Abstract

The present invention provides a frame for an automotive headliner, the frame comprising a number of frame portions configured for reinforcing a cut-out in the headliner, the frame portions comprising carbon fiber reinforced polypropylene as a main component.

IPC Classes  ?

• B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
• B29K 23/00 - Use of polyalkenes as moulding material
• B29K 105/12 - Condition, form or state of moulded material containing reinforcements, fillers or inserts of short lengths, e.g. chopped filaments, staple fibres or bristles
• B29L 31/30 - Vehicles, e.g. ships or aircraft, or body parts thereof
• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners

Abstract

The present invention provides a headliner structure (10) for a vehicle roof. The headliner structure comprises structural pieces (22-1, 22-2, 22-3, 22-4) that are arranged to define all or a portion of a headliner opening corresponding to a roof panel opening (12) in the vehicle roof and overlap along at least a portion of a circumference of the headliner opening, wherein the structural pieces are bonded by molding, and wherein the structural pieces comprise a fiber-reinforced thermoplastic composite material.

IPC Classes  ?

• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners

Abstract

A lighting device for an interior trim part includes a light strip; a light strip carrier attached to the light strip along the length of the light strip, the light strip carrier including a laminar material; an adapter to which the light strip carrier is attached along the length of the light strip; wherein the adapter is configured to be attached to a rear side of an trim part to position the light strip at a front side of the trim part.

IPC Classes  ?

• B60Q 3/54 - Lighting devices embedded in interior trim, e.g. in roof liners
• B60Q 3/217 - Doors, e.g. door sillsSteps
• B60Q 3/62 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by optical aspects using light guides
• B60Q 3/64 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by optical aspects using light guides for a single lighting device
• B60Q 3/66 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by optical aspects using light guides for distributing light among several lighting devices
• F21V 8/00 - Use of light guides, e.g. fibre optic devices, in lighting devices or systems

Abstract

Disclosed herein is a hybrid electronic/mechanical release handle for positioning on the interior of a vehicle door panel comprising a bezel cup carrier containing an electronic sensor and mechanical handle, wherein said bezel cup carrier defines an opening for insertion of one or a plurality of a user's fingers into the bezel cup where the electronic sensor is mechanically engaged to the bezel cup carrier and covered by at least a portion of the mechanical handle.

IPC Classes  ?

• E05B 85/12 - Inner door handles
• E05B 81/76 - Detection of handle operationDetection of a user approaching a handleElectrical switching actions performed by handles
• E05B 81/90 - Manual override in case of power failure
• E05F 15/42 - Detection using safety edges

Abstract

A vehicle mini-bar comprises a housing containing one or more items therein for dispensing; an interface configured to detect and allow one or more users to access and purchase a user selected item located within said housing; one or more cameras and sensors to identify one or more items contained in said housing; one or more sensors to identify a selected user; a processor with recognition software in communication with a user device (APP) wherein said processor reports to said user device the selection and purchase by a user of said user selected item; and wherein said mini-bar includes one or more UVC light emitting diodes (LEDs) and said processor is configured to activate said one or more UVC LEDs to implement a disinfecting lighting sequence.

IPC Classes  ?

• G07F 13/10 - Coin-freed apparatus for controlling dispensing of fluids, semiliquids or granular material from reservoirs with associated dispensing of containers, e.g. cups or other articles

Abstract

An interior trim article for a motor vehicle, comprises a decorative outer skin; a touch-sensor or proximity sensor; and a backlight lighting source disposed behind said touch sensor or proximity sensor to emit light through the touch-sensor and through the decorative outer skin.

IPC Classes  ?

• B60Q 3/54 - Lighting devices embedded in interior trim, e.g. in roof liners
• B60Q 3/64 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by optical aspects using light guides for a single lighting device
• B60Q 3/82 - Switches specially adapted for vehicle interior lighting, e.g. switching by tilting the lens
• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners

Abstract

A system for disinfecting surfaces in a space, such as a vehicle or a building. The system may include a disinfecting module having a UVC light source and/or an ambient heat source for disinfecting the space. In some embodiments, an occupancy sensor is incorporated within the module. In some embodiments, control of the system in incorporated into the functionality of a ride-share application to facilitate disinfection of the vehicle between occupant rides.

IPC Classes  ?

• A61L 2/24 - Apparatus using programmed or automatic operation
• A61L 2/10 - Ultraviolet radiation
• B60H 1/00 - Heating, cooling or ventilating devices
• B60H 3/00 - Other air-treating devices

Goods & Services

Interior trim for automotive vehicles; interior panels for automotive vehicles; interior panels with structural reinforcement for automotive vehicles; trim structural substrate panels for vehicle bodies; interlocking structural substrate panels for vehicle interior trim; load floor and liners for the cargo area of vehicles; battery tray housing and covers; cargo storage bins especially adapted for use in motor vehicles; plastic parts for vehicles, namely automotive decorative and protective trim; upholstery for vehicles; semifinished injection, extrusion, compression, blow, rotational and hybrid molded products of plastic for use in vehicles, namely, instrument panels, door trim, pillar trim, overhead systems, headliners, consoles, seats, floor components and interior trim panels; vehicle interior trim comprised of additives, coating, virgin renewable, recyclable plastic materials or a combination thereof; none of the aforementioned goods in the field of industrial equipment for waste treatment. Injection, extrusion, compression, blow, rotational, and hybrid molding of plastic for others; the use of additives or coatings to produce vehicle interior trim; the reuse of previously manufactured materials to produce vehicle interior trim; none of the aforementioned services in the field of industrial equipment for waste treatment.

Goods & Services

electronic displays for automotive vehicles; Downloadable applications for utilizing mobile vending apparatus; vision systems primarily comprised of cameras, sensors and monitors; Occupant sensors comprised of proximity, capacitance, environmental, pressure or a combination thereof sensors. Lighting for automotive vehicles; disinfecting devices for vehicle interiors. Interior trim for automotive vehicles; interior panels for automotive vehicles; interior trim panels with features comprised of lighting, heating, sensors, electronic systems or a combination thereof for automotive vehicles; decorative panel finishes for vehicle interiors. Manufacture of vehicle parts and accessories for others; prototype fabrication of new products and automotive parts and accessories for others; injection, extrusion, compression, blow, rotational or a combination thereof molding of plastic for others; technical consultancy in the nature of providing advice about how to manufacture finished goods; the use of additives or coatings to produce vehicle interior trim; the reuse of previously manufactured materials to produce vehicle interior trim; 3D printing of electronic components.

Abstract

A lighting device for an interior trim part includes a light strip; a light strip carrier attached to the light strip along the length of the light strip, the light strip carrier including a laminar material; an adapter to which the light strip carrier is attached along the length of the light strip; wherein the adapter is configured to be attached to a rear side of an trim part to position the light strip at a front side of the trim part.

IPC Classes  ?

• B60Q 3/64 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by optical aspects using light guides for a single lighting device
• B60Q 3/51 - Mounting arrangements for mounting lighting devices onto vehicle interior, e.g. onto ceiling or floor
• B60Q 3/78 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by the purpose for generating luminous strips, e.g. for marking trim component edges

Abstract

The disclosure provides an interior trim part for a motor vehicle having a sliding or panoramic roof comprising a headliner and a stiffening frame attached to the headliner and enclosing and stabilizing an opening in the headliner enclosing the sliding or panoramic window, the stiffening frame being made of a fiber-reinforced composite material comprising a fiber mat and a textile lattice material, the textile lattice material being applied over a surface of the fiber mat and impregnated together therewith.

IPC Classes  ?

• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• B29C 70/00 - Shaping composites, i.e. plastics material comprising reinforcements, fillers or preformed parts, e.g. inserts
• B29C 70/08 - Fibrous reinforcements only comprising combinations of different forms of fibrous reinforcements incorporated in matrix material, forming one or more layers, with or without non-reinforced layers
• B29C 70/34 - Shaping by lay-up, i.e. applying fibres, tape or broadsheet on a mould, former or coreShaping by spray-up, i.e. spraying of fibres on a mould, former or core and shaping or impregnating by compression
• B29L 9/00 - Layered products
• B29L 31/30 - Vehicles, e.g. ships or aircraft, or body parts thereof
• B32B 5/02 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by structural features of a layer comprising fibres or filaments
• B32B 5/26 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by the presence of two or more layers which comprise fibres, filaments, granules, or powder, or are foamed or specifically porous one layer being a fibrous or filamentary layer another layer also being fibrous or filamentary
• B32B 7/09 - Interconnection of layers by mechanical means by stitching, needling or sewing

Abstract

The disclosure relates to an interior trim part of a motor vehicle which comprises: a shaped part made of glass or a glass-like material which is arranged on the side of the interior trim part facing the interior of the motor vehicle, a thin-film display device which as seen from the motor vehicle interior is arranged behind the shaped part or is integrated therein, and a control device for activating the thin-film display device, so that the latter transmits an image through the shaped part to the interior of the motor vehicle.

IPC Classes  ?

• B60R 1/00 - Optical viewing arrangementsReal-time viewing arrangements for drivers or passengers using optical image capturing systems, e.g. cameras or video systems specially adapted for use in or on vehicles
• B60K 35/10 - Input arrangements, i.e. from user to vehicle, associated with vehicle functions or specially adapted therefor
• B60Q 9/00 - Arrangement or adaptation of signal devices not provided for in one of main groups
• B60R 11/02 - Arrangements for holding or mounting articles, not otherwise provided for for radio sets, television sets, telephones, or the likeArrangement of controls thereof
• B60R 11/04 - Mounting of cameras operative during driveArrangement of controls thereof relative to the vehicle
• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• G06F 3/147 - Digital output to display device using display panels
• B60K 35/22 - Display screens
• B60K 35/28 - Output arrangements, i.e. from vehicle to user, associated with vehicle functions or specially adapted therefor characterised by the type of the output information, e.g. video entertainment or vehicle dynamics informationOutput arrangements, i.e. from vehicle to user, associated with vehicle functions or specially adapted therefor characterised by the purpose of the output information, e.g. for attracting the attention of the driver
• B60K 35/81 - Arrangements for controlling instruments for controlling displays
• B60R 11/00 - Arrangements for holding or mounting articles, not otherwise provided for

Abstract

A multi-value selection switch that includes an engagement surface with an integrated touch sensor. The integrated touch sensor includes a plurality of detectable positions that correspond to, for instance, a range of absolute or relative target input values between a predefined minimum and maximum. The engagement surface further defines a switch that actuates/activates based on detecting a user-supplied force and/or based on a user momentarily holding a finger/pointer position. A user can select a target input value by bringing a finger or other pointer within operable proximity of an associated detectable position and actuating the switch and/or momentarily pausing. In response, the selection switch outputs a control signal to an associated device to cause the same to adjust operation.

IPC Classes  ?

• H03K 17/96 - Touch switches
• G06F 3/01 - Input arrangements or combined input and output arrangements for interaction between user and computer
• H03K 17/945 - Proximity switches

Abstract

A cover for an airbag device disposed on a supporting portion including an exit opening for an airbag, which is covered with a cover component. The cover includes a cover layer applied to the supporting portion and the cover component, the cover layer being weakened along a weakening line in or near a hinge region of the cover component.

IPC Classes  ?

• B60R 21/2165 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components characterised by the covers for the inflatable member characterised by a tear line for defining a deployment opening
• B60R 21/215 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components characterised by the covers for the inflatable member

Abstract

Disclosed herein is a hybrid electronic/mechanical release handle for positioning on the interior of a vehicle door panel comprising a bezel cup carrier containing an electronic sensor and mechanical handle, wherein said bezel cup carrier defines an opening for insertion of one or a plurality of a user's fingers into the bezel cup where the electronic sensor is mechanically engaged to the bezel cup carrier and covered by at least a portion of the mechanical handle.

IPC Classes  ?

• E05B 81/64 - Monitoring or sensing, e.g. by using switches or sensors
• E05B 81/76 - Detection of handle operationDetection of a user approaching a handleElectrical switching actions performed by handles
• E05B 85/12 - Inner door handles
• E05B 81/90 - Manual override in case of power failure
• E05B 81/78 - Detection of handle operationDetection of a user approaching a handleElectrical switching actions performed by handles as part of a hands-free locking or unlocking operation
• E05B 1/00 - Knobs or handles for wingsKnobs, handles, or press buttons for locks or latches on wings

Abstract

A device for producing an edgefold on a component is suggested, wherein the component includes a support and a cover layer. The component may be an inner lining part of a motor vehicle, without limitation thereto. The device comprises an elastic body, which is set up to pull the cover layer over an edge of the support by deforming the elastic body.

IPC Classes  ?

• B29C 43/36 - Moulds for making articles of definite length, i.e. discrete articles
• B29C 63/16 - Lining or sheathing, i.e. applying preformed layers or sheathings of plasticsApparatus therefor using sheet or web-like material applied by "rubber" bag or diaphragm
• B29C 43/20 - Making multilayered or multicoloured articles

Abstract

An interior trim article for a motor vehicle, comprises a decorative outer skin (20); a touch-sensor (84) or proximity sensor; and a backlight lighting source (82) disposed behind said touch sensor (84) or proximity sensor to emit light through the touch-sensor (84) and through the decorative outer skin.

IPC Classes  ?

• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners

Abstract

A vehicle mini-bar comprises a housing containing one or more items therein for dispensing; an interface configured to detect and allow one or more users to access and purchase a user selected item located within said housing; one or more cameras and sensors to identify one or more items contained in said housing; one or more sensors to identify a selected user; a processor with recognition software in communication with a user device (APP) wherein said processor reports to said user device the selection and purchase by a user of said user selected item; and wherein said mini-bar includes one or more UVC light emitting diodes (LEDs) and said processor is configured to activate said one or more UVC LEDs to implement a disinfecting lighting sequence.

IPC Classes  ?

• A61L 2/10 - Ultraviolet radiation
• G07F 9/00 - Details other than those peculiar to special kinds or types of apparatus
• G07F 11/00 - Coin-freed apparatus for dispensing, or the like, discrete articles
• G07F 9/02 - Devices for alarm or indication, e.g. when emptyAdvertising arrangements in coin-freed apparatus

Abstract

A system (300) for disinfecting surfaces in a space, such as a vehicle or a building. The system (300) may include a disinfecting module having a UVC light source (204) and/or an ambient heat source for disinfecting the space. In some embodiments, an occupancy sensor (106A) is incorporated within the module (300). In some embodiments, control of the system in incorporated into the functionality of a ride-share application to facilitate disinfection of the vehicle between occupant rides.

IPC Classes  ?

• A61L 2/10 - Ultraviolet radiation
• A61L 2/24 - Apparatus using programmed or automatic operation
• F21S 4/24 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape of ribbon or tape form, e.g. LED tapes
• H05B 47/115 - Controlling the light source in response to determined parameters by determining the presence or movement of objects or living beings
• F21V 33/00 - Structural combinations of lighting devices with other articles, not otherwise provided for
• H05B 47/19 - Controlling the light source by remote control via wireless transmission
• B60N 2/00 - Seats specially adapted for vehiclesArrangement or mounting of seats in vehicles
• B60S 1/64 - Other vehicle fittings for cleaning for cleaning vehicle interiors, e.g. built-in vacuum cleaners
• A61L 2/04 - Heat
• G06K 9/00 - Methods or arrangements for reading or recognising printed or written characters or for recognising patterns, e.g. fingerprints

Abstract

An interior component of a vehicle comprises a carrier having a front face directed toward a passenger compartment of the vehicle and an opposite rear face; a speaker including an at least partially transparent diaphragm and a transducer coupled to the diaphragm. Movement of the transducer causes vibration of the diaphragm to generate sound by vibration of the diaphragm, the diaphragm having a front face directed towards the passenger compartment and an opposite rear face. The carrier provides a support along at least part of the periphery of the diaphragm where the diaphragm is attached to the carrier where the front face and the rear face of the diaphragm are free of the carrier across a part of the diaphragm surface so that the diaphragm is suspended in the carrier of the interior component.

IPC Classes  ?

• H04R 1/02 - CasingsCabinetsMountings therein
• H04R 1/34 - Arrangements for obtaining desired frequency or directional characteristics for obtaining desired directional characteristic only by using a single transducer with sound reflecting, diffracting, directing or guiding means
• H04R 7/12 - Non-planar diaphragms or cones
• H04R 17/00 - Piezoelectric transducersElectrostrictive transducers
• F21V 33/00 - Structural combinations of lighting devices with other articles, not otherwise provided for
• H04R 31/00 - Apparatus or processes specially adapted for the manufacture of transducers or diaphragms therefor
• B60R 11/02 - Arrangements for holding or mounting articles, not otherwise provided for for radio sets, television sets, telephones, or the likeArrangement of controls thereof
• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• H04R 7/18 - Mounting or tensioning of diaphragms or cones at the periphery
• H04R 7/26 - Damping by means acting directly on free portion of diaphragm or cone
• F21W 106/00 - Interior vehicle lighting devices
• B60R 11/00 - Arrangements for holding or mounting articles, not otherwise provided for

Abstract

The disclosure relates to an interior trim part for a motor vehicle, which comprises: a support component and a cover layer on a visible side of the support component, wherein the support component has an opening which is covered by the cover layer, and an insert, which is received in the opening and has a top side which is covered by the cover layer, wherein the insert receives an electrical function module or is coupled to the same, which function module is equipped in order to emit and/or receive light and/or signals through the surface of the insert and the cover layer.

IPC Classes  ?

• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• B60Q 3/80 - CircuitsControl arrangements
• B60Q 3/14 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors for dashboards lighting through the surface to be illuminated
• B60K 35/00 - Instruments specially adapted for vehiclesArrangement of instruments in or on vehicles
• B60K 37/06 - Arrangement of fittings on dashboard of controls, e.g. control knobs
• B60Q 3/54 - Lighting devices embedded in interior trim, e.g. in roof liners
• B60Q 3/74 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by the purpose for overall compartment lightingArrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by the purpose for overall compartment lighting in combination with specific lighting, e.g. room lamps with reading lamps
• B60R 11/02 - Arrangements for holding or mounting articles, not otherwise provided for for radio sets, television sets, telephones, or the likeArrangement of controls thereof

Abstract

A method for producing a laminated moulded part comprises a pressure moulding of a blank to form a moulded part in a moulding cavity between a first moulding tool unit and a second moulding tool unit, introducing of a laminating element into the moulding cavity after the pressure moulding of the blank, and a bonding of the moulded part with the laminating element in the moulding cavity.

IPC Classes  ?

• B29C 43/18 - Compression moulding, i.e. applying external pressure to flow the moulding materialApparatus therefor of articles of definite length, i.e. discrete articles incorporating preformed parts or layers, e.g. compression moulding around inserts or for coating articles
• B29C 33/42 - Moulds or coresDetails thereof or accessories therefor characterised by the shape of the moulding surface, e.g. ribs or grooves
• B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
• B29C 63/00 - Lining or sheathing, i.e. applying preformed layers or sheathings of plasticsApparatus therefor
• B29C 69/00 - Combinations of shaping techniques not provided for in a single one of main groups , e.g. associations of moulding and joining techniquesApparatus therefor
• B29C 45/00 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor
• B29L 31/30 - Vehicles, e.g. ships or aircraft, or body parts thereof

Abstract

This disclosure is generally directed to a multi-value selection switch that includes an engagement surface with an integrated touch sensor. The integrated touch sensor includes a plurality of detectable positions that correspond to, for instance, a range of absolute or relative target input values between a predefined minimum and maximum. The engagement surface further defines a switch that actuates/activates based on detecting a user-supplied force and/or based on a user momentarily holding a finger/pointer position. A user can select a target input value by bringing a finger or other pointer within operable proximity of an associated detectable position and actuating the switch and/or momentarily pausing. In response, the selection switch outputs a control signal to an associated device to cause the same to adjust operation.

IPC Classes  ?

• G06F 3/01 - Input arrangements or combined input and output arrangements for interaction between user and computer
• H01H 13/14 - Operating parts, e.g. push-button
• H01H 13/60 - Switches having rectilinearly-movable operating part or parts adapted for pushing or pulling in one direction only, e.g. push-button switch having a single operating member the contact returning to its original state upon the next application of operating force with contact-driving member moved alternately in opposite directions

Abstract

An interior component of a vehicle comprises a carrier having a front face directed toward a passenger compartment of the vehicle and an opposite rear face; a speaker including an at least partially transparent diaphragm and a transducer coupled to the diaphragm, wherein movement of the transducer causes vibration of the diaphragm to generate sound by vibration of the diaphragm, the diaphragm having a front face directed towards the passenger compartment and an opposite rear face; wherein the carrier provides a support along at least part of the periphery of the diaphragm where the diaphragm is attached to the carrier wherein the front face and the rear face of the diaphragm is free off the carrier across a part of the diaphragm surface so that the diaphragm is suspended in the carrier of the interior component.

IPC Classes  ?

• H04R 17/00 - Piezoelectric transducersElectrostrictive transducers
• H04R 7/10 - Plane diaphragms comprising a plurality of sections or layers comprising superposed layers in contact
• H04R 7/20 - Securing diaphragm or cone resiliently to support by flexible material, springs, cords, or strands
• H04R 1/02 - CasingsCabinetsMountings therein
• H04R 1/24 - Structural combinations of separate transducers or of parts of the same transducer and responsive respectively to two or more frequency ranges
• H04R 1/26 - Spatial arrangement of separate transducers responsive to two or more frequency ranges
• H04R 1/34 - Arrangements for obtaining desired frequency or directional characteristics for obtaining desired directional characteristic only by using a single transducer with sound reflecting, diffracting, directing or guiding means
• H04R 31/00 - Apparatus or processes specially adapted for the manufacture of transducers or diaphragms therefor
• G10K 11/28 - Sound-focusing or directing, e.g. scanning using reflection, e.g. parabolic reflectors
• H04R 7/12 - Non-planar diaphragms or cones
• H04R 7/14 - Non-planar diaphragms or cones corrugated, pleated, or ribbed
• H04R 1/28 - Transducer mountings or enclosures designed for specific frequency responseTransducer enclosures modified by provision of mechanical or acoustic impedances, e.g. resonator, damping means
• B60R 11/02 - Arrangements for holding or mounting articles, not otherwise provided for for radio sets, television sets, telephones, or the likeArrangement of controls thereof

Abstract

The invention relates to a vehicle control device comprising a display module with a display on a front face of the display module; a touch-sensitive layer; a transparent cover attached to the front face of the display module, wherein a front face of the transparent cover has a tactile feedback area; a haptic feedback unit configured to provide an active haptic feedback by moving or deforming the transparent cover; and a control unit configured to display a graphical user interface on the display, to receive a user input via the touch-sensitive layer and to trigger a vehicle function in response to the user input.

IPC Classes  ?

• G06F 3/01 - Input arrangements or combined input and output arrangements for interaction between user and computer

Abstract

The disclosure relates to an interior trim part of a motor vehicle which comprises: a shaped part made of glass or a glass-like material which is arranged on the side of the interior trim part facing the interior of the motor vehicle, a thin-film display device which as seen from the motor vehicle interior is arranged behind the shaped part or is integrated therein, and a control device for activating the thin-film display device, so that the latter transmits an image through the shaped part to the interior of the motor vehicle.

IPC Classes  ?

• B60R 1/00 - Optical viewing arrangementsReal-time viewing arrangements for drivers or passengers using optical image capturing systems, e.g. cameras or video systems specially adapted for use in or on vehicles
• B60K 37/06 - Arrangement of fittings on dashboard of controls, e.g. control knobs
• B60Q 9/00 - Arrangement or adaptation of signal devices not provided for in one of main groups
• B60R 11/04 - Mounting of cameras operative during driveArrangement of controls thereof relative to the vehicle
• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• B60R 11/00 - Arrangements for holding or mounting articles, not otherwise provided for
• B60R 11/02 - Arrangements for holding or mounting articles, not otherwise provided for for radio sets, television sets, telephones, or the likeArrangement of controls thereof
• G06F 3/147 - Digital output to display device using display panels

Abstract

The disclosure provides a part of a vehicle, which includes a translucent cover layer having a front surface and a back surface; a heating layer comprising a translucent and opaque heating element extending in a plane of the heating layer, the heating layer located on the back surface side of the cover layer; and a lighting module associated with the heating layer and adapted for lighting the heating layer so that at least part of the heating layer is visible at the front surface side of the cover layer.

IPC Classes  ?

• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• B60Q 3/54 - Lighting devices embedded in interior trim, e.g. in roof liners
• H05B 3/86 - Heating arrangements specially adapted for transparent or reflecting areas, e.g. for demisting or de-icing windows, mirrors or vehicle windshields the heating conductors being embedded in the transparent or reflecting material
• B60Q 3/74 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by the purpose for overall compartment lightingArrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by the purpose for overall compartment lighting in combination with specific lighting, e.g. room lamps with reading lamps
• H05B 3/20 - Heating elements having extended surface area substantially in a two-dimensional plane, e.g. plate-heater

Abstract

A method of forming a skin-foam-substrate type structure particular suitable as an automobile trim component. The method comprises supplying a polymer resin containing a chemical foaming agent and including metal particles capable of inductive heating, that is positioned between a polymeric skin and substrate, followed by inductive heating to cause foaming of the polymeric resin. The foamed polymer resin adheres to the skin and substrate.

IPC Classes  ?

• B32B 5/20 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by features of a layer containing foamed or specifically porous material foamed in situ
• B32B 27/14 - Layered products essentially comprising synthetic resin next to a particulate layer
• B32B 27/32 - Layered products essentially comprising synthetic resin comprising polyolefins
• C08J 9/228 - Forming foamed products
• C08J 9/00 - Working-up of macromolecular substances to porous or cellular articles or materialsAfter-treatment thereof
• C08J 9/08 - Working-up of macromolecular substances to porous or cellular articles or materialsAfter-treatment thereof using blowing gases generated by a previously added blowing agent by a chemical blowing agent developing carbon dioxide
• C08J 9/34 - Chemical features in the manufacture of articles consisting of a foamed macromolecular core and a macromolecular surface layer having a higher density than the core
• C08J 9/10 - Working-up of macromolecular substances to porous or cellular articles or materialsAfter-treatment thereof using blowing gases generated by a previously added blowing agent by a chemical blowing agent developing nitrogen

Abstract

A method for producing a laminated moulded part comprises a pressure moulding of a blank to form a moulded part in a moulding cavity between a first moulding tool unit and a second moulding tool unit, introducing of a laminating element into the moulding cavity after the pressure moulding of the blank, and a bonding of the moulded part with the laminating element in the moulding cavity.

IPC Classes  ?

• B29C 43/18 - Compression moulding, i.e. applying external pressure to flow the moulding materialApparatus therefor of articles of definite length, i.e. discrete articles incorporating preformed parts or layers, e.g. compression moulding around inserts or for coating articles
• B29C 63/00 - Lining or sheathing, i.e. applying preformed layers or sheathings of plasticsApparatus therefor
• B29C 69/00 - Combinations of shaping techniques not provided for in a single one of main groups , e.g. associations of moulding and joining techniquesApparatus therefor
• B29C 33/42 - Moulds or coresDetails thereof or accessories therefor characterised by the shape of the moulding surface, e.g. ribs or grooves
• B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
• B29L 31/30 - Vehicles, e.g. ships or aircraft, or body parts thereof
• B29C 45/00 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor

Abstract

An airbag arrangement comprising a flap, which closes a passage opening for an airbag, a hinge section along a side of the flap, an chute wall, which is connected to the flap via the hinge section; and a material web, which is partially arranged in the flap and partially in the chute wall, and transverses the hinge section, wherein the material web is molded into the chute wall and is anchored in the material of the chute wall.

IPC Classes  ?

• B60R 21/215 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components characterised by the covers for the inflatable member
• B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
• B60R 21/235 - Inflatable members characterised by their material
• B29L 31/30 - Vehicles, e.g. ships or aircraft, or body parts thereof
• B29C 45/00 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor
• B60R 21/16 - Inflatable occupant restraints or confinements designed to inflate upon impact or impending impact, e.g. air bags

Abstract

The disclosure relates to an interior trim part of a motor vehicle which comprises: a shaped part made of glass or a glass-like material which is arranged on the side of the interior trim part facing the interior of the motor vehicle, a thin-film display device which as seen from the motor vehicle interior is arranged behind the shaped part or is integrated therein, and a control device for activating the thin-film display device, so that the latter transmits an image through the shaped part to the interior of the motor vehicle.

IPC Classes  ?

• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• B60Q 3/14 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors for dashboards lighting through the surface to be illuminated

Abstract

The disclosure relates to an interior trim part for a motor vehicle, which comprises: a support component and a cover layer on a visible side of the support component, wherein the support component has an opening which is covered by the cover layer, and an insert, which is received in the opening and has a top side which is covered by the cover layer, wherein the insert receives an electrical function module or is coupled to the same, which function module is equipped in order to emit and/or receive light and/or signals through the surface of the insert and the cover layer.

IPC Classes  ?

• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• B60Q 3/54 - Lighting devices embedded in interior trim, e.g. in roof liners
• B60Q 3/74 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by the purpose for overall compartment lightingArrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by the purpose for overall compartment lighting in combination with specific lighting, e.g. room lamps with reading lamps
• B60R 11/02 - Arrangements for holding or mounting articles, not otherwise provided for for radio sets, television sets, telephones, or the likeArrangement of controls thereof
• B60Q 3/80 - CircuitsControl arrangements
• B60Q 3/14 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors for dashboards lighting through the surface to be illuminated
• B60K 35/00 - Instruments specially adapted for vehiclesArrangement of instruments in or on vehicles
• B60K 37/06 - Arrangement of fittings on dashboard of controls, e.g. control knobs

Abstract

Methods for forming a TPE-skinned composite include forming a skin layer having at least one surface and having a thermoplastic elastomer and an adhesive promoting agent; providing a foam layer; and forming the foam layer onto the said surface of the skin layer to form the TPE-skinned composite. Optional additives such as an organo-silane compound may be added to further improve the adhesion between the skin layer and the foam. The present disclosure also provides a TPE-skinned composite including a skin layer having a thermoplastic elastomer present in an amount of greater than 90 wt. %; and an adhesive promoting agent present in an amount of from 0.5 wt. % to 10 wt. % based upon the total weight of the skin layer.

IPC Classes  ?

• C09J 175/14 - Polyurethanes having carbon-to-carbon unsaturated bonds
• C09J 123/28 - Adhesives based on homopolymers or copolymers of unsaturated aliphatic hydrocarbons having only one carbon-to-carbon double bondAdhesives based on derivatives of such polymers modified by chemical after-treatment by reaction with halogens or halogen-containing compounds

Abstract

Methods for forming a TPE-skinned composite include forming a skin layer having at least one surface and having a thermoplastic elastomer and an adhesive promoting agent; providing a foam layer; and forming the foam layer onto the said surface of the skin layer to form the TPE-skinned composite. Optional additives such as an organo-silane compound may be added to further improve the adhesion between the skin layer and the foam. The present disclosure also provides a TPE-skinned composite including a skin layer having a thermoplastic elastomer present in an amount of greater than 90 wt. %; and an adhesive promoting agent present in an amount of from 0.5 wt. % to 10 wt. % based upon the total weight of the skin layer.

IPC Classes  ?

• C08G 18/48 - Polyethers
• B32B 5/18 - Layered products characterised by the non-homogeneity or physical structure of a layer characterised by features of a layer containing foamed or specifically porous material
• C08J 5/12 - Bonding of a preformed macromolecular material to the same or other solid material such as metal, glass, leather, e.g. using adhesives
• C09J 175/04 - Polyurethanes
• C08G 18/42 - Polycondensates having carboxylic or carbonic ester groups in the main chain
• C09J 5/02 - Adhesive processes in generalAdhesive processes not provided for elsewhere, e.g. relating to primers involving pretreatment of the surfaces to be joined
• C08G 101/00 - Manufacture of cellular products

Abstract

A fastening system comprising a second fastener fastened to a first fastener; the first fastener comprising a hollow housing having a side-wall and a top-wall; a first aperture formed in the side-wall and in the top-wall of the hollow housing, the first aperture configured for entry of the second fastener during fastening of the second fastener and first fastener; a second aperture formed in the side-wall of the hollow housing; a beam formed in the side-wall between the first aperture and the second aperture, the beam attached at opposing ends to the side-wall; the beam blocks the first aperture to inhibit separation of the second fastener from the first fastener through the first aperture; and the beam is configured to be deformed during fastening of the second fastener to the first fastener.

IPC Classes  ?

• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• F16B 5/12 - Fastening strips or bars to sheets or plates, e.g. rubber strips, decorative strips for motor vehicles, by means of clips
• A01K 1/00 - Housing animalsEquipment therefor
• A47G 33/04 - Christmas trees
• B60R 13/00 - Elements for body-finishing, identifying, or decoratingArrangements or adaptations for advertising purposes
• F16B 13/02 - Dowels or other devices fastened in walls or the like by inserting them in holes made therein for that purpose in one piece with protrusions or ridges on the shaft
• F16B 5/06 - Joining sheets or plates to one another or to strips or bars parallel to them by means of clamps or clips
• F16B 21/07 - Releasable fastening devices with snap action in which the socket has a resilient part

Abstract

A method for producing a lined molded article involves compression-molding a blank into a molded article in a mold cavity between a first mold unit and a second mold unit, introducing a lining element into the mold cavity once the blank has been compression-molded, and joining the molded article to the lining element in the mold cavity.

IPC Classes  ?

• B29C 43/18 - Compression moulding, i.e. applying external pressure to flow the moulding materialApparatus therefor of articles of definite length, i.e. discrete articles incorporating preformed parts or layers, e.g. compression moulding around inserts or for coating articles
• B29C 69/00 - Combinations of shaping techniques not provided for in a single one of main groups , e.g. associations of moulding and joining techniquesApparatus therefor
• B29C 63/00 - Lining or sheathing, i.e. applying preformed layers or sheathings of plasticsApparatus therefor
• B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
• B29C 33/42 - Moulds or coresDetails thereof or accessories therefor characterised by the shape of the moulding surface, e.g. ribs or grooves
• B29L 31/30 - Vehicles, e.g. ships or aircraft, or body parts thereof

Abstract

A method of forming a decorative article comprising placing a decorative cover sheet comprising an untextured skin layer, a cushion foam layer and an adhesive layer in a mold space between a front mold half and a rear mold half, placing a substrate on the rear mold half, heating a textured front mold surface and the skin layer with a first heater arrangement between the front mold half and the cover sheet, heating the cover sheet and the substrate with a second heater arrangement between the cover sheet and the rear mold half, forming the skin layer of the decorative cover sheet into contact with the textured front mold surface, forming into the skin layer a textured surface from the textured front mold surface, pressing the substrate against the adhesive layer of the decorative cover sheet, and bonding the cover sheet to the substrate with the adhesive layer.

IPC Classes  ?

• B29B 13/02 - Conditioning or physical treatment of the material to be shaped by heating
• B29C 43/18 - Compression moulding, i.e. applying external pressure to flow the moulding materialApparatus therefor of articles of definite length, i.e. discrete articles incorporating preformed parts or layers, e.g. compression moulding around inserts or for coating articles
• B29C 69/00 - Combinations of shaping techniques not provided for in a single one of main groups , e.g. associations of moulding and joining techniquesApparatus therefor
• B29L 9/00 - Layered products
• B29C 63/02 - Lining or sheathing, i.e. applying preformed layers or sheathings of plasticsApparatus therefor using sheet or web-like material
• B29L 31/30 - Vehicles, e.g. ships or aircraft, or body parts thereof
• B29C 43/20 - Making multilayered or multicoloured articles
• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners

Abstract

This disclosure pertains to a composite fiber mat for producing a support plate for a motor vehicle component, wherein at least a first subarea of the composite fiber mat is provided with at least one reinforcing seam.

IPC Classes  ?

• B29C 43/02 - Compression moulding, i.e. applying external pressure to flow the moulding materialApparatus therefor of articles of definite length, i.e. discrete articles
• D05B 17/00 - Sewing machines for concurrently making thread and welded seams
• B62D 29/04 - Superstructures characterised by material thereof predominantly of synthetic material
• D04H 1/54 - Non-woven fabrics formed wholly or mainly of staple fibres or like relatively short fibres from fleeces or layers composed of fibres without existing or potential cohesive properties by welding together the fibres, e.g. by partially melting or dissolving
• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• B60R 13/08 - Insulating elements, e.g. for sound insulation
• B29C 43/52 - Heating or cooling
• D04H 1/00 - Non-woven fabrics formed wholly or mainly of staple fibres or like relatively short fibres
• D04H 1/52 - Non-woven fabrics formed wholly or mainly of staple fibres or like relatively short fibres from fleeces or layers composed of fibres without existing or potential cohesive properties the fleeces or layers being consolidated by mechanical means, e.g. by rolling by applying or inserting filamentary binding elements
• D04H 1/558 - Non-woven fabrics formed wholly or mainly of staple fibres or like relatively short fibres from fleeces or layers composed of fibres without existing or potential cohesive properties by welding together the fibres, e.g. by partially melting or dissolving in combination with mechanical or physical treatments other than embossing
• B29C 43/18 - Compression moulding, i.e. applying external pressure to flow the moulding materialApparatus therefor of articles of definite length, i.e. discrete articles incorporating preformed parts or layers, e.g. compression moulding around inserts or for coating articles
• B29C 70/00 - Shaping composites, i.e. plastics material comprising reinforcements, fillers or preformed parts, e.g. inserts
• B29K 105/08 - Condition, form or state of moulded material containing reinforcements, fillers or inserts of continuous length, e.g. cords, rovings, mats, fabrics, strands or yarns
• B29K 221/00 - Use of unspecified rubbers as reinforcement
• B29L 31/30 - Vehicles, e.g. ships or aircraft, or body parts thereof

Abstract

This disclosure relates to a method of manufacturing a cover material for a molded part of a motor vehicle and to a respective cover material. The method includes the following: providing a cover skin which is provided with a seam or perforation and comprises a face and a back; and applying a back layer to the back of the cover skin, wherein, prior to applying the back layer, the seam or perforation is sealed on the back of the cover skin by applying a liquid, gelatinous or paste-like sealing material to the back of the cover skin above the seam or perforation.

IPC Classes  ?

• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• B05D 7/24 - Processes, other than flocking, specially adapted for applying liquids or other fluent materials to particular surfaces or for applying particular liquids or other fluent materials for applying particular liquids or other fluent materials

Abstract

The invention relates to an interior trim element for a motor vehicle which comprises: a translucent carrier component with a front side and a rear side, a translucent cover material on the front side of the carrier component and a light source on the rear side of the carrier component, wherein the translucent cover material has a Shore A hardness in the range between 60 and 80, wherein the interior trim element comprises at least one surface of a storage tray or storage compartment of the motor vehicle which is visible to passengers of the motor vehicle, and wherein the light source illuminates the visible surface of the storage tray or storage compartment.

IPC Classes  ?

• B60Q 3/54 - Lighting devices embedded in interior trim, e.g. in roof liners
• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners

Abstract

1). The first portion of the mesh member has a non-planar cross-section by the mesh member being molded into a portion of the at least one rib, such that the mesh member traverses the at least one rib. The disclosure further relates to a mesh member for use in an airbag cover, a vehicle interior panel, e.g. a vehicle interior panel for a dashboard, and a method for making an airbag cover.

IPC Classes  ?

• B60R 21/216 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components characterised by the covers for the inflatable member comprising tether means for limitation of cover motion during deployment
• B60R 21/205 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components in dashboards
• B60R 21/2165 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components characterised by the covers for the inflatable member characterised by a tear line for defining a deployment opening
• B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
• B60R 21/215 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components characterised by the covers for the inflatable member
• B29K 101/12 - Thermoplastic materials
• B29K 105/00 - Condition, form or state of moulded material
• B29L 31/30 - Vehicles, e.g. ships or aircraft, or body parts thereof
• B29K 105/20 - Inserts
• B29C 43/02 - Compression moulding, i.e. applying external pressure to flow the moulding materialApparatus therefor of articles of definite length, i.e. discrete articles

Abstract

A method of forming a blow molded plastic article wherein the article comprises an airflow conduit, comprising: providing a first sheet of insulation material located on a insulation carrier; providing a blow molding mold including two halves and having a molding surface defining a molding cavity to form the article; locating the insulation carrier between the two halves of the blow molding mold; transferring the first sheet of insulation material from the insulation carrier to the blow molding mold; introducing an extrudate of thermoplastic composition between the two halves of the blow molding mold; closing the blow molding mold; forming the extrudate to a shape of the mold cavity of the blow molding mold to form the article; and bonding the extrudate to the first sheet of insulation material as the extrudate is being formed to the shape of the mold cavity.

IPC Classes  ?

• B29C 49/20 - Blow-moulding, i.e. blowing a preform or parison to a desired shape within a mouldApparatus therefor of articles having inserts or reinforcements
• B29C 49/42 - Component parts, details or accessoriesAuxiliary operations
• B29C 49/04 - Extrusion blow-moulding
• B29K 101/12 - Thermoplastic materials
• B29K 675/00 - Use of polyureas or polyurethanes for preformed parts, e.g. for inserts
• B29L 9/00 - Layered products
• B29C 49/24 - Lining or labelling
• B29L 23/00 - Tubular articles
• B29K 105/04 - Condition, form or state of moulded material cellular or porous
• B29C 49/48 - Moulds
• B29C 49/60 - Blow-needles
• B29C 51/08 - Deep-drawing or matched-mould forming, i.e. using mechanical means only
• B29C 51/36 - Moulds specially adapted for vacuum forming

Goods & Services

Surface coatings of plastic and PVC for vehicles. Manufacture of vehicle parts and accessories for others; prototype fabrication for others; injection molding of plastic for others; all of the aforesaid services relating to vehicles.

Abstract

A method of providing interior trim for a motor vehicle comprising forming a first interior trim article providing a first interior trim level, wherein the first article comprises a first article decorative covering overlying a first article cushion member and a first article substrate; and forming a second interior trim article having a base structure comprising the first interior trim article; wherein the second interior trim article provides a second interior trim level different from the first interior trim level; wherein the second interior trim article comprises a second article decorative covering and a second article cushion member overlying the base structure; wherein the first article decorative covering includes an elongated channel; wherein the second article decorative covering comprises a plurality of decorative covering segments joined at a joining seam; and wherein the joining seam is located in the elongated channel.

IPC Classes  ?

• B29C 65/70 - Joining of preformed partsApparatus therefor by moulding
• B29C 65/00 - Joining of preformed partsApparatus therefor
• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• B29C 44/12 - Incorporating or moulding on preformed parts, e.g. inserts or reinforcements
• B29K 101/12 - Thermoplastic materials
• B29L 31/30 - Vehicles, e.g. ships or aircraft, or body parts thereof
• B29K 101/10 - Thermosetting resins
• B29K 711/08 - Leather
• B29K 75/00 - Use of polyureas or polyurethanes as moulding material

Goods & Services

Interior trim for vehicles; interior panels for vehicles; fitted dashboard covers for vehicles; fitted liners for the cargo area of vehicles; cargo storage bins for vehicles;  plastic parts for vehicles, namely automotive decorative and protective trim; upholstery for vehicles. Surface coatings of plastic and PVC. Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles. Manufacture of vehicle parts and accessories for others; prototype fabrication for others; injection molding of plastic for others.

Goods & Services

Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles Manufacture of vehicle parts and accessories to the order and specification of others; prototype fabrication of new products for others; injection molding of plastic for others Interior trim for automotive vehicles; interior panels for automotive vehicles; fitted dashboard covers for vehicles; fitted liners for the cargo area of vehicles; cargo storage bins especially adapted for use in motor vehicles; plastic parts for vehicles, namely automotive decorative and protective trim; upholstery for vehicles

Abstract

The invention relates to a molding device for producing molded parts by means of a rotational molding process. The molding device comprises a molding shell which has a product region for molding the part to be molded, a flange which lies outside of the product region for fixing the molding shell on a frame, and a transition region between the product region and the flange region. At least one relief slot is formed in the transition region, wherein multiple relief slots can be distributed over the circumference of the product region.

IPC Classes  ?

• B29C 41/18 - Slush casting, i.e. pouring moulding material into a hollow mould with excess material being poured off
• B29C 41/38 - Moulds, cores or other substrates

Goods & Services

Interior trim for vehicles; interior panels for vehicles; fitted dashboard covers for vehicles; fitted liners for the cargo area of vehicles; cargo storage bins for vehicles;  plastic parts for vehicles, namely automotive decorative and protective trim; upholstery for vehicles. Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles. Manufacture of vehicle parts and accessories for others; prototype fabrication for others; injection molding of plastic for others.

Goods & Services

Interior trim for vehicles; interior panels for vehicles; fitted dashboard covers for vehicles; fitted liners for the cargo area of vehicles; cargo storage bins for vehicles;  plastic parts for vehicles, namely automotive decorative and protective trim; upholstery for vehicles. Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles. Manufacture of vehicle parts and accessories for others; prototype fabrication for others; injection molding of plastic for others.

Goods & Services

Interior trim for vehicles; interior panels for vehicles; fitted dashboard covers for vehicles; fitted liners for the cargo area of vehicles; cargo storage bins for vehicles;  plastic parts for vehicles, namely automotive decorative and protective trim; upholstery for vehicles. Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles. Manufacture of vehicle parts and accessories for others; prototype fabrication for others; injection molding of plastic for others.

Goods & Services

Interior trim for vehicles; interior panels for vehicles; fitted dashboard covers for vehicles; fitted liners for the cargo area of vehicles; cargo storage bins for vehicles;  plastic parts for vehicles, namely automotive decorative and protective trim; upholstery for vehicles. Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles. Manufacture of vehicle parts and accessories for others; prototype fabrication for others; injection molding of plastic for others.

Abstract

A component of a motor vehicle comprising a photoluminescent interior member formed of a plastic composition, wherein the plastic composition comprises at least one polymer and a plurality of additives comprising at least one photoluminescent material and at least a first ultraviolet protector, wherein the at least one photoluminescent material absorbs electromagnetic radiation in a first ultraviolet range of an electromagnetic spectrum, and thereafter emits electromagnetic radiation in a visible radiation range of the electromagnetic spectrum, and wherein the first ultraviolet protector is an ultraviolet absorber, wherein the ultraviolet absorber absorbs electromagnetic radiation in a second ultraviolet range of the electromagnetic spectrum and does not absorb electromagnetic radiation in the first ultraviolet range of the electromagnetic spectrum.

IPC Classes  ?

• F21V 9/16 - Selection of luminescent materials for light screens
• G01J 1/58 - Photometry, e.g. photographic exposure meter using luminescence generated by light
• G01T 1/10 - Luminescent dosimeters
• G21H 3/02 - Arrangements for direct conversion of radiation energy from radioactive sources into forms of energy other than electric energy, e.g. light in which material is excited to luminesce by the radiation
• G21K 5/00 - Irradiation devices
• H01J 65/06 - Lamps in which a gas filling is excited to luminesce by radioactive material structurally associated with the lamp, e.g. inside the vessel
• H01J 65/08 - Lamps in which a screen or coating is excited to luminesce by radioactive material located inside the vessel
• B60Q 3/00 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors
• B60Q 3/02 - Arrangement of lighting devices for vehicle interior, the mounting or supporting thereof or circuits therefor for lighting passenger or driving compartment
• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• F21K 2/00 - Non-electric light sources using luminescenceLight sources using electrochemiluminescence
• C09K 11/02 - Use of particular materials as binders, particle coatings or suspension media therefor

Abstract

The invention relates to an interior trim component for a motor vehicle, which comprises: a carrier component, which determines the contour of the interior trim component, a cover layer, which is applied to a front side of the carrier component, and a light-emitting layer, which is applied to a back side of the carrier component, wherein the carrier component and the cover layer are transparent.

IPC Classes  ?

• B60Q 3/54 - Lighting devices embedded in interior trim, e.g. in roof liners
• B60Q 3/62 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by optical aspects using light guides
• B60Q 3/64 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by optical aspects using light guides for a single lighting device
• B60Q 3/20 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors for lighting specific fittings of passenger or driving compartmentsArrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors mounted on specific fittings of passenger or driving compartments
• B60Q 3/217 - Doors, e.g. door sillsSteps
• B60Q 3/233 - SeatsArm restsHead rests
• B60Q 3/74 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by the purpose for overall compartment lightingArrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by the purpose for overall compartment lighting in combination with specific lighting, e.g. room lamps with reading lamps
• B60Q 3/76 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors characterised by the purpose for spotlighting, e.g. reading lamps
• B60Q 3/14 - Arrangement of lighting devices for vehicle interiorsLighting devices specially adapted for vehicle interiors for dashboards lighting through the surface to be illuminated

Abstract

The invention proposes a device for manufacture of a composite piece, which exhibits a shaped plate and at least one plastic functional piece molded on to the shaped plate. The device has a heater for heating a plate blank; a shaping tool with at least two shaping elements and for admitting and shaping of the plate blank, to bring the plate blank into a desired shape and thus to manufacture the shaped plate; means for insertion of a shaped mass into the shaping tool for molding the plastic functional piece onto the shaped plate in the shaping tool to manufacture the composite piece, wherein the shaping tool is so configured that after the shaping of the plate blank, at least one cavity remains, in which the plastic functional piece is shaped; and a closing unit for opening and closing the shaping tool; wherein the heater is integrated into the closing unit and the closing unit is furnished to open and close the heater.

IPC Classes  ?

• B29C 45/16 - Making multilayered or multicoloured articles
• B29C 51/42 - Heating or cooling
• B29C 45/14 - Injection moulding, i.e. forcing the required volume of moulding material through a nozzle into a closed mouldApparatus therefor incorporating preformed parts or layers, e.g. injection moulding around inserts or for coating articles
• B29C 51/08 - Deep-drawing or matched-mould forming, i.e. using mechanical means only
• B29C 51/26 - Component parts, details or accessoriesAuxiliary operations

Abstract

The invention relates to an interior trim part, in particular for a motor vehicle, comprising a base component, a decorative layer made of leather or a leather-like material, and a spacing layer between the base component and the decorative layer, the spacing layer being made of a material that is softer than the material of the base component. The base component, the decorative layer and the spacing layer each have a localized area of weakened material, which allows the interior trim part to break away in a controlled manner when a predefined amount of force is applied to the base component, wherein, at least in the area of weakened material, an intermediate layer lies between the decorative layer and the spacing layer, which intermediate layer does not have a localized weakened area. The invention further provides a method for producing the interior trim part.

IPC Classes  ?

• B60R 21/215 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components characterised by the covers for the inflatable member
• B60R 21/2165 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components characterised by the covers for the inflatable member characterised by a tear line for defining a deployment opening
• B32B 7/00 - Layered products characterised by the relation between layers Layered products characterised by the relative orientation of features between layers, or by the relative values of a measurable parameter between layers, i.e. products comprising layers having different physical, chemical or physicochemical properties Layered products characterised by the interconnection of layers
• B26D 3/00 - Cutting work characterised by the nature of the cut madeApparatus therefor
• C14B 1/00 - Manufacture of leatherMachines or devices therefor
• B26D 3/08 - Making a superficial cut in the surface of the work without removal of material, e.g. scoring, incising
• B26F 1/00 - PerforatingPunchingCutting-outStamping-outApparatus therefor

Abstract

The invention relates to an interior lining for a motor vehicle, with a sliding or panoramic roof, which comprises a roof liner and a stiffening frame which is attached to the roof liner, and an opening in the roof liner, which delimits, frames and stabilizes the sliding or panoramic window. The roof liner is constructed in several layers, which comprise at least one core layer and one cover layer. The stiffening frame is produced from a fiber-reinforced composite material, which contains organic synthetic polymer fibers, carbon fibers or natural fibers, or mixtures of these fibers, and a binder made from a duroplastic or thermoplastic material. The surface weight and the bending stiffness of the stiffening frame are greater than those of the roof liner structure, preferably by at least 50%.

IPC Classes  ?

• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners

Goods & Services

Automotive decorative and protective trim.

Goods & Services

Interior trim for vehicles; interior panels for vehicles; fitted dashboard covers for vehicles; fitted liners for the cargo area of vehicles; cargo storage bins for vehicles; semi-finished injection molded products of plastic for use in vehicles, namely fluid recovery bottles, washer fluid bottles, HVAC ducts; plastic parts for vehicles, namely automotive decorative and protective trim; Upholstery for vehicles. Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles . Manufacture of vehicle parts and accessories for others; prototype fabrication for others; injection molding of plastic for others.

Abstract

The present disclosure relates to the production of molded products containing recycled content, and more particularly polyurethane foam which includes polyol recovered from chemical recycling of polyurethane foam scrap, which polyol has been treated to optimize viscosity and/or reactivity characteristics.

IPC Classes  ?

• C08J 11/04 - Recovery or working-up of waste materials of polymers

Abstract

An airbag cover with a support component and a top-cover component, wherein the support component and the top-cover component are covered up with a covering material. A predetermined breakage line is formed between the support component and the top-cover component, which defines at least one serration or one undulation at the edge of the top-cover component, and the covering material exhibits a structural weakening, wherein the contour of the structural weakening is congruent with the contour of the breakage line at least in the area of the serration or the undulation. The breakage line between the support component and the top-cover component and the structural weakening of the covering material are formed at least in the area of the serration or the undulation by means of one or a plurality of cuts, which fully penetrate the support component and partially penetrate the covering material.

IPC Classes  ?

• B60R 21/20 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components

Abstract

The present invention relates to a molded part, in particular, to an interior panel component for a motor vehicle, having a core layer comprising a mixture of natural or synthetic fibers and thermoplastic binding fibers, which are processed to form a nonwoven, and a thermoplastic cover layer, the core layer and the cover layer being fused together and the cover layer being such that the molded part has a visible surface, which is terminated by the cover layer, the visual appearance of the visible surface being at least shaped by the fibers of the core layer. The present invention furthermore relates to the manufacturing of a molded part in which the nonwoven of the core layer is warmed and pre-compressed in a contact heater, and the compressed nonwoven, together with the cover layer is introduced into a mold and recast.

IPC Classes  ?

• B32B 27/00 - Layered products essentially comprising synthetic resin
• B29C 51/14 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor using multilayered preforms or sheets
• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners
• B29C 51/00 - Shaping by thermoforming, e.g. shaping sheets in matched moulds or by deep-drawingApparatus therefor
• B29C 51/08 - Deep-drawing or matched-mould forming, i.e. using mechanical means only

Abstract

A trim means for a motor vehicle comprises a carrier having a B side and a C side. A recess is formed into the B side of the carrier, and the carrier has an aperture in the region at the edge of the recess. A planar lighting unit comes to lie flush in the recess on the B side of the carrier, so that on the B side of the carrier a substantially continuous planar surface of the carrier with the lighting unit is produced. The lighting unit has a connection cable which is guided through the aperture to the C side of the carrier, where it is connected with a plug connector, a further conductor or directly with a control unit. A cover layer is applied onto the B side of the carrier and covers the planar lighting unit and at least a portion of the surface of the carrier. The cover layer forms the visible side of the trim means and is permeable to the light emitted from the lighting unit.

IPC Classes  ?

• F21V 33/00 - Structural combinations of lighting devices with other articles, not otherwise provided for

Goods & Services

Interior trim for vehicles; interior panels for vehicles; fitted dashboard covers for vehicles; fitted liners for the cargo area of vehicles; cargo storage bins for vehicles; semi-finished injection molded products of plastic for use in vehicles, namely fluid recovery bottles, washer fluid bottles, HVAC ducts; plastic parts for vehicles, namely automotive decorative and protective trim; upholstery for vehicles. Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles. Manufacture of vehicle parts and accessories for others; prototype fabrication for others; injection molding of plastic for others.

Goods & Services

Interior trim for vehicles; interior panels for vehicles; fitted dashboard covers for vehicles; fitted liners for the cargo area of vehicles; cargo storage bins for vehicles; semi-finished injection molded products of plastic for use in vehicles, namely fluid recovery bottles, washer fluid bottles, HVAC ducts; plastic parts for vehicles, namely automotive decorative and protective trim; Upholstery for vehicles. Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles. Manufacture of vehicle parts and accessories for others; prototype fabrication for others; injection molding of plastic for others.

Goods & Services

Interior trim for vehicles; interior panels for vehicles; fitted dashboard covers for vehicles; fitted liners for the cargo area of vehicles; cargo storage bins for vehicles; semi-finished injection molded products of plastic for use in vehicles, namely fluid recovery bottles, washer fluid bottles, HVAC ducts; plastic parts for vehicles, namely automotive decorative and protective trim; upholstery for vehicles. Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles. Manufacture of vehicle parts and accessories for others; prototype fabrication for others; injection molding of plastic for others.

Goods & Services

(1) Interior trim for vehicles, namely, automobiles; interior panels for vehicles, namely, automobiles; fitted dashboard covers for vehicles, namely, automobiles; fitted liners for the cargo area of vehicles, namely, automobiles; cargo storage bins for vehicles, namely, automobiles; semi-finished injection molded products of plastic for use in vehicles, namely, automobiles, namely fluid recovery bottles, washer fluid bottles, HVAC ducts; plastic parts for vehicles, namely, automobiles, namely automotive decorative and protective trim. (2) Interior trim for vehicles, namely, automobiles; interior panels for vehicles, namely, automobiles; fitted dashboard covers for vehicles, namely, automobiles; fitted liners for the cargo area of vehicles, namely, automobiles; cargo storage bins for vehicles, namely, automobiles; semi-finished injection molded products of plastic for use in vehicles, namely, automobiles, namely fluid recovery bottles, washer fluid bottles, HVAC ducts; plastic parts for vehicles, namely, automobiles, namely automotive decorative and protective trim. (3) Upholstery for vehicles. (4) Upholstery for vehicles. (5) Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles, namely, automobiles. (6) Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles, namely, automobiles. (1) Manufacture of automobile parts and accessories for other, namely interior trim, interior panels, fitted dashboard covers, fitted liners for cargo areas, cargo storage bins, fluid recovery bottles, washer fluid bottles, HVAC ducts, decorative and protective trim; prototype fabrication for others of automobile parts and accessories for others; injection molding for others of plastic automobile parts and accessories; technical consultancy, inspection and testing services in the field of machined parts for automobiles; design services for others in the field of the fabrication and assembly of machined parts for automobiles. (2) Manufacture of automobile parts and accessories for other, namely interior trim, interior panels, fitted dashboard covers, fitted liners for cargo areas, cargo storage bins, fluid recovery bottles, washer fluid bottles, HVAC ducts, decorative and protective trim; prototype fabrication for others of automobile parts and accessories for others; injection molding for others of plastic automobile parts and accessories; technical consultancy, inspection and testing services in the field of machined parts for automobiles; design services for others in the field of the fabrication and assembly of machined parts for automobiles.

Goods & Services

INTERIOR TRIM FOR VEHICLES, NAMELY, DECORATIVE AND PROTECTIVE TRIM PIECES; INTERIOR PANELS FOR VEHICLES, NAMELY, DOOR PANELS, OVERHEAD PANELS, BODY PANELS, DASHBOARD PANELS, INSTRUMENT PANELS AND FLOORING PANELS; FITTED DASHBOARD COVERS FOR VEHICLES; FITTED LINERS FOR THE CARGO AREA OF VEHICLES; CARGO STORAGE BINS SPECIALLY ADAPTED FOR USE IN MOTOR VEHICLES; SEMI-FINISHED INJECTION MOLDED PRODUCTS OF PLASTIC FOR USE IN VEHICLES, namely, FLUID RECOVERY BOTTLES, WASHER FLUID BOTTLES, HVAC DUCTS; PLASTIC PARTS FOR VEHICLES, namely, AUTOMOTIVE DECORATIVE AND PROTECTIVE TRIM; UPHOLSTERY FOR VEHICLES RUBBER MATS, CARPETS, FLOOR MATS, FLOOR COVERINGS, BACKING LAYERS FOR FLOOR MATS, ALL OF THE FORGOING FOR VEHICLES MANUFACTURE OF VEHICLE PARTS AND ACCESSORIES FOR OTHERS; PROTOTYPE FABRICATION OF NEW PRODUCTS AND AUTOMOTIVE PARTS AND ACCESSORIES FOR OTHERS; INJECTION MOLDING OF PLASTIC FOR OTHERS; TECHNICAL CONSULTANCY IN THE NATURE OF PROVIDING ADVICE ABOUT HOW TO MANUFACTURE MACHINED GOODS

Goods & Services

INTERIOR TRIM FOR VEHICLES, NAMELY, DECORATIVE AND PROTECTIVE TRIM PIECES; INTERIOR PANELS FOR VEHICLES, NAMELY, DOOR PANELS, OVERHEAD PANELS, BODY PANELS, DASHBOARD PANELS, INSTRUMENT PANELS AND FLOORING PANELS; FITTED DASHBOARD COVERS FOR VEHICLES; FITTED LINERS FOR THE CARGO AREA OF VEHICLES; CARGO STORAGE BINS SPECIALLY ADAPTED FOR USE IN MOTOR VEHICLES; SEMI-FINISHED INJECTION MOLDED PRODUCTS OF PLASTIC FOR USE IN VEHICLES, NAMELY, FLUID RECOVERY BOTTLES, WASHER FLUID BOTTLES, HVAC DUCTS; PLASTIC PARTS FOR VEHICLES, NAMELY, AUTOMOTIVE DECORATIVE AND PROTECTIVE TRIM; UPHOLSTERY FOR VEHICLES [ RUBBER MATS, CARPETS, FLOOR MATS, FLOOR COVERINGS, BACKING LAYERS FOR FLOOR MATS, ALL OF THE FORGOING FOR VEHICLES ] MANUFACTURE OF VEHICLE PARTS AND ACCESSORIES FOR OTHERS; PROTOTYPE FABRICATION OF NEW PRODUCTS AND AUTOMOTIVE PARTS AND ACCESSORIES FOR OTHERS; INJECTION MOLDING OF PLASTIC FOR OTHERS; TECHNICAL CONSULTANCY IN THE NATURE OF PROVIDING ADVICE ABOUT HOW TO MANUFACTURE MACHINED GOODS

Goods & Services

INTERIOR TRIM FOR VEHICLES, NAMELY, DECORATIVE AND PROTECTIVE TRIM PIECES; INTERIOR PANELS FOR VEHICLES, NAMELY, DOOR PANELS, OVERHEAD PANELS, BODY PANELS, DASHBOARD PANELS, INSTRUMENT PANELS AND FLOORING PANELS; FITTED DASHBOARD COVERS FOR VEHICLES; FITTED LINERS FOR THE CARGO AREA OF VEHICLES; CARGO STORAGE BINS SPECIALLY ADAPTED FOR USE IN MOTOR VEHICLES; SEMI-FINISHED INJECTION MOLDED PRODUCTS OF PLASTIC FOR USE IN VEHICLES, NAMELY, FLUID RECOVERY BOTTLES, WASHER FLUID BOTTLES, HVAC DUCTS; PLASTIC PARTS FOR VEHICLES, NAMELY, AUTOMOTIVE DECORATIVE AND PROTECTIVE TRIM; UPHOLSTERY FOR VEHICLES RUBBER MATS, CARPETS, FLOOR MATS, FLOOR COVERINGS, BACKING LAYERS FOR FLOOR MATS, ALL OF THE FORGOING FOR VEHICLES MANUFACTURE OF VEHICLE PARTS AND ACCESSORIES FOR OTHERS; PROTOTYPE FABRICATION OF NEW PRODUCTS AND AUTOMOTIVE PARTS AND ACCESSORIES FOR OTHERS; INJECTION MOLDING OF PLASTIC FOR OTHERS; TECHNICAL CONSULTANCY IN THE NATURE OF PROVIDING ADVICE ABOUT HOW TO MANUFACTURE MACHINED GOODS

Goods & Services

(1) Interior trim for vehicles, namely, automobiles; interior panels for vehicles, namely, automobiles; fitted dashboard covers for vehicles, namely, automobiles; fitted liners for the cargo area of vehicles, namely, automobiles; cargo storage bins for vehicles, namely, automobiles; semi-finished injection molded products of plastic for use in vehicles, namely, automobiles, namely fluid recovery bottles, washer fluid bottles, HVAC ducts; plastic parts for vehicles, namely, automobiles, namely automotive decorative and protective trim. (2) Interior trim for vehicles, namely, automobiles; interior panels for vehicles, namely, automobiles; fitted dashboard covers for vehicles, namely, automobiles; fitted liners for the cargo area of vehicles, namely, automobiles; cargo storage bins for vehicles, namely, automobiles; semi-finished injection molded products of plastic for use in vehicles, namely, automobiles, namely fluid recovery bottles, washer fluid bottles, HVAC ducts; plastic parts for vehicles, namely, automobiles, namely automotive decorative and protective trim. (3) Upholstery for vehicles. (4) Upholstery for vehicles. (5) Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles, namely, automobiles. (6) Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles, namely, automobiles. (1) Manufacture of automobile parts and accessories for other, namely interior trim, interior panels, fitted dashboard covers, fitted liners for cargo areas, cargo storage bins, fluid recovery bottles, washer fluid bottles, HVAC ducts, decorative and protective trim; prototype fabrication for others of automobile parts and accessories for others; injection molding for others of plastic automobile parts and accessories; technical consultancy, inspection and testing services in the field of machined parts for automobiles; design services for others in the field of the fabrication and assembly of machined parts for automobiles. (2) Manufacture of automobile parts and accessories for other, namely interior trim, interior panels, fitted dashboard covers, fitted liners for cargo areas, cargo storage bins, fluid recovery bottles, washer fluid bottles, HVAC ducts, decorative and protective trim; prototype fabrication for others of automobile parts and accessories for others; injection molding for others of plastic automobile parts and accessories; technical consultancy, inspection and testing services in the field of machined parts for automobiles; design services for others in the field of the fabrication and assembly of machined parts for automobiles.

Goods & Services

(1) Interior trim for vehicles, namely, automobiles; interior panels for vehicles, namely, automobiles; fitted dashboard covers for vehicles, namely, automobiles; fitted liners for the cargo area of vehicles, namely, automobiles; cargo storage bins for vehicles, namely, automobiles; semi-finished injection molded products of plastic for use in vehicles, namely, automobiles, namely fluid recovery bottles, washer fluid bottles, HVAC ducts; plastic parts for vehicles, namely, automobiles, namely automotive decorative and protective trim. (2) Upholstery for vehicles. (3) Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles, namely, automobiles. (1) Manufacture of automobile parts and accessories for other, namely interior trim, interior panels, fitted dashboard covers, fitted liners for cargo areas, cargo storage bins, fluid recovery bottles, washer fluid bottles, HVAC ducts, decorative and protective trim; prototype fabrication for others of automobile parts and accessories for others; injection molding for others of plastic automobile parts and accessories; technical consultancy, inspection and testing services in the field of machined parts for automobiles; design services for others in the field of the fabrication and assembly of machined parts for automobiles.

Goods & Services

(1) Interior trim for vehicles, namely, automobiles; interior panels for vehicles, namely, automobiles; fitted dashboard covers for vehicles, namely, automobiles; fitted liners for the cargo area of vehicles, namely, automobiles; cargo storage bins for vehicles, namely, automobiles; semi-finished injection molded products of plastic for use in vehicles, namely, automobiles, namely fluid recovery bottles, washer fluid bottles, HVAC ducts; plastic parts for vehicles, namely, automobiles, namely automotive decorative and protective trim. (2) Interior trim for vehicles, namely, automobiles; interior panels for vehicles, namely, automobiles; fitted dashboard covers for vehicles, namely, automobiles; fitted liners for the cargo area of vehicles, namely, automobiles; cargo storage bins for vehicles, namely, automobiles; semi-finished injection molded products of plastic for use in vehicles, namely, automobiles, namely fluid recovery bottles, washer fluid bottles, HVAC ducts; plastic parts for vehicles, namely, automobiles, namely automotive decorative and protective trim. (3) Upholstery for vehicles. (4) Upholstery for vehicles. (5) Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles, namely, automobiles. (6) Rubber mats, carpets, floor mats, floor coverings, backing layers for floor mats, all of the forgoing for vehicles, namely, automobiles. (1) Manufacture of automobile parts and accessories for other, namely interior trim, interior panels, fitted dashboard covers, fitted liners for cargo areas, cargo storage bins, fluid recovery bottles, washer fluid bottles, HVAC ducts, decorative and protective trim; prototype fabrication for others of automobile parts and accessories for others; injection molding for others of plastic automobile parts and accessories; technical consultancy, inspection and testing services in the field of machined parts for automobiles; design services for others in the field of the fabrication and assembly of machined parts for automobiles. (2) Manufacture of automobile parts and accessories for other, namely interior trim, interior panels, fitted dashboard covers, fitted liners for cargo areas, cargo storage bins, fluid recovery bottles, washer fluid bottles, HVAC ducts, decorative and protective trim; prototype fabrication for others of automobile parts and accessories for others; injection molding for others of plastic automobile parts and accessories; technical consultancy, inspection and testing services in the field of machined parts for automobiles; design services for others in the field of the fabrication and assembly of machined parts for automobiles.

Abstract

An energy absorber for a vehicle includes an elongate member having lateral and longitudinal axes. The elongate member may include one or more channels which are oriented to have walls which extend in the general direction of the lateral axis. An upper surface of at least one of the channels may have an engagement feature that may be configured to engage a stationary member of a vehicle when an impact force brings the engagement feature into contact with the stationary member. The channels may be configured to deform and collapse to absorb at least some of the impact force.

IPC Classes  ?

• B60R 21/045 - Padded linings for the vehicle interior associated with the instrument panel or dashboard
• B60R 21/04 - Padded linings for the vehicle interior
• B60K 37/00 - Dashboards

Abstract

A relatively thin printed LED backlight device with an integral diffuser may be integrated into an interior trim component using a molding process, such as injection molding, compression molding and reaction injection molding. The display portion may be placed behind a textile surface or molded grille or may form a portion of the outer surface of the trim component to provide light to low light areas of the vehicle. Electronic circuitry and components may be printed on to the substrate of the device as part of an in-line continuous process at the molding station to allow low inventory and customization of each backlight device.

IPC Classes  ?

• F21V 7/04 - Optical design
• F21V 13/00 - Producing particular characteristics or distribution of the light emitted by means of a combination of elements specified in two or more of main groups

Abstract

An automobile door bracket includes an attachment section and a corrugated section. The door bracket is placed within an automobile door assembly to function as a side impact countermeasure.

IPC Classes  ?

• B60R 21/04 - Padded linings for the vehicle interior

Abstract

A slush moldable composition includes a low density polyethylene resin, propylene-ethylene copolymer, olefin block copolymer, a thermoplastic olefin and silicon oil combination, and an optional pigment A method for forming a instrument panel skin from the slush moldable composition is provided.

IPC Classes  ?

• C08L 23/06 - Polyethene
• C08L 23/14 - Copolymers of propene
• B29C 41/18 - Slush casting, i.e. pouring moulding material into a hollow mould with excess material being poured off

Abstract

A vehicle instrument panel skin comprises residues of a thermoplastic urethane elastomer and a propylene-ethylene copolymer. The thermoplastic urethane elastomer includes a polyol, an organic diisocyanate, an optional chain extender, and an optional hindered amine light stabilizer and a benzotriazole ultraviolet stabilizing agent. A method for forming the instrument panel skin is also provided.

IPC Classes  ?

• C08L 75/08 - Polyurethanes from polyethers
• C08G 18/48 - Polyethers
• C08G 18/66 - Compounds of groups , , or
• B29C 41/18 - Slush casting, i.e. pouring moulding material into a hollow mould with excess material being poured off

Abstract

A trim component such as a bezel for attachment to a trim panel, such as an instrument panel of a vehicle, is disclosed and includes one or more retention tabs (38) for securing the trim component to the trim panel. The retention tabs (38) provide for a plurality of limiting features that help in preventing a non-blunt contactable edge condition from occurring, particularly during an impact between the vehicle and another vehicle or object.

IPC Classes  ?

• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners

Abstract

A vehicle instrument panel skin comprises residues of a thermoplastic urethane elastomer and a propylene-ethylene copolymer. The thermoplastic urethane elastomer includes a polyol, an organic diisocyanate, an optional chain extender, and an optional hindered amine light stabilizer and a benzotriazole ultraviolet stabilizing agent. A method for forming the instrument panel skin is also provided.

IPC Classes  ?

• B32B 27/40 - Layered products essentially comprising synthetic resin comprising polyurethanes
• B32B 27/32 - Layered products essentially comprising synthetic resin comprising polyolefins

Abstract

The present disclosure relates to plastic composites which find use as decorative appliqués for motor vehicle trim applications. An electroformed mold may be manufactured having a surface that provides a cast replication of a selected wood grain. The electroformed surface may then be placed into an injection mold and a plastic article may be formed thereon, thereby replicating the selected wood grain.

IPC Classes  ?

• B60R 13/02 - Trim mouldingsLedgesWall linersRoof liners

Goods & Services

Surface coatings of plastic. Treatment of materials.

Goods & Services

Surface coatings of plastic. Treatment of materials.

Goods & Services

Surface coatings of plastic. Treatment of materials.

Goods & Services

Treatment of materials.

Goods & Services

Surface coatings of plastic. Treatment of materials.

Goods & Services

Surface coatings of plastic. Treatment of materials.

Abstract

A headliner and bracket cooperate to define a trim edge around a vehicle sunroof. The bracket may include a lip the wraps around an edge of the headliner and trim associated with the headliner.

IPC Classes  ?

• B60J 7/043 - Sunroofs

Abstract

The invention relates to a storage compartment (1) for a motor vehicle, comprising a plastic base body (2) and a textile plastic material for sound absorption. The textile plastic material is designed as a surface element (14, 15, 16), which is securely connected to the plastic base body (2) in the edge region (14', 15', 16') by means of injection molding. Thus, a substantially self-supporting surface element (14, 15, 16) is produced. Said self-supporting surface element (14, 15, 16) forms a wall or bottom region (6, 5) of the storage compartment. Alternatively, the surface element (14, 15, 16) made of the textile plastic material can be disposed at a distance to a wall or bottom region (6, 5) of the storage compartment (1), wherein spacer ribs are provided on the plastic base body (2) for defining the spacing. For the production of the inventive storage compartment (1), the surface elements (14, 15, 16) made of the textile plastic material are inserted into an injection mold and are fixed therein. The edge regions (14', 15', 16') thereof are then insert-molded by injection molding such that the surface elements (14, 15, 16) are configured as integral parts of the storage compartment (1).

IPC Classes  ?

• B60R 7/06 - Stowing or holding appliances inside of vehicle primarily intended for personal property smaller than suit-cases, e.g. travelling articles, or maps in driver or passenger space mounted on or below dashboards

Abstract

In at least one embodiment, the present invention relates an airbag assembly for use with a trim panel having a tear seam forming at least one airbag door, and a door chute assembly comprising a laterally extending flange connected to the panel proximate the airbag door. The door chute assembly includes a chute depending from the flange away from the panel and the chute has at least one opening. The airbag assembly further comprises a door panel assembly including at least one door panel disposed within the chute and connected to the airbag door. The door panel has a downwardly depending flange having at least one projection extending laterally through the at least one opening of the chute.

IPC Classes  ?

• B60R 21/20 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components

Abstract

In at least one embodiment, the present invention relates an airbag assembly comprising a panel having a tear seam forming at least one airbag door, and a door chute assembly comprising a laterally extending flange connected to the panel proximate the airbag door. The door chute assembly includes a chute depending from the flange away from the panel and the chute has at least one opening. The airbag assembly further comprises a door panel assembly including at least one door panel disposed within the chute and connected to the airbag door. The door panel has a downwardly depending flange having at least one projection extending laterally through the at least one opening of the chute. The airbag assembly further comprises an inflatable airbag mounted on the door chute.

IPC Classes  ?

• B60R 21/20 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components

Abstract

A holder for receiving and supporting an article includes a sidewall defining a cavity for receiving the article. At least one resiliently deformable support member is attached to the sidewall. The support member has a surface inwardly extending into said cavity. The surface is operable to support the article. The support member includes an upper portion and a lower portion. The lower portion defines a convex surface and the upper surface defines one of a concave surface and a convex surface having a larger radius of curvature than the lower portion.

IPC Classes  ?

• B60N 3/10 - Arrangements or adaptations of other passenger fittings, not otherwise provided for of receptacles for food or beverages, e.g. refrigerated
• B60R 7/04 - Stowing or holding appliances inside of vehicle primarily intended for personal property smaller than suit-cases, e.g. travelling articles, or maps in driver or passenger space
• A47K 1/08 - Accessories for toilet tables, e.g. glass plates, supports therefor

Abstract

The invention relates to a method for producing a noise insulation piece of mass/spring construction. The mass (4) has, at least before a deep draw process, at least one locally defined region (5), with a different weight per area from the other regions. After the deep draw process, the spring layer made from an elastic light material such as a two-component polyurethane foam or a mixed non-woven fibre is applied. The locally different weight per area of the mass (4) is achieved by means of application of a granulate (3) to a base mass layer (1) in particular in locally differing amounts and/or thicknesses, wherein the granulate (3) is fixed to itself and to the base mass layer (1) by means of sintering. After deep drawing, the desired weight per area of the mass (4) can be achieved independent of the degree of drawing. The granulate (3) can alternatively also be applied to a thin and lightweight support layer in locally required amounts or thicknesses.

IPC Classes  ?

• B60R 13/08 - Insulating elements, e.g. for sound insulation

Abstract

In at least one embodiment, the present invention relates an airbag assembly comprising a panel having a tear seam forming at least one airbag door, and a door chute assembly comprising a laterally extending flange connected to the panel proximate the airbag door. The door chute assembly includes a chute depending from the flange away from the panel and the chute has at least one opening comprising a window portion communicating with an angled channel portion. The airbag assembly further comprises a door panel assembly including at least one door panel disposed within the chute and connected to the airbag door. The door panel has a downwardly depending flange having at least one projection extending laterally through the at least one opening of the chute. The airbag assembly further comprises an inflatable airbag mounted on the door chute.

IPC Classes  ?

• B60R 21/16 - Inflatable occupant restraints or confinements designed to inflate upon impact or impending impact, e.g. air bags

Abstract

An automobile door bracket includes an attachment section and a corrugated section. The door bracket is placed within an automobile door assembly to function as a side impact countermeasure.

IPC Classes  ?

• B60R 21/04 - Padded linings for the vehicle interior

Abstract

An automobile interior component includes a substrate component having a seam-mating section. The seam-mating section has a welt protrusion-mating channel that is useful for accurately position a welt strip. The automobile interior component further includes a trim cover having at least one join seam. A welt strip having a welt protrusion section is attached to the trim cover. The welt strip allows positioning of the trim cover over the substrate in that the welt protrusion section is positioned in the welt protrusion-mating channel. A method for manufacturing the automobile interior component is also provided.

IPC Classes  ?

• B62D 39/00 - Vehicle bodies not otherwise provided for

Abstract

In at least one embodiment, the present invention relates to a trim panel for concealing an air bag. The panel comprises a substrate and a cover over the substrate. The cover includes a cover skin. The panel also comprises a tear seam having at least a portion comprising a pattern of alternating residual wall thicknesses in the panel. At least one embodiment of the present invention also relates to a method for making a trim panel for concealing an air bag.

IPC Classes  ?

• B60R 21/20 - Arrangements for storing inflatable members in their non-use or deflated conditionArrangement or mounting of air bag modules or components
