Globe Union Industrial Corp. (Taiwan, Province of China)
Inventor
Yang, Chao-Ta
Chen, His-Tsung
Abstract
A quick install nut is provided. The nut includes an entrance end, an exit end, a first threaded portion corresponding to the entrance end, a second threaded portion corresponding to the exit end and connected with the first threaded portion. The first threaded portion includes a first slot, a segment of first internal thread formed in the first slot, and a first relief space communicating with the first slot radially. The second threaded portion includes a second slot, a segment of second internal thread formed in the second slot, and a second relief space communicating with the second slot radially. The first and the second slots are disposed on a central axis in a staggered manner. A compression wall is formed on the first threaded portion. After being tilted, the nut is placed and moved along a threaded fastener and returned to achieve fast and firm fastening.
Globe Union Industrial Corp. (Taiwan, Province of China)
Inventor
Chang, Yuan-Hao
Yuan, Chia-Hua
Abstract
A thermostatic valve set and a valve assembly containing the same are provided. The thermostatic valve set includes a thermostatic valve and an adapter, both able to switch between a first assembled state and a second assembled state and assembled. The valve assembly includes a seat for mounting the thermostatic valve set and a valve cap for fastening the thermostatic valve set to the seat. The adapter is mounted in a mounting groove of the seat in an oriented manner. When the thermostatic valve set is installed in the second assembled state, it can be positioned on a seat with reversed cold-water and hot-water supplies. The reversed condition is corrected and the thermostatic valve can work well. By the above thermostatic valve set, the valve assemblies are installed back-to-back without modification or rearrangement of the hot-water and the cold-water supply pipelines. Thereby installation time and cost are reduced.
F16K 11/00 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid
Globe Union Industrial Corp. (Taiwan, Province of China)
Inventor
Chang, Jih-Tung
Abstract
A connector assembly for connecting a valve seat with an outlet pipe and a faucet having the same are provided. The valve seat includes an outlet channel provided with an insertion hole and a first axial connection portion arranged at an outer cylindrical wall thereof. The first axial connection portion is located below the insertion hole. The outlet pipe includes an inlet end provided with a mounting portion and a second axial connection portion arranged at an outer surface of the outlet pipe and located close to the mounting portion. The second axial connection portion is detachably mounted into the first axial connection portion from bottom up to form a rotation point. By the outlet pipe rotated around the rotation point, the mounting portion is forced to be mounted and positioned inside the insertion hole of the valve seat firmly with sealing effect.
F16K 27/00 - Construction of housingsUse of materials therefor
E03C 1/04 - Water-basin installations specially adapted to wash-basins or baths
F16K 11/00 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid
06 - Common metals and ores; objects made of metal
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
(1) Bathtub grab bars of metal; metal clothes hooks; shower grab bars of metal
(2) Bathroom accessories, namely, towel bars, towel rings, toilet paper holders, toilet roll holders, soap dispensers
06 - Common metals and ores; objects made of metal
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
(1) Bathtub grab bars of metal; metal clothes hooks; shower grab bars of metal
(2) Bathroom accessories, namely, towel bars, towel rings, toilet paper holders, toilet roll holders, soap dispensers
06 - Common metals and ores; objects made of metal
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
(1) Bathtub grab bars of metal; metal clothes hooks; shower grab bars of metal
(2) Bathroom accessories, namely, towel bars, towel rings, toilet paper holders, toilet roll holders, soap dispensers
06 - Common metals and ores; objects made of metal
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
metal clothes hooks, shower grab bars of metal, bathtub grab bars of metal Bathroom accessories, namely, towel bars, towel rings, toilet paper holders, toilet roll holders
06 - Common metals and ores; objects made of metal
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
metal clothes hooks, shower grab bars of metal, bathtub grab bars of metal Bathroom accessories, namely, towel bars, towel rings, toilet paper holders, toilet roll holders
06 - Common metals and ores; objects made of metal
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
metal clothes hooks, shower grab bars of metal, bathtub grab bars of metal Bathroom accessories, namely, towel bars, towel rings, toilet paper holders, toilet roll holders
Globe Union Industrial Corp. (Taiwan, Province of China)
Inventor
Yuan, Chia-Hua
Chen, His-Tsung
Abstract
A connection assembly for a toilet contains: a toilet flange, two positioning elements, two T-shaped screw nuts, two guiders, and two locking elements. The toilet flange is fixed on a floor of a building, and the toilet flange includes a hub, an annular fringe, two receiving grooves, two through orifices, and an elongated slot. A respective one positioning element includes a locating portion and two flexible wings. The locating portion has a passing orifice. A respective one T-shaped screw nut includes a head and a tubular. A respective one guider is removably fixed on the locating portion of to be received in a respective one fixing orifice of two fixing orifices of the toilet. A respective one locking element is screwed with the threaded orifice, after at least one part of the respective one guider is removed, and the toilet is locked on the toilet flange.
Globe Union Industrial Corp. (Taiwan, Province of China)
Inventor
Li, Chun-Hung
Yu, Yung-Cheng
Tsai, Jiun-Li
Chu, Chu-Cheng
Ni, Kuo-Tung
Abstract
A free-standing faucet which includes a valve assembly, a spout, an inlet tube set, and a free-standing casing tube, a spray holder, and a spray is revealed. The valve assembly consists of a housing, a mixing valve, and a diverter, and a handle. The housing is composed of a mixing valve chamber in which the mixing valve is mounted, a pipe joint connected to the inlet tube set, a connection portion formed on one side of the pipe joint close to the mixing valve chamber, a first cold water channel, and a first hot water channel. The first hot and cold water channels are formed inside the pipe joint and communicating with the connection portion and the inlet tube set. An adapter is connected to the connection portion and having second cold and hot water channels. Thereby the mixing valve can be assembled and positioned easily, securely and accurately.
F16K 11/00 - Multiple-way valves, e.g. mixing valvesPipe fittings incorporating such valvesArrangement of valves and flow lines specially adapted for mixing fluid
E03C 1/04 - Water-basin installations specially adapted to wash-basins or baths
GLOBE UNION INDUSTRIAL CORP. (Taiwan, Province of China)
Inventor
Li, Chunhung
Hsu, Chaoyen
Ni, Kuotung
Lin, Yiping
Abstract
A rough-in assembly for free-standing faucets is revealed. The rough-in assembly having at least a part thereof fixed under a floor includes a base, a first water-contact member and a second water-contact member separated from each other and disposed on the base, and a sleeve mounting seat connected to the base and provided with a top plate portion extending across the first and second water-contact members. Two first hollow-out holes are arranged at the top plate portion and corresponding to control valve sets of the water-contact members respectively. The top plate portion is also for installation and positioning of the free-standing faucet. The position and the direction of least one of the water-contact members can be adjusted so that the rough-in assembly is adapted to use in different water supply pipe arrangements. The disposition of the sleeve mounting seat ensures stability and aesthetics of the free-standing faucet.
Globe Union Industrial Corp. (Taiwan, Province of China)
Inventor
Zhou, Hongsheng
Wang, Yanjun
Li, Shaoqing
Liu, Zhiqiang
Li, Wenjuan
Abstract
A flush toilet is revealed. The flush toilet includes a bowl portion, a drain pipe, an inlet channel, a first outlet channel, a second outlet channel, and a jet channel. The first and second outlet channels are turned into different directions from diversion area of the inlet channel. The second outlet channel further includes a curved potion for changing the direction of water flow so that the direction of a second water flow out of the second outlet channel and along a shed portion of the bowl portion is consistent with the direction of a first water flow out of the first outlet channel and along the shed portion. Thus the first and second water flows are out almost synchronously throughout the bowl portion and combined to form a swirling flow which interacts with a third water flow from the jet channel to create a siphon effect for better waste removal.
GLOBE UNION INDUSTRIAL CORP. (Taiwan, Province of China)
Inventor
Zhou, Hongsheng
Wang, Yanjun
Lin, Shaoqing
Liu, Zhiqiang
Li, Wenjuan
Abstract
A flush toilet is revealed. The flush toilet includes a bowl portion, a drain pipe, an inlet channel, a first outlet channel, a second outlet channel, and a jet channel. The first and second outlet channels are turned into different directions from diversion area of the inlet channel. The second outlet channel further includes a curved portion for changing the direction of water flow so that the direction of a second water flow out of the second outlet channel and along a shed portion of the bowl portion is consistent with the direction of a first water flow out of the first outlet channel and along the shed portion. Thus the first and second water flows are out almost synchronously throughout the bowl portion and combined to form a swirling flow which interacts with a third water flow from the jet channel to create a siphon effect for better waste removal.
Globe Union Industrial Corp. (Taiwan, Province of China)
Inventor
Li, Chunhung
Hsu, Chaoyen
Ni, Kuotung
Lin, Yiping
Abstract
A rough-in assembly for free-standing faucets is revealed. The rough-in assembly having at least a part thereof fixed under a floor includes a base, a first water-contact member and a second water-contact member separated from each other and disposed on the base, and a sleeve mounting seat connected to the base and provided with a top plate portion extending across the first and second water-contact members. Two first hollow-out holes are arranged at the top plate portion and corresponding to control valve sets of the water-contact members respectively. The top plate portion is also for installation and positioning of the free-standing faucet. The position and the direction of least one of the water-contact members can be adjusted so that the rough-in assembly is adapted to use in different water supply pipe arrangements. The disposition of the sleeve mounting seat ensures stability and aesthetics of the free-standing faucet.
GLOBE UNION INDUSTRIAL CORP. (Taiwan, Province of China)
Inventor
Li, Chun-Hung
Chiu, Hui-Ling
Tsai, Tun-Yao
Abstract
A shower head includes a housing, and a jet faceplate mounted to the housing and including a first water jetting area composed of a plurality of subunits and a second water jetting area having a second jet hole therein. The subunits are arranged to present an arc-shaped distribution, each defining therein a plurality of first jet holes. The subunits are in a fan-shaped area of the jet faceplate so that the water line of the ejected water can be concentrated and fan-shaped, enhancing the effect of removing dirt.
Globe Union Industrial Corp. (Taiwan, Province of China)
Inventor
Li, Chunhung
Yu, Yung-Cheng
Tsai, Jiun-Li
Chu, Chu-Cheng
Abstract
A rough-in assembly for mounting a free-standing faucet on a floor is revealed. The rough-in assembly includes a mounting base, a connection tube set having cold-water and hot-water connection tubes, a fixing plate, and a plurality of nuts. The mounting base consists of a bottom plate fixed on a laminated wood, a tube-fixing portion positioned on the bottom plate and provided with two locking slots, and a plurality of bolts projecting from the bottom plate and inserted through a mounting hole on the floor. The cold-water and hot-water connection tubes are locked in the two locking slots of the tube-fixing portion. The fixing plate allows the bolts of the mounting base to pass therethrough. The nuts are threaded on the bolts for fastening the fixing plate on the floor. Thereby the free-standing faucet is secured on the floor firmly and production cost is dramatically reduced.
