Abstract

An inductive sensor device has a scale body having a multiplicity of conductor strip loops arranged in a measurement direction in at least one scale line. A sensor unit is moveable along the scale body and has one coil group for each scale line, the coil group comprising a transmitter coil for producing a transmitter signal and at least one receiver coil. Each coil group provides at least one receiver signal for an evaluation unit for determination of an absolute relative position of the sensor unit relative to the scale body. At least one of the scale lines has at least one modulating section, within which the impedances and/or the apparent resistances of conductor strip loops change from one end of the modulating section to the other, whereby the at least one receiver signal is modulated with regard to its phase position relative to the transmitter signal.

IPC Classes  ?

• G01D 5/20 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing the magnitude of a current or voltage by varying inductance, e.g. by a movable armature
• G01B 7/02 - Measuring arrangements characterised by the use of electric or magnetic techniques for measuring length, width, or thickness

Abstract

A measuring machine and a process for positioning a workpiece in the measuring machine are disclosed. A workpiece carrier holding the workpiece is driven around an axis of rotation, and an optical sensor is positioned in a measuring position parallel to the axis of rotation. In this measuring position, measuring data, such as images, are recorded on the workpiece and made available to a control unit. In the control unit, an offset and/or an inclination of a longitudinal axis of the workpiece relative to the axis of rotation is determined from the measuring data of at least two measuring points on the workpiece and then reduced or eliminated by activating a position correction system of the measuring machine such that a specified positioning condition is fulfilled. The position correction system is configured to tilt and/or translationally move the workpiece carrier relative to the axis of rotation.

IPC Classes  ?

• G01B 11/24 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures
• G01B 11/27 - Measuring arrangements characterised by the use of optical techniques for measuring angles or tapersMeasuring arrangements characterised by the use of optical techniques for testing the alignment of axes for testing the alignment of axes
• G06T 7/70 - Determining position or orientation of objects or cameras

Abstract

A measuring apparatus and a method for determination of a measurement value of an object are disclosed. A sensor unit, produces one sensor signal respectively in different measuring positions along a positioning direction for multiple measurement points on an object, wherein the sensor signal describes the position of the measurement point. A positioning device positions the sensor unit and the object in the different measuring positions relative to one another in a positioning direction. The positioning or relative movement in the positioning direction is influenced by a periodic position deviation of the positioning device, which influences the detected sensor signals of the measurement points. A positioning characteristic describing the wavelength and/or the period of the periodic position deviation is determined. By means of the positioning characteristic, the sensor signals obtained for multiple measurement points in different measuring positions can be corrected to obtain the measurement value for the respective measurement point therefrom.

IPC Classes  ?

• G01B 11/00 - Measuring arrangements characterised by the use of optical techniques
• G01B 11/24 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures

Abstract

The invention relates to a method for determining a position error in a device (20), in particular a measurement instrument (21), that comprises a stator (23), a rotor (24) and a rolling bearing unit (25) arranged therebetween. For calibration purposes, a standard (30) is arranged on the rotor (24) and moved in a movement direction (B), for example rotated about an axis of rotation (D). Measured values of the standard (30) are measured in various positions of the standard (30) in the movement direction (B), by means of a first sensor (31). A second sensor (37) measures at least one position of the rolling bearing unit (25) in the movement direction (B). Based on this measured rolling bearing position, a rolling bearing position is assigned to each measured value for each position of the standard (30) in the movement direction (B), and the position error (F) and optionally a correction rule (K) are determined on the basis thereof.

IPC Classes  ?

• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points
• F16C 41/00 - Other accessories for bearings
• G01B 21/12 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring diameters of objects while moving
• G01M 13/04 - Bearings

Abstract

A measurement device and a measurement system comprising a measurement device and a machine tool are disclosed. The measurement device has a support with a connection body arranged thereon as an interface to a machine side holding device of the machine tool. A measurement unit is arranged on the support including a probe tip, a linear drive unit for movement of the probe tip in a movement direction, a sensor unit for detection of the position of the probe tip in a probing direction, and a measurement control unit communicatively connected with the linear drive unit and the sensor unit. The measurement unit preferably comprises an electrical energy supply, such as a battery. The measurement control unit is configured for wireless communication with a machine control device of the machine tool. Accordingly, the measurement control unit and the machine control device can cooperate to control the measurement progress.

IPC Classes  ?

• G01B 5/28 - Measuring arrangements characterised by the use of mechanical techniques for measuring roughness or irregularity of surfaces
• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points

Goods & Services

Marking tools and instruments; fluid dispensing machines for industrial use, gear pumps, allocation pumps; mixing heads, including being part of fluid dispensing machines for industrial use; accessories of the before-mentioned goods, namely electrical control units, refilling and filling machines, degassing machines, pump test stations, cutters for glass fibers, machines for tempering fluid materials. Mechanical, electrical, electronic, pneumatic, optical, opto-electronic, interferometric instruments, systems and devices in the field of measuring and control technology and/or fluid mechanics, in particular coordinate, form and shaft measuring devices, microscopes, instruments for measuring and testing, in particular of linear dimensions, form, profile and position deviations, workpiece contours, roughness and workpiece surface properties, devices for monitoring test equipment, mechanical, electrical, electronic, pneumatic, optical, opto-electronic and interferometric sensors, camera systems for transmitted and reflected light methods, devices for measuring fluid materials, in particular gear pumps and mixing heads for pure substances, dispersed fluid materials, emulsions and solutions, hand-operated mechanical and electrical measuring devices, in particular calipers, dial gauges, touch probes, outside micrometers, precision indicators, lever gauges, micrometers; measures, gauges and standards, in particular scales, gauge blocks, roughness standards, thread gauges, gauges for measuring instruments, ring gauges, master gears; ball guides; electric marking tools and instruments; electric and mechanical installations for industrial operations in the field of measuring and control technology and/or fluid mechanics; accessories for the before-mentioned goods, in particular measuring tables, electrical and analog display units, sensor components, in particular probe arms, probe elements, camera units, lighting units, measuring lasers, fixtures for holding workpieces, in particular jaw chucks, centering points, collet chucks, mandrels, components in the field of fluid mechanics and pump technology, in particular degassing machines, pump test benches, refilling and filling machines, machines for tempering fluid materials, cutters for glass fibers, electronic components and tools, in particular for control, regulation, data storage and evaluation, data and algorithms for the before-mentioned goods, in particular for control, regulation, data storage, analysis and evaluation. Commissioning, installation, repair, maintenance of installations, systems, machines, devices, tool, sensors, gear pumps, mixing heads and appliances for metering fluid materials in the field of measuring and control technology and/or fluid mechanics, including accessories therefor. Instruction, teaching and practical training in the field of measuring and control technology and/or fluid mechanics, including accessories therefor. Services of physicists, services of engineers and software programming in the field of measurement and control technology and/or fluid mechanics; conducting of technical project planning in the field of measuring and control technology and/or fluid mechanics; services of a technical measuring and test laboratory and conducting of technical tests in the field of measuring and control technology and/or fluid mechanics; calibration and functional testing of instruments in the field of measurement and control technology and/or fluid mechanics.

Goods & Services

Marking tools and instruments being industrial machinery, namely, electromechanical marking machines; fluid dispensing machines for industrial use; gear pumps being positive displacement pumps, allocation pumps being positive displacement pumps, and structural parts for the aforementioned pumps in the nature of pump test stations; mixing heads being parts for fluid dispensing machines for industrial use; structural parts of the before-mentioned goods, namely, electrical control units; refilling and filling machines; degassing machines for industrial use, machines for the forming and treatment of materials, specifically, for tempering fluid materials; Instruments for marking workpieces being industrial machinery Mechanical, electrical, electronic, pneumatic, optical, opto-electronic, interferometric instruments and devices, being scientific instrumentation for measuring linear dimensions, form, profile and position deviations, workpiece contours, and roughness and workpiece surface properties, of workpieces; industrial instrumentation for measuring fluid materials; length measuring instruments being calipers, dial gauges, touch probes, outside micrometers, precision indicators, lever gauges, micrometers; Tool measuring instruments being measures, gauges and standards, in particular, scales, gauge blocks, roughness standards, thread gauges, gauges for measuring instruments, and ring gauges; electric installations for industrial operations in the field of measuring and control technology and fluid mechanics, namely, electric control panels; Electric luminescent display panels, electric sensors, electronic sensory probes for industrial measurement purposes, measuring lasers, and cameras; and ball guides being structural parts for the aforementioned goods in this class; all being components in the field of fluid mechanics and pump technology, specifically for use with degassing machines, pump test benches, refilling and filling machines, machines for tempering fluid materials, cutters for glass fibers Installation, maintenance and repair of machinery, specifically for installations, systems, machines, devices, tool, sensors, gear pumps, mixing heads and appliances for metering fluid materials in the field of measuring and control technology and fluid mechanics, and the accessories therefor Instruction, teaching and practical training in the field of measuring and control technology and fluid mechanics Services of physicists, namely, physics research in the field of measurement and control technology and fluid mechanics; engineering services in the field of measurement and control technology and fluid mechanics; computer software programming in the field of measurement and control technology and fluid mechanics; Scientific and technological services, namely, conducting of technical project planning for engineering projects in the field of measuring and control technology and fluid mechanics; Scientific and technological services, namely, technical measuring, test laboratory and conducting of technical tests, in the field of measuring and control technology and fluid mechanics; Scientific and technological services, namely, calibration and functional testing of instruments, in the field of measuring and control technology and fluid mechanics;

Goods & Services

Fluid dispensing machines For industrial purposes, Gear pumps, Dispensing pumps; Mixing heads, including being components of fluid dispensing machines, For industrial purposes; Fittings for all the aforesaid goods, namely Refilling and filling machines, De-aerating machines, Fibreglass cutters, machines for regulating the temperature of liquids; Mechanical storage units, namely Ball guides and components thereof, namely Ball cages, Guide shafts and Guide bush, Fittings for all the aforesaid goods; Industrial mixing machines and Automatic dispensing machines in the following fields: Measurement and control engineering and/or fluid mechanics, Fittings for all the aforesaid goods; Components, in the following fields: Fluid mechanics and pump technology, namely Refilling and filling machines, fibreglass cutters. Mechanical, electric, electronic, pneumatic, optical, opto-electronic, interferometric, fluid-mechanical measuring and regulating apparatus and measuring and regulating systems consisting thereof; Electrical control apparatus; Coordinate-measuring apparatus, forming apparatus and wave measuring devices; Microscopes; Apparatus for measurement and testing, in particular of length, shape, profile and position deviations, workpiece contours, roughness and workpiece surface properties; Pump test benches; Equipment for monitoring of test media, Mechanical sensors, Electric sensors, Electronic sensors, pneumatic sensors, Optical sensors, Optical-Electric Sensors and Interferometric sensors; Camera systems for transmitted- and reflected-light processes, apparatus for the measurement of liquids, Especially Gear pumps and mixing heads for pure substances, disperse liquids, emulsions and solutions; Hand-operated mechanical and electric measuring apparatus, Especially Slide calipers, Dial indicators, Measuring sensors, Outside micrometers, Dial gauges, Lever indicators, Micrometers; Measures, Gauges and measurement standards, Especially Rules (measuring instruments), Gauge blocks, Roughness measurement standards, Screw-tapping gauges, Gauges for measuring instruments, Ring gauges, Master gears; Electric marking tools and apparatus; Accessories for the aforementioned goods, Especially Measuring tables, Electricity indicators and Analogue display apparatus; Sensor components, Especially Probe arms, probe elements, camera units, battery powered lighting units, Lasers for measuring; Devices for the holding of workpieces, Especially Jaw chucks, lathe centers, Grippers, expanders; Components in the following fields: Fluid mechanics and pump technology, namely Pump test benches, electronic components and apparatus, namely for the control, regulation, data storage and evaluation of data and algorithms for the aforesaid goods, namely for control, regulation, data storage, analysis and evaluation; Electronic marking gauges. Commissioning, Installation, repair, Maintenance in relation to the following goods: Installations, systems, machines, devices, apparatus, sensors, gear pumps, mixing heads and apparatus for the measurement of liquids in the field of measurement and control engineering and/or fluid mechanics, including accessories therefor. Instruction, Teaching and Practical training in the following fields: Measurement and control engineering and/or fluid mechanics, including accessories therefor. Services of physicists, Engineering services and Development of software programs in the following fields: Metrology and Regulatory engineering and/or Fluid mechanics; Conducting technical project studies in the following fields: Metrology and Regulatory engineering and/or Fluid mechanics; Laboratory services relating to technical measurements and testing and Engineering testing in the following fields: Metrology and Regulatory engineering and/or Fluid mechanics; Calibration of apparatus (equipment) and Functionality testing of apparatus in the following fields: Metrology and Regulatory engineering and/or Fluid mechanics.

Abstract

A probe unit and a holder of a measurement apparatus that can be releasably connected to one another, particularly without tools, are disclosed. The probe unit includes a mounting device having a contact surface and the holder comprises a counter-contact surface assigned to the contact surface. The contact surface can be divided into multiple separate surface sections that respectively abut along a line or two-dimensionally against the assigned counter-contact surface, if the mounting device takes a contact position. The holding force is produced by at least one mounting magnet of the mounting device and/or at least one holding magnet of the holder. Thereby a magnetic axial force in an axial direction as well as a magnetic circumferential force in a circumferential direction around the axial direction is created, so that the mounting device and holder are urged relative to one another in a desired rotational position in the circumferential direction.

IPC Classes  ?

• G01R 1/067 - Measuring probes
• G01R 1/16 - Magnets

Abstract

A fiber-optic point probe for a distance measurement system has an optical fiber that can be connected to a light source or an evaluation device. Illumination light is transmitted via the optical fiber to a beam-forming element and is converted into beam-formed illumination light. The beam-formed illumination light is guided along a first optical axis to a planar surface of a deflection element and is reflected thereby. The beam-formed illumination light reflected on the planar surface spreads along a second optical axis, exits on a spherical end surface of the deflection element and forms a focused illumination beam having a focus area outside of the deflection element. An object surface arranged in the focus area can be probed such that a distance relative to a probe internal reference surface can be determined in a contactless manner.

IPC Classes  ?

• G01S 7/481 - Constructional features, e.g. arrangements of optical elements
• G02B 6/26 - Optical coupling means

Goods & Services

Measuring systems and devices, particularly for measuring coordinates, shapes and waves; sensors, particularly tactile and optical sensors; camera systems, particularly for procedures using transferred light or reflected or incident light methods; interferometric sensors; accessories for all the aforesaid goods, specifically sweeping arms or probers, probing elements and rods, devices for collecting workpieces, specifically jaw chucks, centering points, collets, chucks; electronic components and apparatus for all the aforesaid goods, specifically for controlling, monitoring, storing data and evaluation in the field of measuring techniques; data and algorithms for all the aforesaid goods, specifically for controlling, monitoring, storing data and evaluation in the field of measuring techniques. Commissioning, repair and maintenance of measuring systems and devices, especially for measuring coordinates, shapes and waves, sensors, especially tactile and optical sensors, camera systems, especially for procedures using transferred light or reflected or incident light methods, and interferometric sensors. Training in the fields of measuring systems and devices, especially for measuring coordinates, shapes and waves, sensors, especially tactile and optical sensors, camera systems, especially for procedures using transferred light or reflected or incident light methods, and interferometric sensors. Calibration services, updating software, designing measuring programs for measuring systems and devices, especially for measuring coordinates, shapes and waves, sensors, especially tactile and optical sensors, camera systems, especially for procedures using transferred light or reflected or incident light methods, and interferometric sensors.

Goods & Services

Measuring devices, namely, handheld tactile length metrology devices, handheld optical length metrology devices, handheld optical surface metrology devices, calipers, micrometers, length measuring dial indicators, measuring stands in the nature of laboratory furniture for holding workpieces, length measuring instruments, height measuring instruments, height gauges, profilometers, surface measuring instruments, mobile surface roughness measuring instruments, roughness measuring stations comprised of surface roughness testing machines and instruments, contour measuring stations comprised of contour testing machines and instruments, combined contour and surface measuring stations comprised of contour gauges and surface roughness testing machines and instruments, coordinate measuring machines, cylinder coordinate measuring machines, form measuring machines, gear measuring machines, shaft measuring machines, interferometers, and microscopes, all aforesaid goods for measuring coordinates, and for testing and measuring surface roughness, contour and shapes of a workpiece; sensors, namely, tactile and optical sensors for measuring coordinates, and for testing and measuring surface roughness, contour and shapes of a workpiece; accessories specially adapted for all the aforesaid goods, namely, sweeping arms or probers, probing elements for measuring a workpiece; electronic components and apparatus for all the aforesaid goods, namely, electronic control systems comprised of electronic controllers for machines, computers, electronic display screens and data storage computer hardware for controlling, monitoring, storing data and evaluation in the field of measuring techniques; recorded and downloadable computer software for all the aforesaid goods incorporating algorithms for controlling, monitoring, storing data and evaluation in the field of measuring techniques Repair and maintenance of measuring systems and devices, namely, for measuring coordinates, surface roughness and shapes of a workpiece, sensors, namely tactile and optical sensors, camera systems, especially for procedures using transferred light or reflected or incident light methods, and interferometric sensors Training in the fields of using, repairing, maintaining, and designing measuring systems and devices, especially for measuring coordinates, shapes and waves, sensors, especially tactile and optical sensors, camera systems, especially for procedures using transferred light or reflected or incident light methods, and interferometric sensors Calibration services, updating of computer software, designing measuring computer software programs for measuring systems and devices, especially for measuring coordinates, surface roughness and shapes of a workpiece, sensors, especially tactile and optical sensors, camera systems, especially for procedures using transferred light or reflected or incident light methods, and interferometric sensors

Goods & Services

metering systems and Meteorology apparatus, Especially, Coordinate-measuring apparatus, forming apparatus, wave measuring devices; Sensors, Especially, Tactile sensors, Optical sensors, Camera systems, The aforesaid goods in particular for transmitted and reflected light processes, interferometric sensors; Accessories for the aforementioned goods, Especially Probe arms, probe elements, devices for holding workpieces, Especially Jaw chucks, lathe centers, Grippers, expanders; Electronic components and apparatus for the aforesaid goods, namely for control, regulation, data storage and evaluation in the field of measurement technology; Data and algorithms for the aforesaid goods, namely for control, regulation, data storage and evaluation in the field of measurement technology. Commissioning, fix, Maintenance, In relation to the following goods: measuring systems, Measuring devices, Especially, Coordinate-measuring apparatus, forming apparatus, wave-measuring apparatus, Sensors, Especially, Tactile sensors, Optical sensors, Camera systems, The aforesaid goods in particular for transmitted and reflected light processes, interferometric sensors. Provision of training courses, in relation to the following fields: Measuring systems and measuring devices, specifically, Coordinate-measuring apparatus, forming apparatus, wave-measuring apparatus, sensors, specifically, Tactile sensors, optical sensors, Camera systems, the aforesaid goods in particular for transmitted and reflected light processes, interferometric sensors. Calibration, Software update services, Development of measurement programs, In relation to the following goods: metering systems and Meteorology apparatus, Especially, Coordinate-measuring apparatus, forming apparatus, wave-measuring apparatus, Sensors, Especially, Tactile sensors and optical sensors, Camera systems, The aforesaid goods in particular for transmitted and reflected light processes, interferometric sensors.

Abstract

An objective lens mount and a connection device are releasably connected. The connection device is part of an objective lens or an adapter. The objective lens mount has at least one abutment surface that cooperates with at least one counter abutment surface at the connection device. At least two V-shaped first positioning bodies with at least one positioning surface are arranged such that the positioning surfaces face the longitudinal axis. At least one counter positioning surface at the connection device abuts the positioning surfaces of the objective lens mount. The relative position in the circumferential direction is defined via a rotation stop of the objective lens mount that cooperates with a counter rotation stop of the connection device. A locking device retains the connection device at the objective lens mount and effects a force component in the axial direction and preferably a force component in circumferential direction.

IPC Classes  ?

• G02B 7/02 - Mountings, adjusting means, or light-tight connections, for optical elements for lenses
• G02B 7/14 - Mountings, adjusting means, or light-tight connections, for optical elements for lenses adapted to interchange lenses

Abstract

An arrangement (20) comprising a first part (21), a second part (22), and an adjustment device (23). The adjustment device (23) includes at least one adjustment unit (24) having a one first sleeve (25) extending in a respective adjustment direction (R) that is connected with the first part (21). At a free sleeve end (27) of the first sleeve (25) an abutment surface (28) is provided. The first sleeve (25) is arranged in a part cavity (26) of the first part (21) and includes a clearance (34) extending in circumferential direction between the first part (21) and the first sleeve (25). Adjacent to the clearance (34) at least one support part (35) is supported at the first part (21) radially to the adjustment direction (R). An adjustment screw (36) can apply a force to the first sleeve (25) to lengthen or compress it in the respective adjustment direction (R).

IPC Classes  ?

• F16B 5/02 - Joining sheets or plates to one another or to strips or bars parallel to them by means of fastening members using screw-thread

Abstract

A measurement arm receptacle device of a measurement system for releasably arranging a measurement arm. The measurement arm receptacle device comprises a holding device that cooperates with a counter holding device of the measurement arm. The holding and counter holding devices may each comprise at least one retaining magnet. The measurement arm receptacle device comprises an electric contact part movable between a rest position and a working position. In the rest position the contact part is electrically connected with an electric reference potential and in the working position the electric contact part is electrically connected with a measurement arm contact of the measurement arm. Thus it can be unambiguously determined via the contact part, if a measurement arm is arranged at the measurement arm receptacle device and additionally a data carrier of the measurement arm electrically connected with the measurement arm contact can be read out.

IPC Classes  ?

• G01B 5/008 - Measuring arrangements characterised by the use of mechanical techniques for measuring coordinates of points using coordinate measuring machines
• G01B 5/00 - Measuring arrangements characterised by the use of mechanical techniques
• G01B 5/28 - Measuring arrangements characterised by the use of mechanical techniques for measuring roughness or irregularity of surfaces

Abstract

A workpiece holder, measuring device, and a method for executing a measurement by using the workpiece holder. The workpiece holder is configured to hold a workpiece with two opposite arranged workpiece surfaces to be measured in a way that both are accessible by a moveable probe unit and can thus be measured in one setting of the workpiece. For this the workpiece holder comprises a support and a holding body. The holding body has a holding end away from the support with at least one holding surface at which the workpiece is held. In the holding body a free space is formed that adjoins the workpiece surface facing the support when a workpiece is held and makes the workpiece surface accessible for measuring or probing. The accessibility for the probe unit is provided by a transverse channel extending obliquely or orthogonally to the longitudinal axis of the workpiece holder.

IPC Classes  ?

• B23Q 17/20 - Arrangements for indicating or measuring on machine tools for indicating or measuring workpiece characteristics, e.g. contour, dimension, hardness
• G01B 5/00 - Measuring arrangements characterised by the use of mechanical techniques
• B23Q 1/44 - Movable or adjustable work or tool supports using particular mechanisms
• G01B 5/20 - Measuring arrangements characterised by the use of mechanical techniques for measuring contours or curvatures
• G01M 11/02 - Testing optical properties

Abstract

A method for adjusting a measuring device having an interferometer unit with an optical axis, an optical distance measuring device with a measuring axis and a support slide that is moveable along a slide axis. The measuring axis is first aligned parallel to the slide axis. An adjustment body with a first spherical reflection and/or diffraction surface and a retro reflector at the back side is arranged at the support slide. It is brought into a first confocal position, in which a first center point of the first spherical reflection/diffraction surface coincides with the focus of the spherical wavefront that is emitted from the interferometer unit. The retro reflector defines a vertex that is located close to the first center point, such that the measuring axis of the distance measuring device extends close to the focus of the emitted spherical wavefront. In doing so, Abbe-faults can be reduced or eliminated.

IPC Classes  ?

• G01B 9/02 - Interferometers
• G01B 11/255 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures for measuring radius of curvature

Abstract

A measuring system (15) includes a measuring arm receiving unit (18) mounted on the housing (49) or on an axial pin (30) connected to the housing (49) for conjoint rotation so as to be rotatable or pivotable about the axis of rotation (D). A measuring arm (16) can be arranged on the measuring arm receiving unit (18). A motor unit (24) generates a motor torque about the axis of rotation (D) on the measuring arm receiving unit (18). The measuring arm unit (18) is mounted by a ball bearing guide unit (39) to be rotatable about the axis of rotation (D) in the peripheral direction and displaceably along the axis of rotation (D) in the axial direction A. An axial position of the measuring arm unit (18) in the axial direction is defined with the aid of a magnetic axial bearing device (46) and is maintained during operation.

IPC Classes  ?

• G01B 7/34 - Measuring arrangements characterised by the use of electric or magnetic techniques for measuring roughness or irregularity of surfaces
• G01B 7/00 - Measuring arrangements characterised by the use of electric or magnetic techniques
• G01B 5/28 - Measuring arrangements characterised by the use of mechanical techniques for measuring roughness or irregularity of surfaces
• G01B 3/00 - Measuring instruments characterised by the use of mechanical techniques
• G01B 5/00 - Measuring arrangements characterised by the use of mechanical techniques
• G01B 7/016 - Constructional details of contacts
• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points

Abstract

A measuring system (15) includes a measuring arm receiving unit (18) mounted on the housing (49) or on an axial pin (30) connected to the housing (49) for conjoint rotation so as to be rotatable or pivotable about the axis of rotation (D). A measuring arm (16) can be arranged on the measuring arm receiving unit (18). A motor unit (24) generates a motor torque about the axis of rotation (D) on the measuring arm receiving unit (18). A rotary angle specifying the rotary angle position of the measuring arm receiving unit (18) about the axis of rotation (D) is detected by a measuring device (67) having a scale part (68) and a detection unit (69). The scale part (68) is arranged in the form of a circular arc, annularly, or in the form of a disc about or coaxially with the axis of rotation (D).

IPC Classes  ?

• G01B 5/008 - Measuring arrangements characterised by the use of mechanical techniques for measuring coordinates of points using coordinate measuring machines
• G01B 5/28 - Measuring arrangements characterised by the use of mechanical techniques for measuring roughness or irregularity of surfaces
• G01B 3/00 - Measuring instruments characterised by the use of mechanical techniques
• G01B 7/00 - Measuring arrangements characterised by the use of electric or magnetic techniques

Abstract

The invention relates to a measuring arm holding device (18) of a measuring system (15), for the detachable arrangement of a measuring arm (16). To this end, the measuring arm holding device (18) can have a retaining device (25) which interacts with a mating retaining device (26) on the measuring arm (16). In one embodiment, both the retaining device (25) and the mating retaining device (26) each have at least one retaining magnet. The magnet axes of the two retaining magnets are offset to each other when the connection is made, thus generating a magnetic retaining force having a force component which is oriented transversely to the magnet axes. A magnetic force having a vector in two or three spatial directions can thus be generated by a single pair of two retaining magnets. In a further embodiment according to the invention, the measuring arm holding device (18) has an electrical contact part (66) which can be moved between a rest position (I) and a working position (II). In the rest position (I), the contact part is connected to an electrical reference potential, and in the working position (II), the electrical contact part is electrically connected to a measuring arm contact (68) of the measuring arm (16). It can thus be detected clearly via the contact part (69) whether a measuring arm (16) is arranged on the measuring arm holding device (18), and a data carrier, electrically connected to the measuring arm contact, of the measuring arm (16) can also be read.

IPC Classes  ?

• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points
• G01B 5/008 - Measuring arrangements characterised by the use of mechanical techniques for measuring coordinates of points using coordinate measuring machines

Abstract

i) is detected, a reference plane (B) is defined as zero position in the probing direction (x) using the point of contact between the two probe elements. The zero position can thus be determined without calibrated standards or block gauges.

IPC Classes  ?

• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points
• G01B 5/008 - Measuring arrangements characterised by the use of mechanical techniques for measuring coordinates of points using coordinate measuring machines
• G01B 5/00 - Measuring arrangements characterised by the use of mechanical techniques

Abstract

2) about the rotary axis (C), and again measured points in the measuring plane (E) on the upper surface (17) of the workpiece (16) are recorded. Based on these recorded measured points, the actual attitude (Li) of the workpiece (16) deviation from a specified target attitude (Ls) are determined. Adjustment parameters are determined, and an adjustment assembly (24) of the metrological apparatus (15) is activated as a function of the calculated adjustment parameters to adjust the workpiece (16).

IPC Classes  ?

• B23Q 17/22 - Arrangements for indicating or measuring on machine tools for indicating or measuring existing or desired position of tool or work
• G01B 5/004 - Measuring arrangements characterised by the use of mechanical techniques for measuring coordinates of points
• G01B 11/00 - Measuring arrangements characterised by the use of optical techniques
• B23Q 1/44 - Movable or adjustable work or tool supports using particular mechanisms
• B23Q 17/20 - Arrangements for indicating or measuring on machine tools for indicating or measuring workpiece characteristics, e.g. contour, dimension, hardness
• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points
• G01M 11/02 - Testing optical properties
• G01B 5/00 - Measuring arrangements characterised by the use of mechanical techniques
• G01B 5/20 - Measuring arrangements characterised by the use of mechanical techniques for measuring contours or curvatures
• G01B 5/25 - Measuring arrangements characterised by the use of mechanical techniques for measuring angles or tapersMeasuring arrangements characterised by the use of mechanical techniques for testing the alignment of axes for testing the alignment of axes
• G02B 27/62 - Optical apparatus specially adapted for adjusting optical elements during the assembly of optical systems

Abstract

The invention relates to a method for calibrating a measuring device, comprising the following steps: moving, with finite accuracy and thus with positioning error, to various points that lie in a testing volume of the measuring device and that can be characterized by spatial and/or angular coordinates, generating measurement signals at the respective points, and determining parameters of a computing model of the measuring device from the measurement signals and the spatial and/or angular coordinates. The method is characterized in that a coordinate system to which the coordinates of the points of the testing volume relate is defined from points moved to with error, by associating predetermined coordinate values with exactly six coordinates of three points.

IPC Classes  ?

• G01B 11/02 - Measuring arrangements characterised by the use of optical techniques for measuring length, width, or thickness
• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points
• G01B 9/02 - Interferometers

Abstract

The invention relates to a holding apparatus for an optical measurement device. The holding apparatus has two holding units for two preferably telecentric optics units of the measurement device. Each holding unit has a first bearing device and a second bearing device. The two bearing devices are arranged at a distance from one another in the direction of an optical axis of the optics unit. A three-point bearing by three bearing elements for the associated optics unit is provided on each bearing device. At least two of the bearing elements can be positioned along a relevant adjustment axis. The adjustment axes extend substantially at right angles to the relevant optical axis. The optics unit can thus be displaced in a plane spanned by the adjustment axes and can be inclined or tilted on account of the two bearing devices distanced from one another.

IPC Classes  ?

• G02B 7/00 - Mountings, adjusting means, or light-tight connections, for optical elements
• G02B 7/02 - Mountings, adjusting means, or light-tight connections, for optical elements for lenses
• G01B 5/00 - Measuring arrangements characterised by the use of mechanical techniques
• G01B 11/24 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures
• G01B 11/27 - Measuring arrangements characterised by the use of optical techniques for measuring angles or tapersMeasuring arrangements characterised by the use of optical techniques for testing the alignment of axes for testing the alignment of axes
• G02B 13/22 - Telecentric objectives or lens systems

Goods & Services

Electro-optical measuring machines and instruments (other than for astronomy purposes), namely, interferometers, optical 2D- and 3D-coordinate measuring devices based on area scanning, material inspection measuring devices based on scattered light, for use in the optical and high precision industry; accessories for electro-optical measuring machines and instruments, namely, measuring stands (vertical and horizontal), robot arms for 2D- and 3D- scanning of samples, mounts, positioning units, stages, optical and objective lenses, beam expanders, flats, spheres, optical filters, attenuation filters, reflectors and standard samples; computer programs to acquire interferograms under lab and shop floor conditions; computer programs to analyse interferograms namely programs for fringe, phase-shifting and carrier-fringe interferometers used all under lab and shop floor conditions; computer programs for aspherical surface measurements, namely programs to generate software references and to analyse interferograms; computer programs for material characterization, namely, for roughness and for identification classification of inhomogenities. Installation, maintenance and repair of measuring machines and instruments. Teaching, instruction services and practical training to use measuring machines and instruments. Services of engineers and scientists in the scientific and technological field including technological consultancy, namely, calibration services, maintenance and updating of computer programs for measuring machines and instruments.

Abstract

An inductive rotary transmitter includes a rotor and a stator, which form a rotary transmitter. A rotor winding is arranged on the rotor, and a stator winding is arranged on the stator. Apart from the rotor winding, the rotor does not have any ferromagnetic or soft-magnetic material parts for inductive coupling to the stator or the stator winding. The annularly closed magnetic field lines for inductive coupling are formed on the stator side via the stator winding and a plurality of separate stator elements, which are produced from ferromagnetic or soft-magnetic material. The stator elements overlap both the rotor winding and the stator winding at a respective mounting point of the stator element and direct the magnetic field lines (M) around the rotor winding and around the stator winding to effect a magnetic coupling.

IPC Classes  ?

• H01F 38/18 - Rotary transformers
• H01F 27/24 - Magnetic cores

Goods & Services

Electro-optical measuring machines and instruments for use in inspection and measurement of industrial components, other than for astronomy purposes, namely, interferometers, optical 2D- and 3D-coordinate measuring devices based on area scanning, material inspection measuring devices based on scattered light, for use in the optical and high precision industry; accessories for electro-optical measuring machines and instruments for use in inspection and measurement of industrial components, namely, measuring stands, vertical and horizontal, robot arms for 2D- and 3D- scanning of samples, mounts, positioning units, stages, optical and objective lenses, beam expanders, flats, spheres, optical filters, attenuation filters, reflectors and standard samples; computer programs for acquiring interferograms under lab and shop floor conditions; computer programs for analyzing interferograms, namely, programs for fringe, phase-shifting and carrier-fringe interferometers used all under lab and shop floor conditions; computer programs for aspherical surface measurements, namely, programs to generate software references and to analyse interferograms; computer programs for material characterization, namely, for roughness and for identification classification of inhomogenities Installation, maintenance and repair of measuring machines and instruments Teaching, instruction services and practical training services all in the field of use of measuring machines and instruments Services of engineers and scientists in the scientific and technological field, namely, technological consultancy, calibration services, maintenance and updating of computer programs for third parties for measuring machines and instruments

Goods & Services

electro-optical measuring machines and instruments (other than for astronomy purposes), namely, interferometers, optical 2D- and 3D-coordinate measuring devices based on area scanning, material inspection measuring devices based on scattered light, for use in the optical and high precision industry; accessories for electrooptical measuring machines and instruments, namely, measuring stands (vertical and horizontal), robot arms for 2D- and 3D-scanning of samples, mounts, positioning units, stages, optical and objective lenses, beam expanders, flats, spheres, optical filters, attenuation filters, reflectors and standard samples; computer programs to acquire interferograms under lab and shop floor conditions; computer programs to analyse interferograms namely programs for fringe, phase-shifting and carrier-fringe interferometers used all under lab and shop floor conditions; computer programs for aspherical sur-face measurements namely programs to generate software references and to analyse interferograms; computer programs for material characterization, namely, for roughness and for identification classification of inhomogenities. installation, maintenance and repair of measuring machines and instruments. teaching, instruction services and practical training to use measuring machines and instruments. services of engineers and scientists in the scientific and technological field including technological consultancy, namely, calibration services, maintenance and updating of computer programs for measuring machines and instruments.

Goods & Services

Measuring tools, including calipers, squares and protractors (measuring instruments), measures, rulers, aligning means, jigs, dial gauges and dial gauge apparatus, measurement racks, plane tables, concentricity gauges, outside micrometers, slide calipers, height measures; Electronic measuring tools with a digital display, including calipers, depth gauges, height measuring and marking devices, protractors (measuring instruments).

Abstract

The invention relates to a method for calibrating a measuring device, comprising the following steps: moving, with finite accuracy and thus with positioning error, to various points that lie in a testing volume of the measuring device and that can be characterized by spatial and/or angular coordinates, generating measurement signals at the respective points, and determining parameters of a computing model of the measuring device from the measurement signals and the spatial and/or angular coordinates. The method is characterized in that a coordinate system to which the coordinates of the points of the testing volume relate is defined from points moved to with error, by associating predetermined coordinate values with exactly six coordinates of three points.

IPC Classes  ?

• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points
• G01B 9/02 - Interferometers

Goods & Services

Electro-optical measuring instruments, namely interferometers, for use in the optical and high-precision industry; accessories for interferometer, namely 2-axis mounts, 7-axis stages and rails thereof, flats, optical lenses, optical filters and reflectors; measuring units consisting of vertically looking or horizontally arranged interferometers and accessories for measuring flat, spherical or aspherical surfaces; computer programs for data acquisition and interferogram analysis, namely fringe analysis programs, dynamic motion analysis programs and interferogram analysis programs for aspheres; computer programs to generate software references for aspherical surfaces. installation, maintenance and repair of measuring instruments and units. teaching, instruction services and practical training to use measuring instruments and units. calibration services of measuring instruments and units; Installation, maintenance and updating of computer programs.

Goods & Services

Automatic scribing tools and equipment. Hand-operated scribing tools and equipment. Electric scribing tools and equipment; measuring apparatus and instruments, including for industrial and scientific purposes and for test agent monitoring, mechanical, electromechanical, electric and electronic measuring apparatus and measuring instruments with analog or digital displays or electric or optical measuring signal interfaces, including optical and magnetic measuring apparatus and measuring instruments, calliper gauges, meter rule, dial gauge devices, stands for measurement, plane tables, concentricity gages, micrometers, calliper, meters for height measurement; depth measuring calliper gauges, height gauges, dial indicators, micrometers, micrometer gauges, bore measuring instruments, internal micrometers, gauge blocks, protractors, straight edges, bevelled steel squares, steel squares, measuring plates, radius templates, measuring probes, measuring stands, prisms, aligning devices, single axle measuring apparatus with incremental optoelectronic or magnetic measuring systems, coordinate measuring apparatus and tool presetting instruments; measuring microscopes; hardware and software for use in the field of measuring and testing technology. Repair and installation services in the field of measuring and testing technology. Engineering and physics (research); calibration services; computer programming in the field of measuring and testing technology.

Goods & Services

Automatic scribing tools and equipment. Hand-operated scribing tools and equipment. Measuring instruments with analog or digital displays or electric or optical measuring signal interfaces, including optical and magnetic measuring apparatus and measuring instruments, calliper gauges, meter rule, dial gauge devices, stands for measurement, plane tables, concentricity gages, micrometers, calliper, meters for height measurement; depth measuring calliper gauges, height gauges, dial indicators, micrometers, micrometer gauges, bore measuring instruments, internal micrometers, gauge blocks, protractors, straight edges, bevelled steel squares, steel squares, measuring plates, radius templates, measuring probes, measuring stands, prisms, aligning devices, single axle measuring apparatus with incremental optoelectronic or magnetic measuring systems, coordinate measuring apparatus and tool presetting instruments; measuring microscopes; hardware and software for use in the field of measuring and testing technology. Repair and installation services in the field of measuring and testing technology. Engineering and physics (research); calibration services; computer programming in the field of measuring and testing technology.

Goods & Services

Automatic scribing tools and automatic beam trammels and beam trammels with roller, both in the nature of scribers Hand-operated scribing tools and equipment, namely, scriber; Hand-operated scribing tools and equipment, namely, beam trammel, beam trammel with roller, all in the nature of scribers [ Electric scribing tools and equipment, namely, digital height and scribing gauge; ] measuring apparatus and instruments, including for industrial and scientific purposes and for test agent monitoring, and including mechanical, electromechanical, electric and electronic measuring apparatus and measuring instruments with analog or digital displays or electric or optical measuring signal interfaces, including optical and magnetic measuring apparatus and measuring instruments, namely, laboratory calipers in the nature of caliper gauges, graduated rulers in the nature of meter rules, dial gauge devices in the nature of timing dials, [ stands for measurement in the nature of stands specially designed for use with instruments for measuring length, ] tool measuring instruments and distance measuring apparatus, [ distance measuring apparatus in the nature of plane tables, concentricity gauges in the nature of concentration meters, ] micrometers, pocket calipers for measuring, instruments for measuring length in the nature of meters for height measurement, precision divider, spring divider, [ beam compass with round measuring beam, ] marking caliper, marking gauge, marking gauge with round measuring beam, [ height scribing gauge, height and scribing gauge, ] cross beam depth gauges in the nature of depth-measuring caliper gauges, [ instruments for measuring length in the nature of height gauges, ] dial indicators in the nature of timing dials, micrometer gauges, instruments for measuring length in the nature of bore-measuring instruments, [ internal micrometers, length measuring gauges in the nature of gauge blocks, ] protractors, straightedges, measuring apparatus in the nature of angle finders, namely, bevelled steel squares and steel squares, [ instruments for measuring length in the nature of measuring plates, ] radius templates in the nature of protactors, instruments for measuring length in the nature of measuring probes, [ measuring stands in the nature of stands specially designed for use with instruments for measuring length, ] tool measuring instruments and distance measuring apparatus [, prisms, instruments for measuring length in the nature of aligning devices, instruments for measuring length in the nature of single-axle measuring apparatus with incremental optoelectronic or magnetic measuring systems, coordinate measuring machines and instruments for measuring length in the nature of tool presetting instruments; measuring microscopes ] ; hardware and software for use in the field of measuring and testing technology Repair and installation services for goods in the field of measuring and testing devices Engineering and physics research; calibration services; computer programming in the field of measuring and testing technology

Goods & Services

Automatic scribing tools and automatic beam trammels and beam trammels with roller, both in the nature of scribers Hand-operated scribing tools and equipment, namely, scriber; Hand-operated scribing tools and equipment, namely, beam trammel, beam trammel with roller, all in the nature of scribers Electric scribing tools and equipment, namely, digital height and scribing gauge; measuring apparatus and instruments, including for industrial and scientific purposes and for test agent monitoring, and including mechanical, electromechanical, electric and electronic measuring apparatus and measuring instruments with analog or digital displays or electric or optical measuring signal interfaces, including optical and magnetic measuring apparatus and measuring instruments, namely, laboratory calipers in the nature of caliper gauges, graduated rulers in the nature of meter rules, dial gauge devices in the nature of timing dials, stands for measurement in the nature of stands specially designed for use with instruments for measuring length, tool measuring instruments and distance measuring apparatus, distance measuring apparatus in the nature of plane tables, concentricity gauges in the nature of concentration meters, micrometers, pocket calipers for measuring, instruments for measuring length in the nature of meters for height measurement, precision divider, spring divider, beam compass with round measuring beam, marking caliper, marking gauge, marking gauge with round measuring beam, height scribing gauge, height and scribing gauge, cross beam depth gauges in the nature of depth-measuring caliper gauges, instruments for measuring length in the nature of height gauges, dial indicators in the nature of timing dials, micrometer gauges, instruments for measuring length in the nature of bore-measuring instruments, internal micrometers, length measuring gauges in the nature of gauge blocks, protractors, straightedges, measuring apparatus in the nature of angle finders, namely, bevelled steel squares and steel squares, instruments for measuring length in the nature of measuring plates, radius templates in the nature of protactors, instruments for measuring length in the nature of measuring probes, measuring stands in the nature of stands specially designed for use with instruments for measuring length, tool measuring instruments and distance measuring apparatus, prisms, instruments for measuring length in the nature of aligning devices, instruments for measuring length in the nature of single-axle measuring apparatus with incremental optoelectronic or magnetic measuring systems, coordinate measuring machines and instruments for measuring length in the nature of tool presetting instruments; measuring micro-scopes; hardware and software for use in the field of measuring and testing technology Repair and installation services for goods in the field of measuring and testing devices Engineering and physics research; calibration services; computer programming in the field of measuring and testing technology

Abstract

A workpiece contour (13) at least first and second contour geometries (K1-K2) adjoining one another tangentially at a first transition point (U1). Measurement points (M) are recorded along the geometries (K1-K2). Using some measurement points within the first geometry (K1), a first replacement element (G1) is determined and assigned to the first geometry (K1). Analogously, using some measurement points (M) of the second geometry (K2) a second geometry element (G2) assigned to the latter is determined. The size and/or the position of the second geometry element (G2) are calculated under the boundary condition that the second replacement element (G2) adjoins the first replacement element (G1) tangentially. The tangential transition point between the two replacement elements (G1), (G2) forms the first transition point (U1). This method can be iterated using additional or other measurement points (M), until the first transition point (U1) is determined with sufficient accuracy.

IPC Classes  ?

• G01B 5/20 - Measuring arrangements characterised by the use of mechanical techniques for measuring contours or curvatures
• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points
• G01B 21/20 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring contours or curvatures, e.g. determining profile

Goods & Services

Mechanical marking tools and apparatus. Hand-operated marking tools and apparatus. Electric marking tools and apparatus; Measuring apparatus and measuring instruments, including for industrial and scientific purposes and for monitoring test media, mechanical, electromechanical, electric and electronic measuring apparatus and measuring instruments with an analogue or digital measured value display or electric or optical measurement signal interfaces, including optical and magnetic measuring apparatus and measuring instruments, caliper gauges, rules (measuring instruments), dial gauge apparatus, measurement racks, plane tables, concentricity gauges, outside micrometers, slide calipers, height dimensions, depth gauges, height measuring apparatus, dial gauges, micrometer gauges, micrometers, bore measuring apparatus, inside micrometers, gauge blocks, protractors (measuring instruments), straightedges, steel squares, steel angles, measuring plates, plug gauges, ring gauges, test pins, radius gauges, radius templates, measuring probes, measuring stands, V-blocks, aligning means, single-axis measuring apparatus with an incremental optoelectronic or magnetic measuring system, coordinate measuring apparatus and tool pre-setting instruments; Measuring microscopes; Hardware and software for use in the field of measuring and testing technology. Repair and installation services in the field of measuring and testing technology. Engineering services, Physics [research]; Calibration services; Computer programming in the field of measuring and testing technology.

Goods & Services

Mechanical marking tools and apparatus. Hand-operated marking tools and apparatus. Electric marking tools and apparatus; Measuring apparatus and instruments, Including those for industrial and scientific purposes and for monitoring test media; Measurement apparatus and measuring instruments, including mechanical, electromechanical, electric and electronic measuring apparatus and measuring instruments with an analogue or digital measured value display or an electric or optical measurement signal interface; Optical and magnetic measuring apparatus and measuring instruments; Vernier caliper; Rules (measuring instruments); Dial gauges; Comparator stands; Measuring tables; Concentricity gauges; Outside micrometers; Slide calipers; Height dimensions; Depth gauges; Height meters; Dial indicators; Micrometer gauges; Micrometers; Bore measuring apparatus; Inside micrometers; Gauge blocks; Protractors [measuring instruments]; Straight-edges; Steel squares; Steel squares; Measuring plates; Plug gauges; Ring gauges; Test pins; Radius gauges; Radius templates; Measuring sensors; Measuring stands; Prisms [optics]; Aligning means; Single-axis measuring apparatus with an incremental optoelectronic or magnetic measuring system; Coordinate measuring apparatus and tool pre-setting instruments; Measuring microscopes; Hardware and software for use in the field of measuring and testing technology. Repair and installation services for goods in the field of measuring and testing technology. Engineering services, Physics [research]; Calibration services; Computer programming in the field of measuring and testing technology.

Abstract

The invention is a contour standard, which consists of a body having a rotationally symmetrical calibration region. The rotationally symmetrical calibration region encompasses a plurality of non-cylindrical axial sections, which can be concave, convex, by forming a predefined angle as radial projection or as radial depression. The calibration region has at least one measuring section, which runs parallel to the longitudinal axis of the body and which provides for axial calibration variables, as well as radial calibration variables. These calibration variables are compared with the sensed values to the calibration of a measuring instrument and the measuring instrument is adjusted based on the basis of the determined deviation. Due to the rotationally symmetrical calibration region, the contour standard is suitable both for the calibration of touch contour measuring instruments and also for the calibration of contour measuring instruments, which measure optically.

IPC Classes  ?

• G01B 5/20 - Measuring arrangements characterised by the use of mechanical techniques for measuring contours or curvatures
• G01B 3/14 - Templates for checking contours
• G01B 3/30 - Bars, blocks, or strips in which the distance between a pair of faces is fixed, although it may be preadjustable, e.g. end measure, feeler strip
• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points

Goods & Services

Measuring devices, measuring apparatus, measuring tools, measuring machines and measuring instruments in particular for measuring shafts, crankshafts and camshafts, measuring lengths and coordinates, measuring dimensions, with one or several axes, for industrial or scientific purposes, for gage monitoring, for manufacture, assembly, dimensional metrology, quality assurance, machine tools, optical, opto-electronic, tactile, mechanical, electromechanical, electrical, electronic, manually-controlled, CNC controlled, program-controlled, automatic, with analog or digital measuring value indication, with incremental or absolute measuring systems; complete measuring stations, measuring devices, automatic measuring centers, measuring and control systems consisting generally of the aforementioned goods, including all display and printing devices, associated operating systems, application programs and evaluation software, also for statistical quality and process control, software; accessories for the aforementioned goods contained in this class namely shaft clamping devices, chucks, rim chucks, external and internal clamping jaws, centering tip mounts, measuring tripods, test benches, alignment tools, tool setting instruments, length and diameter measuring stations, measuring stands, measuring tables, magnetic feet, measuring tips, measuring tubings, centering tips and tubings, hollow tips, mounting devices, carrier slides, slide elevations, intermediate pieces, mounting adapters, attachments, adapters, plug-on heads, stops, holders, collet chucks, driving devices, magnetic clamping chucks, MK1 holders, MK2 holders, magnets, V-blocks, holding V-blocks, protective V-blocks, V-bearings, pre-stacking V-blocks, lifting and lowering units, lever actuation, drives and rotation drives, adjusting devices, positioning devices, devices for adjusting the measuring force, hand- and foot-operated push-buttons, clamping devices, clamping fixtures, counter bearings, center supports, swivel mechanisms, tailstocks, protective screens, vacuum lifting tools, servo drives, measuring probes, shaft measuring probes, measuring arms, probe units, measuring units, stylus elements, measuring heads, measuring pins, calipers, measuring jaws, depth gages, lever-type gages, probe arms, styli, stylus tips, probe extensions, measuring knife edges, contact slides, precision measuring spindles, calipers, length probe slides, universal probe slides, calibration shafts, calibration discs, calibration standards, testing and measuring plates, testing and measuring pins, testing and measuring cylinders, standards, adjustment standards, roundness standards, roughness standards, master gears, geometric standards, gages, cylinder squares, optical flats, radius gages, radius templates, plug gages, ring gages, connection and extension cables, foot-operated and remote switches, control cabinets, temperature compensators, evaluation instruments, computers, display units, keyboards, monitors, terminals, printers, CDs, DVDs and USB flash drives and memory cards; electronic machine controls, in particular for data logging, data collection, data transmission and data processing; measurement computers and electronic devices for the statistical representation and processing of measuring values; digital storage devices and data carriers, in particular calibration data memories. Calibration services; technical measurements for third parties; design and development of computer hardware and software, in particular in the areas of gaging and testing; updating, installation, copying, rental and maintenance of computer software; computer software consultation; computer systems analyses; services from engineers and physicists, particularly in the areas of gaging and testing; technical project planning and the preparation of technical reports, in particular in the areas of gaging and testing; scientific and technological research and development services, in particular in the areas of gaging and testing; installation, maintenance and repair of software.

Abstract

The invention relates to a measuring device (10) for measuring a dimensional measured value (W) of an object (14) to be measured. The measuring device (10) comprises a measurement recording unit (11) having a sensor (15), in particular a tactile sensor having a key element (16), as well as a control device (12) comprising the user interface. The measurement recording unit (11) and the control device (12) are configured independently of each other in separate component units. As control device (12), a mobile apparatus having a computer unit (26) and a touch sensitive monitor (31) is used, such as, for example, a mobile telephone or a tablet computer. Via the input and output means (29, 30) of the control device (12), the measurement is controlled by the measurement recording unit (11). The control device (12) is also used to represent the measured values (W) that have been measured or a measurement result derived therefrom. The signals of a position sensor (36) and/or of a movement sensor (35) are evaluated and used for the position- and/or movement-dependent control of the measuring device (10).

IPC Classes  ?

• G05B 19/401 - Numerical control [NC], i.e. automatically operating machines, in particular machine tools, e.g. in a manufacturing environment, so as to execute positioning, movement or co-ordinated operations by means of programme data in numerical form characterised by control arrangements for measuring, e.g. calibration and initialisation, measuring workpiece for machining purposes
• G01B 21/00 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant

Goods & Services

Measuring devices, measuring apparatus, measuring tools, measuring machines and measuring instruments in particular for measuring shafts, crankshafts and camshafts, measuring lengths and coordinates, measuring dimensions, with one or several axes, for industrial or scientific purposes, for gage monitoring, for manufacture, assembly, dimensional metrology, quality assurance, machine tools, optical, opto-electronic, tactile, mechanical, electromechanical, electrical, electronic, manually-controlled, CNC controlled, program-controlled, automatic, with analog or digital measuring value indication, with incremental or absolute measuring systems; complete measuring stations, measuring devices, automatic measuring centers, measuring and control systems consisting of electro-optical instruments for use in inspection and measurement of industrial components, optical or contacting probing systems for measuring apparatus for dimensional testing of turned parts, instruments for measuring length, instruments for measuring roundness, instruments for measuring diameter, laser measuring systems, measuring rules, tool measuring instruments and associated operating systems, application programs and evaluation software, also for statistical quality and process control; specially adapted accessories for measuring devices, measuring apparatus, measuring tools, measuring machines and measuring instruments, namely, shaft clamping devices, chucks, rim chucks, external and internal clamping jaws, centering tip mounts, measuring tripods, test benches, alignment tools, tool setting instruments, length and diameter measuring stations, measuring stands, measuring tables, magnetic feet, measuring tips, measuring tubings, centering tips and tubings, hollow tips, mounting devices, carrier slides, slide elevations, intermediate pieces, mounting adapters, attachments, adapters, plug-on heads, stops, holders, collet chucks, driving devices, magnetic clamping chucks, MK1 holders, MK2 holders, magnets, V-blocks, holding V-blocks, protective V-blocks, V-bearings, pre-stacking V-blocks, lifting and lowering units, lever actuation, drives and rotation drives, adjusting devices, positioning devices, devices for adjusting the measuring force, hand- and foot-operated push-buttons, clamping devices, clamping fixtures, counter bearings, center supports, swivel mechanisms, tailstocks, protective screens, vacuum lifting tools, servo drives, measuring probes, shaft measuring probes, measuring arms, probe units, measuring units, stylus elements, measuring heads, measuring pins, calipers, measuring jaws, depth gages, lever-type gages, probe arms, styli, stylus tips, probe extensions, measuring knife edges, contact slides, precision measuring spindles, calipers, length probe slides, universal probe slides, calibration shafts, calibration discs, calibration standards, testing and measuring plates, testing and measuring pins, testing and measuring cylinders, standards, adjustment standards, roundness standards, roughness standards, master gears, geometric standards, gages, cylinder squares, optical flats, radius gages, radius templates, plug gages, ring gages, connection and extension cables, foot-operated and remote switches, control cabinets, temperature compensators, evaluation instruments; computer hardware, video display units, computer keyboards, computer monitors, computer terminals, computer printers; blank CDs, DVDs and USB flash drives and memory cards; electronic machine controls, in particular for data logging, data collection, data transmission and data processing; measurement computers and electronic devices for the statistical representation and processing of measuring values; digital storage devices and data carriers, in particular calibration data memories Calibration services; technical measurements evaluations for third parties in mechanical and aerospace engineering, in automotive and medical industry and in optics; design and development of computer hardware and software, in particular in the areas of gauging and testing; updating, installation, copying, rental and maintenance of computer software; computer software consultation; computer systems analyses; services from engineers and physicists, particularly in the areas of gauging and testing in mechanical and aerospace engineering, in automotive and medical industry and in optics; technical project planning and the preparation of technical reports, in particular in the areas of gauging and testing in mechanical and aerospace engineering, in automotive and medical industry and in optics; scientific and technological research and development services, in particular in the areas of gaging and testing; installation, maintenance and repair of software

Goods & Services

Measuring devices, measuring apparatus, measuring tools, measuring machines and measuring instruments in particular for measuring shafts, crankshafts and camshafts, measuring lengths and coordinates, measuring dimensions, with one or several axes, for industrial or scientific purposes, for gage monitoring, for manufacture, assembly, dimensional metrology, quality assurance, machine tools, optical, opto-electronic, tactile, mechanical, electromechanical, electrical, electronic, manually-controlled, CNC-controlled, program-controlled, automatic, with analog or digital measuring value indication, with incremental or absolute measuring systems; complete measuring stations, measuring devices, automatic measuring centers, measuring and control systems consisting generally of the aforementioned goods, including all display and printing devices, associated operating systems, application programs and evaluation software, also for statistical quality and process control, software; accessories for the aforementioned goods contained in class 09 namely shaft clamping devices, chucks, rim chucks, external and internal clamping jaws, centering tip mounts, measuring tripods, test benches, alignment tools, tool setting instruments, length and diameter measuring stations, measuring stands, measuring tables, magnetic feet, measuring tips, measuring tubings, centering tips and tubings, hollow tips, mounting devices, carrier slides, slide elevations, intermediate pieces, mounting adapters, attachments, adapters, plug-on heads, stops, holders, collet chucks, driving devices, magnetic clamping chucks, MK1 holders, MK2 holders, magnets, V-blocks, holding V-blocks, protective V-blocks, V-bearings, pre-stacking V-blocks, lifting and lowering units, lever actuation, drives and rotation drives, adjusting devices, positioning devices, devices for adjusting the measuring force, hand- and foot-operated push-buttons, clamping devices, clamping fixtures, counter bearings, center supports, swivel mechanisms, tailstocks, protective screens, vacuum lifting tools, servo drives, measuring probes, shaft measuring probes, measuring arms, probe units, measuring units, stylus elements, measuring heads, measuring pins, calipers, measuring jaws, depth gages, lever-type gages, probe arms, styli, stylus tips, probe extensions, measuring knife edges, contact slides, precision measuring spindles, calipers, length probe slides, universal probe slides, calibration shafts, calibration discs, calibration standards, testing and measuring plates, testing and measuring pins, testing and measuring cylinders, standards, adjustment standards, roundness standards, roughness standards, master gears, geometric standards, gages, cylinder squares, optical flats, radius gages, radius templates, plug gages, ring gages, connection and extension cables, foot-operated and remote switches, control cabinets, temperature compensators, evaluation instruments, computers, display units, keyboards, monitors, terminals, printers, CDs, DVDs and USB flash drives abd memory cards; electronic machine controls, in particular for data logging, data collection, data transmission and data processing; measurement computers and electronic devices for the statistical representation and processing of measuring values; digital storage devices and data carriers, in particular calibration data memories. Calibration services; technical measurements for third parties; design and development of computer hardware and software, in particular in the areas of gaging and testing; updating, installation, copying, rental and maintenance of computer software; computer software consultation; computer systems analyses; services from engineers and physicists, particularly in the areas of gaging and testing; technical project planning and the preparation of technical reports, in particular in the areas of gaging and testing; scientific and technological research and development services, in particular in the areas of gaging and testing; installation, maintenance and repair of software.

Goods & Services

Mechanical, electric and electronic measuring devices, in particular length measuring devices, form testers, position measuring devices, hardness testers, mechanical and digital devices for measurement value acquisition, mechanical and digital lever indicators, mechanical, electric and electronic dial indicators with analog and digital display, micrometer screw gauges, comparators; mechanical and digital calipers, in particular for measured value recording, measured value display, data acquisition, data transmission and data processing; complete measuring stations substantially consisting of aforesaid goods, measurement devices, measurement and control systems including all, also displaying and printing auxiliary and supplemental equipment and devices, related operating systems and stored application programs and analysis software, also for statistical quality and process control, software; measuring devices including those for gear inspection, measuring machines and devices for manufacturing, assembly, quality control and machine tools; auxiliary tools and devices for production measurement technology; accessories for aforesaid goods, in particular measuring probes, measuring arms, measuring elements, measuring heads, measuring rollers, measuring braces, measuring jaws, master rings, depth measurement bases, probe levers, probe arms, probe, styli and probe tips, probe extensions, measuring and scribing tips, measurement supporting stands and instrument holders, measuring tables, magnetic bases, measuring and centering rods, mounting devices, vee-blocks, attachments, slip-on heads, positioning stops, holders, collets, catches (drivers), measuring stands, test platforms, testing units, measurement standards, setting standards, calibrating standards, roundness standards, roughness standards, master gears, geometric standards, gauges, testing cylinders, cylindrical squares, optical flats, lifting and lowering mechanisms, drive and rotary drive units, adaptors, setting units, positioning units, devices for adapting the measurement force, connection cables, extension cables, manual and pedal buttons, fixtures, clamping units, tailstocks, center supports, swivel units, protective screens, suction lifters, data storage devices, data media. Conceptual design, development, generation, installation, actualization and maintenance of software, in particular application programs and evaluation software; computer system analysis and; computer software consultancy; planning and implementation of technical projects, in particular draft and implementation of mechanical and electronic systems; preparation of production documents; calibration services; consultancy and research in the field of technology, in particular on measurement technology.

Goods & Services

Mechanical, electric and electronic measuring devices, in particular length measuring devices, form testers, position measuring devices, hardness testers, mechanical and digital devices for measurement value acquisition, mechanical and digital lever indicators, mechanical, electric and electronic dial indicators with analog and digital display, micrometer screw gauges, comparators; mechanical and digital calipers, in particular for measured value recording, measured value display, data acquisition, data transmission and data processing; complete measuring stations consisting primarily of one or more of the aforesaid goods; measurement devices, namely, tool measuring apparatus, distance measuring apparatus, mechanical and electro-optical instruments for use in inspection and measurement of industrial components, coordinate measuring machines, micrometer gauges, revolution counters, material testing instruments, pressure measuring apparatus not for medical purposes and measurement and control systems for all the aforesaid goods, auxiliary and supplemental equipment and devices for displaying and printing, namely, computer monitors and printers for all the aforesaid goods, operating system programs and stored application programs and analysis software for statistical quality and process control, software for electronic measurement apparatus and for monitoring and controlling factory manufacturing process; measuring devices for inspecting tolerances in gears and gear assemblies, measuring machines and devices for measuring distances and tolerances in manufacturing, assembling and quality control processes and for machine tools for industrial components; auxiliary tools and devices for production measurement technology and accessories for aforesaid goods, in particular measuring probes, measuring arms, measuring elements, measuring heads, measuring rollers, measuring braces, measuring jaws, master rings, depth measurement bases, probe levers, probe arms, probe styli and probe tips, probe extensions, measuring and scribing tips, measurement supporting stands and instrument holders, measuring tables, magnetic bases, measuring and centering rods, mounting devices, vee-blocks, attachments, slip-on heads, positioning stops, holders, collets, catches (drivers), measuring stands, lifting and lowering mechanisms, drive and rotary drive units, adaptors, setting units, positioning units, devices for adapting the measurement force, connection cables, extension cables, manual and pedal buttons, fixtures, clamping units, tailstocks, center supports, swivel units, protective screens, suction lifters, data storage devices, namely, blank flash drives and hard disk drives, blank digital data storage media testing and calibrating devices for measuring machines and devices, namely, test platforms, testing units, measurement standards, setting standards, calibrating standards, roundness standards, roughness standards, master gears, geometric standards, gauges, testing cylinders, cylindrical squares, optical flats, all aforesaid auxiliary tools, devices and accessories sold with specified measuring machines and devices as a unit Conceptual design, development, program code generation, installation, project management and maintenance of software, in particular application programs and evaluation software; computer system analysis and computer software consultancy; planning and implementation of technical projects, namely, technical project studies, construction drafting, industrial design, engineering, quality control, consulting and project management services in the implementation of mechanical and electronic systems; preparation of production documents, namely, preparing technical documentation for manufacturing, industrial processes, quality control and technical writing for others; calibration services; consultancy and research in the field of technology, in particular on measurement technology

Goods & Services

Mechanical, electric, electronic and pneumatic measuring devices, in particular length measuring devices, form testers, position measuring devices, hardness testers, mechanical and digital devices for measurement value acquisition, mechanical and digital lever indicators, mechanical, electric,electronic and pneumatic dial indicators with analog and digital display, micrometer screw gauges, comparators; mechanical and digital calipers, in particular for measured value recording, measured value display, data acquisition, data transmission and data processing; complete measuring stations substantially consisting of aforesaid goods, measurement devices, measurement and control systems including all, also displaying and printing auxiliary and supplemental equipment and devices, related operating systems and stored application programs and analysis software, also for statistical quality and process control, software; measuring devices including those for gear inspection, measuring machines and devices for manufacturing, assembly, quality control and machine tools; Auxiliary tools and devices for production measurement technology; Accessories for aforesaid goods, in particular measuring probes, measuring arms, measuring elements, measuring heads, measuring rollers, measuring braces, measuring jaws, master rings, depth measurement bases, probe levers, probe arms, probe styli and probe tips, probe extensions, measuring and scribing tips, measurement supporting stands and instrument holders, measuring tables, magnetic bases, measuring and centering rods, mounting devices, vee-blocks, attachments, slip-on heads, positioning stops, holders, collets, catches (drivers), measuring stands, test platforms, testing units, measurement standards, setting standards, calibrating standards, roundness standards, roughness standards, master gears, geometric standards, gauges, testing cylinders, cylindrical squares, optical flats, lifting and lowering mechanisms, drive and rotary drive units, adaptors, setting units, positioning units, devices for adapting the measurement force, connection cables, extension cables, manual and pedal buttons, fixtures, clamping units, tailstocks, center supports, swivel units, protective screens, suction lifters, data storage devices, data media. conceptual design, development, generation, installation, actualization and maintenance of software, in particular application programs and evaluation software; computer system analysis and computer software consultancy; planning and implementation of technical projects, in particular draft and implementation of mechanical and electronic systems; preparation of production documents; calibration services; consultancy and research in the field of technology, in particular on measurement technology.

Abstract

A measuring arrangement in the form of a measuring counter, a measuring slide or a measuring screw. The measuring arrangement comprises a housing in which a measuring unit, a transmission circuit and a receiving circuit are arranged on a common conductor plate. The transmission circuit and the receiving circuit use a common conductor plate antenna which is also provided on the conductor plate. A voltage supply circuit for supplying a voltage to the measuring unit, the transmission circuit and the receiving circuit is also arranged on the conductor plate. Via a measurement value sensor at the housing a measurement value is detected and converted by the measuring unit into an electrical measurement signal and transmitted via the transmission circuit wirelessly to an external central unit.

IPC Classes  ?

• G01D 11/24 - Housings
• G01L 19/14 - Housings
• G01P 1/02 - Housings
• G01B 3/22 - Feeler-pin gauges, e.g. dial gauges
• H04Q 9/00 - Arrangements in telecontrol or telemetry systems for selectively calling a substation from a main station, in which substation desired apparatus is selected for applying a control signal thereto or for obtaining measured values therefrom

Abstract

The invention relates to a contour meter (10) and also to a method for measuring a workpiece contour (13). The workpiece contour (13) has a plurality of contour geometries (k). At least a first contour geometry (K1) and a second contour geometry (K2) adjoin one another tangentially at a first transition point (U1). Firstly, a multiplicity of measurement points (M) are recorded along the first contour geometry (K1) and the second contour geometry (K2). On the basis of some of the measurement points within the first contour geometry (K1), a first replacement element (G1) is determined and assigned to the first contour geometry (K1). Analogously to this, on the basis of some measurement points (M) of the second contour geometry (K2) a second geometry element (G2) assigned to the latter is determined. The size and/or the position of the second geometry element (G2) are calculated here under the boundary condition that the second replacement element (G2) adjoins the first replacement element (G1) tangentially. The tangential transition point between the two replacement elements (G1), (G2) forms the thus determined first transition point (U1). This method can be repeated iteratively with the aid of additional or other measurement points (M), until the position of the first transition point (U1) has been determined with sufficient accuracy.

IPC Classes  ?

• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points
• G06T 17/10 - Volume description, e.g. cylinders, cubes or using CSG [Constructive Solid Geometry]

Goods & Services

Optical instruments, namely, illuminated magnifiers, microscopes, and optical coordinate measuring machines

Abstract

The invention relates to a contour gage (10) which comprises a body (11) having a rotationally symmetrical calibration region (14). The rotationally symmetrical calibration region (14) has a plurality of non-cylindrical axial sections (17), which can be formed concavely or convexly as a radial protrusion (22) or as a radial depression (23), enclosing a predefined angle. Provided along the calibration region (14) is at least one measuring section (28) extending parallel to the longitudinal axis L of the body (11), which predefines both axial calibration variables Ii (i=1 to n) and radial calibration variables a, b. The values of said calibration variables a, b, Ii can be compared with the values sensed during calibration of the measuring instrument, and the measuring instrument can be adjusted on the basis of the deviations detected. The rotationally symmetrical calibration region (14) makes the contour gage (10) suitable both for the calibration of touch contour measuring instruments and also for the calibration of contour measuring instruments that measure optically.

IPC Classes  ?

• G01B 3/30 - Bars, blocks, or strips in which the distance between a pair of faces is fixed, although it may be preadjustable, e.g. end measure, feeler strip
• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points

Abstract

The invention relates to a measuring device (10) in the form of a dial gauge, a vernier or a micrometer screw gauge. The measuring device (10) has a housing (11) which contains a measuring circuit (14), a transmission circuit and a reception circuit on a shared printed circuit board (22). The transmission circuit (19) and the reception circuit use a shared printed circuit board antenna (21) which is likewise provided on the printed circuit board (22). In addition, the printed circuit board (22) holds a power supply circuit (30) for supplying power to the measuring circuit (14), the transmission circuit and the reception circuit. It is therefore possible to dispense with an interface between the measuring circuit and the transmission circuit or the reception circuit that is accessible from outside the housing (11). The shared power supply circuit (30) reduces the installation space for the overall circuit arrangement. The housing (11) of the measuring device (10) can easily be sealed and therefore produced with the necessary housing protection design. A sensor (12) on the housing (11) is used to record a measured value, which is converted into an electrical measurement signal by the measuring circuit (14) and transmitted wirelessly to an external device (20) by means of the transmission circuit.

IPC Classes  ?

• G01B 3/22 - Feeler-pin gauges, e.g. dial gauges
• G08C 17/02 - Arrangements for transmitting signals characterised by the use of a wireless electrical link using a radio link
• G01B 7/00 - Measuring arrangements characterised by the use of electric or magnetic techniques

Abstract

m) between the probe end (40) and the workpiece surface (11) is formed for detecting measuring errors/inaccuracies.

IPC Classes  ?

• G01B 5/20 - Measuring arrangements characterised by the use of mechanical techniques for measuring contours or curvatures

Abstract

The invention relates to a method for ascertaining the position of an edge in an object surface region of interest by optical scanning. For this purpose, the reflectivity of the object surface region is evaluated. Light is emitted onto the object surface region under different illumination conditions, in particular different light incidence directions, and in each illumination condition a sequence S1 to Sn of camera images B is recorded. Each camera image B of a sequence S1 to Sn is recorded at another illumination intensity I. Subsequently in each case one reflectivity image R1 to Rn is produced from a plurality of or from all camera images B of a sequence S1 to Sn. Thereafter, a resulting reflectivity image E is produced from a plurality of or from all reflectivity images R1 to Rn by weighted addition, in which resulting reflectivity image E the position of an edge in or on the object surface region of interest is determined with subpixel accuracy by applying at least one edge location criterion.

IPC Classes  ?

• G01B 11/02 - Measuring arrangements characterised by the use of optical techniques for measuring length, width, or thickness

Abstract

The invention relates to a measuring device and to a measuring method for determining an absolute distance value between a probe (12) and an object surface (13). To this end, the distance value (d) is determined in punctiform manner in the region of the optical axis (14) of the probe (12). The measuring device comprises a light source (15) that emits short coherent light. In a measuring light path (M), the light is directed through the probe (12) onto the object surface (13) and the light reflected there is received again. Another part of the light of the light source (15) passes through a reference light path to a reference surface area (27) and returns from there. The light reflected on the reference surface area (27) and the object surface (13) is fed to an interferometer (30), where it is divided into a first light path (L1) and a second light path (L2). The two light paths (L1), (L2) have different lengths and compensate for the difference between the reference light path (R) and measuring light path (M). The first interferometer mirror (33) present in the first light path (L1) oscillates in the direction of the optical axis (40) of the first light path (L1). The light from the two light paths (L1), (L2) is superimposed and as a result of the oscillation of the first interferometer mirror (33), interference patterns form in the superimposed light, which are detected by a photosensor (35). The distance value (d) is determined in an evaluation device (37) that is connected to the photosensor (35).

IPC Classes  ?

• G01B 9/02 - Interferometers

Abstract

The invention relates to a measuring device (10) for measuring a surface profile of a workpiece and to a corresponding measuring method. During measurement, a measuring slide (15) is moved in a moving direction (x) in a linear manner and at a distance from the workpiece surface such that the probe tip (25) which is arranged at the slide is not accelerated by the movement of the measuring slide (15). The free end (40) of the probe tip (25) rests on the workpiece surface (11) with a measuring force (Fm) and is deviated during measurement in a measuring direction (z) transverse to the moving direction (x) such that a path-dependent deviation (zT) of the probe end (40) is caused by the surface profile. A measuring sensor (45) detects a deviation variable (s) which describes the deviation of the probe end (40) in the measuring direction (z). In an analysis unit (21) a measuring force alteration variable is generated which is dependent on the deviation variable (s), the measuring force alteration variable describing the alteration of the measuring force (Fm) between the probe end (40) and the workpiece surface (11). On the basis of the measuring force alteration variable it is possible to detect measuring errors or measuring inaccuracies.

IPC Classes  ?

• G01B 3/00 - Measuring instruments characterised by the use of mechanical techniques
• G01B 5/008 - Measuring arrangements characterised by the use of mechanical techniques for measuring coordinates of points using coordinate measuring machines
• G01B 7/008 - Measuring arrangements characterised by the use of electric or magnetic techniques for measuring coordinates of points using coordinate measuring machines
• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points

Abstract

A first screw element is measured by detecting light which is substantially parallel with a screw groove (A4) among lights leaked to the side opposite to a light source (21) with respect to the axis of pipe with use of an optical sensor (2). A second screw element is measured by touching the contact probe (31) of a contact sensor (3) to the flank face (A8) of a screw and detecting the spatial coordinate of the contact probe (31) at the time of contact. The first and second screw elements thus detected are synthesized by an operation processing means (4) and a screw element of a measurement object screw is operated.

IPC Classes  ?

• G01B 21/20 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring contours or curvatures, e.g. determining profile
• G01B 5/20 - Measuring arrangements characterised by the use of mechanical techniques for measuring contours or curvatures
• G01B 11/24 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures

Abstract

Reference is made to a sandwich design for the production of scanning arms (6), and a preferably stiff covering element (22, 23) is placed on either side of a central, resilient foil (21) for this purpose.  At least one of the covering elements (22, 23) can have at least locally defined magnetic properties in order to cooperate, for example, with a sensor coil (11).  The covering elements (22, 23) run substantially flush with the contours of the foil (21), except for small, preferably slot-like cutouts (32 to 35) where the foil (21) is exposed in order to form spring hinges.

IPC Classes  ?

• G01B 7/34 - Measuring arrangements characterised by the use of electric or magnetic techniques for measuring roughness or irregularity of surfaces

Abstract

The Linnik interferometer (4) according to the invention comprises a central beam splitter arrangement (24) constructed such that at least the observation unit (15), the illumination unit (20), and a unit (14) comprising a lens (8) and the reference mirror (10) are disposed on the same side of the measurement head, which opens the way to integrating the Linnik interferometer into a measuring machine. The invention results in a robust and space-saving arrangement that is not sensitive to vibrations.

IPC Classes  ?

• G01B 9/02 - Interferometers
• G01B 9/04 - Measuring microscopes

Abstract

In order to measure tools (2), particularly the cutting edges (3, 4, 5) thereof, the tool is recorded with a camera having a focus plane (14) and low depth of field. While the tool is rotated, images are recorded from which the data for the cutting edge are then extracted.

IPC Classes  ?

• B23Q 17/09 - Arrangements for indicating or measuring on machine tools for indicating or measuring cutting pressure or cutting-tool condition, e.g. cutting ability, load on tool
• B23Q 17/24 - Arrangements for indicating or measuring on machine tools using optics
• G01B 11/24 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures

Abstract

An optical microprobe for common-path interferometers uses micro-optical components and utilizes a light exit surface (11) curved parallel to the optical spherical wave passing through it in order to generate a defined reference beam with an unambiguous phase angle of sufficient intensity and negligible dispersion difference relative to the measurement beam. As an alternative, the light exit surface can be situated so close to the object that as a result of lack of parallelism with respect to the wavefront passing through it, the disturbances brought about remain below a given limit value.

IPC Classes  ?

• G01B 11/00 - Measuring arrangements characterised by the use of optical techniques
• G01B 11/24 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures

Abstract

According to the invention, a planar measuring X-Y measuring system is combined with a high resolution Z-scanning white light interferometer for the measurement of complex 3D objects, such as micro-drills. The imaging measuring system is used as a monitor system for the white light interferometer. A planar Z height scan of the white light interferometer is carried out without any mechanical movement of the axes of the coordinate measuring device. The X, Y, Z measuring values have a resolution higher than one micrometer in the X and Y directions, and a resolution of much higher than one micrometer in the Z direction. The Z height measurement values of the white light interferometer are utilized exclusively for the spatial angular measurement.

IPC Classes  ?

• G01B 11/24 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures
• B23Q 17/24 - Arrangements for indicating or measuring on machine tools using optics

Abstract

For a measuring machine (1) comprising two or more sensors, it is proposed to support the sensors (8, 9) on carriages (14, 15), which are disposed on a common guide (11) and displaceable independently from each other. The carriages (14, 15) are positioned via a common measuring system (27), so that the relative position of the carriages to each other and the absolute position of the sensors can be determined in the coordinate measuring device (1) with great precision. The position of the sensors no longer depends on the production accuracy of a mechanical replaceable system, but is actively determined.

IPC Classes  ?

• G01B 5/008 - Measuring arrangements characterised by the use of mechanical techniques for measuring coordinates of points using coordinate measuring machines
• G01B 7/008 - Measuring arrangements characterised by the use of electric or magnetic techniques for measuring coordinates of points using coordinate measuring machines
• G01B 11/03 - Measuring arrangements characterised by the use of optical techniques for measuring length, width, or thickness by measuring coordinates of points
• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points

Abstract

The invention relates to a contact stylus measuring device, which is equipped particularly for the measurement of surfaces and contours of objects, comprising a contact stylus instrument and a magazine, which is equipped to automatically apply and remove sensing arms to and from the relevant contact points of the contact stylus instrument.

IPC Classes  ?

• G01B 21/04 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring length, width, or thickness by measuring coordinates of points

Abstract

For carrying out 3D measurements, the invention proposes the combination of a rotary table (11) for receiving an object (2) and a scanning device (3) for scanning the surface of the object (2). The object surface is scanned in at least two different rotation positions of the object (2). Preferably, scanning lines are chosen which run both radially to the axis of rotation (12) of the rotary table (11) and also in the peripheral direction with respect to the axis of rotation (12). These scans can be carried out separately one after the other as radial, linear scans and as circular scans, and also simultaneously as spiral scans. In each case, measured values are obtained, from which the spatial form of the object surface is obtained with higher precision and in a shorter measuring time.

IPC Classes  ?

• G01B 5/20 - Measuring arrangements characterised by the use of mechanical techniques for measuring contours or curvatures

Abstract

In a roughness scanner comprising a scanning arm with a scanning needle mounted at one end thereof, a skid carrier having an end supporting a skid with the scanning arm extending along the skid carrier in spaced relationship therefrom, the skid has at one side a guide late including an opening through which the scanning needle extends and a space formed above the guide plate which space is open at least at one side thereof down to the guide plate, so that any liquid collected by the needle and moving upward into the space above the guide late can flow again out of that space.

IPC Classes  ?

• G01B 5/28 - Measuring arrangements characterised by the use of mechanical techniques for measuring roughness or irregularity of surfaces

Abstract

In a measurement system with an optical image acquisition system and relative motion between measurement object and image acquisition system, the focal point (F) of the image acquisition system (3) is allowed to oscillate in the scan direction, in order to create, by superposition of the oscillatory motion of the focal point on the scanning motion, image acquisition intervals during which the focal point (F) rests on the surface of the measurement object (2), or correspondingly the image projected on to the camera chip rests on the camera chip. This occurs preferably under uniform unaccelerated relative motion between measurement object and image acquisition system. A lack of edge-sharpness of the images is avoided in spite of relatively long illumination times and moderate illumination intensities.

IPC Classes  ?

• G01B 11/24 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures

Abstract

A height measuring device (1) has a measuring column (3) on which a vertically displaceable measuring slide (4) is mounted such that it can be moved both manually and using a drive motor (14) by means of a coupling device (15). The measuring slide (4) has a measuring probe (8) which exerts a constant measuring force, which is generated by the drive motor (14) and the coupling device (15), on the measuring point on the workpiece. A measuring system (19) records the height coordinates of the measuring probe (8) and transfers them to a control device (21) for further processing and evaluation. The control device (21) has a logic unit (33) for automating the measurement sequence. Said logic unit automatically detects positioning of the measuring probe (8), which is carried out manually by the user, in a particular direction, then drives the drive motor (14) in a suitable manner in order to scan the workpiece, and uses the signals from the measuring system (19) to determine the measured value or values relevant to the respective measurement. The control device (21) may be set up to detect, in a fully automatic manner, the operator's wish to measure either on a plane or in a bore or on a shaft in one direction or in the opposite direction, in order to independently initiate the desired measuring function.

IPC Classes  ?

• G05B 19/42 - Recording and playback systems, i.e. in which the programme is recorded from a cycle of operations, e.g. the cycle of operations being manually controlled, after which this record is played back on the same machine

Abstract

The invention relates to a device which comprises a lens (8) that can be operated in at least two different measuring modes. A test object (9) is subjected to an interference optical measurement in a first interference mode. In a second imaging measuring mode an optical image is produced on a detector array (12) configured, for example, in a camera-type manner, and said image is supplied to an image processing routine. A changeover from one measuring mode to the other is brought about by switching the pieces of illumination equipment which are connected at different sections to the course of the beam of the device – from the camera point of view, one in front of the beam splitter, and the other one behind the beam splitter, couple the reference light path and the course of the beam.

IPC Classes  ?

• G01B 9/04 - Measuring microscopes

Abstract

In the measurement method according to the invention, a 3D geometry detection of object surfaces is achieved by means of undersampling (contrary to the sampling theorem) in that at least one of the two light bundles (reference light bundle (16) and measurement light bundle (15)), brought to superposition in an interferometer (5), is separated into two components S and P, on the basis of which different interference images (S interference image and P interference image) are produced on two cameras (9, 10). The components are preferably 180° phase shifted with respect to one another. A differential image is produced from the two interference images of the cameras. When using short-coherent light, the pixels of the differential image have a brightness which is different from zero only in that Z region for which the difference between reference light path and measurement light path is less than the coherence length. As a function of the Z coordinate, the viewed pixel of the differential image has a strongly fluctuating brightness variation, wherein the envelope curve or also the standard deviation follows a Gaussian bell curve. The curve maximum sets the Z measurement value for the surface point with which the viewed pixel of the differential image is associated. The method is robust, quick and accurate.

IPC Classes  ?

• G01B 9/02 - Interferometers
• G01B 11/24 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures

IPC Classes  ?

• G01B 21/30 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant for measuring roughness or irregularity of surfaces

Abstract

In the measurement method according to the invention, the exact measurement value is determined in a plurality of stages, wherein methods of white light interferometry are combined with phase measurement. The phase measurement is preferably effected in two stages, wherein operation takes place at first with a relatively large unambiguity area and low measurement accuracy on the basis of a synthetic wavelength (lambda) and then with the true light wavelength. The first and the second interferometer beam paths are each terminated by a mirror, with one of the two mirrors having an oblique position in order to produce an interference stripe pattern on an optical sensor. The result is a robust measurement method with a large measurement range and resolution in the nanometre range.

IPC Classes  ?

• G01B 9/02 - Interferometers
• G01B 11/24 - Measuring arrangements characterised by the use of optical techniques for measuring contours or curvatures

Goods & Services

software for controlling precision measuring instruments

Goods & Services

Computer software for measuring instruments, measuring machines, measuring fixtures, measuring stations, data evaluation facilities and industrial metrology, particularly for measuring program creation, measuring program execution, machine control, measuring station configuration, measurement and execution control, measuring function and measuring run simulation, measuring function execution control, measuring value recording, measured value storage, diagnosis, measurement evaluation and logging, fault analysis, data export and data import, program administration, user administration, license administration, quality and process control; all aforementioned goods as far as they are contained in this class. Design, maintenance and care of computer software for gages, measuring machines, measuring instruments, measuring stations, data evaluation facilities and industrial metrology; all aforementioned services as far as they are contained in this class.

Goods & Services

Computer software for measuring instruments, measuring machines, measuring fixtures, measuring stations, data evaluation facilities and industrial metrology, particularly for measuring program creation, measuring program execution, machine control, measuring station configuration, measurement and execution control, measuring function and measuring run simulation, measuring function and measurement execution control, measuring value recording, measured value storage, diagnosis, measurement evaluation and logging, fault analysis, data export and data import, program administration, user administration, license administration, quality and process control; all aforementioned goods as far as contained in this class. Design, maintenance and care of computer software for gages, measuring machines, measuring instruments, measuring stations, data evaluation facilities and industrial metrology; all aforementioned services as far as contained in this class.

Goods & Services

computer software for use in the field of metrology for controlling and monitoring measuring instruments, measuring machines, measuring fixtures, measuring stations, and data evaluation facilities; computer software for use in the field of metrology for measuring program creation, measuring program execution, machine control, measuring station configuration, measurement and execution control, measuring function and measurement execution control, measuring value recording, measured value storage, diagnosis, measurement evaluation and logging, fault analysis, data export and data import, program administration, user administration, license administration, and quality and process control design and maintenance of computer software for others, namely for use with gauges, measuring machines, measuring instruments, measuring stations, data evaluation facilities and industrial metrology

Goods & Services

Measuring apparatus and instruments, including for industrial and scientific purposes and for test agent monitoring, mechanical, electromechanical, electric and electronic measuring apparatus and measuring instruments with analog or digital displays or electric or optical measuring signal interfaces, including optical and magnetic measuring apparatus and measuring instruments, calliper gauges, depth-measuring calliper gauges, height gauges, dial indicators, micrometers, micrometer gauges, bore-measuring instruments, internal micrometers, gauge blocks, protractors, straight-edges, bevelled steel squares, steel squares, measuring plates, radius templates, measuring probes, measuring stands, prisms, aligning devices, single-axle measuring apparatus with incremental optoelectronic or magnetic measuring systems, coordinate measuring apparatus and tool presetting instruments; hardware and software for use in the field of measuring and testing technology. Repair and installation services in the field of measuring and testing technology. Engineering and physics (research); computer programming in the field of measuring and testing technology.

Goods & Services

Mechanical and digital test indicators, dial indicators, dial comparators, mechanical and digital calipers, particularly for measured value recording, data acquisition, data transmission and data processing; products mainly consisting of the above mentioned goods, namely complete measuring stations, measuring units, measuring and controlling systems including all ancillary and auxiliary equipment and devices also with indicating and printing functions, appertaining operating systems and stored user programs and evaluation software also for the purpose of statistical quality and processing control, software; measuring instruments, measuring machines and units for production applications (shop-floor), assembling, quality securing and machining; ancillary devices and units for measuring in the field of manufacturing; accessories, namely probes, measuring arms, measuring elements (styli), measuring heads, measuring jaws, cross beam depth gauges, pick-ups, probe arms (tracing arms), probe styli, probe centers, tracing arm extensions, scribers, measuring stands, measuring tables, magnetic bases, centering devices, mounting devices, vee-blocks, positioning stops, slip-on head holders, shaft whippers, measuring tripods, surface plates, testing attachments, calibration standards, setting masters, roundness standards, roughness standards, master gears, geometric standards, gauges, cylindrical squares, optical flats, lifting and lowering mechanisms, drive units, rotary drive units, adaptors, setting units, positioning units, setting masters, devices for matching the measured force, connection cables, extension cables, hand and foot switches, workholding fixtures (chucks), attachments, center supports, swivel units, protection screens, suction lifters, data media, data carriers (all the aforesaid products included in this class). Calibration services for the goods mentioned in class 9.

Goods & Services

Mechanical and digital calipers, particularly for measuring value recording, data acquisition, data transmission and data processing; products mainly consisting of the above mentioned goods, namely complete measuring stations, measuring units, measuring and controlling systems including all ancillary and auxilliary equipment and devices also with indicating and printing functions, operating systems belonging thereto and stored user programs and evaluation software also for the purpose of statistical quality and processing control, software; measuring instruments, measuring machines and units for production applications (shop-floor), assembling, quality control and machining; ancillary devices and units for measuring in the field of manufacturing; accessories, namely probes, measuring arms, measuring elements (styli), measuring heads, measuring jaws, cross beam depth gauges, pick-ups, probe arms (tracing arms), probe styli, probe centers, tracing arm extensions, scribers, measuring stands, measuring tables, magnetic bases, centering devices, mounting devices, vee-blocks, positioning stops, slip-on head holders, shaft whippers, measuring tripods, surface plates, testing attachments, calibration standards, setting masters, roundness standards, roughness standard, master gears, geometric standards, gauges, cylindrical squares, optical flats, lifting and lowering mechanisms, drive units, rotary drive units, adaptors, setting units, positioning units, setting masters, devices for matching the measuring force, connection cables, extension cables, hand and foot switches, workholding fixtures (chucks), attachments, center supports, swivel units, protection screens, suction lifters, data media, data carriers (all the aforesaid products included in this class). Calibration service for the goods mentioned in class 9.

Goods & Services

Mechanical and digital calipers, particularly for measuring value recording, data acquisition, data transmission and data processing; products mainly consisting of the above mentioned goods, namely complete measuring stations, measuring units, measuring and controlling systems including all ancillary and auxilliary equipment and devices also with indicating and printing functions, operating systems belonging thereto and stored user programs and evaluation software also for the purpose of statistical quality and processing control, software; measuring instruments, measuring machines and units for production applications (shop-floor), assembling, quality control and machining; ancillary devices and units for measuring in the field of manufacturing; accessories, namely probes, measuring arms, measuring elements (styli), measuring heads, measuring jaws, cross beam depth gauges, pick-ups, probe arms (tracing arms), probe styli, probe centers, tracing arm extensions, scribers, measuring stands, measuring tables, magnetic bases, centering devices, mounting devices, vee-blocks, positioning stops, slip-on head holders, shaft whippers, measuring tripods, surface plates, testing attachments, calibration standards, setting masters, roundness standards, roughness standard, master gears, geometric standards, gauges, cylindrical squares, optical flats, lifting and lowering mechanisms, drive units, rotary drive units, adaptors, setting units, positioning units, setting masters, devices for matching the measuring force, connection cables, extension cables, hand and foot switches, workholding fixtures (chucks), attachments, center supports, swivel units, protection screens, suction lifters, data media, data carriers (all the aforesaid products included in this class). Calibration service for the goods mentioned in class 9.

Goods & Services

Mechanical and digital calipers, particularly for measuring value recording, data acquisition, data transmission and data processing; products mainly consisting of the above mentioned goods, namely complete measuring stations, measuring units, measuring and controlling systems including all ancillary and auxilliary equipment and devices also with indicating and printing functions, operating systems belonging thereto and stored user programs and evaluation software also for the purpose of statistical quality and processing control, software; measuring instruments, measuring machines and units for production applications (shop-floor), assembling, quality control and machining; ancillary devices and units for measuring in the field of manufacturing; accessories, namely probes, measuring arms, measuring elements (styli), measuring heads, measuring jaws, cross beam depth gauges, pick-ups, probe arms (tracing arms), probe styli, probe centers, tracing arm extensions, scribers, measuring stands, measuring tables, magnetic bases, centering devices, mounting devices, vee-blocks, positioning stops, slip-on head holders, shaft whippers, measuring tripods, surface plates, testing attachments, calibration standards, setting masters, roundness standards, roughness standard, master gears, geometric standards, gauges, cylindrical squares, optical flats, lifting and lowering mechanisms, drive units, rotary drive units, adaptors, setting units, positioning units, setting masters, devices for matching the measuring force, connection cables, extension cables, hand and foot switches, workholding fixtures (chucks), attachments, center supports, swivel units, protection screens, suction lifters, data media, data carriers (all the aforesaid products included in this class). Calibration service for the goods mentioned in class 9.

Goods & Services

Mechanical and digital calipers, particularly for measuring value recording, data acquisition, data transmission and data processing; products mainly consisting of the above mentioned goods, namely complete measuring stations, measuring units, measuring and controlling systems including all ancillary and auxiliary equipment and devices also with indicating and printing functions, operating systems belonging thereto and stored user programs and evaluation software also for the purpose of statistical quality and processing control, software; measuring instruments, measuring machines and units for production applications (shop-floor), assembling, quality control and machining; ancillary devices and units for measuring in the field of manufacturing; accessories, namely probes, measuring arms, measuring elements (styli), measuring heads, measuring jaws, cross beam depth gauges, pick-ups, probe arms (tracing arms), probe styli, probe centers, tracing arm extensions, scribers, measuring stands, measuring tables, magnetic bases, centering devices, mounting devices, vee-blocks, positioning stops, slip-on head holders, shaft whippers, measuring tripods, surface plates, testing attachments, calibration standards, setting masters, roundness standards, roughness standards, master gears, geometric standards, gauges, cylindrical squares, optical flats, lifting and lowering mechanisms, drive units, rotary drive units, adaptors, setting units, positioning units, devices for matching the measuring force, connection cables, extension cables, hand and foot switches, workholding fixtures (chucks), attachments, center supports, swivel units, protection screens, suction lifters, data media, data carriers (all the aforesaid products included in this class). Calibration service for the goods above mentioned in Class 09.

Goods & Services

Mechanical and digital calipers, particularly for measuring value recording, data acquisition, data transmission and data processing; products mainly consisting of the above mentioned goods, namely complete measuring stations, measuring units, measuring and controlling systems including all ancillary and auxilliary equipment and devices also with indicating and printing functions, operating systems belonging thereto and stored user programs and evaluation software also for the purpose of statistical quality and processing control, software; measuring instruments, measuring machines and units for production applications (shop-floor), assembling, quality control and machining; ancillary devices and units for measuring in the field of manufacturing; accessories, namely probes, measuring arms, measuring elements (styli), measuring heads, measuring jaws, cross beam depth gauges, pick-ups, probe arms (tracing arms), probe styli, probe centers, tracing arm extensions, scribers, measuring stands, measuring tables, magnetic bases, centering devices, mounting devices, vee-blocks, positioning stops, slip-on head holders, shaft whippers, measuring tripods, surface plates, testing attachments, calibration standards, setting masters, roundness standards, roughness standard, master gears, geometric standards, gauges, cylindrical squares, optical flats, lifting and lowering mechanisms, drive units, rotary drive units, adaptors, setting units, positioning units, setting masters, devices for matching the measuring force, connection cables, extension cables, hand and foot switches, workholding fixtures (chucks), attachments, center supports, swivel units, protection screens, suction lifters, data media, data carriers (all the aforesaid products included in this class). Calibration service for the goods mentioned in class 9.

Goods & Services

Mechanical and digital calipers, particularly for measuring value recording, data acquisition, data transmission and data processing; products mainly consisting of the above mentioned goods, namely complete measuring stations, measuring units, measuring and controlling systems including all ancillary and auxilliary equipment and devices also with indicating and printing functions, operating systems belonging thereto and stored user programs and evaluation software also for the purpose of statistical quality and processing control, software; measuring instruments, measuring machines and units for production applications (shop-floor), assembling, quality control and machining; ancillary devices and units for measuring in the field of manufacturing; accessories, namely probes, measuring arms, measuring elements (styli), measuring heads, measuring jaws, cross beam depth gauges, pick-ups, probe arms (tracing arms), probe styli, probe centers, tracing arm extensions, scribers, measuring stands, measuring tables, magnetic bases, centering devices, mounting devices, vee-blocks, positioning stops, slip-on head holders, shaft whippers, measuring tripods, surface plates, testing attachments, calibration standards, setting masters, roundness standards, roughness standard, master gears, geometric standards, gauges, cylindrical squares, optical flats, lifting and lowering mechanisms, drive units, rotary drive units, adaptors, setting units, positioning units, setting masters, devices for matching the measuring force, connection cables, extension cables, hand and foot switches, workholding fixtures (chucks), attachments, center supports, swivel units, protection screens, suction lifters, data media, data carriers (all the aforesaid products included in this class). Calibration service for the goods mentioned in class 9.

Goods & Services

Mechanical and digital calipers, particularly for measuring value recording, data acquisition, data transmission and data processing; products mainly consisting of the above mentioned goods, namely complete measuring stations, measuring units, measuring and controlling systems including all ancillary and auxilliary equipment and devices also with indicating and printing functions, operating systems belonging thereto and stored user programs and evaluation software also for the purpose of statistical quality and processing control, software; measuring instruments, measuring machines and units for production applications (shop-floor), assembling, quality control and machining; ancillary devices and units for measuring in the field of manufacturing; accessories, namely probes, measuring arms, measuring elements (styli), measuring heads, measuring jaws, cross beam depth gauges, pick-ups, probe arms (tracing arms), probe styli, probe centers, tracing arm extensions, scribers, measuring stands, measuring tables, magnetic bases, centering devices, mounting devices, vee-blocks, positioning stops, slip-on head holders, shaft whippers, measuring tripods, surface plates, testing attachments, calibration standards, setting masters, roundness standards, roughness standard, master gears, geometric standards, gauges, cylindrical squares, optical flats, lifting and lowering mechanisms, drive units, rotary drive units, adaptors, setting units, positioning units, setting masters, devices for matching the measuring force, connection cables, extension cables, hand and foot switches, workholding fixtures (chucks), attachments, center supports, swivel units, protection screens, suction lifters, data media, data carriers (all the aforesaid products included in this class). Calibration service for the goods mentioned in class 9.

Goods & Services

Rotary stroke bearings, particularly high precision rotary stroke bearings for backlash-free linear, rotary or combined motions; parts of the aforementioned goods, especially guide shafts, ball cages, open guide bushes and leather bellows, adjustment elements for precision mechanics. Length measuring instruments. Repair service for the goods mentioned in classes 7 and 9. Calibration service for the goods mentioned in classes 7 and 9.

Goods & Services

Precision measuring instruments, namely, electronic height gages

Goods & Services

HIGH-PRECISION MEASURING INSTRUMENTS, NAMELY, HIGH-PRECISION DIAMETER GAUGES FOR USE IN THE METAL TOOLING INDUSTRY

Goods & Services

HIGH-PRECISION ELECTRONIC MEASURING INSTRUMENTS, NAMELY, HIGH-PRECISION GAUGES FOR MEASURING FORM AND GEOMETRY FOR USE IN THE METAL TOOLING INDUSTRY

Goods & Services

HIGH-PRECISION ELECTRONIC MEASURING INSTRUMENTS, NAMELY, HIGH-PRECISION GAUGES FOR MEASURING SURFACE, FINISH AND PROFILE FOR USE IN THE METAL TOOLING INDUSTRY

Goods & Services

HIGH-PRECISION MEASURING INSTRUMENTS, NAMELY, HIGH-PRECISION TEST DIAL INDICATORS FOR USE IN THE METAL TOOLING INDUSTRY

Goods & Services

High-precision measuring instruments, namely, high-precision universal gauges for measuring length

Goods & Services

HIGH-PRECISION MEASURING INSTRUMENTS, NAMELY, HIGH-PRECISION ELECTRONIC AND AIR GAUGES FOR USE IN THE METAL TOOLING INDUSTRY

Goods & Services

precision measuring instruments, namely, micrometers and dial gauges

Goods & Services

Ball-mounted guides. Mechanical, electrical, electronic, acoustic, optical and pneumatic measuring, checking and control apparatus, particularly mechanical and electrical apparatus as well as automated systems for measuring and checking length, deviations in form, pattern, position, surface conditions, apparatus for verification of control means; comprehensive measuring stations and systems comprising substantially of the aforesaid goods, including auxiliary devices, as well as those for display or printing purposes; multi-dimensional measuring equipment; digital and analog data processing apparatus, including measuring, operating and control calculators, the related operating systems and stored application and operating programs, also for the statistical control of quality and processes; measurement control apparatus, measuring apparatus and automatic measuring systems for machine tools and for flow lines; mechanical and digital vernier calipers, micrometers, mechanical and digital comparators, lever comparators, measuring tracers, measuring brackets, measuring tables, measuring apparatus for threading, setting gages, geometric standards, gages, gage blocks, pin gages, apparatus for measuring height, electronic apparatus for measuring length, measuring stamps, cylindrical gage rings, apparatus for measuring depth, general fittings for measurement purposes, protractor gages, surface plates, measuring V-blocks of steel, inductive gages and incremental gages for measurements, electrical display apparatus, thickness gaging apparatus, boring verification apparatus, limit gages, thread-testing measures, cone-measuring apparatus, gear control machines, wheel gages, ball bearing control apparatus, camshaft control apparatus, audiovisual teaching materials for training and advanced training in connection with metrology and verification, teaching apparatus and instruments. Teaching materials (except apparatus); instructional materials for training and advanced training in the area of metrology and verification, such as printed matter. Repair services. Seminars in the area of metrology and verification. Consulting and development services in connection with metrology and verification; calibration services.

Goods & Services

high-precision industrial metrology measuring tools, apparatus and units, namely, Vernier calipers, micrometers, gauges, dial indicators and comparators, thread gauge indicators, gauges for plain cylindrical parts, blind ends, serrations, thread gauges, gauge blocks, gear testing equipment, mechanical and electrical dial comparators; pneumatic and electronic length measurement instruments; pneumatic and electronic length control instruments, and recording instruments for the foregoing; multi-gauge measuring systems comprising multiple gauges; precision measuring apparatus; statistical quality testing apparatus; surface texture recording and print-out instruments; surface measuring apparatus; form and shape measuring apparatus; "rapide" recorders, form testing instruments; machines for testing for roundness and straightness; profile measuring machines; profile measuring recording apparatus; diameter measuring apparatus and parts of any of the foregoing

Goods & Services

(1) Measuring tools, mechanical, electrical, electronic, acoustic, optical and pneumatic measuring, instruments, namely mechanical and electrical instruments as well as automatic measuring devices for measuring linear dimensions, form, profile and location deviations as well as surface texture and surface roughness, testpiece monitoring systems; complete measuring stations and measuring systems consisting of the above-mentioned goods and including all, even indicating and printing auxiliary and additional instruments; measuring instruments and automatic measuring devices for machines and transfer lines; mechanical and digital callipers, mechanical and digital dial gauges, dial comparators, measuring instruments for threads, gauges, gauge blocks, pin gauges, height measuring devices, electronic length measuring devices, plug gauges, ring gauges, depth measuring devices, thickness gauges, internal measuring instruments, calliper gauges, thread gauges, thread measuring wires, taper gauges, gear measuring instruments, gear testing machines, all of the aforementioned wares being metrological measuring instruments for industrial and/or scientific purposes. (2) Mechanical, electrical, electronic, and pneumatic testing and control instruments, namely mechanical and electrical instruments as well as automatic devices for testing linear dimensions, form, profile and location deviations as well as surface texture and surface roughness, testpiece monitoring systems; indicating and printing auxiliary and additional instruments for use in complete measuring stations and measuring systems; digital and analogue data processing instruments with measuring, evaluation and control computers, required operating systems and stored application programs and evaluation software, even for the statistical quality and process control; size control systems, ball bushings; micrometers, lever-type test indicators, probes, roughness standards, general measurement accessories, inductive and incremental probes, electrical indicating instruments, master gears, camshaft testing instruments, all of the aforementioned wares being metrological measuring instruments for industrial and/or scientific purposes. (3) Mechanical, electrical, electronic, acoustic, optical and pneumatic measuring, instruments, namely mechanical and electrical instruments as well as automatic measuring devices for measuring linear dimensions, form, profile and location deviations as well as surface texture and surface roughness, testpiece monitoring systems; complete measuring stations and measuring systems consisting of the above-mentioned goods and including all, even indicating and printing auxiliary and additional instruments; measuring instruments and automatic measuring devices for machines and transfer lines; mechanical and digital callipers, mechanical and digital dial gauges, dial comparators, measuring instruments for threads, gauges, gauge blocks, pin gauges, height measuring devices, electronic length measuring devices, plug gauges, ring gauges, depth measuring devices, thickness gauges, internal measuring instruments, calliper gauges, thread gauges, thread measuring wires, taper gauges, gear measuring instruments, all of the aforementioned wares being metrological measuring instruments for industrial and/or scientific purposes.

Goods & Services

electronic measuring instruments, namely, read-out gauges for dimensional measurements

Goods & Services

Outils de mesure, comme coulisses de mesure, appareils de traçage, équerres et rapporteurs, règles graduées, règles à ligner, outils à dresser, calibres, compteurs et appareils de comptage, supports de mesure, planchettes, appareils d'essai pour le contrôle de concentricité, palmers, pieds à coulisse, mesureurs pour la hauteur; outils de mesure électroniques avec indicateurs digitaux, comme coulisses de mesure, mesureurs pour la profondeur, appareils de mesure pour la hauteur et de traçage, rapporteurs.

Goods & Services

Metering instruments, in particular multiple-axis measuring apparatus, measuring rules, folding rules, tape decameters, slide calipers, micrometers, counting watches, amplifying comparators, apparatus for measuring saw settings or bores, thickness and internal measurement apparatus, goniometers, electronic strain gauges and measuring instruments, measuring devices with electronic or opto-electronic systems, electro-mechanical measuring devices and benches, automatic measuring machines, digital computers and apparatus for the statistical representation and processing of measured values; measuring tables, stands and mounts; jigs, setting gauges, depth micrometer rods, tapping and radius gauges, calibrated standing or adjustable vices; adjusting accessories, namely rulers, milestones, prisms, water levels, surface plates, squares; scribers, compasses, concentricity control apparatus, revolution and piece counters; magnifying glasses, measuring amplifiers, lights for magnifying glasses; all above-mentioned goods included in this class.
