Abstract

The present invention relates to a cryogenic cooling system and method for particular use in cooling superconducting cables over extended distances, the system and method involving the evaporation of liquid cryogen though an array of spray generators thereby effecting heat transfer utilising the latent heat of vaporisation and optionally through sensible heat transfer in order to provide improved cryogenic cooling over extended distances.

IPC Classes  ?

• F28D 1/02 - Heat-exchange apparatus having stationary conduit assemblies for one heat-exchange medium only, the media being in contact with different sides of the conduit wall, in which the other heat-exchange medium is a large body of fluid, e.g. domestic or motor car radiators with the heat-exchange conduits immersed in the body of fluid
• F28D 21/00 - Heat-exchange apparatus not covered by any of the groups

Abstract

The present invention provides a two stage cryogen cooling system for particular use in cooling a cryogen employed in a superconducting power transmission cable, the cooling system employing a sub-cooler pump such as a venturi pump to effect both cooling stages, the first cooling stage being the cooling of the liquid cryogen flowing through an inner lumen of a cryostat of the cooling system and the second stage being the generation of a supply of gaseous cryogen for supply to a second lumen of the cryostat surrounding the inner lumen.

IPC Classes  ?

• F17C 13/00 - Details of vessels or of the filling or discharging of vessels

Abstract

The present invention provides a reinforced thermoplastic cryostat for a superconductor comprising a thermoplastic conduit and a plurality of reinforced thermoplastic tapes wound around an exterior surface of the thermoplastic conduit in a helical orientation in order to provide a reinforced yet flexible cryostat which meets desired performance and manufacturing requirements.

IPC Classes  ?

• H01B 12/16 - Superconductive or hyperconductive conductors, cables or transmission lines characterised by cooling
• B29C 48/00 - Extrusion moulding, i.e. expressing the moulding material through a die or nozzle which imparts the desired formApparatus therefor
• B29K 101/12 - Thermoplastic materials
• B29L 23/00 - Tubular articles
• C08J 5/24 - Impregnating materials with prepolymers which can be polymerised in situ, e.g. manufacture of prepregs

Abstract

The present invention provides a superconducting cable system suitable for use over long distances and adapted to achieve improved heat absorption through the use of the latent heat of vaporisation of a liquid cryogen, the system including a cryogen supply duct, a superconductor extending longitudinally of the supply duct, a vapour return duct and an evaporation enabling medium disposed between the supply duct and the vapour return duct.

IPC Classes  ?

• H01B 12/16 - Superconductive or hyperconductive conductors, cables or transmission lines characterised by cooling

Abstract

The present invention provides a cryogen cooling system which utilises a venturi pump to effect a temperature reduction of a liquid cryogen which may be used to cool a superconducting material.

IPC Classes  ?

• F25B 19/00 - Machines, plants or systems, using evaporation of a refrigerant but without recovery of the vapour
• F17C 13/08 - Mounting arrangements for vessels
• F25D 3/10 - Devices using other cold materialsDevices using cold-storage bodies using liquefied gases, e.g. liquid air
• H01F 6/04 - Cooling

Abstract

The present invention provides a superconducting cable system designed to facilitate long distance superconducting, the cable system including at least one inner cryostat containing a supply of cryogenic fluid and at least one superconductor extending longitudinally of the inner cryostat and in thermal communication with the cryogenic fluid, the inner cryostat comprising a liquid crystal polymer.

IPC Classes  ?

• C09K 19/38 - Polymers, e.g. polyamides
• H01B 12/16 - Superconductive or hyperconductive conductors, cables or transmission lines characterised by cooling

Abstract

The present invention provides a reinforced thermoplastic cryostat for a superconductor comprising a thermoplastic conduit and a plurality of reinforced thermoplastic tapes wound around an exterior surface of the thermoplastic conduit in a helical orientation in order to provide a reinforced yet flexible cryostat which meets desired performance and manufacturing requirements in relation to suspended cable applications.

IPC Classes  ?

• B29C 63/00 - Lining or sheathing, i.e. applying preformed layers or sheathings of plasticsApparatus therefor
• B29C 63/10 - Lining or sheathing, i.e. applying preformed layers or sheathings of plasticsApparatus therefor using sheet or web-like material by folding, winding, bending or the like by winding helically around tubular articles

Abstract

The present invention provides a superconducting cable system designed to facilitate long distance superconducting, the cable system including at least one inner cryostat containing a supply of cryogenic fluid and at least one superconductor extending longitudinally of the inner cryostat and in thermal communication with the cryogenic fluid, the inner cryostat comprising a liquid crystal polymer.

IPC Classes  ?

• H01B 12/16 - Superconductive or hyperconductive conductors, cables or transmission lines characterised by cooling
• H02G 15/34 - Cable fittings for cryogenic cables

Abstract

The present invention provides a superconducting cable system for suspended cable applications designed to facilitate long distance superconducting, the cable system including at least one inner cryostat containing a supply of cryogenic fluid and at least one superconductor extending longitudinally of the inner cryostat and in thermal communication with the cryogenic fluid, the cable system comprising at least one load carrying member, the inner cryostat comprising a liquid crystal polymer, and wherein the at least one inner cryostat is a single layer cryostat configured to provide structural integrity against pressurised cryogen.

IPC Classes  ?

• H01B 12/16 - Superconductive or hyperconductive conductors, cables or transmission lines characterised by cooling
• F16L 9/12 - Rigid pipes of plastics with or without reinforcement
• F17C 3/08 - Vessels not under pressure with provision for thermal insulation by vacuum spaces, e.g. Dewar flask
• C09K 19/00 - Liquid crystal materials

Abstract

The present invention is concerned with a cryostat joint assembly for use in joining superconducting cables, in particular for simplifying the connection between the cables while ensuring a robust electrical and mechanical connection, the joint assembly including first and second endcaps each terminating one of the cables, each end cap including an electrically conductive tubular plug, and a coupling connectable between the first and second end caps and defining first and second tubular sockets for receiving the first and second plugs such as to provide a cryogen conduit extending through and defined by the pair of plugs and sockets to simultaneously enable the flow of cryogen and electrical current through the joint assembly.

IPC Classes  ?

• H02G 15/08 - Cable junctions
• H02G 15/34 - Cable fittings for cryogenic cables
• F16L 25/01 - Construction or details of pipe joints not provided for in, or of interest apart from, groups specially adapted for realising electrical conduction between the two pipe ends of the joint or between parts thereof
• H01R 4/68 - Connections to or between superconductive conductors
• H01B 12/02 - Superconductive or hyperconductive conductors, cables or transmission lines characterised by their form
• H01B 12/16 - Superconductive or hyperconductive conductors, cables or transmission lines characterised by cooling
• H01R 13/52 - Dustproof, splashproof, drip-proof, waterproof, or flameproof cases
• F16L 39/00 - Joints or fittings for double-walled or multi-channel pipes or pipe assemblies
• F16L 59/18 - Arrangements specially adapted to local requirements at flanges, junctions, valves, or the like adapted for joints

IPC Classes  ?

• B29C 53/58 - Winding and joining, e.g. winding spirally helically
• B29C 53/60 - Winding and joining, e.g. winding spirally helically using internal forming surfaces, e.g. mandrels
• H01B 12/06 - Films or wires on bases or cores

Abstract

A variable performance superconducting cable assembly which is configured to provide a substantially constant current carrying capacity between first and second ends of the cable assembly despite an increasing temperature profile along the length of the cable assembly during use.

IPC Classes  ?

• H01B 12/02 - Superconductive or hyperconductive conductors, cables or transmission lines characterised by their form
• H01B 12/16 - Superconductive or hyperconductive conductors, cables or transmission lines characterised by cooling

Abstract

The present invention provides a reinforced thermoplastic cryostat for a superconductor comprising a thermoplastic conduit and a plurality of reinforced thermoplastic tapes wound around an exterior surface of the thermoplastic conduit in a helical orientation in order to provide a reinforced yet flexible cryostat which meets desired performance and manufacturing requirements.

IPC Classes  ?

• B29C 53/58 - Winding and joining, e.g. winding spirally helically
• B29D 23/00 - Producing tubular articles
• B29C 53/60 - Winding and joining, e.g. winding spirally helically using internal forming surfaces, e.g. mandrels
• H01B 12/06 - Films or wires on bases or cores

Abstract

The present invention relates to a cryogenic cooling system and method for particular use in cooling superconducting cables over extended distances, the system and method involving the evaporation of liquid cryogen though an array of spray generators thereby effecting heat transfer utilising the latent heat of vaporisation and optionally through sensible heat transfer in order to provide improved cryogenic cooling over extended distances..

IPC Classes  ?

• F28D 1/02 - Heat-exchange apparatus having stationary conduit assemblies for one heat-exchange medium only, the media being in contact with different sides of the conduit wall, in which the other heat-exchange medium is a large body of fluid, e.g. domestic or motor car radiators with the heat-exchange conduits immersed in the body of fluid

Abstract

The present invention provides a superconducting cable system suitable for use over long distances and adapted to achieve improved heat absorption through the use of the latent heat of vaporisation of a liquid cryogen, the system including a cryogen supply duct, a superconductor extending longitudinally of the supply duct, a vapour return duct and an evaporation enabling medium disposed between the supply duct and the vapour return duct.

IPC Classes  ?

• H01B 12/16 - Superconductive or hyperconductive conductors, cables or transmission lines characterised by cooling
• F28D 15/00 - Heat-exchange apparatus with the intermediate heat-transfer medium in closed tubes passing into or through the conduit walls

Abstract

The present invention provides a superconducting cable system designed to facilitate long distance superconducting, the cable system including at least one inner cryostat containing a supply of cryogenic fluid and at least one superconductor extending longitudinally of the inner cryostat and in thermal communication with the cryogenic fluid, the inner cryostat comprising a liquid crystal polymer..

IPC Classes  ?

• C09K 19/38 - Polymers, e.g. polyamides
• H01B 12/16 - Superconductive or hyperconductive conductors, cables or transmission lines characterised by cooling

Abstract

The present invention provides a superconducting cable system designed to facilitate long distance superconducting, the cable system including at least one inner cryostat containing a supply of cryogenic fluid and at least one superconductor extending longitudinally of the inner cryostat and in thermal communication with the cryogenic fluid, the inner cryostat comprising a liquid crystal polymer..

IPC Classes  ?

• H01B 12/16 - Superconductive or hyperconductive conductors, cables or transmission lines characterised by cooling
• C09K 19/00 - Liquid crystal materials

Abstract

A monitoring apparatus (30) for a superconducting cable comprises magnetic field probes (60) interspersed with conductors (50) that are part of, or connected to, the superconducting cable. A magnetic field sensor (62) is magnetically coupled to each probe (60) and is configured to produce an output signal depending on the sensed magnetic field. The output signals are analysed to determine the condition of the superconducting cable. The magnetic coupling provides electrical isolation against the voltage of the cable core, and thermal isolation between internal cryogenic temperatures and external ambient temperatures.

IPC Classes  ?

• G01R 15/18 - Adaptations providing voltage or current isolation, e.g. for high-voltage or high-current networks using inductive devices, e.g. transformers
• G01R 15/20 - Adaptations providing voltage or current isolation, e.g. for high-voltage or high-current networks using galvano-magnetic devices, e.g. Hall-effect devices
• G01R 33/12 - Measuring magnetic properties of articles or specimens of solids or fluids

Goods & Services

Measuring apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; apparatus, instruments and cables for electricity; power cables; electric cables and wires; underwater power cables; heat resistant electric cables; insulated cables for electricity; pipes containing electrical cable for delivering electricity; electric conductors; flexible sheaths for electric conductors; photovoltaic apparatus and installations for generating solar electricity; apparatus and instruments for controlling electricity; apparatus and instruments for transforming electricity; apparatus and instruments for regulating electricity; apparatus and instruments for accumulating electricity. Cooling installations for cables; deep-cold keeping and cryogenic technology apparatus; cryostats, other than for laboratory use; cooling apparatus for the preparation of deep cold temperatures. Construction of power plants; building construction supervision; services relating to the construction of transmission lines; repair information in the field of energy systems; electric appliance installation and repair; information on construction and building; repair, upkeep and installation of equipment and apparatus using renewable energy, heating apparatus and equipment, air cooling and conditioning, apparatus and equipment for hot water supply and sanitary installations; building of permanent structures; installing, servicing and repair of machines. Services for the transmission and distribution of electricity generated from renewable resources; transporting electricity from one place to another by pipeline; consultancy and advice services related to the transmission and distribution of electricity generated from renewable resources; distribution of energy and electricity, as well as distribution and supply of water; electricity distribution via cables; storage of electricity; electricity supply and distribution; providing information relating to the distribution of electricity; leasing the use of power lines to third parties for the transmission of electricity; installation of pipe systems for conducting of electricity. Rental of equipment for the treatment and transformation of materials, for energy production and for custom manufacturing; custom manufacture of components for cable systems for bulk power transfer. Scientific, technological, research and design services in the field of renewable energy, namely, scientific analysis and testing, technological design, and research and design services; development of energy power management systems, namely, product development and development of new technology for others; consultancy in the field of renewable energy and energy saving; engineering drawing; quality control; technical construction projects development, namely, construction drafting; services of engineers and scientists who undertake evaluations, estimates, research and reports in the scientific and technological fields, including technological consultancy; design of manufacturing methods.

Goods & Services

Apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; apparatus, instruments and cables for conducting electricity, namely, electrical cables; power cables; electric cables and wires; underwater power cables; heat resistant electric cables; cryogenic pipes with integrated electrical cable for delivering electricity; mineral insulated cables for electricity; electric conductors; flexible sheaths for electric conductors; photovoltaic apparatus and installations for generating solar electricity, namely, photovoltaic cells and modules; apparatus and instruments for controlling electricity; apparatus and instruments for transforming electricity; apparatus and instruments for regulating electricity; apparatus and instruments for accumulating electricity Cooling installations for cables; deep-cold keeping and cryogenic technology apparatus, namely, cryogenic freezers; cryostats, other than for laboratory use; cooling apparatus for the preparation of deep cold temperatures for preserving electric cables Construction of ocean, solar and wind powered plants; building construction supervision; services relating to the construction of transmission lines, namely, construction supervision services; providing information on repair services in the field of energy systems; electric appliance installation and repair; providing information on construction and building; repair, upkeep and installation of equipment and apparatus using renewable energy, namely, in renewable energy plants, heating apparatus and equipment, air cooling and conditioning apparatus and equipment, apparatus and equipment for hot water supply and sanitary installations; building construction, namely, building of permanent structures; installing, servicing and repair of power distribution machines Services for the transmission and distribution of electricity generated from renewable resources, namely, distribution and transmission of electricity leasing the use of power lines to third parties for the transmission of electricity; distribution and transmission of electricity, namely, transporting electricity from one place to another by pipeline; consultancy and advice services related to the transmission and distribution of electricity generated from renewable resources; distribution of energy and electricity, as well as distribution and supply of water; electricity distribution via cables; storage of electricity; electricity supply and distribution; providing information relating to the distribution of electricity; leasing the use of power lines to third parties for the transmission of electricity; installation of pipe systems for conducting of electricity Rental of equipment for the treatment and transformation of materials, for energy production and for custom manufacturing; custom manufacture of components for cable systems for bulk power transfer Scientific, technological, research and design services in the field of renewable energy, namely, scientific analysis and testing, technological design, and research and design services; development of energy power management systems, namely, product development and development of new technology for others; consultancy in the field of renewable energy and energy saving; engineering drawing services; quality control for others; technical construction projects development, namely, construction drafting; services of engineers and scientists who undertake evaluations, estimates, research and reports in the scientific and technological fields, in particular technological consultancy in the field of engineering; and design of manufacturing methods

Goods & Services

Metallic pipes for carrying cables supplying electricity. Measuring apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; apparatus, instruments and cables for electricity; power cables; cables and wires; underwater power cables; heat resistant electric cables; insulated cables for electricity; electric conductors; flexible sheaths for electric conductors; photovoltaic apparatus and installations for generating solar electricity; apparatus and instruments for controlling electricity; apparatus and instruments for transforming electricity; apparatus and instruments for regulating electricity; apparatus and instruments for accumulating electricity. Cooling installations for cables; Deep-cold keeping and cryogenic technology apparatus; cryostats, other than for laboratory use; cooling apparatus for the preparation of deep cold temperatures. Non-metallic pipes for carrying cables supplying electricity. Construction of power plants; building construction supervision; construction of transmission lines; repair information in the field of energy systems; electric appliance installation and repair; information on construction and building; repair, upkeep and installation of equipment and apparatus using renewable energy, heating apparatus and equipment, air cooling and conditioning, apparatus and equipment for hot water supply and sanitary installations; building of permanent structures; installing, servicing and repair of machines; installation of pipe systems for conducting of electricity. Transmission and distribution of electricity generated from renewable resources; transporting electricity from one place to another by pipeline; consultancy and advice services related to the transmission and distribution of electricity generated from renewable resources; distribution of energy and electricity, as well as distribution and supply of water; electricity distribution via cables; Storage of electricity; Electricity supply and distribution; providing information relating to the distribution of electricity; leasing the use of power lines to third parties for the transmission of electricity. Rental of equipment for the treatment and transformation of materials, for energy production and for custom manufacturing; custom manufacture of components for cable systems for bulk power transfer. Scientific, technological, research and design services in the field of renewable energy, namely, scientific analysis and testing, technological design, and research and design services; development of energy power management systems, namely, product development and development of new technology for others; consultancy in the field of renewable energy and energy saving; engineering drawing; quality control; technical construction projects development, namely, construction drafting; services of engineers and scientists who undertake evaluations, estimates, research and reports in the scientific and technological fields, including technological consultancy; Design of manufacturing methods.

Goods & Services

Educational and training services; arranging congresses, seminars, symposiums and conferences relating to the climate; publication of educational and training guides; business mentoring services; training services related to business; training services relating to business management; conducting of educational courses in business; educational and training services in the field of mitigating climate change; Educational and training services in the field of mitigating climate change in agriculture; education and training services in the field of new grid enhancing technologies, opportunities and challenges, promote the trialling of new technology on power systems, and increase awareness of the benefits of new technology; dissemination of educational and training material in the nature of project briefs and reports, benchmarking, setting of educational and training standards and best practices; publication of documents relating to climate change and green energy in the nature of project briefs, reports, benchmarking, setting of standards and promotion of best practices.

Goods & Services

Machines and apparatus for generating electricity from renewable resources and in particular wind, wave and solar power. Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signalling, checking (supervision) apparatus and instruments; apparatus and instruments for conducting, switching, transferring, accumulating, regulating and controlling electricity; electric cables. Construction, installation, maintenance and repair of installations for generating electricity from renewable resources and in particular ocean, solar and wind powered plants; advise and consultancy services in relation to the aforesaid. Services for the supply and distribution of electricity generated from renewable resources; advice and consultancy services in relation to the aforesaid. Services for the generation of electricity from renewable resources; advice and consultancy services relating to the aforesaid. Scientific, technological, research and design services in the field of renewable energy; development of energy power management systems.
