The cooling system comprises at least a cooling wall and a tube for circulating a coolant. The tube is held against the cooling wall by being disposed between this cooling wall and a fixing plate fixed to this wall, particularly by clinching.
Disclosed is a clamping collar comprising a belt (12) bearing a first and a second clamping lug, the collar comprising a clamping rod (14) configured to be retained relative to the first clamping lug (20A) and the second clamping lug respectively by a first stop (30A) borne by the clamping rod and by a second stop. The first clamping lug (20A) has a first bore configured to be passed through by the clamping rod (14) such that the first stop (30A) is retained at the rear of the first bore. The first bore communicates with a first passage opening configured to be passed through by the first stop borne by the clamping rod.
The invention relates to a clamping collar comprising a belt having a geometric winding axis and bearing two clamping lugs (70A, 70B) that can be moved relative to one other by means of a clamping member (14A, 14B, 14C) for clamping the belt, wherein at least one of the clamping lugs, referred to as a triangle-shaped lug, has, when viewed along the winding axis, a triangular shape with a base (71A, 71B) extending substantially along the circumference of the belt and an outer vertex located radially outside the belt, wherein the outer vertex is connected to the base by a front wall (72A, 72B) and a rear wall (73A, 73B), and wherein these walls form, together with the base, the three sides of the triangle. The triangle-shaped lug is at least partially formed in one piece with the band, in a terminal portion of the band that is folded to define the triangular shape, and the terminable portion of the band of the belt is folded onto itself to form a double thickness, at least in one portion of the triangle.
The mounting device for mounting an accessory on a strapping strip comprises a support strip comprising a fixing area for an accessory, a slide system for retaining the support strip relative to the strapping strip while allowing the support strip to slide along the strapping strip and a locking system for blocking this sliding in a given position of the support strip relative to the strapping strip.
F16M 13/02 - Other supports for positioning apparatus or articlesMeans for steadying hand-held apparatus or articles for supporting on, or attaching to, an object, e.g. tree, gate, window-frame, cycle
The clamping device comprises a belt with at least a first and a second clamping end and a clamping member which connects the two clamping ends while being retained relative to them so that the clamping of the clamping member moves the first and second clamping ends relative to each other by clamping the belt. The clamping member is retained relative to at least the first clamping end via a spring and a connecting piece, so that the clamping of the clamping member tends to move the connecting piece relative to the first clamping end against the elastic return of the spring. The connecting piece is able to occupy, relative to the first clamping end, a waiting position in which it holds the spring with respect to the first clamping end.
F16B 2/08 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening external, i.e. with contracting action using bands
The cooling system comprises at least one cooling wall (10) and a tube (22) for circulating a coolant fluid. The tube is held against the cooling wall by being arranged between said cooling wall and a securing plate (24) that is secured to said wall, in particular by clinching.
06 - Common metals and ores; objects made of metal
Goods & Services
Refractory construction materials of metal; transportable buildings of metal; fastening systems of common metal for fastening solar panels to buildings, comprised of clamps, fishplates, rivets, self-drilling screws, rail supports and rail stops; metal fasteners for photovoltaic systems, namely, clamps, rivets, and self-drilling screws; metal fixation devices, namely, clamps, rivets, and self-drilling screws; metal fasteners being hardware, namely, clamps, rivets, and self-drilling screws; metal shelter structures; transportable buildings of metal, namely canopy of metal incorporating solar cells and metal structures for mounting solar panels; shade houses, namely metal shelter structures; roofing, of metal, incorporating photovoltaic cells; roof supports of metal; metallic clamping collars, namely, metal clamps for fastening pipes; screw rings of metal; flanges of metal; clamps of metal; clips of metal for metal structures; metal clamps for metal structures; screw clamps of metal; hand clamping screws of metal being fasteners; junctions of metal for pipes.
8.
Clamping system for connecting tubes, comprising a collar and a seal
The clamping system is used to connect a first and a second tube whose facing ends have bearing surfaces protruding relative to their cylindrical external surface. The clamping system has a clampable collar and a seal. The collar includes a belt able to cooperate with the bearing surfaces of the tubes by this internal periphery delimiting a recess into which the bearing surfaces can be inserted. The seal is supported by the collar in the unclamped state of the latter and has an annular sealing portion which includes a metal washer and a non-metal based washer fixed to the metal washer. The metal washer can carry support lugs to support the washers relative to the collar.
F16L 23/08 - Flanged joints the flanges being connected by members tensioned in the radial plane connection by tangentially arranged pin and nut
F16L 17/04 - Joints with packing adapted to sealing by fluid pressure with sealing rings arranged between outer surface of pipe and inner surface of sleeve or socket with longitudinally split or divided sleeve
F16L 21/06 - Joints with sleeve or socket with a divided sleeve or ring clamping around the pipe ends
F16L 21/08 - Joints with sleeve or socket with additional locking means
F16L 23/18 - Flanged joints characterised by the sealing means the sealing means being rings
F16L 23/22 - Flanged joints characterised by the sealing means the sealing means being rings made exclusively of a material other than metal
9.
Clamping system for connecting tubes, comprising a collar and a seal
The clamping system is used to connect a first and a second tube whose facing ends have bearing surfaces protruding relative to their cylindrical external surface. The clamping system has a clampable collar and a seal. The collar includes a belt able to cooperate with the bearing surfaces of the tubes by this internal periphery delimiting a recess into which the bearing surfaces can be inserted. The seal is supported by the collar in the unclamped state of the latter and includes an annular sealing portion which includes a first washer and a second washer fixed to the first washer by retaining lugs carried by the first washer.
F16L 23/08 - Flanged joints the flanges being connected by members tensioned in the radial plane connection by tangentially arranged pin and nut
F16L 17/04 - Joints with packing adapted to sealing by fluid pressure with sealing rings arranged between outer surface of pipe and inner surface of sleeve or socket with longitudinally split or divided sleeve
F16L 21/06 - Joints with sleeve or socket with a divided sleeve or ring clamping around the pipe ends
F16L 21/08 - Joints with sleeve or socket with additional locking means
F16L 23/18 - Flanged joints characterised by the sealing means the sealing means being rings
F16L 23/22 - Flanged joints characterised by the sealing means the sealing means being rings made exclusively of a material other than metal
10.
Mounting assembly including two end pieces held fitted by a belt
A mounting assembly including two end pieces whose ends are able to be fitted along an axis and a mounting belt disposed around the second end piece in a pre-mounted configuration before the fitting of the first end piece by an opening delimited by a first edge of the belt. The end pieces have respectively a first and a second centering surface able, in the fitted state, to axially overlap and to come into contact to limit the relative clearances of the end pieces. The belt carries a retaining lug which extends outside the belt. In the pre-mounted state, the end pieces are retained in the fitted state by the combination of contact of the centering surfaces and cooperation of the free end of the retaining lug with a bearing surface of the first end piece located on the side of the first edge of the belt.
A fixing piece (30) for fixing a panel to a profile section comprises a flat plate (32) having a front edge (32A) and a rear edge (32B) that are opposite edges in a front-rear direction, the front edge having a flap (34) which extends above the plate so that an insertion slot is delimited between the flap and the plate. The rear edge bears an upwardly extending end stop backrest (36) The fixing piece also has a right hook (38D) and a left hook (38G) which extend downwards from the plate while being spaced apart from one another in a right-left direction. The right hook and the left hook each have at least one catching edge, the catching edges of the right hook and of the left hook being configured to catch on two distinct surfaces.
06 - Common metals and ores; objects made of metal
Goods & Services
Construction materials of metal; transportable buildings of
metal; hardware of metal; fastening systems of common metal;
metal fasteners for photovoltaic systems; metal fixation
devices; metal fasteners [hardware]; metal shelter
structures; transportable structures of metal; shade houses
[metal structures]; roofing, of metal, incorporating
photovoltaic cells; roof supports of metal; metallic
clamping collars; rings of metal; flanges of metal
[collars]; clamps [collars] of metal; clips of metal for
metal structures; clamps for metal structures; screw clamps
of metal; hand clamping screws of metal [fasteners];
junctions of metal.
13.
Clamping system comprising a collar and a pre-mounting clip
A clamping system to connect a first and a second tube whose facing ends have protruding clamping surfaces is provided. The system comprises a collar comprising a belt able to be clamped around the clamping surfaces. The belt has a first and a second flank between which an internal recess able to receive the clamping surfaces is delimited. The collar carries an outer retaining clip comprising a retaining segment located on the side of the first flank and a first and a second link return linking respectively the retaining segment to a first and a second retaining member located on the side of the second flank. The collar is retained axially between the retaining segment and the first and second retaining members. The retaining segment is able to be elastically deformed to allow the insertion of the end of the tube and to retain it pre-mounted in the collar.
The clamping system is used for connecting a first tube and a second tube, the facing ends of which have bearing surfaces that protrude from the cylindrical outer surface thereof. The clamping system comprises a collar (10) that can be tightened as well as a seal (20). The collar comprises a belt (12) capable of interacting with the bearing surfaces of the tubes by the inner periphery delimiting a reinforcement into which the bearing surfaces can be inserted. The seal (20) is supported by the collar in the non-tightened state thereof and comprises an annular sealing portion (21) which comprises a metal washer (22) and a non-metal washer (24) fastened to the metal washer. The metal washer can carry support legs (30, 32) to support the washers relative to the collar.
The clamping system is used for connecting a first tube and a second tube, the facing ends of which have bearing surfaces that protrude from the cylindrical outer surface thereof. The clamping system comprises a collar (10) that can be tightened as well as a seal (20). The collar comprises a belt (12) capable of interacting with the bearing surfaces of the tubes by the inner periphery delimiting a reinforcement into which the bearing surfaces can be inserted. The seal (20) is supported by the collar in the non-tightened state thereof and comprises an annular sealing portion (21) which comprises a first washer (22) and a second washer (24) fastened to the first washer by retaining tabs that the first washer carries.
The clamping system is used for connecting two pipes whose facing ends have protruding bearing surfaces. The clamping system comprises a collar that can be clamped and a washer. The collar includes a belt whose internal periphery delimits a recess into which the bearing surfaces can be inserted. The washer comprises an annular part disposed inside the belt and carrying support lugs which have a hook configured to hook on an edge of the belt and a link section which extends between the annular part and the hook. The link section carries at least one retaining wing bent radially outwardly and having a retaining edge, the retaining wing having a width, measured axially, which decreases towards its free end, the edge of the belt being housed in the space formed between the retaining edge and the hook.
06 - Common metals and ores; objects made of metal
Goods & Services
Metal materials for construction; Buildings, transportable, of metal; Metal hardware; Fasteners of common metal; Fasteners of metal for photovoltaic installations; Fixing devices of metal; Metallic mountings; Structures of metal; Buildings, transportable, of metal; Shade houses [structures of metal]; Roofing of metal, incorporating photovoltaic cells; metal braces for roofing; Metal hose clamps; Rings of metal; Flanges of metal [collars]; Mounting flanges of metal; Collars of metal for fastening structures of metal; Clamps for structures of metal; Screw clamps of metal; Thumbscrews [fasteners] of metal; Fittings of metal for pipes.
Clamping system for connecting two tubes having protruding clamping surfaces. The system comprises a collar having a strip able to cooperate with the clamping surfaces. The strip has a first and a second flank between which an inner recess able to receive the clamping surfaces is delimited. The system has at least one retaining clip having a cross-member which extends across the inner recess, a first and a second wing which extend radially outwardly relative to the cross-member by covering the flanks and a first and a second retaining configuration each having at least one retaining lug. The cross-member is able to be deformed to penetrate into the inner recess.
The clamping collar comprises a metal belt carrying a protruding lug in the vicinity of a first end and a hook in the vicinity of a second end. The hook has a front wall and a common part. The wall is intended to be retained behind the lug while the hook is hooked on the lug to keep the collar in the clamped state. The common part links the front wall to the belt and has a gripping surface protruding radially outwardly and two lateral borders which extend axially on either side of the gripping surface by being radially set back from the gripping surface.
F16L 33/035 - Hose-clips fixed by means of teeth or hooks
F16B 2/06 - Clamps, i.e. with gripping action effected by positive means other than the inherent resistance to deformation of the material of the fastening external, i.e. with contracting action
A clamping system for connecting a first and a second tube whose opposite ends have clamping surfaces protruding from the cylindrical outer surface of said tubes. The system comprises a collar which comprises a belt able to be clamped around said clamping surfaces, the belt having a first and a second flank between which an internal recess able to receive the clamping surfaces is delimited. The collar carries at least one retaining finger which has a free end portion protruding axially beyond the edge of the first flank, said free end portion having a retaining edge configured to be retained outside the belt by a radially protruding element.
A clamping system for connecting a first tube and a second tube, the clamping system including a collar which includes a belt able to be clamped around clamping surfaces of the first and second tubes, the belt has a first and a second flank between which an internal recess able to receive the clamping surfaces is delimited. The collar carries at least one retaining loop disposed outside the belt. The loop has a first end fastened to the collar and a second end which is free and which is located on the outer side of the first flank. The loop is able to adopt a position of active retaining configuration in which its second end protrudes towards the axis of the collar relative to the edge of the first flank, and to be deformed relative to this active configuration so that the second end is moved radially outwardly.
F16L 23/08 - Flanged joints the flanges being connected by members tensioned in the radial plane connection by tangentially arranged pin and nut
F16L 23/036 - Flanged joints the flanges being connected by members tensioned axially characterised by the tensioning members, e.g. specially adapted bolts or C-clamps
F16L 23/18 - Flanged joints characterised by the sealing means the sealing means being rings
F16L 23/026 - Flanged joints the flanges being connected by members tensioned axially characterised by how the flanges are joined to, or form an extension of, the pipes by welding
A clamping system for connecting a first and a second tube whose opposite ends have clamping surfaces protruding from the cylindrical outer surface of the tubes. The system includes a collar having a belt able to be clamped around the clamping surfaces. The belt includes a first and a second flank between which an internal recess able to receive the clamping surfaces is delimited. The collar carries an external retaining device having a retaining bar, which protrudes axially from the first flank while being oriented transversely to the axis of the collar and which has a transverse retaining ridge, the bar being able, from a rest situation in which the retaining ridge projects towards the axis of the collar relative to the edge of the first flank in the unclamped situation of the collar, to be elastically deformed to space the retaining ridge away from the axis of the collar.
F16L 23/16 - Flanged joints characterised by the sealing means
F16L 23/08 - Flanged joints the flanges being connected by members tensioned in the radial plane connection by tangentially arranged pin and nut
F16L 23/036 - Flanged joints the flanges being connected by members tensioned axially characterised by the tensioning members, e.g. specially adapted bolts or C-clamps
A clamping device including a collar which has a belt able to be clamped by the reduction of its diameter and a seal disposed inside the belt by being retained axially relative to the collar. The seal is formed in a strip which is wound on itself and whose ends are configured to cooperate together via a sealing arrangement. The seal undergoes a stress towards the inner surface of the belt and is configured to be elastically deformed against the stress to allow the insertion of an annular object between the seal and the belt.
The tightening device includes a belt (10) having a first and a second end (10A, 10B) and a first and a second tightening lug (14A, 14B) carried by the belt which are formed respectively in a first and a second band portion (12A, 12B) respectively fastened to the outer face of the belt (10) in the vicinity of its first and its second end (10A, 10B). At least the first band portion (12A) is fastened to the belt (10) through at least a first fastening area (18A) formed on a boss (18′A) of the first band portion (12A) protruding inwardly and/or a boss of the belt protruding outwardly.
A belt has a sealing ring disposed in an annular recess of the belt and two tightening lugs born by the ends of the belt. The edges of the recess form wedging steps for the edges of the sealing ring which substantially occupy the entire width of the recess. The ends of the belt exhibit a sealing arrangement which includes lateral tabs, that are formed at the second end and which extend widthwise on the belt, from one edge of the belt to the recess such that each lateral tab includes a part of one of the wedging steps.
A clamping system for connecting a first tube and a second tube whose facing ends have projecting clamping surfaces includes a collar having a belt able to be clamped around the clamping surfaces and a washer supported by the collar. The belt includes a first and a second sidewall between which is delimited an internal recess able to receive the clamping surfaces. The washer carries at least one foldable retaining finger which has a free end portion projecting axially beyond a first edge of the belt over a distance sufficient to allow manual manipulation thereof, the free end portion having a retaining edge configured, when the end portion is folded towards the axis of the belt, to be retained outside the belt by a radially projecting element.
The device includes a sealing sleeve suitable for being disposed around the facing ends of two tubes and a clamping sleeve inside which the sealing sleeve extends. One of the elements constituted by the sealing sleeve and by the clamping sleeve has at least one retaining member suitable for co-operating in axial retention inside the clamping sleeve with a retaining surface of one of the tubes, which retaining surface is covered by the clamping sleeve.
The clamping system comprises a collar that comprises a belt suitable for being clamped around clamping surfaces projecting from tubes. The collar carries a series of angularly distributed foldable fingers, each finger presenting a free operating end projecting axially beyond the first edge of the belt over a distance that is sufficient to enable it to be manipulated by hand. Starting from an initial position in which the fingers define a rest minimum diameter, the fingers are suitable for being folded manually and plastically towards the axis of the belt in order to define a folded-in minimum diameter that is less than said rest minimum diameter.
06 - Common metals and ores; objects made of metal
Goods & Services
Clip clamps of metal; Stop collars of metal; Crimping rings of metal; Flanges of metal (collars); Metal nuts; Clamping and sealing collars of stainless steel; Clamps for exhaust pipes; Clamps of metal for electric cables and ducts; Screw clamps of metal; Junctions of metal for pipes.
06 - Common metals and ores; objects made of metal
08 - Hand tools and implements
17 - Rubber and plastic; packing and insulating materials
20 - Furniture and decorative products
Goods & Services
Ironmongery; cable ties, of metal; junctions of metal for flexible or rigid pipework; fastening devices and straps of metal; fastening collars of metal; clips of metal for cables and pipes; connectors of metal. Hand tools and implements (hand operated); clamps and pneumatic clamps (hand-operated). couplings, not of metal, for flexible or rigid pipework; semi-finished plastic products; connectors, not of metal. Fastening devices and straps of plastic; cable and pipe clips of plastic.
06 - Common metals and ores; objects made of metal
21 - HouseHold or kitchen utensils, containers and materials; glassware; porcelain; earthenware
Goods & Services
Articles de quincaillerie, notamment colliers de serrage
pour tuyaux, tous ces produits étant en métal. Raccords pour tuyauteries souples et pour articles
d'arrosage.
