Glue for glue guns; glue rods for glue guns; adhesives for industrial use; detergents for industrial use and for use in manufacturing processes.. Cleaning preparations, other than for personal use; detergents; cloths impregnated with a detergent, for cleaning; wipes impregnated with a cleaning preparation; cleaning tablets; detergent tablets; cleaning effervescent tablets; detergent effervescent tablets.. Fasteners and fixings; staples for industrial use; staples of metal for plant support and fencing; rivets, brads, nails, cable clamps, blind rivets, eyelets, loops, rings, plugs, all goods of metal; welding and soldering materials; solder; solder wire; wall plugs and wall anchors of metal; expansion plugs of metal; hogrings for fencing and netting.. Powerdriven hand tools; electric and pneumatic handtools, namely, stapling guns, brad guns, staple hammers, staple pliers, nail guns, riveters, blind riveters, eyelet pliers, eyelet punches, staple removers, glue guns, tools for applying adhesive melts, pliers, cable guns, punch pliers, clamps; electric stapling apparatus for book binding machines; power driven staplers for machines for industrial purposes; electric stapling apparatus for printing machines, sorting machines and packaging machines; power driven punching drills; electric hot air guns; battery powered hand tools; welding and soldering equipment, machines and devices; electric soldering apparatus; electric soldering irons; soldering lamps; battery powered glue guns; jets and nozzles for glue guns; battery powered hot air guns; jets and nozzles for hot air guns; battery powered nail guns and nailers; battery powered tackers; battery powered brad nailers; battery powered staple guns; battery powered pruners, pruning shears and pruning saws; battery powered drills, screw drivers and screw extractors; battery powered saws, chainsaws, saber saws, circular saws and jigsaws; battery powered sanders, grinders and angle grinders; battery powered planers, routers; battery powered multi tools; binding machines and battery powered binding machines; soldering apparatus, gas-operated; gas soldering irons. Hand tools; manually operated hand held tools, namely stapling guns, brad guns, staple hammers, staple pliers, nail guns, riveters, blind riveters, eyelet pliers, eyelet punches, staple removers, pliers, cable guns, punch pliers, clamps; loppers and pruners, garden pliers, pliers for plant support and fencing (hand tools); fastening tools and joining tools; setting tools; setting pliers; paint scrapers [hand tools].. Work lights; LED work lights; portable work lights; portable LED work lights; work flood lights; LED work flood lights; work lights for building and renovation work; work lights for painting and upholstery work; work lights for inspection and surveying work; work lights for mechanics and service technicians work; LED work lights for building and renovation work; LED work lights for painting and upholstery work; LED work lights for inspection and surveying work; LED work lights for mechanics and service technicians work; battery powered fans; battery powered fans for ventilation; battery powered extractor fans. Staplers and stapler pliers (office requisites); staples; staples for office purposes and packaging; staple removers; paper hole punches; non-electric stapling machines and stapling pliers for stapling paper; non-electric stapling guns (office requisites); non-electric staplers for paper handling equipment, namely, staplers for photocopiers, staplers for bookbinding apparatus and packaging; tape for household and office purposes; tape dispensers for household and office purposes; adhesives for stationery.. Electrical and thermal insulation articles and materials; heat shrinkable tubing; seals, sealants and fillers; adhesive caulking compounds; silicone sealants; adhesive sealants; sealants for buildings.. Non-metallic fasteners; wall plugs and wall anchors, not of metal; expansion plugs, not of metal.. Cleaning articles; brushes for cleaning; cleaning brushes; battery powered cleaning brushes; cloths for cleaning; cleaning cloths; microfiber cloths for cleaning.
The invention relates to a wire-binding machine (10) having a housing (12), a reel holder (14), a wire reel (16) which is mounted in the reel holder (14) so as to be rotatable about an axis of rotation (18) and which has a reel member (20) and a wire wound in roll-shaped form onto the reel member (20), also having a motor arranged in the housing (12), an unwinding device, which is driven by the motor, for unwinding the wire from the reel member (20), and an apparatus for twisting the unwound wire, wherein the reel holder (14) has a main body (22) which is fastened to the housing (12) and in which the wire reel (16) is at least partially accommodated, and wherein the reel holder (14) has a braking device (28) which inhibits rotation of the wire reel (16). According to the invention, the braking device (28) has a first bearing element (30) connected to the main body (22) for conjoint rotation, a second bearing element (32) which is connected to the wire reel (16) for conjoint rotation and is rotatable about the axis of rotation (18) with respect to the first bearing element (30), and a braking element (34) which is arranged between the first and the second bearing element (30, 32) and which, upon rotation of the second bearing element (32) with respect to the first bearing element (30), applies a friction force inhibiting the rotation.
A stapler for stapling sheet material with staples, each staple having two staple legs and a staple crown. The stapler having an anvil arm, with a stapling unit being pivotable relative to the anvil arm and including a staple magazine receiving the staples and a driver for pushing staples through the sheet material, with a base part, on which the anvil arm is mounted movably towards it, and with two two-armed bending levers pivotably mounted on the anvil arm about a respective pivot axis, each bending lever having a first and a second lever arm. Upon approach of the anvil arm to the base part, the second lever arms are pivoted and bend the staple legs. The pivot axes extend substantially perpendicular to the staple crowns and the second lever arms have end portions which are arranged offset to one another in the axial direction of the pivot axes.
B25C 5/02 - Manually operated portable stapling toolsHand-held power-operated stapling toolsStaple feeding devices therefor with provision for bending the ends of the staples on to the work
The invention relates to a stapling device (10) for stapling together sheet material by means of staples (12) which each have two staple legs (14) and one staple bar (16) which connects the staple legs (14) to each other and runs transversely to them. The stapling device has: an anvil limb (26), which has a support plate (38) for supporting the sheet material and a cutting block (40) with two cutting edges (42) for cutting off excess end portions of the staple legs (14); a staple magazine (32), which is mounted pivotably relative to the anvil limb (26) and receives the staples (12) in a row with their staple legs (16) being oriented parallel to one another and bearing against one another; and a stapling unit (30), which has a driver (36) for pushing forward individual staples (12) via the free ends of their staple legs (14) through the sheet material, a lower part (18), on which the anvil limb (26) is supported so as to be movable towards the lower part against a restoring force, and two two-armed bending levers (50), which are mounted on the anvil limb so as to each be pivotable about a separate pivot axis (52) and which each have a first lever arm (54) having a bending face (56) for bending over the staple legs (14) and a second lever arm (58), the second lever arms (58) being pivoted about the pivot axes (52) by being acted on by the lower part (18) as the anvil limb (26) approaches the lower part (18), and the bending faces (56) bending the staple legs (14) over towards one another and cutting off any excess end portions by pressing against the cutting edges (42). In accordance with the invention, the pivot axes (52) run substantially perpendicularly to the staple legs (16) of the staples (12) received in the staple magazine (32), and that the second lever arms (58) have end portions (66) which start at the free ends (64) of the lever arms and which are arranged offset in relation to one another in the axial direction of the pivot axes (52) such that said end portions move past one another as the anvil limb (26) approaches the lower part (18).
B25C 5/02 - Manually operated portable stapling toolsHand-held power-operated stapling toolsStaple feeding devices therefor with provision for bending the ends of the staples on to the work
