ThyssenKrupp AG

Germany

Back to Profile

1-100 of 5,044 for ThyssenKrupp AG and 24 subsidiaries Sort by
Query
Aggregations
IP Type
        Patent 4,377
        Trademark 667
Jurisdiction
        World 3,558
        United States 1,112
        Europe 216
        Canada 158
Owner / Subsidiary
[Owner] ThyssenKrupp AG 3,246
ThyssenKrupp Presta AG 1,102
ThyssenKrupp Steel Europe AG 952
ThyssenKrupp Industrial Solutions AG 636
Atlas Elektronik GmbH 396
See more
Date
New (last 4 weeks) 17
2025 May (MTD) 11
2025 April 19
2025 March 19
2025 February 20
See more
IPC Class
B62D 5/04 - Power-assisted or power-driven steering electrical, e.g. using an electric servo-motor connected to, or forming part of, the steering gear 297
C22C 38/04 - Ferrous alloys, e.g. steel alloys containing manganese 198
C22C 38/02 - Ferrous alloys, e.g. steel alloys containing silicon 185
C22C 38/06 - Ferrous alloys, e.g. steel alloys containing aluminium 166
B62D 1/19 - Steering columns yieldable or adjustable, e.g. tiltable incorporating energy-absorbing arrangements, e.g. by being yieldable or collapsible 154
See more
NICE Class
09 - Scientific and electric apparatus and instruments 306
42 - Scientific, technological and industrial services, research and design 286
12 - Land, air and water vehicles; parts of land vehicles 264
06 - Common metals and ores; objects made of metal 255
07 - Machines and machine tools 252
See more
Status
Pending 234
Registered / In Force 4,810
  1     2     3     ...     51        Next Page

1.

SAMPLE COLLECTOR FOR AN OXYFUEL PROCESS


Application Number EP2024081408
Publication Number 2025/099107
Status In Force
Filing Date 2024-11-07
Publication Date 2025-05-15
Owner
  • THYSSENKRUPP POLYSIUS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Kimmig, Constantin
  • Sattler, René
  • Rickert, Peter
  • Drepper, Michael

Abstract

The present invention relates to a sample collector 10 for heat treatment of mineral material, wherein the sample collector 10 has a cylindrical tube 30, wherein the tube 30 is designed to pass through a wall of a heat treatment device, wherein a sample container 40 is arranged in the cylindrical tube 30 and is movable in the longitudinal direction of the tube 30, wherein the sample container 40 has, at least on the side facing the outside, a circular cross section 42 perpendicular to the axis of the tube 30 and closes the tube 30, wherein the sample container 40 is connected to a rod element 50 arranged in the longitudinal direction of the tube 30, wherein the rod element 50 is designed to move the sample container 40, wherein the tube 30 has, in the outer region, a connector piece 60 arranged on the underside, wherein the connector piece 60 can receive a laboratory sample container 70 or can be connected thereto, wherein the sample container 40, in a first rotation position and arranged above the connector piece 60, is designed to close the connector piece 60, and wherein the sample container 40, in a second rotation position, which is rotated 180° about the longitudinal axis of the tube 30 with respect to the first rotation position, and arranged above the connector piece 60, is designed to empty into the connector piece 60.

IPC Classes  ?

  • C04B 7/36 - Manufacture of hydraulic cements in general
  • G01N 1/20 - Devices for withdrawing samples in the liquid or fluent state for flowing or falling materials
  • G01N 1/44 - Sample treatment involving radiation, e.g. heat
  • G01N 1/12 - DippersDredgers
  • G01N 1/10 - Devices for withdrawing samples in the liquid or fluent state

2.

PARALLEL-FLOW REGENERATIVE SHAFT KILN AND METHOD FOR BURNING CARBONATE ROCK


Application Number EP2024080727
Publication Number 2025/098857
Status In Force
Filing Date 2024-10-30
Publication Date 2025-05-15
Owner
  • MAERZ OFENBAU AG (Switzerland)
  • THYSSENKRUPP POLYSIUS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor Piringer, Hannes

Abstract

The invention also relates to a parallel-flow regenerative (PFR) shaft kiln (1) for burning and cooling material, such as carbonate rock, said kiln having two shafts (2) which can be operated alternately as a combustion shaft (2a) and a regenerative shaft (2b) and are connected to each other by means of a connecting channel (19), wherein: each shaft (2) has, in the flow direction of the material, a preheating zone (21) for preheating the material, a combustion zone (20) for burning the material and a cooling zone (22) for cooling the material; each shaft (2) has a waste gas outlet (6) for discharging waste gas from the shaft (2); and the PFR shaft kiln (1) has at least one cooling gas duct (44) for conducting cooling gas from the cooling zone (22) to the preheating zone (21). The invention also relates to a method for burning material, such as carbonate rock, in a parallel-flow regenerative shaft kiln (1) with two shafts (2) which are operated alternately as a burning shaft and a regenerative shaft and are connected to each other by means of a connecting channel (19), wherein: the material flows through a material inlet (3) into a preheating zone (21) for preheating the material, a combustion zone (20) for burning the material and a cooling zone (22) for cooling the material in order to reach a material outlet (40); a cooling gas is introduced into the cooling zone; waste gas is discharged from one of the shafts (2) via an exhaust gas outlet (6); and the cooling gas is conducted to the preheating zone (21) via a cool gas duct (44).

IPC Classes  ?

  • F27B 1/00 - Shaft or like vertical or substantially vertical furnaces
  • F27B 1/02 - Shaft or like vertical or substantially vertical furnaces with two or more shafts or chambers, e.g. multi-storey
  • F27B 1/22 - Arrangements of heat-exchange apparatus
  • F27B 15/00 - Fluidised-bed furnacesOther furnaces using or treating finely-divided materials in dispersion
  • F27B 15/10 - Arrangements of air or gas supply devices
  • C04B 2/12 - Preheating, burning, calcining or cooling in shaft or vertical furnaces
  • F27B 1/10 - Details, accessories or equipment specially adapted for furnaces of these types
  • F27D 17/10 - Arrangements for using waste heat

3.

STABILIZER BAR CLAMP FOR SECURING A VEHICLE STABILIZER TO A VEHICLE


Application Number EP2025055222
Publication Number 2025/099329
Status In Force
Filing Date 2025-02-26
Publication Date 2025-05-15
Owner
  • THYSSENKRUPP FEDERN UND STABILISATOREN GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor Hegeler, André

Abstract

The invention relates to a stabilizer bar clamp for securing a vehicle stabilizer to a vehicle. The stabilizer bar clamp has a lateral ribbed structure and a receptacle for a stabilizer bearing, and the stabilizer bar clamp consists predominantly of plastics or fiber-reinforced plastics. The lateral ribbed structure and the receptacle for the stabilizer bearing are removed from the mold entirely laterally, the lateral removal being axial in relation to the receptacle for the stabilizer bearing.

4.

AMMONIA SYNTHESIS AND UREA SYNTHESIS WITH REDUCED CO2 FOOTPRINT


Application Number 18729832
Status Pending
Filing Date 2023-01-19
First Publication Date 2025-05-15
Owner
  • thyssenkrupp Uhde GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Kessler, Frederick
  • Makhynya, Yevgeny

Abstract

The present invention relates to a plant for the synthesis of ammonia, wherein the plant includes at least one reformer for converting a hydrocarbon into hydrogen, wherein the plant includes a converter for converting hydrogen and nitrogen into ammonia, wherein the converter is integrated into a recirculation loop, wherein a first carbon dioxide separator is arranged between the reformer and the recirculation loop, wherein the recirculation loop includes an ammonia separator.

IPC Classes  ?

  • C01C 1/04 - Preparation of ammonia by synthesis
  • C01B 3/02 - Production of hydrogen or of gaseous mixtures containing hydrogen
  • C07C 273/04 - Preparation of urea or its derivatives, i.e. compounds containing any of the groups the nitrogen atoms not being part of nitro or nitroso groups of urea, its salts, complexes or addition compounds from carbon dioxide and ammonia

5.

Your Maritime Powerhouse


Application Number 019184462
Status Pending
Filing Date 2025-05-09
Owner
  • thyssenkrupp AG (Germany)
  • thyssenkrupp Marine Systems GmbH (Germany)
NICE Classes  ?
  • 09 - Scientific and electric apparatus and instruments
  • 12 - Land, air and water vehicles; parts of land vehicles
  • 13 - Firearms; explosives
  • 37 - Construction and mining; installation and repair services
  • 41 - Education, entertainment, sporting and cultural services
  • 42 - Scientific, technological and industrial services, research and design

Goods & Services

Wissenschaftliche, Forschungs-, Navigations-, Vermessungs-, fotografische, Film-, audiovisuelle, optische, Wäge-, Mess-, Signal-, Detektions-, Prüf-, Kontroll-, Rettungs- und Unterrichtsapparate und -instrumente; Geräte und Instrumente zur Aufzeichnung, Übertragung, Wiedergabe oder Verarbeitung von Ton, Bild oder Daten; aufgezeichnete und herunterladbare Medien, Computersoftware, leere digitale oder analoge Aufzeichnungs- und Speichermedien; Computer und Computerperipheriegeräte; elektrotechnische Bauteile; Datenlogger und Datenschreiber; Software; Datenverarbeitungs-Software; Antennen; elektroakustische Bauteile; Rundfunkgeräte; Software zur Überwachung, Analyse, Steuerung und Ausführung von Vorgängen in der physischen Welt; Echolote; Echolotgeräte; Akustische und optische Ortungs-, Mess-, Such- und Steuerungsgeräte; Radarinstrumente; Radargeräte; Funkortungsgeräte; Signalgeräte für elektromagnetische Wellen; Funksendegeräte; Funkempfangsgeräte; Ultraschallmessgeräte; Ortungsgeräte; Simulatoren; Interaktive Computersysteme; Mess-, Erkennungs-, Überwachungs- und Kontrollgeräte; Datenträger; Sensoren; Detektoren sowie Überwachungsinstrumente und -apparate; Monitore; Zielortungsgeräte; Zielsuchgeräte; Zielüberwachungsapparate; Sichtgeräte; Wärmebildgeräte (ausgenommen für medizinische Zwecke); Geräte zur Schadstofferfassung und Schadstoffanalyse in Meeren und Binnengewässern; Sonare; Sonargeräte; Sonaranlagen und Teile hiervon; Bildcompiler; Bedienungskonsolen; Minendetektoren; Simulatoren für die Lenkung und die Kontrolle von Wasserfahrzeugen; Unterwasserortungsgeräte; Navigations- und Steuersysteme für Schiffe; Autopiloten; Überwachungseinrichtungen zur Eisbergdetektion; Lotungsgeräte; Lasergeräte für nicht medizinische Zwecke; Immersionssensoren und Druckmessgeräte für Unterwasserfahrzeuge; GPS-Systeme für maritime Anwendungen; Kommunikationstechnik für den maritimen Einsatz; Überwasserschiffsysteme und -technologien; Künstliche Intelligenz-Systeme für die Automatisierung und Optimierung von maritimen Operationen; Erweiterte Virtual- und Augmented-Reality-Systeme für Trainings- und Simulationszwecke; Drohnentechnologie zur Überwachung und Inspektion maritimer Einrichtungen. Apparate zur Beförderung auf dem Wasser; Wasserfahrzeuge (Boote und Schiffe) und deren Teile; Unterwasserfahrzeuge und deren Teile; Unterseeboote, Unterseefahrzeuge, und deren Teile; Antriebe für Wasserfahrzeuge und Unterwasserfahrzeuge; Antriebseinheiten für Wasserfahrzeuge und Unterwasserfahrzeuge; Unbemannte Wasserfahrzeuge und Unterwasserfahrzeuge und deren Teile; Unterwasservehikel und -drohnen; Schiffskomponenten; Steuerungssysteme für Schiffsantriebe; Spezialisierte maritime Sicherheits- und Rettungsfahrzeuge; Fregatten, Korvetten, Patrouillenschiffe und Unterstützungsschiffe für maritime Einsätze; Hybrid- und Elektroantriebssysteme für Wasserfahrzeuge zur Reduzierung von Emissionen; Autonome Oberflächenfahrzeuge für Forschungs- und Überwachungsaufgaben; Modulare Fahrzeugkomponenten für Wasserfahrzeuge. Munition und Geschosse; Sprengstoffe; Schwere Geschütze; Torpedos; Torpedoträger; Torpedos mit Sprengköpfen zur U-Boot-Abwehr; Torpedoträger für Schiffe zur U-Boot-Abwehr; Minen (Sprengkörper); Sprengsätze zum Räumen von Minenfeldern. Installationsarbeiten und Reparaturdienstleistungen von Wasserfahrzeugen, Unterwasserfahrzeugen, Unterseebooten und Torpedos; Wartungsarbeiten und Instandsetzungsdienstleistungen von Wasserfahrzeugen, Unterwasserfahrzeugen, Unterseebooten und Torpedos; Umbauten von Wasserfahrzeugen; Installation, Wartung und Reparatur von Computer-Hardware und Telekommunikationsgeräten; Reparatur und Wartung von Datenverarbeitungsgeräten und Geräten der Nachrichtentechnik. Schiffsumbauten und -modifikationen; Dienstleistungen für die Demontage von Schiffen und maritimen Strukturen; Bereitstellung von Dock- und Trockendockanlagen; Dienstleistungen zur Modernisierung und zum Retrofitting älterer Schiffe und Unterwasserfahrzeuge; Reinigungsdienste speziell für Unterwasser- und Marineanlagen; Umweltsanierungsdienste in Meeres- und Binnengewässern. Ausbildung und Unterhaltung; Aus- und Weiterbildung im Bereich Schiffbau und Schiffsbedienung; Organisation und Durchführung von Seminaren, Workshops und Konferenzen im maritimen Bereich; Simulationstraining für maritime Notfallsituationen; Spezialisierte Trainingsangebote für Marinepersonal, auch in virtuellen Umgebungen. Konstruktionsdienstleistungen für den Bau von Wasserfahrzeugen und Unterwasserfahrzeugen; Konzeption und Entwicklung von Software und Hardware für die Signalverstärkung und -übertragung; Entwicklung, Programmierung und Implementierung von Software; Entwicklung von Computerhardware; Hosting-Dienste, Software as a Service [SaaS]; Prüfung, Authentifizierung und Qualitätskontrolle; Durchführung von Messungen in Bezug auf Wasserfahrzeuge und Unterwasserfahrzeuge; Beratungsdienstleistungen für den Entwurf von Wasserfahrzeugen und Unterwasserfahrzeugen; Erstellung technischer Gutachten in Bezug auf Wasserfahrzeuge und Unterwasserfahrzeuge; Entwurf, Entwicklung und Aktualisierung von Computersoftware in Bezug auf Wasserfahrzeuge und Unterwasserfahrzeuge; technologische Beratungs- und Planungsdienstleistungen in Bezug auf Wasserfahrzeuge und Unterwasserfahrzeuge; lngenieurdienstleistungen in Bezug auf Wasserfahrzeuge und Unterwasserfahrzeuge; Forschungs- und Entwicklungsdienstleistungen und Beratung auf dem Gebiet der Meerestechnik; technische Überwachung und Inspektion in Bezug auf Wasserfahrzeuge und Unterwasserfahrzeuge; Entwurf von Wasserfahrzeugen; Beratung in Bezug auf Umweltschutztechnologien im maritimen Bereich; Durchführung von Umweltverträglichkeitsstudien im maritimen Sektor; Bereitstellung von Cloud-basierten Lösungen für maritime Operationsmanagement-Systeme; Energiemanagement- und Effizienzberatung für maritime Einrichtungen; Entwicklung und Design maritimer Technologien und Systeme; Entwicklung und Integration von Umweltüberwachungssystemen für maritime Ökosysteme; Forschungsdienstleistungen im Bereich der Tiefsee-Technologie und -exploration; Beratungsdienste für die Einführung und Umsetzung von Nachhaltigkeitspraktiken in maritimen Operationen.

6.

AMMONIA SYNTHESIS AND UREA SYNTHESIS WITH REDUCED CO2 FOOTPRINT


Application Number 18729850
Status Pending
Filing Date 2023-01-19
First Publication Date 2025-05-08
Owner
  • thyssenkrupp Uhde GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Kessler, Frederick
  • Makhynya, Yevgeny

Abstract

The present invention relates to an apparatus for synthesis of ammonia, in which the gases formed on the burner side of the primary reformer are used at least partly as reactants.

IPC Classes  ?

  • C01C 1/04 - Preparation of ammonia by synthesis
  • C01B 3/02 - Production of hydrogen or of gaseous mixtures containing hydrogen
  • C01B 3/36 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents using oxygen or mixtures containing oxygen as gasifying agents
  • C07C 273/10 - Preparation of urea or its derivatives, i.e. compounds containing any of the groups the nitrogen atoms not being part of nitro or nitroso groups of urea, its salts, complexes or addition compounds combined with the synthesis of ammonia

7.

METHOD FOR CONTROLLING THE WHEEL SLIP OF A MOTOR VEHICLE, CONTROL UNIT AND MOTOR VEHICLE


Application Number 18933441
Status Pending
Filing Date 2024-10-31
First Publication Date 2025-05-08
Owner
  • thyssenkrupp Presta AG (Liechtenstein)
  • thyssenkrupp AG (Germany)
Inventor Lapis, Leonard

Abstract

A method for controlling wheel slip of a motor vehicle having at least two wheels, an electromechanical braking system, an electric drive system, and a steer-by-wire steering system comprises: converting a target trajectory of the motor vehicle into a target movement of the motor vehicle; determining wheel-specific target longitudinal and target transverse slip values for the wheels based on the target movement using a vehicle and tyre model; and adjusting actual longitudinal and actual transverse slip values of the wheels to the respective target longitudinal and target transverse slip values by the electromechanical brake system and the electric drive system as a function of a steering angle of the steer-by-wire steering system. A motor vehicle may include a control unit designed to carry out such a method.

IPC Classes  ?

  • B60W 30/02 - Control of vehicle driving stability
  • B60W 10/184 - Conjoint control of vehicle sub-units of different type or different function including control of braking systems with wheel brakes
  • B60W 10/20 - Conjoint control of vehicle sub-units of different type or different function including control of steering systems

8.

HUB ASSEMBLY FOR A WIND TURBINE


Application Number EP2024080825
Publication Number 2025/093679
Status In Force
Filing Date 2024-10-31
Publication Date 2025-05-08
Owner
  • THYSSENKRUPP ROTHE ERDE GERMANY GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Becker, Daniel
  • Töfke, Matthias
  • Burtchen, Marco
  • Neidnicht, Martin

Abstract

The invention relates to a hub assembly (1) for a wind turbine, comprising: a hub body (2), with at least one connection surface (3) in which a first hole circle (4) is formed; a blade-side extender bearing unit (5) comprising a first bearing ring (6) with a second hole circle (7) which is aligned to the first hole circle (4) and a second bearing ring (8) for fastening to a rotor blade of the wind turbine, wherein the second bearing ring (8) is arranged coaxially to the first bearing ring (6) so as to be rotatable about the common bearing axis; and a hub-side extender bearing unit (9), wherein the hub body (2) is screwed to the first bearing ring (6) via the first and the second hole circle (4, 7) and wherein the hub-side extender bearing unit (9) comprises at least two tabs (10) which each extend over a circumferential portion of the hole circles (4, 7) and have a corresponding hole circle arc which is aligned to the hole circles (4, 7), wherein the tabs (10) are inserted in the screw connection of the hub body (2) with the first bearing ring (6).

IPC Classes  ?

9.

clean2hem


Application Number 019181427
Status Pending
Filing Date 2025-05-02
Owner
  • thyssenkrupp AG (Germany)
  • thyssenkrupp Automotive Body Solutions GmbH (Germany)
NICE Classes  ? 07 - Machines and machine tools

Goods & Services

Reinigungsgeräte und Reinigungseinrichtungen für digitale Rollfalzköpfe; Reinigungsstationen für Maschinen in der Fahrzeugkarosseriebearbeitung; Maschinen zur Reinigung und Wartung von Falzmaschinen und Teilen davon; Vorrichtungen zur automatisierten Reinigung von Maschinenteilen; schwenkbare Reinigungsgeräte und Reinigungseinrichtungen für digitale Rollfalzköpfe.

10.

PLA COATING OF FERTILISERS


Application Number 18690674
Status Pending
Filing Date 2022-09-08
First Publication Date 2025-05-01
Owner
  • thyssenkrupp Uhde GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor Makhynya, Yevgeny

Abstract

The present disclosure relates to a particulate fertilizer, where the particulate fertilizer has a coating, where the coating contains polylactic acid compound. The polylactic acid compound has a proportion of 70% to 99% of L-lactic acid monomer units and a proportion of 1% to 30% of D-lactic acid monomer units. This polylactic acid compound comprises at least one first polylactic acid and at least one second polylactic acid. The first polylactic acid has a proportion of 50% to 67% of L-lactic acid monomer units and a proportion of 33% to 50% of D-lactic acid monomer units and the second polylactic acid has a proportion of 95% to 100% of L-lactic acid monomer units and a proportion of 0% to 5% of D-lactic acid monomer units.

IPC Classes  ?

  • C05G 5/30 - Layered or coated, e.g. dust-preventing coatings
  • C05C 9/00 - Fertilisers containing urea or urea compounds
  • C05G 5/12 - Granules or flakes

11.

METHOD AND PLANT FOR PRODUCING AMMONIA WITH AUTOTHERMAL REFORMER


Application Number EP2024080327
Publication Number 2025/088183
Status In Force
Filing Date 2024-10-25
Publication Date 2025-05-01
Owner
  • THYSSENKRUPP UHDE GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Poschlad, Katja
  • Dostal, Daniela
  • Gandhi, Shivam

Abstract

The present invention relates to a method for producing ammonia, comprising the steps of: providing three reactant gases, specifically a hydrocarbon-containing reactant gas, an air-based reactant gas and a vapour-containing reactant gas; heating at least one of the three reactant gases using a fuelled burner device, wherein at least one heated reactant gas is obtained; feeding the at least one heated reactant gas and the remaining of the three reactant gases to an autothermal reformer; autothermally reforming the three reactant gases, wherein a reformed gas mixture is obtained; feeding the reformed gas mixture to an ammonia synthesis circuit with a synthesis circuit gas; reacting the synthesis circuit gas in a converter, wherein ammonia is created in the synthesis circuit gas; and splitting the synthesis circuit gas into a first partial stream and a second partial stream, characterised in that the first partial stream is supplied to the fuelled burner device as hydrogen-containing combustion gas. The invention further relates to a corresponding ammonia synthesis plant and to a method for retrofitting an ammonia synthesis plant.

IPC Classes  ?

  • C01B 3/02 - Production of hydrogen or of gaseous mixtures containing hydrogen
  • C01B 3/38 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents using catalysts
  • C01C 1/04 - Preparation of ammonia by synthesis

12.

METHOD FOR CONTROLLING A STEERING SYSTEM, CONTROL UNIT, STEERING SYSTEM AND MOTOR VEHICLE


Application Number EP2024078999
Publication Number 2025/082955
Status In Force
Filing Date 2024-10-16
Publication Date 2025-04-24
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor Arányi, Miklós

Abstract

The underlying invention relates, in particular, to a method for controlling an electrically assisted steering system (1) of a motor vehicle, wherein the steering system (1) comprises at least two steered wheels (5) and at least one electric motor (7) at least for assisting a steering action of at least one of the steered wheels (5), wherein the electric motor (7) is connected for its energy supply via at least two, in particular three, line phases to an energy source, wherein the method comprises the following steps carried out by a control unit (3): - determining whether there is an existing or imminent occurrence of a generator mode of the electric motor (7), in which the electric motor (7) operates as a generator; and - if an existing or an imminent occurrence of a generator mode is determined, short-circuiting of at least two of the line phases of the electric motor (7).

IPC Classes  ?

  • B62D 5/04 - Power-assisted or power-driven steering electrical, e.g. using an electric servo-motor connected to, or forming part of, the steering gear

13.

METHOD FOR OPERATING AN ADJUSTMENT DRIVE OF A MOTOR-ADJUSTABLE STEERING COLUMN, CONTROL UNIT, STEERING COLUMN AND MOTOR VEHICLE


Application Number 18916362
Status Pending
Filing Date 2024-10-15
First Publication Date 2025-04-24
Owner
  • thyssenkrupp Presta AG (Liechtenstein)
  • thyssenkrupp AG (Germany)
Inventor
  • Riedmann, Patrick
  • Willi, Andreas
  • Vitalis, Daniel
  • Major, Gabor

Abstract

The disclosure relates to a method for operating an adjustment drive of a motor-adjustable steering column for a motor vehicle, said steering column comprising an actuating unit with a rotatably mounted steering spindle, to which a steering wheel is attached, wherein the actuating unit is adjustable by at least one adjustment drive for setting a longitudinal position and/or height position of the steering wheel, wherein in the method: a) a setpoint value of an adjustment speed of the actuating unit is predefined; b) on the basis of the setpoint value, the at least one adjustment drive is driven with a voltage signal by way of at least one controller; c) an actual value of the adjustment speed of the actuating unit is detected after a predetermined time period and is compared with the setpoint value; and d) the setpoint value is reduced depending on the result of the comparison between setpoint value and actual value until the voltage signal for driving the adjustment drive lies below the maximum value of a supply voltage, in particular an onboard electrical system voltage of the motor vehicle.

IPC Classes  ?

  • B62D 1/181 - Steering columns yieldable or adjustable, e.g. tiltable with power actuated adjustment, e.g. with position memory

14.

ELECTROMECHANICAL BRAKING DEVICE FOR A MOTOR VEHICLE


Application Number EP2024078748
Publication Number 2025/082876
Status In Force
Filing Date 2024-10-11
Publication Date 2025-04-24
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Csenki, Levente
  • Kovács, Dénes

Abstract

The present invention relates to an electromechanical braking device (1) for a motor vehicle, said braking device comprising at least one electric brake actuator (4) having a braking component (32) which can be adjusted and brought into braking engagement with a mating braking component (2), wherein the brake actuator (4) can be controlled by an electric control unit (100). In order to allow for improved operational reliability during continuous operation, according to the invention the control unit (100) is designed to be integrated with the brake actuator (4), and a heat dissipation element (45) is thermally coupled to the control unit (100) and is thermally conductingly connected to an exposed outer surface (46) of the brake actuator (4) or has an exposed outer surface (46) of the brake actuator (4).

IPC Classes  ?

  • B60T 13/74 - Transmitting braking action from initiating means to ultimate brake actuator with power assistance or driveBrake systems incorporating such transmitting means, e.g. air-pressure brake systems with electrical assistance or drive
  • F16D 65/00 - Parts or details of brakes
  • F16D 65/18 - Actuating mechanisms for brakesMeans for initiating operation at a predetermined position arranged in or on the brake adapted for drawing members together
  • F16D 65/78 - Features relating to cooling
  • F16D 121/24 - Electric or magnetic using motors
  • F16D 125/40 - Screw-and-nut
  • F16D 125/48 - Rotating members in mutual engagement with parallel stationary axes, e.g. spur gears
  • F16D 123/00 - Multiple operation forces

15.

METHOD FOR MANUFACTURING AN ELECTROMECHANICAL BRAKING DEVICE FOR A MOTOR VEHICLE, AND ELECTROMECHANICAL BRAKING DEVICE FOR A MOTOR VEHICLE


Application Number EP2024078753
Publication Number 2025/082877
Status In Force
Filing Date 2024-10-11
Publication Date 2025-04-24
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Csenki, Levente
  • Kovács, Dénes

Abstract

The present invention relates to a method for manufacturing an electromechanical braking device (1) for a motor vehicle, said braking device comprising at least one electric brake actuator (4) having an electromechanical adjusting device (3) which can adjust a braking component (32) and bring said braking component into braking engagement with a mating braking component (2), wherein the brake actuator (4) can be controlled by an electric control unit (100). In order to allow for efficient manufacture, according to the invention the method comprises the steps: providing a brake housing (45) that comprises the adjusting device (3); fixing the electric control unit (100) to the brake housing (45) and electrically connecting the control unit (100) to the brake actuator (4); attaching a control housing (101) to the brake housing (45) such that the control unit (100) is enclosed between the control housing (101) and the brake housing (45).

IPC Classes  ?

  • B60T 13/74 - Transmitting braking action from initiating means to ultimate brake actuator with power assistance or driveBrake systems incorporating such transmitting means, e.g. air-pressure brake systems with electrical assistance or drive
  • F16D 55/226 - Brakes with substantially-radial braking surfaces pressed together in axial direction, e.g. disc brakes with axially-movable discs or pads pressed against axially-located rotating members by clamping an axially-located rotating disc between movable braking members, e.g. movable brake discs or brake pads with a common actuating member for the braking members the braking members being brake pads in which the common actuating member is moved axially
  • F16D 65/18 - Actuating mechanisms for brakesMeans for initiating operation at a predetermined position arranged in or on the brake adapted for drawing members together

16.

METHOD FOR SYNTHESIZING AMMONIA AND PLANT FOR PRODUCING AMMONIA


Application Number 18694613
Status Pending
Filing Date 2022-09-22
First Publication Date 2025-04-17
Owner
  • thyssenkrupp Uhde GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor Keller, Patrick

Abstract

The disclosure relates to a process for producing ammonia. A hydrocarbon mixture and steam are supplied to a primary reformer. The hydrocarbon mixture and the steam are at least partly converted to carbon monoxide and hydrogen in the primary reformer. The gas mixture from the primary reformer is directed into a secondary reformer. The secondary reformer is supplied with process air, at least comprising oxygen and nitrogen, such that unconverted hydrocarbon is converted to carbon monoxide and hydrogen.

IPC Classes  ?

  • C01B 3/02 - Production of hydrogen or of gaseous mixtures containing hydrogen
  • B01D 53/047 - Pressure swing adsorption
  • C01C 1/04 - Preparation of ammonia by synthesis
  • C25B 1/04 - Hydrogen or oxygen by electrolysis of water
  • C25B 15/08 - Supplying or removing reactants or electrolytesRegeneration of electrolytes

17.

HIGH-TENSILE STEEL EXHIBITING IMPROVED RESISTANCE TO HYDROGEN EMBRITTLEMENT


Application Number EP2024070325
Publication Number 2025/078050
Status In Force
Filing Date 2024-07-17
Publication Date 2025-04-17
Owner THYSSENKRUPP STEEL EUROPE AG (Germany)
Inventor
  • Bienholz, Stefan
  • Marx, Volker
  • Castro Müller, Cássia
  • Köyer, Maria
  • Bartelheimer, Aleksandra

Abstract

The invention relates to a flat steel product to be subjected to hot forming, to a shaped sheet metal blank, to a process for manufacturing the flat steel product, and to a process for manufacturing the shaped sheet metal blank, wherein the flat steel product and the sheet metal blank, in particular in combination with an aluminum-based corrosion-resistant coating, exhibit improved resistance to hydrogen embrittlement.

IPC Classes  ?

  • C21D 1/673 - Quenching devices for die quenching
  • C21D 9/46 - Heat treatment, e.g. annealing, hardening, quenching or tempering, adapted for particular articlesFurnaces therefor for sheet metals
  • C22C 38/02 - Ferrous alloys, e.g. steel alloys containing silicon
  • C22C 38/04 - Ferrous alloys, e.g. steel alloys containing manganese
  • C22C 38/06 - Ferrous alloys, e.g. steel alloys containing aluminium
  • C23C 2/12 - Aluminium or alloys based thereon
  • C21D 1/18 - HardeningQuenching with or without subsequent tempering
  • C21D 1/26 - Methods of annealing
  • C21D 8/02 - Modifying the physical properties by deformation combined with, or followed by, heat treatment during manufacturing of plates or strips
  • C22C 38/12 - Ferrous alloys, e.g. steel alloys containing tungsten, tantalum, molybdenum, vanadium or niobium
  • C22C 38/14 - Ferrous alloys, e.g. steel alloys containing titanium or zirconium
  • C22C 38/26 - Ferrous alloys, e.g. steel alloys containing chromium with niobium or tantalum
  • C22C 38/28 - Ferrous alloys, e.g. steel alloys containing chromium with titanium or zirconium
  • C22C 38/32 - Ferrous alloys, e.g. steel alloys containing chromium with boron

18.

TRACK LINK ASSEMBLY WITH WEAR SENSING DEVICE


Application Number 18729454
Status Pending
Filing Date 2023-01-17
First Publication Date 2025-04-10
Owner
  • Berco S.p.A. (Italy)
  • thyssenkrupp AG (Germany)
Inventor
  • Grenzi, Francesco
  • Maggiolini, Enrico
  • Bruno, Piero

Abstract

A track assembly of a track-type mobile machine comprises a track link body with at least two window openings, a track shoe, and a plurality of bolts with which the track shoe is attached to the track link body, wherein the track shoe is clamped with the track link body along a clamping length of the bolt, the clamping length extending from a bolt head of the bolt to a fastening section of the bolt, wherein the track assembly further comprises a wear sensing device for measuring wear of at least one surface portion of the track link body. In order to provide a track assembly where the wear sensing device is easily removable from the track link body and a mounted wear sensing device can easily be replaced by a new one, it is suggested that the bolt comprises a bolt section adjoining the clamping length, the bolt section extending into a receiving bore arranged in the track link body, the receiving bore extending from the window opening to the surface portion of the track link body where the wear is to be measured, wherein at least the part of the bolt section received in the receiving bore comprises a recess in which the wear sensing device is arranged.

IPC Classes  ?

  • B62D 55/28 - Ground-engaging parts or elements detachable

19.

METHOD FOR ACTIVATING A PARKING BRAKE IN A MOTOR VEHICLE, AND MOTOR VEHICLE WITH AN ELECTROMECHANICAL BRAKE DEVICE


Application Number EP2024077590
Publication Number 2025/073687
Status In Force
Filing Date 2024-10-01
Publication Date 2025-04-10
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Lapis, Leonard
  • Dobcsanyi, Akos
  • Szimandl, Barna
  • Scheidt, Alexander
  • Erdelyi, Zoltan Szabolcs

Abstract

The present invention relates to a method for activating a parking brake in a motor vehicle (10), comprising a plurality of wheels (11, 12) which can be driven by a vehicle drive, and at least one electromechanical brake device (1) which interacts with at least one wheel (11, 12) and can be moved selectively into a service brake position or a parking brake position. In order to enable reliable activation of the parking brake with a relatively small load and adjustment force, the invention proposes the following steps: a. adjusting the brake device (1) into a service brake position in order to generate a service brake torque for holding the vehicle (10) at a standstill, b. detecting a downhill torque exerted on the wheel (11) by a downhill force (H), c. applying a compensation torque, opposed to the downhill torque, by the vehicle drive, and reducing the service brake torque by the magnitude of the compensation torque, d. adjusting the brake device (1) into a parking brake position, e. cancelling the compensation torque.

IPC Classes  ?

  • B60T 13/74 - Transmitting braking action from initiating means to ultimate brake actuator with power assistance or driveBrake systems incorporating such transmitting means, e.g. air-pressure brake systems with electrical assistance or drive
  • F16D 65/18 - Actuating mechanisms for brakesMeans for initiating operation at a predetermined position arranged in or on the brake adapted for drawing members together
  • F16D 55/226 - Brakes with substantially-radial braking surfaces pressed together in axial direction, e.g. disc brakes with axially-movable discs or pads pressed against axially-located rotating members by clamping an axially-located rotating disc between movable braking members, e.g. movable brake discs or brake pads with a common actuating member for the braking members the braking members being brake pads in which the common actuating member is moved axially
  • F16D 125/36 - Helical camsBall-rotating ramps

20.

PART OF A TRACKED VEHICLE, UNDERCARRIAGE ASSEMBLY OF A TRACKED VEHICLE COMPRISING SAID PART, TRACKED VEHICLE COMPRISING SAID PART AND PROCESS FOR PRODUCING SAID PART OF A TRACKED VEHICLE


Application Number EP2024077679
Publication Number 2025/073735
Status In Force
Filing Date 2024-10-02
Publication Date 2025-04-10
Owner
  • BERCO S.P.A. (Italy)
  • THYSSENKRUPP AG (Germany)
Inventor Grenzi, Francesco

Abstract

A part of a tracked vehicle (1), for example of an undercarriage assembly (30A, 30B) of a tracked vehicle according to the present invention is made of a steel having one or more of the following features: -a content of carbon comprised between 0,1-0,7 %wt; -a content of manganese comprised between 0,6-2 % wt; -a content of silicon equal to or lower than 1,3 % wt -a content of chromium equal to or lower than 0,8 % wt -a content of sulfur equal to or lower than 0,1 % wt -a content of phosphorus equal to or lower than 0,05 % wt; -a content of molybdenum equal to or lower than 0,13 % wt -a content of nitrogen equal to or lower than 0,04 % wt -a content of niobium equal to or lower than 0,07 % wt -a content of vanadium equal to or lower than 0,4 % wt.

IPC Classes  ?

  • C22C 38/00 - Ferrous alloys, e.g. steel alloys
  • B62D 55/00 - Endless-track vehicles
  • C22C 38/02 - Ferrous alloys, e.g. steel alloys containing silicon
  • C22C 38/04 - Ferrous alloys, e.g. steel alloys containing manganese
  • C22C 38/12 - Ferrous alloys, e.g. steel alloys containing tungsten, tantalum, molybdenum, vanadium or niobium
  • C22C 38/18 - Ferrous alloys, e.g. steel alloys containing chromium
  • C22C 38/22 - Ferrous alloys, e.g. steel alloys containing chromium with molybdenum or tungsten
  • C22C 38/24 - Ferrous alloys, e.g. steel alloys containing chromium with vanadium
  • C22C 38/26 - Ferrous alloys, e.g. steel alloys containing chromium with niobium or tantalum

21.

SYNTHESIZING GREEN AMMONIA WITH A VARIABLE THROUGHPUT


Application Number EP2024077390
Publication Number 2025/073609
Status In Force
Filing Date 2024-09-27
Publication Date 2025-04-10
Owner
  • THYSSENKRUPP UHDE GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Gorval, Evgeni
  • Keil, Bernd
  • Heun, Reinhard
  • Buß, Stephan

Abstract

32223222 in said synthesis unit(s). The invention additionally relates to a system which is configured for carrying out the method.

IPC Classes  ?

  • B01J 19/24 - Stationary reactors without moving elements inside
  • C01C 1/04 - Preparation of ammonia by synthesis
  • C25B 1/04 - Hydrogen or oxygen by electrolysis of water

22.

DEVICE AND METHOD FOR SYNTHESIZING GREEN AMMONIA


Application Number EP2024077796
Publication Number 2025/073798
Status In Force
Filing Date 2024-10-02
Publication Date 2025-04-10
Owner
  • THYSSENKRUPP UHDE GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Gorval, Evgeni
  • Keil, Bernd
  • Bagga, Karan

Abstract

The invention relates to a method for synthesizing ammonia, having the steps of: - providing hydrogen; - supplying the hydrogen to an ammonia synthesis circulator (10) comprising an ammonia converter (3) in which ammonia is catalytically synthesized; a circulator (1) which supplies a reactant gas mixture, containing the hydrogen and nitrogen, to the ammonia converter (3); and a cooling section (5) in which ammonia is condensed out of a product gas mixture of the ammonia converter (3), wherein the ammonia synthesis circuit (10) is first operated in a full-load operation, in which the ammonia synthesis circuit (10) provides a nominal flow rate of hydrogen, and the ammonia synthesis circuit (10) is converted from the full-load operation to a partial-load operation, in which the ammonia synthesis circuit (10) provides a flow rate of hydrogen which is lower than the nominal flow rate. In the partial-load operation, a first gas flow is branched off from the reactant gas flow and is conducted to the inlet of the circulator (1), and a second gas flow is branched off from the product gas mixture and is conducted to the inlet of the circulator (1).

IPC Classes  ?

  • C01C 1/04 - Preparation of ammonia by synthesis
  • C25B 1/04 - Hydrogen or oxygen by electrolysis of water

23.

TK


Application Number 019167145
Status Pending
Filing Date 2025-04-03
Owner thyssenkrupp AG (Germany)
NICE Classes  ?
  • 06 - Common metals and ores; objects made of metal
  • 07 - Machines and machine tools
  • 09 - Scientific and electric apparatus and instruments
  • 11 - Environmental control apparatus
  • 12 - Land, air and water vehicles; parts of land vehicles
  • 35 - Advertising and business services
  • 42 - Scientific, technological and industrial services, research and design

Goods & Services

Unedle Metalle und deren Legierungen; Materialien aus Metall für das Bau- und Konstruktionswesen; transportable Bauten aus Metall. Maschinen, Werkzeugmaschinen und kraftbetriebene Werkzeuge, ausgenommen für Landfahrzeuge; Kupplungen und Vorrichtungen zur Kraftübertragung, ausgenommen für Landfahrzeuge; Teile von Motoren und Triebwerken, nämlich Anlasser, Schalldämpfer und Zylinder; 3D-Drucker; Industrieroboter. Elektrolyseure; elektrische Kontrollapparate; herunterladbare Computerprogramme ausgenommen Software im Bereich der Augenheilkunde; herunterladbare elektronische Publikationen. Geräte und Anlagen zu Beleuchtungs-, Heizungs-, Kühlungs-, Dampferzeugungs-, Lüftungs- und Wasserversorgung. Fahrzeugteile, nämlich Stoßdämpfer, Nockenwellen, Lenksäulen. Beratungs- und Assistenzdienste im Bereich Werbung, Marketing und Verkaufsförderung; Unternehmensverwaltung; Geschäftsführung; Unternehmensberatung; Unternehmensberatungsdienste; Hilfe in Geschäftsangelegenheiten, Geschäftsführung und administrative Dienstleistungen; Betriebswirtschaftliche Analyse-, Recherche- und Informationsdienstleistungen; Werbung und Verkaufsförderung und diesbezügliche Beratung; Bereitstellen eines Online-Marktplatzes für Käufer und Verkäufer von Waren und Dienstleistungen; Verkaufsförderung für Dritte. Forschung auf dem Gebiet der Chemie, der Technik, des Maschinenbaus; Forschungs- und Entwicklungsdienste bezüglich neuer Produkte für Dritte; Qualitätsprüfung; Software as a Service [SaaS]; Technologieberatung; Umweltschutzforschung; Unterwasserforschung; wissenschaftliche Forschung.

24.

DEVICE FOR UNLOADING AND/OR RECOVERING AN UNMANNED UNDERWATER VEHICLE FROM THE WATER


Application Number EP2024076026
Publication Number 2025/067970
Status In Force
Filing Date 2024-09-18
Publication Date 2025-04-03
Owner
  • ATLAS ELEKTRONIK GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Rühle, Christian
  • Engel, Robert
  • Stelke, Peter

Abstract

The invention relates to a device (20) for unloading and/or recovering an unmanned underwater vehicle from the water (30) onto a platform (24). The device comprises a boom (26), a cable winch (28) which is secured to the boom, and a multistage anti-sway system (32). The boom (26) is designed to project beyond the edge of the platform (24), the cable winch is designed to pull the unmanned underwater vehicle (22) substantially perpendicularly out of the water (30), and the multistage anti-sway system (32) is designed to reduce a swaying movement of the unmanned underwater vehicle (22) when the unmanned underwater vehicle (22) is completely suspended in the air on the cable winch (28). The boom (26) has a receiving area (41) for the unmanned underwater vehicle (22), and one stage of the anti-sway system (32) is designed to fix the unmanned underwater vehicle (22) in the receiving area (41).

IPC Classes  ?

  • B63B 21/66 - Equipment specially adapted for towing underwater objects or vessels, e.g. fairings for tow-cables
  • B63B 27/16 - Arrangement of ship-based loading or unloading equipment for cargo or passengers of lifts or hoists
  • B63G 8/00 - Underwater vessels, e.g. submarines
  • B66C 13/02 - Devices for facilitating retrieval of floating objects, e.g. for recovering craft from water

25.

DEVICE FOR REDUCING SWAYING MOVEMENTS


Application Number EP2024076027
Publication Number 2025/067971
Status In Force
Filing Date 2024-09-18
Publication Date 2025-04-03
Owner
  • ATLAS ELEKTRONIK GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor Michalzik, Dirk

Abstract

The invention relates to a device (20) for reducing swaying movements of a towing means (32) when hauling an unmanned underwater vehicle (34) onto a platform (36) and/or when recovering the unmanned underwater vehicle (34) by means of a crane (38). The device has a boom (22) which is designed to be installed on the platform, and a fork (24) is connected to the boom (22). The device (20) is designed to surround the towing means from at least three sides between a first contact point where the towing means contacts the crane (38) and the unmanned underwater vehicle (34) contacts the fork (24).

IPC Classes  ?

  • B63B 27/16 - Arrangement of ship-based loading or unloading equipment for cargo or passengers of lifts or hoists
  • B63B 27/36 - Arrangement of ship-based loading or unloading equipment for cargo or passengers for floating cargo
  • B66C 13/02 - Devices for facilitating retrieval of floating objects, e.g. for recovering craft from water
  • B63G 8/00 - Underwater vessels, e.g. submarines

26.

METHOD FOR CONTROLLING A STEER-BY-WIRE STEERING SYSTEM, CONTROL UNIT AND MOTOR VEHICLE


Application Number EP2024076066
Publication Number 2025/067980
Status In Force
Filing Date 2024-09-18
Publication Date 2025-04-03
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Arányi, Miklós
  • Szepessy, Imre

Abstract

The invention relates to a method for controlling a steer-by-wire steering system for a motor vehicle (1) in normal operation, wherein the motor vehicle (1) comprises a front axle (10) with front wheels (FL, FR) and a rear axle (20) with rear wheels (RL, RR) and at least two actuators (5, 6, 7, 8) for changing the vehicle trajectory of the motor vehicle (1), which are connected to a control unit (9), comprising the following steps: * determining the desired vehicle trajectory, * determining the respective power reserve of the actuators (5, 6, 7, 8) by comparison of the actually consumed power with the maximum available power of the respective actuator (5, 6, 7, 8), * transferring the respective power reserve to the control unit (9), and * actuating the actuator (5, 6, 7, 8) with the higher power reserve for changing the vehicle trajectory by a control signal of the control unit (9).

IPC Classes  ?

  • B62D 5/04 - Power-assisted or power-driven steering electrical, e.g. using an electric servo-motor connected to, or forming part of, the steering gear
  • B62D 9/00 - Steering deflectable wheels not otherwise provided for
  • B60W 10/20 - Conjoint control of vehicle sub-units of different type or different function including control of steering systems

27.

STEER-BY-WIRE STEERING SYSTEM, MOTOR VEHICLE, AND METHOD FOR DETERMINING AN ABSOLUTE STEERING ANGLE


Application Number 18891627
Status Pending
Filing Date 2024-09-20
First Publication Date 2025-04-03
Owner
  • thyssenkrupp Presta AG (Liechtenstein)
  • thyssenkrupp AG (Germany)
Inventor
  • Arányi, Miklós
  • Szepessy, Imre

Abstract

A steer-by-wire steering system for a motor vehicle comprises a steering wheel angle detection apparatus, a feedback actuator and a wheel actuator. The wheel actuator has a wheel actuator control device which is communicatively connected to a feedback actuator control device and is designed to calculate an absolute steering angle on the basis of sensor values from at least two first rotational angle sensors on a second gearwheel of the steering wheel angle detection apparatus and sensor values from at least two second rotational angle sensors on a motor shaft of the feedback actuator. A motor vehicle can include such a system and a method for determining an absolute steering angle can use such a system.

IPC Classes  ?

  • B62D 6/00 - Arrangements for automatically controlling steering depending on driving conditions sensed and responded to, e.g. control circuits
  • B62D 5/00 - Power-assisted or power-driven steering

28.

ANTENNA ARRANGEMENT FOR AN UNDERWATER VEHICLE


Application Number EP2024075991
Publication Number 2025/067959
Status In Force
Filing Date 2024-09-17
Publication Date 2025-04-03
Owner
  • HAGENUK MARINEKOMMUNIKATION GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Timm, Klaas
  • Albrecht, Jenny

Abstract

An antenna arrangement (20) for an underwater vehicle (46) is disclosed. The antenna arrangement comprises an antenna (22) and a pressure-resistant container (24). The antenna (22) is designed to send and/or receive radio signals at a frequency of more than 1 GHz. The pressure-resistant container (24) is designed to accommodate the radio module (26) for the antenna (22) in a replaceable manner. The antenna (22) and the radio module (26) have an electrical connection to one another. Furthermore, the antenna and the container are designed to be arranged on the underwater vehicle (46) so as to be jointly extensible in a mast.

IPC Classes  ?

  • H01Q 1/34 - Adaptation for use in or on ships, submarines, buoys or torpedoes
  • H01Q 1/12 - SupportsMounting means

29.

TOWING DEVICE, RECOVERY DEVICE, AND SYSTEM FOR RECOVERING A CABLE-BOUND UNMANNED UNDERWATER VEHICLE FROM THE WATER


Application Number EP2024076024
Publication Number 2025/067968
Status In Force
Filing Date 2024-09-18
Publication Date 2025-04-03
Owner
  • ATLAS ELEKTRONIK GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor Rühle, Christian

Abstract

The invention relates to a towing device (28) for recovering a cable-bound unmanned underwater vehicle (22) from the water (24) onto a platform (26) and/or for lowering the underwater vehicle from the platform (26) into the water (24). The towing device (28) comprises a towing means (32) and a holding element (50). The towing means (32) is designed to be connected to the underwater vehicle (22) and is designed to receive a force in order to recover the underwater vehicle from the water (24). The holding element (50) is connected to the towing means (32), wherein the holding element (50) is designed to be gripped by a lifting device (36) in order to recover the underwater vehicle (22) from the water (24). The holding element (50) additionally has an opening (57) which is designed to receive the cable (34) with little tensile stress.

IPC Classes  ?

  • B63B 27/16 - Arrangement of ship-based loading or unloading equipment for cargo or passengers of lifts or hoists
  • B63C 7/02 - Salvaging of disabled, stranded, or sunken vesselsSalvaging of vessel parts or furnishings, e.g. of safesSalvaging of other underwater objects in which the lifting is done by hauling
  • B63G 8/00 - Underwater vessels, e.g. submarines
  • B66C 13/02 - Devices for facilitating retrieval of floating objects, e.g. for recovering craft from water

30.

DEVICE FOR RECEIVING AN UNMANNED UNDERWATER VEHICLE


Application Number EP2024076025
Publication Number 2025/067969
Status In Force
Filing Date 2024-09-18
Publication Date 2025-04-03
Owner
  • ATLAS ELEKTRONIK GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Rühle, Christian
  • Sackmann, Malte
  • Ott, André
  • Hops, Dirk Hinrich

Abstract

The invention relates to a device (20) for receiving an unmanned underwater vehicle (22) below the water surface by means of a platform (31). The device comprises a frame, which is designed to at least partly enclose the unmanned underwater vehicle (22), and a holding mechanism, which is designed to produce a mechanical connection between the frame and the unmanned underwater vehicle (22) in order to fix the unmanned underwater vehicle (22) in the frame (24).

IPC Classes  ?

  • B63B 27/36 - Arrangement of ship-based loading or unloading equipment for cargo or passengers for floating cargo
  • B63B 27/16 - Arrangement of ship-based loading or unloading equipment for cargo or passengers of lifts or hoists
  • B63G 8/00 - Underwater vessels, e.g. submarines

31.

DAMPER VALVE AND VIBRATION DAMPER


Application Number 18891361
Status Pending
Filing Date 2024-09-20
First Publication Date 2025-03-27
Owner
  • thyssenkrupp Bilstein GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor Flick, Martin

Abstract

A damper valve for a vibration damper, in particular of a motorized vehicle, comprises a valve body, at least one control disc arranged on the valve body and at least one rotatably mounted adjustment element, wherein the valve body, the control disc and the adjustment element are arranged coaxially, wherein the control disc is connected to the adjustment element for conjoint rotation and the control disc is rotatable relative to the valve body in order to open up at least one of a plurality of through-channels in the valve body for the flow of a damper fluid or to block the flow, wherein the valve body has a plurality of recesses with different opening areas which are covered by at least one valve disc, wherein in each case one through-channel leads into in each case one of the recesses.

IPC Classes  ?

  • F16F 9/516 - Special means providing automatic damping adjustment resulting in the damping effects during contraction being different from the damping effects during extension
  • B60G 13/08 - Resilient suspensions characterised by arrangement, location, or type of vibration-dampers having dampers dissipating energy, e.g. frictionally of fluid type hydraulic
  • B60G 17/08 - Characteristics of fluid dampers
  • F16F 9/19 - Devices with one or more members, e.g. pistons, vanes, moving to and fro in chambers and using throttling effect involving only straight-line movement of the effective parts with a closed cylinder and a piston separating two or more working spaces therein with a single cylinder
  • F16F 9/348 - Throttling passages in the form of annular discs operating in opposite directions
  • F16F 9/44 - Means on or in the damper for manual or non-automatic adjustmentSprings, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details such means combined with temperature correction

32.

RADIAL PISTON COMPRESSOR


Application Number EP2024075208
Publication Number 2025/061520
Status In Force
Filing Date 2024-09-10
Publication Date 2025-03-27
Owner
  • THYSSENKRUPP DYNAMIC COMPONENTS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor Kunz, Michael

Abstract

The present invention relates to a radial piston compressor comprising a compressor unit (1) and a drive device (2) for driving the compressor unit (1), wherein: the compressor unit (1) comprises a plurality of combinations (13) of piston and working chamber, said combinations being disposed radially around an eccentric shaft (11, 12); the eccentric shaft (11, 12) is driven by the drive device (2); each combination (13) of piston and working chamber comprises a piston (132) having a piston axis (K) and having a center of mass (M); the compressor unit (1) comprises a piston guide ring (14); the pistons (132) are each equipped with a contact face (1321) for the piston guide ring (14); the piston guide ring (14) is in contact with the contact face (1321); the contact face (1321a) of the pistons (132) is oriented at an inclination toward the piston axis (K).

IPC Classes  ?

  • F04B 1/0408 - Pistons
  • F04B 27/04 - Multi-cylinder pumps specially adapted for elastic fluids and characterised by number or arrangement of cylinders having cylinders in star- or fan-arrangement

33.

PROCESS AND PLANT FOR PRODUCING HYDROGEN FROM AMMONIA


Application Number 18832815
Status Pending
Filing Date 2023-01-27
First Publication Date 2025-03-27
Owner
  • thyssenkrupp Uhde GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Kleyensteiber, Alexander
  • Mielke, Bernd
  • Noelker, Klaus

Abstract

A process for producing hydrogen by cracking of ammonia includes cracking ammonia in the presence of a catalyst to hydrogen and nitrogen, wherein the ammonia is cracked without preceding noncatalytic oxidation in the absence of an oxidant merely by supply of heat in the presence of the catalyst. In one of several alternatively possible process variants, the cracking of the ammonia is conducted in a reactor analogously to a primary reformer, wherein the catalyst is disposed in at least one tube through which ammonia flows. In the combustion chamber of the reactor, a mixture of ammonia and hydrogen is preferably combusted, where the nitrogen formed in the reaction is an inert component that serves as an additional heat carrier. A mixture of hydrogen and ammonia is advantageous since it has a moderate flame temperature, has better combustion properties than pure ammonia and, depending on the mixing ratio, emits less NOx than the two pure substances.

IPC Classes  ?

  • C01B 3/04 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of inorganic compounds, e.g. ammonia

34.

DAMPER VALVE AND VIBRATION DAMPER


Application Number 18891174
Status Pending
Filing Date 2024-09-20
First Publication Date 2025-03-27
Owner
  • thyssenkrupp Bilstein GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor Flick, Martin

Abstract

A damper valve for a vibration damper, in particular of a vehicle, comprises a valve body, at least one control disc arranged on the valve body, and at least one rotatably mounted adjustment element, wherein the valve body, the control disc and the adjustment element are arranged coaxially, and wherein the control disc is connected to the adjustment element for conjoint rotation and the control disc is rotatable relative to the valve body in order to open up or block at least one of a plurality of through-channels in the valve body for the flow of a damper fluid, wherein the control disc has at least two through-openings with different cross sections, in order to change the flow of the damper fluid, in particular the flow cross section, through the through-channels in the valve body.

IPC Classes  ?

  • F16F 9/46 - Means on or in the damper for manual or non-automatic adjustmentSprings, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details such means combined with temperature correction allowing control from a distance
  • B60G 17/08 - Characteristics of fluid dampers

35.

VERTICAL CENTRIFUGAL ROLL MILL


Application Number EP2024075448
Publication Number 2025/061554
Status In Force
Filing Date 2024-09-12
Publication Date 2025-03-27
Owner
  • THYSSENKRUPP POLYSIUS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Marton, Mario
  • Strotmann, Jan

Abstract

The present invention relates to a method for operating a vertical centrifugal roll mill, characterized in that activated clays are fed via the pneumatic classifier material inlet (80), while a material selected from the list encompassing clinker, gypsum, limestone and used hardened cement stone is fed via the primary material inlet (90).

IPC Classes  ?

  • B02C 15/00 - Disintegrating by milling members in the form of rollers or balls co-operating with rings or discs
  • B02C 23/02 - Feeding devices

36.

SIMULATION SYSTEM FOR TRAINING CREW MEMBERS OF A MILITARY WATERCRAFT


Document Number 03258724
Status Pending
Filing Date 2023-06-26
Open to Public Date 2025-03-26
Owner
  • THYSSENKRUPP AG (Germany)
  • THYSSENKRUPP MARINE SYSTEMS GMBH (Germany)
Inventor
  • Brass, Stephan
  • Schlenger, Johannes
  • Matthiesen, Jan

Abstract

The invention relates to a simulation system for simultaneously training a plurality of crew members of a military watercraft. The simulation system comprises a first simulation environment with a physical control room of the watercraft for training a first group of crew members. The first simulation environment comprises one or more first physical control elements of the watercraft for setting one or more control parameters for operating the watercraft. The simulation system further comprises a second simulation environment, spatially separate from the first simulation environment, for training a second group of crew members. The second simulation environment comprises technical means configured to provide a visual simulation that comprises one or more at least partially virtual copies of one or more second physical control elements of the watercraft for setting the control parameters.

IPC Classes  ?

  • G09B 9/00 - Simulators for teaching or training purposes
  • G09B 9/06 - Simulators for teaching or training purposes for teaching control of vehicles or other craft for teaching control of ships, boats, or other waterborne vehicles
  • G09B 9/14 - Motion systems for aircraft simulators controlled by fluid actuated piston or cylinder ram

37.

ROLLER HEMMING DEVICE, ROLLER HEMMING METHOD AND METHOD FOR SETTING A HEMMING PROCESS


Application Number 18884568
Status Pending
Filing Date 2024-09-13
First Publication Date 2025-03-20
Owner
  • thyssenkrupp Automotive Body Solutions GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Becker, Denis
  • Sehr, Benjamin
  • Mathieu, Alexander

Abstract

A method for setting a roller hemming process for hemming a plurality of identical component arrangements comprises guiding a hemming roller arranged on a robot by the robot in accordance with a predetermined hemming path for forming a hemming flange of a component of a component arrangement, wherein a hemming process force acting on the hemming roller by the robot during forming is detected, wherein the hemming process force can be changed by a corresponding control of the robot, and a target hemming quality to be achieved is predetermined. The robot is controlled to achieve the target hemming quality, taking into account the detected hemming process force and an actual geometry of a formed hemming flange resulting from the forming process.

IPC Classes  ?

  • B21D 19/04 - Flanging or other edge treatment, e.g. of tubes by continuously-acting tools moving along the edge shaped as rollers
  • B21D 39/02 - Application of procedures in order to connect objects or parts, e.g. coating with sheet metal otherwise than by platingTube expanders of sheet metal by folding, e.g. connecting edges of a sheet to form a cylinder
  • B21D 43/00 - Feeding, positioning or storing devices combined with, or arranged in, or specially adapted for use in connection with, apparatus for working or processing sheet metal, metal tubes or metal profilesAssociations therewith of cutting devices
  • B25J 11/00 - Manipulators not otherwise provided for

38.

METHOD FOR OPERATING A STEELWORKS


Application Number 18290988
Status Pending
Filing Date 2022-08-03
First Publication Date 2025-03-20
Owner ThyssenKrupp Steel Europe AG (Germany)
Inventor
  • Schubert, Daniel
  • Ahrenhold, Frank
  • Jäger, Nils
  • Weinberg, Matthias
  • Becker, Roswitha
  • Suer, Julian

Abstract

The invention relates to a method for operating a steelworks, for example in a blast furnace converter route, or with a direct reduction of iron ore with hydrogen with downstream electrical steel route, preferably additionally a secondary steel route. To carry out the method, the following are balanced: A) a number of starting material flows of supplied starting materials, B) a number of by-product material flows from emitted by-products, and C) a number of energy flows of used energy.

IPC Classes  ?

  • C21B 13/00 - Making spongy iron or liquid steel, by direct processes
  • C21C 5/28 - Manufacture of steel in the converter

39.

AMMONIA SYNTHESIS PLANT FOR PARTIAL-LOAD OPERATION WHICH CHANGES, AND METHOD FOR OPERATING AN AMMONIA SYNTHESIS PLANT


Application Number EP2024075336
Publication Number 2025/056589
Status In Force
Filing Date 2024-09-11
Publication Date 2025-03-20
Owner
  • THYSSENKRUPP UHDE GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Gorval, Evgeni
  • Keil, Bernd

Abstract

The present invention relates to an ammonia synthesis plant having a hydrogen device and a synthesis circuit, wherein the synthesis circuit has a conveying device, a converter and a first bypass line. The hydrogen device is designed to provide hydrogen. The conveying device is designed to cyclically convey a gas mixture, containing nitrogen, hydrogen and ammonia, in a synthesis circuit conveying direction, wherein the conveying device has a suction side and a pressure side. The converter is designed to catalytically convert nitrogen and hydrogen at least partially into ammonia, wherein the converter has an inlet and an outlet, wherein the inlet of the converter is fluidically connected to the pressure side of the conveying device and the outlet of the converter is fluidically connected to the suction side of the conveying device. The first bypass line is arranged from the suction side of the conveying device to the pressure side of the suction device parallel to the conveying device in the fluidically opposite direction and is designed for the stoppable return of a first partial stream of the gas mixture from the pressure side of the conveying device to the suction side of the conveying device, wherein the first bypass line has a cooling device which is designed to cool the first partial stream of the gas mixture. The first bypass line has a second bypass line, which is arranged parallel to the cooling device in the fluidically same direction, and which is designed for the stoppable guiding through of a second partial stream of the first partial stream in order to bypass the cooling device.

IPC Classes  ?

  • C01C 1/04 - Preparation of ammonia by synthesis
  • C25B 1/04 - Hydrogen or oxygen by electrolysis of water

40.

METHOD FOR OPERATING A STEERING COLUMN WHICH CAN BE ADJUSTED USING A MOTOR, STEERING COLUMN, AND MOTOR VEHICLE


Application Number EP2024074427
Publication Number 2025/051666
Status In Force
Filing Date 2024-09-02
Publication Date 2025-03-13
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Riedmann, Patrick
  • Willi, Andreas

Abstract

122222122) by a sensor.

IPC Classes  ?

  • B62D 1/18 - Steering columns yieldable or adjustable, e.g. tiltable

41.

TKMS


Application Number 019152749
Status Pending
Filing Date 2025-03-07
Owner thyssenkrupp AG (Germany)
NICE Classes  ?
  • 09 - Scientific and electric apparatus and instruments
  • 12 - Land, air and water vehicles; parts of land vehicles
  • 13 - Firearms; explosives
  • 37 - Construction and mining; installation and repair services
  • 42 - Scientific, technological and industrial services, research and design

Goods & Services

Scientific, research, navigation, surveying, photographic, cinematographic, audiovisual, optical, weighing, measuring, signalling, detecting, testing, inspecting, life-saving and teaching apparatus and instruments; Apparatus and instruments for recording, transmitting, reproducing or processing sound, images or data; Recorded or downloadable media, computer software, blank digital or analogue media recording and storage media; Computers and computer peripherals; Electrotechnical components; Data loggers and recorders; Software; Computer programmes for data processing; Aerials; Electro acoustic components; Radios; Software for monitoring, analysing, controlling and running physical world operations; Marine depth finders; Echo sounding devices; Acoustic and optical locating, measuring, search and guidance devices; Radar apparatus; Radar apparatus; radio ranging apparatus; signalling devices for electromagnetic waves; Radio transmitters; Radio receiving tuners; Ultrasonic measuring apparatus; Position fixing apparatus; Instrumentation simulators; Interactive computer systems; Measuring, detecting, monitoring and controlling equipment; Data carriers; Sensors; Detectors and monitoring instruments and apparatus; Monitors; target location apparatus; target seekers; Target surveillance apparatus; Display units; Thermal imaging apparatus [other than for medical use]; Apparatus for detection of contaminants and analysis of contaminants in seas and inland waterways; Sonars; Sonars; Sonar installations and parts therefor; Image compilers [software]; Control panels; Minesweeping [detecting] apparatus; Simulators for the steering and control of water vehicles; Underwater positioning devices; navigation system for ships, Control systems for ships; Steering apparatus, automatic, for vehicles; Monitoring devices for iceberg detection; Sounding apparatus; Laser equipment for non-medical purposes. Apparatus for locomotion by water; Vessels [boats and ships], related parts; Underwater vehicles and parts therefor; Submarines, Underwater vehicles, related parts; Unmanned watercraft, Unmanned underwater vehicles, related parts; Torpedo carriers [military vehicles]. Ammunition and projectiles; Explosives; Heavy guns; Torpedoes; Anti submarine torpedoes fitted with warheads; Naval anti-submarine torpedo carrier systems; Mines [explosives]; Explosive devices for minefield clearance. Installation services and Repair, in relation to the following goods: vessels, Underwater vehicles, underwater and Torpedoes; Maintenance and Maintenance, in relation to the following goods: vessels, Underwater vehicles, underwater and Torpedoes; Rebuilding, in relation to the following goods: vessels; Computer hardware and telecommunication equipment installation, maintenance and repair; Repair and maintenance of data processing equipment and apparatus for telecommunications technology. Construction services for building the following goods: water craft and Underwater vehicles; Design and development of software and hardware for signal amplification and transmission; Software development, programming and implementation; Computer hardware development; Hosting, software as a service (SaaS); Testing, authentication and quality control; Conducting of measurements in relation to water vehicles and submarine vehicles; Consultancy in relation to the design of water vehicles and submarine vehicles; Surveying in relation to water vehicles and submarine vehicles; Design, development and Updating, in relation to the following goods: Computer software relating to water vehicles and underwater vehicles; Technological consultancy, Technological planning services, in relation to the following goods: water craft and Underwater vehicles; Engineering in relation to water vehicles and submarine vehicles; Research and development services and consultancy in the field of marine technology; Technical monitoring and inspection in relation to water vehicles and submarine vehicles; design of marine vessels.

42.

neostrip


Application Number 1842841
Status Registered
Filing Date 2024-12-06
Registration Date 2024-12-06
Owner
  • thyssenkrupp Schulte GmbH (Germany)
  • thyssenkrupp AG (Germany)
NICE Classes  ?
  • 06 - Common metals and ores; objects made of metal
  • 40 - Treatment of materials; recycling, air and water treatment,

Goods & Services

Common metals and their alloys, ores; materials of metal for building and construction; non-electric cables and wires of common metal; metal hardware; hinges and continuous bindings of metal; hinges and continuous bindings of the following materials: iron, steel, tungsten, molybdenum, tantalum, magnesium, cobalt, bismuth, cadmium, titanium, zirconium, antimony, beryllium [glucinium], chromium, germanium, vanadium, gallium, celtium [hafnium], indium, niobium [columbium], rhenium and thallium; hinges and continuous bindings of the following materials: non-ferrous metals and non-ferrous metals and their alloys; hinges and continuous bindings of the following materials: copper, brass, aluminium, bronze, gold and silver; hinges and continuous bindings of the following materials: cadmium, cobalt, nickel, lead, tin, zinc, silicon and manganese; rings and continuous rings of the following materials: iron, steel, tungsten, molybdenum, tantalum, magnesium, cobalt, bismuth, cadmium, titanium, zirconium, antimony, beryllium [glucinium], chromium, germanium, vanadium, gallium, celtium [hafnium], indium, niobium [columbium], rhenium and thallium; rings and continuous rings of the following materials: non-ferrous metals and non-ferrous metals and their alloys; rings and continuous rings of the following materials: copper, brass, aluminium, bronze, gold and silver; rings and continuous rings of the following materials: cadmium, cobalt, nickel, lead, tin, zinc, silicon and manganese; semi-finished goods of the following materials: iron, steel, tungsten, molybdenum, tantalum, magnesium, cobalt, bismuth, cadmium, titanium, zirconium, antimony, beryllium [glucinium], chromium, germanium, vanadium, gallium, celtium [hafnium], indium, niobium [columbium], rhenium and thallium; semi-finished goods of the following materials: non-ferrous metals and non-ferrous metals and their alloys; semi-finished goods of the following materials: copper, brass, aluminium, bronze, gold and silver; semi-finished goods of the following materials: cadmium, cobalt, nickel, lead, tin, zinc, silicon and manganese. Surface coating of bindings, continuous bindings, rings, continuous rings and semi-finished articles of metal, non-ferrous metals and non-ferrous metal alloys, of copper, brass, aluminium, bronze, gold and silver, and of cadmium, cobalt, nickel, lead, tin, zinc, silicon and manganese; treatment of bindings, continuous bindings, rings, continuous rings and semi-finished articles of metal, non-ferrous metals and non-ferrous metal alloys, of copper, brass, aluminium, bronze, gold and silver, and of cadmium, cobalt, nickel, lead, tin, zinc, silicon and manganese.

43.

CARBON DIOXIDE SEPARATION DEVICE


Application Number 18722135
Status Pending
Filing Date 2022-12-15
First Publication Date 2025-03-06
Owner
  • Thyssenkrupp Industrial Solutions AG (Germany)
  • thyssenkrupp AG (Germany)
Inventor Menzel, Johannes

Abstract

A carbon dioxide separation apparatus comprises an absorption apparatus and a desorption apparatus, wherein the absorption apparatus comprises a gas inlet for the gas to be purified and a gas outlet for the purified gas, wherein the absorption apparatus comprises an absorption solvent inlet and a solution outlet, wherein the desorption apparatus comprises at least one first solution inlet, an absorption solvent outlet, a hot solvent inlet and a carbon dioxide outlet, wherein the solution outlet is connected to the first solution inlet via a first solution conduit, wherein the first solution conduit comprises a first heat exchanger, wherein the absorption solvent outlet is connected to the absorption solvent inlet via an absorption solvent conduit, wherein the absorption solvent conduit comprises the first heat exchanger so that the heat of the solvent stream is transferred to the solution stream, wherein the absorption solvent conduit comprises a branch to a hot solvent conduit, wherein the hot solvent conduit is connected to the hot solvent inlet, wherein the hot solvent conduit comprises a second heat exchanger, and wherein the pressure of the solvent in the second heat exchanger is 0.2 bar to 5 bar higher than the pressure in the desorption apparatus at the absorption solvent outlet.

IPC Classes  ?

  • B01D 53/14 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by absorption

44.

ROTATION SENSOR FOR A STEERING SYSTEM, AND STEERING SYSTEM FOR A MOTOR VEHICLE


Application Number EP2024067290
Publication Number 2025/045408
Status In Force
Filing Date 2024-06-20
Publication Date 2025-03-06
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Dreher, Simon
  • Hödl, Benedikt
  • Ferencz, Dávid

Abstract

The present invention relates to a rotation sensor (4) for a steering system (1) of a motor vehicle, comprising a magnetic element (41), which can be attached to a steering shaft (10) and can be rotated about an axis (L), and two stator elements (42a,b), which are fixedly coaxially arranged relative to the magnetic element and are axially spaced apart from one another and which are operatively connected to at least one sensor element (6) by means of two flux conductors (5a,b), wherein: each flux conductor (5a,b) comprises a collecting portion (51a,b) connected to a stator element (42a,b), a coupling portion (58a,b) connected to the collecting portion, and a compensator portion (52a,b); the sensor element (6) is disposed between the two coupling portions (58a,b), which lie axially opposite one another. In order to allow an optimized design and to reduce the manufacturing complexity, according to the invention the compensator portions (52a,b) of the two flux conductors (5a,b) are disposed without overlap in the axial direction.

IPC Classes  ?

  • B62D 6/10 - Arrangements for automatically controlling steering depending on driving conditions sensed and responded to, e.g. control circuits responsive only to input torque characterised by the means for sensing torque
  • G01D 5/245 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing characteristics of pulses or pulse trainsMechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means generating pulses or pulse trains using a variable number of pulses in a train

45.

METHOD FOR OPERATING AN AMMONIA FACILITY WHEN A RENEWABLE ENERGY SOURCE FAILURE OCCURS


Application Number EP2024073161
Publication Number 2025/045616
Status In Force
Filing Date 2024-08-19
Publication Date 2025-03-06
Owner
  • THYSSENKRUPP UHDE GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Gorval, Evgeni
  • Keil, Bernd

Abstract

The present invention relates to the operation of an ammonia facility, which uses renewable energy sources for producing in particular green ammonia, in the absence of the renewable energy form.

IPC Classes  ?

  • C01C 1/04 - Preparation of ammonia by synthesis
  • B01J 8/00 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes
  • B01J 19/00 - Chemical, physical or physico-chemical processes in generalTheir relevant apparatus

46.

TWO-STAGE GRINDING OF MATERIAL FOR PRODUCTION OF A BINDER, ESPECIALLY A CEMENT


Application Number EP2024073518
Publication Number 2025/045706
Status In Force
Filing Date 2024-08-22
Publication Date 2025-03-06
Owner
  • THYSSENKRUPP POLYSIUS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Schefer, Dirk
  • Schmitz, Thomas
  • Wilczek, Michael
  • Sachse, Carsten

Abstract

The present invention relates to an apparatus (10) for grinding a mineral material, wherein the apparatus comprises a first grinding apparatus (20) and a second grinding apparatus (30) downstream of the first grinding apparatus (20), wherein the first grinding apparatus (20) is designed to achieve a Blaine fineness of 2500 to 5000 cm2/g, wherein the second grinding apparatus (30) has an energy input of at least 100 kW/m3.

IPC Classes  ?

47.

PREVENTING VARYING PRESSURE LOADING OF A STEAM GENERATOR IN STANDBY MODE


Application Number EP2024073160
Publication Number 2025/045615
Status In Force
Filing Date 2024-08-19
Publication Date 2025-03-06
Owner
  • THYSSENKRUPP UHDE GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Keil, Bernd
  • Gorval, Evgeni

Abstract

The present invention relates to a device having a steam generator (10), wherein the steam generator (10) has a first side (11) and a second side (12), wherein the second side (12) is designed to generate steam, wherein the device has a first bypass line (20), wherein the first bypass line (20) is arranged to bypass the first side (11) of the steam generator (10), wherein the first bypass line (20) has a first bypass valve (22), wherein the second side (12) is connected to a steam discharge line (30), wherein the steam discharge line (30) has a steam shut-off valve (32), wherein the second side (12) has a pressure measuring device (40), wherein the device has a control device (50), wherein the control device (50) is connected to the pressure measuring device (40) and the first bypass valve (22), wherein the control device is designed to control the first bypass valve (22) depending on the pressure recorded by the pressure measuring device (40).

IPC Classes  ?

  • F22B 35/00 - Control systems for steam boilers
  • F01K 13/02 - Controlling, e.g. stopping or starting

48.

COMPONENT GRINDING OF CEMENT COMPONENTS


Application Number EP2024073517
Publication Number 2025/045705
Status In Force
Filing Date 2024-08-22
Publication Date 2025-03-06
Owner
  • THYSSENKRUPP POLYSIUS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor Marton, Mario

Abstract

The present invention relates to a process for producing cement on the basis of at least two components, characterized in that at least two of the components are ground separately.

IPC Classes  ?

49.

STEERING COLUMN FOR A MOTOR VEHICLE AND ENERGY ABSORPTION ELEMENT FOR A STEERING COLUMN


Application Number EP2024073765
Publication Number 2025/045790
Status In Force
Filing Date 2024-08-23
Publication Date 2025-03-06
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Lampert, Remo
  • Raich, Thomas
  • Domig, Markus
  • Heeb, Tobias

Abstract

The present invention relates to a steering column (1) for a motor vehicle, the steering column comprising a second component (33) which can be moved relative to a first component (31) in a longitudinal direction, wherein: an energy absorption element is mounted between the first component (31) and the second component (33), the energy absorption element comprising at least one U-shaped bending strip (6) having a first leg (61) which extends in the longitudinal direction in a first plane (B), the first leg being fastened to the first component (31) and being connected by a bend (62) to a second leg (63) which extends in the longitudinal direction in a second plane spaced from the first plane, the second leg being fastened to the second component (33); a break-loose device is provided which is designed such that, when a predefined crash force is exceeded, the break-loose device breaks loose and allows a relative movement of the first component (31) relative to the second component (33) in the longitudinal direction. In order to allow improved response behavior in the breaking loose, according to the invention the break-loose device has a connection between the second leg (63) and the first component (31), said connection being releasable in the longitudinal direction.

IPC Classes  ?

  • B62D 1/18 - Steering columns yieldable or adjustable, e.g. tiltable
  • B62D 1/19 - Steering columns yieldable or adjustable, e.g. tiltable incorporating energy-absorbing arrangements, e.g. by being yieldable or collapsible

50.

SYSTEM FOR PRODUCING THERMALLY ACTIVATED MATERIALS


Application Number EP2024072872
Publication Number 2025/040528
Status In Force
Filing Date 2024-08-14
Publication Date 2025-02-27
Owner
  • THYSSENKRUPP POLYSIUS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Lemke, Jost
  • Uhde, Martin

Abstract

The present invention relates to a system (10) for producing thermally activated materials, wherein: the system (10) has a thermal activation device (20); the thermal activation device (20) has a material cooler (24); the thermal activation device (20) has a feed for oxygen-enriched gas (30); the system (10) has an air separation system (40); the air separation system (40) has an oxygen outlet (41) for oxygen-enriched gas and a nitrogen outlet (42) for nitrogen-enriched gas; the oxygen outlet (41) is connected to the feed for oxygen-enriched gas (30); the system (10) has a combustible material processing device (50, 55, 56); the combustible material processing device (50, 55, 56) has a protective gas inlet (52), characterised in that the nitrogen outlet (42) and the protective gas inlet (52) are connected together directly or via a gas heating device, wherein the material cooler (24) is connected at least partially as the gas heating device.

IPC Classes  ?

  • F23L 7/00 - Supplying non-combustible liquids or gases, other than air, to the fire, e.g. oxygen, steam
  • F23G 5/033 - Methods or apparatus, e.g. incinerators, specially adapted for combustion of waste or low-grade fuels including pretreatment comminuting or crushing
  • F23K 1/00 - Preparation of lump or pulverulent fuel in readiness for delivery to combustion apparatus

51.

ASWCore


Application Number 1840878
Status Registered
Filing Date 2024-10-10
Registration Date 2024-10-10
Owner
  • ATLAS ELEKTRONIK GmbH (Germany)
  • thyssenkrupp AG (Germany)
NICE Classes  ? 09 - Scientific and electric apparatus and instruments

Goods & Services

Surveillance and control equipment systems for vessels with sonar; software for vessels with sonar; sonar; navigation systems; electronic apparatus and instruments for military use, included in this class; active sonar; passive sonar; underwater detection apparatus; systems consisting of apparatus and instruments for simulation and training; subsystems for the aforementioned goods, included in this class.

52.

DAMPING VALVE DEVICE FOR A SHOCK ABSORBER OF A MOTOR VEHICLE


Application Number EP2024073159
Publication Number 2025/040606
Status In Force
Filing Date 2024-08-17
Publication Date 2025-02-27
Owner
  • THYSSENKRUPP BILSTEIN GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Smeljanskij, Dmitrij
  • Maslowski, Benjamin
  • Schmidt, Christoph

Abstract

The invention comprises a damping valve device (54a, b, c) for a vibration damper (10) of a motor vehicle, having a coil (52), an axially movable armature (62) which is at least partially located within the coil (52), a main valve (68) with a main piston (76; 120), which fluidically separates a main control compartment (82; 118) and a pilot control compartment (84; 122) from each other, a pilot valve (70) with a pilot working compartment (100, 132) and a sliding plunger (102; 126), which is located in the pilot working compartment (100; 132) and is axially movable by means of the armature (62), and a connecting channel (98; 130) which is arranged between the pilot control compartment (84; 122) and the pilot working compartment (100; 132) and fluidically connects them to each other, and wherein the main valve (68) has a main valve seat (90), wherein a spring assembly (77) is attached to the main piston (76, 120) and lies against the main valve seat (90) in the closed position of the main valve (68).

IPC Classes  ?

  • F16F 9/46 - Means on or in the damper for manual or non-automatic adjustmentSprings, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details such means combined with temperature correction allowing control from a distance

53.

METHOD FOR RECOVERING PROCESS CONDENSATE


Application Number 18386547
Status Pending
Filing Date 2023-11-02
First Publication Date 2025-02-20
Owner
  • thyssenkrupp Uhde GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor Von Trotha, Thilo

Abstract

A method and a system for producing synthesis gas, wherein process condensate is used to produce steam. To this end, steam is used to strip volatile impurities, in particular carbon dioxide, from the process condensate and then preferably convert the impurities together with flue gas and discharge them. Then a pH of at least 7.0 is preferably set by adding additives, the process condensate being evaporated and recycled as output steam for producing synthesis gas. In this way, it is possible to suppress the corrosive effect of the process condensate such that no, or less, corrosion-resistant stainless-steel must be used in the manufacture of the system components that come into contact with the process condensate. The steam used to strip the volatile impurities is preferably generated by heat from the synthesis gas and/or flue gas.

IPC Classes  ?

  • C01B 3/38 - Production of hydrogen or of gaseous mixtures containing hydrogen by reaction of gaseous or liquid organic compounds with gasifying agents, e.g. water, carbon dioxide, air by reaction of hydrocarbons with gasifying agents using catalysts
  • B01D 19/00 - Degasification of liquids
  • B01J 12/00 - Chemical processes in general for reacting gaseous media with gaseous mediaApparatus specially adapted therefor
  • B01J 19/00 - Chemical, physical or physico-chemical processes in generalTheir relevant apparatus
  • B01J 19/24 - Stationary reactors without moving elements inside

54.

ROTATION SENSOR FOR A STEERING SYSTEM OF A MOTOR VEHICLE, AND STEERING SYSTEM FOR A MOTOR VEHICLE


Application Number EP2024059580
Publication Number 2025/036576
Status In Force
Filing Date 2024-04-09
Publication Date 2025-02-20
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor Dreher, Simon

Abstract

The present invention relates to a rotation sensor (4) for a steering system (1) of a motor vehicle, the rotation sensor comprising a magnetic element (56), which can be rotated about a sensor axis (L), and a stator (5), which is fixed relative to the sensor axis (L) and has coaxially arranged stator elements (51, 52) having two axially spaced collecting portions (53, 54) between which a sensor element (6) is arranged, wherein the stator (5) and the sensor element (6) are arranged in a sensor housing (41). In order to allow for simpler assembly and to reduce the construction complexity, the invention proposes that the sensor element (6) is rotatably mounted relative to the stator (5) about a rotation axis (D) which is parallel to and radially spaced apart from the sensor axis (L).

IPC Classes  ?

  • G01D 5/14 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing the magnitude of a current or voltage
  • G01D 5/244 - Mechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means influencing characteristics of pulses or pulse trainsMechanical means for transferring the output of a sensing memberMeans for converting the output of a sensing member to another variable where the form or nature of the sensing member does not constrain the means for convertingTransducers not specially adapted for a specific variable using electric or magnetic means generating pulses or pulse trains

55.

MODULAR UNDERWATER VEHICLE WHICH IS CAPABLE OF COMPLETELY RESURFACING


Application Number EP2024072065
Publication Number 2025/036745
Status In Force
Filing Date 2024-08-02
Publication Date 2025-02-20
Owner
  • THYSSENKRUPP MARINE SYSTEMS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Hempfling, Florian
  • Hardt, Jan-Christoph
  • Röthig, Philipp

Abstract

The invention relates to a modular underwater vehicle (10). The underwater vehicle (10) has at least one bow module (20) and at least one stern module (30), and the underwater vehicle (10) has at least one payload module (40) between the bow module (20) and the stern module (30). The invention is characterized in that the underwater vehicle (10) has at least one port-side module and at least one starboard-side module, wherein the at least one port-side module is arranged next to the first payload module (40), the starboard-side module is arranged next to the first payload module (40), the starboard-side module has at least one buoyancy-generating device (60), and the port-side module has at least one buoyancy-generating device (60).

IPC Classes  ?

  • B63G 8/00 - Underwater vessels, e.g. submarines
  • B63G 8/22 - Adjustment of buoyancy by water ballastingEmptying equipment for ballast tanks

56.

TAILOR-MADE SEMIFINISHED PRODUCT, AND EXTERNAL SIDEWALL REINFORCEMENT


Application Number EP2024072015
Publication Number 2025/036741
Status In Force
Filing Date 2024-08-02
Publication Date 2025-02-20
Owner THYSSENKRUPP STEEL EUROPE AG (Germany)
Inventor
  • Breidenbach, Andreas
  • Stegmeyer, Ralf
  • Quandt, Joachim

Abstract

The invention relates to a tailor-made semifinished product (H) for producing a press hardened external sidewall reinforcement (10, 10') as well as to a press hardened external sidewall reinforcement (10, 10').

IPC Classes  ?

57.

METHOD FOR THE PRODUCTION OF SHEET METAL COMPONENTS AND DEVICE THEREFOR


Application Number 18722052
Status Pending
Filing Date 2022-12-15
First Publication Date 2025-02-20
Owner ThyssenKrupp Steel Europe AG (Germany)
Inventor
  • Kibben, Martin
  • Sieczkarek, Peter
  • Linnepe, Michael
  • Petric, Alexander

Abstract

The disclosure relates to a method and a device for the production of dimensionally accurate sheet metal components.

IPC Classes  ?

  • B21D 22/06 - Stamping using rigid devices or tools having relatively-movable die parts
  • B21D 22/30 - Deep-drawing to finish articles formed by deep-drawing

58.

PBU


Application Number 019145182
Status Pending
Filing Date 2025-02-19
Owner
  • thyssenkrupp AG (Germany)
  • thyssenkrupp rothe erde Germany GmbH (Germany)
NICE Classes  ?
  • 07 - Machines and machine tools
  • 09 - Scientific and electric apparatus and instruments
  • 37 - Construction and mining; installation and repair services
  • 42 - Scientific, technological and industrial services, research and design

Goods & Services

Blattlager für Windenergieanlagen; Pitchlager für Windenergieanlagen; Lagereinheiten für Blattlager von Windenergieanlagen; Extender-Lagereinheiten für die Integration von Wälzlagern; Extender-Lagereinheiten für die Integration von Antriebssystemen; Kugellaufbahnen; Rollenlaufbahnen; kombinierte Kugel- und Rollenlaufbahnen; Elektrische Antriebssysteme für die Steuerung von Blattlagern; Hydraulische Antriebssysteme für die Steuerung von Blattlagern; Elektrisch/hydraulisch kombinierte Antriebssysteme von Blattlagern: Mechanische Baugruppe zur Optimierung der Systemsteifigkeit von Blattlagerungen in Windenergieanlagen, Mechanische Baugruppe zur Reduzierung der Nabenabmessungen, Mechanische Baugruppe zur Vereinfachung der Fertigung und Montage von Naben; Mechanische Baugruppe zur Erhöhung des Blattwurzeldurchmessers; Modulare und standardisierte Blattverstellsysteme und Pitchsysteme für Windkraftanlagen; Zubehörteile und Komponenten für Pitchsysteme, einschließlich Befestigungselemente, Dichtungen, Montagehilfen und Adapterplatten; Lager- und Antriebseinheiten für Rotorblätter. Elektronische Steuerungseinheiten für Antriebe von Blattlagern in Windenergieanlagen; Hydraulische Steuerungseinheiten für Antriebe von Blattlagern in Windenergieanlagen; Sensoriksysteme für die Überwachung und Steuerung von Blattlagern während Inbetriebnahme, Montage und Betrieb; Software für die Integration und Steuerung modularer Pitchsysteme. Installations-, Wartungs- und Reparaturdienstleistungen im Zusammenhang mit Lagereinheiten und für Blattlager und Antriebssystemen von Windenergieanlagen. Ingenieur Dienstleistungen betreffend die Entwicklung, Inbetriebnahme, Montage und Wartung von Lagereinheiten und Antriebssystemen für Windenergieanlagen; Entwicklung und Konstruktion von Lagereinheiten und Antriebssystemen für Windenergieanlagen; Technologische Beratung zur Optimierung der Systemsteifigkeit von Blattlagerbaugruppen; Dienstleistungen im Bereich Prototypentwicklung und Integration von Plug-and-Play-Lösungen für Windenergieanlagen.

59.

forward sensing


Application Number 019145197
Status Pending
Filing Date 2025-02-19
Owner
  • thyssenkrupp AG (Germany)
  • thyssenkrupp Materials Services Digital Innovations GmbH (Germany)
NICE Classes  ?
  • 35 - Advertising and business services
  • 38 - Telecommunications services
  • 42 - Scientific, technological and industrial services, research and design

Goods & Services

Supply chain management services; Supply chain management relating to supply chain solutions and transparency of supply chains. Providing of access to platforms and portals on the internet for providing information and transparency relating to supply chains, linking of orders and contracts and early detection of bottlenecks and disruptions; Providing of access to internet portals and databases, for others, for the providing of information and transparency relating to supply chains, linking of orders and contracts and early detection of bottlenecks and disruptions. Design and development of computer software for supply chain management; Providing online non-downloadable software for use in supply chain management; Design and development of computer software for logistics, supply chain management and e-business portals; software as a service (saas) services featuring software for supply chain management.

60.

CARBON DIOXIDE SEPARATION APPARATUS


Application Number 18722066
Status Pending
Filing Date 2022-12-15
First Publication Date 2025-02-13
Owner
  • thyssenkrupp Industrial Solutions AG (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Menzel, Johannes
  • Von Morstein, Olaf

Abstract

A carbon dioxide separation apparatus comprises an absorption apparatus and a desorption apparatus, wherein the absorption apparatus comprises a gas inlet for the gas to be purified and a gas outlet for the purified gas, wherein the absorption apparatus comprises an absorption solvent inlet and a solution outlet, wherein the desorption apparatus comprises at least one first solution inlet, an absorption solvent outlet, a hot solvent inlet and a carbon dioxide outlet, wherein the solution outlet is connected to the first solution inlet via a first solution conduit, wherein the first solution conduit comprises a first heat exchanger, wherein the absorption solvent outlet is connected to the absorption solvent inlet via an absorption solvent conduit, wherein the absorption solvent conduit comprises the first heat exchanger so that the heat of the solvent stream is transferred to the solution stream, wherein the absorption solvent conduit comprises a branch to a hot solvent conduit, wherein the hot solvent conduit is connected to the hot solvent inlet, wherein the hot solvent conduit comprises a second heat exchanger.

IPC Classes  ?

  • B01D 53/14 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols by absorption
  • B01D 53/18 - Absorbing unitsLiquid distributors therefor
  • B01D 53/34 - Chemical or biological purification of waste gases
  • B01D 53/50 - Sulfur oxides
  • B01D 53/62 - Carbon oxides
  • B01D 53/78 - Liquid phase processes with gas-liquid contact
  • B01D 53/96 - Regeneration, reactivation or recycling of reactants

61.

STEERING DEVICE FOR A MOTOR VEHICLE


Application Number 18799463
Status Pending
Filing Date 2024-08-09
First Publication Date 2025-02-13
Owner
  • thyssenkrupp Presta AG (Liechtenstein)
  • thyssenkrupp AG (Germany)
Inventor
  • Marten, Marco
  • Polmans, Kristof
  • Szepessy, Imre
  • Rohrmoser, Manuel

Abstract

A steering device for a motor vehicle, in particular a “steer-by-wire” steering device, comprises a steering wheel, which is able to act on a steering sensor for measuring the rotation angle position of the steering wheel, an electromechanical actuator, which is able to act on a rack for steering wheels, and an electronic controller, which is adapted to detect the steering wheel angle position and to control the electromechanical actuator, wherein the steering device further comprises a feedback actuator acting on the steering wheel, wherein the controller is adapted to measure natural oscillations of the motor vehicle and to apply them with a corresponding amplitude to the feedback actuator.

IPC Classes  ?

  • B62D 5/04 - Power-assisted or power-driven steering electrical, e.g. using an electric servo-motor connected to, or forming part of, the steering gear
  • B62D 5/22 - Power-assisted or power-driven steering fluid, i.e. using a pressurised fluid for most or all the force required for steering a vehicle specially adapted for particular type of steering gear or particular application for rack-and-pinion type
  • B62D 6/00 - Arrangements for automatically controlling steering depending on driving conditions sensed and responded to, e.g. control circuits
  • B62D 15/02 - Steering position indicators

62.

REACTOR AND METHOD FOR THE PYROLYSIS OF HYDROCARBON-CONTAINING FLUIDS


Application Number EP2024071053
Publication Number 2025/031807
Status In Force
Filing Date 2024-07-24
Publication Date 2025-02-13
Owner
  • THYSSENKRUPP UHDE GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Antweiler, Nicolai
  • Wuwer, Matthias

Abstract

The invention relates to a reactor (1) at least for the pyrolysis of hydrocarbon-containing fluids at least in order to produce at least hydrocarbon-containing fluids. The reactor (1) has at least one reactor casing (2) and a reactor chamber (3) arranged within the reactor casing (2). The reactor (1) has a reactor head (4) and a reactor sump (5), wherein the reactor head (4) and the reactor sump (5) have respective feed openings (6), which can be closed at least temporarily, and discharge openings (7), through which at least fluids or solids, in particular particles, are to be introduced or discharged such that particles are at least temporarily continuously introduced into the reactor chamber (3) through the reactor head (4) in order to produce a fluidized bed (8). In a reactor in which instabilities of the electric heat input can be prevented during a methane pyrolysis for producing hydrogen and pyrolytic carbon, multiple conical components (9) are arranged in the reactor chamber (3), wherein the conical components (9) are designed to be hollow and have an inlet opening (10) and an outlet opening (11), and the inlet opening (10) has a larger diameter than the outlet opening (11).

IPC Classes  ?

  • B01J 4/00 - Feed devicesFeed or outlet control devices
  • B01J 6/00 - CalciningFusing
  • B01J 8/08 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with moving particles
  • B01J 8/12 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with moving particles moved by gravity in a downward flow

63.

METHOD FOR THE PRODUCTION OF SHEET METAL PARTS AND DEVICE THEREFOR


Application Number 18717183
Status Pending
Filing Date 2022-12-08
First Publication Date 2025-02-13
Owner ThyssenKrupp Steel Europe AG (Germany)
Inventor
  • Kibben, Martin
  • Sieczkarek, Peter
  • Linnepe, Michael
  • Petric, Alexander

Abstract

The present disclosure provides a method and a device for producing sheet-metal parts with substantially reduced spring-back.

IPC Classes  ?

  • B21D 22/30 - Deep-drawing to finish articles formed by deep-drawing
  • B21D 22/21 - Deep-drawing without fixing the border of the blank

64.

STEERING COLUMN FOR A MOTOR VEHICLE


Application Number EP2024059779
Publication Number 2025/031618
Status In Force
Filing Date 2024-04-11
Publication Date 2025-02-13
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor Bachmann, Andreas

Abstract

The present invention relates to a steering column (1) for a motor vehicle, comprising a steering shaft (4) which is mounted in a steering column housing (3) to rotate about a longitudinal axis (L) extending in a longitudinal direction, a rotation limiter (5) for limiting the rotation of the steering shaft (4), and a feedback actuator (6) for coupling a feedback moment into the steering shaft (4), comprising an actuator housing (61) and an actuator shaft (62) which can be rotationally driven relative thereto by a motor. In order to permit an optimised design and improved manufacture and assembly, the invention proposes that the feedback actuator (6) and the steering column (1) have a releasable connection.

IPC Classes  ?

  • B62D 5/00 - Power-assisted or power-driven steering

65.

METHOD AND REACTOR ASSEMBLY FOR PYROLYZING HYDROCARBON-CONTAINING FLUIDS, AND REACTOR ASSEMBLY


Application Number EP2024071554
Publication Number 2025/031881
Status In Force
Filing Date 2024-07-30
Publication Date 2025-02-13
Owner
  • THYSSENKRUPP UHDE GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Antweiler, Nicolai
  • Krüger, Matthias

Abstract

The invention relates to a method and a reactor assembly at least for pyrolyzing hydrocarbon-containing fluids at least in order to generate at least hydrogen-containing fluids. The hydrocarbon-containing fluids are supplied to a reactor shaft of a reactor (1) in countercurrent with a fluidized bed of the reactor (1), said fluidized bed consisting of particles, wherein at least the particles of the fluidized bed and the hydrocarbon-containing fluids are heated to a defined temperature ranging from 800-1600 °C, and particles of the fluidized bed are introduced at a reactor head (2) and are discharged at a reactor sump (3). In a method in which instabilities of the electric heat input can be prevented during a methane pyrolysis for producing hydrogen and pyrolytic carbon, the particle size of the particles of the fluidized bed are conditioned after discharging the particles from the reactor sump (3) such that the particles subjected to the conditioning process are at least partly introduced at the reactor head (2), and the particles introduced at the reactor head (2) have a uniform particle size x1, said uniform particle size having a grain size range.

IPC Classes  ?

  • B01J 6/00 - CalciningFusing
  • B01J 8/00 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes
  • B01J 8/12 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with moving particles moved by gravity in a downward flow
  • B01J 19/00 - Chemical, physical or physico-chemical processes in generalTheir relevant apparatus

66.

DEVICE AND METHOD FOR PRODUCING A POLYESTER DEPOLYMERIZATE, AND DEVICE AND METHOD FOR PRODUCING A POLYESTER


Application Number 18709231
Status Pending
Filing Date 2022-11-03
First Publication Date 2025-02-06
Owner
  • Uhde Inventa-Fischer GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Schoennagel, Matthias
  • Hess, Christopher
  • Hittorff, Martin
  • Schubert, Michael
  • Pawelski, Alexander
  • Koch, Heinrich

Abstract

A PET recycling (the reprocessing of polyethylene terephthalate wastes) has already been practised for many decades in a variety of different ways, since PET is available in large quantities. Environmental protection and sustainability in resource utilization, however, call for ever higher recycling rates in the decades to come. If the concept of a circular economy is to be achieved, this rate must ultimately amount, sooner or later, to 100%.

IPC Classes  ?

  • C08J 11/24 - Recovery or working-up of waste materials of polymers by chemically breaking down the molecular chains of polymers or breaking of crosslinks, e.g. devulcanisation by treatment with organic material by treatment with organic oxygen-containing compounds containing hydroxyl groups
  • C08J 11/14 - Recovery or working-up of waste materials of polymers by chemically breaking down the molecular chains of polymers or breaking of crosslinks, e.g. devulcanisation by treatment with steam or water
  • C08J 11/26 - Recovery or working-up of waste materials of polymers by chemically breaking down the molecular chains of polymers or breaking of crosslinks, e.g. devulcanisation by treatment with organic material by treatment with organic oxygen-containing compounds containing carboxylic acid groups, their anhydrides or esters

67.

METHOD AND DEVICE FOR SEPARATING A HYDROCARBON-CONTAINING FEEDSTOCK STREAM BY EXTRACTIVE DISTILLATION


Application Number 18709396
Status Pending
Filing Date 2022-11-02
First Publication Date 2025-02-06
Owner
  • thyssenkrupp Uhde GmbH (Germany)
  • thyssenkrupp Uhde Engineering Services GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Kleiber, Michael
  • Bettinger, Simone
  • Schuch, Frank
  • Gratowski, Martin
  • Gehrke, Helmut

Abstract

The disclosure relates to a process for separating a hydrocarbon-containing feedstock stream by extractive distillation, wherein the feedstock stream is contacted with a water-soluble solvent for aromatics in countercurrent. An aliphatics fraction is distillatively removed as aliphatics product stream from the mixture obtained. The aromatics are stripped from the aromatics-enriched solvent that remains and the aromatics-depleted solvent is recycled in a solvent circuit, with compounds having a lower boiling point compared to the solvent accumulating in the solvent circuit as impurities. At least a substream of the solvent circuit is purified for removal of the impurities, wherein the substream for the purifying is subjected to a thermal separation process, in which the impurities are at least partly discharged in a top product and the purified solvent that remains is recycled into the solvent circuit. An apparatus for carrying out the process is also disclosed.

IPC Classes  ?

68.

METHOD FOR CONTROLLING A STEER-BY-WIRE STEERING SYSTEM, CONTROL DEVICE AND MOTOR VEHICLE


Application Number 18790844
Status Pending
Filing Date 2024-07-31
First Publication Date 2025-02-06
Owner
  • thyssenkrupp Presta AG (Liechtenstein)
  • thyssenkrupp AG (Germany)
Inventor
  • Miano, Carlo Mario
  • Lapis, Leonard
  • Polmans, Kristof

Abstract

A method for controlling a steer-by-wire steering system for a motor vehicle having steerable front and rear wheels in emergency steering operation comprises checking the steering system for the presence of a fault state and performing the emergency steering operation to maintain original driving behaviour if a fault state is detected, including: determining a target lateral acceleration on the basis of a current steering wheel position and a current vehicle speed, determining a yaw moment and, from the yaw moment, a general wheel steering angle for the original driving behaviour, where the general wheel steering angle is equal to a difference between a front wheel steering angle and a rear wheel steering angle, determining a front wheel steering angle correction and a rear wheel steering angle correction, and determining drive torques and/or braking torques for the front wheels and the rear wheels, which are distributed appropriately by the torque vectoring system.

IPC Classes  ?

  • B62D 7/15 - Steering linkageStub axles or their mountings for individually-pivoted wheels, e.g. on king-pins the pivotal axes being situated in more than one plane transverse to the longitudinal centre line of the vehicle, e.g. all-wheel steering characterised by means varying the ratio between the steering angles of the steered wheels
  • B62D 5/04 - Power-assisted or power-driven steering electrical, e.g. using an electric servo-motor connected to, or forming part of, the steering gear
  • B62D 9/00 - Steering deflectable wheels not otherwise provided for

69.

HYDROACOUSTIC SOUND TRANSMITTER ARRAY


Document Number 03247943
Status Pending
Filing Date 2023-05-22
Open to Public Date 2025-02-04
Owner
  • THYSSENKRUPP AG (Germany)
  • ATLAS ELEKTRONIK GMBH (Germany)
Inventor Bochentin, Thorsten

Abstract

The invention discloses a hydroacoustic sound transmission array for transmitting a frequency-modulated waterborne sound signal having a plurality of sound transmission transducers. The plurality of sound transmission transducers comprise a first sound transmission transducer and a second sound transmission transducer. The first sound transmission transducer has a first design frequency and the second sound transmission transducer has a second design frequency, wherein the first design frequency differs from the second design frequency. A distance between the first sound transmission transducer and the second sound transmission transducer is selected such that the distance is between half the wavelength of the first design frequency and half the wavelength of the second design frequency.

IPC Classes  ?

  • B06B 1/02 - Processes or apparatus for generating mechanical vibrations of infrasonic, sonic or ultrasonic frequency making use of electrical energy
  • G01S 7/521 - Constructional features
  • G01S 7/524 - Transmitters
  • G01S 15/10 - Systems for measuring distance only using transmission of interrupted, pulse-modulated waves
  • G01S 15/34 - Systems for measuring distance only using transmission of continuous waves, whether amplitude-, frequency-, or phase-modulated, or unmodulated using transmission of continuous, frequency-modulated waves while heterodyning the received signal, or a signal derived therefrom, with a locally-generated signal related to the contemporaneously transmitted signal

70.

ELECTROMECHANICAL BRAKE DEVICE FOR A MOTOR VEHICLE


Application Number EP2023079670
Publication Number 2025/021309
Status In Force
Filing Date 2023-10-24
Publication Date 2025-01-30
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Csenki, Levente
  • Kovács, Dénes

Abstract

The present invention relates to an electromechanical brake device (1) for a motor vehicle, comprising an actuating device (5) which has at least one electric motor (41, 42) and to which a brake part (32) is operatively connected which can be adjusted along an adjusting direction (V) and can be brought into braking engagement with a corresponding brake part (2), wherein the motor (41, 42) can be activated by an electric control unit (100). In order to make reduced complexity and improved operation possible, the invention proposes that the actuating device (5) and the control unit (100) are of integrated configuration with the brake device (1).

IPC Classes  ?

  • B60T 13/74 - Transmitting braking action from initiating means to ultimate brake actuator with power assistance or driveBrake systems incorporating such transmitting means, e.g. air-pressure brake systems with electrical assistance or drive
  • F16D 65/18 - Actuating mechanisms for brakesMeans for initiating operation at a predetermined position arranged in or on the brake adapted for drawing members together

71.

METHOD AND DEVICE FOR SEPARATING A HYDROCARBON-CONTAINING FEEDSTOCK STREAM BY EXTRACTIVE DISTILLATION


Application Number 18709457
Status Pending
Filing Date 2022-11-02
First Publication Date 2025-01-30
Owner
  • thyssenkrupp Uhde GmbH (Germany)
  • thyssenkrupp Uhde Engineering Services GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Kleiber, Michael
  • Bettinger, Simone
  • Schuch, Frank
  • Gratowski, Martin
  • Gehrke, Helmut

Abstract

The disclosure relates to a process for separating a hydrocarbon-containing feedstock stream by extractive distillation. The feedstock stream is contacted with a water-soluble solvent for aromatics in countercurrent, an aliphatics fraction is distillatively removed as aliphatics product stream from the mixture obtained. The aromatics are stripped from the aromatics-enriched solvent that remains and the aromatics-depleted solvent is recycled in a solvent circuit, with aliphatic compounds and/or compounds with aliphatic moieties accumulating in the solvent circuit as impurities. At least a substream of the solvent circuit is purified for removal of the impurities, wherein for the purifying, a liquid/liquid extraction is carried out between the substream and an extractant for aliphatics and the raffinate of the liquid/liquid extraction is recycled into the solvent circuit. An apparatus for carrying out the process is also disclosed.

IPC Classes  ?

  • C10G 53/04 - Treatment of hydrocarbon oils, in the absence of hydrogen, by two or more refining processes plural serial stages only including at least one extraction step
  • B01D 3/14 - Fractional distillation
  • B01D 3/40 - Extractive distillation
  • B01D 11/04 - Solvent extraction of solutions which are liquid

72.

INCREASING THE PROPORTION OF SUBSTITUTE FUELS IN THE PRODUCTION OF ACTIVATED CLAYS


Application Number EP2024070143
Publication Number 2025/021593
Status In Force
Filing Date 2024-07-16
Publication Date 2025-01-30
Owner
  • THYSSENKRUPP POLYSIUS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Fit, Leo
  • Wagner, Eugen
  • Grund, Guido

Abstract

The present invention relates to a device for heat-treating a mineral material, wherein the device has an activation device (30), wherein the activation device (30) is designed as an entrained flow reactor, wherein the activation device (30) is connected to a separation cyclone (40) to separate the activated mineral material from the gas flow, wherein the device has a material cooler (60), wherein the separation cyclone (40) is connected, via a first material line (51), to the material cooler (60) to transfer activated material, wherein the material cooler (60) is connected, via a gas line (80), to the activation device (30) to supply a gas flow which is preheated in the material cooler (60), wherein the activation device (30) has a combustion device for a substitute fuel, characterised in that the separation cyclone (40) is connected to a second material line (52), wherein the second material line (52) is connected to the activation device (30) or the gas line (80) to transfer activated material into the activation device (30).

IPC Classes  ?

  • F27B 15/00 - Fluidised-bed furnacesOther furnaces using or treating finely-divided materials in dispersion
  • C04B 2/12 - Preheating, burning, calcining or cooling in shaft or vertical furnaces
  • F27B 15/09 - Arrangement of devices for discharging

73.

METHOD FOR CAPTURING THE POSITION OF TWO MOVABLE COMPONENTS OF A STEERING COLUMN FOR A MOTOR VEHICLE, AND STEERING COLUMN FOR A MOTOR VEHICLE


Application Number EP2024061819
Publication Number 2025/016575
Status In Force
Filing Date 2024-04-30
Publication Date 2025-01-23
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Willi, Andreas
  • Kreutz, Daniel
  • Blättler, Simon
  • Waibel, Gerhard
  • Linher, Thomas
  • Vitalis, Daniel

Abstract

The present invention relates to a method for capturing the position of two movable components (21, 22) of a steering column (1) for a motor vehicle, which are able to be moved relative to one another in a movement direction over a plurality of movement ranges (V1, V2, V3), wherein the relative position of the components (21, 22) is captured as a position value by a sensor (72) of f position-capturing device (7). The aim of the invention is to allow improved position capturing with relatively little complexity. To achieve this aim, according to the invention at least two sensors (73, 74) of the position-capturing device (7) capture a position value (P1, P2) for each of the movement regions (V1, V2, V3), each of the movement regions (V1, V2, V3) being assigned a clearly distinguishable combination of the at least two position values (P1, P2) of the at least two sensors (73, 74).

IPC Classes  ?

  • B62D 1/181 - Steering columns yieldable or adjustable, e.g. tiltable with power actuated adjustment, e.g. with position memory
  • B62D 1/183 - Steering columns yieldable or adjustable, e.g. tiltable adjustable between in-use and out-of-use positions, e.g. to improve access
  • B62D 1/189 - Steering columns yieldable or adjustable, e.g. tiltable with tilt adjustmentSteering columns yieldable or adjustable, e.g. tiltable with tilt and axial adjustment the entire steering column being tiltable as a unit

74.

METHOD FOR OPERATING AN AMMONIA PLANT, AND PLANT FOR PRODUCING AMMONIA


Application Number 18715658
Status Pending
Filing Date 2022-12-02
First Publication Date 2025-01-16
Owner
  • thyssenkrupp Uhde GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Mielke, Bernd
  • Noelker, Klaus
  • Meurer, Dirk
  • Birwe, Tobias
  • Keil, Bernd
  • Elischewski, Johannes
  • Tiegs, Markus

Abstract

In a process for operating an ammonia plant, a gas mixture comprising nitrogen, hydrogen and ammonia is conveyed cyclically in a synthesis circuit with a conveying device which comprises at least a first compressor, nitrogen and hydrogen are converted at least partly into ammonia in a converter, the gas mixture is cooled in a cooling device in such a way that ammonia condenses out of the gas mixture, and hydrogen is provided at least partly by electrolysis. In this process, the utilization of fluctuating renewable energies can be integrated into existing plant designs, for the provision of hydrogen; for this reason, a master controller is provided and the master controller keeps at least the pressure in the synthesis circuit approximately constant via at least one control loop, on the basis of the anticipated amount of hydrogen. For this, the apparatus comprises a first bypass line for circumventing the first compressor, and a second bypass line for circumventing the cooling device.

IPC Classes  ?

  • C01C 1/04 - Preparation of ammonia by synthesis
  • B01D 53/00 - Separation of gases or vapoursRecovering vapours of volatile solvents from gasesChemical or biological purification of waste gases, e.g. engine exhaust gases, smoke, fumes, flue gases or aerosols
  • B01J 8/00 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes
  • B01J 8/06 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds in tube reactorsChemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds the solid particles being arranged in tubes
  • C25B 15/08 - Supplying or removing reactants or electrolytesRegeneration of electrolytes

75.

DECOMPOSITION OF AMMONIA ON NICKEL-BASED CATALYSTS


Application Number EP2024069377
Publication Number 2025/012277
Status In Force
Filing Date 2024-07-09
Publication Date 2025-01-16
Owner
  • THYSSENKRUPP UHDE GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor Kleyensteiber, Alexander

Abstract

233332233222. The gas mixture obtained in this manner is discharged from the tubular reactor at a gas temperature in the range from 550 to 750°C.

IPC Classes  ?

  • C01B 3/04 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of inorganic compounds, e.g. ammonia
  • B01J 8/06 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds in tube reactorsChemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds the solid particles being arranged in tubes
  • B01J 19/24 - Stationary reactors without moving elements inside

76.

thyssenkrupp decarbon


Application Number 1833635
Status Registered
Filing Date 2024-07-11
Registration Date 2024-07-11
Owner thyssenkrupp AG (Germany)
NICE Classes  ?
  • 01 - Chemical and biological materials for industrial, scientific and agricultural use
  • 06 - Common metals and ores; objects made of metal
  • 07 - Machines and machine tools
  • 09 - Scientific and electric apparatus and instruments
  • 11 - Environmental control apparatus
  • 37 - Construction and mining; installation and repair services
  • 40 - Treatment of materials; recycling, air and water treatment,
  • 42 - Scientific, technological and industrial services, research and design

Goods & Services

Chemical products for commercial and scientific purposes, namely hydrocarbons, alkanes, isobutyl, olefins, aromatics; chemical catalysts. Rings made of metal [unworked/worked]; seamless rolled rings made of metal [unworked/worked]; metal containers, in particular pressure vessels for polymerization reactions. Machines and parts of machines for the cement, lime, plaster, ceramic, refractory, metallurgy and chemical industry, for mining and the power and energy industries; excavators, bucket wheel excavators, spreading machines, conveying machines and conveying installations, belt conveyors, grinding machines and mills, beating and pressing machines, crushers and crushing installations, shredders (machines), grinding machines and installations composed thereof; dust aspirators, pulverising machines, compacting and vibration machines, drilling machines, separating machines, separators for separating solids from liquids, classifiers for classifying solids, transfer and conveying machines, mining machines; machines for mixing, homogenising, dispensing, sorting, pelletising, crushing, transporting, conveying, packing and loading solid materials, transporters [conveyors] for solids; combined containers and mixers for manufacturing concrete, containers for inclined conveying installations and machines for filling the aforesaid containers; elevating apparatus for handling loads and systems consisting thereof, namely for handling solids for cement works; high-pressure machines and high-pressure devices for the production of molded bodies for the chemical, ceramic, and electrical industries, the plastics industry, and powder metallurgy; filling and packaging machines with dosing function; high-pressure pumps; dosing pumps; piston compressors; fittings for high-pressure machines for the treatment and manufacture of materials; high-pressure valves; high-pressure fittings for machines for the treatment and manufacture of materials; high-pressure connection and transmission components for machines; high-pressure extraction systems; isostatic presses; apparatus and devices for high-pressure extraction, namely filter machines, separators, and centrifuges; high-pressure water jet systems for water jet cutting systems; high-pressure textile dyeing systems; conveyors with unbalance drive, magnetic drive, and crankshaft drive; screens [machines] and screening machines as well as systems composed of such machines; vibrating mixers [machines]; vibrating crushers [machines]; vibrators [machines] for loosening and compacting, for industrial purposes; high-pressure devices and high-pressure equipment for urea plants; gas generators, gasifiers for generating synthesis gas from carbon-containing fuels; anti-friction bearings for machines, ball bearings, wire race bearings for machines; revolving joints, ball bearing slewing rings, roller bearing slewing rings; sprockets being parts of machines; ball race bearings; ring-shaped parts for machines, made of metal; retainers for roller bearings, retainers for ball bearings; all the aforesaid goods including being parts of machines. Controllers (regulators); display devices; recording apparatus, dosimeters; receiving tubes for scientific research in laboratories; high-pressure valve test benches; capacitors; electrolytic cells. Industrial treatment installations for the cement industry, the lime industry, the plaster industry, the ceramic industry, the refractory industry, the metallurgy industry, the chemical industry, the mining industry and the power and energy industry, namely furnaces, calciners, preheaters, coolers, separators for purifying air and gas; polymerization installations using high pressure; hydrogen generators for industrial purposes; high-pressure sterilization systems; fluidized bed dryers; fluidized bed coolers; vibrating plate dryers; vibrating plate coolers; cyclone dryers; degassers being separators for the cleaning and purification of liquids by removing gas from liquids; degassers being separators for the cleaning and purification of liquids using chemical degassing of oxygen; polymerization installations using high-pressure or low-pressure processes; polymerization systems. Installation, assembly, repair, maintenance, and servicing of chemical plants; construction of polymerization plants; installation, assembly, repair, maintenance, and servicing of alkaline water electrolysis systems for hydrogen production; consulting services related to the construction of power plants; construction of power plants; assembly and installation of industrial or machine systems for the electrochemistry, chlor-alkali industry, and green hydrogen industry as well as for the production of chlorine, hydrogen, caustic soda, or potassium hydroxide; cleaning, maintenance, servicing, and repair of industrial or machine systems for the electrochemistry, chlor-alkali industry, and green hydrogen industry as well as for the production of chlorine, hydrogen, caustic soda, or potassium hydroxide; dismantling and restoration of industrial or machine systems for the electrochemistry, chlor-alkali industry, and green hydrogen industry as well as for the production of chlorine, hydrogen, caustic soda, or potassium hydroxide; assembly, installation, maintenance, servicing, repair, dismantling, and refurbishment of electrolysers; consulting services related to all the aforementioned services; installation of electrochemical treatment systems; installation of chemical plants; installation, maintenance and servicing of facilities and systems for the cement, lime, gypsum, refractory, metallurgical, and chemical industries, for mining and the power or energy industries; installation, assembly, repair, maintenance, and servicing of high-pressure devices; installation, assembly, repair, maintenance, and servicing of systems for processing hydrocarbons; installation, assembly, repair, maintenance, and servicing of devices and equipment for removing harmful nitrogen compounds in exhaust gases; installation, maintenance, and repair services related to metal rings, revolving joints, ball bearing slewing rings, roller bearing slewing rings, anti-friction bearings, live rings, wire race bearings, toothed rings, ball race bearings. Electrochemical treatment; chemical treatment of devices and instruments used in electrochemistry, the chlor-alkali industry, and the green hydrogen industry, as well as in the production of chlorine and hydrogen, caustic soda lye, or potassium hydroxide; rental of chemical processing machines and apparatus for use in electrochemistry, the chlor-alkali industry, and the green hydrogen industry, as well as in the production of chlorine, hydrogen, caustic soda lye, or potassium hydroxide; textile dyeing using high-pressure technology; processing of materials on order [for third parties] through water jet cutting; processing natural and chemical substances using high-pressure technology; generation of heating energy through the production of synthesis gas; material processing, namely machining of workpieces for others [machine shop services], cutting of profiles, cutting of slit strips, cutting of sheets, plates, or trapezoids, material hardening, and surface refinement through hot-dip galvanizing, hot-dip aluminizing, electrolytic galvanizing, and/or organic coating; application of coatings on industrial or machine systems as part of repair and maintenance; application of coatings in the form of electrochemically active or other surface-active preparations on machines and systems as part of repair and maintenance. Design services, namely design for others in the field of fuel cells and electrolysers; technical layout design and planning of power plants; technical and scientific consulting in the field of hydrogen utilization; technological consulting regarding the use of hydrogen and oxygen as alternative fuel and energy sources; research, design, development, and technical inspection regarding industrial plants and machines for electrochemistry, the chlor-alkali industry, the green hydrogen industry, and the production of chlorine, hydrogen, caustic soda lye, or potassium hydroxide; construction planning and technical planning of chemical plants; construction planning and technical planning of alkaline water electrolysis systems for hydrogen production; scientific and technological services, namely engineering and industrial design services related to technical consulting and planning for the construction, expansion, or dismantling and operation of chemical plants or parts of chemical plants; research and development in the field of chemistry and technology, particularly concerning chemical production processes and related chemical plants or parts thereof; engineering services related to data processing; engineering, namely engineering services related to process technology; engineering, namely engineering consulting related to the design, planning, installation supervision, utilization, operation, inspection, maintenance, repair, conversion, expansion, and dismantling of chemical plants and other industrial plants; engineering, namely engineering services related to technical approval planning and the preparation of environmental reports; design of construction plans for the cement industry, lime industry, gypsum industry, ceramic industry, refractory industry, metallurgical industry, chemical industry, mining industry, and power or energy industries, namely furnaces, calciners, preheaters, coolers, separators for air and gas purification; conducting of chemical and technical evaluations and analyses; technical consulting; creation of computer programs for the operation of machines and machine parts for the cement, lime, gypsum, ceramic, refractory, metallurgical, and chemical industries, for mining and the power or energy industries; engineering, namely engineering consulting related to the design, planning, installation supervision, utilization, operation, inspection, maintenance, repair, conversion, expansion, and dismantling of systems and machine parts for the cement, lime, gypsum, ceramic, refractory, metallurgical, and chemical industries, for mining and the power or energy industries; scientific and technological services by engineers and industrial designers, namely consulting and planning services for the construction, expansion, or dismantling as well as for the operation of chemical plants or parts of chemical plants; research and development in the field of chemistry and technology, particularly concerning chemical manufacturing processes; engineering services, namely software engineering services for data processing programs for controlling and operating high-pressure and sterilization systems, cooling devices, particularly coolers and heaters; engineering consulting regarding the design, planning, installation supervision, commissioning, operation, inspection, maintenance, repair, conversion, and demolition of high-pressure devices; engineering services related to official approval planning and environmental reports; creation of programs for data processing of information arising from the aforementioned services and engineering work; creation of programs for data processing for the operation of high-pressure devices and systems composed of them; engineering services, namely engineering consulting regarding the design, planning, installation supervision, commissioning, operation, inspection, maintenance, repair, conversion, expansion, and demolition of chemical plants, polymerization plants, and other industrial plants; creation of programs for data processing for the operation of apparatus and equipment for processing hydrocarbons, particularly for the hydrogenation and dehydrogenation of hydrocarbons; development of processes and design of plants for third parties as well as engineering services for others in the field of hydrocarbon processing.

77.

HEIGHT-LEVEL ADJUSTMENT SYSTEM FOR A CHASSIS OF A MOTOR VEHICLE


Application Number 18768813
Status Pending
Filing Date 2024-07-10
First Publication Date 2025-01-16
Owner
  • thyssenkrupp Bilstein GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Priess, Jens
  • Klabbers, Daniel Petrus Johannes

Abstract

A height-level adjustment system for a chassis of a motor vehicle comprises a spring and a spring seat against which the spring lies at one end, the spring seat including a threaded sleeve which is attached coaxially with respect to the spring and has an external thread and a threaded ring, which is attached to the threaded sleeve, with an internal thread which interacts with the external thread of the threaded sleeve, wherein the spring seat has a connecting element which is attached to the threaded sleeve for connecting the spring seat to the body of a motor vehicle.

IPC Classes  ?

78.

A METHOD OF CONFIGURING A PLANT FOR THE PRODUCTION OF GREEN AMMONIA


Application Number 18705433
Status Pending
Filing Date 2022-10-27
First Publication Date 2025-01-16
Owner
  • thyssenkrupp Uhde GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Bagga, Karan
  • Mielke, Bernd

Abstract

The disclosure relates to a process for producing ammonia, wherein a hydrocarbon mixture and steam are supplied to a primary reformer. The hydrocarbon mixture and the steam are at least partly converted to carbon monoxide and hydrogen in the primary reformer. The gas mixture from the primary reformer is directed into a secondary reformer. The secondary reformer is supplied with process air, at least comprising oxygen and nitrogen, such that unconverted hydrocarbon is converted to carbon monoxide and hydrogen. In examples, the firing output of the primary reformer is increased, the oxygen content of the process air is reduced before the process air is directed into the secondary reformer.

IPC Classes  ?

  • C25B 15/023 - Measuring, analysing or testing during electrolytic production
  • H02J 3/38 - Arrangements for parallelly feeding a single network by two or more generators, converters or transformers

79.

SYSTEM HAVING A SAMPLE STORE FOR PREPARING A SAMPLE MATERIAL IN THE CEMENT OR LIME INDUSTRY FOR CALORIMETRIC MEASUREMENT


Application Number 18713107
Status Pending
Filing Date 2022-11-22
First Publication Date 2025-01-16
Owner
  • thyssenkrupp Polysius GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Ruether, Thomas
  • Enders, Michael

Abstract

The present invention relates to a system 24 having a sample store 10 for preparation of a sample material in the cement or lime industry for a calorimetric measurement, having an accommodation body 12 having at least one or a multitude of storage sites 14 each for accommodating a sample vessel containing a sample material, wherein the sample store 10 has a temperature control device for cooling or heating the storage sites 14 of the accommodation body 12.

IPC Classes  ?

  • G01N 25/48 - Investigating or analysing materials by the use of thermal means by investigating the development of heat, i.e. calorimetry, e.g. by measuring specific heat, by measuring thermal conductivity on solution, sorption, or a chemical reaction not involving combustion or catalytic oxidation

80.

STARTING UP A PLANT FOR CATALYTICALLY DECOMPOSING AMMONIA


Application Number EP2024069358
Publication Number 2025/012271
Status In Force
Filing Date 2024-07-09
Publication Date 2025-01-16
Owner
  • THYSSENKRUPP UHDE GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Makhynya, Yevgeny
  • Kleyensteiber, Alexander

Abstract

232233.

IPC Classes  ?

  • C01B 3/04 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of inorganic compounds, e.g. ammonia
  • B01J 8/06 - Chemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds in tube reactorsChemical or physical processes in general, conducted in the presence of fluids and solid particlesApparatus for such processes with stationary particles, e.g. in fixed beds the solid particles being arranged in tubes
  • B01J 19/24 - Stationary reactors without moving elements inside

81.

biobrik


Application Number 019129925
Status Pending
Filing Date 2025-01-10
Owner
  • thyssenkrupp AG (Germany)
  • thyssenkrupp Materials Trading GmbH (Germany)
NICE Classes  ?
  • 04 - Industrial oils and greases; lubricants; fuels
  • 42 - Scientific, technological and industrial services, research and design

Goods & Services

Fuel; Fuels from biomass; Fuels for the manufacture of cast iron. Development and testing of production methods for substitution goods for casting coke.

82.

METHOD FOR PRODUCING A HOT-DIP-COATED STEEL SHEET AND HOT-DIP-COATED STEEL SHEET


Application Number 18710024
Status Pending
Filing Date 2022-11-10
First Publication Date 2025-01-09
Owner ThyssenKrupp Steel Europe AG (Germany)
Inventor
  • Cetinkaya, Burak William
  • Junge, Fabian

Abstract

This disclosure relates to a method of producing a hot-dip-coated steel sheet and to a hot-dip-coated steel sheet.

IPC Classes  ?

  • C23C 2/06 - Zinc or cadmium or alloys based thereon
  • B21B 1/22 - Metal rolling methods or mills for making semi-finished products of solid or profiled cross-sectionSequence of operations in milling trainsLayout of rolling-mill plant, e.g. grouping of standsSuccession of passes or of sectional pass alternations for rolling bands or sheets of indefinite length
  • C23C 2/26 - After-treatment
  • C23C 2/40 - PlatesStrips

83.

COARSE PARTICLE SIZE ESTIMATION FOR A BULK MATERIAL


Application Number EP2024067251
Publication Number 2025/008195
Status In Force
Filing Date 2024-06-20
Publication Date 2025-01-09
Owner
  • THYSSENKRUPP POLYSIUS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Wilczek, Michael
  • Riering, Luca
  • Kühnrich, Moritz

Abstract

The present invention relates to a method for ascertaining the particle size distribution of a bulk material on a conveyor belt, wherein the surface is detected, wherein the detected surface is subjected to an image analysis, wherein the image data are present as a grayscale image or are converted into a grayscale image, wherein the image analysis of the image data uses a first distance transformation and a first segmentation method, for example a first watershed transformation, for determining the particles, wherein the size of the first particles thus recognized is determined, characterized in that the image data are modified to form modified image data by virtue of the first particles recognized in the first step being set to black, wherein the image analysis of the modified image data uses a second distance transformation and a second segmentation method, for example a second watershed transformation, for determining the particles, wherein the size of the second particles thus recognized is determined, wherein the size of the first particles and the size of the second particles are used for determining the particle size distribution.

IPC Classes  ?

  • G06T 7/12 - Edge-based segmentation
  • G06T 7/136 - SegmentationEdge detection involving thresholding
  • G06T 7/62 - Analysis of geometric attributes of area, perimeter, diameter or volume

84.

COMPACT DEGASSING OF PROCESS WATER IN A FUEL-CELL INSTALLATION


Application Number EP2024067989
Publication Number 2025/008244
Status In Force
Filing Date 2024-06-26
Publication Date 2025-01-09
Owner
  • THYSSENKRUPP MARINE SYSTEMS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor Mechsner, Alfred

Abstract

The present invention relates to a fuel-cell waste-water degassing tank (10), wherein the fuel-cell waste-water degassing tank (10) has a housing (20), wherein the fuel-cell waste-water degassing tank (10) has an anode-water area (30) and a cathode-water area (40) located in the housing (20), wherein the fuel-cell waste-water degassing tank (10) has an anode-water inlet (32), located in the anode-water area (30), and a cathode-water inlet (42), located in the cathode-water area (40), wherein the fuel-cell waste-water degassing tank (10) has a water outlet (60), located in the cathode-water area (40), wherein the fuel-cell waste-water degassing tank (10) has an anode-gas outlet (34) in the anode-water area (30), wherein the fuel-cell waste-water degassing tank (10) has a cathode-gas outlet (44) in the cathode-water area (40), wherein between the anode-water area (30) and the cathode-water area (40) there is a water overpass, wherein the water overpass has a water inlet (52) in the anode-water area (30), wherein the water overpass has a transfer point (50), wherein the transfer point (50) is located at the transition of the anode-water area (30) to the cathode-water area (40), wherein the water inlet (52) is located below the transfer point (50).

IPC Classes  ?

  • H01M 8/04119 - Arrangements for control of reactant parameters, e.g. pressure or concentration of gaseous reactants with simultaneous supply or evacuation of electrolyteHumidifying or dehumidifying

85.

GAS PRESSURE REGULATING SYSTEM FOR A MANNED OR UNMANNED UNDERWATER VEHICLE HAVING A FUEL CELL DEVICE


Application Number EP2024067990
Publication Number 2025/008245
Status In Force
Filing Date 2024-06-26
Publication Date 2025-01-09
Owner
  • THYSSENKRUPP MARINE SYSTEMS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Mechsner, Alfred
  • Rohwer, Bennet

Abstract

The present invention relates to a gas pressure regulating system (10) for operating a fuel cell device (11), in particular for pressure regulation of the supplied gas.

IPC Classes  ?

  • H01M 8/04089 - Arrangements for control of reactant parameters, e.g. pressure or concentration of gaseous reactants
  • H01M 8/04303 - Processes for controlling fuel cells or fuel cell systems applied during specific periods applied during shut-down

86.

NON-GRAIN-ORIENTED METAL ELECTRICAL STRIP OR SHEET, METHOD FOR PRODUCING A NON-GRAIN-ORIENTED ELECTRICAL STRIP, AND USE


Application Number EP2024062237
Publication Number 2025/008095
Status In Force
Filing Date 2024-05-03
Publication Date 2025-01-09
Owner THYSSENKRUPP STEEL EUROPE AG (Germany)
Inventor
  • Vidovic, Anton
  • Winkler, Nina Maria
  • Fischer, Olaf
  • Matos Costa, Aleksander
  • Machalitza, Karsten
  • Lübke, Jan

Abstract

The invention relates to a non-grain-oriented metal electrical strip or sheet which is characterized, in addition to its alloy composition, by a thickness of < 0.270 mm and a 0.2% proof stress Rp0.2 > 420 MPa. Another aspect of the invention relates to a method for producing a non-grain-oriented electrical strip and to a use.

IPC Classes  ?

  • C21D 8/12 - Modifying the physical properties by deformation combined with, or followed by, heat treatment during manufacturing of articles with special electromagnetic properties
  • C22C 38/00 - Ferrous alloys, e.g. steel alloys
  • C22C 38/02 - Ferrous alloys, e.g. steel alloys containing silicon
  • C22C 38/04 - Ferrous alloys, e.g. steel alloys containing manganese
  • C22C 38/06 - Ferrous alloys, e.g. steel alloys containing aluminium
  • C22C 38/14 - Ferrous alloys, e.g. steel alloys containing titanium or zirconium
  • H01F 1/16 - Magnets or magnetic bodies characterised by the magnetic materials thereforSelection of materials for their magnetic properties of inorganic materials characterised by their coercivity of soft-magnetic materials metals or alloys in the form of sheets

87.

HOLLOW SHAFT


Application Number EP2024068116
Publication Number 2025/008264
Status In Force
Filing Date 2024-06-27
Publication Date 2025-01-09
Owner THYSSENKRUPP STEEL EUROPE AG (Germany)
Inventor
  • Brüggenbrock, Michael
  • Eiden, Stefan
  • Flöth, Thomas
  • Grosserüschkamp, Thomas
  • Bogatsch, Maik

Abstract

The present invention relates to a formed hollow shaft (1) made of a steel material, comprising a hollow shaft body (2) having a first wall thickness (3) which has at least in parts along its axis (A), wherein the first wall thickness (3) comprises a radially outer boundary zone (3.1), wherein the boundary zone (3.1) of the first wall thickness (3) defines a higher hardness in comparison to the remaining partial wall thickness (3.2).

IPC Classes  ?

  • C21D 7/04 - Modifying the physical properties of iron or steel by deformation by cold working of the surface
  • B21D 13/02 - Corrugating sheet metal, rods or profiles, or bending sheet metal, rods or profiles into wave form by pressing
  • B21J 1/00 - Preparing metal stock
  • B21D 13/08 - Corrugating sheet metal, rods or profiles, or bending sheet metal, rods or profiles into wave form by combined methods
  • B21D 13/10 - Corrugating sheet metal, rods or profiles, or bending sheet metal, rods or profiles into wave form into a peculiar profiling shape
  • B21K 1/06 - Making machine elements axles or shafts
  • B21D 15/02 - Corrugating tubes longitudinally
  • B21D 41/04 - ReducingClosing
  • C21D 7/10 - Modifying the physical properties of iron or steel by deformation by cold working of the whole cross-section, e.g. of concrete reinforcing bars
  • C21D 8/10 - Modifying the physical properties by deformation combined with, or followed by, heat treatment during manufacturing of tubular bodies
  • C21D 9/08 - Heat treatment, e.g. annealing, hardening, quenching or tempering, adapted for particular articlesFurnaces therefor for tubular bodies or pipes
  • C22C 38/00 - Ferrous alloys, e.g. steel alloys
  • C22C 38/02 - Ferrous alloys, e.g. steel alloys containing silicon
  • C22C 38/04 - Ferrous alloys, e.g. steel alloys containing manganese
  • C22C 38/06 - Ferrous alloys, e.g. steel alloys containing aluminium
  • C22C 38/28 - Ferrous alloys, e.g. steel alloys containing chromium with titanium or zirconium
  • C22C 38/32 - Ferrous alloys, e.g. steel alloys containing chromium with boron

88.

SIMPLIFICATION OF THE PROCESS OF CAPTURING CARBON DIOXIDE FROM EXHAUST GASES OF A CEMENT SYSTEM


Application Number EP2024066918
Publication Number 2025/002910
Status In Force
Filing Date 2024-06-18
Publication Date 2025-01-02
Owner
  • THYSSENKRUPP POLYSIUS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Lemke, Jost
  • Kimmig, Constantin

Abstract

The invention relates to a device for thermally treating a mineral material. The device has a heat consumer, in particular a comminuting device (10), and a treatment device (20), wherein the treatment device has a gas outlet, and the heat consumer, in particular the comminuting device (10), has a gas inlet. The invention is characterized in that the device has a gas-gas heat exchanger (30), said gas-gas heat exchanger (30) having a first side with a first inlet and a first outlet and a second side with a second inlet and a second outlet. The gas outlet is connected to the first inlet, and the second outlet is connected to the gas inlet. The gas-gas heat exchanger (30) is a rotary heat exchanger.

IPC Classes  ?

  • F27B 7/20 - Details, accessories or equipment specially adapted for rotary-drum furnaces
  • F27D 17/00 - Arrangements for using waste heatArrangements for using, or disposing of, waste gases
  • C04B 7/43 - Heat treatment, e.g. precalcining, burning, meltingCooling
  • F27B 7/38 - Arrangements of cooling devices
  • C04B 7/36 - Manufacture of hydraulic cements in general

89.

STEERING SYSTEM FOR A MOTOR VEHICLE


Application Number EP2024059216
Publication Number 2025/002609
Status In Force
Filing Date 2024-04-04
Publication Date 2025-01-02
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Korol, Daniel
  • Fejes, Tamás
  • Willi, Andreas
  • Vitalis, Daniel
  • Riedmann, Patrick
  • Blättler, Simon
  • Vargha, Balázs
  • Szego, Gergo

Abstract

The present invention relates to a steering column (1) for a motor vehicle, comprising two components (3, 4) which can be shifted relative to one another and a position detection device (7) which has a sensor unit (71) connected to one component (3), which sensor unit is movable, in a shifting direction, relative to a target unit (72) connected to the other component (4), and is designed to detect the relative position of the target unit (71), wherein the target unit (71) has a target element (73) which extends in a planar manner in parallel with the shifting direction (x) and which has a measurement variable that can be detected by the sensor unit (71) and that varies along the shifting direction. In order to make improved position detection possible, according to the invention the target unit (72) has a plastics layer (75) connected to the target element (73).

IPC Classes  ?

  • B62D 1/181 - Steering columns yieldable or adjustable, e.g. tiltable with power actuated adjustment, e.g. with position memory

90.

COLOR OPTIMIZATION OF ACTIVATED CLAY


Application Number EP2024067134
Publication Number 2025/002950
Status In Force
Filing Date 2024-06-19
Publication Date 2025-01-02
Owner
  • THYSSENKRUPP POLYSIUS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Berger, Claudia
  • Fit, Leo
  • Priesemann, Christina
  • Brinkmann, Christian
  • Beisheim, Theodor

Abstract

The invention relates to a device for activating and optimizing the color of a mineral material, wherein the device has an activation and color optimization device. The invention is characterized in that the device has a tubular reactor (30) behind the color optimization device (20) in the material flow direction, wherein the tubular reactor (30) has a solid material inlet (34), said solid material inlet (34) being connected to the color optimization device (20) in order to transfer the activated and color-optimized material, and the tubular reactor (30) has a gas inlet (36). The tubular reactor (30) has a length (32) of 5 m to 50 m, the tubular reactor (30) is connected to a deflecting device (40) at the tubular reactor end, and the deflecting device (40) has a solid material outlet (42) and a gas outlet (44).

IPC Classes  ?

  • F27B 15/00 - Fluidised-bed furnacesOther furnaces using or treating finely-divided materials in dispersion
  • F27B 15/02 - Details, accessories or equipment specially adapted for furnaces of these types
  • F27B 15/12 - Arrangements of dust collectors
  • F27B 15/16 - Arrangements of cooling devices
  • F27B 15/20 - Arrangements of monitoring devices, of indicators, of alarm devices
  • F27D 15/02 - Cooling
  • F27D 19/00 - Arrangement of controlling devices
  • C04B 7/12 - Natural pozzuolanasNatural pozzuolana cements
  • F27D 9/00 - Cooling of furnaces or of charges therein

91.

DEVICE FOR OBTAINING THE WEB TENSION OF A WEB MATERIAL FOR A CLEANING DEVICE, CLEANING DEVICE, ROBOT WITH A CLEANING DEVICE, PROCESSING STATION WITH A CLEANING DEVICE


Application Number EP2024067832
Publication Number 2025/003145
Status In Force
Filing Date 2024-06-25
Publication Date 2025-01-02
Owner
  • THYSSENKRUPP AUTOMOTIVE BODY SOLUTIONS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Siebenborn, Christoph
  • Schneider, Marc

Abstract

The invention relates to a device (10) for maintaining the web tension of a web material (BM), in particular a cleaning fleece, for a cleaning device (100) with at least one carrier unit (11) and a guide unit (12), which is arranged on the carrier unit (11), wherein the carrier unit (11) comprises at least a first and a second fixed deflection means (13, 14) and the guide unit (12) comprises at least a first and a second movable deflection means (15, 16), which are movable with the guide unit (12) relative to the carrier unit (11) along a longitudinal axis (L), wherein - the second movable deflection means (16) and the first stationary deflection means (13) are arranged at a distance A from one another, and - the first movable deflection means (15) and the second stationary deflection means (14) are arranged at a distance B from one another, and - the guide unit (12) is arranged movably on the carrier unit (11) in such a way that the distances A and B can be varied by the same amount by moving the guide unit (12) along the longitudinal axis (L).

IPC Classes  ?

  • B65H 20/34 - Arrangements for accumulating surplus web by making loops with rollers
  • A47L 11/40 - Parts or details of machines not provided for in groups , or not restricted to one of these groups, e.g. handles, arrangements of switches, skirts, buffers or levers
  • B65G 45/10 - Cleaning devices

92.

PLATFORM AND METHOD FOR MOUNTING IT


Application Number EP2024068054
Publication Number 2025/003294
Status In Force
Filing Date 2024-06-27
Publication Date 2025-01-02
Owner THYSSENKRUPP STEEL EUROPE AG (Germany)
Inventor
  • Qaimi, Dr. Siear
  • Galal, Dr. Galal

Abstract

The invention relates to a platform (10) for temporarily or permanently mounting to an existing tower structure (1) of a wind turbine, comprising: a scaffold (20) for receiving a crane; and jibs (30) for fastening the platform (10) to the tower structure (1).

IPC Classes  ?

  • B66C 23/18 - Cranes comprising essentially a beam, boom or triangular structure acting as a cantilever and mounted for translatory or swinging movements in vertical or horizontal planes or a combination of such movements, e.g. jib cranes, derricks or tower cranes specially adapted for use in particular locations or for particular purposes
  • F03D 13/10 - Assembly of wind motorsArrangements for erecting wind motors

93.

Ammonia synthesis device


Application Number 18692679
Grant Number 12228036
Status In Force
Filing Date 2022-09-15
First Publication Date 2024-12-26
Grant Date 2025-02-18
Owner
  • thyssenkrupp Uhde GmbH (Germany)
  • thyssenkrupp AG (Germany)
Inventor
  • Gorval, Evgeni
  • Mielke, Bernd

Abstract

The present disclosure relates to an ammonia plant, wherein the ammonia plant comprises a converter, a first heat exchanger, and a removal apparatus. The converter and the first heat exchanger are connected to one another via a product gas connection in such a way that the ammonia synthesis product gas is guided out of the converter via the first heat exchanger to the removal apparatus. The removal apparatus and the converter are connected to one another via a reactant gas connection in such a way that the circulation gas is guided from the removal apparatus to the converter. The ammonia plant comprises a hydrogen feed that is connected to the converter via a second heat exchanger. The ammonia plant comprises a first electric heater and a steam turbine. The first electric heater is connected to the converter or to the steam turbine.

IPC Classes  ?

  • F01D 15/10 - Adaptations for driving, or combinations with, electric generators
  • C01C 1/04 - Preparation of ammonia by synthesis
  • F01D 19/00 - Starting of machines or enginesRegulating, controlling, or safety means in connection therewith
  • F01D 25/10 - Heating, e.g. warming-up before starting

94.

CHEMICAL PLANT AND METHOD FOR A HYDRODESULFURIZATION OF A HYDROCARBON- AND SULFUR-CONTAINING FEEDSTOCK STREAM


Application Number EP2024065777
Publication Number 2024/260753
Status In Force
Filing Date 2024-06-07
Publication Date 2024-12-26
Owner
  • THYSSENKRUPP UHDE GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Büker, Karsten
  • Antweiler, Nicolai

Abstract

The invention relates to a chemical plant (1) for a hydrodesulfurization of a hydrocarbon- and sulfur-containing feedstock stream (17), comprising a hydrofiner (18) for generating a desulfurized product stream (20) and a hydrogen sulfide-containing byproduct stream (8) from the feedstock stream (17), thereby adding a hydrogen-containing gas stream (25), a reactor (2) which is connected downstream of the hydrofiner (18) for dissociating hydrogen sulfide contained in the hydrogen sulfide-containing byproduct stream (8) into the constituents of hydrogen and sulfur, thereby generating a dissociated stream (9), and a first separating device (19) which is connected downstream of the reactor (2) for separating sulfur from the dissociated stream (9), thereby generating a sulfur-containing stream (10) and a residual stream (23), wherein the reactor (2) comprises an electrically heated reaction chamber (5) in order to thermally dissociate the hydrogen sulfide, and the chemical plant (1) has a first recirculation line (24), by means of which the residual stream (23) can be at least partly recirculated into the hydrogen-containing gas stream (25). The invention also relates to a method for a hydrodesulfurization of a hydrocarbon- and sulfur-containing feedstock stream (17).

IPC Classes  ?

  • C10G 45/02 - Refining of hydrocarbon oils using hydrogen or hydrogen-generating compounds to eliminate hetero atoms without changing the skeleton of the hydrocarbon involved and without cracking into lower boiling hydrocarbonsHydrofinishing
  • C01B 3/04 - Production of hydrogen or of gaseous mixtures containing hydrogen by decomposition of inorganic compounds, e.g. ammonia
  • C01B 17/04 - Preparation of sulfurPurification from gaseous sulfur compounds including gaseous sulfides
  • C10G 49/00 - Treatment of hydrocarbon oils, in the presence of hydrogen or hydrogen-generating compounds, not provided for in a single one of groups , , , , or

95.

PRESSURIZED-WATER-RESISTANT ELECTROMAGNETIC SOUND TRANSDUCER


Application Number EP2024067074
Publication Number 2024/261046
Status In Force
Filing Date 2024-06-19
Publication Date 2024-12-26
Owner
  • HAGENUK MARINEKOMMUNIKATION GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Helfmeier, Kilian
  • Halbig, Sebastian

Abstract

The invention relates to a pressurized-water-resistant electromagnetic sound transducer (20) having the following features: - a sound-transducer module (22); - a pressurized-water-resistant housing (24) having a receptacle (26) for the sound-transducer module (22); - a pressure plate (28) which covers the sound-transducer module (22) in such a way that a cavity (32) is formed between a vibration element (30) of the sound-transducer module and the pressure plate (28), which cavity enables sound propagation; - wherein the pressure plate (28) has multiple through-openings (34) through which the sound can pass through the pressure plate (28); - a grating (36) which covers the through-openings (34) and has openings (38) having a smaller diameter than the through-openings (34) of the multiple through-openings (34); - a flexible membrane (40) which is spanned across the grating (36) in such a way that, under normal pressure, a gap (42) is formed between the membrane (40) and the grating (36), and under water pressure, the membrane (40) rests on the grating (36); - and a cover (44) which is designed to protect the membrane (40) from rough mechanical action being applied thereto from the outside and to allow the flexible membrane (40) to vibrate in order to emit the sound through holes in the cover (44).

IPC Classes  ?

  • H04R 1/44 - Special adaptations for subaqueous use, e.g. for hydrophone
  • H04R 1/02 - CasingsCabinetsMountings therein

96.

VIBRATION DAMPER


Application Number EP2024067269
Publication Number 2024/261140
Status In Force
Filing Date 2024-06-20
Publication Date 2024-12-26
Owner
  • THYSSENKRUPP BILSTEIN GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Peng Zhu, Peng
  • Schulte, Christof

Abstract

The invention relates to a vibration damper comprising: - an inner tube (10) that is filled or can be filled with a damping medium, - a coaxial outer tube (11) that is fluidically connected to the inner tube (10) by at least one bottom valve (12) and forms an annular gap (13) with the inner tube (10), - a piston unit (14) comprising a piston rod (15) and a piston (16) having a piston valve (17), which forms a first, piston-rod-side working chamber (18) and a second, piston-rod-remote working chamber (19) in the inner tube (10), - a compensation module (20) comprising a compensation chamber (21) for the volume of damping medium displaced by the piston rod (15), a gas chamber (22) that is connected to the compensation chamber (21), and an adjustable damping valve (23) for adjusting the damping effect, and - a bypass device (24) for fluidically connecting the two working chambers (18, 19) via the damping valve (23), wherein the first working chamber (18) is fluidically connectable to the second working chamber (19) by the damping valve (23) in the rebound stage and to the compensation chamber (21) by the damping valve (23) in the compression stage.

IPC Classes  ?

  • F16F 9/46 - Means on or in the damper for manual or non-automatic adjustmentSprings, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium Details such means combined with temperature correction allowing control from a distance
  • F16F 9/18 - Devices with one or more members, e.g. pistons, vanes, moving to and fro in chambers and using throttling effect involving only straight-line movement of the effective parts with a closed cylinder and a piston separating two or more working spaces therein
  • F16F 9/06 - Springs, vibration-dampers, shock-absorbers, or similarly-constructed movement-dampers using a fluid or the equivalent as damping medium using both gas and liquid

97.

Sheet Metal Component and Method for Producing Same


Application Number 18827239
Status Pending
Filing Date 2024-09-06
First Publication Date 2024-12-26
Owner ThyssenKrupp Steel Europe AG (Germany)
Inventor
  • Schulz, Jennifer
  • Köyer, Maria
  • Ruthenberg, Manuela

Abstract

A sheet metal component made of a hot-formed flat steel product including a steel substrate consisting of, in mass. %,, C: 0.1-0.4%, Mn: 0.5-3.0%, Si: 0.05-0.5% Cr: 0.005-1.0%, B: 0.0005-0.01% and optionally one or more of V, Ti, Nb, Al, Ni, Cu, Mo, and W, where the contents of the respective optionally present alloy element are: V: 0.001-0.2%, Ti: 0.001-0.1%, Nb: 0.001-0.1%, Al: 0.01-0.2%, Ni: 0.01-0.4%, Cu: 0.01-0.8% Mo: 0.002-1.0%, W: 0.001-1.0%, and the remainder iron and unavoidable impurities, wherein the unavoidable impurities include less than 0.1% P, less than 0.05% S, and less than 0.01% N, and an Al corrosion protection layer applied to the steel substrate, wherein the component is optionally hardened. An adhesive section having an SDR value of 3-30%, determined according to ISO 25178, is provided on the free outer face of the corrosion protection coating for adhering the sheet metal component to another component.

IPC Classes  ?

  • C21D 9/46 - Heat treatment, e.g. annealing, hardening, quenching or tempering, adapted for particular articlesFurnaces therefor for sheet metals
  • C21D 1/18 - HardeningQuenching with or without subsequent tempering
  • C21D 6/00 - Heat treatment of ferrous alloys
  • C21D 8/02 - Modifying the physical properties by deformation combined with, or followed by, heat treatment during manufacturing of plates or strips
  • C22C 21/02 - Alloys based on aluminium with silicon as the next major constituent
  • C22C 38/00 - Ferrous alloys, e.g. steel alloys
  • C22C 38/02 - Ferrous alloys, e.g. steel alloys containing silicon
  • C22C 38/04 - Ferrous alloys, e.g. steel alloys containing manganese
  • C22C 38/06 - Ferrous alloys, e.g. steel alloys containing aluminium
  • C22C 38/12 - Ferrous alloys, e.g. steel alloys containing tungsten, tantalum, molybdenum, vanadium or niobium
  • C22C 38/14 - Ferrous alloys, e.g. steel alloys containing titanium or zirconium
  • C22C 38/22 - Ferrous alloys, e.g. steel alloys containing chromium with molybdenum or tungsten
  • C22C 38/28 - Ferrous alloys, e.g. steel alloys containing chromium with titanium or zirconium
  • C22C 38/32 - Ferrous alloys, e.g. steel alloys containing chromium with boron
  • C23C 2/12 - Aluminium or alloys based thereon
  • C23C 2/26 - After-treatment
  • C23C 2/28 - Thermal after-treatment, e.g. treatment in oil bath
  • C23C 2/40 - PlatesStrips

98.

COLOR OPTIMIZATION OF ACTIVATED CLAY USING AMMONIA


Application Number EP2024066005
Publication Number 2024/260784
Status In Force
Filing Date 2024-06-11
Publication Date 2024-12-26
Owner
  • THYSSENKRUPP POLYSIUS GMBH (Germany)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Flasspöhler, Melanie
  • Jacome Rincon, Carlos

Abstract

33-containing compound (31).

IPC Classes  ?

  • C04B 7/12 - Natural pozzuolanasNatural pozzuolana cements

99.

TRACK LINK PRODUCTION METHOD


Application Number 18698703
Status Pending
Filing Date 2022-10-04
First Publication Date 2024-12-19
Owner
  • Berco S.p.A. (Italy)
  • thyssenkrupp AG (Germany)
Inventor Grenzi, Francesco

Abstract

The present disclosure refers to a method for manufacturing a track link for a running gear of a tracked vehicle, comprising the following method steps: P1) providing a forging blank of steel, P2) hot forging the forging blank to produce a track link blank and hot trimming of the track link blank to form at least a wheel tread part of the track link blank, P3) quenching the track link blank to a temperature T1, P4) low temperature tempering the track link blank at a temperature of 200±50° C., and P5) finish machining the tempered track link blank to produce the final shape of the track link.

IPC Classes  ?

  • C21D 9/00 - Heat treatment, e.g. annealing, hardening, quenching or tempering, adapted for particular articlesFurnaces therefor
  • C21D 1/18 - HardeningQuenching with or without subsequent tempering
  • C21D 6/00 - Heat treatment of ferrous alloys
  • C21D 8/00 - Modifying the physical properties by deformation combined with, or followed by, heat treatment
  • C22C 38/00 - Ferrous alloys, e.g. steel alloys
  • C22C 38/02 - Ferrous alloys, e.g. steel alloys containing silicon
  • C22C 38/04 - Ferrous alloys, e.g. steel alloys containing manganese
  • C22C 38/42 - Ferrous alloys, e.g. steel alloys containing chromium with nickel with copper
  • C22C 38/44 - Ferrous alloys, e.g. steel alloys containing chromium with nickel with molybdenum or tungsten
  • C22C 38/48 - Ferrous alloys, e.g. steel alloys containing chromium with nickel with niobium or tantalum

100.

STEERING ACTUATOR FOR A STEER-BY-WIRE STEERING SYSTEM OF A MOTOR VEHICLE, AND METHOD FOR OPERATING A STEERING ACTUATOR


Application Number EP2024058935
Publication Number 2024/256052
Status In Force
Filing Date 2024-04-02
Publication Date 2024-12-19
Owner
  • THYSSENKRUPP PRESTA AG (Liechtenstein)
  • THYSSENKRUPP AG (Germany)
Inventor
  • Fejes, Tamás
  • Sneider, Janos
  • Raither, Wolfram
  • Mazza, Lukas

Abstract

The present invention relates to a steering actuator (4) for a steer-by-wire steering system (1) of a motor vehicle, said steering actuator comprising an actuator housing (41) in which an actuator rod (5) is mounted so as to be axially translationally displaceable, which actuator rod has a coaxial spindle thread (51) that engages in a spindle nut (43) that is axially supported in the actuator housing (41) and can be rotationally driven by a motor, wherein a sensor device is provided for detecting the position of the actuator rod (5) in the actuator housing (41). In order to enable a more compact design with reduced outlay, according to the invention the sensor device has a rotary sensor (7) that interacts with the spindle nut (43).

IPC Classes  ?

  • B62D 5/04 - Power-assisted or power-driven steering electrical, e.g. using an electric servo-motor connected to, or forming part of, the steering gear
  • B62D 15/02 - Steering position indicators
  1     2     3     ...     51        Next Page
