Abstract

A plow blade system is adapted for mounting to a vehicle. The system includes a central blade having two transversally opposite ends and a mount for mounting the blade to the vehicle in a configuration where the central blade is orientable transversally to a longitudinal orientation of movement of the vehicle. The system further includes a lateral blade. The system further includes a hinge pivotally coupling a lateral edge of the lateral blade to one of the opposite ends of the central blade about a pivot axis. The hinge has an upper hinge element and a lower hinge element. The upper hinge element is interspaced from the lower hinge element. The lower hinge element has a multi-axis rotary joint.

IPC Classes  ?

• E01H 5/06 - Apparatus propelled by animal or engine powerApparatus propelled by hand with driven dislodging or conveying elements, e.g. conveying pneumatically dislodging essentially by non-driven elements, e.g. scraper blades

Goods & Services

Attachments for vehicles, namely, snow plow blades Attachments for vehicles, namely, land vehicle parts in the nature of pivoting snowplow blade for all types of road surfaces

Goods & Services

Attachments for vehicles, namely, snow plow blades; machines for use in agriculture, namely, an articulated picker transportation module for small fruits and vegetables harvesting, agricultural irrigation, fertilizer distribution, packaging fruits and vegetables and weeding Attachments for vehicles, namely, land vehicle parts in the nature of pivoting snowplow blade for all types of road surfaces; agricultural equipment, namely, a harvester helper in the nature of utility hitch trails designed for use in protecting workers from the elements and transporting harvested fruits and vegetables

Abstract

A mobile harvesting system is towable longitudinally by a vehicle along a field. The mobile harvesting system includes a trailer frame having wheels and a tongue configured for coupling to the vehicle. A harvesting frame is elongated and pivotally mounted to the trailer frame for pivoting between a longitudinal orientation and a transversal orientation. The harvesting frame has a plurality of sleigh attachments distributed along its length. A plurality of harvester sleighs are each coupled to a corresponding one of the sleigh attachments at a corresponding transversal position relative to the trailer frame. Each harvester sleigh has a first runner transversally spaced apart from a second runner, the first runner and the second runner both being longitudinally oriented and structurally interconnected by a sleigh frame.

IPC Classes  ?

• A01D 46/00 - Picking of fruits, vegetables, hops, or the likeDevices for shaking trees or shrubs

Goods & Services

(1) Attachments for vehicles, namely snow blades; agricultural equipment namely an harvester helper; machines for use in agriculture, namely, for agricultural irrigation, fertilizer distribution, harvesting, packaging food, and weeding.

Goods & Services

(1) Attachments for vehicles, namely snow blades.

Abstract

A plow blade securable to a vehicle, has: a central section having: a central panel, and a member secured to the central panel via a transversal rib, the member defining at least one channel; two lateral sections having: lateral panels having lateral and medial edges, the lateral panels defining slots, and beams secured to the lateral panels and protruding from the medial edges, the beams slidably received within the at least one channel; and at least one actuator operatively connected to the central section and the two lateral sections, wherein the two lateral sections are movable relative to the central section between a collapsed configuration and an extended configuration, the two lateral sections being overlapped by the central section in the collapsed configuration and being offset from the central section in the extended configuration, in the collapsed configuration, portions of the transversal rib are received within the slots.

IPC Classes  ?

• E01H 5/06 - Apparatus propelled by animal or engine powerApparatus propelled by hand with driven dislodging or conveying elements, e.g. conveying pneumatically dislodging essentially by non-driven elements, e.g. scraper blades

Abstract

A plow blade system adapted for mounting to a vehicle, the blade system having a blade orientable transversally to a longitudinal orientation of movement of the vehicle and having two opposite ends, and two side wall assemblies; each side wall assembly having a primary sidewall portion mounted to a corresponding end of the blade, the primary sidewall portion extending longitudinally from the corresponding end in a first longitudinal working direction, a sidewall extension slidably mounted to the primary sidewall portion, and a sidewall actuator mounted between the primary sidewall portion and the sidewall extension and operable to selectively slidingly extend the sidewall extension in a second longitudinal working direction opposite to the first longitudinal working direction and retract the sidewall extension within the primary sidewall portion.

IPC Classes  ?

• E01H 5/06 - Apparatus propelled by animal or engine powerApparatus propelled by hand with driven dislodging or conveying elements, e.g. conveying pneumatically dislodging essentially by non-driven elements, e.g. scraper blades
