Abstract

The invention relates to a drive module for a single- or multi-track vehicle driveable by drive energy provided by human muscle power and electric motor, in particular a pedelec, comprising a module housing and an electric motor arranged in an interior surrounded by the module housing. The invention also relates to a single- or multi-track vehicle, which is driveable by drive energy provided by human muscle power and electric motor, in particular a pedelec. Finally, the invention relates to a method for connecting a drive module having an electric motor to a vehicle frame of a single- or multi-track vehicle driveable by drive energy provided by human muscle power and electric motor, and to a method for operating a single- or multi-track vehicle driveable by drive energy provided by human muscle power and electric motor.

IPC Classes  ?

• B62J 43/13 - Arrangements of batteries for propulsion on rider-propelled cycles with additional electric propulsion
• B62J 45/421 - Sensor arrangementsMounting thereof characterised by mounting at the pedal crank
• B62J 45/423 - Sensor arrangementsMounting thereof characterised by mounting on or besides the wheel
• B62J 50/22 - Information-providing devices intended to provide information to rider or passenger electronic, e.g. displays
• B62K 3/04 - Frames having a substantially-horizontal top bar
• B62L 3/02 - Brake-actuating mechanismsArrangements thereof for control by a hand lever
• B62M 6/45 - Control or actuating devices therefor
• B62M 6/50 - Control or actuating devices therefor characterised by detectors or sensors, or arrangement thereof
• B62M 6/55 - Rider propelled cycles with auxiliary electric motor power-driven at crank shafts parts
• B62M 6/60 - Rider propelled cycles with auxiliary electric motor power-driven at axle parts

Abstract

The invention relates to a drive unit (15, 1) for a transport means that can be driven simultaneously by drive energy provided by human muscle power and via an electric motor, said drive unit comprising: a supporting structure (18); an input drive shaft for transmitting drive energy generated from human muscle power; an output drive shaft (35) for delivering drive energy to a driving device; a first electric motor-driven drive unit (1) having a drive shaft transmission (19A); and a second electric motor-driven drive unit (1) having a variable shaft transmission (19B, 19). The invention also relates to a transport means comprising such a drive unit (15, 1).

IPC Classes  ?

• B62M 6/40 - Rider propelled cycles with auxiliary electric motor
• B62M 11/04 - Transmissions characterised by use of interengaging toothed wheels or frictionally-engaging wheels of changeable ratio
• F16H 49/00 - Other gearing

Abstract

The invention relates to a means of transport, in particular a bicycle, e-bike, pedelec or cargo bike, comprising: an electric motor-driven drive unit (10) having a muscle-power input shaft, which is designed to receive drive energy generated by human muscle power, and a drive output shaft (21); a wheel (8) driven by the drive unit (10) via the drive output shaft (21); and a frame on which a seating device and the wheel (8) are mounted, wherein: the wheel (8) has a first wheel end face (35) and a second wheel end face (36) which are located at a distance from one another along the wheel rotational axis (R); the drive unit (10) is mounted on the frame via a single-sided guide element (13); the wheel (8) is supported on the single-sided guide element (13) via the drive unit (10) exclusively on either the first or the second wheel end face (35, 36); the drive unit (10) has a support structure (27) connected to the single-sided guide element (13) for conjoint rotation therewith and supports the drive output shaft (21) and the muscle-power input shaft rotatably relative to the frame; and the support structure (27) externally surrounds at least part of the muscle-power input shaft in the radial direction of the rotational axis (11).

IPC Classes  ?

• B62K 7/04 - Frames having a carrying platform
• B62K 25/00 - Axle suspensions
• B62K 25/02 - Axle suspensions for mounting axles rigidly on cycle frame or fork, e.g. adjustably
• B62M 1/38 - Rider propulsion of wheeled vehicles with rotary cranks, e.g. with pedal cranks for directly driving the wheel axle
• B62M 6/65 - Rider propelled cycles with auxiliary electric motor power-driven at axle parts with axle and driving shaft arranged coaxially
• B62M 9/00 - Transmissions characterised by use of an endless chain, belt, or the like
• B62J 17/083 - Frame mounted hoods specially adapted for rider propelled cycles

Goods & Services

Batteries for electric vehicles; electric accumulators for vehicles; electric batteries; electronic control instruments; digital sensors; Digital electronic controllers; Battery chargers; Head protection; Drivers helmets; Bicycle helmets; Sports helmets; Protective helmets for sports; Helmets and spectacles for sports; Sports goggles; Sunglasses; Sports glasses; mobile apps; Location devices; Navigation, guidance, tracking, targeting and map making devices; Bicycle speedometers; Satellite navigational system for bicycles; Computers for use with bicycles; Sports training simulators; Batteries for E-bikes. Vehicles and conveyances; Electric vehicles; Pedal driven land vehicles; Electrically powered land vehicles; Electric bicycles; Two-wheeled motor vehicles; Motorised bicycles; Bicycles; Sports bicycles; Freight bicycles; Folding bikes; Wheelchairs; Electrically operated wheelchairs; Electrically operated scooters; Parts and fittings for land vehicles; Parts and accessories of bicycles so far as included in class 12; parts and accessories for motorized two-wheelers so far as included in Class 12; parts and accessories for motorized bicycles so far as included in Class 12; engines for land vehicles in so far as included in Class 12; electric motors for land vehicles in so far as included in Class 12; Geared electric motors for land vehicles; Mechanical transmissions for land vehicles; Gear boxes for hydraulic transmissions of land vehicles; Gear units for power transmissions of land vehicles; motors for bicycles; Saddles for bicycles, cycles or motorcycles; Bicycle saddles; Saddle covers for bicycles; Stands for bikes [parts of]; Stands for bicycles [parts of]; Bicycle kickstands; Mudguards; Bicycle mudguards; Wheel hubs; Hubs for bicycle wheels; Bicycle handle bars; Bicycle handlebar grips; Saddlebags adapted for bicycles; Gears for bicycles; Front derailleurs; Bicycle pedals; Wheels; Wheel trims; Bicycle tyres; Tubeless tires [tyres] for bicycles, cycles; Tubeless tyres for bicycles; Inner tubes for tyres; Inner tubes for bicycle tyres; Foot straps for bicycles; Bottle cages for bicycles; Bicycle brake lever grips; Brake cables for bicycles; Brakes for vehicles; Bicycle brakes; Hydraulic disc brakes; Spokes for bicycle wheels; Cranks for bicycles; Bicycle cranks; Bicycle handlebars; Frames for bicycles; Bicycle frames; Drive trains [bicycle parts]; Drivetrains for bicycles; Suspension systems for bicycles; Luggage racks for bicycles; Shock absorbers for bicycles; Bicycle bells; Metal bells for bicycles; Cycle bells; Gears for cycles; Gear wheels for bicycles; Dress guards for bicycles, cycles; Saddle supports for bicycles; Direction signals for bicycles; Direction indicators for bicycles; Bicycle stabilisers; Chain guards for bicycles; Drive-chain guards for two-wheeled motor vehicles; Kickstands for bicycles; Cycle stands; Baskets adapted for bicycles; Children's bicycle seats; Front chain rings for bicycles; Roller chains for bicycles; Rack trunk bags for bicycles; Spindles of bicycles; Spray guards for vehicles of class 12; Audible warning systems for bicycles; Fitted bicycle covers; Pumps for inflating pneumatic tyres; Pumps for bicycle tyres; Bicycle chains; Brake levers for cycles; Bicycle trailers; Child carrying trailers for bicycles; Trailers for transporting bicycles; Gear boxes for land vehicles; Gear units for land vehicles; Transmission components for land vehicles; Pedelecs; Accessories for Pedelecs; Parts of Pedelecs; Accessories for E-Bikes; Parts of E-Bikes; parts and accessories for E-Bikes so far as included in Class 12; parts and accessories for pedelecs so far as included in Class 12. Retail services in relation to bicycles; Retail services in relation to bicycle accessories; Retail services in relation to e-bikes; Retail services in relation to e-bike accessories; Retail services relating to sporting goods; Retail services in relation to sporting articles; Retail services in relation to sporting equipment; Wholesale services relating to sporting goods; Wholesale services in relation to sporting articles; Wholesale services in relation to sporting equipment; Advertising services relating to the commercialization of new products; Digital advertising services; Digital marketing; Product marketing; Marketing. Advisory services relating to the maintenance and repair of mechanical and electrical equipment; Providing information relating to the repair of bicycles; Providing information relating to the repair of E-bikes; Providing information relating to the repair or maintenance of electric motors; Vehicle repair, maintenance, refuelling and recharging; Repair or maintenance of electric motors; Recharging of batteries; Providing information relating to the repair or maintenance of sporting equipment; Providing information relating to the installation of electrical apparatus; maintenance and repair of bicycles; maintenance and repair of e-bikes; Maintenance and repair of sports and fitness equipment; Maintenance and repair of gears.

Abstract

A vehicle with a traction mechanism unit, a method for assembling a vehicle, a method for avoiding pedal kickback in a vehicle, a method for transmitting a drive torque of a single-track or multi-track vehicle via a traction mechanism unit, and a method for eliminating interaction between a drive train with a traction mechanism unit and a suspension/damping device in a single-track or multi-track vehicle, and a corresponding traction mechanism unit.

IPC Classes  ?

• B62M 9/16 - Tensioning or adjusting equipment for chains, belts, or the like
• B60B 27/02 - Hubs adapted to be rotatably arranged on axle
• B62J 6/00 - Arrangement of optical signalling or lighting devices on cyclesMounting or supporting thereofCircuits therefor
• B62J 13/04 - Guards for chain, chain drive or equivalent drive, e.g. belt drive completely enclosing the chain drive or the like
• B62J 45/41 - Sensor arrangementsMounting thereof characterised by the type of sensor
• B62J 45/412 - Speed sensors
• B62K 25/28 - Axle suspensions for mounting axles resiliently on cycle frame or fork with pivoted chain-stay
• B62L 1/02 - BrakesArrangements thereof in which cycle wheels are engaged by brake elements
• B62M 6/55 - Rider propelled cycles with auxiliary electric motor power-driven at crank shafts parts
• B62M 9/02 - Transmissions characterised by use of an endless chain, belt, or the like of unchangeable ratio

Goods & Services

Batteries for electric vehicles; electric accumulators for vehicles; electric batteries; electronic control instruments; digital sensors; Digital electronic controllers; Battery chargers; Head protection; Drivers helmets; Bicycle helmets; Sports helmets; Protective helmets for sports; Helmets and spectacles for sports; Sports goggles; Sunglasses; Sports glasses; mobile apps; Location devices; Navigation, guidance, tracking, targeting and map making devices; Bicycle speedometers; Satellite navigational system for bicycles; Computers for use with bicycles; Sports training simulators; Batteries for E-bikes. Vehicles and conveyances; Electric vehicles; Pedal driven land vehicles; Electrically powered land vehicles; Electric bicycles; Two-wheeled motor vehicles; Motorised bicycles; Bicycles; Sports bicycles; Freight bicycles; Folding bikes; Wheelchairs; Electrically operated wheelchairs; Electrically operated scooters; Parts and fittings for land vehicles; Parts and accessories of bicycles so far as included in class 12; parts and accessories for motorized two-wheelers so far as included in Class 12; parts and accessories for motorized bicycles so far as included in Class 12; engines for land vehicles in so far as included in Class 12; electric motors for land vehicles in so far as included in Class 12; Geared electric motors for land vehicles; Mechanical transmissions for land vehicles; Gear boxes for hydraulic transmissions of land vehicles; Gear units for power transmissions of land vehicles; motors for bicycles; Saddles for bicycles, cycles or motorcycles; Bicycle saddles; Saddle covers for bicycles; Stands for bikes [parts of]; Stands for bicycles [parts of]; Bicycle kickstands; Mudguards; Bicycle mudguards; Wheel hubs; Hubs for bicycle wheels; Bicycle handle bars; Bicycle handlebar grips; Saddlebags adapted for bicycles; Gears for bicycles; Front derailleurs; Bicycle pedals; Wheels; Wheel trims; Bicycle tyres; Tubeless tires [tyres] for bicycles, cycles; Tubeless tyres for bicycles; Inner tubes for tyres; Inner tubes for bicycle tyres; Foot straps for bicycles; Bottle cages for bicycles; Bicycle brake lever grips; Brake cables for bicycles; Brakes for vehicles; Bicycle brakes; Hydraulic disc brakes; Spokes for bicycle wheels; Cranks for bicycles; Bicycle cranks; Bicycle handlebars; Frames for bicycles; Bicycle frames; Drive trains [bicycle parts]; Drivetrains for bicycles; Suspension systems for bicycles; Luggage racks for bicycles; Shock absorbers for bicycles; Bicycle bells; Metal bells for bicycles; Cycle bells; Gears for cycles; Gear wheels for bicycles; Dress guards for bicycles, cycles; Saddle supports for bicycles; Direction signals for bicycles; Direction indicators for bicycles; Bicycle stabilisers; Chain guards for bicycles; Drive-chain guards for two-wheeled motor vehicles; Kickstands for bicycles; Cycle stands; Baskets adapted for bicycles; Children's bicycle seats; Front chain rings for bicycles; Roller chains for bicycles; Rack trunk bags for bicycles; Spindles of bicycles; Spray guards for vehicles of class 12; Audible warning systems for bicycles; Fitted bicycle covers; Pumps for inflating pneumatic tyres; Pumps for bicycle tyres; Bicycle chains; Brake levers for cycles; Bicycle trailers; Child carrying trailers for bicycles; Trailers for transporting bicycles; Gear boxes for land vehicles; Gear units for land vehicles; Transmission components for land vehicles; Pedelecs; Accessories for Pedelecs; Parts of Pedelecs; Accessories for E-Bikes; Parts of E-Bikes; parts and accessories for E-Bikes so far as included in Class 12; parts and accessories for pedelecs so far as included in Class 12. Retail services in relation to bicycles; Retail services in relation to bicycle accessories; Retail services in relation to e-bikes; Retail services in relation to e-bike accessories; Retail services relating to sporting goods; Retail services in relation to sporting articles; Retail services in relation to sporting equipment; Wholesale services relating to sporting goods; Wholesale services in relation to sporting articles; Wholesale services in relation to sporting equipment; Advertising services relating to the commercialization of new products; Digital advertising services; Digital marketing; Product marketing; Marketing. Advisory services relating to the maintenance and repair of mechanical and electrical equipment; Providing information relating to the repair of bicycles; Providing information relating to the repair of E-bikes; Providing information relating to the repair or maintenance of electric motors; Vehicle repair, maintenance, refuelling and recharging; Repair or maintenance of electric motors; Recharging of batteries; Providing information relating to the repair or maintenance of sporting equipment; Providing information relating to the installation of electrical apparatus; maintenance and repair of bicycles; maintenance and repair of e-bikes; Maintenance and repair of sports and fitness equipment; Maintenance and repair of gears.

Goods & Services

Batteries for electric vehicles; electric accumulators for vehicles; electric batteries; electronic control instruments; digital sensors; Digital electronic controllers; Battery chargers; Head protection; Drivers helmets; Bicycle helmets; Sports helmets; Protective helmets for sports; Helmets and spectacles for sports; Sports goggles; Sunglasses; Sports glasses; mobile apps; Location devices; Navigation, guidance, tracking, targeting and map making devices; Bicycle speedometers; Satellite navigational system for bicycles; Computers for use with bicycles; Sports training simulators; Batteries for E-bikes. Vehicles and conveyances; Electric vehicles; Pedal driven land vehicles; Electrically powered land vehicles; Electric bicycles; Two-wheeled motor vehicles; Motorised bicycles; Bicycles; Sports bicycles; Freight bicycles; Folding bikes; Wheelchairs; Electrically operated wheelchairs; Electrically operated scooters; Parts and fittings for land vehicles; Parts and accessories of bicycles so far as included in class 12; parts and accessories for motorized two-wheelers so far as included in Class 12; parts and accessories for motorized bicycles so far as included in Class 12; engines for land vehicles in so far as included in Class 12; electric motors for land vehicles in so far as included in Class 12; Geared electric motors for land vehicles; Mechanical transmissions for land vehicles; Gear boxes for hydraulic transmissions of land vehicles; Gear units for power transmissions of land vehicles; motors for bicycles; Saddles for bicycles, cycles or motorcycles; Bicycle saddles; Saddle covers for bicycles; Stands for bikes [parts of]; Stands for bicycles [parts of]; Bicycle kickstands; Mudguards; Bicycle mudguards; Wheel hubs; Hubs for bicycle wheels; Bicycle handle bars; Bicycle handlebar grips; Saddlebags adapted for bicycles; Gears for bicycles; Front derailleurs; Bicycle pedals; Wheels; Wheel trims; Bicycle tyres; Tubeless tires [tyres] for bicycles, cycles; Tubeless tyres for bicycles; Inner tubes for tyres; Inner tubes for bicycle tyres; Foot straps for bicycles; Bottle cages for bicycles; Bicycle brake lever grips; Brake cables for bicycles; Brakes for vehicles; Bicycle brakes; Hydraulic disc brakes; Spokes for bicycle wheels; Cranks for bicycles; Bicycle cranks; Bicycle handlebars; Frames for bicycles; Bicycle frames; Drive trains [bicycle parts]; Drivetrains for bicycles; Suspension systems for bicycles; Luggage racks for bicycles; Shock absorbers for bicycles; Bicycle bells; Metal bells for bicycles; Cycle bells; Gears for cycles; Gear wheels for bicycles; Dress guards for bicycles, cycles; Saddle supports for bicycles; Direction signals for bicycles; Direction indicators for bicycles; Bicycle stabilisers; Chain guards for bicycles; Drive-chain guards for two-wheeled motor vehicles; Kickstands for bicycles; Cycle stands; Baskets adapted for bicycles; Children's bicycle seats; Front chain rings for bicycles; Roller chains for bicycles; Rack trunk bags for bicycles; Spindles of bicycles; Spray guards for vehicles of class 12; Audible warning systems for bicycles; Fitted bicycle covers; Pumps for inflating pneumatic tyres; Pumps for bicycle tyres; Bicycle chains; Brake levers for cycles; Bicycle trailers; Child carrying trailers for bicycles; Trailers for transporting bicycles; Gear boxes for land vehicles; Gear units for land vehicles; Transmission components for land vehicles; Pedelecs; Accessories for Pedelecs; Parts of Pedelecs; Accessories for E-Bikes; Parts of E-Bikes; parts and accessories for E-Bikes so far as included in Class 12; parts and accessories for pedelecs so far as included in Class 12. Retail services in relation to bicycles; Retail services in relation to bicycle accessories; Retail services in relation to e-bikes; Retail services in relation to e-bike accessories; Retail services relating to sporting goods; Retail services in relation to sporting articles; Retail services in relation to sporting equipment; Wholesale services relating to sporting goods; Wholesale services in relation to sporting articles; Wholesale services in relation to sporting equipment; Advertising services relating to the commercialization of new products; Digital advertising services; Digital marketing; Product marketing; Marketing. Advisory services relating to the maintenance and repair of mechanical and electrical equipment; Providing information relating to the repair of bicycles; Providing information relating to the repair of E-bikes; Providing information relating to the repair or maintenance of electric motors; Vehicle repair, maintenance, refuelling and recharging; Repair or maintenance of electric motors; Recharging of batteries; Providing information relating to the repair or maintenance of sporting equipment; Providing information relating to the installation of electrical apparatus; maintenance and repair of bicycles; maintenance and repair of e-bikes; Maintenance and repair of sports and fitness equipment; Maintenance and repair of gears.

Abstract

A means of transport, in particular a pedelec, which can be driven by means of drive energy produced electromotively and by human muscular power, comprising a drive unit in which an electric drive motor and a harmonic drive transmission are nested one inside the other, thereby saving space.

IPC Classes  ?

• B62M 6/55 - Rider propelled cycles with auxiliary electric motor power-driven at crank shafts parts
• H02K 7/116 - Structural association with clutches, brakes, gears, pulleys or mechanical starters with gears
• H02K 11/215 - Magnetic effect devices, e.g. Hall-effect or magneto-resistive elements

Abstract

A narrow drive unit for a means of locomotion drivable simultaneously by drive energy provided by human muscular strength and by electric motors, comprising two harmonic gearings and two electric motors, wherein the sum of the drive energy provided by human muscular strength and the electric motors can be transmitted to an output shaft.

IPC Classes  ?

• B62M 6/60 - Rider propelled cycles with auxiliary electric motor power-driven at axle parts
• H02K 7/116 - Structural association with clutches, brakes, gears, pulleys or mechanical starters with gears
• H02K 7/08 - Structural association with bearings
• H02K 7/18 - Structural association of electric generators with mechanical driving motors, e.g.with turbines
• F16H 49/00 - Other gearing

Abstract

The invention relates to: a vehicle comprising a traction mechanism unit (16); a method (60) for assembling a vehicle (F); a method (65) for avoiding pedal kickback in a vehicle (F); a method for transmitting a drive torque of a single-track or multi-track vehicle via a traction mechanism unit (16); and a method for eliminating the interaction between a drive train comprising a traction mechanism unit (16) and a spring/damper device (10) in a single-track or multi-track vehicle (F); and a corresponding traction mechanism unit (16).

IPC Classes  ?

• B62K 25/28 - Axle suspensions for mounting axles resiliently on cycle frame or fork with pivoted chain-stay
• B62M 9/02 - Transmissions characterised by use of an endless chain, belt, or the like of unchangeable ratio

Goods & Services

Batteries for electric vehicles; electric accumulators for vehicles; electric batteries; electronic control instruments; digital sensors; Digital electronic controllers; Battery chargers; Head protection; Drivers helmets; Bicycle helmets; Sports helmets; Protective helmets for sports; Helmets and spectacles for sports; Sports goggles; Sunglasses; Sports glasses; mobile apps; Location devices; Navigation, guidance, tracking, targeting and map making devices; Bicycle speedometers; Satellite navigational system for bicycles; Computers for use with bicycles; Sports training simulators; Batteries for E-bikes. Vehicles and conveyances; Electric vehicles; Pedal driven land vehicles; Electrically powered land vehicles; Electric bicycles; Two-wheeled motor vehicles; Motorised bicycles; Bicycles; Sports bicycles; Freight bicycles; Folding bikes; Wheelchairs; Electrically operated wheelchairs; Electrically operated scooters; Parts and fittings for land vehicles; Parts and accessories of bicycles so far as included in class 12; parts and accessories for motorized two-wheelers so far as included in Class 12; parts and accessories for motorized bicycles so far as included in Class 12; engines for land vehicles in so far as included in Class 12; electric motors for land vehicles in so far as included in Class 12; Geared electric motors for land vehicles; Mechanical transmissions for land vehicles; Gear boxes for hydraulic transmissions of land vehicles; Gear units for power transmissions of land vehicles; motors for bicycles; Saddles for bicycles, cycles or motorcycles; Bicycle saddles; Saddle covers for bicycles; Stands for bikes [parts of]; Stands for bicycles [parts of]; Bicycle kickstands; Mudguards; Bicycle mudguards; Wheel hubs; Hubs for bicycle wheels; Bicycle handle bars; Bicycle handlebar grips; Saddlebags adapted for bicycles; Gears for bicycles; Front derailleurs; Bicycle pedals; Wheels; Wheel trims; Bicycle tyres; Tubeless tires [tyres] for bicycles, cycles; Tubeless tyres for bicycles; Inner tubes for tyres; Inner tubes for bicycle tyres; Foot straps for bicycles; Bottle cages for bicycles; Bicycle brake lever grips; Brake cables for bicycles; Brakes for vehicles; Bicycle brakes; Hydraulic disc brakes; Spokes for bicycle wheels; Cranks for bicycles; Bicycle cranks; Bicycle handlebars; Frames for bicycles; Bicycle frames; Drive trains [bicycle parts]; Drivetrains for bicycles; Suspension systems for bicycles; Luggage racks for bicycles; Shock absorbers for bicycles; Bicycle bells; Metal bells for bicycles; Cycle bells; Gears for cycles; Gear wheels for bicycles; Dress guards for bicycles, cycles; Saddle supports for bicycles; Direction signals for bicycles; Direction indicators for bicycles; Bicycle stabilisers; Chain guards for bicycles; Drive-chain guards for two-wheeled motor vehicles; Kickstands for bicycles; Cycle stands; Baskets adapted for bicycles; Children's bicycle seats; Front chain rings for bicycles; Roller chains for bicycles; Rack trunk bags for bicycles; Spindles of bicycles; Spray guards for vehicles of class 12; Audible warning systems for bicycles; Fitted bicycle covers; Pumps for inflating pneumatic tyres; Pumps for bicycle tyres; Bicycle chains; Brake levers for cycles; Bicycle trailers; Child carrying trailers for bicycles; Trailers for transporting bicycles; Gear boxes for land vehicles; Gear units for land vehicles; Transmission components for land vehicles; Gear boxes for water vehicles; Gear units for water vehicles; Transmission components for water vehicles; Pedelecs; Accessories for Pedelecs; Parts of Pedelecs; Accessories for E-Bikes; Parts of E-Bikes; parts and accessories for E-Bikes so far as included in Class 12; parts and accessories for pedelecs so far as included in Class 12. Retail services in relation to bicycles; Retail services in relation to bicycle accessories; Retail services in relation to e-bikes; Retail services in relation to e-bike accessories; Retail services relating to sporting goods; Retail services in relation to sporting articles; Retail services in relation to sporting equipment; Wholesale services relating to sporting goods; Wholesale services in relation to sporting articles; Wholesale services in relation to sporting equipment; Advertising services relating to the commercialization of new products; Digital advertising services; Digital marketing; Product marketing; Marketing. Advisory services relating to the maintenance and repair of mechanical and electrical equipment; Providing information relating to the repair of bicycles; Providing information relating to the repair of E-bikes; Providing information relating to the repair or maintenance of electric motors; Vehicle repair, maintenance, refuelling and recharging; Repair or maintenance of electric motors; Recharging of batteries; Providing information relating to the repair or maintenance of sporting equipment; Providing information relating to the installation of electrical apparatus; maintenance and repair of bicycles; maintenance and repair of e-bikes; Maintenance and repair of sports and fitness equipment; Maintenance and repair of gears.

Abstract

The invention relates to a means of transport (F), in particular pedelec, which can be driven by means of drive energy produced electromotively and by human muscular power, comprising a drive unit (1) in which an electric drive motor (27) and a harmonic drive transmission (18) are nested one inside the other, thereby saving space.

IPC Classes  ?

• F16H 49/00 - Other gearing
• H02K 7/116 - Structural association with clutches, brakes, gears, pulleys or mechanical starters with gears
• B62M 6/55 - Rider propelled cycles with auxiliary electric motor power-driven at crank shafts parts
• B62M 21/00 - Transmissions characterised by use of resilient elements therein
• B62M 23/00 - Transmissions characterised by use of other elementsOther transmissions

Abstract

The invention relates to a particularly slim drive unit (1) for a means of locomotion (F) which can be driven simultaneously by drive energy supplied by human muscular strength and electric motors, said drive unit (1) comprising two strain wave gears (13, 18) and two electric motors (22, 27), the sum of the drive energy supplied by human muscular strength and the electric motors (22, 27) being transmissible to a driven output shaft (12).

IPC Classes  ?

• B62M 21/00 - Transmissions characterised by use of resilient elements therein
• F16H 49/00 - Other gearing
• H02K 7/116 - Structural association with clutches, brakes, gears, pulleys or mechanical starters with gears
• B62M 23/00 - Transmissions characterised by use of other elementsOther transmissions
• B62M 6/55 - Rider propelled cycles with auxiliary electric motor power-driven at crank shafts parts
• B62M 6/60 - Rider propelled cycles with auxiliary electric motor power-driven at axle parts

Goods & Services

Batteries for electric vehicles; electric accumulators for vehicles; electric batteries; electronic control instruments; digital sensors; Digital electronic controllers; Battery chargers; Head protection; Drivers helmets; Bicycle helmets; Sports helmets; Protective helmets for sports; Helmets and spectacles for sports; Sports goggles; Sunglasses; Sports glasses; mobile apps; Location devices; Navigation, guidance, tracking, targeting and map making devices; Bicycle speedometers; Satellite navigational system for bicycles; Computers for use with bicycles; Sports training simulators; Batteries for E-bikes. Vehicles and conveyances; Electric vehicles; Pedal driven land vehicles; Electrically powered land vehicles; Electric bicycles; Two-wheeled motor vehicles; Motorised bicycles; Bicycles; Sports bicycles; Freight bicycles; Folding bikes; Wheelchairs; Electrically operated wheelchairs; Electrically operated scooters; Parts and fittings for land vehicles; Parts and accessories of bicycles so far as included in class 12; parts and accessories for motorized two-wheelers so far as included in Class 12; parts and accessories for motorized bicycles so far as included in Class 12; engines for land vehicles in so far as included in Class 12; electric motors for land vehicles in so far as included in Class 12; Geared electric motors for land vehicles; Mechanical transmissions for land vehicles; Gear boxes for hydraulic transmissions of land vehicles; Gear units for power transmissions of land vehicles; motors for bicycles; Saddles for bicycles, cycles or motorcycles; Bicycle saddles; Saddle covers for bicycles; Stands for bikes [parts of]; Stands for bicycles [parts of]; Bicycle kickstands; Mudguards; Bicycle mudguards; Wheel hubs; Hubs for bicycle wheels; Bicycle handle bars; Bicycle handlebar grips; Saddlebags adapted for bicycles; Gears for bicycles; Front derailleurs; Bicycle pedals; Wheels; Wheel trims; Bicycle tyres; Tubeless tires [tyres] for bicycles, cycles; Tubeless tyres for bicycles; Inner tubes for tyres; Inner tubes for bicycle tyres; Foot straps for bicycles; Bottle cages for bicycles; Bicycle brake lever grips; Brake cables for bicycles; Brakes for vehicles; Bicycle brakes; Hydraulic disc brakes; Spokes for bicycle wheels; Cranks for bicycles; Bicycle cranks; Bicycle handlebars; Frames for bicycles; Bicycle frames; Drive trains [bicycle parts]; Drivetrains for bicycles; Suspension systems for bicycles; Luggage racks for bicycles; Shock absorbers for bicycles; Bicycle bells; Metal bells for bicycles; Cycle bells; Gears for cycles; Gear wheels for bicycles; Dress guards for bicycles, cycles; Saddle supports for bicycles; Direction signals for bicycles; Direction indicators for bicycles; Bicycle stabilisers; Chain guards for bicycles; Drive-chain guards for two-wheeled motor vehicles; Kickstands for bicycles; Cycle stands; Baskets adapted for bicycles; Children's bicycle seats; Front chain rings for bicycles; Roller chains for bicycles; Rack trunk bags for bicycles; Spindles of bicycles; Spray guards for vehicles of class 12; Audible warning systems for bicycles; Fitted bicycle covers; Pumps for inflating pneumatic tyres; Pumps for bicycle tyres; Bicycle chains; Brake levers for cycles; Bicycle trailers; Child carrying trailers for bicycles; Trailers for transporting bicycles; Gear boxes for land vehicles; Gear units for land vehicles; Transmission components for land vehicles; Gear boxes for water vehicles; Gear units for water vehicles; Transmission components for water vehicles; Pedelecs; Accessories for Pedelecs; Parts of Pedelecs; Accessories for E-Bikes; Parts of E-Bikes; parts and accessories for E-Bikes so far as included in Class 12; parts and accessories for pedelecs so far as included in Class 12. Retail services in relation to bicycles; Retail services in relation to bicycle accessories; Retail services in relation to e-bikes; Retail services in relation to e-bike accessories; Retail services relating to sporting goods; Retail services in relation to sporting articles; Retail services in relation to sporting equipment; Wholesale services relating to sporting goods; Wholesale services in relation to sporting articles; Wholesale services in relation to sporting equipment; Advertising services relating to the commercialization of new products; Digital advertising services; Digital marketing; Product marketing; Marketing. Advisory services relating to the maintenance and repair of mechanical and electrical equipment; Providing information relating to the repair of bicycles; Providing information relating to the repair of E-bikes; Providing information relating to the repair or maintenance of electric motors; Vehicle repair, maintenance, refuelling and recharging; Repair or maintenance of electric motors; Recharging of batteries; Providing information relating to the repair or maintenance of sporting equipment; Providing information relating to the installation of electrical apparatus; maintenance and repair of bicycles; maintenance and repair of e-bikes; Maintenance and repair of sports and fitness equipment; Maintenance and repair of gears.

Goods & Services

Belt pulleys; Belt drives; Belts for motors and engines; Belts for machines; Belts for farm vehicle machines. Vehicles and conveyances; Electric vehicles; Pedal driven land vehicles; Electrically powered land vehicles; Electric bicycles; Motorised bicycles; Bicycles; Sports bicycles; Folding bikes; Wheelchairs; Electrically operated wheelchairs; Electrically operated scooters; Parts and fittings for land vehicles; Geared electric motors for land vehicles; Mechanical transmissions for land vehicles; Gear boxes for hydraulic transmissions of land vehicles; Gear units for power transmissions of land vehicles; Engines for bicycles; Saddles for bicycles, cycles or motorcycles; Bicycle saddles; Saddle covers for bicycles; Stands for bicycles [parts of]; Bicycle kickstands; Bicycle mudguards; Wheel hubs; Hubs for bicycle wheels; Bicycle handlebars; Handlebar ends for bicycles; Saddlebags adapted for bicycles; Gears for bicycles; Front derailleurs; Bicycle pedals; Wheels; Wheel trims; Bicycle tyres; Tubeless tyres for bicycles; Inner tubes for pneumatic tyres; Inner tubes for bicycle tyres; Belt pulleys for land vehicles; Toe straps for use on bicycles; Water bottle cages for bicycles; Brake levers for cycles; Bicycle brake lever grips; Brake cables for bicycles; Brakes for vehicles; Bicycle brakes; Hydraulic disc brakes; Spokes for bicycle wheels; Bicycle handlebar grips; Bicycle cranks; Bicycle frames; Drive trains [bicycle parts]; Gears for cycles; Drivetrains for bicycles; Suspension systems for bicycles; Luggage carriers for cycles; Bicycle carriers; Shock absorbers for bicycles; Bicycle bells; Metal bells for bicycles; Cycle bells; Gear wheels for bicycles; Dress guards for bicycles; Bicycle seat posts; Bicycle stabilisers; Direction indicators for bicycles; Chain guards for bicycles; Drive-chain guards for two-wheeled motor vehicles; Cycle stands; Baskets adapted for bicycles; Children's bicycle seats; Chainwheels for bicycles; Roller chains for bicycles; Rack trunk bags for bicycles; Spindles of bicycles; Spray prevention flaps for vehicles; Audible warning systems for bicycles; Fitted bicycle covers; Tire inflators; Pumps for bicycle tyres; Bicycle chains; Bicycle trailers; Trailers for transporting bicycles; Child carrying trailers; Gear boxes for land vehicles; Gear units for land vehicles; Transmission components for land vehicles; Pedelecs; motorized bicycles; cargo bikes; parts and fittings for bicycles as far as included in class 12; parts and fittings for motorized bicycles as far as included in class 12; parts and fittings for motorized zwo-wheelers as far as included in class 12; motors for land vehicles as far as included in class 12; electric motors for land vehicles as far as included in class 12; fittings for Pedelecs; Parts of Pedelecs; fittings of e-bikes; parts of e-bikes; parts and fittings as far as included in class 12; parts and fittings for Pedelec as far as included in class 12. Advisory services relating to the maintenance and repair of mechanical and electrical equipment; Providing information relating to the repair of bicycles; Providing information relating to the repair or maintenance of electric motors; charging of electric vehicles; Automobile repair; Vehicle maintenance; maintenance and repair of e-bikes; Repair or maintenance of electric motors; Recharging of batteries; Providing information relating to the repair or maintenance of sporting equipment; Providing information relating to the installation of electrical apparatus; Maintenance and repair of bicycles; Maintenance and repair of gears; Maintenance and repair of sports and fitness equipment; Providing information relating to the repair of e-bikes.

Goods & Services

Batteries for electric vehicles; electric accumulators for vehicles; electric batteries; electronic control instruments; digital sensors; Digital electronic controllers; Battery chargers; Head protection; Drivers helmets; Bicycle helmets; Sports helmets; Protective helmets for sports; Helmets and spectacles for sports; Sports goggles; Sunglasses; Sports glasses; mobile apps; Location devices; Navigation, guidance, tracking, targeting and map making devices; Bicycle speedometers; Satellite navigational system for bicycles; Computers for use with bicycles; Sports training simulators; Batteries for E-bikes. Vehicles and conveyances; Electric vehicles; Pedal driven land vehicles; Electrically powered land vehicles; Electric bicycles; Two-wheeled motor vehicles; Motorised bicycles; Bicycles; Sports bicycles; Freight bicycles; Folding bikes; Wheelchairs; Electrically operated wheelchairs; Electrically operated scooters; Parts and fittings for land vehicles; Parts and accessories of bicycles so far as included in class 12; parts and accessories for motorized two-wheelers so far as included in Class 12; parts and accessories for motorized bicycles so far as included in Class 12; engines for land vehicles in so far as included in Class 12; electric motors for land vehicles in so far as included in Class 12; Geared electric motors for land vehicles; Mechanical transmissions for land vehicles; Gear boxes for hydraulic transmissions of land vehicles; Gear units for power transmissions of land vehicles; motors for bicycles; Saddles for bicycles, cycles or motorcycles; Bicycle saddles; Saddle covers for bicycles; Stands for bikes [parts of]; Stands for bicycles [parts of]; Bicycle kickstands; Mudguards; Bicycle mudguards; Wheel hubs; Hubs for bicycle wheels; Bicycle handle bars; Bicycle handlebar grips; Saddlebags adapted for bicycles; Gears for bicycles; Front derailleurs; Bicycle pedals; Wheels; Wheel trims; Bicycle tyres; Tubeless tires [tyres] for bicycles, cycles; Tubeless tyres for bicycles; Inner tubes for tyres; Inner tubes for bicycle tyres; Foot straps for bicycles; Bottle cages for bicycles; Bicycle brake lever grips; Brake cables for bicycles; Brakes for vehicles; Bicycle brakes; Hydraulic disc brakes; Spokes for bicycle wheels; Cranks for bicycles; Bicycle cranks; Bicycle handlebars; Frames for bicycles; Bicycle frames; Drive trains [bicycle parts]; Drivetrains for bicycles; Suspension systems for bicycles; Luggage racks for bicycles; Shock absorbers for bicycles; Bicycle bells; Metal bells for bicycles; Cycle bells; Gears for cycles; Gear wheels for bicycles; Dress guards for bicycles, cycles; Saddle supports for bicycles; Direction signals for bicycles; Direction indicators for bicycles; Bicycle stabilisers; Chain guards for bicycles; Drive-chain guards for two-wheeled motor vehicles; Kickstands for bicycles; Cycle stands; Baskets adapted for bicycles; Children's bicycle seats; Front chain rings for bicycles; Roller chains for bicycles; Rack trunk bags for bicycles; Spindles of bicycles; Spray guards for vehicles of class 12; Audible warning systems for bicycles; Fitted bicycle covers; Pumps for inflating pneumatic tyres; Pumps for bicycle tyres; Bicycle chains; Brake levers for cycles; Bicycle trailers; Child carrying trailers for bicycles; Trailers for transporting bicycles; Gear boxes for land vehicles; Gear units for land vehicles; Transmission components for land vehicles; Gear boxes for water vehicles; Gear units for water vehicles; Transmission components for water vehicles; Pedelecs; Accessories for Pedelecs; Parts of Pedelecs; Accessories for E-Bikes; Parts of E-Bikes; parts and accessories for E-Bikes so far as included in Class 12; parts and accessories for pedelecs so far as included in Class 12. Retail services in relation to bicycles; Retail services in relation to bicycle accessories; Retail services in relation to e-bikes; Retail services in relation to e-bike accessories; Retail services relating to sporting goods; Retail services in relation to sporting articles; Retail services in relation to sporting equipment; Wholesale services relating to sporting goods; Wholesale services in relation to sporting articles; Wholesale services in relation to sporting equipment; Advertising services relating to the commercialization of new products; Digital advertising services; Digital marketing; Product marketing; Marketing. Advisory services relating to the maintenance and repair of mechanical and electrical equipment; Providing information relating to the repair of bicycles; Providing information relating to the repair of E-bikes; Providing information relating to the repair or maintenance of electric motors; Vehicle repair, maintenance, refuelling and recharging; Repair or maintenance of electric motors; Recharging of batteries; Providing information relating to the repair or maintenance of sporting equipment; Providing information relating to the installation of electrical apparatus; maintenance and repair of bicycles; maintenance and repair of e-bikes; Maintenance and repair of sports and fitness equipment; Maintenance and repair of gears.

Goods & Services

Vehicles and conveyances. Clothing. Sporting articles and equipment. IT services.
