Abstract

An air fryer includes a fryer body, a cooking chamber is arranged in the fryer body, an annular air guiding chamber which concaves upwards and opens downwards is arranged at a top of the cooking chamber, a frying basket having a top opening is arranged in the cooking chamber, the top opening of the frying basket is at least partially located under the air guiding chamber, and a vent hole communicating with the cooking chamber is formed in a lower portion of the frying basket; a hot air chamber is arranged in the fryer body, and an air outlet and an air inlet of the hot air chamber are suitable for communicating with the air guiding chamber and the cooking chamber respectively; and an air guiding and distributing member used to guide airflow to enter the air guiding chamber from at least two directions is arranged in the air outlet.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

An air fryer with air suction on a side portion includes a machine body, a cooking chamber arranged in the machine body, a hot air circulation system arranged on a side portion of the cooking chamber, communicating with the cooking chamber, and a frying basket arranged in the cooking chamber and having a top opening. A food tray with a through hole is suspended in the frying basket, a ventilation hole is formed in a side wall of the frying basket below the food tray, and the circulating heat flow generated by the hot air circulation system enters the cooking chamber, and then is adapted to enter the frying basket from the top opening of the frying basket, penetrate through the food tray from an upper space of the food tray to enter a lower space of the food tray, and then flow out of the ventilation hole.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• F24C 15/32 - Arrangements of ducts for hot gases, e.g. in or around baking ovens

Abstract

A top-visible air fryer includes a fryer body, a decorative ring, and a heat insulation ring. The fryer body is internally provided with a cooking chamber with a top opening, and an inner transparent plate for closing the top opening is arranged at the top opening; the decorative ring is arranged above the top opening, a viewing window corresponding to the top opening is arranged in a middle of the decorative ring, and a visible panel is arranged at an upper opening of the viewing window; the heat insulation ring is arranged between the top opening and the decorative ring, an open pore corresponding to the top opening is arranged in a middle of the heat insulation ring, a lower side of the heat insulation ring is connected to the fryer body, an upper side of the heat insulation ring is connected to a lower side of the decorative ring.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

In particular to a frying pan, a frying basket assembly and an air fryer, a frying pan applied to an air fryer is provided. The frying pan is provided with a plurality of arched protrusions at intervals in a transverse extending direction, the arched protrusions are suitable for being formed by upwards recessing of the frying pan, and the arched protrusions are provided with a plurality of air vents for hot air to pass; a frying basket assembly is provided. The frying basket assembly includes a frying basket body and an accommodating chamber with a top opening arranged inside the frying basket body, and the frying pan as described above is detachably arranged in the accommodating chamber. The air fryer includes a fryer body, a cooking chamber with a top or lateral opening arranged inside the fryer body and an air frying system communicating with the cooking chamber.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• A47J 37/10 - Frying pans, e.g. frying pans with integrated lids or basting devices
• A47J 37/12 - Deep fat fryers, e.g. for frying fish or chips

Abstract

Disclosed is an air fryer with good safety features, including a body, a cooking cavity located within the body, the body having a top opening connected to the cooking cavity at the top, and a lid provided at the top opening to open and close the top opening; the body having a side opening connected to the cooking cavity on the side, and a side cover provided at the side opening to open and close the side opening, wherein the body has a linkage control system inside, the linkage control system being electrically connected to the control circuit inside the body; the linkage control system is also suitable for transmission cooperation with the lid and the side cover, when the lid and the side cover close the top opening and the side opening, the linkage control system is conductive with the control circuit of the body.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

Disclosed is an air fryer with good thermal insulation, including a body, a cooking cavity located within the body, and a hot air circulation system connected to the cooking cavity, wherein at least part of the outside of the cooking cavity is equipped with a heat insulation component that matches the outer wall of the cooking cavity, the heat insulation component and the outer wall of the cooking cavity are suitable for forming a heat insulation chamber, the heat insulation chamber contains a heat insulation medium. By providing a heat insulation component that matches the outer wall of the cooking cavity on the outside of the cooking cavity to form a heat insulation chamber, and placing a heat insulation medium inside the heat insulation chamber, the air fryer can reduce the impact of high temperatures inside the cooking cavity on the electrical components outside.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

Disclosed is high energy efficient air fryer, the frying basket includes a body, wherein the body is provided with a first cooking chamber and a second cooking chamber, the first cooking chamber is equipped with a first circulation fan, and the first cooking chamber has a first air outlet corresponding to the first circulation fan, the first air outlet is connected to the second cooking chamber through a first pipeline; the second cooking chamber is equipped with a second circulation fan, and the second cooking chamber has a second air outlet corresponding to the second circulation fan, the second air outlet is connected to the first cooking chamber through a second pipeline.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• A47J 27/00 - Cooking-vessels
• F24C 15/00 - DOMESTIC STOVES OR RANGESDETAILS OF DOMESTIC STOVES OR RANGES, OF GENERAL APPLICATION Details
• F24C 15/32 - Arrangements of ducts for hot gases, e.g. in or around baking ovens

Abstract

This application provides an air fryer with excellent cooking performance, including a body, a cooking cavity located inside the body, and a frying system, the cooking cavity is connected with the frying system, the body has multiple seasoning boxes on the outside, and the body has multiple feeding mechanisms corresponding to the seasoning boxes inside, one end of the multiple feeding mechanisms is connected with the corresponding seasoning box, and the other end is connected with the cooking cavity.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• A47J 36/32 - Time-controlled igniting mechanisms or alarm devices

Abstract

A multifunctional cooking device includes a machine base, a packaging mechanism arranged on a front portion of the machine base, a steaming and boiling mechanism arranged on a rear portion of the machine base, and a frying and grilling mechanism arranged on the upper portion of the machine base and positioned above the steaming and boiling mechanism. A food bag can be vacuumized and sealed through the packaging mechanism. The steaming and boiling mechanism is provided with a steaming and boiling cavity for placing food and a heating assembly for heating the steaming and boiling cavity. A heating medium is arranged in the steaming and boiling cavity, and food packaged and vacuum-sealed can be cooked through the steaming and boiling cavity, and steamed and boiled food can be fried and grilled through the frying and grilling mechanism.

IPC Classes  ?

• A47J 44/00 - Multi-purpose machines for preparing food
• A47J 27/04 - Cooking-vessels for cooking food in steamDevices for extracting fruit juice by means of steam
• A47J 27/10 - Cooking-vessels with water-bath arrangements for domestic use
• A47J 36/32 - Time-controlled igniting mechanisms or alarm devices
• A47J 37/06 - RoastersGrills Sandwich grills
• B65B 25/00 - Packaging other articles presenting special problems
• B65B 31/04 - Evacuating, pressurising or gasifying filled containers or wrappers by means of nozzles through which air or other gas, e.g. an inert gas, is withdrawn or supplied
• F24C 7/08 - Arrangement or mounting of control or safety devices

Abstract

An air fryer includes fryer body, cooking cavity, hot air cavity outside the cooking cavity, and frying system within the hot air cavity. The cooking cavity has ventilation holes corresponding to the frying system and having return holes and hot air holes. Frying basket assembly has a food basket and a flow guide, front and rear side of the basket have inlet and outlet holes corresponding to the return holes. The flow guide extends from left and right sides of the basket to rear side of the basket. Channel is formed between the flow guide and the cooking cavity. Heat flow enters the cooking cavity through the hot air holes and is guided into the channel and flows to a front of the cooking cavity, enters the basket from the inlet holes and flows out from the outlet holes and back to the hot air cavity through the return holes.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• F24C 15/14 - Spillage trays or grooves
• F24C 15/32 - Arrangements of ducts for hot gases, e.g. in or around baking ovens

Abstract

Disclosed is a temperature-adjustable outdoor air fryer. The air fryer is provided therein with a cooking cavity, an external circulation air duct is provided outside the cooking cavity, a temperature-control fan and a heat generating source configured to cooperate with an outer wall of the cooking cavity through thermal transfer are provided in the external circulation air duct, and the heat generating source is a relevant heat generating item susceptible to oxygen content; the air fryer is further provided therein with a control system and a variable-speed drive motor and a temperature sensor which are electrically connected to the control system, wherein the drive motor is connected to the temperature-control fan, and the temperature sensor extends into the cooking cavity.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• A47J 37/07 - Roasting devices for outdoor useBarbecues

Abstract

Disclosed is frying basket with detachable viewing window. The frying basket includes frying basket main body, door panel assembly, viewing window, and viewing window panel. The frying basket main body is provided with accommodating cavity, and side part of frying basket main body is provided with viewing port communicating with the accommodating cavity. Door panel assembly is provided on outer side of the frying basket main body and fixedly connected to the frying basket main body. The door panel assembly is provided with viewing window port corresponding to the viewing port. Transparent board is provided between the door panel assembly and the frying basket main body to seal the viewing port. Viewing window panel is detachably arranged on the door panel assembly to seal the viewing window port. Disclosed is air fryer, comprising air fryer main body and the aforementioned frying basket with detachable viewing window arranged thereon.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

A fryer plate that is accommodated inside a fryer basket, including: a holding portion holding food and including a first air hole; and a support portion coupled to the holding portion. The support portion is coupled to the fryer basket, the holding portion is spaced apart from an inner bottom wall surface of the fryer basket, and a first air passage is formed between the support portion and the inner bottom wall surface of the fryer basket and is in connection with the first air hole.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• A47J 36/20 - Perforated bases or perforated containers to be placed inside a cooking utensil

Abstract

Air fryer with transparent window includes body, wherein side portion of body is provided with opening portion in communication with cooking cavity inside air fryer; opening portion is provided with drawer-type frying basket in insertable manner; drawer-type frying basket includes frying basket and door panel portion connected to one side of frying basket; door panel portion is used for blocking opening portion; hollow portions are correspondingly configured on both door panel portion and side wall of frying basket; window member is arranged in hollow portion of door panel portion; rear window cover is mounted between inner side of door panel portion and frying basket; rear window cover is provided with hollow structures corresponding to hollow portions on door panel portion and frying basket; and one side of rear window cover abuts against frying basket, and the other side abuts against window member.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

The present disclosure provides a frying basket with a detachable handle and an air fryer, including a frying basket body and a handle section, wherein the frying basket body and the handle section are detachably connected to each other; the inner part of the frying basket body is provided with a space to accommodate the handle section; the frying basket body is thereon provided with a mounting port; one end of the handle section is provided with a mounting base; and the mounting base is fitted and embedded in the mounting port. The present disclosure can solve the existing problems that the frying basket and handle cannot be disassembled and are inconvenient in transportation.

IPC Classes  ?

• A47J 45/07 - Handles for hollow-ware articles of detachable type
• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

Frying basket assembly having separated handle and air fryer are disclosed. Frying basket assembly includes handle including mounting portion and frying basket provided with mounting groove corresponding thereto, one of mounting portion and mounting groove is provided with hook, the other is provided with snapping position corresponding thereto, hook is connected with elastic member to make hook move towards direction of snapping position, and when handle is mounted on frying basket and reaches final position, hook is clamped into snapping position. Frying basket having separated handle and air fryer are further disclosed, including frying basket body and handle portion, wherein frying basket body and handle portion are detachably connected, and space capable of accommodating handle portion inside frying basket body exists, frying basket body is provided with mounting port, one end of handle portion is provided with mounting base, and mounting base fits and is embedded into mounting port.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

Provided is a flip-type multifunctional air fryer, including a cookware, a head, a base and a side plate provided between the head and the base, wherein a bottom of the head has an open structure, an air frying module is mounted in the head, the cookware at least includes a basket, the head is rotatably connected with the side plate, and the head at least has two positions in a rotation process: a first position where a bottom opening of the head faces downwards and is communicated with a top opening of the basket; a second position where the bottom opening of the head faces upwards and is connected with a bottom of the cookware.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

Provided is lifting multifunctional air fryer, including machine body, cookware and lifting drive component, wherein the cookware includes at least frying basket and frying pan, and the machine body includes machine head, base, and side plate arranged between the machine head and the base, to define first cooking chamber for accommodating the frying basket and second cooking chamber for accommodating the frying pan. Air frying module is arranged above the first cooking chamber, and the air frying module communicates the inner chamber of frying basket; first heating element is arranged above the second cooking chamber, and second heating element is arranged below, both of them are connected to the frying pan; the first heating element is driven by the lifting drive component to lift, so that the height between the first heating element and the second heating element is adapted to that of ingredients on the frying pan.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• A47J 36/32 - Time-controlled igniting mechanisms or alarm devices

Abstract

The present disclosure provides an overturnable dual-purpose multifunctional air fryer, including a machine core and a fryer, wherein the machine core has a bottom opening which is provided with a thermal circulation fan and a heating element therein, and the fryer has a top opening; and the machine core and the fryer are detachably connected, and the machine core and the fryer can be in: a first matching state, where the machine core is located above the fryer, and the bottom opening of the machine core faces downward and communicates to the top opening of the fryer; and a second matching state, where the fryer is located above the machine core, and the bottom opening of the machine core faces upward and connects to a bottom of the fryer.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

The present application provides a handle mounting structure for an air fryer and an air fryer. The air fryer includes a door panel and a handle, wherein the handle is separately mounted on the door panel. The handle mounting structure includes: a mounting groove, which is arranged on the door panel, wherein a first mounting member is provided on the mounting groove; and a mounting plate, arranged on the handle, wherein a second mounting member is provided on the mounting plate. At least one of the first mounting member and the second mounting member is an elastic element; and the first mounting member and the second mounting member abut against each other, to mount the handle onto the door panel.

IPC Classes  ?

• A47J 45/07 - Handles for hollow-ware articles of detachable type
• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

A multiform basket for an air fryer and an air fryer having multiple use forms are disclosed. The multiform basket is formed by splicing left and right pots together, wherein at least one removable baffle is provided at the joint between the left and the right pots, such that one or two placement cavities are formed inside the basket; alternatively, one pot is provided with a positioning post, while the other is provided with a positioning hole matching the positioning post and further a receiving slot corresponding to the positioning post, wherein the positioning post is movable to be accommodated in the receiving slot when the left and the right pots are not spliced together. The air fryer is provided with a removable door panel assembly or a drawer-type pot assembly capable of completely closing the door frame.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

Provided are basket with detachable cover plate for air fryer and air fryer having basket with detachable cover plate. The basket includes basket body and handle provided at side of basket body, and top portion of basket body is of opening structure, cover plate matched with opening is provided at opening of basket, and cover plate is detachably installed at opening of basket; the air fryer includes cooking cavity located inside air fryer, and basket and hot air device provided inside cooking cavity, and hot air device is located above basket, when cover plate is installed on basket, interior of basket is hermetically isolated by cover plate from hot air device, and when cover plate is detached from upper opening of basket, interior of basket is in communication with hot air device.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• F24C 7/06 - Arrangement or mounting of electric heating elements
• F24H 3/02 - Air heaters with forced circulation
• A47J 36/32 - Time-controlled igniting mechanisms or alarm devices

Abstract

Disclosed is a steam air fryer, comprising a cooking chamber which is located in the air fryer, wherein a hot airflow generation assembly is provided at the top of the cooking chamber; a water supply system for supplying water to the cooking chamber; and a heating disc which is located at the bottom of the cooking chamber and heats water to produce high-temperature steam diffusing upwards. According to the present disclosure, steam is produced by the heating disc at the bottom of the cooking chamber to achieve steam cooking, making cleaning easy.

IPC Classes  ?

• A47J 36/24 - Warming devices
• A47J 37/06 - RoastersGrills Sandwich grills
• A47J 27/04 - Cooking-vessels for cooking food in steamDevices for extracting fruit juice by means of steam
• A47J 36/38 - Parts, details or accessories of cooking-vessels for withdrawing or condensing cooking vapours from cooking utensils

Abstract

An air fryer with a transparent window, the air fryer comprising a body, wherein a side portion of the body is provided with an opening portion in communication with a cooking cavity (1) inside an air fryer; the opening portion is provided with a drawer-type frying basket in an insertable manner; the drawer-type frying basket comprises a frying basket (10) and a door panel portion connected to one side of the frying basket (10); the door panel portion is used for blocking the opening portion; hollow portions are correspondingly configured on both the door panel portion and a side wall of the frying basket (10); a window member (3) is arranged in the hollow portion of the door panel portion; a rear window cover (2) is mounted between an inner side of the door panel portion and the frying basket (10); the rear window cover (2) is provided with hollow structures corresponding to the hollow portions on the door panel portion and the frying basket (10); and one side of the rear window cover (2) abuts against the frying basket (10), and the other side thereof abuts against the window member (3) to tightly press and fix the window member (3) on the door panel portion. The air fryer can realize the positioning and mounting of the window member (3), and can also effectively prevent heat in the frying basket (10) from leaking out.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

An air fryer having broiling and baking functions comprises a cooking cavity, located in the air fryer, a heat circulation fan and a heating device mounted in an upper part of the cooking cavity; a heating plate, provided at the bottom of the cooking cavity; and a frying basket assembly, provided in the cooking cavity, wherein the frying basket assembly comprises a frying basket body and a broiling board provided at the bottom of the frying basket body, and the broiling board is heated by the heating plate. Further disclosed is a frying basket structure for an air fryer, comprising a frying basket body, located in a cooking cavity inside the air fryer, wherein a hollowed-out opening is provided at bottom of the frying basket body; and a broiling board, detachably fixed at the bottom of the frying basket body and covering the hollowed-out opening.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• A47J 27/12 - Multiple-unit cooking-vessels

Abstract

The present disclosure provides a steam-type air fryer, which has a steam system, a steam conveying structure, a water tank structure, a steam-generator heat dissipation structure, and a steam-generator cleaning structure, and relates to the technical field of steam-type air fryers.

IPC Classes  ?

• A47J 27/04 - Cooking-vessels for cooking food in steamDevices for extracting fruit juice by means of steam
• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

Disclosed is a steam-type air fryer including a main body. A chamber is disposed in the main body. A heating element is disposed in the main body. An air duct plate is disposed on an upper side of the chamber. A hot air wind wheel and a heating tube are disposed in the air duct plate. The steam-type air fryer further includes a door sealing structure, wherein an openable door panel and a door frame are disposed on a side of the air fryer. An opening is provided in a side of the chamber facing the door panel. A second sealing ring is mounted between the door frame and the door panel. The steam-type air fryer further includes a water tank mounted at the top of the steam-type air fryer and including a water tank body and a top cover located on the top of the water tank body.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• A47J 27/00 - Cooking-vessels
• A47J 27/04 - Cooking-vessels for cooking food in steamDevices for extracting fruit juice by means of steam
• A47J 36/06 - Lids or covers for cooking-vessels

Abstract

Disclosed is a steam-type air fryer, including: an air outlet structure, including a body shell, the body shell is provided therein with a cooking cavity, a steam generator in the body shell generates hot steam which is introduced into the cooking cavity, the cooking cavity is provided with an air outlet hole for discharging residual steam, a cold wind passage into which external cold air enters is formed between the cooking cavity and the body shell; and a water inlet structure, including an air fryer main body, an upper end of the air fryer main body is provided with a water tank seat, the water tank seat is detachably provided with a water tank, wherein the water tank is provided therein with a water outlet seat extending upward, the water tank seat is provided with a water outlet pipe corresponding to the water outlet seat.

IPC Classes  ?

• A47J 37/00 - BakingRoastingGrillingFrying
• A47J 37/06 - RoastersGrills Sandwich grills
• A47J 27/04 - Cooking-vessels for cooking food in steamDevices for extracting fruit juice by means of steam

Abstract

An air fryer with a detachable fryer assembly. The air fryer has a cooking cavity provided therein, wherein a fryer (1) is arranged inside the cooking cavity; an opening is formed at one side of the cooking cavity, and a panel (6) that can be pulled out together with the fryer (1) is arranged at the opening; and an inner side of the panel (6) is detachably connected to the fryer (1), thereby solving the problems of it being difficult to detach a panel from a fryer of an existing air fryer and it being difficult to clean same. A hollowed-out window (11) is arranged in the middle of one side of the fryer (1) that faces toward the panel (6); the middle of the panel (6) is hollowed out, and a transparent viewing window (65) corresponding to the hollowed-out window (11) is mounted therein; a viewing-window protection cover (62) corresponding to the transparent viewing window (65) is mounted at an outer side of the panel (6); and the transparent viewing window (65) in the panel (6) and the hollowed-out window (11) in the fryer (1) together form a visual pot body mechanism, such that a user can conveniently and clearly see the situation inside the fryer (1).

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

The present disclosure discloses an air fryer applicable for cooking a pizza, including a bottom bracket provided in a cooking cavity of the air fryer, wherein an air duct plate is provided between an upper part of the bottom bracket and a heating pipe on the top of the cooking cavity, a passing-air reflux port is provided in the middle of the air duct plate, an edge of the air duct plate extends downwards to form a hot air passage with an inner wall of the cooking cavity, and a pizza placement cavity is formed between the bottom bracket and the air duct plate.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• A47J 36/20 - Perforated bases or perforated containers to be placed inside a cooking utensil
• A47J 36/34 - Supports for cooking-vessels

Abstract

An air fryer with a steaming function includes a cooking chamber and a water tank arranged inside a housing. A steam generator is also arranged in the air fryer. A heating chamber is provided in the steam generator. The heating chamber in the steam generator is connected to a water tank via a water pump. High-temperature steam produced in the heating chamber of the steam generator is introduced into the cooking chamber. The steam generator is equipped with an over-temperature protector and a temperature sensor. Each of the over-temperature protector, the temperature sensor, the water pump, and the steam generator is electrically connected to the controller.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills
• A23L 5/10 - General methods of cooking foods, e.g. by roasting or frying
• A47J 27/04 - Cooking-vessels for cooking food in steamDevices for extracting fruit juice by means of steam
• A47J 36/32 - Time-controlled igniting mechanisms or alarm devices
• A47J 36/42 - Devices to prevent deposition of scale, i.e. fur, or the like

Abstract

A drain structure of an air fryer having a steaming function is provided. The air fryer includes a shell, a cooking cavity located at a lower side of the interior of the shell and a control cavity located at an upper side of the interior of the shell. The control cavity is provided therein with a control panel and a drive motor. The upper side of the shell is provided with a vent in communication with the control cavity. A top portion of the shell is provided with a water tank. The shell is provided therein with a steam generator in communication with the water tank. The steam generator is configured to input steam into the cooking cavity. The water tank is in a structure that is opened at bottom and closed at top, and the water tank is detachably mounted on the shell.

IPC Classes  ?

• A47J 27/04 - Cooking-vessels for cooking food in steamDevices for extracting fruit juice by means of steam
• A47J 37/06 - RoastersGrills Sandwich grills

Goods & Services

Multicookers; Air-conditioning apparatus; Air-conditioning installations; Air fryers; Fruit roasters; Hot-air space heating apparatus; Hot air blowers; Hot plates; Household air cleaners; Radiators, electric; Reheating furnaces for industrial purposes; Rotisseries; Ventilation hoods for stoves

Goods & Services

Food processors, electric; Meat mincers [machines]; Beverage processing machines; Ironing machines; Dishwashers; Kitchen machines, electric; Washing machines [laundry]; Machines and apparatus for cleaning, electric; Vacuum cleaners; Cordless vacuum cleaners; Electric fruit squeezers; Compressed air machines. Downloadable mobile applications; Downloadable computer programs; Data processing apparatus; Chipcards; Electrolysers; Smartphones; Wearable activity trackers; Remote controls; Eyeglasses; Rechargeable batteries. Hot air therapeutic apparatus; Body composition monitors; Dental apparatus and instruments; Thermo-electric compresses [surgery]; Furniture especially made for medical purposes; Breast pumps; Babies' bottles; Baby feeding pacifiers; Sex toys; Artificial limbs. Multicookers; Air fryers; Electric egg boilers; Kettles, electric; Electric cooking pots; Induction cookers; Microwave ovens for household purposes; Electric coffee machines; Apparatus for heating milk; Electric pans; Cooking utensils, electric; Ice cream freezers; Ice machines and apparatus; Air sterilizers; Hair dryers; Laundry dryers, electric; Toilet seats; Sanitary apparatus and installations; Disinfectant apparatus; Water sterilizers; Sterilizers; Sterilizers for household use; Radiators, electric. Containers for household or kitchen use; Beverage stirrers; Cooking pots; Frying pans; Kitchen utensils; Trash cans; Ironing boards; Toothbrushes, electric; Heads for electric toothbrushes; Thermally insulated containers for food.

Goods & Services

Food processors, electric; Meat mincers [machines]; Beverage processing machines; Ironing machines; Dishwashers; Kitchen machines, electric; Washing machines [laundry]; Machines and apparatus for cleaning, electric; Vacuum cleaners; Cordless vacuum cleaners; Electric fruit squeezers; Compressed air machines. Downloadable mobile applications; Downloadable computer programs; Data processing apparatus; Chipcards; Electrolysers; Smartphones; Wearable activity trackers; Remote controls; Eyeglasses; Rechargeable batteries. Hot air therapeutic apparatus; Body composition monitors; Dental apparatus and instruments; Thermo-electric compresses [surgery]; Furniture especially made for medical purposes; Breast pumps; Babies' bottles; Baby feeding pacifiers; Sex toys; Artificial limbs. Multicookers; Air fryers; Electric egg boilers; Kettles, electric; Electric cooking pots; Induction cookers; Microwave ovens for household purposes; Electric coffee machines; Apparatus for heating milk; Electric pans; Cooking utensils, electric; Ice cream freezers; Ice machines and apparatus; Air sterilizers; Hair dryers; Laundry dryers, electric; Toilet seats; Sanitary apparatus and installations; Disinfectant apparatus; Water sterilizers; Sterilizers; Sterilizers for household use; Radiators, electric. Containers for household or kitchen use; Beverage stirrers; Cooking pots; Frying pans; Kitchen utensils; Trash cans; Ironing boards; Toothbrushes, electric; Heads for electric toothbrushes; Thermally insulated containers for food.

Abstract

An air fryer with a flip function includes a body and an internal cavity installed in a lower interior of the body. A first wind wheel is mounted on an inner side at an upper end of the internal cavity. A heating pipe is installed below the first wind wheel. A partition is arranged above the internal cavity within the body. A cold circulation channel is formed between the internal cavity, the partition and the body. A second wind wheel is mounted on an upper end of the cold circulation channel. A detachable flip rack is horizontally provided in a middle portion of the internal cavity. A drive motor is arranged on an outer side of the internal cavity to drive one end of the detachable flip rack to rotate. An opening is provided on one side of the inner cavity. A flip openable panel is provided at the opening.

IPC Classes  ?

• A47J 37/01 - Vessels uniquely adapted for baking
• A47J 37/04 - Roasting apparatus with movably-mounted food supports or with movable heating implementsSpits
• A47J 37/06 - RoastersGrills Sandwich grills
• A47J 27/00 - Cooking-vessels
• A47J 43/18 - Holding or clamping devices for supporting fowl, venison, or other meat, or vegetables, during cooking or during subsequent cutting

Goods & Services

(1) Air conditioners; air fryers; electric radiators; fruit roasters; hot air bath fittings; hot air ovens; hot plates; multicookers; rotisseries; ventilating fans

Abstract

A rotation type air fryer comprises an upper casing (1), a lower casing (2), an upper core assembly (3), and a lower core assembly (4). The upper casing (1) and the lower casing (2) are assembled vertically to form an external casing. The upper core assembly (3) and the lower core assembly (4) are assembled vertically to form an internal core assembly. A cold air circulation channel is arranged between the external casing and the internal core assembly. A food insertion and removal opening is correspondingly formed at each of the lower core assembly (4) and the lower casing (2). A detachable main shaft (5) is rotatably installed inside the lower core assembly (4). A food frame (6) is provided at the main shaft (5). An electric drive mechanism drives the main shaft (5) to rotate. A rotating door member (7) can be detachably installed at the food insertion and removal opening. The rotation type air fryer can rotate food whiling heating the same, such that food is thoroughly and uniformly heated. The present invention has a high efficiency in roasting food, and enables food to be inserted and removed conveniently.

IPC Classes  ?

• A47J 37/06 - RoastersGrills Sandwich grills

Abstract

An air fryer having a rotation function comprises a main body (1) and an inner cavity (2) arranged at a lower inner portion of the main body (1). A first fan (6) is installed at an upper inner side of the inner cavity (2). A heating tube (15) is installed under the first fan (6). A partition plate (3) is provided inside the main body (1) and positioned above the inner cavity (2). A cooling circulation channel (13) is arranged between the inner cavity (2) and the partition plate (3) and between the inner cavity (2) and the main body (1). A second fan (4) is installed at an upper end of the cooling circulation channel (13). A rotating frame (10) is laterally provided at a middle portion of the inner cavity (2). One end of the rotating frame (10) is driven to rotate by a driving motor (7) at an outer side of the inner cavity (2). An opening is arranged at one side of the inner cavity (2) and a panel (14) capable of being rotatably opened is provided at the opening. The air fryer can rotate food whiling heating the same, such that food is uniformly heated, thereby increasing efficiency of roasting food, and enabling food to be inserted and removed conveniently.

IPC Classes  ?

• A47J 37/04 - Roasting apparatus with movably-mounted food supports or with movable heating implementsSpits

Goods & Services

Deep fryers, electric; [ electric kitchen ranges, gas kitchen ranges; Electric roasters; ] Electric cooking utensils, namely, electric roasters [ ; Hot plates; Roasting apparatus, namely, electric griddle, electric grills; Multi-functional pot, namely, electric cooking pots; Bakers' ovens; Bread baking machines; Fruit roasters; Cookers, , namely, gas cookers, electric slow cookers; Cooking apparatus and installations, namely, cooking stoves; electric toasters, electric toaster ovens; Kettles, electric; Microwave ovens; Bread-making machines ]

Abstract

The present disclosure relates to a drain structure of an air fryer having a steaming function. The air fryer comprises a shell, a cooking cavity located at a lower side of the interior of the shell and a control cavity located at an upper side of the interior of the shell, the control cavity is provided therein with a control panel and a drive motor, the upper side of the shell is provided with a vent in communication with the control cavity, a top portion of the shell is provided with a water tank, the shell is provided therein with a steam generator in communication with the water tank, the steam generator is configured to input steam into the cooking cavity, the water tank is in a structure that is opened at bottom and closed at top, and the water tank is detachably mounted on the shell. The structure of the present disclosure is easy to use, and the water tank needs to be removed to add water, thus effectively preventing overflow risk.

IPC Classes  ?

• A47J 27/04 - Cooking-vessels for cooking food in steamDevices for extracting fruit juice by means of steam
• A47J 37/00 - BakingRoastingGrillingFrying

Abstract

A steam generator for an air fryer with a steaming function is disclosed. The air fryer includes a cooking chamber and a water tank arranged inside a housing. A steam generator is also arranged in the air fryer. A heating chamber is provided in the steam generator. The heating chamber in the steam generator is connected to a water tank via a water pump. High-temperature steam produced in the heating chamber of the steam generator is introduced into the cooking chamber. The steam generator is equipped with an over-temperature protector and a temperature sensor. Each of the over-temperature protector, the temperature sensor, the water pump, and the steam generator is electrically connected to the controller.

IPC Classes  ?

• A47J 27/04 - Cooking-vessels for cooking food in steamDevices for extracting fruit juice by means of steam
• A47J 37/00 - BakingRoastingGrillingFrying
• A47J 44/00 - Multi-purpose machines for preparing food
