Abstract

The invention relates to a rotary flow meter for measuring gas flow, comprising a pair of three-toothed rotors, each of which has the shape of a double helical gear, wherein the first rotor is a mirror reflection of the second rotor, and the rotors are adapted to rotate in opposite directions; moreover, the flow meter comprises a body sealing the rotors adapted to form temporary measurement chambers having a strictly defined volume, formed between the outer surfaces of the rotors and the inner surface of the body. The rotary flow meter according to the invention is characterised by the rotors adapted not to contact each other and which are synchronised via an external module synchronising the rotation of the rotors.

IPC Classes  ?

• G01F 3/10 - Geared or lobed impeller meters

Goods & Services

Pumps [machines], Compressors and blowers for use in gas flow measurement systems; Blowing machines for the compression, exhaustion and transport of gases; Machines for pressurizing air; Wind turbines; Centrifugal machines; Turbocompressors. Equipment, assemblies, accessories, installations and software for gas measurement systems for measuring, processing and monitoring the flow of gas; Measuring, counting, alignment and calibration apparatus for use in gas flow measurement systems; Volumetric measuring apparatus; Flowmeters; Gas flow meters; Gasometers [measuring instruments]; Rotary gas meters; Turbine meters; Thermometers, not for medical purposes; Gas pressure indicators; Data loggers; Pressure recorders; Pressure transducers; Electronic temperature recorders, other than for medical use; Telemetry apparatus; Monitoring devices for use in gas flow measurement systems, including gas consumption monitoring devices, Gas flow monitors; Communication equipment for use in gas flow measurement systems, including electronic signal transmitters, Apparatus for the transmission of data, Data transmitters, Communication interface units; Electronic network systems, equipment, Assemblies and software for use in gas flow measurement systems; Tap boxes; Data transmission software. Engineering services; Mechanical research; Technical research; Technological consultation services; All the aforesaid services being in the field of systems, apparatus, assemblies and software relating to gas flow measurement.
