An endcap, e.g. for a linear luminaire. The endcap has projecting structure attached to and projecting from an inner surface thereof. The projecting structure defines at least two positions aligned with and spaced from one another along the inner surface. One or more crush ribs are connected to the projecting structure at each of the at least two positions. A trough is recessed into the inner surface of the endcap and surrounds at least a portion of each of the at least two positions. The trough provides space to receive any material that is separated from the one or more crush ribs when the endcap is inserted into a channel.
F21V 15/015 - Devices for covering joints between adjacent lighting devicesEnd coverings
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
A printed circuit board (PCB) is adapted to accept high-voltage, alternating-current (AC) power. Mounted on the PCB are two series of LED light engines. A first series of LED light engines is configured to illuminate during a first portion of the AC power cycle, and a second series of LED light engines is configured to illuminate during a second portion of the AC power cycle. The first portion and the second portion are different from one another. For example, the first series may be configured to illuminate during the positive half-cycle, and the second series may be configured to illuminate during the negative half-cycle. LED light engines of the first series and the second series may be interdigitated with one another on the PCB.
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 19/00 - Fastening of light sources or lamp holders
A set of louvers (20) adapted for use with a linear luminaire (10) has a first wall (22), a second wall (24) spaced from the first wall (22), and a plurality of louvers (30) extending between the first wall (22) and the second wall (24). Each of the plurality of louvers (30) is fixed to the first wall (22) and the second wall (24), and may be integrally formed with the walls, and each of the plurality of louvers (30) is spaced from the others. First and second side portions (47) depend from the first wall (22) and the second wall (24). An internal cavity (45) of the set of louvers is defined by bottoms of the plurality of louvers (30) and the first and second side portions (47). Engaging structures (42) are defined on surfaces of the first and second side portions (47) that face one another across the internal cavity (45).
F21V 11/06 - Screens not covered by groups , , or using crossed laminae or stripsScreens not covered by groups , , or using lattices or honeycombs
F21V 17/16 - Fastening of component parts of lighting devices, e.g. shades, globes, refractors, reflectors, filters, screens, grids or protective cages characterised by specific fastening means or way of fastening by deformation of parts of the lighting deviceSnap action mounting
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 15/01 - Housings, e.g. material or assembling of housing parts
F21V 17/00 - Fastening of component parts of lighting devices, e.g. shades, globes, refractors, reflectors, filters, screens, grids or protective cages
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
A filter circuit including a first common mode suppression module, a first differential mode suppression module, a first differential mode capacitor module, a second differential mode suppression module, a second common mode suppression module, a second differential mode capacitor module, a rectifier module, and a π-shaped filter module; the first differential mode suppression module is electrically connected with the first common mode suppression module and the second differential mode suppression module, the second common mode suppression module is electrically connected with the second differential mode suppression module and the rectifier module, and the rectifier module is electrically connected with the π-shaped filter module; the first differential mode capacitor module is connected between the first differential mode suppression module and the second differential mode suppression module, the second differential mode capacitor module is connected between the second common mode suppression module and the rectifier module.
A rotating bracket includes an endcap, a fastener, a support, a spacer, and securement structure. The endcap is adapted to fit an end of a linear lighting channel and has a keyed opening. The fastener has a keyed shank complementary to the keyed opening of the endcap and is adapted to be inserted into the endcap with the keyed shank of the fastener engaging the keyed opening of the endcap. The support has a slot or opening adapted to accommodate the fastener. The spacer is adapted to insert over the fastener such that it is positioned between the endcap and an inner face of the support. The securement structure engages the end of the fastener beyond an outer face of the support. Linear luminaires using the rotating bracket are also disclosed.
An electrical gang box adapted for use with drivers is disclosed. The electrical gang box includes a main compartment with a front opening sized and adapted to accept an electrical control and structure around the front opening to secure the electrical control within the front opening and within the main compartment. The electrical gang box also includes a lower compartment that extends below the main compartment, is set back from the front of the main compartment and is open to the main compartment along an upper portion. The gang box may also include one or more pairs of rails disposed on opposite interior walls. In such cases, a divider panel is sized to slide into and extend between the rails to divide the gang box. Multiple-gang boxes with these features are also disclosed.
A strip of encapsulated linear lighting with a partially encapsulated electrical connector is disclosed, as are processes for manufacturing such strips of encapsulated linear lighting. In these processes, connecting structure is connected to a strip of linear lighting. A portion of the connecting structure is then sheathed in a stopper. The stopper is used to dam a vessel or channel, the dammed vessel or channel is filled with resin, and the resin is caused or allowed to cure. The stopper protects the connecting structure from resin during the encapsulation process and leaves its contacts unencapsulated and exposed. The connecting structure can be connected to external structures, like a power cable or another segment of encapsulated linear lighting, after manufacture. A joint between the connecting structure and another structure can be overmolded or otherwise protected.
A regulator circuit and driver including the regulator circuit use a variable-resistance element, such as a transistor, to limit the current in the circuit when the current is above a defined current threshold. The circuit may be comprised of a first amplifier circuit that senses a current in the circuit and generates a voltage signal in proportion thereto. The circuit also includes a mechanism for controlling a voltage applied to the first circuit element to limit the current flow. That may be a second amplifier circuit that takes the voltage signal from the first op amp and a reference voltage and outputs a control voltage for the variable-resistance element, or it may be a digital computing device that outputs a control voltage that causes the variable-resistance element to stop current flow for some defined period of time around current peaks.
A set of louvers adapted for use with a linear luminaire has a first wall, a second wall spaced from the first wall, and a plurality of louvers extending between the first wall and the second wall. Each of the plurality of louvers is fixed to the first wall and the second wall, and may be integrally formed with the walls, and each of the plurality of louvers is spaced from the others. First and second side portions depend from the first wall and the second wall. An internal cavity of the set of louvers is defined by bottoms of the plurality of louvers and the first and second side portions. Engaging structure is defined on inwardly-facing surfaces of the first and second side portions. Combinations including the set of louvers and a linear luminaire in which the set of louvers “snaps on” externally to the linear luminaire are disclosed.
A strip of encapsulated linear lighting with a partially encapsulated electrical connector is disclosed, as are processes for manufacturing such strips of encapsulated linear lighting. In these processes, connecting structure is connected to a strip of linear lighting. A portion of the connecting structure is then sheathed in a stopper. The stopper is used to dam a vessel or channel, the dammed vessel or channel is filled with resin, and the resin is caused or allowed to cure. The stopper protects the connecting structure from resin during the encapsulation process and leaves its contacts unencapsulated and exposed. The connecting structure can be connected to external structures, like a power cable or another segment of encapsulated linear lighting, after manufacture. A joint between the connecting structure and another structure can be overmolded or otherwise protected.
F21S 4/24 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape of ribbon or tape form, e.g. LED tapes
F21V 23/06 - Arrangement of electric circuit elements in or on lighting devices the elements being coupling devices
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 15/01 - Housings, e.g. material or assembling of housing parts
A linear luminaire includes an enclosure with a top that is at least translucent. The enclosure may be extruded from a plastic or, in some cases, co-extruded with two different materials so that the pair of sidewalls can be made of an opaque material. The enclosure may be open along a bottom side opposite the top. In some embodiments, an elongate rigid printed circuit board (PCB) carrying LED light engines is installed between the pair of sidewalls in slot structure defined on respective inner faces. The PCB may carry connecting structure staggered along the length of its underside. In some embodiments, the PCB may be adapted to accept high-voltage alternating current (AC) directly, without converting the power to another form.
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 15/01 - Housings, e.g. material or assembling of housing parts
F21V 19/00 - Fastening of light sources or lamp holders
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
LED (light emitting diodes) lighting fixtures for use in display, commercial, industrial, residential, and architectural accent lighting applications; LED and HID light fixtures; LED flood light for decorative purposes
A linear luminaire includes a three-sided enclosure with a top that is at least translucent and a pair of depending sidewalls spaced apart by the top. The three-sided enclosure may be extruded from a plastic or, in some cases, co-extruded with two different materials so that the pair of sidewalls can be made of an opaque material. The three-sided enclosure may be open along a bottom aspect. An elongate rigid printed circuit board (PCB) carrying LED light engines is installed between the pair of sidewalls in slot structure defined on respective inner faces. The PCB may carry connecting structure staggered along the length of its underside. The PCB may also carry circuit components on its underside.
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
A connector for a strip of linear lighting includes an outer shell or block and an adapter configured to be removably inserted into a cavity of the outer shell. The adapter may be a printed circuit board (PCB) adapted to mount wires on one side or edge. On the opposite side or edge, a series of contact pins are formed on the underside of the adapter. The outer shell includes a pressure-applying mechanism, like screws that insert through its thickness and are secured in a bar with threaded holes. The adapter is positioned such that the screws bear on and supply pressure to the contact pins. A strip of linear lighting is inserted into a slot beneath the adapter such that the contact pins of the adapter coincide with the solder pads or other electrical contacts of the strip of linear lighting.
A connector for a strip of linear lighting includes an outer shell or block and an adapter configured to be removably inserted into a cavity of the outer shell. The adapter may be a printed circuit board (PCB) adapted to mount wires on one side or edge. On the opposite side or edge, a series of contact pins are formed on the underside of the adapter. The outer shell includes a pressure-applying mechanism, like screws that insert through its thickness and are secured in a bar with threaded holes. The adapter is positioned such that the screws bear on and supply pressure to the contact pins. A strip of linear lighting is inserted into a slot beneath the adapter such that the contact pins of the adapter coincide with the solder pads or other electrical contacts of the strip of linear lighting.
H01R 4/46 - Clamping area between two screws placed side by side
H01R 11/26 - End pieces terminating in a screw clamp, screw or nut
H01R 11/01 - Individual connecting elements providing two or more spaced connecting locations for conductive members which are, or may be, thereby interconnected, e.g. end pieces for wires or cables supported by the wire or cable and having means for facilitating electrical connection to some other wire, terminal, or conductive member, blocks of binding posts characterised by the form or arrangement of the conductive interconnection between their connecting locations
H01R 12/61 - Fixed connections for flexible printed circuits, flat or ribbon cables or like structures connecting to flexible printed circuits, flat or ribbon cables or like structures
H01R 12/81 - Coupling devices for flexible printed circuits, flat or ribbon cables or like structures connecting to another cable except for flat or ribbon cable
An electrical gang box adapted for use with drivers is disclosed. The electrical gang box includes a main compartment with a front opening sized and adapted to accept an electrical control and structure around the front opening to secure the electrical control within the front opening and within the main compartment. The electrical gang box also includes a lower compartment that extends below the main compartment, is set back from the front of the main compartment and is open to the main compartment along an upper portion. The gang box may also include one or more pairs of rails disposed on opposite interior walls. In such cases, a divider panel is sized to slide into and extend between the rails to divide the junction box. Multiple-gang boxes with these features are also disclosed.
A method for making continuous encapsulated linear lighting is disclosed. In this method, a PCB is placed within a channel, and the channel is dammed by one or more stoppers. The dammed segment is filled and then caused or allowed to cure. The stoppers are then removed from their initial positions and moved along the channel. If one runs out of channel before the desired length of linear lighting is achieved, a second piece of channel is abutted to the previous segment of channel, the PCB is laid into it, and a segment is dammed, filled, and cured. The process continues iteratively until the desired length is achieved or more channel is required. The PCB may initially be cut to the full desired length and applied to the channel piecewise as needed.
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 15/01 - Housings, e.g. material or assembling of housing parts
A method for making continuous encapsulated linear lighting is disclosed. In this method, a PCB is placed within a channel, and the channel is dammed by one or more stoppers. The dammed segment is filled and then caused or allowed to cure. The stoppers are then removed from their initial positions and moved along the channel. If one runs out of channel before the desired length of linear lighting is achieved, a second piece of channel is abutted to the previous segment of channel, the PCB is laid into it, and a segment is dammed, filled, and cured. The process continues iteratively until the desired length is achieved or more channel is required. The PCB may initially be cut to the full desired length and applied to the channel piecewise as needed.
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
B29C 70/68 - Shaping composites, i.e. plastics material comprising reinforcements, fillers or preformed parts, e.g. inserts by incorporating or moulding on preformed parts, e.g. inserts or layers
B29C 70/72 - Encapsulating inserts having non-encapsulated projections, e.g. extremities or terminal portions of electrical components
An under-counter lighting system places a light-guide panel (LGP) or a set of LGPs under a countertop, or another such work surface, in order to backlight it. Specifically, a base layer is secured to a support, such as a cabinet. The base layer includes a support layer and a number of support posts attached to the support layer. An LGP layer includes the LGP or LGPs. Each of the LGPs has openings that correspond to positions of the support posts, such that the LGPs receive the support posts through their thicknesses. A countertop is secured to the tops of the support posts and may have a depending lip or other such feature sufficient to hide the base layer and the LGP layer. The resulting light, usually at least partially transmitted through the countertop itself, can serve as ambient light, task light, or accent light, depending on the installation.
Connectors for linear lighting are disclosed. These connectors are adapted to electrically connect two strips of linear lighting, or a single strip of linear lighting and an appropriate number of wires. At least the portions of the connectors that accept the strips of linear lighting have sloped ramps that provide strain relief to the strips of linear lighting. Additionally, pivoting connectors that allow their sides to rotate relative to one another are disclosed.
F21K 9/00 - Light sources using semiconductor devices as light-generating elements, e.g. using light-emitting diodes [LED] or lasers
F21K 9/20 - Light sources comprising attachment means
F21K 9/27 - Retrofit light sources for lighting devices with two fittings for each light source, e.g. for substitution of fluorescent tubes
F21S 2/00 - Systems of lighting devices, not provided for in main groups or , e.g. of modular construction
F21S 4/00 - Lighting devices or systems using a string or strip of light sources
F21S 4/20 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports
F21S 4/24 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape of ribbon or tape form, e.g. LED tapes
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 21/005 - Supporting, suspending, or attaching arrangements for lighting devicesHand grips for several lighting devices in an end-to-end arrangement, i.e. light tracks
F21V 23/06 - Arrangement of electric circuit elements in or on lighting devices the elements being coupling devices
H01R 4/36 - Conductive members located under tip of screw
H01R 4/38 - Clamped connectionsSpring connections using a clamping member acted on by screw or nut
H01R 4/46 - Clamping area between two screws placed side by side
H01R 11/03 - Individual connecting elements providing two or more spaced connecting locations for conductive members which are, or may be, thereby interconnected, e.g. end pieces for wires or cables supported by the wire or cable and having means for facilitating electrical connection to some other wire, terminal, or conductive member, blocks of binding posts characterised by the type of the connecting locations on the individual element or by the type of the connections between the connecting locations and the conductive members
H01R 11/09 - Individual connecting elements providing two or more spaced connecting locations for conductive members which are, or may be, thereby interconnected, e.g. end pieces for wires or cables supported by the wire or cable and having means for facilitating electrical connection to some other wire, terminal, or conductive member, blocks of binding posts characterised by the type of the connecting locations on the individual element or by the type of the connections between the connecting locations and the conductive members the connecting locations being identical
H01R 12/63 - Fixed connections for flexible printed circuits, flat or ribbon cables or like structures connecting to another shape cable
H01R 25/14 - Rails or bus-bars constructed so that the counterparts can be connected thereto at any point along their length
H01R 27/02 - Coupling parts adapted for co-operation with two or more dissimilar counterparts for simultaneous co-operation with two or more counterparts
H01R 33/94 - Holders formed as intermediate parts for linking a counter-part to a coupling part
A linear luminaire having high ingress protection includes a light-generating assembly and a channel. The light-generating assembly is an elongate, self-contained, sealed optical assembly that includes all elements necessary to generate light and to direct, focus, or modify the generated light in a particular way. Typically, the light-generating assembly would include an outer optical element and a light source positioned within a cavity of the body of the light-generating assembly. The outer optical element may be a lens, diffuser, or other such element. The light source may be a strip of LED linear lighting, a string of connected LED modules, or any other suitable device. The light-generating assembly may optionally include a second optical element, such as a lens or diffuser, that is supported within the body. The ends of the body of the light-generating assembly may be sealed by fitted endcaps, by polymeric resin, or by other means.
F21V 31/00 - Gas-tight or water-tight arrangements
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
A voltage-regulating drive circuit for an LED luminaire is disclosed. The drive circuit includes one or several series of LED light engines. A voltage source with a regulator is connected to the series of LED light engines to forward-bias the light engines. The circuit also includes a driver integrated circuit, which may drive the series of LED light engines using, e.g., pulse-width modulation (PWM). The circuit also includes a feedback circuit connected to the cathode end of the series of LED light engines. The feedback circuit receives a remainder voltage and creates a feedback output signal that upregulates or downregulates the regulator of the voltage source to keep a minimum operating voltage on the driver integrated circuit and to compensate for variations in forward voltages among LED light engines in the series.
H05B 45/10 - Controlling the intensity of the light
F21V 23/06 - Arrangement of electric circuit elements in or on lighting devices the elements being coupling devices
H05B 45/355 - Power factor correction [PFC]Reactive power compensation
H05B 45/56 - Circuit arrangements for operating light-emitting diodes [LED] responsive to malfunctions or undesirable behaviour of LEDsCircuit arrangements for operating light-emitting diodes [LED] responsive to LED lifeProtective circuits involving measures to prevent abnormal temperature of the LEDs
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
H05B 45/18 - Controlling the intensity of the light using temperature feedback
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
H05B 45/34 - Voltage stabilisationMaintaining constant voltage
H05B 47/24 - Circuit arrangements for protecting against overvoltage
H05B 45/14 - Controlling the intensity of the light using electrical feedback from LEDs or from LED modules
LED luminaire drive circuitry, control methods, and a luminaire using the circuitry are disclosed. The LED drive circuitry includes a voltage source with a voltage regulator. A feedback circuit is connected to the cathode end of a series of LED light engines. The feedback circuit receives a remainder voltage and produces a feedback output voltage to the voltage regulator to adjust the voltage applied to the series of LED light engines. The voltage regulator may thus maintain at least a minimum voltage on a driver integrated circuit. The control methods include methods of allocating power to series of LED light engines to obey both individual and collective power budgets, as well as methods of controlling heat output. All of these methods involve ramping the light output of the series of LED light engines down by a uniform factor when they consume too much power or generate too much heat.
H05B 45/56 - Circuit arrangements for operating light-emitting diodes [LED] responsive to malfunctions or undesirable behaviour of LEDsCircuit arrangements for operating light-emitting diodes [LED] responsive to LED lifeProtective circuits involving measures to prevent abnormal temperature of the LEDs
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
A linear luminaire includes a channel with a bottom and sidewalls that arise from opposite sides of the bottom. A printed circuit board (PCB) including a number of LED light engines is mounted in the channel, and may be mounted on stand-offs away from the bottom of the channel. A mounting bracket is connected to an underside of the channel bottom. The linear luminaire also includes a base that can serve as a raceway for wires and cable. The base also has a bottom and sidewalls, and attaches releasably to the channel by means of cooperating engaging structures on the mounting bracket of the channel and portions of the sidewalls of the base.
F21S 4/20 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21Y 113/10 - Combination of light sources of different colours
Encapsulated linear lighting with improved light diffusion is disclosed. The encapsulated linear lighting includes a channel and a long narrow strip of printed circuit board (PCB) with light engines disposed off-center on the PCB. The PCB is installed along a bottom inner surface of a sidewall of the channel so that the light engines are adjacent a bottom of the channel. The encapsulated linear lighting includes a covering that encapsulates and protects the PCB.
Encapsulated linear lighting with improved light diffusion is disclosed. The encapsulated linear lighting includes a channel and a long narrow strip of printed circuit board (PCB) with light engines disposed off-center on the PCB. The PCB is installed along a bottom inner surface of a sidewall of the channel so that the light engines are adjacent a bottom of the channel. The encapsulated linear lighting includes a covering that encapsulates and protects the PCB.
Interchangeable driver systems including at least a driver and a receptacle are disclosed. The receptacle provides a compartment, space, or other connection point for a power input as well as connecting structure that releasably and interchangeably connects to the driver. The driver has complementary electrical and mechanical connecting structure. The electrical and mechanical connections between the driver and the receptacle are such that when a mechanical connection between them is made, an electrical connection is also made. The receptacle may take the form of an enclosure that surrounds a substantial portion of the driver, or it may take the form of a short base with a socket that receives a connecting portion of the driver.
H05K 7/14 - Mounting supporting structure in casing or on frame or rack
H01R 13/631 - Additional means for facilitating engagement or disengagement of coupling parts, e.g. aligning or guiding means, levers, gas pressure for engagement only
A linear luminaire is disclosed. The linear luminaire includes a channel, in which a strip of linear lighting is disclosed. The strip of linear lighting may have an individual optic positioned over each LED light engine. A set of louvers is provided. The set of louvers is arranged such that an individual louver is positioned over each one of the LED light engines. The individual louvers are generally cylindrical in shape. The individual louvers are connected by a web or platform that carries engaging structure allowing the set of louvers to snap or slide into the channel. The channel is covered with a channel cover, which has edges that extend out over at least a portion of the channel sidewalls, making it more difficult for dust and other foreign matter to enter the channel. The channel cover may be transparent.
F21K 9/66 - Details of globes or covers forming part of the light source
F21K 9/69 - Details of refractors forming part of the light source
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 17/10 - Fastening of component parts of lighting devices, e.g. shades, globes, refractors, reflectors, filters, screens, grids or protective cages characterised by specific fastening means or way of fastening
A linear luminaire is disclosed. The linear luminaire includes a channel, in which a strip of linear lighting is disclosed. The strip of linear lighting may have an individual optic positioned over each LED light engine. A set of louvers is provided. The set of louvers is arranged such that an individual louver is positioned over each one of the LED light engines. The individual louvers are generally cylindrical in shape. The individual louvers are connected by a web or platform that carries engaging structure allowing the set of louvers to snap or slide into the channel. The channel is covered with a channel cover, which has edges that extend out over at least a portion of the channel sidewalls, making it more difficult for dust and other foreign matter to enter the channel. The channel cover may be transparent.
F21K 9/66 - Details of globes or covers forming part of the light source
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21K 9/69 - Details of refractors forming part of the light source
F21V 17/10 - Fastening of component parts of lighting devices, e.g. shades, globes, refractors, reflectors, filters, screens, grids or protective cages characterised by specific fastening means or way of fastening
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
An electrical gang box adapted for use with drivers is disclosed. The electrical gang box includes a main compartment with a front opening sized and adapted to accept an electrical control and structure around the front opening to secure the electrical control within the front opening and within the main compartment. The electrical gang box also includes a lower compartment that extends below the main compartment, is set back from the front of the main compartment and is open to the main compartment along an upper portion. The gang box may also include one or more pairs of rails disposed on opposite interior walls. In such cases, a divider panel is sized to slide into and extend between the rails to divide the junction box. Multiple-gang boxes with these features are also disclosed.
An electrical gang box adapted for use with drivers is disclosed. The electrical gang box includes a main compartment with a front opening sized and adapted to accept an electrical control and structure around the front opening to secure the electrical control within the front opening and within the main compartment. The electrical gang box also includes a lower compartment that extends below the main compartment, is set back from the front of the main compartment and is open to the main compartment along an upper portion. The gang box may also include one or more pairs of rails disposed on opposite interior walls. In such cases, a divider panel is sized to slide into and extend between the rails to divide the junction box. Multiple-gang boxes with these features are also disclosed.
Lighting circuits and strips of linear lighting that can accept either a lower voltage or a higher voltage are disclosed. In the lighting circuit, a repeating block including LED light engines and current-setting elements is divided into two sub-blocks. Terminals are provided that allow the sub-blocks to be connected to voltage and ground in various ways. When the two sub-blocks are connected electrically in parallel with one another, the lighting circuit accepts the lower voltage; when the two sub-blocks are connected electrically in series with one another, the lighting circuit accepts the higher voltage. Circuitry that automatically detects the applied voltage and switches between series and parallel configurations may be included in some embodiments.
F21S 2/00 - Systems of lighting devices, not provided for in main groups or , e.g. of modular construction
F21S 4/20 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports
F21V 21/005 - Supporting, suspending, or attaching arrangements for lighting devicesHand grips for several lighting devices in an end-to-end arrangement, i.e. light tracks
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
F21V 23/02 - Arrangement of electric circuit elements in or on lighting devices the elements being transformers or impedances
The disclosure relates to methods for connecting encapsulated linear lighting to power, including the use of through-hole mounting into flexible encapsulated linear lighting, and the creation of overmolds to protect electrical connections. The disclosure also relates to linear luminaires having channels that accommodate overmolds and allow electrical cables to exit the encapsulated linear lighting in desired, and controllable, directions.
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
Linear lighting for which the light output is selectable among two or more predetermined options using onboard circuitry is disclosed. In this linear lighting, the onboard input-side power circuit for the linear lighting has multiple branches. One branch of the input-side power circuit directs all power applied to its solder pad directly to the LED light engines. The other branches of the input-side power circuit have components in them that moderate or control the effective light output of the LED light engines. For example, each circuit branch that offers a reduced light output may include a pulse-width modulation (PWM) oscillator circuit that reduces the duty cycle of the LED light engines. A working embodiment may have, e.g., one circuit branch that produces 100% of rated light output, one circuit branch that produces 50% of rated light output, and one circuit branch that produces 25% of rated light output.
Lighting circuits using LED light engines and strips of linear lighting using these circuits are described. The lighting circuits are designed to produce different levels of light output at least in part using onboard components. In some embodiments, the circuit contains several current-setting elements, such as resistors, which are coupled to their own terminals such that the light output of the lighting circuit is determined by which of the terminals are connected to power. In other embodiments, a transistor in the lighting circuit may be adapted to allow or prevent current flow in the circuit based on a control signal applied to its gate. The circuit thus has separate power and control signal lines, and an external device, such as a pulse-width modulation signal generator, may be applied to the control signal line to modulate the light output.
A channel system that includes a first channel section, a second channel section, and a hinge joint between the first and second channel sections is disclosed. The hinge joint allows the first channel section to fold against the second channel section for storage and shipping of the channel system. In one embodiment, the hinge joint itself includes a hinge member that extends between the two channel sections and bends hingedly to allow movement and two intermediate endcaps, which cap the channel sections on either side of the hinge joint. The hinge joint may be designed to “snap back” to a fully extended position. Mechanical securement structure may be added to the first channel section and the second channel section to improve force and retention during the “snap back” movement.
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 19/00 - Fastening of light sources or lamp holders
F21V 17/02 - Fastening of component parts of lighting devices, e.g. shades, globes, refractors, reflectors, filters, screens, grids or protective cages with provision for adjustment
F21V 23/06 - Arrangement of electric circuit elements in or on lighting devices the elements being coupling devices
A channel system that includes a first channel section, a second channel section, and a hinge joint between the first and second channel sections is disclosed. The hinge joint allows the first channel section to fold against the second channel section for storage and shipping of the channel system. In one embodiment, the hinge joint itself includes a hinge member that extends between the two channel sections and bends hingedly to allow movement and two intermediate endcaps, which cap the channel sections on either side of the hinge joint. The hinge joint may be designed to "snap back" to a fully extended position. Mechanical securement structure may be added to the first channel section and the second channel section to improve force and retention during the "snap back" movement.
F21S 4/22 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 15/01 - Housings, e.g. material or assembling of housing parts
A drive circuit for an LED luminaire is disclosed. The drive circuit includes one or several series of LED light engines. A voltage source with a regulator is connected to the series of LED light engines to forward-bias the light engines. The circuit also includes an integrated circuit driver, which may drive the series of LED light engines using, e.g., pulse-width modulation (PWM). The circuit also includes a feedback circuit connected to the cathode end of the series of LED light engines. The feedback circuit receives a remainder voltage and creates a feedback output signal that upregulates or downregulates the regulator of the voltage source to keep a minimum operating voltage on the integrated circuit driver and also to compensate for variations in forward voltages among LED light engines in the series. A switching element, such as a bipolar junction transistor, protects the driver from high voltages.
A linear luminaire includes a channel with a bottom and sidewalls that arise from opposite sides of the bottom. The channel has an upper compartment and a lower compartment, the sidewalls being of a shape and extent such that at opposite ends of the channel, the upper compartment overhangs the lower compartment in a longitudinal direction. An elongate, rigid printed circuit board (PCB) is mounted in the upper compartment of the channel, aligned along the longitudinal direction, the PCB extending to each of the opposite ends of the channel in the upper compartment and having one or more LED light engines mounted thereon. The PCB may be mounted on stand-offs, such that it is above the bottom of the channel and defines the boundary between the upper and lower compartments. The overhung upper compartment creates a cableway space when two linear luminaires are abutted end-to-end or are adjacent.
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 23/06 - Arrangement of electric circuit elements in or on lighting devices the elements being coupling devices
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
Methods for controlling power consumption and temperature in an LED luminaire are disclosed. The LED luminaire has one or more sets of LED light engines disposed on a printed circuit board (PCB), some or all of which are activated in response to an instruction or set of instructions. The instruction or set of instructions are processed to derive an indication of power consumption for each of the one or more sets of LED light engines. Power allocations for the one or more sets of LED light engines are adjusted to meet targets. This can be done by, e.g., ramping up or down the duty cycle of active sets of LED light engines by a uniform factor until the targets are met. Temperature control methods similarly ramp down the duty cycle of active sets of LED light engines uniformly over time if the measured temperature of the PCB exceeds limits.
H05B 45/355 - Power factor correction [PFC]Reactive power compensation
H05B 45/56 - Circuit arrangements for operating light-emitting diodes [LED] responsive to malfunctions or undesirable behaviour of LEDsCircuit arrangements for operating light-emitting diodes [LED] responsive to LED lifeProtective circuits involving measures to prevent abnormal temperature of the LEDs
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
H05B 45/18 - Controlling the intensity of the light using temperature feedback
Connectors for linear lighting are disclosed. These connectors are adapted to electrically connect two strips of linear lighting, or a single strip of linear lighting and an appropriate number of wires. At least the portions of the connectors that accept the strips of linear lighting have sloped ramps that provide strain relief to the strips of linear lighting. Additionally, pivoting connectors that allow their sides to rotate relative to one another are disclosed.
H01R 4/38 - Clamped connectionsSpring connections using a clamping member acted on by screw or nut
F21S 4/00 - Lighting devices or systems using a string or strip of light sources
F21V 23/06 - Arrangement of electric circuit elements in or on lighting devices the elements being coupling devices
H01R 11/03 - Individual connecting elements providing two or more spaced connecting locations for conductive members which are, or may be, thereby interconnected, e.g. end pieces for wires or cables supported by the wire or cable and having means for facilitating electrical connection to some other wire, terminal, or conductive member, blocks of binding posts characterised by the type of the connecting locations on the individual element or by the type of the connections between the connecting locations and the conductive members
H01R 11/09 - Individual connecting elements providing two or more spaced connecting locations for conductive members which are, or may be, thereby interconnected, e.g. end pieces for wires or cables supported by the wire or cable and having means for facilitating electrical connection to some other wire, terminal, or conductive member, blocks of binding posts characterised by the type of the connecting locations on the individual element or by the type of the connections between the connecting locations and the conductive members the connecting locations being identical
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
H01R 27/02 - Coupling parts adapted for co-operation with two or more dissimilar counterparts for simultaneous co-operation with two or more counterparts
F21V 21/005 - Supporting, suspending, or attaching arrangements for lighting devicesHand grips for several lighting devices in an end-to-end arrangement, i.e. light tracks
H01R 4/36 - Conductive members located under tip of screw
H01R 33/94 - Holders formed as intermediate parts for linking a counter-part to a coupling part
H01R 25/14 - Rails or bus-bars constructed so that the counterparts can be connected thereto at any point along their length
H05K 1/14 - Structural association of two or more printed circuits
F21K 9/20 - Light sources comprising attachment means
F21S 4/20 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports
H01R 12/63 - Fixed connections for flexible printed circuits, flat or ribbon cables or like structures connecting to another shape cable
H01R 4/46 - Clamping area between two screws placed side by side
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21S 2/00 - Systems of lighting devices, not provided for in main groups or , e.g. of modular construction
F21V 23/04 - Arrangement of electric circuit elements in or on lighting devices the elements being switches
H01R 43/20 - Apparatus or processes specially adapted for manufacturing, assembling, maintaining, or repairing of line connectors or current collectors or for joining electric conductors for assembling or disassembling contact members with insulating base, case or sleeve
H01R 35/04 - Turnable line connectors with limited rotation angle
F21S 4/24 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape of ribbon or tape form, e.g. LED tapes
F21K 9/00 - Light sources using semiconductor devices as light-generating elements, e.g. using light-emitting diodes [LED] or lasers
F21K 9/27 - Retrofit light sources for lighting devices with two fittings for each light source, e.g. for substitution of fluorescent tubes
Channels and channel covers for linear lighting are disclosed. The channels have an upper compartment for linear lighting and a lower compartment that may be used as a raceway, to engage parts, and for rear entry of wires. Endcaps for the channels may engage the lower compartment. Cover-lenses for linear lighting channels are also disclosed. The cover-lenses may include diffusing material and implement a thickness gradient in order to maximize the amount of diffusing material where the emitted light intensity is expected to be greatest. Diverging Fresnel features may be superimposed on the thickness gradient in order to counteract any converging effect of the thickness gradient and cause emitted light to spread more evenly.
F21K 9/237 - Details of housings or cases, i.e. the parts between the light-generating element and the basesArrangement of components within housings or cases
F21V 3/04 - GlobesBowlsCover glasses characterised by materials, surface treatments or coatings
F21V 5/04 - Refractors for light sources of lens shape
Channels and channel covers for linear lighting are disclosed. The channels have an upper compartment for linear lighting and a lower compartment that may be used as a raceway, to engage parts, and for rear entry of wires. Endcaps for the channels may engage the lower compartment. Cover-lenses for linear lighting channels are also disclosed. The cover-lenses may include diffusing material and implement a thickness gradient in order to maximize the amount of diffusing material where the emitted light intensity is expected to be greatest. Diverging Fresnel features may be superimposed on the thickness gradient in order to counteract any converging effect of the thickness gradient and cause emitted light to spread more evenly.
F21K 9/237 - Details of housings or cases, i.e. the parts between the light-generating element and the basesArrangement of components within housings or cases
F21V 3/04 - GlobesBowlsCover glasses characterised by materials, surface treatments or coatings
F21V 5/04 - Refractors for light sources of lens shape
Channels and channel covers for linear lighting are disclosed. The channels have an upper compartment for linear lighting and a lower compartment that may be used as a raceway, to engage parts, and for rear entry of wires. Endcaps for the channels may engage the lower compartment. Cover-lenses for linear lighting channels are also disclosed. The cover-lenses may include diffusing material and implement a thickness gradient in order to maximize the amount of diffusing material where the emitted light intensity is expected to be greatest. Diverging Fresnel features may be superimposed on the thickness gradient in order to counteract any converging effect of the thickness gradient and cause emitted light to spread more evenly.
F21S 4/00 - Lighting devices or systems using a string or strip of light sources
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 3/10 - GlobesBowlsCover glasses characterised by materials, surface treatments or coatings characterised by coatings
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
F21V 5/04 - Refractors for light sources of lens shape
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
Channels and channel covers for linear lighting are disclosed. The channels have an upper compartment for linear lighting and a lower compartment that may be used as a raceway, to engage parts, and for rear entry of wires. Endcaps for the channels may engage the lower compartment. Cover-lenses for linear lighting channels are also disclosed. The cover-lenses may include diffusing material and implement a thickness gradient in order to maximize the amount of diffusing material where the emitted light intensity is expected to be greatest. Diverging Fresnel features may be superimposed on the thickness gradient in order to counteract any converging effect of the thickness gradient and cause emitted light to spread more evenly.
F21S 4/00 - Lighting devices or systems using a string or strip of light sources
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 5/04 - Refractors for light sources of lens shape
F21V 3/10 - GlobesBowlsCover glasses characterised by materials, surface treatments or coatings characterised by coatings
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
A flexible cover for a linear lighting channel is described, as are enclosures and luminaires using this kind of flexible cover. The flexible cover has sufficient flexibility to be bent or coiled to a bend radius of 6 inches (15.2 cm) or smaller, and can thus be coiled for shipping and uncoiled for installation. Typically, the cover is made of a polymer that is at least translucent. Covers may be made in various shapes, including lens and prism shapes, and channels may be made with sidewalls that make complementary shapes in order to engage with and retain the covers.
A linear luminaire is disclosed. The linear luminaire includes a channel, in which a strip of linear lighting is disclosed. The strip of linear lighting may have an individual optic positioned over each LED light engine. A set of louvers is provided. The set of louvers is arranged such that an individual louver is positioned over each one of the LED light engines. The individual louvers are generally cylindrical in shape. The individual louvers are connected by a web or platform that carries engaging structure allowing the set of louvers to snap or slide into the channel. The channel is covered with a channel cover, which has edges that extend out over at least a portion of the channel sidewalls, making it more difficult for dust and other foreign matter to enter the channel. The channel cover may be transparent.
F21V 11/08 - Screens not covered by groups , , or using diaphragms containing one or more apertures
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 5/04 - Refractors for light sources of lens shape
F21V 17/10 - Fastening of component parts of lighting devices, e.g. shades, globes, refractors, reflectors, filters, screens, grids or protective cages characterised by specific fastening means or way of fastening
F21V 29/70 - Cooling arrangements characterised by passive heat-dissipating elements, e.g. heat-sinks
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
Methods for making encapsulated linear lighting with opaque ends are disclosed. Linear lighting is placed in a polymeric channel, and the channel is filled with a resin in order to encapsulate the linear lighting. In order to prevent leaks, the channel is dammed at both ends of the linear lighting with stoppers. The channel has interior engaging features, such as grooves or ridges, that engage with complementary features on the sidewalls of the stoppers to form a seal between the channel and the stoppers. The resin within the channel is caused or allowed to cure. The stoppers are moved back from the cured mass to form a gap. An opaque resin may be poured into the channel and spills into the gap to coat the top and end face or faces of the linear lighting. Once all resin layers are cured, the stoppers are removed from the channel.
F21S 4/22 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape
F21V 15/01 - Housings, e.g. material or assembling of housing parts
Methods and systems for controlling compound ramps in LED luminaires and lighting circuits are disclosed. In a compound ramp, the light output of one set of LED light engines increases while the light output of another set of LED light engines decreases. During such a ramp, the methods and systems may control the total light output to keep it relatively constant. In some embodiments, the methods and systems may also control the color of the emitted light maintain ideal color characteristics.
Encapsulated linear lighting with improved light diffusion is disclosed. The encapsulated linear lighting includes a channel and a long narrow strip of printed circuit board (PCB) with light engines disposed off-center on the PCB. The PCB is installed along a bottom inner surface of a sidewall of the channel so that the light engines are adjacent a bottom of the channel. The encapsulated linear lighting includes a covering that encapsulates and protects the PCB.
F21S 4/22 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
57.
Output stabilization of mixed color temperature LED lighting systems
Methods and systems for controlling compound ramps in LED luminaires and lighting circuits are disclosed. In a compound ramp, the light output of one set of LED light engines increases while the light output of another set of LED light engines decreases. During such a ramp, the methods and systems may control the total light output to keep it relatively constant. In some embodiments, the methods and systems may also control the color of the emitted light maintain ideal color characteristics.
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
Goods & Services
Electrical devices relating to lighting, namely, electric
light dimmers, power adapters, battery packs, transformers,
power supplies, power controllers and amplifiers, junction
boxes, electrical connectors, electrical wires, electrical
plugs, light systems comprising light sensors and switches. LED (light emitting diode) lighting fixtures; LED (light
emitting diodes) lighting fixtures for use in display,
commercial, industrial, residential, and architectural
accent lighting applications; LED and HID light fixtures;
LED landscape lights; LED light strips for decorative
purposes; LED underwater lights.
Junction boxes and partitions for junction boxes are disclosed. The junction boxes have a central area for installation of a driver or another such component and at least one wrap-around compartment in which wire connections can be made. In many cases, the junction box may have two wrap-around compartments, often mirror images of one another, that provide separate spaces for high- and low-voltage wire connections. The interior walls or partitions that create the compartments may be carried by and arise from the base of a junction box, or they may be carried by a separate piece that inserts over the driver, fully encloses or caps it, and also carries partition portions to create fully-divided compartments when used in combination with a junction box base that has no partitions of its own.
A flexible cover for a linear lighting channel is described, as are enclosures and luminaires using this kind of flexible cover. The flexible cover has sufficient flexibility to be bent or coiled to a bend radius of 6 inches (15.2 cm) or smaller, and can thus be coiled for shipping and uncoiled for installation. Typically, the cover is made of a polymer that is at least translucent. Covers may be made in various shapes, including lens and prism shapes, and channels may be made with sidewalls that make complementary shapes in order to engage with and retain the covers.
C08L 83/00 - Compositions of macromolecular compounds obtained by reactions forming in the main chain of the macromolecule a linkage containing silicon with or without sulfur, nitrogen, oxygen, or carbon onlyCompositions of derivatives of such polymers
C08L 27/06 - Homopolymers or copolymers of vinyl chloride
F21W 131/40 - Lighting for industrial, commercial, recreational or military use
A flexible cover for a linear lighting channel is described, as are enclosures and luminaires using this kind of flexible cover. The flexible cover has sufficient flexibility to be bent or coiled to a bend radius of 6 inches (15.2 cm) or smaller, and can thus be coiled for shipping and uncoiled for installation. Typically, the cover is made of a polymer that is at least translucent. Covers may be made in various shapes, including lens and prism shapes, and channels may be made with sidewalls that make complementary shapes in order to engage with and retain the covers.
A weather-resistant junction box is disclosed. The junction box includes a back panel and a number of sidewalls arising from the back panel to create an enclosure with an open face. A removable panel is constructed and arranged to cover and close the open face. A cap with an overhang extends over the top of the enclosure, extending out and down over the top portions of its sidewalls. Internally, the enclosure is divided by one or more partitions into a driver compartment and two or more connection compartments. Each of the connection compartments includes at least one opening, or a knock-out for the opening. All of the openings or knock-outs for all of the connection compartments may be located in the same panel of the junction box.
Optical systems for linear lighting, particularly linear lighting that is installed in a channel, are disclosed, as are light fixtures that use these optical systems. The optical systems have multiple optical elements, usually a first lens adapted to be positioned close to a strip of linear lighting installed in a channel, and a second lens adapted to be positioned farther from the strip of linear lighting. In some cases, the first optical element may be a diffuser. The two optical elements are optically aligned with one another such that light from the first optical element reaches the second optical element. The multiple optical elements may be adapted to physically support one another, and to engage with structure provided by the channel for securing a cover. Some optical systems may be adapted to compensate for variations in the color or intensity of the emitted light.
Optical systems for linear lighting, particularly linear lighting that is installed in a channel, are disclosed, as are light fixtures that use these optical systems. The optical systems have multiple lenses, usually a first lens adapted to be positioned close to a strip of linear lighting installed in a channel, and a second lens adapted to be positioned farther from the strip of linear lighting. The two lenses are optically aligned with one another such that light from the first lens reaches the second lens. The two lenses may, e.g., form an Abbe condenser lens system. In some embodiments, diffusing features may be integrated into one or both lenses to effect light mixing. The multiple lenses may be adapted to physically support one another, and to engage with structure provided by the channel for securing a cover.
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
Optical systems for linear lighting, particularly linear lighting that is installed in a channel, are disclosed, as are light fixtures that use these optical systems. The optical systems have multiple optical elements, usually a first lens adapted to be positioned close to a strip of linear lighting installed in a channel, and a second lens adapted to be positioned farther from the strip of linear lighting. In some cases, the first optical element may be a diffuser. The two optical elements are optically aligned with one another such that light from the first optical element reaches the second optical element. The multiple optical elements may be adapted to physically support one another, and to engage with structure provided by the channel for securing a cover. Some optical systems may be adapted to compensate for variations in the color or intensity of the emitted light.
An in-ground channel for linear lighting is disclosed. In the channel, two upright sidewalls are spaced apart by a bottom. Each of the sidewalls has an inwardly-extending upper support flange proximate to an upper end. The inwardly-extending upper support flanges are aligned with one another on respective sidewalls. A shelf is mounted between the two upright sidewalls at a position below the inwardly-extending support flanges. The shelf divides the in-ground channel into an upper section and a lower section. The upper section houses linear lighting and the lower section provides a raceway. The channel has only a single mounting flange attached to one of the two sidewalls at a position level with the bottom. The channel typically also includes a cover adapted to engage the upper support flanges. The shelf may be removable, mounted via a pair of inwardly-extending lower support flanges, for access to the lower section.
E01F 9/506 - Road surface markingsKerbs or road edgings, specially adapted for alerting road users characterised by the road surface marking material, e.g. comprising additives for improving friction or reflectivityMethods of forming, installing or applying markings in, on or to road surfaces
F21S 8/02 - Lighting devices intended for fixed installation of recess-mounted type, e.g. downlighters
Interchangeable driver systems including at least a driver and a receptacle are disclosed. The receptacle provides a compartment, space, or other connection point for a power input as well as connecting structure that releasably and interchangeably connects to the driver. The driver has complementary electrical and mechanical connecting structure. The electrical and mechanical connections between the driver and the receptacle are such that when a mechanical connection between them is made, an electrical connection is also made. The receptacle may take the form of an enclosure that surrounds a substantial portion of the driver, or it may take the form of a short base with a socket that receives a connecting portion of the driver.
Modular channel systems are disclosed. The channels include a pair of sidewalls and a channel bottom. The pair of sidewalls and the channel bottom are separate, modular, and connected at or proximate to the sidewall bottoms by complementary engaging structures carried by the parts. In some cases, an intermediate member may be placed in the joints between the bottom and the sidewalls. The sidewalls may have flanges for flush-mounting the channel in a wall or similar structure, and the sidewalls may be separate and modular, adapted to make a push-together or slide-together connection with the sidewalls. The channels are adapted to be covered and closed by a cover. The upper portions of the sidewalls and the cover may have complementary engaging shapes, such that the sidewalls are without internally-extending flanges or ridges for supporting the cover.
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 15/01 - Housings, e.g. material or assembling of housing parts
F21V 17/16 - Fastening of component parts of lighting devices, e.g. shades, globes, refractors, reflectors, filters, screens, grids or protective cages characterised by specific fastening means or way of fastening by deformation of parts of the lighting deviceSnap action mounting
Connectors for linear lighting are disclosed. These connectors include one side with a slot adapted to accept a strip of linear lighting. The other side may have either another slot for a second strip of linear lighting, if two strips of linear lighting are to be electrically connected end-to-end, or a set of terminal blocks for connecting the strip of linear lighting to wires, such as a set of power leads. The slot has a set of contacts, spaced from one another, that make physical contact with solder pads or other such electrical connecting structures on the linear lighting. The terminal blocks have conductive cages to make contact with the wires. Both the set of contacts in the slot and pressor members in the cages are driven into engagement by sets of adjustable positioning members that bear on them.
An electrical gang box adapted for use with drivers is disclosed. The electrical gang box includes a main compartment with a front opening sized and adapted to accept an electrical control and structure around the front opening to secure the electrical control within the front opening and within the main compartment. The electrical gang box also includes a lower compartment that extends below the main compartment, is set back from the front of the main compartment and is open to the main compartment along an upper portion. The gang box may also include one or more pairs of rails disposed on opposite interior walls. In such cases, a divider panel is sized to slide into and extend between the rails to divide the junction box. Multiple-gang boxes with these features are also disclosed.
Lighting circuits using LED light engines and strips of linear lighting using these circuits are described. The lighting circuits are designed to produce different levels of light output at least in part using onboard components. In some embodiments, the circuit contains several current-setting elements, such as resistors, which are coupled to their own terminals such that the light output of the lighting circuit is determined by which of the terminals are connected to power. In other embodiments, a transistor in the lighting circuit may be adapted to allow or prevent current flow in the circuit based on a control signal applied to its gate. The circuit thus has separate power and control signal lines, and an external device, such as a pulse-width modulation signal generator, may be applied to the control signal line to modulate the light output.
F21S 4/24 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape of ribbon or tape form, e.g. LED tapes
F21V 23/04 - Arrangement of electric circuit elements in or on lighting devices the elements being switches
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
Linear lighting is disclosed. The linear lighting includes a narrow, elongate printed circuit board (PCB). A plurality of LED light engines are disposed on the PCB and are electrically connected to it. The PCB is divided physically and electrically into repeating blocks, which are physically in series with one another and electrically in parallel. A pair of conductors extends the entire length of the linear lighting. Each of the conductors has a service loop corresponding to the position of each of the cut points. A covering encapsulates the PCB and the pair of conductors. The service loops in the conductors provide for additional length of conductor when the linear lighting is cut at a cut point, so that the linear lighting can be connected to power.
F21S 4/22 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
Optical systems for linear lighting, particularly linear lighting that is installed in a channel, are disclosed, as are light fixtures that use these optical systems. The optical systems have multiple lenses, usually a first lens adapted to be positioned close to a strip of linear lighting installed in a channel, and a second lens adapted to be positioned farther from the strip of linear lighting. The two lenses are optically aligned with one another such that light from the first lens reaches the second lens. The two lenses may, e.g., form an Abbe condenser lens system. In some embodiments, diffusing features may be integrated into one or both lenses to effect light mixing. The multiple lenses may be adapted to physically support one another, and to engage with structure provided by the channel for securing a cover.
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
Lighting circuits and strips of linear lighting that can accept either a lower voltage or a higher voltage are disclosed. In the lighting circuit, a repeating block including LED light engines and current-setting elements is divided into two sub-blocks. Terminals are provided that allow the sub-blocks to be connected to voltage and ground in various ways. When the two sub-blocks are connected electrically in parallel with one another, the lighting circuit accepts the lower voltage; when the two sub-blocks are connected electrically in series with one another, the lighting circuit accepts the higher voltage. Circuitry that automatically detects the applied voltage and switches between series and parallel configurations may be included in some embodiments.
09 - Scientific and electric apparatus and instruments
11 - Environmental control apparatus
Goods & Services
Electrical devices relating to lighting, namely, electric light dimmers, power adapters, battery packs, transformers, power supplies, power controllers and amplifiers, junction boxes, electrical connectors, electrical wires, electrical plugs, light systems comprising light sensors and switches LED (light emitting diode) lighting fixtures; LED (light emitting diodes) lighting fixtures for use in display, commercial, industrial, residential, and architectural accent lighting applications; LED and HID light fixtures; LED landscape lights; LED light strips for decorative purposes; LED underwater lights
A weather-resistant junction box is disclosed. The junction box includes a back panel and a number of sidewalls arising from the back panel to create an enclosure with an open face. A removable panel is constructed and arranged to cover and close the open face. A cap with an overhang extends over the top of the enclosure, extending out and down over the top portions of its sidewalls. Internally, the enclosure is divided by one or more partitions into a driver compartment and two or more connection compartments. Each of the connection compartments includes at least one opening, or a knock-out for the opening. All of the openings or knock-outs for all of the connection compartments may be located in the same panel of the junction box.
Connectors for linear lighting are disclosed. These connectors are adapted to electrically connect two strips of linear lighting, or a single strip of linear lighting and an appropriate number of wires. At least the portions of the connectors that accept the strips of linear lighting have sloped ramps that provide strain relief to the strips of linear lighting. Additionally, pivoting connectors that allow their sides to rotate relative to one another are disclosed.
F21V 23/06 - Arrangement of electric circuit elements in or on lighting devices the elements being coupling devices
H01R 4/38 - Clamped connectionsSpring connections using a clamping member acted on by screw or nut
F21S 4/00 - Lighting devices or systems using a string or strip of light sources
H01R 11/09 - Individual connecting elements providing two or more spaced connecting locations for conductive members which are, or may be, thereby interconnected, e.g. end pieces for wires or cables supported by the wire or cable and having means for facilitating electrical connection to some other wire, terminal, or conductive member, blocks of binding posts characterised by the type of the connecting locations on the individual element or by the type of the connections between the connecting locations and the conductive members the connecting locations being identical
H01R 11/03 - Individual connecting elements providing two or more spaced connecting locations for conductive members which are, or may be, thereby interconnected, e.g. end pieces for wires or cables supported by the wire or cable and having means for facilitating electrical connection to some other wire, terminal, or conductive member, blocks of binding posts characterised by the type of the connecting locations on the individual element or by the type of the connections between the connecting locations and the conductive members
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
H01R 27/02 - Coupling parts adapted for co-operation with two or more dissimilar counterparts for simultaneous co-operation with two or more counterparts
F21V 21/005 - Supporting, suspending, or attaching arrangements for lighting devicesHand grips for several lighting devices in an end-to-end arrangement, i.e. light tracks
H01R 4/36 - Conductive members located under tip of screw
Assemblies are disclosed that allow a driver, or another type of electronic component, to be mounted in association with an electrical gang box. In one embodiment, the gang box has an opening in a bottom panel. The driver has a flange that is larger than the opening and a body that is smaller than the opening. The driver is inserted through the opening so that the flange rests on the interior surface of the bottom panel with at least a majority of the body of the driver extending outside of the gang box. In another embodiment, the gang box has an opening in a side or rear panel and an adapter mounts the driver outside of the gang box. These assemblies allow for the use of low-voltage and other types of electrical components while leaving space in the gang box for conventional electrical elements, such as switches and dimmers.
Methods for making encapsulated linear lighting with opaque ends are disclosed. Linear lighting is placed in a polymeric channel, and the channel is filled with a resin in order to encapsulate the linear lighting. In order to prevent leaks, the channel is dammed at both ends of the linear lighting with stoppers. The channel has interior engaging features, such as grooves or ridges, that engage with complementary features on the sidewalls of the stoppers to form a seal between the channel and the stoppers. The resin within the channel is caused or allowed to cure. The stoppers are moved back from the cured mass to form a gap. An opaque resin may be poured into the channel and spills into the gap to coat the top and end face or faces of the linear lighting. Once all resin layers are cured, the stoppers are removed from the channel.
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 15/01 - Housings, e.g. material or assembling of housing parts
LED simulated neon with a reinforcing member is disclosed. The simulated neon has a flexible covering with a translucent upper portion and an opaque lower portion. At least the lower portion is filled with a transparent, flexible material. A channel is formed in the transparent, flexible material. Linear lighting is provided in the channel, along with a reinforcing member. The reinforcing member is shaped and oriented such that it can bend in the primary bending plane of the simulated neon but provides strain relief and at least partially restricts or interferes with bending in other planes. The reinforcing member may, for example, have a rectangular cross-section, wider than it is thick. It may be made of plastic or metal, and its thickness may vary depending on the material of which it is made.
F21S 4/26 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape of rope form, e.g. LED lighting ropes, or of tubular form
F21K 9/60 - Optical arrangements integrated in the light source, e.g. for improving the colour rendering index or the light extraction
Optical systems for linear lighting, particularly linear lighting that is installed in a channel, are disclosed, as are light fixtures that use these optical systems. The optical systems have multiple optical elements, usually a first lens adapted to be positioned close to a strip of linear lighting installed in a channel, and a second lens adapted to be positioned farther from the strip of linear lighting. In some cases, the first optical element may be a diffuser. The two optical elements are optically aligned with one another such that light from the first optical element reaches the second optical element. The multiple optical elements may be adapted to physically support one another, and to engage with structure provided by the channel for securing a cover. Some optical systems may be adapted to compensate for variations in the color or intensity of the emitted light.
Methods for making encapsulated linear lighting are disclosed. In these methods, linear lighting is placed in a polymeric channel, and the channel is filled with a resin in order to encapsulate the linear lighting. In order to prevent leaks, the channel is dammed at both ends of the linear lighting with stoppers. The channel has interior engaging features, such as grooves or ridges, that engage with complementary features on the sidewalls of the stoppers to form a seal between the channel and the stoppers. The resin within the channel is caused or allowed to cure, and once cured, the stoppers are removed from the channel.
Channel systems adapted to diffuse light are disclosed. The channels include a bottom and a pair of sidewalls. The interior surfaces of the sidewalls are free from inward projections or ridges that would prevent light from linear lighting installed in the channel from reaching the cover. In some cases, the sidewalls may bend inwardly to capture and engage the cover. In various embodiments, the cover may be a diffuser, a lens, or a prism. In some cases, the bottom of the channel may be sloped or angled to direct the light from linear lighting installed on it.
F21V 21/35 - Supporting elements displaceable along a guiding element with direct electrical contact between the supporting element and electric conductors running along the guiding element
F21V 21/002 - Supporting, suspending, or attaching arrangements for lighting devicesHand grips making direct electrical contact, e.g. by piercing
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
Multi-purpose channels are disclosed. These channels include sidewalls and a bottom, which may be either modular or of single-piece construction. An outwardly-extending flange is removably connected to at least one sidewall, allowing the channel to be mounted flush in a wall or converted for mounting in another fashion.
F21V 21/35 - Supporting elements displaceable along a guiding element with direct electrical contact between the supporting element and electric conductors running along the guiding element
F21V 21/002 - Supporting, suspending, or attaching arrangements for lighting devicesHand grips making direct electrical contact, e.g. by piercing
F21V 15/01 - Housings, e.g. material or assembling of housing parts
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
Junction boxes and partitions for junction boxes are disclosed. The junction boxes have a central area for installation of a driver or another such component and at least one wrap-around compartment in which wire connections can be made. In many cases, the junction box may have two wrap-around compartments, often mirror images of one another, that provide separate spaces for high- and low-voltage wire connections. The interior walls or partitions that create the compartments may be carried by and arise from the base of a junction box, or they may be carried by a separate piece that inserts over the driver, fully encloses or caps it, and also carries partition portions to create fully-divided compartments when used in combination with a junction box base that has no partitions of its own.
LED (light emitting diode) lighting fixtures; LED (light emitting diodes) lighting fixtures for use in display, commercial, industrial, residential, and architectural accent lighting applications; LED and HID light fixtures; LED landscape lights; LED light strips for decorative purposes; LED underwater lights; none of the foregoing for use in medical treatments
Modular channels are disclosed. The channels include a pair of sidewalls and a channel bottom. The pair of sidewalls and the channel bottom are separate, modular, and connected at or proximate to the sidewall bottoms by complementary engaging structures carried by the parts. In some cases, an intermediate member may be placed in the joints between the bottom and the sidewalls. The intermediate member may be made of plastic or rubber, and typically has a constant cross section. It may be a tube or have a round or ellipsoid cross section. The sidewalls may have flanges for flush-mounting the channel in a wall or similar structure. The sidewalls and bottom may carry various channels for alignment with other channels or mounting on other structures.
F21S 4/00 - Lighting devices or systems using a string or strip of light sources
F21V 15/01 - Housings, e.g. material or assembling of housing parts
F21V 21/002 - Supporting, suspending, or attaching arrangements for lighting devicesHand grips making direct electrical contact, e.g. by piercing
F21V 21/35 - Supporting elements displaceable along a guiding element with direct electrical contact between the supporting element and electric conductors running along the guiding element
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
LED-based light guide panels (LGPs) with an onboard driver are disclosed. The driver accepts power in a first form and convert it to a second form suitable for driving LED light engines. The driver may be a switched-mode power supply or a simpler driver architecture that is particularly adapted for LGP applications. In some embodiments, the driver may comprise a DC/DC converter. The driver may be placed in the frame of the LGP, or in a driver layer that lies beneath the light guide. In some embodiments, control elements may also be embedded within the frame. For example, the LGP may include a motion or occupancy sensor that changes the state of the LGP or turns it off when the area around the LGP is unoccupied. The LGP may also include an internal network interface that allows it to be controlled by an external system.
F21V 23/02 - Arrangement of electric circuit elements in or on lighting devices the elements being transformers or impedances
F21V 23/04 - Arrangement of electric circuit elements in or on lighting devices the elements being switches
F21K 9/61 - Optical arrangements integrated in the light source, e.g. for improving the colour rendering index or the light extraction using light guides
F21S 4/28 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports rigid, e.g. LED bars
F21V 7/24 - Reflectors for light sources characterised by materials, surface treatments or coatings, e.g. dichroic reflectors characterised by the material
Junction boxes and partitions for junction boxes are disclosed. The junction boxes have a central area for installation of a driver or another such component and at least one wrap-around compartment in which wire connections can be made. In many cases, the junction box may have two wrap-around compartments, often mirror images of one another, that provide separate spaces for high- and low-voltage wire connections. The interior walls or partitions that create the compartments may be carried by and arise from the base of a junction box, or they may be carried by a separate piece that inserts over the driver, fully encloses or caps it, and also carries partition portions to create fully-divided compartments when used in combination with a junction box base that has no partitions of its own.
Assemblies are disclosed that allow a driver to be mounted in association with an electrical gang box. In one embodiment, the gang box has an opening in a bottom panel. The driver has a flange that is larger than the opening and a body that is smaller than the opening. The driver is inserted through the opening so that the flange rests on the interior surface of the bottom panel with at least a majority of the body of the driver extending outside of the gang box. In another embodiment, the gang box has an opening in a side or rear panel and an adapter mounts the driver outside of the gang box. These assemblies allow for the use of low-voltage and other types of electrical components while leaving space in the gang box for conventional electrical elements, such as switches and dimmers.
F21V 7/28 - Reflectors for light sources characterised by materials, surface treatments or coatings, e.g. dichroic reflectors characterised by coatings
Linear lighting with a mirror finish is disclosed, as is a luminaire including the linear lighting. The mirror finish may be a film applied to the PCB, such as a specular film. In another embodiment, the mirror finish may be a piecewise-continuous mirror coating that is applied in pieces, e.g., using surface mount technology. The mirror finish may also be created by polishing, treating, or otherwise working a surface of the PCB, or by applying an interference filter coating, a dichroic coating, or another similar type of coating that selectively reflects light.
Connectors for linear lighting are disclosed. These connectors include one side with a slot adapted to accept a strip of linear lighting. The other side may have either another slot for a second strip of linear lighting, if two strips of linear lighting are to be electrically connected end-to-end, or a set of terminal blocks for connecting the strip of linear lighting to wires, such as a set of power leads. The slot has a set of contacts, spaced from one another, that make physical contact with solder pads or other such electrical connecting structures on the linear lighting. The terminal blocks have conductive cages to make contact with the wires. Both the set of contacts in the slot and pressor members in the cages are driven into engagement by sets of adjustable positioning members that bear on them.
An in-ground channel for linear lighting is disclosed. In the channel, two upright sidewalls are spaced apart by a bottom. Each of the sidewalls has an inwardly-extending upper support flange proximate to an upper end. The inwardly-extending upper support flanges are aligned with one another on respective sidewalls. A shelf is mounted between the two upright sidewalls at a position below the inwardly-extending support flanges. The shelf divides the in-ground channel into an upper section and a lower section. The upper section houses linear lighting and the lower section provides a raceway. The channel has only a single mounting flange attached to one of the two sidewalls at a position level with the bottom. The channel typically also includes a cover adapted to engage the upper support flanges. The shelf may be removable, mounted via a pair of inwardly-extending lower support flanges, for access to the lower section.
F21S 8/02 - Lighting devices intended for fixed installation of recess-mounted type, e.g. downlighters
F21V 33/00 - Structural combinations of lighting devices with other articles, not otherwise provided for
F21V 21/02 - Wall, ceiling, or floor basesFixing pendants or arms to the bases
F21V 17/16 - Fastening of component parts of lighting devices, e.g. shades, globes, refractors, reflectors, filters, screens, grids or protective cages characterised by specific fastening means or way of fastening by deformation of parts of the lighting deviceSnap action mounting
F21V 15/01 - Housings, e.g. material or assembling of housing parts
F21W 111/02 - Use or application of lighting devices or systems for signalling, marking or indicating, not provided for in groups for roads, paths or the like
LED simulated neon with a reinforcing member is disclosed. The simulated neon has a flexible covering with a translucent upper portion and an opaque lower portion. At least the lower portion is filled with a transparent, flexible material. A channel is formed in the transparent, flexible material. Linear lighting is provided in the channel, along with a reinforcing member. The reinforcing member is shaped and oriented such that it can bend in the primary bending plane of the simulated neon but provides strain relief and at least partially restricts or interferes with bending in other planes. The reinforcing member may, for example, have a rectangular cross-section, wider than it is thick. It may be made of plastic or metal, and its thickness may vary depending on the material of which it is made.
F21S 4/00 - Lighting devices or systems using a string or strip of light sources
F21S 4/22 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape
F21Y 103/10 - Elongate light sources, e.g. fluorescent tubes comprising a linear array of point-like light-generating elements
An elongate, flexible printed circuit board (PCB) has a central section that carries LED light engines and other components, and a pair of wings, one on each side of the central section, adjacent to the central section. The wings carry adhesive to secure the PCB to a substrate, and may be separated from the central section in some cases by fold or score lines. The LED light engines may be positioned on a first side of the PCB and electrically connected to one or more components on a second side of the PCB. Taken together, the wings may have the same width as the central section, or they may have a greater width.
F21S 4/22 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape
H05K 1/18 - Printed circuits structurally associated with non-printed electric components
F21V 23/06 - Arrangement of electric circuit elements in or on lighting devices the elements being coupling devices
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
Linear lighting is disclosed. The linear lighting includes a narrow, elongate printed circuit board (PCB). A plurality of LED light engines are disposed on the PCB and are electrically connected to it. The PCB is divided physically and electrically into repeating blocks, which are physically in series with one another and electrically in parallel. A pair of conductors extends the entire length of the linear lighting. Each of the conductors has a service loop corresponding to the position of each of the cut points. A covering encapsulates the PCB and the pair of conductors. The service loops in the conductors provide for additional length of conductor when the linear lighting is cut at a cut point, so that the linear lighting can be connected to power.
H05B 33/08 - Circuit arrangements for operating electroluminescent light sources
F21K 9/20 - Light sources comprising attachment means
F21S 4/20 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports
F21S 4/24 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape of ribbon or tape form, e.g. LED tapes
H05K 1/18 - Printed circuits structurally associated with non-printed electric components
99.
Printed circuit board and component arrangements for linear LED lighting
Printed circuit board (PCB) arrangements for linear lighting are disclosed. In one embodiment, an elongate, flexible PCB carries light-emitting diode (LED) light engines on one side of the PCB and components on the other. The components may be, e.g., resistors, current controllers, color controllers, or network interfaces. In another embodiment, two PCBs, each with components mounted on a single side, are connected together electrically and mechanically to function as one. In yet another embodiment, an elongate, flexible PCB has a central section that carries LED light engines and other components, and a pair of wings, one on each side of the central section. The wings carry adhesive to secure the PCB to a substrate.
F21S 4/22 - Lighting devices or systems using a string or strip of light sources with light sources held by or within elongate supports flexible or deformable, e.g. into a curved shape
F21V 23/00 - Arrangement of electric circuit elements in or on lighting devices
F21V 23/06 - Arrangement of electric circuit elements in or on lighting devices the elements being coupling devices
H05K 1/18 - Printed circuits structurally associated with non-printed electric components
A power and control assembly is disclosed. An LED driver is sized and adapted to fit within a single compartment of an electrical gang box. The driver has a groove or channel, and an electrical element, such as a switch, is sized to fit within the groove.
