
• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• B29C 65/48 - Joining of preformed partsApparatus therefor using adhesives
• B32B 37/12 - Methods or apparatus for laminating, e.g. by curing or by ultrasonic bonding characterised by using adhesives

Abstract

The invention relates to a film molding tool for laminating a component with a laminating element or for molding a thermoplastic film from a grained geometry, an alternative method for lower die production and the use of a corresponding film molding tool. In particular, the invention relates to a production method for a lower die that reduces both production time and production costs, exhibits long service lives and also provides high molding quality. To do this, a thin shell mold of a film molding tool is produced from nickel by means of electrochemical deposition and stiffened by means of metal spraying, wherein the metal spray layer incorporates a honeycomb-shaped woven fabric.

IPC Classes  ?

• B29C 33/38 - Moulds or coresDetails thereof or accessories therefor characterised by the material or the manufacturing process

Abstract

The invention relates to a film molding tool for laminating a component with a laminating element or for molding a thermoplastic film with a grained geometry, to an alternative method for producing grain shells, and to the use of a corresponding film molding tool. In particular, the invention relates to a method for producing grain shells, said method saving on production time and production costs, producing long service lives, and additionally allowing a high molding quality. For this purpose, the molding shell of a film molding tool is provided with a ceramic layer which has a grained structure and thus allows the grained structure to be transferred onto the laminating element during the lamination method.

IPC Classes  ?

• B29C 33/02 - Moulds or coresDetails thereof or accessories therefor with incorporated heating or cooling means
• B29C 33/42 - Moulds or coresDetails thereof or accessories therefor characterised by the shape of the moulding surface, e.g. ribs or grooves
• B29C 33/56 - CoatingsReleasing, lubricating or separating agents
• B22D 23/00 - Casting processes not provided for in groups

Abstract

In order significantly to reduce the risk of contamination of a bag for medical purposes, in particular due to residual particles of tube material caused during cutting of a tube for access to the bag, the invention proposes a system (1) for producing a bag for medical purposes, comprising a tube transfer station (2) with a transfer means (3) for transferring a tube (11) coming into the tube transfer station (2) to a holder (10) and for the severing there of a tube section (17) transferred to the holder (10) from a remaining portion (18) of the incoming tube (11) in order subsequently to be able to make the severed tube section (17) connectable to two film layers for forming an access to the bag, wherein the tube transfer station (2) has a tube-tension-holding means (15) on the holder side and also a tube-pulling means (16), which means are designed to introduce tensile forces (19) between the severed tube section (17) and the remaining portion (18) of the incoming tube (11) while the severing takes place.

IPC Classes  ?

• A61J 1/14 - Containers specially adapted for medical or pharmaceutical purposes DetailsAccessories therefor
• A61J 1/10 - Bag-type containers
• B26D 3/16 - Cutting rods or tubes transversely
• B26D 7/14 - Means for treating work or cutting member to facilitate cutting by tensioning the work
• B26D 1/04 - Cutting through work characterised by the nature or movement of the cutting memberApparatus or machines thereforCutting members therefor involving a cutting member which does not travel with the work having a linearly-movable cutting member
• B29C 65/00 - Joining of preformed partsApparatus therefor
• B29L 31/00 - Other particular articles
• B29C 65/02 - Joining of preformed partsApparatus therefor by heating, with or without pressure
• A61J 1/16 - Holders for containers

Abstract

The invention relates to a device (1) for use with a system (3) for thermoforming semi-finished goods (4), particularly for vacuum laminating a film element (5) on a carrier part, comprising a tenter frame (2) having a holding device (20) for holding a tool used to work the semi-finished goods, a pressure difference transducer (25) for producing a negative pressure or an excess pressure in at least one region (26) of the device (1) the pressure of which can be manipulated, spaces (30, 31, 32, 33) resulting between the tenter frame (2) and the holding device (20) and/or the tool, and a sealing device (40) comprising flat sealing elements (45, 46, 47, 48) for the face sealing of the spaces (30, 31, 32, 33) in order to seal off the at least one region (26) the pressure of which can be manipulated with respect to the surroundings (49), characterized in that a variable-surface sealing face (50) can be produced by at least one of the planar sealing elements (45, 46, 47, 48), by which the spaces (30, 31, 32, 33) can be sealed.

IPC Classes  ?

• B29C 51/10 - Forming by pressure difference, e.g. vacuum
• B29C 51/26 - Component parts, details or accessoriesAuxiliary operations
• B29C 51/30 - Moulds
• B29C 51/38 - Opening, closing or clamping means
• B29C 51/36 - Moulds specially adapted for vacuum forming

Abstract

The aim of the invention is to avoid the risk of contamination of a bag for medical purposes, in particular to significantly reduce the amount of residual particles of material during the cutting of a tube for access to the bag. The invention proposes a system (1) for producing a bag for medical purposes comprising a tube transfer station (2) having transfer means (3) for transferring a tube (11), which is being transported towards the tube transfer station (2), to a holder (10) and for separating there a tube section (17) transferred to the holder (10) from a remainder (18) of the tube (11), in order to then render the separated tube section (17) connectible to two film layers to form an access to the bag. The tube transfer station (2) comprises at least one air nozzle (55, 57), and an effective area (58) of the at least one air nozzle (55, 57) is directed onto a designated location (20) for separation such that a forced air flow (56) in the designated location (20) forced by air blown out and/or drawn in can be adjusted for separation.

IPC Classes  ?

• B29C 65/00 - Joining of preformed partsApparatus therefor
• B26D 7/00 - Details of apparatus for cutting, cutting-out, stamping-out, punching, perforating, or severing by means other than cutting
• B26D 3/00 - Cutting work characterised by the nature of the cut madeApparatus therefor
• A61J 1/00 - Containers specially adapted for medical or pharmaceutical purposes
• A61M 39/00 - Tubes, tube connectors, tube couplings, valves, access sites or the like, specially adapted for medical use
• B29C 65/78 - Means for handling the parts to be joined, e.g. for making containers or hollow articles
• B26D 7/18 - Means for removing cut-out material or waste
• B26D 3/16 - Cutting rods or tubes transversely
• A61J 1/10 - Bag-type containers
• A61J 1/14 - Containers specially adapted for medical or pharmaceutical purposes DetailsAccessories therefor
• A61M 1/02 - Blood transfusion apparatus
• A61M 39/14 - Tube connectors or tube couplings for connecting tubes having sealed ends
• A61M 39/18 - Methods or apparatus for making the connection under sterile conditions, i.e. sterile docking
• A61M 39/08 - TubesStorage means specially adapted therefor
• B29C 65/02 - Joining of preformed partsApparatus therefor by heating, with or without pressure
• B29L 31/00 - Other particular articles

Abstract

The invention relates to a device for welding a connection region of a film to a connection part having an axial direction. In the case of conventional devices, there is the risk of steep workpiece edges causing uncontrolled weak spots in the film and in the weld seam. According to the invention, the film is extended in a controlled manner such that the film has a length reserve. The film is extended in such a way that the film has a deformation cross-section that runs out such that the deformation is not visible on the final product. In this connection, the invention further relates to a use of a film, to a method for welding, to a method for producing bags, to a system for producing bags, and to a bag.

IPC Classes  ?

• A61J 1/10 - Bag-type containers
• A61J 1/14 - Containers specially adapted for medical or pharmaceutical purposes DetailsAccessories therefor
• B29C 65/02 - Joining of preformed partsApparatus therefor by heating, with or without pressure
• B29C 65/48 - Joining of preformed partsApparatus therefor using adhesives

Abstract

The invention relates to a device (1) for filling a bag (2), a bag contour sealing tool for producing a bag, a sealing tool for sealing a bag, a method for filling a bag, a method for producing a bag, a system for producing and filling a bag and a bag which is produced and filled using said system or has been produced using a bag contour sealing tool. The invention enables a bag to be filled, in particular a bag for medical purposes, without the need for the bag to have a filling port. As a result, resources and costing can be saved and there is harm to the environment.

IPC Classes  ?

• B65B 39/08 - Nozzles, funnels or guides for introducing articles or materials into containers or wrappers adapted to support containers or wrappers by means of clamps
• B65D 33/00 - Details of, or accessories for, sacks or bags
• B65B 3/00 - Packaging plastic material, semiliquids, liquids or mixed solids and liquids, in individual containers or receptacles, e.g. bags, sacks, boxes, cartons, cans or jars
• B29C 65/02 - Joining of preformed partsApparatus therefor by heating, with or without pressure
• B29C 65/48 - Joining of preformed partsApparatus therefor using adhesives
• B29L 31/00 - Other particular articles

Goods & Services

Machines and machine tools for the treatment of materials and production purposes; machines and machine tools for the treatment and production of plastic plates and plastic foils; machine tools for working metals; motors, other than for land vehicles; machine couplings and transmission components (except for land vehicles); forming and laminating machines and forming and laminating installations constructed therefrom; press laminating machines; vacuum forming machines; machines for vacuum forming and pneumatic forming of plastic plates and plastic foils; machines for vacuum forming and pneumatic forming of plastic plates and plastic foils for packaging, in particular for manufacturing transparent packaging; machines for vacuum forming and pneumatic forming as well as presses and devices for mechanical pressing of plastic plates and plastic foils and laminating the plastic plates and plastic foils as well as plastic-coated and coating-free textile materials onto preformed carriers for producing composite elements, such as dashboards, interior lining and interior lining parts, in particular for the automotive industry; thermoforming machines; thermoforming machines for coated films; folding machines and installations constructed therefrom; edge folding machines and installations constructed therefrom; machines for folding edges of plastic parts; agricultural machines; extruders; blowers; riveting machines; stamping calender for plastics; shredding, cutting and granulating machines for foils; moulds and machine tools for the aforesaid machines; cutting machine components, namely waterjet supports for cutting installations; robots for conveying plastic foils, textiles, plastic plates and carriers to the aforesaid machines; robots for transferring and discharging the parts produced in the aforesaid machines; machines for sorting and piling the goods produced in the aforesaid machines; machines for pulling out assembled articles within a foil produced on the aforesaid machines; machines for removing waste parts during the production of articles on the aforesaid machines; punching machines; die cutters (machines) for pre-cutting and die-cutting articles produced out of the plastic foils and plastic plates on the aforesaid machines; slitting and cross-cutting machines and installations constructed therefrom for cutting articles produced from plastic foils and plastic plates on the aforesaid machines; machines for producing mono-extruded and co-extruded plastic foils and plastic plates; waste shredders for producing plastic granules; installations for producing thermoformed parts, mainly constructed from the aforesaid pressing, stamping, cutting, granulating machines and extruders; high frequency generators; high frequency welding machines; ultrasound and vibration welding machines; hot air welding machines; thermo-contact welding machines; heat impulse welding machines; friction welding machines; foil welding machines; plastic foils welding machines; welding presses, in single column and portal design; robots for feeding the aforesaid machines with foils and auxiliary materials, such as stiffening materials; robots for gathering and transferring; machines for producing packages; robots for producing packages from thermoformed plastic foils and plastic plates as well as plastic foils and plastic plates welded by using high-frequency energy; mechanical appliances for pulling out assembled articles within a foil produced on the aforesaid machines; mechanical appliances for removing waste parts that accumulate during the production of articles on the aforesaid machines; electric machine tools, in particular welding tools for the aforesaid machines; foaming tools and moulds (machine tools); pressing and punching machines; mechanical pressing and stamping tools; pressing machines for industrial purposes; hot contact gluing machines, in particular for gluing glass and metal parts; assembly lines (mainly consisting of the aforesaid machines) for positioning and gluing plastic, metal and ceramic parts onto interior and exterior panelling parts, in particular in the automotive industry; foil slitting and cross-cutting machines; installations mainly composed of the aforesaid machines; assembly lines (mainly consisting of the aforesaid machines) for forming, cutting and stacking of package parts; rotational moulding machines for manufacturing foil skins, mainly for the automotive industry; robots (machines); industrial robots (machines); cup forming machines; film pre-heating stations; thermoforming machines for refrigerator inner containers; machines for manufacturing refrigerator inner doors; machines for producing food capsules; machines for manufacturing and filling infusion, dialysis and multi-chamber bags; machines for manufacturing blood bags; machines for manufacturing blood filters; machines for manufacturing colostomy bags; machines for manufacturing catheters; machines for manufacturing urine bags; filling machines; blister forming machines; blister closing machines; blister packing machines; sliding tables; packaging machines; bag packing machines; machine tools for the aforesaid machines. Measuring apparatus; measuring instruments; measuring equipment; measuring tools; jigs (measuring instruments); checking gauge (measuring equipment). Industrial high-frequency heating and drying installations, in particular for paper gluing and fabric fixation in the clothing industry. Construction; repair, servicing and maintenance of machines, installations, robots, mechanical apparatus and accessories; installation services for machines, installations, robots and mechanical apparatus included in class 7. Scientific and technological services and research and design relating thereto; industrial analysis and research; design and development of computer hardware and software; technical design of plants for the aforesaid machines, robots, equipment, apparatus and installations.

Goods & Services

Machines and machine tools for the treatment of materials and production purposes; machines and machine tools for the treatment and production of plastic plates and plastic foils; machine tools for working metals; motors, other than for land vehicles; machine couplings and transmission components (except for land vehicles); forming and laminating machines and forming and laminating installations constructed therefrom; press laminating machines; vacuum forming machines; machines for vacuum forming and pneumatic forming of plastic plates and plastic foils; machines for vacuum forming and pneumatic forming of plastic plates and plastic foils for packaging, in particular for manufacturing transparent packaging; machines for vacuum forming and pneumatic forming as well as presses and devices for mechanical pressing of plastic plates and plastic foils and laminating the plastic plates and plastic foils as well as plastic-coated and coating-free textile materials onto preformed carriers for producing composite elements, such as dashboards, interior lining and interior lining parts, in particular for the automotive industry; thermoforming machines; thermoforming machines for coated films; folding machines and installations constructed therefrom; edge folding machines and installations constructed therefrom; machines for folding edges of plastic parts; agricultural machines; extruders; blowers; riveting machines; stamping calender for plastics; shredding, cutting and granulating machines for foils; moulds and machine tools for the aforesaid machines; cutting machine components, namely waterjet supports for cutting installations; robots for conveying plastic foils, textiles, plastic plates and carriers to the aforesaid machines; robots for transferring and discharging the parts produced in the aforesaid machines; machines for sorting and piling the goods produced in the aforesaid machines; machines for pulling out assembled articles within a foil produced on the aforesaid machines; machines for removing waste parts during the production of articles on the aforesaid machines; punching machines; die cutters (machines) for pre-cutting and die-cutting articles produced out of the plastic foils and plastic plates on the aforesaid machines; slitting and cross-cutting machines and installations constructed therefrom for cutting articles produced from plastic foils and plastic plates on the aforesaid machines; machines for producing mono-extruded and co-extruded plastic foils and plastic plates; waste shredders for producing plastic granules; installations for producing thermoformed parts, mainly constructed from the aforesaid pressing, stamping, cutting, granulating machines and extruders; high frequency generators; high frequency welding machines; ultrasound and vibration welding machines; hot air welding machines; thermo-contact welding machines; heat impulse welding machines; friction welding machines; foil welding machines; plastic foils welding machines; welding presses, in single column and portal design; robots for feeding the aforesaid machines with foils and auxiliary materials, such as stiffening materials; robots for gathering and transferring; machines for producing packages; robots for producing packages from thermoformed plastic foils and plastic plates as well as plastic foils and plastic plates welded by using high-frequency energy; mechanical appliances for pulling out assembled articles within a foil produced on the aforesaid machines; mechanical appliances for removing waste parts that accumulate during the production of articles on the aforesaid machines; electric machine tools, in particular welding tools for the aforesaid machines; foaming tools and moulds (machine tools); pressing and punching machines; mechanical pressing and stamping tools; pressing machines for industrial purposes; hot contact gluing machines, in particular for gluing glass and metal parts; assembly lines (mainly consisting of the aforesaid machines) for positioning and gluing plastic, metal and ceramic parts onto interior and exterior panelling parts, in particular in the automotive industry; foil slitting and cross-cutting machines; installations mainly composed of the aforesaid machines; assembly lines (mainly consisting of the aforesaid machines) for forming, cutting and stacking of package parts; rotational moulding machines for manufacturing foil skins, mainly for the automotive industry; robots (machines); industrial robots (machines); cup forming machines; film pre-heating stations; thermoforming machines for refrigerator inner containers; machines for manufacturing refrigerator inner doors; machines for producing food capsules; machines for manufacturing and filling infusion, dialysis and multi-chamber bags; machines for manufacturing blood bags; machines for manufacturing blood filters; machines for manufacturing colostomy bags; machines for manufacturing catheters; machines for manufacturing urine bags; filling machines; blister forming machines; blister closing machines; blister packing machines; sliding tables; packaging machines; bag packing machines; machine tools for the aforesaid machines. Measuring apparatus; measuring instruments; measuring equipment; measuring tools; jigs (measuring instruments); checking gauge (measuring equipment). Industrial high-frequency heating and drying installations, in particular for paper gluing and fabric fixation in the clothing industry. Construction; repair, servicing and maintenance of machines, installations, robots, mechanical apparatus and accessories; installation services for machines, installations, robots and mechanical apparatus included in class 7. Scientific and technological services and research and design relating thereto; industrial analysis and research; design and development of computer hardware and software; technical design of plants for the aforesaid machines, robots, equipment, apparatus and installations.

Abstract

A thermoforming device is described. It relates to a mold assembly including a first and second mold, and to a mold that can be used in a thermoforming device. It also relates to a method for thermoforming a product. The thermoforming device is characterized in that the thermoforming device comprises a second pre-stretcher, in addition to a first pre-stretcher and a calibration element, and that the second pre-stretcher is at least partially and moveably arranged in a second mold body. A movement relative to the second mold body and towards the same forming cavity of the first pre-stretcher, the second pre-stretcher, and the calibration element, can be individually controlled, and the second pre-stretcher at least partially surrounds the first pre-stretcher and the calibration element.

IPC Classes  ?

• B29C 51/04 - Combined thermoforming and prestretching, e.g. biaxial stretching
• B29C 51/10 - Forming by pressure difference, e.g. vacuum
• B29C 51/26 - Component parts, details or accessoriesAuxiliary operations
• B29C 51/20 - Thermoforming apparatus having movable moulds or mould parts
• B29C 51/38 - Opening, closing or clamping means
• B29K 105/00 - Condition, form or state of moulded material
