Valves, hydraulic valves as machine components that is counterbalance valves, regenerative counterbalance valves, pressure control valves, flow control valves, check valves, valves for hydraulic pumps and motor, electrically operated valves, pneumatic operated valve, hydraulic operated valves, manually operated valves, hydraulic distributors as machine parts, customized manifold as machine parts, pump control valves, servo-valves, hydraulic pumps, hydraulic motors other than for land vehicles.

Abstract

A machine (1) comprises: - a rotor (10) exhibiting a preset number (n) of end zones (1 1); - a stator (20) exhibiting a recess (21) delimited by an inner surface (22a). The rotor (10) is eccentrically mounted internally of the recess (21) of the stator (20) and is movable relative to the stator (20) by performing a roto-orbital movement about an axis (A1) of the recess (21). Each end zone (1 1) of the rotor (10) is provided with a rolling element (16) suitable for rolling on the inner surface (22a) of the recess (21), in such a manner as to remain in contact with the inner surface (22a) of the recess (21 ), while the rotor (10) is roto-orbiting about the axis (A1) of the recess (21 ). The machine (1 ) is further provided with a balancing arrangement, so that pressurized fluid exerts axially balanced focus on the rotor (10).

IPC Classes  ?

• F01C 21/08 - Rotary pistons
• F01C 21/10 - Outer members for co-operation with rotary pistonsCasings
• F04C 2/22 - Rotary-piston machines or pumps of internal-axis type with equidirectional movement of co-operating members at the points of engagement, or with one of the co-operating members being stationary, the inner member having more teeth or tooth-equivalents than the outer member
• F04C 15/00 - Component parts, details or accessories of machines, pumps or pumping installations, not provided for in groups
• F01C 1/22 - Rotary-piston machines or engines of internal-axis type with equidirectional movement of co-operating members at the points of engagement, or with one of the co-operating members being stationary, the inner member having more teeth or tooth-equivalents than the outer member
• F01C 19/02 - Radially-movable sealings for working fluids
• F01C 19/08 - Axially-movable sealings for working fluids

Goods & Services

Valves as machine components; valves for pumps; pump control valves; [ servo-valves; ] back pressure valves as parts of machines; [ hydraulic pumps; motors other than for land vehicles, namely, oleodynamic motors; ] machine parts, namely, oleodynamic distributors

Goods & Services

(1) Pressure relief valves; safety valves; solenoid valves; stop valves; valves for industrial machinery.

Goods & Services

Valves, pumps, oleodynamic motors and oleodynamic distributors.

Goods & Services

Components for oleodynamic devices and installations; valves, oleodynamic distributors, pumps, oleodynamic motors and engines.
