Abstract

A hand-held observation device includes: a laser rangefinder (LRF) unit configured to measure a distance between the observation device and a target point on a remote target, a camera configured to capture images of the target, a pose detection unit configured to detect a pose of the observation device, a display unit configured to display an image of the target, a user input device and a digital processing unit comprising a memory for storing program data and measurement data. The digital processing unit can receive a measurement request from the user, can receive image data from the camera, can continuously receive pose data from the pose detection unit, can trigger range measurements to target points using the LRF unit, can receive range-measurement data from the LRF unit, can calculate 3D target point coordinates for the target points, can store the 3D target point coordinates in the memory, can compare the stored 3D target point coordinates with the measurement request to determine one or more regions with missing 3D target points coordinates, can continuously-monitor the pose of the observation device based on the pose data, can detect when the measurement axis of the LRF unit aims at a region with missing 3D target point coordinates, and can trigger an additional range measurement for measuring 3D target point coordinates.

IPC Classes  ?

• G01S 17/894 - 3D imaging with simultaneous measurement of time-of-flight at a 2D array of receiver pixels, e.g. time-of-flight cameras or flash lidar
• G01C 3/04 - Adaptation of rangefinders for combination with telescopes or binoculars
• G01C 15/00 - Surveying instruments or accessories not provided for in groups
• G01S 7/51 - Display arrangements
• G01S 17/50 - Systems of measurement based on relative movement of target
• G01S 17/86 - Combinations of lidar systems with systems other than lidar, radar or sonar, e.g. with direction finders

Goods & Services

(1) Dispositifs à infrarouges pour le guidage d'armes; détecteurs; viseurs optiques et optoélectroniques; appareils de vue optiques et optoélectroniques; appareils optiques et optoélectroniques de mesure; appareils et instruments d'observation; jumelles [optique]; télescopes; télémètres à laser; dispositifs de recherche de cibles, de localisation, de surveillance et de poursuite optiques, électroniques et optoélectroniques; lunettes de vision nocturne; logiciels relatifs aux articles mentionnés; pièces et parties constitutives de ces articles compris dans cette classe.

Goods & Services

(1) Dispositifs à infrarouges pour le guidage d'armes; détecteurs; viseurs optiques et optoélectroniques; appareils de vue optiques et optoélectroniques; appareils optiques et optoélectroniques de mesure; appareils et instruments d'observation; jumelles [optique]; télescopes; télémètres à laser; dispositifs de recherche de cibles, de localisation, de surveillance et de poursuite optiques, électroniques et optoélectroniques; lunettes de vision nocturne; logiciels relatifs aux articles mentionnés; pièces et parties constitutives de ces articles compris dans cette classe.

Goods & Services

Infrared devices for guiding weapons; detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus; optical and optoelectronic measuring apparatus; observation apparatus and instruments; binoculars; telescopes; laser range finders; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices; night vision goggles; software relating to the aforesaid articles; parts and components of these articles included in this class.

Goods & Services

Infrared devices for guiding weapons; detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus; optical and optoelectronic measuring apparatus; observation apparatus and instruments; binoculars; telescopes; laser range finders; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices; night vision goggles; software relating to the aforesaid articles; parts and components of these articles included in this class.

Goods & Services

Infrared devices for guiding weapons; Detectors; Optical finders and Optoelectronic finders; Optical and optoelectronic sighting apparatus; optical meters and Optoelectronic measuring apparatus; Observation apparatus and instruments; Binoculars; Telescopes; Laser range finders; Optic, electronic and optoelectronic target seeking, positioning, surveillance and tracking devices; Night vision goggles; Software relating to the aforesaid goods; Parts for the aforesaid goods, included in class 9.

Goods & Services

Infrared devices for guiding weapons; Detectors; Optical finders and Optoelectronic finders; Optical and optoelectronic sighting apparatus; optical meters and Optoelectronic measuring apparatus; Observation apparatus and instruments; Binoculars; Telescopes; Laser range finders; Optic, electronic and optoelectronic target seeking, positioning, surveillance and tracking devices; Night vision goggles; Software relating to the aforesaid goods; Parts for the aforesaid goods, included in class 9.

Goods & Services

Infrared devices for guiding weapons; detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus; optical and optoelectronic measuring apparatus; observation apparatus and instruments; binoculars; telescopes; laser range finders; optical, electronic and optoelectronic target seeking, locating and monitoring devices; night-vision devices; software relating to the aforesaid articles; parts and components of these articles included in this class; navigation and measuring instruments, apparatus and instruments for recording, transmission, reproduction or processing of sound, images or data; downloadable and recorded media; security tokens used as encryption devices for transmitting and installing software; smartwatches, portable activity trackers for locating and tracking movement; virtual reality headsets and smartglasses. Design and development of software; computer system design; Software as a Service [SaaS], computer Platform as a Service [PaaS] especially in connection with military applications in the framework of optoelectronic apparatus, observation apparatus, target acquisition apparatus, laser range finders and laser target markers.

Goods & Services

Infrared devices for guiding weapons; detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus; optical and optoelectronic measuring apparatus; observation apparatus and instruments; binoculars; telescopes; laser range finders; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices; software relating to the aforesaid articles; night-vision devices; parts and components of these articles included in this class.

Goods & Services

Infrared devices, namely, infrared sensors for guiding weapons; infrared and thermal detectors; optical and optoelectronic viewfinders; optical and optoelectronic distance measuring apparatus; observation apparatus and instruments, namely, binoculars; telescopes; laser range finders; optical, electronic and optoelectronic target seeking, locating and monitoring devices, namely, GNSS satellite target trackers, GPS tracking devices; night-vision devices, namely, night vision goggles; downloadable software for detecting, viewing, tracking targets relating to the aforesaid articles; parts and components of these articles included in this class, namely, tripods for telescopes, anti-reflecting devices namely optical filters, power cables; navigation and measuring instruments in the nature of compass, gyroscope, GNSS satellite target trackers and GPS navigation device and instruments for measuring length, and apparatus for recording, transmission, reproduction or processing of sound, images or data; downloadable and recorded media, namely, pre-recorded electronic media devices featuring downloadable digital maps; security token hardware used as encryption devices for transmitting and installing software; smartwatches, and portable wearable activity trackers for locating and tracking movement; virtual reality headsets and smartglasses Design and development of software; computer system design; Software as a Services (SAAS) services featuring software, and computer Platform as a Service (PAAS) featuring computer software platforms for data processing especially in connection with military applications in the framework of optoelectronic apparatus, observation apparatus, target acquisition apparatus, laser range finders and laser target markers

Goods & Services

Infrared devices, namely, infrared sensors for guiding weapons; thermal and infrared detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus, namely, angle viewfinders; optical and optoelectronic distance measuring apparatus; observation apparatus and instruments, namely, binoculars; telescopes; laser range finders; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices, namely, GNSS satellite target trackers and GPS tracking devices; night-vision devices, namely, night vision goggles; parts and components of these articles included in this class, namely, tripods for telescopes, anti-reflecting devices namely optical filters, power cables

Goods & Services

(1) Dispositifs à infrarouges pour le guidage d'armes; détecteurs; viseurs optiques et optoélectroniques; appareils de vue optiques et optoélectroniques; appareils optiques et optoélectroniques de mesure; appareils et instruments d'observation; jumelles [optique]; télescopes; télémètres à laser; dispositifs de recherche de cibles, de localisation, de surveillance et de poursuite optiques, électroniques et optoélectroniques; logiciels relatifs aux articles mentionnés; dispositifs de vision nocturne; pièces et parties constitutives de ces articles compris dans cette classe.

Abstract

The invention pertains to a hand-held observation device comprising : a laser rangefinder (LRF) unit configured to measure a distance between the observation device and a target point on a remote target, a camera configured to capture images of the target, a pose detection unit configured to detect a pose of the observation device, a display unit configured to display (125) an image of the target, a user input device and a digital processing unit comprising a memory for storing programme data and measurement data, wherein the digital processing unit is configured to receive (110) a measurement request from the user, to receive (120) image data from the camera, to continuously receive (130) pose data from the pose detection unit, to trigger (140) range measurements to target points using the LRF unit, to receive (150) range-measurement data from the LRF unit, to calculate (160), based on the pose data and on the range measurement data, 3D target point coordinates for the target points, to store the 3D target point coordinates in the memory, to compare the stored 3D target point coordinates with the measurement request to determine (170) one or more regions with missing 3D target points coordinates, to continuously monitor (180) the pose of the observation device based on the pose data, to detect (190), based on the continuously monitored pose, when the measurement axis of the laser rangefinder unit aims at a region with missing 3D target point coordinates, and to automatically trigger an additional range measurement for measuring 3D target point coordinates in the region the measurement axis aims at.

IPC Classes  ?

• G01C 15/00 - Surveying instruments or accessories not provided for in groups
• G01C 3/04 - Adaptation of rangefinders for combination with telescopes or binoculars

Goods & Services

Infrared devices for guiding weapons; Detectors; Optical finders and Optoelectronic finders; Optical and optoelectronic sighting apparatus; optical meters and Optoelectronic measuring apparatus; Observation apparatus and instruments; Binoculars; Telescopes; Laser range finders; Optic, electronic and optoelectronic target seeking, positioning, surveillance and tracking devices; Night vision goggles; Software relating to the aforesaid goods; Parts for the aforesaid goods, included in class 9.

Goods & Services

Infrared devices for guiding weapons; detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus; optical and optoelectronic measuring apparatus; observation apparatus and instruments; binoculars; telescopes; laser range finders; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices; night-vision devices; software relating to the aforesaid articles; parts and components of these articles included in this class. Planning and placement of advertising; digital and online advertising services; placement of advertising in the media; organization of advertising campaigns and advice relating thereto; creation, development and dissemination of advertising material, marketing material, promotional material and public relations material, including via mobile apparatus, the Internet and other interactive media; marketing agency services; brand marketing; content marketing; e-mail marketing, social marketing, mobile marketing; advertising by computer, smartphone and tablet; online advertising on computer-aided communication networks; compilation of advertisements for use as websites on the Internet; data processing services [office functions]; production of advertising for videos, films, computers, websites on the Internet, mobile devices; providing advertising, including online via websites or via wireless transmission; production of advertising films and image films; organization and conducting of commercial events, media events, events for advertising, promotion and business purposes; financial sponsorship (advertising services) for corporate and brand communication. Repair and maintenance of optical and optoelectronic apparatus and instruments, in particular binoculars and telescopes for night and/or day vision, monocular and binocular aiming devices, target detection and aiming aids.

Goods & Services

Infrared devices for guiding weapons; detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus; optical and optoelectronic measuring apparatus; observation apparatus and instruments; binoculars; telescopes; laser range finders; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices; software relating to the aforesaid articles; night-vision devices; parts and components of these articles included in this class.

Goods & Services

Infrared devices for guiding weapons; detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus; optical and optoelectronic measuring apparatus; observation apparatus and instruments; binoculars; telescopes; laser range finders; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices; night vision goggles; software relating to the aforesaid articles; parts and components of these articles included in this class.

Goods & Services

(1) Dispositifs à infrarouges pour le guidage d'armes; détecteurs; viseurs optiques et optoélectroniques; appareils de vue optiques et optoélectroniques; appareils optiques et optoélectroniques de mesure; appareils et instruments d'observation; jumelles [optique]; télescopes; télémètres à laser; dispositifs de recherche de cibles, de localisation, de surveillance et de poursuite optiques, électroniques et optoélectroniques; dispositifs de vision nocturne; logiciels relatifs aux articles mentionnés; pièces et parties constitutives de ces articles compris dans cette classe. (1) Planification et placement de publicité; services de publicité digitale et en ligne; placement de publicité dans les médias; organisation de campagnes publicitaires et conseils y relatifs; création, développement et diffusion de matériel publicitaire, de matériel de marketing, de matériel promotionnel et de matériel de relations publiques, y compris via des appareils mobiles, l'internet et d'autres médias interactifs; services d'agences de marketing; brand marketing; content marketing; marketing par courrier électronique, marketing social, marketing mobile; publicité par ordinateur, smartphone et tablettes; services de publicité en ligne sur les réseaux de communication assistés par ordinateur; compilation de publicités à utiliser comme sites web sur Internet; services de traitement de données [travaux de bureau]; production de publicité pour vidéo, films, ordinateurs, sites Web sur Internet, dispositifs mobiles; fourniture de publicité, y compris en ligne via des sites web informatiques ou par transmission sans fil; production de films publicitaires et films d'image; organisation et conduite d'évènements commerciaux, d'évènements médiatiques, évènements à des fins de publicité, de promotion et d'affaires; parrainage financier (services de publicité) pour la communication d'entreprise et de marque. (2) Réparation et entretien des appareils et instruments optiques et optoélectroniques, en particulier des jumelles et télescopes pour vision de jour et/ou de nuit, dispositifs à viser, de détection de cibles et d'aide à la visée monoculaires et binoculaires.

Goods & Services

Infrared devices for guiding weapons, namely infrared gun scopes for weapons; radar, infrared and motion detectors ; optical and optoelectronic viewing apparatus, namely, digital photograph viewers, underwater digital photograph viewers, binoculars, telescopes; optical and optoelectronic measuring apparatus, namely optical profiler; observation apparatus and instruments, namely, electronic infrared detectors for observing the infrared spectrum, radar detectors for observation of moving objects; binoculars; telescopes; laser range finders; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices, namely, surveillance devices in the nature of electronic security tags, GPS tracking devices; night vision devices, namely, vision goggles; recorded software relating to the aforesaid articles, namely, for guiding weapons, tracking targets, laser range finders; parts and components of these articles, namely, sonar parts, microscope parts, lenses for telescopes Preparing and placement of advertisements; digital and online advertising services; placement of advertising in the media; advertising services, namely, organization of advertising campaigns and advice relating thereto; creation, development and dissemination of advertising material, marketing material, promotional material and public relations material, all in the nature of advertising material, in particular via mobile phones and the Internet; marketing agency services, namely, marketing services; brand marketing; content marketing; e-mail marketing, social marketing, and mobile marketing services; advertising by computer, smartphone and tablet, namely, online advertising; online advertising on computer-aided communication networks; compilation of advertisements for use as websites on the Internet; data processing services ; production of advertising, namely, production of advertising materials for videos, films, computers, websites on the Internet, mobile devices; providing advertising services, in particular online via websites and via wireless networks for display on mobile devices; production of advertising films; organization and conducting of commercial events, media events, events for advertising, promotion and business purposes Repair and maintenance of optical and optoelectronic apparatus and instruments, in particular binoculars and telescopes for night and/or day vision, monocular and binocular aiming devices, target detection and aiming aids

Goods & Services

(1) Dispositifs à infrarouges pour le guidage d'armes, nommément, radars, capteurs de mouvements infrarouges, lunettes de visées, détecteurs, nommément, capteurs de mouvements et radars de haute précision pour la surveillance aéroportée et terrestre à application civile, viseurs optiques et optoélectroniques, nommément, jumelles monoculaires, appareils de vue optiques et optoélectroniques, nommément, lentilles grossissantes, lasers infrarouges pour la surveillance terrestre, objectifs pour caméras vidéo, appareils optiques et optoélectroniques de mesure, nommément, profileurs optiques, radars de mesure de vitesse pour des applications civiles, appareils et instruments d'observation, nommément, jumelles, télescopes, longue-vue, imageurs thermiques, caméras thermiques, boules optroniques, détecteurs infrarouges électroniques pour l'observation du spectre infrarouge, détecteurs radar pour l'observation d'objets en mouvement, capteurs optiques; télémètres à laser, dispositifs électroniques et optoélectroniques de recherche de cibles, de localisation, de surveillance et de poursuite optiques, électroniques et optoélectroniques, nommément, capteurs de distance, capteurs de position, périscopes, lunettes de visées, télescopes, longue-vue, surveillance terrestre à base d'imagerie radar consistant en des imageurs thermiques, dispositifs de repérage GPS constitués d'ordinateurs, de logiciels, d'émetteurs, de récepteurs et de dispositifs d'interface réseau, lunettes de vision nocturne, logiciels relatifs aux articles mentionnés, nommément, systèmes électroniques de navigation GPS, systèmes de capteurs, à savoir les capteurs de vitesse, capteurs de trajectoire d'objets en mouvement, logiciel informatique de reconnaissance vocale à utiliser dans le cadre de la transmission de la voix, logiciels pour la transmission de données numériques et d'informations pour la surveillance terrestre, pièces et parties constitutives de ces articles compris dans cette classe.

Goods & Services

(1) Dispositifs à infrarouges pour le guidage d'armes; détecteurs; viseurs optiques et optoélectroniques; appareils de vue optiques et optoélectroniques; appareils optiques et optoélectroniques de mesure; appareils et instruments d'observation; jumelles [optique]; télescopes; télémètres à laser; dispositifs de recherche de cibles, de localisation, de surveillance et de poursuite optiques, électroniques et optoélectroniques; logiciels relatifs aux articles mentionnés; dispositifs de vision nocturne; pièces et parties constitutives de ces articles compris dans cette classe.

Goods & Services

Infrared devices for guiding weapons, namely infrared gun scopes for weapons; radar detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus, namely digital photograph viewers, underwater digital photograph viewers; optical and optoelectronic measuring apparatus, namely optical profilers; observation apparatus and instruments, namely electronic infrared detectors for observing the infrared spectrum, radar detectors for observation of moving objects; binoculars; telescopes; laser range finders for cameras; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices, namely surveillance devices in the nature of electronic security tags, GPS tracking devices; night vision apparatus, namely night vision goggles; parts and components of these articles included in this class, namely sonar parts, microscope parts, lenses for telescopes

Goods & Services

Infrared devices namely infrared gun scopes for guiding weapons; radar detectors; optical and optoelectronic viewing apparatus, namely, binoculars and telescopes; optical and optoelectronic measuring apparatus, namely, distance measuring apparatus, rangefinder; observation apparatus and instruments, namely, electronic infrared detectors for observing the infrared spectrum, radar detectors for observation of moving objects; binoculars; telescopes; laser range finders; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices, namely, surveillance devices in the nature of electronic security tags, GPS tracking devices; night-vision devices, namely, night vision goggles, night vision binoculars; downloadable software relating to the aforesaid articles, namely, for guiding weapons, tracking targets, radar detectors; parts and components of these articles included in this class, namely, optical lens sights lenses for telescopes, glass fiber reinforced

Abstract

The inventive Device is comprising a laser rangefinder for determining the distance along a laser axis between the device and a target object. The laser rangefinder is comprising a pumping laser and a thulium and/or holmium doped fiber laser with a thulium and/or holmium doped fiber section and two Bragg gratings arranged on both sides of the thulium and/or holmium doped fiber section of the thulium and/or holmium doped fiber laser wherein the thulium and/or holmium doped fiber laser is pumped by the pumping laser and configured to emit laser light with a wavelength in the range of 1900 nm to 2150 nm. The inventive device has an improved applicability.

IPC Classes  ?

• G01S 7/484 - Transmitters
• G01S 7/481 - Constructional features, e.g. arrangements of optical elements
• H01S 3/00 - Lasers, i.e. devices using stimulated emission of electromagnetic radiation in the infrared, visible or ultraviolet wave range
• H01S 3/067 - Fibre lasers
• H01S 3/094 - Processes or apparatus for excitation, e.g. pumping using optical pumping by coherent light
• H01S 3/0941 - Processes or apparatus for excitation, e.g. pumping using optical pumping by coherent light of a semiconductor laser, e.g. of a laser diode
• H01S 3/16 - Solid materials
• H01S 3/23 - Arrangement of two or more lasers not provided for in groups , e.g. tandem arrangement of separate active media
• H01S 3/1123 - Q-switching
• G01S 17/10 - Systems determining position data of a target for measuring distance only using transmission of interrupted, pulse-modulated waves

Abstract

The invention relates to an observation device having a location determination functionality for the high-accuracy determination of the spatial location and thus the position and orientation (for example, Euler angles: azimuth, elevation angle, and roll angle) of the observation device by analysis of a recorded camera image of the terrain surrounding the camera by means of the three-dimensional map information of a digital terrain model (DTM). For this purpose, the observation device comprises a camera having an objective lens and a camera sensor, a data memory, a sensor system, an analysis unit, and a display screen.

IPC Classes  ?

• G01C 21/06 - NavigationNavigational instruments not provided for in groups by terrestrial means involving measuring of drift angleNavigationNavigational instruments not provided for in groups by terrestrial means involving correction for drift
• G01C 9/08 - Means for compensating acceleration forces due to movement of instrument
• G01C 19/02 - Rotary gyroscopes
• G01C 21/08 - NavigationNavigational instruments not provided for in groups by terrestrial means involving use of the magnetic field of the earth
• G02B 23/18 - HousingsCapsMountingsSupports, e.g. with counterweight for binocular arrangements

Abstract

Optoelectronic measuring device having an electronic magnetic compass and a compensation device assigned to the magnetic compass for compensating device-fixed interference fields and is designed to occupy at least two defined, repeatable operating states and generates a different device-fixed interference field in each of the operating states. The measuring device is designed to occupy at least two defined, repeatable application states, the magnetic compass being exposed to a different external magnetic interference field in each of the application states. The compensation device being designed to measure a first, second and third magnetic field set in a first, second and third overall state of the measuring device, and to determine by means of the processing unit a first, second and third set of parameters based on the first, second and third magnetic field set respectively, and to derive a fourth parameter set based on the first, second and third parameter set.

IPC Classes  ?

• G01C 17/38 - Testing, calibrating, or compensating of compasses
• G01C 17/26 - Observing the compass card or needle using electric pick-offs for transmission to final indicator, e.g. photocell

Abstract

The invention pertains to a hand-held observation device and methods for observing distant targets, comprising at least a first optical observation channel defining a first observation optical axis by receiving and imaging optical light rays onto an image plane for observations of a user, a first eyepiece being arranged at the first optical observation channel, and a laser range finder for determining, along an axis of the laser range finder, a distance between the observation device and a target, wherein at least one light source is adapted to emit light to illuminate a user's eye at the first eyepiece, an image sensor that is adapted to capture images of the eye, and comprises an electronic image processing unit for determining, in real-time, eye parameters that indicate a gazing direction of the user.

IPC Classes  ?

• G01S 17/08 - Systems determining position data of a target for measuring distance only
• G01S 7/497 - Means for monitoring or calibrating
• G01S 7/481 - Constructional features, e.g. arrangements of optical elements
• G01S 7/48 - Details of systems according to groups , , of systems according to group
• G06F 3/01 - Input arrangements or combined input and output arrangements for interaction between user and computer
• G02B 27/64 - Imaging systems using optical elements for stabilisation of the lateral and angular position of the image
• G02B 27/00 - Optical systems or apparatus not provided for by any of the groups ,
• G01C 3/08 - Use of electric radiation detectors
• G01S 17/88 - Lidar systems, specially adapted for specific applications

Abstract

The invention relates to an observation device comprising a laser rangefinder, wherein the laser rangefinder is controllable by the eye of a user of the hand-held observation device. In particular, said eye-control of the rangefinder also pertains to controlling an opto-mechanical stabilization unit of the device for actively and equally stabilizing both transmitter and receiver channels of the integrated laser rangefinder.

IPC Classes  ?

• A61B 3/113 - Objective types, i.e. instruments for examining the eyes independent of the patients perceptions or reactions for determining or recording eye movement
• B81B 7/02 - Microstructural systems containing distinct electrical or optical devices of particular relevance for their function, e.g. microelectro-mechanical systems [MEMS]
• G01S 17/08 - Systems determining position data of a target for measuring distance only
• G02B 23/00 - Telescopes, e.g. binocularsPeriscopesInstruments for viewing the inside of hollow bodiesViewfindersOptical aiming or sighting devices

Goods & Services

Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signaling, checking (supervision), emergency (life-saving) and teaching apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; apparatus for recording, transmission or reproduction of sound or images; data processing equipment, computer software; optoelectronic apparatus and instruments and modules for observing and measuring distance, angles and positions; optical and optoelectronic apparatus and instruments; infrared optical apparatus; infrared detectors; infrared devices for guiding weapons; optical, electronic, electro-optical and photoelectric sensors; detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus; optical and optoelectronic measuring apparatus; observation apparatus and instruments; surveying apparatus and instruments; binoculars; telescopes; laser range finders; goniometers; theodolites; navigation apparatus and instruments; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices; directional compasses; electronic turn signals; night vision apparatus; light amplification apparatus; night vision goggles; thermal imaging apparatus [other than for medical use]; periscopes; image processing apparatus; parts and components of these articles included in this class.

Goods & Services

Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signaling, checking (supervision), emergency (life-saving) and teaching apparatus and instruments; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity; apparatus for recording, transmission or reproduction of sound or images; data processing equipment, computer software; optoelectronic apparatus and instruments and modules for observing and measuring distance, angles and positions; optical and optoelectronic apparatus and instruments; infrared optical apparatus; infrared detectors; infrared devices for guiding weapons; optical, electronic, electro-optical and photoelectric sensors; detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus; optical and optoelectronic measuring apparatus; observation apparatus and instruments; surveying apparatus and instruments; binoculars; telescopes; laser range finders; goniometers; theodolites; navigation apparatus and instruments; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices; directional compasses; electronic turn signals; night vision apparatus; light amplification apparatus; night vision goggles; thermal imaging apparatus [other than for medical use]; periscopes; image processing apparatus; parts and components of these articles included in this class.

Abstract

Disclosed is an optoelectronic measuring device having an electronic magnetic compass for determining an azimuthal alignment of the measuring device and a compensation unit, which is associated with the magnetic compass, for compensating for device-fixed interference fields, wherein the measuring device assumes at least two defined, repeatable operating states, has a different device-fixed interference field in each of the operating states, and the compensation unit carries out an initial compensation of the electronic magnetic compass in a first operating state of the measuring device, wherein the compensation unit has a detection unit for detecting a present operating state, a memory unit for storing a magnetic offset resulting from the different device-fixed interference fields between the first and a second operating state of the measuring device, and a computer unit for computing the azimuthal alignment of the measuring device depending on an ascertained operating state and based on the magnetic offset.

IPC Classes  ?

• G01B 11/27 - Measuring arrangements characterised by the use of optical techniques for measuring angles or tapersMeasuring arrangements characterised by the use of optical techniques for testing the alignment of axes for testing the alignment of axes
• G01C 17/38 - Testing, calibrating, or compensating of compasses
• G01C 21/08 - NavigationNavigational instruments not provided for in groups by terrestrial means involving use of the magnetic field of the earth
• G01V 7/06 - Analysis or interpretation of gravimetric records

Abstract

The invention relates to an optoelectronic measuring device (1) having an electronic magnetic compass (10) for determining an azimuthal alignment of the measuring device and a compensation unit, which is associated with the magnetic compass, for compensating for device-fixed interference fields, wherein the measuring device is designed for the purpose of assuming at least two defined, repeatable operating states, wherein the measuring device has a different device-fixed interference field in each of the operating states, and the compensation unit has a compensation functionality for carrying out an initial compensation of the electronic magnetic compass in a first operating state of the measuring device, characterized in that the compensation unit has a detection unit for detecting a present operating state of the measuring device, a memory unit for storing a magnetic offset (13) resulting from the different device-fixed interference fields between the first operating state and a second operating state of the measuring device, and a computer unit for computing the azimuthal alignment of the measuring device depending on an ascertained operating state and based on the magnetic offset.

IPC Classes  ?

• F41G 3/06 - Aiming or laying means with rangefinder
• F41G 11/00 - Details of sighting or aiming apparatusAccessories
• G01C 17/38 - Testing, calibrating, or compensating of compasses
• G01S 19/05 - Cooperating elementsInteraction or communication between different cooperating elements or between cooperating elements and receivers providing aiding data

Goods & Services

Scientific, nautical, surveying, photographic, cinematographic, optical, weighing, measuring, signaling, supervision checking, emergency life saving and teaching apparatus and instruments, namely pressure measuring apparatus, sensing and signaling devices for measurement and quality control of materials processing by laser; apparatus and instruments for conducting, switching, transforming, accumulating, regulating or controlling electricity, namely electrical controlling devices, electric control panels; apparatus for recording, transmission or reproduction of sound or images; data processing equipment; computer software for use as a spreadsheet, word processing, and software for operating optoelectronic measuring devices; optoelectronic apparatus and instruments and modules for observing and measuring distance, angles and positions, namely optoelectronic measuring devices for creating touch or gesture-sensitive surfaces that interact with computer and other technology systems; optical and optoelectronic apparatus and instruments, namely optical inspection apparatus for industrial use; infrared optical apparatus, namely infrared optical detection apparatus; infrared detectors; infrared devices for guiding weapons, namely infrared gun scopes for weapons; optical, electronic, electrooptical and photoelectric sensors for measuring solar radiation; radar detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus, namely digital photograph viewers, underwater digital photograph viewers; optical and optoelectronic measuring apparatus, namely optical profilers; observation apparatus and instruments, namely electronic infrared detectors for observing the infrared spectrum; surveying apparatus and instruments, namely surveying machines and instruments; binoculars; telescopes; laser range finders for cameras; goniometers; theodolites; electronic navigational apparatus and instruments; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices, namely surveillance devices in the nature of electronic security tags, GPS tracking devices; directional compasses; electronic turn signals, namely electronic turn signal relays; night vision apparatus, namely night vision goggles; light amplification apparatus, namely light amplification image intensifiers; thermal imaging apparatus other than for medical use, namely thermal imaging cameras; periscopes; image processing apparatus, namely raster image processors; parts and components of these articles included in this class, namely sonar parts, microscope parts, lenses for telescopes

Goods & Services

[ Infrared devices for guiding weapons, namely infrared gun scopes for weapons; radar detectors; ] optical and optoelectronic viewfinders; [ optical and optoelectronic viewing apparatus, namely digital photograph viewers, underwater digital photograph viewers; ] optical and optoelectronic measuring apparatus, namely optical profilers; [ observation apparatus and instruments, namely electronic infrared detectors for observing the infrared spectrum, radar detectors for observation of moving objects ] ; binoculars; telescopes; laser range finders for cameras; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices, namely surveillance devices in the nature of electronic security tags [ , GPS tracking devices ] ; [ night vision apparatus, namely night vision goggles; ] parts and components of these articles included in this class, namely sonar parts, microscope parts, lenses for telescopes

Goods & Services

(1) Infrared devices for guiding weapons, namely infrared gun scopes for weapons; radar detectors; optical and optoelectronic viewfinders; optical and optoelectronic viewing apparatus, namely digital photograph viewers, underwater digital photograph viewers; optical and optoelectronic measuring apparatus, namely optical profilers; observation apparatus and instruments, namely electronic infrared detectors for observing the infrared spectrum, radar detectors for observation of moving objects; binoculars; telescopes; laser range finders for cameras; electronic and optoelectronic target seeking, locating, surveillance and optical tracking devices, namely surveillance devices in the nature of electronic security tags for goods, GPS tracking devices consisting of computers, computer software, transmitters, receivers, and network interface devices; night vision apparatus, namely night vision goggles; parts and components of these articles included in this class, namely sonar parts, microscope parts, lenses for telescopes.

Abstract

The invention relates to a hand-held observation device. The observation device is characterized in that a first observation channel comprises a first opto-mechanical stabilization unit for actively and equally stabilizing, during an observation, a first observation optical axis and an LRF axis of an integrated laser range finder by compensating for hand jitter during the observation, the first opto-mechanical stabilization unit being adapted for continuously adjusting and setting a lateral position (with respect to the optical axis) of at least one lens of the objective optical system of the first optical observation channel, in a way automatically controlled by an electronic processing and control unit, which reads and processes the gyro sensor data, particularly in a way wherein the adjusting of the lateral position of the at least one lens equally stabilizes the first observation optical axis and the LRF axis in one go.

IPC Classes  ?

• G01C 3/04 - Adaptation of rangefinders for combination with telescopes or binoculars
• G01S 17/08 - Systems determining position data of a target for measuring distance only
• G02B 27/64 - Imaging systems using optical elements for stabilisation of the lateral and angular position of the image
• G01C 3/08 - Use of electric radiation detectors

Abstract

The invention relates to a hand-held observation device (1). The observation device is characterized in that a first observation channel (20) comprises a first opto-mechanical stabilization unit (22A) for actively and equally stabilizing, during an observation, a first observation optical axis (40) and an LRF axis (3A) of an integrated laser range finder by compensating for hand- jitter during the observation, the first opto-mechanical stabilization unit (22A) being adapted for continuously adjusting and setting a lateral position (with respect to the optical axis) of at least one lens (23A) of the objective optical system of the first optical observation channel (20), in a way automatically controlled by an electronic processing and control unit (50), which reads and processes the gyro sensor data, particularly in a way wherein the adjusting of the lateral position of the at least one lens (23A) equally stabilizes the first observation optical axis (40) and the LRF axis (3A) in one go.

IPC Classes  ?

• G01S 7/481 - Constructional features, e.g. arrangements of optical elements
• G01S 17/08 - Systems determining position data of a target for measuring distance only

Abstract

The invention relates to a method (100) for monitoring the accuracy of the azimuthal orientation of a handheld optoelectronic measuring device to be determined (110) by means of an electronic magnetic compass, including an automatic ascertainment (120) of an estimated accuracy value by the measuring device based on measured data of the magnetic compass, characterized by a safety check (200), within the scope of which a probability that the estimated accuracy value meets a previously determined (140) accuracy criterion is automatically ascertained (220) by the measuring device, and the ascertained probability is provided (230) to a user as a return value. The invention also relates to a handheld optoelectronic measuring device including an electronic magnetic compass for carrying out the method according to the invention.

IPC Classes  ?

• G01C 25/00 - Manufacturing, calibrating, cleaning, or repairing instruments or devices referred to in the other groups of this subclass
• F41G 3/02 - Aiming or laying means using an independent line of sight
• F41G 3/06 - Aiming or laying means with rangefinder
• F41G 3/32 - Devices for testing or checking
• G01B 21/00 - Measuring arrangements or details thereof, where the measuring technique is not covered by the other groups of this subclass, unspecified or not relevant
• G01C 3/08 - Use of electric radiation detectors
• G01C 17/02 - Magnetic compasses
• G01C 17/38 - Testing, calibrating, or compensating of compasses
• G08B 3/10 - Audible signalling systemsAudible personal calling systems using electric transmissionAudible signalling systemsAudible personal calling systems using electromagnetic transmission
• G08B 6/00 - Tactile signalling systems, e.g. personal calling systems
• G08B 29/14 - Checking intermittently signalling or alarm systems checking the detection circuits
• G08B 31/00 - Predictive alarm systems characterised by extrapolation or other computation using updated historic data

Abstract

The invention relates to an optoelectronic distance measuring device having a transmitting unit having a driver stage for a light source for emitting optical pulses as pulsed-mode-intensity-modulated optical radiation, having a receiving unit for receiving a portion of the optical radiation, said portion being reflected from a target object, and converting it into an electrical reception signal, by means of a photosensitive electrical component. It also has an analogue-digital converter for digitizing the reception signal, and an electronic evaluation unit which is designed in such a way that a distance from the target object can be ascertained on the basis of a signal propagation time using the digitized reception signal.

IPC Classes  ?

• G01C 3/08 - Use of electric radiation detectors
• G01S 17/10 - Systems determining position data of a target for measuring distance only using transmission of interrupted, pulse-modulated waves
• G01S 7/484 - Transmitters
• G01S 7/486 - Receivers

Abstract

The invention relates to a handheld observation device including a digital magnetic compass for measuring a magnetic field direction of a magnetic field present, a gravitation sensor for measuring a gravitational field direction of a gravitational field present, and a control and evaluation unit configured for determining an externally referenced orientation of the observation device depending on a measured magnetic field direction and a measured gravitational field direction and with application of an algorithmic disturbance suppression, for which compensation parameters are stored. The observation device can also include a video tracking system (4) for recording an image sequence and for deriving orientation changes of the observation device.

IPC Classes  ?

• G01C 17/38 - Testing, calibrating, or compensating of compasses
• H04N 7/18 - Closed-circuit television [CCTV] systems, i.e. systems in which the video signal is not broadcast
• G01C 17/02 - Magnetic compasses
• G06T 7/70 - Determining position or orientation of objects or cameras

Abstract

The invention relates to a portable observation device having an observation path for optical targeting of a target object, and comprising an optoelectronic rangefinder for measuring the distance in the direction of the targeting. The rangefinder includes a transmission unit for emitting a temporal sequence of pulses of optical radiation, a reception unit for receiving a portion of the optical radiation cast back by the target object and for determining signal information and an electronic evaluation unit, which a distance to the target object can be determined on the basis of a signal travel time between emission and reception of the optical radiation. When a trigger is actuated manually, the distance is determined including the signal information from a specified minimum number of pulses, which define a minimum length of a time window of the distance measurement.

IPC Classes  ?

• G01S 17/10 - Systems determining position data of a target for measuring distance only using transmission of interrupted, pulse-modulated waves
• G01S 17/02 - Systems using the reflection of electromagnetic waves other than radio waves
• F41G 3/06 - Aiming or laying means with rangefinder
• F41G 3/02 - Aiming or laying means using an independent line of sight
• G01S 7/484 - Transmitters
• G01S 7/497 - Means for monitoring or calibrating
• G01C 15/00 - Surveying instruments or accessories not provided for in groups

Abstract

The invention relates to a method for a field compensation of an electronic compass for influences to a geomagnetic field by magnetic objects in the vicinity of the compass, that is done with acquiring a magnetic field value by a magnetic field sensor and acquiring an inclination with respect to level plane by an accelerometer, in a discrete set of multiple orientations of the compass. Therein, a user guidance for subsequently orienting the compass into a predetermined desired range of orientation is provided to the user. In the following, compensation data are calculated from those magnetic sensor acquisitions to compensate for the influences in such a way, that a magnetic north heading is determinable based on the compensated magnetic field values. Therein, the user guidance for the compensation is done with a gathering of directional information based on rotary rate readings from a gyroscope for an azimuthal component of the orientation.

IPC Classes  ?

• G01C 17/38 - Testing, calibrating, or compensating of compasses
• G01C 17/28 - Electromagnetic compasses
